Panasonic All in One Printer DA-PC700 User manual

Panasonic All in One Printer DA-PC700 User manual

Digital Imaging System

Operating Instructions (For Printer)

DA-PC700

Options

DA-PM64D (Except Europe)

Before operating this machine, please read these instructions completely and keep these operating instructions for future reference.

English

TRADEMARKS/COPYRIGHTS

The following trademarks and registered trademarks are used throughout this manual.

Microsoft, MS-DOS, Windows, and Windows NT are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

i386, i486, and Pentium are either registered trademarks or trademarks of Intel Corporation.

Adobe, the Adobe logo, Adobe PostScript, Acrobat, Acrobat Reader, and Acrobat logo are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.

Apple, the Apple logo, LaserWriter, Mac, Mac logo, Macintosh, Power Macintosh, and TrueType are either registered trademarks or trademarks of Apple Computer, Inc. in the United States and/ or other countries.

Novell, Novell Client, Novell Directory Services, Novell Distributed Print Services, Netware, intraNetware, NDPS, NDS, , IPX, IPX/SPX, NDS Admin, NDS Administrator are either registered trademarks or trademarks of Novell, Inc., in the United States and/or other countries.

Panasonic Document Imaging Company has made every effort to supply trademark information about company names, products and services mentioned in this documentation. All third party and/or other trademarks identified herein are the property of their respective owners.

Copyright © 2001 by Matsushita Graphic Communication Systems, Inc.

All rights reserved.

Copyright protection claimed includes all forms and matters of copyrightable material and information now allowed by statutory or judicial law or hereinafter granted, including without limitation, material generated from the software programs that are displayed on the screen such as styles, templates, icons, screen displays, looks, etc.

Contents are subject to change without notice.

Printed in Japan.

Preface

Welcome to the DP-6000/7000.*

Written with the new user in mind, these Operating Instructions provide all the necessary information about operating the printer functions, installing the printer drivers as well as the setup and operation when using this machine as a network printer. To get the most out of the machine, please read this manual before using it. This manual is written with the assumption that you are familiar with the basic knowledge and way of using your operating system. Refer to the manuals of these products for information on them.

Note that this manual is written for users operating the DP-6000/7000 with a client computer installed with an English edition operating system only, unless otherwise indicated.

Regarding the maintenance of this machine and copying functions, please see the Operating

Instructions (For Copier).

After reading, keep this manual handy for a quick reference should you encounter any difficulties when using the machine.

In this manual, safety instructions are described with the symbol . Always read and follow these instructions before performing the required procedure.

Reception interference:

When installed at a certain location, the machine may cause interference with radio and television reception. If you notice flickering or distorted images or noises on your audio-visual units, your machine may be causing radio interference. Switch it off, and if the interference disappears, the machine is the cause of radio interference.

Perform the following procedures until the interference is corrected.

• Move the machine and the TV and radio away from each other.

• Reposition or re-orientate the machine and/or the TV and radio.

• Unplug the machine, TV and radio, and replug them into outlets that operate on different circuits.

• Re-orientate the TV and/or radio antennas and cables until the interference stops. For an outdoor antenna, you should ask your local electrician for support.

• Use coaxial cable antennas.

* DP-6000 USA/Canada only.

i

ii

Types of Manuals

The types of manuals available for the DP-6000/7000 are as follows:

Manual bundled with the main unit (i.e. the copier)

• Operating Instructions (For Copier)

Explains the handling of the main unit and the copier functions.

Manuals bundled with the Printer/Scanner Unit

• Operating Instructions (For Printer)

Explains the printer functions, installation/configuration of the printer drivers as well as the setup and operation when using the machine as a network printer.

• Operating Instructions (For Scanner)

Explains the scanner functions and installation/configuration of the scanner driver.

Using These Operating Instructions

Organization

The following is a summary of each chapter:

Chapter 1 Overview of the Printer

Explains some of the main components of the printer, preparations for printing, special features of the printer, network environments, power saver and the contents of the included CD-ROM.

Chapter 2 Setup

Explains the cable connections and the allocation of memory.

Chapter 3 Useful Operations

Explains about printing, cancellation of printing, outputting operations and control panel operations during printing.

Chapter 4 Installing/Configuring the Printer Drivers

Explains how to install/configure the printer drivers.

Chapter 5 Setup for Direct Print Utility

Explains the setup process when using Direct Print Utility to print.

Chapter 6 Setup for TCP/IP (Windows NT/Windows 2000)

Explains the setup process when using TCP/IP protocol to print from a Windows NT/

Windows 2000 machine.

Chapter 7 Setup for Windows Networking

Explains the setup process when using Windows Networking to print.

Chapter 8 Setup for NetWare

Explains the setup process when using Novell NetWare to print.

Chapter 9 Using Internet Printing Protocol

Explains the setup process when using Internet Printing Protocol (IPP) to print.

iii

Chapter 10 Using Internet Services

Explains how to use Internet Services with the printer.

Chapter 11 Setting Print Mode

Explains how to print using emulation mode.

Chapter 12 Printing Reports/Lists

Explains the types of reports/lists and the printing method.

Chapter 13 Configuring by the Tools Mode Screen

Explains the items that can be set from the Tools Mode screen as well as the setting method. Read this when setting up the printer.

Chapter 14 Precautions and Limitations

Explains the precautions and limitations when using the printer functions in general,

NetWare, TCP/IP (LPD), and SMB.

Chapter 15 Troubleshooting

Explains how to solve problems when the printer is not functioning properly. When problems occur, read this first before treating them as breakdowns.

Appendix

Explains the main specifications of the printer functions, the interface connector pins and allocation signals, printing to postcards, printing with overlays, and printing secured print/sample set jobs.

Glossary

Explains the meanings of the terms used in this instructions.

iv

Conventions

Icons used in this manual:

Indicates important information and must be read in detail.

Indicates supplementary information.

Indicates references used in this manual. Manual titles are noted without double quotes while specific sections like "1.9.2 Disabling the power saver mode" are found within double quotes.

Special marks/characters used in this manual:

" " : Double quotes are used to indicate names of files, windows, dialog boxes and input contents e.g. The "Select a Printer" dialog box appears.

Bold face

: Boldface characters refer to window menu items, dialog box items and all kinds of buttons e.g. Click

OK

.

When a checkbox is checked, it indicates ON, otherwise it indicates OFF.

Example: "Image Enhancement" is on.

"Image Enhancement" is off.

The item with the radio button checked is the selected item.

Example: "Millimeter" is selected.

v

vi

Safety Notes

Read these safety notes as well as those of the Operating Instructions (For Copier) before using the printer functions of this machine.

This section describes the graphic symbols used throughout this instructions.

is used to alert operators to an operating procedure, practice or condition that, if not strictly observed, can result in severe injury or loss of life.

is used to alert operators to an operating procedure, practice or condition that, if not strictly observed, might result in safety hazards.

This symbol is used to alert operators to a specific operating procedure that requires close attention. Read and follow instructions carefully to ensure the task is accomplished safely.

This symbol is used to alert operators to a specific operating procedure that must not be performed. Read and follow instructions carefully.

This symbol is used to alert operators to a specific operating procedure that should be emphasised for operating safety. Read and follow instructions carefully.

Heated Flammable Electric

surface shock

Pinched

fingers

Prohibited No fire Do not Do not

tear down touch

Instructions Unplug Ground/Earth

Precaution for power and earth connection

Switch off the machine and host computer before connecting the interface cable. Connecting the cable with a live machine and computers can cause a shock hazard.

Table of Contents

Preface

Types of Manuals

Using These Operating Instructions

Safety Notes

Contents

Chapter 1 Overview of the Printer

1.1

1.2

1.3

1.4

1.5

1.6

1.7

1.8

1.9

Main Components and Their Functions .............................................................................................. 2

1.1.1

1.1.2

Back View ......................................................................................................................... 2

Using the Touch Panel Display ......................................................................................... 3

Getting Ready to Print ......................................................................................................................... 4

Special Features of the Printer ............................................................................................................. 6

Setting Printer Environment ................................................................................................................ 7

Network Printer Environments ............................................................................................................ 8

Setting IP Address for Network Environment ................................................................................... 13

1.6.1

Flow of Setting ................................................................................................................ 13

1.6.2

1.6.3

Using Touch Panel Display for Setting ........................................................................... 14

Checking/Setting DHCP Environment ............................................................................ 17

Setting Port ........................................................................................................................................ 18

1.7.1

Activating Port ................................................................................................................ 18

1.7.2

Other Setting Items .......................................................................................................... 21

Power Saver ....................................................................................................................................... 22

1.8.1

1.8.2

Using the Power Saver Mode .......................................................................................... 22

Automatic Power Saver Mode ........................................................................................ 22

About the included CD-ROM ........................................................................................................... 23

Chapter 2 Setup

2.1

2.2

Connecting Interface Cables .............................................................................................................. 26

2.1.1

Parallel ............................................................................................................................. 26

2.1.2

Ethernet ........................................................................................................................... 27

Memory Allocation ............................................................................................................................ 28

2.2.1

2.2.2

Uses ................................................................................................................................. 28

Suggested Values ............................................................................................................. 28

Chapter 3 Useful Operations

3.1

3.2

Flow of Printing .................................................................................................................................. 30

3.1.1

For Windows ................................................................................................................... 30

3.1.2

3.1.3

Basic Way of Printing ...................................................................................................... 31

Online Help ..................................................................................................................... 31

Checking Job Status .......................................................................................................................... 32

vii

3.3

3.4

3.5

3.6

Cancelling Printing From Printer ...................................................................................................... 33

3.3.1

Cancelling Jobs in Process .............................................................................................. 33

3.3.2

Cancelling Jobs in the Printer .......................................................................................... 34

Forced Outputting .............................................................................................................................. 35

3.4.1

3.4.2

Outputting Waiting Jobs .................................................................................................. 35

Outputting in Emulation Mode ........................................................................................ 36

Switching Printer to Offline .............................................................................................................. 37

Printing vs Copying/Scanning ........................................................................................................... 38

Chapter 4 Installing/ Configuring the Printer Drivers

4.1

4.2

4.3

About the Printer Drivers ................................................................................................................... 44

4.1.1

The PCL 6 Printer Drivers ............................................................................................... 44

4.1.2

4.1.3

Installation/Configuration Methods ................................................................................ 44

Settings on the Printer ..................................................................................................... 44

Installing/Uninstalling the Printer Drivers ........................................................................................ 45

4.2.1

For a Local Printer ........................................................................................................... 45

4.2.2

4.2.3

For a Network Printer ...................................................................................................... 48

Uninstalling the Printer Drivers ...................................................................................... 49

Configuring the Printer Drivers ......................................................................................................... 51

4.3.1

Accessing the Printer Properties Dialog Box .................................................................. 51

4.3.2

Setting the Printer Properties ........................................................................................... 53

Chapter 5 Setup for the Direct Print Utility

5.1

5.2

5.3

5.4

5.5

Using the Direct Print Utility ............................................................................................................ 76

5.1.1

System Configuration ...................................................................................................... 76

5.1.2

5.1.3

Target Computers (Windows 95/98/Me) ......................................................................... 76

Flow of Setup .................................................................................................................. 77

Setup of the Printer ............................................................................................................................ 78

5.2.1

When the LPD Port is Disabled ...................................................................................... 78

5.2.2

Other Settings .................................................................................................................. 80

Installing the Direct Print Utility ....................................................................................................... 81

5.3.1

5.3.2

5.3.3

5.3.4

Overview ......................................................................................................................... 81

Setting the TCP/IP Protocol ............................................................................................ 82

Installation Procedure ...................................................................................................... 83

Setting the Port ................................................................................................................ 85

Status Indication ................................................................................................................................ 88

Uninstalling ....................................................................................................................................... 90

viii

Chapter 6 Setup for TCP/IP (Windows NT/Windows 2000)

6.1

6.2

6.3

Setup for TCP/IP (Windows NT/Windows 2000) ............................................................................. 94

6.1.1

Flow of Setup .................................................................................................................. 94

Setup for the Printer ........................................................................................................................... 95

6.2.1

6.2.2

Setting the LPD Port to Enable ....................................................................................... 95

Other Settings .................................................................................................................. 99

Setup for Windows NT/Windows 2000 ........................................................................................... 100

6.3.1

For Windows NT 4.0/Windows 2000 ............................................................................ 100

Chapter 7 Setup for Windows Networking

7.1

7.2

7.3

7.4

7.5

Introduction ...................................................................................................................................... 102

7.1.1

7.1.2

System Structure ............................................................................................................ 102

Setup Procedure ............................................................................................................. 103

Setting NetBEUI in Printer .............................................................................................................. 104

7.2.1

Activating Port and Setting Protocol ............................................................................. 104

7.2.2

Other Settings ................................................................................................................ 106

Setting TCP/IP in Printer ................................................................................................................. 108

7.3.1

7.3.2

Defining IP Address ...................................................................................................... 108

Activating Port and Setting Protocol ............................................................................. 108

7.3.3

Other Settings ................................................................................................................ 110

Changing Printer and Workgroup Name ......................................................................................... 111

7.4.1

Through Windows Networking ..................................................................................... 111

Auto Driver Downloading ............................................................................................................... 116

7.5.1

7.5.2

Preparation for Auto Driver Downloading .................................................................... 116

Auto Downloading of Printer Driver ............................................................................. 118

Chapter 8 Setup for NetWare

8.1

8.2

8.3

8.4

Using NetWare .................................................................................................................................. 122

8.1.1

System Configuration .................................................................................................... 122

8.1.2

8.1.3

Target Computers .......................................................................................................... 122

Interface ......................................................................................................................... 123

Setup for NetWare ........................................................................................................................... 124

8.2.1

Flow of Setup ................................................................................................................ 124

Setup for the Printer ......................................................................................................................... 125

8.3.1

Setting the Port to Enable .............................................................................................. 125

8.3.2

8.3.3

Other Settings ................................................................................................................ 127

Printing the Printer Settings List ................................................................................... 128

Setup for the Client .......................................................................................................................... 129

8.4.1

Windows 95/98/Me, Windows NT 4.0 or Windows 2000 ............................................ 129

ix

Chapter 9 Using the Internet Printing Protocol

9.1

9.2

Introduction ...................................................................................................................................... 132

9.1.1

9.1.2

System Environment ..................................................................................................... 132

Setup .............................................................................................................................. 133

9.1.3

Other Setting Items ........................................................................................................ 134

Setup of the Printer and Installing the Printer Driver ...................................................................... 135

9.2.1

For Windows 2000 ........................................................................................................ 135

Chapter 10 Using Internet Services

10.1

Using Internet Services .................................................................................................................... 140

10.1.1

Structure of the Internet Services Screen ...................................................................... 140

10.1.2

10.1.3

System Environment ..................................................................................................... 141

Target Host Computers and Browsers ........................................................................... 141

10.2

Configuring Browser ....................................................................................................................... 142

10.2.1

Checking Browsers ........................................................................................................ 142

10.2.2

Checking Proxy Server and Port Number ..................................................................... 143

10.3

Configuring Printer .......................................................................................................................... 144

10.3.1

10.3.2

Activating Internet Service ............................................................................................ 144

Other Internet Service Settings Items ............................................................................ 146

10.4

Activating Browser .......................................................................................................................... 147

10.4.1

Activating Browser ........................................................................................................ 147

10.4.2

Help ............................................................................................................................... 148

Chapter 11 Setting Print Mode

11.1

Print Mode Operation ....................................................................................................................... 150

11.2

PCL 6 Settings ................................................................................................................................... 151

11.2.1

List of PCL 6 Settings Items ......................................................................................... 151

11.2.2

Setting Procedure .......................................................................................................... 156

Chapter 12 Printing Reports/Lists

12.1

Types of Reports/Lists ...................................................................................................................... 160

12.1.1

Types and Paper Sizes .................................................................................................... 160

12.1.2

12.1.3

Printer Settings List ......................................................................................................... 161

Job History Report .......................................................................................................... 163

12.1.4

12.1.5

12.1.6

12.1.7

Error History Report ........................................................................................................ 166

PCL Settings List ............................................................................................................ 168

PCL Fonts List ................................................................................................................ 170

PostScript Fonts List ...................................................................................................... 172

12.1.8

12.1.9

Print Meter Report .......................................................................................................... 174

PostScript Settings List ................................................................................................... 176

12.1.10

Stored Print Job List ........................................................................................................ 178

12.2

How to Print Report/List ................................................................................................................... 180

x

Chapter 13 Configuring by the Tools Mode Screen

13.1

Tools Mode ....................................................................................................................................... 182

13.1.1

13.1.2

Displaying the Tools Mode Screen ................................................................................ 182

Exiting the Tools Mode Screen ..................................................................................... 183

13.2

System/Meter Settings ..................................................................................................................... 184

13.2.1

Common Settings .......................................................................................................... 184

13.2.2

13.2.3

13.2.4

Copy Mode Settings ...................................................................................................... 186

Print/Scan Mode Settings .............................................................................................. 187

Setting Procedure .......................................................................................................... 195

Chapter 14 Precautions and Limitations

14.1

In General .......................................................................................................................................... 198

14.2

On Using NetWare ............................................................................................................................ 200

14.2.1

14.2.2

Setting Printer ................................................................................................................ 200

Setting Server ................................................................................................................ 201

14.2.3

14.2.4

During Printing .............................................................................................................. 202

Using Token Ring interface port * ................................................................................ 202

14.2.5

Others ............................................................................................................................ 202

14.3

On Using TCP/IP (LPD) .................................................................................................................. 203

14.3.1

14.3.2

During Setup .................................................................................................................. 203

During Switching Power On/Off ................................................................................... 203

14.3.3

During Printing .............................................................................................................. 204

14.4

On Using SMB ................................................................................................................................ 205

14.4.1

14.4.2

14.4.3

During Setup .................................................................................................................. 205

During Switching Power On/Off ................................................................................... 205

During Printing .............................................................................................................. 206

Chapter 15 Troubleshooting

15.1

When Problems Occur ...................................................................................................................... 208

15.2

When the Print Quality is Poor ......................................................................................................... 212

15.3

Using Direct Print Utility ................................................................................................................... 216

15.4

Using NetWare .................................................................................................................................. 218

15.4.1

The Printer is not Printing ............................................................................................. 218

15.4.2

15.4.3

When "Switch Off the Power" Appears ........................................................................ 221

Unable to Obtain Desired Print Results ........................................................................ 221

15.4.4

No Notification .............................................................................................................. 222

15.5

Using TCP/IP ................................................................................................................................... 223

15.5.1

15.5.2

When Using Windows 95/98/Me .................................................................................. 223

When Using Windows NT 4.0 ....................................................................................... 224

*May not be available. Please see your Panasonic Authorized representative for details.

xi

15.6

Using SMB ...................................................................................................................................... 225

15.6.1

The Printer is not Found ................................................................................................ 225

15.6.2

15.6.3

Cannot Print ................................................................................................................... 226

Cannot Delete Documents From the Printer Window ................................................... 226

15.6.4

Cannot Perform Auto Driver Downloading .................................................................. 227

15.7

Using Internet Services .................................................................................................................... 228

Appendix

A

B

C

D

Main Specifications .......................................................................................................................... 230

A.1

Specifications of the Printer ............................................................................................ 230

A.2

Printing Area ................................................................................................................... 231

Connectors and Allocation Signal .................................................................................................... 232

Printing Data Combined Using Overlays .......................................................................................... 234

C.1

Creating an Overlay ....................................................................................................... 234

C.2

Printing with an Overlay ............................................................................................... 235

Printing Secured Print and Sample Set Jobs .................................................................................... 236

D.1

D.2

Storing Secured Print/Sample Set Jobs ......................................................................... 237

Printing Secured Print/Sample Set Jobs ........................................................................ 238

Glossary ............................................................................................................................................ 241

Index ................................................................................................................................................. 243

xii

Overview of the Printer

1.1

Main Components and Their Functions .................................................. 2

1.2

Getting Ready to Print ............................................................................ 4

1.3

Special Features of the Printer ............................................................... 6

1.4

Setting Printer Environment.................................................................... 7

1.5

Network Printer Environments ............................................................... 8

1.6

Setting IP Address for Network Environment ...................................... 13

1.7

Setting Port ........................................................................................... 18

1.8

Power Saver......................................................................................... 22

1.9

About the Attached CD-ROM .............................................................. 23

1.1

Main Components and Their

Functions

1

The names and functions of various parts of the machine related to the printer feature are given below.

For other parts, see "1.1 Main Components and Their Functions" of the Operating Instructions (For

Copier) of the same series.

1.1.1

Back View

Parallel interface connector

Connects the printer to a host computer by a Centronics/IEEE 1284-compliant interface cable.

Ethernet interface connector

Connects the printer to network by a twisted pair cable.

Slot for expansion interface

Attaches the optional interface kit for Token Ring.

2

1.1.2

1.1 Main Components and Their Functions

Using the Touch Panel Display

There are buttons on the touch panel display for various operations. Touch these buttons directly to enable the feature to be selected. Read this sub-section together with "1.3 Using the Touch Panel Display" of the Operating Instructions (For Copier).

The buttons displayed on the menu screen are explained below.

1

Menu screen

Select the Menu button on the control panel to display this screen. Select the buttons on this screen to display the respective setting screen.

Scan Mode

Select this button to display the Scan Mode screen for setting the various scan features.

Operating Instructions (For Scanner)

Copy Mode

Select this button to display the Copy Mode screen for setting the various copy features.

Operating Instructions (For Copier)

Retrieve Stored Jobs

Select this button to retrieve the settings registered in the Job Memory to copy or scan.

• Operating Instructions (For Copier)

• Operating Instructions (For Scanner)

Print Report/List

Select this button to print the various reports/ lists on the machine settings.

"Chapter 12 Printing Reports/Lists"

Print Mode

Select this button to set the emulation mode and to set the printer to Online or Offline mode.

"3.4 Forced Outputting",

"Chapter 11 Setting Print Mode"

3

1.2

Getting Ready to Print

1

This section explains the procedure for setting up the printer. The flow of operations is as follows:

Check that the printer is switched off before handling it. If not, there is a danger of electric shock.

Connect the cable and make the necessary settings.

"Chapter 2 Setup"

4

Parallel

Carry out the necessary installation and setup of the host computer.

"Chapter 4 Installing/Configuring the Printer Drivers"

When connecting to the host computer directly

When connecting to a network

1.2 Getting Ready to Print

1

When the printer is used via a network, it is necessary to define settings according to the network environment.

• "1.4 Setting Printer Environment"

• "1.5 Network Printer Environments"

• "1.6 Setting IP Address for Network Environment"

• "Chapter 7 Setup for Windows Networking"

• "Chapter 8 Setup for NetWare"

5

1.3

Special Features of the

Printer

1

The special features of the printer are as follows:

• It supports PCL5e and PCL6 emulations but only PCL6 drivers are provided.

• Printing can be specified without having to take into consideration the printer language as there is an automatic printer language detection feature.

• High quality printing can be achieved with its 600 dpi laser-style resolution.

Also, it comes with an image-enhancement feature which can increase resolution and produce smooth printing without any notches (equivalent to 2,400 dpi).

• Besides the standard parallel interface, it can be used in a network (multi-protocol) environment through the standard network interface for Ethernet. Or an optional Token Ring interface can be installed.*

1

• Ethernet and Token Ring are mutually exclusive i.e. they cannot be used at the same time.

For details on Ethernet, refer to "2.1.2 Ethernet". For details on Token Ring, refer to the manual of the Token Ring kit, Token Ring Board Installation Guide.

• dpi is the abbreviation of Dot Per Inch and is the unit that indicates the number of dots that can be printed within a one-inch area. It is used as a unit indicating resolution.

• Protocol is the essential communication regulation for carrying out data transmission.

* 1. This may not be available. Please see your Panasonic Authorized representative for details.

6

1.4

Setting Printer Environment

Setup the printer environment by following the flow chart below. Check the necessary settings for the printer environment as you proceed. When using AppleTalk, refer to the manuals that come with the PostScript software kit.

1

*1

*2

*3

*4

*5

*6

Refer to "Chapter 7 Setup for Windows Networking"

Refer to "1.6 Setting IP Address for Network Environment"

Refer to "1.7 Setting Port"

Refer to "Chapter 4 Installing/Configuring Printer Drivers"

Refer to "Chapter 8 Setup for NetWare"

Refer to "Chapter 9 Using Internet Printing Protocol"

7

1.5

Network Printer

Environments

1

The DP-6000/7000 series printer can be used as a network printer when connected to the network.

The printer supports multiple protocols. As a result, one printer can be shared even over different network environments.

This section describes the different network environments that be setup for the printer.

Windows Networking (for Windows 95/98/Me, Windows NT 4.0 or Windows 2000)

Server Message Block (SMB) is a protocol for sharing files and/or printers on

Windows 95/98/Me, Windows NT 4.0, and Windows 2000. Print data or settings can be sent directly to the printer on the same network (Ethernet interface) without going through the server when SMB is used.

Activate the SMB port on the printer, select the network printer on each of the operating system (OS) (Windows 95/98/Me, Windows NT 4.0, or Windows 2000), and you can print by just installing the printer. You can use NetBEUI and TCP/IP as the transport protocol for SMB.

"Chapter 7 Setup for Windows Networking" when using Windows Networking.

8

1.5 Network Printer Environments

TCP/IP Direct Print Utility (for Windows 95/98/Me).

The TCP/IP Direct Print Utility is a software which allows print data to be sent directly from a Windows 95/98/Me computer to a printer on the same network

(Ethernet interface) without going through a server.

As the printer supports the TCP/IP (LPD) protocol, the print data can be sent directly and printed from the Windows 95/98/Me computer when using this software. You will need to setup the IP address on the printer and on the Windows 95/98/Me computer.

"1.7 Port Setting"

1

9

1

1.5 Network Printer Environments

TCP/IP (for Windows NT 4.0/Windows 2000)

As the printer supports TCP/IP (LPD) protocol, print data can be sent directly and printed from a Windows NT 4.0/Windows 2000 computer. You will have to setup the

IP address on the printer and on the Windows NT 4.0/Windows 2000 computer. And once the printer on the Windows NT 4.0/Windows 2000 computer is shared, you can also print from other Windows NT 4.0/Windows 2000 or Windows 95/98/Me computer on the network.

"1.7 Port Setting"

10

1.5 Network Printer Environments

AppleTalk (for Macintosh)

As the printer supports AppleTalk protocol, you can print from Macintosh using

EtherTalk.

When using EtherTalk port, refer to the manuals that come with the optional PostScript software kit.

1

NetWare

The printer can be used in an environment using Novell NetWare as a network OS.

"Chapter 8 Setup for NetWare"

11

1

1.5 Network Printer Environments

Internet printing

The printer supports Internet Printing Protocol (IPP). And if Windows 2000 is installed, with the client software needed to output to an IPP printer (IPP port monitor), you can specify the printer supporting IPP from

Add Printer

in the control panel. With this IPP, you can print to a far away printer through the internet or an intranet.

"Chapter 9 Using Internet Printing Protocol"

Token Ring

The printer supports Token Ring. When the printer is installed with the optional interface port for Token Ring, you can use the printer in a network environment with

NetWare or TCP/IP existing alone or together.

When the interface port for Token Ring is installed, the Ethernet interface cannot be used.

Also, the items that can be set are also different. When Token Ring is used, refer to the manuals that come with the Token Ring kit. The Token Ring port may not be available.

Please see your Panasonic Authorized representative for details.

12

1.6

Setting IP Address for

Network Environment

This section describes the necessary settings when installing in a network environment using TCP/IP protocol.

1.6.1

Flow of Setting

Here, we will set the following items:

• IP address

• subnet mask

• gateway address

Setting method

1

13

1

1.6 Setting IP Address for Network Environment

1.6.2

Using Touch Panel Display for Setting

Setting IP address/subnet mask/gateway address

Procedure

Press

Settings/Meter Check

on the control panel and on the screen displayed, select

Tools Mode

.

Enter the access number of the system administrator and touch

Confirm

.

The factory default of the access number is "11111".

Select

Print/Scan Mode Settings

.

14

Select

Network Settings

.

1.6 Setting IP Address for Network Environment

1

Using or , or by using the finger to touch, select

TCP/IP: IP Address

and then touch

Change Settings

.

Select

Specify Address

.

• The IP address will be displayed when there is a DHCP environment.

• The IP address will be set as Auto Obtain (DHCP) for factory settings.

15

1

1.6 Setting IP Address for Network Environment

Using the keypad on the control panel, enter the IP address.

Once three digits are entered, it will move to the next bit automatically. To move to the next bit when less than three digits are entered, touch

Enter/Next

.

Once the input is completed, touch

Save

.

If necessary, enter the subnet mask and gateway address.

Touch

Close

to display the screen at Step .

Touch

Exit Tools

.

The machine will be rebooted.

16

1.6.3

1.6 Setting IP Address for Network Environment

Checking/Setting DHCP Environment

As Windows NT/Windows 2000 can activate Dynamic Host Configuration Protocol

(DHCP), the printer can obtain address information from the DHCP server when there is a Windows NT/Windows 2000 computer on the network.

When in a DHCP environment, use the Windows Internet Name Service (WINS) server at the same time.

If you are not sure if you have a DHCP environment, follow the procedure below to check.

If the DHCP environment has been set up, you do not need to input the IP address as it will be automatically set.

If the DHCP environment is not set up, set the IP address by following the procedure in

"1.6.2 Using Touch Panel Display for Setting".

Procedure

Print out the Printer Settings List by referring to "12.2 How to Print Report/List".

When the following addresses under

Communication Settings

are obtained:

(

TCP/IP

:)

IP Address

,

Subnet Mask

,

Gateway Address

;

(

WINS

:)

Primary WINS Server Address

,

Secondary WINS Server

Address

:

The DHCP server and WINS server are operating. The printer IP address is set by the DHCP server. The name listed in

Host Name

of

SMB

in the printer settings list is registered in the WINS server.

When the following addresses under

Communication Settings

are not obtained:

(

TCP/IP

:)

IP Address

,

Subnet Mask

,

Gateway Address

;

(

WINS

:)

Primary WINS Server Address

,

Secondary WINS Server

Address

:

There are no DHCP server and WINS server. Set the IP address manually by referring to "1.6.2 Using Touch Panel Display for Setting".

When the following addresses under

Communication Settings

are obtained:

(

TCP/IP

:)

IP Address

,

Subnet Mask

,

Gateway Address

; but the following addresses are not obtained: (

WINS

:)

Primary WINS Server

Address

,

Secondary WINS Server Address

There is no WINS server. Do not use the DHCP environment as the printer cannot be used due to a change in the IP address allocated to the machine. Set the IP address manually by referring to "1.6.2 Using Touch Panel Display for

Setting".

1

17

1.7

Setting Port

1

After setting or checking the IP address, activate the port to be used and the UDP agent. This section describes the procedure to set the LPD port to Enable (factory setting: Enable) as well as the UDP agent to

On (factory setting: On) as we will be using remotely controlled software like Auto Configuration.

• Refer to "Chapter 7 Setup for Windows Networking" when using SMB port and to "Chapter 8 Setup for NetWare" when using NetWare port.

• Refer to the manuals that come with the PostScript software kit when using EtherTalk port.

1.7.1

Activating Port

Activate the LPD port by using the touch panel display based on the following procedure:

Procedure

Press the

Settings/Meter Check

button on the control panel and on the screen displayed, touch

Tools Mode

.

Enter the access number of the system administrator and touch

Confirm

.

The factory default of the access number is "11111".

18

1.7 Setting Port

Select

Print/Scan Mode Settings

.

Select

Port Settings

.

Select

LPD

.

Select

Port Status

and then touch

Change Settings

.

Although the default setting of Port Status is Enable, we display the Disable setting here for illustrating this procedure of activating the port.

19

1

1

1.7 Setting Port

Select

Enable

.

When the IP address has not been entered using Specify Address (factory setting: using Auto Obtain (DHCP)), the screen for setting the IP address will be displayed when LPD is set to Enable. Enter the IP address on the IP address setting screen.

Select

Save

.

Select

Close

twice.

Select

Network Settings

.

Select

Agent: UDP Start Up

and then touch

Change Settings

.

20

Select

Enable

and then touch

Save

.

1.7 Setting Port

1

1.7.2

Select

Close

to return to the screen of Step 4.

Select

Exit Tools

.

The machine will be rebooted.

Other setting items

If necessary, define the settings for the following items related to LPD. However, there is no need to change the factory setting of these items under normal conditions.

• LPD Print Mode

• LPD PJL Switch

• LPD TBCP Filter

• LPD Connection Time-Out

• LPD Spool

(Factory setting: PCL*)

(Factory setting: On)

(Factory setting: Enable)

(Factory setting: 16 sec)

(Factory setting: Hard Disk spool)

Refer to "Chapter 13 Configuring by the Tools Mode Screen". These items can also be set using Internet Services. Refer to "Chapter 10 Using Internet Services" for information on

Internet Services.

• * If the optional PostScript software kit is installed, factory setting will be Auto.

• With LPD, you can store the print data output from the application in the spool file of the printer temporarily to be processed for printing. Set the spool mode by using the LPD spool of the receive buffer capacity.

Spool mode:

The mode which stores print data output from the application in the spool file of the printer temporarily to be processed for printing. You can choose to save the spool file in either the RAM disk which uses the printer memory or the hard disk connected to the printer. As the processing of print data after spooling will be done in the printer, the application in the client is released sooner. Requests from multiple clients can be processed at the same time.

Non spool mode:

The mode which processes printing while the print data output from the application is being received by the printer. When the printer is processing printing request from a client, printing request from other clients cannot be received.

21

1.8

Power Saver

1

1.8.1

Using the Power Saver Mode

Power saver is a feature to help reduce the power consumption of the machine to save power.

Procedure

Press the "Power Saver (On/Off)" button on the control panel.

The display will become completely black and the "Power Saver (On/Off)" button will be lit.

Depending on the state of the printer, both the "Communicating" and "Job in

Memory" indicators may be lit.

To disable the power saver mode, press the lit "Power Saver (On/Off)" button.

The "Power Saver (On/Off)" button will be unlit and the Power Saver mode is off.

When the machine receives a print job, it will automatically exit the Power

Saver mode.

1.8.2

Automatic Power Saver Mode

Even when the "Power Saver (On/Off)" button is not pressed, the machine will automatically switch to a waiting mode if it is left switched on without being used for a certain period of time. This is called the Auto Power Saver mode which consists of the following two modes:

• Low Power Mode: the state where the temperature of the heater is lowered.

• Sleep Mode: the state where the power of the heater is off and power can be saved most.

The machine will automatically enter the Low Power Mode after a certain period of time and then switch to the Sleep mode after another lapse of time. During these two modes, the display will become completely black and the Power Saver (On/Off) button lit.

Once the lit "Power Saver (On/Off)" button is pressed, it will become unlit and the power saver mode will be disabled.

For details on setting the Power Saver and preventing the Power Save mode to enter Sleep

Mode, refer to Time-Out and System Setup of "13.2.1 Common Settings".

For the DP-6000/7000 without the printer installed, the Power Saver mode is different. For details, refer to "1.5 Saving Power" and "6.1 List of Custom Preset Functions " of the

Operating Instructions (For Copier).

22

1.9

About the Attached

CD-ROM

The files included in the CD-ROM are as follows:

CD-ROM for the printer kit: "PCL6 Printer Driver, Utilities & Documentation"

• PCL6 (PCL 6 printer drivers)

(for Windows 95/98/Me, Windows NT 4.0, Windows 2000)

• DP (Direct Print Utility)

(for Windows 95/98/Me)

• SCN (Network Scanner Utility)

(for Windows 95/98, Windows NT 4.0, Windows 2000)

• ACROBAT (Adobe Acrobat Reader)

(for Windows 95/98, Windows NT 4.0, Windows 2000)

• Manual (in pdf format):

Printer.pdf: "Operating Instructions (For Printer)";

Scanner.pdf: "Operating Instructions (For Scanner)"

• Readme.txt

If you cannot install the software from the CD-ROM directly, copy the contents to a floppy disk first before carrying out the installation.

1

23

This page is intentionally left blank.

Setup

2.1

Connecting Interface Cables ................................................................ 26

2.2

Memory Allocation .............................................................................. 28

2.1

Connecting Interface Cables

2

When connecting the printer to a host computer directly, use the parallel interface.

When connecting the printer to the network, use the Ethernet or the (optional) Token Ring interface.

This printer can be connected to the parallel and Ethernet interface at the same time. It can receive print data from all the connected interfaces.

When connecting the interface cable, switch off the power supply to prevent electric shock.

When the optional Token Ring interface is connected to the printer, you cannot use the Ethernet interface.

And as a result, the EtherTalk port cannot be used either.

When using the optional Token Ring, refer to the manuals of the Token Ring kit.

2.1.1

Parallel

The procedure for connecting to the parallel interface is as follows:

When connecting the printer to a host computer using parallel interface, you need parallel interface cable that is IEEE 1284 compliant and less than six (6) feet long or a one that is shielded. For details, contact your local authorized Panasonic service representative.

Switch off the power supply of the printer and the host computer.

Insert the interface cable connector to the parallel interface connector and secure it by the wire clips on both sides.

Connect the other end of the interface cable to the host computer.

Switch on the power supply.

If necessary, define the following settings:

• Print Mode

• PJL Switch

• Auto Eject Time

• Bi-directional Communication

(Factory setting: PCL*)

(Factory setting: On)

(Factory setting: 30 seconds)

(Factory setting: Enable)

"Chapter 13 Configuring by the Tools Mode Screen" for details on each of the items and the way to set them.

• For normal usage, there is no need to change the factory settings of all the items except the bi-directional protocol.

• * If the optional PostScript software kit is installed, factory setting will be Auto.

26

2.1.2

2.1 Connecting Interface Cables

Ethernet

The Ethernet interface supports the following types of cable:

• 100Base-TX (Twisted Pair Cable)

• 10Base-T (Twisted Pair Cable)

The Ethernet interface cannot be installed together with the Token Ring interface.

The procedure for connecting to the Ethernet interface is as follows:

Switch off the power supply of the printer.

Connect the interface cable to the Ethernet interface connector.

Use an interface cable that is suitable for your network connection.

Switch on the printer.

2

When the printer is connected to a 100Base-TX/10Base-T connector, and you want to fix the transmission speed of either connector, or you want to specify printer settings for the environment used, refer to "Chapter 13 Configuring by the Tools Mode Screen" for details.

27

2.2

Memory Allocation

2

This section explains how to allocate memory.

2.2.1

Uses

Memory is meant for the following uses:

• System

• Receive buffer

• Page buffer

• PCL memory

Suggested Values 2.2.2

System use

Area used by the printer system, with the capacity remaining unchanged.

Receive buffer use

A receive buffer is prepared for each of the multiple ports so as to receive data from the ports. The various types of buffer are as follows:

• Parallel receive buffer

• SMB spool

• LPD spool

• IPP spool

• NetWare receive buffer

• AppleTalk receive buffer

When you are not using the parallel interface, stop the port, and allocate memory for other uses.

For the NetWare receive buffer, the default value is usually sufficient.

For the AppleTalk receive buffer, it is recommended that as many areas are maintained as possible.

Page buffer use

Area for drawing the actual print image. It is possible to allocate this area from the remaining area after all the other uses have been allocated. To confirm the page buffer capacity, print the Printer Settings List and then check the page buffer capacity. If the page buffer is too small, it will affect the performance and 2 sided printing may be rejected.

28

PCL memory use

Area for the use of PCL. This memory is used to store the interim data for creating the print image. By increasing the memory capacity, the printing speed may be increased.

The memory capacity is 2.50 to 32.00 MB in increments of 0.25 MB. The default is

5.0 MB.

Useful

Operations

3.1

Flow of Printing ................................................................................... 30

3.2

Checking Job Status ............................................................................ 32

3.3

Cancelling Printing From Printer ........................................................ 33

3.4

Forced Outputting ................................................................................ 35

3.5

Switching Printer to Offline ................................................................ 37

3.6

Printing vs Copying/Scanning ............................................................. 38

3.1

Flow of Printing

3

3.1.1

For Windows

The basic flow of printing from a Windows environment after installing the printer driver is as follows:

(This may differ according to the host computer and system configuration used.)

Activate application software used by the host

device

Refer to the manual of the application regarding its operation.

If necessary

Operate menu

Before sending print data from the client computer, check the following:

(1) Port status in Tools Mode>Printer/Scan Mode Settings>Port Settings

(the enabled port is highlighted)

(2) Print mode of the port in Port Settings>(selected port)>Print Mode

"Chapter 13 Configuring by the Tools Mode Screen"

Specify printing from application software

Refer to the manual of the application regarding its operation.

If necessary

Stop printing

"3.3 Cancelling Printing From Printer"

If necessary

Output

"3.4 Forced Outputting"

End

30

3.1.2

3.1.3

3.1 Flow of Printing

Basic Way of Printing

The basic way of printing is as follows.

For details, refer to the online Help in the printer driver.

The way to display the printer properties dialog box differs according to the application used. Refer to the manual of the respective application.

From the File menu, select

Print

.

Check that the correct printer is used at the

Name list box, and then click

Properties

.

Click the Paper/Output tab.

If necessary, define the various settings on this tab.

If necessary, define the settings on other tabs.

Click

OK

.

Online Help

Refer to the online Help for explanation on each of the printer driver items and on the operation during printing.

"4.3 Configuring the Printer Drivers" for details on the printer driver items.

Click the "?" at the top right corner of the window of the printer driver screen.

With the mouse pointer having an "?" attached, click on top of the item which you need an explanation.

The explanation will be displayed in a pop-up window.

Click anywhere on the screen to close the

3

31

3.2

Checking Job Status

3

The status of jobs stored in the memory can be checked by pressing the button,

Job Status Stop

on the control panel.

You can also check the job status of the printer using Internet Service.

Procedure

Press

Job Status Stop

on the control panel.

The Job Status screen is displayed.

Check the job status and touch

Close

.

To check the detailed contents, touch the job directly by your fingers.

• Select to display jobs that you are looking for and to return to the previous screen, select .

• To check the contents of Scan Job and Mailbox, see the Operating

Instruction (For Scanner).

• If Output Waiting Jobs is selected, jobs with "Print Wait" messages can be output when the print preparation is complete. If Output Waiting Jobs cannot be selected, wait awhile before trying again.

Check the contents and touch

Exit

.

32

3.3

Cancelling Printing From

Printer

To cancel a print job in process, cancel it from the host computer first. When you are not able to do so, choose one of the following operations to be done from the printer.

• 3.3.1 Cancelling Jobs in Process

• 3.3.2 Cancelling Jobs in the Printer

If printing is to be cancelled from the host computer, refer to the manual of the application software used.

3.3.1

Cancelling Jobs in Process

Procedure

Press the button,

Stop

on the control panel or select

Stop

on the screen.

The printer will be stopped temporarily.

3 or

Press the button,

Clear C

on the control panel.

The job will be erased and printing stopped. However, the page that is being printed will be printed completely and then output.

Printing can be cancelled from the Job Status Check screen.

See "3.3.2 Cancelling Jobs in the Printer".

33

3

3.3.2

3.3 Cancelling Printing From Printer

Cancelling Jobs in the Printer

The procedure to cancel jobs that are stored in the printer is as follows:

Once this operation is carried out, the data will be erased.

Procedure

Press

Job Status Stop

on the control panel.

The Job Status screen is displayed.

Touch the job that you need to cancel directly with your finger on the Job Status screen.

Select to display the jobs that you are looking for and to return to the previous screen, select .

Select

Stop

from the screen displayed.

Jobs in process will be stopped temporarily. Jobs in waiting will have a "The print job in the print queue will be deleted. Are you sure?" confirmation screen displayed.

34

To cancel jobs in process, press the button,

Clear C

on the control panel. For jobs in waiting, select

Yes

on the confirmation screen.

For all the jobs that you want to cancel, repeat Steps to .

3.4

Forced Outputting

This section explains about forced outputting which consists of the following two types:

• 3.4.1 Outputting Waiting Jobs

• 3.4.2 Outputting in Emulation Mode

3.4.1

Outputting Waiting Jobs

Procedure

Press the button,

Job Status Stop

on the control panel.

The Job Status screen is displayed.

Select

Output Waiting Jobs

on the Job Status screen.

Jobs with "Print Wait" message can be output when the they are ready to print.

3

If Output Waiting Jobs cannot be selected, wait awhile before trying again.

35

3

3.4.2

Outputting in Emulation Mode

Procedure

Press the button,

Job Status Stop

on the control panel.

3.4 Forced Outputting

On the Job Status screen displayed, touch with your finger directly on the job displayed with "Data Wait" message.

Select to display the jobs that you are looking for and to return to the previous screen, select .

From the screen displayed, select

End Receive Data

.

Printing starts.

When there are jobs that are being printed or that are waiting to be printed, printing will start only when the processing of these jobs is completed.

36

3.5

Switching Printer to Offline

Select

Print Mode

from the Menu screen to switch the printer to offline.

Once

Offline

is selected, the printer will not be able to receive data. Also, data that is being transmitted will be interrupted and cannot be printed.

Select

Online

for the printer to resume receiving of data.

Menu screen

3

Select

Print Mode

37

3.6

Printing vs Copying/

Scanning

The touch panel display will be as follows during printing or transmission.

When

Exit

is selected on the screen displayed, the next copying/scanning operation can be programmed ahead without disrupting the current printing operations.

3

The following table explains about the relationship between the printing function and the copying/ scanning function.

Control Panel Operations

Defining the copy/scan settings

Select

Press

Exit

during printing

Interrupt

during printing

Printer Actions

Cannot print but can receive printing instructions from computers.

After a certain time has passed after the settings, the document sent by the computer will be printed.

During copying/scanning, printing cannot be done. After these jobs are completed, documents sent by the computer will be printed in the order received.

Copying/scanning operations can be programmed ahead without disrupting the current printing operation.

Printing will be stopped temporarily and the copy/scan functions can be used. However, printing instructions can be received from the computers. When

Interrupt

is pressed again to exit the interrupt mode, printing will restart. Even during the interrupt mode, the print processing will start if no operations are carried out after a certain time*. Documents sent by the computer will be printed according to the order received.

* : This time setting is done from the Tools Mode screen. See "Chapter 13 Configuring by the Tools

Mode Screen" for details on the setting method.

38

This page is intentionally left blank.

This page is intentionally left blank.

This page is intentionally left blank.

This page is intentionally left blank.

Installing/

Configuring the Printer

Drivers

4.1

About the Printer Drivers ..................................................................... 44

4.2

Installing/Uninstalling the Printer Drivers ............................................ 45

4.3

Configuring the Printer Drivers ............................................................ 51

4.1

About the Printer Drivers

4

This section gives an overview of the printer drivers.

4.1.1

4.1.2

4.1.3

The PCL 6 Printer Drivers

The PCL 6 printer drivers are installed on Windows operating systems to provide a standard interface between an application program and the printer. By installing these printer drivers, print jobs are converted into the PJL and PCL 6 printer languages and then printed through the printer device.

These printer drivers are system specific, each will only run on either Windows 95/98/

Me, or Windows NT 4.0/Windows 2000. There are altogether two different printer drivers provided:

• PCL 6 printer driver for Windows 95/98/Me

• PCL 6 printer driver for Windows NT 4.0/Windows 2000

Installation/Configuration Methods

The methods of installing/configuring these different printer drivers as well as the procedures for printing using these drivers are basically the same. Regardless of the operating system (OS) you are using, the basic steps are similar except for the look of some of the dialog boxes. Only one printer driver will be used to discuss these operations in this chapter but any differences among these drivers will be pointed out.

Settings on the Printer

Make sure the PJL switch for the interface is turned to

ON

. If the PJL switch is turned to

OFF

, the following functions will be disabled:

• Collate

• Staple

• Punch

• Image Enhancement

To turn the PJL switch:

1. Select

Settings/Meter Check

on the control panel of the printer.

2. Select

Tools Mode

in LCD display.

3. Select

Print/Scan Mode

Setting.

4. Select

Port

Settings.

5. Select

IPP

.

And you can reach to the

PJL

Switch.

44

4.2

Installing/Uninstalling the

Printer Drivers

This section describes the procedure for installing and uninstalling the printer drivers.

Two methods of installation are described here, one for a local printer and the other for a network printer. If you have installed an earlier version of the printer driver, uninstall it first by following the procedure in 4.2.3 before installing the new version.

You can also use the Add Printer Wizard to install the printer driver. Refer to ReadMe in CD-ROM (PCL

Printer Driver, Utilities & Documentation) for more details.

4.2.1

For a Local Printer

Local printer refers to a printer that is directly connected to your computer.

Procedure

Start Windows 95, Windows 98, Windows Me, Windows NT 4.0 or Windows 2000.

In this example, we will install the PCL 6 driver on the Windows 98 OS.

Click

Start

and select

Run

.

The "Run" dialog box appears.

Insert in the "PCL Printer Driver, Utilities & Documentation" CD-ROM and enter "E:\Driver_PCL6\Win9x_Me\Setup\Setup.exe" on the Run dialog box.

Then click

OK

.

In this example, we assume that drive E is the CD-ROM drive. Enter the appropriate letter for your CD-ROM drive.

The "End User Licence Agreement" dialog box appears.

Read through the licence agreement carefully. If you have no objections to it, click on the checkbox for "I accept the terms of the above Licence Agreement" and then click

Next

.

4

45

4

4.2 Installing/Uninstalling the Printer Drivers

The "Printer Installation" dialog box appears.

Check the printer model and then click

Next

.

The "Available Platforms" dialog box appears.

Choose

Yes

or

No

in "Do you want to share this printer on the network?".

Then click

Next

.

The "Printer Installation" dialog box appears.

Determine the Port and Printer Name.

Then click

Next

.

46

4.2 Installing/Uninstalling the Printer Drivers

The "Ready to Start Copying" dialog box appears.

Click

Finish

to continue.

After the installation is completed, the following "Installation Successful" dialog box appears.

For Windows 95/98/Me For Windows NT 4.0/Windows 2000

To restart the system, click

Restart Windows Now

.

To exit the installation, click

Exit to Windows

.

To configure the printer driver, click

Printer Setup

(for the Windows 95/98/

Me driver) or

Printer Properties

and

Document Defaults

(for the Windows

NT 4.0/Windows 2000 driver).

"4.3 Configuring the Printer Drivers" for details on configuring the printer driver.

• You must restart Windows in order for the driver to work properly.

• You may run the "Setup.exe" program to install the Windows 95/98/Me printer driver as an alternate driver on the Windows NT/Windows 2000 server (workstation) after you have installed the printer driver for Windows

NT 4.0/Windows 2000. In this case, as there is no need to restart Windows, click Exit to Windows. When downloading the alternate Windows 95/98/Me driver installed in Windows NT/Windows 2000, on the Windows 95/98/Me client computer, use the "Add Printer Wizard" dialog box.

4

47

4

4.2 Installing/Uninstalling the Printer Drivers

4.2.2

For a Network Printer

Network printer refers to printer that is connected to your computer through a network.

Procedure

Follow Steps to of "4.2.1 For a local printer" to display the "Printer

Installation" dialog box.

Click

Add Network Port

.

The "Add Network Printer Port" dialog box appears. Select the network printer from

Network Neighborhood

and then click

OK

.

If you do not know the network address of the network printer, consult your system administrator.

The "Printer Installation" dialog box showing the network path of the network printer appears.

Click

Next

.

48

Follow Steps to of "4.2.1 For a local printer" to complete the installation procedure.

4.2.3

4.2 Installing/Uninstalling the Printer Drivers

Uninstalling the Printer Drivers

For drivers installed by the "Setup.exe" program, use the "Unsetup.exe" program to uninstall.

For Windows 95/98/Me alternate drivers installed in Windows NT/Windows 2000 server

(workstation), use the "Unsetup.exe" program to uninstall the Windows 95/98/Me drivers and then activate the "Unsetup.exe" program of the Windows NT/Windows 2000 driver.

To uninstall the alternate drivers downloaded using the "Add Printer Wizard" dialog box at the client computer, open the "Printers" window and erase the applicable printer icons.

Procedure

Click

Start

and select

Run

.

In the "Run" dialog box displayed, click

Browse.

In this example, we will uninstall the PCL 6 driver on the Windows 98 OS.

Insert in the "PCL Driver/Network Utility (Windows)" CD-ROM and select the

CD-ROM drive in the "Browse" dialog box.

Next, select (Driver_PCL6\Win9x_Me\Setup) Unsetup.exe from the CD-ROM and click

Open

to close the "Browse" dialog box.

When uninstalling any driver, remember to use the "Unsetup.exe" program of the correct driver and of the same version as the "Setup.exe" program used for installation.

The path for the unsetup program appears in the "Run" dialog box.

Click

OK

to continue.

The following "Printer Uninstall" dialog box appears.

Check the printer model and then click

Next

.

4

The following "Ready to Start Deleting" dialog box appears.

49

4

4.2 Installing/Uninstalling the Printer Drivers

Click

Finish

to continue.

When the uninstallation is completed, click

Restart Windows Now

to ensure that the driver is completely removed from the system.

50

4.3

Configuring the Printer

Drivers

This section describes how to configure the printer driver from the printer properties dialog box.

This dialog box will appear if you click

Printer Setup

(for the Windows 95/98/Me drivers) or

Printer Properties

(for the Windows NT 4.0/Windows 2000 drivers) on the "Installation

Successful" screen. If you have quit the printer setup program, follow the procedure in "4.3.1

Accessing the Printer Properties Dialog Box" to display this dialog box.

The printer properties dialog box includes many tabs for you to set up the printing conditions, such as "Printer" and "Paper/Output". You will need to specify the appropriate options on the "Printer" tab first before the other tabs. If not, the other tabs may not show options appropriate to your machine.

For the Windows NT 4.0/Windows 2000 drivers: You have to define settings on the "Printer" tab from this printer properties dialog box before accessing the

document default

dialog box (for the

Windows NT 4.0 driver) or

printing preferences

dialog box (for the Windows 2000 driver) to define the other properties.

For details of all the different properties, refer to "4.3.2 Setting the Printer Properties".

4.3.1

Accessing the Printer Properties Dialog Box

For Windows 95/98/Me

Click

Start

, select

Settings

, followed by

Printers

.

The "Printers" window appears.

Select "Panasonic DP-6000/7000" printer icon.

Select

Properties

from the "File" menu to display the "Properties" dialog box.

4

51

4

4.3 Configuring the Printer Drivers

For Windows NT 4.0/Windows 2000

Accessing the printer properties dialog box

Follow Steps and of the procedure for Windows 95/98/Me to select the

Panasonic DP-6000/7000 printer icon.

Select

Properties

from the "Printer" menu to display the following "Properties" dialog box.

Define the Printer settings for the PCL 6 driver.

For Windows NT 4.0

For Windows 2000

Accessing the document defaults/printing preferences dialog box

Follow Steps and of the procedure for Windows 95/98/Me to select the

Panasonic DP-6000/7000 printer icon.

Select

Document Defaults

(

Printing Preferences

for Windows 2000) from the

"Printer" menu to display the following document default/printing preferences dialog box to define settings on the other tabs.

For Windows 2000: You can also click the "Printing Preference" button on the

"General" tab of the printer properties dialog box to display the printing preferences dialog box.

52

4.3.2

4.3 Configuring the Printer Drivers

Setting the Printer Properties

Through the printer properties (and document default/printing preference) dialog box, the printer driver will provide an interface for you to ensure that the driver settings match those of the physical printer and to select printer option settings for the different properties.

The settings made here will be the default printer configuration for printing the subsequent job.

Although an application may change the page setup each time a job is printed, it will not affect these default settings. Changes to these configurations can only be made through these dialog boxes.

Before listing the different properties of each tab, here is a summary of them:

Printer

Settings here include the printer hardware options installed (e.g. High Capacity Feeder and

Finisher) and other printer settings that are not configured frequently, like Error Report,

Select Substitution Tray, Bypass Feed Orientation, and Job Owner Settings.

(for Windows NT 4.0/Windows 2000 drivers: Device Halftoning)

Paper/Output

This property controls several aspects of how the printer works with paper and how it handles a print job. Settings include Job Type, Paper Size, Paper Source, Output

Destination, Image Orientation, 2 Sided Print and number of Copies.

Output Options

Includes settings on how the printed output is to be processed. Settings include Collate,

Staple Position, Punch Position, and if you want the First Sheet from a different tray.

(for Windows NT 4.0/Windows 2000 drivers: EMF Spooling)

Graphics

Settings contained here control the quality of printed output as well as how the graphics and TrueType fonts will be processed and printed.

(for Windows NT 4.0/Windows 2000 drivers: Halftone Color Adjustment)

Overlays

Allows you to create, use and delete page overlays for the printer.

Layout

This property provides six job finishing features to modify the printed layout: Multi-Up,

Booklet Creation, Fit To Output Size, Zoom, Logical On Physical, and Poster.

Watermarks

A Watermark is a light image printed in the background on a page. The PCL 6 driver allows text (as watermark) to be printed in the background or foreground and placed across the first page or all pages of a document. This property dialog allows you to create, delete and modify such watermarks.

4

53

4.3 Configuring the Printer Drivers

Printer

4

The "Printer" tab defines two main types of settings: the current hardware configuration of the printer (

Paper Source Options

and

Paper Output Options

) as well as other printer settings that are not configured frequently. The hardware options installed to your printer must be correctly indicated here. You can simply click

Auto

Configure

to display the correct hardware option settings.

Paper Source Options

Specify the optional paper source that can be attached to your printer other than the standard tray.

Multi-Tray

(This Option is not available)

High Capacity Feeder

(default condition: off)

Select this if your printer is installed with the High Capacity Feeder. The printer image display on the "Paper/Output" tab will be updated once this is selected.

• If High Capacity Feeder is not checked, Tray 6 (High Capacity) will not be available for Paper Source on the "Paper/Output" tab.

Paper Output Options

Specify the optional paper output devices that can be attached to your printer for additional capacity over the standard tray.

Finisher

(default condition: off)

Select this if your printer is installed with this the finisher.

If Finisher is not checked, Finisher Tray 1 and Finisher Tray 2 will not be available for

Output Destination on the "Paper/Output" tab.

54

4.3 Configuring the Printer Drivers

Error Report

Specify whether or not errors are to be reported when printing a PCL 6 job. Options include:

• No Reporting

The printer will not generate any error report.

• Error Page (default)

Error page will be printed when the printer encounters an error in printing the job.

Select Substitution Tray

Specify the output action when the tray with the paper size specified by the print job is not found. Options include:

• Use Printer Settings (default)

Paper will be fed according to the printer settings.

• Use Bigger Size (No Zoom)

The next bigger size to the specified paper size will be used for outputting the job without adjusting the image size and position. However, if a larger paper size is not available, a smaller paper size will be used.

• None (Abort Job)

The print job will be aborted.

Bypass Feed Orientation

Specify the orientation of the paper to be loaded in the bypass tray. Options include:

• Landscape Setting (default)

• Portrait Setting

Even when Portrait Setting has been selected, some paper sizes need to be loaded and fed only in landscape orientation because of the bypass tray specification.

Device Halftoning

(for Windows NT 4.0/Windows 2000)

Click to display the "Device Color/Halftone Properties" dialog box to define the color and halftone properties for the printing device.

Job Owner Settings

Click to display the Job Owner Settings dialog box to define the job owner name, which is required by the printer to generate the Print Volume Report. The name can be entered in 1 to 31 characters. If you do not specify the name, the printer will use the user's login name.

Auto Configuration

Click to automatically display the correct hardware options (

Paper Source Options

and

Paper Output Options

) instead of manually specifying each device option. The driver will detect the configuration of your printer through the network and automatically set up these options. Once the printer has been configured automatically, the printer network address will be displayed on the tab, right below

Error Report

.

To use this feature, you will need to activate the SNMP Agent at the printer.

You may be prompted to select either Broadcast or Printer Network Address to search, and either TCP/IP or IPX as the protocol to search for the printer network address in some cases.

Restore Defaults

Restore the settings in the dialog box to their default values.

55

4

4.3 Configuring the Printer Drivers

Paper/Output

4

For Windows 95/98/Me For Windows NT 4.0/Windows 2000

The "Paper/Output" tab has option settings that determine the print environment in which a job is printed. Notice that there are image displays of the job type, paper size, image orientation and 2 sided print on the left of these combo boxes, which will change according to the selections made. There is also a display of the printer with clickable image areas of the paper input and output devices. You can either click on these displays or choose from the combo boxes to make selections.

Job Type

Specify the type of job that you want to output. Options include:

• Print (default)

Select this for the usual print job.

• Secured Print

Select this when you want to keep the job in the printer, and to be printed only when requested from the printer control panel.

• Sample Set

Select this when you want to print only the first copy of multiple collated copies as sample. The rest of the copies will be stored in the printer until requested from the printer control panel.

"Appendix D Printing Secured Print and Sample Set Jobs" for details on printing secured print and sample set jobs.

56

4.3 Configuring the Printer Drivers

Paper Size

Specify the paper size to be used. Options include:

• A4 (210

×

297 mm)

• 11

×

17" (Ledger)

• 8.5

×

14" (Legal)

• 5.5

×

8.5" (Statement)

• A3 (297

×

420 mm)

• 8.5

×

11" (Letter) (default)

• A5 (148

×

210 mm)

• B4 (257

×

364 mm)

• B5 (182

×

257 mm)

• 8.5

×

13" (Folio)

• A6 (105

×

148 mm)

• B6 (128

×

182 mm)

• 8K (267

×

388 mm)

• Booklet on Letter

• Booklet on Ledger

• Booklet on A4

• Booklet on A3

You can define your own paper size by clicking the Custom Paper Size button.

Paper Source

Specify the tray to use. Options include:

• Auto (default)

Paper will be automatically selected.

• Tray 1

• Tray 2

• Tray 3

• Tray 4

• Tray 5 (Bypass)

• Tray 6 (High Capacity)

(available only if High Capacity Feeder is selected for Paper Source Options on the

"Printer" tab)

4

57

4

4.3 Configuring the Printer Drivers

The paper sizes available for each paper source are as follows:

Paper Size Auto Tray 1 Tray 2 Tray3/Tray 4 Tray 6

A4

11

×

17"

8.5

×

14"

5.5

×

8.5"

A3

8.5

×

11"

×

×

×

×

×

×

×

A5

B4

×

×

×

B5

8.5

×

13"

A6

B6

×

×

×

×

×

×

×

×

×

×

×

×

Bk

on Letter*

Bk

on Ledger*

× ×

Bk

on A4*

Bk

on A3*

Custom

×

×

×

×

: Not supported; : supported; Bk: Booklet

× ×

×

×

Tray 5 (Bypass) supports all paper sizes, except Booklet on Letter, Booklet on Ledger, Booklet on A4 and Booklet on A3.

• *

not available for any of the paper source if Fit To Output Size or Logical On Physical is selected for Layout Mode on the "Layout" tab.

Output Destination

Specify an output destination. Options include:

• Main Tray (default)

(not available together with any of the finisher trays)

• Finisher Tray 1

(available only if Finisher is selected for Paper Output Options on the "Printer" tab; not available together with the Main Tray)

• Finisher Tray 2

(available only if Finisher is selected for Paper Output Options on the "Printer" tab and Tray 5 (Bypass) is not selected for Paper Source on the "Paper/Output" tab; not available together with the Main Tray)

58

4.3 Configuring the Printer Drivers

Image Orientation

Specify the orientation of the image when printed.

• Portrait (default)

Portrait means the page is printed with the height of the image greater than the width.

• Landscape

Landscape means the page is printed with the width of the image greater than the height.

2 Sided Print

Specify whether you want to print on one or both sides of the paper.

If you are printing on both sides, you have to decide on whether to align to the long or short edge of the paper. Options include:

• 1 Sided Print (default)

Prints only on one side of the paper.

• Flip on Long Edge

Two-sided printing aligned to the long edge of the paper (available only if Tray 5

(Bypass) is not selected for Paper Source on the "Paper/Output" tab).

• Flip on Short Edge

Two-sided printing aligned to the short edge of the paper (available only if Tray 5

(Bypass) is not selected for Paper Source on the "Paper/Output" tab).

Copies

(default: 1)

Specify the number of copies to print. The valid range is 1-999 copies.

Custom Paper Size

Click the Custom Paper Size button to display the Custom Paper Size dialog for defining your own paper size.

Restore Defaults

Restore the settings in the dialog box to their default values.

4

59

4.3 Configuring the Printer Drivers

Output Options

4

60

For Windows 95/98/Me For Windows NT 4.0/Windows 2000

The "Output Options" tab has some advanced features for sending a print job. There is an image display of the Collate Settings which represents the current selection. Clicking this image will toggle both the check box setting and the image display between the collate and uncollate selections. Image displays of the Staple Position and Punch Position will be shown only when they are selected. Each click on these images will select the next item in their combo box and update the image displays as well.

Collate Settings

Specify how you want your document to be arranged.

Collate

(default: on)

Click on the check box to collate or uncollate your documents. Enabled if more than one copy is selected for Copies on the "Paper/Output" tab.

Finishing

Specify where to staple and punch your printed document. The Staple Position and Punch

Position drop-down lists are enabled only if all of the following conditions are met:

(1) Finisher is selected for Paper Output Options on the "Printer" tab;

(2) Finisher Tray 2 is selected for Output Destination on the "Paper/Output" tab;

(3) Collate is selected for Collate Settings; &

(4) Booklet Creation is not selected for Layout Mode on the "Layout" tab.

Staple Position

Specify the staple positions around the paper edge which can be used for stapling:

• None (default)

Staple function off.

• Top Left Corner

Apply one staple at the top-left corner of paper.

• Top Double

Apply two staples at the top edge of paper.

4.3 Configuring the Printer Drivers

• Top Right Corner

Apply one staple at the top-right corner of paper.

• Left Double

Apply two staples at the left edge of paper.

• Right Double

Apply two staples at the right edge of paper.

• Bottom Left Corner

Apply one staple at the bottom-left corner of paper.

• Bottom Double

Apply two staples at the bottom edge of paper.

• Bottom Right Corner

Apply one staple at the bottom-right corner of paper.

The Finisher can staple up to a maximum of 50 sheets.

The paper sizes and positions that can be stapled are as follows:

Size

A3

A4

A5

B4

B5

8.5

×

11"

8.5

×

13"

8.5

×

14"

11

×

17"

Document


Orientation

Top Double

Bottom Double

Left Double

Right Double

Top Left Corner

Top Right Corner

Bottom Left Corner

Bottom Right Corner

Portrait

Landscape

Portrait

Landscape

Portrait

Landscape

Portrait

Landscape

Portrait

Landscape

Portrait

×

×

×

Landscape

Portrait

Landscape

×

Portrait

Landscape

×

Portrait

Landscape

×

×

: Not supported; : supported

×

×

×

×

×

×

The staple positions available for selection may differ according to the document image orientation specified on the printer driver screen. Specify the document image orientation first before selecting the staple position.

4

61

4

4.3 Configuring the Printer Drivers

Punch Position

Specify the punch position around the paper edge which can be used for punching:

• None (default)

• Top

• Bottom

• Left

• Right

The following paper size/orientation can be used for punching.

(long edge) or (short edge) is the edge of the paper which can be punched.

The punch positions available for selection may differ according to the document image orientation specified on the printer driver screen. Specify the document image orientation first before selecting the punch position.

• B5 portrait (long edge)

• A4 portrait (long edge)

• B4 (short edge)

• A3 (short edge)

• 8.5

×

11" portrait (long edge)

• 11

×

17" (short edge)

• For A4, A5, B5, 8.5

×

11", the positions that can be stapled and punched may differ according to the paper orientation. When specifying the staple/punch positions, take note of the orientation of the paper loaded in the tray.

• You cannot specify stapling or punching for documents that are of different paper sizes.

• You cannot specify stapling or punching for paper loaded in the bypass tray.

62

4.3 Configuring the Printer Drivers

First Sheet

Enables you to select for the first sheet of your document, a paper source different from the rest of the output sheets as selected in

Paper Source

on the "Paper/Output" tab. Note that the paper size used for this different paper source must be the same as the rest of the document. Options include:

None

The first sheet will use the same paper source as the rest.

Different Paper Source

Specify the paper source for the first sheet:

• Auto (default)

• Tray 1

• Tray 2

• Tray 3

• Tray 4

• Tray 5 (Bypass)

• Tray 6 (High Capacity)

EMF Spooling

(for Windows NT 4.0/Windows 2000) (default: off)

Specifies the format in which to store printing information on your disk while a job is waiting to be printed. Turning this control on will enable the EMF disk file format.

Otherwise, RAW format will be used. Enabled if

Vector

is selected for

Graphics Mode

on the "Graphics" tab.

Restore Defaults

Restore the settings in the dialog box to their default values.

4

63

4.3 Configuring the Printer Drivers

Graphics

4

64

The "Graphics" tab has option settings that affect the quality of a printed output.

Notice that there is a visual representation of the selected graphics mode. Clicking it will toggle both the radio button setting and the image display between the Raster and

Vector selections.

Graphics Mode

Enables you to optimise graphic printing, increasing speed and quality. Options include:

• Raster

All graphics are sent to the printer as bitmap raster images (i.e. images composed of individual dots). Under this option, the printed output may appear to be a closer match to the screen image than the other mode, but printing is slower.

• Vector (default)

This mode enables images to be printed faster but not all graphic images can be printed under this mode. If the printed graphic images do not appear the same way as they did on your screen, select Raster and reprint your graphic.

Halftone

Halftone refers to a type of pattern that is applied to the printed image. By using a combination of black dots, these patterns produce a grey appearance on the printed image.

This Halftone feature is designed to process images (e.g. photographs) but not computer generated art (e.g. clip art). The appearance of the printed image will be differed by the

Halftone settings. Note the different settings available for the different drivers.

For Windows 95/98/Me:

• Device (default)

Image objects will be rendered by default halftoning attributes.

• Line Art

Provides solid lines and sharp contrasts between shaded areas and is used for images with intricate lines.

4.3 Configuring the Printer Drivers

• Fine

Provides smooth shades of grey.

• Coarse

Provides rough greyscale with high contrasts for images that will be scanned or copied.

• Diffusion

Creates the appearance of greyscales by randomly placing individual dots of ink. Best for photographic images but requires more processing time. Available only if Raster is selected for Graphics Mode.

For Windows NT 4.0/Windows 2000:

• Device (default)

Image objects will be rendered by default halftoning attributes.

Available only if Vector is selected for Graphics Mode.

• System

Image objects will be rendered by the system halftoning. Click Halftone Color

Adjustment for system halftone color adjustment.

Image Enhancement

(default: on)

Click to enhance the quality of the output image.

All Texts to Black

(default: off)

Click to print all colored text in black except white. If this is not selected, colors will be printed in varying degrees of grey. Disabled if Print as Graphics is selected for TrueType

Mode.

TrueType Mode

The driver is capable of downloading the Windows TrueType fonts in three different ways:

• Download as TrueType (default)

Prints text by downloading the complete character set of TrueType fonts in an outline form that the printer can deal with directly. Downloaded fonts are vector-based, scalable typefaces.

• Download as Bitmap

Prints text by downloading each TrueType character as an individual bitmap font.

Downloaded fonts are raster-based, non-scalable typefaces.

• Print as Graphics

Prints text as graphic images. The printed output may appear to be a closer match to the screen image than the other options, though it may print slower.

Enabled only if the Raster is selected for Graphics Mode.

Use Printer TrueType Fonts

(default: on)

When this check box is selected, the printer prints by using the printer-resident fonts instead of by downloading fonts to the printer, unless the required fonts are not present in the printer. This will speed up the printing process and give your printer its best performance. Disabled if Print as Graphics is selected for TrueType Mode.

65

4

4

4.3 Configuring the Printer Drivers

Halftone Color Adjustment

(for Windows NT 4.0/Windows 2000)

Click to display the "Halftone Color Adjustment" dialog box for setting the color adjustment values that are used to adjust the color of bitmap images for printing. Color adjustments affect certain attributes of the image, such as contrast and brightness. Enabled only if System is selected for Halftone.

The "Negative" check box in the "Halftone Color Adjustment" dialog box specifies whether or not the colors of bitmap images are inverted. Inverting colors produces a negative image of the bitmap.

Restore Defaults

Restore the settings in the dialog box to their default values.

Overlays

66

The "Overlays" tab allows you to create, use and delete page overlays for your printer. A

Page Overlay is a group of PCL commands and/or data created, downloaded and stored in the printer by you. Once stored in the printer, a page overlay can be invoked upon request and eliminates the need to download the same information over again, thus saving transmission time.

Load Overlay

When you want to use a file from an external source as an overlay, click this button to inform the overlay manager of the file and its location.

If you source an external file from a floppy disk and then remove the disk from the disk drive, the file will no longer be available as an overlay. If you intend to use this file regularly, it is recommended that you copy the file to your system local disk before using this button.

Create Overlay

Creates and stores a Page Overlay from a file containing the overlay that you want.

"Appendix C Printing Data Combined Using Overlays" for details on creating and printing with an overlay.

4.3 Configuring the Printer Drivers

Delete Overlay

To delete an overlay, select it in the "Overlay" list box, and click

Delete Overlay

. Click

Yes

to confirm deletion or

No

to abort the action.

Delete All

Deletes all overlays from any and all of the destinations.

Query Page Overlay

When this check box is selected, a message box requesting for confirmation will appear whenever a page overlay command is sent to the printer. If this is not selected, the selected page overlay file will be sent directly to the printer.

This option is not active if No Overlay is selected or if the currently selected overlay has been permanently downloaded to the printer.

Selected Overlay status

Displays information on the selected overlay.

Overlay Creation status

Displays information regarding the creation of overlays.

4

67

4.3 Configuring the Printer Drivers

Layout

4

68

For Windows 95/98/Me For Windows NT 4.0/Windows 2000

The Layout property provides six job finishing features for you to modify the printed layout of a document. Notice that an image is displayed for each type of layout mode selected and which also indicates the current page orientation.

Layout Mode

Provides a list of the job finishing options:

Multi-Up (default)

Booklet Creation

Fit To Output Size

Zoom

Logical On Physical

Poster

Selecting each of the features will display one of the following corresponding options:

(1)

Multi-Up

(available when

Multi-Up

is selected for

Layout Mode

)

The Multi-Up function allows more than one document page to be printed on the same physical page.

Pages Per Sheet

(default: 1)

Lists the possible pages per sheet for the Multi-Up printing function: 1, 2, 4, 6, 9, 16.

Page Border

Specify the options of page border to be printed around each document page:

• None (default)

No page border is drawn.

• Grid

A rectangle is drawn to divide each document page.

4.3 Configuring the Printer Drivers

• Shadow

A rectangle with drop shadow effect is drawn around each document page.

Enabled when more than 1 is selected for Pages Per Sheet.

No Rotation on Same Sheet

(default: off)

Specify how Multi-Up document pages of different orientation are to be handled on the same physical page by comparing other document pages with the first document page. When this is not selected, document pages with different orientation from the first document page will be rotated to match its orientation, with minimum size reduction. When this is selected, document pages with different orientation from the first document page will not be rotated but will be scaled down in order to fit into the same physical page. Enabled when more than 1 is selected for Pages Per Sheet.

(2)

Booklet Creation

(available when

Booklet Creation

is selected for

Layout Mode

)

This function allows the document to be printed as a booklet. It ensures that the output sheets when folded and stacked will have the correct page order of a booklet.

When this feature is chosen in

Layout Mode

, the following dialog box will be displayed.

4

Take note of the message and click

OK

to proceed.

Booklet Creation

There are two ways to create a booklet:

• Fit To Paper Size (default)

Each document page is scaled down and printed to fit the booklet output using a defined paper size.

• Use Booklet Paper Size

Special booklet size is used to create the booklet without scaling the document pages. When this is selected, the following sizes are available for selection:

• Booklet on Letter (default)

• Booklet on Ledger

• Booklet on A4

• Booklet on A3

Gutter

(default: 0)

Specify the gap of between 0-150 dots to be created between the two pages on each sheet of paper.

Pages Per Split

(default: No Limit)

Specify the number of pages to be printed as a booklet (4. 8, 12, 16, or No Limit).

69

4

4.3 Configuring the Printer Drivers

(3) Fit To Output Size (available when Fit To Output Size is selected for Layout

Mode)

This function allows document to be printed on a specified paper size that is different from the original page size of the document by scaling the document page to fit onto the specified page size.

Fit to Output Size

(default: A4 (210

×

297 mm))

Lists the possible paper sizes that can be used. The options available are similar to the settings of Paper Size on the "Paper/Output" tab. This function can output to all paper sizes.

(4)

Zoom

(available when

Zoom

is selected for

Layout Mode

)

This function allows enlargement or reduction of each document page to be printed.

Zoom %

(default: 100%)

Define a zoom % of between 50 to 400 % for enlargement (>100 %) or reduction

(<100 %) of your page.

Page Position

Specify the position where the document page is to be printed on the output:

• Top Left

• Top Right

• Center (default)

• Bottom Left

• Bottom Right

(5)

Logical On Physical

(available when

Logical On Physical

is selected for

Layout

Mode

)

This function allows you to print on a paper size that is different from the page size designated for your document, without scaling the page image. You may also specify a page border and/or a position for printing the document page.

Output Size

(default: A4 (210

×

297 mm))

Lists the possible paper sizes that can be used. The options available are similar to the settings of Paper Size on the "Paper/Output" tab.

70

4.3 Configuring the Printer Drivers

Page Position

Specify the position where the document page is to be printed on the output:

• Top Left

• Top Right

• Center (default)

• Bottom Left

• Bottom Right

Page Border

Specify the options of page border to be printed around each document page:

• None (default)

No page border is drawn.

• Shadow

A rectangle with drop shadow effect is drawn around each document page.

(6)

Poster

(available when

Poster

is selected for

Layout Mode

)

This function allows you to enlarge proportionally and print the image of each document across multiple physical pages.

4

Style

Specify the style for outputting the document image (i.e. the number of times of its page size to enlarge):

• 2 x 2

• 3 x 3

• 4 x 4

• Custom

If Custom is selected, a zoom % (from 150 to 400 %) is available for you to define the custom poster style.

Overlap

It allows an overlapped width between 0-150 dots to be created between each enlarged image across different physical pages.

Page Position

Specify the position where the document page is to be printed on the output:

• Top Left

• Top Right

• Center (default)

• Bottom Left

• Bottom Right

Restore Defaults

Restore the settings in the dialog box to their default values.

71

4.3 Configuring the Printer Drivers

Watermarks

4

72

For Windows 95/98/Me For Windows NT 4.0/Windows 2000

This property allows you to create, edit and delete watermarks, which are light images printed in the background on a page.

The procedure to create a watermark is as follows:

Specify the text for the watermark in

Text

(maximum 100 characters).

Select

Fonts

to display the "Font" dialog box and specify the font, font style and size. Font style includes regular, italic, bold and bold italic; size ranges from 6-

900.

Select

Color

to display the "Color" dialog box and specify/create the required color.

Specify the position and angle of the text by adjusting the Angle scrollbar (-90 to

+90 degrees) and the scrollbar just below the preview window* which moves the x and y position values. These position values are in the 1/100ths (0.01) of an inch and are offsets from the page center. To reset the position to the paper origin, press

Center Watermark

.

Click

Add

to add the new watermark to the "Watermark" list.

The procedure to edit a watermark is as follows:

Select an existing watermark from the "Watermark" drop-down list.

Make changes to it as required.

Click

Update

to replace the previous version or

Add

to save a modified version of the watermark.

The procedure to delete a watermark is as follows:

Select an existing watermark from the "Watermark" list.

Click

Delete

to remove the watermark from the list.

4.3 Configuring the Printer Drivers

To print a watermark, the options available include:

In Background

Selecting this prints the watermark underneath the primary texts and graphics in the document. Otherwise the watermark will be printed on top of all images in the document. Disabled if As Outline Only is selected.

First Page Only

Selecting this prints watermark on the first page of the document only. Otherwise the watermark will be printed on all pages.

As Outline Only

Selecting this prints the text outline of the watermark which is always printed on top of all document images. Disabled if In Background is selected.

4

73

This page is intentionally left blank

Setup for the

Direct Print

Utility

5.1

Using the Direct Print Utility .............................................................. 76

5.2

Setup of the Printer .............................................................................. 78

5.3

Installing the Direct Print Utility ......................................................... 81

5.4

Status Indication ................................................................................... 88

5.5

Uninstalling .......................................................................................... 90

5.1

Using the Direct Print Utility

This section explains the operations environment when using the Direct Print Utility as well as the flow of setup.

5.1.1

System Configuration

To use the Direct Print Utility, install the software on Windows 95, Windows 98, or

Windows Me, setup the port and connect the printer to an Ethernet or Token Ring network.

5

5.1.2

Target Computers (Windows 95/98/Me)

The target computers must meet all the following requirements:

• Installed with the English version of Windows 95/98/Me

• IBM PC-AT or compatible computer

• Equipped with Intel CPU (x86 compatible)

• Using TCP/IP protocol in a network environment

• Installed with a printer driver compatible with the printer

• Computer name setup by ASCII characters

• Use only single-byte uppercase/lowercase letters, numbers, hyphen (-) and underscore (_) for ASCII character.

• If non-ASCII characters are used in a computer name, the printer may not print normally. If non-ASCII characters are used, change the computer name in Control

Panel > Network > Identification.

76

5.1.3

5.1 Using the Direct Print Utility

Flow of Setup

Setup for the printer

Set the LPD port to Enable (factory setting: Enable) and define the setting for the protocol to be used by the transport layer.

"5.2 Setting Up the Printer"

Installing the Direct Print Utility

Install the Direct Print Utility on a PC with Windows 95/98/Me OS only.

"5.3 Installing the Direct Print Utility"

Printing

Print from the application that is being used (e.g. Word, Excel). As the printing method differs according to application, refer to the respective manual for information on how to print. Check the selected printer in the application before printing.

77

5.2

Setup of the Printer

5

To use the Direct Print Utility, it is necessary to set the LPD port to Enable (factory setting: Enable).

The protocol to be used by the transport layer for the Windows 95/98/Me OS for the Direct Print

Utility is TCP/IP (factory setting:

Off

).

When setting the port to Enable leads to insufficient memory, a message about the insufficient memory may be displayed on the control panel and the port status may be set to Disable automatically. If this happens, set the ports which are not in use to Disable and change the memory size.

5.2.1

When the LPD Port is Disabled

Follow the procedure below to set the LPD port to Enable and to define the setting of the protocol to be used by the transport layer.

Procedure

Press the

Settings/Meter Check

button on the control panel and select

Tools

Mode

on the screen displayed.

Enter the access number of the system administrator and touch

Confirm

.

The factory setting of the access number is "11111".

78

Select

Print/Scan Mode Settings

.

5.2 Setup of the Printer

Select

Port Settings

.

Select

LPD

.

Select

Port Status

and then touch

Change Settings

.

Although the default setting of Port Status for LPD Port is Enable, we display the Disable setting here for illustrating this procedure of activating the port.

79

5.2 Setup of the Printer

Select

Enable

.

5

5.2.2

Select

Save

.

Restart the machine for the changes of setting to take place.

Other Settings

If necessary, define the setting of the following items on the printer. However, there is no need to change the factory setting of these items for normal use.

• Print Mode

• PJL Switch

• LPD Spool

(factory setting: PCL*)

(factory setting: On)

(factory setting: Hard Disk spool)

* If the optional PostScript software kit is installed, factory setting will be Auto.

"Chapter 13 Configuring by the Tools Mode Screen" for details on the printer setting items.

80

5.3

Installing the Direct Print

Utility

This section describes the installation method for Windows 95, Windows 98 or Windows Me.

5.3.1

Overview

To use Direct Print Utility, it is necessary to set the PC as follows:

Setting the protocol (TCP/IP)

• "5.3.2 Setting the TCP/IP protocol" for details on the setting method.

• The manuals that come with Windows 95/98/Me for details on the setting of the TCP/IP protocol.

Installing the Direct Print Utility software

"5.3.3 Installation Procedure" for details on the installation method.

Setting up the printer

(Installing the printer driver)

If no printer has been set up earlier, it is necessary to add one to the local printer port.

"4.2 Installing/Uninstalling the Printer Drivers" for details on the way to install the printer driver as it is necessary to install a printer driver compatible with the printer during the setting up of the printer.

Setting the Direct Print Utility port

"5.3.4 Setting the Port" for details on the way to set the port.

81

5

5.3 Installing the Direct Print Utility

5.3.2

Setting the TCP/IP Protocol

The protocol needed to setup the Direct Print Utility port is the TCP/IP protocol.

If you try to install the Direct Print Utility without installing the necessary protocol first, the following corresponding dialog box will be displayed:

Follow the procedure below to install the TCP/IP protocol:

The manuals that come with Windows 95/98/Me for details on the way to install the TCP/

IP protocol.

Procedure

Start Windows 95, Windows 98 or Windows Me.

Click

Start

and select

Settings

, followed by

Control Panel

. Double-click the

"Network" icon to display its dialog box.

Click

Add

on the "Configuration" tab dialog.

The "Select Network Component Type" dialog box appears.

Click

Protocol

in the "Select Network Component Type" dialog box. Then, click

Add

.

The "Select Network Protocol" dialog box appears.

Click

Microsoft

in the "Manufacturers" box in the "Select Network Protocol" dialog box.

A list of protocols appears in the "Network Protocols" box.

Click

TCP/IP

.

Then click

OK

.

Click

OK

on the "Network" dialog box.

Restart the system.

82

5.3.3

5.3 Installing the Direct Print Utility

Installation Procedure

The procedure to install the Direct Print Utility is as follows:

Procedure

Start Windows 95, Windows 98 or Windows Me.

Click

Start

and select

Run

to display its dialog box.

Insert in the "PCL Driver/Network Utility (Windows)" CD-ROM and enter

"E:\Utilities\Win9x_Me\Dp\Setup.exe" on the Run dialog box. Then click

OK

.

The "Welcome" dialog box appears.

In this example, we assume that drive E is the CD-ROM drive. Enter the appropriate letter for your CD-ROM drive.

83

5.3 Installing the Direct Print Utility

Read the welcome message carefully and then click

Next

to continue with the installation.

5

If you do not need to change the destination location, click

Next

to continue.

When the installation is completed, a dialog box like the one below appears.

Click on the radio button of "Yes, I want to restart my computer now" and then click

Finish

to complete the installation

Restart the system for the installation to complete.

84

5.3.4

5.3 Installing the Direct Print Utility

Setting the Port

To setup the Direct Print Utility port, a printer must be seup first. If no printer has been setup earlier, it is necessary to add one to the local printer port.

The installation procedure of the Direct Print Utility port is as follows:

Procedure

Double-click the "My Computer" icon, followed by the "Printers" icon. Then doubleclick the icon of the printer for which you will change the port setting. The following window appears.

From the "Printer" menu, click

Properties

.

A dialog box for setting up the printer properties appears.

85

5.3 Installing the Direct Print Utility

Click the "Details" tab.

Click

Add Port

.

The "Add Port" dialog box appears.

5

Click on the radio button for

Other

, followed by the port,

FX TCP/IP DPU Port

and then

OK

.

The "FX TCP/IP DPU Port Setup" dialog box appears.

Enter the port name and IP address by referring to the explanations below.

After all the settings are made, click

OK

.

86

5.3 Installing the Direct Print Utility

Port Name

Enter a name for identifying the printer.

Use only alphanumeric characters in the name. Do not use colon (:) or space.

IP Address

Enter the IP address allocated to the printer. When the DNS (Domain Name

System) has been set, the printer host name can be entered instead.

• IP address consists of four numbers separated by periods, with each value between 0-255 (xxx.xxx.xxx.xxx). If you do not know the IP address of your printer, either ask your system administrator or print out the printer settings list to check.

• After entering the host name, click OK to verify if the host already exists in the network. If the host entered does not exist, setup cannot be done. You can stop the verification process of the host name by clicking Cancel.

87

5.4

Status Indication

After the printer has been set up, a new printer window will be displayed.

This section explains the various items and possible status displayed in the printer window.

5

88

[Document Name]

Name of the print file.

[Status]

Status of the printer.

The various kinds of status listed below will be displayed only when a print job is sent from a PC with a port setup by Direct Print Utility. They will not be displayed if printing is sent from a shared computer via the PC setup with the port to the printer shared over a network.

Printing*

The printer is printing.

Sending

Print data is being sent to the printer.

Unable to print (Network Error)

The printer is unable to print.

Either the power is off or there is a problem in the network.

When Network Error occurs, printing cannot be automatically re-executed.

Unable to print (Spool Error)

The printer is unable to print.

Either disk capacity is insufficient while spooling the file to be printed or an error arises in the spool file.

When Spool Error occurs, printing cannot be automatically re-executed. After solving the problem, printing will be re-executed once the machine is activated.

Deleting

A document is being deleted.

Spooling*

The Print Manager is storing a print file to the memory (hard disk).

Pause

The process of printing or sending is stopped temporarily.

To enable printing to restart, select Pause Printing from the "Document" menu of the

"Printer" window.

5.4 Status Indication

[Owner]

Owner (user who sends print instructions) of the print file.

[Progress]

Total number of pages for a print file. During printing, the number of printed pages will be indicated here.

[Started At]

Time when printing started.

* : This will be displayed by the Windows 95/98/Me spooler, and not the Direct Print Utility.

89

5.5

Uninstalling

5

This section describes the procedure for deleting the Direct Print Utility from Windows 95,

Windows 98, Windows Me.

To delete the Direct Print Utility from the system, carry out the following steps:

Delete all the relevant printer ports: FX TCP/IP DPU Port.

Delete all the related files: FX DPU Port.

Restart the system.

Procedure

Start Windows 95, Windows 98 or Windows Me.

Double-click the "My Computer" icon and the "Printers" icon.

Open the "Properties" dialog box of a printer that uses the relevant printer port

(e.g.FX TCP/IP DPU Port). Click the "Details" tab and change the port setting from the printer port used to another one like LPT1.

Save the new setting by clicking "Apply".

Repeat Step for all other printers that use this printer port.

In any of the "Properties" dialog box of the printers, click

Delete Port

.

A "Delete Port" dialog box appears. Select all the entries of the relevant printer port

(e.g. FX TCP/IP DPU Port) and click

OK

. Make sure all the entries for the Direct

Print Utility Port have been deleted before proceeding to the next step.

90

Click

Start

and select

Settings

, followed by

Control Panel

.

Double-click the "Add/Remove Programs" icon.

Under the "Install/Uninstall" tab, search and select the program to be deleted

(e.g. Fx DPU Port). Then, click

Add/Remove

.

5.5 Uninstalling

A "Confirm File Deletion" dialog box appears.

Click

Yes

.

A "Remove Programs From Your Computer" dialog box appears.

Click

OK

when the uninstall is successfully completed.

A message recommending that you restart your system appears.

Click

OK

and restart the system.

91

This page is intentionally left blank.

Setup for

TCP/IP

(Windows NT/

Windows 2000)

6.1

Setup for TCP/IP (Windows NT/Windows 2000) ............................... 94

6.2

Setup for the Printer ............................................................................. 95

6.3

Setup for Windows NT/Windows 2000 ............................................ 100

7

6.1

Setup for TCP/IP

(Windows NT/Windows

2000)

This section describes the flow of setup for connecting the printer to a Windows NT/Windows 2000 server (workstation) using the TCP/IP protocol. To print in a TCP/IP environment, ensure that the

Windows NT/Windows 2000 server (workstation), client, and printer have been assigned their respective IP addresses to connect to the network. It is necessary to specify at the Windows NT/

Windows 2000 server (workstation), the IP address assigned to the printer using the port settings. A printer driver compatible with the printer must be used for the setup.

6.1.1

Flow of Setup

There are three possible network printer connections when printing from environments using Windows NT/Windows 2000:

[1] From a Windows 95/98/Me client through a Windows NT/Windows 2000 server

(workstation)

[2] From a Windows NT/Windows 2000 server (workstation) directly

[3] From a Windows NT/Windows 2000 client through a Windows NT/Windows 2000 server (workstation)

Unless otherwise indicated, the following flow is applicable to all three connections.

Setup for the printer

Set the LPD port to Enable (factory setting: Enable), the protocol used by the transport layer to

TCP/IP

and enter the IP address.

"6.2 Setup for the Printer"

Setup for Windows NT/Windows 2000

Install the printer for Windows NT/Windows 2000.

For [1] only: Next, install the Windows 95/98/Me driver as an alternate driver in the Windows NT/Windows 2000 server (workstation) if necessary.

"6.3 Setup for Windows NT/Windows 2000"

For [1] and [3] only: Setting up the client

For [1]:

• When the Windows NT/Windows 2000 server (workstation) is installed with an alternate Windows 95/98/Me driver, download the driver using the "Add

Printer Wizard" dialog box. Select

Network printer server

as the printer connection and the printer installed for Windows NT/Windows 2000 in Step

.

• When the Windows NT/Windows 2000 server (workstation) is not installed with an alternate Windows 95/98/Me driver, install the driver using the

"Setup.exe" program from the CD-ROM.

For [3]: Download the Windows NT/Windows 2000 driver using the "Add

Printer Wizard" dialog box, select

Network printer server

as the printer connection and the printer installed for Windows NT/Windows 2000 in Step

. Otherwise, run the "Setup.exe" program from the CD-ROM to install the

Windows NT/Windows 2000 driver.

"4.2 Installing/Uninstalling the Printer Drivers" for details on the

installation of the printer driver.

94

6.2

Setup for the Printer

This section describes the procedure to set the LPD port to Enable (factory setting: Enable).

The protocol used by the transport layer is TCP/IP.

When setting the port to Enable leads to insufficient memory, a message about the insufficient memory may be displayed on the control panel and the port status may be set to Disable automatically. If this happens, set the ports which are not in use to Disable and change the memory size.

6.2.1

Setting the LPD Port to Enable

Follow the procedure below to set the LPD port to Enable. Once the LPD port is enabled, the protocol and the IP address can be set. If necessary, set the subnet mask and the gateway address.

Procedure

Press the

Settings/Meter Check

button on the control panel and select

Tools

Mode

on the screen displayed.

Enter the access number of the system administrator and touch

Confirm.

The factory setting of the access number is "11111".

6

95

6.2 Setup for the Printer

Select

Print/Scan Mode Settings

.

Select

Port Settings

.

Select

LPD

.

7

96

Select

Port Status

and then touch

Change Settings

.

Although the default setting of Port Status for LPD Port is Enable, we display the Disable setting here for illustrating this procedure of activating the port.

6.2 Setup for the Printer

Select

Enable

.

Select

Save

.

Restart the machine for the new setting to take place.

Repeat Steps to .

Select

NetWork Settings

.

Select

TCP/IP: Subnet Mask

and then touch

Change Settings

.

6

97

6.2 Setup for the Printer

Enter the subnet mask using the numeric keypad.

To move to the next bit, touch

Enter/Next

.

When the input is completed, select

Save

.

Repeat Steps to and input

TCP/IP: Gateway Address

in the same way.

Select

Save

until the screen of Step appears.

Select

Exit Tools.

98

6.2.2

6.2 Setup for the Printer

Other Settings

If necessary, set the following settings on the printer. However, the factory setting of these items do not need to be changed for normal use.

• Print Mode

• PJL Switch

• LPD Spool

"Chapter 13 Configuring by the Tools Mode Screen" for details on the printer setting items.

(Factory setting: PCL*)

(Factory setting: On)

(Factory setting: Hard Disk spool)

* If the optional PostScript software kit is installed, factory setting will be Auto.

6

99

6.3

Setup for Windows NT/

Windows 2000

This section describes the procedure for installing the printer driver on Windows NT 4.0/Windows

2000. A printer driver compatible with the printer must be used for the setup.

6.3.1

For Windows NT 4.0/Windows 2000

The PC must be installed with

TCP/IP protocol

(protocol) and

Microsoft TCP/IP

Printing

(service). It is necessary to specify at the Windows NT/Windows 2000 server

(workstation), the IP address assigned to the printer using the port settings.

Manuals that come with Windows NT 4.0/Windows 2000 for details on the installation method.

Procedure

Install the printer driver for Windows NT 4.0/Windows 2000 by running the

"Setup.exe" program. Click

Add Network Port

and select the network printer from

Network Neighborhood

.

"4.2.2 For a Network Printer" for details on the installation of the printer driver.

For printing from a Windows 95/98/Me client through a Windows NT/

Windows 2000 server (workstation):

To share the Windows 95/98/Me printer driver as an alternate driver in the

Windows NT/Windows 2000 server (workstation), install the printer driver for

Windows 95/98/Me into the Windows NT/Windows 2000 server (workstation) by Add Printer Wizard.

"4.2.1 For a Local Printer" for details on the installation of the printer driver.

100

Setup for

Windows

Networking

7.1

Introduction ........................................................................................ 102

7.2

Setting NetBEUI in Printer ................................................................. 104

7.3

Setting TCP/IP in Printer .................................................................... 108

7.4

Changing Printer and Workgroup Name ............................................. 111

7.5

Auto Driver Dowloading ................................................................... 116

7.1

Introduction

Server Message Block (SMB) is a protocol for sharing files and/or printers through the network. It is supported by Windows OS. You can use NetBEUI or TCP/IP as the transport protocol for SMB.

This section explains the operating environment and setup procedure for using SMB. Before setting up SMB, check the following information.

7.1.1

System Structure

SMB operates in an environment where the port is set and the printer connected to the network. It uses NetBEUI or TCP/IP as the transport protocol.

7

• You can use either NetBEUI or TCP/IP, or even both as the transport protocol for

SMB. When setting up the printer, refer to "7.2 Setting NetBEUI in Printer" for details on NetBEUI and to "7.3 Setting TCP/IP in Printer" for TCP/IP.

• You will need to setup the IP address in the computer and printer if you are using

TCP/IP.

102

7.1.2

7.1 Introduction

Setup Procedure

Follow the procedure below to setup the printer for the Windows Networking environment.

Procedure

Setup the port status and transport protocol at the printer.

• When using NetBEUI

From the touch panel display, select Enable for the port status of SMB

(factory setting: Enable), followed by On for NetBEUI (factory setting: On).

"7.2 Setting NetBEUI in Printer"

• When using TCP/IP

From the touch panel display, select Enable for the port status of SMB (factory setting: Enable), followed by On for TCP/IP (factory setting: On).

"7.3 Setting TCP/IP in Printer"

Change the printer and workgroup name.

If necessary, change the SMB setting file, "config.txt" as well as the printer and workgroup name from the host computer.

"7.4 Changing Printer and Workgroup Name"

Install the printer driver to the host computer.

"7.5 Auto Driver Downloading"

7

103

7.2

Setting NetBEUI in Printer

When using NetBEUI for SMB, you have to set the following items from the touch panel display.

• select Enable for port status of SMB (factory setting: Enable)

• select On for NetBEUI as the transport protocol (factory setting: On)

7.2.1

Activating Port and Setting Protocol

Follow the procedure below to activate the SMB port using the touch panel display.

Procedure

Press the

Settings/Meter Check

button on the control panel and select

Tools

Mode

on the screen displayed.

7

Enter the access number of the system administrator and touch

Confirm.

The factory setting of the access number is "11111".

Select

Print/Scan Mode Settings

.

104

7.2 Setting NetBEUI in Printer

Select

Port Settings

.

Select

SMB

.

SMB

Select

Port Status

and then touch

Change Settings

.

Although the default setting of Port Status for SMB Port is Enable, we display the Disable setting here for illustrating the procedure of activating the port.

Select

Enable

.

7

105

7.2 Setting NetBEUI in Printer

Select

On

for

NetBEUI

.

7

7.2.2

Select

Save

twice.

Select

Close

twice and then

Exit Tools

.

The machine will be rebooted.

Other Settings

If necessary, define the settings for the following items at the printer. However, there is no need to change the factory setting of these items for normal usage.

• SMB Print Mode

• SMB PJL Switch

• SMB Spool

(Factory setting: PCL*)

(Factory setting: On)

(Factory setting: Hard Disk spool)

Refer to "Chapter 13 Configuring by the Tools Mode Screen".

• * If the optional PostScript software kit is installed, factory setting will be Auto.

• With SMB, you can store the print data output from the application in the spool file of the printer temporarily to be processed for printing. Set the spool mode by using the

SMB spool of the receive buffer capacity.

Spool mode:

The mode which stores print data output from the application in the spool file of the printer temporarily to be processed for printing. You can choose to save the spool file in either the RAM disk which has used the printer memory or the hard disk connected to the printer. As the processing of print data after spooling will be done in the printer, the application in the client is released sooner. Requests from multiple clients can be processed at the same time.

Non spool mode:

The mode which processes printing while the print data output from the application is being received by the printer. When the printer is processing printing request from a client, printing request from other clients cannot be received.

106

7.2 Setting NetBEUI in Printer

Also, you have to define the following settings if you are using Internet Services:

• Workgroup

• Host Name

• Administrator Name

• Administrator Password

• Administrator Password Check

• Maximum Sessions

• Auto Driver Download

• Unicode Support

• Auto Master Mode

• Encrypst Password

• Printer Language

(Factory setting: ADMIN)

(Factory setting: admin)

(Factory setting: 5)

(Factory setting: On)

(Factory setting: Enable)

(Factory setting: On)

(Factory setting: On)

(Factory setting: English)

Refer to "Chapter 10 Using Internet Services" for details on using Internet

Services.

7

107

7.3

Setting TCP/IP in Printer

When using TCP/IP for SMB, you have to set the following items from the touch panel display:

• define IP address (if the IP address has not been defined)

• select Enable for port status of SMB (factory setting: Enable)

• select On for TCP/IP as the transport protocol (factory setting: On)

7.3.1

7.3.2

Defining IP Address

Refer to "1.6 Setting IP Address for Network Environment" for information on defining the IP address.

Depending on the network environment used, it may be necessary to set the subnet mask and gateway address as well. Discuss with your network administrator on the necessary settings to make.

Activating Port and Setting Protocol

Follow the procedure below to activate the SMB port using the touch panel display.

Procedure

Press the

Settings/Meter Check

button on the control panel and select

Tools

Mode

on the screen displayed.

Enter the access number of the system administrator and touch

Confirm.

The factory setting of the access number is "11111".

108

Select

Print/Scan Mode Settings

.

7.3 Setting TCP/IP in Printer

Select

Port Settings

.

Select

SMB

.

SMB

Select

Port Status

and then touch

Change Settings

.

Although the default setting of Port Status for SMB Port is Enable, we display the Disable setting here for illustrating the procedure of activating the port.

109

7

7.3 Setting TCP/IP in Printer

Select

Enable

.

Select

ON

for

TCP/IP

.

7.3.3

Select

Save

twice.

Select

Close

twice, followed by

Exit Tools

.

The machine will be rebooted.

Other settings

Refer to "7.2.2 Other Settings".

110

7.4

Changing Printer and

Workgroup Name

If necessary, you will need to change the SMB printer and workgroup names. However, you cannot change these names using the printer control panel. Instead, change them from Internet Services or

Windows host computer. This section describes the procedure to change these names from the

Windows host computer.

Refer to "Chapter 10 Using Internet Services" for details on operating Internet Services.

7.4.1

Through Windows Networking

You can change the SMB setting by accessing the file in the printer via the Windows network from the host computer, and then changing the information there. However, only the administrator is allowed to do this.

The procedure below explains how to overwrite the setting file (config.txt) at the first instance. Subsequently, you will need to know the following items that have been set: SMB

Host Name, Workgroup, Administrator Name, and Administrator Password.

The factory setting of Administrator Name and Password of config.txt is both

"admin".

Procedure

Open

Network Neighborhood

from the Windows client computer, followed by

Workgroup

(factory setting: Workgroup) and then the printer.

The factory setting of the host name of the printer is "FX-xxxxxx" (where xxxxxx is the last three bytes of the Ethernet address of the printer). You can confirm the name by referring to Host Name of SMB on the Printer Settings

List.

Double-click the admintool folder.

The following dialog box will be displayed.

• For Windows 95/98/Me

7

• For Windows NT 4.0/Windows 2000

111

7.4 Changing Printer and Workgroup Name

For Windows 95/98/Me, enter only the password (SMB Administrator

Password) and for Windows NT 4.0/Windows 2000, enter the user name (SMB

Administrator Name) and password (SMB Administrator Password). Then, click

OK

. The admintool folder will be opened.

The factory setting of both Administrator Name and Password is "admin".

Using a text editor like Memo, open

config.txt

.

If necessary, change the workgroup and host name, and then overwrite and close config.txt.

• The workgroup and host names can be set up to 15 bytes.

• For details on config.txt, refer to next page, "Setting format of config.txt".

The message.txt file is created inside the admintool folder.

Open

message.txt

and check that it displays the following information.

If message.txt is not displayed, select Refresh from the "View" menu. If an error message appears, check the contents that have been set again.

Close

message.txt

.

Switch off the printer, and wait for at least five seconds before switching it on again.

112

7.4 Changing Printer and Workgroup Name

Setting format of config.txt

Item

Printer Language

Host Name

Workgroup

Remarks

Language to be used.

Host name of the printer

Name of workgroup of printer

Value

Japanese/

English

Factory Setting

English

Maximum

15 bytes

FX-xxxxxx

(xxxxxx: last 3 bytes of the printer MAC address)

WORKGROUP Maximum

15 bytes

On/Off On

On/Off On

Disk/Memory/ Off

Off

NETBEUI

TCP/IP

Spool

Activation of NetBEUI protocol

Activation of TCP/IP protocol

Activation of spool function.

Can select from Disk, Memory, and Off.

If Disk is not recognised when it is selected, it will become Off.

Max Spool Size The maximum receive buffer size during spooling.

Can be set in 256 Kbyte units.

Max Receive Buffer The maximum receive buffer size during non-spooling.

Can be set in 32 Kbyte units.

Auto Driver Download Activation of the automatic downloading of printer driver.

PJL

Print Mode

Activation of PJL

Set the printer language.

Auto Master Mode

Encrypt Password

512 - 32768

(unit: Kbyte)

64 - 1024

(unit: Kbyte)

Enable/Disable

1024 Kbyte

256 Kbyte

Enable

On/Off On

AUTO/PS/PCL AUTO

On Activation of the automatic browse On/Off master feature.

No available when WINS Server is designated.

Activation of the encrypt password feature.

On/Off On

Time Zone

Summer Time

Set the time zone in units of minutes.

Set the period of summer time

-720 to 720 540 mins

(unit: minutes) (Japan) hour-start-end

(h-hhddmmhhddmm)

113

7

7.4 Changing Printer and Workgroup Name

Item Remarks Value

Maximum Sessions Maximum connections of printer.

3 - 10

Unicode Support Set whether to use unicode or local code (Shift JIS).

Factory Setting

5

Enable/Disable Disable

DHCP Activation of DHCP.

On/Off

WINS DHCP Resolve Activation of WINS DHCP Resolve. On/Off

IP Address Set the IP address.

-----

On

On

0.0.0.0

0.0.0.0

0.0.0.0

0.0.0.0

Subnet Mask

Gateway Address

Set the subnet mask.

Set the gateway address.

WINS Primary Server Set the WINS primary server

Address address

WINS Secondary

Server Address

Set the WINS secondary server address.

Administrator Name Administrator name.

Administrator

Password

Location

Reboot

-----

-----

-----

-----

Password of administrator.

Current setting not displayed.

Maximum

20 bytes

Maximum

14 bytes.

Comments on location of machine. Maximum

48 bytes.

Printer will be rebooted after the On/Off editing of the config.txt parameter setting file if set to On.

Usually set to Off when activated.

Machine will not be rebooted even if it is set to On if there is an error in the setting.

0.0.0.0

ADMIN admin

-----

Off

114

Example of config.txt

7.4 Changing Printer and Workgroup Name

115

7

7.5

Auto Driver Downloading

When installing printer driver to Windows 95, Windows 98 or Windows Me client computer, you can define setting to use the automatic driver downloading feature.

This feature is not applicable to Windows NT 4.0 or Windows 2000.

7.5.1

Preparation for Auto Driver Downloading

The following procedure explains the preparations needed in order to use the auto driver downloading feature. Only the administrator can define this setting.

Procedure

Open

Network Neighborhood

from the Windows client computer, followed by

Workgroup

(factory setting: Workgroup) and then the printer (e.g. Fx-0a62fd).

By referring to "7.4 Changing Printer and Workgroup Name", open the config.txt inside the "admintool" folder, and then check that Auto Driver

Download is set to Enable (factory setting: Enable).

116

Close config.txt and then open the "drivers" folder.

7.5 Auto Driver Downloading

Insert the CD-ROM that comes with this manual into the CD-ROM drive and open it through Windows Explorer or My Computer.

Create a folder inside the "drivers" folder. Name the folder with a maximum of eight characters. You can create up to a maximum of two levels of folders.

Here, we will create a folder called

win98

.

Copy the appropriate printer driver (e.g. 9x-eng-pcl) in the CD-ROM to the "win98" folder. Close the "drivers" folder.

Switch off the power of the printer, and wait for five seconds before switching it on again.

Open

Network Neighborhood

from the Windows client computer, followed by

Workgroup

(factory setting: Workgroup) and then the printer (e.g. Fx-0a62fd).

You will notice that there is a printer icon of the printer driver (9x-eng-pcl) that you copied, added into the printer icon folder.

You are now ready for auto driver downloading.

7

117

7.5 Auto Driver Downloading

7.5.2

Auto Downloading of Printer Driver

The following procedure explains how to use this auto downloading feature of the printer driver to install printer driver to the client computer. We will install the PCL 6 printer driver to Windows 98 here as an example.

If you are not sure of your Workgroup or Host Name, see your system administrator.

Procedure

Open

Network Neighborhood

from the Windows client computer, followed by

Workgroup

(factory setting: Workgroup) and then the printer (e.g. Fx-0a62fd).

The factory setting of Workgroup is Workgroup and host name of the printer is

"FX-xxxxxx" (where xxxxxx is the last three bytes of the Ethernet address of the printer). See your system administrator for the current setting.

The following message appears. Select

Yes

.

The Add Printer Wizard dialog box appears.

Select

Yes

if you want to print from MS-DOS-based programs and

No

if you do not want to, and then click

Next

.

118

7.5 Auto Driver Downloading

If necessary, change

Printer name

.

Click

Yes

if you want to use the printer as a default printer and

No

if you do not want to.

Then click

Next

.

Click

Yes

if you want to print a test page and

No

if you do not want to. Then click

Finish

to start the installation.

If you have chosen to print a test page, the following message appears.

Check that the test page has been correctly printed and then click

Yes

.

7

119

7.5 Auto Driver Downloading

The printer icon of the newly installed printer is added to the "Printers" folder and the printer is now ready for use.

The printer window is displayed for you to specify settings.

From the "Printers" menu, select

Properties

.

The printer properties dialog box is displayed.

Refer to "4.3 Configuring the Printer Drivers" to configure your settings.

120

Setup for

NetWare

8.1

Using NetWare ................................................................................... 122

8.2

Setup for NetWare ............................................................................. 124

8.3

Setup for the Printer ........................................................................... 125

8.4

Setup for the Client ............................................................................ 129

8.1

Using NetWare

This section explains the characteristics and the operating environment of the printer when it is connected to a Novell NetWare network.

8.1.1

System Configuration

The system configuration is as follows:

6

8.1.2

This printer is compatible with NetWare 3.1X/4.1/4.1X/5.X. It also supports Directory Services using the Print Server mode.

This printer does not support Novell Distributed Print Services (NDPS), a feature introduced by NetWare 5.

Print server mode (PSERVER mode) in which the printer functions as a print server

In the PSERVER mode, the printer will function as a print server and retrieve print jobs from the print queue for printing. As it fully utilizes the functions of the printer, this mode is superior to the remote printer mode in terms of system capacity. However, in this mode, the printer will take up one user license of the file server.

Target Computers

The target computers must meet the following requirements:

Compatible file servers

Novell-accredited PC which can be installed with NetWare 3.1X/4.1/4.1X/5.X.

Compatible workstations

Novell-accredited PC which can run Windows 95, Windows 98, Windows Me, Windows NT 4.0, or Windows 2000.

122

8.1.3

8.1 Using NetWare

Interface

The printer supports the following types of Ethernet interface:

10Base-T (Twisted Pair Cable)

100Base-TX (Twisted Pair Cable)

The following frame types are supported:

Ethernet II specification

IEEE 802.3 specification

IEEE 802.3/802.2 specification

IEEE 802.3/802.2/SNAP specification

The printer will send out packets of each frame type on the connected network and activate automatically by the frame type which responded first.

However, if other protocols are running simultaneously on the same network, use the frame type that the NetWare server is using.

Some network components (such as the hub) may not support automatic setup for frame type. If the data link indicator light of the port which is connected to the printer of the network component does not light up, match the setting (IPX/SPX setting) of the frame type of the printer to the frame type of the file server.

123

8

8.2

Setup for NetWare

6

This section describes the flow of setup the printer in a network environment running NetWare.

8.2.1

Flow of Setup

Setting up the printer

Set the NetWare interface port to Enable (factory setting: Disable) and activate the protocol to be used from the printer control panel. Print the printer settings list and check the device name (Host Interface Setup>NetWare

>

Device).

"8.3 Setup for the Printer"

Setting the NetWare print service

Using PCONSOLE or NetWare Administrator (NWADMIN), create print queue, print server and printer and assign the respective objects.

When using in the PSERVER mode, use the device name checked in Step for the print server name. Set Printer Location as Auto Load (Local).

• For information on how to use PCONSOLE or NWADMIN, see the manual which comes with NetWare. For NetWare 5.X, only NWADMIN is available for use.

Setting up the client

Install a printer driver compatible with the printer to a PC. Different printer drivers are used for different operating systems.

Use a PC that is functioning properly as a client of NetWare.

"8.4 Setup for the Client"

124

8.3

Setup for the Printer

This section describes the procedure to set the port for NetWare interface to Enable (factory setting:

Disable), activate the protocol to be used, print the printer settings list and check the device name.

8.3.1

Setting the Port to Enable

Activate the NetWare

®

port by the following procedure:

When setting the port to Enable leads to insufficient memory, a message about the insufficient memory may be displayed on the control panel and the port status may be set to Disable automatically. If this happens, set the ports which are not in use to

Disable and change the memory size.

Procedure

Press the

Settings/Meter Check

button on the control panel and select

Tools

Mode

on the screen displayed.

Enter the access number of the system administrator and touch

Confirm.

The factory setting of the access number is "11111".

8

125

8.3 Setup for the Printer

Select

Print/Scan Mode Settings

.

Select

Port Settings

.

6

Select

NetWare

.

Select

Port Status

and then touch

Change Settings

.

126

8.3 Setup for the Printer

Select

Enable

.

Select

On

for the protocol to be used for NetWare.

8.3.2

Select

Save

twice.

Select

Close

twice and then

Exit Tools

.

The machine will be rebooted.

Other Settings

When necessary, adjust the following settings on the printer. However, the factory setting of these items do not need to be changed for normal use.

Print Mode

PJL Switch

NetWare Receive Buffer

IPX/SPX

(Factory setting: PCL*)

(Factory setting: On)

(Factory setting: 256 KB)

(Factory setting: On)

"Chapter 13 Configuring by the Tools Mode Screen" for details on the settings of the printer.

* If the optional PostScript software kit is installed, factory setting will be Auto.

8

127

6

8.3 Setup for the Printer

8.3.3

Printing the Printer Settings List

Follow the procedure below to print the printer settings list. When the printer settings list is printed, check the network address (Maintenance Mode Settings>IPX/SPX

Setup>Network Address) and device name (Host Interface Setup>NetWare>Device).

Procedure

When the Menu screen is not displayed, press the

Menu

button on the control panel.

Select

Print Report/List

on the screen displayed.

Select

Printer Settings List

and then press the

Start

button on the control panel.

The printer settings list will be printed.

128

8.4

Setup for the Client

When the OS of the PC is Windows 95, Windows 98, Windows Me, Windows NT 4.0 or Windows

2000, install the printer driver following the procedure below.

8.4.1

Windows 95/98/Me, Windows NT 4.0 or Windows 2000

Procedure

Install the printer driver for Windows 95/98/Me, Windows NT 4.0 or Windows

2000 by running the "Setup.exe" program. Click

Add Network Port

and select the network printer from

Network Neighborhood

.

"4.2.2 For a Network Printer" for details on the installation of the printer driver.

• When you are printing, make sure that you uncheck the "Enable Banner" check box displayed on the "Printer Settings" tab of the printer properties dialog box. Otherwise, you might not be able to obtain the desired printing result.

• When you encounter any problem, you can refer to the Readme.txt file in the

"Inffile" folder of the driver that you are installing, stored in the "PCL6

Printer Driver, Utilities & Documentation" CD-ROM.

129

8

This page is intentionally left blank

Using the

Internet

Printing

Protocol

9.1

Introduction ........................................................................................ 132

9.2

Setup of the Printer and Installing the Printer Driver ........................ 135

9.1

Introduction

This machine supports the Internet Printing Protocol (IPP). As Windows 2000 is installed with the

IPP port monitor, the client software for outputting to IPP printer, you can specify printing to an

IPP-supported printer from the Add Printer window of the printer program in the control panel.

Using IPP, you can print to a distant printer via the Internet or an intranet.

9.1.1

System Environment

The essential system environment is as follows:

• using TCP/IP protocol

• Microsoft Windows 2000 Server

• Microsoft Windows 2000 Professional

• Microsoft Windows 2000 Advanced Server

132

9.1.2

9.1 Introduction

Setup

Procedure

Define the IP address.

"1.6 Setting IP Address For Network Environment"

At the printer, select Tools Mode, Print/Scan Mode Settings, Port Settings,

Internet Service, Enable (factory setting: Enable).

"Chapter 13 Configuring by the Tools Mode Screen"

At the computer and on the Internet Services screen, select the Properties tab,

Port Status, and then check the Enable (factory setting: Enable) check box for

IPP.

At the computer, setup the printer and install the driver.

"Chapter 4 Installing and Configuring Printer Drivers"

9

133

9.1 Introduction

9.1.3

Other Setting Items

If necessary, define the following items related to IPP on the Internet Services screen

(Properties tab > Protocol settings > IPP). However, there is no need to change the factory setting of these items for normal usage.

• IPP Port Number

• IPP Print Mode

• IPP PJL Switch

(Factory setting: 80)

(Factory setting: PCL*)

(Factory setting: On)

• IPP TBCP Filter

• IPP Access Control

(Factory setting: Disable)

(Factory setting: Disable)

• IPP DNS (Factory setting: Disable)

• IPP Connection Time-Out (Factory setting: 60 sec)

• IPP Spool (Factory setting: Hard Disk spool)

• These settings cannot be defined at the printer touch panel display.

• * If the optional PS3 (PostScript software) kit is installed, factory setting will be Auto.

• Port Number is the port number used for receiving data. It is fixed at 631 and for additional port, you can define the number as 80 or between 8000-9999. If you assign 0 as the port number, the added port will not be enabled. This setting is effective after the printer is rebooted.

• With IPP, you can store the print data output from the application in the spool file of the printer temporarily to be processed for printing. Set the spool mode by using the IPP spool of the receive buffer capacity.

Spool mode:

The mode which stores print data output from the application in the spool file of the printer temporarily to be processed for printing. You can choose to save the spool file in either the RAM disk which has used the printer memory or the hard disk connected to the printer. As the processing of print data after spooling will be done in the printer, the application in the client is released sooner. Requests from multiple clients can be processed at the same time.

Non spool mode:

The mode which processes printing while the print data output from the application is being received by the printer. When the printer is processing printing request from a client, printing request from other clients cannot be received.

• The maximum spool number is 1,000. However, depending on the empty capacity, you may spool up to 200 only.

For non spool mode, if a job is sent when the printer is in sleep mode, the buffer may become full and the printing request may not be completed. When this happens, deactivate the sleep mode of the printer and the printing request will be completed.

134

9.2

Setup of the Printer and

Installing the Printer Driver

After the printer protocol setup is done, carry out the following procedure on the computer.

• Before installing the printer driver on the client computer, check that Internet Protocol (TCP/IP) has been installed. If it has not been installed, refer to the Windows 2000 manual to install it.

• When using the internet printing via the proxy server, an error message, "Cannot be connected to the internet" may appear when setting the printer. When this happens, change the setting of the IP address without going through the proxy server by selecting Printer, Settings, Control Panel, and then Internet

Options. For details on the setup method, refer to the Windows 2000 manual.

9.2.1

For Windows 2000

Procedure

Click

Start

, and then select

Settings

, followed by

Printers

.

The Printers window appears.

Double click

Add Printer

.

The Add Printer Wizard dialog box appears.

9

Click

Next

.

135

9.2 Setup of the Printer and Installing the Printer Driver

Select

Network printer

and then click

Next

.

The screen to locate your printer appears.

Select

Connect to a printer on the Internet or on your intranet

, enter the following URL, and then click

Next

: http: //"printer IP address"/ipp

The printer connection dialog box appears.

136

If the DNS setting has been defined for the client and the host name is effective, you can enter the host name instead.

Click

OK

.

The screen to select the manufacturer and model of your printer appears.

Insert the "PCL6 Printer Driver, Utilities & Documentation" CD-ROM to the

CD-ROM drive.

9.2 Setup of the Printer and Installing the Printer Driver

Click

Have Disk

.

The Install From Disk dialog box appears.

9

Enter "E:\Driver_PCL6\English\Win2000\Setup\Setup.exe" at

Copy manufacturer's files from

, and then click

OK

.

• In this example, we assume that drive E is the CD-ROM drive. Enter the appropriate letter for your CD-ROM drive.

• You can also click Browse to locate the driver folder inside the CD-ROM.

The screen to select the printer driver appears.

Select

Panasonic DP-6000/7000

and then click

Next

.

The screen to specify whether to use this printer as the default printer appears.

137

9.2 Setup of the Printer and Installing the Printer Driver

Select

Yes

when you want to use the printer as the default printer and

No

when you do not want to use it as the default.

The essential files will be copied.

After the copying is done, the following screen appears.

Click

Finish

.

138

Using

Internet

Services

10.1 Using Internet Services ...................................................................... 140

10.2 Configuring Browser .......................................................................... 142

10.3 Configuring Printer ............................................................................. 144

10.4 Activating Browser ............................................................................ 147

10.1

Using Internet Services

Internet Services is a software that enables the user to display the printer/job status or change the printer settings via a web browser when the DP-6000/7000 printer has been configured for the TCP/

IP environment.

Using the Properties dialog box of Internet Services, you can define the settings on the printer control panel, like the items of system settings or the various network port settings.

Depending on the items, some settings become effective only after rebooting (after switching on/off the printer, or after defining the system settings using the printer control panel).

10.1.1

Structure of the Internet Services Screen

The Internet Services screen consists of four parts: a panel each at the top and bottom parts of the window (top panel, bottom panel), as well as two frames on the left and right at the middle part of the window (left frame, right frame).

The contents of each part change according to the features used (Jobs, Status, Properties,

Maintenance, or Support).

140

10.1 Using Internet Services

Top panel

The top panel is at the top of the window. A logo mark and the printer name are displayed on the top page (default status) as well as on every category page. In addition, you will find tabs to link to the top page and to move to each category on every category page.

Bottom panel

The bottom panel is at the bottom of the window. It displays links to the Customer Support Home

Page, copyright screen, and the Help file. The contents in this panel remain unchanged regardless of which page is displayed.

Right and left frame

The right and left frames are in the middle of the window. The contents in these frames will change according to the items selected in the category.

10.1.2

System Environment

To use Internet Services, you will need to activate the network environment using

TCP/IP protocol as well as to set the Internet service to Enable (factory setting:

Disable) at the printer.

10.1.3

Target Host Computers and Browsers

To use Internet Services, you will need to activate the network environment using

TCP/IP protocol on the client computer. You will also need an approved version of

Internet Browser software installed.

Host computers

• Microsoft Windows 95 OS

• Microsoft Windows 98 OS

• Microsoft Windows Me OS

• Microsoft Windows NT Server 4.0

• Microsoft Windows NT Workstation 4.0

• Microsoft Windows 2000 Server

• Microsoft Windows 2000 Professional

• Macintosh OS 8.0 onwards

Browsers

• Netscape Communicator (version 4.51 or higher for Windows/version 4.5 or higher for Macintosh)

• Internet Explorer version (version 4.01 or higher for Windows/version 5.0 or higher for Macintosh)

141

10.2

Configuring Browser

10

Before using Internet Services, check the following settings on your browser.

10.2.1

Checking Browsers

For Netscape Communicator

Procedure

From the Edit menu, select

Preferences

.

From the Category tree, click

Advanced

.

If the Enable Java check box is not selected, select it.

Click the "+" sign on the left of

Advanced

.

Click

Cache

under

Advanced

.

Select

Once per session

or

Every time

for

Document in cache is compared to document on network

.

Click

OK

. The dialog box is closed.

For Internet Explorer

Procedure

Select

Internet Options

from the View menu for version 4.x, and

Internet

Options

from the Tools menu for version 5.x.

Click

Settings

for

Temporary Internet files

on the General tab.

In

Check for newer versions of stored pages

, select either

Every visit to the page

or

Every time you start Internet Explorer

, and then click

OK

.

Click

OK

on the Internet Options dialog box.

142

10.2 Configuring Browser

10.2.2

Checking Proxy Server and Port Number

Here, the proxy server setting and port number when using Internet Services are explained.

Proxy server setting

When using Internet Services, it is recommended that you do not connect to a proxy server but make direct connections.

When you define connection to be made to a proxy server, it might take a long time to set the IP address at the browser or the screen might not be displayed. When this happens, change the setting to a direct connection at the browser. For details on how to define these settings, refer to the manuals of the browser that you are using.

Port number setting

The factory setting of the port number of the Internet Services is 80. The port number can also be changed from the Properties screen. The port numbers that can be set are

80, 8000 - 9999.

After the port number has been changed, it is necessary to specify the number after ":" of the address when connecting from the browser.

For example, for port number, "8080", enter the number to the internet or IP address as follows: http://13.199.56.142:8080.

You can check the port number under Communications Settings of the Printer Settings

List. For details of the Printer Settings List, refer to "12.1.2 Printer Settings List".

143

10.3

Configuring Printer

10

This section describes the configurations to be done at the printer.

10.3.1

Activating Internet Service

Activate Internet Service on the touch panel display by the following procedure.

If the IP address has not been defined, follow the message displayed to define it after the Internet Service is activated.

Procedure

Press the

Settings/Meter Check

button on the control panel and select

Tools

Mode

on the screen displayed.

Enter the access number of the system administrator by using the numeric keypad and touch

Confirm

.

The factory setting of the access number is "11111".

Select

Print/Scan Mode Settings

.

144

Select

Port Settings

.

Select

Internet Service

.

SMB

With

Port Status

selected, touch

Change Settings

.

10.3 Configuring Printer

Select

Enable

and then touch

Save

.

145

10

10.3 Configuring Printer

Select

Close

twice until the screen at Step 4 is displayed.

Select

Exit Tools

.

The machine will be rebooted.

10.3.2

Other Internet Service Settings Items

Define the following settings for Internet Service after Internet Service has been enabled at the printer. You can define these items by clicking

Internet Services

Settings

on the Properties tab.

• Auto Refresh Interval

• Administration Mode

• Administrator Name

• Administrator Password

• Confirmation Password

(Factory setting: 30 sec)

(Factory setting: Enable)

146

10.4

Activating Browser

This section describes the procedure to activate the browser when using the Internet

Services.

10.4.1

Activating Browser

Procedure

Switch on the host computer and activate the browser.

At the address column of the browser, enter the IP address or internet address of the printer, and then press

Enter

on the keyboard.

• Example of specifying an IP address

147

10.4 Activating Browser

The screen of the Internet Services is displayed.

10.4.2

Help

For details on the items of each screen, click

Help

to check.

148

Help

Setting Print

Mode

11.1 Print Mode Operation......................................................................... 150

11.2 PCL 6 Settings .................................................................................... 151

5

11.1

Print Mode Operation

You can define the PCL 6 settings in Print Mode. The settings can be changed during printing and will be reflected in the next job.

Use this mode to set default values for PCL 6 jobs. When you print using the printer driver, the parameters set by the driver will override those set here in the PCL 6 settings.

Print Mode can be used to switch the printer to

Offline

. When

Online

is selected, the printer is able to receive data. When

Offline

is selected, the printer will automatically assume the state of not being able to receive data. Data that is being transmitted will be disrupted and will not be printed.

(Menu screens)

Select

Print Mode

150

11.2

PCL 6 Settings

This section explains the values that can be set in the PCL 6 Settings and the setting procedure.

11.2.1

List of PCL 6 Settings Items

Menu Item Description

Paper Tray

Output Size

Sets the paper tray that supplies paper.

Available options:

• Auto *

• Tray 1

• Tray 3

• Tray 4

• Tray 5 (Bypass Tray)

• Tray 6 (High Capacity)

When Auto is selected, the various paper sizes in Output Size will be available.

When any of the specific tray is selected, only Adjust to Specified Tray will be displayed in Output Size and no other options of paper size will be available for selection.

Sets the paper size.

Available options:

• A5

• B5

• A4 *

• B4

• A3

• 8.5

×

11"

• 8.5

×

13"

• 8.5

×

14"

• 11

×

17"

• 5.5

×

8.5"

Output Destination Sets to output with printed page facing down.

Available options:

With the standard paper output device installed

• Output Tray *

With the optional Finisher installed

• Finisher Tray 1*

• Finisher Tray 2

Output Orientation Sets the orientation for printing for PCL only.

Available options:

• Portrait *

• Landscape

* factory setting

11

151

5

11.2 PCL 6 Settings

Menu Item

2 Sided Print

Font

Description

Sets two-sided printing.

Available options:

• Off *

• On (with another set of options of

Flip on Short Edge

and

Flip on Long Edge

*)

Sets the font to be the default.

Available options (00 - 80):

• 00 - CG Times -

• 01 - CG Times It

• 02 - CG Times Bd -

-

• 03 - CG Times BdIt

• 04 - Univers Md

• 05 - Univers MdIt

• 06 - Univers Bd

-

-

-

-

• 07 - Univers BdIt

• 08 - Univers MdCd

• 09 - Univers MdCdIt

• 10 - Univers BdCd

• 11 - Univers BdCdIt

• 12 - AntiqueOlv

• 13 - AntiqueOlv It

• 14 - AntiqueOlv Bd

• 15 - CG Omega

• 16 - CG Omega It

• 17 - CG Omega Bd

• 18 - CG Omega BdIt

• 19 - Garamond Antiqua -

• 20 - Garamond Krsv -

• 21 - Garamond Hlb -

• 22 - Garamond KrsvHlb -

• 23 - Courier *

• 24 - Courier It -

-

-

-

-

-

-

-

-

-

-

-

-

-

• 25 - Courier Bd

• 26 - Courier BdIt

• 27 - LetterGothic

• 28 - LetterGothic It

• 29 - LetterGothic Bd

• 30 - Albertus Md

• 31 - Albertus Xb

• 32 - Clarendon Cd

• 33 - Coronet

• 34 - Marigold

• 35 - Arial

• 36 - Arial It

• 37 - Arial Bd

• 38 - Arial BdIt

• 39 - Times New

• 40 - Times New It -

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

(CG Times)

(CG Times Italic)

(CG Times Bold)

(CG Times Bold Italic)

(Univers Medium)

(Univers Medium Italic)

(Univers Bold)

(Univers Bold Italic)

(Univers Medium Condensed)

(Univers Medium Condensed Italic)

(Univers Bold Condensed)

(Univers Bold Condensed Italic)

(Antique Olive)

(Antique Olive Italic)

(Antique Olive Bold)

(CG Omega)

(CG Omega Italic)

(CG Omega Bold)

(CG Omega Bold Italic)

(Garamond Antiqua)

(Garamond Kursiv)

(Garamond Halbfett)

(Garamond Kursiv Halbfett)

(Courier)

(Courier Italic)

(Courier Bold)

(Courier Bold Italic)

(Letter Gothic)

(Letter Gothic Italic)

(Letter Gothic Bold)

(Albertus Medium)

(Albertus Extra Bold)

(Clarendon Condensed)

(Coronet)

(Marigold)

(Arial)

(Arial Italic)

(Arial Bold)

(Arial Bold Italic)

(Times New Roman)

(Times New Roman Italic)

* factory setting

152

11.2 PCL 6 Settings

Menu Item

Font (con't...) • 41 - Times New Bd

• 42 - Times New BdIt

• 43 - Symbol

• 44 - Wingdings

• 45 - Line Printer

• 46- Times Roman

• 47 - Times IT

• 48 - Times Bd

• 49 - Times BdIt

• 50 - Helvetica

• 51 - Helvetica Ob

• 52 - Helvetica Bd

• 53 - Helvetica BdOb

• 54 - CourierPS

• 55 - CourierPS Ob

• 56 - CourierPS Bd

• 57 - CourierPS BdOb

• 58 - SymbolPS

• 59 - Palatino Roman

• 60 - Palatino It

• 61 - Palatino Bd

• 62 - Palatino BdIt

• 63 - ITCBookman Lt

• 64 - ITCBookman LtIt

• 65 - ITCBookmanDm

• 66 - ITCBookmanDm It -

• 67 - HelveticaNr -

• 68 - HelveticaNr Ob -

-

-

• 69 - HelveticaNr Bd

• 70 - HelveticaNrBdOb -

-

• 71 - N C Schbk Roman -

• 72 - N C Schbk It -

-

-

-

-

-

-

-

-

• 73 - N C Schbk Bd

• 74 - N C SchbkBdIt

• 75 - ITC A G Go Bk

• 76 - ITC A G Go BkOb -

• 77 - ITC A G Go Dm -

-

-

-

• 78 - ITC A G Go DmOb -

• 79 - Zapfc MdIt -

• 80 - ZapfDingbats -

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

Description

(Times New Roman Bold)

(Times New Roman Bold Italic)

(Symbol)

(Wingdings)

(Line Printer)

(Times Roman)

(Times Italic)

(Times Bold)

(Times Bold Italic)

(Helvetica)

(Helvetica Oblique)

(Helvetica Bold)

(Helvetica Bold Oblique)

(CourierPS)

(CourierPS Oblique)

(CourierPS Bold)

(CourierPS Bold Oblique)

(SymbolPS)

(Palatino Roman)

(Palatino Italic)

(Palatino Bold)

(Palatino Bold Italic)

(ITC Bookman Light)

(ITC Bookman Light Italic)

(ITC Bookman Demi)

(ITC Bookman Demi Italic)

(Helvetica Narrow)

(Helvetica Narrow Oblique)

(Helvetica Narrow Bold)

(Helvetica Narrow Bold Oblique)

(New Century Schoolbook Roman)

(New Century Schoolbook Italic)

(New Century Schoolbook Bold)

(New Century Schoolbook Bold Italic)

(ITC Avant Garde Gothic Book)

(ITC Avant Garde Gothic Book Oblique)

(ITC Avant Garde Gothic Demi)

(ITC Avant Garde Gothic Demi Oblique)

(ITC Zapf Chancery Medium Italic)

(ITC Zapf Dingbats)

* factory setting

11

153

5

11.2 PCL 6 Settings

Menu Item

Symbol Set

Point Size

Description

Sets the specific set of symbols provided by a font with each symbol set defined with a specific application in mind.

Available options (35 altogether):

• ROMAN-8 * (Roman 8)

• ISO L1 (ISO 8859-1) (Latin 1)

• ISO L2

• ISO L5

• ISO L6

• PC-8

• PC-8 DN

• PC-775

-

-

-

-

-

-

(ISO 8859-2 Latin 2)

(ISO 8859-9 Latin 5)

(ISO 8859-10 Latin 6)

(PC-8)

(PC-8 DN)

(PC-775)

• PC-850

• PC-852

• PC-1004

• PC-8 TK

• WIN L1

• WIN L2

• WIN L5

• DESKTOP

-

-

-

-

-

-

-

-

(PC-850)

(PC-852)

(PC-1004) (OS/2)

(PC Turkish)

(Windows 3.1 Latin 1)

(Windows 3.1 Latin 2)

(Windows 3.1 Latin 5)

(DeskTop)

• PS TEXT

• MC TEXT

• MS PUB

• MATH-8

• PI FONT

• LEGAL

• ISO-4

• ISO-6

• ISO-11

• ISO-15

• ISO-17

• ISO-21

• ISO-60

• ISO-69

• WIN 3.0

• WINBALT

• SYMBOL

• WINGDINGS

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

(PS Text)

(MC Text)

(Microsoft Publishing)

(Math 8) (HP Math 8)

(Pi Font) (HP Pi Font)

(Legal) (HP Legal)

(ISO 4) (United Kingdom)

(ISO 6) (ASCII)

(ISO 11) (Swedish:names)

(ISO 15) (Italian)

(ISO 17) (Spanish)

(ISO 21) (German)

(ISO 60) (Norwegian, v.1)

(ISO 69) (French)

(Windows 3.0 Latin 1)

(Windows Baltic)

(Symbol)

(Wingdings)

Sets the height of the font.

Available options: 4.00 to 50.00 in increments of 1.00 or 0.25 (12.00*).

The point size item available depends on the font source and font number selected.

* factory setting

154

11.2 PCL 6 Settings

Menu Item Description

Pitch

Form Lines

Sets the pitch of the font in character per inch.

Available options: 6.00 to 24.00 in increments of 1.00 or 0.01 (10.00*).

• Pitch is the horizontal spacing of a fixed-space (bitmap or scalable) font in terms of number of characters per inch.

This characteristic is ignored when selecting a proportionately-spaced (bitmap or scalable) font but is saved in the font select table and available when fixed spaced font is selected.

Sets the lines of text within a page.

Available options: 5-128 lines (64*).

Maximum No. of Sets Sets the number of output sets.

Available options: 1*-999 sets.

• When there is a specific number of output from the host device, this value can be displayed and printed out. Also, it can be changed on the setting of the operator panel. However, number of specified output from Netware and lpd cannot be changed to the operator panel.

• If there is instruction from the host device regarding the number of output copy, that value will be reflected and printed.

However, for number of output copy specified by Netware and lpd port, the value of the control panel will not be overwritten after printing.

Image Enhancement Enable or disable image enhancement. Image enhancement is to raise the resolution and to produce smooth print of sharp edges.

Available options:

• On *

Off

Hex Dump Turns on/off the Hex (adecimal) Dump mode. Turning on the Hex Dump mode allows data that is sent to the printer in plain ASCII format.

Available options:

• On

• Off *

• Turning on the Hex Dump mode allows data that is sent to the printer to be printed in plain ASCII format. It will not be interpreted by the emulation. Hex

Dump is used for troubleshooting.

• Hex Dump is supported in the Parallel, LPD and Netware interfaces.

* factory setting

11

155

11.2 PCL 6 Settings

11.2.2

Setting Procedure

This section describes the setting procedure of PCL 6 Settings by using the illustration of setting

Paper Size

to

A3

.

Procedure

Select

Print Mode

from the menu screen.

5

Touch

PCL6 Settings

.

Select the PCL 6 Settings item,

Paper Size

, by touching until it is selected or by touching the item itself and then touch

Change Settings

.

156

Select

A3

and then touch

Save

.

Select

Close

until the menu screen appears.

11.2 PCL 6 Settings

11

157

This page is intentionally left blank

Printing

Reports/Lists

12.1 Types of Reports/Lists ....................................................................... 160

12.2 How to Print Report/List .................................................................... 180

12.1

Types of Reports/Lists

12.1.1

Types and Paper Sizes

This section explains the types of reports/lists that can be printed and the necessary paper sizes for printing them.

Types

Besides printing data sent from the host computers, the printer is also equipped to print the following reports/lists:

• Printer Settings List

• Job History Report

• Error History Report

• PCL Settings List

• PCL Fonts List

• PostScript Fonts List

• Print Meter Report

• PostScript Settings List

• Stored Print Job List

The PostScript Fonts List and PostScript Settings List are available only when the optional PostScript Software kit is installed.

Paper sizes

To print these reports/lists, it will be print in 8.5 x 11 in. size. To change the paper size, please contact to your local authorized Panasonic Service Representative.

160

12.1.2

Printer Settings List

About Printer Settings List

Prints the information in the system menu.

Printing result

The following items will be included in the list:

• System Settings

• Printer Settings

• Communication Settings

The result of the printing is shown on the next page.

12.1 Types of Report/List

12

161

12.1 Types of Report/List

162

12.1 Types of Report/List

12.1.3

Job History Report

About Job History Report

It is possible to check whether the print and scan data sent from the computer is properly printed.

From the Tools Mode screen, you can decide whether to print out the job history report automatically whenever there are more than 50 items of print data.

Even if the job history report is set to be printed out automatically, it is possible to print it with the latest print jobs (maximum 50) from the Menu screen>

Print Report/List

.

Printing result

Up to 50 of the latest print jobs will be printed in the job history report. The following items will be included in the list:

• Date

• Time

• Input

• Output

• Job Info

• Page Info

• Pages

• Sheets

• Job Status

• The print log is basically printed chronologically but the printing sequence can be changed when cancelling jobs or executing jobs with short processing time.

• If you want the print log to be printed out automatically when there are 50 jobs, see

"Chapter 13 Configuring by the Tools Mode Screen" for the setting method.

• The print log will disappear if the memory is initialized.

The following items may be printed in the "Job Status" column:

Job Status

Out of Page Buffer

PDL Auto Switch Fail

Remarks

Cause: As printer is out of page buffer, print data cannot be processed.

Treatment: Carry out one of the following treatments:

• install more memory

• increase the page buffer

Cause: Printer language cannot be automatically selected when the printer mode is set to Auto.

Treatment: Fix the selection of the printer language by the touch panel display or command.

12

163

12.1 Types of Report/List

Printing Content

PJL Syntax Error

Remarks

C a u s e : A P J L c o m m a n d s y n t a x e r r o r h a s o c c u r r e d .

Treatment: Check the printer settings or correct the PJL command.

Print LANG Not Installed Cause: An uninstalled printer language is specified.

Treatment: Look at the Printer Settings List to check if the specified printer language is installed.

Scan Data Repository ERR Cause: DNS is not set or DNS address is not correctly set.

Treatment: Check whether the DNS address is correctly set. Or use the IP address to set the scan data repository address.

Invalid IP Address-DHCP Cause: The IP address set at DHCP is no more effective.

Expired

Out of PCL Memory

Treatment: Check the DHCP environment or set the IP address at the printer.

Cause: As the printer is out of PCL memory, printing cannot be processed.

Treatment: Increase the PCL memory setting.

PCL Command Error Cause: A PCL command error has occurred.

Treatment: Check the print data.

Max. User Number Exceeded Cause: It is detected that the user number for Security Print and

Sample Set documents has exceeded 200 (maximum).

Treatment: Delete documents or users that are no more in use, and then print again.

Template Syntax ERR Cause: A job template syntax error for scanning is detected.

Treatment: Specify other correct job template or recreate another job template.

PostScript LANG Interpret Cause: A PostScript error has occurred.

ERR Treatment: Check the print data.

PCL Memory Low, Page

Simplified

Cause: Lossy compression. Job is very complex, display list takes up too much memory, decomposer will perform lossy compression. Job can still be printed but image cannot be guaranteed.

Treatment: Increase the PCL memory and print again.

The result of the printing is shown on the next page.

164

12.1 Types of Report/List

12

165

12.1 Types of Report/List

12.1.4

Error History Report

About Error History Report

Prints information related to printer errors.

Printing result

The Error History Report will display up to 50 of the latest errors.

The following items will be printed:

• Date

• Time

• Error Code

• Error Type

The result of the printing is shown on the next page.

166

12.1 Types of Report/List

12

167

12.1 Types of Report/List

12.1.5

PCL Settings List

About PCL Settings

Prints the PCL settings of the printer

Printing result

The following items will be printed:

• Paper Tray

• Output Size

• Paper Size

• Output Destination

• Output Orientation

• 2 Sided Print

• Binding Edge

• Font

• Symbol Set

• Font Size

• Font Pitch

• Form Lines

• Vertical Motion Index

• Number of Sets

• Image Enhancement

• PCL Mode

The result of the printing is shown on the next page.

168

12.1 Types of Report/List

12

169

12.1 Types of Report/List

12.1.6

PCL Fonts List

About PCL Fonts List

Prints the list of PCL fonts that are resident in the printer.

Printing result

The result of the printing is shown on the next page.

170

12.1 Types of Report/List

12

171

12.1 Types of Report/List

12.1.7

PostScript Fonts List

About PostScript Fonts List

Prints the list of PostScript fonts that are resident in the printer.

Printing result

The result of the printing is shown on the next page.

172

12.1 Types of Report/List

12

173

12.1 Types of Report/List

12.1.8

Print Meter Report

About Print Meter Report

Prints the number of pages printed and the number of sheets of paper used for printing for each job owner. Also prints the total number of pages printed as well as the total number of sheets of paper used.

Printing result

The following items will be printed:

• Job Owner

• Pages

• Sheets

The result of the printing is shown on the next page.

174

12.1 Types of Report/List

12

175

12.1 Types of Report/List

12.1.9

PostScript Settings List

About PostScript Settings List

Prints the list of logical printers with their PostScript settings.

The list printed out is named "PostScript Logical Printer List".

Printing result

The following items will be included in the list:

• Format

• Option

• Print Control

The result of the printing is shown on the next page.

176

12.1 Types of Report/List

12

177

12.1 Types of Report/List

12.1.10

Stored Print Job List

About Stored Print Job List

Prints information about the mailbox size, Secured Print and Sample Set jobs.

Printing result

The following items will be included in the list:

Mailbox Size

• Size Used

• Free Space

Secured Print/Sample Set

• User ID

• Document Name

• Document Size

• Stored Date

• Pages

The result of the printing is shown on the next page.

178

12.1 Types of Report/List

12

179

12.2

How to Print Report/List

This section explains how to print report/list by illustrating the printing of PCL Fonts List.

Procedure

When the menu screen is not displaying anything, press the "Menu" button on the control panel.

Select

Print Report/List

.

Select

PCL Fonts List

on the screen and press the

Start

button on the control panel.

The PCL Fonts List will be printed.

When there are other jobs waiting, the message "Job Wait" will be displayed. In this case, printing will start once the jobs that are in queue are completed.

180

Configuring by the Tools

Mode Screen

13.1 Tools Mode ........................................................................................ 182

13.2 System/Meter Settings ........................................................................ 184

13.1

Tools Mode

The Settings/Meter Check feature is for the system administrator to select the default value of features as well as to customise the features for use while using the Tools Mode screen.

This section explains the procedure to enter and exit the Tools Mode screen.

13.1.1

Displaying the Tools Mode Screen

The procedure to enter the Tools Mode screen is described here. You need the access number of the system administrator in order to operate the Settings/ Meter Check feature.

The factory setting of the access number is "11111".

Procedure

Press the

Settings/Meter Check

button on the control panel.

Select

Tools Mode

on the screen displayed.

Enter the access number of the system administrator by using the numeric keypad and touch

Confirm

.

Press the Clear C button if you need to correct the input number.

"Changing the access number of the administrator" of "6.3 Configuring the

Machine with Tools Mode" of the Operating Instructions (For Copier).

182

13.1 Tools Mode

When you want to change the setting of any item of the copier and printer/ scanner, select

Copy Mode Settings

and

Print/Scan Mode Settings

respectively.

Here, we select

Print/Scan Mode Settings

as an example.

Select the required item.

13.1.2

Exiting the Tools Mode Screen

You can return to the default screen by the following procedure after you have selected the required features.

If "System Administration Mode Exit Timer" default is defined in Time-outs, the machine will exit the mode once the set time has elapsed and the default screen will be displayed.

The factory setting is 10 minutes.

Procedure

Select

Exit Tools

on the Tools Mode screen.

183

13

13.2

System/Meter Settings

10

This section describes the items that can be set in the Tools Mode screen and the setting procedure.

Depending on the items, you can also make settings using the Internet Services. Refer to "Chapter

10 Using Internet Services" for details.

13.2.1

Common Settings

Menu Item

Screen Layout

Description

Sets the default screen when the power is switched on; when recovering from the power saver mode (sleep mode); or when restarting the machine.

Available options: Menu, Copy Mode*, Scan Mode.

Paper Tray Attributes Regardless of the settings in Tools Mode, the Auto Tray Switching (ATS) feature is always enabled when the machine is used as a printer.

See "Paper Tray Attributes" of "6.1 List of Custom Preset Functions" of the Operating Instructions (For Copier).

Original/Paper Size Sensing See "Original/Paper Size Sensing" of "6.1 List of Custom Preset Functions" of the

Operating Instructions (For Copier).

Audio Tones

Time-Outs

Items:

Scan Job Complete Tone

The tone when a scan job is completed without error.

Available options: Off, Soft, Normal*, Loud.

Print Job Complete Tone

The tone when a print job is completed without error.

Available options: Off, Soft, Normal*, Loud.

For details on other items, see "Audio Tones" of "6.1 List of Custom Preset

Functions" of the Operating Instructions (For Copier).

Items:

Set Date

Sets the present date (Year/Month/Day).

Available options: Year (2000-2099), Month (1-12), Day (1-31).

The date set here will be printed on the list and report.

Set Time

Sets the present time (Hours : Minutes).

Available options: Hours (1-12 AM/PM or 0-23), Minute (00-59).

Copy Job Complete Timeout

Sets the time required for the machine to return to the default settings after a copy job is completed.

Available options: 1-59 seconds, 1-10 minutes, Disable (2 minutes*).

Job Program Incomplete

Sets the time required for the machine to return to the default settings after the last selection of a button.

Available options: 7-59 seconds, 1-10 minutes, Disable (2 minutes*).

* factory setting

184

Menu Item

Time-Outs (con't...)

Report Settings

System Setup

13.2 System/Meter Settings

Description

Auto Resume

Sets the time required for the machine to start the job automatically if the job is not resumed by the user within the specified time.

Available options: 1-59 seconds, 1-10 minutes, Disable (2 minutes*).

Print Start

Sets the time required for the machine to start printing automatically after the last selection of a button. Available options: 1-59 seconds, 1-10 minutes (30 seconds*).

System Admin. Mode Exit Timer

Sets the time required for the machine to exit System Administration Mode automatically after the last selection of a button.

Available options: 10-60 minutes (in 1 minute increment), Disable (10 minutes*).

Auto Power Saver Timer

Sets the power saver timer (Last Selection to Low Power Mode + Low Power

Mode to Sleep Mode).

Available options for Last Selection to Low Power Mode: 1-240 minutes.

Available options for Low Power Mode to Sleep Mode: 1-239 minutes, Disable.

Total time entered must be within 6-240 minutes (15 minutes + 45 minutes*).

Item:

• Job History Report

A feature to automatically print information (job history) about print and scan jobs that have been executed.

Available options: Do not print*, Print automatically.

When it is set to

Print automatically

, print jobs that have not been automatically printed previously will be printed automatically when their number reaches 50.

Print jobs that are being executed or waiting to be executed will not be recorded.

Items:

• Sleep Mode

Sets whether to enable or disable the machine to automatically enter Sleep mode during Power Save mode.

Available options: Enable*, Disable.

• Copy: Maximum No. of Sets

Sets the maximum number of sets allowed for a copy job.

Available options: 1-999*.

• Copy: Output Sets (Collated)

Sets how the copies should be delivered when Collated has been selected for

Copy Output.

Available options: Auto*, Face Up.

• Copy: Size Mismatch Warning

Sets whether to display a warning message when the machine detects that the document size/orientation is different from the selected paper size/orientation.

Available options: No, Yes*, Auto Correct.

If

No

is selected, copies will be made based on the user selections. If

Auto

Correct

is selected, copies will be made with Image Rotation set to

OFF

.

* factory setting

185

13

10

13.2 System/Meter Settings

Menu Item

System Setup (con't...)

Change of Access Number

Description

• Print Mode: Paper Switch

Sets whether or not to print when there is no paper in the machine that matches the selected paper size for the print job.

Available options: Cancel Job, Use Bigger Size*.

If

Cancel Job

is selected, the machine will cancel the print job. If

Use Bigger

Size

is selected, the machine will select the next bigger paper size.

• Print: Single-page Job Output

Sets how a print job with single-page output is to be delivered.

Available options: Face Up, Face Down*.

• Print Mode: Printable Area

Select whether to create the output image on the standard area (area excluding a 4 mm width from all sides of the paper) or extended area (area excluding a 2 mm width from all sides of the paper).

Available options: Standard*, Extended.

• Scan Mode: Edge Erase

Sets the width of the edges from all four sides of the paper when scanning.

Available options: Top & Bottom Edges (0* - 50 mm),

Left & Right Edges (0* - 50 mm).

• Output to Finisher

Select whether to enable or disable copies from being delivered to the Finisher when the paper size has been changed to a larger one in the middle of a print job.

Available options: Enable, Disable*.

See step 5 to 6 of the procedure of "Changing the access number of the administrator" of "6.3 Configuring the Machine by using Tools Mode" of the

Operating Instructions (For Copier).

13.2.2

Copy Mode Settings

Menu Item

Screen Layout

Feature Defaults

Image Quality

Original Size Defaults

R/E Presets

Description

See "Screen Layout" of "6.1 List of Custom Preset Functions" of the Operating

Instructions (For Copier).

See "Feature Defaults" of "6.1 List of Custom Preset Functions" of the Operating

Instructions (For Copier).

See "Image Quality" of "6.1 List of Custom Preset Functions" of the Operating

Instructions (For Copier).

See "Original Size Defaults" of "6.1 List of Custom Preset Functions" of the

Operating Instructions (For Copier).

See "R/E Presets" of "6.1 List of Custom Preset Functions" of the Operating

Instructions (For Copier).

* factory setting

186

13.2 System/Meter Settings

13.2.3

Print/Scan Mode Settings

Menu Item

Screen Layout

Feature Defaults

Network Settings

Description

See "2.6 Custom Presets for Scanning Features" of the Operating Instructions (For

Scanner).

See "2.6 Custom Presets for Scanning Features" of the Operating Instructions (For

Scanner).

Items:

• Ethernet Board Setting

Sets the Ethernet interface type.

Available options: 10BT/100BTX AUTO*, 100Base-TX, 10Base-T.

• TCP/IP: IP Address

Select whether to obtain the necessary information (IP address, subnet mask, gateway address) for using the TCP/IP protocol from the DHCP server automatically or manually. Check with the network system administrator for the value to specify.

Displayed as "aaa.bbb.ccc.ddd" where aaa, bbb, ccc, ddd are each a 3-digit value of 000 - 255. However, "aaa" cannot be 127 or any number from 224-255.

Available options: Auto Obtain (DHCP), Auto Obtain (BOOTP), Specify

Address.

The IP address can be set when any of the interface cards (TCP/IP of

LPD, SMB, Salutation, FTP Client, Agent: Start UDP, Internet Service) using TCP/IP is activated.

• When a wrong IP address is set, the whole network might be adversely affected.

• This machine does not support Classless Inter Domain Routing

(CIDR). Hence, even if the subnet mask is set to

"255.255.240.0", it will still activate as "255.255.255.0".

• TCP/IP: Subnet Mask

Sets the necessary subnet mask for using the TCP/IP protocol.

Displayed as "aaa.bbb.ccc.ddd" where aaa, bbb, ccc, ddd are each one of the following values: 000, 128, 192, 224, 240, 248, 252, 254, 255. However, the bits in the middle cannot be set to 0. Check with the network system administrator for the value to specify.

This machine does not support Classless Inter Domain Routing

(CIDR). Hence, even if the subnet mask is set to

"255.255.240.0", it will still activate as "255.255.255.0".

• TCP/IP: Gateway Address

Sets the necessary gateway address for using the TCP/IP protocol.

Displayed as "aaa.bbb.ccc.ddd" where aaa, bbb, ccc, ddd are each a 3-digit value of 000 - 255. However, "aaa" cannot be 127 or any number from 224-255.

Check with the network system administrator for the value to specify. Define this setting only when it is necessary to set the gateway address. In environments where the gateway address can be set dynamically, there is no need to define the setting.

* factory setting

13

187

10

13.2 System/Meter Settings

Menu Item Description

Network Settings (con't...) • TCP/IP: DNS Server

Sets the IP address of the Domain Name System (DNS) server when asked to see the DNS while using the TCP/IP protocol. Displayed as "aaa.bbb.ccc.ddd" where aaa, bbb, ccc, ddd are each a 3-digit value of 000 - 255. However, "aaa" cannot be 127 or any number from 224-255. Check with the network system administrator for the value to specify.

• Agent: IPX Start Up

Defines the setting of the agent which uses IPX as a protocol of the transport layer.

Available options: Off*, On.

Agent is necessary when using SNMP software with which you can manage multiple printers from a distance. The printer information is controlled by this agent and the SNMP software will collect the printer information from the agent. When you use SNMP software in the NetWare environment, activate the agent by IPX.

• Agent: UDP Start Up

Defines the setting of the agent which uses UDP as a protocol of the transport layer.

Available options: Off, On*.

Agent is necessary when using SNMP software with which you can manage multiple printers from a distance. The printer information is controlled by this agent and the SNMP software will collect the printer information from the agent.

If UDP is set to On when the IP address is not set, the IP address setting screen will be displayed. Set the IP address using this screen. At this point, if the IP address is not set using this screen,

Agent: UDP Start Up will be forcibly set to Off.

• Agent: Community String

Specifies the community name for enabling the settings from the SNMP software to this machine.

Input no more than 12 characters from A-Z, 0-9 and space.

Community String will be displayed when Agent: IPX Start Up or

Agent: UDP Start Up is set to ON.

• IPX/SPX Setting

Sets the operation frame type of IPX/SPX or the type of Token Ring.

Options available depend on whether the Ethernet card or Token Ring card is installed.

Available options when the Ethernet card is installed:

• AUTO* : Sets automatically the frame type.

• Ethernet II : Uses the Ethernet II specification frame type.

• Ethernet 802.3

: Uses the IEEE 802.3/802.2 specification frame type.

• Ethernet 802.2

: Uses the IEEE 802.2 specification frame type.

• Ethernet SNAP : Uses the IEEE 802.3/802.2/SNAP specification frame type.

Available options when the Token Ring card is installed:

• Auto

• Token Ring

• Token Ring SNAP

IPX/SPX setting will be displayed when Agent: IPX Start Up,

IPX/SPX of Transport or NetWare: Port Status of NetWare is set to On.

* factory setting

188

13.2 System/Meter Settings

Menu Item Description

Network Settings (con't...) • Token Ring: Transmit Rate

Sets the transmit rate of the Token Ring.

Available options:

• Auto*

• 4 Mbps

• 16 Mbps

• 100 Mbps

This item is available for selection when the Token Ring is installed.

• Token Ring: Max Packet Size

Sets the maximum packet size of the Token Ring.

Available options:

• 1500 Bytes*

• 2088 Bytes

• 4472 Bytes

• 8232 Bytes

This item is available for selection when the Token Ring is installed.

• Token Ring: Source Routing

Sets the source routing setting.

Available options:

• No

• Yes*

This item is available for selection when the Token Ring is installed.

Port Settings >

Parallel

To be set when using the parallel port.

Items:

• Port Status

Defines the setting of the parallel port when the power is on.

Available options: Disable, Enable*.

The note items at the end of this tabulation of print/mode settings.

• Print Mode

Sets the print mode.

Available option: Auto*, PCL, PostScript.

• PJL Switch

Sets the PJL commands sent from the host device to valid or invalid.

Available options: Off, On*.

• Auto Eject Time

Sets the time to automatically print and output any remaining data in the printer when it is in a continuous state of not receiving data.

Available options: 5-1275 seconds in increments of 5 seconds (30 seconds*).

• Adobe Communication Protocol

Can be set when the optional PostScript software kit is installed.

Available options: Standard*, Binary, TBCP.

• Bi-directional Communication

Sets the bidirectional communication setting.

Available options: Disable, Enable*.

* factory setting

13

189

13.2 System/Meter Settings

Menu Item

Port Settings >

SMB

Port Settings >

NetWare

Port Settings >

LPD

Description

To be set when using the SMB port.

Items:

• Port Status

Define the setting of the SMB port when the power is on.

Available options: Disable, Enable*.

The note items at the end of this tabulation of print/mode settings.

• Transport Protocol

Define the setting of the transport protocols, TCP/IP and NetBEUI.

Available option for TCP/IP: On*, Off. Available option for NetBEUI: On*, Off.

• Print Mode

Sets the print mode.

Available option: Auto*, PCL, PostScript.

• PJL Switch

Sets the PJL commands sent from the host device to valid or invalid.

Available options: Off, On*.

• TBCP Filter

Define the setting of the TBCP Filter when the optional PostScript software kit is installed.

Available options: Disable*, Enable.

To be set when using the Netware port.

Items:

• Port Status

Define the settings of the NetWare port when the power is on.

Available options: Disable*, Enable.

The note items at the end of this tabulation of print/mode settings.

• Transport Protocol

Define the setting of the transport protocols, TCP/IP and IPX/SPX.

Available option for TCP/IP: On, Off*. Available option for IPX/SPX: On*, Off.

• Print Mode

Sets the print mode.

Available option: Auto*, PCL, PostScript.

• PJL Switch

Sets the PJL commands sent from the host device to valid or invalid.

Available options: Off, On*.

• TBCP Filter

Define the setting of the TBCP Filter when the optional PostScript software kit is installed.

Available options: Disable*, Enable.

To be set when using the LPD port.

Items:

• Port Status

Define the settings of the LPD port when the power is on.

Available options: Disable, Enable*.

The note items at the end of this tabulation of print/mode settings.

If LPD is set to Enable when the IP Address is set to Specify Address, the IP Address setting screen will be displayed. Enter the IP Address using the displayed screen.

* factory setting

190

Menu Item

Port Settings >

LPD (con't...)

Port Settings >

EtherTalk

Port Settings >

Salutation

Port Settings >

FTP Client

Port Settings >

Internet Service

13.2 System/Meter Settings

Description

• Print Mode

Sets the print mode.

Available option: Auto*, PCL, PostScript.

• PJL Switch

Sets the PJL commands sent from the host device to valid or invalid.

Available options: Off, On*.

• TBCP Filter

Define the setting of the TBCP Filter when the optional PostScript software kit is installed.

Available options: Disable, Enable*.

• Connection Time-Out

Define the time-out.

Available options: 2 - 3,600 sec (16 sec*).

Items:

• Port Status

Define the setting of the EtherTalk port when the power is on.

Available options: Disable*, Enable.

The note items at the end of this tabulation of print/mode settings.

• Print Mode

Sets the print mode.

Available option: PostScript*.

• PJL Switch

Sets the PJL commands sent from the host device to valid or invalid.

Available options: Off, On*.

Item:

• Port Status

Sets the salutation port when using the network scanner driver and the mailbox viewer.

Available options: Disable*, Enable.

This port uses the salutation protocol meant for the communication between the Panasonic network scanner driver and the mailbox viewer. It is not guaranteed to work when connected to any other salutation protocol.

Item:

• Port Status

Sets the FTP Client port.

Available options: Disable*, Enable.

Item:

• Port Status

Define the setting of the Internet Service port when using Internet Service.

Available options: Disable, Enable*.

The note items at the end of this tabulation of print/mode settings.

* factory setting

13

191

13.2 System/Meter Settings

Menu Item

Port Settings >

IPP

Memory Changes

Description

Items:

• Port Status

Define the setting of the IPP port when the power is on.

Available options: Disable*, Enable.

The note items at the end of this tabulation of print/mode settings.

• Print Mode

Sets the print mode.

Available option: Auto*, PCL, PostScript.

• PJL Switch

Sets the PJL commands sent from the host device to valid or invalid.

Available options: Off, On*.

• TBCP Filter

Define the setting of the TBCP Filter when the optional PostScript software kit is installed.

Available options: Disable*, Enable.

• Access Control

Available options: Disable*, Enable.

• DNS

Available options: Disable*, Enable.

• Add Port Number

Available options: 80, 0, 8,000 - 8,999 (in increments of 1 unit)

• Connection Time-Out

Available options: 0 - 65,535 sec (in increments of 1 sec)

Items:

• Parallel Receive Buffer

• NetWare Receive Buffer

• AppleTalk Receive Buffer

Sets the memory capacity of the receive buffer for the respective interfaces.

Receive buffer is the temporary storage location of the data sent from the PC.

The memory capacity of the buffer can be changed according to the status and objective of the usage. The increase of memory capacity for the buffer can speed up the release of the host device of each interface.

Available memory capacity: 64 KB - 1024 KB in increments of 32 KB (256 KB*).

The maximum memory capacity may change according to the free memory space.

• LPD Spool

• SMB Spool

Sets the memory capacity of the LPD Spool and SMB Spool.

There are three parts of the LPD Spool and SMB Spool:

(1) Off (non-spool mode)

During LPD processing from a PC, data from other PCs cannot be received.

There is a receive buffer meant for LPD use.

Available memory capacity: 64 KB - 1024 KB in increments of 32 KB (256 KB*).

The maximum memory capacity may change according to the free memory space.

* factory setting

192

Menu Item

Memory Changes

(con't...)

13.2 System/Meter Settings

Description

(2) Memory (spool mode):

There is a receive buffer for spooling.

Available memory capacity: 0.50 MB - 32.00 MB in increments of 0.25 MB (0.50

MB*).

The maximum memory capacity may change according to the free memory space.

(3) Hard Disk* (spool mode)

There is a receive buffer for spooling.

• IPP Spool

Sets the memory capacity of the IPP Spool.

There are two parts of the IPP Spool:

(1) Off (non-spool mode)

Available memory capacity: 64 KB - 1024 KB in increments of 32 KB (256 KB*).

(2) Hard Disk* (spool mode)

There is a receive buffer for spooling.

• PCL Memory

Sets the memory capacity for the use of PCL 6. The printing speed may be increased when the memory capacity is increased. When printing documents with large amounts of data, the resolution might decrease. Increasing the memory capacity might prevent a decrease of resolution.

Available memory capacity: 2.50-32.00 MB in increments of 0.25 MB (5.0 MB*).

• When the Port Status of the port is set to Disable, the item corresponding to the port will not be selectable.

• Depending on the data volume sent from the computer, the releasing time for the computer may not be changed even if the memory capacity is increased.

• After removing the RAM module and switching on the power, the following process will be executed automatically if memory becomes insufficient compared with the previous memory setting:

(1) Change and allocate the setting values of the various memories

(e.g. Receive buffer memory).

(2) If allocation in (1) is not possible, set the status of port related to

Ethernet to Disable and reallocate.

• When increasing the memory capacity of the receive buffer, either disable the port status of the port not in use or install the RAM module.

• Error code (086-701 or 086-705) may be displayed after memory changes. Simply press the Job Status Stop button on the control panel and you can continue using the machine.

• All data stored in each of the memory capacity will be cleared if system is reset.

13

* factory setting

193

13.2 System/Meter Settings

Menu Item

Memory Changes

(con't...)

Delete Stored Print Job

Initialize Memory/Disk

Description

• PostScript Memory

Sets the memory capacity for the use of PostScript. The printing speed may be increased when the memory capacity is increased.

Available memory capacity: 4.50-32.00 MB in increments of 0.25 MB (4.5 MB*).

Delete stored print jobs listed according to the types of print jobs:

• Secured Print

• Sample Print

Executes the initialization of NV memory and hard disk. It can also execute system reset.

• Initialize Memory

Executes initialization of NV memory. NV memory is the nonvolatile memory that maintains the printer setting contents even after the power has been switched off.

• Initialize Print Meter

Executes initialization of Print Meter memory.

• All Hard Disks

• Hard Disk Partition 1

• Hard Disk Partition 2

• Hard Disk Partition 3

Executes initialization of the hard disk or the hard disk partition 1-3

* factory setting

• If the distributed memory capacity cannot be maintained and memory becomes insufficient when the port status is at Enable, the following processes will be automatically executed:

A. Change and allocate the setting values of the various memories (e.g. Receive buffer).

B. If allocation in A is not possible, set the status of the Ethernet port to Disable and reallocate.

• When the interface board is installed, disable the port status of the port not in use.

• After removing the RAM module and switching on the power, the above process will be executed even if the memory becomes insufficient compared with the previous memory setting.

194

13.2 System/Meter Settings

13.2.4

Setting Procedure

As an example, the procedure to enable the port status of LPD by the Print/Scan Mode

Settings is explained here.

Procedure

Press the

Settings/Meter Check

button on the control panel and select

Tools

Mode

on the screen displayed.

Enter the access number of the system administrator by using the numeric keypad and touch

Confirm

.

The factory setting of the access number is "11111".

13

Select

Print/Scan Mode Settings

.

195

13.2 System/Meter Settings

Select

Port Settings

.

Select

LPD

.

Select

Port Status

and then touch

Change Settings

.

Select

Enable

.

196

Select

Save

.

Precautions and

Limitations

14.1 In General........................................................................................... 198

14.2 On Using NetWare ............................................................................. 200

14.3 On Using TCP/IP (LPD) ..................................................................... 203

14.4 On Using SMB ................................................................................... 205

14.1

In General

11

13.12 System/Meter Settings

This section explains the precautions and limitations of using this printer in general.

When switching on/off power

• After you have turned off the power, wait at least two seconds before turning it on again. If not, it might lead to the breakdown of the hard disk and memory.

• Do not switch off the power during the following circumstances:

(1) When the Communicating indicator and the Job in Memory indicator are lighted up.

Reason:

• The jobs stored in the memory might be cancelled.

• As there is a possibility of the printer hard disk being accessed, the printer hard disk might not be usable after this.

(2) During the five-second interval after the message, "Ready to Copy" is displayed and the printer is set to online mode.

Reason:

• As there is a possibility of the printer hard disk being accessed, the printer hard disk might not be usable after this.

• When "Printing" is displayed immediately after switching on the printer even no data have been sent, press the

Job Status Stop

button on the control panel to display the Job Status Confirm screen. Next, select jobs with "Printing" displayed, followed by

Stop

. Then press the

Clear C

button.

When cancelling printing

When the printing is not allowed to end normally such as by cancelling printing, the command information sent from the host will not be reflected in the control panel.

When initialized hard disk

• When the hard disk is initialized, all the data registered in it will be erased.

When specifying multiple-copy printing instruction (sorting) for a document with more than 701 pages

The copies will be sorted to 700 pages each and then output.

When using the collate feature for sorting multiple copies of printing

Collate Settings

of the "Output Options" tab of the printer properties dialog box has been checked. However, when the collate feature in the print dialog box of applications like

Microsoft Word 7.0 is selected, the desired print result may not always be obtainable.

When this happens, uncheck the collate feature and print again.

198

14.1 In General

When using the finisher with the puncher attached

• Papers that have been punched or stapled are output to finisher tray 2.

• Do not remove any paper from finisher tray 2 when the printer is outputting paper to it.

• Once finisher tray 2 is full with paper, printing will stop.

When this happens, remove all paper from finisher 2. Printing will resume automatically.

14

199

14.2

On Using NetWare

11

13.12 System/Meter Settings

This section explains the precautions and limitations of using this printer with NetWare.

14.2.1

Setting Printer

If there is not enough memory after the port status is set to Enable, the display might display a message of the insufficient memory and the port status might be set to Disable automatically.

When this happens, either set the port status of ports not in use to Disable or change the memory size, increasing the memory.

Take note of the following limitations on the names:

Item

Device Name

Tree

File Server Name

Context

Print Server Name

Limitation

Use only half-width alphanumeric characters.

Cannot use mathematical symbol (+ =), dot (.), backslash (\), tilde

(~).

There is no difference between underscore(_) and space( ).

1

There is no difference between the capital and small letters of halfwidth alphanumeric characters.

Use only half-width alphanumeric characters.

Cannot use mathematical symbol (+ =), dot (.), backslash (\), tilde

(~).

There is no difference between underscore(_) and space( ).

There is no difference between the capital and small letters of halfwidth alphanumeric characters.

Use only half-width alphanumeric characters.

Cannot use mathematical symbol (+ =), dot (.), backslash (\), tilde

(~).

There is no difference between underscore(_) and space( ).

1

There is no difference between the capital and small letters of halfwidth alphanumeric characters.

Use only half-width alphanumeric characters.

Cannot use mathematical symbol (+ =), dot (.), backslash (\), tilde

(~).

There is no difference between underscore(_) and space( ).

2

There is no difference between the capital and small letters of halfwidth alphanumeric characters.

Use only half-width alphanumeric characters.

Cannot use mathematical symbol (+ =), dot (.), backslash (\), tilde

(~).

There is no difference between underscore(_) and space( ).

1

There is no difference between the capital and small letters of halfwidth alphanumeric characters.

1: The following characters cannot be used in the present Netware file server when it is operating in bindery mode but in order to standardize the directory service and the limitations, there is no limitation at the printer without taking into consideration the type of operating mode: semicolon(;), colon (:), asterisk (*), question mark(?) , comma (,), double quotation ("), greater than/less than symbol (<>), bracket ([ ]), pipe (| )

2: Mathematical symbol (=) and dot (.) cannot be used as context and can be only used as delimiters.

200

14.2 On Using NetWare

14.2.2

Setting Server

For NDS

Take note of the following when setting up environment in NDS:

Item

No. of file server

No. of print queue

For Pserver Mode

Up to 16 servers per tree

Up to 48 queues

No. of notifying candidates Up to 48 users

No. of password characters Up to 32 characters

*

*: If 33 or more characters are used to set the password, printing cannot be carried out.

For Bindery

Take note of the following when setting up environment in bindery:

Item

No. of file server

For Pserver Mode

Up to 16 servers per tree

No. of print queue Up to 48 queues

No. of notifying candidates Up to 48 users

No. of password characters Up to 32 characters

*

*: If 33 or more characters are used to set the password, printing cannot be carried out.

Workload of Bindery reference queue (for directory service/Pserver mode)

This printer does not support bindery reference queue. As such, printing with bindery reference queue is not allowed.

14

201

11

14.2.3

During Printing

The following printer features are applicable when using NWADMIN or

PCONSOLE:

Parameter

Interrupt Print Job

Stop Printer

Pause Printer

Activate Printer

Paper Edge mark

Form feed

Printer rewind

Mount paper

Stop print server

Port status

×

×

×

: Not supported; : supported

14.2.4

Using Token Ring Interface Port

• When the Token Ring interface port is installed, the MAC address will be changed.

• When using gateway in Token Ring environment, set Source Routing to Yes.

14.2.5

Others

To search for NetWare printer from SNMP applications, set Agent: IPX Start Up to

On (factory setting: On) (Tools Mode > Print/Scan Mode Settings > Network Settings)

202

14.3

On Using TCP/IP (LPD)

Be aware of the following precautions and limitations when using the printer with the TCP/IP (lpd) protocol.

14.3.1

During Setup

Setting up at the printer

Be very careful in setting IP addresses which are controlled as an entire system. Consult your network administrator before defining any IP address.

Depending on the network environment used, it may be necessary to set up the subnet mask and gateway. Consult your network administrator to set up the necessary items.

If setting the port to

Enable

leads to insufficient memory, a message to that effect will be displayed on the control panel and the port status may be set to

Disable

automatically. When this happens, set the ports which are not in use to

Disable

, change the memory size, or install more memory.

Specify the size for the receive buffer memory as required by the environment. If the size of the receive buffer memory is smaller than the file data to be received, the data may not be received.

Setting up at the PC/workstation

Be very careful in setting up IP addresses which are controlled as an entire system. Consult your network administrator before defining any IP address.

Before setting any network (such as the IP address) to a host being used under Network

Information Service (NIS), consult the NIS administrator.

14.3.2

During Switching Power On/Off

Take note of the following when switching off the printer:

When LPD Spool is set to Memory (spool mode)

All the print data spooled to the printer memory, including print data which is being output, will be deleted. When the printer is switched on again, the print data will not be found.

However, if the printer is switched off immediately after the print data has been sent, the data may be stored on the PC. In this case, when it is switched on again, the stored print data will be printed first even if new print data has been specified.

When LPD Spool is set to Hard Disk (spool mode)

All the spooled print data, including print data which is being printed, will be saved. When the power is switched on again, the stored print data will be printed first even if new print data has been specified.

14

203

11

When LPD Spool is set to Off (non-spool mode)

All the print data spooled to the printer receive buffer, including print data which is being output, will be deleted. When the printer is switched on again, the print data will not be found.

However, if the power is switched off immediately after the print data has been sent, the data may be stored in the PC. In this case, when the power is switched on again, the stored print data will be printed first even if new print data has been specified.

14.3.3

During Printing

Take note of the following when printing:

When LPD Spool is set to Hard Disk or Memory (spool mode)

If the print data is larger than the hard disk or the remaining memory capacity at the point of receiving data, the data will not be received by the printer.

Some client computers may re-send immediately when the print data has exceeded the receiving capacity. When this occurs, the client computer appears as if it has crashed. To rectify this situation, the client computer must be stopped from sending print data.

When LPD Spool is set to Off (non-spool mode)

The printer will process print data as soon as data is being received. If the printer has accepted a print request from a client computer, it will not receive another print request from another client computer.

When the IP address or computer name is changed

When the IP address or computer name of a PC/workstation is changed, it may not be able to process enquiries or deletion requests from the printer correctly. Make sure the printer is free of all spooled data and then switch off/on the printer.

The function to stop/eject print data spooled to the printer spool can be setup from the control panel. Refer to "3.3 Cancelling Printing from Printer" and "3.4 Forced Outputting" for information on the setup method.

204

14.4

On Using SMB

Be aware of the following precautions and limitations when using the printer with SMB.

14.4.1

During Setup

Setting up the printer

Be very careful in setting up IP addresses which are controlled as an entire system. Consult your network administrator before defining any IP address.

Depending on the network environment used, it may be necessary to set up the subnet mask and gateway. Consult your network administrator to set up the necessary items.

If setting the port to

Enable

leads to insufficient memory, a message to that effect will be displayed on the control panel and the port status may be set to

Disable

automatically. When this happens, set the ports which are not in use to

Disable

, change the memory size, or install more memory.

Specify the size for the receive buffer memory (SMB spool) as required by the environment. If the size of the receive buffer memory (SMB spool) is smaller than the file data to be received, the data may not be received.

Setting up the PC/workstation

Be very careful in setting up IP addresses which are controlled as an entire system. Consult your network administrator before defining any IP address.

Before setting any network (such as the IP address) to a host being used under Network

Information Service (NIS), consult the NIS administrator.

14.4.2

During Switching Power On/Off

Take note of the following when switching off the printer:

When SMB Spool is set to Memory (spool mode)

All the print data spooled to the printer memory, including print data which is being output, will be deleted. When the printer is switched on again, the print data will not be found.

However, if the printer is switched off immediately after the print data has been sent, the data may be stored on the host computer. In this case, when it is switched on again, the stored print data will be printed first even if new print data has been specified.

When SMB Spool is set to Hard Disk (spool mode)

All the spooled print data, including print data which is being printed, will be saved. When the power is switched on again, the stored print data will be printed first even if new print data has been specified.

When SMB Spool is set to Off (non-spool mode)

All the print data spooled in the printer receive buffer, including print data which is being output, will be deleted. When the printer is switched on again, the print data will not be found.

205

14

11

However, if the power is switched off immediately after the print data has been sent, the data may be stored in the host device. In this case, when the power is switched on again, the stored print data will be printed first even if new print data has been specified.

14.4.3

During Printing

Take note of the following when printing:

When SMB Spool is set to Hard Disk or Memory (spool mode)

If the print data is larger than the hard disk or the remaining memory capacity at the point of receiving data, the data will not be received by the printer.

Some client computers may re-send immediately when the print data has exceeded the receiving capacity. When this occurs, the client computer appears as if it has crashed. To rectify this situation, the client computer must be stopped from sending print data.

When SMB Spool is set to Off (non-spool mode)

The printer will process print data as soon as data is being received. If the printer has accepted a print request from a host computer, it will not receive another print request from another host computer.

When the IP address or computer name is changed

When the IP address or computer name of a PC/workstation is changed, it may not be able to process enquiries or deletion requests from the printer correctly. Make sure the printer is free of all spooled data and then switch off/on the printer.

The function to stop/eject print data spooled to the printer spool can be setup from the control panel. Refer to "3.3 Cancelling Printing from Printer" and "3.4 Forced Outputting" for information on the setup method.

When printer is in offline mode

If the printer receives print request from a host device when it is in offline mode, it will not receive the data and an error message dialog box will be displayed on the host device.

However, with SMB, print data will be sent from the host computer even in offline mode.

Deleting jobs

For Windows NT 4.0, you cannot delete jobs if it is not installed with Service Pack 3 and above. If you delete jobs while the computer is receiving data, an error message will be displayed. When this happens, the Retry button on the error message is not effective.

206

Troubleshooting

15.1 When Problems Occur........................................................................ 208

15.2 When the Print Quality is Poor ........................................................... 212

15.3 Using the Direct Print Utility ............................................................ 216

15.4 Using NetWare ................................................................................... 218

15.5 Using TCP/IP ..................................................................................... 223

15.6 Using SMB ......................................................................................... 225

15.7 Using Internet Services ...................................................................... 228

15.1

When Problems Occur

Check the conditions of the printer again before treating it as a breakdown.

If messages are displayed, carry out treatment accordingly.

If the print quality is poor, proceed to "15.2 When the Print Quality is Poor" to carry out the appropriate treatment.

• This printer uses precision parts and high voltage.

Never open or remove machine covers that are secured with screws unless specifically instructed in the Operating Instructions (For Copier). A high voltage component can cause a shock hazard.

• Do not try to alter the machine configuration, or modify any parts. An unauthorized modification can cause smoke or fire.

Condition

No power.

Cannot print.

Cause

Are the printer breaker switch and power switch turned on?

Is the power cord securely connected?

Is the power voltage suitable?

Is the machine offline or in the setting mode of the Tools Mode screen?

Is there any message being shown on the display?

Treatment

Turn on the printer breaker switch and power switch.

Turn off the power switch and check that the power cord is plugged in properly.

Then turn on the power switch.

Check that the power source is

120V, 15A; or 220-240 V, 7 A.

Check that the power capacity matches the specified printer highest consumption power:

1.35 kW (120 V model)

1.20 kW (220-240 V model).

Treat according to the displayed condition:

• "Offline"

Select

Online

from the

Print

Mode

screen (

Menu

screen

>

Print Mode)

.

• Others

Exit the

Tools Mode

screen.

"Chapter 3 Useful

Operations";

"Chapter 13 Configuring by the Tools Mode Screen"

Treat according to the message displayed.

208

15.1 When Problems Occur

Condition

Cannot print .

Cause

Is the interface cable securely connected?

Is the interface card activated?

When the printer and the host computers are connected by a parallel interface cable, the host computer is not responding to bidirectional communication.

Is the operating environment of the host computer correctly set?

Is the memory capacity enough?

Printing is done on a paper size different from the one specified in the printing instruction.

Is a different paper size being set?

Cannot print although paper size has been set and printing instruction sent. The following message is also printed in the print history report:

"APS Disabled (APS OFF or Machine Malfunction)".

1. Is

Tools Mode

>

Common

Settings

>

System Setup

>

Print

Mode:Forced Print

set to

No

(Cancel Print)

?

2. Are all the trays in

Tools

Mode>Common Settings

>

Paper Tray Attributes

>

Trays

for APS/ATS

set to

Disable

?

Treatment

Turn the switch off and check the interface cable connection.

Check the port status of the interface.

"Chapter 13 Configuring by the Tools Mode Screen"

By default, the bidirectional communication setting of the printer is set to ON. If the host computer is not responding to bidirectional communication, printing cannot be done. In this case, turn the bidirectional communication setting to OFF from the printer control panel and then print again.

"Chapter 13 Configuring by the Tools Mode Screen"

Check the operating environment of the host computer such as the printer driver.

Contact your authorized Panasonic representative to install additional memory.

When the memory capacity is not enough, the printer will disable the interface automatically and reboot.

Replace with the correct paper size and print again.

Operating Instructions (For

Copier)

Set

Print Mode:Forced Print

to

Yes (Change Size).

Once this is done, the paper tray with the closest paper size to the specified size will be selected for printing if there is no such size in the selected paper tray.

Set the paper tray to be used for

APS (Auto Paper Selection) to

Enable

.

"Chapter 13 Configuring by the Tools Mode Screen"

209

15

15.1 When Problems Occur

Condition

When printing color document, lines might not be printed.

No printing is sent but display shows "Printing".

Cause

Is the line set to the finest width?

Is the power of the host computer turned on after the printer has been turned on?

Treatment

From the "Graphics" tab of the printer properties dialog box, select

Raster

for

Graphics Mode

. Or from the application program, select a thicker width for the line or darken the color.

Press the

Job Status Stop

button to display the Job Status

Check screen. Select jobs with the

"Printing" status. Then select

Stop

on the screen and press the

Clear

C

button on the control panel.

Check that the power of the host device is switched on.

Poor print quality.

There might be an image error.

Paper cannot be output.

The paper tray is stuck.

Error code 086-701 or 086-

705 is displayed.

Data is left in the machine.

Has the cover been opened and the power switched off during printing?

Has the Memory Changes setting been changed at the Tools Mode screen?

"15.2 When the Print

Quality is Poor"

Stop printing or force the remaining data to be output.

"3.3 Cancelling Printing

from Printer";

"3.4 Forced Outputting"

Switch off the power without forcefully moving the paper tray.

After a few seconds, switch it on.

Check that the printer is in the state to receive data and then push in/pull out paper tray.

Press the

Job Status Stop

button.

210

15.1 When Problems Occur

Condition

Output without stapling/ punching despite stapling/ punching instructions from the client.

After paper of the wrong sizes in the paper tray have been replaced with the correct one, any printing specified to be output from the tray will result in paper jam. Or the message "Put in

XX-sized paper" is displayed.

Cause

Has stapling instructions been issued to just 1 page of paper.

Have the paper size been specified by the Tools Mode screen?

Treatment

Is the paper in the paper tray of the same size and orientation as that specified at the client?

When issuing double stapling

(left/right/top) instruction to B5/

A4/8.5 x 11" paper, the print job might be output without stapling/ punching. When this happens, change the paper to a different orientation and from the Tools

Mode screen, change the paper size.

Has stapling/punching instructions been issued to documents of mixed sizes?

Documents of mixed sizes cannot be stapled/punched.

Has stapling instructions been issued to more than 50 pages of paper?

Only 2-50 pages of paper can be stapled.

When paper of a different size have been set in the paper tray, always specify the paper size by the Tools

Mode screen.

Operating Instructions (For

Copier)

When printing has not been correctly processed, the information will be saved in Job History Report.

When printing has not been processed, make use of the Job History feature to check the print processing condition. Print data that cannot be correctly processed might be discarded.

"12.2 How to Print Report/List" for details on how to print the Job History.

15

211

15.2

When the Print Quality is

Poor

When the print quality is poor, carry out the necessary treatment according to the condition as close to those listed below as possible. When printing documents with large amount of data, the resolution might decrease. Increasing the PCL memory data might prevent a decrease of resolution.

Also, depending on the application, things that are not visible on the screen might be printed and details might not be clearly printed. Increasing the PCL memory might solve this problem.

If the print quality does not improve after the treatment, contact your local authorized Panasonic service representative.

Condition

Printing is not clear (faded, not sharp).

Black spots printed.

Cause

The paper has excessive moisture.

The drum or toner cartridge is defective or damaged.

The toner in the toner cartridge has been used up.

The paper used is not suitable.

The drum or toner cartridge is defective or damaged.

Treatment

Replace with new paper.

Operating Instructions (For

Copier)

Replace with a new drum or toner cartridge.

Operating Instructions (For

Copier)

Replace with new toner cartridge.

Operating Instructions (For

Copier)

Load the suitable paper.

Operating Instructions (For

Copier)

Replace with a new drum or toner cartridge.

Operating Instructions (For

Copier)

Black spots printed.

The drum or toner cartridge is defective or damaged.

Replace with a new drum or toner cartridge.

Operating Instructions (For

Copier)

212

15.2 When the Print Quality is Poor

Condition

Stains at equal intervals

Cause

The transportation route for the paper is stained.

The drum or toner cartridge is defective or damaged.

Treatment

Print a few more pages and send the job again.

Replace with a new drum or toner cartridge.

Operating Instructions (For

Copier)

White spots in the printed black portion.

The paper used is not suitable.

The drum or toner cartridge is defective or damaged.

Load the suitable paper.

Operating Instructions (For

Copier)

Replace with a new drum or toner cartridge.

Operating Instructions (For

Copier)

Smudges when scrubbed with fingers.

The paper has moisture.

The paper used is not suitable.

The front cover is not completely closed.

Replace with a new paper.

Operating Instructions (For

Copier)

Replace with suitable paper.

Operating Instructions (For

Copier)

Close the front cover.

Page is printed completely black.

The drum or toner cartridge is defective or damaged.

May be due to high voltage problems.

Replace with a new drum or toner cartridge.

Operating Instructions (For

Copier)

Contact your local authorized

Panasonic service representative

15

213

15.2 When the Print Quality is Poor

Condition

Nothing is printed.

Character void.

Cause

Multiple sheets of paper are fed at once (double feeding).

The toner in the toner cartridge has been used up.

The drum or toner cartridge is defective or damaged.

May be due to high voltage problem.

The paper has moisture.

The paper used is not suitable.

Treatment

Fan the paper and load it again.

Operating Instructions (For

Copier)

Replace with a new toner cartridge.

Operating Instructions (For

Copier)

Replace with a new drum or toner cartridge.

Operating Instructions (For

Copier)

Contact your local authorized

Panasonic service representative

.

Replace with new paper.

Operating Instructions (For

Copier)

Replace with suitable paper.

Operating Instructions (For

Copier)

The drum or toner cartridge is not properly set.

Set the drum or toner cartridge properly.

Operating Instructions (For

Copier)

214

Condition

Paper has wrinkles.

Printing smeared.

15.2 When the Print Quality is Poor

Cause

The paper used is not suitable.

The paper used is from different reams.

Treatment

Replace with suitable paper.

Operating Instructions (For

Copier)

Replace with suitable paper.

Operating Instructions (For

Copier)

The paper has moisture.

Replace with new paper.

Operating Instructions (For

Copier)

Vertical white strips.

Printing is slanted.

The drum or toner cartridge is not correctly set.

The drum or toner cartridge is defective or damaged.

Toner in the toner cartridge has been used up.

The guide clips of the paper tray are not set in the correct positions.

Adjust and set it correctly.

Operating Instructions (For

Copier)

Replace with a new drum/toner cartridge.

Operating Instructions (For

Copier)

Replace with a new toner cartridge.

Operating Instructions (For

Copier)

Adjust and set the side guide and end guide correctly.

Operating Instructions (For

Copier)

15

215

15.3

Using the Direct Print Utility

This section provides information on the possible causes, status displays, verifying methods and recommended actions pertaining to errors which may occur when the printer is used with the Direct

Print Utility.

networks.

Cause

The printer and the PC are connected to different

An error has occurred on the network between the PC and the printer. Connection cannot be established.

The IP address of the printer is entered wrongly.

The printer is switched off after the print instruction has been sent from the PC. Or the print instruction is sent to the printer which is switched off.

Print instructions from multiple PCs are sent to the printer at the same time.

Printing files cannot be spooled due to insufficient disk capacity of the PC.

Status Display

Unable to print (Network Error)

Verification Check with the system administrator of the network to verify that the network connecting the PC and that connecting the printer are linked by a router or a gateway.

Action

Treatment

Connect the printer directly to the network connecting the PC.

Status Display

Unable to print (Network Error)

Verification -

Action Ask the system administrator of the network to check the network for errors.

Status Display

Unable to print (Network Error)

Verification From the printer window, select

Properties

"Printer" menu. Click the "Details" tab of the dialog box displayed. Then select

Port Settings

. Compare the IP addresses in the "FX TCP/IP DPU Port Setup" dialog box and the printer settings list.

from the

Action

"12.1.2 Printer Settings List" for the way to output a printer settings list.

Enter the correct IP address set at the printer, in the

"FX TCP/IP DPU Port Setup" dialog box.

Status Display

Unable to print (Network Error)

Verification Check whether or not the printer is switched on.

Action Switch on the printer.

Status Display

Unable to print (Network Error)

Verification -

Action - (

Printing will be reprocessed automatically.

)

Status Display

Unable to print (Spool Error)

Verification Double-click

My Computer

and right-click the disk installed with Windows 95/98/Me (e.g. C-drive).

Select

Properties

from the menu displayed and the check the free space available.

Action After erasing unnecessary files to increase the free space available, select

Pause Printing

from the

"Document" menu of the "Printer" window to enable printing to restart.

216

Cause

The spool setting is not correct.

15.3 Using the Direct Print Utility

Treatment

Status Display -

(The print processing cannot be completed and nothing will be printed)

Verification From the window of the printer, select

Properties

from the "Printer" menu. On the "Details" tab, check that

FX TCP/IP DPU Port

is displayed at

Print to the following port

. Click

Spool Settings

to display its dialog box. Check if the "Print directly to the printer" radio button is selected.

Action Change the spool setting by selecting any other radio button other than

Print directly to the printer

.

217

15

15.4

Using NetWare

This section provides information on the possible causes, verifying methods and recommended actions pertaining to errors which may occur when using the printer with NetWare.

15.4.1 The printer is not Printing

Cause

The network component is not compatible with the auto setup of the frame type.

There is a breakdown in the network from the workstation to the printer.

The user name and group name are not registered in User of the print queue.

Verification

Check if the data link lamp of the network component board connected to the printer is on.

Check if the frame type of file server in the network is similar.

Using NWADMIN from the workstation, check if the target printer object can be seen.*

Using NWADMIN from the workstation, and referring to the target queue object, check if the user name and group name are registered in User*.

Jobs cannot be sent to the print queue.

Jobs cannot be sent to the print queue.

Using PCONSOLE, check if Yes is set up for "User can register with the queue" at the Current Queue

Status of Print Queue Information.

Using NWADMIN from the workstation, check if the operator flag is checked by Recognition of the target print queue.*

Action

From the printer, set up the frame type specified to the file server which you want to connect.

Switch the network cable between the workstation and printer that cannot be used for transmitting.

1. Re-send the print jobs to a print queue which is correctly registered with the user name or group name at User of Print

Queue Information.

2. Using NWADMIN from the workstation, register the user name and group name at User of Print Queue Information.*

Using PCONSOLE, set it to Yes.

Using NWADMIN from the workstation, check if each item of the operator flag is checked by

Recognition of the target print queue. *

The user name and group name are not registered in the print server user of the print server.

Using NWADMIN from the workstation, check if the user name and group name are registered with the User of the target print server.*

1. Re-send the print jobs to a print queue which is correctly registered with the user name or group name at User of Print

Server Information.

2. Using NWADMIN from the workstation, register the user name and group name at User of the target print server.*

218

15.4 Using NetWare

Cause

The print queue to which the job is sent is not assigned to the printer.

Verification

Using NWADMIN from the workstation, check if the target printer is assigned to the serviced printer in the list under User of the target print server.*

The print queue has exceeded the maximum number of supported queues of the printer

(in the print server mode).

Using NWADMIN from the workstation, check if the desired print queue is assigned to the assigned print queue of the target print queue.*

Action

1. Re-send the job to a print queue registered with user name and group name at User of Print

Server Information.*

2. Using NWADMIN from the workstation, check if the user name and group name are registered at User of the target print server.*

Re-send the job to a print queue assigned to the printer.*

The slave file server is not set up (in the bindery service mode).

Using PCONSOLE from the workstation, check if the slave file server is registered in the Service

NetWare Server by the print server of the Print Server Information. *

Using PCONSOLE from the workstation, reflect the setting parameter after having registered the slave file server.

The print type is incorrect.

Using PCONSOLE from the workstation, check if Printer:

Parallel, Port: LPT1, Position: Auto mode (local) is defined for Printer

Information > Printer > Printer xxx

Environment .*

Using PCONSOLE from the workstation, set Printer: Parallel,

Port: LPT1, Position: Auto mode

(local) and reflect the parameter.*

The setting for the slave file server is incorrect (in the bindery service mode).

Using PCONSOLE from the workstation, check if the printer type has been set up as Defined at the Print Server Information >

Printer > Printer xxx Environment

Setting.*

The paper number of the print job and that of the loaded paper are different.

Using PCONSOLE from the workstation, check if the first page paper number of the environment setting after selecting the target printer is similar to the job number.*

Print job data format and workstation print environment setting are not similar.

-

The level setting for the IPX checksum is incorrect.

If it is not Defined, change it to

Defined and reflect the parameter.*

Using PCONSOLE from the workstation, make the first page paper number and job number similar in the target printer environment setting.*

At the console screen of the file server, execute a set command and check if the IPX checksum is set to level 2.

When printing bindery-format file using PostScript language, enable

TBCP at the printer. When using

Windows at the workstation, set do not output Ctrl-D.

At the console screen of the file server, enter the following command and set the IPX checksum to level 0 or 1.

set Enable IPX Checksum=X

(X: 0 or 1)

219

15

15.4 Using NetWare

Cause

The level setting for the NCP packet signature is incorrect.

The default printer name is incorrect.

Verification

At the console screen of the file server, execute a set command and check if the NCP packet signature is set to level 3.

Print the Printer Settings List or output the Start Up Page. Check the lower six characters (3 bytes) of the MAC address.

Action

At the console screen of the file server, enter the following command, and after setting the

NCP packet signature to either level

0, 1 or 2, restart the file server:

set NCP Packet Signature

Option=X (X: 0, 1 or 2)

1. Set up a printer name which uses the correct MAC address.

2. Set up any printer name except the default.

The directory tree name is not set.

Context is not set.

Print the Printer Settings List and check if the tree name is specified.

Print the Printer Settings List and check if the context is specified.

Set the tree name.

Set the context.

Connected to another printer object.

Using NWADMIN from the workstation, check if the object is correctly assigned by the layout information of the desired print server.*

1. Using the "PCL Printer Driver,

Utilities & Documentation" CD-

ROM from the workstation, set the file server name, tree, context, active mode correctly.

2. Using the "PCL Printer Driver,

Utilities & Documentation" CD-

ROM from the workstation, set another host name.

Activate the NetWare port.

NetWare port cannot be activated.

File server is down.

Print the Printer Settings List.

Search for the target file server in

Network Neighborhood on

Windows.

Activate the file server.

There are printers with similar host name on the network.

Switch off the printer, using

NWADMIN from the station, check that the status of the concerned printer object is job waiting.

Using Internet Services from the workstation, set the file server name, tree, context, active mode is correctly set.

Network port is not activated.

Print the Printer Settings List, check if the network number when using

IPX/SPX is at 0000000 (NetWare server down). Also, check if the IP address when using TCP/IP is at

0.0.0.0 (fixed IP not set or address supply server (DHCP) is down).

For IPX/SPX, activate NetWare.

For TCP/IP, set the fixed IP address or activate the address supply server (DHCP).

* Refer to NetWare online documentation for details on the way to set and check.

220

15.4 Using NetWare

15.4.2

When "Switch Off the Power" Appears

Cause

An error occurs in the

NetWare interface.

Verification

-

Action

Switch Off, and then On the power.

15.4.3

Unable to Obtain Desired Print Results

Cause

The print language of the print job and that setup at the printer are different.

Verification

Check the print language of the printer.

Action

Set the same print language for the print job and the printer.

15

221

15.4 Using NetWare

15.4.4

No Notification

This section provides information on the possible causes, verifying methods and recommended actions when there are no messages on the workstations which have been sent print instructions.

No notification of printer errors

Cause

Not registered in the Notify

Candidate List of the print server.

Verification

Using PCONSOLE from the workstation, check if the user name and group name are registered in Print Server

Information > Printer > Printer xxx

Environment Settings > Notify.

Action

Register the user name and group name in the Notify.

No end-of-job notification

Cause

When sending jobs from the workstation, the NOTIFY option has not been specified.

The NetWare CASTOFF utility is executed on the workstation.

Verification

Check if the NOTIFY option is specified when jobs are sent.

-

Action

When jobs are sent, specify the

NOTIFY option.

Execute the NetWare CASTON utility on the workstation.

222

15.5

Using TCP/IP

This section provides information on the possible causes, verifying methods and recommended actions pertaining to errors which may occur when the printer is used with TCP/IP (LPD).

15.5.1 When Using Windows 95/98/Me

The printer and the PC are connected to different networks.

Cause

An error has occurred on the network between the PC and the printer. Connection cannot be established.

The IP address of the printer is entered wrong.

The printer is switched off after the print instruction has been sent from the PC. Or the print instruction is sent to the printer which is switched off.

Print instructions from multiple PCs are sent to the printer at the same time.

Printing files cannot be spooled due to insufficient disk capacity of the PC.

Status Display

Unable to print (Network Error)

Verification Check with the system administrator of the network to verify that the network connecting the PC and that connecting the printer are linked by a router or a gateway.

Action Connect the printer directly to the network connecting the PC.

Status Display

Unable to print (Network Error)

Verification -

Action Ask the system administrator of the network to check the network for errors.

Status Display

Unable to print (Network Error)

Verification From the printer window, select

Properties

"Printer" menu. Click the "Details" tab of the dialog box displayed. Then select

Port Settings

. Compare the IP addresses in the "FX TCP/IP DPU Port Setup" dialog box and the printer settings list.

from the

Action

"12.1.2 Printer Settings List" for the way to output a printer settings list.

Enter the correct IP address set at the printer, in the

"FX TCP/IP DPU Port Setup" dialog box.

Status Display

Unable to print (Network Error)

Verification Check whether or not the printer is switched on.

Action Switch on the printer.

Status Display

Verification

Action

-

Unable to print (Network Error)

- (

Printing will be reprocessed automatically.

)

Status Display

Unable to print (Spool Error)

Verification Double-click

My Computer

and right-click the disk installed with Windows 95/98/Me (e.g. C-drive).

Select

Properties

from the menu displayed and the check the free space available.

Action After erasing unnecessary files to increase the free space available, select

Pause Printing

from the

"Document" menu of the "Printer" window to enable printing to restart.

15

223

15.5 Using TCP/IP

15.5.2

When Using Windows NT 4.0

When the printer is not printing

Cause

Incorrect IP address.

If LPD spool is set to memory, the print data sent by the user in a single print instruction has exceeded the upper limit of the receiving capacity set up by the control panel of the printer.

An irrecoverable error has occurred during printing.

Verification

Ask the network administrator to check that the IP address is correct.

Check the upper limit of the receiving capacity from the touch panel display and compare it with the print data which was sent in the single print instruction.

Check the display of "LPD Error" from the printer control panel.

Action

Set up the correct IP address for the printer.

1. If a single file of print data has exceeded the upper limit of the receiving capacity, split the file into smaller ones to keep them below the upper limit of the receiving capacity.

2. If multiple files have exceeded the upper limit of the receiving capacity, reduce the number of files which can be sent at one time.

Power Off and On the printer.

The transport protocol is different from that of the client.

The data format of the print data to be processed by the printer and that sent by the client are different.

Check the selected transport protocol on the touch panel display.

Select the same transport protocol as that of the client.

-

If the client is running Windows, disable the output function of Ctrl-

D.

Refer to the PRINTER.WRI file provided by Windows 4.0 for the details.

Unable to obtain the desired print results

Cause

The specified print language and that of the print data are different.

If it is running in Windows, the printer driver for this printer has not been used (a printer driver from another company has been used).

Verification

Check the specified print language and that of the print data.

Check that the printer driver which came with this printer has been selected.

Action

Specify the same print language as that of the print data.

Select the printer driver which came with this printer. If it does not appear on the selection list, install and select the printer driver.

If a printer driver from another maker is used, the printer may not print properly.

224

15.6

Using SMB

This section provides information on the possible causes, verifying methods and recommended actions pertaining to errors which may occur when using the printer with SMB.

15.6.1 The Printer is not Found

Cause

The transport protocol used by the client computer and printer is different.

There are multiple browsers.

Verification

On the client computer, you can find the printer when searching it as another computer (Start > Find >

Other computer) but not when searching it in the Network

Neighborhood.

(same as above)

Action

Specify similar transport protocol for

SMB in the printer and every client computer.

When there are multiple client computers within the same workgroup, change the Auto Master

Mode in the config.txt file to Off, and then reboot the printer.

The network (subnet) is wrong.

(same as above)

Name search of the host name is not working correctly (for TCP/

IP)

When specifying the printer IP address and the responded Host

Name do not respond to the PING command issued.

When the printer and client computer is in a different network, contact your system administrator.

Check the settings of the config.txt

file (WINS Primary Server, WINS

Secondary Server, Subnet Mask) with the settings on the client computer (e.g. WINS, DNS,

LMHOST).

The host name specified already exists in the printer.

Check if Status of SMB on the

Printer Settings List indicates that the host name is repetitive.

Change the Host Name of the config.txt file to another name not in use.

Or, change the host name used by

Internet Services to another name not in use.

Or, reset the printer settings to default values.

15

225

15.6 Using SMB

15.6.2 Cannot Print

Cause

The printer is processing print instructions from other client computer.

(only for non-spool mode)

The printer has exceeded the maximum number of connections allowed.

Verification

Check if the printer is processing print instructions. (For Windows

95/98, Windows NT 4.0, an error message about insufficient storing space for waiting print jobs is displayed.)

Check if the printer is processing requests (e.g. print instruction, status enquiry) from multiple client computers at the same time.

(For Windows 95/Windows 98, an error message about remote computer cannot be used is displayed.)

Action

After the printer has processed the print instructions, send a print job to the printer or at the printer, change the mode to spool mode.

Wait for a while, then send print instruction again.

Or, increase the value of Maximum

Sessions on the config.txt file, and then reboot the printer.

(only for printer system administrator)

15.6.3 Cannot Delete Documents from the Printer Window

Cause

Tried to delete all documents displayed in the printer window.

(only possible for printer administrator)

Verification

Check if you are trying to delete print jobs from the Printer menu on the printer window.

Action

Select the document you want to delete, and then select

Cancel

Printing

from the Document menu.

The Owner of the document is not correct.

Check if Owner of the selected document is similar to the name used for logon to Windows.

Logon to Windows again using the name of Owner of the document, and then delete the document.

Service Pack 3.0 and above is not installed.

(for Windows NT 4.0)

Check the version of Service Pack installed. Click on Start, then Run and type in "winver" (without the quotes) and hit enter.

Install Service Pack 3.0 or above.

226

15.6 Using SMB

15.6.4 Cannot Perform Auto Driver Downloading

Cause

The auto driver downloading feature is not working.

Different types of printer drivers are saved.

Verification

Check the setting of Auto Driver

Download in the config.txt file.

(only for printer administrator)

Check the printer type, and then check if the correct printer driver is saved.

Action

Set Auto Driver Download to Enable in the config.txt file, and then reboot the printer.

(only for printer administrator)

After saving the correct printer driver, reboot the printer.

(only for printer administrator)

The printer driver is not saved within two levels from the drivers folder.

Check if the folder containing the printer driver is within two levels from the drivers folder.

The printer driver is not saved in a folder which is named within eight alphanumeric characters.

Open driver.txt of the drivers folder, and check if there is a message about the folder name not within the 8.3 format.

Save the printer driver inside a folder within two levels from the drivers folder, and then reboot the printer.

(only for printer administrator).

Change the folder name to one within eight alphanumeric characters, and then reboot the printer.

(only for printer administrator)

15

227

15.7

Using Internet Services

Cannot be connected to Internet

Services.

Cause

The Please wait message is displayed throughout.

The Refresh button is not working.

Selecting the left frame menu does not change the right frame settings.

The screen display is distorted.

The latest information is not displayed.

The new settings are not reflected by clicking the Apply New Settings button.

Treatment

Is the printer working properly?

Check if the power of the printer is switched On.

Is Internet Services activated?

Print out the Printer Settings List to check.

Is the internet address correctly entered?

Check the internet address again. If cannot be connected, enter the

IP address to connect again.

Is a proxy server used?

Depending on the proxy server, connections might not be made.

Without using the proxy server, either change the browser setting or the address to which you want to connect to one without using the proxy server.

Wait for awhile as instructed.

If nothing happens, try clicking the Refresh button. And even then, if nothing happens, check if the printer is working properly.

Are you using the target OS and browser?

By referring to "10.1.3 Target host computers and browsers", check if the OS and browser you are using can be used.

Change the window size of the browser.

Click the Refresh button.

Is the value entered correct?

If the value entered is not within the correct range, it will be changed to a value within the correct range automatically.

Clicking the Apply New Settings button prompt messages like no data or the server has returned ineffective or unrecognizable response.

Even if the job you want to delete is checked, the selection is unchecked later.

The job cannot be deleted.

When LPD or SMB is selected, a message will appear to say that it is not spool mode.

Is the password correct?

The entry for Confirm Password is not similar to Password. Enter the correct password.

Reboot the printer.

Is the Auto Refresh set?

Either set Auto Refresh Interval of Internet Services Settings on the

Properties tab to Void or to a higher value.

Wait for awhile, and then click the Refresh button. Even if jobs are deleted from LPD of Job List, they might not be deleted from

System. When this happens, delete the job from System again.

After the present page is displayed, the printer might be rebooted.

Click the Refresh button. If nothing happens, try changing from the browser.

228

Appendix

A Main Specifications ........................................................................... 230

B Connectors and Allocation Signal ...................................................... 232

C Printing Data Combined Using Overlays ............................................ 234

D Printing Secured Print and Sample Set Jobs ....................................... 236

A

Main Specifications

A.1

Specifications of the Printer

The specification of the printer model or the main unit (i.e. copier only) with the printer kit installed is as follows:

We regret that improvements in specifications/appearance of the product may be made without prior notice.

Power : 120 VAC, 15 A (60 Hz);

220-240 VAC, 7 A (50/60 Hz)

Power consumption (maximum) : 1.35 kW (120 V model); 1.20 kW (220-240 V model)

Dimensions : (W) 24.4 in.

×

(D) 30.5 in.

×

(H) 42.5 in. (including DADF)

(W) 620

×

(D) 775

×

(H) 1080 mm (including DADF)

Minimum space requirements : (W) 40.0 in.

×

(D) 30.5 in.

(W) 1017

×

(D) 775 mm

Weight : 407 lb

185 kg (main unit + DADF)

Installation space : See below

65.7 in.

-67.6 in.

1668

- 1718

mm

0-2 in./0-50 mm

0-2 in./0-50 mm

0-2 in./0-50 mm

0-2 in./0-50 mm

17.1 in.

434 mm

18.4 in.

493 mm

2 in. /50 mm

65.7 in.

-67.6 in.

1668

- 1718

mm

15.7 in./400 mm

43.4 in. - 45.4 in.

1104 - 1154 mm

18.4 in.

493 mm

27.8 in./705 mm

15.7 in./400 mm

52.4 in. - 54.3 in.

1330 - 1380 mm

2 in./50 mm

230

A.2

Appendix A Main Specifications

Printing Area

The printing area of each paper size is about the area remaining after subtracting 4 mm from all edges of the paper and may change according to each printer control language.

a

Printing area b

Paper size

A3 (297

×

402 mm)

B4 (257

×

364 mm)

A4 (210

×

297 mm)

B5 (182

×

257 mm)

A5 (148

×

210 mm)

A6 (105

×

148 mm)

B6 (128

×

182 mm)

11

×

17" (Ledger)

8.5

×

14" (Legal)

8.5

×

13" (Folio)

8.5

×

11" (Letter)

5.5

×

8.5" (Statement)

8K (267

×

388 mm)

Postcard* (100

×

148 mm)

a

6804

600 dpi

b

9711

5859

4749

4089

3285

2268

2811

6390

4890

4890

4890

3090

6096

2151

8388

6804

5859

4749

3285

4089

9990

8190

7590

6390

4890

8955

3285

• Unit: dot a: scan direction b: sub-scan direction

The postcard feature is not available in some countries.

231

232

B

Connectors and Allocation

Signal

This section describes the parallel interface (centronics/IEEE1284-compliant interface).

Shape of the connector

The printer is installed with the IEEE 1284-B type of interface. The shape of the connector is as follows:

18

1

19

36

Pin arrangement

The pin arrangement of the various signals when bidirectional is OFF is as follows:

Pin No.

7

8

9

5

6

1

2

3

4

10

11

12

13

14

15

16

17

18

Signal name nStrobe

Data1

Data2

Data3

Data4

Data5

Data6

Data7

Data8 nAck

Busy

PError

Select nAutoFd

(RESERVED)

Logic GND

Chassis Gnd

Peripheral Logic High

I/O

I

I

I

I

I

I

I

I

I

O

O

O

O

-

-

O

-

I

Pin No.

23

24

25

26

27

19

20

21

22

28

29

30

31

32

33

34

35

36

Signal name

Signal Ground

Signal Ground

Signal Ground

Signal Ground

Signal Ground

Signal Ground

Signal Ground

Signal Ground

Signal Ground

Signal Ground

Signal Ground

Signal Ground nInit nFault

(RESERVED)

(RESERVED)

(RESERVED) nSelectIn

• Looking from the printer, I is the input signal, O is the output signal, - is not a signal.

• When bidirectional is ON, the connection adheres to the IEEE 1284-B connector

I/O

-

-

-

-

-

-

-

-

-

-

-

I

-

I

-

-

O

-

Appendix B Connectors and Allocation Signal

standard.

Meaning of the signals

When the bidirectional is OFF:

• nStrobe (Pin No.1)

The synchronous signal for the reading of data 1-8; needs the LOW active pulse.

• Data1-8 (Pin No.2-9)

For the 8-bit parallel data input, Data 1 is LSB (lowest bit) and Data 8 is MSB (uppermost bit).

• nAck (Pin No.10)

A LOW active pulse signal which indicates that the received data has been taken in.

• Busy (Pin No.11)

A HIGH active signal which indicates that the printer is unable to receive data.

• PError (Pin No.12)

A HIGH active signal which indicates that there is no more paper.

• Select (Pin No.13)

A HIGH active signal which indicates that it is possible to receive data.

• nAutoFd (Pin No.14)

The signal when the bidirectional is ON.

• Chassic Gnd (Pin No.17)

Connected to frame ground.

• Peripheral Logic High (Pin No.18)

+5V voltage on the printer side.

• Signal Ground (Pin No.19-30)

Connected to the various signal ground.

• nInit (Pin No.31)

The LOW active pulse signal which requests for the initialization of the printer.

• nFault (Pin No.32)

The LOW active signal which indicates that errors such as paper jams have occurred in the printer.

• nSelectIn (Pin No.36)

The signal when the bidirectional is ON.

When the bidirectional is ON:

All connections adhere to the IEEE 1284 connector standard.

233

C

Printing Data Combined

Using Overlays

You can use the overlay feature to combine data for printing.

For example, you can first a create an overlay for a blank form and store it in the printer. Later, you can send the data for the form to the printer to print out the data with the form.

Here, we will explain the process by printing from Word on Windows 98 as an example.

C.1

Depending on the application software, the way to display the printer properties dialog box might be different. Check the manual for the application software used.

Creating an Overlay

First of all, create the overlay.

Procedure

Using the application software, create the form.

From the File menu, select

Print

.

Check that the correct printer is used at the

Name list box, and then click

Properties

.

The printer properties dialog box appears.

Click the Overlays tab.

Create

Create Overlay

.

The Create Page Overlay dialog box appears.

234

C.2

Printing with an Overlay

Next, print your data with the overlay.

Procedure

Appendix C Printing Data Combined Using Overlays

Enter a name for the overlay in the "File name" box.

If you wish, select another directory other than the default C:\pageover.

Enter a name (e.g. "Form1") for the overlay in the "File name" box and then click

OK

.

Click

OK

to close the printer properties dialog box. Then click

OK

to close the

Print dialog box. When a confirmation message, "Create Page Overlay" appears, click

Yes

to confirm.

The overlay will be stored in your computer.

Using the application software, create the data for the form.

From the File menu, select

Print

.

Check that the correct printer is used at the

Name list box, and then click

Properties

.

The printer properties dialog box appears.

Click the Overlays tab.

Select the overlay (e.g. "Form1") to be used from

Overlays

.

Click

OK

to close the printer properties dialog box. Then click

OK

to close the Print dialog box.

The data will be printed with the overlay.

235

D

Printing Secured Print and

Sample Set Jobs

This section explains the Secured Print and Sample Set features.

Secured Print

On the computer, you can attach a password to a print job, send it to the printer for storing, and then print out the job later using the printer control panel. This feature is known as Secured Print. You can also send data to the printer without a password.

This feature is useful for storing frequently used data in the printer, and then using only the printer control panel and not the computer to print it out.

Sample Set

When printing multiple copies, you can print out only the first set to check the printing result first before printing the remaining copies from the printer control panel. This feature is known as Sample Set.

236

D.1

Appendix D Printing Secured Print and Sample Set Jobs

Storing Secured Print/Sample Set Jobs

The following procedure describes how to store a Secured print or Sample set job:

Procedure

Refer to "4.3.1 Accessing the printer properties dialog box" to display the printer properties dialog box.

Click the Paper/Output tab.

From the Job Type list box, select

Secured

Print

or

Sample Set

.

The Secured Print Settings or Sample Set

Settings dialog box appears.

When Secured Print is created

For

User ID

, specify a user ID using 1-24 characters.

This is mandatory. If no user ID is specified, you will be prompted by a warning message.

For

Document Name

, specify a document name using 1-24 characters.

This is optional. If you do not enter a name here, it will be retrieved from the application.

For Secured Print Settings only

For

Password

, specify a password using 1-

4

numbers

.

This is optional. The password specified will be displayed by one * for each number entered.

After

Password

is entered,

Confirm

Password

will be enabled for you to re-enter the password for confirmation.

Click

OK

.

A button,

Secured Print Settings

or

Sample

Set Settings

will become available just below the "Job Type" list box.

237

Appendix D Printing Secured Print and Sample Set Jobs

D.2

Printing Secured Print/Sample Set Jobs

The following procedure describes how to print from the printer control panel, a

Secured print or Sample set job that has been stored in the printer.

Here, we will print a Secured Print job as an illustration.

Procedure

Press the button,

Job Status Stop

on the control panel.

The Job Status screen is displayed.

Click the tab,

Stored Print Job

.

Select

Secured Print

or

Sample Set

, depending on the type of job you want to print.

Here, we will illustrate by selecting

Secured Print

.

238

Appendix D Printing Secured Print and Sample Set Jobs

The list of jobs grouped under user ID appears. Select the job belonging to your user ID.

A Password Entry screen appears.

Enter your password and then

Confirm

.

This Password Entry screen will not appear for Sample Set jobs as well as

Secured Print jobs without a password entered in the printer driver (see Step

of "D.1 Storing Secured Print/Sample Set Jobs").

The list of jobs under your user ID appears.

Select the job that you want to print, and select

Print

.

239

Appendix D Printing Secured Print and Sample Set Jobs

The following screen appears.

For Secured Print job:

The following document will be printed.

User ID : 8888

Document Name : Orange

Stored Date/Time : 2001/05/22 10:27 (AM)

Select whether to save or delete document after printing.

Print and Delete

Print and Save

Cancel Job

Select

Print and Delete

if you want to print and then delete the job.

Select

Print and Save

if you want to print the job without deleting it.

For Sample Set job:

Select

Yes

.

The job will be printed.

240

Glossary

[A3]

420

×

297 mm paper.

[A4]

297

×

210 mm paper.

[A5]

210

×

148 mm paper.

[ACK]

The signal indicating that the printer is ready to receive data from the computer or that data is correctly received.

[B4]

364

×

257 mm paper.

[B5]

257

×

182 mm paper.

[Buffer]

The place where data received by the computer is stored.

[Busy]

Signal indicating that the printer is not able to receive data from the host device.

[CPI]

Stands for Character Per Inch, which is the number of characters that can be printed within a width of 1 inch.

[CR]

Stands for Carriage Return, which is the change of line.

[DTR Control]

Stands for Data Terminal Ready, which is the hardware signal that indicates whether the printer can receive data from the computer.

[DPI]

Stands for Dot Per Inch, which is the number of dots that can be printed within a width of 1 inch.

Used as the unit for resolution.

[DPU]

Stands for Direct Print Utility, a software which uses TCP/IP protocol to allow PC to send and print data directly to a printer located on the same network.

[Emulation]

The ability of the printer to perform the features of other printers.

[Folio]

8.5

×

13" (330

×

216 mm) paper.

[Hard clip area]

The actual rectangular area on the paper which can be printed.

[Statement]

5.5

×

8.5" (140

×

216 mm) paper. Also known as

Half Letter.

[Image Enhancement]

Feature which makes the border between black and white smooth, with rough edges reduced, giving the appearance of a higher resolution.

[Job]

A group of print data. The stopping and output of printing are conducted on a job basis. For mode menu changes, the new settings will be effective from the next job.

[LED]

Stands for Light Emitting Diode.

[Ledger]

11

×

17" (432

×

279 mm) paper.

[Legal]

8.5

×

14" (356

×

216 mm) paper.

[Letter]

8.5

×

11" (279

×

216 mm) paper.

241

Glossary

[NV Memory]

Non-volatile memory which allows the settings of the printer to be maintained even when power is off.

[Page buffer]

The actual place where print data is retrieved and stored. The page buffer memory is secured after the printer memory is allocated to memories such as form memory, receive buffer memory etc., and the size of page buffer memory can be confirmed on the printer settings list.

[Parity check]

The checking of whether the data sent is being received.

[Power Saver]

The feature which saves the power consumption by lowering the temperature of the printer's fuser. The power saver mode is automatically activated when the time set has elapsed after the previous print job.

[Printing area]

The actual area on paper which can be printed.

[Protocol]

The rules of communication necessary for carrying out data transmission.

[RAM]

Stands for Random Access Memory, which is the memory device where information can be retrieved as well as recorded.

[ROM]

Stands for Read Only Memory, which is the memory device specific for the retrieval of information.

[Scaling]

The enlargement and reduction of the input size

(document size) by matching the output size

(paper size).

[Scaling Point]

The limit of the specification of the plotting area.

242

Index

Symbol

2 Sided Print ----------------------------------------- 59, 152

A

All Texts to Black ----------------------------------------- 65

AppleTalk ------------------------------------------------- 11

Audio Tones --------------------------------------------- 184

Auto Configuration -------------------------------------- 55

Auto Driver Downloading --------------------- 116, 227

E

EMF Spooling --------------------------------------------- 63

Error History Report ------------------------------------- 166

Error Report ----------------------------------------------- 55

Ethernet interface ------------ 2, 8, 9, 12, 26, 27, 123

EtherTalk -------------------------------------------------- 11

B

Booklet Creation ----------------------------------------- 69

Bypass Feed Orientation -------------------------------- 55

C

Cancelling Printing from Printer

Jobs in Process -------------------------------------- 33

Jobs in the Printer ---------------------------------- 34

Change of Access Number ---------------------------- 186

Collate ----------------------------------------------- 44, 60

Common Settings -------------------------------------- 184

Copies ------------------------------------------------------ 59

Copy Mode Settings ----------------------------------- 186

Custom Paper Size --------------------------------------- 59

F

Feature Defaults of Copy Mode Settings --------------------------- 186 of Print/Scan Mode Settings --------------------- 187

Finisher ------------------------------------------- 54, 58, 60

First Sheet ------------------------------------------------- 63

Fit To Output Size ---------------------------------------- 70

Flip on Long Edge ---------------------------------------- 59

Flip on Short Edge ---------------------------------------- 59

Font ------------------------------------------------------- 152

Forced Outputting in Emulation Mode --------------------------------- 36

Waiting Jobs ---------------------------------------- 35

Form Lines ---------------------------------------------- 155

G

Graphics Mode ------------------------------------------- 64

D

Delete Stored Print Job -------------------------------- 194

Device Halftoning ---------------------------------------- 55

Direct Print Utility ---------------------------------------- 9

Installing --------------------------------------------- 81

Setup of the printer --------------------------------- 78

Troubleshooting ---------------------------------- 216

Uninstalling ----------------------------------------- 90

Using ------------------------------------------------- 76

Dynamic Host Configuration Protocol (DHCP) ----- 17

H

Halftone ---------------------------------------------------- 64

Halftone Color Adjustment ----------------------------- 66

Hex Dump ----------------------------------------------- 155

High Capacity Feeder (HCF) --------------------- 54, 57

I

Image Enhancement -------------------------- 44, 65, 155

Image Orientation ----------------------------------------- 59

Image Quality ------------------------------------------- 186

Initialize Memory/Disk -------------------------------- 194

Internet Printing Protocol (IPP) ----------------- 12, 132

Internet Services -------------------------- 107, 140, 228

243

Index

IP Address ------------------------------------------------- 13

IPX Start Up -------------------------------------------- 188

IPX/SPX Setting ---------------------------------------- 188

Output Size ---------------------------------------------- 151

Overlays -------------------------------------------- 66, 234

J

Job History Report ------------------------------------- 163

Job Status -------------------------------------------------- 32

Job Type --------------------------------------------------- 56

L

Layout Mode ---------------------------------------------- 68

Logical On Physical ------------------------------------- 70

Low Power Mode ---------------------------------------- 22

LPD -------------------------------------------------------- 21

M

Maximum No. of Sets --------------------------------- 155

Memory Allocation -------------------------------------- 28

Memory Changes --------------------------------------- 192

Multi-Up --------------------------------------------------- 68

N

NetBEUI -------------------------------------- 8, 102, 104

NetWare ------------------------------------- 11, 122, 200 precautions/limitations -------------------------- 200

Setup for the client ------------------------------- 129

Setup for the printer ------------------------------ 125

Troubleshooting ---------------------------------- 218

NetWare Administrator (NWADMIN) ------------- 124

Network Printer Environments -------------------------- 8

Network Settings --------------------------------------- 187

No Rotation on Same Sheet ---------------------------- 69

O

Original Size Defaults --------------------------------- 186

Original/Paper Size Sensing -------------------------- 184

Output Destination -------------------------------- 58, 151

Output Orientation ------------------------------------- 151

P

Page buffer ------------------------------------------------ 28

Paper Output Options ------------------------------------ 54

Paper Size ------------------------------------------------- 57

Paper Source ---------------------------------------------- 57

Paper Source Options ------------------------------------ 54

Paper Tray ----------------------------------------------- 151

Paper Tray Attributes ---------------------------------- 184

Parallel interface -------------------------------------- 2, 26

PCL 5e ------------------------------------------------------ 6

PCL 6 Settings ------------------------------------------ 151

PCL Fonts List ------------------------------------------ 170

PCL Settings List --------------------------------------- 168

PCONSOLE --------------------------------------------- 124

Pitch ------------------------------------------------------ 155

PJL switch ------------------------------------------------- 44

Point Size ------------------------------------------------ 154

Port Settings

EtherTalk -------------------------------------------- 191

FTP Client ------------------------------------------ 191

Internet Service ------------------------------------ 191

IPP --------------------------------------------------- 192

LPD -------------------------------------------------- 190

NetWare -------------------------------------------- 190

Parallel ----------------------------------------------- 189

Salutation ------------------------------------------- 191

SMB ------------------------------------------------- 190

Poster ------------------------------------------------------- 71

PostScript Fonts List ------------------------------------ 172

PostScript Logical Printer List ------------------------- 176

PostScript Settings List --------------------------------- 176

Power Saver ----------------------------------------------- 22

Print Meter Report ------------------------------------- 174

Print Mode ---------------------------------------------- 150

Print server (PSERVER) mode ----------------------- 122

244

Index

Print/Scan Mode Settings ----------------------------- 187

Printer Driver

"Graphics" tab -------------------------------------- 64

"Layout" tab ----------------------------------------- 68

"Output Options" tab ------------------------------ 60

"Overlays" tab -------------------------------------- 66

"Paper/Output" tab --------------------------------- 56

"Printer" tab ----------------------------------------- 54

"Watermarks" tab ---------------------------------- 72

Installing --------------------------------------------- 45 overview --------------------------------------------- 44

Uninstalling ----------------------------------------- 49

Printer Settings List ------------------------------------ 161

Printing Area -------------------------------------------- 231

Printing from Windows environment ----------------- 30

Punch ------------------------------------------------------- 44

Punch Position -------------------------------------------- 62

T

TCP/IP --------- 8, 9, 10, 12, 13, 78, 82, 94, 102, 108 precautions/limitations -------------------------- 203

Troubleshooting ---------------------------------- 223

Time-Outs ----------------------------------------------- 184

Token Ring ---------------------------- 2, 6, 12, 26, 202

Tools Mode --------------------------------------------- 182

TrueType Mode ------------------------------------------ 65

U

UDP Start Up ------------------------------------------- 188

Use Printer TrueType Fonts ---------------------------- 65

W

Watermarks ----------------------------------------------- 72

WINS Server ---------------------------------------------- 17

R

R/E Presets ---------------------------------------------- 186

Receive buffer -------------------------------------------- 28

Report Settings ----------------------------------------- 185

Report/List ---------------------------------------------- 160

Z

Zoom ------------------------------------------------------- 70

S

Sample Set ----------------------------------------- 56, 236

Screen Layout of Common Settings ------------------------------- 184 of Copy Mode Settings --------------------------- 186 of Print/Scan Mode Settings --------------------- 187

Secured Print ---------------------------------------- 56, 236

Select Substitution Tray --------------------------------- 55

Server Message Block (SMB) -------- 8, 102, 205, 225

Sleep Mode ------------------------------------------------ 22

Staple ------------------------------------------------------- 44

Staple Position -------------------------------------------- 60

Stored Print Job List ----------------------------------- 178

Symbol Set ---------------------------------------------- 154

System Setup -------------------------------------------- 185

245
