Panasonic Stereo Amplifier CY-PAD1003W User manual
4 Channel Power Amplifier
Model:
CY-PA4003W
2 Channel Power Amplifier
Model:
CY-PA2003W
Digital Mono Amplifier
(CY-PA4003W)
Model:
CY-PAD1003W
Operating Instructions
 Please read these instructions carefully before using this product and keep this manual for future reference.
Read the operating instructions for the unit and all other
components of your car audio system carefully before
using the system. They contain instructions about
how to use the system in a safe and effective manner.
Panasonic assumes no responsibility for any problems
resulting from failure to observe the instructions given
in this manual.
This pictograph intends to alert you to
the presence of important operating
instructions. Failure to heed the
Warning instructions may result in severe injury
or death.
This manual uses pictographs to show you how to use
the product safely and to alert you to potential dangers
resulting from improper connections and operations.
The meaning of the pictographs are explained below.
It is important that you fully understand the meanings
of the pictographs in order to use this manual and the
system properly.
Caution
This pictograph intends to alert you to
the presence of important operating
instructions. Failure to heed the
instructions may result in injury or
material damage.
Please follow the laws and regulations
of your province or country for
installation of the unit.
This unit cannot be used alone.
This unit is a power amplifier for use with Panasonic
car audio products and speakers.
For more details about safety information, refer to
the operating instructions for the connected devices.
For power connection, use the optional power cord
specially designed for use with Panasonic car-audio/
AV system.
Power cord kit (option): CA-PAC75
2
CY-PA4003W/PA2003W/PAD1003W
English
English
Safety Information
Warning
Observe the following warnings when using the
unit.
Use the proper power supply.
This product is designed for operation with a negative
grounded 12 V DC battery system. Never operate this
product with other battery system, especially a 24 V DC
battery system.
Do not disassemble or modify the unit.
Do not disassemble, modify the unit or attempt to
repair the product yourself. If the product needs to
be repaired, consult your dealer or an authorised
Panasonic Service Center.
Do not use the unit when it is out of order.
If the unit is out of order (no power, no sound) or in an
abnormal state (has foreign objects in it, is exposed to
water, is smoking, or smells), turn it off immediately
and consult your dealer.
Refer fuse replacement to qualified service
personnel.
When the fuse blows out, eliminate the cause and have
it replaced with the fuse prescribed for this unit by a
qualified service engineer. Incorrect replacement of
the fuse may lead to smoke, fire, and damage to the
product.
When replacing one fuse which has blown, replace
other fuses at the same time.
In some cases, fuses may deteriorate without failing.
Using different substitutes or fuses with higher ratings,
or connecting the unit directly without a fuse, could
cause fire or damage to the unit. If the replacement fuse
fails, contact your nearest Panasonic Service Center for
service.
Warning
Observe the following warnings when installing.
Disconnect the lead from the negative () battery
terminal before installation.
Wiring and installation with the negative () battery
terminal connected may cause electrical shock and
injury due to a short circuit.
Some cars equipped with the electrical safety
system have specific procedures of battery terminal
disconnection.
FAILURE TO FOLLOW THE PROCEDURE MAY
LEAD TO THE UNINTENDED ACTIVATION OF THE
ELECTRICAL SAFETY SYSTEM RESULTING IN
DAMAGE TO THE VEHICLE AND PERSONAL INJURY
OR DEATH.
Never use safety-related components for
installation, grounding, and other such functions.
Do not use safety-related vehicle components (fuel
tank, brake, suspension, steering wheel, pedals
airbags, etc.) for wiring or fixing the product or its
accessories.
Check for piping, gasoline tank, electric wiring, and
other items before installing the product.
If you need to open a hole in the vehicle chassis to
attach or wire the product, first check where the wire
harness, gasoline tank, and electric wiring are located.
Then open the hole from outside if possible.
After installation and wiring, you should check the
normal operation of other electrical equipment.
The continuation of their using in abnormal conditions
may cause fire, electrical shock or a traffic accident.
In the case of installation to an airbag-equipped
car, confirm warnings and cautions of the vehicle
manufacturer before installation.
Make sure the leads do not interfere with driving or
getting in and out of the vehicle.
Failure to heed this caution may result in an accident
and/or injury.
Caution
Observe the following cautions when using this
unit.
Turn off the power supply before changing the
switch setting.
Keep the sound volume at an appropriate level.
Keep the volume level low enough to be aware of road
and traffic conditions while driving.
This unit is designed for use exclusively in
automobiles.
Do not operate the unit for a prolonged period with
the engine turned off.
Operating the audio system for a long period of time
with the engine turned off will drain the battery.
Do not expose the unit to direct sunlight or
excessive heat.
Otherwise these will raise the interior temperature
of the unit, and it may lead to smoke, fire, or other
damage to the unit.
Do not use the product where it will be exposed to
water, moisture, or dust.
Exposure of the unit to water, moisture, or dust may
lead to smoke, fire, or other damage to the unit. Make
especially sure that the unit does not get wet in car
washes or on rainy days.
Stop to use the unit when the red indicator
(PROTECT) lights up.
If the red indicator lights up, this unit will
automatically shut down. Confirm the speaker and
other audio system’s wiring.
Do not touch the heat dissipation region of the
amplifier.
If this unit is operated at a high output continuously,
the upper side of the unit will get very hot. Do not
touch it nor place anything on top of the unit.
Contact your local dealer for information about
battery capacity. (If there is not enough battery
capacity, increase the number of batteries.)
Depending on the way you use this unit, (using at
high volume for extended periods, increasing the
number of amplifiers etc. ) there may be insufficient
battery capacity. There is a danger that the battery will
run flat, or other electronic parts may stop operating.
Do not knock anything against this unit when
loading or unloading objects from the trunk.
Doing so will cause damage to this unit.
CY-PA4003W/PA2003W/PAD1003W
3
English
English
Safety Information (continued)
Caution
Observe the following cautions when installing.
Refer wiring and installation to qualified service
personnel.
Installation of this unit requires special skills and
experience. For maximum safety, have it installed by
your dealer. Panasonic is not liable for any problems
resulting from your own installation of the unit.
Follow the instructions to install and wire the product.
Not following the instructions to properly install and
wire the product could cause an accident or fire.
Take care not to damage the leads.
Prevent them from getting caught in the vehicle
chassis, screws, and moving parts such as seat rails.
Do not scratch, pull, bend or twist the leads. Do not run
them near heat sources or place heavy objects on them.
If leads must be run over sharp metal edges, protect
the leads by winding them with vinyl tape or similar
protection.
Use the designated parts and tools for installation.
Use the supplied or designated parts and appropriate
tools to install the product. The use of parts other than
those supplied or designated may result in internal
damage to the unit. Faulty installation may lead to an
accident, a malfunction or fire.
Do not install the product where it is exposed to
strong vibrations or is unstable.
Avoid slanted or strongly curved surfaces for
installation. If the installation is not stable, the unit may
fall down while driving and this can lead to an accident
or injury.
We strongly recommended you to wear gloves for
installation work to protect yourself from injuries.
Failure to heed this caution may result in an accident
and/or injury.
Be sure to grip both sides of this unit securely before
attempting to move it.
Since this unit is quite heavy, the unit may fall down
and this can lead to an accident or injury.
Cover the unused terminals with insulating tape to
prevent them from short circuiting.
When an extension lead is used, it should be as
thick and short as possible; connect it firmly with
insulating tape.
Wire breaks and short circuits can cause electrical
shock or fire.
4
CY-PA4003W/PA2003W/PAD1003W
Use the spacer included when installing the unit so
that the fan and air hole on the base side of the unit
are not covered. <CY-PAD1003W>
If the fan and air hole on the base side of the unit are
covered, the unit will become extremely hot and may
fail.
Caution for mounting the unit:
Never mount the unit in any of the following locations
to avoid damage due to overheating;
• Near the heater port.
• Places like the dashboard or rear deck, where it may
be exposed to direct sunlight.
Do not mount the unit near the door, where it could be
exposed to rain.
Keep a safe distance between the unit and other
electronic equipment.
When a short circuit occurs, such as in the speaker
output terminal, etc. the overload protection circuit will
operate. This circuit protects the power amplifier from
further damage when a short circuit occurs. Operation
will temporarily stop. In this case, check the cause of
the short-circuit and if the problem is fixed, normal
operation will resume.
Since the power amplifier has a very large output, the
unit should be installed in the trunk of your car.
Do not install this unit under a carpet, otherwise the
unit may fail because of immature heat dissipation.
In case more than one power amplifier is used, make
sure to employ the power cord and the fuse having
the current capacity larger than the total current
corresponding to the maximum consumption powers
of all the amplifiers.
Caution for the power cord (option):
Follow an expert’s instruction for the use of the cord
separately sold.
For the power, make sure to use the battery lead (yellow)
separately sold and specially designed for Panasonic
car-audio/AV system, and to connect directly to the car
battery. Use the cord having the fuse capacity larger
than that of this unit. Connect the power cord and other
cords corresponding to the power supply after all the
connections to the speaker are completed.
Keep the battery lead (yellow) away from the speaker
cord.
Make sure to use the ground lead (black) separately
sold and specially designed for car audio system, and
to connect it to the metal portion of the car chassis.
Wire the battery lead (yellow), the ground lead (black),
the speaker cords, and this unit with as much distance
as possible from the antenna, the antenna cords and
the car stereo (car radio).
If the ground wire is common to both left/right and
front/rear speaker wirings, this unit cannot be used.
Always use the independent lead wire for the speakers
to be used. In this case, redo the wiring.
Caution for the speaker cord (option):
The speaker cords and the power amplifier unit should
be kept away from the antenna and antenna extension
cord.
Do not directly ground the speaker cords; do not share
the negative leads of multiple speakers.
When using the RCA cords, keep away from the
speaker cords.
Caution for the speaker (option):
Use speakers with a suitable maximum input.
In case of 4-channel/3-channel connection
<CY-PA4003W>:
Use speakers with the impedance of 28 .
In case of 2-channel/stereo connection:
Use speakers with the impedance of 48 .
CY-PA4003W/PA2003W/PAD1003W
5
English
Before Reading These Instructions
Before Use
Contents
Panasonic welcomes you to our constantly growing
family of electronic products owners. We endeavor to give
you the advantages of precise electronic and mechanical
engineering, manufactured with carefully selected
components, and assembled by people who are proud
of the reputation their work has built for our company.
We know this product will bring you many hours of
enjoyments, and after you discover the quality, value and
reliability we have built into it, you too will be proud to be
a member of our family.
 Check the connections according to the manual of
the device you have connected, and switch on the
connected device’s power supply.
 Adjust the GAIN to a satisfactory volume. (page 11, 12)
 Refer to individual instruction and installation manuals
for each device for detailed installation and wiring.
English
CY-PA4003W
4 Channel Power Amplifier
CY-PA2003W
2 Channel Power Amplifier
2
CY-PAD1003W
Digital Mono Amplifier
Differences among 3 Models
This Operating instruction manual is for 3 models CY-PA4003W, CY-PA2003W and CY-PAD1003W. All illustrations
throughout this manual represent model CY-PA4003W unless otherwise specified. The following table describes the
differences among 3 models.
Models
CY-PA4003W
CY-PA2003W
CY-PAD1003W
Speaker connection
4/3/2-channel speaker
2/1-channel speaker
1-channel speaker
Maximum power output
250 W4 channel
600 W2 channel
1 100 W1 channel
Input channel
4-channel
2-channel
2-channel
4CH/2CH input selection
Yes
No
No
HPF (High Pass Filter)
Yes
Yes
No
Subsonic filter switch
No
No
Yes
Fuse
35 A2
25 A3
25 A3
Speaker input connector
2 (1 for front speaker, 1 for
rear speaker)
1 (for left/right speaker)
1 (for left/right speaker)
Features
Before Reading These Instructions ... 6
Before Use .............................. 7
Features ................................. 8
Location of Controls .................. 10
Speaker System Setting
<CY-PA4003W> .................... 14
Speaker System Setting
<CY-PA2003W> .................... 17
Speaker System Setting
<CY-PAD1003W> .................. 18
Note for Bridge Speaker Connection .... 19
Installation ............................. 20
Wiring .................................. 22
Wiring <CY-PA4003W> .............. 24
RCA .......................................................... 24
SPEAKERS INPUT .................................... 25
Accessories
Item
Safety Information ..................... 2
Diagram
Operating Instructions
(YEFM285832A)
Qty.
1
Note:
 The number in parenthesis underneath each accessory
part name is the part number for maintenance and
service.
 Accessories and their parts numbers are subject to
modification without prior notice due to improvements.
Wiring <CY-PA2003W> .............. 26
RCA .......................................................... 26
SPEAKERS INPUT .................................... 27
Wiring <CY-PAD1003W>............. 28
RCA .......................................................... 28
SPEAKERS INPUT .................................... 29
Installation Hardware (screws, cords, etc.) (page 20)
Troubleshooting ....................... 30
Maintenance ........................... 32
Specifications ......................... 32
6
CY-PA4003W/PA2003W/PAD1003W
CY-PA4003W/PA2003W/PAD1003W
7
CY-PA4003W
250 W  4 channel maximum power output
Total 1 000 W maximum power output
An amplifier connected to the 4-, 3- or
2-channel speaker
2CH/4CH input selection:
The 4-channel speaker output is available under the
2-channel speaker input setting.
Low-Pass Filter for subwoofer, High Pass
Filter:
Switchover of LPF/OFF/HPF is available.
CY-PA2003W
600 W  2 channel maximum power output
English
English
Features
<Common features of 3 models>
5.1-channel Surround System (Combination with other Panasonic car audio products)
High Level Speaker Input connection:
You can enjoy a powerful 5.1-channel surround system by connecting Head Unit (CQ-VD7003W, CQ-VD6503W, option),
4-channel amplifier (CY-PA4003W) and monaural amplifier for subwoofer (CY-PAD1003W).
For more details, refer to the operating instructions for the connected devices.
The high-quality playback sound is produced when
connecting the unit to the speaker output lead of the Head
Unit.
Use it when the Head Unit is not equipped with the
terminal for the RCA output lead.
Bass boost control system:
The bass boost circuit is employed to play back the deep
bass on the front and rear speakers.
Crossover Frequency Control:
The frequency band in the treble and the bass, which
are played back on the front and rear speakers, can be
adjusted.
RCA output terminals:
Equipped with RCA output for adding a power amplifier.
4 Channel Power Amplifier:
CY-PA4003W
Head Unit
(In-dash color LCD monitor/
DVD player):
CQ-VD7003W, option
or
CQ-VD6503W, option
Digital Mono Amplifier (for
subwoofer):
CY-PAD1003W
Subwoofer: CJ-SW3003N, option
Center speaker:
EAB-CF2, option
Front speakers:
CJ-DA1733N, option
Surround Speakers:
CJ-DA6943N, option
Total 1 200 W maximum power output
Low-Pass Filter for subwoofer, High Pass
Filter:
Switchover of LPF/OFF/HPF is available.
CY-PAD1003W
1 100 W  1 channel maximum power output
Low-Pass Filter for subwoofer:
Switchover of LPF/OFF is available.
8
CY-PA4003W/PA2003W/PAD1003W
CY-PA4003W/PA2003W/PAD1003W
9
<CY-PA4003W>






For channel A (except )
Caution
 Turn off the power supply before changing the
switch setting.
 Stop to use the unit when the red indicator
(PROTECT) lights up.
If the red indicator lights up, this unit will
automatically shut down. Confirm the speaker and
other audio system’s wiring.
 High level speaker input terminal (SPEAKERS
INPUT)
When connecting Head Unit without RCA output
terminals.
 Power/protection indicator (PWR/PROTECT)
Lights green: When the Head Unit power is on.
Lights red:
• When the speaker cords are short-circuited.
• When the speaker output line comes contact with the
car grounding wire.
• When this unit fails and the speaker output generates
a DC power source.
• When the amplifier internally creates a high-pitched
sound.
• When the connection of the Head Unit or this unit is
not completed.
English
English
Location of Controls

 
 











 

For channel B (except )
 Crossover filter switch (LPF, OFF, HPF)
LPF (Low Pass Filter): LPF cuts off the treble, and
outputs only a low-pitched sound for the subwoofer.
OFF: All frequency bands are output without filtering.
Select when a subwoofer is not connected.
HPF (High Pass Filter): Sound is output from the
speakers for a high-pitched sound and midrange
sound after deleting the low-pitched sound.
 BASS BOOST control knob
Turn this knob to boost the 45 Hz frequency sound.
It enhances the low-pitched sound.
For some speakers, the sound may be distorted
because of the excessive power input to them. In that
case, turn down the bass level until the distortion
stops.
Setting range: 0 dB to 15 dB
 Crossover frequency control knob (FREQUENCY)
The frequency band of the treble and the bass played
back on the front and rear speakers is adjusted.
Setting range: 50 Hz to 250 Hz
 GAIN control knob
In some instances, the acoustical output from each
speaker may not be balanced properly depending upon
the type of speakers or Head Unit being used.
Up: Turn up the knob when the sound volume is not
satisfactory even though the volume of the Head
Unit is increased.
Down: Turn down the knob when the sound is
distorted.
 Speaker output terminals (For CH A)
Equipped with RCA output for adding a power
amplifier.
It is not a Speaker input terminal.
 Channel A input terminals (LEFT, RIGHT)
 Channel B input terminals (LEFT, RIGHT)
 Speaker channel select switch (4CH, 2CH)
4CH: When connecting Head Unit with 2 preout leads.
2CH: When connecting Head Unit with 1 preout lead.
 Fuses (FUSES) (35 A2)
 Upper cover
 Channel B speaker output connector (SPEAKERS)
 Left Side ()
 Left Side ()
 Right Side ()
 Right Side ()
 Battery connector (12 V)
To the car battery, continuous 12 V DC.
 Amplifier control connector (CONT)
To the head unit’s external amplifier control power
lead or to the car battery, continuous 12 V DC.
 Ground connector (GND)
To a clean, bare metallic part of the car chassis.
 Input select switch (LINE, SPEAKERS)
LINE: When using RCA INPUT connectors.
SPEAKERS: When using SPEAKER INPUT connectors.
 Channel A speaker output connector (SPEAKERS)
 Left Side ()
 Left Side ()
 Right Side ()
 Right Side ()
The upper cover can be reinstalled along with the
reinstallation of the main body of the unit, such that
the cover is aligned with other devices for neat and
better look.
How to dismount:
Unscrew the terminal screw
with Allen wrench .
Note:
 Do not insert anything between the upper cover and
this unit. Doing so will cause damage to this unit.
10
CY-PA4003W/PA2003W/PAD1003W
CY-PA4003W/PA2003W/PAD1003W
11
<CY-PA2003W>







English
English
Location of Controls (continued)


<CY-PA2003W>




<CY-PAD1003W> 








<CY-PAD1003W>


Caution
 Turn off the power supply before changing the
switch setting.
 Stop to use the unit when the red indicator
(PROTECT) lights up.
If the red indicator lights up, this unit will
automatically shut down. Confirm the speaker and
other audio system’s wiring.
 High level speaker input terminal (SPEAKERS
INPUT)
When connecting Head Unit without RCA output
terminals.
 Speaker output terminals
Equipped with RCA output for adding a power
amplifier.
It is not a Speaker input terminal.
 Speaker input terminals (LEFT, RIGHT)
 Input select switch (LINE, SPEAKERS)
LINE: When using RCA INPUT connectors.
SPEAKERS: When using SPEAKER INPUT connectors.
12
CY-PA4003W/PA2003W/PAD1003W
 GAIN control knob
In some instances, the acoustical output from each
speaker may not be balanced properly depending upon
the type of speakers or Head Unit being used.
Up: Turn up the knob when the sound volume is not
satisfactory even though the volume of the Head
Unit is increased.
Down: Turn down the knob when the sound is
distorted.
 BASS BOOST control knob
Turn this knob to boost the 45 Hz frequency sound.
It enhances the low-pitched sound.
For some speakers, the sound may be distorted
because of the excessive power input to them. In that
case, turn down the bass level until the distortion
stops.
Setting range: 0 dB to 15 dB
 Crossover filter switch (LPF, OFF, HPF)
LPF (Low Pass Filter): LPF cuts off the treble, and
outputs only a low-pitched sound for the subwoofer.
OFF: All frequency bands are output without filtering.
Select when a subwoofer is not connected.
<CY-PA2003W>
HPF (High Pass Filter): Sound is output from the
speakers for a high-pitched sound and midrange
sound after deleting the low-pitched sound.
 Crossover frequency control knob (FREQUENCY)
The frequency band of the treble and the bass played
back on the front and rear speakers is adjusted.
Setting range: 50 Hz to 250 Hz
 Power/protection indicator (PWR/PROTECT)
Lights green: When the Head Unit power is on.
Lights red:
• When the speaker cords are short-circuited.
• When the speaker output line comes contact with the
car grounding wire.
• When this unit fails and the speaker output generates
a DC power source.
• When the amplifier internally creates a high-pitched
sound.
• When the connection of the Head Unit or this unit is
not completed.
 Speaker output connector
<CY-PAD1003W>
<CY-PA2003W>
 SP ()
 Left Side ()
 SP ()
 Left Side ()
 SP ()
 Right Side ()
 SP ()
 Right Side ()
 Fuses (FUSES) (25 A3)
 Upper cover

 

 


 Battery connector (12 V)
To the car battery, continuous 12 V DC.
 Amplifier control connector (CONT)
To the head unit’s external amplifier control power
lead or to the car battery, continuous 12 V DC.
 Ground connector (GND)
To a clean, bare metallic part of the car chassis.
 <CY-PAD1003W>
Subsonic filter switch (OFF, ON)
Switch ON to remove noise from subwoofer.
The upper cover can be reinstalled along with the
reinstallation of the main body of the unit, such that
the cover is aligned with other devices for neat and
better look.
How to dismount:
Unscrew the terminal screw
with Allen wrench .
Note:
 Do not insert anything between the upper cover and
this unit. Doing so will cause damage to this unit.
CY-PA4003W/PA2003W/PAD1003W
13
English
English
Speaker System Setting <CY-PA4003W>
4CH Input
2-channel Speaker System (Monaural)
4-channel Speaker System
INPUT CH A INPUT CH B
INPUT CH A INPUT CH B
Switch to 4CH.
Switch to 4CH.
Speaker output CH A
Right
Left
(min. 2 ) (min. 2 )
RCA cord (option)
(from Head Unit output terminal)
Speaker output CH A
LeftRight
(min. 4 )
RCA cord (option)
(from Head Unit output terminal)
Subwoofer
(Bridge connection)
(Monaural)
Speaker output CH B
Speaker output CH B
Right (min. 2 )
Left (min. 2 )
LeftRight (min. 4 )
Subwoofer
(Bridge connection)
(Monaural)
2-channel Speaker System (Stereo)
3-channel Speaker System
Input the front right channel (red)/rear right
channel (red).
INPUT CH A INPUT CH B
Switch to 4CH.
Speaker output CH A
Right
Left
(min. 2 ) (min. 2 )
RCA cord (option)
(from Head Unit output terminal)
Special Application
Example: Connecting left channel audio output to
CH A and right channel audio output to CH B.
Input the front left channel
(white)/rear left channel
(white).
Speaker output CH A
(Outputs left channel audio.)
Switch to 4CH.
Left
(min. 4 )
RCA cord (option)
(from Head Unit output terminal)
(Bridge connection)
(Bridge connection)
Speaker output CH B
14
Subwoofer
(Bridge connection)
LeftRight (Monaural)
(min. 4 )
CY-PA4003W/PA2003W/PAD1003W
Speaker output CH B
(Outputs right channel audio.)
Right
(min. 4 )
Note:
 When the Head Unit is connected to the RCA cord, note
that the RCA white and red leads differ in color from the
unit terminals.
 Connect both front left/rear left and front right/rear
right inputs. Using a single input connection halves the
output.
CY-PA4003W/PA2003W/PAD1003W
15
Speaker System Setting <CY-PA2003W>
English
English
Speaker System Setting <CY-PA4003W> (continued)
2-channel Speaker System (Stereo)
2CH Input
Special Application
Example: If the Head Unit only has a single pre-out,
connect it to this unit for 4-channel audio output.
4-channel Speaker System
INPUT
Input the right channel (red).
Input the left channel (white).
Switch to 2CH.
RCA cord (option)
(from Head Unit output terminal)
Speaker output CH A
Right
Left
(min. 2 ) (min. 2 )
Not used.
RCA cord (option)
(from Head Unit output terminal)
Note:
 The fader control is ineffective.
 The speaker outputs A and B are at the same
level.
 The 3-channel speaker output is not allowed
with the 2-channel input connection.
 When the Head Unit is connected to the RCA
cord, note that the RCA white and red leads
differ in color from the unit terminals.
Speaker output CH B
Left (min. 2 ) Right (min. 2 )
Special Application
Example: If the Head Unit only has a single pre-out,
connect it to this unit for 2-channel audio output.
2-channel Speaker System
Input the left channel (white).
Speaker output
Left
(min. 2 )
Right
(min. 2 )
1-channel Speaker System (Monaural)
INPUT
Input the right channel (red).
Switch to 2CH.
Speaker output CH A
Left (min. 4 )
RCA cord (option)
(from Head Unit output terminal)
Not used.
RCA cord (option)
(from Head Unit output terminal)
(Bridge connection)
Speaker output CH B
(Bridge connection)
Right (min. 4 )
16
CY-PA4003W/PA2003W/PAD1003W
Note:
 This is not a monaural output.
 The 3-channel speaker output is not allowed
with the 2-channel input connection.
 When the Head Unit is connected to the RCA
cord, note that the RCA white and red leads
differ in color from the unit terminals.
Speaker output
LeftRight
(min. 4 )
Subwoofer
(Bridge connection)
(Monaural)
CY-PA4003W/PA2003W/PAD1003W
17
Note for Bridge Speaker Connection
 In case of 2-channel/stereo connection:
In case of multiple speakers to be mounted in a bridge
connection, confirm the summed impedance to be 48
 in order to avoid ignition, smoking, or damage.
2-channel (Monaural) Speaker System
INPUT
Total impedance: 4 
Total impedance: 4 
Speaker: 2 
RCA cord (option)
(from Head Unit output terminal)
Speaker output
English
English
Speaker System Setting <CY-PAD1003W>
Speaker: 8 
Speaker: 8 
Speaker: 2 
Right
(min. 4 )
Do not make a connection in such a manner.
Total impedance: 2 
Speaker output
Left
(min. 4 )
Note:
 Connect the right and left RCA output terminals of the
Head Unit to the input terminals of this unit.
Speaker: 4 
Speaker: 4 
<CY-PA4003W>
1-channel (Monaural) Speaker System
Note for RCA Input Connection:
INPUT
Switch to ON.
 Selectively assign each front and rear output to either
RCA INPUT A or B, in accordance with the system from
which the output is coming.
 In case of a single line coming from the RCA output of
Head Unit, connect the line to RCA INPUT A.
Do not connect it to RCA INPUT B.
RCA cord (option)
(from Head Unit output terminal)
(min. 2 )
Speaker output
18
Subwoofer (Monaural)
CY-PA4003W/PA2003W/PAD1003W
CY-PA4003W/PA2003W/PAD1003W
19
Preparation
Caution
 Please follow the laws and regulations of your
province or country for installation of the unit.
 We strongly recommended you to wear gloves for
installation work to protect yourself from injuries.
 Be sure to grip both sides of this unit securely
before attempting to move it.
Since this unit is quite heavy, the unit may fall down
and this can lead to an accident or injury.
 Disconnect the cable from the negative () battery
terminal (see caution below).
Caution
 If your car is equipped with air bag and/or antitheft systems specific procedures may be required
for connection and disconnection of the battery to
install this product.
 Before attempting installation of this electronic
component contact your car dealer or manufacturer
to determine the required procedure and strictly
follow their instructions.
 FAILURE TO FOLLOW THE PROCEDURE MAY
RESULT IN THE UNINTENDED DEPLOYMENT OF
AIR BAGS OR ACTIVATION OF THE ANTI-THEFT
SYSTEM RESULTING IN DAMAGE TO THE VEHICLE
AND PERSONAL INJURY.
English
English
Installation
Installation Hardware
(For Installation)
No.
Item
Diagram
Mounting the Unit
Qty.
Tapping Screw
(5 mm20 mm)
4

Plain Washer
(5 mm)
4

Allen wrench
1

Installation Hardware
(For Wiring)
No.
Item

Speaker input
connector

Terminal cover
for short-circuit
prevention
Diagram
Qty.
2
2
 CY-PA4003W: 2 (1 for front speaker, 1 for rear speaker)
CY-PA2003W, CY-PAD1003W: 1 (for left/right speaker)
<CY-PAD1003W> Installation
Hardware (For Installation)
No.
Item
Diagram
Qty.

Spacer
4

Tapping Screw
(5 mm40 mm)
4
Note:
 For power connection, use the optional power cord
specially designed for use with Panasonic car-audio/
AV system.
 Use only the supplied screws for installation. If parts
are missing please consult with your Panasonic dealer
for advice.
20
CY-PA4003W/PA2003W/PAD1003W
Caution
 Never mount the unit in any of the following locations
to avoid damage due to overheating;
• Near the heater port.
• Places like the dashboard or rear deck, where it may
be exposed to direct sunlight.
 Do not mount the unit near the door, where it could
be exposed to rain.
 You run the risk of interfering with the mounting or
causing damage by drilling into the gas tank, a wiring
harness, or other component.
 Keep a safe distance between the unit and other
electronic equipment.
 If this unit is operated at a high output continuously,
the upper side of the unit will get very hot. Do not
touch it nor place anything on top of the unit.
 When a short circuit occurs, such as in the speaker
output terminal, etc. the overload protection circuit
will operate. This circuit protects the power amplifier
from further damage when a short circuit occurs.
Operation will temporarily stop. In this case, check
the cause of the short-circuit and if the problem is
fixed, normal operation will resume.
 Since the power amplifier has a very large output, the
unit should be installed in the trunk of your car.
 Do not install this unit under a carpet, otherwise the
unit may fail because of immature heat dissipation.
 Use the spacer included when installing the unit so
that the fan and air hole on the base side of the unit
are not covered. <CY-PAD1003W>
If the fan and air hole on the base side of the unit are
covered, the unit will become extremely hot and may
fail.
Before Mounting the Unit
1 Make the temporary connections.
2 Confirm the proper operation of the unit.
Confirm the proper connection and setting, and no
blowout of the fuses.
3 Confirm after the installation of the unit that the spare
tires, the jack, the tools, etc. can be picked up without
obstruction.
Install the unit to a metallic portion of the car
Since the power amplifier has a very large output, the
unit should be installed in the boot of your car.
<CY-PA4003W, CY-PA2003W>
 Tapping Screw
(5 mm20 mm)
 Plain Washer (5 mm)
Drill four holes
3.5 mm
321 mm
178 mm
Metallic panel
(thickness: more
than 15 mm)
<CY-PAD1003W>
 Tapping Screw
(5 mm40 mm)
 Plain Washer (5 mm)
 Spacer
291 mm
178 mm
Drill four holes
3.5 mm
Metallic panel
(thickness: more than 15 mm)
Note:
 If you wish to install the unit without using the spacer
included, drill holes in the Metallic panel etc so that the
fan and air holes on the base side of the unit are not
covered.
Base side of CY-PAD1003W:
Fan
Air hole
CY-PA4003W/PA2003W/PAD1003W
21
Caution
 This unit is designed for use in a car having a 12 V
negative ground battery system.
 Be sure to insulate any exposed wires to prevent short
circuiting with the car chassis. Bundle all cables, and
prevent cable terminals from touching any metal parts.
 Note that if your car has a driving computer or a
navigation computer, disconnecting the cable from the
battery may clear the memory.
 Run the cords avoiding the spots where the
temperature can be extremely high.
 Continuous use of a system that exceeds the maximum
permissible input levels may damage the speakers.
 Since the power amplifier has a very large output, the
unit should be installed in the trunk of your car.
 Do not install this unit under a carpet, otherwise the
unit may fail because of immature heat dissipation.
Caution for the power cord (option):
 Follow an expert’s instruction for the use of the cord
separately sold.
 For the power, make sure to use the battery lead (yellow)
separately sold and specially designed for Panasonic
car-audio/AV system, and to connect directly to the car
battery. Use the cord having the fuse capacity larger
than that of this unit. Connect the power cord and other
cords corresponding to the power supply after all the
connections to the speaker are completed.
 Keep the battery lead (yellow) away from the speaker
cord.
English
English
Wiring
 Make sure to use the ground lead (black) separately
sold and specially designed for car audio system, and
to connect it to the metal portion of the car chassis.
 Wire the battery lead (yellow), the ground lead (black),
the speaker cords, and this unit with as much distance
as possible from the antenna, the antenna cords and
the car stereo (car radio).
 If the ground wire is common to both left/right and
front/rear speaker wirings, this unit cannot be used.
Always use the independent lead wire for the speakers
to be used. In this case, redo the wiring.
Speaker Output Terminal Screw Connection
(10 mm)
Speaker terminal
Caution for the speaker cord (option):
 The speaker cords and the power amplifier unit should
be kept away from the antenna and antenna extension
cord.
 Do not directly ground the speaker cords; do not share
the negative leads of multiple speakers.
 When using the RCA cords, keep away from the
speaker cords.
Caution for the speaker (option):
 Use speakers with a suitable maximum input.
 In case of 4-channel/3-channel connection
<CY-PA4003W>:
Use speakers with the impedance of 28 .
 In case of 2-channel/stereo connection:
Use speakers with the impedance of 48 .
Speaker cord
<CY-PA2003W, CY-PAD1003W>
<CY-PA4003W>
Terminal screw
Terminal screw
Power Terminal Screw Connection
Terminal screw
Battery terminal
External amplifier control terminal
Terminal Cover for Short-circuit Prevention
Ground terminal
This terminal cover is for preventing short-circuit between adjacent terminals. Before connecting each lead, pass it through
the terminal cover. After connecting the leads to the terminals, cover the speaker output terminals and power terminals
with this cover. Make sure that the projections to prevent slipping out are facing down.
<CY-PA4003W>
1 Using a nipper or cutter, expose approximately 10 mm
long of the core of the speaker cord and twist its end.
2 Attach the speaker terminal onto the speaker cord.
3 Unscrew the terminal screw.
4 Insert the screw into the terminal of the cord. Securely
fasten the screw.
<CY-PA2003W, CY-PAD1003W>
For power connection, use the optional battery lead
(yellow) specially designed for car-audio system and
connect it directly to the car battery.
Use the cord having the fuse capacity larger than that of
this unit.
Securely tighten each lead with a terminal screw.
1 Unscrew the terminal screw.
2 Insert the screw into the terminal of the lead. Securely
fasten the screw.
Ground Lead (Black)
External Amplifier Control Lead
(Blue/white stripe)
Battery Lead (Yellow)
Corrugated tube
 Terminal cover for short-circuit prevention
If the battery lead has to be routed through high
temperature area, protect it with a corrugated tube
(option).
 Terminal cover for short-circuit prevention
Battery Lead (Yellow)
22
CY-PA4003W/PA2003W/PAD1003W
CY-PA4003W/PA2003W/PAD1003W
23
English
English
Wiring <CY-PA4003W>
Speaker Connections with RCA cord
Speaker Connections with SPEAKERS INPUT Connectors
Example: 4 channel speaker connection (4CH input)
Example: 4 channel speaker connection (4CH input)
Note for RCA Input Connection:
 Selectively assign each front and rear output to either RCA INPUT A or B, in accordance with the system from which the
output is coming.
 In case of a single line coming from the RCA output of Head Unit, connect the line to RCA INPUT A.
Do not connect it to RCA INPUT B.
INPUT CH B
INPUT CH A
4/2 CHANNEL SWITCH
4CH
CH A
SPEAKERS INPUT
Not used.
CH B
SPEAKERS INPUT
Not used.
CH B
SPEAKERS INPUT
CH A
SPEAKERS
INPUT
INPUT CH A (Not used.)
INPUT CH B (Not used.)
Ground lead
R (Red)
RCA cord
(option)
RCA cord
(option)
R (Red)
L (White)
PRE-OUT
(Rear)
PRE-OUT
(Front)
Front (L)
(min. 2 )
Head Unit
Front (R)
(min. 2 )
External Amplifier Control Lead
(Blue/white stripe)
To Head Unit’s external amplifier control
power lead.
Rear (L)
(min. 2 )
24
Rear (R)
(min. 2 )
CY-PA4003W/PA2003W/PAD1003W
Battery Lead (Yellow)
To the car battery,
continuous 12 V DC.
CH A
Speaker lead’s color
White
White/black stripe
Gray
Gray/black stripe
Channel
Front left ()
Front left ()
Front right ()
Front right ()
CH B
Speaker lead’s color
Green
Green/black stripe
Violet
Violet/black stripe
Channel
Rear left ()
Rear left ()
Rear right ()
Rear right ()
Note for the ground lead of the speaker input
connector:
 Connect to the Head Unit’s earth.
 Do not allow the speaker output and ground to
short out. Doing so will cause damage to this
unit.
External Amplifier Control Lead
(Blue/white stripe)
To Head Unit’s external amplifier control power lead.
Ground Lead (Black)
To a clean, bare metallic part of the car
chassis.
Ground Lead (Black)
To a clean, bare metallic
part of the car chassis.
Speaker output CH B
Rear Speaker Output
Head Unit
Speaker output CH A
Front (L) (min. 2 ) Front (R) (min. 2 )
Speaker output CH A
Ground lead
 Speaker input
connector
R (Red)
L (White)
Front Speaker Output
Power amplifier
4/2 CHANNEL SWITCH
4CH
INPUT SELECT
LINE
LPF/OFF/HPF
OFF
OUTPUT
(For CH A)
When connecting L (White)
another power
amplifier:
INPUT SELECT
SPEAKERS
Rear (L)
(min. 2 )
Rear (R)
(min. 2 )
Battery Lead (Yellow)
To the car battery, continuous 12 V DC.
Speaker output CH B
CY-PA4003W/PA2003W/PAD1003W
25
English
English
Wiring <CY-PA2003W>
Speaker Connections with RCA cord
Speaker Connections with SPEAKERS INPUT Connectors
Example: 2 channel speaker connection
INPUT
Example: 2 channel speaker connection
INPUT SELECT
LINE
OUTPUT
When connecting another
power amplifier:
INPUT SELECT
SPEAKERS
SPEAKERS
INPUT
SPEAKERS INPUT
Not used.
INPUT
(Not used.)
L (White)
R (Red) L (White)
R (Red)
Speaker lead’s color
White
White/black stripe
Gray
Gray/black stripe
Ground lead
RCA cord
(option)
RCA cord
(option)
L (White)
 Speaker input connector
R (Red)
Channel
Left ()
Left ()
Right ()
Right ()
PRE-OUT
Power amplifier
Speaker Output
Head Unit
Head Unit
External Amplifier Control Lead
(Blue/white stripe)
To Head Unit’s external amplifier control
power lead.
Note for the ground lead of the speaker input
connector:
 Connect to the Head Unit’s earth.
 Do not allow the speaker output and ground
to short out. Doing so will cause damage to
this unit.
External Amplifier Control Lead
(Blue/white stripe)
To Head Unit’s external amplifier control power lead.
Ground Lead (Black)
To a clean, bare metallic
part of the car chassis.
Speaker output
Left (min. 2 )
Right (min. 2 )
Battery Lead (Yellow)
To the car battery,
continuous 12 V DC.
Ground Lead (Black)
To a clean, bare metallic part of the
car chassis.
Speaker output
Left (min. 2 )
26
CY-PA4003W/PA2003W/PAD1003W
Right (min. 2 )
Battery Lead (Yellow)
To the car battery, continuous
12 V DC.
CY-PA4003W/PA2003W/PAD1003W
27
English
English
Wiring <CY-PAD1003W>
Speaker Connections with RCA cord
Speaker Connections with SPEAKERS INPUT Connectors
Example: 2 channel Input System
Example: 2 channel Input System
INPUT SELECT
LINE
INPUT
OUTPUT
When connecting another
power amplifier:
INPUT SELECT
SPEAKERS
SPEAKERS
INPUT
SPEAKERS INPUT
Not used.
L (White)
R (Red) L (White)
RCA cord
(option)
INPUT
(Not used.)
R (Red)
Ground lead
RCA cord
(option)
L (White)
 Speaker input connector
R (Red)
Speaker lead’s color
White
White/black stripe
Gray
Gray/black stripe
Channel
Left ()
Left ()
Right ()
Right ()
PRE-OUT
Power amplifier
Speaker Output
Head Unit
Head Unit
Right (min. 4 )
External Amplifier Control Lead
(Blue/white stripe)
To Head Unit’s external amplifier control
power lead.
Right (min. 4 )
Note for the ground lead of the speaker input
connector:
 Connect to the Head Unit’s earth.
 Do not allow the speaker output and ground to
short out. Doing so will cause damage to this unit.
External Amplifier Control Lead
(Blue/white stripe)
To Head Unit’s external amplifier control power lead.
Ground Lead (Black)
To a clean, bare metallic
part of the car chassis.
Left (min. 4 )
28
CY-PA4003W/PA2003W/PAD1003W
Battery Lead (Yellow)
To the car battery,
continuous 12 V DC.
Ground Lead (Black)
To a clean, bare metallic part of the
car chassis.
Battery Lead (Yellow)
To the car battery, continuous
12 V DC.
CY-PA4003W/PA2003W/PAD1003W
29
If You Suspect Something Wrong
Check and take steps as described below.
If the described suggestions do not solve the problem,
it is recommended to take the unit to your nearest
authorized Panasonic Service Center. The product should
be serviced only by qualified personnel. Please refer
checking and repair to professionals.
Panasonic shall not be liable for any accidents arising out
of neglect of checking the unit or your own repair after
your checking.
Never take measures especially those other than
indicated by italic letters in “Possible solution”
described below because those are too dangerous for
users to handle themselves.
Warning
 Do not use the unit in abnormal condition, for
example, without sound, or with smoke or foul
smell, which can cause ignition or electric shock.
Immediately stop using the unit and consult your
dealer.
 Never try to repair the unit by yourself because it is
dangerous to do so.
Possible cause  Possible solution
Problem
No sound available.
English
English
Troubleshooting
The power cord (battery, power and ground) is connected in the wrong way.
 Check the wiring.
The contact of the ground lead is poor.
 Make sure that the ground lead is connected to an unpainted part of the chassis
securely.
Problem
No sound available.
(continued)
Bad sound quality
(Distorted sound)
Noise
The bass is too much enhanced.
 Set the bass boost appropriately.
Sound comes out from
only either the Front
2CH or the Rear 2CH.
<CY-PA4003W>
The 2CH/4CH setting of the speaker input is incorrect.
 Set it correctly.
Only the bass is
available.
<CY-PA4003W, CY-PA2003W>
The Crossover Filter Switch (LPF/OFF/HPF) is turned off.
 Set it on LPF or HPF according to the speaker connection.
<CY-PAD1003W>
The Crossover Filter Switch (LPF/OFF) is turned off.
 Set it on LPF according to the speaker connection.
The speaker received damage because of too small input capacity.
 Obtain the right speaker allowed to connect this unit, and replace the fuse. (page
32)
The speaker cord is bitten with a screw of the vehicle.
 Correct the wiring of the speaker cord.
The knob for sound volume control is not properly adjusted.
 Properly adjust it.
 Adjust the volume of the Head Unit.
Input Select (LINE/SPEAKERS) is not set in accordance with the speaker output cord
of the Head Unit.
 Check the Input Select (LINE/SPEAKERS) setting.
There is an electromagnetic-wave generator such as a cellular phone near the unit or
its electrical lines.
 Keep the electromagnetic-wave generator such as a cellular phone away from
the unit and the wiring of the unit. If noise cannot be eliminated due to the wiring
harness of the car, consult your dealer.
Fuse blows out.
 Eliminate the cause of fuse blowout and replace the fuse with new one. Consult
your dealer.
The speaker cord is short-circuited.
 Check the speaker cord, and replace the fuse.
The speaker cord is not properly connected.
 Properly reconnect so that the polarity matches between the speaker cord and
the terminal.
Possible cause  Possible solution
Only the treble is
available.
The setting of Crossover Frequency Control is incorrect.
 Check the Crossover Frequency Control setting.
The Protect lamp lights
red.
The speaker cord is short-circuited.
 Check the speaker cord, and replace the fuse.
The speaker received damage because of too small input capacity.
 Obtain the right speaker allowed to connect this unit, and replace the fuse. (page
32)
The speaker cord is not properly connected.
 Properly reconnect so that the polarity matches between the speaker cord and
the terminal.
Fuse blows out.
 Eliminate the cause of fuse blowout and replace the fuse with new one. Consult
your dealer.
30
CY-PA4003W/PA2003W/PAD1003W
CY-PA4003W/PA2003W/PAD1003W
31
<CY-PA4003W>
Power Supply:
Product Servicing
If the suggestions in the charts do not solve the problem,
we recommend that you take it to your nearest authorized
Panasonic Service Center. The product should be serviced
only by a qualified technician.
Replacing the Fuse
Warning
Use fuses of the same specified rating.
CY-PA4003W: 35 A2
CY-PA2003W: 25 A3
CY-PAD1003W: 25 A3
When replacing one fuse which has blown, replace
other fuses at the same time.
In some cases, fuses may deteriorate without failing.
Using different substitutes or fuses with higher
ratings, or connecting the unit directly without a fuse,
could cause fire or damage to the unit.
If the replacement fuse fails, contact your nearest
Panasonic Service Center for service.
Maintenance
DC 12 V (11 V–16 V), test
voltage 14.4 V,
Negative Ground
Current Consumption:
32 A (at 64 W4)
Speaker Impedance:
4
Power Output (“EIA” Power):
2-CH: 190 W2 (20 Hz20 000 Hz, 1 %, 4 )
3-CH: 64 W2190 W (20 Hz20 000 Hz, 1 %, 4 )
4-CH: 64 W4 (20 Hz20 000 Hz, 1 %, 4 )
Maximum Power Output:
2-CH: 220 W2 (20 Hz20 000 Hz, 10 %)
3-CH: 85 W2220 W (20 Hz20 000 Hz, 10 %)
4-CH: 85 W4 (20 Hz20 000 Hz, 10 %)
Total Harmonic Distortion: 0.08 % (1 000 Hz, at 10 W)
Low Pass Filter:
50 Hz250 Hz
High Pass Filter:
50 Hz250 Hz
Bass Boost :
0 dB15 dB (Middle
Frequency: 45 Hz)
Signal to Noise Ratio:
90 dB (IHF, A)
Frequency Response:
20 Hz20 kHz
Input Sensitivity:
0.2 V6 V
Input Impedance:
More than 46 k
Dimensions (WHD):
28062333 mm
Weight:
4.4 k
Note:
 Specifications and design are subject to modification
without notice due to improvements.
 Some figures and illustrations on this manual may be
different from your product.
English
English
Troubleshooting (continued) Specifications
<CY-PA2003W>
Power Supply:
DC 12 V (11 V–16 V), test
voltage 14.4 V,
Negative Ground
Current Consumption:
44 A (at 200 W2)
Speaker Impedance:
4
Power Output (“EIA” Power):
1-CH (Monaural): 480 W1 (20 Hz20 000 Hz, 1 %, 4 )
2-CH (Stereo): 200 W2 (20 Hz20 000 Hz, 1 %, 4 )
Maximum Power Output:
1-CH (Monaural): 550 W1 (20 Hz20 000 Hz, 10 %)
2-CH (Stereo): 260 W2 (20 Hz20 000 Hz, 10 %)
Total Harmonic Distortion: 0.08 % (1 000 Hz, at 10 W)
Low Pass Filter:
50 Hz250 Hz
High Pass Filter:
50 Hz250 Hz
Bass Boost:
0 dB15 dB (Middle
Frequency: 45 Hz)
Signal to Noise Ratio:
90 dB (IHF, A)
Frequency Response:
20 Hz20 kHz
Input Sensitivity:
0.2 V6 V
Input Impedance:
More than 43 k
Dimensions (WHD):
28062333 mm
Weight:
4.5 k
Note:
 Specifications and design are subject to modification
without notice due to improvements.
 Some figures and illustrations on this manual may be
different from your product.
<CY-PAD1003W>
Power Supply:
DC 12 V (11 V–16 V), test
voltage 14.4 V,
Negative Ground
Current Consumption:
29 A (at 350 W1)
Speaker Impedance:
4
Power Output (“EIA” Power):
1-CH (Monaural): 350 W1 (10 Hz8 000 Hz, 1 %, 4 )
Maximum Power Output:
1-CH (Monaural): 600 W1 (10 Hz8 000 Hz, 10 %)
Total Harmonic Distortion: 0.2 % (1 000 Hz, at 10 W)
Low Pass Filter:
50 Hz250 Hz
Bass Boost:
0 dB15 dB (Middle
Frequency: 45 Hz)
Subsonic Filter:
20 Hz, 3 dB, 12 dB/oct
Signal to Noise Ratio:
90 dB (IHF, A)
Frequency Response:
10 Hz8 kHz
Input Sensitivity:
0.2 V6 V
Input Impedance:
More than 22 k
Dimensions (WHD):
28062303 mm
Weight:
4.0 k
Note:
 Specifications and design are subject to modification
without notice due to improvements.
 Some figures and illustrations on this manual may be
different from your product.
Caution on Cleaning
Alcohol
Pesticide
Thinner
Wax
Benzine
Your product is designed and manufactured to require
minimum maintenance. Use a dry soft cloth for routine
exterior cleaning. Never use benzine, thinner or other
solvents.
32
CY-PA4003W/PA2003W/PAD1003W
CY-PA4003W/PA2003W/PAD1003W
33
CY-PA4003W/PA2003W/PAD1003W
Matsushita Electric Industrial Co., Ltd.
Web Site: http://panasonic.net
YEFM285832A FU0106-2046 Printed in China
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
