SEN SUS IN F O TA IN ME N T VÄLKOMMEN! We hope you will enjoy many years of driving pleasure in your Volvo. The car has been designed for the safety and comfort of you and your passengers. Volvo is one of the world's safest passenger vehicles. Your Volvo is also designed to meet applicable safety and environmental requirements. In order to increase your enjoyment of your Volvo, we recommend that you read this supplement as well as the instructions and maintenance information in the owner's manual. The owner's manual is also available as a mobile app (Volvo Manual) and on the Volvo Cars support site (support.volvocars.com). TABLE OF CONTENTS INTRODUCTION AUDIO AND MEDIA 6 MY CAR 10 Audio and media 20 Volvo Sensus 6 MY CAR - search paths 11 Audio and media - overview 20 7 MY CAR - menu options 11 Audio and media - operating the system 21 MY CAR - car settings 13 Favourites 25 MY CAR - driving support system 14 Save as favourite 25 MY CAR - System options 16 Audio and media - audio settings 26 MY CAR - Climate settings 17 Audio and media - general audio settings 26 MY CAR Information 17 Audio and media - advanced audio settings 27 Setting the equaliser 27 Setting the audio profile 27 Setting the audio volume and automatic volume control 28 Radio 28 Radio tuning 29 Automatic radio tuning 29 Radio station list* 29 Manual radio tuning 30 Radio stations as presets 31 RDS functions 32 Alarms in the event of accidents and disasters 32 Traffic information (TP) 33 Enhanced Other Networks (EON) 33 News broadcasts 33 Volvo Cars support site 2 MY CAR Introduction Radio programme types (PTY) 34 Volume control for interrupting radio programme types (PTY) 34 Radio text 34 Playback and navigation of DVD* video discs 42 Camera angle for playback of DVD* video discs 43 DivX® Video On Demand* 43 Picture settings* 44 Automatic radio frequency update (AF) 35 Regional radio programmes (REG) 35 Resetting RDS functions 35 Media player - compatible file formats 44 Digital radio (DAB)* 36 45 Storing channel groups (Ensemble learn) 36 External audio source via AUX/USB* input Navigation in channel group list (Ensemble) 37 Connecting an external audio source via AUX/USB* input 46 DAB to DAB link 37 Playback and navigation of external audio source* 47 Digital radio (DAB)* - wavelength 37 48 Digital radio (DAB)* - subchannel 38 Setting the audio volume for external audio source Digital radio (DAB)* - resetting 38 Media player 38 CD/DVD* 39 Playback and navigation of CD/ DVD* disc 39 Playback and navigation of burned discs with audio/video files* 40 Fast forward/reverse Media Bluetooth®* 49 Making and receiving calls* 55 Bluetooth® 56 settings handsfree phone* - audio Bluetooth®* version information 56 Phone book* 57 Phone book* - quick search for contacts 58 Phone book* - character table keypad in centre console 58 Phone book* - searching for contacts 59 Phone book* - new contact 60 Phone book* - speed dial numbers 61 Phone book* - receiving a vCard 61 Phone book* - memory status 61 Phone book* - clearing 62 Remote control* 62 Remote control* - functions 63 Connecting and disconnecting a Bluetooth® device* 50 Registering a Bluetooth® device* 50 Remote control* - battery replacement 64 Automatic connection of Bluetooth® device* 51 Audio and media - menu overview 65 Menu overview - AM Changing to another Bluetooth® device* 65 52 Menu overview - FM 65 41 Disconnecting the Bluetooth® device* 52 Menu overview - Digital radio (DAB)* 66 Scan disc track or audio file 41 Removing a Bluetooth® device* 53 Menu overview - CD Audio 67 Random selection of disc track or audio file 42 Bluetooth® handsfree phone* 53 Menu overview - CD/DVD* Data 67 Bluetooth® 54 Menu overview - DVD* Video 68 handsfree phone* - overview 3 ALPHABETICAL INDEX Menu overview - iPod®* Menu overview - USB* 69 Menu overview - Media Bluetooth®* 69 Menu overview - AUX 70 Menu overview - 4 68 Bluetooth® handsfree* 70 Licenses 71 Type approval 73 Alphabetical Index 83 INTRODUCTION INTRODUCTION Introduction Owner's Manual in mobile devices This supplement is a supplement to the normal owner's manual for the car. Volvo Sensus Volvo Sensus is the heart of the personal Volvo experience and connects you with the car and outside world. Sensus provides information, entertainment and assistance when it is needed. Sensus consists of intuitive functions that both enhance the car journey and simplifies ownership of the car. In the event of uncertainty regarding any of the car's functions, consult the owner's manual in the first instance. For answers to additional questions it is recommended to contact a dealer or a representative of Volvo Car Corporation. The specifications, design features and illustrations in this supplement are not binding. We reserve the right to make modifications without prior notice. © Volvo Car Corporation Options/accessories All types of option/accessory are marked with an asterisk: *. In addition to standard equipment, the supplement also describes options (factory fitted equipment) and certain accessories (retrofitted extra equipment). The equipment described in the supplement is not available in all cars - they have different equipment depending on adaptations for the needs of different markets and national or local laws and regulations. In the event of uncertainty over what is standard or an option/accessory, contact a Volvo dealer. 6 NOTE The Owner's manual is available for download as a mobile application (applies for certain car models and mobile devices), see www.volvocars.com. The mobile application also includes video and searchable content and easy navigation between different sections. An intuitive navigation structure makes it possible to receive relevant support, information and entertainment when it is necessary, without distracting the driver. Sensus covers all the car's solutions that enable connection* to the outside world and provides you with intuitive control over all the car's capabilities. Volvo Sensus combines and presents many functions in several of the car's systems on the centre console's screen. With Volvo Sensus the car can be personalised by means of an intuitive user * Option/accessory. INTRODUCTION interface. Settings can be made in Car settings, Audio and media, Climate control, etc. Overview More information on your car is available on the Volvo Cars website and support site. With the centre console buttons and controls or the steering wheel's right-hand keypad* functions can be activated or deactivated and many different settings can be made. Support on the Internet Go to support.volvocars.com or use the QR code below to visit the page. The support page is available for most markets. With a press on MY CAR all settings related to the driving and control of the car are presented, such as City Safety, locks and alarm, automatic fan speed, setting the clock, etc. With a press on the respective function RADIO, *, NAV* and CAM1 other MEDIA, TEL*, sources, systems and functions can be activated, e.g. AM, FM, CD, DVD*, TV*, Bluetooth®*, navigation* and park assist camera*. For more information about all functions/ systems, see the relevant section in the owner's manual or its supplement. Volvo Cars support site Control panel in centre console. The figure is schematic - the number of functions and layout of the buttons both vary, depending on the equipment selected and the market. Navigation* - NAV, see separate supplement (Sensus Navigation). Audio and media - RADIO, MEDIA, TEL*, see the relevant section in this supplement. Function settings - MY CAR, see MY CAR (p. 10). Internet-connected car *, see the respective section in this supplement2. QR code that leads to the support page. The information on the support page is searchable and can also be subdivided into different categories. Available here is support for options related to e.g. Internet connected services and functions, Volvo On Call*, the navigation system* and apps. Video and step-by-step instructions explain different procedures, e.g. how the car is connected to the Internet via a mobile phone. Climate control system, see the Owner's Manual. Park assist camera - CAM1, see the Owner's Manual. 1 2 Applies to certain car models. Information only available if the car is equipped with this function. }} * Option/accessory. 7 INTRODUCTION || Downloadable information from the support page Maps For cars equipped with Sensus Navigation*, there is the facility to download maps from the support page. Apps For selected Volvo models from model year 2014 and 2015, the owner's manual is available in the form of an app. The Volvo On Call* app can also be accessed from here. Owner's manuals from previous model years Owner's manuals from previous model years are available here in PDF format. The Quick Guide and supplement can also be accessed from the support page. Select car model and model year in order to download the publication required. Contact On the support page there is contact information for customer support and the nearest Volvo dealer. Log in to the Volvo Cars website Create a personal Volvo ID and log in to www.volvocars.com. Once you are logged in you can get an overview of service, agreements and warranties, amongst other things. There is also information here about accessories and software adapted for your car model. 8 * Option/accessory. MY CAR MY CAR MY CAR and layout of the buttons both vary, depending on the equipment selected and the market. MY CAR is a menu source that handles many of the car's functions, e.g. City Safety™, locks and alarm, automatic fan speed, setting the clock, etc. MY CAR - opens the menu system MY CAR. OK/MENU - press the button in the centre console or the thumbwheel on the steering wheel to select/tick in the highlighted menu option or store the selected function in the memory. Certain functions are standard, others are optional - the range also varies depending on the market. TUNE - turn the knob in the centre console or the thumbwheel on the steering wheel to scroll up/down through the menu options. Operation Navigation in the menus is carried out using buttons in the centre console or with the steering wheel's right-hand keypad*. EXIT EXIT functions Depending on the function the cursor is on when EXIT is depressed briefly, and on which menu level, one of the following may occur: • • • • • phone call is rejected current function is interrupted input characters are deleted most recent selections are undone leads up in the menu system. A long press on EXIT leads to the normal view for MY CAR or if you are in the normal view, to the highest menu level (main source menu). Control panel in centre console and steering wheel keypad. The figure is schematic - the number of functions 10 * Option/accessory. MY CAR MY CAR - search paths MY CAR is a menu source that handles many of the car's functions, e.g. setting the clock, door mirrors and locks. Current menu level is shown at the top right of the centre console's screen. The search paths to the menu system's functions are specified on the form: Settings Car settings Lock settings Doors unlock Driver door, then all. The following is an example of how a function can be accessed and adjusted using the steering wheel keypad: 6. 7. Scroll between the options All doors and Driver door, then all and press the thumbwheel - the option is selected. Exit the programming by backing out of the menus incrementally with short presses on EXIT or with one long press. The procedure is the same for the centre console controls (p. 10): OK/MENU, EXIT and the TUNE knob. Related information • • MY CAR (p. 10) MY CAR - menu options (p. 11) MY CAR - menu options MY CAR is a menu source where many of the car's functions can be handled, e.g. setting the clock, door mirrors and locks. The following options are available in menu source MY CAR: • My S601 • Trip statistics2 • DRIVe3/Hybrid2 • Support systems • Settings My S601 1. Press the centre console button MY CAR. 2. Scroll to the desired menu, e.g. Settings , with the thumbwheel and then press the thumbwheel - a submenu opens. The screen shows a grouping of all of the car's driver support systems - these can be activated or deactivated here. 3. Scroll to the desired menu, e.g. Car settings and press the thumbwheel - a submenu opens. Trip statistics2 4. Scroll to Lock settings and press the thumbwheel - a new submenu opens. The screen shows the history as a bar chart with average consumption of electricity and fuel. 5. Scroll to Doors unlock and press the thumbwheel - a submenu of selectable functions opens. DRIVe3 1 2 3 Depending on car model. Applies to the V60 Twin Engine and S60L Twin Engine. Applies to the V40, V40 Cross Country, S60, S60L, V60, V60 Cross Country, XC60. MY CAR MY CAR MY CAR My S601 Trip statistics DRIVe }} 11 MY CAR || Parts of the Volvo DRIVe concept are described here, among other things. Select from among the following headings: • Start/Stop Here there is information about the Start/ Stop function. • Eco driving guide Tips, advice and a description of what it means to drive economically can be found here. Hybrid2 MY CAR Driver support system MY CAR The screen shows a summary of the current status of the car's driver support systems. Settings MY CAR • Driving modes The car's different drive modes are explained. • Eco driving guide Tips, advice and a description of what it means to drive economically can be found here. 2 Applies 12 to the V60 Twin Engine and S60L Twin Engine. Menus under settings • Car settings, see MY CAR - car settings (p. 13) • Driver support systems, see MY CAR driving support system (p. 14) • System options, see MY CAR - System options (p. 16) • Audio settings, see Audio and media - general audio settings (p. 26) Menu level 1 • Climate settings, see MY CAR - Climate Menu level 2 • Favourites (FAV) - link a normally used Hybrid The screen shows whether the motor or engine is driving the car and how the motive force is flowing. Settings The menus are structured as follows: settings (p. 17) function in MY CAR to FAV button, see Favourites (p. 25) Menu level 3 Information on the car's drive system is found here. Select from among the following headings: • Power flow Support systems Menu level 4 Shown here are the 4 first menu levels under Settings. Certain functions are standard, others are optional - the range also varies depending on the market. When selecting whether a function should be activated/On or deactivated/Off a square is displayed: On: Selected square. Off: Empty square. • Select On/Off with OK - then back out of the menu with EXIT. • Volvo On Call, described in a separate manual. • Information, see MY CAR Information (p. 17) Related information • • MY CAR (p. 10) MY CAR - search paths (p. 11) MY CAR MY CAR - car settings Car settings menu option in the MY CAR menu source handles many of the car's functions, e.g. Car key memory and Lock settings for doors. Car settings Car key memory Audible confirmation On On Off Off Reduced Guard Activate once Ask when exiting On Off Lock settings On Off Doors unlock All doors Driver door, then all Keyless entry All doors Any door Doors on same side Approach light duration Off 30 sec Side mirror settings 60 sec Fold mirrors 90 sec Tilt left mirror Automatic door locking Unlock confirmation light Tilt right mirror Light settings Interior light Floor lights Ambient light Ambient light colours Door lock confirmation light Home safe light duration Off 30 sec 60 sec 90 sec Triple indicator On Off On Off Both front doors }} 13 MY CAR || Temporary LH traffic Steering wheel force Low On Medium Off High or Temporary RH traffic Speed in infotainment display On On Off Off Active bending lights On Off Auxiliary lights On Off Tyre pressure system Warns if tyre pressure is too low Calibrate tyre pressure Tyre pressure system Calibrate tyre pressure Reset car settings All menus in Car settings are given original factory settings. Related information • • MY CAR (p. 10) MY CAR - menu options (p. 11) MY CAR - driving support system Driving support systems menu option in the MY CAR menu source handles functions such as e.g. Collision warning system and Lane keeping aid. Driver support systems Collision Warning On Off Warning distance Long Normal Short Warning sound On Off Lane Departure Warning Lane Departure Warning On Off 14 MY CAR On at start-up On Off Increased sensitivity On Off Lane Keeping Aid Lane Keeping Aid On Off Assistance alternatives Full function Speed alert On Off • • MY CAR (p. 10) MY CAR - menu options (p. 11) DSTC On Off City Safety On Off BLIS On Off Distance Alert Vibration only On Steering assist only Off Road Sign Information Related information Driver Alert On On Off Off 15 MY CAR MY CAR - System options The system settings menu option in the MY CAR menu source handles functions such as e.g. time and languages. Show help text On Off System options Explanatory text for the display screen's current content is shown with this option selected. Time Distance and fuel units The combined instrument panel's clock is adjusted here. MPG (UK) Time format km/l 12 h 24 h Screen saver On Off The display screen's current content fades out after a period of inactivity and is replaced by a blank screen if this option is selected. MPG (US) l/100km Temperature unit Celsius Fahrenheit Selects the unit for the display of outside temperature and setting of the climate control system. Volume levels The current screen content returns if any of the display screen's buttons or controls are actuated. Front park assist volume Language Phone ringing volume Selects language for menu texts. Rear park assist volume Reset system options All menus in System options are given original factory settings. 16 Related information • • MY CAR (p. 10) MY CAR - menu options (p. 11) MY CAR MY CAR - Climate settings Interior air quality system Climate settings menu option in the MY CAR menu source handles functions such as e.g. fan adjustment and recirculation. On Off MY CAR Information Information menu option in the MY CAR menu source handles functions such as Number of keys and VIN number. Climate settings Reset climate settings Information Automatic blower adjustment All menus in Climate settings are given original factory settings. Number of keys Normal High Low Recirculation timer On Off Automatic rear defroster Related information • • MY CAR (p. 10) MY CAR - menu options (p. 11) VIN number DivX® VOD code Bluetooth software version in car Related information • • MY CAR (p. 10) MY CAR - menu options (p. 11) On Off Auto start steering wheel heater On Off Auto start driver seat heater On Off 17 AUDIO AND MEDIA AUDIO AND MEDIA Audio and media Audyssey MultEQ* The audio and media system consists of radio (p. 28), media player (p. 38) as well as the option to communicate with mobile phone* (p. 53) . Information is presented on a 5-inch screen* in the upper section of the centre console. Functions can be controlled via buttons in the steering wheel, in the centre console below the screen or via a remote control* (p. 62) . If the audio and media system is active when the engine is switched off then it is automatically activated the next time the key is inserted into key position I or higher, and it continues with the same source (e.g. radio) as before the engine was switched off (the driver's door must be closed on cars with Keyless systems*). The audio and media system can be used for 15 minutes at a time without the remote control key being in the ignition switch by pressing the On/Off button. When the car is being started the audio and media system is switched off temporarily and continues when the engine has started. Audio and media - overview Overview of the audio and media system's different parts. The Audyssey MultEQ system has been used in the development and tuning of the sound to ensure a world-class sound experience. AUX and USB* inputs for external audio sources (p. 45) (e.g. iPod®). Steering wheel keypad*. 5-inch screen. Centre console control panel. NOTE Remove the remote control key from the ignition switch if the infotainment system is used when the engine is switched off. This is to avoid discharging the battery unnecessarily. 20 * Option/accessory. AUDIO AND MEDIA Audio and media - operating the system tions1 or chapter2. A long press fast forwards through disc tracks or searches for the next available radio station. The audio and media system is controlled from the centre console and partly from the steering wheel buttons. The information is presented on the screen in the upper section of the centre console. SOUND - press for access to audio settings (bass, treble, etc.). For more information, see general audio settings (p. 26) . VOL - raise or lower the volume. – ON/OFF/MUTE – short press starts the system and long press (until the screen is off) switches off. Note that the whole of the Sensus system (including navigation* and phone functions*) starts/switches off at the same time. Briefly press to mute the sound (MUTE) or restore the sound if it had been switched off. Disc insert and eject slot. Main sources – press to select the main source (e.g. RADIO, MEDIA). Last active source is shown (e.g. FM1). A new source view is selected if the main source button is pressed while in RADIO or MEDIA. If you are in TEL* or NAV* and press the main source button then a shortcut menu is shown with commonly used menu options. Disc eject. Scroll/fast wind/search – Short press scrolls between disc tracks, preset radio sta- 1 2 OK/MENU - press the thumbwheel in the steering wheel or the button in the centre Does not apply to DAB. Only applies to DVD discs. }} * Option/accessory. 21 AUDIO AND MEDIA || console to accept selections in menus. If you are in the normal view and press OK/MENU a menu is shown for the selected source (e.g. RADIO or MEDIA). Arrow to the right of the screen is shown when there are underlying menus. TUNE - turn the thumbwheel in the steering wheel or the knob in the centre console to scroll among tracks/folders, radio and TV* stations, phone contacts* or to navigate among choices on the display screen. INFO button to see the remaining information. EXIT – short press leads upwards in the menu system, interrupts current function, interrupts/rejects phone calls or erases entered characters. Long press leads to normal view, or if you are in normal view to the highest menu level (main source view), from where you can reach the same main source buttons located in the centre console (6). Preset buttons, input of numbers and letters. FAV - shortcut to a favourite setting. The button can be programmed for a commonly used function (e.g. FM, AUX). For more information, see favourites (p. 25). MUTE – press to switch off the radio/media audio or restore the audio if it has been switched off. INFO - If more information than can be shown on the screen is available, press the 22 * Option/accessory. AUDIO AND MEDIA Menus The example shows navigation to different functions when a disc is played back. (1) Main source button, (2) Normal view, (3) Shortcut/Source menu, (4) Quick menu, (5) Source menu. }} 23 AUDIO AND MEDIA || Main source button – press to change the main source or to show the Shortcut/Source menu in the active source. Normal view – normal mode for the source. Shortcut/Source menu – shows commonly used menu options in the main sources, e.g. TEL and MEDIA (accessed by pressing the active source's main source button (1)). Quick menu – fast mode when TUNE is turned, e.g. for changing disc tracks, radio station, etc. Source menu – for menu navigation (accessed by pressing OK/MENU). The appearance depends on the source, equipment in the car, settings, etc. Select main source by pressing a main source button (1) (RADIO, MEDIA, TEL). To navigate through the source menus, use the controls TUNE, OK/MENU, EXIT or the main source button (1). For available functions, see Audio and media menu overview (p. 65). 24 AUDIO AND MEDIA Favourites • Save (p. 25) frequently used functions as favourites. Possible functions that can be saved are within radio, media, reversing camera and menu source MY CAR where many of the car's functions are handled, e.g. setting the clock, door mirrors and locks. The function is then accessed easily by pressing the FAV button. In MEDIA mode: • • • • • • DAB1*/DAB2* DISC USB* iPod®* Bluetooth®* AUX TV* It is also possible to select and save a favourite for MY CAR, CAM* and NAV*. Favourites can also be selected and saved under MY CAR. Save as favourite Save frequently used functions as favourites (p. 25). The function can then be started easily by pressing the FAV button (p. 21). To save a function as a favourite: 1. Select a main source (e.g. RADIO, MEDIA). 2. Select a wavelength or source (FM1, Disc, etc.). 3. Press and hold the FAV button until the "favourites menu" is shown. 4. Turn TUNE to select an option from the list and press OK/MENU to save. > When the main source (e.g. RADIO, MEDIA) is active the saved function is available via a short press on FAV. Related information • • • • FAVThe button can be used to save functions that are used frequently so that the function can be started simply by pressing FAV. You can select a favourite (e.g. Equalizer) for each function in accordance with the following: Audio and media (p. 20) MY CAR (p. 10) Radio (p. 28) Media player (p. 38) Related information • • Audio and media (p. 20) MY CAR - car settings (p. 13) In RADIO mode: • • 3 AM3 FM1/FM2 Does not apply to the V60 Twin Engine and S60L Twin Engine. * Option/accessory. 25 AUDIO AND MEDIA Audio and media - audio settings The audio system is pre-calibrated for optimal sound reproduction, but can be adapted to your needs. Setting for optimal sound reproduction The audio system is pre-calibrated for optimum sound reproduction by means of digital signal processing. This calibration takes into account loudspeakers, amplifiers, passenger compartment acoustics, listener position etc. for each combination of car model and audio system. There is also a dynamic calibration that takes into account the position of the volume control, radio reception and vehicle speed. The controls explained in these operating instructions, e.g. Bass, Treble and Equalizer, are only intended for the user to be able to adapt the sound reproduction according to personal taste. Audio and media - general audio settings • Balance – Balance between the left and General audio settings for the audio and media system. • Subwoofer* - Bass speaker level. • DPL II surround level/4 – Level for sur- Press the SOUND button (p. 21) to access the audio settings menu (Bass, Treble, etc.). Scroll forward with SOUND or OK/MENU to your selection (e.g. Treble). Adjust the setting by turning TUNE and save the setting with OK/MENU. right-hand speakers. round. Related information • Audio and media - operating the system (p. 21) Continue pressing SOUND or OK/MENU to access other options: • Surround* - Can be set to the On/Off position. When On is selected, the system selects the setting for optimal sound reprothen duction. Normally DPLII and appear in the display screen. If the recording is made with Dolby Digital technology then playback will take place with this setting, then appears in the display screen. When Off is selected, 3-channel stereo is available. • Bass - Bass level. • Treble - Treble level. • Fader – Balance between the front and rear speakers. 4 26 Only when Surround is activated. * Option/accessory. AUDIO AND MEDIA Audio and media - advanced audio settings Setting the equaliser Setting the audio profile Set the equaliser* and adjust the volume separately for different radio frequencies or TV. Set the audio profile* and optimise your audio experience in accordance with your needs. 1. Press OK/MENU in the normal view for the media source in order to access Audio settings and select Equalizer. Setting the audio profile (p. 27) 2. Setting the audio volume and automatic volume control (p. 28) Select wavelength by turning TUNE and confirm with OK/MENU. 3. Adjust the audio settings by turning TUNE and confirm with OK/MENU. Continue in the same way with other wavelengths you want to change. The sound experience can be optimised for the driver's seat, both front seats or the rear seat. If there are passengers in both the front and rear seats then the option recommended is; both front seats. Access the options in the normal view for the media source by pressing OK/MENU and selecting Audio settings Sound stage. Adapt the audio settings for radio and media according to your requirements. The following functions can be adapted: • • • Setting the equaliser (p. 27) • Setting the audio volume for external audio source (p. 48) Related information • Audio and media - operating the system (p. 21) 4. When you have finished with audio settings, press EXIT to confirm and return to normal view. Related information • • Audio and media - audio settings (p. 26) Audio and media - operating the system (p. 21) Related information • Audio and media - advanced audio settings (p. 27) • Audio and media - operating the system (p. 21) * Option/accessory. 27 AUDIO AND MEDIA Setting the audio volume and automatic volume control Radio • It is possible to listen to the AM5 and FM radio frequencies, and in certain cases also digital radio (DAB)* (p. 36). Storing channel groups (Ensemble learn) (p. 36) • Navigation in channel group list (Ensemble) (p. 37) The audio system compensates for disrupting noises in the passenger compartment by increasing the volume in relation to the speed of the car. The compensation level can be set to low, medium, high or off. Select level in the normal view for the media source by pressing OK/MENU and then selecting Audio settings Volume compensation. • • • • • • • Radio stations as presets (p. 31) Related information Related information Set the audio compensation for excessive noise in the passenger compartment. • • Audio and media - advanced audio settings (p. 27) Audio and media - operating the system (p. 21) Controls for radio functions. For operating the radio, see Operating the system (p. 21). • • • Radio programme types (PTY) (p. 34) Radio text (p. 34) DAB to DAB link (p. 37) Digital radio (DAB)* - wavelength (p. 37) Digital radio (DAB)* - subchannel (p. 38) Digital radio (DAB)* - resetting (p. 38) Menu overview - AM (p. 65) Menu overview - FM (p. 65) Menu overview - Digital radio (DAB)* (p. 66) AM5/FM radio • • • • • Radio tuning (p. 29) Radio stations as presets (p. 31) RDS functions (p. 32) Radio programme types (PTY) (p. 34) Radio text (p. 34) Digital radio* (DAB) • 5 28 Digital radio (DAB)* (p. 36) Does not apply to the V60 Twin Engine and S60L Twin Engine. * Option/accessory. AUDIO AND MEDIA Radio tuning Automatic radio tuning Radio station list* The radio automatically compiles a radio station list* (p. 29) of the strongest radio stations whose signals it is currently receiving. It is possible to activate automatic (p. 29)- or manual (p. 30) radio tuning. Searches for the next/previous available station. The radio automatically compiles a radio station list of the strongest radio stations whose signals it is currently receiving. This enables you to find a station when you drive into an area where you do not know the radio stations and their frequencies. NOTE The reception is dependent both on how good the signal strength and signal quality are. The transmission may be disturbed by various factors such as tall buildings or the transmitter being far away. Coverage level can also vary depending on where in the country you are located. 1. Press RADIO, turn TUNE until the desired wavelength (e.g. FM1) is shown, press OK/ MENU. 2. / in the centre console (or Hold in in the steering wheel keypad*). The radio searches for the next/previous available station. To go to the list and select a station: 1. Select the desired wavelength (e.g. FM1). 2. Turn TUNE one step in either direction. This displays the list of all stations in the area. The currently tuned station is indicated with enlarged text in the list. 3. Turn TUNE again in either direction to select a station from the list. 4. Confirm your choice by pressing OK/MENU. }} * Option/accessory. 29 AUDIO AND MEDIA NOTE Manual radio tuning • The list only shows the frequencies of stations that are currently being received, not a complete list of all radio frequencies on the selected wavelength. The radio automatically compiles a radio station list* (p. 29), but it is possible to perform radio tuning manually. • If the signal from the currently received station is weak, this may prevent the radio from updating the station list. If this occurs, press the INFO button (while the station list is shown in the display screen) in order to change to manual tuning and set a frequency. If the station list is no longer shown, turn TUNE one step in either direction to show the list again, and press INFO to switch. The list disappears from the display screen after a few seconds. If the station list is no longer shown, turn TUNE one step in either direction and press the INFO button in the centre console to change to manual tuning (p. 30) (or to return from manual tuning to the function for Station list). 30 The preset from the factory is that the radio shows the station list of the strongest stations in the area when you turn TUNE. When the radio station list is shown, press the INFO button in the centre console to change to manual tuning. This allows you to select a frequency from the list of all available radio frequencies in the selected wavelength. In other words, if turn TUNE one step in a manual search the frequency is changed from e.g. 93.3 to 93.4 MHz, etc. To manually select a station: 1. Press the RADIO button, turn TUNE until the desired wavelength (e.g. FM1) is shown, press OK/MENU. 2. Turn TUNE to select a frequency. NOTE The preset from the factory is that the radio automatically searches for the stations in the area where you are driving (see section "Radio station list"). But if you have changed over to manual tuning (by pressing the INFO button in the centre console when the station list was shown), then the radio remains set in the function for manual tuning the next time you switch on the radio. To change back to the function for "Radio station list", turn TUNE one step (to show the complete list of stations) and press the button INFO. Note that if you press INFO when the station list is not shown then INFO is activated. For more information on this function, see Audio and media - operating the system (p. 21). * Option/accessory. AUDIO AND MEDIA Radio stations as presets Frequently used radio stations are optimally saved as presets in order to facilitate simple activation. A list of pre-selected channels can be shown in the screen*. To activate/deactivate the function, in the normal view for the AM/FM source, press OK/MENU and select Show presets. Related information • Audio and media - operating the system (p. 21) Digital radio* (DAB) 10 station presets can be stored per wavelength. DAB has 2 memories for presets: DAB1 and DAB2. Storage of presets is performed by means of a long press on the desired preset button, for more information see FM radio above. The stored presets are selected using the preset buttons. Station presets. AM6/FM radio 10 presets can be stored per wavelength (e.g. FM1). The stored presets are selected using the preset buttons. 1. Tune into a station, see Radio tuning (p. 29). 2. Hold in one of the preset buttons for a few seconds, the sound disappears during this time and returns when the station is stored. The preset button can now be used. 6 Does A preset contains one channel but no subchannels. If a subchannel is being played and a preset is saved then only the main channel is registered. This is because subchannels are temporary. At the next attempt to retrieve the preset, the channel which contained the subchannel will be played. The preset is not dependent on the channel list. A list of pre-selected channels can be shown in the screen*. To activate/deactivate the function, in the normal view for the DAB source, press OK/MENU and select Show presets. NOTE The audio system's DAB system does not support all functions in the DAB standard. not apply to the V60 Twin Engine and S60L Twin Engine. * Option/accessory. 31 AUDIO AND MEDIA RDS functions RDS allows the radio to switch automatically to the strongest transmitter. RDS allows you to get traffic information (TP), for example. RDS (Radio Data System) links FM transmitters into a network. An FM transmitter in such a network sends information that gives an RDS radio the following functions: • Automatically switches to a stronger transmitter if reception in the area is poor. • Searches for programme type, such as traffic information or news. • Receives text information on current radio programme. NOTE Some radio stations do not use RDS or only selected parts of its functionality. If a required programme type is located the radio can switch stations interrupting the audio source currently in use. For example, if the CD player is in use, it is paused. The interrupting transmission is played back at a preset volume (p. 34). The radio returns to the previous audio source and volume when the set programme type is no longer broadcast. The programme functions alarm (ALARM!) traffic information (TP) and news (NEWS) interrupt one another in order of priority, where alarm has the 32 highest priority. For additional programme interruption settings (EON Distant and EON Local), see EON (p. 33). Press EXIT to return to the interrupted audio source, press OK/MENU to clear the message. Related information • Alarms in the event of accidents and disasters (p. 32) • • Radio text (p. 34) • • Automatic radio frequency update (AF) (p. 35) Regional radio programmes (REG) (p. 35) Resetting RDS functions (p. 35) Alarms in the event of accidents and disasters The radio function is used to warn of serious accidents and catastrophes. The message ALARM! appears on the display screen when an alarm message is transmitted. The alarm cannot be temporarily interrupted or deactivated. Related information • RDS functions (p. 32) AUDIO AND MEDIA Traffic information (TP) Enhanced Other Networks (EON) News broadcasts This function allows traffic information that is broadcast within a set radio station's RDS network to break through. EON is useful in urban areas with many regional radio stations. It allows the distance between the car and the radio station transmitter to determine when programme functions should interrupt the current audio source. This function allows news broadcasts within a set radio station's RDS network to break through. The TP symbol indicates that the function is activated. If the preset station can send traffic information then this is shown by TP glowing brightly in the display screen, otherwise TP will be grey. To activate/deactivate, in the normal view for the FM source, press OK/MENU and select TP. – – • Local – interrupts only if the radio station transmitter is close. TP from selected station/all stations The radio can only interrupt for traffic information from the selected station or all stations within the RDS network. To change, in the normal view for the FM source, press OK/MENU and select Advanced settings Set TP favourite. – Related information • 7 To activate/deactivate, in the normal view for the FM source, press OK/MENU and select one of the options under Advanced settings EON: • Distant7 – interrupts if the station transmitter is far away, even if there is a lot of static. Related information • The symbol NEWS shows that the function is active. – To activate/deactivate, in the normal view for the FM source, press OK/MENU and select News settings News. News from selected station/all stations The radio can only interrupt for news from the selected station or all stations in the RDS network. – RDS functions (p. 32) To change, in the normal view for the FM source, press OK/MENU and select News settings Set news favourite. Related information • RDS functions (p. 32) RDS functions (p. 32) Factory settings. 33 AUDIO AND MEDIA Radio programme types (PTY) The PTY function can be used to select one or more radio programme types, such as Pop Music and Serious Classical Music. After selecting a programme type, navigation only takes place within the channels that are broadcasting that type. PTY can be selected for DAB radio. The PTY symbol is shown in the screen when the function is active. This function allows programme types broadcast within a set station's RDS network to break through. Volume control for interrupting radio programme types (PTY) The interrupting programme types, e.g. NEWS or TP, are heard at the volume selected for each respective programme type. If the volume level is adjusted during the programme interruption, the new level is saved until the next programme interruption. Radio text Certain RDS stations transmit information on programme content, artists etc. This information is shown in the display screen8. Radio text can be shown for FM and DAB radio. Radio text for FM radio – Related information • • Radio programme types (PTY) (p. 34) NOTE RDS functions (p. 32) Only one of the functions "Show radio text" and "Show presets" can be activated at a time. If one of them is activated when the other is already activated, then the previously activated function is deactivated automatically. Both functions can be deactivated. PTY for DAB radio Programme type is selected in the normal view for the DAB source by pressing OK/MENU and then PTY filtering. Exit this mode as follows: Press EXIT. > An indicator is shown in the screen when PTY is activated. – In some cases DAB radio will exit PTY mode, see DAB to DAB link (p. 37). To activate/deactivate, in the normal view for the FM/DAB source, press OK/MENU and select Show radio text. Related information • • RDS functions (p. 32) Digital radio (DAB)* (p. 36) Related information • Volume control for interrupting radio programme types (PTY) (p. 34) • RDS functions (p. 32) 8 34 Only cars with 7-inch screen. * Option/accessory. AUDIO AND MEDIA Automatic radio frequency update (AF) The function automatically selects the best frequency for the set radio station. In order to find the best frequency the function may, in exceptional cases, need to search the entire FM wavelength. – To activate/deactivate, in the normal view for the FM source, press OK/MENU and select Advanced settings Alternative frequency. Related information • Regional radio programmes (REG) Resetting RDS functions This function causes the radio to continue with a regional radio transmitter despite that its signal strength is low. All radio settings can be reset to the original factory settings. The symbol REG shows that the function is active. – To activate/deactivate, in the normal view for the FM source, press OK/MENU and select Advanced settings REG. – To reset, in the normal view for the FM source, press OK/MENU and select Advanced settings Reset all FM settings. Related information • RDS functions (p. 32) Related information • RDS functions (p. 32) RDS functions (p. 32) 35 AUDIO AND MEDIA Digital radio (DAB)* DAB (Digital Audio Broadcasting) is a digital broadcasting system for radio. The car supports DAB, DAB+ and DMB. NOTE Coverage for DAB is not available in all locations. If there is no coverage then the message No reception is shown in the display screen. Service and Ensemble • Service - Channel, radio channel (only audio services are supported by the system). • Ensemble - A collection of radio channels on the same frequency. • Digital radio (DAB)* - resetting (p. 38) Storing channel groups (Ensemble learn) Storage of channel groups (Ensemble learn) for digital radio (DAB). When the vehicle is moved to a new broadcasting area, programming of existing channel groups in the area may be necessary. Programming of channel groups creates an updated list of all available channel groups. The list is not updated automatically. For programming, in the normal view for the DABsource, press OK/MENU and select Ensemble learn. Programming can also take place as follows: 1. Turn TUNE one step in either direction. > Ensemble learn is shown in the list of available channel groups. Press OK/MENU. > New programming is started. Related information 36 • Storing channel groups (Ensemble learn) (p. 36) 2. • Navigation in channel group list (Ensemble) (p. 37) Programming can be cancelled with EXIT. • • • • • • • Radio (p. 28) Radio stations as presets (p. 31) Radio programme types (PTY) (p. 34) Radio text (p. 34) Related information • • Digital radio (DAB)* (p. 36) Navigation in channel group list (Ensemble) (p. 37) DAB to DAB link (p. 37) Digital radio (DAB)* - wavelength (p. 37) Digital radio (DAB)* - subchannel (p. 38) * Option/accessory. AUDIO AND MEDIA Navigation in channel group list (Ensemble) Navigation in the channel group list (Ensemble) for digital radio (DAB). To navigate in and access the channel group list turn TUNE. The name of the Ensemble is shown in the upper part of the display screen. When switching to the new Ensemble the name changes to the new one. • Service - Shows channels irrespective of the channel group to which they are allocated. The list can also be filtered using the selection of programme type (PTY filtering), see Radio programme types (PTY) (p. 34). DAB to DAB link Digital radio (DAB)* - wavelength DAB to DAB linking means that the DAB radio can go from one channel with poor or no reception to the same channel in another channel group with better reception. DAB is transmitted on wavelength Band III. There may be a certain delay when changing channel group. There may be a period of silence between the current channel no longer being available to the new channel becoming available. – To activate/deactivate, in the normal view for the DAB source, press OK/MENU and select Advanced settings DAB linking. It is not certain that all channel groups will be found. – In the normal view for the DAB source, wavelengths can be activated/deactivated by pressing OK/MENU and then selecting Advanced settings DAB band. Related information • Digital radio (DAB)* (p. 36) Related information • Storing channel groups (Ensemble learn) (p. 36) • • Digital radio (DAB)* (p. 36) Radio programme types (PTY) (p. 34) * Option/accessory. 37 AUDIO AND MEDIA Digital radio (DAB)* - subchannel Digital radio (DAB)* - resetting Media player Secondary components are usually named subchannels. These are temporary and can contain e.g. translations of the main programme into other languages. All DAB settings can be reset to the original factory settings. The media player can playback audio and video from CD/DVD* discs (p. 39) and externally connected audio sources via the AUX/USB* input (p. 45) or wirelessly stream audio files from external devices via Bluetooth®. Certain media players and have the option to communicate with a mobile phone* via Bluetooth®. If one or more subchannels are broadcast then symbol is shown to the left of the channel the name in the display screen. A subchannel is indicated by the - symbol appearing to the left of the channel name in the display screen. Press – Reset is performed in the normal view for the DAB source by pressing OK/MENU and then selecting Advanced settings Reset all DAB settings. Related information • Digital radio (DAB)* (p. 36) to access the subchannels. Subchannels can only be accessed on the selected main channel and not on any other channel without selecting it. – In the normal view for the DAB source, display of subchannels can be activated/deactivated by pressing OK/MENU and then selecting Advanced settings Sub channels. Controls for the media player. For operating the media player, see Operating the system (p. 21). Related information • • • • 38 Audio and media (p. 20) Media Bluetooth®* (p. 49) Remote control* (p. 62) Media player - compatible file formats (p. 44) * Option/accessory. AUDIO AND MEDIA CD/DVD* Media player (p. 38) can play back pre-recorded and burned CD/DVD discs. The media player supports and can play the following main types of discs and files: Playback and navigation of CD/ DVD* disc For basic information on playback and navigation, see Operating the system (p. 21). See below for a more detailed description. NOTE • • Pre-recorded CD discs (CD Audio). Starting playback of a disc Burned CD discs with audio and/or video files. • • Pre-recorded DVD video discs. Press the MEDIA button in the normal view for the media source, turn TUNE until Disc is shown and press OK/MENU. If there is a disc in the media player then the disc starts playing back automatically, otherwise Insert disc is shown in the display screen. Then insert a disc, with text side up. The disc starts to play back automatically. Burned DVD discs with audio and/or video files. For more information about the supported formats, see compatible file formats (p. 44). Related information • Audio and media - operating the system (p. 21) • Playback and navigation of CD/DVD* disc (p. 39) • Playback and navigation of DVD* video discs (p. 42) A video film is only shown when the car is stationary. When the car is moving at a speed of over about 8 km/h no picture is shown and No visual media available while driving appears on the display screen, although the audio is heard during this time. The picture is shown again as soon as the car's speed falls below about 6 km/h. If a disc with audio/video files is inserted into the player then the disc's folder structure needs to be loaded. Depending on the quality of the disc and the quantity of information there may be a certain delay before playback starts. Disc eject Press the eject button (p. 21) to eject the disc. NOTE Some audio files that are copy-protected by record companies or privately copied audio files cannot be loaded by the player. Related information • Audio and media - operating the system (p. 21) • Playback and navigation of burned discs with audio/video files* (p. 40) Pause in playback (pause) • When the volume is reduced entirely or MUTE is pressed, the media player is paused. When the Playback and navigation of DVD* video discs (p. 42) • Fast forward/reverse (p. 41) A disc remains in the ejected position for about 12 seconds, after which it is inserted back into the player for safety reasons. 9 volume is increased or MUTE is pressed again, the media player starts. It is also possible to pause via the menu system9, press OK/MENU and select Play/Pause. Does not apply to CD Audio. }} * Option/accessory. 39 AUDIO AND MEDIA • • Scan disc track or audio file (p. 41) • Media player - compatible file formats (p. 44) Random selection of disc track or audio file (p. 42) Playback and navigation of burned discs with audio/video files* Playback and navigation of burned discs with audio/video files. NOTE A video film is only shown when the car is stationary. When the car is moving at a speed of over about 8 km/h no picture is shown and No visual media available while driving appears on the display screen, although the audio is heard during this time. The picture is shown again as soon as the car's speed falls below about 6 km/h. NOTE Some audio files that are copy-protected by record companies or privately copied audio files cannot be loaded by the player. Audio files have the symbol , video files and folders have the symhave the symbol bol . When playback of a file is complete the playback of the other files (of the same type) in that particular folder continues. Change10 of folder takes place automatically when all the files in the current folder have been played back. The system 10 40 automatically detects and changes setting when a disc containing only audio files or only video files is loaded into the media player and then plays back these files. However, the system does not change setting if a disc containing a mixture of audio and video files is loaded into the media player, but instead the player continues to play back the previous file type. Repeat folder This function makes it possible to play files in a folder over and over again. When the last file has been played out, playback of the first file starts again. 1. Press OK/MENU 2. Turn TUNE to Repeat folder 3. Press OK/MENU to activate/deactivate the function. Related information • Audio and media - operating the system (p. 21) • Playback and navigation of CD/DVD* disc (p. 39) • Playback and navigation of DVD* video discs (p. 42) • • Fast forward/reverse (p. 41) Scan disc track or audio file (p. 41) If Repeat folder is activated then this does not take place. * Option/accessory. AUDIO AND MEDIA • Random selection of disc track or audio file (p. 42) • Media player - compatible file formats (p. 44) • DivX® Video On Demand* (p. 43) Fast forward/reverse Scan disc track or audio file It is possible to fast forward/rewind audio and video files11. This function play backs the first ten seconds of each disc track/audio file.12 Hold the button for / depressed in order to fast forward/rewind audio or video files forward/backward. To scan selected source: 1. Press OK/MENU in the normal view for the selected source Audio files are fast forwarded/rewound at one speed, while video files can be fast forwarded/ rewound at several speeds. Repeatedly press the / to increase the fast forward/ buttons rewind speed for video files. Release the button to return to viewing at normal speed. 2. Turn TUNE to Scan > The first 10 seconds of each disc track or audio file are played. 3. Cancel the scan with EXIT, the disc track or audio file being played back will continue playing. Related information 11 12 Related information • Audio and media - operating the system (p. 21) • • Playback and navigation of CD/DVD* disc (p. 39) Audio and media - operating the system (p. 21) • • Playback and navigation of external audio source* (p. 47) Playback and navigation of CD/DVD* disc (p. 39) • Playback and navigation of external audio source* (p. 47) • Media Bluetooth®* (p. 49) Only applies to CD/DVD* discs, USB and iPod®. Does not apply to DVD video discs. For externally connected audio sources via the AUX/USB input this only applies to USB and iPod®. Not supported by all mobile phones. * Option/accessory. 41 AUDIO AND MEDIA Random selection of disc track or audio file Playback and navigation of DVD* video discs This function plays the tracks/audio files in random order13. When playing back a DVD video disc a disc menu may appear on the display screen. The disc menu gives access to additional functions and settings, such as selecting subtitles, language and scene selection. To listen to the tracks/audio files in random order for the selected source: 1. Press OK/MENU in the normal view for the selected source 2. Turn TUNE to Random 3. Press OK/MENU to activate/deactivate the function. Related information • Audio and media - operating the system (p. 21) • Playback and navigation of CD/DVD* disc (p. 39) • Playback and navigation of external audio source* (p. 47) • Media Bluetooth®* (p. 49) Navigation in the DVD video disc's menu For basic information on playback and navigation, see Operating the system (p. 21). See below for a more detailed description. NOTE A video film is only shown when the car is stationary. When the car is moving at a speed of over about 8 km/h no picture is shown and No visual media available while driving appears on the display screen, although the audio is heard during this time. The picture is shown again as soon as the car's speed falls below about 6 km/h. Navigation in the DVD video disc's menu is performed using the number keys in the centre console as illustrated above. Changing chapter or title Turn TUNE to access the list of chapters and navigate through them (if the film is being played back then it is paused). Press OK/MENU to select the chapter, this also leads back to the original position (if the film was being played back then it is restarted). Press EXIT to access the title list. Titles are selected in the title list by turning TUNE and the selection is confirmed with OK/ MENU, this also leads back to the chapter list. Press OK/MENU to activate the selection and 13 42 Does not apply to DVD video discs. For externally connected audio sources via the AUX/USB input this only applies to USB and iPod®. Not supported by all mobile phones. * Option/accessory. AUDIO AND MEDIA return to the start position. Use EXIT to cancel the selection and this leads back to the original position (without any selection being made). The chapter can also be changed by pressing on / on the centre console or the steering wheel keypad*. Related information • Audio and media - operating the system (p. 21) • Playback and navigation of CD/DVD* disc (p. 39) • Camera angle for playback of DVD* video discs If the DVD video disc supports it, the function can be used to choose from which camera position a particular scene should be shown. In the normal view for the disc source, press OK/MENU and select Advanced settings Angle. Related information DivX® Video On Demand* The media player can be registered to play back files of the type DivX® VOD from CD-/DVD discs, USB or iPod®. The code for registration can be found in the menu system MY CAR, see MY CAR (p. 10). For more information visit www.divx.com/vod. Related information • Audio and media - operating the system (p. 21) Camera angle for playback of DVD* video discs (p. 43) • Playback and navigation of DVD* video discs (p. 42) • Playback and navigation of burned discs with audio/video files* (p. 40) • Playback and navigation of burned discs with audio/video files* (p. 40) • • • Fast forward/reverse (p. 41) • Playback and navigation of external audio source* (p. 47) • Scan disc track or audio file (p. 41) • Audio and media - operating the system (p. 21) Random selection of disc track or audio file (p. 42) Media player - compatible file formats (p. 44) * Option/accessory. 43 AUDIO AND MEDIA Picture settings* You can adjust the display settings (when the car is stationary) for brightness and contrast. 1. In playback mode, press OK/MENU and select Image settings, confirm with OK/ MENU. 2. Turn TUNE to the adjustment option and confirm with OK/MENU. 3. Adjust the setting by turning TUNE and confirm with OK/MENU. To return to the settings list, press the OK/ MENU or EXIT. The picture settings can be reset to factory settings with the Reset option. Media player - compatible file formats Technical data for file formats .avi and .divx The media player can play back a variety of file types and is compatible with the formats in the following tables. For the file to be played back, the following criteria must be met: Compatible file formats for CD/DVD discs NOTE Dual format, double-sided discs (DVD Plus, CD-DVD format) are thicker than regular CD discs and therefore playback cannot be guaranteed and malfunction may arise. If a CD contains a mixture of MP3 and CDDA tracks, all MP3s will be ignored. Related information • Audio and media - operating the system (p. 21) • Audio and media (p. 20) Audio format CD audio, mp3, wma, aac, m4a Video format CD video, DVD video, divx, avi, asf Compatible file formats via USB connection Audio and video files in the following table are supported by the system for playback via the USB connection. 44 Audio format mp3, wma, aac, m4a Video format divx, avi, asf DivX version 3, 4, 5, 5:2 Image size 32x32-720x576 pixels Video frame rate Up to 30 fps Total capacity (total bit rate) Up to 4 Mbps on average, up to 8 Mbps maximum (incl. video bit rate and audio bit rate) Audio format MP3 (MPEG-1/2 Layer 3), MPEG-1 (Layer 2), AC3 (Dolby D) DivX standard See table below for audio specifications Audio channels (ch) 2ch for MP3/MPEG-1, 5.1ch for AC3 Audio specifications for file formats .avi and .divx Format kHz kbps MPEG-1 Layer 2 44.1 64–384 48 64–384 * Option/accessory. AUDIO AND MEDIA Format kHz kbps MPEG-2 Layer 3 (MP3) 16 8–160 22.05 8–160 24 8–160 32 32–320A 44.1 32–320A 48 32–320A 48 64–448 MPEG-1 Layer 3 (MP3) AC3 Does not apply to 144 kbps. A Technical data for file format .asf Audio sampling rate 8 kHz External audio source via AUX/ USB* input Audio bit rate 16, 24, 32 or 40 kbps (for 8 kHz sampling) An external audio source, e.g. an iPod® or MP3 player, can be connected (p. 46) to the audio system. Related information • Playback and navigation of CD/DVD* disc (p. 39) • Playback and navigation of DVD* video discs (p. 42) • Playback and navigation of burned discs with audio/video files* (p. 40) • Playback and navigation of external audio source* (p. 47) For the file to be played back, the following criteria must be met: Image size 32x32-720x576 pixels Video frame rate Up to 30 fps Total capacity (total bit rate) Up to 384 kbs (incl. video bit rate and audio bit rate) Audio format ITU-T G.726 Audio channels (ch) 1ch 14 An audio source connected to the USB input can be operated14 using the car's audio controls. A device connected via the AUX input cannot be controlled via the car. An iPod® or MP3 player with rechargeable batteries is recharged (when the ignition is on or the engine is running) if the device is plugged into the USB connection. Stereo not supported Only applies to the media source connected via the USB connection. }} * Option/accessory. 45 AUDIO AND MEDIA || USB memory MP3 player To facilitate the use of a USB memory stick, only store music files on it. It takes a lot longer for the system to load storage media that contains anything other than compatible music files. Many MP3 players have their own file systems that are not supported by the audio system. For use in the system, an MP3 player must be set in USB Removable device/Mass Storage Device mode. NOTE The system supports mobile media compliant with USB 2.0 and the FAT32 file system and can handle 1000 folders with a maximum of 254 subfolders/files in every folder. The top level, which can handle up to 1000 subfolders/files, is an exception to this. Connecting an external audio source via AUX/USB* input An external audio source, e.g. an iPod® or MP3 player, can be connected to the audio system via any of the connection points in the tunnel console. iPod® An iPod® is charged and supplied with power by the USB connection via the player's connection cable. NOTE The system only supports the playback of audio files from iPod®. NOTE When using a longer model USB memory stick the use of a USB adapter cable is recommended. This is to avoid mechanical wear to the USB input and the connected USB memory stick. NOTE When an iPod® is used as audio source, the car's infotainment system has a menu structure that is similar to the iPod® player's own menu structure. Connection points for external audio sources. To connect the audio source: 1. In the normal view for the media source, press MEDIA, turn TUNE to the desired audio source USB, iPod or AUX and press OK/MENU. > If USB is selected then Connect USB is shown in the display screen. 2. Connect your audio source to one of the connections in the tunnel console storage compartment (see Connection points for external audio sources(p. 46)). USB hub It is possible to connect a USB hub to the USB connection and thereby connect multiple USB devices simultaneously. USB device selection is carried out in the normal view for the USB source by pressing OK/MENU and then selecting Select USB device. 46 Related information • Audio and media - operating the system (p. 21) • Playback and navigation of external audio source* (p. 47) • Setting the audio volume for external audio source (p. 48) * Option/accessory. AUDIO AND MEDIA The text Reading USB is shown in the screen when the system is loading the storage media's file structure. Depending on the file structure and number of files there may be some delay before loading is finished. NOTE The system supports most iPod® models produced in 2005 or later. NOTE To prevent damage to the USB connection, this is shut off if the USB connection is shortcircuited or if a connected USB unit is taking too much power (this may happen if the unit connected does not meet the USB standard). The USB connection is reactivated automatically the next time the ignition is turned on, unless the fault persists. Related information • External audio source via AUX/USB* input (p. 45) • Playback and navigation of external audio source* (p. 47) 15 16 17 Playback and navigation of external audio source* Playback and navigation of external audio source15. For basic information on playback and navigation, see Operating the system (p. 21). See below for a more detailed description. Audio files have the symbol , video files* and folders have the symhave the symbol bol . See Compatible file formats (p. 44) for information about file formats that are supported by the media player. When playback of a file is complete the playback of the other files (of the same type) in that particular folder continues. Change16 of folder takes place automatically when all the files in the current folder have been played back. The system automatically detects and changes setting when a device containing only audio files or only video files is connected to the USB port and then it plays back these files. However, the system does not change setting if a device containing a mixture of audio and video files is connected to the USB port, but instead the player continues to play back the previous file type. Search function15 The keypad on the control panel in the centre console can be used to find a filename in the current folder. The search function is accessed either by turning TUNE (to access the folder structure) or by pressing one of the letter keys. As a letter or character in a search string is entered you get closer to your search target. After a few seconds the search results are shown on the screen. Start playback of a file by pressing OK/MENU. Repeat folder17 This function makes it possible to play files in a folder over and over again. When the last file has been played out, playback of the first file starts again. 1. Press OK/MENU 2. Turn TUNE to Repeat folder 3. Press OK/MENU to activate/deactivate the function. Fast forward/reverse For information, see Fast forward/rewind (p. 41). Only applies to USB and iPod®. If Repeat folder is activated then this does not take place. Only applies to USB. }} * Option/accessory. 47 AUDIO AND MEDIA || Pause When the volume is reduced entirely or MUTE is pressed, the media player is paused. When the volume is increased or MUTE is pressed again, the media player starts. It is also possible to pause via the menu system18 by pressing OK/MENU, selecting USB MENU and then Play/Pause. NOTE A video film is only shown when the car is stationary. When the car is moving at a speed of over about 8 km/h no picture is shown and No visual media available while driving appears on the display screen, although the audio is heard during this time. The picture is shown again as soon as the car's speed falls below about 6 km/h. Related information • Connecting an external audio source via AUX/USB* input (p. 46) • External audio source via AUX/USB* input (p. 45) • • Scan disc track or audio file (p. 41) • DivX® Video On Demand* (p. 43) 18 48 • Picture settings* (p. 44) Setting the audio volume for external audio source Set the volume for an external audio source (p. 45). If the volume is too high or too low then the quality of the sound may deteriorate. If an external audio source (e.g. an MP3 player or iPod®) is connected to the AUX input then the audio source that is connected can have a different volume than the audio system's internal volume (e.g. radio). Correct this by adjusting the volume of the input: 1. In the normal view for the media source, press the MEDIA button and turn TUNE to AUX and wait a few seconds or press OK/ MENU. 2. Press OK/MENU and then turn TUNE to AUX input volume. Confirm with OK/ MENU. 3. Turn TUNE to adjust the volume for the AUX input. Random selection of disc track or audio file (p. 42) Does not apply to iPod® * Option/accessory. AUDIO AND MEDIA NOTE If the external audio source's volume is too high or too low, the quality of the sound may deteriorate. The audio quality may also be impaired if the player is charged while the infotainment system is in AUX mode. In which case, avoid charging the player via the 12 V socket. Media Bluetooth®* The car's media player is equipped with Bluetooth® and can wirelessly play streaming audio files from external devices with Bluetooth®, such as mobile phones and PDAs. the mobile phone's functions, see Bluetooth® handsfree phone* (p. 53). Switch between the main sources TEL and MEDIA to operate each one's functions. NOTE The Bluetooth® media player must support the Audio/Video Remote Control Profile (AVRCP) and Advanced Audio Distribution Profile (A2DP). The player should use AVRCP version 1.3, A2DP 1.2. Otherwise some functions may not work. Related information • Audio and media - advanced audio settings (p. 27) • Audio and media - operating the system (p. 21) Not all mobile phones and external media players available in the market are fully compatible with the Bluetooth® function in the car's media player. Volvo recommends that you contact an authorised Volvo dealer for information on compatible phones and external media players. Media Bluetooth® functions, controls overview. The device must first be registered and connected to the car (p. 50). Navigation and control of the audio can be carried out via the centre console buttons or via the steering wheel keypad*. In some external devices it is also possible to change tracks from the device. To play back the audio the car's media player must first be set in Bluetooth mode. When a mobile phone is connected to the car, it is also possible to remotely control a selection of NOTE The car's media player can only play the audio files via the Bluetooth® function. Related information • • Scan disc track or audio file (p. 41) Random selection of disc track or audio file (p. 42) * Option/accessory. 49 AUDIO AND MEDIA Connecting and disconnecting a Bluetooth® device* The car is equipped with Bluetooth® and can wirelessly communicate with other Bluetooth® devices after registration and connection (p. 50). A maximum of ten Bluetooth® devices can be registered. Registration is performed once per device. After registration the device no longer needs to be activated as visible/searchable. When the Bluetooth® function is active and the last device connected is in range it is connected automatically to the car. When the car searches for the last device connected its name is shown in the display screen. To connect to another device, press EXIT and select to change device (p. 52). When the Bluetooth® device is out of range of the car it is automatically disconnected. It is also possible to manually disconnect (p. 52) a device. To deregister a Bluetooth® device from the car, select Removing a Bluetooth® device* (p. 53). The car will then not locate the device automatically. It is possible to have two Bluetooth® devices connected simultaneously. One phone and one media device, which it is possible to switch between (p. 52). It is also possible to call with the phone and simultaneously stream audio files. 50 Related information • Audio and media - operating the system (p. 21) • • Media Bluetooth®* (p. 49) Bluetooth® handsfree phone* (p. 53) Registering a Bluetooth® device* It is possible to have two Bluetooth® devices connected simultaneously. One phone and one media device, which it is possible to switch between. It is also possible to call with the phone and simultaneously stream audio files. A maximum of ten Bluetooth® devices can be registered. Registration is performed once per device. After registration the device no longer needs to be activated as visible/searchable. NOTE If the phone's operating system is updated then it is possible that the registration of the phone is interrupted. In which case, disconnect the phone, see Removing a Bluetooth® device* (p. 53) and then reconnect it. Connecting an external device takes place in different ways depending on whether or not the device has been connected previously. The connection options below presume that this is the first time the device is being connected (registered) and that no other device is connected. The connection options show the connection of a phone. Connecting a media device (p. 49) is performed in the same way, but starting from the main source MEDIA. There are two possible ways of connecting devices, either search for the external device from the * Option/accessory. AUDIO AND MEDIA car, or search for the car from the external device. If one option does not work then try with the other. Alternative 2 - Search for the car with the Bluetooth® function of the external device If you are not already in the normal view for the phone, press TEL in the centre console. 1. Make the car searchable/visible via Bluetooth®. Turn TUNE to Phone settings, confirm with OK/MENU, select Discoverable and confirm with OK/MENU. 2. Select My Volvo Car on the external device's screen and follow the instructions. 3. Enter an optional PIN code into the external device, then select the option to connect. 4. Press OK/MENU and then enter the same PIN code via the car's keypad in the centre console. Example of normal view for the phone. Alternative 1 - search for the external device via the car's menu system 1. Make the external device searchable/visible via Bluetooth®, see the external device's manual or www.volvocars.com. 2. Press OK/MENU and follow the instructions on the car's display screen. > The external device is now connected and can be controlled from the car. When the external device is connected, the external device's Bluetooth® name is shown in the car's display screen and the device can be controlled from the car. Related information • Audio and media - operating the system (p. 21) • Connecting and disconnecting a Bluetooth® device* (p. 50) Automatic connection of Bluetooth® device* When one, or several, Bluetooth® devices are registered (p. 50) in the car, the last connected device is connected automatically when it is in range. When the Bluetooth® function is active and the last device connected is in range it is connected automatically. When the car searches for the last device connected its name is shown in the display screen. If the last connected device is not available then the system will try to connect an previously connected device. To connect to another device, press EXIT, select to connect a new device (p. 50) or change to another already registered device (p. 52). Related information • Audio and media - operating the system (p. 21) • Connecting and disconnecting a Bluetooth® device* (p. 50) Connection failed, press EXIT twice and connect in accordance with Alternative 2. * Option/accessory. 51 AUDIO AND MEDIA Changing to another Bluetooth® device* 2. It is possible to change from a connected device to another one if there are several devices in the car. The device must first have been registered (p. 50) to the car. Changing media device 1. 2. 3. Check that the external device is searchable/ visible via Bluetooth®, see the manual for the external device. 3. In the normal view for the Bluetooth® media source, press OK/MENU and select Change device. > The car searches for previously connected devices. The external devices detected are specified with their respective Bluetooth® name in the screen. Related information Select the device to be connected. > Connection of the external device takes place. Changing phone 1. 52 In the normal view for the phone source, press OK/MENU and select Change phone. > The car searches for previously connected devices. The external devices detected are specified with their respective Bluetooth® name in the screen. Check that the external device is searchable/ visible via Bluetooth®, see the manual for the external device. Select the device to be connected. > Connection of the external device takes place. • Audio and media - operating the system (p. 21) • Connecting and disconnecting a Bluetooth® device* (p. 50) Disconnecting the Bluetooth® device* When the Bluetooth® device is out of range of the car it is automatically disconnected. It is also possible to disconnect a phone manually. When the mobile phone has been disconnected an ongoing call can be continued by using the mobile phone's built-in microphone and speaker. The handsfree function is deactivated when the engine is switched off and the door is opened. If you want to deregister a Bluetooth® device from the car, select Remove Bluetooth® device (p. 53). The car will then not locate the device automatically. Manual disconnection of phone The phone can be manually disconnected in the normal view for the phone source by pressing OK/MENU and then selecting Disconnect phone. NOTE Even when your mobile phone has been manually disconnected, some mobile phones may automatically couple up to the last handsfree unit connected, e.g. when a new call begins. * Option/accessory. AUDIO AND MEDIA Related information Removing a Bluetooth® device* • Audio and media - operating the system (p. 21) • Connecting and disconnecting a Bluetooth® device* (p. 50) If you do not want a device registered to the car any longer then it is possible to remove (deregister) it from the car. The car will then not locate the device automatically. • • Media Bluetooth®* (p. 49) Removing a media device Bluetooth® handsfree phone* (p. 53) In the normal view for the Bluetooth® media source, press OK/MENU and select Remove Bluetooth device. Turn TUNE to select the device to be removed, confirm with OK/MENU. Bluetooth® Bluetooth® handsfree phone* A mobile phone equipped with Bluetooth® can be connected wirelessly to the car. Removing a phone In the normal view for the phone source, press OK/MENU and select Remove Bluetooth device. Turn TUNE to select the device to be removed, confirm with OK/MENU. Related information • Audio and media - operating the system (p. 21) • Connecting and disconnecting a Bluetooth® device* (p. 50) • • Media Bluetooth®* (p. 49) Bluetooth® handsfree phone* (p. 53) Phone functions, controls overview. The device must first be registered and connected to the car (p. 50). The audio and media system acts as handsfree, with the facility to remotely control a selection of the mobile phone's functions. The mobile phone can be operated by its own keys irrespective of whether or not it is connected. When a mobile phone is connected to the car, it is also possible to stream audio files from the phone or another Bluetooth®-connected media device, see Media Bluetooth®* (p. 49). Switch between the main sources TEL and MEDIA to operate each one's functions. }} * Option/accessory. 53 AUDIO AND MEDIA || NOTE Only a selection of mobile phones are fully compatible with the handsfree function. Volvo recommends that you seek assistance from an authorised Volvo dealer for information on compatible phones. Related information • Audio and media - operating the system (p. 21) • Connecting and disconnecting a Bluetooth® device* (p. 50) • • Making and receiving calls* (p. 55) Activate A short press on TEL activates/searches last connected phone. If a phone is already connected, and TEL is pressed, a shortcut menu is shown with commonly used menu options for the symbol indicates that a phone phone. The is connected. • Bluetooth® handsfree phone* overview System overview for Bluetooth® handsfree phone. Bluetooth® handsfree phone* - audio settings (p. 56) Bluetooth®* version information (p. 56) To call 1. 2. 3. symbol appears at Make sure that the the top of the screen and that the handsfree function is in phone mode. Dial either the desired number or the speed dial number (p. 61). Or in normal view turn TUNE to the right to access the phone book, and to the left for the call register for all calls. For information on the phone book, see Phone book* (p. 57). Press OK/MENU. The call is interrupted with EXIT. 54 System overview Mobile phone Microphone Steering wheel keypad Centre console control panel Related information • Audio and media - operating the system (p. 21) • Connecting and disconnecting a Bluetooth® device* (p. 50) * Option/accessory. AUDIO AND MEDIA Making and receiving calls* Call lists Functions for handling phone calls. The call lists are copied to the handsfree function at each new connection and are then updated during the connection. In normal view, turn to the left with TUNE to see the call register for All calls . Incoming call – Press OK/MENU to answer the call, even if the audio system is in e.g. RADIO or MEDIA mode. Refuse or end with EXIT. Automatic answer The automatic answer function means that calls are accepted automatically. – To activate/deactivate, in the normal view for the phone source, press OK/MENU and select Call options Auto answer. In call menu In the normal view for the phone source, one press on OK/MENU during the current call gives access to the following functions: • Mute - audio system microphone is muted. • Mobile phone - the call is transferred from handsfree to the mobile phone. For some mobile phones the connection is interrupted. This is normal. The handsfree function asks if you want to reconnect. • Dial number - option to call a third party using the number keys (current call set in standby). In the normal view for the phone source, press OK/MENU and select All calls to view all call registers: • • • • • All calls is no number stored then this menu can be reached with one long press on 1. Related information • Audio and media - operating the system (p. 21) • • Bluetooth® handsfree phone* (p. 53) • Phone book* (p. 57) Bluetooth® handsfree phone* - audio settings (p. 56) Missed calls Answered calls Dialled calls Call duration NOTE Certain mobile phones show a list of the last dialled numbers in reverse order. Voice mailbox A speed dial number for the voice mailbox can be programmed in the normal view for the phone source, and then accessed later via a long press on 1. The voice mailbox number is changed in normal view for the phone source by pressing OK/MENU and selecting Call options Voicemail number Change number. If there * Option/accessory. 55 AUDIO AND MEDIA Bluetooth® handsfree phone* audio settings It is possible to adjust the call volume, audio system volume and ring signal volume, and change the ring tone. Phone call volume Ring signals The built-in ring signals for the handsfree function can be selected in the normal view for the phone source by pressing OK/MENU and then selecting Phone settings Sounds and volume Ring signals Ring signal 1 etc. Ring volume In the normal view for the phone source, press OK/MENU and select Phone settings Sounds and volume Ring volume. Adjust by turning VOL, press OK/MENU to hear the audio volume and press EXIT to save. 19 56 The car's current Bluetooth® version can be seen from the normal view in the main sources MEDIA or TEL: Press OK/MENU and select Bluetooth software version in car. For some mobile phones, the ringtone on the phone connected will not be switched off when one of the inbuilt signals for the handsfree system is used. • Press OK/MENU and select Phone settings Bluetooth software version in car. In order to select the connected phone's ring signal19, in the normal view for the phone source, press OK/MENU and then select Phone settings Sounds and volume Ring signals Mobile phone ring signal • Audio and media - operating the system (p. 21) • • Bluetooth® handsfree phone* (p. 53) NOTE Audio system volume If an audio source is active during an incoming call then it can be muted automatically. To activate/deactivate, in the normal view for the phone source, press OK/MENU and select Phone settings Sounds and volume Mute radio/media. Show the car's current Bluetooth® version. • The phone call volume can only be changed during a call. Use the steering wheel keypad* or turn the VOL control. Providing there is no ongoing call taking place, the audio system volume is controlled in the normal way by turning VOL. Bluetooth®* version information Related information Media Bluetooth®* (p. 49) Related information • Audio and media - operating the system (p. 21) • Bluetooth® handsfree phone* (p. 53) Not supported by all mobile phones. * Option/accessory. AUDIO AND MEDIA Phone book* There are two phone books. These are combined in the car and are shown as a single phone book. • • The car downloads the connected mobile phone's phone book and only shows this phone book when the mobile phone it was downloaded from is connected. The car also has a built-in phone book. This contains all the contacts stored in the car irrespective of which phone was connected when saving them. These contacts are visible for all users, regardless of the mobile phone that is connected to the car. If a contact is is saved in the car then the symbol shown in front of the contact in the phone book. NOTE Changes made from the car to a record in the mobile phone's telephone book will result in a new record in the car's telephone book, i.e. changes will not be saved to the phone. From the car, this will now look like you have double records, with different icons. Note also that when a shortcut number is saved or a change to a contact is made, this will result in a new record in the car's phone book. All use of the phone book requires that the symbol appears at the top of the screen and that the handsfree function is in phone mode. 3. Copy the mobile's phone book to the car's phone book The audio and media system stores a copy of each registered mobile phone's phone book. The phone book can be copied automatically to the audio and media system during each connection. – To activate/deactivate the function, in the normal view for the phone source, press OK/MENU and select Phone settings Download phone book. If the phone book contains a ringing caller's contact information then this is shown in the screen. Press OK/MENU and then select Options Copy to car memory. > The symbol is shown in front of the saved contact in the car's phone book and the contact is saved. Related information • Audio and media - operating the system (p. 21) • • • • • Bluetooth® handsfree phone* (p. 53) Phone book* - speed dial numbers (p. 61) Phone book* - receiving a vCard (p. 61) Phone book* - memory status (p. 61) Phone book* - clearing (p. 62) Copy individual contact to the car's phone book There is also the option to copy an individual contact from the mobile phone's phone book to the car. 1. In the normal view for the phone source, press OK/MENU and select Phone book Search contact. 2. Select the contact and press OK/MENU. * Option/accessory. 57 AUDIO AND MEDIA Phone book* - quick search for contacts Phone book* - character table keypad in centre console In the normal view for the phone source, turn TUNE to the right to show a list of contacts. Character table of possible characters for use in the phone book. Turn TUNE to select and press OK/MENU to call. Under the name of the contact is the phone number that is selected by default. If the symbol > appears to the right of the contact then there are several phone numbers stored for the contact. Press OK/MENU to show the numbers. Change and dial a number other than that selected by default by turning TUNE. Press OK/ MENU to dial. Search in the list of contacts by using the centre console's keypad to key in the start of the contact's name. For the function of the buttons, see Phone book* - character table keypad in centre console (p. 58). The list of contacts can also be accessed from normal view by pressing and holding the button on the centre console's keypad with the letter that the contact searched for starts with. For example, a long press on the button for 6 gives instant access to that part of the list where the contacts with the letter M are located. Related information 58 • Audio and media - operating the system (p. 21) • Bluetooth® handsfree phone* (p. 53) Key Key Function +0pw #* Function Space . , - ? @ : ; / ( ) 1 Related information • Audio and media - operating the system (p. 21) • • Bluetooth® handsfree phone* (p. 53) ABCÅÄÆÀÇ2 DEFÈÉ3 Phone book* (p. 57) GHIÌ4 JKL5 MNOÖØÑÒ6 PQRSß7 TUVÜÙ8 WXYZ9 Shift between upper and lower case letter. * Option/accessory. AUDIO AND MEDIA Phone book* - searching for contacts Searching for contacts in the phone book (p. 57). Search contacts using the text wheel. Character list Changing the input mode (see following table) Phone book To search for or edit a contact, in the normal view for the phone source, press OK/MENU and select Phone book Search. NOTE There is no text wheel for High Performance, so TUNE cannot be used there to input characters: only the digit and letter buttons on the control panel in the centre console can be used for this. 1. Turn TUNE to the desired letter, press OK/ MENU to confirm. The number and letter buttons on the control panel in the centre console can also be used. 2. Continue with the next letter and so on. The result of the search is shown in the phone book (3). 3. To change the input mode to numbers or special characters, or to go to the phone book, turn TUNE to one of the options (see explanation in the table below) in the list for changing the input mode (2), press OK/ MENU. 123/ABC Change between letters and numbers with OK/MENU. More Change to special characters with OK/MENU. Leads to the phone book (3). Turn TUNE to select a contact, press OK/MENU to see the saved numbers and other information. A short press on EXIT deletes an input character. A long press on EXIT will clear all entered characters. By pressing a number key in the centre console when the text wheel is shown (see previous illustration), a new character list (1) is shown in the screen. Continue repeatedly pressing the number key to the desired letter and then release. Continue with the next letter and so on. When a button is depressed the entry is confirmed when another button is depressed. To enter a number, hold in the corresponding number key. Related information • Audio and media - operating the system (p. 21) • Bluetooth® handsfree phone* (p. 53) * Option/accessory. 59 AUDIO AND MEDIA Phone book* - new contact 1. When the Name row is selected, press OK/ MENU to reach the input mode (illustration above). 2. Turn TUNE to the desired letter, press OK/ MENU to confirm. The number and letter buttons on the control panel in the centre console can also be used. Create new contact in the phone book. Entering letters for New contact. Changing the input mode (see following table). Input field. In the normal view for the phone source, new contacts can be added by pressing OK/MENU and then selecting Phone book New contact. NOTE There is no text wheel for High Performance, so TUNE cannot be used there to input characters: only the digit and letter buttons on the control panel in the centre console can be used for this. 60 3. Continue with the next letter and so on. The name entered is shown in the input field (2) in the screen. 4. To change the input mode to numbers, special characters, change between uppercase/ lowercase letters, etc., turn TUNE to one of the options (see explanation in the following table) in the list (1) and then press OK/ MENU. 123/AB C Change between letters and numbers with OK/MENU. More Change to special characters with OK/MENU. OK Save and go back to Add contact with OK/MENU. Change between uppercase and lowercase letters with OK/ MENU. Press OK/MENU, the cursor moves to the input field (2) at the top of the display screen. The cursor can now be moved, with TUNE, to the appropriate place to e.g. insert new letters or delete with EXIT. To be able to insert new letters first go back to the input mode, by pressing OK/ MENU. When the name has been fully entered, select OK in the list on the display screen (1) and press OK/MENU. Now continue with the telephone number in the same way as above. When the telephone number has been entered, press OK/MENU and select a telephone number type (Mobile phone, Home, Work or General). Press OK/MENU to confirm. When all details have been filled in, select Save contact in the menu to save the contact. Related information • Audio and media - operating the system (p. 21) • • Bluetooth® handsfree phone* (p. 53) Phone book* (p. 57) * Option/accessory. AUDIO AND MEDIA Phone book* - speed dial numbers Phone book* - receiving a vCard Phone book* - memory status Store as speed dial number in the phone book (p. 57) in order to easily dial a number or a contact. Receiving electronic business cards (vCard) to the car's phone book (p. 57). Show phone book (p. 57) memory status. In the normal view for the phone source, speed dial numbers can be added by pressing OK/MENU and then selecting Phone menu Phone book Speed dial. Dialling with speed dial numbers can be performed in phone mode using the number keys on the keypad in the centre console, by pressing a number key and then pressing OK/MENU. If there is no contact stored on the speed dial number then an option is shown to save a contact to the selected speed dial number. It is possible to receive a vCard to the car's phone book from other mobile phones (other than the one currently connected to the car). In order to allow this the car is set to visible mode for Bluetooth®. The function is activated in the normal view for the phone source by pressing OK/MENU and then selecting Phone book Receive vCard. Related information • Audio and media - operating the system (p. 21) • Bluetooth® handsfree phone* (p. 53) The memory status of the car's phone book and the connected mobile phone's phone book can be viewed in the normal view for the phone source by pressing OK/MENU and then selecting Phone book Memory status. Related information • Audio and media - operating the system (p. 21) • Bluetooth® handsfree phone* (p. 53) Related information • Audio and media - operating the system (p. 21) • Bluetooth® handsfree phone* (p. 53) * Option/accessory. 61 AUDIO AND MEDIA Phone book* - clearing Remote control* Clear the car's built-in phone book (p. 57). The remote control can be used for all functions in the audio and media system. The remote control's buttons have the same functions as the buttons in the centre console or steering wheel keypad*. The car's phone book can be deleted, this is carried out in the normal view for the phone source by pressing OK/MENU and then selecting Phone book Clear phone book. NOTE Deleting the car's telephone book only deletes contacts in the car's telephone book. Contacts in the mobile phone's phone book are not deleted. Related information • Audio and media - operating the system (p. 21) • Bluetooth® handsfree phone* (p. 53) Corresponds to TUNE in the centre console. When using the remote control, first press the remote control's button to position F. Then 62 * Option/accessory. AUDIO AND MEDIA aim the remote control at the IR receiver, which is located to the right of the INFO button (p. 21) in the centre console. WARNING Keep loose objects such as mobile phones, cameras, remote controls for accessories, etc. in the glove compartment or other compartments. Otherwise they may injure people in the car in the event of sudden braking or a collision. NOTE Do not expose the remote control to direct sunlight (e.g. on the instrument panel) - otherwise problems may arise with the batteries. Related information • Audio and media - operating the system (p. 21) Remote control* - functions Key Possible functions to be controlled using the remote control. Key To previous, cancels function, deletes input characters Function Navigate up/down Change between: Navigate right/left L = Rear left display screen* F = Front display screen Confirm selection or go to the menu system for the selected source R = Rear right display screen* Change to navigation* Volume, decrease Change to radio source (e.g. FM1) Change to media source (Disc, TV* etc.) Change to Bluetooth® handsfree* Scroll/fast rewind, change track/ song Play/pause Stop Scroll/fast forward, change track/ song Function Volume, increase 0-9 Preset channels, number and letter input Shortcuts for favourite setting Information about the current programme, song, etc. Also used when there is more information available than can be shown in the display screen Selection of language for soundtrack Menu }} * Option/accessory. 63 AUDIO AND MEDIA || Key Function Subtitles, selection of language for text Remote control* - battery replacement How to replace the batteries in the remote control for the audio and media system. Teletext*, On/Off Related information • Audio and media - operating the system (p. 21) NOTE 3. Refit the cover. NOTE Be sure to dispose of the exhausted batteries in an environmentally safe manner. Battery life is normally 1-4 years and depends on how much the remote control is used. The remote control is powered by four batteries of the AA/LR6 type. Take along extra batteries for a long journey. 64 1. Push down the catch on the battery cover and slide the battery cover in the direction of the infrared lens. 2. Remove the used batteries, turn the new batteries in accordance with the symbols in the battery compartment and fit them. * Option/accessory. AUDIO AND MEDIA Audio and media - menu overview Menu overview - AM Menu overview - FM Overview of possible options and settings in the audio and media system menus. Overview of possible options and settings for AM radio. Overview of possible options and settings for FM radio. RADIO • • • AM (p. 65)20 FM (p. 65) DAB (p. 66) See page Main menu FM1/FM2 See page Show presets* (p. 31) TP (p. 33) Show radio text (p. 34) Show presets* (p. 31) (p. 33) Audio settings MEDIA • • • • • • • Main menu AMA See footnote B CD Audio (p. 67) CD/DVD Data (p. 67) (p. 27) Sound stage* (p. 27) News settings Equalizer* (p. 27) Advanced settings Volume compensation (p. 28) REG (p. 35) Reset all audio settings (p. 26) Alternative frequency (p. 35) EON (p. 33) Set TP favourite (p. 33) PTY settings (p. 34) Reset all FM settings (p. 35) DVD Video (p. 68) iPod®(p. 68) USB (p. 69) Media Bluetooth®(p. 69) AUX (p. 70) TEL • Bluetooth handsfree®(p. 70) Related information • 20 Audio and media - operating the system (p. 21) A B Does not apply to the V60 Twin Engine and S60L Twin Engine. The menu options for audio settings are the same for all audio sources. Related information • Audio and media - menu overview (p. 65) Does not apply to the V60 Twin Engine and S60L Twin Engine. }} * Option/accessory. 65 AUDIO AND MEDIA || (p. 26) Menu overview - Digital radio (DAB)* Sound stage* (p. 27) Sound stage* (p. 27) Overview of possible options and settings for DAB radio. Equalizer* (p. 27) Equalizer* (p. 27) Volume compensation (p. 28) Reset all audio settings (p. 26) Audio settings Volume compensation Reset all audio settings (p. 28) Main menu DAB1*/DAB2* See page Ensemble learn (p. 36) PTY filtering (p. 34) (p. 26) Turn off PTY filtering Related information • Audio and media - menu overview (p. 65) Show presets* (p. 34) (p. 31) Related information • • Audio and media - menu overview (p. 65) Audio and media - operating the system (p. 21) Advanced settings DAB linking (p. 37) DAB band (p. 37) Sub channels (p. 38) Show PTY text (p. 34) Reset all DAB settings (p. 38) Audio settings 66 (p. 26) * Option/accessory. AUDIO AND MEDIA Menu overview - CD Audio Menu overview - CD/DVD* Data Overview of possible options and settings for CD Audio. Overview of possible options and settings for CD/DVD Data. Main menu CD Audio (Disc menu) See page Main menu CD/DVD Data (Disc menu) Random (p. 42) Play Scan (p. 41) Audio settings (p. 26) (p. 39) Stop (p. 39) Random (p. 42) Repeat folder (p. 40) Change subtitles (p. 39) Sound stage* (p. 27) Equalizer* (p. 27) Volume compensation (p. 28) Change audio track (p. 39) Reset all audio settings (p. 26) Scan (p. 41) Audio settings (p. 26) Related information • • Pause See page Audio and media - menu overview (p. 65) Audio and media - operating the system (p. 21) Sound stage* (p. 27) Equalizer* (p. 27) Volume compensation (p. 28) Reset all audio settings (p. 26) Related information • • Audio and media - menu overview (p. 65) Audio and media - operating the system (p. 21) * Option/accessory. 67 AUDIO AND MEDIA Menu overview - DVD* Video Overview of possible options and settings for DVD Video. (p. 28) Reset all audio settings (p. 26) Main menu DVD Video (Disc menu) See page DVD disc menu (p. 42) Play/Pause/Continue (p. 42) Stop (p. 42) Image settings Subtitles (p. 42) Source menu (p. 42) See footnote B Audio tracks Angle DivX® VOD code Audio settings Pop-up menuA*video and TV* Random (p. 42) Press OK/MENU when a video file is being played back or TV* is being shown in order to access the pop-up menu. Scan (p. 41) Audio settings (p. 26) DVD disc TOP menuC (p. 43) A B (p. 26) C Sound stage* (p. 27) Equalizer* (p. 27) Overview of possible options and settings for iPod®. See page See footnote C (p. 43) Menu overview - iPod®* Main menu iPod DVD disc menu Advanced settings 68 Volume compensation (p. 44) Sound stage* (p. 27) Equalizer* (p. 27) (p. 42) Volume compensation (p. 28) (p. 42) Reset all audio settings (p. 26) (p. 21) Only applies when playing back videos or displaying TV. What is shown in the pop-up menu for the source menu depends on what is being played back or displayed, it can be e.g. CD/DVD data menu or USB menu. Only applies to DVD video discs. Related information • • Related information • • Audio and media - menu overview (p. 65) Audio and media - operating the system (p. 21) Audio and media - menu overview (p. 65) Audio and media - operating the system (p. 21) * Option/accessory. AUDIO AND MEDIA Menu overview - USB* Overview of possible options and settings for USB. Main menu USB Volume compensation (p. 28) Reset all audio settings (p. 26) See page Related information Play Pause (p. 47) Stop (p. 47) Random (p. 42) Repeat folder (p. 47) Select USB device (p. 45) Change subtitles (p. 47) Change audio track (p. 47) Scan Audio settings • • Audio and media - menu overview (p. 65) Audio and media - operating the system (p. 21) Menu overview - Media Bluetooth®* Overview of possible options and settings for Media Bluetooth®. Main menu Media Bluetooth® See page Random (p. 42) Change device (p. 52) Remove Bluetooth device (p. 53) Scan (p. 41) Bluetooth software version in car (p. 56) Audio settings (p. 26) Sound stage* (p. 27) (p. 41) Equalizer* (p. 27) (p. 26) Volume compensation (p. 28) Sound stage* (p. 27) Reset all audio settings (p. 26) Equalizer* (p. 27) Related information • • Audio and media - menu overview (p. 65) Audio and media - operating the system (p. 21) * Option/accessory. 69 AUDIO AND MEDIA Menu overview - AUX Overview of possible options and settings for AUX. Menu overview - Bluetooth® handsfree* Receive vCard (p. 61) Overview of possible options and settings for Bluetooth® handsfree. Memory status (p. 61) Clear phone book (p. 62) Main menu AUX See page AUX input volume (p. 48) Main menu Bluetooth® handsfree (Phone menu) See page Audio settings (p. 26) All calls (p. 55) Sound stage* (p. 27) All calls (p. 55) Equalizer* (p. 27) Missed calls (p. 55) Volume compensation (p. 28) Answered calls (p. 55) Reset all audio settings (p. 26) Dialled calls (p. 55) Call duration (p. 55) Change phone (p. 52) Remove Bluetooth device (p. 53) Phone settings Related information • • 70 Audio and media - menu overview (p. 65) Audio and media - operating the system (p. 21) Phone book (p. 57) Search (p. 59) New contact (p. 60) Speed dials (p. 61) Discoverable (p. 50) Sounds and volume (p. 56) Download phone book (p. 57) Bluetooth software version in car (p. 56) Call options Auto answer (p. 55) * Option/accessory. AUDIO AND MEDIA Voicemail number Disconnect phone (p. 55) (p. 52) Related information • • Audio and media - menu overview (p. 65) Audio and media - operating the system (p. 21) Licenses A license is an agreement for the right to operate a certain activity or the right to use someone else's entitlement according to the terms and conditions in the agreement. The following text is Volvo's agreement with the manufacturer/developer. Sensus software This software uses parts of sources from clib2 and Prex Embedded Real-time OS - Source (Copyright (c) 1982, 1986, 1991, 1993, 1994), and Quercus Robusta (Copyright (c) 1990, 1993), The Regents of the University of California. All or some portions are derived from material licensed to the University of California by American Telephone and Telegraph Co. or Unix System Laboratories, Inc. and are reproduced herein with the permission of UNIX System Laboratories, Inc. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution. Neither the name of the <ORGANIZATION> nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission. THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. This software is based in part on the work of the Independent JPEG Group. This software uses parts of sources from "libtess". The Original Code is: OpenGL Sample Implementation, Version 1.2.1, released January 26, 2000, developed by Silicon Graphics, Inc. The Original Code is Copyright (c) 1991-2000 Silicon Graphics, Inc. Copyright in any portions created by third parties is as indicated elsewhere herein. }} 71 AUDIO AND MEDIA || 72 All Rights Reserved. Copyright (C) [1991-2000] Silicon Graphics, Inc. All Rights Reserved. Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the "Software"), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the following conditions: The above copyright notice including the dates of first publication and either this permission notice or a reference to http:// oss.sgi.com/projects/FreeB/ shall be included in all copies or substantial portions of the Software. THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL SILICON GRAPHICS, INC. BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE. Except as contained in this notice, the name of Silicon Graphics, Inc. shall not be used in advertising or otherwise to promote the sale, use or other dealings in this Software without prior written authorization from Silicon Graphics, Inc. This software is based in parts on the work of the FreeType Team. This software uses parts of SSLeay Library: Copyright (C) 1995-1998 Eric Young ([email protected]). All rights reserved DivX® DivX Certified® to play DivX® video. DivX®, DivX Certified® and associated logos are registered trademarks of DivX, Inc. and are used under license. ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, Inc. This is an official DivX Certified device that plays DivX video. Visit www.divx.com for more information and software tools to convert your files into DivX video. ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play DivX Video-on-Demand (VOD) content. To generate the registration code, locate the DivX VOD section in the device setup menu. Go to http://vod.divx.com with this code to complete the registration process and learn more about DivX VOD. Covered by one or more of the following U.S. Patents: 7,295,673; 7,460,668; 7,515,710; 7,519,274. Related information • Volvo Sensus (p. 6) AUDIO AND MEDIA Type approval Type approval for Bluetooth® module can be read in the table. }} 73 AUDIO AND MEDIA || Declaration of Conformity for Bluetooth® module Country/ Area Countries in the EU: Exporting country: Japan Manufacturer: Alpine Electronics Inc. Type of equipment: Bluetooth® device For further information visit http://ec.europa.eu/enterprise/rtte/faq.htm #informing 74 AUDIO AND MEDIA Country/ Area Czech Republic: Alpine Electronics, Inc. tímto prohlašuje, že tento Bluetooth® Module je ve shodě se základními požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES. Denmark: Undertegnede Alpine Electronics, Inc. erklærer herved, at følgende udstyr Bluetooth® Module overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF. Germany: Hiermit erklärt Alpine Electronics, Inc., dass sich das Gerät Bluetooth® Module in Übereinstimmung mit den grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet. }} 75 AUDIO AND MEDIA || 76 Country/ Area Estonia: Käesolevaga kinnitab Alpine Electronics, Inc. seadme Bluetooth® Module vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele. UK: Hereby, Alpine Electronics, Inc., declares that this Bluetooth® Module is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Spain: Por medio de la presente Alpine Electronics, Inc. declara que el Bluetooth® Module cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE. Greece: Η Α Α Η Α Α Α Alpine Electronics, Inc. Η Ω Α Α Η Bluetooth® Module Η Α 1999/5/ Ω Α Ω . France: Par la présente Alpine Electronics, Inc. déclare que l'appareil Bluetooth® Module est conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE. Italy: Con la presente Alpine Electronics, Inc. dichiara che questo Bluetooth® Module è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE. Latvia: Ar šo Alpine Electronics, Inc. deklarē, ka Bluetooth® Module atbilst Direktīvas 1999/5/EK būtiskajām prasībām un citiem ar to saistītajiem noteikumiem. Lithuania: Šiuo Alpine Electronics, Inc. deklaruoja, kad šis Bluetooth® Module atitinka esminius reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas. Netherlands: Hierbij verklaart Alpine Electronics, Inc. dat het toestel Bluetooth® Module in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG. Malta: Hawnhekk, Alpine Electronics, Inc., jiddikjara li dan Bluetooth® Module jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC. Hungary: Alulírott, Alpine Electronics, Inc. nyilatkozom, hogy a Bluetooth® Module megfelel a vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak. AUDIO AND MEDIA Country/ Area Poland: Niniejszym Alpine Electronics, Inc. oświadcza, że Bluetooth® Module jest zgodny z zasadniczymi wymogami oraz pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/EC. Portugal: Alpine Electronics, Inc. declara que este Bluetooth® Module está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE. Slovenia: Alpine Electronics, Inc. izjavlja, da je ta Bluetooth® Module v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 1999/5/ES. Slovakia: Alpine Electronics, Inc. týmto vyhlasuje, že Bluetooth® Module spĺňa základné požiadavky a všetky príslušné ustanovenia Smernice 1999/5/ES. Finland: Alpine Electronics, Inc. vakuuttaa täten että Bluetooth® Module tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen. Sweden: Härmed intygar Alpine Electronics, Inc. att denna Bluetooth® Module står I överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG. Iceland: Alpine Electronics, Inc. hereby certifies that this Bluetooth® Module conforms to the essential characteristic requirements and other relevant regulations of directive 1999/5/EC. Norway: Alpine Electronics, Inc. erklærer herved at utstyret Bluetooth® Module er i samsvar med de grunnleggende krav og øvrige relevante krav i direktiv 1999/5/EF. }} 77 AUDIO AND MEDIA || Country/ Area China: 第十三条 进口和生产厂商在其产品的说明书或使用手册中,应刊印下述有关内容 1. 标明附件中所规定的技术指标和使用范围,说明所有控制 ■ 使用频率 2.4 - 2.4835 GHz ■ 等效全向辐射 ■ 最大 率(EIRP) 率谱密度 ■ 载频容限 天线增益 天线增益 10dBi 时 ≤100 mW 或≤20 dBm ① ≤20 dBm / MHz(EIRP) ① 率(对应载波±2.5 倍信道带宽以外) ≤-36 dBm / 100 kHz (30 - 1000 MHz) ≤-33 dBm / 100 kHz (2.4 - 2.4835 GHz) ≤-40 dBm / 1 MHz (3.4 - 3.53 GHz) ≤-40 dBm / 1 MHz (5.725 - 5.85 GHz) ≤-30 dBm / 1 MHz (其它 1 - 12.75 GHz) 2. 不得擅自更改发射频率 大发射 率(包括额外 3. 使用时不得对各种合法的无线电通信业 续使用 4. 使用微 率无线电设备,必须忍 5. 不得在飞机和机场附近使用 78 10dBi 时 20 ppm ■ 杂散发射(辐射) • • • • • 调整及开关等使用方法 装射频 产生有害干扰 各种无线电业 率放大器),不得擅自外接天线或改用其它发射天线 一旦发现有干扰现象时,应立即停止使用,并采 的干扰或工业 科学及医疗应用设备的辐射干扰 措施消除干扰后方可继 AUDIO AND MEDIA Country/ Area Taiwan: 低効率電波輻射性電機管理辧法第十条 第十二條 經型式認證合格之低 率射頻電機,非經許可,公司 商號或使用者均不得擅自 變更頻率 大 率或變更原設計之特性及 能 第十四條 低 率射頻電機之使用不得影響飛航安全及干擾合法通信;經發現有干擾現象時, 應立即停用,並改善至無干擾時方得繼續使用 前 項合法通信,指依電信法規定 作業之無線電通信 低 率射頻電機須忍受合法通信或工業 科學及醫療用電波 輻射性電機設備之干 擾 }} 79 AUDIO AND MEDIA || Country/ Area South Korea: 제품 정보 Volvo Car Korea 신청자 코드: KCC-CMM-N25-IAM21L3, KCC-CMM-N25-IAM21L2 and KCC-CMM-N25-IAM21L1 제품 명: Bluetooth Audio Navigation Radio 모델 명: IAM2.1 산 날짜: March/2010 Alpine Electronics, Inc Made in Japan 고객 정보 Volvo Car Korea 볼보자동차코리아 서울시 용산구 한남2동 726-173 볼보빌딩 4층 볼보자동차 고객센터 1588-1777 http://www.volvocars.com/kr 사용자 주의사항 ※당해 무선설비는 전파혼신 가능성이 있으므로 인명안전과 관련된 서비스는 할 수 없습니다 80 AUDIO AND MEDIA Country/ Area The United Arab Emirates: South Africa: Jamaica: Approved for use in Jamaica SMA EI: IAM2.1 Thailand: This telecommunication equipment conforms to NTC technical requirement. Oman 81 ALPHABETICAL INDEX ALPHABETICAL INDEX A Alarm for accidents and disasters Audio settings surround B 32 26 20, 26 E Battery remote control 64 Equalizer Bluetooth® handsfree media microphone off streaming audio transfer call to mobile 53 49 55 49 55 Audio and media introduction manage the system menu overview menus overview 20 21 65 21 20 Audio profile 27 C audio system functions overview 26 20 Calls incoming operation 53 53 Audio system 20 CD 39 Audio volume external audio source phone phone/media player ring signal, phone speed/noise compensation 21 48 56 56 56 28 Controls centre console 21 AUX input 20, 45 D DAB Radio 28, 36 Digital radio (DAB) 36 DVD 39 27 I Image settings 44 Infotainment system source buttons 21 Infotainment system (Audio and media) 20 iPod®, connection 46 K Keypad in the steering wheel 21 M Making calls 53 Media, Bluetooth® 49 Media player compatible file formats 38 44 Menu navigation audio and media 21 Microphone 54 83 ALPHABETICAL INDEX Mobile phone connect handsfree register phone 50 53 50 MY CAR car settings climate settings driver support system information menu Option search paths system settings 10 13 17 14 17 11 11 16 R Radio DAB 28 28, 36 T Traffic information (TP) 33 Type approval Bluetooth® 73 U Radio programme types (PTY) 34 RDS 32 USB, connection 46 Remote control battery replacement 62 64 USB input 45 S News broadcasts 33 Normal view 21 Sensus Signal input, external Steering wheel keypad P 84 55 50 V N Phone connect handsfree incoming call making calls phone book phone book, shortcut receiving a call register phone Support 50 53 53 53 57 57 surround Volvo Sensus 6 20, 45 21 7 20, 26 6 TP 26697 (English), AT 1817, MY19, Copyright © 2000-2018 Volvo Car Corporation
