Steam oven
User Manual
2
www.electrolux.com
CONTENTS
1. SAFETY INFORMATION....................................................................................3
2. SAFETY INSTRUCTIONS..................................................................................4
3. PRODUCT DESCRIPTION................................................................................ 7
4. BEFORE FIRST USE......................................................................................... 7
5. DAILY USE......................................................................................................... 8
6. CLOCK FUNCTIONS....................................................................................... 10
7. USING THE ACCESSORIES........................................................................... 12
8. ADDITIONAL FUNCTIONS.............................................................................. 15
9. HINTS AND TIPS............................................................................................. 15
10. CARE AND CLEANING..................................................................................28
11. TROUBLESHOOTING....................................................................................32
12. INSTALLATION.............................................................................................. 33
13. ENERGY EFFICIENCY.................................................................................. 34
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can
be safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com/webselfservice
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
ENGLISH
1.
3
SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damages that are the
result of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
•
•
•
•
•
•
•
•
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away from the appliance unless continuously
supervised.
Children of less than 3 years of age should be kept
away from the appliance unless continuously
supervised.
Do not let children play with the appliance.
Keep all packaging away from children and dispose of
it appropriately.
Keep children and pets away from the appliance when
it operates or when it cools down. Accessible parts are
hot.
If the appliance has a child safety device, it should be
activated.
Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
•
Only a qualified person must install this appliance and
replace the cable.
4
www.electrolux.com
•
•
•
•
•
•
•
•
•
WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements.
Always use oven gloves to remove or put in
accessories or ovenware.
Before carrying out any maintenance, disconnect the
appliance from the power supply.
Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric
shock.
Do not use the appliance before installing it in the
built-in structure.
Do not use a steam cleaner to clean the appliance.
Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can
scratch the surface, which may result in shattering of
the glass.
If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
To remove the shelf supports first pull the front of the
shelf support and then the rear end away from the
side walls. Install the shelf supports in the opposite
sequence.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
•
•
•
•
Remove all the packaging.
Do not install or use a damaged
appliance.
Follow the installation instructions
supplied with the appliance.
Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
•
•
•
•
Do not pull the appliance by the
handle.
Keep the minimum distance from
other appliances and units.
Install the appliance in a safe and
suitable place that meets installation
requirements.
The appliance is equipped with an
electric cooling system. It must be
operated with the electric power
supply.
ENGLISH
2.2 Electrical connection
2.3 Use
WARNING!
Risk of fire and electric
shock.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
All electrical connections should be
made by a qualified electrician.
The appliance must be earthed.
Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
Always use a correctly installed
shockproof socket.
Do not use multi-plug adapters and
extension cables.
Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need to
be replaced, this must be carried out
by our Authorised Service Centre.
Do not let mains cables touch or
come near the appliance door or the
niche below the appliance, especially
when it operates or the door is hot.
The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
If the mains socket is loose, do not
connect the mains plug.
Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
The electrical installation must have
an isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation
device must have a contact opening
width of minimum 3 mm.
This appliance complies with the
E.E.C. Directives.
5
WARNING!
Risk of injury, burns and
electric shock or explosion.
•
•
•
•
•
•
•
•
•
•
•
•
This appliance is for household use
only.
Do not change the specification of this
appliance.
Make sure that the ventilation
openings are not blocked.
Do not let the appliance stay
unattended during operation.
Deactivate the appliance after each
use.
Be careful when you open the
appliance door while the appliance is
in operation. Hot air can release.
Do not operate the appliance with wet
hands or when it has contact with
water.
Do not apply pressure on the open
door.
Do not use the appliance as a work
surface or as a storage surface.
Open the appliance door carefully.
The use of ingredients with alcohol
can cause a mixture of alcohol and
air.
Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
WARNING!
Risk of damage to the
appliance.
•
To prevent damage or discoloration to
the enamel:
– do not put ovenware or other
objects in the appliance directly
on the bottom.
– do not put aluminium foil directly
on the bottom of cavity of the
appliance.
– do not put water directly into the
hot appliance.
– do not keep moist dishes and
food in the appliance after you
finish the cooking.
– be careful when you remove or
install the accessories.
6
www.electrolux.com
•
•
•
•
•
Discoloration of the enamel or
stainless steel has no effect on the
performance of the appliance.
Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
This appliance is for cooking
purposes only. It must not be used for
other purposes, for example room
heating.
Always cook with the oven door
closed.
If the appliance is installed behind a
furniture panel (e.g. a door) make
sure the door is never closed when
the appliance is in operation. Heat
and moisture can build up behind a
closed furniture panel and cause
subsequent damage to the appliance,
the housing unit or the floor. Do not
close the furniture panel until the
appliance has cooled down
completely after use.
2.4 Steam Cooking
WARNING!
Risk of burns and damage to
the appliance.
•
Released Steam can cause burns:
– Do not open the appliance door
during the steam cooking
operation.
– Open the appliance door with
care after the steam cooking
operation.
2.5 Care and cleaning
WARNING!
Risk of injury, fire, or
damage to the appliance.
•
•
•
Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
Make sure the appliance is cold.
There is the risk that the glass panels
can break.
Replace immediately the door glass
panels when they are damaged.
•
•
•
•
•
Contact the Authorised Service
Centre.
Be careful when you remove the door
from the appliance. The door is
heavy!
Clean regularly the appliance to
prevent the deterioration of the
surface material.
Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use any abrasive products,
abrasive cleaning pads, solvents or
metal objects.
If you use an oven spray, follow the
safety instruction on it's packaging.
Do not clean the catalytic enamel (if
applicable) with any kind of detergent.
2.6 Internal lighting
WARNING!
Risk of electric shock.
•
•
•
The type of light bulb or halogen lamp
used for this appliance is for
household appliances only. Do not
use it for house lighting.
Before replacing the lamp, disconnect
the appliance from the power supply.
Only use lamps with the same
specifications.
2.7 Service
•
•
To repair the appliance contact an
Authorised Service Centre.
Use original spare parts only.
2.8 Disposal
WARNING!
Risk of injury or suffocation.
•
•
•
Disconnect the appliance from the
mains supply.
Cut off the mains electrical cable
close to the appliance and dispose of
it.
Remove the door catch to prevent
children or pets from becoming
trapped in the appliance.
ENGLISH
7
3. PRODUCT DESCRIPTION
3.1 General overview
1 2 3
4
5
6
7
8
9
17
5
16
4
10
3
11
2
12
1
15
14
13
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
3.2 Accessories
•
•
Wire shelf
For cookware, cake tins, roasts.
Baking tray
•
Control panel
Knob for the heating functions
Power lamp / symbol
Display
Control knob (for the temperature)
Temperature indicator / symbol
Water tank indicator
Water drawer
Heating element
Lamp
Fan
Cavity embossment - Aqua cleaning
container
Shelf support, removable
Draining pipe
Water outlet valve
Shelf positions
Steam inlet
For cakes and biscuits.
Grill- / Roasting pan
To bake and roast or as pan to collect
fat.
4. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
To set the Time of day refer
to "Clock functions" chapter.
4.1 Initial Cleaning
Remove all accessories and removable
shelf supports from the oven.
Refer to "Care and cleaning" chapter.
Clean the oven and the accessories
before the first use.
Put the accessories and the removable
shelf supports back to their initial
position.
4.2 Preheating
Preheat the empty oven before first use.
1. Set the function .Set the maximum
temperature.
2. Let the oven operate for 1 hour.
3. Set the function . Set the
maximum temperature.
4. Let the oven operate for 15 minutes.
5. Set the function . Set the
maximum temperature.
6. Let the oven operate for 15 minutes.
7. Turn off the oven and let it cool
down.
Accessories can become hotter than
usual. The oven can emit an odour and
8
www.electrolux.com
smoke. Make sure that the airflow in the
room is sufficient.
5. DAILY USE
WARNING!
Refer to Safety chapters.
Oven func‐
tion
5.1 Retractable knobs
To use the appliance press the knob.
The knob comes out.
5.2 Setting a heating function
Moist Fan
Baking
1. Turn the knob for the heating
functions to select a heating function.
2. Turn the control knob to select the
temperature.
The lamp turns on when the oven
operates.
3. To turn off the oven, turn the knob for
the heating functions to the off
position.
5.3 Heating functions
Oven func‐
tion
Application
The oven is off.
Off position
Light
True Fan +
Steam
To turn on the lamp
without a cooking func‐
tion.
To steam dishes. Use
this function to de‐
crease the length of the
cooking time and to pre‐
serve the vitamins and
nutrients in the food.
Select the function and
set the temperature be‐
tween 130 °C to 230 °C.
Bottom Heat
True Fan
Cooking
Application
This function is de‐
signed to save energy
during cooking. For the
cooking instructions re‐
fer to "Hints and tips"
chapter, Moist Fan Bak‐
ing. The oven door
should be closed during
cooking so that the
function is not interrup‐
ted and to ensure that
the oven operates with
the highest energy effi‐
ciency possible. When
you use this function,
the temperature in the
cavity may differ from
the set temperature.
The heating power may
be reduced. For general
energy saving recom‐
mendations refer to
"Energy Efficiency"
chapter, Energy Sav‐
ing.This function was
used to comply with the
energy efficiency class
according to EN
60350-1.
To bake cakes with
crispy bottom and to
preserve food.
To bake on up to three
shelf positions at the
same time and to dry
food.
Set the temperature 20
- 40 °C lower than for
Conventional Cooking.
ENGLISH
Oven func‐
tion
Application
Oven func‐
tion
To roast larger meat
joints or poultry with
Turbo Grilling bones on one shelf po‐
sition. To make gratins
and to brown.
Fast Grilling
To grill flat food in large
quantities and to toast
bread.
9
Application
To bake and roast food
on one shelf position.
Conventional Refer to "Care and
cleaning" chapter for
Cooking
(Top / Bottom more information about:
Heat) / Aqua Aqua Clean.
Clean
To bake pizza. To make
intensive browning and
Pizza Setting a crispy bottom.
5.4 Display
A
B
C
A. Clock functions
B. Timer
C. Clock function
5.5 Buttons
Button
Function
Description
MINUS
To set the time.
CLOCK
To set a clock function.
PLUS
To set the time.
5.6 Steam Cooking
Use only water. Do not use
filtered (demineralised) or
distilled water. Do not use
other liquids. Do not put
flammable or alcoholic
liquids into the water drawer.
1. Set the function .
2. Press the cover of the water drawer
to open it.
3. Fill the water drawer with water until
the Tank Full indicator is on.
The maximum capacity of the tank is
900 ml. It is sufficient for
approximately 55 - 60 minutes of
cooking.
4. Push the water drawer to its initial
position.
5. Set the temperature between 130 °C
and 230 °C.
Steam cooking gives good results
with this temperature range.
6. Empty the water tank after the steam
cooking is completed.
10
www.electrolux.com
Wait for at least 60 minutes after each
use of the steam function to prevent hot
water from exiting the water outlet valve.
CAUTION!
The appliance is hot. There
is a risk of burns. Be careful
when you empty the water
drawer.
1. Prepare the draining pipe (C),
included in the package with the user
manual. Put the connector (B) onto
one of the ends of the draining pipe.
2. Put the second end of the draining
pipe (C) into a container. Put it at a
lower position than the outlet valve
(A).
5.7 Tank empty indicator
The indicator
shows that the tank is
empty and must be refilled.
A
B
For more information refer to "Steam
Cooking".
C
5.8 Tank Full indicator
The indicator
shows that the oven is
prepared for steam cooking.
If you put too much water
into the tank, the safety
outlet moves the excess
water to the bottom of the
oven.
Remove the water with a
sponge or cloth.
5.9 Emptying the water tank
CAUTION!
Make sure that the oven is
cold before you start to
empty the water tank.
3. Open the oven door and put the
connector (B) into the outlet valve
(A).
4. Push the connector again and again
to empty the water tank.
The water may remain inside after
is on.
the Tank Empty indicator
Wait until the water flow from the
water outlet valve stops.
5. Remove the connector from the valve
when the water stops flowing.
Do not use the drained water
to fill the water tank again.
6. CLOCK FUNCTIONS
6.1 Clock functions table
Clock function
Application
TIME OF DAY
To set, change or check the time of day.
DURATION
To set how long the appliance operates.
END
To set when the appliance deactivates.
TIME DELAY
To combine DURATION and END function.
ENGLISH
Clock function
Application
MINUTE MIND‐
ER
To set countdown time. This function has no effect on
the operation of the appliance. You can set the MINUTE
MINDER at any time, also when the appliance is off.
6.2 Setting the time. Changing
the time
You must set the time before you
operate the oven.
flashes when you connect the
The
appliance to the electrical supply, when
there was a power cut or when the timer
is not set.
or
to set the correct
Press the
time.
After approximately five seconds, the
flashing stops and the display shows the
time of day you set.
To change the time of day press
again and again until
starts to flash.
6.3 Setting the DURATION
1. Set an oven function and
temperature.
2. Press
again and again until
starts to flash.
3. Press
time.
or
The display shows
to set the DURATION
.
4. When the time ends,
flashes and
an acoustic signal sounds. The
appliance deactivates automatically.
5. Press any button to stop the acoustic
signal.
6. Turn the knob for the oven functions
and the knob for the temperature to
the off position.
6.4 Setting the END
1. Set an oven function and
temperature.
again and again until
2. Press
starts to flash.
3. Press
or
The display shows
11
to set the time.
.
4. When the time ends,
flashes and
an acoustic signal sounds. The
appliance deactivates automatically.
5. Press any button to stop the signal.
6. Turn the knob for the oven functions
and the knob for the temperature to
the off position.
6.5 Setting the TIME DELAY
1. Set an oven function and
temperature.
again and again until
2. Press
starts to flash.
3. Press
or
DURATION.
4. Press
.
5. Press
END.
or
to set the time for
to set the time for
6. Press
to confirm.
Appliance turns on automatically later on,
works for the set DURATION time and
stops at the set END time. At the set time
an acoustic signal sounds.
7. The appliance deactivates
automatically. Press any button to
stop the signal.
8. Turn the knob for the oven functions
and the knob for the temperature to
the off position.
6.6 Setting the MINUTE
MINDER
1. Press
again and again until
starts to flash.
2. Press
or
to set the necessary
time.
The Minute Minder starts automatically
after 5 seconds.
3. When the set time ends, an acoustic
signal sounds. Press any button to
stop the acoustic signal.
4. Turn the knob for the oven functions
and the knob for the temperature to
the off position.
12
www.electrolux.com
6.7 Cancelling the clock
functions
1. Press the
again and again until
the necessary function indicator
starts to flash.
2. Press and hold .
The clock function goes out after some
seconds.
7. USING THE ACCESSORIES
WARNING!
Refer to Safety chapters.
7.1 Inserting the accessories
Wire shelf:
Push the shelf between the guide bars of
the shelf support and make sure that the
feet point down.
Small indentation at the top
increase safety. The
indentations are also anti-tip
devices. The high rim
around the shelf prevents
cookware from slipping of
the shelf.
7.2 Accessories for steam
cooking
Baking tray/ Deep pan:
Push the baking tray / deep pan between
the guide bars of the shelf support.
The steam kit accessories
are not supplied with the
oven. For more information,
please contact your local
supplier.
The dietary baking dish for steam
cooking functions
The dish consists of a glass bowl, a lid
with a hole for the injector tube (C) and a
steel grill to put at the bottom of the
baking dish.
Wire shelf and baking tray / deep pan
together:
Push the baking tray / deep pan between
the guide bars of the shelf support and
the wire shelf on the guide bars above.
ENGLISH
Glass bowl (A)
Injector for direct steam cooking (D)
Lid (B)
Steel grill (E)
The injector and the injector tube
•
Do not put the hot baking dish on
cold / wet surfaces.
•
Do not put cold liquids in the baking
dish when it is hot.
•
Do not use the baking dish on a hot
cooking surface.
C
D
"C" is the injector tube for steam cooking,
"D" is the injector for direct steam
cooking.
Injector tube (C)
13
14
www.electrolux.com
•
Do not clean the baking dish with
abrasives, scourers and powders.
Make sure that you do not crush the
injector tube or let it touch a heating
element on the top of the oven.
4. Set the oven for the steam cooking
function.
7.4 Direct steam cooking
7.3 Steam cooking in a dietary
baking dish
Put the food onto the steel grill in the
baking dish and put the lid on it.
1. Put the injector tube into the special
hole in the lid of the dietary baking
dish.
C
Put the food onto the steel grill in the
baking dish. Add some water.
CAUTION!
Do not use the lid of the
dish.
WARNING!
Be careful when you use the
injector when the oven
operates. Always use oven
gloves to touch the injector
when the oven is hot.
Always remove the injector
from the oven when you do
not use a steam function.
The injector tube is specially
made for cooking and does
not contain dangerous
materials.
1. Put the injector (D) into the injector
tube (C). Connect the other end into
the steam inlet.
2. Put the baking dish onto the second
shelf position from the bottom.
3. Put the other end of the injector tube
into the steam inlet.
ENGLISH
15
When you cook food such as chicken,
duck, turkey, kid or large fish, put the
injector (D) directly into the empty part of
the meat. Make sure that you do not
cause a blockage of the holes.
2. Put the baking dish onto the first or
second shelf position from the
bottom.
Make sure that you do not crush the
injector tube or let it touch a heating
element on the top of the oven.
3. Set the oven for the steam cooking
function.
For more information about steam
cooking, refer to the cooking tables for
steam cooking in the chapter "Hints and
Tips".
8. ADDITIONAL FUNCTIONS
8.1 Cooling fan
When the oven operates, the cooling fan
turns on automatically to keep the
surfaces of the oven cool. If you turn off
the oven, the cooling fan can continue to
operate until the oven cools down.
dangerous overheating. To prevent this,
the oven has a safety thermostat which
interrupts the power supply. The oven
turns on again automatically when the
temperature drops.
8.2 Safety thermostat
Incorrect operation of the oven or
defective components can cause
9. HINTS AND TIPS
WARNING!
Refer to Safety chapters.
The temperature and baking
times in the tables are
guidelines only. They
depend on the recipes and
the quality and quantity of
the ingredients used.
9.1 Cooking recommendations
The oven has five shelf positions.
Count the shelf positions from the bottom
of the oven floor.
Your oven may bake or roast differently
to the oven you had before. The below
tables provide you with the standard
settings for temperature, cooking time
and shelf position.
If you cannot find the settings for a
special recipe, look for the similar one.
The oven has a special system which
circulates the air and constantly recycles
the steam. With this system you can
cook in a steamy environment and keep
16
www.electrolux.com
the food soft inside and crusty outside. It
decreases the cooking time and energy
consumption.
Baking cakes
Do not open the oven door before 3/4 of
the set cooking time is up.
If you use two baking trays at the same
time, keep one empty level between
them.
Cooking meat and fish
Use a deep pan for very fatty food to
prevent the oven from stains that can be
permanent.
To prevent too much smoke in the oven
during roasting, add some water into the
deep pan. To prevent the smoke
condensation, add water each time after
it dries up.
Cooking times
Cooking times depend on the type of
food, its consistency, and volume.
Initially, monitor the performance when
you cook. Find the best settings (heat
setting, cooking time, etc.) for your
cookware, recipes and quantities when
you use this appliance.
Leave the meat for approximately 15
minutes before carving so that the juice
does not seep out.
9.2 True Fan + Steam
Cakes and pastries
Food
Tempera‐
ture (°C)
Time (min)
Shelf po‐ Comments
sition
Apple cake1)
160
60 - 80
2
In a 20 cm cake mould
Tarts
175
30 - 40
2
In a 26 cm cake mould
Fruit cake
160
80 - 90
2
In a 26 cm cake mould
Sponge cake
160
35 - 45
2
In a 26 cm cake mould
Panettone1)
150 - 160
70 - 100
2
In a 20 cm cake mould
Plum cake1)
160
40 - 50
2
In a bread tin
Small cakes
150 - 160
25 - 30
3 (2 and
4)
In a baking tray
Biscuits
150
20 - 35
3 (2 and
4)
In a baking tray
Sweet buns1)
180 - 200
12 - 20
2
In a baking tray
Brioches1)
180
15 - 20
3 (2 and
4)
In a baking tray
1) Preheat the oven for 10 minutes.
Bread and pizza
Preheat the oven for 10 minutes.
Use the baking tray.
ENGLISH
Food
Temper‐
ature
(°C)
White
bread,
2x 0.5
kg each
Rolls, 6
- 8, 0.5
kg
Time
(min)
Shelf
posi‐
tion
Food
Temper‐
ature
(°C)
Time
(min)
180 - 190 45 - 60
2
Pizza
200 - 220 20 - 30
190 - 210 20 - 30
2 (2
and 4)
Shelf
posi‐
tion
2
Flans
Prepare in the cake mould.
Food
Temperature (°C)
Time (min)
Shelf position
Vegetables filled
170 - 180
30 - 40
1
Lasagne
170 - 180
40 - 50
2
Potato gratin
160 - 170
50 - 60
1 (2 and 4)
Meat
Use the second shelf position.
Use the wire shelf.
Food
Tempera‐
ture (°C)
Time (min)
Time (min)
Chicken,
200
whole, 1 kg
55 - 65
Roast pork, 180
1 kg
90 - 110
Turkey,
170
whole, 4 kg
180 - 240
Veal, 1 kg
180
90 - 110
170 - 180
120 - 150
Roast beef
- rare, 1 kg
210
45 - 50
Duck,
whole, 2 2.5 kg
60 - 90
55 - 65
Rabbit, cut
in pieces
170 - 180
Roast beef 200
- medium, 1
kg
Roast beef 190
- well done,
1 kg
65 - 75
Food
Tempera‐
ture (°C)
Use the first shelf position.
Use the second shelf position.
Food
Tempera‐
ture (°C)
Time (min)
Lamb, leg,
1 kg
175
110 - 130
Food
Tempera‐
ture (°C)
Goose,
160 - 170
whole, 3 kg
Time (min)
150 - 200
Fish
Use the second shelf position.
17
18
www.electrolux.com
Food
Time (min)
Tomatoes
15
White asparagus
35 - 45
Green asparagus
25 - 35
Courgette slices
20 - 25
Carrots
35 - 40
Fennel
30 - 35
Kohlrabi
25 - 30
Preheat the oven for 10 minutes.
Pepper strips
20 - 25
Use the second shelf position.
Celery slices
30 - 35
Food
Tempera‐
ture (°C)
Time (min)
Trout, 3 - 4
fish, 1.5 kg
180
25 - 35
Tuna, 4 - 6
fillets, 1.2
kg
175
35 - 50
Hake
200
20 - 30
Steam reheating
Reheat your dish on the plate.
Time (min)
Meat
Use the second shelf position.
Casserole / 130
Gratin
15 - 25
Set the temperature to 150°C.
Pasta and
sauce
130
10 - 15
Side dishes 130
(e.g. rice,
potatoes,
pasta)
10 - 15
One-plate
dishes
130
10 - 15
Meat
130
10 - 15
Vegetables 130
10 - 15
Food
Tempera‐
ture (°C)
9.3 Cooking in the dietary
baking dish
Use the function:True Fan + Steam.
Vegetables
Use the second shelf position.
Set the temperature to 150°C.
Food
Time (min)
Broccoli florets
20 - 25
Aubergine
15 - 20
Cauliflower florets
25 - 30
Food
Time (min)
Cooked ham
55 - 65
Poached chicken
breast
25 - 35
Kasseler (smoked
loin of pork)
80 - 100
Fish
Use the second shelf position.
Set the temperature to 150°C.
Food
Time (min)
Trout
25 - 30
Salmon filet
25 - 30
Side dishes
Use the second shelf position.
Set the temperature to 150°C.
Food
Time (min)
Rice
35 - 40
Unpeeled pota‐
toes, medium
50 - 60
Boiled potatoes,
quartered
35 - 45
ENGLISH
Food
Time (min)
Polenta
40 - 45
19
9.4 Baking and roasting
Cakes
Food
Top / Bottom Heat
True Fan Cooking
Time
(min)
Com‐
ments
Tempera‐
ture (°C)
Shelf po‐
sition
Tempera‐ Shelf po‐
ture (°C)
sition
Whisked
recipes
170
2
160
3 (2 and
4)
45 - 60
In a cake
mould
Short‐
bread
dough
170
2
160
3 (2 and
4)
20 - 30
In a cake
mould
Buttermilk 170
cheese‐
cake
1
165
2
60 - 80
In a 26 cm
cake
mould
Apple
cake (Ap‐
ple pie)1)
170
2
160
2 (left and 80 - 100
right)
In two 20
cm cake
moulds on
a wire
shelf
Strudel
175
3
150
2
60 - 80
In a baking
tray
Jam-tart
170
2
165
2 (left and 30 - 40
right)
In a 26 cm
cake
mould
Sponge
cake
170
2
160
2
50 - 60
In a 26 cm
cake
mould
Christmas 160
cake /
Rich fruit
cake1)
2
150
2
90 - 120
In a 20 cm
cake
mould
Plum
cake1)
175
1
160
2
50 - 60
In a bread
tin
Small
cakes one level
170
3
140 - 150
3
20 - 30
In a baking
tray
-
140 - 150
2 and 4
25 - 35
In a baking
tray
Small
cakes two levels
20
www.electrolux.com
Food
Top / Bottom Heat
True Fan Cooking
Tempera‐
ture (°C)
Shelf po‐
sition
Tempera‐ Shelf po‐
ture (°C)
sition
Small
cakes three lev‐
els
-
-
140 - 150
1, 3 and 5 30 - 45
In a baking
tray
Biscuits /
pastry
stripes one level
140
3
140 - 150
3
30 - 35
In a baking
tray
Biscuits / pastry
stripes two levels
-
140 - 150
2 and 4
35 - 40
In a baking
tray
Biscuits /
pastry
stripes three lev‐
els
-
140 - 150
1, 3 and 5 35 - 45
In a baking
tray
Meringues 120
- one level
3
120
3
80 - 100
In a baking
tray
Merin‐
gues- two
levels1)
-
-
120
2 and 4
80 - 100
In a baking
tray
Buns1)
190
3
190
3
12 - 20
In a baking
tray
Eclairs one level
190
3
170
3
25 - 35
In a baking
tray
Eclairs two levels
-
170
2 and 4
35 - 45
In a baking
tray
Plate tarts 180
2
170
2
45 - 70
In a 20 cm
cake
mould
Rich fruit
cake
160
1
150
2
110 - 120
In a 24 cm
cake
mould
Victoria
sandwich
170
1
160
2 (left and 50 - 60
right)
-
1) Preheat the oven for 10 minutes.
Time
(min)
Com‐
ments
In a 20 cm
cake
mould
ENGLISH
21
Bread and pizza
Food
Top / Bottom Heat
True Fan Cooking
Tempera‐ Shelf po‐
ture (°C)
sition
Tempera‐ Shelf po‐
ture (°C)
sition
190
1
190
Rye bread 190
1
Bread
rolls 1)
190
Pizza1)
Scones1)
White
bread1)
Time
(min)
Com‐
ments
1
60 - 70
1-2
pieces,
500 gr per
piece
180
1
30 - 45
In a bread
tin
2
180
2 (2 and
4)
25 - 40
6 - 8 rolls
in a bak‐
ing tray
230 - 250
1
230 - 250
1
10 - 20
In a bak‐
ing tray or
a deep
pan
200
3
190
3
10 - 20
In a bak‐
ing tray
Time
(min)
Com‐
ments
1) Preheat the oven for 10 minutes.
Flans
Food
Top / Bottom Heat
True Fan Cooking
Tempera‐ Shelf po‐
ture (°C)
sition
Tempera‐ Shelf po‐
ture (°C)
sition
200
2
180
2
40 - 50
In a mould
Vegetable 200
flan
2
175
2
45 - 60
In a mould
Quiches1) 180
1
180
1
50 - 60
In a mould
Lasagne1) 180 - 190
2
180 - 190
2
25 - 40
In a mould
Cannello‐
ni1)
2
180 - 190
2
25 - 40
In a mould
Time
(min)
Com‐
ments
50 - 70
On a wire
shelf
Pasta flan
180 - 190
1) Preheat the oven for 10 minutes.
Meat
Food
Beef
Top / Bottom Heat
True Fan Cooking
Tempera‐ Shelf po‐
ture (°C)
sition
Tempera‐ Shelf po‐
ture (°C)
sition
200
190
2
2
22
www.electrolux.com
Food
Top / Bottom Heat
True Fan Cooking
Time
(min)
Com‐
ments
Tempera‐ Shelf po‐
ture (°C)
sition
Tempera‐ Shelf po‐
ture (°C)
sition
Pork
180
2
180
2
90 - 120
On a wire
shelf
Veal
190
2
175
2
90 - 120
On a wire
shelf
English
210
roast beef,
rare
2
200
2
50 - 60
On a wire
shelf
English
210
roast beef,
medium
2
200
2
60 - 70
On a wire
shelf
English
210
roast beef,
well done
2
200
2
70 - 75
On a wire
shelf
Shoulder
of pork
180
2
170
2
120 - 150
With rind
Shin of
pork
180
2
160
2
100 - 120
2 pieces
Lamb
190
2
175
2
110 - 130
Leg
Chicken
220
2
200
2
70 - 85
Whole
Turkey
180
2
160
2
210 - 240
Whole
Duck
175
2
220
2
120 - 150
Whole
Goose
175
2
160
1
150 - 200
Whole
Rabbit
190
2
175
2
60 - 80
Cut in
pieces
Hare
190
2
175
2
150 - 200
Cut in
pieces
Pheasant
190
2
175
2
90 - 120
Whole
Time
(min)
Com‐
ments
Fish
Food
Top / Bottom Heat
True Fan Cooking
Tempera‐ Shelf po‐
ture (°C)
sition
Tempera‐ Shelf po‐
ture (°C)
sition
190
2
175
2
40 - 55
3 - 4 fish
Tuna fish / 190
Salmon
2
175
2
35 - 60
4 - 6 fillets
Trout /
Sea
bream
ENGLISH
9.5 Grilling
Set the maximum temperature.
Preheat the oven for 3 minutes.
Use the fourth shelf position.
Food
Quantity
Time (min)
Pieces
Quantity
(kg)
1st side
2nd side
Fillet steaks
4
0.8
12 - 15
12 - 14
Beef steaks
4
0.6
10 - 12
6-8
Sausages
8
-
12 - 15
10 - 12
Pork chops
4
0.6
12 - 16
12 - 14
Chicken (cut in 2)
2
1
30 - 35
25 - 30
Kebabs
4
-
10 - 15
10 - 12
Breast of chicken
4
0.4
12 - 15
12 - 14
Hamburger
6
0.6
20 - 30
-
Fish fillet
4
0.4
12 - 14
10 - 12
Toasted sandwiches
4-6
-
5-7
-
Toast
4-6
-
2-4
2-3
9.6 Turbo Grilling
Pork
Use the first or the second shelf position.
Beef
Preheat the oven.
To calculate the roasting time multiple
the time given in the table below by the
centimetres of thickness of the fillet.
Food
Tempera‐
ture (°C)
Time (min)
Shoulder,
neck, ham
joint, 1 - 1.5
kg
160 - 180
90 - 120
Chop, spare 170 - 180
rib, 1 - 1.5
kg
60 - 90
5-6
Meat loaf,
0.75 - 1 kg
160 - 170
50 - 60
180 - 190
6-8
150 - 170
90 - 120
170 - 180
8 - 10
Pork knuck‐
le (precooked),
0.75 - 1 kg
Food
Tempera‐
ture (°C)
Time (min)
Roast beef
or fillet, rare
190 - 200
Roast beef
or fillet, me‐
dium
Roast beef
or fillet, well
done
23
24
www.electrolux.com
Veal
Fish (steamed)
Food
Tempera‐
ture (°C)
Time (min)
Food
Tempera‐
ture (°C)
Time (min)
Roast veal,
1 kg
160 - 180
90 - 120
Whole fish,
1 - 1.5 kg
210 - 220
40 - 60
Knuckle of
veal, 1.5 - 2
kg
160 - 180
120 - 150
Cover trays with grease proof paper or
baking parchment.
Lamb
Food
9.7 Drying - True Fan Cooking
Tempera‐
ture (°C)
Time (min)
Leg of lamb, 150 - 170
roast lamb,
1 - 1.5 kg
100 - 120
Saddle of
160 - 180
lamb, 1 - 1.5
kg
40 - 60
Poultry
Food
Tempera‐
ture (°C)
Time (min)
Poultry por‐
tions, 0.2 0.25 kg
each
200 - 220
30 - 50
Chicken,
half, 0.4 0.5 kg each
190 - 210
35 - 50
Chicken,
poulard, 1 1.5 kg
190 - 210
50 - 70
Duck, 1.5 2 kg
180 - 200
80 - 100
Goose, 3.5 - 160 - 180
5 kg
120 - 180
Turkey, 2.5 - 160 - 180
3.5 kg
120 - 150
Turkey, 4 - 6 140 - 160
kg
150 - 240
For a better result, stop the oven halfway
through the drying time, open the door
and let it cool down for one night to
complete the drying.
Vegetables
For one tray use the third shelf position.
For 2 trays use the first and fourth shelf
position.
Food
Tempera‐
ture (°C)
Time
(h)
Beans
60 - 70
6-8
Peppers
60 - 70
5-6
Vegetables for
soup
60 - 70
5-6
Mushrooms
50 - 60
6-8
Herbs
40 - 50
2-3
Fruit
Set the temperature to 60 - 70 °C.
For one tray use the third shelf position.
For 2 trays use the first and fourth shelf
position.
Food
Time (h)
Plums
8 - 10
Apricots
8 - 10
Apple slices
6-8
Pears
6-9
9.8 Moist Fan Baking recommended accessories
Use the dark and non-reflective tins and
containers. They have better heat
ENGLISH
25
absorption than the light colour and
reflective dishes.
Pizza pan
Baking dish
Flan base tin
Ramekins
Dark, non-reflective
28 cm diameter
Dark, non-reflective
26 cm diameter
Ceramic
8 cm diame‐
ter, 5 cm
height
Dark, non-reflective
28 cm diameter
9.9 Moist Fan Baking
For the best results follow suggestions
listed in the table below.
Food
Accessories
Temperature Shelf posi‐ Time (min)
(°C)
tion
Sweet rolls, 12
pieces
baking tray or dripping 175
pan
3
40 - 50
Rolls, 9 pieces
baking tray or dripping 180
pan
2
35 - 45
Pizza, frozen,
0.35 kg
wire shelf
180
2
45 - 55
Swiss roll
baking tray or dripping 170
pan
2
30 - 40
Brownie
baking tray or dripping 170
pan
2
45 - 50
Soufflè, 6
pieces
ceramic ramekins on
wire shelf
190
3
45 - 55
Sponge flan
base
flan base tin on wire
shelf
180
2
35 - 45
Victoria sand‐
wich
baking dish on wire
shelf
170
2
35 - 50
Poached fish,
0.3 kg
baking tray or dripping 180
pan
2
35 - 45
26
www.electrolux.com
Food
Accessories
Temperature Shelf posi‐ Time (min)
(°C)
tion
Whole fish, 0.2
kg
baking tray or dripping 180
pan
3
25 - 35
Fish fillet, 0.3 kg pizza pan on wire shelf 170
3
30 - 40
Poached meat,
0.25 kg
baking tray or dripping 180
pan
3
35 - 45
Shashlik, 0.5 kg baking tray or dripping 180
pan
3
40 - 50
Cookies, 16
pieces
baking tray or dripping 150
pan
2
30 - 45
Macaroons, 20
pieces
baking tray or dripping 180
pan
2
45 - 55
Muffins, 12
pieces
baking tray or dripping 170
pan
2
30 - 40
Savory pastry,
16 pieces
baking tray or dripping 170
pan
2
35 - 45
Short crust bis‐
cuits, 20 pieces
baking tray or dripping 150
pan
2
40 - 50
Tartlets, 8
pieces
baking tray or dripping 170
pan
2
30 - 40
Vegetables,
baking tray or dripping 180
poached, 0.4 kg pan
2
35 - 45
Vegetarian
omelette
pizza pan on wire shelf 180
3
35 - 45
Mediterranean
vegetables, 0.7
kg
baking tray or dripping 180
pan
4
35 - 45
9.10 Information for test
institutes
Tests according to IEC 60350-1.
Food
Function
Acces‐
sories
Small
cake
Conven‐
Baking
tional Cook‐ tray
ing
Shelf
posi‐
tion
Tem‐
pera‐
ture
(°C)
Time (min)
Comments
3
170
20 - 30
Put 20 small
cakes per one
baking tray.
ENGLISH
27
Food
Function
Acces‐
sories
Shelf
posi‐
tion
Tem‐
pera‐
ture
(°C)
Time (min)
Comments
Small
cake
True Fan
Cooking /
Fan Cook‐
ing
Baking
tray
3
150 160
20 - 35
Put 20 small
cakes per one
baking tray.
Small
cake
True Fan
Cooking /
Fan Cook‐
ing
Baking
tray
2 and
4
150 160
20 - 35
Put 20 small
cakes per one
baking tray.
Apple pie Conven‐
Wire
tional Cook‐ shelf
ing
2
180
70 - 90
Use 2 tins (20
cm diameter), di‐
agonally shifted.
Apple pie True Fan
Cooking /
Fan Cook‐
ing
Wire
shelf
2
160
70 - 90
Use 2 tins (20
cm diameter), di‐
agonally shifted.
Fatless‐
ponge
cake
Conven‐
Wire
tional Cook‐ shelf
ing
2
170
40 - 50
Use a cake
mould (26 cm di‐
ameter).
Preheat the oven
for 10 minutes.
Fatless‐
ponge
cake
True Fan
Cooking /
Fan Cook‐
ing
Wire
shelf
2
160
40 - 50
Use a cake
mould (26 cm di‐
ameter).
Preheat the oven
for 10 minutes.
Fatless‐
ponge
cake
True Fan
Cooking /
Fan Cook‐
ing
Wire
shelf
2 and
4
160
40 - 60
Use a cake
mould (26 cm di‐
ameter). Diago‐
nally shifted.
Preheat the oven
for 10 minutes.
Short
bread
True Fan
Cooking /
Fan Cook‐
ing
Baking
tray
3
140 150
20 - 40
-
Short
bread
True Fan
Cooking /
Fan Cook‐
ing
Baking
tray
2 and
4
140 150
25 - 45
-
Short
bread
Conven‐
Baking
tional Cook‐ tray
ing
3
140 150
25 - 45
-
28
www.electrolux.com
Food
Function
Acces‐
sories
Shelf
posi‐
tion
Tem‐
pera‐
ture
(°C)
Time (min)
Toast
4-6
pieces
Grilling
Wire
shelf
4
max.
2 - 3 minutes Preheat the oven
first side; 2 - 3 for 3 minutes.
minutes sec‐
ond side
Wire
4
shelf and
dripping
pan
max.
20 - 30
Beef bur‐ Grilling
ger
6 pieces,
0.6 kg
Comments
Put the wire shelf
on the fourth lev‐
el and the drip‐
ping pan on the
third level of the
oven. Turn the
food halfway
through the
cooking time.
Preheat the oven
for 3 minutes.
10. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
10.1 Notes on cleaning
Clean the front of the oven with a soft
cloth with warm water and a mild
cleaning agent.
To clean metal surfaces, use a dedicated
cleaning agent.
Clean the oven interior after each use.
Fat accumulation or other food remains
may result in a fire. The risk is higher for
the grill pan.
Clean all accessories after each use and
let them dry. Use a soft cloth with warm
water and a cleaning agent. Do not clean
the accessories in the dishwasher.
Clean stubborn stains with a special
oven cleaner.
If you have nonstick accessories, do not
clean them using aggressive agents,
sharp-edged objects or a dishwasher. It
can cause damage to the nonstick
coating.
Moisture can condense in the oven or on
the door glass panels. To decrease the
condensation, operate the oven for 10
minutes before cooking. Clean the
moisture from the cavity after each use.
10.2 Stainless steel or
aluminium ovens
Clean the oven door with a damp cloth or
sponge only. Dry it with a soft cloth.
Do not use steel wool, acids or abrasive
materials as they can damage the oven
surface. Clean the oven control panel
with the same precautions.
10.3 Cleaning the door gasket
Regularly do a check of the door gasket.
The door gasket is around the frame of
the oven cavity. Do not use the oven if
the door gasket is damaged. Contact an
Authorised Service Centre.
To clean the door gasket, refer to the
general information about cleaning.
ENGLISH
10.4 Removing the shelf
supports
To clean the oven, remove the shelf
supports.
WARNING!
Make sure that the oven
is cool before you touch
it. There is a risk of
burns.
CAUTION!
Be careful when you remove
the shelf supports.
1. Pull the front of the shelf support
away from the side wall.
29
5. Turn off the oven and let it cool
down.
6. When the oven is cool, clean it with a
soft cloth.
10.6 Cleaning the water tank
WARNING!
Do not put water into the
water tank during the
cleaning procedure.
During the cleaning
procedure, some water can
drip from the steam inlet
onto the cavity of the oven.
Put a dripping pan on the
shelf level directly below the
steam inlet to prevent water
from falling onto the bottom
of the oven cavity.
2. Pull the rear end of the shelf support
away from the side wall and remove
it.
1
2
Install the removed accessories in the
opposite sequence.
After some time, you can have lime
deposits in your oven. To prevent this,
clean the parts of the oven that generate
the steam. Empty the tank after each
steam cooking.
Types of water
10.5 Aqua Clean
•
This cleaning procedure uses humidity to
help remove remaining fat and food
particles from the oven.
•
1. Put 300 ml of water into the cavity
embossment at the bottom of the
oven.
2. Set the function: .
3. Set the temperature to 90 °C.
4. Let the oven operate for 30 minutes.
•
Soft water with low lime content recommended type. It decreases the
quantity of cleaning procedures.
Tap water - you can use it if your
domestic water supply has purifier or
water sweetener.
Hard water with high lime content it does not have an effect on the
performance of the oven but it
increases the quantity of cleaning
procedures.
30
www.electrolux.com
CALCIUM QUANTITY TABLE INDICATED FROM W.H.O. (World Health
Organization)
Calcium de‐
posit
Water hardness
(French de‐
grees)
(German de‐
grees)
0 - 60 mg/l
0-6
0-3
Sweet of soft
75 cycles - 2.5
months
60 - 120 mg/l
6 - 12
3-7
Medium hard‐
ness
50 cycles - 2
months
120 - 180 mg/l
12 - 18
8 - 10
Hard or calca‐
reous
40 cycles - 1.5
months
over 180 mg/l
over 18
over 10
Very hard
30 cycles - 1
month
1. Fill in the water tank with 850 ml of
water and 50 ml of citric acid (five
teaspoons). Turn off the oven and
wait for approximately 60 minutes.
2. Turn on the oven and set the
function: True Fan + Steam. Set the
temperature 230 °C. Turn off the
oven after 25 minutes and let it cool
down for 15 minutes.
3. Turn on the oven and set the
function: True Fan + Steam. Set the
temperature between 130 and 230
°C. Turn off the oven after 10
minutes.
Let it cool down and continue with the
removal of the tank contents. Refer to
"Daily Use" chapter, Emptying the water
tank.
4. Rinse the water tank and clean the
remaining lime residue in the oven
with a cloth.
5. Clean the drain pipe by hand in warm
water with soap. To prevent damage,
do not use acids, sprays or similar
cleaning agents.
10.7 Removing and installing
door
The oven door has two glass panels.
You can remove the oven door and the
internal glass panel to clean it. Read the
whole "Removing and installing door"
instruction before you remove the glass
panels.
Water classifi‐ Run decalcifi‐
cation
cation every
The oven door may close if
you try to remove the
internal glass panel before
you remove the oven door.
CAUTION!
Do not use the oven without
the internal glass panel.
1. Open the door fully and hold both
hinges.
2. Lift and turn the levers fully on both
hinges.
ENGLISH
31
sure the glass slides out of the
supports completely.
3. Close the oven door halfway to the
first opening position. Then lift and
pull forward and remove the door
from its seat.
8. Clean the glass panels with water
and soap. Dry the glass panels
carefully. Do not clean the glass
panels in the dishwasher.
When the cleaning is completed, install
the glass panel and the oven door.
The screen-printing zone must face the
inner side of the door. Make sure that
after the installation the surface of the
glass panel frame on the screen-printing
zones is not rough when you touch it.
When installed correctly the door trim
clicks.
Make sure that you install the internal
glass panel in the seats correctly.
A
10.8 Replacing the lamp
4. Put the door on a soft cloth on a
stable surface.
5. Hold the door trim (B) on the top
edge of the door at the two sides and
push inwards to release the clip seal.
2
B
1
6. Pull the door trim to the front to
remove it.
7. Hold the door glass panel by its top
edge and carefully pull it out. Make
WARNING!
Risk of electric shock.
The lamp can be hot.
1. Turn off the oven.
Wait until the oven is cooled down.
2. Disconnect the oven from the mains.
3. Put a cloth on the bottom of the
cavity.
CAUTION!
Always hold the halogen
lamp with a cloth to prevent
grease residue from burning
on the lamp.
32
www.electrolux.com
The back lamp
1. Turn the lamp glass cover to remove
it.
2. Clean the glass cover.
3. Replace the lamp with a suitable 300
°C heat-resistant lamp.
4. Install the glass cover.
11. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
11.1 What to do if...
Problem
Possible cause
Remedy
The oven does not heat
up.
The oven is deactivated.
Activate the oven.
The oven does not heat
up.
The clock is not set.
Set the clock.
The oven does not heat
up.
The necessary settings are Make sure that the settings
not set.
are correct.
The oven does not heat
up.
The fuse is blown.
Make sure that the fuse is
the cause of the malfunc‐
tion. If the fuse is blown
again and again, contact a
qualified electrician.
The display shows "12.00". There was a power cut.
Reset the clock.
The lamp does not oper‐
ate.
The lamp is defective.
Replace the lamp.
Steam and condensation
settle on the food and in
the cavity of the oven.
You left the dish in the
oven for too long.
Do not leave the dishes in
the oven for longer than 15
- 20 minutes after the
cooking process ends.
There is water inside the
oven.
There is too much water in
the tank.
Deactivate the oven and
wipe the water with a cloth
or sponge.
The indicator "Tank Full"
There is not enough water
in the tank.
Fill the tank with water until
the indicator comes on. If
water starts to come out in‐
side the oven, and the indi‐
cator is still off, contact a
qualified service engineer.
is off.
The indicator "Tank Empty" There is no water in the
tank.
is on.
Fill the tank. If the indicator
is still on, contact a quali‐
fied service engineer.
The steam cooking does
not work.
Fill the water tank.
There is no water in the
tank.
ENGLISH
33
Problem
Possible cause
Remedy
The steam cooking does
not work.
Lime obstructs the hole.
Check the steam inlet
opening. Remove the lime.
It takes more than three
There are lime deposits in
minutes to empty the water the oven.
tank or the water leaks
from the steam inlet open‐
ing.
11.2 Service data
If you cannot find a solution to the
problem yourself, contact your dealer or
an Authorised Service Centre.
Clean the water tank. Re‐
fer to "Cleaning the water
tank".
plate is on the front frame of the oven
cavity. Do not remove the rating plate
from the oven cavity.
The necessary data for the service
centre is on the rating plate. The rating
We recommend that you write the data here:
Model (MOD.)
.........................................
Product number (PNC)
.........................................
Serial number (S.N.)
.........................................
12. INSTALLATION
WARNING!
Refer to Safety chapters.
12.1 Building In
548
21
min. 550
80
60
520
600
18
20
114
589
594
min. 560
595+-1
60
198
5
3
523
20
34
www.electrolux.com
548
70
60
21
min. 550
20
520
18
590
114
min. 560
589
594
198
60
595+-1
5
3
523
20
12.2 Securing the appliance to
the cabinet
A
B
12.3 Electrical installation
The manufacturer is not
responsible if you do not
follow the safety precautions
from the Safety chapters.
12.4 Cable
Cable types applicable for installation or
replacement:
H07 RN-F, H05 RN-F, H05 RRF, H05
VV-F, H05 V2V2-F (T90), H05 BB-F
For the section of the cable refer to the
total power on the rating plate. You can
also refer to the table:
Total power (W)
Section of the ca‐
ble (mm²)
maximum 1380
3 x 0.75
maximum 2300
3x1
maximum 3680
3 x 1.5
The earth cord (green / yellow cable)
must be 2 cm longer than phase and
neutral cables (blue and brown cables).
This appliance is supplied with a main
plug and a main cable.
13. ENERGY EFFICIENCY
13.1 Product Fiche and information according to EU 65-66/2014
Supplier's name
Electrolux
ENGLISH
Model identification
EOC5H40X
KOCEH40X
Energy Efficiency Index
95.3
Energy efficiency class
A
Energy consumption with a standard load, con‐
ventional mode
0.93 kWh/cycle
Energy consumption with a standard load, fanforced mode
0.81 kWh/cycle
Number of cavities
1
Heat source
Electricity
Volume
72 l
Type of oven
Built-In Oven
Mass
EN 60350-1 - Household electric cooking
appliances - Part 1: Ranges, ovens,
steam ovens and grills - Methods for
measuring performance.
13.2 Energy saving
The oven contains features which help
you save energy during everyday
cooking.
Make sure that the oven door is closed
properly when the oven operates. Do not
open the door too often during cooking.
Keep the door gasket clean and make
sure it is well fixed in its position.
Use metal cookware to improve energy
saving.
When possible, do not preheat the oven
before cooking.
EOC5H40X
29.5 kg
KOCEH40X
29.2 kg
35
Cooking with fan
When possible, use the cooking
functions with fan to save energy.
Residual heat
When the cooking duration is longer than
30 minutes, reduce the oven temperature
to minimum 3 - 10 minutes before the
end of cooking. The residual heat inside
the oven will continue to cook.
Use the residual heat to warm up other
dishes.
Keep food warm
Choose the lowest possible temperature
setting to use residual heat and keep a
meal warm.
Moist Fan Baking
Function designed to save energy during
cooking.
Keep breaks between baking as short as
possible when you prepare a few dishes
at one time.
14. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol .
Put the packaging in relevant containers
to recycle it. Help protect the
environment and human health by
recycling waste of electrical and
*
electronic appliances. Do not dispose of
appliances marked with the symbol
with the household waste. Return the
product to your local recycling facility or
contact your municipal office.
867355233-B-102019
www.electrolux.com/shop
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Related manuals

Download PDF

advertising
