ENGLISH
INSTALLATION MANUAL
AIR CONDITIONER
• Please read this installation manual completely before installing the product.
• Installation work must be performed in accordance with the national wiring
standards by authorized personnel only.
• Please retain this installation manual for future reference after reading it
thoroughly.
TYPE : FLOOR STANDING
P/NO : MFL68588801
www.lg.com
2
TIPS FOR SAVING ENERGY
ENGLISH
TIPS FOR SAVING ENERGY
Here are some tips that will help you minimize the power consumption when you use the air
conditioner. You can use your air conditioner more efficiently by referring to the instructions
below:
• Do not cool excessively indoors. This may be harmful for your health and may consume
more electricity.
• Block sunlight with blinds or curtains while you are operating the air conditioner.
• Keep doors or windows closed tightly while you are operating the air conditioner.
• Adjust the direction of the air flow vertically or horizontally to circulate indoor air.
• Speed up the fan to cool or warm indoor air quickly, in a short period of time.
• Open windows regularly for ventilation as the indoor air quality may deteriorate if the air conditioner is used for many hours.
• Clean the air filter once every 2 weeks. Dust and impurities collected in the air filter may
block the air flow or weaken the cooling / dehumidifying functions.
For your records
Staple your receipt to this page in case you need it to prove the date of purchase or for warranty
purposes. Write the model number and the serial number here:
Model number :
Serial number :
You can find them on a label on the side of each unit.
Dealer’s name :
Date of purchase :
IMPORTANT SAFETY INSTRUCTIONS
3
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
Always comply with the following precautions to avoid dangerous situations and ensure peak
performance of your product
! WARNING
It can result in serious injury or death when the directions are ignored
! CAUTION
It can result in minor injury or product damage when the directions are ignored
! WARNING
• Installation or repairs made by unqualified persons can result in hazards to you and others.
• The product shall be installed according to the wiring regulations of the corresponding country.
• The information contained in the manual is intended for use by a qualified service technician
familiar with safety procedures and equipped with the proper tools and test instruments.
• Failure to carefully read and follow all instructions in this manual can result in equipment malfunction, property damage, personal injury and/or death.
Installation
• Do not turn on the breaker or power under condition that front panel, cabinet, top cover, control box
cover are removed or opened.
- it may cause fire, electric shock, explosion or death.
• Do not use a defective or underrated circuit breaker. Use this appliance on a dedicated circuit.
- There is risk of fire or electric shock.
• For electrical work, contact the dealer, seller, a qualified electrician, or an Authorized Service Center.
- Do not disassemble or repair the product. There is risk of fire or electric shock.
• Always ground the product.
- There is risk of fire or electric shock.
• Install the panel and the cover of control box securely.
- There is risk of fire or electric shock.
• Always install a dedicated circuit and breaker.
- Improper wiring or installation may cause fire or electric shock
• Use the correctly rated breaker or fuse.
- There is risk of fire or electric shock.
• Do not modify or extend the power cable.
- There is risk of fire or electric shock.
• Be cautious when unpacking and installing the product.
- Sharp edges could cause injury. Be especially careful of the case edges and the fins on the condenser and evaporator.
• For installation, always contact the dealer or an Authorized Service Center.
- There is risk of fire, electric shock, explosion, or injury.
• Do not install the product on a defective installation stand.
- It may cause injury, accident, or damage to the product.
• Be sure the installation area does not deteriorate with age.
- If the base collapses, the air conditioner could fall with it, causing property damage, product failure,
and personal injury.
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
4
IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
• Do not let the air conditioner run for a long time when the humidity is very high and a door or a window is left open.
- Moisture may condense and wet or damage furniture.
• Use a vacuum pump or Inert (nitrogen) gas when doing leakage test or air purge. Do not compress
air or Oxygen and Do not use Flammable gases. Otherwise, it may cause fire or explosion.
- There is the risk of death, injury, fire or explosion.
Operation
• Do not store or use flammable gas or combustibles near the product.
- There is risk of fire or failure of product.
! CAUTION
Installation
• Always check for gas (refrigerant) leakage after installation or repair of product.
- Low refrigerant levels may cause failure of product.
• Install the drain hose to ensure that water is drained away properly.
- A bad connection may cause water leakage.
• Keep level even when installing the product.
- To avoid vibration or water leakage.
• Do not install the product where the noise or hot air from the outdoor unit could damage the neighborhoods.
- It may cause a problem for your neighbors.
• Use two or more people to lift and transport the product.
- Avoid personal injury.
• Do not install the product where it will be exposed to sea wind (salt spray) directly.
- It may cause corrosion on the product. Corrosion, particularly on the condenser and evaporator fins, could
cause product malfunction or inefficient operation.
TABLE OF CONTENTS
5
ENGLISH
TABLE OF CONTENTS
2
3
TIPS FOR SAVING ENERGY
19 FINAL CHECK AND TEST
IMPORTANT SAFETY INSTRUCTIONS
20 INSTALLATION GUIDE
6
INSTALLATION OF UNIT
6
7
8
8
8
9
10
Selection of the best location
Piping length and the elevation
The Indoor Unit Installation
Outdoor unit Installation
Refrigerant amount
Installation Method
Preparation of installation parts and
tools
Plumbing materials and storage methods
Preparation of Piping
Connection of piping
Precautions in bending
Form the Piping
Connecting the Cable to Indoor Unit
Connecting the cables to the outdoor
unit
Power Supply and Wiring
Vacuum Drying of the Connecting
Pipes and the Indoor Unit
Checking the Drainage
11
13
14
14
15
15
16
16
17
18
RUN
AT THE SEASIDE
6
INSTALLATION OF UNIT
ENGLISH
INSTALLATION OF UNIT
Selection of the best location
Indoor unit
- There should not be any heat source or
steam near the unit.
- There should not be any obstacles to prevent
the air circulation.
- A place where air circulation in the room will
be good.
- A place where drainage can be easily obtained.
- A place where noise prevention is taken into
consideration.
- Do not install the unit near the door way.
- Ensure the spaces indicated by arrows from
the wall, ceiling, or other obstacles.
- The indoor unit must keep the maintenance
space.
40 cm
cm
100
5 cm
40 cm
Outdoor unit
- If an awning is built over the unit to prevent
direct sunlight or rain exposure, be careful
that heat radiation from the condenser is not
restricted.
- There should not be any animals or plants
which could be affected by hot air discharged.
- Ensure the spaces indicated by arrows from
the wall, ceiling, fence or other obstacles.
- Place with fluent water draining
Install at a place with fluent water draining to
prevent damage from localized heavy rain
and avoid frequent flooded area.
Su
nro
of
More than
50 cm
Fe
ob nce o
sta r
cle
s
More than
50
30 c
cm
More than 50 cm
More than 100 cm
INSTALLATION OF UNIT
ENGLISH
Piping length and the elevation
GAS SIDE
LIQUID SIDE
Max.
Length
A (m)
AP-C(H)246KLA0
Ø 15.88 (5/8)
Ø 9.52 (3/8)
30
20
AP-C286KLA0
AP-C308KLA0
Ø 15.88 (5/8)
Ø 9.52 (3/8)
50
30
mm (inch)
MODEL
Max.
Elevation
B (m)
Indoor unit
A
B
7
Outdoor unit
! CAUTION
• Capacity is based on standard length and maximum allowance length is on the basis of reliability.
8
INSTALLATION OF UNIT
Outdoor unit Installation
1 The mounting floor should be strong and
1 Install the outdoor unit on the concrete or
solid enough to prevent it from vibration.
2 Drill the piping hole with 70 mm diameter
hole-core drill at either the right or the left
of indoor unit. The hole should be sightly
slant to the outdoor side.
3 Insert the plastic tube through the hole.
4 Cut the extruded outside part of the plastic
tube, if necessary.
any solid base securely and horizontally by
securing it with bolts (Ø12 mm) and nuts.
2 If there is any vibration transmitted to the
building, mount the rubber underneath the
outdoor unit.
200 mm
70 mm
Refrigerant amount
Before shipment, this air conditioner is filled
with the rated amount of refrigerant including
additional amount required for air-purging,
subject to 7.5 m piping length. (The rated
amount of refrigerant is indicated on the name
plate.) But when the piping length exceeds
7.5 meters, additional charge is required according to the following table.
70 mm
90 mm
ENGLISH
The Indoor Unit Installation
Wall
Core Drill
(Unit: g)
MODEL
REFRIGERANT
CHARGE
AP-C246KLA0
AP-H246KLA0
AP-C286KLA0
AP-C308KLA0
25 per 1 m
Example)
In case of 10 m long pipe(one-way), the
amount of refrigerant to be replenished is:
(10 - 7.5) x 25 = 62.5 g
INSIDE
Plastic tube
(Bushing)
OUTSIDE
Wall
Tilt
Cut if necessary
More than 15 mm
INSTALLATION OF UNIT
ENGLISH
Installation Method
No.
1
9
Installation works
Preparation of tools and installation parts
Descriptions
Preparation of installation
2
Flaring the pipes
To insert the flare nuts, mounted on the connection parts of both indoor and outdoor unit,
onto the copper pipes.
3
Pipe bending
To insert the flare nuts, mounted on the connection parts of both indoor and outdoor unit,
onto the copper pipes.
4
Connection of installation parts (elbows,
socket etc)
To reduce the flow resistance of refrigerant.
5
6
7
Tighten the flare nut (outdoor)
Blowing the pipings
Tighten the flare nut (indoor)
Connection of long piping
Connecting the pipings of the outdoor unit.
To remove dust and scale in working.
8
Check a gas-leakage of the connecting part of
the pipings.
Connecting the pipings of the indoor unit.
9
Vacuum drying of the piping and indoor unit
10
Open the 3-way (liquid side) and 3-way (gas
side) valves.
The air which contains moisture and which remains in the refrigeration cycle may cause a
malfunction on the compressor
11
12
Form the pipings
Checking the drainage (indoor unit)
To prevent heat loss and sweat
13
Connecting the cable between outdoor and
indoor unit
To ensure if water flow drain hose of indoor
unit.
14
Connecting the main cable to outdoor unit
15
Supply the power to the crankcase heater
(Before the operating the unit)
Preparation of the operating
16
Cooling operation (Use the remote control or
display of the indoor unit)
To prevent the liquid back to the compressor.
(Heat pump only)
10 INSTALLATION OF UNIT
ENGLISH
Preparation of installation parts and tools
No.
1
2
3
4
5
Installation Parts, Tools
Flaring tool (Ø 9.52 - Ø 15.88)
Remear
Pipe cutter (MAX 35 mm Copper pipe)
Wrench (H5, H4 hexagonal wrench)
Pipe bender
Use
Flaring the pipes
Remove burrs from cut edges of pipes.
Cutting the pipings
To open the service valve
Bending the pipings
6
Leak detector
Check a gas-leakage of connecting part of the
pipings
7
Manifold gauge
To measure the pressure, to charge the refrigerant
8
9
10
Charge-nipple
Vacuum pump
Charge cylinder balance
To connect the bombe
To remove the air in the pipe.
To measure the refrigerant amount
11
Bombe (R410A)
Gas charge
Cleaning the pipe
12
13
14
15
Spanner
Monkey spanner
Driver(
,
)
Benchi (150 mm)
16
Tapeline
To make holes through the concrete wall and
blocks
17
18
19
Core drill
Voltmeter, Amperemeter, Clampmeter
Insulation resistance tester
To measure the current and voltage
To measure the insulation resistance
20
Glass thermometer
To measure the intake and outlet air temperature of the indoor unit
21
22
23
24
Copper tubes
Insulation material
Tape
Electrical Leakage Breaker
To use the connecting pipings
To cover the connecting pipings
To finish the connecting pipings
To shut off the main power
25
Cable
To connect the cable from outdoor unit to indoor unit
26
Drain hose sockets, elbows
To remote the condensing water
To tighten the connecting parts of the pipings
Cutting the wires
To measure the length
INSTALLATION OF UNIT
11
Pipe must be able to obtain the specified thickness and should be used with low impurities.
Also when handling storage, pipe must be careful to prevent a fracture, deformity and wound.
Should not be mixed with contaminations such as dust, moisture.
Refrigerant piping on three principles
Drying
Should be no moisture
inside
Items
Cause
failure
Moisture
- Significant hydrolysis of
refrigerant oil
- Degradation of refrigerant
oil
- Poor insulation of the
compressor
- Do not cold and warm
- Clogging of EEV, Capillary
- No moisture in the pipe
- Until the connection is
completed, the plumbing
pipe entrance should be
strictly controlled.
- Stop plumbing at rainy
day.
Counter- Pipe entrance should be
measure
taken side or bottom.
- When removal burr after
cutting pipe, pipe entrance
should be taken down.
- Pipe entrance should be
fitted cap when pass
through the walls.
Cleanliness
Airtight
No dust inside.
There is no refrigerant
leakage
Dust
Leakage
- Degradation of refrigerant
oil
- Poor insulation of the
compressor
- Do not cold and warm
- Clogging of EEV, Capillary
- Gas shortages
- Degradation of refrigerant
oil
- Poor insulation of the
compressor
- Do not cold and warm
- No dust in the pipe.
- Until the connection is
completed, the plumbing
pipe entrance should be
strictly controlled.
- Pipe entrance should be
taken side or bottom.
- When removal burr after
cutting pipe, pipe entrance
should be taken down.
- Pipe entrance should be
fitted cap when pass
through the walls.
- Airtightness test should
be.
- Brazing operations to comply with standards.
- Flare to comply with standards.
- Flange connections to
comply with standards.
ENGLISH
Plumbing materials and storage methods
12 INSTALLATION OF UNIT
Welding, as when heating without nitrogen substitution a large amount of the oxide film is
formed on the internal piping.
The oxide film is a caused by clogging EEV, Capillary, oil hole of accumulator and suction hole of
oil pump in compressor.
It prevents normal operation of the compressor.
In order to avoid this problem, Welding should be done after replacing air by nitrogen gas.
When welding plumbing pipe, the work is required.
How to work
Regulator
Welding Point
Nitrogen gas
Pressure 0.02MPa less
Oxide scale
Note) should not block the outlet side.
When the internal pressure in pipe is abo
ve the atmospheric pressure, pinhole is
occurred and it is a leakage cause.
Taping
(Should not
contain air)
Auxiliary valve
Nitrogen
ENGLISH
Nitrogen substitution method
! CAUTION
1 Always use the nitrogen.(not use oxygen, carbon dioxide, and a Chevron gas):
Please use the following nitrogen pressure 0.02MPa
Oxygen --------- Promotes oxidative degradation of refrigerant oil.
Because it is flammable, it is strictly prohibited to use
Carbon dioxide --- Degrade the drying characteristics of gas
Chevron Gas ---- Toxic gas occurs when exposed to direct flame.
2 Always use a pressure reducing valve.
3 Please do not use commercially available antioxidant.
The residual material seems to be the oxide scale is observed.
In fact, due to the organic acids generated by oxidation of the alcohol contained in the anti-oxidants, ants nest corrosion occurs. (causes of organic
acid ’ alcohol + copper + water + temperature)
INSTALLATION OF UNIT 13
Main cause of gas leakage is defect in flaring work. Carry out correct flaring work in the following
procedure.
Cut the pipes and the cable.
- Use the accessory piping kit or the pipes purchased locally.
- Measure the distance between the indoor
and the outdoor unit.
- Cut the pipes a little longer than measured
distance.
- Cut the cable 1.5 m longer than the pipe
length.
Copper
tube
Slanted Uneven Rough
90°
Pipe
Reamer
Burrs removal
- Completely remove all burrs from the cut
cross section of pipe/tube.
- Put the end of the copper tube/pipe to downward direction as you remove burrs in order
to avoid to let burrs drop in the tubing.
Point down
Flare nut
Putting nut on
- Remove flare nuts attached to indoor and
outdoor units, than put them on pipe/tube
having completed burr removal.
(Not possible to put them on after flaring
work)
Flaring work
- Carry out flaring work using dedicated flaring
tool for R410A as shown below.
Outside diameter
mm
inch
Ø6.35
1/4
Ø9.52
3/8
Ø12.7
1/2
Ø15.88
5/8
Ø19.05
3/4
A
mm
1.1~1.3
1.5~1.7
1.6~1.8
1.6~1.8
1.9~2.1
Copper tube
Handle
Bar
"A"
Yoke
Cone
Copper pipe
Clamp handle
Red arrow mark
Smooth all round
Inside is shining without scratches.
Firmly hold copper tube in a bar(or die) as indicated dimension in the table above.
Check
- Compare the flared work with figure below.
- If flare is noted to be defective, cut off the
flared section and do flaring work again.
Bar
= Improper flaring =
Even length
all round
Inclined Surface Cracked Uneven
damaged
thickness
ENGLISH
Preparation of Piping
14 INSTALLATION OF UNIT
ENGLISH
Connection of piping
Spanner (fixed)
1 Move the indoor tubing and drain hose to
2
3
4
5
6
7
the hole
- Remove tubing holder and pull the tubing
out of the chassis.
Replace the tubing holder into original position
Route the tubing and the drain hose
staight backwards.
Insert the connecting cable into the indoor
unit through the hole.
- Do not connect the cable to the indoor
unit
- Make a small loop with the cable for easy
connection later.
Tape the tubing and the connecting cable.
Indoor unit installation.
Connecting the pipings to the indoor unit.
- Align the center of the pipings and suffciently tighten the flare nut with fingers.
- Finally, tighten the flare nut with troque
wrench until the wrench clicks.
When tightening the flare nut with troque
wrench, ensure the direction for tightening follows the arrow on the wrench.
Outside diameter
mm
inch
Ø6.35
1/4
Ø9.52
3/8
Ø12.7
1/2
Ø15.88
5/8
Ø19.05
3/4
Torque
N·m
16±2
38±4
55±6
75±7
110±10
Flare nut
Connection pipe
Torque wrench
Indoor unit tubing
Drain pipe
Indoor unit
drain hose
Adhesive Vinyl tape(narrow)
Precautions in bending
1 If it is necessary to bend or stretch the tubing, use the spring which is attached to the
tubing in stead of pipe bender.
- Please make a careful notice to make a
smooth line.
- Hold the tubing with your two hands
closely and then bend or stretch it slowly
not to make any crack.
- Remember that the radius (R) should not
exceed 70 mm (Refer to Fig. 1)
2 Do not repeat the bending process to prevent the tubing from cracking or crushing.
3 Keep in mind that the bending part should
not be cracked and make the radius (R) as
long as possible (Refer to Fig. 2)
Spring
R70 mm
Indoor unit tubing
Flare nut
Pipings
(Fig. 1)
Spanner
Torque wrench
R
(Fig. 2)
INSTALLATION OF UNIT 15
1 Wrap the connecting portion of indoor unit
with the insulation material and secure it
with two Plastic Bands. (for the right piping)
- If you connect an additional drain hose,
the end of the drain-outlet should be kept
distance from the ground. (Do not dip it
into water, and fix it on the wall to avoid
swinging in the wind.)
* In case of the outdoor unit is installed below
position of the indoor unit.
2 Tape the Piping, and Connecting Cable
from down to up.
3 Form the piping gathered by taping along
the exterior wall and fix it onto the wall by
saddle or equivalent.
Connecting the Cable to Indoor Unit
- In order to protect cable, it should be inserted “Bushing Rubber”.
- The inside and outside connecting cable can
be connected after opening the inlet grille.
1 Open the inlet grille manually. (Fig 1)
2 Open the control cover with Driver(⊕).
3 Connect the cables (LG does not supply) to
the terminal block in the control box.
4 Secure the control cover to the original position with the screw.
5 Close the inlet grille. (Fig 3)
Fig 1
Gas side
piping
Main cable
Liquid side
piping
Connecting
cable
Fig 2
Trap is required to prevent the electrical parts
from entering the water.
* In case of the outdoor unit is installed upper
position of the indoor unit.
1 Tape the piping and connecting cable from
down to up.
2 In order to prevent water from entering the
room, form a trap and tape the piping.
3 Fix the piping onto the wall with saddle or
bracket.
Fig 3
Seal a small opening around
the piping with gum type sealer.
Trap
Trap
Knock-out holes
ENGLISH
Form the Piping
16 INSTALLATION OF UNIT
ENGLISH
Detail of Fig 2
- Cooling Model
1
2
3
To outdoor unit
- Heat Pump Model
1
2
3
4
To outdoor unit
Power Supply and Wiring
The unit is completely wired internally at the
factory according to general rule of electrical
technology, but local rules, if they are required, should be complied with.
1 Power supply
Power source must fulfill the following
conditions:
- The working voltage should be higher
than 90 % and lower than 110 % of the
rated voltage marked on the name plate.
- The starting voltage should be higher than
85 % of the rated voltage marked on the
name plate.
Connecting the cables to the
outdoor unit
1 Open the control board cover from the outdoor unit by removing the screws.
2 Connect wires to the terminals on the control board individually and secure the cables onto the control board with clamp.
Voltage
Power source voltage
working voltage
Starting voltage
Starting point
Time
2 Wiring
After the confirmation of the above conditions, prepare the wiring as follows:
- Use the power supply cord(Rubber insulation, type Ho7RNF approved by HAR or
SAA) suitable for the product's electriccal
capacity.
UNIT
3 Secure the control board cover to the original position with the screws.
! CAUTION
Perform grounding
• This product should be grounded.
• Defective grounding could cause an electric shock.
VOLTS
AP-C246KLA0
AP-H246KLA0 450/750 V
AP-C286KLA0
AP-C308KLA0
Conductor
cross-sectional area
2.5 mm2
INSTALLATION OF UNIT 17
UNIT
Circuit breaker
capacity
H/P
1 Phase
C/O
3 Phase
30 A
30 A
20 A
- The screws which fasten the wiring in the
casing of electrical fittings are liable to
come loose from vibrations to which the
unit is subjected during the course of
transportation. Check them and make
sure that they are all tightly fastened.
(If they are loose, it could give rise to
burn-out of the wires.)
- See to it that the starting voltage is maintained at more than 90 percent of the
rated voltage marked on the name plate.
- The following troubles would be caused
by voltage drop-down.
Vibration of a magnetic switch, damage
on the contact point there of, fuse breaking, disturbance to the normal function of
a overload protection device.
Vacuum Drying of the Connecting Pipes and the Indoor
Unit
The air which contains moisture remaining in
the refrigeration cycle may cause a malfunction on the compressor.
1 Confirm that both the liquid side valve and
the gas side valve are set to the closed position.
2 After connecting the piping, check the
joints for gas leakage with gas leak detector.
3 Remove the service port nut, and connect
the gauge manifold and the vacuum pump
to the service port by the charge hose.
4 Vacuum the indoor unit and the connecting
pipes until the pressure in them lowers to
below - 76 cmHg.
5 Remove the valve stem nuts, and fully
open the stems of the 2-way and 3-way
valves with a hexagon wrench.
6 Tighten the valve stem nuts of the 2-way
valve and 3-way valve.
7 Disconnect the charge hose and fit the nut
to the service port.
(Tightening torque: 1.8 kg·m)
Liquid side
Indoor unit
Closed
Outdoor unit
2-way valve/
3-way valve
Gas side
3-way
valve
Vaccum pump
OPEN
CLOSE
Closed
ENGLISH
- Provide a recognized circuit breaker as
below between power source and unit.
A disconnection device to adequately disconnect all supply lines must be fitted.
(for service operations)
18 INSTALLATION OF UNIT
ENGLISH
Checking the Drainage
1 Remove the inlet grille with your hands as
shown (right and left) and pull in the direction indicated by the arrow.
2 Check the drainage
- Pour a glass of water into the drain pan.
- Ensure if water flows drain hose of indoor
unit.
FINAL CHECK AND TEST RUN 19
After installing the unit, perform the final check and running test as follows:
Final check points
① Is the unit securely mounted?
② Is the installation location adequate?
③ Is the water piping work adequately and without leakage?
④ Are trapped drain lines installed at condensate drain connections?
⑤ Has the refrigeration cooling cycle been kept sealed?
⑥ Is the electrical wiring adequate and are the screws tightened on terminals?
After the above final checkings, prepare the running test as follows:
① Connect compound gauges to the check joints at discharge and suction sides of the compressor.
② Turn all switches "OFF".
③ Turn the main switch "ON".
Running test should be accomplished as follows:
① Set operation switch at "FAN" and the fan will start. Check to ensure that the fan sounds normal.
② Next, set it at "COOL" and the compressor will start. Check to ensure that the compressor
sounds normal.
③ Check discharge and suction pressure on the compound gauges.
④ Check working voltage, phase balance and running current.
⑤ Check to ensure that the thermistor functions properly.
⑥ Check to ensure that the high pressure control switch functions correctly.
ENGLISH
FINAL CHECK AND TEST RUN
20 INSTALLATION GUIDE AT THE SEASIDE
ENGLISH
INSTALLATION GUIDE AT THE SEASIDE
! CAUTION
• Air conditioners should not be installed
in areas where corrosive gases, such as
acid or alkaline gas, are produced.
• Do not install the product where it could
be exposed to sea wind (salty wind) directly. It can result corrosion on the
product. Corrosion, particularly on the
condenser and evaporator fins, could
cause product malfunction or inefficient
performance.
• If outdoor unit is installed close to the
seaside, it should avoid direct exposure
to the sea wind. Otherwise it needs additional anticorrosion treatment on the
heat exchanger.
1 Selecting the location(Outdoor Unit)
If the outdoor unit is to be installed close
to the seaside, direct exposure to the sea
wind should be avoided. Install the outdoor
unit on the opposite side of the sea wind
direction.
Sea wind
Sea wind
2 In case, to install the outdoor unit on the
seaside, set up a windbreak to prevent
oudoor unit from the sea wind.
Windbreak
Sea wind
- It should be strong enough like concrete
to prevent the outdoor unit from the sea
wind.
- The height and width should be more
than 150% of the outdoor unit.
- It should be keep more than 70 cm of
space between outdoor unit and the
windbreak for easy air flow.
3 Place with fluent water draining
- Install at a place with fluent water draining to prevent damage from localized
heavy rain and avoid frequent flooded
area.
- If you can’t meet above guide line in the
seaside installation, please contact LG
Electronics for the additional anticorrosion.
- Periodic ( more than once/year ) cleaning of the dust or salt particles stuck on
the heat exchanger by using water
21
ENGLISH
22
ENGLISH
23
ENGLISH
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
