SENSUS INFOTAINMENT
VÄLKOMMEN!
We hope you will enjoy many years of driving pleasure in your Volvo. The
car has been designed for the safety and comfort of you and your passengers. Volvo is one of the world's safest passenger vehicles. Your
Volvo is also designed to meet applicable safety and environmental
requirements.
In order to increase your enjoyment of your Volvo, we recommend that
you read this supplement as well as the instructions and maintenance
information in the owner's manual. The owner's manual is also available
as a mobile app (Volvo Manual) and on the Volvo Cars support site
(support.volvocars.com).
TABLE OF CONTENTS
INTRODUCTION
AUDIO AND MEDIA
6
MY CAR
10
Audio and media
20
Volvo Sensus
6
MY CAR - search paths
11
Audio and media - overview
20
7
MY CAR - menu options
11
Audio and media - operating the system
21
MY CAR - car settings
13
Favourites
25
MY CAR - driving support system
14
Save as favourite
25
MY CAR - System options
16
Audio and media - audio settings
26
MY CAR - Climate settings
17
Audio and media - general audio settings
26
MY CAR Information
17
Audio and media - advanced audio
settings
27
Setting the equaliser
27
Setting the audio profile
27
Setting the audio volume and automatic volume control
28
Radio
28
Radio tuning
29
Volvo Cars support site
2
MY CAR
Introduction
Automatic radio tuning
29
Radio station list*
29
Manual radio tuning
30
Radio stations as presets
31
RDS functions
32
Alarms in the event of accidents and
disasters
32
Traffic information (TP)
33
Enhanced Other Networks (EON)
33
News broadcasts
33
Radio programme types (PTY)
34
Searching radio programme types (PTY)
34
Random selection of disc track or
audio file
43
Show radio programme types (PTY)
35
Playback and navigation of DVD*
video discs
43
Volume control for interrupting radio
programme types (PTY)
35
44
Radio text
Camera angle for playback of DVD*
video discs
35
Automatic radio frequency update (AF)
36
DivX®
Regional radio programmes (REG)
36
Scan radio frequencies
36
Resetting RDS functions
37
Digital radio (DAB)*
37
Bluetooth® handsfree phone* - overview
56
Making and receiving calls*
56
Bluetooth® handsfree phone* - audio
settings
57
Bluetooth®* version information
58
45
Phone book*
58
45
Phone book* - quick search for contacts
59
Media player - compatible file formats
45
60
External audio source via AUX/USB*
input
47
Phone book* - character table keypad in centre console
Phone book* - searching for contacts
60
Connecting an external audio source
via AUX/USB* input
48
Phone book* - new contact
61
Playback and navigation of external
audio source*
49
Phone book* - speed dial numbers
62
Phone book* - receiving a vCard
63
Phone book* - memory status
63
Phone book* - clearing
63
Video On Demand*
Picture settings*
Storing channel groups (Ensemble learn)
38
Navigation in channel group list
(Ensemble)
38
DAB to DAB link
38
50
Digital radio (DAB)* - wavelength
Setting the audio volume for external
audio source
39
Digital radio (DAB)* - subchannel
39
Media Bluetooth®*
51
Remote control*
64
51
Remote control* - functions
65
Digital radio (DAB)* - resetting
39
Connecting and disconnecting a
Bluetooth® device*
Media player
40
Registering a Bluetooth® device*
52
CD/DVD*
40
53
Playback and navigation of CD/
DVD* disc
40
Automatic connection of Bluetooth®
device*
Changing to another Bluetooth® device*
53
Playback and navigation of burned
discs with audio/video files*
41
Fast forward/reverse
42
Scan disc track or audio file
43
Disconnecting the Bluetooth® device*
54
Removing a Bluetooth® device*
55
Bluetooth® handsfree phone*
55
Remote control* - battery replacement
66
Audio and media - menu overview
66
Menu overview - AM
67
Menu overview - FM
67
Menu overview - Digital radio (DAB)*
68
Menu overview - CD Audio
68
Menu overview - CD/DVD* Data
69
3
ALPHABETICAL INDEX
Menu overview - DVD* Video
Menu overview -
4
iPod®*
69
70
Menu overview - USB*
70
Menu overview - Media Bluetooth®*
71
Menu overview - AUX
71
Menu overview - Bluetooth® handsfree*
72
Licenses
73
Type approval
75
Alphabetical Index
85
INTRODUCTION
INTRODUCTION
Introduction
Owner's Manual in mobile devices
This supplement is a supplement to the normal
owner's manual for the car.
Volvo Sensus
Volvo Sensus is the heart of the personal Volvo
experience and connects you with the car and
outside world. Sensus provides information,
entertainment and assistance when it is needed.
Sensus consists of intuitive functions that both
enhance the car journey and simplifies ownership of the car.
In the event of uncertainty regarding any of the
car's functions, consult the owner's manual in the
first instance. For answers to additional questions
it is recommended to contact a dealer or a representative of Volvo Car Corporation.
The specifications, design features and illustrations in this supplement are not binding. We
reserve the right to make modifications without
prior notice.
© Volvo Car Corporation
Options/accessories
All types of option/accessory are marked with an
asterisk: *.
In addition to standard equipment, the supplement also describes options (factory fitted equipment) and certain accessories (retrofitted extra
equipment).
The equipment described in the supplement is
not available in all cars - they have different
equipment depending on adaptations for the
needs of different markets and national or local
laws and regulations.
In the event of uncertainty over what is standard
or an option/accessory, contact a Volvo dealer.
6
NOTE
The Owner's manual is available for download
as a mobile application (applies for certain car
models and mobile devices), see
www.volvocars.com.
The mobile application also includes video
and searchable content and easy navigation
between different sections.
An intuitive navigation structure makes it possible
to receive relevant support, information and
entertainment when it is necessary, without distracting the driver.
Sensus covers all the car's solutions that enable
connection* to the outside world and provides
you with intuitive control over all the car's capabilities.
Volvo Sensus combines and presents many functions in several of the car's systems on the centre
console's screen. With Volvo Sensus the car can
be personalised by means of an intuitive user
* Option/accessory.
INTRODUCTION
interface. Settings can be made in Car settings,
Audio and media, Climate control, etc.
Overview
More information on your car is available on the
Volvo Cars website and support site.
With the centre console buttons and controls or
the steering wheel's right-hand keypad* functions
can be activated or deactivated and many different settings can be made.
Support on the Internet
Go to support.volvocars.com or use the QR code
below to visit the page. The support page is available for most markets.
With a press on MY CAR all settings related to
the driving and control of the car are presented,
such as City Safety, locks and alarm, automatic
fan speed, setting the clock, etc.
With a press on the respective function RADIO,
*, NAV* and CAM1 other
MEDIA, TEL*,
sources, systems and functions can be activated,
e.g. AM, FM, CD, DVD*, TV*, Bluetooth®*, navigation* and park assist camera*.
For more information about all functions/
systems, see the relevant section in the owner's
manual or its supplement.
Volvo Cars support site
Control panel in centre console. The figure is schematic
- the number of functions and layout of the buttons both
vary, depending on the equipment selected and the market.
Navigation* - NAV, see separate supplement
(Sensus Navigation).
Audio and media - RADIO, MEDIA, TEL*, see
the relevant section in this supplement.
Function settings - MY CAR, see MY CAR
(p. 10).
Internet-connected car *, see the
respective section in this supplement2.
QR code that leads to the support page.
The information on the support page is searchable and can also be subdivided into different categories. Available here is support for options related to e.g. Internet connected services and functions, Volvo On Call*, the navigation system* and
apps. Video and step-by-step instructions explain
different procedures, e.g. how the car is connected to the Internet via a mobile phone.
Climate control system, see the Owner's
Manual.
Park assist camera - CAM1, see the Owner's
Manual.
1
2
Applies to certain car models.
Information only available if the car is equipped with this function.
}}
* Option/accessory.
7
INTRODUCTION
||
Downloadable information from the
support page
Maps
For cars equipped with Sensus Navigation*, there
is the facility to download maps from the support
page.
Apps
For selected Volvo models from model year 2014
and 2015, the owner's manual is available in the
form of an app. The Volvo On Call* app can also
be accessed from here.
Owner's manuals from previous model years
Owner's manuals from previous model years are
available here in PDF format. The Quick Guide
and supplement can also be accessed from the
support page. Select car model and model year in
order to download the publication required.
Contact
On the support page there is contact information
for customer support and the nearest Volvo
dealer.
Log in to the Volvo Cars website
Create a personal Volvo ID and log in to
www.volvocars.com. Once you are logged in you
can get an overview of service, agreements and
warranties, amongst other things. There is also
information here about accessories and software
adapted for your car model.
8
* Option/accessory.
MY CAR
MY CAR
MY CAR
and layout of the buttons both vary, depending on the
equipment selected and the market.
MY CAR is a menu source that handles many of
the car's functions, e.g. City Safety™, locks and
alarm, automatic fan speed, setting the clock,
etc.
MY CAR - opens the menu system MY CAR.
OK/MENU - press the button in the centre
console or the thumbwheel on the steering
wheel to select/tick in the highlighted menu
option or store the selected function in the
memory.
Certain functions are standard, others are
optional - the range also varies depending on the
market.
TUNE - turn the knob in the centre console
or the thumbwheel on the steering wheel to
scroll up/down through the menu options.
Operation
Navigation in the menus is carried out using buttons in the centre console or with the steering
wheel's right-hand keypad*.
EXIT
EXIT functions
Depending on the function the cursor is on when
EXIT is depressed briefly, and on which menu
level, one of the following may occur:
•
•
•
•
•
phone call is rejected
current function is interrupted
input characters are deleted
most recent selections are undone
leads up in the menu system.
A long press on EXIT leads to the normal view
for MY CAR or if you are in the normal view, to
the highest menu level (main source menu).
Control panel in centre console and steering wheel keypad. The figure is schematic - the number of functions
10
* Option/accessory.
MY CAR
MY CAR - search paths
MY CAR is a menu source that handles many of
the car's functions, e.g. setting the clock, door
mirrors and locks.
Current menu level is shown at the top right of
the centre console's screen. The search paths to
the menu system's functions are specified on the
form:
Settings Car settings Lock settings
Doors unlock Driver door, then all.
The following is an example of how a function
can be accessed and adjusted using the steering
wheel keypad:
6.
7.
Scroll between the options All doors and
Driver door, then all and press the thumbwheel - the option is selected.
Exit the programming by backing out of the
menus incrementally with short presses on
EXIT or with one long press.
The procedure is the same for the centre console
controls (p. 10): OK/MENU, EXIT and the TUNE
knob.
Related information
•
•
MY CAR (p. 10)
MY CAR - menu options (p. 11)
MY CAR - menu options
MY CAR is a menu source where many of the
car's functions can be handled, e.g. setting the
clock, door mirrors and locks.
The following options are available in menu
source MY CAR:
•
•
•
•
•
My S601
Trip statistics2
DRIVe3/Hybrid2
Support systems
Settings
My S601
1.
Press the centre console button MY CAR.
2.
Scroll to the desired menu, e.g. Settings ,
with the thumbwheel and then press the
thumbwheel - a submenu opens.
The screen shows a grouping of all of the car's
driver support systems - these can be activated
or deactivated here.
3.
Scroll to the desired menu, e.g. Car settings
and press the thumbwheel - a submenu
opens.
Trip statistics2
4.
Scroll to Lock settings and press the
thumbwheel - a new submenu opens.
The screen shows the history as a bar chart with
average consumption of electricity and fuel.
5.
Scroll to Doors unlock and press the
thumbwheel - a submenu of selectable functions opens.
DRIVe3
1
2
3
Depending on car model.
Applies to the V60 Twin Engine and S60L Twin Engine.
Applies to the V40, V40 Cross Country, S60, S60L, V60, V60 Cross Country, XC60.
MY CAR
MY CAR
MY CAR
My S601
Trip statistics
DRIVe
}}
11
MY CAR
||
Parts of the Volvo DRIVe concept are described
here, among other things. Select from among the
following headings:
• Start/Stop
Here there is information about the Start/
Stop function.
• Eco driving guide
Tips, advice and a description of what it
means to drive economically can be found
here.
Hybrid2
MY CAR
Driver support system
MY CAR
The screen shows a summary of the current status of the car's driver support systems.
Settings
MY CAR
• Driving modes
The car's different drive modes are explained.
• Eco driving guide
Tips, advice and a description of what it
means to drive economically can be found
here.
2 Applies
12
to the V60 Twin Engine and S60L Twin Engine.
Menus under settings
• Car settings, see MY CAR - car settings
(p. 13)
• Driver support systems, see MY CAR driving support system (p. 14)
• System options, see MY CAR - System
options (p. 16)
• Audio settings, see Audio and media - general audio settings (p. 26)
Menu level 1
• Climate settings, see MY CAR - Climate
Menu level 2
• Favourites (FAV) - link a normally used
Hybrid
The screen shows whether the motor or
engine is driving the car and how the motive
force is flowing.
Settings
The menus are structured as follows:
Menu level 3
Information on the car's drive system is found
here. Select from among the following headings:
• Power flow
Support systems
Menu level 4
Shown here are the 4 first menu levels under
Settings. Certain functions are standard, others
are optional - the range also varies depending on
the market.
When selecting whether a function should be
activated/On or deactivated/Off a square is displayed:
On: Selected square.
Off: Empty square.
•
Select On/Off with OK - then back out of
the menu with EXIT.
settings (p. 17)
function in MY CAR to FAV button, see
Favourites (p. 25)
• Volvo On Call, described in a separate manual.
•
Information, see MY CAR Information
(p. 17)
Related information
•
•
MY CAR (p. 10)
MY CAR - search paths (p. 11)
MY CAR
MY CAR - car settings
Car settings menu option in the MY CAR menu
source handles many of the car's functions, e.g.
Car key memory and Lock settings for doors.
Car settings
Car key memory
Audible confirmation
On
On
Off
Off
Reduced Guard
Activate once
Ask when exiting
On
Off
Lock settings
On
Off
Doors unlock
All doors
Driver door, then all
Keyless entry
All doors
Any door
Doors on same side
Both front doors
Approach light duration
Off
30 sec
Side mirror settings
60 sec
Fold mirrors
90 sec
Tilt left mirror
Automatic door locking
Unlock confirmation light
Tilt right mirror
Light settings
Interior light
Floor lights
Ambient light
Ambient light colours
Door lock confirmation light
Home safe light duration
Off
30 sec
60 sec
90 sec
Triple indicator
On
Off
On
Off
}}
13
MY CAR
||
Temporary LH traffic
Steering wheel force
Low
On
Medium
Off
High
or
Temporary RH traffic
Speed in infotainment display
On
On
Off
Off
Active bending lights
On
Off
Auxiliary lights
On
Off
Tyre pressure system
Warns if tyre pressure is too low
Calibrate tyre pressure
Tyre pressure system
Calibrate tyre pressure
Reset car settings
All menus in Car settings are given original
factory settings.
Related information
•
•
MY CAR (p. 10)
MY CAR - menu options (p. 11)
MY CAR - driving support system
Driving support systems menu option in the MY
CAR menu source handles functions such as
e.g. Collision warning system and Lane keeping
aid.
Driver support systems
Collision Warning
On
Off
Warning distance
Long
Normal
Short
Warning sound
On
Off
Lane Departure Warning
Lane Departure Warning
On
Off
14
MY CAR
On at start-up
On
Off
Increased sensitivity
On
Off
Lane Keeping Aid
Lane Keeping Aid
On
Off
Assistance alternatives
Full function
Speed alert
On
Off
•
•
MY CAR (p. 10)
MY CAR - menu options (p. 11)
DSTC
On
Off
City Safety
On
Off
BLIS
On
Off
Distance Alert
Vibration only
On
Steering assist only
Off
Road Sign Information
Related information
Driver Alert
On
On
Off
Off
15
MY CAR
MY CAR - System options
The system settings menu option in the MY CAR
menu source handles functions such as e.g.
time and languages.
Show help text
On
Off
System options
Explanatory text for the display screen's current content is shown with this option selected.
Time
Distance and fuel units
The combined instrument panel's clock is
adjusted here.
MPG (UK)
Time format
km/l
12 h
24 h
Screen saver
On
Off
The display screen's current content fades out
after a period of inactivity and is replaced by a
blank screen if this option is selected.
MPG (US)
l/100km
Temperature unit
Celsius
Fahrenheit
Selects the unit for the display of outside temperature and setting of the climate control system.
Volume levels
The current screen content returns if any of
the display screen's buttons or controls are
actuated.
Front park assist volume
Language
Phone ringing volume
Selects language for menu texts.
Rear park assist volume
Reset system options
All menus in System options are given original factory settings.
16
Related information
•
•
MY CAR (p. 10)
MY CAR - menu options (p. 11)
MY CAR
MY CAR - Climate settings
Interior air quality system
Climate settings menu option in the MY CAR
menu source handles functions such as e.g. fan
adjustment and recirculation.
On
Off
MY CAR Information
Information menu option in the MY CAR menu
source handles functions such as Number of
keys and VIN number.
Climate settings
Reset climate settings
Information
Automatic blower adjustment
All menus in Climate settings are given original factory settings.
Number of keys
Normal
High
Low
Recirculation timer
On
Off
Automatic rear defroster
Related information
•
•
MY CAR (p. 10)
MY CAR - menu options (p. 11)
VIN number
DivX® VOD code
Bluetooth software version in car
Related information
•
•
MY CAR (p. 10)
MY CAR - menu options (p. 11)
On
Off
Auto start steering wheel heater
On
Off
Auto start driver seat heater
On
Off
17
AUDIO AND MEDIA
AUDIO AND MEDIA
Audio and media
Audyssey MultEQ*
The audio and media system consists of radio
(p. 28), media player (p. 40) as well as the
option to communicate with mobile phone*
(p. 55) . Information is presented on a 5-inch
screen* in the upper section of the centre console. Functions can be controlled via buttons in
the steering wheel, in the centre console below
the screen or via a remote control* (p. 64) .
If the audio and media system is active when the
engine is switched off then it is automatically
activated the next time the key is inserted into
key position I or higher, and it continues with the
same source (e.g. radio) as before the engine
was switched off (the driver's door must be
closed on cars with Keyless systems*).
The audio and media system can be used for 15
minutes at a time without the remote control key
being in the ignition switch by pressing the
On/Off button.
When the car is being started the audio and
media system is switched off temporarily and
continues when the engine has started.
Audio and media - overview
Overview of the audio and media system's different parts.
The Audyssey MultEQ system has been used in
the development and tuning of the sound to
ensure a world-class sound experience.
AUX and USB* inputs for external audio
sources (p. 47) (e.g. iPod®).
Steering wheel keypad*.
5-inch screen.
Centre console control panel.
NOTE
Remove the remote control key from the ignition switch if the infotainment system is used
when the engine is switched off. This is to
avoid discharging the battery unnecessarily.
20
* Option/accessory.
AUDIO AND MEDIA
Audio and media - operating the
system
tions1 or chapter2. A long press fast forwards through disc tracks or searches for the
next available radio station.
The audio and media system is controlled from
the centre console and partly from the steering
wheel buttons. The information is presented on
the screen in the upper section of the centre
console.
SOUND - press for access to audio settings
(bass, treble, etc.). For more information, see
general audio settings (p. 26) .
VOL - raise or lower the volume.
- ON/OFF/MUTE - short press starts
the system and long press (until the screen
is off) switches off. Note that the whole of
the Sensus system (including navigation*
and phone functions*) starts/switches off at
the same time. Briefly press to mute the
sound (MUTE) or restore the sound if it had
been switched off.
Disc insert and eject slot.
Main sources - press to select the main
source (e.g. RADIO, MEDIA). Last active
source is shown (e.g. FM1). A new source
view is selected if the main source button is
pressed while in RADIO or MEDIA. If you are
in TEL* or NAV* and press the main source
button then a shortcut menu is shown with
commonly used menu options.
Disc eject.
Scroll/fast wind/search - Short press
scrolls between disc tracks, preset radio sta-
1
2
OK/MENU - press the thumbwheel in the
steering wheel or the button in the centre
Does not apply to DAB.
Only applies to DVD discs.
}}
* Option/accessory.
21
AUDIO AND MEDIA
||
console to accept selections in menus. If you
are in the normal view and press OK/MENU
a menu is shown for the selected source
(e.g. RADIO or MEDIA). Arrow to the right of
the screen is shown when there are underlying menus.
TUNE - turn the thumbwheel in the steering
wheel or the knob in the centre console to
scroll among tracks/folders, radio and TV*
stations, phone contacts* or to navigate
among choices on the display screen.
INFO button to see the remaining information.
EXIT - short press leads upwards in the
menu system, interrupts current function,
interrupts/rejects phone calls or erases
entered characters. Long press leads to
normal view, or if you are in normal view to
the highest menu level (main source view),
from where you can reach the same main
source buttons located in the centre console
(6).
Preset buttons, input of numbers and letters.
FAV - shortcut to a favourite setting. The button can be programmed for a commonly
used function (e.g. FM, AUX). For more information, see favourites (p. 25).
MUTE – press to switch off the radio/media
audio or restore the audio if it has been
switched off.
INFO - If more information than can be
shown on the screen is available, press the
22
* Option/accessory.
AUDIO AND MEDIA
Menus
The example shows navigation to different functions when a disc is played back. (1) Main source button, (2) Normal view, (3) Shortcut/Source menu, (4) Quick menu, (5) Source
menu.
}}
23
AUDIO AND MEDIA
||
Main source button - press in order to
change the main source or to show the
Shortcut/Source menu in the active source.
Normal view - normal mode for the source.
Shortcut/Source menu - shows commonly
used menu options in the main sources, e.g.
TEL and MEDIA (accessed by pressing the
active source's main source button (1)).
Quick menu - fast mode when TUNE is
turned, e.g. for changing disc tracks, radio
station, etc.
Source menu - for menu navigation
(accessed by pressing OK/MENU).
The appearance depends on the source, equipment in the car, settings, etc.
Select main source by pressing a main source
button (1) (RADIO, MEDIA, TEL). To navigate
through the source menus, use the controls
TUNE, OK/MENU, EXIT or the main source button (1).
For available functions, see Audio and media menu overview (p. 66).
24
AUDIO AND MEDIA
Favourites
•
Save (p. 25) frequently used functions as
favourites. Possible functions that can be saved
are within radio, media, reversing camera and
menu source MY CAR where many of the car's
functions are handled, e.g. setting the clock,
door mirrors and locks. The function is then
accessed easily by pressing the FAV button.
In MEDIA mode:
•
•
•
•
•
•
DAB1*/DAB2*
DISC
USB*
iPod®*
Bluetooth®*
AUX
TV*
It is also possible to select and save a favourite
for MY CAR, CAM* and NAV*. Favourites can
also be selected and saved under MY CAR.
Save as favourite
Save frequently used functions as favourites
(p. 25). The function can then be started easily
by pressing the FAV button (p. 21).
To save a function as a favourite:
1.
Select a main source (e.g. RADIO, MEDIA).
2.
Select a wavelength or source (FM1, Disc,
etc.).
3.
Press and hold the FAV button until the
"favourites menu" is shown.
4.
Turn TUNE to select an option from the list
and press OK/MENU to save.
> When the main source (e.g. RADIO,
MEDIA) is active the saved function is
available via a short press on FAV.
Related information
•
•
•
•
FAVThe button can be used to save functions
that are used frequently so that the function can
be started simply by pressing FAV. You can
select a favourite (e.g. Equalizer) for each function in accordance with the following:
Audio and media (p. 20)
MY CAR (p. 10)
Radio (p. 28)
Media player (p. 40)
Related information
•
•
Audio and media (p. 20)
MY CAR - car settings (p. 13)
In RADIO mode:
•
•
3
AM3
FM1/FM2
Does not apply to the V60 Twin Engine and S60L Twin Engine.
* Option/accessory.
25
AUDIO AND MEDIA
Audio and media - audio settings
The audio system is pre-calibrated for optimal
sound reproduction, but can be adapted to your
needs.
Setting for optimal sound reproduction
The audio system is pre-calibrated for optimum
sound reproduction by means of digital signal
processing.
Audio and media - general audio
settings
• Balance – Balance between the left and
General audio settings for the audio and media
system.
• Subwoofer* - Bass speaker level.
• DPL II surround level/4 – Level for sur-
Press the SOUND button (p. 21) to access the
audio settings menu (Bass, Treble, etc.). Scroll
forward with SOUND or OK/MENU to your
selection (e.g. Treble).
This calibration takes into account loudspeakers,
amplifiers, passenger compartment acoustics, listener position etc. for each combination of car
model and audio system.
Adjust the setting by turning TUNE and save the
setting with OK/MENU.
There is also a dynamic calibration that takes into
account the position of the volume control, radio
reception and vehicle speed.
• Surround* - Can be set to the On/Off posi-
The controls explained in these operating instructions, e.g. Bass, Treble and Equalizer, are only
intended for the user to be able to adapt the
sound reproduction according to personal taste.
right-hand speakers.
round.
Related information
•
Audio and media - operating the system
(p. 21)
Continue pressing SOUND or OK/MENU to
access other options:
tion. When On is selected, the system
selects the setting for optimal sound reproduction. Normally DPLII and
then
appear in the display screen. If the recording
is made with Dolby Digital technology then
playback will take place with this setting,
then appears in the display screen.
When Off is selected, 3-channel stereo is
available.
• Bass - Bass level.
• Treble - Treble level.
• Fader – Balance between the front and rear
speakers.
4
26
Only when Surround is activated.
* Option/accessory.
AUDIO AND MEDIA
Audio and media - advanced audio
settings
Setting the equaliser
Setting the audio profile
Set the equaliser* and adjust the volume separately for different radio frequencies or TV.
Set the audio profile* and optimise your audio
experience in accordance with your needs.
1.
Press OK/MENU in the normal view for the
media source in order to access Audio
settings and select Equalizer.
Setting the audio profile (p. 27)
2.
Setting the audio volume and automatic volume control (p. 28)
Select wavelength by turning TUNE and confirm with OK/MENU.
3.
Adjust the audio settings by turning TUNE
and confirm with OK/MENU. Continue in the
same way with other wavelengths you want
to change.
The sound experience can be optimised for the
driver's seat, both front seats or the rear seat. If
there are passengers in both the front and rear
seats then the option recommended is; both front
seats. Access the options in the normal view for
the media source by pressing OK/MENU and
selecting Audio settings Sound stage.
Adapt the audio settings for radio and media
according to your requirements.
The following functions can be adapted:
•
•
•
Setting the equaliser (p. 27)
•
Setting the audio volume for external audio
source (p. 50)
Related information
•
Audio and media - operating the system
(p. 21)
4.
When you have finished with audio settings,
press EXIT to confirm and return to normal
view.
Related information
•
•
Audio and media - audio settings (p. 26)
Audio and media - operating the system
(p. 21)
Related information
•
Audio and media - advanced audio settings
(p. 27)
•
Audio and media - operating the system
(p. 21)
* Option/accessory.
27
AUDIO AND MEDIA
Setting the audio volume and
automatic volume control
Set the audio compensation for excessive noise
in the passenger compartment.
Radio
It is possible to listen to the AM5 and FM radio
frequencies, and in certain cases also digital
radio (DAB)* (p. 37).
The audio system compensates for disrupting
noises in the passenger compartment by increasing the volume in relation to the speed of the car.
The compensation level can be set to low,
medium, high or off. Select level in the normal
view for the media source by pressing
OK/MENU and then selecting Audio settings
Volume compensation.
Related information
•
Audio and media - advanced audio settings
(p. 27)
•
Audio and media - operating the system
(p. 21)
Controls for radio functions.
For operating the radio, see Operating the system (p. 21).
AM5/FM radio
•
•
•
•
•
•
5
28
Radio tuning (p. 29)
Digital radio* (DAB)
•
•
Digital radio (DAB)* (p. 37)
Storing channel groups (Ensemble learn)
(p. 38)
•
Navigation in channel group list (Ensemble)
(p. 38)
•
•
•
•
•
•
•
•
Radio stations as presets (p. 31)
Scan radio frequencies (p. 36)
Radio programme types (PTY) (p. 34)
Radio text (p. 35)
DAB to DAB link (p. 38)
Digital radio (DAB)* - wavelength (p. 39)
Digital radio (DAB)* - subchannel (p. 39)
Digital radio (DAB)* - resetting (p. 39)
Related information
•
•
•
Menu overview - AM (p. 67)
Menu overview - FM (p. 67)
Menu overview - Digital radio (DAB)*
(p. 68)
Radio stations as presets (p. 31)
Scan radio frequencies (p. 36)
RDS functions (p. 32)
Radio programme types (PTY) (p. 34)
Radio text (p. 35)
Does not apply to the V60 Twin Engine and S60L Twin Engine.
* Option/accessory.
AUDIO AND MEDIA
Radio tuning
Automatic radio tuning
Radio station list*
The radio automatically compiles a radio station
list* (p. 29) of the strongest radio stations
whose signals it is currently receiving. It is possible to activate automatic (p. 29)- or manual
(p. 30) radio tuning.
Searches for the next/previous available station.
The radio automatically compiles a radio station
list of the strongest radio stations whose signals
it is currently receiving. This enables you to find
a station when you drive into an area where you
do not know the radio stations and their frequencies.
NOTE
The reception is dependent both on how
good the signal strength and signal quality
are. The transmission may be disturbed by
various factors such as tall buildings or the
transmitter being far away. Coverage level can
also vary depending on where in the country
you are located.
1.
Press RADIO, turn TUNE until the desired
wavelength (e.g. FM1) is shown, press OK/
MENU.
2.
Hold in
/
in the centre console (or
in the steering wheel keypad*). The radio
searches for the next/previous available station.
To go to the list and select a station:
1.
Select the desired wavelength (e.g. FM1).
2.
Turn TUNE one step in either direction. This
displays the list of all stations in the area.
The currently tuned station is indicated with
enlarged text in the list.
3.
Turn TUNE again in either direction to select
a station from the list.
4.
Confirm your choice by pressing OK/MENU.
}}
* Option/accessory.
29
AUDIO AND MEDIA
NOTE
Manual radio tuning
•
The list only shows the frequencies of
stations that are currently being received,
not a complete list of all radio frequencies on the selected wavelength.
The radio automatically compiles a radio station
list* (p. 29), but it is possible to perform radio
tuning manually.
•
If the signal from the currently received
station is weak, this may prevent the radio
from updating the station list. If this
occurs, press the INFO button (while the
station list is shown in the display screen)
in order to change to manual tuning and
set a frequency. If the station list is no
longer shown, turn TUNE one step in
either direction to show the list again, and
press INFO to switch.
The list disappears from the display screen after
a few seconds.
If the station list is no longer shown, turn TUNE
one step in either direction and press the INFO
button in the centre console to change to manual
tuning (p. 30) (or to return from manual tuning
to the function for Station list).
30
The preset from the factory is that the radio
shows the station list of the strongest stations in
the area when you turn TUNE. When the radio
station list is shown, press the INFO button in the
centre console to change to manual tuning. This
allows you to select a frequency from the list of
all available radio frequencies in the selected
wavelength. In other words, if turn TUNE one
step in a manual search the frequency is
changed from e.g. 93.3 to 93.4 MHz, etc.
To manually select a station:
1.
Press the RADIO button, turn TUNE until the
desired wavelength (e.g. FM1) is shown,
press OK/MENU.
2.
Turn TUNE to select a frequency.
NOTE
The preset from the factory is that the radio
automatically searches for the stations in the
area where you are driving (see section
"Radio station list").
But if you have changed over to manual tuning (by pressing the INFO button in the centre console when the station list was shown),
then the radio remains set in the function for
manual tuning the next time you switch on
the radio. To change back to the function for
"Radio station list", turn TUNE one step (to
show the complete list of stations) and press
the button INFO.
Note that if you press INFO when the station
list is not shown then INFO is activated. For
more information on this function, see Audio
and media - operating the system (p. 21).
* Option/accessory.
AUDIO AND MEDIA
Radio stations as presets
Frequently used radio stations are optimally
saved as presets in order to facilitate simple activation.
A list of pre-selected channels can be shown in
the screen*. To activate/deactivate the function,
in the normal view for the AM/FM source, press
OK/MENU and select Show presets.
Related information
•
Audio and media - operating the system
(p. 21)
Digital radio* (DAB)
10 station presets can be stored per wavelength.
DAB has 2 memories for presets: DAB1 and
DAB2. Storage of presets is performed by
means of a long press on the desired preset button, for more information see FM radio above.
The stored presets are selected using the preset
buttons.
Station presets.
AM6/FM radio
10 presets can be stored per wavelength (e.g.
FM1).
The stored presets are selected using the preset
buttons.
1.
Tune into a station, see Radio tuning (p. 29).
2.
Hold in one of the preset buttons for a few
seconds, the sound disappears during this
time and returns when the station is stored.
The preset button can now be used.
6 Does
A preset contains one channel but no subchannels. If a subchannel is being played and a preset
is saved then only the main channel is registered.
This is because subchannels are temporary. At
the next attempt to retrieve the preset, the channel which contained the subchannel will be
played. The preset is not dependent on the channel list.
A list of pre-selected channels can be shown in
the screen*. To activate/deactivate the function,
in the normal view for the DAB source, press
OK/MENU and select Show presets.
NOTE
The audio system's DAB system does not
support all functions in the DAB standard.
not apply to the V60 Twin Engine and S60L Twin Engine.
* Option/accessory.
31
AUDIO AND MEDIA
RDS functions
With RDS the radio can automatically change to
the strongest transmitter. RDS provides the
facility to receive e.g. traffic information (TP) and
to search for certain programme types (PTY).
RDS (Radio Data System) links FM transmitters
into a network. An FM transmitter in such a network sends information that gives an RDS radio
the following functions:
•
Automatically switches to a stronger transmitter if reception in the area is poor.
•
Searches for programme type, such as traffic
information or news.
•
Receives text information on current radio
programme.
NOTE
Some radio stations do not use RDS or only
selected parts of its functionality.
If a required programme type is located the radio
can switch stations interrupting the audio source
currently in use. For example, if the CD player is
in use, it is paused. The interrupting transmission
is played back at a preset volume (p. 35). The
radio returns to the previous audio source and
volume when the set programme type is no
longer broadcast.
The programme functions alarm (ALARM!), traffic
information (TP), news (NEWS), and programme
32
types (PTY) interrupt one another in order of priority, where alarm has the highest priority and
programme types has the lowest. For additional
programme interruption settings (EON Distant
and EON Local), see EON (p. 33). Press EXIT
to return to the interrupted audio source, press
OK/MENU to clear the message.
Alarms in the event of accidents
and disasters
Related information
The alarm cannot be temporarily interrupted or
deactivated.
•
Alarms in the event of accidents and disasters (p. 32)
•
•
Radio text (p. 35)
•
•
Automatic radio frequency update (AF)
(p. 36)
Regional radio programmes (REG) (p. 36)
Resetting RDS functions (p. 37)
The radio function is used to warn of serious
accidents and catastrophes.
The message ALARM! appears on the display
screen when an alarm message is transmitted.
Related information
•
RDS functions (p. 32)
AUDIO AND MEDIA
Traffic information (TP)
Enhanced Other Networks (EON)
News broadcasts
This function allows traffic information that is
broadcast within a set radio station's RDS network to break through.
EON is useful in urban areas with many regional
radio stations. It allows the distance between the
car and the radio station transmitter to determine
when programme functions should interrupt the
current audio source.
This function allows news broadcasts within a
set radio station's RDS network to break
through.
The TP symbol indicates that the function is activated. If the preset station can send traffic information then this is shown by TP glowing brightly
in the display screen, otherwise TP will be grey.
To activate/deactivate, in the normal view for
the FM source, press OK/MENU and select
TP.
–
TP from selected station/all stations
The radio can only interrupt for traffic information
from the selected station or all stations within the
RDS network.
To change, in the normal view for the FM
source, press OK/MENU and select
Advanced settings Set TP favourite.
–
Related information
•
7
–
To activate/deactivate, in the normal view for
the FM source, press OK/MENU and select
one of the options under Advanced
settings EON:
• Local – interrupts only if the radio station
transmitter is close.
•
Distant7
– interrupts if the station transmitter is far away, even if there is a lot of static.
Related information
•
The symbol NEWS shows that the function is
active.
–
To activate/deactivate, in the normal view for
the FM source, press OK/MENU and select
News settings News.
News from selected station/all stations
The radio can only interrupt for news from the
selected station or all stations in the RDS network.
–
RDS functions (p. 32)
To change, in the normal view for the FM
source, press OK/MENU and select News
settings Set news favourite.
Related information
•
RDS functions (p. 32)
RDS functions (p. 32)
Factory settings.
33
AUDIO AND MEDIA
Radio programme types (PTY)
The PTY function can be used to select one or
more radio programme types, such as Pop
Music and Serious Classical Music. After selecting a programme type, navigation only takes
place within the channels that are broadcasting
that type.
PTY can be selected for FM and DAB radio. The
PTY symbol is shown in the screen when the
function is active. This function allows programme types broadcast within a set station's
RDS network to break through.
PTY for FM radio
1.
2.
In the normal view for the FM source, activate
by pressing OK/MENU and first selecting
programme types under Advanced settings
PTY settings Select PTY.
Following which, the PTY function must be
activated by pressing OK/MENU and then
selecting Advanced settings PTY
settings Receive traffic bulletins from
other networks.
Deactivation of the PTY function is carried out in
the normal view for the FM source by pressing
OK/MENU and then Advanced settings PTY
settings Receive traffic bulletins from
other networks. Selected programme types
(PTY) are not reset.
34
Searching radio programme types
(PTY)
Resetting and removing PTY is carried out in the
normal view for the FM source by pressing
OK/MENU and then Advanced settings PTY
settings Select PTY Clear all.
This function searches the whole frequency
band for the selected radio programme type.
PTY for DAB radio
1.
In the normal view for the FM source, select
one or more PTY by pressing OK/MENU
and then Advanced settings PTY
settings Select PTY.
2.
Then press OK/MENU and select
Advanced settings PTY settings
Seek PTY.
Programme type is selected in the normal view
for the DAB source by pressing OK/MENU and
then PTY filtering. Exit this mode as follows:
–
Press EXIT.
> An indicator is shown in the screen when
PTY is activated.
In some cases DAB radio will exit PTY mode, see
DAB to DAB link (p. 38).
To finish searching, press EXIT.
–
Related information
•
Searching radio programme types (PTY)
(p. 34)
•
•
Show radio programme types (PTY) (p. 35)
•
Volume control for interrupting radio programme types (PTY) (p. 35)
RDS functions (p. 32)
To continue searching for another broadcast
of the selected programme types, press on
or
.
Related information
•
•
•
Radio programme types (PTY) (p. 34)
Show radio programme types (PTY) (p. 35)
RDS functions (p. 32)
AUDIO AND MEDIA
Show radio programme types (PTY)
Some radio stations broadcast information about
programme type and programme category. The
current station's radio programme type, e.g. Pop
Music and Serious Classical Music, can be
shown in the screen. PTY can be selected for
FM and DAB radio.
Show radio programme type for FM
radio
To activate/deactivate, in the normal view for
the FM source, press OK/MENU and select
Advanced settings PTY settings
Show PTY text.
–
Volume control for interrupting
radio programme types (PTY)
The interrupting programme types, e.g. NEWS or
TP, are heard at the volume selected for each
respective programme type. If the volume level is
adjusted during the programme interruption, the
new level is saved until the next programme
interruption.
Radio text
Certain RDS stations transmit information on
programme content, artists etc. This information
is shown in the display screen8. Radio text can
be shown for FM and DAB radio.
Radio text for FM radio
–
Related information
•
•
Radio programme types (PTY) (p. 34)
NOTE
RDS functions (p. 32)
Only one of the functions "Show radio text"
and "Show presets" can be activated at a
time. If one of them is activated when the
other is already activated, then the previously
activated function is deactivated automatically. Both functions can be deactivated.
Show radio programme type for DAB
radio
To activate/deactivate, in the normal view for
the DAB source, press OK/MENU and
select Advanced settings Show PTY
text.
–
Related information
•
•
•
8
Radio programme types (PTY) (p. 34)
To activate/deactivate, in the normal view for
the FM/DAB source, press OK/MENU and
select Show radio text.
Related information
•
•
RDS functions (p. 32)
Digital radio (DAB)* (p. 37)
Searching radio programme types (PTY)
(p. 34)
RDS functions (p. 32)
Only cars with 7-inch screen.
* Option/accessory.
35
AUDIO AND MEDIA
Automatic radio frequency update
(AF)
The function automatically selects the best frequency for the set radio station.
In order to find the best frequency the function
may, in exceptional cases, need to search the
entire FM wavelength.
To activate/deactivate, in the normal view for
the FM source, press OK/MENU and select
Advanced settings Alternative
frequency.
–
Related information
•
Regional radio programmes (REG)
Scan radio frequencies
This function causes the radio to continue with a
regional radio transmitter despite that its signal
strength is low.
The function automatically searches for available
radio channels and takes into account any programme type filtering (PTY).
The symbol REG shows that the function is
active.
When a station is found, it is played for
approx. 10 seconds before scanning is resumed.
When a station is playing back it is saved as a
preset in the usual way, see Radio stations as
presets (p. 31).
–
To activate/deactivate, in the normal view for
the FM source, press OK/MENU and select
Advanced settings REG.
Related information
•
–
RDS functions (p. 32)
RDS functions (p. 32)
To start scanning, in the normal view for the
FM/AM9/DAB* source, press OK/MENU
and select Scan.
NOTE
Scanning stops if a station is saved.
Scanning can also be selected in DAB-PTY
mode. In which case only channels of the preselected programme type are played.
Related information
•
•
9
36
Radio programme types (PTY) (p. 34)
Digital radio (DAB)* (p. 37)
Does not apply to the V60 Twin Engine and S60L Twin Engine.
* Option/accessory.
AUDIO AND MEDIA
Resetting RDS functions
Digital radio (DAB)*
All radio settings can be reset to the original factory settings.
DAB (Digital Audio Broadcasting) is a digital
broadcasting system for radio. The car supports
DAB, DAB+ and DMB.
–
To reset, in the normal view for the FM
source, press OK/MENU and select
Advanced settings Reset all FM
settings.
Digital radio (DAB)* - subchannel (p. 39)
Digital radio (DAB)* - resetting (p. 39)
NOTE
Coverage for DAB is not available in all locations. If there is no coverage then the message No reception is shown in the display
screen.
Related information
•
•
•
RDS functions (p. 32)
Service and Ensemble
•
Service - Channel, radio channel (only audio
services are supported by the system).
•
Ensemble - A collection of radio channels
on the same frequency.
Related information
•
Storing channel groups (Ensemble learn)
(p. 38)
•
Navigation in channel group list (Ensemble)
(p. 38)
•
•
•
•
•
•
•
Radio (p. 28)
Radio stations as presets (p. 31)
Scan radio frequencies (p. 36)
Radio programme types (PTY) (p. 34)
Radio text (p. 35)
DAB to DAB link (p. 38)
Digital radio (DAB)* - wavelength (p. 39)
* Option/accessory.
37
AUDIO AND MEDIA
Storing channel groups (Ensemble
learn)
Navigation in channel group list
(Ensemble)
Storage of channel groups (Ensemble learn) for
digital radio (DAB).
Navigation in the channel group list (Ensemble)
for digital radio (DAB).
When the vehicle is moved to a new broadcasting
area, programming of existing channel groups in
the area may be necessary.
To navigate in and access the channel group list
turn TUNE. The name of the Ensemble is shown
in the upper part of the display screen. When
switching to the new Ensemble the name
changes to the new one.
There may be a certain delay when changing
channel group. There may be a period of silence
between the current channel no longer being
available to the new channel becoming available.
•
–
Programming of channel groups creates an
updated list of all available channel groups. The
list is not updated automatically.
For programming, in the normal view for the
DABsource, press OK/MENU and select
Ensemble learn. Programming can also take
place as follows:
1.
Turn TUNE one step in either direction.
> Ensemble learn is shown in the list of
available channel groups.
2.
Press OK/MENU.
> New programming is started.
Service - Shows channels irrespective of the
channel group to which they are allocated.
The list can also be filtered using the selection of programme type (PTY filtering), see
Radio programme types (PTY) (p. 34).
DAB to DAB link
DAB to DAB linking means that the DAB radio
can go from one channel with poor or no reception to the same channel in another channel
group with better reception.
To activate/deactivate, in the normal view for
the DAB source, press OK/MENU and
select Advanced settings DAB linking.
Related information
•
Storing channel groups (Ensemble learn)
(p. 38)
•
•
Digital radio (DAB)* (p. 37)
Radio programme types (PTY) (p. 34)
Programming can be cancelled with EXIT.
Related information
•
•
38
Digital radio (DAB)* (p. 37)
Navigation in channel group list (Ensemble)
(p. 38)
* Option/accessory.
AUDIO AND MEDIA
Digital radio (DAB)* - wavelength
Digital radio (DAB)* - subchannel
Digital radio (DAB)* - resetting
DAB is transmitted on wavelength Band III.
Secondary components are usually named subchannels. These are temporary and can contain
e.g. translations of the main programme into
other languages.
All DAB settings can be reset to the original factory settings.
It is not certain that all channel groups will be
found.
–
In the normal view for the DAB source, wavelengths can be activated/deactivated by
pressing OK/MENU and then selecting
Advanced settings DAB band.
Related information
•
Digital radio (DAB)* (p. 37)
If one or more subchannels are broadcast then
the
symbol is shown to the left of the channel
name in the display screen. A subchannel is indicated by the - symbol appearing to the left of the
channel name in the display screen.
Press
–
Reset is performed in the normal view for the
DAB source by pressing OK/MENU and
then selecting Advanced settings Reset
all DAB settings.
Related information
•
Digital radio (DAB)* (p. 37)
to access the subchannels.
Subchannels can only be accessed on the
selected main channel and not on any other
channel without selecting it.
–
In the normal view for the DAB source, display of subchannels can be activated/deactivated by pressing OK/MENU and then
selecting Advanced settings Sub
channels.
* Option/accessory.
39
AUDIO AND MEDIA
Media player
CD/DVD*
The media player can playback audio and video
from CD/DVD* discs (p. 40) and externally
connected audio sources via the AUX/USB*
input (p. 47) or wirelessly stream audio files
from external devices via Bluetooth®. Certain
media players and have the option to communicate with a mobile phone* via Bluetooth®.
Media player (p. 40) can play back pre-recorded
and burned CD/DVD discs.
The media player supports and can play the following main types of discs and files:
Pre-recorded CD discs (CD Audio).
Starting playback of a disc
Burned CD discs with audio and/or video
files.
•
•
Pre-recorded DVD video discs.
Press the MEDIA button in the normal view for
the media source, turn TUNE until Disc is shown
and press OK/MENU. If there is a disc in the
media player then the disc starts playing back
automatically, otherwise Insert disc is shown in
the display screen. Then insert a disc, with text
side up. The disc starts to play back automatically.
Burned DVD discs with audio and/or video
files.
Related information
For operating the media player, see Operating
the system (p. 21).
Related information
•
•
•
•
40
Audio and media (p. 20)
For basic information on playback and navigation, see Operating the system (p. 21). See
below for a more detailed description.
•
•
For more information about the supported formats, see compatible file formats (p. 45).
Controls for the media player.
Playback and navigation of CD/
DVD* disc
•
Audio and media - operating the system
(p. 21)
•
Playback and navigation of CD/DVD* disc
(p. 40)
•
Playback and navigation of DVD* video discs
(p. 43)
If a disc with audio/video files is inserted into the
player then the disc's folder structure needs to
be loaded. Depending on the quality of the disc
and the quantity of information there may be a
certain delay before playback starts.
Disc eject
Press the eject button (p. 21) to eject the disc.
A disc remains in the ejected position for
about 12 seconds, after which it is inserted back
into the player for safety reasons.
Media Bluetooth®* (p. 51)
Pause in playback (pause)
Remote control* (p. 64)
When the volume is reduced entirely or MUTE is
pressed, the media player is paused. When the
volume is increased or MUTE is pressed again,
Media player - compatible file formats
(p. 45)
* Option/accessory.
AUDIO AND MEDIA
the media player starts. It is also possible to
pause via the menu system10, press OK/MENU
and select Play/Pause.
NOTE
A video film is only shown when the car is
stationary. When the car is moving at a speed
of over about 8 km/h no picture is shown and
No visual media available while driving
appears on the display screen, although the
audio is heard during this time. The picture is
shown again as soon as the car's speed falls
below about 6 km/h.
NOTE
Some audio files that are copy-protected by
record companies or privately copied audio
files cannot be loaded by the player.
•
•
Scan disc track or audio file (p. 43)
•
Media player - compatible file formats
(p. 45)
Random selection of disc track or audio file
(p. 43)
Playback and navigation of burned
discs with audio/video files*
Playback and navigation of burned discs with
audio/video files.
NOTE
A video film is only shown when the car is
stationary. When the car is moving at a speed
of over about 8 km/h no picture is shown and
No visual media available while driving
appears on the display screen, although the
audio is heard during this time. The picture is
shown again as soon as the car's speed falls
below about 6 km/h.
NOTE
Some audio files that are copy-protected by
record companies or privately copied audio
files cannot be loaded by the player.
Related information
•
Audio and media - operating the system
(p. 21)
•
Playback and navigation of burned discs with
audio/video files* (p. 41)
•
Playback and navigation of DVD* video discs
(p. 43)
•
Fast forward/reverse (p. 42)
10
11
Audio files have the symbol
, video files
have the symbol
and folders have the sym.
bol
When playback of a file is complete the playback
of the other files (of the same type) in that particular folder continues. Change11 of folder takes
place automatically when all the files in the cur-
Does not apply to CD Audio.
If Repeat folder is activated then this does not take place.
}}
* Option/accessory.
41
AUDIO AND MEDIA
||
rent folder have been played back. The system
automatically detects and changes setting when
a disc containing only audio files or only video
files is loaded into the media player and then
plays back these files. However, the system does
not change setting if a disc containing a mixture
of audio and video files is loaded into the media
player, but instead the player continues to play
back the previous file type.
Repeat folder
This function makes it possible to play files in a
folder over and over again. When the last file has
been played out, playback of the first file starts
again.
1.
Press OK/MENU
2.
Turn TUNE to Repeat folder
3.
Press OK/MENU to activate/deactivate the
function.
Related information
•
Audio and media - operating the system
(p. 21)
•
Playback and navigation of CD/DVD* disc
(p. 40)
•
Playback and navigation of DVD* video discs
(p. 43)
•
•
Fast forward/reverse (p. 42)
12
42
•
Random selection of disc track or audio file
(p. 43)
•
Media player - compatible file formats
(p. 45)
•
DivX® Video On Demand* (p. 45)
Fast forward/reverse
It is possible to fast forward/rewind audio and
video files12.
Hold the button for
/
depressed in
order to fast forward/rewind audio or video files
forward/backward.
Audio files are fast forwarded/rewound at one
speed, while video files can be fast forwarded/
rewound at several speeds. Repeatedly press the
/
to increase the fast forward/
buttons
rewind speed for video files. Release the button
to return to viewing at normal speed.
Related information
•
Audio and media - operating the system
(p. 21)
•
Playback and navigation of CD/DVD* disc
(p. 40)
•
Playback and navigation of external audio
source* (p. 49)
Scan disc track or audio file (p. 43)
Only applies to CD/DVD* discs, USB and iPod®.
* Option/accessory.
AUDIO AND MEDIA
Scan disc track or audio file
This function play backs the first ten seconds of
each disc track/audio file.13
To scan selected source:
1.
Press OK/MENU in the normal view for the
selected source
2.
Turn TUNE to Scan
> The first 10 seconds of each disc track or
audio file are played.
3.
Cancel the scan with EXIT, the disc track or
audio file being played back will continue
playing.
Random selection of disc track or
audio file
Playback and navigation of DVD*
video discs
This function plays the tracks/audio files in random order14.
When playing back a DVD video disc a disc
menu may appear on the display screen. The
disc menu gives access to additional functions
and settings, such as selecting subtitles, language and scene selection.
To listen to the tracks/audio files in random order
for the selected source:
1.
Press OK/MENU in the normal view for the
selected source
2.
Turn TUNE to Random
3.
Press OK/MENU to activate/deactivate the
function.
Related information
•
•
Audio and media - operating the system
(p. 21)
Audio and media - operating the system
(p. 21)
•
•
Playback and navigation of CD/DVD* disc
(p. 40)
Playback and navigation of CD/DVD* disc
(p. 40)
•
•
Playback and navigation of external audio
source* (p. 49)
Playback and navigation of external audio
source* (p. 49)
•
Media Bluetooth®* (p. 51)
Related information
•
13
14
Media
Bluetooth®*
For basic information on playback and navigation, see Operating the system (p. 21). See
below for a more detailed description.
NOTE
A video film is only shown when the car is
stationary. When the car is moving at a speed
of over about 8 km/h no picture is shown and
No visual media available while driving
appears on the display screen, although the
audio is heard during this time. The picture is
shown again as soon as the car's speed falls
below about 6 km/h.
(p. 51)
Does not apply to DVD video discs. For externally connected audio sources via the AUX/USB input this only applies to USB and iPod®. Not supported by all mobile phones.
Does not apply to DVD video discs. For externally connected audio sources via the AUX/USB input this only applies to USB and iPod®. Not supported by all mobile phones.
}}
* Option/accessory.
43
AUDIO AND MEDIA
||
Navigation in the DVD video disc's
menu
Navigation in the DVD video disc's menu is performed using the number keys in the centre console as illustrated above.
Changing chapter or title
Turn TUNE to access the list of chapters and
navigate through them (if the film is being played
back then it is paused). Press OK/MENU to
select the chapter, this also leads back to the
original position (if the film was being played
back then it is restarted). Press EXIT to access
the title list.
the selection and this leads back to the original
position (without any selection being made).
Camera angle for playback of DVD*
video discs
The chapter can also be changed by pressing on
/
on the centre console or the steering
wheel keypad*.
If the DVD video disc supports it, the function
can be used to choose from which camera position a particular scene should be shown.
Related information
In the normal view for the disc source, press
OK/MENU and select Advanced settings
Angle.
•
Audio and media - operating the system
(p. 21)
•
Playback and navigation of CD/DVD* disc
(p. 40)
•
Camera angle for playback of DVD* video
discs (p. 44)
•
Playback and navigation of burned discs with
audio/video files* (p. 41)
•
•
•
•
Related information
•
Audio and media - operating the system
(p. 21)
Fast forward/reverse (p. 42)
Scan disc track or audio file (p. 43)
Random selection of disc track or audio file
(p. 43)
Media player - compatible file formats
(p. 45)
Titles are selected in the title list by turning
TUNE and the selection is confirmed with OK/
MENU, this also leads back to the chapter list.
Press OK/MENU to activate the selection and
return to the start position. Use EXIT to cancel
44
* Option/accessory.
AUDIO AND MEDIA
DivX® Video On Demand*
Picture settings*
The media player can be registered to play back
files of the type DivX® VOD from CD-/DVD
discs, USB or iPod®.
You can adjust the display settings (when the
car is stationary) for brightness and contrast.
1.
In playback mode, press OK/MENU and
select Image settings, confirm with OK/
MENU.
2.
Turn TUNE to the adjustment option and
confirm with OK/MENU.
3.
Adjust the setting by turning TUNE and confirm with OK/MENU.
The code for registration can be found in the
menu system MY CAR, see MY CAR (p. 10).
For more information visit www.divx.com/vod.
Related information
•
Audio and media - operating the system
(p. 21)
•
Playback and navigation of DVD* video discs
(p. 43)
•
Playback and navigation of burned discs with
audio/video files* (p. 41)
The picture settings can be reset to factory settings with the Reset option.
•
Playback and navigation of external audio
source* (p. 49)
•
Audio and media - operating the system
(p. 21)
•
Audio and media (p. 20)
To return to the settings list, press the OK/
MENU or EXIT.
Media player - compatible file
formats
The media player can play back a variety of file
types and is compatible with the formats in the
following tables.
Compatible file formats for CD/DVD
discs
NOTE
Dual format, double-sided discs (DVD Plus,
CD-DVD format) are thicker than regular CD
discs and therefore playback cannot be guaranteed and malfunction may arise.
If a CD contains a mixture of MP3 and CDDA
tracks, all MP3s will be ignored.
Related information
Audio format
CD audio, mp3, wma, aac, m4a
Video format
CD video, DVD video, divx, avi,
asf
Compatible file formats via USB
connection
Audio and video files in the following table are
supported by the system for playback via the
USB connection.
Audio format
mp3, wma, aac, m4a
Video format
divx, avi, asf
}}
* Option/accessory.
45
AUDIO AND MEDIA
||
Technical data for file formats .avi
and .divx
For the file to be played back, the following criteria must be met:
DivX version
3, 4, 5, 5:2
Image size
32x32-720x576 pixels
kHz
kbps
MPEG-2 Layer 3 (MP3)
16
8–160
22.05
8–160
24
8–160
32
32–320A
MPEG-1 Layer 3 (MP3)
Video frame
rate
Up to 30 fps
44.1
32–320A
DivX standard
48
32–320A
Total
capacity
(total bit
rate)
Up to 4 Mbps on average, up
to 8 Mbps maximum (incl. video
bit rate and audio bit rate)
48
64–448
Audio format
MP3 (MPEG-1/2 Layer 3),
MPEG-1 (Layer 2), AC3 (Dolby
D)
Audio channels (ch)
AC3
A
Does not apply to 144 kbps.
Technical data for file format .asf
See table below for audio
specifications
2ch for MP3/MPEG-1, 5.1ch
for AC3
Audio specifications for file formats .avi
and .divx
46
Format
Format
kHz
kbps
MPEG-1 Layer 2
44.1
64–384
48
64–384
Audio sampling rate
8 kHz
Audio bit rate
16, 24, 32 or 40 kbps (for 8
kHz sampling)
Related information
•
Playback and navigation of CD/DVD* disc
(p. 40)
•
Playback and navigation of DVD* video discs
(p. 43)
•
Playback and navigation of burned discs with
audio/video files* (p. 41)
•
Playback and navigation of external audio
source* (p. 49)
For the file to be played back, the following criteria must be met:
Image size
32x32-720x576 pixels
Video frame
rate
Up to 30 fps
Total capacity
(total bit rate)
Up to 384 kbs (incl. video bit
rate and audio bit rate)
Audio format
ITU-T G.726
Audio channels (ch)
1ch
Stereo not supported
* Option/accessory.
AUDIO AND MEDIA
External audio source via AUX/
USB* input
An external audio source, e.g. an iPod® or MP3
player, can be connected (p. 48) to the audio
system.
USB memory
MP3 player
To facilitate the use of a USB memory stick, only
store music files on it. It takes a lot longer for the
system to load storage media that contains anything other than compatible music files.
Many MP3 players have their own file systems
that are not supported by the audio system. For
use in the system, an MP3 player must be set in
USB Removable device/Mass Storage
Device mode.
NOTE
The system supports mobile media compliant
with USB 2.0 and the FAT32 file system and
can handle 1000 folders with a maximum of
254 subfolders/files in every folder. The top
level, which can handle up to 1000 subfolders/files, is an exception to this.
NOTE
An audio source connected to the USB input can
be operated15 using the car's audio controls. A
device connected via the AUX input cannot be
controlled via the car.
An iPod® or MP3 player with rechargeable batteries is recharged (when the ignition is on or the
engine is running) if the device is plugged into
the USB connection.
15
When using a longer model USB memory
stick the use of a USB adapter cable is recommended. This is to avoid mechanical wear
to the USB input and the connected USB
memory stick.
iPod®
An iPod® is charged and supplied with power by
the USB connection via the player's connection
cable.
NOTE
The system only supports the playback of
audio files from iPod®.
NOTE
When an iPod® is used as audio source, the
car's infotainment system has a menu structure that is similar to the iPod® player's own
menu structure.
USB hub
It is possible to connect a USB hub to the USB
connection and thereby connect multiple USB
devices simultaneously. USB device selection is
carried out in the normal view for the USB source
by pressing OK/MENU and then selecting
Select USB device.
}}
Only applies to the media source connected via the USB connection.
* Option/accessory.
47
AUDIO AND MEDIA
||
Related information
•
Audio and media - operating the system
(p. 21)
•
Playback and navigation of external audio
source* (p. 49)
•
Setting the audio volume for external audio
source (p. 50)
Connecting an external audio
source via AUX/USB* input
An external audio source, e.g. an iPod® or MP3
player, can be connected to the audio system via
any of the connection points in the tunnel console.
The text Reading USB is shown in the screen
when the system is loading the storage media's
file structure. Depending on the file structure and
number of files there may be some delay before
loading is finished.
NOTE
The system supports most iPod® models produced in 2005 or later.
NOTE
To prevent damage to the USB connection,
this is shut off if the USB connection is shortcircuited or if a connected USB unit is taking
too much power (this may happen if the unit
connected does not meet the USB standard).
The USB connection is reactivated automatically the next time the ignition is turned on,
unless the fault persists.
Connection points for external audio sources.
To connect the audio source:
1.
2.
48
In the normal view for the media source,
press MEDIA, turn TUNE to the desired
audio source USB, iPod or AUX and press
OK/MENU.
> If USB is selected then Connect USB is
shown in the display screen.
Related information
•
External audio source via AUX/USB* input
(p. 47)
•
Playback and navigation of external audio
source* (p. 49)
Connect your audio source to one of the
connections in the tunnel console storage
compartment (see Connection points for
external audio sources(p. 48)).
* Option/accessory.
AUDIO AND MEDIA
Playback and navigation of external
audio source*
Playback and navigation of external audio
source16.
For basic information on playback and navigation,
see Operating the system (p. 21). See below for
a more detailed description.
, video files*
Audio files have the symbol
and folders have the symhave the symbol
bol
.
See Compatible file formats (p. 45) for information about file formats that are supported by the
media player.
When playback of a file is complete the playback
of the other files (of the same type) in that particular folder continues. Change17 of folder takes
place automatically when all the files in the current folder have been played back. The system
automatically detects and changes setting when
a device containing only audio files or only video
files is connected to the USB port and then it
plays back these files. However, the system does
not change setting if a device containing a mixture of audio and video files is connected to the
USB port, but instead the player continues to play
back the previous file type.
16
17
18
19
Search function16
The keypad on the control panel in the centre
console can be used to find a filename in the
current folder.
The search function is accessed either by turning
TUNE (to access the folder structure) or by
pressing one of the letter keys. As a letter or
character in a search string is entered you get
closer to your search target. After a few seconds
the search results are shown on the screen.
Pause
When the volume is reduced entirely or MUTE is
pressed, the media player is paused. When the
volume is increased or MUTE is pressed again,
the media player starts. It is also possible to
pause via the menu system19 by pressing
OK/MENU, selecting USB MENU and then
Play/Pause.
NOTE
A video film is only shown when the car is
stationary. When the car is moving at a speed
of over about 8 km/h no picture is shown and
No visual media available while driving
appears on the display screen, although the
audio is heard during this time. The picture is
shown again as soon as the car's speed falls
below about 6 km/h.
Start playback of a file by pressing OK/MENU.
Repeat folder18
This function makes it possible to play files in a
folder over and over again. When the last file has
been played out, playback of the first file starts
again.
1.
Press OK/MENU
2.
Turn TUNE to Repeat folder
3.
Press OK/MENU to activate/deactivate the
function.
Fast forward/reverse
For information, see Fast forward/rewind (p. 42).
Related information
•
Connecting an external audio source via
AUX/USB* input (p. 48)
•
External audio source via AUX/USB* input
(p. 47)
•
•
Scan disc track or audio file (p. 43)
Random selection of disc track or audio file
(p. 43)
Only applies to USB and iPod®.
If Repeat folder is activated then this does not take place.
Only applies to USB.
Does not apply to iPod®
}}
* Option/accessory.
49
AUDIO AND MEDIA
•
•
DivX® Video On Demand* (p. 45)
Picture settings* (p. 45)
Setting the audio volume for
external audio source
Set the volume for an external audio source
(p. 47). If the volume is too high or too low then
the quality of the sound may deteriorate.
Related information
•
Audio and media - advanced audio settings
(p. 27)
•
Audio and media - operating the system
(p. 21)
If an external audio source (e.g. an MP3 player or
iPod®) is connected to the AUX input then the
audio source that is connected can have a different volume than the audio system's internal volume (e.g. radio). Correct this by adjusting the volume of the input:
1.
In the normal view for the media source,
press the MEDIA button and turn TUNE to
AUX and wait a few seconds or press OK/
MENU.
2.
Press OK/MENU and then turn TUNE to
AUX input volume. Confirm with OK/
MENU.
3.
Turn TUNE to adjust the volume for the AUX
input.
NOTE
If the external audio source's volume is too
high or too low, the quality of the sound may
deteriorate. The audio quality may also be
impaired if the player is charged while the
infotainment system is in AUX mode. In which
case, avoid charging the player via the 12 V
socket.
50
* Option/accessory.
AUDIO AND MEDIA
Media Bluetooth®*
The car's media player is equipped with
Bluetooth® and can wirelessly play streaming
audio files from external devices with Bluetooth®,
such as mobile phones and PDAs.
the mobile phone's functions, see Bluetooth®
handsfree phone* (p. 55). Switch between the
main sources TEL and MEDIA to operate each
one's functions.
NOTE
The Bluetooth® media player must support
the Audio/Video Remote Control Profile
(AVRCP) and Advanced Audio Distribution
Profile (A2DP). The player should use AVRCP
version 1.3, A2DP 1.2. Otherwise some functions may not work.
Not all mobile phones and external media
players available in the market are fully compatible with the Bluetooth® function in the
car's media player. Volvo recommends that
you contact an authorised Volvo dealer for
information on compatible phones and external media players.
Media Bluetooth® functions, controls overview.
The device must first be registered and connected to the car (p. 52).
Navigation and control of the audio can be carried out via the centre console buttons or via the
steering wheel keypad*. In some external devices
it is also possible to change tracks from the
device.
To play back the audio the car's media player
must first be set in Bluetooth mode.
When a mobile phone is connected to the car, it
is also possible to remotely control a selection of
NOTE
The car's media player can only play the audio
files via the Bluetooth® function.
Related information
•
•
Scan disc track or audio file (p. 43)
Random selection of disc track or audio file
(p. 43)
Connecting and disconnecting a
Bluetooth® device*
The car is equipped with Bluetooth® and can
wirelessly communicate with other Bluetooth®
devices after registration and connection
(p. 52).
A maximum of ten Bluetooth® devices can be
registered. Registration is performed once per
device. After registration the device no longer
needs to be activated as visible/searchable.
When the Bluetooth® function is active and the
last device connected is in range it is connected
automatically to the car. When the car searches
for the last device connected its name is shown
in the display screen. To connect to another
device, press EXIT and select to change device
(p. 53).
When the Bluetooth® device is out of range of
the car it is automatically disconnected. It is also
possible to manually disconnect (p. 54) a
device. To deregister a Bluetooth® device from
the car, select Removing a Bluetooth® device*
(p. 55). The car will then not locate the device
automatically.
It is possible to have two Bluetooth® devices connected simultaneously. One phone and one
media device, which it is possible to switch
between (p. 53). It is also possible to call with
the phone and simultaneously stream audio files.
* Option/accessory.
}}
51
AUDIO AND MEDIA
||
Related information
•
Audio and media - operating the system
(p. 21)
•
•
Media Bluetooth®* (p. 51)
Bluetooth®
handsfree phone* (p. 55)
Registering a Bluetooth® device*
Bluetooth®
It is possible to have two
devices
connected simultaneously. One phone and one
media device, which it is possible to switch
between. It is also possible to call with the
phone and simultaneously stream audio files.
car, or search for the car from the external device.
If one option does not work then try with the
other.
If you are not already in the normal view for the
phone, press TEL in the centre console.
A maximum of ten Bluetooth® devices can be
registered. Registration is performed once per
device. After registration the device no longer
needs to be activated as visible/searchable.
NOTE
If the phone's operating system is updated
then it is possible that the registration of the
phone is interrupted. In which case, disconnect the phone, see Removing a Bluetooth®
device* (p. 55) and then reconnect it.
Connecting an external device takes place in different ways depending on whether or not the
device has been connected previously. The connection options below presume that this is the
first time the device is being connected (registered) and that no other device is connected. The
connection options show the connection of a
phone. Connecting a media device (p. 51) is performed in the same way, but starting from the
main source MEDIA.
There are two possible ways of connecting devices, either search for the external device from the
52
Example of normal view for the phone.
Alternative 1 - search for the external
device via the car's menu system
1.
Make the external device searchable/visible
via Bluetooth®, see the external device's
manual or www.volvocars.com.
2.
Press OK/MENU and follow the instructions
on the car's display screen.
> The external device is now connected and
can be controlled from the car.
Connection failed, press EXIT twice and connect
in accordance with Alternative 2.
* Option/accessory.
AUDIO AND MEDIA
Alternative 2 - Search for the car with
the Bluetooth® function of the external
device
1.
Make the car searchable/visible via
Bluetooth®. Turn TUNE to Phone settings,
confirm with OK/MENU, select
Discoverable and confirm with OK/MENU.
2.
Select My Volvo Car on the external device's screen and follow the instructions.
3.
Enter an optional PIN code into the external
device, then select the option to connect.
4.
Press OK/MENU and then enter the same
PIN code via the car's keypad in the centre
console.
When the external device is connected, the external device's Bluetooth® name is shown in the
car's display screen and the device can be controlled from the car.
Related information
•
Audio and media - operating the system
(p. 21)
•
Connecting and disconnecting a Bluetooth®
device* (p. 51)
Automatic connection of Bluetooth®
device*
Changing to another Bluetooth®
device*
When one, or several, Bluetooth® devices are
registered (p. 52) in the car, the last connected
device is connected automatically when it is in
range.
It is possible to change from a connected device
to another one if there are several devices in the
car. The device must first have been registered
(p. 52) to the car.
When the Bluetooth® function is active and the
last device connected is in range it is connected
automatically. When the car searches for the last
device connected its name is shown in the display screen. If the last connected device is not
available then the system will try to connect an
previously connected device.
Changing media device
1.
Check that the external device is searchable/
visible via Bluetooth®, see the manual for the
external device.
2.
In the normal view for the Bluetooth® media
source, press OK/MENU and select
Change device.
> The car searches for previously connected
devices. The external devices detected are
specified with their respective Bluetooth®
name in the screen.
3.
Select the device to be connected.
> Connection of the external device takes
place.
To connect to another device, press EXIT, select
to connect a new device (p. 52) or change to
another already registered device (p. 53).
Related information
•
Audio and media - operating the system
(p. 21)
•
Connecting and disconnecting a Bluetooth®
device* (p. 51)
Changing phone
1.
Check that the external device is searchable/
visible via Bluetooth®, see the manual for the
external device.
}}
* Option/accessory.
53
AUDIO AND MEDIA
||
2.
3.
In the normal view for the phone source,
press OK/MENU and select Change
phone.
> The car searches for previously connected
devices. The external devices detected are
specified with their respective Bluetooth®
name in the screen.
Select the device to be connected.
> Connection of the external device takes
place.
Related information
•
Audio and media - operating the system
(p. 21)
•
Connecting and disconnecting a Bluetooth®
device* (p. 51)
Disconnecting the Bluetooth®
device*
When the Bluetooth® device is out of range of
the car it is automatically disconnected. It is also
possible to disconnect a phone manually.
When the mobile phone has been disconnected
an ongoing call can be continued by using the
mobile phone's built-in microphone and speaker.
Related information
•
Audio and media - operating the system
(p. 21)
•
Connecting and disconnecting a Bluetooth®
device* (p. 51)
•
•
Media Bluetooth®* (p. 51)
Bluetooth® handsfree phone* (p. 55)
The handsfree function is deactivated when the
engine is switched off and the door is opened.
If you want to deregister a Bluetooth® device
from the car, select Remove Bluetooth® device
(p. 55). The car will then not locate the device
automatically.
Manual disconnection of phone
The phone can be manually disconnected in the
normal view for the phone source by pressing
OK/MENU and then selecting Disconnect
phone.
NOTE
Even when your mobile phone has been manually disconnected, some mobile phones may
automatically couple up to the last handsfree
unit connected, e.g. when a new call begins.
54
* Option/accessory.
AUDIO AND MEDIA
Removing a Bluetooth® device*
Bluetooth®
If you do not want a
device registered to the car any longer then it is possible to
remove (deregister) it from the car. The car will
then not locate the device automatically.
Bluetooth® handsfree phone*
A mobile phone equipped with Bluetooth® can
be connected wirelessly to the car.
Removing a media device
In the normal view for the Bluetooth® media
source, press OK/MENU and select Remove
Bluetooth device. Turn TUNE to select the
device to be removed, confirm with OK/MENU.
Activate
A short press on TEL activates/searches last
connected phone. If a phone is already connected, and TEL is pressed, a shortcut menu is
shown with commonly used menu options for the
phone. The
symbol indicates that a phone
is connected.
Removing a phone
In the normal view for the phone source, press
OK/MENU and select Remove Bluetooth
device. Turn TUNE to select the device to be
removed, confirm with OK/MENU.
Related information
•
Audio and media - operating the system
(p. 21)
•
Connecting and disconnecting a Bluetooth®
device* (p. 51)
•
•
Media Bluetooth®* (p. 51)
Bluetooth® handsfree phone* (p. 55)
NOTE
Only a selection of mobile phones are fully
compatible with the handsfree function. Volvo
recommends that you seek assistance from
an authorised Volvo dealer for information on
compatible phones.
Phone functions, controls overview.
The device must first be registered and connected to the car (p. 52).
The audio and media system acts as handsfree,
with the facility to remotely control a selection of
the mobile phone's functions. The mobile phone
can be operated by its own keys irrespective of
whether or not it is connected.
When a mobile phone is connected to the car, it
is also possible to stream audio files from the
phone or another Bluetooth®-connected media
device, see Media Bluetooth®* (p. 51). Switch
between the main sources TEL and MEDIA to
operate each one's functions.
To call
1.
Make sure that the
symbol appears at
the top of the screen and that the handsfree
function is in phone mode.
2.
Dial either the desired number or the speed
dial number (p. 62). Or in normal view turn
TUNE to the right to access the phone book,
and to the left for the call register for all calls.
For information on the phone book, see
Phone book* (p. 58).
3.
Press OK/MENU.
The call is interrupted with EXIT.
}}
* Option/accessory.
55
AUDIO AND MEDIA
||
Related information
•
Audio and media - operating the system
(p. 21)
•
Connecting and disconnecting a Bluetooth®
device* (p. 51)
•
•
Making and receiving calls* (p. 56)
•
Bluetooth® handsfree phone* overview
System overview for Bluetooth® handsfree
phone.
Bluetooth® handsfree phone* - audio settings (p. 57)
Making and receiving calls*
Functions for handling phone calls.
Incoming call
–
Refuse or end with EXIT.
Automatic answer
Bluetooth®* version information (p. 58)
The automatic answer function means that calls
are accepted automatically.
–
In the normal view for the phone source, one
press on OK/MENU during the current call gives
access to the following functions:
Mobile phone
Microphone
• Mute - audio system microphone is muted.
• Mobile phone - the call is transferred from
Steering wheel keypad
Centre console control panel
Related information
•
•
Audio and media - operating the system
(p. 21)
Connecting and disconnecting a
device* (p. 51)
To activate/deactivate, in the normal view for
the phone source, press OK/MENU and
select Call options Auto answer.
In call menu
System overview
56
Press OK/MENU to answer the call, even if
the audio system is in e.g. RADIO or MEDIA
mode.
Bluetooth®
handsfree to the mobile phone. For some
mobile phones the connection is interrupted.
This is normal. The handsfree function asks if
you want to reconnect.
• Dial number - option to call a third party
using the number keys (current call set in
standby).
* Option/accessory.
AUDIO AND MEDIA
Call lists
The call lists are copied to the handsfree function
at each new connection and are then updated
during the connection. In normal view, turn to the
left with TUNE to see the call register for All
calls .
In the normal view for the phone source, press
OK/MENU and select All calls to view all call
registers:
•
•
•
•
•
All calls
Missed calls
Answered calls
Dialled calls
Call duration
NOTE
Certain mobile phones show a list of the last
dialled numbers in reverse order.
is no number stored then this menu can be
reached with one long press on 1.
Bluetooth® handsfree phone* audio settings
Related information
•
Audio and media - operating the system
(p. 21)
It is possible to adjust the call volume, audio system volume and ring signal volume, and change
the ring tone.
•
•
Bluetooth® handsfree phone* (p. 55)
Phone call volume
Bluetooth® handsfree phone* - audio settings (p. 57)
•
Phone book* (p. 58)
The phone call volume can only be changed during a call. Use the steering wheel keypad* or turn
the VOL control.
Audio system volume
Providing there is no ongoing call taking place,
the audio system volume is controlled in the normal way by turning VOL.
If an audio source is active during an incoming
call then it can be muted automatically. To activate/deactivate, in the normal view for the phone
source, press OK/MENU and select Phone
settings Sounds and volume Mute
radio/media.
Voice mailbox
Ring volume
A speed dial number for the voice mailbox can be
programmed in the normal view for the phone
source, and then accessed later via a long press
on 1.
In the normal view for the phone source, press
OK/MENU and select Phone settings
Sounds and volume Ring volume. Adjust by
turning VOL, press OK/MENU to hear the audio
volume and press EXIT to save.
The voice mailbox number is changed in normal
view for the phone source by pressing
OK/MENU and selecting Call options
Voicemail number Change number. If there
Ring signals
The built-in ring signals for the handsfree function can be selected in the normal view for the
* Option/accessory.
}}
57
AUDIO AND MEDIA
||
phone source by pressing OK/MENU and then
selecting Phone settings Sounds and
volume Ring signals Ring signal 1 etc.
NOTE
For some mobile phones, the ringtone on the
phone connected will not be switched off
when one of the inbuilt signals for the handsfree system is used.
In order to select the connected phone's ring signal20, in the normal view for the phone source,
press OK/MENU and then select Phone
settings Sounds and volume Ring
signals Mobile phone ring signal
Related information
•
Audio and media - operating the system
(p. 21)
•
Bluetooth® handsfree phone* (p. 55)
20
58
Bluetooth®* version information
Phone book*
Show the car's current Bluetooth® version.
There are two phone books. These are combined in the car and are shown as a single
phone book.
The car's current Bluetooth® version can be seen
from the normal view in the main sources MEDIA
or TEL:
•
Press OK/MENU and select Bluetooth
software version in car.
•
Press OK/MENU and select Phone
settings Bluetooth software version in
car.
Related information
•
Audio and media - operating the system
(p. 21)
•
•
Bluetooth® handsfree phone* (p. 55)
Media Bluetooth®* (p. 51)
•
The car downloads the connected mobile
phone's phone book and only shows this
phone book when the mobile phone it was
downloaded from is connected.
•
The car also has a built-in phone book. This
contains all the contacts stored in the car
irrespective of which phone was connected
when saving them. These contacts are visible
for all users, regardless of the mobile phone
that is connected to the car. If a contact is
saved in the car then the symbol
is
shown in front of the contact in the phone
book.
NOTE
Changes made from the car to a record in the
mobile phone's telephone book will result in a
new record in the car's telephone book, i.e.
changes will not be saved to the phone. From
the car, this will now look like you have double
records, with different icons. Note also that
when a shortcut number is saved or a change
to a contact is made, this will result in a new
record in the car's phone book.
Not supported by all mobile phones.
* Option/accessory.
AUDIO AND MEDIA
All use of the phone book requires that the
symbol appears at the top of the screen and that
the handsfree function is in phone mode.
3.
Copy the mobile's phone book to the
car's phone book
The audio and media system stores a copy of
each registered mobile phone's phone book. The
phone book can be copied automatically to the
audio and media system during each connection.
–
To activate/deactivate the function, in the
normal view for the phone source, press
OK/MENU and select Phone settings
Download phone book.
If the phone book contains a ringing caller's contact information then this is shown in the screen.
Copy individual contact to the car's
phone book
There is also the option to copy an individual contact from the mobile phone's phone book to the
car.
1.
In the normal view for the phone source,
press OK/MENU and select Phone book
Search contact.
2.
Select the contact and press OK/MENU.
Press OK/MENU and then select Options
Copy to car memory.
> The symbol
is shown in front of the
saved contact in the car's phone book and
the contact is saved.
Related information
•
Audio and media - operating the system
(p. 21)
•
•
•
•
•
Bluetooth® handsfree phone* (p. 55)
Phone book* - speed dial numbers (p. 62)
Phone book* - receiving a vCard (p. 63)
Phone book* - memory status (p. 63)
Phone book* - clearing (p. 63)
Phone book* - quick search for
contacts
In the normal view for the phone source, turn
TUNE to the right to show a list of contacts.
Turn TUNE to select and press OK/MENU to
call.
Under the name of the contact is the phone
number that is selected by default. If the symbol
> appears to the right of the contact then there
are several phone numbers stored for the contact. Press OK/MENU to show the numbers.
Change and dial a number other than that
selected by default by turning TUNE. Press OK/
MENU to dial.
Search in the list of contacts by using the centre
console's keypad to key in the start of the contact's name. For the function of the buttons, see
Phone book* - character table keypad in centre
console (p. 60).
The list of contacts can also be accessed from
normal view by pressing and holding the button
on the centre console's keypad with the letter
that the contact searched for starts with. For
example, a long press on the button for 6 gives
instant access to that part of the list where the
contacts with the letter M are located.
Related information
•
Audio and media - operating the system
(p. 21)
•
Bluetooth® handsfree phone* (p. 55)
* Option/accessory.
59
AUDIO AND MEDIA
Phone book* - character table
keypad in centre console
Key
+0pw
Character table of possible characters for use in
the phone book.
Key
Function
#*
Phone book* - searching for
contacts
Searching for contacts in the phone book
(p. 58).
Function
Space . , - ? @ : ; / ( ) 1
ABCÅÄÆÀÇ2
DEFÈÉ3
Related information
•
Audio and media - operating the system
(p. 21)
•
•
Bluetooth® handsfree phone* (p. 55)
Phone book* (p. 58)
GHIÌ4
JKL5
Search contacts using the text wheel.
MNOÖØÑÒ6
Character list
PQRSß7
Changing the input mode (see following
table)
TUVÜÙ8
Phone book
WXYZ9
To search for or edit a contact, in the normal view
for the phone source, press OK/MENU and
select Phone book Search.
Shift between upper and lower
case letter.
60
* Option/accessory.
AUDIO AND MEDIA
NOTE
There is no text wheel for High Performance,
so TUNE cannot be used there to input characters: only the digit and letter buttons on the
control panel in the centre console can be
used for this.
1.
Turn TUNE to the desired letter, press OK/
MENU to confirm. The number and letter
buttons on the control panel in the centre
console can also be used.
2.
Continue with the next letter and so on. The
result of the search is shown in the phone
book (3).
3.
To change the input mode to numbers or
special characters, or to go to the phone
book, turn TUNE to one of the options (see
explanation in the table below) in the list for
changing the input mode (2), press OK/
MENU.
123/ABC
More
Change between letters and
numbers with OK/MENU.
Phone book* - new contact
Create new contact in the phone book.
Change to special characters
with OK/MENU.
Leads to the phone book (3).
Turn TUNE to select a contact,
press OK/MENU to see the
saved numbers and other information.
A short press on EXIT deletes an input character.
A long press on EXIT will clear all entered characters.
By pressing a number key in the centre console
when the text wheel is shown (see previous illustration), a new character list (1) is shown in the
screen. Continue repeatedly pressing the number
key to the desired letter and then release. Continue with the next letter and so on. When a button is depressed the entry is confirmed when
another button is depressed.
To enter a number, hold in the corresponding
number key.
Related information
•
Audio and media - operating the system
(p. 21)
•
Bluetooth® handsfree phone* (p. 55)
Entering letters for New contact.
Changing the input mode (see following
table).
Input field.
In the normal view for the phone source, new
contacts can be added by pressing OK/MENU
and then selecting Phone book New
contact.
NOTE
There is no text wheel for High Performance,
so TUNE cannot be used there to input characters: only the digit and letter buttons on the
control panel in the centre console can be
used for this.
* Option/accessory.
}}
61
AUDIO AND MEDIA
||
1.
2.
3.
4.
When the Name row is selected, press OK/
MENU to reach the input mode (illustration
above).
Turn TUNE to the desired letter, press OK/
MENU to confirm. The number and letter
buttons on the control panel in the centre
console can also be used.
123/AB
C
Change between letters and
numbers with OK/MENU.
More
Change to special characters with
OK/MENU.
OK
Save and go back to Add contact with OK/MENU.
Continue with the next letter and so on. The
name entered is shown in the input field (2)
in the screen.
Change between uppercase and
lowercase letters with OK/
MENU.
To change the input mode to numbers, special characters, change between uppercase/
lowercase letters, etc., turn TUNE to one of
the options (see explanation in the following
table) in the list (1) and then press OK/
MENU.
Press OK/MENU, the cursor
moves to the input field (2) at the
top of the display screen. The cursor can now be moved, with
TUNE, to the appropriate place to
e.g. insert new letters or delete
with EXIT. To be able to insert
new letters first go back to the
input mode, by pressing OK/
MENU.
When the name has been fully entered, select
OK in the list on the display screen (1) and press
OK/MENU. Now continue with the telephone
number in the same way as above.
When the telephone number has been entered,
press OK/MENU and select a telephone number
type (Mobile phone, Home, Work or General).
Press OK/MENU to confirm.
When all details have been filled in, select Save
contact in the menu to save the contact.
62
Phone book* - speed dial numbers
Store as speed dial number in the phone book
(p. 58) in order to easily dial a number or a contact.
In the normal view for the phone source, speed
dial numbers can be added by pressing
OK/MENU and then selecting Phone menu
Phone book Speed dial.
Dialling with speed dial numbers can be performed in phone mode using the number keys on
the keypad in the centre console, by pressing a
number key and then pressing OK/MENU. If
there is no contact stored on the speed dial number then an option is shown to save a contact to
the selected speed dial number.
Related information
•
Audio and media - operating the system
(p. 21)
•
Bluetooth® handsfree phone* (p. 55)
Related information
•
Audio and media - operating the system
(p. 21)
•
•
Bluetooth® handsfree phone* (p. 55)
Phone book* (p. 58)
* Option/accessory.
AUDIO AND MEDIA
Phone book* - receiving a vCard
Phone book* - memory status
Phone book* - clearing
Receiving electronic business cards (vCard) to
the car's phone book (p. 58).
Show phone book (p. 58) memory status.
Clear the car's built-in phone book (p. 58).
The memory status of the car's phone book and
the connected mobile phone's phone book can
be viewed in the normal view for the phone
source by pressing OK/MENU and then selecting Phone book Memory status.
The car's phone book can be deleted, this is carried out in the normal view for the phone source
by pressing OK/MENU and then selecting
Phone book Clear phone book.
It is possible to receive a vCard to the car's
phone book from other mobile phones (other
than the one currently connected to the car). In
order to allow this the car is set to visible mode
for Bluetooth®. The function is activated in the
normal view for the phone source by pressing
OK/MENU and then selecting Phone book
Receive vCard.
Related information
•
Audio and media - operating the system
(p. 21)
•
Bluetooth® handsfree phone* (p. 55)
NOTE
Related information
•
Audio and media - operating the system
(p. 21)
•
Bluetooth® handsfree phone* (p. 55)
Deleting the car's telephone book only deletes contacts in the car's telephone book.
Contacts in the mobile phone's phone book
are not deleted.
Related information
•
Audio and media - operating the system
(p. 21)
•
Bluetooth® handsfree phone* (p. 55)
* Option/accessory.
63
AUDIO AND MEDIA
Remote control*
aim the remote control at the IR receiver, which is
located to the right of the INFO button (p. 21) in
the centre console.
The remote control can be used for all functions
in the audio and media system. The remote control's buttons have the same functions as the
buttons in the centre console or steering wheel
keypad*.
WARNING
Keep loose objects such as mobile phones,
cameras, remote controls for accessories, etc.
in the glove compartment or other compartments. Otherwise they may injure people in
the car in the event of sudden braking or a
collision.
NOTE
Do not expose the remote control to direct
sunlight (e.g. on the instrument panel) - otherwise problems may arise with the batteries.
Related information
•
Audio and media - operating the system
(p. 21)
Corresponds to TUNE in the centre console.
When using the remote control, first press the
to position F. Then
remote control's button
64
* Option/accessory.
AUDIO AND MEDIA
Remote control* - functions
Key
Possible functions to be controlled using the
remote control.
Key
Function
Change between:
F = Front display screen
Change to navigation*
Scroll/fast rewind, change track/
song
Play/pause
Stop
Scroll/fast forward, change track/
song
Navigate up/down
Teletext*, On/Off
Related information
•
Audio and media - operating the system
(p. 21)
Volume, decrease
Change to radio source (e.g. FM1)
Change to Bluetooth® handsfree*
Function
Subtitles, selection of language for
text
Confirm selection or go to the
menu system for the selected
source
R = Rear right display screen*
Key
To previous, cancels function, deletes input characters
Navigate right/left
L = Rear left display screen*
Change to media source (Disc, TV*
etc.)
Function
Volume, increase
0-9
Preset channels, number and letter
input
Shortcuts for favourite setting
Information about the current programme, song, etc. Also used when
there is more information available
than can be shown in the display
screen
Selection of language for soundtrack
Menu
* Option/accessory.
65
AUDIO AND MEDIA
Remote control* - battery
replacement
How to replace the batteries in the remote control for the audio and media system.
NOTE
Battery life is normally 1-4 years and depends
on how much the remote control is used.
The remote control is powered by four batteries
of the AA/LR6 type.
Take along extra batteries for a long journey.
3.
Refit the cover.
NOTE
Be sure to dispose of the exhausted batteries
in an environmentally safe manner.
Audio and media - menu overview
Overview of possible options and settings in the
audio and media system menus.
RADIO
•
•
•
AM (p. 67)21
FM (p. 67)
DAB (p. 68)
MEDIA
•
•
•
•
•
•
•
CD Audio (p. 68)
CD/DVD Data (p. 69)
DVD Video (p. 69)
iPod®(p. 70)
USB (p. 70)
Media Bluetooth®(p. 71)
AUX (p. 71)
TEL
•
Bluetooth handsfree®(p. 72)
Related information
•
66
1.
Push down the catch on the battery cover
and slide the battery cover in the direction of
the infrared lens.
2.
Remove the used batteries, turn the new batteries in accordance with the symbols in the
battery compartment and fit them.
Audio and media - operating the system
(p. 21)
* Option/accessory.
AUDIO AND MEDIA
Menu overview - AM
Menu overview - FM
Overview of possible options and settings for
AM radio.
Overview of possible options and settings for
FM radio.
See page
Main menu FM1/FM2
See page
Show presets*
(p. 31)
TP
(p. 33)
Scan
(p. 36)
Show radio text
Main menu
AMA
Audio settings
See footnote
A
B
B
(p. 27)
21
(p. 26)
(p. 27)
(p. 35)
Equalizer*
(p. 27)
Show presets*
(p. 31)
Volume compensation
(p. 28)
Scan
(p. 36)
Reset all audio settings
(p. 26)
(p. 33)
(p. 27)
News settings
Equalizer*
(p. 27)
Advanced settings
Volume compensation
(p. 28)
REG
(p. 36)
Reset all audio settings
(p. 26)
Alternative frequency
(p. 36)
EON
(p. 33)
Set TP favourite
(p. 33)
PTY settings
(p. 34)
Related information
•
Audio settings
(p. 37)
Sound stage*
Sound stage*
Does not apply to the V60 Twin Engine and S60L Twin Engine.
The menu options for audio settings are the same for all audio
sources.
Reset all FM settings
Related information
•
Audio and media - menu overview (p. 66)
Audio and media - menu overview (p. 66)
Does not apply to the V60 Twin Engine and S60L Twin Engine.
* Option/accessory.
67
AUDIO AND MEDIA
Menu overview - Digital radio
(DAB)*
Overview of possible options and settings for
DAB radio.
Main menu DAB1*/DAB2*
See page
Ensemble learn
(p. 38)
PTY filtering
(p. 34)
Turn off PTY filtering
Reset all DAB settings
Audio settings
(p. 39)
(p. 26)
Sound stage*
(p. 27)
Equalizer*
(p. 27)
Volume compensation
(p. 28)
Reset all audio settings
(p. 26)
(p. 34)
Show radio text
(p. 35)
Show presets*
(p. 31)
Scan
(p. 36)
Menu overview - CD Audio
Overview of possible options and settings for
CD Audio.
Main menu CD Audio (Disc
menu)
See page
Random
(p. 43)
Scan
(p. 43)
Audio settings
(p. 26)
Sound stage*
(p. 27)
Audio and media - menu overview (p. 66)
Equalizer*
(p. 27)
Audio and media - operating the system
(p. 21)
Volume compensation
(p. 28)
Reset all audio settings
(p. 26)
Related information
•
•
Advanced settings
DAB linking
(p. 38)
DAB band
(p. 39)
Related information
68
Sub channels
(p. 39)
Show PTY text
(p. 34)
•
•
Audio and media - menu overview (p. 66)
Audio and media - operating the system
(p. 21)
* Option/accessory.
AUDIO AND MEDIA
Menu overview - CD/DVD* Data
Overview of possible options and settings for
CD/DVD Data.
Main menu CD/DVD Data
(Disc menu)
Play
Pause
See page
(p. 40)
Volume compensation
(p. 28)
Reset all audio settings
(p. 26)
Overview of possible options and settings for
DVD Video.
Main menu DVD Video (Disc
menu)
See page
Audio and media - menu overview (p. 66)
DVD disc menu
Audio and media - operating the system
(p. 21)
(p. 43)
Play/Pause/Continue
(p. 43)
Related information
•
•
Menu overview - DVD* Video
Stop
(p. 40)
Stop
(p. 43)
Random
(p. 43)
Subtitles
(p. 43)
Repeat folder
(p. 41)
Audio tracks
(p. 43)
Change subtitles
(p. 40)
Advanced settings
Change audio track
(p. 40)
Scan
(p. 43)
Audio settings
(p. 26)
Sound stage*
(p. 27)
Equalizer*
(p. 27)
Angle
(p. 44)
DivX® VOD code
(p. 45)
Audio settings
(p. 26)
Sound stage*
(p. 27)
Equalizer*
(p. 27)
}}
* Option/accessory.
69
AUDIO AND MEDIA
||
Volume compensation
(p. 28)
Reset all audio settings
(p. 26)
Menu overview - USB*
Overview of possible options and settings for
iPod®.
Overview of possible options and settings for
USB.
Main menu iPod
See page
Main menu USB
Pop-up menuA*video and TV*
Random
(p. 43)
Play
Press OK/MENU when a video file is being
played back or TV* is being shown in order to
access the pop-up menu.
Scan
(p. 43)
Audio settings
(p. 26)
Image settings
Source menu
See footnote B
DVD disc menu
See footnote C
DVD disc TOP menuC
A
B
C
•
•
Pause
(p. 45)
Sound stage*
(p. 27)
(p. 21)
See page
(p. 49)
Stop
(p. 49)
Random
(p. 43)
Repeat folder
(p. 49)
Equalizer*
(p. 27)
Select USB device
(p. 47)
(p. 43)
Volume compensation
(p. 28)
Change subtitles
(p. 49)
(p. 43)
Reset all audio settings
(p. 26)
Change audio track
(p. 49)
Scan
(p. 43)
Audio settings
(p. 26)
Only applies when playing back videos or displaying TV.
What is shown in the pop-up menu for the source menu
depends on what is being played back or displayed, it can be
e.g. CD/DVD data menu or USB menu.
Only applies to DVD video discs.
Related information
70
Menu overview - iPod®*
Audio and media - menu overview (p. 66)
Audio and media - operating the system
(p. 21)
Related information
•
•
Audio and media - menu overview (p. 66)
Audio and media - operating the system
(p. 21)
Sound stage*
(p. 27)
Equalizer*
(p. 27)
* Option/accessory.
AUDIO AND MEDIA
Volume compensation
(p. 28)
Reset all audio settings
(p. 26)
Related information
•
•
Audio and media - menu overview (p. 66)
Audio and media - operating the system
(p. 21)
Menu overview - Media Bluetooth®*
Menu overview - AUX
Overview of possible options and settings for
Media Bluetooth®.
Overview of possible options and settings for
AUX.
Main menu AUX
See page
AUX input volume
(p. 50)
Audio settings
(p. 26)
Main menu Media Bluetooth®
See page
Random
(p. 43)
Change device
(p. 53)
Remove Bluetooth device
(p. 55)
Sound stage*
(p. 27)
Scan
(p. 43)
Equalizer*
(p. 27)
Bluetooth software version in car
(p. 58)
Volume compensation
(p. 28)
Audio settings
(p. 26)
Reset all audio settings
(p. 26)
Sound stage*
(p. 27)
Equalizer*
(p. 27)
Related information
Volume compensation
(p. 28)
Reset all audio settings
(p. 26)
•
•
Audio and media - menu overview (p. 66)
Audio and media - operating the system
(p. 21)
Related information
•
•
Audio and media - menu overview (p. 66)
Audio and media - operating the system
(p. 21)
* Option/accessory.
71
AUDIO AND MEDIA
Menu overview - Bluetooth®
handsfree*
Receive vCard
(p. 63)
Overview of possible options and settings for
Bluetooth® handsfree.
Memory status
(p. 63)
Clear phone book
(p. 63)
Main menu Bluetooth® handsfree (Phone menu)
See page
All calls
(p. 56)
All calls
(p. 56)
Missed calls
(p. 56)
Answered calls
(p. 56)
Dialled calls
(p. 56)
Call duration
(p. 56)
Change phone
(p. 53)
Remove Bluetooth device
(p. 55)
Voicemail number
Disconnect phone
(p. 56)
(p. 54)
Related information
•
•
Audio and media - menu overview (p. 66)
Audio and media - operating the system
(p. 21)
Phone settings
Phone book
72
(p. 58)
Search
(p. 60)
New contact
(p. 61)
Speed dials
(p. 62)
Discoverable
(p. 52)
Sounds and volume
(p. 57)
Download phone book
(p. 58)
Bluetooth software version in
car
(p. 58)
Call options
Auto answer
(p. 56)
* Option/accessory.
AUDIO AND MEDIA
Licenses
A license is an agreement for the right to operate
a certain activity or the right to use someone
else's entitlement according to the terms and
conditions in the agreement. The following text is
Volvo's agreement with the manufacturer/developer.
Sensus software
This software uses parts of sources from clib2
and Prex Embedded Real-time OS - Source
(Copyright (c) 1982, 1986, 1991, 1993, 1994),
and Quercus Robusta (Copyright (c) 1990,
1993), The Regents of the University of
California. All or some portions are derived from
material licensed to the University of California by
American Telephone and Telegraph Co. or Unix
System Laboratories, Inc. and are reproduced
herein with the permission of UNIX System
Laboratories, Inc. Redistribution and use in
source and binary forms, with or without
modification, are permitted provided that the
following conditions are met: Redistributions of
source code must retain the above copyright
notice, this list of conditions and the following
disclaimer. Redistributions in binary form must
reproduce the above copyright notice, this list of
conditions and the following disclaimer in the
documentation and/or other materials provided
with the distribution. Neither the name of the
<ORGANIZATION> nor the names of its
contributors may be used to endorse or promote
products derived from this software without
specific prior written permission. THIS
SOFTWARE IS PROVIDED BY THE COPYRIGHT
HOLDERS AND CONTRIBUTORS "AS IS" AND
ANY EXPRESS OR IMPLIED WARRANTIES,
INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE
ARE DISCLAIMED. IN NO EVENT SHALL THE
COPYRIGHT OWNER OR CONTRIBUTORS BE
LIABLE FOR ANY DIRECT, INDIRECT,
INCIDENTAL, SPECIAL, EXEMPLARY, OR
CONSEQUENTIAL DAMAGES (INCLUDING,
BUT NOT LIMITED TO, PROCUREMENT OF
SUBSTITUTE GOODS OR SERVICES; LOSS OF
USE, DATA, OR PROFITS; OR BUSINESS
INTERRUPTION) HOWEVER CAUSED AND ON
ANY THEORY OF LIABILITY, WHETHER IN
CONTRACT, STRICT LIABILITY, OR TORT
(INCLUDING NEGLIGENCE OR OTHERWISE)
ARISING IN ANY WAY OUT OF THE USE OF
THIS SOFTWARE, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGE.
This software is based in part on the work of the
Independent JPEG Group.
This software uses parts of sources from
"libtess". The Original Code is: OpenGL Sample
Implementation, Version 1.2.1, released January
26, 2000, developed by Silicon Graphics, Inc. The
Original Code is Copyright (c) 1991-2000 Silicon
Graphics, Inc. Copyright in any portions created
by third parties is as indicated elsewhere herein.
All Rights Reserved. Copyright (C) [1991-2000]
Silicon Graphics, Inc. All Rights Reserved.
Permission is hereby granted, free of charge, to
any person obtaining a copy of this software and
associated documentation files (the "Software"),
to deal in the Software without restriction,
including without limitation the rights to use,
copy, modify, merge, publish, distribute,
sublicense, and/or sell copies of the Software,
and to permit persons to whom the Software is
furnished to do so, subject to the following
conditions: The above copyright notice including
the dates of first publication and either this
permission notice or a reference to http://
oss.sgi.com/projects/FreeB/ shall be included in
all copies or substantial portions of the Software.
THE SOFTWARE IS PROVIDED "AS IS",
WITHOUT WARRANTY OF ANY KIND,
EXPRESS OR IMPLIED, INCLUDING BUT NOT
LIMITED TO THE WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE AND
NONINFRINGEMENT. IN NO EVENT SHALL
SILICON GRAPHICS, INC. BE LIABLE FOR ANY
CLAIM, DAMAGES OR OTHER LIABILITY,
WHETHER IN AN ACTION OF CONTRACT,
TORT OR OTHERWISE, ARISING FROM, OUT
OF OR IN CONNECTION WITH THE SOFTWARE
OR THE USE OR OTHER DEALINGS IN THE
SOFTWARE. Except as contained in this notice,
the name of Silicon Graphics, Inc. shall not be
used in advertising or otherwise to promote the
sale, use or other dealings in this Software
}}
73
AUDIO AND MEDIA
||
without prior written authorization from Silicon
Graphics, Inc.
This software is based in parts on the work of the
FreeType Team.
This software uses parts of SSLeay Library:
Copyright (C) 1995-1998 Eric Young
([email protected]). All rights reserved
DivX®
DivX Certified® to play DivX® video. DivX®, DivX
Certified® and associated logos are registered
trademarks of DivX, Inc. and are used under
license. ABOUT DIVX VIDEO: DivX® is a digital
video format created by DivX, Inc. This is an
official DivX Certified device that plays DivX
video. Visit www.divx.com for more information
and software tools to convert your files into DivX
video.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX
Certified® device must be registered in order to
play DivX Video-on-Demand (VOD) content. To
generate the registration code, locate the DivX
74
VOD section in the device setup menu. Go to
http://vod.divx.com with this code to complete
the registration process and learn more about
DivX VOD. Covered by one or more of the
following U.S. Patents: 7,295,673; 7,460,668;
7,515,710; 7,519,274.
Related information
•
Volvo Sensus (p. 6)
AUDIO AND MEDIA
Type approval
Type approval for Bluetooth® module can be
read in the table.
}}
75
AUDIO AND MEDIA
||
Declaration of Conformity for Bluetooth® module
Country/
Area
Countries
in the EU:
Exporting country: Japan
Manufacturer: Alpine Electronics Inc.
Type of equipment: Bluetooth® device
For further information visit http://ec.europa.eu/enterprise/rtte/faq.htm #informing
76
AUDIO AND MEDIA
Country/
Area
Czech
Republic:
Alpine Electronics, Inc. tímto prohlašuje, že tento Bluetooth® Module je ve shodě se základními požadavky a dalšími příslušnými
ustanoveními směrnice 1999/5/ES.
Denmark:
Undertegnede Alpine Electronics, Inc. erklærer herved, at følgende udstyr Bluetooth® Module overholder de væsentlige krav og
øvrige relevante krav i direktiv 1999/5/EF.
Germany:
Hiermit erklärt Alpine Electronics, Inc., dass sich das Gerät Bluetooth® Module in Übereinstimmung mit den grundlegenden
Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet.
}}
77
AUDIO AND MEDIA
||
78
Country/
Area
Estonia:
Käesolevaga kinnitab Alpine Electronics, Inc. seadme Bluetooth® Module vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud
direktiivist tulenevatele teistele asjakohastele sätetele.
UK:
Hereby, Alpine Electronics, Inc., declares that this Bluetooth® Module is in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC.
Spain:
Por medio de la presente Alpine Electronics, Inc. declara que el Bluetooth® Module cumple con los requisitos esenciales y
cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
Greece:
Η
Α Α Η
Α
Α
Α Alpine Electronics, Inc. Η Ω
Α Α
Η
Bluetooth® Module
Η Α 1999/5/
Ω
Α
Ω
.
France:
Par la présente Alpine Electronics, Inc. déclare que l'appareil Bluetooth® Module est conforme aux exigences essentielles et aux
autres dispositions pertinentes de la directive 1999/5/CE.
Italy:
Con la presente Alpine Electronics, Inc. dichiara che questo Bluetooth® Module è conforme ai requisiti essenziali ed alle altre
disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.
Latvia:
Ar šo Alpine Electronics, Inc. deklarē, ka Bluetooth® Module atbilst Direktīvas 1999/5/EK būtiskajām prasībām un citiem ar to
saistītajiem noteikumiem.
Lithuania:
Šiuo Alpine Electronics, Inc. deklaruoja, kad šis Bluetooth® Module atitinka esminius reikalavimus ir kitas 1999/5/EB Direktyvos
nuostatas.
Netherlands:
Hierbij verklaart Alpine Electronics, Inc. dat het toestel Bluetooth® Module in overeenstemming is met de essentiële eisen en de
andere relevante bepalingen van richtlijn 1999/5/EG.
Malta:
Hawnhekk, Alpine Electronics, Inc., jiddikjara li dan Bluetooth® Module jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti
oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC.
Hungary:
Alulírott, Alpine Electronics, Inc. nyilatkozom, hogy a Bluetooth® Module megfelel a vonatkozó alapvetõ követelményeknek és az 1999/5/EC
irányelv egyéb elõírásainak.
AUDIO AND MEDIA
Country/
Area
Poland:
Niniejszym Alpine Electronics, Inc. oświadcza, że Bluetooth® Module jest zgodny z zasadniczymi wymogami oraz pozostałymi
stosownymi postanowieniami Dyrektywy 1999/5/EC.
Portugal:
Alpine Electronics, Inc. declara que este Bluetooth® Module está conforme com os requisitos essenciais e outras disposições da
Directiva 1999/5/CE.
Slovenia:
Alpine Electronics, Inc. izjavlja, da je ta Bluetooth® Module v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 1999/5/ES.
Slovakia:
Alpine Electronics, Inc. týmto vyhlasuje, že Bluetooth® Module spĺňa základné požiadavky a všetky príslušné ustanovenia Smernice 1999/5/ES.
Finland:
Alpine Electronics, Inc. vakuuttaa täten että Bluetooth® Module tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja
sitä koskevien direktiivin muiden ehtojen mukainen.
Sweden:
Härmed intygar Alpine Electronics, Inc. att denna Bluetooth® Module står I överensstämmelse med de väsentliga egenskapskrav
och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.
Iceland:
Alpine Electronics, Inc. hereby certifies that this Bluetooth® Module conforms to the essential characteristic requirements and other relevant
regulations of directive 1999/5/EC.
Norway:
Alpine Electronics, Inc. erklærer herved at utstyret Bluetooth® Module er i samsvar med de grunnleggende krav og øvrige relevante
krav i direktiv 1999/5/EF.
}}
79
AUDIO AND MEDIA
||
Country/
Area
China:
第十三条
进口和生产厂商在其产品的说明书或使用手册中,应刊印下述有关内容
1. 标明附件中所规定的技术指标和使用范围,说明所有控制
■ 使用频率
2.4 - 2.4835 GHz
■ 等效全向辐射
■ 最大
率(EIRP)
率谱密度
■ 载频容限
天线增益
天线增益
10dBi 时
≤100 mW 或≤20 dBm
①
≤20 dBm / MHz(EIRP) ①
率(对应载波±2.5 倍信道带宽以外)
≤-36 dBm / 100 kHz (30 - 1000 MHz)
≤-33 dBm / 100 kHz (2.4 - 2.4835 GHz)
≤-40 dBm / 1 MHz (3.4 - 3.53 GHz)
≤-40 dBm / 1 MHz (5.725 - 5.85 GHz)
≤-30 dBm / 1 MHz (其它 1 - 12.75 GHz)
2. 不得擅自更改发射频率
大发射
率(包括额外
3. 使用时不得对各种合法的无线电通信业
续使用
4. 使用微
率无线电设备,必须忍
5. 不得在飞机和机场附近使用
80
10dBi 时
20 ppm
■ 杂散发射(辐射)
•
•
•
•
•
调整及开关等使用方法
装射频
产生有害干扰
各种无线电业
率放大器),不得擅自外接天线或改用其它发射天线
一旦发现有干扰现象时,应立即停止使用,并采
的干扰或工业
科学及医疗应用设备的辐射干扰
措施消除干扰后方可继
AUDIO AND MEDIA
Country/
Area
Taiwan:
低効率電波輻射性電機管理辧法第十条
第十二條
經型式認證合格之低
率射頻電機,非經許可,公司
商號或使用者均不得擅自 變更頻率
大
率或變更原設計之特性及
能
第十四條
低 率射頻電機之使用不得影響飛航安全及干擾合法通信;經發現有干擾現象時, 應立即停用,並改善至無干擾時方得繼續使用 前
項合法通信,指依電信法規定 作業之無線電通信 低 率射頻電機須忍受合法通信或工業 科學及醫療用電波 輻射性電機設備之干
擾
}}
81
AUDIO AND MEDIA
||
Country/
Area
South
Korea:
제품 정보
Volvo Car Korea
신청자 코드: KCC-CMM-N25-IAM21L3, KCC-CMM-N25-IAM21L2 and KCC-CMM-N25-IAM21L1
제품 명: Bluetooth Audio Navigation Radio
모델 명: IAM2.1
산 날짜: March/2010
Alpine Electronics, Inc
Made in Japan
고객 정보
Volvo Car Korea
볼보자동차코리아
서울시 용산구 한남2동 726-173 볼보빌딩 4층
볼보자동차 고객센터 1588-1777
http://www.volvocars.com/kr
사용자 주의사항
※당해 무선설비는 전파혼신 가능성이 있으므로 인명안전과 관련된 서비스는 할 수 없습니다
82
AUDIO AND MEDIA
Country/
Area
The United Arab
Emirates:
South
Africa:
Jamaica:
Approved for use in Jamaica SMA EI: IAM2.1
Thailand:
This telecommunication equipment conforms to NTC technical requirement.
Oman
83
ALPHABETICAL INDEX
ALPHABETICAL INDEX
A
Alarm for accidents and disasters
Audio
settings
surround
B
32
26
20, 26
E
Battery
remote control
66
Equalizer
Bluetooth®
handsfree
media
microphone off
streaming audio
transfer call to mobile
55
51
56
51
56
Audio and media
introduction
manage the system
menu overview
menus
overview
20
21
66
21
20
Audio profile
27
C
audio system
functions
overview
26
20
Audio system
20
Calls
incoming
operation
55
55
Audio volume
external audio source
phone
phone/media player
ring signal, phone
speed/noise compensation
21
50
57
57
57
28
CD
40
Controls
centre console
21
AUX input
20, 47
27
I
Image settings
45
Infotainment system
source buttons
21
Infotainment system (Audio and media)
20
iPod®, connection
48
K
Keypad in the steering wheel
21
M
Making calls
55
D
Media,
Bluetooth®
51
DAB Radio
Media player
compatible file formats
40
45
Menu navigation audio and media
21
Microphone
56
28, 37
Digital radio (DAB)
37
DVD
40
85
ALPHABETICAL INDEX
Mobile phone
connect
handsfree
register phone
52
55
52
MY CAR
car settings
climate settings
driver support system
information
menu Option
search paths
system settings
10
13
17
14
17
11
11
16
R
Radio
DAB
28
28, 37
T
Traffic information (TP)
33
Type approval
Bluetooth®
75
U
Radio programme types (PTY)
34
RDS
32
USB, connection
48
Remote control
battery replacement
64
66
USB input
47
S
News broadcasts
33
Normal view
21
Sensus
Signal input, external
Steering wheel
keypad
P
86
56
52
V
N
Phone
connect
handsfree
incoming call
making calls
phone book
phone book, shortcut
receiving a call
register phone
Support
52
55
55
55
58
58
surround
Volvo Sensus
6
20, 47
21
7
20, 26
6
TP 23907 (English), AT 1717, MY18, Copyright © 2000-2017 Volvo Car Corporation
