Printed in China
WQ55030-1
U
Portable Player Dock
PDX-30 OWNER’S MANUAL
English
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
RISK OF ELECTRIC SHOCK DO
NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
• Explanation of Graphical Symbols
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert you to the presence of
uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert you to the presence of important operating
and maintenance (servicing) instructions in the literature
accompanying the appliance.
IMPORTANT
Please record the serial number of this unit in the space below.
MODEL:
Serial No.:
The serial number is located on the rear of the unit. Retain this Owner’s Manual in a safe place for future reference.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8� Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
9� Do not defeat the safety purpose of the polarized or groundingtype plug. A
polarized plug has two blades with one wider than the other. A grounding
type plug has two blades and a third grounding prong. The wide blade or
the third prong are provided for your safety. If the provided plug does not
fit into your outlet, consult an electrician for replacement of the obsolete
outlet.
1�
2�
3�
4�
5�
6�
7�
10� Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
11� Only use attachments/accessories specified by the manufacturer.
12� Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
13� Unplug this apparatus during lightning storms or when unused for long
periods of time.
14� Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
CAUTION: Read this before operating your unit.
To assure the finest performance, please read this manual carefully. Keep it in a safe place for future reference.
Dock terminal [ ]
1� Install this unit in a well ventilated, cool, dry, clean place - away from direct sunlight, heat sources, vibration, dust, moisture, and/or cold. (Do not use/keep this
unit in a car etc.)
2� Locate this unit away from other electrical appliances, motors, or transformers to avoid humming sounds.
3� Do not expose this unit to sudden temperature changes from cold to hot, and do not locate this unit in an environment with high humidity (i.e. a room with a
humidifier) to prevent condensation inside this unit, which may cause an electrical shock, fire, damage to this unit, and/or personal injury.
4� Avoid installing this unit where foreign objects may fall onto this unit and/or this unit may be exposed to liquid dripping or splashing. On the top of this unit,
do NOT place:
− Other components, as they may cause damage and/or discoloration on the surface of this unit.
− Burning objects (i.e. candles), as they may cause fire, damage to this unit, and/or personal injury.
− Containers with liquid in them, as they may fall and liquid may cause electrical shock to the user and/or damage to this unit.
5� Do not cover this unit with a newspaper, tablecloth, curtain, etc. in order not to obstruct heat radiation. If the temperature inside this unit rises, it may cause
fire, damage to this unit, and/or personal injury.
6� Do not operate this unit upside-down. They may overheat, possibly causing damage.
7� Do not use force on switches, knobs, and/or cords.
8� When disconnecting the power cable from the wall outlet, grasp the AC plug; do not pull the cord.
9� Do not clean this unit with chemical solvents; this might damage the finish. Use a clean, dry cloth.
10� Only the voltage specified on this unit must be used. Using this unit with a higher voltage than specified is dangerous and may cause fire, damage to this unit,
and/or personal injury. Yamaha will not be held responsible for any damage resulting from use of this unit with a voltage other than that specified.
11� Do not attempt to modify or fix this unit. Contact qualified Yamaha service personnel when any service is needed. The cabinet should never be opened for any
reason.
12� When not planning to use this unit for long periods of time (i.e. when going on vacation), disconnect the power cable from the AC wall outlet.
13� Be sure to read the “TROUBLESHOOTING” section regarding common operating errors before concluding that the unit is faulty.
14� Before moving this unit, disconnect the power cable from the wall outlet.
15� Be sure to use the AC adaptor supplied with this unit. Using an AC adaptor other than the one provided may cause fire or damage to this unit.
16� Install this unit near the wall outlet and where the power cable can be reached easily.
17� For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet.
This will prevent damage to the product due to lightning and power-line surges.
18� The batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
Connects the iPhone or iPod series. When the iPhone or iPod is connected, its battery will be charged. When the iPhone or iPod is disconnected, the unit will be in
standby mode. The iPhone or iPod can be connected (or disconnected) anytime.
There is a chance that placing this unit too close to a CRT-based (Braun tube) TV set might impair picture color. Should this happen, move this unit away from
the TV set.
(Volume keys) [ ]
Status indicator (LED) [ ]
Indicates the current status of the unit.
LED status
Even if an iPhone or iPod is not connected to this unit, this unit is not disconnected from the AC power source as long as it is connected to the wall outlet. In
this state, this unit is designed to consume a very small quantity of power.
CAUTION
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.
FCC INFORMATION (for US customers)
The unit is in standby mode. An iPhone or iPod is not connected, or has stopped playing. (However, lights
up for 30 seconds after connecting or stopping playback.)
Flashes green
Connecting, please wait.
Flashes green once
Adjusting the volume level with the volume keys on the unit or operating with the remote control.
Lights up green
The unit turns on. An iPhone or iPod is connected.
Lights up green and flashes red
Flashes red for 2 seconds: An unsupported iPod is connected.
Keeps flashing red: Connection failed. (Connect again.)
Flashes red
The protection circuitry has been activated. (Disconnect the AC adaptor and wait for a while.)
Flashes red once
The volume of this unit is set to maximum or minimum.
DC IN 15 V jack [ ]
Connect the AC adaptor to this jack to supply power. When the AC adaptor is connected, the unit will be in standby mode, consuming a small quantity of
electricity. When an iPhone or iPod is connected to the unit in standby mode, the unit turns on. When the iPhone or iPod is disconnected, the unit returns to
standby mode.
TROUBLESHOOTING
Refer to the table below if the unit does not function properly. If the problem you are experiencing is not listed below, or if the instruction below does not help, turn
off this unit, disconnect the power cable, and contact the nearest authorized Yamaha dealer or service center.
Problem
Cause
Remedy
No sound
The iPhone or iPod is not connected firmly.
Connect the iPhone or iPod firmly.
The iPhone or iPod software version has not been
updated.
Download the latest iTunes software to update the
iPhone or iPod firmware version to the latest.
The power of the unit is off.
Connect the AC adaptor correctly.
The volume is turned down.
Turn up the volume.
The protection circuitry has been activated by
excessive volume.
Turn down the volume.
Compliance with FCC regulations does not guarantee that interference will
not occur in all installations. If this product is found to be the source of
interference, which can be determined by turning the unit “OFF” and “ON”,
please try to eliminate the problem by using one of the following measures:
Relocate either this product or the device that is being affected by the
interference.
Utilize power outlets that are on different branch (circuit breaker or fuse)
circuits or install AC line filter/s.
In the case of radio or TV interference, relocate/reorient the antenna. If the
antenna lead-in is 300 ohm ribbon lead, change the lead-in to coaxial type
cable.
If these corrective measures do not produce satisfactory results, please contact
the local retailer authorized to distribute this type of product. If you can not
locate the appropriate retailer, please contact Yamaha Electronics Corp.,
U.S.A. 6660 Orangethorpe Ave, Buena Park, CA 90620.
The above statements apply ONLY to those products distributed by Yamaha
Corporation of America or its subsidiaries.
The iPhone or iPod being used is not supported by
this unit, or the iPhone or iPod is not connected
firmly.
Use the supported iPhone or iPod.
Connect the iPhone or iPod firmly.
NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
– Reorient or relocate the receiving antenna
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
FCC WARNING
Change or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
PDX-30 is a portable player dock designed for iPhone or iPod series. The unit can be operated by the remote control. Also the iPhone or iPod set into the unit is
automatically charged so you can enjoy playing music as long as you want.
Alphabetical letters below ( , , etc.) can be used for reference to the illustrations on the separate sheet “Quick Manual” for details.
■ Supplied accessories
Remote control [ ].................................................................................................................................................................................................................................. 1
AC adaptor (DC 15 V, 2.66 A, model number: NU40-2150266-I3) [ ]................................................................................................................................................. 1
Power cable [ ]....................................................................................................................................................................................................................................... 1
Owner’s Manual (this manual).................................................................................................................................................................................................................. 1
Quick Manual............................................................................................................................................................................................................................................ 1
■ Copyright and logo marks
The current status of this unit
Off
INTRODUCTION
Yamaha and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your equipment by playing it at
a safe level. One that lets the sound come through loud and clear without annoying blaring or distortion - and, most importantly, without affecting
your sensitive hearing. Since hearing damage from loud sounds is often undetectable until it is too late, Yamaha and the Electronic Industries
Association’s Consumer Electronics Group recommend you to avoid prolonged exposure from excessive volume levels. Operate this unit by the
following procedure.
FOR CANADIAN CUSTOMERS
This Class B digital apparatus complies with Canadian ICES-003.
/
Adjusts the volume level.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
We Want You Listening For A Lifetime
1� IMPORTANT NOTICE : DO NOT MODIFY THIS UNIT!
This product, when installed as indicated in the instructions contained in
this manual, meets FCC requirements.
Modifications not expressly approved by Yamaha may void your authority,
granted by the FCC, to use the product.
2� IMPORTANT : When connecting this product to accessories and/or
another product use only high quality shielded cables. Cable/s supplied
with this product MUST be used. Follow all installation instructions.
Failure to follow instructions could void your FCC authorization to use
this product in the USA.
3� NOTE : This product has been tested and found to comply with the
requirements listed in FCC Regulations, Part 15 for Class “B” digital
devices. Compliance with these requirements provides a reasonable level
of assurance that your use of this product in a residential environment will
not result in harmful interference with other electronic devices.
This equipment generates/uses radio frequencies and, if not installed and
used according to the instructions found in the users manual, may cause
interference harmful to the operation of other electronic devices.
CONTROLS AND FUNCTIONS
Cannot change the volume of this unit
by changing the volume of the iPhone or
iPod.
The iPhone or iPod display does not
change by pressing the remote control
volume keys.
The unit cannot be operated by the remote
control.
iPod™, iPhone™
iPod is a trademark of Apple Inc., registered in the U.S. and other countries.
iPhone is a trademark of Apple Inc.
SPECIFICATIONS
Supported iPod.................................................................................................................................................iPod (5th generation), iPod classic, iPod nano, iPod touch
“Made for iPod” means that an electronic accessory has been designed to connect specifically to iPod and has been certified by the developer to meet Apple
performance standards.
“Works with iPhone” means that an electronic accessory has been designed to connect specifically to iPhone and has been certified by the developer to meet Apple
performance standards.
Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards.
Supported iPhone........................................................................................................................................................................................................... iPhone, iPhone 3G
Maximum RMS output power per channel (6 Ω 1 kHz, 10% THD)......................................................................................................................................15 W + 15 W
Power Supply
U.S.A. and Canada models.........................................................................................................................................................................................AC 120 V, 60 Hz
Other models..............................................................................................................................................................................................AC 100 to 240 V, 50/60 Hz
REPLACING THE BATTERY IN THE REMOTE CONTROL
1
2
3
Power Consumption............................................................................................................................................................................................................................ 10 W
Power Consumption without connecting iPod/iPhone...........................................................................................................................................................less than 1 W
Dimensions (W x D x H)............................................................................................................................................................................................350 x 125 x 109 mm
(13-12/16” x 4-15/16” x 4-5/16”)
Weight (without accessories)...............................................................................................................................................................................................1.7 kg (3.7 lbs)
iPod (4th generation or before), iPod without Dock connector, iPod photo or iPod mini are not supported by this unit.
*Specifications are subject to change without notice.
Printed in China
WQ92780
MENU
PDX-30
a
c
b
7m
( 23 feet )
30˚
30˚
MENU
g
d
e
f
iPhone & iPod touch
Alternative & Punk
Blues
Latin
Jazz
Pop
R&B
Rock
iPod
MENU
MENU
Alternative & Punk
Blues
Latin
Jazz
Pop
R&B
Rock
© 2008 Yamaha Corporation All rights reserved.
Alternative & Punk
Blues
Latin
Jazz
Pop
Alternative & Punk
Blues
Latin
Jazz
Pop
R&B
Rock
Alternative & Punk
Blues
Latin
Jazz
Pop
Download PDF

advertising
