Panasonic Car Video System CY-BT200U User manual

CY-BT200U
Hands Free Kit with Audio Streaming featuring Bluetooth® technology
Kit mains libres avec streaming audio et technologie Bluetooth®
Juego de manos libres con Audio Streaming y tecnología Bluetooth®
CY-BT200U
Operating Instructions
Manuel d’instructions
Manual de Instrucciones
¡Please read these instructions (including “Limited Warranty” and “Customer Services Directory”) carefully before using this product and
keep this manual for future reference.
¡Prière de lire attentivement ces instructions (y compris la “Garantie limitée” et le “Répertoire des services à la clientèle”) avant d’utiliser ce
produit et conserver ce mode d’emploi pour s’y référer ultérieurement.
¡Lea con atención estas instrucciones antes de utilizar el producto y guarde este manual para poderlo consultar en el futuro.
Safety Information
■ Read the operating instructions for the unit and all other components of your car audio system carefully before using the
system. They contain instructions about how to use the system in a safe and effective manner. Panasonic assumes no
responsibility for any problems resulting from failure to
observe the instructions given in this manual.
Warning
This pictograph intends to alert you to the presence of important operating instructions and
installation instructions. Failure to heed the
instructions may result in severe injury or
death.
Warning
Observe the following warnings when using
this unit.
❑ Comply with regulations.
Always comply with legal requirements and local restrictions
when using this unit.
❑ Keep away from the medical devices.
This unit and mobile phones can interfere with the functioning of medical devices such as hearing aids or pacemakers.
2
■ This manual uses pictographs to show you how to use the
product safely and to alert you to potential dangers resulting
from improper connections and operations. The meanings of
the pictographs are explained below. It is important that you
fully understand the meanings of the pictographs in order to
use this manual and the system properly.
Caution
This pictograph intends to alert you to the presence of important operating instructions and
installation instructions. Failure to heed the
instructions may result in injury or material damage.
Failure to observe this may arise the malfunction of medical devices resulting in personal injury or death.
❑ The driver should not neither adjust the unit nor
make a pair while driving.
Adjusting this unit or establishing the pairing between this unit
and a Bluetooth-ready device will distract the driver from looking ahead of the car and accordingly can cause accidents.
Always stop the car in a safe location and use the parking brake
before adjustment or making a pair.
❑ Use the proper power supply (12 V).
This product is designed for operation with a negative
grounded 12 V DC battery system. Never operate this product with other battery systems, especially a 24 V DC battery
system.
❑ Do not disassemble or modify the unit.
Do not disassemble, modify the unit or attempt to repair the
product yourself. If the product needs to be repaired, consult
your dealer or an authorized Panasonic Servicenter.
❑ Do not use the unit when it is out of order.
If the unit is out of order (no power, no sound) or in an
abnormal state (has foreign objects in it, is exposed to
water, is smoking, or smells), turn it off immediately and
consult your dealer.
❑ Stop using this unit and a Bluetooth-ready device
whenever requested.
This unit shares the communication frequency with other
private or public wireless communication equipment such as
a wireless LAN and other wireless communication radios.
You should stop using this unit whenever you are notified
that your unit disturbs other wireless communication immediately.
Observe the following warnings when
installing. (including whole assembly of the
devices for system up)
English
Warning
❑ Disconnect the lead from the negative (–) battery
terminal before installation.
Wiring and installation with the negative (–) battery terminal
connected may cause electrical shock and injury due to a
short circuit.
Some cars equipped with the electrical safety system have
specific procedures of battery terminal disconnection.
FAILURE TO FOLLOW THE PROCEDURE MAY LEAD TO THE
UNINTENDED ACTIVATION OF THE ELECTRICAL SAFETY
SYSTEM RESULTING IN DAMAGE TO THE VEHICLE AND
PERSONAL INJURY OR DEATH.
❑ Never use safety-related components for installation, grounding, and other such functions.
Do not use safety-related vehicle components (fuel tank,
brake, suspension, steering wheel, pedals, airbag, etc.) for
wiring or fixing the product or its accessories.
❑ Installing the product on the air bag cover or in a
location where it interferes with airbag operation is
prohibited.
3
Safety Information (continued)
Warning
❑ Check for piping, gasoline tank, electric wiring, and
other items before installing the product.
If you need to open a hole in the vehicle chassis to attach or
wire the product, first check where the wire harness, gasoline tank, and electric wiring are located. Then open the hole
from outside if possible.
❑ Never install the product in a location where it interferes with your field of vision.
❑ After installation and wiring, you should check the
normal operation of other electrical equipment.
The continuation of their using in abnormal conditions may
cause fire, electrical shock or a traffic accident.
❑ In the case of installation to an airbag-equipping
car, confirm warnings and cautions of the vehicle
manufacturer before installation.
❑ Make sure the leads do not interfere with driving or
getting in and out of the vehicle.
❑ Insulate all exposed wires to prevent short circuiting.
4
❑ If there seem to be something wrong with the system, park your car in a safe place and identify the
abnormality.
Observe the following cautions when using this
unit.
❑ Keep the sound volume at an appropriate level.
Keep the volume level low enough to be aware of road and
traffic conditions while driving.
❑ This unit is designed for use exclusively in automobiles.
❑ Do not expose the unit to direct sunlight or excessive heat.
Otherwise these will raise the interior temperature of the
unit, and it may lead to smoke, fire, or other damage to the
unit.
❑ Do not use the product where it is exposed to water,
moisture, or dust.
Exposure of the unit to water, moisture, or dust may lead to
smoke, fire, or other damage to the unit. Make especially sure
that the unit does not get wet in car washes or on rainy days.
Observe the following cautions when
installing. (including whole assembly of the
devices for system up)
English
Caution
❑ Refer wiring and installation to qualified service
personnel.
Installation of this unit requires special skills and experience.
For maximum safety, have it installed by your dealer.
Panasonic is not liable for any problems resulting from your
own installation of the unit.
❑ Follow the instructions to install and wire the product.
Not following the instructions to properly install and wire the
product could cause an accident or fire.
❑ Take care not to damage the leads.
When wiring, take care not to damage the leads. Prevent
them from getting caught in the vehicle chassis, screws, and
moving parts such as seat rails. Do not scratch, pull, bend or
twist the leads. Do not run them near heat sources or place
heavy objects on them. If leads must be run over sharp
metal edges, protect the leads by winding them with vinyl
tape or similar protection.
5
Safety Information (continued)
Caution
❑ Do not install the product where it is exposed to
strong vibrations or is unstable.
Avoid slanted or strongly curved surfaces for installation. If
the installation is not stable, the unit may fall down while
driving and this can lead to an accident or injury.
❑ Make sure that wiring is completed before installation.
❑ To prevent damage to the unit, do not connect the
power connector until the whole wiring is completed.
❑ Secure the mobile phone to prevent it from moving
while driving.
CAUTION:
• PLEASE
FOLLOW THE LAWS AND REGULATIONS OF YOUR STATE, PROVINCE OR COUNTRY FOR WIRING,
INSTALLATION, AND USE OF THIS UNIT AND THE DEVICES TO BE CONNECTED.
6
Part 15 of the FCC Rules
FCC Warning:
Any unauthorized changes or modifications to this
equipment would void the user's authority to operate
this device.
This transmitter must not be co-located or operated in
conjunction with any other antenna or transmitter.
This equipment complies with FCC radiation exposure
limits set forth for uncontrolled equipment and meets
the FCC radio frequency (RF) Exposure Guidelines in
Supplement C to OET65. This equipment has very low
levels of RF energy that it deemed to comply without
maximum permissive exposure evaluation (MPE). But it
is desirable that it should be installed and operated with
at least 20 cm and more between the radiator and person’s body (excluding extremities: hands, wrists, feet
and legs).
NOTICE
English
The following applies only in the U.S.A.
This equipment has been tasted and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.This equipment generates, uses
and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for help.
7
Customer Services Directory
U.S.A.
Obtain Product Information and Operating Assistance; locate
your nearest Dealer or Servicenter; purchase Parts and
Accessories; or make Customer Service and Literature requests
by visiting our Web Site at:
http://www.panasonic.com/support
or, contact us via the web at:
http://www.panasonic.com/contactinfo
You may also contact us directly at:
1-800-211-PANA (7262),
Monday-Friday 9 am-9 pm; Saturday-Sunday 10 am-7 pm, EST.
For hearing or speech impaired TTY users,
TTY : 1-877-833-8855
Accessory Purchases:
Purchase Parts, Accessories and Instruction Books online for all
Panasonic Products by visiting our Web Site at:
http://www.pasc.panasonic.com
or, send your request by E-mail to:
[email protected]
You may also contact us directly at:
1-800-332-5368 (Phone) 1-800-237-9080 (Fax Only)
(Monday-Friday 9 am to 8 pm, EST.)
8
Panasonic Services Company
20421 84th Avenue South, Kent, WA 98032
(We accept Visa, MasterCard, Discover Card, American Express,
and Personal Checks)
For hearing or speech impaired TTY users,
TTY : 1-866-605-1277
Service in Puerto Rico
Panasonic Puerto Rico, Inc.
Panasonic Sales Company
Factory Servicenter:
Ave. 65 de Infantería, Km. 9.5, San Gabriel Industrial Park,
Carolina, Puerto Rico 00985
Phone (787) 750-4300, Fax (787) 768-2910
WARRANTY SERVICE
FOR PRODUCT OPERATION ASSISTANCE, please contact:
Our Customer Care Centre:
Telephone #:
1-800 #:
Fax #:
Email link:
IF YOU SHIP THE PRODUCT TO A SERVICENTRE
Carefully pack and send prepaid, adequately insured and preferably in the original carton.
Include details of the defect claimed, and proof of date of original
purchase.
English
CANADA
(905) 624-5505
1-800-561-5505
(905) 238-2360
“Contact Us” on www.panasonic.ca
FOR PRODUCT REPAIRS, please locate your nearest Authorized
Servicentre at www.panasonic.ca:
Link : “ServicentresTM locator” under “Customer support”
9
Limited Warranty
During the “Labor” warranty period, there will be no charge for labor. During the
“Parts” warranty period, there will be no charge for parts. You must carry in or mail
in your product pre paid during the warranty period. If non-rechargeable batteries are
included, they are not warranted. This warranty only applies to products purchased
and serviced in the United States or Puerto Rico. This warranty is extended only to
the original purchaser of a new product which was not sold “as is”. A purchase
receipt or other proof of the original purchase date is required for warranty service.
U.S.A.
PANASONIC CONSUMER ELECTRONICS COMPANY,
DIVISION OF PANASONIC CORPORATION OF NORTH AMERICA
One Panasonic Way, Secaucus, New Jersey 07094
PANASONIC SALES COMPANY,
DIVISION OF PANASONIC PUERTO RICO, INC.
Ave. 65 de infantería, Km. 9.5, San Gabriel Industrial Park
Carolina, Puerto Rico 00985
CARRY-IN OR MAIL-IN SERVICE
For Carry-In or Mail-In Service in the United States, call 1-800-211-PANA
(7262) or visit
Panasonic Web Site: http://www.panasonic.com
For assistance in Puerto Rico, call Panasonic Sales Company (787)-750-4300
or fax (787)-768-2910.
PANASONIC AUTO PRODUCTS
LIMITED WARRANTY
LIMITED WARRANTY COVERAGE
If your product does not work properly because of defects in materials and
workmanship.
Panasonic Consumer Electronics Company or Panasonic Sales Company (collectively referred to as “the warrantor”) will, for the length of the period indicated in the chart below, which starts with the date of original purchase (“warranty period”), at its option either (a) repair your product with new or refurbished
parts, or (b) replace it with a new or refurbished product. The decision to
repair or replace will be made by the warrantor.
Categories
Audio Components (except items listed below)
MXE Series Audio Components (except items listed
below)
Speakers
Defective Car Audio Speakers under warranty must be
exchanged at the place of purchase. Contact your
Dealer for details.
Accessories (in exchange for defective items)
10
Parts
One (1) Year
Two (2) Years
Labor
One (1) Year
Two (2) Years
One (1) Year
Not Applicable
Ninety (90) Days Not Applicable
LIMITED WARRANTY LIMITS AND EXCLUSIONS
This warranty ONLY COVERS failures due to defects in materials and workmanship,
and DOES NOT COVER normal wear and tear or cosmetic damage. The warranty
ALSO DOES NOT COVER damages which occurred during shipment, failures which
are caused by products not supplied by the warrantor, failures which result from
accident, misuse, abuse, neglect, bug infestation, mishandling, misapplication, alteration, faulty installation, set-up adjustment, maladjustment of consumer control,
improper maintenance, improper antenna, inadequate signal reception or pickup,
power line surge, improper voltage supply, lightning, modification, commercial use
(such as use in hotels, offices, restaurants, or other business uses) or rental use of
the product, or service by anyone other than the technician from Factory Servicenter
or other authorized service centers, or damage that is attributable to acts of God.
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER “LIMITED
WARRANTY COVERAGE”. THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR
ARISING OUT OF ANY BREACH OF THIS WARRANTY. (As examples, this excludes
damages for lost time, cost of having someone remove or re-install an installed unit
Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the
exclusions may not apply to you.
This warranty gives you specific legal rights and you may also have other
rights which vary from state to state. If a problem with this product develops
during or after the warranty period, you may contact your dealer or
Servicenter. If the problem is not handled to your satisfaction, then write to
warrantor’s Consumer Affairs Department at the addresses of the warrantor.
PARTS AND SERVICE WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY ARE YOUR RESPONSIBILITY.
Customer’s Record
Model
No.
Serial
No.
Dealer’s
No.
Code
No.
Dealer’s
Address
Date of
Purchase
CANADA
English
if applicable, travel to and from the servicer, and loss of media, data or other memory contents. The items listed are not exclusive, but are for illustration only.) ALL
EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED WARRANTY.
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga Ontario L4W 2T3
PANASONIC PRODUCT LIMITED WARRANTY
Panasonic Canada Inc. warrants this product to be free from defects in materials and workmanship and agrees to remedy any such defect for a period as
stated below from the date of original purchase.
CAR AUDIO PRODUCT – ONE (1) YEAR, PARTS AND LABOUR
(The labour to install or remove the product is not warranted)
ACCESSORIES - NINETY (90) DAYS, (IN EXCHANGE FOR DEFECTIVE ITEMS)
LIMITATIONS AND EXCLUSIONS
This warranty does not apply to products purchased outside Canada or to any
product which has been improperly installed, subjected to usage for which the
product was not designed, misused or abused, damaged during shipping, or
which has been altered or repaired in any way that affects the reliability or detracts
from the performance, nor does it cover any product which is used commercially.
Dry cell batteries are also excluded from coverage under this warranty.
This warranty is extended to the original end user purchaser only. A purchase
receipt or other proof of the original purchase date is required before warranty
service is performed.
THIS EXPRESS, LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
IN NO EVENT WILL PANASONIC CANADA INC. BE LIABLE FOR ANY SPECIAL,
INDIRECT OR CONSEQUENTIAL DAMAGES.
In certain instances, some jurisdictions do not allow the exclusion or limitation
of incidental or consequential damages, or the exclusion of implied warranties,
so the above limitations and exclusions may not be applicable.
11
Components
Operating Instructions
Microphone with Bracket (5 m)
(YFM264C099ZA)
(L0FBBB000005)
Q'ty: 1
Product Registration Card
Q'ty: 1
System-up connecting cable (3 m)
(YEAJ071812A)
Q'ty: 1
Customer Care Plan
Q'ty: 1
Double-sided Tape
(YFX994C128ZA)
Q'ty: 1
CY-BT200U
Main Unit
Q'ty: 2
Double-sided Tape
(YFX994C129ZA)
Q'ty: 1
Switch Unit (2 m)
Q'ty: 1
Cable Clamp
(ASMYSW100N)
Q'ty: 1
Note:
¡ The number in parentheses underneath each accessory part name is the part number for maintenance and service.
¡ Accessories and their part numbers are subject to modification without prior notice due to improvements.
12
Q'ty: 5
Safety Information ............................ 2
Customer Services Directory .......... 8
Limited Warranty ............................ 10
Components ................................... 12
Introduction .................................... 14
Glossary .......................................... 16
Names of Controls and Functions ... 17
Preparation (Bluetooth Audio) ....... 18
Basic Operation (Bluetooth Audio) .. 19
Preparation (Hands-Free Kit) ......... 20
Basic Operation (Hands-Free Kit) .... 22
Advanced Operation (Hands-Free Kit) . 23
Installation ...................................... 24
Wiring .............................................. 26
Troubleshooting ............................. 28
Specifications ................................. 34
English
Contents
13
Introduction
Panasonic welcomes you to our constantly growing family of electronic products owners.
We endeavor to give you the advantages of precise electronic and mechanical engineering, manufactured with carefully
selected components, and assembled by people who are proud of the reputation their work has built for our company. We
know this product will bring you many hours of enjoyment, and after you discover the quality, value and reliability we have
built into it, you too will be proud to be a member of our family.
Hands Free Kit with Audio Streaming featuring Bluetooth® technology
❑ Overview
What users can do with CY-BT200U
Connection of this unit to a head unit allows users to perform the
functions described below.
Listening to the audio system (Bluetooth audio)
Combination of this unit and a Bluetooth-ready mobile phone or
audio device allows users to play the phone or device through
this unit.
Hands-free conversation on a mobile phone
(Hands-Free Kit)
Combination of this unit and a Bluetooth-ready mobile phone
allows users to have hands-free conversation on the phone.
¡ Telephone picking up
¡ Callback with use of the call register
This unit is designed only for receiving calls with taking
account of safety. No call can be made with this unit.
14
(But a call-back call can be made.)
This unit does not support the voice dial function.
Note:
¡ A certain distance shall be provided between this unit and the
Bluetooth-ready device. Failure to observe this may cause low
quality tone or bad connection condition.
¡ Do not use this unit and other wireless devices at the same
time. Failure to observe this may cause interference between
this unit and those devices.
¡ Bluetooth connection will shorten the battery life of the
Bluetooth-ready device.
¡ This unit cannot support the cable connection mobile phones.
¡ This unit (only 1 unit) is connectable to the head unit through
the Expansion Module (CY-EM100U, option) as well as connectable to the head unit directly.
English
❑ Installation sample
Microphone with Bracket
Switch Unit
Head unit
Main Unit
CY-BT200U
15
Glossary
Bluetooth®
Remote Control Profile)
The Bluetooth word mark and logo are owned by the Bluetooth
SIG, Inc. and any use of such marks by Matsushita Electric
Industrial Co.,Ltd. is under license. Other trademarks and trade
name are those of their respective owners.
Link key
Bluetooth
Bluetooth is a name of the wireless communication technology
for the mobile information equipment such as portable PCs,
PDAs, mobile phones, etc. These devices can be connected each
other without cables and communicate each other.
Bluetooth uses 2.45 GHz band’s wave that can be used without a
license. Bluetooth chips are relatively small and their power consumption is low. Communication service distance of Bluetooth is
approximately 10 m.
Bluetooth profile
Bluetooth profile is a standard protocol used in Bluetooth communications settled for each category of the communication
equipment.
This hands-free unit supports the following Bluetooth profiles:
HFP (Hands-Free Profile), OPP (Object Push Profile), A2DP
(Advanced Audio Distribution Profile), AVRCP (Audio/Video
16
This is an up to 16-byte password used for device identification.
Entering the same PIN number of the device to be connected
allows identification. Once identification is completed, the Link
key is established. Identification is enabled without input of the
Bluetooth Pin Number from next time thanks to holding the Link
key at both sides.
PIN (Personal Identification Number)
This is a password used for self identification.
Pairing
Pairing is authentication between 2 Bluetooth devices with using
a link key.
Pairing allows Bluetooth devices to communicate each other.
iPod®
iPod is a trademark of Apple Inc., registered in the U.S. and other
countries.
Main unit
English
Names of Controls and Functions
Microphone with Bracket
Switch Unit
Status indicator (Blue LED)
lights: Call waiting/Talking
stays out: Not connected
blinks rapidly: Receiving a call
blinks slowly: Pairing/
Reconnecting
CY-BT200U
[Hang-on] /Blue LED
[Hang-up] /Red LED
System-up connector
To a Head unit or a port of Expansion
module
Switch Unit connector
To the Switch Unit
Microphone connector
To the microphone with
Bracket
17
Preparation (Bluetooth Audio)
Perform electrical wiring for CY-BT200U (this unit) and
install it. (\ page 26, 27) Refer to the individual instructions
for the devices to be connected as well.
q Items for preparation
¡ CY-BT200U (this unit)
¡ Bluetooth-ready audio device
Note: For the models to be supported, visit the Web Site at:
http://www.panasonic.com (Refer to the description regarding
Car Audio/AV.)
We do not guarantee that all the functions of this unit are
available on all of the Bluetooth-ready devices.
¡ Head unit
The models to be supported are shown below as of December
2007.
CQ-VX100U/CQ-VW100U, CQ-RX400U/CQ-RX200U
w Pairing
This unit should register the Bluetooth-ready device to be coupled before using.
Pairing establishment is performed on the menu screen of the
head unit. Refer to the Operating Instructions of the head unit for
further information.
Note:
¡ If another device is already registered, deletion of the registered data for the device is required in advance. Refer to the
Operating Instructions of the head unit for further information.
¡ Only the latest paired the Bluetooth-ready is usable.
¡ This unit is displayed as “Panasonic BT200” on the screen of
the Bluetooth-ready device.
¡ If the displayed device is different from the connected device,
the pairing is not successfully completed. Try to establish the
pairing again.
¡ Once pairing is established, this operation is not required until
replacing the Bluetooth-ready device with another Bluetoothready device.
e Volume adjustment
18
(head unit)
The connected Bluetooth-ready device is operable from the
head unit. Refer to the Operating Instructions of the head unit
for further information.
Note: Some audio devices may be inoperable from the head
unit.
❑ Track selection
[7] (TRACK): Next track
[6] (TRACK): Preceding track (press twice)
❑ Automatic reconnection
English
Basic Operation (Bluetooth Audio)
This unit stores the data of the device that was connected to this
unit last time. (Stored data for 1 Bluetooth audio device and for 1
Hands-Free Kit) Turning on the power of the head unit allows
this unit to automatically attempt to connect to the device that
was connected last time.
Note: With regard to some devices, reconnection cannot be performed.
Note: Hold down for fast forward/reverse.
❑ Pause
Press [BAND] (5h).
Press again to cancel.
19
Preparation (Hands-Free Kit)
Perform electrical wiring for CY-BT200U (this unit) and
install it. (\ page 26, 27) Refer to the individual instructions
for the devices to be connected as well.
q Items for preparation
¡ CY-BT200U (this unit)
¡ Bluetooth-ready mobile phone
Note: For the models to be supported, visit the Web Site at:
http://www.panasonic.com (Refer to the description regarding
Car Audio/AV.)
We do not guarantee that all the functions of this unit are
available on all mobile phones.
¡ Head unit
The models to be supported are shown below as of December
2007.
CQ-VX100U/CQ-VW100U, CQ-RX400U/CQ-RX200U
20
w Pairing
This unit should register the Bluetooth mobile phone to be coupled before using.
Pairing establishment is performed on the menu screen of the
head unit. Refer to the Operating Instructions of the head unit for
further information.
Note:
¡ If another device is already registered, deletion of the registered data for the device is required in advance. Refer to the
Operating Instructions of the head unit for further information.
¡ Only the latest paired mobile phone is usable.
¡ This unit is displayed as “Panasonic BT200” on the screen of
the mobile phone.
¡ If the displayed device is different from the connected device,
the pairing is not successfully completed. Try to establish the
pairing again.
¡ Once pairing is established, this operation is not required until
replacing the phone with another mobile phone.
t Volume adjustment
Position the microphone appropriately to catch sounds satisfactorily. The direction of the sun visor may change the volume.
Note: The volume is adjustable only when receiving calls.
r Communication test on
paired mobile phone
Check whether the paired mobile phone is available. (Call to the
paired mobile phone.)
English
e Microphone positioning
(head unit)
q Adjust the ring volume.
The ring tone may come from the mobile phone depending on
your head unit or mobile phone. Refer to the individual instructions for the head unit or mobile phone for details.
w Adjust the volume of telephone conversation.
21
Basic Operation (Hands-Free Kit)
Note:
Caution
This unit is designed only for receiving calls with taking
account of safety. No call can be made with this unit. (But a
call-back call can be made.)
¡ Bluetooth connection will make the battery life of mobile
phone shorter.
¡ Depending upon the mobile phone, the display backlight of a
mobile phone remains on when the ignition switch is in the
ACC ON position. In this case, you should turn off the backlight
with the mobile phone ( \ Manual of your mobile phone).
¡ Do not turn off the power of the Head unit during a phone
conversation. Otherwise, some mobile phones cut the conversation.
¡ In some cases such as the manner mode, the ring tone is disabled while the ring tone is set to off.
❑ Receiving a call
❑ Automatic reconnection
When a call comes in, the state indicator blinks rapidly.
When you get out of the car, turning off the power of the Head unit allows automatic disconnection of communication between this unit and the mobile phone.
After communication is disconnected, the mobile phone can be used as usual.
When you get in the car, turning on the power of the Head unit allows automatic connection of communication between this unit and the mobile phone.
(Some mobile phone models require automatic connection setting. In some
cases, connection setting is required on the selection screen appearing on the
mobile phone while connection is established.) After communication is connected, the hands-free function is available.
¡ Telephone conversation during driving may result in consequences adverse to safety. Follow your local laws and regulations.
¡ Appropriately adjust the volume of incoming calls in
advance ( \ Operating instructions of your head unit).
1 Press the [Hang-on] to receive a call.
2 Adjust the volume if necessary. ( \ Operating
instructions of your head unit).
3 Press the
22
[Hang-up] to end a call.
❑ Calling back
A callback call can be made.
However, the callback function is disabled after disconnecting
Bluetooth communication. (e.g. communication disconnection
between the Hands Free Kit with Audio Streaming featuring
Bluetooth® technology and mobile phone, and communication
disconnection by turning off the power of the Head unit)
Refer to the Operating Instructions of the head unit for further
information.
Note: Some mobile phones cannot display the telephone number of an incoming call or callback.
❑ Rejection of incoming calls
Press the
English
Advanced Operation (Hands-Free Kit)
[Hang-up] to reject an incoming call.
❑ Disconnection of Bluetooth
You can disconnect Bluetooth temporarily.
Disconnection
Refer to the Operating Instructions of the head unit for further
information.
Reconnection
Refer to the Operating Instructions of the head unit for further
information.
Note: You cannot disconnect Bluetooth in the talking state but
end a call.
23
Installation
Warning
❑ Installation Hardware
¡This installation information is designed for professional
installers with knowledge of automobile electrical safety systems and is not intended for non-technical, do-it-yourself individuals. It does not contain instructions on the electrical installation and avoidance of potential harm to air bag, anti-theft and
ABS braking or other systems necessary to install this product.
Any attempt to install this product in a motor vehicle by anyone
other than a professional installer could cause damage to the
electrical safety systems and could result in serious personal
injury or death.
¡If your car is equipped with air bag and/or anti-theft systems,
specific procedures may be required for connection and disconnection of the battery to install this product. Before attempting
installation of this electronic component against the manufacturer’s recommendation, you must contact your car dealer or
manufacturer to determine the required procedure and strictly
follow their instructions.
FAILURE TO FOLLOW THE PROCEDURE MAY RESULT IN THE
UNINTENDED DEPLOYMENT OF AIR BAGS OR ACTIVATION OF
THE ANTI-THEFT SYSTEM RESULTING IN DAMAGE TO THE VEHICLE AND PERSONAL INJURY OR DEATH.
24
Main Unit
q
CY-BT200U
Q'ty: 1
w
Switch Unit
(2 m)
Q'ty: 1
e
Microphone with Bracket
(5 m)
Q'ty: 1
r
System-up connecting cable
(3 m)
Q'ty: 1
Double-sided Tape
t
(12 x 55 mm)
Q'ty: 2
Double-sided Tape
y
(15 x 30 mm)
Q'ty: 1
Cable Clamp
u
Q'ty: 5
¡ Make sure that wiring is completed before installation.
¡ Do not install the product where it is exposed to strong
vibrations or is unstable. Avoid slanted or strongly curved
surfaces for installation. If the installation is not stable,
the unit may fall down while driving and this can lead to
an accident or injury.
1 Remove the cable from the battery negative
terminal.
2 Connect all the cables of CY-BT200U (this
unit).
3 Secure the Main unit q, Switch Unit w and
Microphone with Bracket e.
q Attach the Main unit q and the Switch Unit w with the
double-sided tape t y.
Switch Unit w
Main Unit q
Peel off the back papers
Peel off the back papers
English
Caution
w Secure the microphone with bracket e.
e Secure all connection cables with Cable Clamp u.
Attach the Microphone with
Bracket e by clipping on the
sun visor etc.
Fix the cable with the
Cable Clamp u.
Sun visor
4 Reconnect the Battery Cable.
25
Wiring
Connection between CY-BT200U (this unit) and the head unit
Microphone with Bracket e
Main Unit q
Switch Unit w
CY-BT200U
■ How to disconnect cord with lock
Disconnect the cord while pressing the lock section in the arrow direction.
● Pulling the cord with excessive force may cause damage to the cord.
● Be sure to unlock the connection portion when disconnecting the cord.
System-up connecting
cable r
Head unit (e.g. CQ-VX100U, Option)
26
w Switch Unit
r System-up connecting
cable (main unit side)
r System-up connecting
cable (connected
device side)
English
Connection among CY-BT200U (this unit) and two or more devices
Head unit
(e.g. CQ-VX100U, Option)
Head unit/Expansion module
connection cable
(supplied with CY-EM100U)
Microphone with Bracket e
Main Unit q
Switch Unit w
System-up connecting cable r
CY-BT200U
iPod
Expansion Module
(CY-EM100U, Option)
Direct Cable for iPod (CA-DC300U, Option)
27
Troubleshooting
If You Suspect Something Wrong
Check and take steps as described below.
If the described suggestions do not solve the problem, it is
recommended to take the unit to your nearest authorized
Panasonic Servicenter. The product should be serviced only
by qualified personnel. Please refer the checking and the
repair to professionals. Panasonic shall not be liable for any
accidents arising out of neglect of checking the unit or your
own repair after your checking.
Warning
¡ Do not use the unit in an irregular condition, for example, without sound, or with smoke or a foul smell, which
can cause ignition or electric shock. In case that such
conditions occur, immediately stop using this unit and
consult your dealer.
¡ Never try to repair the unit by yourself because it is dangerous to do so.
■ Common
Problem
Reconnection failed
28
Possible cause a Possible solution
With regard to some devices, reconnection cannot be automatically performed.
● Turn off the power of the Bluetooth-ready device, and then turn on the power of the
device again.
The Link key of the Bluetooth-ready device is different from that of this unit.
● Try to establish the pairing again. If the pairing was not successfully established,
delete “Panasonic BT200” from the pairing list of the Bluetooth-ready device.
Possible cause a Possible solution
English
Problem
There is another wireless device near the unit.
● Switch off the wireless device or keep it away from these Hands Free Kit with
Audio Streaming featuring Bluetooth® technology.
The distance between this unit and the Bluetooth-ready device is too long, or the
Bluetooth-ready device is hidden behind a metallic object from this unit.
● Change the location of the Bluetooth-ready device.
✽ Consult your dealer to move the main unit.
Pairing failed
The Bluetooth function of the Bluetooth-ready device is deactivated.
● Refer to the Operating Instructions of the Bluetooth-ready device. (With regard to
some devices, the power saving mode is activated after a certain time.)
The automatic reconnection setting of the Bluetooth-ready device is deactivated.
● Refer to the Operating Instructions of the Bluetooth-ready device.
The profile of the Bluetooth-ready device is not supported.
● Check the description of the supported profiles. ( \ page 34)
29
Troubleshooting (continued)
■ Hands-Free Kit
Problem
Possible cause a Possible solution
The head unit is set to OFF.
● Turn on the power of the head unit.
CY-BT200U (this unit) is set to the disconnection mode.
● Cancel the disconnection mode.
CY-BT200U (this unit)
cannot receive a call.
Your mobile phone is out of service area.
● Drive your car to the service area of your mobile phone.
Bluetooth connection is disconnected. (The blue indicator does not light up.)
● Establish Bluetooth connection again.
The mobile phone is selected to the setting so that the ring volume is zero such as the
manner mode.
● Refer to the operating instructions for the mobile phone and change the setting.
(The ringtone of some mobile phones does not come from the speakers mounted
in a car but only from the mobile phones.)
The hands-free voices
accompany the echo
or howling.
30
Distance between the microphone and the speaker is too short.
● Keep sufficient distance between the microphone and the speakers or decrease
the volume of voice (Refer to the manual of your Head unit.).
✽ Echo may be produced depending on the line status or mobile phone to be used.
Possible cause a Possible solution
English
Problem
There is another wireless device near the unit.
● Switch off the wireless device or keep it away from these Hands Free Kit with
Audio Streaming featuring Bluetooth® technology.
The voice quality of
hands-free is low
(Distortion, noise etc.).
The distance between CY-BT200U (this unit) and the mobile phone is too long or too
short.
● Keep a proper distance between CY-BT200U (this unit) and the mobile phone.
The reception condition of the mobile phone is poor, or the line status is bad.
● Use the mobile phone in areas with good reception condition.
Telephone
conversation is
suspended.
The phone
conversation is hard
to hear.
Receiving condition of your mobile phone is bad.
● Drive your car to the place where receiving condition is good and park your car in
a safe place with parking brake used, and then you make a call.
If you and the person on the other end of the line talk at the same time, you may have
difficulty to hear his or her voice, and vise versa. (This is not machine failure.)
● The telephone conversation should be conducted alternately.
31
Troubleshooting (continued)
Problem
Talking volume is low
or noisy.(claim from
the person on the
other end of the line)
Possible cause a Possible solution
Distance between the microphone and the talker is too long or the connection of microphone is not proper.
● Make the microphone closer to the talker. Or connect the microphone’s connector
properly.
The window is open, or the air conditioner blows air to the microphone.
● Close the window, change the air direction from the air conditioner, or change the
microphone position.
Some mobile phones do not send Bluetooth data even if incoming calls are indicated on
the screen of your mobile phone.
● A call-back call cannot be made.
A call-back call
cannot be made.
The calling party activates the caller ID blocking function.
● A call-back call cannot be made.
An international call was received.
● A call-back call may not be made internationally depending on a contract with the
mobile phone company. Check the contract.
32
Possible cause a Possible solution
English
Problem
The Switch Unit is disconnected.
● Connect the Switch Unit securely and properly.
The CY-BT200U (this
unit) is inoperable.
Audio output comes
out of the mobile
phone after
reconnection.
The power of the Head unit is set to off.
● Turn on the power of the Head unit.
For other than the above
● Turn on and off the power of the Head unit.
● Toggle the ignition switch between ACC ON and ACC OFF of the car, or turn on and
off the mobile phone.
For some mobile phone models, audio output does not switch to the hands-free kit
automatically.
● Refer to the instruction manual for the mobile phone regarding audio switching.
33
Specifications
Power supply
Current consumption
Communication Frequency
Number of channels
Channel width
Communication mode
RF output
Service area
Applicable Bluetooth version
Supported profile
Microphone impedance
Dimensions (W x H x D)
Weight
34
:DC 12 V (11 – 16 V), test voltage 14.4 V, negative ground
(Supplied from a head unit or a Expansion Module)
:Less than 1.0 A
:2,402 MHz – 2,480 MHz
:79 channels
:1.0 MHz
:Frequency hopped spread spectrum communication
:–1 dBm (0.8 mW)
:Within 10 m
:Ver. 1.2
:HFP (Hands-Free Profile), OPP (Object Push Profile), A2DP (Advanced Audio Distribution Profile),
AVRCP (Audio/Video Remote Control Profile)
:600 Ω
:72.8 x 102 x 24 mm {2 7/8 ” x 4 ”x 15/16”} (Excluding Switch Unit and Microphone)
:0.5 kg {1 lb. 16 oz} (Excluding Switch Unit and Microphone)
English
Note:
¡ Specifications and design are subject to modification without notice due to improvements.
¡ Some figures and illustrations in this manual may be different from your product.
FCC ID:ACJ932CY-BT100U
Canada: License No
IC: 216J-CYBT100U
35
Panasonic Consumer
Electronics Company,
Division of Panasonic
Corporation of North America
One Panasonic Way, Secaucus,
New Jersey 07094
http://www.panasonic.com
Panasonic Sales Company,
Division of Panasonic Puerto
Rico, Inc. (“PSC”)
Ave. 65 de Infantería, Km. 9.5
San Gabriel Industrial Park,
Carolina, Puerto Rico 00985
http://www.panasonic.com
YFM264C099ZA
© 2007 Matsushita Electric Industrial Co., Ltd. All Rights Reserved
Panasonic Canada Inc.
5770 Ambler Drive,
Mississauga, Ontario
L4W 2T3
http://www.panasonic.ca
PTW1107-0138
Printed in Taiwan

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
