Safety Guidelines
Caution: Always use a power cable is properly grounded. Please use the AC
cords listed below for each area:
USA......................UL
Canada.................CSA/cUL
FCC Information
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy, and if not installed and used in accordance with the
instructions, may cause harmful interference will not occur in a particular
installation. If this equipment does cause by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio / TV technician for help.
FCC Warning
To assure continued FCC compliance, the user must the provided grounded
power supply cord and the provided shielded video interface cables to connect
to this equipment. Also, any unauthorized changes or modifications to this
equipment would void the user’s authority to operate this device.
Caution (for the product without main power switch)
Since there is not the main power switch used into the product. So
it is better to detach the power supply cord from the inlet of the
power source while the product is not used for a time. And the main
plug of the product is used as the disconnect device, the disconnect
device shall remain readily operable.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.
Operating Instructions
Important Safeguards
Before using your TV, please read these instructions completely, and keep this
manual for future reference.
Carefully observe and comply with all warnings, cautions and instructions placed on
the unit or described in the operating instructions or service manual.
The User Manual uses the following symbols, to ensure a safe operation and
prevent any damage to operators or properties:
WARNING ----- Ignorance or inappropriate use may
cause damage to the product.
ATTENTION --- Ignorance or inappropriate use may
cause injury to the user.
Examples:
Prohibition
Warning (Attention) symbol (indicating “Electric
Shock”).
WARNING
Never place TV on an unstable cart, stand, or table. The
TV may fall, causing serious personal injury, death, or
serious damage to the TV.
Never overload wall outlets and extension cords.
Never allow anything to rest on or roll over the power
cord, and never place the TV where the power cord is
subject to wear or abuse.
Keep the product away from moisture:
- Do not expose this appliance to rain or moisture.
- If water penetrates into the product, stop the
operation; unplug the connector and contact with
your dealer. Continuous use in this case may result
in fire or electric shock.
WARNING
Never place item such as vases, aquariums, or
candles on top of the TV.
Never use a damaged power cord:
Heavy objects, heat, or tensile force may damage the
power cord and cause fire or electric shock.
Never block or cover the slots or openings, in the TV
cabinet back, bottom, and sides. Never place the TV:
- on a bed, sofa, rug, or similar surface;
- too close to drapes, curtains, or walls; or
- in a confined space such as bookcase, built-in
cabinet, or any other place with poor ventilation.
The slots and openings are provided to protect the TV
from overheating and to help maintain reliable operation of the TV.
Do not use the product if any abnormality occurs:
If any smoke or odor becomes apparent, unplug the
connector and contact the manufacturer immediately.
Do not try to repair the product by yourself.
WARNING
Operating Instructions
Avoid using dropped or damaged appliances:
If the product is dropped and the housing is damaged,
the internal components may function abnormally.
Unplug the connector immediately and contact
the manufacturer for repair. Continuous use of the
product may cause fire or electric shock.
WARNING
While it is thundering, do not touch the connecting
cables or apparatus.
ATTENTION
Do not install the product close to smoke or moisture:
Fire or electric shock may be caused when the product
is installed close to smoke or moisture.
Do not installed the product in an area with heavy dust
or high humidity:
Fire or electric shock may be caused when the product
is installed in a place with heavy dust or high humidity.
Instructions for moving the product:
Ensure that the power connector and any other leads
are unplugged before moving the product.
The power cable should be kept away from heat
sources:
The heat produced by any heat source may melt the
covering of the power cable.
Hold the power connector when removing the power
cable:
Pulling the power cable itself may damage the vires
inside the cable and cause fire or electric shock.
Do not touch the connector with wet hands:
To avoid risk of electric shock.
Unplug the connector
ATTENTION
Insert batteries in accordance with instructions:
Insert the batteries with correct polarities (positive ⊕
and negative ⊖).
Incorrect polarities may cause breakage and leakage
of the batteries, hurt operators and contaminate the
remote controller.
Do not block or cover the vents:
Blocking the vents may cause overheating and fire.
Do not install the product in a place with little or no
ventilation. Never cover the vents with towels, blankets
or dusters.
Unplug the connector:
Unplug the power connector when the product will not
be used for a long time.
Unplug the connector
Always make sure the antenna system is properly grounded to provide
adequate protection against voltage surges and built-up static charges.(see
Section 810 of the National Electric Code.)
Antenna lead-in wire
Ground clamp
Electric service equipment
Ground clamp
Antenna discharge unit
(NEC Section 810-20)
Grounding conductors
(NEC Section 810-21)
Power service grounding
electrode system (NEC Art 250 Part H)
Use extreme care to make sure you are never in a position where your body
(or any item your are in contact with, such as a ladder or screwdriver) can
accidentally touch overhead power lines. Never locate the antenna near
overhead power lines or other electrical circuits. Never attempt to install any
of the following during lightning activity:
a). an antenna system; or b).cables, wires, or any home theater component
connected to an antenna or phone system.
Operating Instructions
❖Notes others
▪ Although the LCD screen is made with high-precision technology and has
effective pixels of 99.99% or more, black dots may appear or bright points of
light (red, blue, or green) may appear constantly on the LCD screen. This is a
structural property of the LCD panel and is not a malfunction.
▪ LCD (Liquid Crystal Display) may cause interference in image, sound, etc.of
the other electronic equipment that is easy to receive electromagnetic waves
(i.e. AM radios and video equipment) under certain installed condition. In
particular, it may affect electronic equipment beyond the residential until where
a LCD TV is used.
▪ The screen on this TV is manufactured from glass. To prevent damage, never
strike the glass with a sharp or heavy object.
▪ Your LCD television contains a small amount of Mercury. When the television is
no longer useful, please follow local electronic waste guidelines for proper
disposal.
▪ If you have the LCD screen facing to the sun, the LCD screen will be damaged.
Locate the TV in the place such away from windows side or out side of the
rooms with windows.
▪ This product is designed for indoor use only.
▪ Operating environment:
Temperature: 5°C ~30°C
Humidity: 20% to 85% non-condensing
Precaution
1.
2.
3.
4.
5.
6.
7.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that product heat.
9 Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades wider than the other. A grounding type plug has
two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long
periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
15. The apparatus shall not be exposed to dripping or splashing and that no
objected filled with liquids, such as vase, shall be placed on the apparatus.
Operating Instructions
Contents
Safety Guidelines............................ 1
Important Safeguards..................... 2
Precaution........................................ 7
1. Before use................................... 9
■ Selection of “Language”............27
■ Setting of “V-Chip”....................28
■ Selection of “Closed Caption”....33
1.1 Open the Package..........................9
■ Selection of “Blue Back”............34
1.2 Installation.......................................9
■ Using “Default”.........................34
2. Product Features........................ 10
3. Supplied Accessories................. 10
4. Names and Functions of Parts.. 11
■ Using the “Tuner Mode”............35
■ Using the “Searching”...............35
4.1 Side View........................................11
■ Using the “TV”..........................35
4.2 Front View.......................................11
■ Using the “Channel Skip”..........36
4.3 Rear View.......................................12
■ Using the “Channel Name”.......36
4.4 Remote Control...............................13
■ Selecting Channel.....................36
5. Connect Accessory Devices...... 16
6. Basic Operation.......................... 20
■ Channel Preview........................37
6.1 Power ON/OFF...............................20
■ Using “Contrast”.......................37
6.2 Selection of Input Mode..................20
■ Using “Brightness”.....................37
6.3 Other Function................................21
■ Using “Color Temperature”........38
6.4 OSD Option Adjustment..................22
■ Using “Auto Setting”..................38
◆ Using the Video Menu................ 23
■ Using “Phase”...........................38
◆ Using the TV Menu(Analog)........ 35
◆ Using the Geometric Menu......... 37
■ Adjustment of “Contrast”...........23
■ Using “Manual Clock”...............39
■ Adjustment of “Brightness”.........23
■ Using “Display Adjustment”.......39
■ Adjustment of “Saturation”.........23
■ Adjustment of “Hue”..................24
■ Using the “General” Menu........40
■ Adjustment of “Sharpness”.........24
■ Using the “Caption” Menu.........42
■ Selection of “Phase” setting........24
■ Setting of “Parental”..................44
■ Selection of “Color
■ EPG(Electronic Program Guide)..45
■ Selecting Channel.....................46
■ Channel Preview........................47
Temperature”.............................25
■ Selection of “Advance
Picture Adjust”...........................25
◆ Using the Audio Menu................ 26
◆ Using the Setup Menu................ 27
■ Adjustment of “Bass”.................26
■ Adjustment of “Treble”...............26
■ Adjustment of “Balance”............27
■ Selection of “Surround”.............27
◆ Using the DTV Menu(Digital)....... 40
7. Technical Specification.............. 48
8. Support the Signal Mode........... 49
9. Cleaning Simple
Troubleshooting.......................... 50
1. Before use
The product is a 37” WXGA (WXGA resolution) LCD TV Player. It has passed
the UL and cUL safety certifications, and is an ideal product for personal and
commercial use. The product is a precise electronic product. Users should read
the following instructions carefully to maximize the performance and life span of
the product:
1.1 Open the Package
- The product is packaged in a carton together with other standard accessories.
Any optional accessories shall be packed separately in another carton.
- Due to the size & weight of the product, it is recommended that it should be
moved by a minimum of two people.
- The protective glass and the glass substrate are installed on the front of the
product. Since both glasses can be broken and scraped easily, move the
product gently. Never place the unit with the glass facing downwards unless it
is protected with soft pads.
- When opening the carton, check that the product is in good condition and that
all standard accessories and items are included.
- Whenever possible, use the handles on the back of the Display for transport.
1.2 Installation
- Please use caution if wall mounting this product. Follow all directions from the
manufacturer of the wall mount and be sure to securely fasten the product to
the mount.
While the TV can be wall mounted, improper wall installation may void the
warranty.
- Due to the higher power consumption, always use the jack exclusively
designed for this product. If an extended line is required, please consult with
your service agent.
- The product should be installed on a flat surface to avoid tipping. The distance
between the back of the product and the wall should be maintained for proper
ventilation.
- Avoid installing the product in the kitchen, bathroom or any other places with
higher humidity so as not to shorten the service life of the electronic
components.
- Please ensure the product be installed horizontally, any 90 degree clockwise
or counterclockwise installation may induce poor ventilation and subsequent
component damage.
Operating Instructions
2. Product Features
The 37” LCD TV Player provides quality image displays and is suitable for a variety of multi media applications:
1. Available input signals
- The product provides HDMI input connector.
- The product provides VGA (D-Sub 15 PIN) input connector.
- The product supports PC images resolutions up to (1024 x [email protected]) with a
vertical frequency of 60Hz.
- The product provides component video (RCA) input connectors. It supports the
quality input images of DVD and HDTV (480p/720p/1080i).
- The product provides composite video (RCA) and S-Video (DIN 4 PIN) input
connectors.
- The product provides five sets of stereo audio input connectors, one set of
audio output connector (RCA) and one set of SPDIF output connector for DTV.
Note: The support signal mode, please refer to page 49.
2. Power Management Function
The machine provides an automatic power control function.
3. WXGA LCD TV Panel
The WXGA LCD TV panel provides high resolution and high contrast image.
The number of pixels is 1366 (H) x 768 (V). The contrast is 1000:1.
4.Others
- The LCD TV unit provides cool, middle, warm and user color temperature
options. The user may customize their favorite color temperature.
3. Supplied Accessories
Remote control.................................................... 1
Batteries (AAA)................................................... 2
Owner’s manual (This booklet)........................... 1
Warranty Card..................................................... 1
Insertion Card...................................................... 1
Power Cord......................................................... 1
* Screws (M5x60)................................................ 4
* It is used for installation Wall Mount adapter
brackets on Back Cover.
When the user buys the Wall Mount from
PEERLESS. Please see Fig.1.
10
Fig.1
Screws
(M5x60) x 4
4. Names and Functions of Parts
4.1 Side View
The functions of the buttons are described as follows:
Sketch map
STANDBY: Press
and turn off.
(Standby) to turn on
VOL.+/A. They are used as  /  buttons in
the OSD Menu screen.
B. Press to adjust the volume.
CH.+/A. They are used as  /  buttons in
the OSD Menu screen.
B. Press to scan through channels. To
scan quickly through channels, press
and hold down either channels.
MENU: Press to display the menu. Press
again to exit the menu.
SOURCE: Press to cycle display DTV, TV,
AV, S-Video, YPbPr1, YPbPr2, VGA, and
HDMI source. When display the OSD-menu,
press it to confirm.
4.2 Front View
Sketch map
(IR) Infrared Receiver: Receives IR signals from the remote control.
(Power on / Standby) LED:
Press
(Power) to turn on and off.
Indicator on (Red)
Indicator on (Green)
Standby mode
Power on mode
11
Operating Instructions
4.3 Rear View
Sketch map
a
b
1
2
3
4
5
6
7
8
9
1
a Use the power cord connect to an earthed 120V, 60Hz AC outlet.
b Signal input and other terminals:
1. ANT1 & ANT2: 75Ω Coaxial connector for Antenna/Cable Network.
Note: ANT 1 is for ATSC(DTV), and ANT 2 is for NTSC(ATV). (Refer to page 19.)
2. OPTICAL OUTPUT: Connect the optical output to the optical input connector
of the Amplifier. (Only for DTV)
3. RS-232: The D-SUB 9 Pins terminal is used as a control port for serial
communication between PC and Panel. (Only for after-sales service & DTV)
4. Audio Output: Connect audio amplifier or other TV set that with audio input.
5. HDMI INPUT: For high quality picture display purposes. Connects to HDMI or
DVI (with DVI to HDMI Adapter-not provided) digital output connector of the
DVD or HDTV Set-top box.
6. D-Sub (VGA) INPUT: For PC display purposes. Connects to the Mini D-Sub
15 Pins analog output connector of the PC display card.
7. VGA/DVI AUDIO INPUT: Connect the audio input terminal to the audio output
terminal of DVD or HDTV Set-top box with VGA/DVI output terminal.
8. YPbPr (COMP1) INPUT: Connect the Component video input terminal to the
Component output terminal of the video output device.
YPbPr (COMP1) Audio INPUT: Connect the audio input terminal to the audio
output terminal of the video output device.
9. YPbPr (COMP2) INPUT: Connect the Component video input terminal to the
Component output terminal of the video output device.
YPbPr (COMP2) Audio INPUT: Connect the audio input terminal to the audio
output terminal of the video output device.
12
. S-Video INPUT: Connects to the S-Video out jack of your VCR or other video
equipment that has S-Video.
S-Video Audio Input: Connect the audio input terminal to the audio output
terminal of the S-Video output device.
. Video Input: Connect the component video input terminal to the video output
terminal of the video output device.
Video Audio Input: Connect the audio input terminal to the audio output
terminal of the Video output device.
4.4 Remote Control
1 Power (
2
3
4
5
6
7
8
9
): Press to turn on and
off.
Mute (
): Press to mute the
1
sound. Press again or press
VOL+/- to restore the sound.
0~9 Number Buttons: In TV
mode, press 0~9 to select a
3
channel; the channel changes
after 2 seconds.
6
EPG: Press to display EPG
(Electronic Program Guide) menu.
8
Source (
): Press to select the
signal sources.
DTV: Press to select Digital TV
mode.
Dot: Press number buttons with it
to select the channels directly in
DTV.
VOL +/-: Press to adjust the
volume.
CH +/-: Press to changes channels.
MTS: Press to repeatedly to cycle
through the Multi-channel TV sound
(MTS) options. Such as Stereo,
Mono, or Separate Audio
Program (SAP broadcast).
,,,, Enter: Press ,,,
to move the on-screen cursor. To
select an item, press Enter to confirm.
Exit: Press to return or exit the OSD menu.
Menu: Press to display the OSD menu.
V-Chip: Press to select the child protect mode.
2
4
5
7
9
13
Operating Instructions
CCD: Press to select the Closed
Caption mode.
Freeze: Press to freeze the picture,
14
1
2
press again to restore the picture.
(This button is not available for
3
VGA mode.)
4
Display: Press to display the
5
channel information and it
6
7
disappear after 3 seconds.
8
9
Favorite: Press repeatedly to cycle
through the favorite channel list.
Add/Erase: Press to add or delete
favorite channel.
S.Mode: Adjust the TV sound by
selecting one of the preset factory
settings, such as Normal, News,
Cinema, Concert, or User.
PIC.Size: Press to change the
screen size, such as Full, 4:3,
Panoramic. (Note: In VGA mode, it
can select picture size is Full.
While in DTV mode, it can select
picture size is: Full and 4:3. )
Recall: Press to return to previous
channel.
Sleep: Press to sleep a time for the
TV to turn off automatically, such as
15Min, 30Min, 60Min, 90Min, 120Min and, OFF. To cancel sleep time, press
Sleep repeatedly until sleep OFF appears.
P.Mode: Adjust the TV picture by selecting one of the preset factory settings,
such as Hi-Bright, User, Cinema, Normal and Vivid.
System: Press repeatedly to cycle through the system options: AUTO,
NTSC3.58 and PAL.(This button is activate for AV, S-Video input source.)
Color Buttons:
Red: Press this button to access the red item or page.
Blue: Press this button to access the blue item or page.
Green: Press this button to access the green item or page.
Yellow: Press this button to access the yellow item or page.
Insertion of Batteries
- Turn the remote control upside down, press and slide off the battery cover.
- Insert two 1.5V (AAA) batteries into the compartment, take care to observe the
⊕ and ⊖ markings indicated inside.
- Replace the cover and slide in reverse until the lock snaps.
Range of Remote Control
- Ensure the remote control is pointed
towards the Remote control window
on the display unit.
- No obstacles should be placed
between the remote control and the
remote control window.
- The effective receiving range for the
signal is within 5-8 meters from the
front of the remote control window,
and 30° to the left or right side
and 20° above or below the control
window.
Sketch map
20°
20°
30° 30°
Care For Remote Control
-
Avoid spilling liquids on the remote.
Avoid dropping or otherwise jarring the remote.
Always store the remote control at dry and normal room temperature place.
If the remote is nor performing satisfactorily, replace the batteries. The batteries
should be replaced after one year.
- If the remote control will be idled for a long time (above 1 month) take out the
batteries to avoid leakage from the batteries.
- Clean up the entire remote control especially the battery compartment if any
leakage found.
- Do not mix using different kind of new and used batteries together to avoid
leakage.
15
Operating Instructions
5. Connect Accessory Devices
Note:
The meaning of switch off LCD TV mentioned into the below operation:
Since there is not the main power switch used into the LCD TV. Switch off LCD
TV is only meaning of , detaching the power supply cord of LCD TV from the
inlet of the power source , in order to shut off the power source of LCD TV.
 Connecting a DVD player or other
equipment
Switch off LCD TV and external equipment before connecting cables.
1. Connect a DVD player or other
equipment’s Component Video Out
(Y,Pb,Pr/Y,Cb,Cr) to the LCD TV’s
corresponding Component In
(Y,Pb,Pr/Y,Cb,Cr) terminal on
COMP1 or COMP2.
2. Connect a DVD player’s Audio Out to
the TV Component L/R terminal.
3. Press Power to turn on the LCD TV,
then turn on external equipment.
4. Press INPUT to select YPbPr1 or
YPbPr2 signal source.
 Connecting the Computer
Switch off LCD TV and external equipment before connecting cables.
1. Connect a computer’s D-Sub(VGA)
Out to the LCD TV’s D-Sub(VGA) In
terminal.
2. Connect a computer’s Audio Out to
the LCD TV’s VGA/DVI Audio In
terminal.
3. Press Power to turn on the LCD TV,
then turn on external equipment.
4. Press INPUT to select VGA signal
source.
16
Green
Red
Blue White
Red
DVD or other equipment
White
Red
 Connecting the DVD player or HDTV Set-top box using HDMI input
Switch off TV and external equipment before connecting cables.
1. Connect the LCD TV to the DVD player or HDTV Set-top box with the HDMI
cable.
2. Connect the DVI AUDIO input terminal to the audio output terminal of HDTV
Set-top box with DVI output terminal, and a DVI to HDMI conversion cable
should be adopted.
3. Press Standby to turn on the TV, then turn on external equipment.
4. Press Source to select HDMI signal source.
Note:
1. The above step 2 is used if you connect DVI output to the HDMI input of the LCD TV.
The above step 1 is used if you connect HDMI output to the HDMI input of the LCD TV.
2. HDMI is not compatible with PC.
White
Red
HDMI/DVI adapter
DVI
DVD or Set top box
or other equipment
 Connecting AUDIO OUTPUT
jacks to a stereo amplifier
Switch off TV and external equipment
before connecting cables.
1. Connect the TV Audio Output (R/L)
to the stereo amplifier In (R/L).
2. Press Standby to turn on the TV,
then turn on external equipment.
DVD or Set top box
or other equipment
Red
White
Stereo Amplifier
17
Operating Instructions
 Connecting the DVD or VCR player devices
Switch off TV and external equipment before connecting cables.
1. Connect a DVD or VCR player’s Video Out to the TV’s Video In terminal by a
Video cable.
2. Connect a DVD or VCR player’s S-VIDEO Out to the TV’s S-VIDEO In terminal
by a S-VIDEO cable.
3. Connect a DVD or VCR player’s Audio Out to the TV’s L/R terminal by a Audio
cable.
4. Press Standby to turn on the TV, then turn on external equipment.
5. Press Source to select AV or S-VIDEO signal source.
White
Red
DVD or VCR
player
Yellow
Red
White
DVD or VCR
player
 Connecting SPDIF(Optical) terminal to a stereo amplifier
Switch off TV and external equipment before connecting cables.
1. Connect one end of an optical cable to the TV Digital Audio (Optical) Output port.
2. Connect the other end of the optical cable to the digital audio (Optical) input on
the audio equipment.
3. Press Standby to turn on the TV, then turn on external equipment.
Note:
1. When connecting the TV to external
audio devices, such as amplifiers and
speakers, please be sure to turn the
TV speakers off.
2. Only for DTV.
Caution:
Do not look into the optical output port. Looking
at the laser beam may damage your vision.
Stereo Amplifier
18
 Connect to antenna
ATSC (DTV) & NTSC(ATV) input connection config
1. There are two Antennas:
- ANT 1 is only for ATSC channel of Air.
- ANT 2 is only for Air or Cable Signal of NTSC.
2. The user can select the Antenna input as below:
A. One Antenna is for Air signal config.
Splitter
ANT 1 (DTV)
ANT 2 (ATV)
Air Signal
(NTSC + ATSC)
B. Two Antenna config A
ANT 1 is only for ATSC channel of Air.
ANT 2 is only for Cable signal of NTSC.
Air Signal
ATSC
ANT 1 (DTV)
Cable Signal
NTSC
ANT 2 (ATV)
C. Two Antenna config B
ANT 1 is only for ATSC channel of Air.
ANT 2 is only for Air or Cable Signal of NTSC.
Air Signal
(NTSC + ATSC)
Splitter
ANT 1 (DTV)
ANT 2 (ATV)
Cable Signal NTSC
Cable Box
Note:
After connection, if your product has the interference, please don’t select the connections A or C, use only B.
19
Operating Instructions
6. Basic Operation
6.1 Power ON/OFF
The Display is in Standby mode.
- Press the Standby
on the
remote control or on the control
panel to turn on the unit. The
power indicator changes from red
to green.
- Press the Standby
on the
remote control or on the control
panel again to return the display to
standby mode.
The power indicator changes from
green to red.
Note: For protecting your LCD TV
product, the interval time between
turn on the LCD TV product and
shut down it should be kept at
least one minute.
Standby
Source
6.2 Selection of Input Mode
- Press Source on the remote control
or on the LCD TV control panel to
select the signal source you desired.
When no input from the selected
signal source, “No signal” will appear, press Source on the remote control or on
the control panel again to search the next source.
Note:
The LCD-TV will automatically turn itself off after approximately 15 minutes if no
signal input. When no signal is inputted for about 14 minutes. A “No signal and
going to power down” wording will appear.
20
6.3 Other Function
Freeze:
- Press it to hold the current video and
press again to cancel and return to
normal viewing.
Sleep:
- Press repeatedly until it displays the
time in minutes that you want the TV
to remain on before shutting off.
Note: When “Turn off by Timer setting?”
wording will appear remain one minute
on before shutting off, you can press “ ”
or “ ” button to selected, press “Enter”
to confirm. If select “Cancel” or no operation, the LCD-TV will automatically turn
off after one minutes, if select “OK”, it will
turn off immediately.
Add/Erase:
- Press this button to add/erase
current channel to/from the list of
favorite directly.
1 Add current channel into the list
of favorite if a heart shape mark
Freeze
Add/Erase
Sleep
displaying on the left top of screen.
2 Erase current channel from the list of favorite if a broken heart shape mark
displaying.
Note: - If you don’t want do add/erase this channel to/from the list of favorite,
press this button again.
- For addition, it will be put at last of the favorite list and the first channel in
favorite list will overflow in case of the list is full.
- Erase favorite channel while in DTV mode, broken heart shape mark is
not displaying.
21
Operating Instructions
6.4 OSD Option Adjustment
Learning about the menu system
After you have installed the batteries into the remote control, you will need to
set some preferences on the LCD using the menu system. You can access the
menu using the buttons on your LCD TV or remote control.
The OSD menu displayed in the following sequence (circular display):
Video
Audio
Setup
TV
Geometric
The Side Panel
1 Press Menu button to display the
menu system.
2 Press  or  button to select a menu.
3 Press  or  button to select an item.
4 Press  ,  ,  ,  button to select
or adjust a setting, press Enter button
to confirm.
5 If you do not make a selection within
15 seconds, the main menu closes
automatically; the other menus close
automatically within 6 seconds.
6 To close an on-screen menu instantly,
press Exit or MENU button.

MENU
SOURCE
Source

Enter
Menu
Remote Control
22
DTV
◆ Using the Video Menu
Note:Video Menu is just for TV, AV, S-Video, YPbPr1, YPbPr2, HDMI, and DTV
input source mode. It is not available in other input source mode.
■ Adjustment of “Contrast”
1 Press Menu button on the remote
control, and then press  or 
until the “Video” menu appears.
2 Press  or  button to highlight
the item.
3 Press  or  button adjust.
4 Press Menu or Exit button to
return.
■ Adjustment of “Brightness”
1 Press Menu button, and then press
 or  button until the “Video”
menu appears.
2 Press  or  button to highlight
the item.
3 Press  or  button to adjust.
4 Press Menu or Exit button to
return.
■ Adjustment of “Saturation”
1 Press Menu button, and then press
 or  button until the “Video”
menu appears.
2 Press  or  button to highlight
the item.
3 Press  or  button to adjust.
4 Press Menu or Exit button to
return.
23
Operating Instructions
■ Adjustment of “Hue”
1 Press Menu button, and then press
 or  button until the “Video”
menu appears.
2 Press  or  button to highlight
the item.
3 Press  or  button to adjust.
4 Press Menu or Exit button to
return.
■ Adjustment of “Sharpness”
1 Press Menu button, and then press
 or  button until the “Video”
menu appears.
2 Press  or  button to highlight
the item.
3 Press  or  button to adjust.
4 Press Menu or Exit button to
return.
■ Selection of “Phase” setting
1 Press Menu button, and then press
 or  button until the “Video”
menu appears.
2 Press  or  button to highlight
the item.
3 Press  or  button to adjust.
4 Press Menu or Exit button to
return.
Note: This is a feature just used for
YPbPr input source.
24
■ Selection of “Color Temperature”
1 Press Menu button, and then press
 or  button until the “Video”
menu appears.
2 Press  or  button to highlight
the item.
3 Press  or  button to select one
of “Cool”, “Middle”, “Warm” or
“User” for balance of whitening.
4 Press Menu or Exit button to
return.
If you select the item of “User”, a status
bar below comes up for you to adjust
the color temperature to you desirable
value.
■ Selection of “Advance Picture Adjust”
1 Press Menu button, and then press
 or  button until the “Video”
menu appears.
2 Press  or  button to highlight
the item.
3 Press Enter button to confirm for
sub-selection as shown in the table
below.
4 Press  or  button to highlight
the item.
5 Press  or  button to select.
6 Press Menu or Exit button to
return.
25
Operating Instructions
Table of Video Adjustment Setting
Item
Status
DNR
Off, Low, Middle,
Strong
Selecting to control the sharpness
and noise reduction.
CTI
Low, Middle, Strong,
Off
Select dynamic color improve level.
Flesh Tone
On, Off
Select “On” to correct the flash tone
automatically.
Adaptive Luma
Control
On, Off
Selecting to control the lum.
◆ Using the Audio Menu
■ Adjustment of “Bass”
1 Press Menu button, and then press
 or  button until the “Audio”
menu appears.
2 Press  or  button to highlight
the item.
3 Press  or  button to adjust.
4 Press Menu or Exit button to
return.
■ Adjustment of “Treble”
1 Press Menu button, and then press
 or  button until the “Audio”
menu appears.
2 Press  or  button to highlight
the item.
3 Press  or  button to adjust.
4 Press Menu or Exit button to
return.
26
Description
■ Adjustment of “Balance”
1 Press Menu button, and then press
 or  button until the “Audio”
menu appears.
2 Press  or  button to highlight
the item.
3 Press  or  button to adjust.
4 Press Menu or Exit button to
return.
■ Selection of “Surround”
1 Press Menu button, and then press
 or  button until the “Audio”
menu appears.
2 Press  or  button to highlight
the item.
3 Press  or  button to select
“On” or “Off”.
4 Press Menu or Exit button to
return.
◆ Using the Setup Menu
■ Selection of “Language”
1 Press Menu button, and then press
 or  button until the “Setup”
menu appears.
2 Press  or  button to highlight
the item.
3 Press  or  button to choose
“English”, “Francese” or “Español”.
4 Press Menu or Exit button to
return.
27
Operating Instructions
■ Setting of “V-Chip”
Some programs and movies include signals that classify the content of the
program (dialog, language, sex, violence). The “V-Chip” control feature in this
detects the signals and blocks the programs according to your selections. To
use this feature, perform the following setup.
Adjustment only for TV, DTV, AV, S-VIDEO input signal.
1 Press Menu button, and then press
 or  button until the “Setup”
menu appears.
2 Press  or  button to highlight
the item.
3 Press Enter button to confirm.
The “V-Chip” menu includes the “V-Chip Enable”, “Block MPAA Rating”, “Block
TV Rating”, “Block MPAA Unrated”, “Block TV None Rating” and “Change
Password” functions. You can use these functions after entering the correct PIN
code.
Entering the PIN code
▪Blocking Reset status:
Set your 4-digit code by pressing the Number buttons (0~9), and then press
Enter.
▪When the PIN code is already stored:
Press the Number buttons (0~9) to enter the 4-digit PIN code used for
blocking channels, and then press Enter.
Note:
The initial password for the system is “0000”.
If you had forgotten the password, please contact with service centre.
If the input is invalid, a message will pop up as below;
28
You can press Enter button to display “Input Your Password Please” menu
again, then entering the PIN code, or press ,, or  button move cursor to
“Cancel” and press Enter button to close up this menu.
✿ Using the “Change Password” item
1 When enter the “V-Chip” menu,
select “Change Password”.
2 Press  or  button to highlight
the “Change Password” item.
3 Press Enter button to confirm.
4 Press Number buttons (0~9) to
enter the 4-digit PIN code to
change the password, then use 
button move to Confirm item,
enter the 4-digit PIN code again.
5 Press Enter button to confirm.
Note:Please operate “Change Password”
at the first time.
✿ Using the “V-Chip Enable” item
1 When enter the “V-Chip” menu,
select “V-Chip Enable”.
2 Press  or  button to highlight
the “V-Chip Enable” item.
3 Press  or  button to select “On”
or “Off”.
On: The V-Chip setting functions
are activate.
Off: The V-Chip setting functions
are not activate.
4 Press Menu or Exit button to return.
✿ Using the “Block MPAA Rating” item
1 When enter the “V-Chip” menu,
select “Block MPAA Rating”.
2 Press  or  button to highlight
the “Block MPAA Rating” item.
3 Press Enter button to confirm.
4 Press  or  button to select an
item, then press Enter button to
lock (display“”) or unlock
(display “”).
29
Operating Instructions
For Movie previously shown in theaters:
•G
(general audience)
• PG
(parental guidance suggested)
• PG-13
(13 years and older)
•R
(Restricted)
• NC-17
(18 years and older)
•X
(Adult)
If you set PG-13: G and PG movies be available, PG-13, R, NC-17, and X will be
blocked.
5 Press Menu button to exit the sub-menu.
✿Using the “Block TV Rating” item
1 When enter the “V-Chip” menu,
select “Block TV Rating”.
2 Press  or  button to highlight
the “Block TV Rating” item.
3 Press Enter button to confirm.
4 Press ,, or  button to select
an item, then press Enter button to
lock (display “”) or unlock
(display “”).
5 Press Menu button to exit the
sub-menu.
For Television programs including made-for-TV
movies:
General TV Ratings:
• TV-G
(general audience) (individual categories do not apply)
• TV-PG
(parental guidance suggested)
• TV-14
(14 years and older)
• TV-MA
(mature audience)
Children TV Ratings:
• TV-Y
(youth) (individual content categories do not apply)
• TV-Y7
(youth, 7 years and up)
30
Content Categories:
• Dialog - sexual dialogue
• Language - adult language
• Sex scenes - sexual situations
• Violence
• F Violence - fantasy violence
(applies to TV-PG and Above,
(applies to TV-PG and Above,
Above, TV-MA)
(applies to TV-PG and Above,
Above, TV-MA)
(applies to TV-PG and Above,
Above, TV-MA)
(applies only to TV-Y7)
Unlocking programs temporarily
(In TV signal source)
1 If you try to watch a TV program
that exceeds the TV Rating you
set, the TV enters program lock
mode. You can either unlock the
program temporarily or select a
non-locked program to watch,
press CH+/- button to select the
program.
TV-14)
TV-14 and
TV-14 and
TV-14 and
V-CHIP BLOCK
TV-PG
LV
Enter Password
_ _ _ _
2 To temporarily unlock the program, press the Number buttons (0~9) to enter
your 4-digit PIN code.
(In DTV signal source)
1 If you try to watch a DTV program that exceeds the DTV Guideline you set,
the DTV enters program lock mode. You can either unlock the program
temporarily or select a non-locked program to watch, press CH+/- button to
select the program.
2 To temporarily unlock the program, press the Number buttons (0~9) to enter
your 4-digit PIN code.
Password
If the correct code is entered, the program lock mode is released and the
normal picture appears.
31
Operating Instructions
✿Using the “Block MPAA Unrated” item
1 When enter the “V-Chip” menu,
select “Block MPAA Unrated”.
2 Press  or  button to highlight
the “Block MPAA Unrated” item.
3 Press  or  button to select “No”
or “Yes”.
Yes: You can’t watch the “MPAA
Unrated” programs.
No: You can watch the “MPAA
Unrated” programs.
4 Press Menu button to exit the
sub-menu.
✿Using the “Block TV None Rating” item
1 When enter the “V-Chip” menu,
select “Block TV None Rating”.
2 Press  or  button to highlight
the “Block TV None Rating” item.
3 Press  or  button to select “No”
or “Yes”.
Yes: You can’t watch the “TV
None Rating” programs.
No: You can watch the “TV None
Rating” programs.
4 Press Menu button to exit the
sub-menu.
Hot keys:
- You can also press V-Chip button on the remote control to enter V-Chip
menu.
32
■ Selection of “Closed Caption”
The closed caption features has two options:
Adjustment only for TV, DTV, AV, S-VIDEO input signal.
• Captions: An on-screen display of the dialogue, narration, and sound effects
of the TV programs and videos that are closed captioned (usually
marked as “C/C” in TV listings.
• Text:
An on-screen display of information not related to the current
program, such as weather or stock data (when provided by
individual stations).
To view captions or text:
1 Press Menu button, and then press
 or  button until the “Setup”
menu appears.
2 Press  or  button to highlight
the item.
3 Press  or  to choose one of
“C1”, “C2”, “C3”, “C4”, “T1”, “T2”,
“T3”, “T4”, “Off”, as follows:
• To view captions, highlight C1, C2,
C3, or C4 (C1 displays translation
of the primary language in your
area).
Trees near the church.
Note:
If the program or video you selected is not
closed captioned, no captions will display
on-screen.
• To view text, highlight T1, T2, T3, or T4.
World Weather
Temp
New York
London
HongKong
Note:
▪
▪
▪
F
53
51
80
C
12
11
25
Current
Weather
Sunny
Cloudy
Clear
Note:
If text is not available in your area, a black
rectangle may appear on-screen. If this happens, turn off the Closed Caption feature.
A closed caption signal may not display in the following situations:
when a videotape has been dubbed
when the signal reception is weak
when the signal reception is nonstandard
33
Operating Instructions
4 Select “Off” to close this function.
5 Press Enter button to confirm your selection.
Hot keys:
- You can also press CCD button on the remote control to select.
■ Selection of “Blue Back”
1 Press Menu button, and then press
 or  button until the “Setup”
menu appears.
2 Press  or  button to highlight
the item.
3 Press  or  button to choose
“On” or “Off”, when select “On” to
set screen to a pleasant blue
background when it detects no
signal available if turn on.
4 Press Menu or Exit button to
return.
■ Using “Default”
1 Press Menu button, and then press
 or  button until the “Setup”
menu appears.
2 Press  or  button to highlight
the item.
3 Press Enter button to confirm, it
will reset to restore factory default
settings.
When display “Make sure set
Default?” Menu, you can press 
or  button move cursor to “OK”,
then Press “Enter” button. After
that, a confirmation message will
pop up.
Note: Just reset the items in the setup menu don’t include the protected-items
(Needs pin code enter, such as password) and properties such as skipped channel,
channel name.
34
◆ Using the TV Menu(Analog)
Note:
TV menu is only for TV input source mode, thus it is not available in other input
source mode.
■ Using the “Tuner Mode”
1 Press Menu button, and then press
 or  button until the “TV”
menu appears.
2 Press  or  button to highlight
the item.
3 Press  or  button to choose
“Air” or “Cable”.
4 Press Menu or Exit button to
return.
■ Using the “Searching”
1 Press Menu button, and then press
 or  button until the “TV”
menu appears.
2 Press  or  button to highlight
the item.
3 Press Enter button to confirm.
4 Press Menu or Exit button to
return.
■ Using the “TV”
1 Press Menu button, and then press
 or  button until the “TV”
menu appears.
2 Press  or  button to highlight
the item.
3 Press  or  button to select the
channel number.
4 Press Menu or Exit button to
return.
35
Operating Instructions
■ Using the “Channel Skip”
1 Press Menu button, and then press
 or  button until the “TV”
menu appears.
2 Press  or  button to highlight
the item.
3 Press  or  button to “On” or
“Off”, when select “On” the channel
is skipped.
4 Press Menu or Exit button to
return.
■ Using the “Channel Name”
1 Press Menu button, and then press
 or  button until the “TV”
menu appears.
2 Press  or  button to highlight
the item.
3 Press Enter button to confirm, it
will display “Channel Name” list.
4 Use , ,  or  button for
select, and move cursor to “OK”,
then press Enter button for confirm
you selection. If you want to cancel
this operation, move cursor to
“Cancel” and press Enter button
for close this setting.
5 Press Menu or Exit button to
return.
Note: It will be invalid if the current
source is not TV.
■ Selecting Channel
1 Press CH +/- button on the remote control to search the channels, the channel
numbers will increase or decrease by 1 for each pressing excluding the
skipped channels.
2 Press number buttons 0~9 to select the corresponding channel content. If the
channel number is bigger than 9, just press the two number buttons
successively. If the channel number is bigger than 100, just press the three
number buttons successively. The time interval should not exceed 2 seconds.
36
3 If the channel number you pressed is bigger than the maximum channel
number that the setting is permitted, the channel will be changed by you
pressed two number buttons.
■ Channel Preview
Press Recall button to switch between present channel and previous channel. (Only
for DTV or TV input source.)
Hot keys:
- You can also press Recall button on the remote control.
◆ Using the Geometric Menu
Note:
If your current input source is “VGA”, push Menu button enter into this menu. It is
not available in other input source mode.
■ Using “Contrast”
1 Press Menu button on the remote
control, and then press  or 
button until the “Geometric” menu
appears.
2 Press  or  button to highlight
the item.
3 Press  or  button to adjust.
4 Press Menu or Exit button to
return.
■ Using “Brightness”
1 Press Menu button, and then press
 or  button until the “Geometric”
menu appears.
2 Press  or  button to highlight
the item.
3 Press  or  button to adjust.
4 Press Menu or Exit button to
return.
37
Operating Instructions
■ Using “Color Temperature”
1 Press Menu button, and then press
 or  button until the “Geometric”
menu appears.
2 Press  or  button to highlight
the item.
3 Press  or  button to select one
of “Cool”, “Middle”, “Warm” or
“User” for the balance of back light.
4 Press Menu or Exit button to
return.
If you select the item of “User”, a status
bar below comes up for you to adjust
the color temperature to you desirable
value.
■ Using “Auto Setting”
1 Press Menu button, and then press
 or  button until the “Geometric”
menu appears.
2 Press  or  button to highlight
the item.
3 Press Enter button to confirm.
4 Press Menu or Exit button to
return.
Note:
This item will auto-adjust the picture display.
■ Using “Phase”
1 Press Menu button, and then press
 or  button until the “Geometric”
menu appears.
2 Press  or  button to highlight
the item.
3 Press  or  button to adjust.
4 Press Menu or Exit button to
return.
38
■ Using “Manual Clock”
1 Press Menu button, and then press
 or  button until the “Geometric”
menu appears.
2 Press  or  button to highlight
the item.
3 Press  or  button to adjust.
4 Press Menu or Exit button to
return.
■ Using “Display Adjustment”
1 Press Menu button, and then press
 or  button until the “Geometric”
menu appears.
2 Press  or  button to highlight
the item.
3 Press Enter button to confirm for
sub-selection as shown in the table
below.
4 Press Menu or Exit button to
return.
Table of Parental Setting
Items
Description
Horizontal
Position
Use “” to “” to select it.
Use “” to “” to move the image left or right.
Vertical
Position
Use “” to “” to select it.
Use “” to “” to move the image up or down.
39
Operating Instructions
◆ Using the DTV Menu(Digital)
Note:
DTV menu is only for DTV input source mode, thus it is not available in other input
source mode.
■ Using the “General” Menu
✿Using the “Audio Language” item
1 When enter the “General” menu,
select “Audio Language”.
2 Press  or  button to highlight
the “Audio Language” item.
3 Press  or  button to choose
“English”, “Français” or “Español”.
4 Press Menu or Exit button to exit.
✿Using the “Time Zone” item
1 When enter the “General” menu,
select “Time Zone”.
2 Press  or  button to highlight
the “Time Zone” item.
3 Press  or  button to choose one
of “Eastern Time”, “Indiana”,
“Central Time”, “Mountain Time”,
“Arizona”, “Pacific Time”, “Alaska”
or “Hawaii”.
4 Press Menu or Exit button to exit.
✿Using the “SPDIF Type” item
1 When enter the “General” menu,
select “SPDIF Type”.
2 Press  or  button to highlight
the “SPDIF Type” item.
3 Press  or  button to choose one
of “Dolby Digital”, “PCM”, or “OFF”.
4 Press Menu or Exit button to exit.
40
✿Using the “Auto Scan” item
The TV will begin memorizing all of
the available channels. It will takes
about several minutes.
1 When enter the “General” menu,
select “Auto Scan”.
2 Press  or  button to highlight
the “Auto Scan” item.
3 Press Enter button to confirm and
start.
4 Press Menu or Exit button to exit.
✿Using the “Manual Scan” item
The TV will begin memorizing all of
the available channels. It will takes
about several minutes. This option
consists of “Add-on Mode” and
“Range Mode”.
1 When enter the “General” menu,
select “Manual Scan”.
2 Press  or  button to highlight
the “Manual Scan” item.
3 Press Enter button to confirm.
4 Press  or  button to select
“Add-on Mode” or “Range Mode”.
* Add-on Mode: Scan missing
channels.
* Range Mode: Scan with a range of
channels.
5 Press Menu or Exit button to exit.
Note:
- The default is “Add-on Mode”.
- If there is no lost channel at last scanning. The channel found will be 0.
41
Operating Instructions
✿Using the “Channel Skip” item
1 When enter the “General” menu,
select “Channel Skip”.
2 Press  or  button to highlight
the “Channel Skip” item.
3 Press Enter button to confirm and
pop up the “Skip” menu.
4 Press  or  button to select an
item, then press Enter button to
confirm your selection. When item
display ““ , it will skip this
channels.
5 Press Menu or Exit button to exit.
■ Using the “Caption” Menu
✿Using the “Analog Closed Caption”
item
1 When enter the “Caption” menu,
select “Analog Closed Caption”.
2 Press  or  button to highlight
the “Analog Closed Caption” item.
3 Press  or  button to choose
“CC1~CC4”, or “OFF”.
4 Press Menu or Exit button to exit.
42
✿Using the “Digital Closed Caption”
item
1 When enter the “Caption” menu,
select “Digital Closed Caption”.
2 Press  or  button to highlight
the “Digital Closed Caption” item.
3 Press  or  button to choose
“Service1~Service6”, or “OFF”.
4 Press Menu or Exit button to exit.
Note:
- When press CCD button on the
remote control to select digital
closed caption, the OSD menu of
Caption is not synchronization with
hotkey CCD button.
✿Using the “Digital Caption Style” item
1 When enter the “Caption” menu,
select “Digital Caption Style”.
2 Press  or  button to highlight
the “Digital Caption Style” item.
3 Press Enter button to confirm.
4 Press  or  button to choose
“As Broadcaster”, or “Custom”.
5 Press Menu or Exit button to exit.
If you select “Custom”, you can change
these settings.
• Font Size: This option consists of
“Large”, “Small”, and “Medium”.
• Font Color: This option consists of
“White”, “Green”, “Blue”, “Red”,
“Cyan”, “Yellow”,“Magenta”, and
“Black”. You can change the color of
the letter.
• Font Opacity: This option consists of
“Solid”, “Translucent”, and
“Transparent”. You can change the
opacity of the letter.
• Background Color: This option
consists of “White”, “Green”, “Blue”,
“Red”, “Cyan”, “Yellow”, “Magenta”,
43
Operating Instructions
and “Black”. You can change the background color of the caption.
• Background Opacity: This option consists of “Solid”, “Translucent”,and
“Transparent”. You can change the background opacity of the caption.
• Window Color: This option consists of “White”, “Green”, “Blue”, “Red”, “Cyan”,
“Yellow”, “Magenta”, and “Black”. You can change the window color of the
caption.
• Window Opacity: This option consists of “Solid”, “Translucent”,and “Transparent”.
You can change the window opacity of the caption.
■ Setting of “Parental”
The TV programs and movies shown on TV are given a rating signal based on
the following rating systems. To block programs you feel unsuitable for your
children, you need to set the TV for the desired rating systems.
The TV’s “Parental” control feature functions by receiving the rating signal from
your local broadcasting station or cable service provider.
✿Using the “Password” item
1 When enter the “Parental” menu,
press Enter button, then press the
Number buttons (0~9) to enter the
4-digit PIN code, and then press
Enter, it will display the Parental
sub page menu.
2 Press Menu or Exit button to exit.
Note:
The initial password for the system is
“0000”.
If you had forgotten the password please
contact with service centre.
If input the 4-digit PIN is invalid, a message will pop up as side;
44
✿Operate the “Channel Block” as below:
1 When enter the “Channel Block” menu.
2 Press  or  button to select an item.
3 Press Enter button to lock or unlock.
* When it display lock, you can not watch the channels.
* When it display unlock, you can watch the channels.
4 Press Menu or Exit button to exit.
Note:
* When there is more than one channel page:
- To up page, press the Red button.
- To down page, press the Green button.
✿Unlocking channels temporarily
* If you try to watch a TV program that exceeds the “Channel Block” you set, the
TV enters program lock mode. You can either unlock the program temporarily
or select a non-locked program to watch, press CH+/- button to select the
program.
* To temporarily unlock the program, press the Number buttons (0~9) to enter
your 4-digit PIN code.
Password
If the correct code is entered, the program lock mode is released and the normal
picture appears.
■ EPG(Electronic Program Guide)
Your TV has an “Electronic Program Guide” to help you navigate through all the
possible viewing options. The EPG supplies information, such as program lists,
start and end times of all available channels. In addition, detailed information
about the program is often available in the EPG.
(The availability and the amount of program details will vary depending on the
broadcaster.)
a
b
c
d
e
f
g
i
h
45
Operating Instructions
a Current Date and Time: Displays the local date and time.
b Channel List:
Displays the previous channel number, current
channel number, current channel name and next
channel number.
c Program List:
Displays the presenting date, starting time, program
title, lock indicator and closed caption flag of the
programs.(The availability of additional details
depends on the broadcaster.)
d Video:
Displays “Channel Locked!” instead of the video
when the current channel is block.
Displays “Program Locked!” instead of the video
when the current program is block.
e Channel Info:
Displays the channel number and name of the
currently selected channel.
f Program Details:
Displays the starting time, ending time, presenting
date, content advisory of the selected program.
Does not display any data when the current channel
is block.
g Program Description:
Displays the details program descriptions of the
selected program.
h Page Index:
Displays the page index for the program
descriptions.
Displays when the program description is more than
one page.
i Help List:
Displays the function that is enabled.
Hot Key:
You can press EPG button on the remote control to display it.
Note:
* The EPG begins its list with the channel that is currently active.
* The EPG will only work when you are receiving digital channels.
■ Selecting Channel
1 Press CH+/- button to search the channels, the channel number will increase
or decrease by 1 for each pressing excluding the skipped channels.
2 Press number buttons and Dot button to select the corresponding channel
content. The time interval should not exceed 2 seconds. The operation is
shown as below:
13 - 1
Number
buttons
46
Dot
Number
button button
3 How to operate in the “Channel List” menu
- Press Enter button to display the “Channel List” menu.
Channel List
13-1 TV # 1
13-2 TV # 2
Channel Detail
City TV is a contemporary TV station
in Toronto!
13-3 TV # 3
13-4 TV # 4
2-2 PATTERN
4-2 TV # 8
- Press  or  button to select the channel number, and then press Enter
button to display that channel content. You can also press CH +/- button to
select the channel.
- Press Enter button again to display the channel details.
- Press Enter button once to exit the channel details.
■ Channel Preview
Press Recall button to switch between present channel and previous channel.
(Only for DTV or TV input source.)
Hot keys:
- You can also press Recall button on the remote control.
47
Operating Instructions
7. Technical Specification
Product Model:
LCT37SHA
Screen Size:
37” diagonal
Screen Area:
819.6mm(H) x 460.8mm(V)
Aspect Ratio:
16:9
External Size:
925.8mm(W) x 708.0mm(H) x 240.0mm(D) (with Stand)
Net Weight:
xxx kg (with Stand)
Resolution:
1366 (H) x 768 (V) pixels (Each pixel has R/G/B 3 color
cells)
Pixel Dot Pitch:
0.2mm(H) x 0.6mm(V)
Color:
16.7 millions of colors (R/G/B each 256 scales)
Gray Scale:
256 (R/G/B each 8-bit)
High Brightness:
500cd/m2
Contrast (Dark Room):
1000:1 (Typical)
TV System:
NTSC M, ATSC
Sound:
Mono, Stereo, SAP (BTSC)
Sound Effect:
Acoustic Cinema Enhancement
Power Supply:
AC 120V, 60Hz
Power Consumption:
230W
Antenna Input (F Type) x 2 (NTSC & ATSC)
RS-232 (D-Sub 9 Pin Type) x 1 (Only for DTV)
VGA (D-Sub 15 Pin Type) x 1
HDMI (Ver 1.1) connector x 1
Input/Output Terminal:
Component Video - YPbPr x 2 (RCA Terminals)
Video Input (RCA Terminals) x 1
S-Video Input Mini Din 4 Pin Terminal x 1
Stereo, Audio x 5
1 set of Audio Output terminals (RCA, L&R)
SPDIF (Optical) x 1 (Only for ATSC)
Agent System:
UL, cUL, FCC
NOTE:
• The specifications shown above may be changed without notice for quality
improvement.
48
8. Support the Signal Mode
A. D-Sub Mode (VGA)
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
31.50
60.00
37.86
72.81
35.16
56.25
37.90
60.32
48.08
72.19
48.40
60.00
Resolution
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
480i
15.734
59.94
Resolution
640 x 480
800 x 600
1024 x 768
B. HDTV Mode (YPbPr)
480p(720x480)
31.468
59.94
720p(1280x720)
45.00
60.00
1080i(1920x1080)
33.75
60.00
Resolution
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
480p
31.468
59.94
720p
45.00
60.00
1080i
33.75
60.00
C. HDMI Mode
- When the signal received by the Display exceeds the allowed range, a warning
message shall appear on the screen.
- You can confirm the input signal format from the on-screen.
49
Operating Instructions
9. Cleaning Simple Troubleshooting
1 Important:
- Make sure that the power cable is removed from the AC outlet before cleaning
the product.
- Do not use volatile solvent (such as toluene, rosin and alcohol) to clean the
Display. Such chemicals may damage the housing, screen glass and remote
control, and cause the paint to peel.
2 Cleaning of Housing and Remote Control:
- Use a soft cotton cloth for cleaning.
- If the housing or remote control are seriously contaminated, use a soft cloth
moistened with diluted neutral clean the Display. Wring water out of the cloth
before cleaning to prevent water from penetrating into the housing. Wipe the
Display with a dry cloth after cleaning.
3 Cleaning of Screen:
- Use a soft cotton cloth to clean the screen gently.
- The screen glass is very fragile; so do not scrape it with any sharp object. Do
not press or tap the screen to avoid cracking. When the screen is seriously
contaminated, use a soft cloth moistened with diluted neutral cleaner to clean
the Display. Wring water out of the cloth before cleaning to prevent water from
penetrating into the housing. Wipe the display with a dry cloth after cleaning.
4 Simple Troubleshooting:
Use the following check list for troubleshooting when you have problems with
your unit. Contact your local dealer for assistance if problem persist.
SYMPTOMS
POSSIBLE SOLUTIONS
POWER
TV does not operate.
• Make sure the power cord is plugged in.
• Try another Wall outlet.
TV Broadcast reception
Poor sound or No sound.
• Station or Cable TV experiencing problems, tune
to another station.
• Check Volume adjustments.
• Check for sources of possible interference.
• Station or Cable TV experiencing problems, turn
to another station.
Poor picture or No pic- • Check antenna or Cable TV connections, reorient
antenna.
ture.
• Check for source of possible interference.
• Check picture control adjustments.
50
SYMPTOMS
Poor reception on some
channels.
POSSIBLE SOLUTIONS
• Station or Cable TV experiencing problems, tune
to another station.
• Station signal is weak, reorient antenna to receive
weaker station.
• Check for source of possible interference.
• Station or Cable TV experiencing problems, tune
to another station.
Poor color or no color.
• Check picture control adjustments.
• Check antenna or Cable TV connections, reorient
antenna.
• Check for source of possible interference.
Picture wobbles or drifts.
• Station or Cable TV experiencing problems, tune
to another station.
• Cable TV company is scrambling signal.
• Check antenna orientation.
No CATV reception.
• Check all Cable TV connections.
Horizontal or diagonal • Check antenna connections, reorient antenna.
bars on screen.
• Check for sources of possible interference.
TV shuts off.
• No broadcast on station tuned with Auto off
activated.
• Sleep Timer is set.
• Power interrupted.
Display is not shown in
• Select proper language in the menu options.
your language.
Remote Control
• Aim the remote control at the remote sensor.
The remote control does
not function.
• Operate within approx.5 meters or reduce the light
in the room.
• Clear the path of the beam.
• The batteries are weak. Replace the batteries.
• Check the batteries are inserted correctly.
51
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
