Color Video Monitor/Receiver
Operating Instructions
a EE py
UIT
CEE) (mon |) (Tem oir wi ) [ogo] 3 [77]
| RL TI N
A ETC Landforms |
| Lise |
* tue Rye Menara, North Car dina
Abpalschian Mountains dr Appalschians, great
MÉURtaiN sytem of apa North Armerios, Atarky
paralie) with the Atlantic Coast, and extending from
the prevines of Québec in Canada to northern
Г.
+; fr
+ СР
E
A
ъ
ВЫ
= ar
E
FY
a
Le JE
+
Myr Lidge Mounting, Marth Cu.
MT E
13715
CT-36DV60
For additional information about Panasonic products, visit our Internet site on the
| World Wide Web at: http://www.panasonic.com
Table of Contents
Specifications ................... LL. 3
Safety Instructions ...................... 4
Introduction........ñ._e eereroeanaoraca 6
Average Power Consumption ............. 6
Important Information ................... 7
FCC Statement ....................... 7
FCC Caution ............... . ....... И
Installation ......._—._e_w.esronxcorrerrono o, 8
Television Location .................... 8
Optional External Equipment Connections ..8
AC Power Supply Cord ................. 8
Remote Control Battery Installation ........ 8
TV Antenna/Cable Connections .......... 9
Other Video Equipment ................. 9
Care and Cleaning .................... 9
Location of Controls (TV/Monitor)......... 10
Quick Reference Control Operation ...... .10
Location of Control For The Home Theater
Remote Unit.................. cc. .... 11
Basic Remote Control Functions ......... 11
Remote Control Quick Reference Functional '
KeyChart ............... cit, 12
Special Functions . . .................... 14
MultiButton ......................... 14
RecallButton ........................ 14
R-Tune (Rapid Tume) Button ............ 14
Optional Equipment Connection and Operation . 15
Stereo Connection (To Audio AMP) ....... 15
Video/Audio Connection. ............... 15
TV MODE |
Trilingual Animated Icons ..........e.—.. 16
TV Modelcons ..................... 16
Menu Language Selection.............. 16
Picture Adjustment ................... 16
Picture Norm ....................... 16
Color, Tint, Brightness, Picture and
Sharpness Adjustments ............... 16
ColorTemp ........................ 17
AutoColor ........ an. 17
Video NR ......................... 17
Audio Adjustment .................... 18
AudioNorm ....................... 18
Bass, Treble and Balance ............. 18
Mode - Stereo/SAP/Mono ............. 18
Speaker о .........,................ 19
Surround ......... 2... eeriecro, 19
AlSound .......................... 19
TV/PC/DTV.......22 210 ea eu ne aa a usa au» 20
SetUpFeatures ...................... 20
Clock Auto ........... ......ererora 20
Clock Manual. aa as 22
SetDay ........................... 22
Auto Power On . .................... 22
Geomagnetic Corr (Correction) .......... 23
Mode. ..... J 23
AutoProgram....................... „24
Manual Program. .................... ‚24
Closed Caption On Mute ..............25
Closed Caption Mode ............. ee 25
"Timer Features.......... as 1e da aa 0000 26
1 26
Program Timer ....................... 26
Ири! бе!ес? ............ 2..5... 2.2.5... 27
Favoritechannel ...................... 27
Channel Scan........................ 27
Favorite Channel Select ............... 28
Спаппе! СарНоп ...................... 28
PresetCaption ....................... 28
Manual Caption... .................... 29
LockoutFeatures. ..................... 30
LockoutMode. ...................... 30
Unlock. ........ cL, 31
Control Panel Lock Feature ............. 31
Programming the Home Theater Remote ...32
Infrared Remote Codes For components. . .32
VCR Infrared Codes Index ............... 33
Cable Box and CD Players В
Infrared Codes Index ..................34
Cassette Players, Receivers, and Amplifiers
Infrared Codes Index .................. 35
Laser Disc, DSS, and DVD
Infrared Codes Index. ................ 36
PC MODE |
PC Input Connection (Rear) .............. 37
PC Input Connection (Front) .............. 38
TV/PC/DTV iii irri tinea a 39
Trilingual Animated Icons ............... 39
PC Mode 1соп$ ...................... 39
Picture Adjustments ................... 39
Picture Norm . ....................... 39
Color, Tint, Brightness, Picture and
~ Sharpness Adjustments . . ............. 39
Color TeMp 111 40
Audio Adjustments .................... 40
AudioNorm . ............... ......... 40
Bass, Treble and Balance .............. 40
Speaker ....... eceere, 41
Surround ....2020 001 A aa Le aa es 41
AlSound ................ oo. 41
Set Up Features..............000 000000 42
AutoPowerOn....................... 42
Geomagnetic Corr (Correction) .......... 42
InputSelect ...............c iit. 42
Display Adj............í_eweeeroccoorence 43
Display AdjustChart .................. 42
Table of Contents (cont’d.)
DTV MODE Surround... e... dere.
Components Video Connections .......... 44 Al Sound ............ e... e...
pco a tee de SetUp Features ............... nao
riingual Animated Icons. ............. Ne
DTV Mode Icons. . . . . . | В 45 Agpact Rato UE
Picture Adjustments 45 Color matrix. III
Color Tint. Brighinéés Picture and 45 Geomagnetic corr (Correction) ..........
Sharpness Adjustments Cee 45 TROUBLESHOOTING SECTION
ColorTemp ........................ 46 Troubleshooting Chart. ..................
Audio Adjustments ................... 46 Computer Resolution Set Up ui
AudioNorm ........................ 46 ForWindows 95 .................... a
Bass, Treble and Balance ............. 46 Computer Resolution Set Up O
Speaker . . oii anna nee 47 For Windows 3.X.................... >
-
Specifications
Power Source: 120 V ac, 60 Hz TF
Channel Capability: 181 channels (See chart) Channel Capability Chart
VHF 2-13, UHF 14-69,
Cable 125 channels BAND CHANNELS a
Video Input Jacks (2): 1 V p-p, 75 ohm, phono jack type | нЕ 19 e
Audio Input Jacks (2): 500mV rms, 4.7K ohm UHF 56 =
To Audio Amp Jacks: 0~2.0V rms, 4.7K ohm CABLE (Mid-Band) 15 +
S-Video Input Jack (2): S-Video (Y-C) Connector CABLE (Super Band) 14
DTV Input Jacks: Component Video (Y, Ps, Pa) CABLE (Hyper Band) 28
‘| Stereo Sound: NTSC with DBX Noise Reduction f CABLE (Ultra Band) 56
Surround Sound: Matrix
TOTAL CHANNELS 181
Computer Monitor Specifications Lu
PC and Mac Compatible Yes =
Viewable Image Size 36.0 inches =
Dot Pitch Date Grade >
Multi-scan Rate Yes a
Horizontal Frequency Range 15 KHz to 38 kHz
Vertical Frequency Range 50 Hz to 120 Hz
Max. Data Resolution 800 x 600 € 60 Hz
Linearity Correction Automatic
S-Curve Correction Yes
Dynamic Astigmatism and
Focus Correction . Yes e,
Audio Input-computer Mini-jack on front panel =
Computer Input 2-Front and rear 15-pin connector e,
z
Signal Capability Chart u
Signal Format Horiz. Freq. Vert. Freq. a
NTSC 15.75 kHz 60 Hz Interlaced =
VGA 540 x 480 315 kHz 70 Hz =
VGA text 31.5 kHz 70 Hz
VGA | 640 x 480 31.5 kHz 60 Hz
SVGA 800 x 600 37.9 kHz 60 Hz
MAC2 640 x 480 35 kHz 66.6 Hz
Specifications are subject to change without notice or obligation.
Safety Instructions
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: To reduce the risk of electric shock do not remove cover or back. No Ho
user-serviceable parts inside. Refer servicing to qualified service personnel.
The lightning flash with The exclamation point within
arrow-head within a triangle a triangle is intended to tell the
is intended to tell the user user that important operating
that parts inside the product and servicing instructions are
are a risk of electric shock to in the papers with the
persons. appliance.
Note To CATV System Installer: This reminder is provided to direct the CATV system installer's attention to Article
820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be
Satéty In ¿ HI Ang System Fare Veda Acoso ae point of cable entry as practical.
1. Read and apply the operating instructions provided with your television receiver.
2. Read all of the instructions given here and retain them for later use.
3. Unplug this television receiver from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp
cloth for cleaning.
4. Do not use attachments not recommended by the television receiver manufacturer as they may cause hazards.
>. Do not use this television receiver near water. For example: Avoid placing it near a bathtub, washbowl, kitchen sink, or
laundry tub, in a wet basement, or near a swimming pool, etc.
6. Do not place this television receiver on an unstable cart, stand or table. The television receiver may fall, causing serious
injury to a child or adult, and serious damage to the appliance. Use only with a cart or stand recommended by the
manufacturer, or sold with the television receiver. Wall or shelf mounting should follow the manufacturer's’ instructions,
and should use a mounting kit approved by the manufacturer.
6A. An appliance and cart combination should be moved with care. Quick stops, excessive force, and
uneven surfaces may cause the appliance and cart combination to overturn,
7. Slots and openings in the cabinet and the back or bottom are provided for ventilation, and to insure °
reliable operation of the television receiver and to protect it from overheating. These openings must not be blocked or
covered. The openings should never be blocked'by'placing the television receiver on a bed;-sofa,'rug-or-other similar
surface. This television receiver should never be placed near or over a radiator or heat register. This television receiver
should not be placed in a built-in installation such as a bookcase unless proper ventilation is provided.
8. Operate only from the type of power source indicated on the marking label. If you are not sure of the type of power
supplied to your home, consult your television dealer or local power company. For television receivers designed to
operate from battery power, refer to the operating instructions.
9. This television receiver is equipped with a polarized alternating-current ling plug (a plug having one blade wider than the
other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug
fully into the outlet, try reversing the plug. If
the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do EXAMPLE OF ANTENNA GROUNDING AS >
not defeat the safety purpose of the polarized PER NATIONAL ELECTRICAL CODE (NEC) a REA LEAD-IN
plug.
10. Do not allow anything to rest on the power
cord. Do not locate this television receiver GROUND
where the cord will be damaged by people CLAMP
walking on it.
11. Follow all warnings and instructions marked AE UNIT
on the television receiver. TT {NEC SECTION 810-20)
12. Do not overload wall outlets and extension
cords as this can result in fire or electric
shock. ELECTRIC
13. Never push objects of any kind into this SERVICE Tal = [ GROUNDING CONDUCTORS
television receiver through cabinet slots as EQUIPMENT 1 = (NEC SECTION 810-21)
they may touch dangerous voltage points or
short out parts that could result in a fire or GROUND CLAMPS
electric shock. Never spill liquid of any kind on | а EOWER SERVICE GROUNDING
the television receiver. (NEC ART 250, PART H)
14. if an outside antenna is connected to the television equipment, be sure the antenna system is grounded so as to provide
some protection against voltage surges and built up static charges. In the U.S. Section 810 of the National Electrical
Code and in Canada Part 1 of the Canadian Electrical Code provides information with respect to proper grounding of the
mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors,
location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
See Figure.
15. For added protection for this television receiver during a lightning storm, or when itis left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to the receiver due to
lightning and power-line surges.
16. An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power
circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system extreme care
should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
17. Unplug this television receiver from the wall outlet, and refer servicing to qualified service personnel under the following
conditions:
a. When the power cord or plug is damaged or frayed. Toe
b. If liquid has been spilled into the television receiver.
с. If the television receiver has been exposed to rain or water.
d. If the television receiver does not operate normally by following the operating instructions. Adjust only those controls
that are covered by the operating instructions as improper adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to restore the television receiver to normal operation.
e. If the television receiver has been dropped or the cabinet has been damaged.
f. When the television receiver exhibits a distinct change in performance - this indicates a need for service.
18. Do not attempt to service this television receiver yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
19. When replacement parts are required, be sure the service technician has used replacement parts specified by the
manufacturer that have the. same characteristics as the original part. Unauthorized substitutions may result in fire,
electric shock, or other hazards.
20. Upon completion of any service or repairs to this television receiver, ask the service technician to perform routine safety
“checks to determine that the television is in safe operating condition.
21. WARNING: To prevent fire or shock hazard, do not expose this appliance to rain or moisture.
22. CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT USE THIS (POLARIZED) PLUG WITH A RECEPTACLE OR
OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.
NOTE: This equipment 15 designed to operate in the U.S.A, Canada and other countries where the broadcasting system and
AC house current is exactly the same as in the U.S. A. and Canada.
Important Information Regarding Use of Video Games, Computers, Teletext or Other Fixed Image Displays.
The extended use of fixed image program material can cause a permanent «shadow image" on the picture tube. This
background image is viewable on normal programs in the form of a stationary fixed image. This type of irreversible picture
tube deterioration can be limited by observing the following steps:
A. Reduce the brightness/contrast setting to a minimum viewing level.
3. Do not display the fixed image for extended periods of time.
C. Turn the power off when not in actual use.
NOTE: The marking or retained image on the picture tube resulting from fixed image use is not an operating defect and as
such is not covered by Warranty. This product is not designed to display fixed image patterns for extended periods of
time.
Introduction.
Congratulations on Your New Purchase
Your new TV/Monitor features an all solid state chassis which is designed to give you many years of
enjoyment. It was thoroughly tested and adjusted at the factory for best performance.
In order for you to take full advantage of your new TV/Monitor, please read and follow the
installation and operating instructions contained herein.
Customer’s Record
The model and serial number of this product may be found on its back cover. You should note the
model and serial number in the space provided and retain this book as a permanent record of your
purchase to aid in identification in the event of theft or loss
Model Number: Serial Number:
You may register your new television set on the Internet at:
http://www.prodreg.com/panasonic
a MN. _ .
For Customer Assistance: Call the Panasonic Customer Call Center, 2F-3 One
Panasonic Way, Secaucus, NJ 07094 (Headquarters) 800-211-PANA-(7262),
Monday-Friday (9 a.m.-9 p.m. EST), Saturday-Sunday (9 a.m.-7 p.m. EST),* "+
-
Average Power Consumption
VGA SVGA Standby
TV Mode Mode Mode Mode
180W 170W 175W 1.7W
IMPORTANT INFORMATION
FCC STATEMENT:
This equipment was tested and found to comply within
the limits for a Class B digital device, pursuant to Part
15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference with radio communications. However,
there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by tuning the equipment on
and off, the user is encouraged to try to correct the
interference by one or more of the following measures:
* Reposition or relocate the receiving antenna.
* Increase the separation between the equipment
and radio/TV receiver.
* Connect the equipment into an outlet on a circuit
different from that to which the radio/TV is
connected... a
+ Consult the dealer or an experienced radio/TV
technician for assistance.
FCC CAUTION:
Pursuant to 47CFR, Part 15.21 of the FCC rules, any
changes or modifications to this monitor not
expressly approved -by Matsushita Electric
Corporation of America could cause harmful
interference and would void the user’s authority to
operate this device.
To assure continued compliance, the shielded
video cable with bonded ferrite cores provided
must be used when connecting this TV to a
computer device. (Part #TSX4515-3). The TDK EMI
filter, also provided, Part #ANF-106U, must be used
to plug this TV into a grounding type outlet.
CANADIAN NOTICE:-
This class B digital apparatus meets all
requirements of the Canadian Interference-Causing
~+ Equipment Regulations.
AVIS CANADIEN:
Cet appareil numérique de la classe B respecte
toutes les exigences du règlement sur le matériel
brouilleur du Canada. - :
Important: Changes or modifications not
expressly approved by the party responsible
for compliance could void the user's authority -
to operate the equipment.
FCC Declaration of Conformity
Responsible party:
Matsushita Electric Corporation of America
One Panasonic Way
Secaucus, NJ 07094
U.S.A.
Telephone Number: 1-800-211-7262
(9 a.m.-9 p.m., Mon-Fri, EST)
(9 a.m.-7 p.m., Sat-Sun, EST)
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
| (1) this device may not cause harmful interference,
| and (2) this device must accept any interference
received, including interference that may cause
I undesired operation.
FIT
GG
=D
Three-wire plug with EMI filter
- a
+ Ha +
Installation
Video Monitor/Receiver Location
This video monitor/receiver is intended to be used with an optional stand. Consult your dealer for available options.
Locate for comfortable viewing. Avoid placing where sunlight or other bright light (including reflections) will fall on
the screen. Use of some types of fluorescent lighting may reduce remote control transmitter range.
Adequate ventilation is essential to prevent internal component failure. Keep away from areas of excessive heat or
moisture. To insure optimum color purity do not position equipment containing magnets (motors, fans, external
speakers, etc.) nearby.
Optional External Equipment Connections
The Video/Audio connections between components can be made with shielded video and audio cables. For best
performance, video cables should be of 75 ohm type coaxial shielded cables. Cables are available from dealer or
electronic supply house.
Before you purchase any cables, check out the type of output and input connectors your various components
require. Also determine the length of cable you will need.
Power Supply Cord
MAKE SURE PLUG IS INSERTED FULLY INTO THE EMI FILTER. SEE
PAGE 7 ILLUSTRATION.
This product is equipped with a three-wire grounding type plug-a plug with two blades and a
third pin which is round. This plug will only fit into a grounding type outlet.
This is a safety feature. If you are unable to insert the plug into the outlet, contact your
electrician to replace your obsolete outlet. DO NOT DEFEAT THE SAFETY PURPOSE OF
THE GROUNDING TYPE PLUG.
Remote Control Battery Installation
Batteries: Use two “AA” batteries.
1. Remove the battery compartment cover on back of the remote.
2. Install the batteries in the battery compartment. (Polarity (+)
or (-) must be correct.)
3. Reattach the battery cover.
Helpful Hints:
For frequent Remote Control users, replace old batteries with
Alkaline batteries for longer life.
(Y) Battery
Precaution on Battery Use
Incorrect installation can cause battery leakage and corrosion
that will damage the Remote Control.
Observe the following Precautions: _ Press Down Here
1. Batteries must be replaced as a pair. and Slide Cover
2. Do not combine a used battery with a new one.
3. Do not mix battery types (Example: “Zinc Carbon” with “Alkaline”). =
4, Do not attempt to charge, short-circuit, disassemble, heat or .: —
burn used batteries. 3 У
5. Battery replacement is necessary when Remote Control
reacts sporadically or stops operating the television.
NOTE: |
Whenever you remove the batteries to replace
them, you may need to reset the Remote Control
Infrared Codes. We recommend that you initially
record the codes in the Infrared Remote Codes for
Specific Components section, prior to setting up the
remote.
Installation (cont’d.)
TV Antenna/Cable Connections |
Antenna Connection - For proper reception of VHF/UHF channels, an
external antenna is required. For best reception, an outdoor antenna is
recommended. In the SETUP menu, set the MODE to TV. (Refer to Antenna |
Mode section.)
Indoor Outdoor
Typical VHF/UHF Antenna
Incoming Cable from Home Antenna
VHF/UHF
75 Ohm on Back of Set 300 Ohm
VHF/UHF |
on Back of Set O = 6
(© | ”
300 to 75 ohm Matching
CA Transformer (Not included)
- a=
=
— tm”
Cable Connection — For reception of cable channels, connect the cable supplied by your local cable company. In
the SETUP menu, set the MODE to CABLE. (Refer to Antenna Mode section.)
Incoming Cable from Cable Company
75 Ohm
VHF/UHF
On Back of Set
(00 — Cm
Note: Certain cable systems offset some channels to reduce interference, or have premium (scrambled)
channels. A cable converter box is required for proper reception. Check with your local Cable company for
compatibility requirements.
Other Video Equipment
VCRs, Video Disc Players, Computers, TV games, and DSS equipment can also be connected to the antenna
input connection.
Care and Cleaning
Picture Tube (Turn television off)
Use a mild soap solution or window cleaner and a clean cloth. DO NOT USE ABRASIVE CLEANERS. Avoid
excessive moisture and wipe dry.
. Plastic Cabinet
- Wipe the cabinet with a soft cloth dampened with water or a mild detergent solution and wipe dry with a soft clean
* cloth. Avoid excessive moisture. Do not use benzene, thinners or other petroleum- based cleaners.
Remote Control Transmitter
Use a soft cloth slightly moistened with a mild detergent and then wipe dry with a soft clean cloth. Avoid excessive
moisture. Do not use benzene, thinners or other petroleum-based cleaners.
-9-
Location of Controls (TV/Monitor)
De AA
o a EE
Ty = —— “Ea
LES) Gio) Gomi Ton] pie [era] 13)
—# Hut Rugs Hm Hit, HTH Caras
Appalachian Moymtyng
Mountain
3)
Push here to
open door
Remote Control
Sensor
Front Control Panel
POWER VOLUME} vw CHANNELA ACTION INPUT 4 \ | ETE
li. =
| IT; =
ID FS
HA + ne?
LA
\/ Cu va H fi
Quick Reference Control Operation
© Power Button — Press to turn television ON or OFF.
O Volume Buttons — Press to adjust Sound Level, Audio and Video Menus and to select operating features
when menus are displayed.
(3) Channel Buttons — Press to select programmed channels or to highlight desired features when menus
are displayed.
(4) Action Button - Press to display Main Menu and access or exit On Screen feature and Adjustment Menus.
® Input Button - TV Mode press to select TV or one of two Video Inputs. PC Mode press to select Front or
Rear PC Input.
® Audio Input — Use Front PC Audio input jack when connected to a PC sound source Audio output.
7) PC Input - Connect to a computer having a 15-pin output terminal.
- 10 -
Location of Controls for the Home Theater Remote Unit
Basic Remote Control Functions
The following is a basic overview of the remote control
unit for TV/Monitor operation. Ensure the TV mode
button is selected by initiaily pressing (9 .
> € i
| (1 Power Button - Press to turn the TV ON or OFF.
|
Volume Buttons - Press to adjust TV sound level.
Use with Channel buttons to navigate in menus.
(3) Channel Buttons - Press to select channels. Use
with Volume buttons to navigate in menus.
(4) Action Button - Press to display Main Menu and
access or exit On-Screen feature and Adjustment
Menus.
(5) Input Button - Press to select TV or one of two (2)
Video Inputs. Also used to select Front or Rear PC
Input.
(6) Mute Button - Press to mute sound. A second
press returns sound. но
(7) Numeric Keypad (0 through 9 Buttons) - Press’
desired channel to access any channel. vi
=
(8) R-Tune (Rapid Tune) Button - Switches between |
two (2) channels.
J
CD VIER 0 (9) Recal Button - Press to display Time, Status or
| > <> ©, Sleep Timer, Channel, Video Mode, Channel
N Caption (Station Identifier), and Audio Mode.
—(3 (O Multi Button - Programmable to operate up to six
(6) Remote Function buttons simultaneously.
APver Functions Buttons - Programmable to
operate many brands of VCR's.
(12) Mode Selection Buttons - Selects the operations
mode for the remote control.
A3VCR/DSS Channel Buttons - These buttons are
used to select VCR or DSS channels (Up/Down).
Home Theater ,
Remote Control Helpful Hints:
TNQ2AE012 if the selected component does not respond to the
remote controi, ensure that the proper mode is
selected. First, press the Mode Selection Button
that corresponds to that component. For example,
after first pressing the TV mode button, the remote
will remain in the TV mode for any following
commands. If a different mode bution is pressed
while operating the television, the TV mode button
must be pressed again to reset the TV mode
condition.
- 11 -
Remote Control
Quick Reference Functional Key Chart
MODE
FUNCTION
TV Selects Channel
VCR, VCR 2 Selects Channel
CABLE, DSS Selects Channel
(2) (3) ® Selects CD Player
(4) (5) @ Selects Tape Cassette Player
@ VCR 1 |
(7) иене
CD PLAYER Selects Track Number
LD PLAYER Selects Track Number
ALL COMPONENTS Programmable Button That Can Operate Up To Six (8) Remote
По Functions At Once
TV. Select the TV Input Mode
Also Selects Front or Rear PC Input
ALL COMPONENTS Turns On and Off Selected Components
TV, DSS, VCR, VCR 2 LDP
CABLE
RECEIVER/AMPLIFIER
Mutes TV Audio
Mutes Audio
Mutes Audio
TV TV Mode Selection for Remote Control
CABLE Cable Mode Selection for Remote Control
DSS (DIGITAL SATELLITE DSS Mode Selection for Remote Control
SYSTEM)
VCR VCR Mode Selection for Remote Control
RECEIVER/AMPLIFIER
Receiver/Amplifier Mode Selection for Remote Control
COMPAËT DISC CD Mode Selection for Remote Control
CASSETTE DECK, AUX Mode Selection for Remote Control
VCR 2, DVD Enables User to Operate a Cassette Deck, Digital Video Disc or
Second VCR
LASER DISC PLAYER
LD Mode Selection for Remote Control
4b|9| 88/6/6158 89 8 8 8 8 | ©
TV
CABLE
DSS
LOP
CD
RECEIVER/AMPLIFIER
DVD
Channel Up/Down, Menu Navigation
Channel Up/Down
DSS Guides and Menu Navigation
Skip
FF, REW
Preset or Tuning Frequency
Skip FWD/Skip REW
A
Y
TV
CABLE
DSS
RECEIVER/AMPLIFIER
VCR, VCR 2
LDP
Volume Up/Down, Menu Navigation
Volume Up/Down
DSS Guides and Menu Navigation
Volume Up/Down
TV Volume Up/Down
TV Volume Up/Down
- 12 -
Remote Control
Quick Reference Functional Key Chart (cont'd.)
KEY MODE FUNCTION
a
(R-TUNE}
ee 05
LDP
TV
CABLE
VCR, VCR 2
DSS
RECEIVER/AMPLIFIER
A/B Repeat
Switches Between Two (2) Channels
Switches Between Two (2) Channels
Switches Between Two (2) Channels
Switches Between Two (2) Channets
Switches Between AM and FM
CD Selects Next Disc
AUTO TAPE RECORDER Selects Audio Tape Recorder A or B
TV Activates TV Menus
DSS Acts as Menu Button for DSS
TV Displays Channel, Sleep Time, Channel Caption, Time and
ет DSS Audio Mode
RECALL VCR, VCR 2 Displays Current DSS Settings
LDP Displays Current VCR Settings
Displays Current LDP Settings
DSS DSS Guide
REW VCR, VCR 2. a Rewind
LDP Rewind
TAPE- Rewind
"CD Selects Previous Track
DVD Rewind
DSS Enter/Select
VCR, VCR 2 Play
PLAY LDP Play
[>] TAPE Play (in Norma! Direction)
CD Play
DVD Play
DSS Exit/Clear
VCR, VCR 2 Fast Forward
FF LDP Fast Forward
TAPE Fast Forward
CD Selects Next Track
DVD Fast Forward
DSS One Touch Record in DSS Mode
REC VCR, VCR 2 Record
TAPE Record
CABLE VCR Record
DVD Stop
VCR, VCR 2 Stop
STOP LDP Stop
(2 | ТАРЕ Stop
CD Stop
CABLE VCR Stop
DVD Pause
VCR, VCR 2 Pause
PAUSE LDP Pause
TAPE Pause
CD Pause
CABLE VCR Pause
TVNCR VCR, VCR 2 Selects TV/VCR Mode
DSS Selects TV/DSS Mode
CD CABLE Selects TV/VCR Mode
VCR, VCR 2 Channel Up/Down
VCR/DBS CH
DSS Channel Up/Down
D © р
- 13 -
Special Functions
MULTI Button
The MULTI Button can be programmed to issue
several commands at the same time.
Example: TV Power/On, VCR Power/ON, and Cable
Box Power/On.
Procedure:
1. Enter proper infrared codes for all devices before
programming. See code section.
2. Point your Remote Control Transmitter away from
all equipment remote sensors, then:
Press and
keep holding
о \
Then ALSO
4
5 9
Release after 3
© “eo
NOTE: Waiting more than 30 seconds without pressing
another button will exit the programming mode.
Press and keep
holding for 3
seconds
3. Press a maximum of 6 function buttons on the
Remote Control. Each button you press is equal to
one function. If 6 Remote button functions are
entered, all will register in the «fut» button
memory when the sequence is entered. When
finished, press the (MuLTD to exit the programming
mode.
NOTE: Buttons which continuously perform a function
as long as pressed (Volume Up/Down; Channel
Up/Down, etc.) cannot be programmed; only those
buttons which perform a function when initially
pressed (Power On/Off, Mute, Direct Channel
Entry, etc.) can be programmed.
The following is a flow chart example of remote
functions that can be programmed into the (MULTD
button: - -
PRESS AT THE SAME TI TIME
FOR 3 SECONDS
O © O
O — —
PRESS PRESS
PRESS TO EXIT
17: PROGRAMMING MODE
Pressing the «MULT»> button will now activate the VCR
Power/On, Cable Box Power/On, and the Receiver
Power/On at the same time. РО
RECALL Button OUT
Press the RECALL Button to review:
(1) Audio Mode status
2) CH number or Video Input selected
© Channel Caption (Station Identifier)
@ Clock time
(6) Sleep Timer status
©
VIDEO 1:
KXYZ CH3 @
© 29 1:00
R-TUNE Button
Pressing the R-TUNE (RAPID TUNE) button toggles to
the previously tuned program.
PROGRAM PROGRAM
CURRENTLY VIEWED PREVIOUSLY VIEWED
Press Button
—eo s E
en
_— ;————
В НЫ
Press Button Again
- 14 -
Optional Equipment Connection and Operation
To Audio AMP Connection (Stereo) . :
Connect to an external audio amp auxiliary input for monitoring sound through a stereo system.
TERMINALS ON BACK OF MONITOR |
“TO AUDIO AMP” terminals
cannot be used directly with
external speakers.
Adjustment. — When : an audio amp is connected to TO # AUDIO AMP” terminals:
1. Select TV SPEAKERS “ON” Mode. (Refer to the Menu TV Speakers section. )
2. Set volume of audio amp to near minimum.
3. Adjust volume of TV to desired listening level.
4. Adjust volume of audio amp to match the level of TV,
5. Select TV SPEAKERS "OFF&VAO" Mode. (Refer to the Audio Menu TV Speakers section.)
6. Audio bass, treble, balance, volume and mute can now be controlled by the TV Remote Control.
NOTE: When Selecting TV SPEAKERS “OFFEFAO” Mode, the TV sound output is always at a constant level and cannot
changed (Refer to the Audio Menu TV Speakers section).
Audio/Video Input Connection
S-Video connection is optional
and overrides the standard Video
connection when connected.
TERMINALS ON BACK OF MONITOR
VCR S-VIDEO (YC)
CONNECTOR OPTIONAL
I)
[O a o ос pis
R
i
= ame OT] AUDIO OUT
rar AUDIO ‚© VCR or VIDEO
DISC PLAYER
pe INPUT TO TO AUDIO TUN 2 РОТ 1 |
Operation
1. Connect optional equipment as shown to INPUT 1 or 2 terminals. If S-Video is to be used, connect
S-Video (YC) connector to S-Video terminal 1 or 2 and connect audio cables to L & R Audio
INPUT 1 or 2 terminals. |
2. “Select the desired Video mode by pressing Input or TV/VIDEO button.
3. Operate optional equipment (VCR, DVD or VDP) as instructed in Optional Equipment manual.
NOTE:
* You must select the proper VIDEO Input Mode where the equipment is connected.
« Connection of optional S-VIDEQ jack automatically disconnects Video Input 1 or 2 jacks.
r---- — —
— Ñ—— ] jj: 0 = Ral et Sle НМ Банный ЧА ll
-15 -
TV Mode
Trilingual Animated Icons
The Icons allows the users to configure the TV
according to their preference. It will also set up the
monitor to operate with external components
connected to the terminal jacks
TV Mode Icons
GET, UP
PKTURE
NOTE: Only the selected icon (red) will be animated.
(emo Display and Exit menus
e
CH BUTTONS
Highlight Desired
Feature on Menus
VOL BUTTONS
Selects or Ajusts
Features on Menus
NE Located on Remote Control
Menu Language Selection
The MENU LANGUAGE is factory set to ENGLISH.
Follow the instructions to change it to SPANISH,
FRENCH, and back to ENGLISH (TV, PC, and DTV
mode).
1 Press :
2. Press A or y and € or №№ to highlight
the Language ENGLISH /ESPAÑOL/FRANCAIS
Icon.
3. Press to display the Language select menu.
¿MTS
ENGLISH
ESPANOL
FRANCAIS
Press A or Y to select ENGLISH, ESPAÑOL
or FRANCAIS for the Language Menu.
e Press twice to exit menus.
Picture Adjustments
Picture Norm
Use to reset Color, Tint, Brightness, Picture, and
Sharpness adjustments to the factory preset level for
TV Mode only.
1. Press (==).
2. Press A or № and < or > to highlight the
Picture Icon.
3. Press to display the Picture Adjustment
Menu.
PICTURE! VIDEO
PICTURE NORM
‘CONOR
Ay
BRIGHTNESS
SHARBNESS
GEES
mn,
4. Press A or y to highlight PICTURE NORM.
5. Press «a or > to select “SET” to normalize
Color, Tint, Brightness, Picture, and Sharpness.
6. Press twice to exit menus.
Color, Tint, Brightness, Picture, and
Sharpness Adjustments
Helpful Hints:
COLOR - Adjust for desired color intensity.
TINT - Adjust for natural flesh tones.
BRIGHTNESS - Adjust so dark areas of picture
slightly became black for a crisp detail.
PICTURE - Adjust the white areas of the picture as
desired.
SHARPNESS - Adjust for best clarity of outline
detail. |
1. Press E
2. Press A or y and < or > to highlight the
Picture Icon.
3. Press to display the Picture Adjustment
menu.
- 16 -
Picture Adjustments (cont’d.)
Color, Tint, Brightness, etc. (cont’d.)
4. Press A or Y to select the desired Picture
Adjustment (Color, Tint, Brightness, Picture,
or Sharpness).
5. Press El or № to adjust your selection. (The
Selected Picture Adjustment will be displayed.)
6. Repeat steps 4 and 5 for the remaining Picture
Adjustments.
7. Press (Gn) (==) twice to exit menus.
Color Temp
To select one of three (3) options for picture
temperature.
Helpful Hints:
NORMAL - No tint
WARM - Reddish tint
COOL - Bluish tint
1. Press (=).
2. Press A or M and € or > to highlight the
Picture Icon.
3. Press to display the Picture Adjustment menu.
BTL
OFF
4. Press or Y to highlight COLOR TEMP.
5. Press € or > to select NORMAL, WARM, or
COOL.
6. Press twice to exit menus.
Auto Color
To automatically optimize color ‘adjustment to
compensate for signal variations.
1. Press E
2. Press A or № and < or > to highlight the
Picture Icon.
3. Press (=) to display the Picture Adjustment Menu.
Ш
с
O
=
>
-
Mi
PRESS, CHRYAFOR MORE
4. Press A or y to highlight AUTO COLOR.
5. Press € or > to select ON or OFF.
6. Press twice to exit menus.
Video NR
This feature increases the horizontal resolution in
the picture.
1. Press (==).
2. Press A or № and <Q or > to highlight the
Picture Icon.
3. Press E (==) to display the Picture Adjustment a
menu.
PICTURE VIDEO
RRESSICHE MP ORIMORE
4. Press A or y to highlight VIDEO NR (Noise
Reduction).
5. Press J or > to select ON or OFF.
6. Press: twice to exit menus.
- 17 -
|
<
=
e,
O
m
Audio Adjustments
Helpful Hints:
Setting TV mode Audio Adjustments will also
change PC Mode and DTV mode Audio Adjustment.
Audio Norm
This feature is used to reset Bass, Treble and Balance
b
1.
2.
6.
ack to a factory preset level.
Press E).
Press A or y and < or > to highlight
the Audio Icon.
Press to display the Audio Adjustment Menu.
Press A or № to highlight AUDIO NORM.
Press < or № to select “YES” to Normalize
Bass, Treble and Balance.
Press twice to exit Menus.
Bass, Treble & Balance
6.
7.
„AUDIO? AUDIO
Seo Eat
Press A or ÆŸ to highlight BASS, TREBLE or
BALANCE.
Press «< or > to adjust for desired audio
response.
Repeat steps 4 and 5 for remaining audio
functions.
Press the (em) twice to exit menus.
Mode — Stereo/SAP/Mono
When Audio is broadcast in Stereo or SAP an ON
Screen display will appear on initial “Turn On” and
“Channel Change”.
indicated in red.
The available choices will be
Helpful Hints:
Helpful Hints:
BASS - To increase or decrease the Bass response.
TREBLE - To increase or decrease the Treble
response.
BALANCE - To emphasize the Right and Left
Speaker's volume.
Press .
Press A or y and < or № to highlight
the Audio Icon.
Press to display the Audio Adjustment Menu.
STEREO - Two channel audio reception.
SAP - Second Audio Programming (such as
bilingual audio, weather reports, etc.).
MONO - Use when stereo signal is weak.
- 18 -
Press Ge) |
Press A or 7 and El or > to highlight the
Audio Icon.
Press the to display the Audio Adjustment
Menu.
Press A or y to highlight MODE.
Press € or D to select STEREO, SAP (Second
Audio Programming) or MONO. The selected
mode will be highlighted.
Press twice to exit menus.
Audio Adjustments (cont’d.)
Speaker
This feature is used to turn the internal speakers “ON”
or “OFF”, It is used when the TV is connected to an
external audio amplifier. (Refer to “To Audio Amp”
connection section for further information.)
1. Press ,
2. Press JAN or Y and < or > to select the
Audio Icon.
3. Press to display the audio Adjustment Menu.
4. Press AN or Y to highlight SPEAKER.
5. Press € or > to select ON, OFF&VAO or
OFF&FAO.
* ON-TV speakers operate normally.
* OFF&VAQ — (Variable Audio Output) — TV
speakers off, the sound output varies according to
the TV volume, use the TV remote to control the
volume, muting, bass, treble, and balance of the
external stereo system.
* OFFEFAO (Fixed Audio Output) — TV speakers off,
sound output is fixed.
6. Press twice to exit menus.
Surround
Use the Surround Feature to enhance audio response
when listening to Stereo broadcasts.
1. Press E
2. Press A or Y and € ог № to highlight the
Audio Icon.
3. Press to display the Audio Adjustment Menu.
4. Press /A or W7 to highlight SURROUND.
5. Press Él or to select SURROUND ON or
OFF.
6. Press twice to exit menus.
Al Sound
This feature is used to maintain constant sound level
when switching between programs with different sound
levels. For example, when the broadcast program
switches to a commercial, the commercial sound level
will be maintained close to the level of the broadcast
program. |
1. Press (Leo). : В
2. Press AAN or Y and El or ¥ to highlight the
Audio Icon.
3. Press to display the Audio Adjustment Menu.
Te
"AUDIO
4. Press £\ or-\7 to highlight Al SOUND.
5. Press © or J to select Al SOUND ON or OFF.
6. Press twice to exit menus.
-19-
1
-
e,
=
>
FH
—
<
=
O
=
m
TV/PC/DTV
Helpful Hints:
TV - Television mode
PC - Computer mode
DTV - Digital television mode
Press =).
Press /2\ or NY and € or > to select the TV/
PC/DTV Icon.
Press =) to display the TV/PC/DTV mode menu.
4. Press € or > to highlight Tv, PC (Front or
Rear), or DTV.
NOTE: Press Input button while in PC mode to select
PC Front or Rear.
5. Press twice to exit menus.
Set Up Features
Clock Auto (TV Mode)
This feature automatically adjusts the TV clock to the
correct time whenever the TV is tuned to a PBS (Public
Broadcasting Service) station for 10 minutes or until
the correct time and day are displayed (Refer to your
local TV guide for PBS channel number).
NOTE: A plus or minus one-hour offset can be
programmed to adjust the clock when there is
a time zone difference between the PBS TV
station and the viewer.
1. Press
2. Press A or Y and & or }® to highlight the
Set Up Icon.
3. Press to display the Set Up menu.
NOTE: This menu is not available when AUTO
POWER ON is set.
AUTO TIME SET
AUTO POWER ON —
GEOMAGNETIC CORR
PRESS CH т FOR MORE
4. Press A or Y to highlight CLOCK.
5. Press Él or P to select AUTO (if necessary).
6. Press to highlight AUTO TIME SET.
7. Press & or > to display the AUTO TIME SET
Menu.
8. Press AN to highlight PBS CHANNEL.
- 20 -
Set up Features (cont’d. )
Clock Auto (cont’d)
AUTO VIE SET
KEEPRISETATUNEDJTOIRBS
| RTE SIO
O RES DO CODO Cels
PBS CHANNEL ;
WAITING FOR CORRECT TIME AND DAY
Ш
oO
O
=
>
-
9. Tune TV or Cable Box to PBS channel, using the
Remote Control Keypad to enter PBS channel
number. AUTORTIME SEN
10. Press \ to highlight TIME ZONE ADJUST. -
| ED PO UR)
CTS E dor E
CORRECTATIME[RUEFASE)
SETATIM ESMANVGATEY,
ES wa RIC'AB [GRO |
О RBSIC MUNIE (o) - COMPLETED READ MENU
TIME ZONE ADJUST
SUV LUE
11. Press El for minus one-hour offset or > for plus AUTO TINE GET
one-hour offset (if necessary).
12. Press \&/ to highlight ACTIVATE. COREE
- NOTANIMEJDATAJEOUND
PIEASEISETMDAYSAND
INCOMPLETED READ MENU
TUN EMVIORICABIEIDON
CH'ANNEIMNOW | .
14. Press four times to exit menus.
ACTIVATE
13. Press < or > to display the AUTO TIME SET
ACTIVATE Menu.
+
<
=
e
о
m
Set Up Features (Cont’d.)
Clock Manual
Clock (when set) will display On Screen at initial turn
on, after a channel change and when pressing (RECALD .
It must be set in order to operate the dual Timer
feature.
1. Press E.
2. Press A or №7 and a or № 10 highlight the
Set Up Icon.
3. Press (==) to display the Set Up menu.
NOTE: This menu is not available when AUTO
POWER ON is set.
PRESSICHEMEORIMORE!
4. Press Le or y to highlight CLOCK.
5. Press a or № to select MANUAL.
6. Press A or W to highlight SET TIME.
7. Press < or > to Set Hours (set AM/PM
accordingly).
8. Press y to highlight minutes position.
9. Press < or > to set minutes.
10. Press twice to exit menus.
Set Day
The day of the week must be set in order to operate the
Dual Timer feature.
1. Press ,
2. Press A or №7 and € or > to highlight the
Set Up Icon.
3. Press to display the Set Up menu.
4. Press (A or Y to highlight SET DAY.
5. Press a or № to select proper day of the week.
6. Press twice to exit Menus. -
Auto Power On 3
Automatically turns the television on when a VCR,
Cable Box, etc., are powered. The monitor needs to be
plugged into the switched outlet of the device. Setting
the Auto Power On feature will cancel the time and
timer control settings. The Main Menu Icon for the
TIMER CONTROL will be replaced with an EXIT Icon.
Press (==) |
2. Press A or Y and El or № to > highlight the
Set Up Icon.
3. Press (==) to display the Set Up menu.
4. Press A or 7 to highlight AUTO POWER ON.
5. Press € or => to select SET.
6. Press twice to exit menus.
- 22.
Set Up Features (cont'd.)
Geomagnetic Corr (Correction) .
This monitor incorporates a special adjustment feature
for the convenience of the customer. This adjustment is
present at the factory. However, adjustment may be
required when the monitor is moved (due to the
influence of earth's magnetic field) which may cause
the picture to tilt slightly. If necessary, .follow these
procedures to adjust the tilt.
1. Press (=).
2. Press A or № and < or > to highlight the
Set Up Icon.
3. Press to display the Set Up menu.
4. Press A or Y to highlight GEOMAGNETIC
CORR.
5. Press € or > to display the Geomagnetic
Correction adjustment menu.
6. Press A or № to adjust the picture tilt until left
and right side of tilt adjustment bar is parallel to the
bottom of picture frame (if necessary).
NOTE: Discoloration may be visible in picture
corners if tilt bar is not parallel to the
bottom of picture frame.
tilt adjustment bar
7. Press twice to exit menus.
Mode
IMPORTANT NOTE: The proper input mode must
be selected for the type of signal at the antenna
input.
* TV is used when the television is not connected to
a Cable TV System, for example, when using a
VHF/UHF antenna (Channels 02-69).
* CABLE is used when the television is connected to
a Cable TV System and when not using a Cable
Box (Channels 01-125).
NOTE: Some Cable TV Systems encode (scramble)
program material on specific channels. A cable
company supplied decoder is required to
reproduce an acceptable picture. Certain
Cable TV Systems offset some channels to
reduce interference. It will be necessary to use
the cable company supplied converter to
receive these specific channels:
1. Press .
2. Press (A or Y and El or to highlight the
Set Up Icon.
3. Press to display the Set Up menu.
Xn ROGRAM
UATNPROGRAM
4. Press AA or Y to highlight MODE.
5. Press a or > to select TV or CABLE.
6. Press twice to exit menus.
-23.-
Ш
a
e)
=
>
-
|
pt
=
©
=
m
Set Up Features (cont'd.)
Auto Program
The Auto Programming feature allows you to place
channels with a video signal into Channel Scan
Memory. When you press /\ or \&, only those
channels with a video signal will accessed. TV or Cable
Tuning mode must be set properly for your system.
Helpful Hints:
After Auto Programming:
Blue channel number indicates channel is in
Channel Scan Memory.
-All channels are available by direct access using the
Keypad numbers “0 through 9”.
After Auto Programming Scan has completed, up to
15 channels will be programmed into the FAVORITE
Channel Scan if space is available. Any original
channels that were programmed into FAV
CHANNEL will remain. (Refer to Favorite Channel
Scan for deleting unwanted channels.)
1. Press =)
2. Press A or y and € or > to highlight the
Set Up Icon.
3. Press to display the Set Up menu.
MODE. pe
AUTO PROGRAM
a MANUAL PROGRAM
NE CC ON MUTE
E CC MODE
PRESSCH Y FOR MORE
4. Press A or W7 to highlight AUTO PROGRAM.
5. Press a or № to start Auto Programming Scan.
Channels will automatically advance until all
channels have been scanned.
6. Channel numbers with video signal present will
turn blue which indicates stored in Channel Scan
Memory.
7. Press twice to exit menus.
NOTE: Some channels with very weak signals may be
- locked into memory. These must be deleted
manually using the Manual Program feature.
Manual Program
This feature allows you to select which channels are
placed into Channel Scan Memory so when you press
/A or 7 only those channels you desire will be
accessed. 2
1. Press the
2. Press A or № апа < or > to highlight the
Set Up Icon.
3. Press to display the Set Up menu.
4. Press A or y to highlight MANUAL
PROGRAM.
5. Press a or № to display Manual Programming
Menu.
MANUAL PROGRAM
ENTER CHANNEL
к.
CAD
219 QUE
6. Use the Remote Control Keypad numbers “0
through 9” or A or E to select channels.
7. Press № to add channel(s) to memory (blue).
Press the € to delete channel(s) from memory
(yellow).
8. Repeat Steps 6 and 7 to continue adding or
deleting channels.
9. Press twice to exit menus.
- 24 -
Set Up Features (cont’d.)
[cc] On Mute
Activates the On Screen Closed Caption feature when
the MUTE> on the Remote Control is pressed. To
deactivate press <MUTE> again.
NOTE: This feature only functions when the Close
Caption Mode is in the “OFF” position. The
program being viewed must be broadcast with
Closed Caption. (Refer to your local TV guide).
1. Press (==)
2. Press A or y and < or > to highlight the
Set UP Icon.
3. Press to display the Set Up menu.
4. Press A or № to highlight CC ON MUTE.
5. Press < or > to select NO, C1, C2, C3 or C4.
Recommended Set Up for Closed Caption when using
(MUTE)
* CC ON MUTE: C1
* CC MODE: OFF
6. Press twice to exit menus.
7. Press MUTE> when program being viewed is
broadcast with Closed Caption to activate.
NOTE: Press (MUTE> again to deactivate.
Mode
This television contains a built in decoder that is
capable of providing a visual depiction of the audio
portion. The program viewed must include Closed
Captioning (CC) for the television to display it. CC is
displayed in the form of text across the screen (white or
colored letters on a back background). It allows the
viewer to read the dialogue of a television program or
other information.
1. Press
2. Press A or 7 and € or > to hiohlight the,
Set Up Icon.
3. Press to display the Set Up menu.
4. Press A or y to highlight CC MODE.
5. Press < or № to select OFF, Ct, C?, T1, Te,
C3,C4, T3 or T4,
» CAPTION OFF — Use when Closed Caption is not
desired.
+ CAPTION C1 - For video related information that
can be displayed (up to 4 lines of script on the
screen, where it does not obstruct relevant parts of
the picture). Script can be in any language.
* CAPTION C2 — Another mode used for video
related information.
» CAPTION C3 and C4 — Other modes used for
video related information. |
» TEXT T1 — Blanks out large portion of the picture
on the television screen, and displays program
guide or any other information currently being
transmitted.
* TEXT T2, T3 & T4 - Other modes that display
information and blank out a large portion of the
picture on the television screen.
6. Press (==) twice to exit menus.
. 25.
Ш
Q
O
2
=>
=
Ч
<
—
e
=
m
Timer Features
Sleep Timer
This feature is used for automatic turn OFF in 30, 60 or
90 minutes as desired. =
NOTE: Display will be flash 3, 2 and 1 to indicate the
last three remaining minutes prior to turn OFF.
To deactivate, press a or > until "NO" is
displayed.
Press
Press A or Y and al or № to highlight the
Timer Icon.
Press (=m) button to display the Timer Control
menu.
TIMER 2
SATSSUN
cofoo
серое
20
4. Press or № to select 30, 60 or 90 (minutes)
;' for Sleep Timer to be activated.
5. Press (==) twice to exit menus.
NOTE: To deactivate Sleep Timer, repeat steps 1
through 4. In step 4, select "NO” instead of
minutes. Timer Control is not available when
Audio Power On is set.
Special Feature:
Automatic turn “OFF” after 90 minutes.
The TV has a special feature that will shut itself OFF
after 90 minutes when turned ON by the program
timer unless a function key is pressed during the 90
minutes.
This feature is used to insure that the TV will not
remain ON unattended for an extended period of
time,
Programming the OFF timer will also cancel the
automatic OFF feature.
Program Timer
The (Dual Program) Timer feature is capable of turning
the TV ON to a desired channel and then turning the
television OFF at a predetermined time.
NOTE: The clock and day must be set for this feature
to operate. (Refer to Set Up Menu to Set Time
and Day.)
Helpful Hints:
+ The Program Timer overrides the Sleep Timer.
« Program Timer can only access channels in
Program Channel Memory.
« “Set Time First” will appear on screen when
trying to set Timer Day Option without the clock
being set.
* If the Program Timer “ON” functions while the
set is operating the set will automatically tune to
the channel designated in the Program Timer.
1. Press (==).
2. Press А or Y and €. or > to highlight the
Timer Icon.
; Loy J
3. Press (==) to display the Timer Control menu.
TIMER 2
4. Press A or \V/ to highlight TIMER 1 or TIMER 2
setting.
* Day or days to activate the Timer.
* ON (time) - hours and minutes
* OFF (time) - hours and minutes |
» CH - the channel the TV is tuned to when the ON
Timer activates.
« SET - NO (Timer feature will not activate)
- YES {Timer feature will activate)
- 26 -
Timer Features (cont’d.)
Program Timer (cont'd.)
5.
6.
10.
11.
12.
13.
16.
17.
Highlight the Timer 1 Day/Days option.
Press € or > to set the day or days for the TV
to tum ON.
The options for setting day are: (MON-FRI), (SAT-
SUN), (DAILY), (SUN), (MON), (TUE), (WED),
(THR), (FRI, (SAT), (EVR SUN), (EVR MON),
(EVR TUE), (EVR WED), (EVR THR), (EVR FRI),
(EVR SAT).
Press y to hightight the ON (Hours/Minutes).
Press a or > to set the time for the TV to
turn ON.
Press W to highlight the OFF (Hours/Minutes).
Press € or > 10 to set the time for the TV to turn
OFF.
Press to highlight CH.
Press a or EP to select a channel {from
Program Channel Memory). for: :the TV to be tuned
to when it turns ON.
Press № 10 hightight SET.
‚ 112
TIMER 1 - TIMER 2
DE COMEN.
NN Bean oogap
OFF ooo
% 6 > pd
NO)
. Press № to activate or a to deactivate Timer 1.
YES=Feature is activated
NO=Feature is not activated
. Press y to set Timer 2 {if desired). Follow Steps
6 through 14.
Press twice to exit menus.
Pressing agaín will return you to the
Timer icon.
Input Select
1. Press
2. Press A or NV and a or № to highlight the
- Input Select Icon.
3. Press to display the Input Select menu.
ET Y ХНА С НЯ:
Press al or > to select TV, Video 1 or Video 2.
Press twice to exit menus.
Favorite Channel
Channel Scan
This feature is used to select which Channels will be
accessed when using Æ\ or \&/, ALL or FAV
(Favorite) Channels.
a >
NOTE: Channels must be programmed into Favorite
Channel Select Memory first.
1. Press (==).
2. Press A or Y and < or > to y highlight the
Favorite Channel Icon.
3. Press E to display the Favorite Channel menu.
”
FAVORITE | A
A 1 El
FAVECHESELECT NO
4. Press (A or Y to highlight CHAN SCAN.
5. Press a or № to select ALL or FAV (Favorite).
« ALL - The A or Y will access all channels in
Channel Memory.
* FAV -The A or Y will only access channels in
Favorite Channel Select Memory.
6. Press twice to exit menus, .
- 27 -
Ш
Oo
O
=
>
[=
-
<
=
e,
=
m
Favorite Channel (cont’d.)
Favorite Channel Select
The favorite Channel Programming aliows you to
program up to 15 of your favorite channels. You can
use the CH buttons on the Remote Control to scan
channels without going through channels you do not
normally view.
1. Press Co
2. Press A or \&/ and El or № to highlight the
Favorite Channel icon.
3. Press =) to display the Favorite Channel
menu.
4. Press A or ¥/ to highlight CHAN SCAN. Then,
press al or № to select FAV option for Favorite
Channels setting.
5. Press (A or \ to highlight “FAV CH SELECT".
6. Press E or № to display the Favorite Channel
Select.
НИЯ с 7
E
MEL ST
7, Enter the channel number you wish to add or
delete from Favorite Channel Memory (using the
Remote Keypad or A or 07 ).
8. Press > to add or press € to delete channel
from Favorite Channel Memory.
9. Repeat steps 7 and 8 to add or delete channels
(up to 15 channels may be stored in Favorite
Channel Memory).
10. When you are done with adding and deleting
channel, press twice to return to normal
viewing. :
11. Press A or y to scan through the Favorite
Channels you programmed.
Channel Caption
Preset Caption
This feature allows you to select from 56 preset
captions, and assign corresponding channel numbers
utilized in you area. Captions are easily assigned to the
channel numbers you select by following the steps
outlined below.
1. Press
2. Press A or y and a or > to highlight the
Channel Caption icon.
3. Press to display the Channel Caption menu.
PRESET CAPTION NO
mm Te
4. Press (A or © to highlight PRESET CAPTION.
5. Press € or № to display the Preset Caption
menu.
PRESET(CARTION
6. Use the Remote Control keypad, to assign the
channel number to the Channel Caption in your
area (Refer to your local TV guide).
NOTE: To delete press Ea while channel number is
highlighted.
PRESETICARTION
INPUT CHANNEL NUMBER
ABC Ш E. и
7. Press y to select a different Preset Caption,
then repeat step 6 until all desired Preset Captions
have assigned channel numbers.
8. Press three times to exit menus.
- 28 -
Channel Caption (cont’d. )
Manual Caption
The Channel Caption {Station Identifier) allows y you to
input the call names of up to 30 stations into memory
(using up to 4 characters). The call name will then
display, along with the channel number when changing
channels or pressing (RECALL _
ENTER CAPTION 3
AYTO MOVEISELECTO RI
> WEE CNEL
- KXYZ CH 3
LL | A Ш
В | | | a)
Channel | 8. Press al or № to select first character in ©
(Station channel caption (STATION IDENTIFIER). >
| -
Identif
entifier) NOTE: To delete characters, press € or }® until an
1. Press empty space is displayed and the character
position.
2. Press A or v and < or > to highlight the 9. Press Y to move to second character position,
Channe! Caption Icon. and repeat steps 8 and 9 until the complete caption
is entered (up to 4 characters).
3. Press to display the Channel Caption menu.
10. Press A or VW repeatediy to highlight ENTER
CHANNEL CHA .. : CHANNEL NUMBER. Then repeat steps 6 through
ESPN CA 10 to continue adding Channel Captions
re | (STATION IDENTIFIERS).
11. Press three times to exit menus.
4. Press Y to highlight MANUAL CAPTION.
5. Press < or > to display the Manual Caption
menu.
AY VANE
ITWwEES CANTE
6. Use the Remote Control Keypad or El or №
to enter channel number you wish to assign a
channel caption (STATION IDENTIFIER).
7. Press \& to highlight ENTER CAPTION.
- 29.
=
<
=
O
>)
m
Lockout Features
Lockout Mode
This feature allows locking out the following from
viewing:
* Game - Lockout Channel 3& 4, VGA & Video Inputs.
* Channel - Lockout up to 4 Channels.
All - Lockout Ali Channels plus Video Inputs.
NOTE: This feature will Lockout your selection for up to
48 hours. Be sure to understand this feature
before using. Use a code that you will easily
| remember.
1. Press E9..
2. Press A or y and < or >» to highlight the
Lock Icon.
3. Press (E) to display the Lock menu.
NOTE: When the Lockout Menu. is displayed, the
Game Lock option will be highlighted..
À or D 0500 (où
4. Press or €” to select GAME, CH (CHANNEL)
or ALL.
Game Lockout Menu
LOCK LOCKS
ат
Channels Lockout Menu
LOCK LOCKS
„= (В
LOCK MODE
All Lockout Menu
NOTE: When the LOCK MODE CHANNEL is selected,
perform procedure Steps A through D.
LOCK 'LOCHE
re В
Step A
Press \¢/ to highlight “LOCK THESE CHANNELS”.
Step B
Then use the Remote Control Keypad or a or > to
select a channel you desire to lockout.
Step C
Press №7 to select next channel position.
Step D
Then repeat Step B & C until, desired Channels are
locked out (up to 4 channels).
5. Press © to highlight “HOW LONG?”.
6. Press a or №» to select 12, 24 or 48 (hours
lockout time).
7. Press 7 to highlight “ENTER CODE” then enter a
3 digit code by using the Remote Control Keypad.
IMPORTANT NOTE: Use a code you can easily
remember.
8. Press ) to activated “CHANNELS LOCKED” wil
display on screen.
CHANNELS LOCKED
Lock Feature Activated
- 30 -
Lockout Features (cont d. )
Unlock
Follow Steps 1 through 3 from previous section and
enter same 3 digit code as in Step 7. Channel
Unlocked display will appear. |
ENE CEE TV UNER
DD =
ENTER SAME 3 DIGIT CODE
CHANNELS UNLOCKED
IF 3 DIGIT CODE IS THE SAME
INCORRECT UNLOCK
CODE ENTERED
IF 3 DIGIT CODE IS NOT THE SAME
CONTROL PANEL LOCK FEATURE
Procedure
| , ACTION
With the Monitor turned ON, press the © and
VOLUME RIGHT ( p>) buttons on .the control panel
simultaneously, then quickly press the Lo) and
CHANNEL UP (A) buttons on the control panel
simultaneously. This will activate ‘the Control Panel
Lock feature, to deactivate repeat procedure.
Helpful Hints:
1* There will be no On Screen display. -
* To confirm if the Control Panel Lock feature is
activated, press. any button other that the
POWER rbutton (the Power button is never
disabled).
e Buttons should be pressed ‘quickly. and
released. Do not hold down.
E
LL
(m)
O
=
=>
ul
Programming the Home Theater Remote
The remote control can be set to control other manufacturers components, by utilizing the MODE SELECTION
BUTTONS for CABLE, DSS, VCR, RCVR (a Receiver or Amplifier), CD, LD, and AUX (for Cassette Players,
Second VCR or a DVD). | |
Use the following procedure for setting up the Use the following procedure for setting up the
remote control using the numerical buttons when remote control when the components remote
2 the component's remote code is known. access code is not known. This procedure uses the
“ ethod”.
= : Determine the brand of the component. sequence m © , ,
= Confirm that the components is plugged in
m [2] Identify the code(s) associated with the and operating properly, then turn it OFF.
brand from the infrared code index {see [6]
following pages). Record all possible oe AA Press and hold the button, then
codes. | о
the ROWER) button so that both are
[3] Confirm that the component is plugged in 1 > 9 pressed at the same time for
and operating properly, then turn it OFF. atleast5seconds. Then let go of the
[4] press and hold the button, then buttons.
the rowr, button so that both are Press the appropriate Mode button for
pressed at the same time for the device.
aticast5 sSéctonds. Then let go of the
buttons.
[5] Press the appropriate MODE button
for the component.
[6] Enter the 3-digit-code, by using the
Remote Control Keypad “0” through
“9” buttons.
Press the > button to step over to the
next code. — +
Press the «owe» button to test the
remote. If the correct code is sent, the
component will turn on.
G Once the correct code is found, press
TNQ2AE012 the button to store the code.
Repeat from step above until the
proper components code is found. It may
take several attempts before the correct
[7] Press the Æwë button to test the remote. code is found.
If the correct code is setup for the
component (in step (© ), the component
Now the remote is set for the entered
code. |
will turn on.
Note: Some brands have multiple codes. Repeat Note: If an incorrect code is entered, or when
the procedure using another listed code the operation is not completed within 30
until the component responds correctly. seconds, the settings will not change.
Infrared Remote Codes for Specific Components
Helpful Hint: Write down the code numbers for your components in the space provided below. This
will serve as a handy reference whenever you need to reprogram your remote control.
CABLE VCR CD
Cable TV Converter Box PIT] Video Cassette Recorder LIL Compact Disc Player (11
DSS CT RER [|A || Lo [TT]
Digital Satellite System Receiver or Amplifier Laser Disc Player
EE (| |] HER
Other Component Other Component Other Component
LTL LLL] HER
Other Component Other Component Other Component
- 32 -
‘VCR Infrared Codes Index
The Universal Infrared Remote Control is capable of operating many brands of VCRs. Refer to the Programming
the Remote Control section for procedures.
NOTE: The Universal Remote Control memory is limited; therefore, some models of VCRs may not operate. The
Universal Remote Control not designed to control all features that are available in all models.
NOTE: After entering the proper infrared code, press the Remote VCR(*) Selection Mode button. A second VCR
can be activated using the same codes, from AUX (**) Selection Mode button. Refer to the Remote
Control Key Functions section for Remote VCR and VCR 2 function key listing.
| Code Index for VCRs
VCR Brand Code(s) VCR Brand Code(s) a
O
Adventura 000 MTC 000,240 =
Aiko 278 Multitech 000,072 >
Aiwa 000 NEC 038,041,067 Lu
Akai 041,061 Nikko 037
VCR American High 035 Noblex 240
Asha 240 Olympus 035
x Audiovox 037 Optimus 037,048,104
Beaumark 240 Panasonic 035,162,225,454
Bell & Howell 104 Penney. 035,037,038,042
Broksonic 121,184 7 240
Calix 037 Pentax 042
Canon 035 Philco 035
Carver 081 Philips 035, 081
CCE 072,278 Pilot 037
Citizen’ 037,278 Pioneer 067
‚ Сой 072 Protec 072
Craig 037,047,072,240 Pulsar 039
Curtis Mathes 035,041,060 Quarter 046
Cybernex 240 Quartz 046
Second VCR Daewoo 045,278 Quasar 035
a | Dynatech * 000 Radio Shack 000,037
Electrohome 037 Radix 037
* * Electrophonic 037 Randex 037
Emerex 032 RCA 042,060
Emerson 000,002,037,043, Realistic 000,035,037,046
061,121,184,278 047,048,104,240
Fisher 047,104 Ricoh 034
Fuji 033,035 Runco 039
Funai 000 Samsung 045,240
Garrard 000 Sanky 039,048
GE 035,060 Sansui 041,067
Goldstar 037,038 Sanyo 046,047,104,240
Gradiente 000 Scott 043,045,121,184
Hartey-Davidson 000 Sears 035,037,042,046,
Harman-Kardon 038 047,104
Harwood 072 Sharp 048
Headquarter 046 Shintom 072
HI-Q 047 Shogun 240
Hitachi 041,042 Singer 072
Jensen 041 Sony 032,033,034,035
JVC 041,067 STS 042
Kenwood 038,041,067 Sylvania 000,035,043,081
7 KLH 072 Symphonic 000
Kodak 035,037 Tatung 041
Lloyd 000 Teac 000,041
Logik 072 Technics 035,162
LXI 037 Teknika 000,035,037
Magnavox 035,039,081 TMK 240
Magnin 240 y Toshiba 043,045
Marantz 035,081 Totevision 037,240
Marta 037 Unitech 240
Matsushita 035 Vector 045
MEI ” 035 Vector Reseach 038
Memorex 000,035,037,039 Video Concepts 045,061
046,047,048,104 Videosonic 240
240 Wards 000,035,042,047
MGA 043,061 048,072,240
MGN 240 XR-1000 000,035,072
Minolta 042 Yamaha 038
Mitsubishi 043,061,067 Zenith 033,034,039
Motorola 035,048
- 33 -
Cable Converter Box and CD Players
Infrared Codes Index
The Universal Infrared Remote Control is capable of operating many brands of Cable Converter Boxes and CD
Players. Refer to the Programming the Remote Control section for procedures. `
NOTE: The Universal Remote Control memory is limited; therefore, some models of Cable Converter Boxes and
CD Players may not operate. The Universal Remote Control is not designed to control all features that are
available in all models.
NOTE: After entering the proper infrared code, press the Remote CBL Selection Mode button (yy). Refer to the
Remote Control Key Functions section for Remote CBL function key listing.
Codes for Cable Converter Box
= -
<<
= Brand of Brand of
- Cable-TVBox Code(s) Cable-TV Box Code(s)
m
Ca ble ABC 003,007,008,011 Pionner 144,533
` 013,014,017 Pulsar 000
: Archer . . 153 RCA 021
pe Century 153 Regal 020,259
Citizen 153 Rembrandt 011
Contec . . 019 Runco . 000
Dae Ryung. 008 ~ Samsung 144
Gerrard 153 Scientific Atlanta 008,017,477
General Instrument 011 ‚476 Signature 011
Goldstar 144 Sprucer 021
> Hamlin 009,020,259 Starcom,: + - 003,015
Hitachi 011 Stargate ..- _ 015
Hytex 007 Starquest * “015
Jasco 153 Tocom 012,013
Jerrold 003,011 012,014 Toshiba 000
015,476 Tusa 015
Memorex 090 Умка a 153
Oak 007,019 United Artist 007
Panasonic 000,021,107 United Cable _ 003
Paragon 000 Universal - 153
- Philips 153 Zenith . 000,525
NOTE: After entering the proper infrared code, press the Remote CD Selection Mode button (77 77). Refer to the
Remote Control Key Functions section, for Remote CD Players function key listing.
Codes for CD Players
Brand of Brand of
CD Players Code(s) CD Players Code(s)
Aiwa 124 Onkyo 101 aE
CD Player CA Audio Lab 29 Optimus 000,032,037,
Carver 7 157 305,426,468
pg Y Denon 003 Panasonic 029,367
DKK 000 Philips 157
Emerson 305 Pioneer 032,468
Fisher 048 Proton 157
Genexxa 032.305 QED 157
C ГВ Harman-Kardon 426 | Quasar 029
Hitachi 032 RCA 305
JVC 072 Rotel 157
Kenwood 028,037,048,190 SAE 157
Krell 157 Sansui 157,305
LXI 305 Scott 305
Magnavox 157 Sears 305
Marantz 029,157 Sharp 037
MCS 029 Sherwood 426
Mission 157 Sony 000
Nakamichi 147 Technics 029,303
N NSM 157 Victor 072
- 34 -
Cassette Players, Receivers, and Amplifiers
Infrared Codes Index
The Universal Infrared Remote Control is capable of operating many brands of Cassette Players, Receivers, or
Amplifiers. Refer to the programming the Remote Control section for procedures.
NOTE: The Universal Remote Control memory is limited; therefore, some models of Cassette Players, Receivers,
and Amplifiers may not operate. The Universal Remote Control is not designed to control all features that
are available in ali models. `
NOTE: After entering the proper infrared code, press the Remote AUX Selection Mode button { %). Refer to the
Remote Control Key Functions section for Remote Cassette Players function key listing.
Code Index for Cassette Players w
a
Brand of Brand of ©
Cassette Cassette Players Code(s) Cassette Players Code(s) я
Players >
Aiwa 029 Panasonic 272 sy ="
x Carver 029 Philips 029 a
Denon 076 Pionner 027,220
Kenwood 070 Snsui 029
Magnavox 029 Sherwood - 337,338
Marantz 029 Sony °C 170,243
Nakamichi 147 Technics 229
Optimus 027,220,337,338 Wards 027
Yamaha 094,097
NOTE: After entering the proper infrared code, press the Remote RCVR Selection Mode button (% x). Refer to
the Remote Control Key functions section for Remote Receivers/Amplifiers function key listing.
f
Code Index for Receivers and Amplifiers
Brand of Brand of
Receiver/ Receiver/
Amplifier Code(s) Amplifier Code(s)
ADC 531 Panasonic 039
Aiwa 121,158,189 Penney 195
1 Carvar 008,042,189,269 Philips 189,269
Receivers Casio 195 Pioneer 013,014,080,300,
Amplifiers Clarinette 195 531
- Denon 004 Quasar 039
Fisher 042,219 RCA 531
JVC 074 Realistic . 195
Kenwood 027,186 Sansui 189,321
Lloyd's 195 Sanyo 219
Magnavox 189,195,269,531 Sharp 186
Marantz 039,189,269,321 Sherwood 502
MCS 039 Sony 158
Modulaire 195 Technics 039,208,308,309,
NAD 320 518
Nakamichi 321,347 Victor 074
Onkyo 135 Wards 013,014,042,080,
Optimus 013,080,186,219, Yamaha 158,189
300,531 Yorx 176,186,354
195
- 35 -
Laser Disc, DSS (Digital Satellite System),
and DVD (Digital Videodisc)
Infrared Codes Index
The Universal Infrared Remote Control is capable of operating selected brands of Laser Disc, DSS Digital Satellite
System, and DVD (Digital Videodisc). Refer to the Programming the Remote Control section for procedures.
NOTE: The Universal Remote Control memory is limited; therefore, some models of Laser Disc, DSS Digital
Satellite System, and DVD (Digital Videodisc) may not operate. The Universal Remote Control is not
designed to control all features that are available in all models.
NOTE: After entering the proper infrared code, press the Remote LD Selection Mode button (©). Refer to the
я Remote Control Key Functions section for Remote Laser Disc function key listing.
3 Codes for Laser Disc
=. Laser Di
Ш Player Brand of
© ,[ | Laser Disc Code(s)
- Mitsubishi 059
NAD 059
Panasonic 204
Pionner ; 059
Quasar 204
= Sony 201
NOTE: After entering the proper infrared code, press the Remote DSS Selection Mode button (CC). Refer to the
Remote Contro! Key Functions section for Remote DSS function key listing.
DSS Codes for DSS (Digital Satellite System)
OO Brand of
Sattelite Code(s)
Panasonic 701
©» ВСА 566
Зопу 639
NOTE: After entering the proper infrared code, press the Remote AUX Selection Mode button ( X ). Refer to the
Remote Control Key Functions section for Remote DVD function key listing.
Digital
Videodisc
*
pk
Codes for DVD (digital Videodisc)
Brand of
DVD Code(s)
Panasonic 490
PC Input Connection (Rear) . .:
Operation
1. Select PC (Rear) mode from the TV/PC/DTV menu (located in the TV/PC/DTV Icon).
NOTE: To select PC (front) press the INPUT button, while PC (rear) is highlighted in the TV/PC/DTV menu.
2. Connect the 15-pin connector cable (the supplied cable meets FCC standards) from the computer 15-pin
output terminal to the monitor PC INPUT 15-pin terminal, as shown.
3. Connect an audio/video to Mini-jack cable from the computer Audio output sound source jack to the monitor
PC INPUT AUDIO L & R jacks, as shown.
NOTE: To operate your Monitor and computer properly, refer to the instructions furnished with the computer.
To 15-pin Input
terminal of computer
TT —
TERMINALS ON BACK OF MONITOR
e
O ©) VIDEO
© @
poses to Mini-jack Cable
(not supplied)
TERMINALS ON BACK OF COMPUTERY
y
From Audio output
source of computer
15-pin Connector Cable (TSXX4515-3)
(Use of the supplied cable is recommended)
From 15-pin output
terminal of computer
Li
©
e,
=
o
а.
Helpful Hints:
resolution.
If the monitor image is scrambled after connecting to a computer,
refer to the troubleshooting section for changing the computer
scrambled image
- 37 -
ED |
ны
O
=
e
=
m
> VIOC e
PC Input Connections (Front)
Operation
1. Select PC (Front) from the TV/PC/DTV menu (located in the TV/PC/DTV Icon).
NOTE: To select PC (Rear) press the INPUT button, while PG (Front) is highlighted in the TV/PC/DTV menu.
2. Connect a 15-pin Connector cable (the supplied cable meets FCC standards) from the computer 15-pin
output terminal to the monitor PC INPUT 15-pin terminal, as shown.
3. Connect an Mini-jack cable from the computer Audio output sound source jack to the monitor AUDIO INPUT
jack, as shown.
NOTE: To operate your . Monitor and computer properly, refer to the instructions furnished with
the computer.
TERMINALS ON FRONT OF MONITOR
(LOCATED BEHIND FRONT CONTROL DOOR)
AUDIO __ PC INPUT
соо
To front Audio
Input of monitor
To 15-pin input
terminal of computer
OU
Mini-jack Cable
| 15-pin Connector Cable (TS XX4515-3)
(not supplied)
(Use the supplied cable is recommended)
[1
a
a From 15-pin output
From Audio Output terminal of computer
source of computer A A
_—
С
LL
E
E —
и
[PN
ri
PE
TERMINALS ON BACK OF COMPUTER
1]
Helpful Hints:
An Input signal must be connected to the input
terminals of the monitor, in order to access PC and
DTV mode Icon menus.
Helpful Hints:
If the monitor image is scrambled after connecting to a computer, scrambled image
refer to the troubleshooting section for changing the computer
resolution.
- 38 -
los НЫ
This feature 15 used to select the PC mode for monitor
display.
NOTE: Connect a computer having a 15-pin output
terminal. If necessary, you can adjust the
picture size and position using the Display
Adjust menu.
1. Press: (em) .
2. Press /A or Y and El or P to highlight the
TV/PC/DTV Icon.
3. Press to display the TV/PC/DTV MODE 4
menu. 5,
6.
T
PICTURE NORM NO
COYOR сосоо {| ососо
UL ocoocool 000066
PREES eN) Y GER ONCE
Press /A) or 7 to highlight PICTURE NORM.
Press a or > to select "SET” to normalize
Color, Tint, Brightness, Picture, and Sharpness for
the PC mode.
Press the ES) twice to exit menus.
Color, Tint, Brightness, Picture, and
Sharpness
Helpful Hints;
4. Press El or > to highlight'PC (FRONT).
5. Press (fera) twice to exit menus.
Helpful Hints:
When there is no signal applied, the Icon menus in
the PC and DTV mode will appear small and
COLOR - Adjust for desired color intensity.
TINT - Adjust for natural flesh tones.
BRIGHTNESS - Adjust so dark areas of picture
slightly became black for a crisp detail.
PICTURE - Adjust the white areas of the picture as
desired.
SHARPNESS - Adjust for best clarity of outline
detail.
distorted.
Trilingual Animated Icons
PC Mode Icons 3.
[PICTURE]
Ei A
[ak =
20)
NOTE: Oniy the selected icon (red) will be animated.
Picture Adjustments 4
Picture Norm
Use to reset Color, Tint, Brightness, Picture, and
Sharpness to the factory preset level for PC Mode only. 5.
1. Press
2. Press A or Y and a or > to highlight the 6.
Picture Icon.
3. Press to display the VIDEO Adjustment menu.
- 39 -
This is a normal condition. 1.
Press ==
Press A or №7 and a or № to highlight the
Picture Icon.
Press the (Ga) to display the VIDEO Adjustment
menu.
IECTURE VIDEO
ecco fl acean
260500 002000
RRESSICHINVIRORIMORE
Press /A or W/ to select the desired Video
Adjustment (Color, Tint, Brightness, Picture or
Sharpness).
Press J or >» to adjust your selection. (The
selected Video Adjustment will be displayed).
Repeat steps 4 and 5 for remaining Video
Adjustments. :
Press twice to exit menus.
Ш
Q
O
=
©
.
vU
o
=
O
o
m
Picture Adjustments (cont’d.)
Color Temp
To select one of three
temperature.
Helpful Hints:
NORMAL - No tint
WARM - Reddish tint
COOL - Bluish tint
(3) options for picture
1. Press
2. Press A or К and or > to highlight the
Picture Icon.
3. Press to display the Video Adjustment
menu.
WS VIDEO
an Ta
! co “fa
E Po . - Aa '
CO INORMAIS
MES AT
e Зуя
4. Press A or W to highlight COLOR TEMP.
5. Press @ or ¥ to select NORMAL, WARM, or
COOL.
NOTE: The selected Mode will also change Color
Temp inTV Mode and DTV Mode.
6. Press twice to exit menus.
Audio Adjustment
Helpful Hints:
Set PC Mode Audio Adjustments will also change
TV Mode and DTV Mode Audio Adjustments.
Audio Norm
This feature is used to reset Bass, Treble, and Balance
back to a factory preset level.
1. Press |
2. Press A or y and a or № to highlight the
Audio icon.
3. Press to display the Audio Adjustment
menu.
a
AUCIORR AUDIO
Bre |
©
FI — eE
sooacfloococo
cocoelecese
cocoo[|occos
URES
BAWANGE
В @&
4. Press A or Y to highlight AUDIO NORM.
5. Press a or > to select “SET” to normalize
Bass, Treble, and Balance.
6. Press twice to exit menus.
Bass, Treble, and Balance
Use with front or rear PC audio input jacks when
connected to a PC sound source audio output.
Helpful Hints:
BASS - To increase or decrease the Bass
response >
TREBLE - To increase or decrease the Treble
response
BALANCE - To emphasize the Right and Left
speakers’ volume
1. Press (=)
2. Press A or \& and < or > to highlight the
Audio Icon.
3. Press E) to display the Audio Adjustment menu.
0600000000
eee
RES “eno Placer
4, Press A or №7 to highlight BASS, TREBLE, or
BALANCE.
5. Press a or > to adjust for desired audio
response. (The select Audio Adjustment will be
displayed.)
6. Repeat steps 4 and 5 for remaining audio functions.
7. Press twice to exit menus.
- 40 -
Audio Adjustments (cont’d.)
Speaker
This feature is used to turn the internal speakers “ON”
or “OFF”. It is used when the monitor is connected to
an external audio amplifier. (Refer “To Audio Amp”
. Surround |
-Use the Surround Feature to enhance audio response
when listening to Stereo sound.
Connection section for further information).
1.
2.
Press
Press @ or Y and № or a to select the
1.
2.
Press
Press А, or Y: and < or D to highlight the
Audio icon.
Audio icon.
3, Press to display the Audio Adjustment menu.
COTO)
de
Jar
dd mid
AUDIO
4. Press AA or Y to hightight SPEAKER.
5. Press < or > to select ON, OFFEVAO or
--OFFAFAO.
+ ON- TV speakers operate normally.
» OFF&VAO (Variable Audio Output) — TV speakers
off, the sound output varies according to the TV
volume, use the TV remote to control the volume,
muting, bass, treble and balance of the External
Stereo System.
« OFF&FAO (Fixed Audio Output) — TV speakers off,
sound output is fixed.
6. Press twice to exit menus.
3. Press (&=) to display the Audio Adjustment menu.
AUDIO AUDIO
B®
EL] 1
ОМ
SURROUND
SO UND,
A FEB ED v сев (0988 —
wr
4. Press A or № to highlight SURROUND.
5. Press € or № to select SURROUND ON or
OFF.
6. Press (>) twice to exit menus.
Al Sound
This feature is used to maintain constant sound level
when switching between- programs signals with
different sound levels.
ue
=
e,
=
=
a
1. Press
2. Press (A or y and « or № to highlight the
Audio Icon.
3. Press to display the Audio Adjustment menu.
4. Press AN or Y to highlight Al SOUND.
5. Press a or > to select Al SOUND ON or OFF.
6. Press twice to exit menus.
- 41 -
=
O
=
=
U
m
Set Up Features
‘Helpful Hints: ~~
Setting PC Mode Set Up Features will also change
TV Mode and DTV Mode Set Up Features. -
Auto Power On - This feature automatically
turns the monitor ON when AC power is applied.
1. Press .
2. Press A or \&/ and al or № to select the Set
Up Icon.
3. Press Ce sE to > display the Set Up menu.
AUTO POWER ON
GEOMAGNEMTICRCORR NO
NOTE: Setting the Auto Power On feature will cancel
the time and timer control setting. Also, the TV Mode
Main Menu Icon for the Control will be replaced with an
Exit icon.
. +
4. Press A or y to highlight AUTO POWER ON.
5. Press < .or > to select SET.
6. Press twice to exit menus.
Geomagnetic Corr (Correction)
This monitor incorporates a special adjustment feature
for the convenience of the customer. This adjustment is
preset at the factory. However, adjustment may be
required when the monitor is moved (due to the
influence of earth’s magnetic field) which may cause
the picture to tilt slightly. If necessary, follow these
procedures to adjust the tilt.
1. Press E E
2. Press A or Y and < or > to highlight the
Set Up Icon.
3. Press = to display the Set Up Menu.
4. Press A or W/ to highlight GEOMAGNETIC
CORR. $
5. Press <a or > to display the Geomagnetic
Correction adjustment menu.
F
tilt adjustment bar
6. Press € or №» to adjust the picture tilt until left
and right side of tilt adjustment bar is parallel to the
bottom of picture frame (if necessary).
NOTE: Discoloration may be visible in picture
corners if tilt bar is not parallel to the
bottom of picture frame.
7. Press twice to exit menus.
Input Select
This feature is used to select PC Input Front or PC
Input Rear for the monitor Input signals.
1. Press (ES)
2. Press A or Y and al or № 10 highlight the
Input Select Icon.
3. Press E | to display the Input Select Menu.
(FRONT)
(REAR)
4. Press a or № to select FRONT or REAR.
NOTE: PC Front or PC Rear can also be selected by
pressing the Input button while input Select
menu is displayed.
5. Press twice to exit menus.
„42 -
Display Adj
This feature is used to adjust the image on the monitor.
1.
2.
Press 2 |
Press JAN or 7 and a or > to highlight the
Display Adj Icon.
Press to display the Display Adj menu.
DISPIAYADISPIAY¿ADJ:
Op
CHEN с e с о ео с о об
ANSTZEI 50066000000
оосооейс ооо
SIZE
особое [рос
PRESSED 9 FORMFRE
¿»|
Y. PCC ccooofjcocoeo
HARE ZU IDE 0006500002000
PARALËLEIL esovajecvoo
ERESSICHIR*MEOR{MORE
Press AN or © to highlight H. POSITION, H.
SIZE, V. POSITION, V. SIZE, V. PCC,
TRAPEZOID, or PARALLEL (PARALLELOGRAM).
DISPL'AY/ADJ:
Press € or >» to adjust your selection. (The
selected Display Adj will be displayed).
Repeat steps 4 and § for the remaining Display
Adjustments.
Press twice to exit menus.
- 43 -
Display Adjust Chart
Press
Selection al No
H. POSITION moves the picture to left moves the picture to right
O || O |) O
H.POSMON | -p-*--
| IP
H. SIZE decreases the horizontal size increases the horizontal size
H. SIZE pt
V. POSITION moves the picture upward moves the picture downward
O tu O —
v.POSMON «ре
V. SIZE decreases the vertical size increases the vertical size | e
Y, SIZE “+ Al er
V. PCC decreases the distortion increases the distortion
y. PCC pt.
TRAPEZOID to make bottom edge narrower to make top edge narrower
TRAPEZOID -f 2 --
PARALLEL to collapse to the right to collapse to the left
PARALLEL -+ A.
PC MODE
DTV Mode
Component Video Connection
Helpful Hints:
An input signal must be connected to the input
terminals of the monitor, in order to access PC
and DTV mode Icon menus.
Operation
1. Select DTV mode from the TV/PC/DTV menu (located in the TV/PC/DTV Icon).
2. Connect audio/video cables from the Component Video output terminais to the monitor DIGITAL TV INPUT
terminals, as shown.
NOTE: To operate your Monitor with component video devices properly, refer to the instructions furnished with the
component video device.
Helpful Hints:
When there is no signal applied, the Icon menus in
the PC and DTV mode will appear small and
distorted.
This is a normal condition.
TERMINALS ON BACK OF DEVICE
AUDIO QUT
se 9 OL,
= Y
7 Le] O. | © Oveo
A; ie ae © se ST
AUDIO
года
TERMINALS ON BACK OF MONITOR
COMPONENT “59 OUT
©
IL PO
IT PO
| ==
=,
№
<
<=
©
©
m
From audio/video
output of device
AUDIO [AUDIO e A,
[Pc INPUT
To audio/video
input of monitor
audio/video Cable
{not supplied)
- 44 -
TV/PC/DTV
This feature is used to select the DTV mode for monitor
display.
1. Press .
2. Press JA or \&7/ and e or > to highlight the
TV/PC/DTV Icon.
3. Press to display the TV/PC/DTV MODE
menu.
ju ve DTV |
4. Press © or > to highlight DTV,
5. Press twice to exit menus.
Trilingual Animated Icons
DTV Mode Icons
HE He
a
NOTE: Only the selected icon (red) will be animated.
Picture Adjustments
Picture Norm
Use to reset Color, Tint, Brightness, Picture, and
Sharpness to the factory preset level (DTV Mode).
1. Press
2. Press A or № and < or > to highlight the
Picture Icon.
3. Press to display the VIDEO Adjustment
menu.
4. Press (A or ¥/ to highlight PICTURE NORM.
5. Press a or > to select “SET” to normalize
Color, Tint, Brightness, Picture, and Sharpness -
(DTV mode).
6. Press the twice to exit menus.
Color, Tint, Brightness, Picture, and
Sharpness
Helpful Hints:
COLOR - Adjust for desired color intensity.
TINT - Adjust for natural flesh tones.
BRIGHTNESS - Adjust so dark areas of picture
slightly became black for a crisp detail.
PICTURE - Adjust the white areas of the picture
as desired.
SHARPNESS - Adjust for best clarity of outline
detail. |
mea =
289
1. Press .
2. Press A or y and € or № to highlight the
Picture Icon.
3. Press the to display the VIDEO Adjustment
menu.
RICTURE VIDEO
poJliols! |
Ш
о
о
=
„>
--
Oo
4. Press (A ог E to select the desired Video
Adjustment (Color, Tint, Brightness, Picture or
Sharpness).
Press € or № to adjust your selection. (The
selected Video Adjustment will be displayed).
Repeat steps 4 and 5 for remaining Video
Adjustment.
hd
7. Press twice to exit menus.
- 45 -
Picture Adjustment (cont’d.)
Color Temp
Use to select one of three (3) options for picture
temperature.
Helpful Hints:
NORMAL - No tint as
WARM - Reddish tint
COOL - Bluish tint
MoN
1. Press | | Cn Cee
SEO © RE A
2. Press [oN or 7 and € or № to highlight the
Picture Icon.
3. Press to display the Video Adjustment menu. 4: Press AN or Y to highlight AUDIO NORM.
5. Press € or > to select “SET” to normalize
VIDEO _ Bass, Treble, and Balance.
6. Press twice to exit menus.
Bass, Treble, and Balance
A ZE a 1 TU Helpful Hints:
"OA os
ma e NADO _ .
я er] response To increase or decrease, the Bass
NIT ое GE ket Зе . .
| - TREBLE - To increase or decrease the Treble
response
a. Press @ or © to highlight COLOR TEMP. BALANCE - To emphasize the Right and Left
speakers' volume
5. Press a or > to select Normal, Warm or Cool
mode.
1. Press .
6. Press (=m) twice to exit menus.
| 2. Press A or Y and Él or № to highlight the
Audio Adjustment Audio Icon.
Helpful Hints: | 3. Press to display the Audio Adjustment Menu.
AUDIO AUDIO
IT
я
Е
U
=
<
=
O
©
m
Setting DTV mode Audio Adjustments will also’
change TV Mode and PC mode Audio Adjustment.
a
Audio Norm
This feature is used to reset Bass, Treble, and Balance
back to a factory preset level. es MR |
1. Press . i = 3
tri LI Hin oars
2. Press £\ or Y and € or > to highlight the
Audio Icon.
3. Press (=) to display the Audio Adjustment menu. 4. Press A or 7 to highlight BASS, TREBLE, or
BALANCE.
5. Press a or >» to adjust for desired audio
response. (The selected Audio Adjustment will be
displayed.)
6. Repeat steps 4 and 5 for remaining audio
functions.
7. Press twice to exit menu.
- 46 -
Audio Adjustments (cont’d.)
Speaker
This feature is used to turn the internal speakers “ON”
or “OFF”. It is used when the monitor is connected to
an External Audio Amplifier. (Refer to “To Audio Amp”
Connection section for further information).
1. Press
2. Press A or NA and al or >» to select the
Audio Icon.
3. Press to display the Audio Adjustment menu.
Taxes E ON |
RAEN о Lips
à SAP oy SEN
Des D OH MQUF о),
©
+
“= ' _— .- PSE E tent
4. Press A or Y ‘to highlight SPEAKER.
5. ‘Press Él or ¥ to select ON, OFF&VAO or
OFF&FAO.
+ ON — TV speakers operate normally.
ee OFF&VAO (Variable Audio Output) — TV speakers
off, the sound output varies according to the TV
volume, use the TV remote to control the volume,
muting, bass, treble and balance of the External
Stereo System.
› OFF&FAO (Fixed Audio Output)
- sound output is fixed.
— TV speakers off,
Press twice to exit menus,
©
Surround
Use the Surround Feature to enhance audio response
when listening to Stereo sound.
1. Press (= |
2. Press A or Y and El or ? to highlight the
Audio icon.
3. Press
menu.
to display the Audio Adjustment
ae
SERINE CE _— rape
SURROUNDE ar
ra A, | En
TS A MOE |
4. Press A or y to highlight SURROUND.
5. Press a or № to select SURROUND ON or
OFF.
6. Press (==) twice to exit menus.
Al Sound
This feature is used to maintain constant sound level
when switching between programs with different sound
levels. a
1. Press (=) . ©
>
2. Press A or Y and < or > to highlight the t=
Audio Icon,
3. Press (ES) to display the Audio Adjustment
menu.
AUDIONE AUDIO
tira
©
D
"Te
! OR
GEES SICHINARORIMO RE |
a)
4, Press A or y to highlight Al SOUND.
5. Press a or № to select Al SOUND ON or OFF.
6. Press twice to exit menus.
„47 -
v
or’
<
=
O
v
mM
Set Up Features
Helpful Hints:
Setting DTV mode Set Up Features will also
change TV Mode and PC mode Set Up Features.
Auto Power On
This feature automatically turns the monitor ON when
AC power is applied.
1. Press .
2. Press A or \&/ and € or № to select the Set
Up Icon.
3. Press to display the Set Up menu.
EU]
4. Press A or Y to highlight AUTO POWER ON.
5. Press a or № to select SET.
6. Press &™ twice to exit menus.
Aspect Ratio
This feature is used to change the aspect ratio of the
screen when connected to a DTV unit.
1. Press (==).
2. Press /A or Y and El or }® to highlight the
Set Up Icon.
3. Press to display the Set Up menu.
SU]
4. Press € or y> to select AUTO, 16:92 (wide
picture), or 4:3 (normal picture).
5, Press twice to exit menus.
Color Matrix
This feature is used to change the picture Color Matrix
to Standard or High..
1. Press
2. Press A or №7 and € or № to highlight the
Set Up Icon.
3. Press to display the Set Up menu.
4. Press € or > to select AUTO, HD (High
Definition), or SD (Standard Definition),
5, Press twice to exit menus.
Geomagnetic Corr (Correction)
This monitor incorporates a special adjustment feature
for the convenience of the customer. This adjustment is
preset at the factory. However, adjustment may be
required when the monitor is moved (due to the
influence of earth’s magnetic field) which may cause
the picture to tilt slightly. If necessary, follow these
procedures to adjust the tilt.
1. Press (€):
2. Press A or y and € or La to © highlight the
Set Up Icon.
Press (==) to display the Set Up menu.
©
pou EU
a
RIM'ATRIX
GEOMAGNETIC CORR
4. Press A or \& to
GEOMAGNETIC CORR.
highlight
n
Press El or № to display the Geomagnetic
Correction adjustment menu.
tilt adjustment bar
6. Press a or > to adjust the picture tilt until left
and right side of tilt adjustment bar is parallel to the
bottom of picture frame (if necessary).
NOTE: Discoloration may be visible in picture
corners ¡f tilt bar is not parallel to the
bottom of picture frame.
7. Press twice to exit menus.
- 48 -
Troubleshooting Chart
Before you call for service, determine the symptoms and make a few simple checks shown below
Symptoms
Check
Picture Sound
Dy - INPUT CONNECTORS SEATED PROPERLY
; - EQUIPMENT CONNECTED TO INPUT CONNECTIONS
AN - ANTENNA LOCATION AND/OR CONNECTION
NOISY SOUND
Dh - ELECTRICAL APPLIANCES, LIGHTS, CARS, AND TRUCKS
‘ - DIATHERMY AND OTHER MEDICAL EQUIPMENT
To N - VIDEO INPUT CONNECTORS SEATED PROPERLY
INTERFERENCE NOISY SOUND
- VOLUME CONTROL SETTING
Y - TV SPEAKERS (IF APPLICABLE) IN THE OFF MODE
- - AUDIO INPUT CONNECTOR SEATED PROPERLY
- TRY ANOTHER CHANNEL
NORMAL PICTURE NO SOUND |
NT
+" war
- THAT AC POWER LINE 1S PLUGGED INTO AC OUTLET
- BRIGHTNESS AND AUDIO CONTROLS SET PROPERLY
- VIDEO AND AUDIO INPUT CONNECTORS SEATED PROPERLY
NO PICTURE NO SOUND
(| ? 2? - COLOR CONTROL SETTINGS
© - TRY ANOTHER CHANNEL
y N
NO COLOR NORMAL SOUND
VIDEO
- MONITOR/RECEIVER IN VIDEO MODE WITH NO SIGNAL
NORMAL PICTURE NO SOUND
CHK Y - PRESS AND HOLD ACTION AND POWER BUTTONS AT THE SAME
{| <> TIME FOR 5 SECONDS. SCREEN WILL SHUT OFF, THEN TURN
N BACK ON. TV WILL BE SET TO CHANNEL 3 AND CYCLE THROUGH
A SPECIAL TEST
CHK MODE NORMAL SOUND
PC MODE
NN - COMPUTER CABLE SEATED PROPERLY
- COMPUTER RESOLUTION NOT SET PROPERLY
DN (REFER TO FOLLOWING PAGES FOR SET UP PROCEDURES)
SCRAMBLED IMAGE NORMAL SOUND
A D» - ADJUST GEOMAGNETIC CORRECTION LOCATED IN
$3 J THE SET-UP MENU (IF APPLICABLE)
y
DISCOLORATION NORMAL SOUND
D = C D» - MOVE UNSHIELDED SPEAKERS AWAY FROM PICTURE TUBE
a - TURN OFF SET, ALLOW TO COOL, TURN SET BACK ON
DISCOLORED
PICTURE NORMAL SOUND
- 49 -
er
=
<=
-
O
O
L
2
Ur
a1
=
O
o.
--
|
=
O
=
о
=
m
©
I
e,
O
A
rs
©
Troubleshooting (cont’d.)
Computer Resolution Set Up For
Windows 95 Version
The resolution on your computer may have to be set to
800 x 600 pixels or less. To change, follow these
procedures.
1. Shut down and restart the computer.
2. While the “Starting Windows 95” message is
displayed on screen, quickly press “F8” key, then
press ENTER key.
STARTING WINDOWS 95
anT hou
ОМ
OFF
3. Windows 95 start up menu will be displayed. Then
select “Safe mode” by using down arrow key or
type in the number.
Microsoft windows 95
startup menu .
3. FER
A. .....
Bean.
4. Press “ENTER” key.
safe mode safe mode
safe mode safe mode
En
5. Click on the “Start” button, and then point to
Settings.
|} Programs» safe mode
[| Document»
[__] Printers
|| Find + {7 Taskbar
[Help +»
[| Run > ON
[| Shut Down ОБЕ
Start |
6. Click on “Control Panel”.
7. Double-click “Display” icon. The Display Properties
box will appear...
Cono pene Ге
| File Edit View Help
— | Display |. —
_ 1 5 JL dL
к” safe mode
8. Click on the tab labeled “Settings” at the top of the
Display Properties box.
DisplayARroperties
Background Screen Saver | Appearance | Settin
-
=
9. Select resolution from the “Desktop Area” menu
box, 800 x 600 pixels or less, then click OK.
DisplayaProperties
[Background| Screen Saver Appearance Setting
Less More
NN
safe mode 800 by 600 pixels
10. Restart the computer before the new setting will
take effect.
11. Restart Windows 95 in normal mode.
- 50 -
Troubleshooting (cont’d.)
Computer Resolution Set Up For Windows 6. Press ENTER key, then press the Down arrow key
Version 3.X on the computer keyboard to highlight “VGA”.
The resolution on your computer may have to be set to |
VGA. To change, follow these procedures. —
1. Restart the computer from DOS. OC Mtro CBE 07
00000000660 0000000000
(db 0000000000 0000000000
0000000000 0000000000
00002000000 0000000000
0000000000 000000006050
0290900000000 0000000000
VGA |
(#9 999 2009 WN Mo MA press Mo (1) aan tap
7. Press ENTER key while VGA is highlighted. The
screen will return to previous Windows Setup
screen, then check that Display setting was
2. Type “cdwindows”, then press ENTER key on changed to VGA.
Computer keyboard.
ed -
0009050000 092020000000
С „09000000000
у
0002000000 WU ODD
Acceptthe confiquration]shown[above
000000000220 2000000900
ооо 608000000000
8. Press ENTER key while “Accept the configuration
3. Type “setup”, then press ENTER key on Computer shown above” is highlighted.
keyboard.
Ca>cdiwindows>setup
hayelaskeditolchangelthelty pelof{Displaygtol
Me nai .
5000000000 0000000000
г 70000, 009000000000
0090900000200 0020000020900
GERT Accept the configuration shown above
0020020000 vv w hd Wd WW A WL ur
2000000000 0000000000
4. Windows Setup screen will be displayed. Pressthe 9. Press ENTER key to accept driver. This will return
Up or Down arrow key on the computer keyboard you back to DOS prompt. Then enter Window 3.X
to highlight “Display”. from DOS.
пола
BE ee
0900000090 np000000000
po 000 0000090600
000000600000 EEE ETE aaa
ompietechanges:TAcceptihe contigurationstow nfabove ma ”
0900900000 0000000060
209006500000 000000000020
5. Press ENTER key.
=
=
--
O
O
и
N
w
=
00
=
о
ея
---
- 51 -
Panasonic Consumer Electronics
Company, Division of Matsushita
Electric Corporation of America
One Panasonic Way
Secaucus, New Jersey 07094
. Panasonic Sales Company,
Division of Matsushita Electric
of Puerto Rico Inc. (“PCS”)
Ave.65 de Infanteria, km. 9.5
San Gabriel industrial Park
Carolina, Puerto Rico 00985
Panasonic Canada Inc.
5770 Ambler Drive
Mississauga, Ontario L4W 2T3
Canada

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
