Sony Cordless Telephone SPP-A1050 User manual
3-230-536-11(3)
Cordless Telephone
with Answering System
Operating Instructions
When programming emergency numbers and (or) making test calls
to emergency numbers:
1. Remain on the line and briefly explain to the dispatcher the
reason for the call.
2. Perform such activities in the off-peak hours, such as early
morning or late evenings.
Operation is subject to the following two conditions: (1)This device
may not cause interference, and (2)This device must accept any
interference, including interference that may cause undesired
operation.
The model and the serial numbers are located at the
bottom of the unit. Record the serial number in the
space provided below. Refer to these numbers
whenever you call upon your Sony dealer regarding
this product.
Model No. SPP-A1050 Serial No.
SPP-A1050
A fully charged battery pack lasts for about:
• Approx. 7 hours when you use the handset continuously
• Approx. 6 days when the handset is in standby mode.
Notes
• The battery pack will gradually discharge over a long period of time, even if not in
use.
• If you leave the battery pack in the handset without charging it, the battery pack
will be completely discharged.
It may require several times of charging to recover its full capacity.
To obtain the best performance from battery
Caution
You are cautioned that any changes or modifications not expressly
approved in this manual could void your authority to operate this
equipment.
Privacy of communications may not be ensured when using this
phone.
Note
Owner’s Record
Battery duration
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for
help.
Do not place the handset on the base unit after each call. The battery works
best if the handset is returned to the base unit after two or three calls.
However, do not leave the handset off the base unit for a long period of
time as this will completely discharge the battery pack.
For the customers in the USA
The TALK/BATT LOW lamp lights up.
Press (SPEED DIAL).
Enter the desired speed dialing number ((0) to (9)).
The phone number stored in the speed dialing number will be
dialed.
Setting the ringer type
You can select a ringer type from four types.
1 Press (PGM).
2 Press (#).
3 Press
a number button, (1) to (4),
to select a ringer type.
Note
Battery life may vary depending on usage condition and ambient temperature.
4 Press (PGM).
Making and receiving calls
Making calls
1 Pick up the handset from the base
unit.
2 Press (TALK/FLASH).
TALK/BATT
LOW lamp
TALK/BATT LOW lamp lights up,
then you’ll hear a dial tone. If you
hear beeps, move closer to the base
unit.
(CHANNEL)
3 Dial the phone number.
4 When you’re done talking, press
VOL
switch
(OFF) or replace the handset on
the base unit.
The TALK/BATT LOW lamp goes
off.
The cordless telephone operates at a frequency that may cause
interference to nearby TVs and VCRs; the base unit should not be
placed near or on the top of a TV or VCR; and, if interference is
experienced, moving the cordless telephone farther away from the
TV or VCR will often reduce or eliminate the interference.
Receiving calls
Choose the best location
1 When you hear the phone ring;
(REDIAL/PAUSE)
(*TONE)
Away from noise sources such as a
window by a street with heavy traffic
Away from heat sources, such as
radiators, airducts, and sunlight
Away from a microwave oven
Away from excessive
moisture, extremely
low temperatures,
dust, mechanical
vibration, or shock
2
3
Press (TALK/FLASH).
If the battery lasts only a few minutes even after 10 hours of charging, the
usable life of the battery has expired and needs replacement. Contact your
local Sony authorized dealer or service center, and ask for a Sony BP-T18
rechargeable battery pack.
Caution
Away from television
sets and other
electronic equipment
1
When to purchase a new battery pack
Sony Corporation  2001 Printed in China
Setting up the phone
Making calls with speed dialing
2
• Press (TALK/FLASH) (or any key except (OFF)) .
or
• Pick up the handset from the base unit when the handset is
placed on the base unit.
The TALK/BATT LOW lamp lights up at the same time the
LINE lamp on the base unit lights up.
When you’re done talking, press (OFF) or replace the handset
on the base unit.
The TALK/BATT LOW and LINE lamps go off.
Turning off the ringer
1
2
3
4
Press (PGM).
Press (#).
Press (5).
Press (PGM).
The ringer on the handset is turned off.
To turn the ringer on again
Follow the instructions described in “Setting the ringer type.”
Checking the ringer type
1
2
3
Press (PGM).
4
Press (PGM).
Press (#).
Press (0).
The currently selected ringer sounds.
Note
If you hear no sound (only key beep), the ringer on the handset has been turned off.
Setting the base ringer
1 base
Press (MENU) until you hear “Set
ringer”.
“- -” blinks on the display.
2 on
Press (SELECT) to turn the ringer
or off.
3 Press
(TIME/SET).
The base ringer setting is
Additional tasks
Near a central location and
on a level surface
To
Do this
Select a better channel
Press (CHANNEL).
Adjust the handset
volume
Set the VOL switch to H (high), M (middle) or L
(low).
Switch to tone dialing
temporarily
Press (*TONE) while using the telephone after
you’re connected. The line remains in tone dialing
until disconnected.
Away from a personal
computer
Switch to another call
(“call waiting” service*)
Press (TALK/FLASH) to access the flash function.
Press (TALK/FLASH) again to return to the first
caller.
Away from another
cordless telephone
* You need to subscribe to this service from your telephone company.
Connect the base unit
If you want to hang the base unit on the wall, mount the unit first (see
“Mounting the base unit on the wall”).
Be sure to save the receipt and attach it to your WARRANTY card
when having your equipment repaired at an authorized Sony
service center.
3
When using your telephone equipment, basic safety precautions
should always be followed to reduce the risk of fire, electric shock
and injury to persons, including the following:
1. Do not use this product near water, for example, near a bath
tub, wash bowl, kitchen sink, or laundry tub, in a wet
basement, or near a swimming pool.
2. Avoid using a telephone (other than a cordless type) during an
electrical storm. There may be a remote risk of electric shock
from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of
the leak.
4. Use only the power cord and batteries indicated in this manual.
Do not dispose of batteries in a fire. They may explode. Check
with local codes for possible special disposal instructions.
SAVE THESE
INSTRUCTIONS
INFORMATION FOR FCC
REGURATION CLAIM
1. This equipment complies with Part 15 and Part 68 of the FCC
rules for the United States. On the bottom of this equipment is a
label that contains, among other information, the FCC
certification number and ringer equivalence number (REN) for
this equipment. If requested, this information must be provided
to the telephone company.
2. This equipment connect to nationwide telephone network
through a modular telephone jack which applicable certification
jack (connector) is USOC-RJ11C.
3. The FCC compliant telephone cord and modular plug is
provided with this equipment. This equipment is designed to
be connected to the telephone network or premises wiring
using a compatible modular jack that is part 68 compliant.
4. The REN is used to determine the quantity of devices which
may be connected to the telephone line. Excessive RENs on the
telephone line may result in the devices not ringing in response
to an incoming call. In most, but not all areas, the sum of the
REN’s should not exceed five (5.0). To be certain of the number
of devices that may be connected to a line, as determined by the
total RENs, contact the local telephone company.
5. If this equipment (SPP-A1050) causes harm to the telephone
network, the telephone company will notify you in advance
that temporary discontinuance of service may be required. But
if advance notice isn’t practical, the telephone company will
notify the customer as soon as possible. Also, you will be
advised of your right to file a complaint with the FCC if you
believe it is necessary.
6. The telephone company may make changes to it’s facilities,
equipment, operations or procedures that could affect the
operation of the equipment. If this happens the telephone
company will provide advance notice so you can make the
necessary modifications to maintain uninterrupted service.
7. If trouble is experienced with this equipment (SPP-A1050), for
repair or warranty information, please contact Sony Direct
Response Center: Tel 1-800-222-7669. If the equipment is
causing harm to the telephone network, the telephone company
may request that you disconnect the equipment until the
problem is resolved.
8. All repairs will be performed by an authorized Sony service
station.
9. This equipment may not be used on coin service provided by
the Phone Company or Party Lines.
10. This equipment is hearing aid compatible.
4 Press
(PLAY/STOP) to exit the
menu set up mode.
Note
The base ringer is preset to on.
Locating the handset
You can page the handset from the base unit. Note that you cannot page if
the handset is in use.
Press (HANDSET LOCATOR).
The handset rings for about
one minute.
If the handset battery becomes weak during a call
To stop ringing, press
(OFF) on the handset.
You hear a beep and the TALK/BATT LOW lamp on the handset flashes.
The call will disconnect soon. Replace the handset on the base unit to
charge.
For the customers in the USA
IMPORTANT SAFETY
INSTRUCTIONS
Notes
• Before dialing, make sure you can hear the dial tone, otherwise you cannnot dail
correctly.
• When the TALK/BATT LOW lamp lights up by pressing (TALK/FLASH) , the LINE
lamp on the base unit lights up simultaneously.
announced.
For optimum performance, charge the battery for a full
10 hours.
Hook the cord.
Note that during the first 10 - 15 minutes of charging, the phone will be
inactive, i.e., unable to make or receive a call.
After this initial 10 - 15 minutes, you may be able to use the phone, but the
battery duration will be very short; thus it is recommended that you fully
charge the battery before the next usage.
To AC outlet
To DC IN 9V
2 AC power adaptor
(supplied AC-T130)
1
To LINE
1 Connect
the telephone line cord to the LINE jack and to a
telephone outlet.
2 Connect
the AC power adaptor to the DC IN 9V jack and to an
AC outlet.
3 Raise the antenna. Make sure it points towards the ceiling.
Notes
• Use only the supplied AC-T130 AC power adaptor. Do not
use any other AC power adaptor.
• Connect the AC power adaptor to a continuous power
supply.
• Place the base unit close to the AC outlet so that you can
unplug the AC power adaptor easily.
Tip
If your telephone outlet is not modular, contact your telephone
service company for assistance.
Polarity of the plug
Modular
Choosing the dialing mode
For the telephone to work properly, select an appropriate dialing mode
(tone or pulse). The default setting is tone.
1
Press (TALK/FLASH).
The TALK/BATT LOW lamp lights up.
2
Press (REDIAL/PAUSE) to redial the number last dialed.
Note
If the number last dialed exceeds 16 digits, only the first 16 digits are dialed.
Storing phone numbers
1 Press (PGM).
The TALK/BATT LOW lamp
flashes.
2 Press
one of the dialing buttons
((0) to (9)) for the phone number
3 Enter the phone number you want
to store.
You can enter up to 16 digits,
including a tone and a pause, each
of which is counted as one digit.
2 Press (*TONE).
3 Press
(1) for pulse dialing or (2)
for tone dialing.
4 Press (PGM).
You hear a confirmation beep and
the TALK/BATT LOW lamp goes
off.
Note
Do not allow more than 20 seconds to elapse between each step of the procedure.
Prepare the battery pack
Charge the battery pack for more than 10 hours before you start using your
phone.
1 Slide open the battery compartment lid of the handset.
2 Connect
the battery connector with correct polarity (black wire
goes on right side and red wire goes on left).
3 Insert the battery pack, and close the lid.
4 Place the handset on the base unit.
The CHARGE lamp lights up when the handset is properly
seated on the charge terminals of the base unit. Charge the
battery pack for more than 10 hours so that the battery is fully
charged. The CHARGE lamp remains lit even after charging is
completed.
Red
3
2 select
Press (SELECT) repeatedly to
the day of the week.
3 Press (TIME/SET).
The day is set and the hour is
announced.
4 select
Press (SELECT) repeatedly to
the hour.
5 Press (TIME/SET).
The hour is set and the minute is
announced.
to be stored.
The TALK/BATT LOW lamp
flashes.
BP-T18
Black
Setting the time and day of the week
“- -” blinks on the display.
You can dial with a touch of a few buttons by storing a phone number on a
dialing button. You can store up to 10 different phone numbers.
TALK/BATT
LOW lamp
Setting up the answering
machine
1 hear
Press (MENU) repeatedly until you
“Set day and time”.
Speed dialing
1 Press (PGM).
2
Tips
• You can page the handset even when “RINGER” is set to “RINGER OFF”.
• To stop ringing at the base unit, press (HANDSET LOCATOR).
Redialing
Telephone line cord (supplied)
To telephone outlet
1
Note
If a call comes in paging, paging is cancelled.
4
CHARGE lamp
6 select
Press (SELECT) repeatedly to
the minute.
7 Press (TIME/SET).
The day and time you just entered
is announced and the clock
restarts.
4 Press (PGM).
(SPEED DIAL)
(REDIAL/PAUSE)
You’ll hear a confirmation beep,
and the number is stored. The
TALK/BATT LOW lamp goes off.
Notes
• In step 3, if you don’t enter the phone number,
the previously stored number will be erased.
• Do not allow more than 30 seconds to elapse
between each step of the procedure.
• Before storing phone numbers, make sure the
handset is not in use.
Tips
• If you enter a wrong number, start from the beginning.
• Use the supplied directory to write down what you stored on the speed dialing
numbers.
8 Press
(PLAY/STOP) to exit the
menu setup mode.
You will hear a long confirmation
beep.
Notes
• Press and hold (SELECT) to increase the minute setting by 10.
• The time and day are preset to Monday, 12:00 AM.
• “CL” flashes when the day and time is cleared or delayed due to a power
interruption, or when you connect the base unit to the AC outlet for the first time.
Tip
All the mailbox buttons ((MAILBOX 1), (MAILBOX 2) and (MAILBOX 3)) work as the
(PLAY/STOP) button; press any of the three in this case.
To store the previous number dialed
Press (REDIAL/PAUSE) directly after step 2, then go to step 4.
To hear the current time
To store a number to be dialed via Private Branch
Exchange (PBX)
Press (TIME/SET).
The current time setting is announced.
Before entering a phone number in step 3, do as follows:
1
2
Enter the outside line access digit (e.g. 9).
Press (REDIAL/PAUSE).
To change a stored number
To store a new number, follow the instructions described previously.
(continued)
When the memory is full
Recording the greeting
You can record your own greeting for the “normal” and “announcement
only” modes (see “Selecting the Announcement Only Mode”).
1 out-going
Press (MENU) repeatedly until “Set
message” is announced.
“- -” blinks on the display.
(ERASE)
2 Press (REC/MEMO).
“Now recording” is announced
and a long beep sounds.
3 Speak
into the base unit microphone
(MIC). The display starts counting.
You can record up to 90 seconds.
4 To
stop recording, press
(PLAY/STOP).
MIC
The total recording time of this answering machine is approximately 15
minutes (including the greeting, messages, and memo).
When the remaining recording time becomes less than 30 seconds, “F”
flashes on the display and the answering machine goes into the memory
full status.
In this status, the answering machine will not answer a call until after 10
rings even if the answering function is on.
To avoid this erase unnecessary messages (see “Erasing messages”). You
can also erase the messages from an outside phone (see “Picking up new
messages”).
(REPEAT/SLOW)
(PLAY/STOP) (SKIP/QUICK)
To
Do this
Stop playback
Press a mailbox button ((MAILBOX 1), (MAILBOX 2)
or (MAILBOX 3)).
Repeat the current message
Press (REPEAT/SLOW) during play back.
Skip the current message
Press (SKIP/QUICK).
Go back to the previous
message
Press (REPEAT/SLOW) within the first two seconds
of the current message playback.
Play back slowly
Press and hold (REPEAT/SLOW) during play back.
Release (REPEAT/SLOW) to return to normal.
Play back quickly
Press and hold (SKIP/QUICK) during play back.
Release (SKIP/QUICK) to return to normal.
1
2
Press (MENU) repeatedly until “Set out-going message” is
announced.
Press (ERASE).
Notes
• You can also erase the greeting during playback.
• If you have erased your own greeting, the prerecorded greeting will be assigned
automatically.
Prerecorded greetings
Normal mode:
“Hello, I’m unable to answer your call right
now. Please leave your name, number and
message after the tone.”
To adjust the speaker
volume, press
(VOLUME)(+) or (-).
Press (SELECT) repeatedly to select a ring duration (2, 4, 6, or
Toll Saver).
To answer after 2 rings, select “2”.
To answer after 4 rings, select “4”.
To answer after 6 rings, select “6”.
Select “Toll Saver” to answer after 2 rings when there are new
messages, and 4 rings where there are no new messages.
3
Press (TIME/SET).
The ring duration setting is announced.
4
Press (PLAY/STOP) to exit the menu setup mode.
You have the option of having a beep tell you if you have received any new
incoming messages.
1 Press (MENU) repeatedly until you
(VOLUME)
hear “Set audible message alert”.
“- -” blinks on the display.
4 Press (PLAY/STOP) to stop
recording.
The message number on the
display increases by one.
Operating from an outside
phone
To operate the answering machine from a touch-tone phone while you are
away from home, you need to set the remote ID code (security code).
(VOLUME)
Tip
There are 8 steps for the volume level (1 to 8). The volume level is preset to 5.
Erasing messages
1 Press and hold (ERASE) for more
than two seconds.
2 Press
a button for the mailbox you
want to erase ((MAILBOX 1),
(MAILBOX 2) or (MAILBOX 3)).
You will hear a long confirmation
beep and all “old” messages in the
selected mailbox are erased.
message alert on or off.
3 Press (TIME/SET).
The setting is announced.
4 Press (PLAY/STOP) to exit the
Note
Press and hold (SELECT) to increase the remote ID code (security code) by 10.
Call your telephone number from a touch-tone phone.
When you hear the greeting, press (#) and enter your remote
ID code (security code).
You will hear a confirmation beep.
The number of new messages will be announced.
Press the keys in the “Table of control codes” below for the
desired operation command.
When you are finished, disconnect the line.
Notes
• Do not let two seconds elapse between each digit of the remote ID code (security
code) and the control code.
• If you did not turn on the answering machine, your phone answers automatically
after 10 rings.
• If the message recording memory runs out, the answering machine turns off
automatically. “Memory full. Please enter your security code” is announced.
• If you enter wrong remote ID code (security code) three times, the line will
disconnect.
• If no keys are pressed within 20 seconds, the line will disconnect.
Message counter
(ANSWER ON/OFF)
Mailbox usage
This phone offers you three voice mailboxes, providing a convenient way to
share the mailbox feature with other members of your household or
business.
When a caller calls
To turn off the answering function
Press (ANSWER ON/OFF) on the base unit.
The ANSWER ON/OFF button goes off.
Note
The answering function is preset to on.
Tip
The answering machine will automatically answer a call after 10 rings, even if the
answering function is off and announces “Please enter your security code” to prompt
the caller to turn on the answering function.
You cannot store a speed
dialing number.
• Make sure you follow the procedure in storing the
number correctly.
• Replace the handset to the base unit for a while.
You cannot make a speed
dialing call.
• You pressed the number button to which no
phone number has been stored.
Speed dialing is incorrect.
• Store a correct number.
The clock is incorrect.
• There was a power interruption. Reset the time.
The phone does not
accept your remote ID
code (security code).
• Make sure you call from a touch-tone phone.
• Make sure the remote ID code (security code) is
correct.
• Make sure you entered the remote ID code
(security code) within two seconds after you‘ve
entered (#).
(*)(5) Press to access simple voice menu.
Press again to access advanced voice
menu.
Record a memo
(*)(8) Select the mailbox by entering “1”, “2”
or “3”.
Erase individual messages
(#)(9) Press during play back
Turn answering machine on/off (#)(0) Turns the system on/off. “Answer
machine on” or “Answer machine off”
is announced.
Mounting the base unit on the
wall
Hang-up tab
• You entered wrong remote ID codes (security
The line is disconnected
codes) three times.
when you call your phone
from a touch-tone phone.
The CHARGE lamp does
not light up when you
place the handset to
charge.
• Wipe the charge terminals of the base unit and the
handset with a soft cloth for better contact of the
charge terminals.
• Make sure the handset is placed on the base unit
properly.
The battery duration is
short.
• The battery pack was charged less than 10 hours
(due to power failure, etc.).
• The usage life of the battery has expired and
needs replacement.
Message counter
The message counter on the base unit shows the following information.
1 Raise the hang-up tab.
2 Plug the telephone line cord to the LINE
When the counter shows It means
Flashing number
Number of messages not yet played back.
CL
Flashes when the day and time is cleared or delayed
due to a power interruption, or when you connect the
base unit to the AC outlet for the first time. Reset the
time correctly.
3 Attach the wall bracket to the center of
A
The announcement only mode is selected.
F
The recording area is full. Erase unnecessary messages.
4 Plug the telephone line cord to the
Specification
jack and the AC power adaptor to the
DC IN 9V jack, and hook the cords.
4 Press (PLAY/STOP) to exit the
2
Telephone
line cord
the base unit.
Align the f marks of the wall bracket
with those of the base unit.
telephone outlet, and hook the base unit
to the wall plate.
AC power
adaptor
cord
3
5 Plug the AC power adaptor to an AC
outlet. Then raise the antenna so that it
points towards the ceiling.
General
Frequency band
Operating channel
Dial signal
Supplied accessories
902 - 928 MHz
30 channels
Tone, 10 PPS (pulse) selectable
AC power adaptor AC-T130
Telephone line cord (1)
Rechargeable battery pack BP-T18
Directories (1 sheet)
Wall bracket (1)
Handset
4,5
Power source
Battery life
Wall
plate
To answer the call
Notes
• Press (VOLUME)(+) or (-) to adjust the speaker volume. If the speaker volume is
set at its minimum level, you will not be able to hear incoming calls.
• The answering machine will stop automatically when the handset or a parallel phone
is picked up. If the answering machine does not stop, press either (PLAY/STOP) on
the base unit, or (*)(0) on the handset or parallel phone.
The recording will remain as a new message.
• The battery is weak. Charge the battery for more
than 10 hours.
• The caller’s message is too long.
• The caller’s voice is too low. The unit disconnects
the line when it detects seven seconds of silence.
1
Press (TALK) on the handset.
You hear a beep every
three seconds during the
conversation.
The caller’s message is
interrupted.
The setting is announced.
Notes
• If four minutes have passed while recording the incoming message, the line will be
disconnected automatically.
• If the message is shorter than two seconds, it will not be recorded.
• Move the handset closer to the base unit.
• Place the base unit away from noise sources.
• Press (CHANNEL) for a channel that gives better
reception.
• Adjust the speaker volume.
You can set the answering machine to play the greeting without recording
incoming messages (announcement only mode). You might want to select
this mode when, for example, you expect to be away for a while and you
cannot pick up messages.
The message will be recorded, but to hear it you will need to play back the
message (see “Playing back messages”).
You hear interference
during conversation.
Notes
(*)(7) “Now recording” is announced.
(#)(7) Review your greeting
You can screen calls by leaving the answering machine on while you are at
home. When a call is answered, you can hear the message being recorded
through the base unit. You can decide either to continue recording or to
answer the call.
• Make sure the telephone line cord is securely
connected to the telephone outlet.
• Make sure the ringer is turned on.
No sound from the
speaker of the base unit.
Key
Check greeting
The caller can choose one of the two ways to leave a message:
• If calling from a touch-tone phone, the caller select a mailbox by pressing
(*)(1) (MAILBOX 1), (*)(2) (MAILBOX 2) or (*)(3) (MAILBOX 3)
while the caller hears the greeting. The greeting stops and a beep will
sound, then the caller can start recording a message
• Wait until the greeting finishes, then start recording a message. When
the caller does not select a mailbox, the message is automatically
recorded to MAILBOX 1.
The base unit does not
ring.
• The remaining recording time is less than 30 seconds
or 99 messages were recorded. The answering
machine becomes “Memory full” status and does not
record messages. Erase messages.
• The message is less than two seconds. The
answering machine does not record messages less
than two seconds in length.
(#)(6) Press during play back to skip forward.
Screening calls
• Make sure the ringer is turned on.
• The battery may be weak. Charge the battery for
more than 10 hours.
• Make sure you have set up the base unit correctly.
• Move the handset closer to the base unit.
• Replace the handset to the base unit for a while to
reset the random security code.
Message is not recorded.
Record greeting
Notes
• To activate announcement only mode, you have to turn on the answering machine.
• The announcement only mode is preset to off.
The handset does not
ring.
Table of control codes
Skip forward
menu setup mode. The display
shows “A” when the answering
machine is set to the
announcement only mode.
The phone does not connect • Make sure the dialing mode is set correctly.
at all, even though the
number you dial is correct.
The handset does not ring • The handset may be engaged in conversation.
• The battery may have little or no power. Charge
when calling from the
the battery for more than 10 hours.
base unit.
• Replace the handset to the base unit for a while.
• Raise the antenna of the base unit vertically.
• Place the base unit away from noise sources.
Selecting the Announcement
Only Mode
Press (ANSWER ON/OFF) on
the base unit.
The ANSWER ON/OFF
button lights up.
• Make sure you have set up the base unit correctly.
• Move the handset closer to the base unit.
• Replace the handset to the base unit for a while to
reset the random security code.
• Make sure the telephone line cord is securely
connected to the telephone outlet.
• Make sure the battery is fully charged.
Tips
• Press (*)(0) on the touch-tone keypad or (PLAY/STOP) on the base unit to
disconnect the line.
• Cut off the Remote Control Card and carry it with you to see how to operate from
an outside phone.
(#)(5) Stops every function
Turning on the answering function
Solution
The phone does not redial • Make sure the last dialed number is really the one
you want to dial.
correctly.
Stop operation
3 Press (TIME/SET).
Caution: Do not handle damaged or leaking nickel-cadmium batteries.
You hear no dial tone.
Play back messages in MAILBOX 3 (#)(3) Plays back from the first new message.
(#)(4) Press during play back to repeat a
Repeat/skip backward
message. To skip backward, press
within two seconds after the current
message starts.
announcement only mode on or
off.
Call toll free number: 1-800-822-8837 (United States and Canada only)
4 Press (PLAY/STOP) to exit the
Note
The display shows the total number of “new” (i.e. unreviewed) messages. Therefore,
the display is reset to “0” when you have played back all new messages, whether they
have been erased or not. Be sure to erase unnecessary messages before the memory
becomes full.
1 Press (MENU) repeatedly until you
hear “Set announce only”.
2 Press (SELECT) to set the
Nickel-Cadmium batteries are recyclable. You can help
preserve our environment by returning your unwanted
batteries to your nearest point for collection, recycling or
proper disposal.
Note: In some areas the disposal of nickel-cadmium
batteries in household or business trash may be
prohibited.
Problem
You hear four short error
beeps when you press
(TALK/FLASH).
Press (ERASE) while playing back the message that you want to erase.
Notes
• When the audible message alert is turned on, you will hear a beep every 10 seconds
if there are any new messages.
• To stop the beep, press any button related to the answering machine function or
(VOLUME)(+)/(-).
• The audible message alert is preset to off.
RECYCLING NICKEL-CADMIUM BATTERIES
3 Press (TIME/SET) to confirm your
Play back messages in MAILBOX 1 (#)(1) Plays back from the first new message.
Play back messages in MAILBOX 2 (#)(2) Plays back from the first new message.
menu setup mode.
For the customers in the USA
Should any problem persist after you have made these checks, consult your
nearest authorized Sony dealer.
menu setup mode.
Get help
2 Press (SELECT) to set the audible
• During a power interruption, you cannot make or receive calls, and you
cannot use the answering machine.
2 Press (SELECT) to change the
choice.
The new remote ID code (security
code) is announced.
To
To erase individual messages
On power failure
Troubleshooting
remote ID code (security code)
setting.
4
On battery pack
• Store the battery pack at a temperature between 41°F (5°C) and 95°F
(35°C) for best performance.
• If you do not use the handset for a long period of time, remove the
battery pack after charging for more than 10 hours. This maintains
battery life.
1 Press (MENU) repeatedly until you
hear “Set security code”.
3
Notes on power sources
RBRC (Rechargeable Battery Recycling Corporation) advises you about spent battery
collection by the following phone number.
Setting the remote ID code (security code)
1
2
Notes
• When the number of rings is set to “Toll Saver”, the phone answers after 2 rings if
new messages are recorded. If no new message are recorded, it answers after 4
rings. When you hear 3 rings, you will know that there are no new messages. You
can save the toll for the call when you pick up messages from an outside phone.
• The number of rings is preset to 4 rings.
Setting the audible message alert
microphone (MIC) to record your
message.
A memo can be up to four minutes
in length.
MIC
Picking up new messages
Notes
• When you have reached the minimum or maximum volume level, you will hear
three short beeps.
• You cannot adjust the speaker volume while the phone is ringing.
If you have any questions or problems concerning your phone, please
consult your nearest Sony dealer.
3 Speak into the base unit
Adjusting the speaker volume
You can select the number of times the phone rings before it answers to take
a message.
There are four modes: 2, 4, 6, and Toll Saver.
2
“Now recording” is announced
and counting starts.
Tips
• If there are no new messages, all the previously reviewed messages are played back.
• The messages are saved even after a power failure.
Setting the number of rings
Press (MENU) repeatedly until you hear “Set number of rings”.
“- -” blinks on the display.
((MAILBOX 1), (MAILBOX 2) or
(MAILBOX 3)) to which you want to
leave the message.
Notes
• If a call comes in, the play back will stop.
• A time and day stamp is announced after each message.
Announcement only mode: “Hello, I’m unable to answer your call right
now. Please call again. Thank you.”
1
1 Press (REC/MEMO).
2 Press a mailbox button
Notes
• If the memory becomes full, the answering machine will stop recording.
• “Memory full” is announced if no recording space is available when you press
(REC/MEMO).
• If your message is shorter than two seconds, the recording will be canceled.
• The display flashes “99” if you record a memo for more than 99 seconds.
• If a call comes in during recording, the recording will be stopped.
Additional tasks when playing back messages
To erase the greeting
• Clean the cabinets with a soft cloth slightly moistened with water or a
mild detergent solution. Do not use any type of abrasive pad, scouring
powder or solvent such as alcohol or benzine as they may damage the
finish of the cabinet.
• If the charge terminals of the base unit and handset are soiled, wipe them
with a soft cloth.
Press a mailbox button
((MAILBOX 1), (MAILBOX 2)
or (MAILBOX 3)) to play
back new messages in the
selected mailbox.
(ERASE)
Press (MENU) repeatedly until “Set out-going message” is announced.
Then press (PLAY/STOP) to play back the greeting.
Record a new greeting by following the instructions on the previous page.
The new greeting replaces the old one.
You can leave messages for other users of the unit.
If there are new messages, the display flashes the number of new messages.
You will hear beeps if the audible message alert setting is on (see “Setting the
audible message alert”).
To check the greeting
To change the greeting
Maintenance
Playing back messages
Your greeting replays
automatically.
Notes
• If you do not record your own greeting, the prerecorded greeting will be assigned
automatically.
• If your greeting is less than two seconds, the greeting is not recorded. The
prerecorded greeting will be assigned automatically.
• If a call comes in during recording, recording stops automatically.
• If 90 seconds have passed or memory becomes full in step 3, recording stops
automatically.
• “Memory full” is announced if no recording space is available when you press
(REC/MEMO). Erase unnecessary messages (see “Erasing messages”).
Tip
To record a greeting for the “announcement only” mode, select the announcement
only mode first (see “Selecting the Announcement Only Mode”), then follow the
instructions above. Otherwise, the normal greeting will be recorded.
Recording a memo message
Dimensions
Telephone
line cord
Wall
bracket
Mass
Base unit
Power source
Battery charging time
Dimensions
AC power adaptor
AC outlet
Tip
To remove the wall bracket, press the lower tabs.
Rechargeable battery pack BP-T18
Standby: Approx. 6 days
Talk: Approx. 7 hours
Approx. 56 x 43 x 178 mm (w/h/d), antenna excluded
(approx. 2 1⁄4 x 1 3⁄4 x 7 1⁄8 inches)
Antenna: Approx. 32 mm (approx. 1 1⁄4 inches)
Approx. 220 g (approx. 7.7 oz), battery included
Mass
DC 9V from AC power adaptor AC-T130
Approx. 10 hours
Approx. 172 x 65 x 205 mm (w/h/d), antenna excluded
(approx. 6 7⁄8 x 2 5⁄8 x 8 1⁄8 inches)
Antenna: Approx. 153 mm (approx. 6 1⁄8 inches)
Approx. 500 g (approx. 1 lb 2 oz), wall bracket excluded
Answering machine
Maximum recording time
Greeting message
Incoming and Memo message
About 15 minutes, using incorporated IC
Up to 90 seconds per each
Up to 4 minutes per message
Design and specifications are subject to change without notice.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
