Panasonic CRT Television CT 13R18B User manual
PANASONIC CONSUMER ELECTRONICS COMPANY,
DIVISION OF
MATSUSHITA ELECTRIC CORPORATION OF AMERICA
One Panasonic Way
Secaucus, New Jersey 07094
PANASONIC SALES COMPANY,
DIVISION OF
MATSUSHITA ELECTRIC OF PUERTO RICO,
INC., Ave. 65 de Infanteria, Km. 9.5
San Gabriel Industrial Park
Carolina, Puerto Rico 00985
Panasonic Color Television
Limited Warranty
Limited Warranty Coverage
If your product does not work properly because of a defect in materials or workmanship, Panasonic Consumer Electronics
Company or Panasonic Sales Company (collectively referred to as “the warrantor”) will, for the length of the period indicated
on the chart below, which starts with the date of original purchase ("warranty period"), at its option either (a) repair your
product with new or refurbished parts, or (b) replace it with a new or a refurbished product. The decision to repair or replace
will be made by the warrantor.
TV CATEGORIES
9”-21” diagonal
ALL PARTS EXCEPT CRT
1 (ONE) YEAR
LABOR
90 DAYS
CRT
2 (TWO) YEARS
OWNER'S
MANUAL
COLOR TELEVISION
SERVICE
CARRY-IN
During the "Labor" warranty period there will be no charge for labor. During the "Parts" warranty period, there will be no
charge for parts. You must carry-in your product or arrange for in-home service (in-home service available only for 22”
[diagonal] and larger screen), as applicable, during the warranty period. If non-rechargeable batteries are included, they are
not warranted. This warranty only applies to products purchased and serviced in the United States or Puerto Rico. This
warranty is extended only to the original purchaser of a new product which was not sold "as is". A purchase receipt or other
proof of the original purchase date is required for warranty service.
Carry-in or In-Home Service
For Carry-In or In-Home Service (as applicable) in the United States call 1-800-211-PANA(7262) or visit Panasonic Web Site:
http://www.panasonic.com
For assistance in Puerto Rico call Panasonic Sales Company (787)-750-4300 or fax (787)-768-2910.
In-Home service, if applicable, requires clear, complete and easy access to the product by the authorized servicer and does
not include removal or re-installation of an installed product. It is possible that certain in-home repairs will not be completed
in-home, but will require that the product, or parts of the product, be removed for shop diagnosis and/or repair and then returned.
Limited Warranty Limits And Exclusions
This warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER normal wear and
tear or cosmetic damage, nor does it cover markings or retained images on the picture tube resulting from viewing fixed
images (including, among other things, letterbox pictures on standard 4:3 screen TV’s, or non-expanded standard 4:3
pictures on wide screen TV’s, or onscreen data in a stationary and fixed location). The warranty ALSO DOES NOT COVER
damages which occurred in shipment, or failures which are caused by products not supplied by the warrantor, or failures
which result from accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation, set-up
adjustments, misadjustment of consumer controls, improper maintenance, power line surge, lightning damage, modification,
or commercial use (such as in a hotel, office, restaurant, or other business), rental use of the product, service by anyone
other than a Factory Servicenter or other Authorized Servicer, or damage that is attributable to acts of God.
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER "LIMITED WARRANTY COVERAGE". THE
WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF
THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY. (As examples, this excludes damages for
lost time, cost of having someone remove or re-install an installed unit if applicable, or travel to and from the servicer. The
items listed are not exclusive, but are for illustration only.) ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE
WARRANTY OF MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED WARRANTY.
Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an
implied warranty lasts, so the exclusions may not apply to you.
This warranty gives you specific legal rights and you may also have others rights which vary from state to state. If a problem
with this product develops during or after the warranty period, you may contact your dealer or Servicenter. If the problem is not
handled to your satisfaction, then write to the warrantor's Consumer Affairs Department at the addresses listed for the warrantor.
PARTS AND SERVICE (INCLUDING COST OF AN IN-HOME SERVICE CALL, WHERE APPLICABLE) WHICH ARE NOT
COVERED BY THIS LIMITED WARRANTY ARE YOUR RESPONSIBILITY.
J3M11001B U
03/07
ENGLISH
CT-13R18B
CT-13R28W
CT-13R38S
CAUTION
Changes or modifications not expressly approved by the party responsible for compliance with the FCC
Rules could void the user's authority to operate this equipment.
ATTENTION
If you purchase a universal remote control from your local retailer, please contact the remote manufacturer for the required programming code.
TV/CATV MODE SELECTION
When shipped from the factory, the TV/CATV menu option is set to the "CATV" (Cable Television)
mode. If not using CATV, set this menu option to "TV " mode.
For Product Information, Operating Assistance, Literature Request, Dealer Locations, and
all Customer Service inquiries please contact:
1-800-211-PANA (7262), Monday-Friday 9am - 9pm; Saturday-Sunday 10am - 7pm, EST.
Web Site: http://www.panasonic.com
You can purchase parts, accessories or
locate your nearest servicenter by visiting
our Web Site.
Accessory Purchases:
1-800-332-5368 (Customer Orders Only)
Panasonic Services Company 20421 84th Avenue South, Kent, WA 98032
(6 am to 5 pm Monday - Friday; 6 am to 10:30 am Saturday; PST)
(Visa, MasterCard, Discover Card, American Express, Check)
Service in Puerto Rico
Matsushita Electric of Puerto Rico, Inc. Panasonic Sales Company/Factory Servicenter:
Ave. 65 de Infanteria, Km. 9.5, San Gabriel Industrial Park, Carolina, Puerto Rico 00985
Phone (787) 750-4300
Fax (787) 768-2910
Printed in Thailand
ANTENNA/CATV CONNECTIONS
ANTENNA CONNECTIONS
Connect the antenna to the antenna jack.
from Antenna
Single 75 ohm cable
300 ohm twin-lead wire
300-75 OHM MATCHING
TRANSFORMER
(not supplied)
300 ohm twin-lead wire
Single 75 ohm cable
ANT.
Back of TV
COMBINER
(not supplied)
This television has an extended tuning range and can tune
most cable channels without using a cable company
supplied converter box. Some cable companies offer
"premium pay channels" in which the signal is scrambled.
Descrambling these signals for normal viewing requires the
use of a descrambler device which is generally provided by
the cable company.
CATV CONNECTIONS
Incoming CATV
Converter/Descrambler
ANT.
Switch
Splitter
For Subscribers to Unscrambled Basic Cable
with Scrambled Premium Channels
Back of TV
Converter/Descrambler
A B
For Subscribers to Basic Cable TV Service
For Subscribers to Scrambled Cable TV Service
For basic cable service not requiring a converter/
descrambler box, connect the CATV 75 ohm coaxial
cable directly to the antenna jack on the back of the
television.
If you subscribe to a cable service which requires the use of a
converter/descrambler box, connect the incoming cable to the
converter/descrambler box and connect the output of the box to
the antenna jack on the back of the television. Follow the
connections shown left. Set the television to the output of the
converter/descrambler box (usually channel 3 or 4) and use the
converter/descrambler box to select channels.
3M11001B-E
2
5/15/03, 4:35 PM
If you subscribe to a cable service in which basic cable
channels are unscrambled and premium channels require
the use of a converter/descrambler box, you may wish to
use a two-set signal splitter (sometimes called a "two-set
coupler") and an A/B switch box from the cable installer or
an electronics supply store. Follow the connections shown
left. With the switch in the "B" position, you can directly tune
any nonscrambled channels on your TV. With the switch in
the "A" position, tune your TV to the output of the converter/
descrambler box (usually channel 3 or 4) and use the box
to tune scrambled channels.
TQB2AA0490-1
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
dangerous voltage within the product's
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
REDUCE THE RISK OF ELECTRIC
CAUTION: TO
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
WARNING:
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
IMPORTANT SAFEGUARDS
1. READ INSTRUCTIONS- All the safety and
operating instructions should be read before
the unit is operated.
2. RETAIN INSTRUCTIONS- The safety and
operating instructions should be retained for
future reference.
3. HEED WARNINGS-All warnings on the unit
and in the operating instructions should be
adhered to.
4. FOLLOW INSTRUCTIONS- All operating and
use instructions should be followed.
5. CLEANING- Unplug this unit from the wall
outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp
cloth for cleaning the exterior cabinet only.
6. ATTACHMENTS- The manufacturer of this
unit does not make any recommendations for
attachments, as they may cause hazards.
7. WATER AND MOISTURE- Do not use this
unit near water. For example, near a bathtub,
washbowl, kitchen sink, laundry tub, in a wet
basement, or near a swimming pool.
8. ACCESSORIES- Do not place this unit on an
unstable cart, stand, tripod, bracket, or table.
The unit may fall, causing serious injury, and
serious damage to the unit.
PORTABLE CART WARNING
(symbol provided by RETAC)
S3126A
8A. An appliance and cart combination should be
moved with care. Quick stops, excessive
force, and uneven surfaces may cause the
appliance and cart combination to overturn.
9. VENTILATION- Slots and openings in the
cabinet back or bottom are provided for
ventilation, to ensure reliable operation of the
unit and to protect it from overheating. These
openings must not be blocked or covered. The
openings should never be blocked by placing
the unit on a bed, sofa, rug, or other similar
surface. This unit should never be placed near
or over a radiator or heat source. This unit
should not be placed in a built-in installation,
such as a bookcase, or rack unless proper
ventilation is provided or the manufacturer's
instructions have been adhered to.
10. POWER SOURCE- This unit should be
operated only from the type of power source
indicated on the rating plate. If you are not
sure of the type of power supply to your home,
consult your appliance dealer or local power
company. For units intended to operate from
battery power, or other sources, refer to the
operating instructions.
11. GROUNDING OR POLARIZATION- This
unit is equipped with a polarized alternating
current line plug (a plug having one blade
wider than the other). This plug will fit into the
power outlet only one way. This is a safety
feature. If you are unable to insert the plug
fully into the outlet, try reversing the plug. If
the plug still fails to fit, contact your electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the polarized
plug. If your unit is equipped with a 3-wire
grounding-type plug, a plug having a third
(grounding) pin, this plug will only fit into a
grounding-type power outlet. This too, is a
safety feature. If you are unable to insert the
plug into the outlet, contact your electrician to
replace your obsolete outlet. Do not defeat
the safety purpose of the grounding-type plug.
12. POWER-CORD PROTECTION- Powersupply cords should be routed so that they
are not likely to be walked on or pinched by
items placed upon or against them, paying
particular attention to cords at plugs,
convenience receptacles, and the point
where they exit from the appliance.
13. LIGHTNING- To protect your unit during a
lightning storm, or when it is left unattended
and unused for long periods of time, unplug it
from the wall outlet and disconnect the
antenna or cable system. This will prevent
damage to the unit due to lightning and
power line surges.
14. POWER LINES- An outside antenna system
should not be located in the vicinity of
overhead power lines, or other electric light
or power circuits, or where it can fall into
such power lines or circuits. When installing
an outside antenna system, extreme care
should be taken to keep from touching such
power lines or circuits as contact with them
might be fatal.
15. OVERLOADING- Do not overload wall
outlets and extension cords as this can result
in a risk of fire or electric shock.
16. OBJECT AND LIQUID ENTRY- Do not push
objects through any openings in this unit as
they may touch dangerous voltage points or
short out parts that could result in fire or
electric shock. Never spill or spray any type
of liquid into the unit.
17. OUTDOOR ANTENNA GROUNDING- If an
outside antenna or cable system is connected to the unit, be sure the antenna or
cable system is grounded to provide some
protection against voltage surges and built-up
static charges. Section 810 of the National
Electrical Code, ANSI/NFPA 70, provides
information with respect to proper grounding
of the mast and supporting structure,
grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors,
location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
18. SERVICING- Do not attempt to service this
unit yourself as opening or removing covers
may expose you to dangerous voltage or
other hazards. Refer all servicing to qualified
service personnel.
19. DAMAGE REQUIRING SERVICE- Unplug
this unit from the wall outlet and refer
servicing to qualified service personnel under
the following conditions:
a. When the power-supply cord or plug is
damaged.
b. If liquid has been spilled, or objects have
fallen into the unit.
c. If the unit has been exposed to rain or water.
d. If the unit does not operate normally by
following the operating instructions.
Adjust only those controls that are
covered by the operating instructions, as
an improper adjustment of other controls
may result in damage and will often
require extensive work by a qualified
technician to restore the unit to its normal
operation.
e. If the unit has been dropped or the cabinet
has been damaged.
f. When the unit exhibits a distinct change
in performance, this indicates a need for
service.
20. REPLACEMENT PARTS- When replacement
parts are required, be sure the service
technician uses replacement parts specified
by the manufacturer or those that have the
same characteristics as the original part.
Unauthorized substitutions may result in fire,
electric shock or other hazards.
21. SAFETY CHECK- Upon completion of any
service or repairs to this unit, ask the service
technician to perform safety checks to
determine that the unit is in proper operating
condition.
22. HEAT- The product should be situated away
from heat sources such as radiators, heat
registers, stoves, or other products (including
amplifiers) that produce heat.
23. NOTE TO CATV SYSTEM INSTALLER
This reminder is provided to call the CATV
system installer's attention to Article 820-40
of the NEC that provides guidelines for proper
grounding and, in particular, specifies that the
cable ground shall be connected to the
grounding system of the building, as close to
the point of cable entry as practical.
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE
ANTENNA LEAD IN WIRE
GROUND CLAMP
ELECTRIC
SERVICE
EQUIPMENT
GROUNDING
CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
NEC-NATIONAL ELECTRICAL CODE
S2898A
REMOTE CONTROL
Before using the remote control transmitter, batteries must first be installed.
HOW TO INSTALL BATTERIES
Use two "AA" size penlight batteries (supplied)
for the transmitter. The batteries may last
approximately one year depending on how
much the remote control is used. For best
performance, it is recommended that batteries
should be replaced on a yearly basis, or when
the remote operation becomes erratic. Do not
mix old and new batteries or different types.
1. Slide the battery compartment cover.
1
POWER
CH
2
VOL
VOL
7
3
CH
2. Install two "AA" (penlight size) batteries.
3. Replace the battery compartment cover.
BATTERY PRECAUTIONS
These precautions should be followed when
using batteries in this device:
1. Use only the size and type of batteries
specified.
2. Be sure to follow the correct polarity when
installing the batteries as indicated in the
battery compartment. Reversed batteries
may cause damage to the device.
3. Do not mix different types of batteries
together (e.g. Alkaline and Carbon-zinc) or
old batteries with fresh ones.
4. If the device is not to be used for a long
period of time, remove the batteries to
prevent damage or injury from possible
battery leakage.
5. Do not try to recharge batteries not intended
to be recharged; they can overheat and
rupture.
(Follow battery manufacturer's directions.)
POWER SOURCE
TO USE AC POWER SOURCE
Use the AC polarized line cord provided for operation on AC. Insert the AC cord plug into a
standard 120V 60Hz polarized AC outlet.
NOTES:
1. Never connect the AC line cord plug to other than
the specified voltage (120V 60Hz). Use the attached
power cord only.
2. If the polarized AC cord does not fit into a nonpolarized AC outlet, do not attempt to file or cut the
blade. It is the user's responsibility to have an
electrician replace the obsolete outlet.
3. If you cause a static discharge when touching the
unit, and the unit fails to function, simply unplug the
unit from the AC outlet, wait a few minutes, and plug
it back in. The unit should return to normal operation.
4
6
MUTE
R-TUNE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
TV/VIDEO
RECALL
8
9
LOCATION OF CONTROLS
CLOSED CAPTION
WHAT IS CLOSED CAPTIONING?
This television has the capability to decode and display Closed Captioned television programs.
Closed Captioning will display text on the screen for hearing impaired viewers or it will
translate and display text in another language.
EPJ
POWER
VOLUME
CHANNEL
TO VIEW CLOSED CAPTIONS
VIDEO IN AUDIO IN
ACTION
1
Press ACTION and press
then press ACTION.
2
Press ▲ to select CC mode and then press , then press ▲ or ▼
to select desired Closed Caption (e.g. CAPTION CH1), then press
ACTION.
to select the SET UP mode,
OFF
1
2
3
4
5
6
3
1. EPJ (Earphone) Jack - Plug an earphone or monaural headphones with an 1/8 miniplug into
this jack for private listening.
2. Remote Sensor - Signals from the Remote Control unit are received here.
3. POWER - Press to turn the TV on or off.
4. VOLUME / - Press to raise or lower the level of the sound. And also, press to select the
desired setting during On-Screen operations.
ACTION - Press to display the On-screen menu function. And also, press to enter or select
information for On-Screen operations.
5. CHANNEL ▲ / ▼ - Press to select a higher or lower numbered channel set into memory. And
also, press to select the desired setting during On-Screen operations.
6. AUDIO/VIDEO IN Jacks - Audio and video signal cables from an external source can be
connected here.
NOTE:
If needed customer can enter the OSD by pressing VOLUME
same time.
and
2
Press
NOTE:
All four arrows can be used to select the SET UP mode, not just
TIMER
EXIT
LOCK
SET UP
LANGUAGE / IDIOMA / LANGUE
: CABLE
MODE
CC
Press ACTION twice.
This TV is fitted with a V-CHIP controller which provides you with channel viewing access controls
and restrictions. This function allows adult screening of TV programs based upon ratings.
: OFF
/
Press
and then press ▲ or ▼ to select desired language
(e.g. English), then press ACTION.
/ ACTION
AUTO PROGRAM
MANUAL PROGRAM
3
/
SETTING LOCK
SET UP
.
TEXT CH2
• When activating the Closed Captioned Decoder, there will be a short delay before the
Closed Captioned text appears on the screen.
• Closed Captioned text is only displayed in locations where it is available.
• If no caption signal is received, no captions will appear, but the television will remain in
the Caption Mode.
• Misspellings or unusual characters may occasionally appear during Closed Captioning.
This is normal with Closed Captioning, especially with live programs. This is because
during live programs, captions are also entered live. These transmissions do not allow
time for editing.
• When Captions are being displayed, on-screen displays, such as volume and mute may
not be seen or may interfere with Closed Captions.
• Some cable systems and copy protection systems may interfere with the Closed
Captioned signal.
• If using an indoor antenna or if TV reception is very poor, the Closed Caption Decoder
may not appear or may appear with strange characters or misspelled words. In this case,
adjust the antenna for better reception or use an outdoor antenna.
of the front panel at the
to select the SET UP mode, then press ACTION.
TEXT CH1
Text: The Text Closed Caption Mode will usually fill 1/2 of full screen with a programming
schedule or other information. After selecting a Closed Caption Mode, it will stay in effect until
it is changed, even if the channel is changed. If the Captions signal is lost due to a commercial
or a break in the signal, the Captions will reappear when the signal is received again. If the
channels are changed, the Captions will be delayed approximately 10 seconds.
For television programs broadcasting with Closed Captions, look in your TV guide for the
Closed Captions symbol (CC).
This TV can display the channel number, on screen displays and picture adjustments on the
screen in English, Spanish or French.
Press ACTION.
CAPTION CH2
Captions: This Closed Caption Mode will display text on the screen in English or another
language (depending on the setting of the Closed Captions ). Generally, Closed Captions in
English are transmitted on Captions Channel 1 and Closed Captions in other languages are
transmitted on Captions Channel 2.
SETTING LANGUAGE
1
CAPTION CH1
/
/ ACTION
LANGUAGE/IDIOMA/LANGUE
1
2
3
Press ACTION.
TV OPERATION
4
Enter the same password for confirmation only for the first time.
1
2
5
Press ▲ or ▼ to select the V-CHIP option, then press
Press or to select the ON, then press ACTION.
6
Press ▲ or ▼ to select the TV RATING or MOVIE RATING option, then press
7
Press or to select the desired rating for the applicable video or TV channel, then
press ACTION.
ENGLISH
ESPAÑOL
4
Press ACTION to select the EXIT mode, then press
ACTION again.
FRANCAIS
/
/ACTION
NOTE:
If Spanish or French is chosen, the Closed Caption indicators will be in the selected language,
but the Closed Caption text will not be affected by the language selection.
To turn on the TV, press POWER.
The VOLUME can be adjusted to a desired level by pressing VOL (VOLUME)
or
Enter your password (4 digits) using Direct channel selection (0-9).
In the event of entering an incorrect password, press or wait a few seconds to delete
the wrong password.
.
.
The sound level will be indicated on the TV screen by GREEN BARS AND A NUMBER.
As the sound level increases, so do the number of BARS AND THE NUMBER on the
screen. The same is true for decreasing the level.
3
Press ▼ to select the LOCK mode, then press ACTION.
Set the TV/CATV menu option to the appropriate position. When shipped from the
factory, this menu option is in the CATV setting. See "To Memorize Channels".
.
TV RATING
OFF
TV–Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
TV - VHF/UHF channels
CABLE - CABLE TV channels
4
TV-Y : all children
TV-PG : parental guidance
TV-Y7 : 7 years old and above
TV-14 : 14 years old and above
TV-G : children’s program
TV-MA : 17 years old and above
When you select TV-Y7, TV-PG, TV-14 or TV-MA, press RECALL to explain the rating.
Press ▲ or ▼ to select the desired rating you want. Press to select the setting ON or OFF,
then press ACTION.
CH (CHANNEL) ▲ and ▼
Press and release the CH (CHANNEL) ▲ or ▼ . The channel automatically stops at the
next channel set into memory. Press and hold the button down to change channels more
quickly.
For proper operation, before selecting channels, they should be set into the TV's
memory. See "To Memorize Channels".
MOVIE RATING
DIRECT CHANNEL SELECTION (0-9) - Press these buttons to select a channel.The
channel number will appear on the upper right corner of the TV screen. If an invalid
channel number is selected, the display will revert to the previous channel.
TV MODE DIRECT CHANNEL SELECTION - When the TV/CATV menu option is in the
TV position, all channels can be instantly selected by using two buttons (For example, to
select channel 2, press "0", then "2". If you press only "2", channel selection will be
delayed for a few seconds). For channels 10 and above, press the 2 digits in order.
CATV mode direct channel selection
When the TV/CATV menu option is in the CATV position, channels can be selected as
follows:
1-9
Press "0" twice, then 1-9 as needed.
Example, to select channel 2, press "002".
10-12
Press "0", then remaining 2 digits.
Example, to select channel 12, press "012".
13-99
Press the 2 digits in order.
Example, to select channel 36, press "36".
100-125
Press the 3 digits in order.
Example, to select channel 120, press "120".
NOTE: If the station being viewed stops broadcasting, the TV will automatically shut off
after 15 minutes.
3M11001B-E
4
OFF
G
PG
G
: all ages
PG
: parental guidance
PG-13 : parental guidance
for under 13 years old
8
PG-13
R
NC-17
X
: Parental guidance for under 17
years old
NC-17 : 17 years old and above
: adult only
X
R
Press ACTION twice.
NOTES:
• If you forget your password, turn on the TV. Reduce the volume to a minium level. Press and
hold VOLUME on the front of the TV and press the 0 button on the remote control
simultaneously. Select the LOCK mode, then enter a new password.
• If you want to change the password, follow steps 1-3 and select the "CHANGE PASSWORD"
option then enter your new password.
• The V-Chip function is activated only on programs and tapes that have the rating signal.
• Once you block a program using the V-Chip function, the blocked program cannot be watched
based on the content of the show. When the program starts, the "INPUT PASSWORD" will
appear on the screen. When you want to release the V-Chip temporarily, enter the password.
If you change the channel or turn off the TV while the V-Chip function was temporarily
released, the original setting will be resumed. If you return to the channel you were watching
you must re-enter your password to temporarily release your V-Chip function again.
• If you are changing channels using a VCR or a cable box, while the TV remains on channel
3 or 4, the V-Chip operates differently. When you enter your password to temporarily
release the block on any channel, you have completely disabled the V-Chip function for all
stations. To reset the V-Chip turn your TV off and back on.
• Some cable boxes are built with a delay feature, in some cases it can take up to 10 seconds
for a program to appear after the password has been input.
5/15/03, 4:35 PM
TO MEMORIZE CHANNELS
CONNECTION TO OTHER EQUIPMENT
This TV is equipped with a channel memory feature which allows channels to skip up or down to the
next channel set into memory, skipping over unwanted channels.
Before selecting channels, they must be programmed into the TV's memory. In addition to normal
VHF and UHF channels, this TV can receive up to 113 Cable TV channels. To use this TV with an
antenna, set the TV/CATV menu option to the TV setting. When shipped from the factory, this menu
option is in the CATV setting.
The exact arrangement you use to interconnect various video and audio components to the TV is
dependent on the model and features of each component. Check the Owner's Manual provided with
each component for the location of video and audio inputs and outputs.
“TO MEMORIZE CHANNELS” cannot be selected if the AV mode is selected.
Press the TV/VIDEO to select the AV mode to use the TV as a monitor.
Operate your VCR as usual.
TV/CATV SELECTION
1
Press ACTION and press
ACTION.
2
Press ▼ to select MODE mode and then press . Then press
to select the TV or CABLE mode, then press ACTION.
3
The connection diagrams below are offered as suggestions. You may need to modify them to
accommodate your particular assortment of components. The diagrams are intended to show
component video and audio interconnections only.
to select the SET UP mode, then press
TIMER
EXIT
LOCK
SET UP
NOTE:
TV/VIDEO only exists in the remote control.
TV/AV SELECTION
or
SET UP
LANGUAGE/IDIOMA/LANGUE
MODE
: TV CABLE
AUTO PROGRAM
MANUAL PROGRAM
CC
: OFF
Press ACTION twice.
If you connect the TV to a VCR, camcorder or TV
game, through the audio/video in jacks, use the
TV/VIDEO to make your selection.
Press the TV/VIDEO repeatedly to select the
desired mode.
"AUX" will display on the screen for 4 seconds.
/ / /ACTION
NOTE:
Contact your cable company to determine the type of cable system used in your area.
AUTOMATIC CHANNEL MEMORY
2. To connect the TV to a TV Game
The TV can also be used as a display device for
many video games. However, due to the wide
variety of different types of signal generated by
these devices and subsequent hook-up variations
required, they have not all been included in the
suggested connection diagrams. You'll need to
consult each component's Owner's Manual for
additional information.
To Audio/Video OUT
AUX
Front of TV
CHANNEL
1
to select the SET UP mode, then press
Press ACTION and press
ACTION.
SET UP
LANGUAGE / IDIOMA / LANGUE
: CABLE
MODE
AUTO PROGRAM
2
Press ▼ twice to select AUTO PROGRAM mode and then press .
The TV will begin memorizing all the channels available in your area.
3
Press ACTION twice.
(not supplied)
MANUAL PROGRAM
CC
: OFF
/
/
1. To connect the TV to a VCR
/ ACTION
VCR
Front of TV
CHANNEL
VIDEO IN AUDIO IN
3. To connect the TV to a camcorder
To playback from the camcorder, connect the
camcorder to the TV as shown.
To AV OUT Front of TV
jack
CHANNEL
To Audio/
VIDEO
Video OUT
(not supplied)
MANUAL CHANNEL MEMORY
1
to select the SET UP mode, then press
Press ACTION and press
ACTION.
: CABLE
AUTO PROGRAM
3
Select the desired channels to be added or deleted using Direct
Channel Selection (10 keys. 0-9), CH ▲ or ▼.
.
MANUAL PROGRAM
CC
/
TROUBLESHOOTING GUIDE
Before requesting service, please refer to the following chart for the symptom and possible solution.
/ ACTION
SYMPTOMS
ADD
CH 012
Press or to select ADD or DELETE.
If an unmemorized channel was selected (step 3), the channel
indicator will be yellow. Press or if you wish to ADD the
unmemorized channel. The channel indicator will change from yellow
to blue when a channel is added and the channel will be memorized.
If a memorized channel was selected (step 3), the channel indicator
will be blue.
Press or if you wish to DELETE the channel from memory. The
channel indicator will change from blue to yellow when a channel is
deleted.
Repeat Steps 3 and 4 for each channel to be added or deleted.
TV does not operate
Poor sound or No sound
Poor picture or No picture
Poor reception on some
channels
Press ACTION three times.
Poor color or no color
SETTING TIMER
You can set the TV to turn off after a preset amount time.
2
Press ACTION and press
ACTION.
Press
and then press
to select the TIMER mode, then press
Picture wobbles or drifts
TIMER
SLEEP
or
: 10
No CATV reception
to select desired time, then press
/
/ ACTION
ACTION.
After the timer is programmed, the display will disappear then reappear momentarily every
ten minutes to remind you the timer function is operating.
To confirm the timer setting, repeat step 1. The remaining time will be displayed.
To cancel the timer setting, select the OFF.
ADJUSTING PICTURE
Horizontal or diagonal bars
on screen
No reception above
channel 13
No Remote operation
TV shuts off
You can adjust the settings for color, sharpness, contrast, brightness and tint.
1
2
3
Cannot see closed
caption
Press ACTION twice to select the PICTURE mode.
Press ▲ or ▼ to select desired picture, then press
Press
or
(not supplied)
: OFF
/
1
AUDIO
SET UP
MODE
Press ▲ twice to select MANUAL PROGRAM mode and then press
5
.
Display is not shown in
your language
POSSIBLE SOLUTIONS
• Make sure the power cord is plugged in.
• Try another AC outlet.
• Power is off, check fuse or circuit breaker.
• Unplug unit for an hour, then plug it back in.
• Station or CATV experiencing problems, tune to another station.
• Check sound adjustments (VOLUME and MUTE).
• Check for sources of possible interference.
• Station or CATV experiencing problems, tune to another station.
• Make sure channels are set into memory.
• Check antenna or CATV connections, adjust antenna.
• Check for sources of possible interference.
• Check picture control adjustments.
• Station or CATV experiencing problems, tune to another station.
• Make sure channels are set into memory.
• Station is weak, adjust antenna to receive desired station.
• Check for sources of possible interference.
• Station or CATV experiencing problems, tune to another station.
• Make sure channels are set into memory.
• Check picture control adjustments.
• Check antenna or CATV connections, adjust antenna.
• Check for sources of possible interference.
• Station or CATV experiencing problems, tune to another station.
• Make sure channels are set into memory.
• CATV company is scrambling signal.
• Adjust antenna.
• Check all CATV connections.
• Set TV/CATV menu option to the CATV mode.
• Station or CATV system problems, try another station.
• Check antenna connections, adjust or re-direct antenna.
• Check for sources of possible interference.
• Make sure TV/CATV menu option is in the appropriate mode.
• If using antenna, check UHF antenna connections.
• Batteries are weak, dead or inserted incorrectly.
• Remote is out of range, move closer to TV (within 15 feet).
• Make sure Remote is aimed at sensor.
• Confirm there are no obstructions between the Remote and the TV.
• Make sure the power cord is plugged in.
• No broadcast on station tuned.
• Timer is set.
• Power interrupted.
• TV station experiencing problems or program tuned is not closed captioned.
Try another channel.
• Check CATV connection or VHF/UHF antenna, reposition or rotate antenna.
• Select the Closed caption.
• Select proper language in the SET UP mode.
to adjust the setting.
SPECIFICATIONS
COLOR
more vibrant color
TINT
greenish hue
reddish hue
BRIGHTNESS
increase brightness
decrease brightness
increase contrast
makes picture
clearer
decrease contrast
SHARPNESS
reduces color
makes picture softer
AC Power Input:
AC Power Consumption:
Chassis Construction:
Picture Tube:
Horizontal resolution:
Audio Power Output Rating:
Speaker:
Tuner Type:
Remote Control:
Receiving Channels:
TO RETURN TO INITIAL SETTING
Select the NORMAL then select SET as in step2.
Antenna Input Impedance:
Input:
Dimensions:
Weight:
3M11001B-E
VIDEO IN AUDIO IN
LANGUAGE / IDIOMA / LANGUE
2
4
VIDEO IN AUDIO IN
TV GAME
5
120V, 60Hz
54 Watts
IC Solid state
13" (measured diagonally)
260 lines
1.0 Watts
1-1/2"x2-1/2” Full Range, 8 ohm
181 Channel, Quartz PLL Frequency Synthesized
Infrared, Direct Access, 2 x AA batteries (not supplied)
VHF
2-13
UHF
14-69
CATV 1-125
75 Ohm (VHF/UHF/CATV) Coaxial Input
Video: 1.0 Vp-p 75 ohm
Audio: 300 mV, 47k ohm
14-1/8" (W) x 13-15/16" (D) x 13-1/4" (H)
20.9 Ibs
5/15/03, 4:35 PM
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
