Uniden 1360 Owner Manual
Model 1360
Call Waiting / Caller ID
Speakerphone with
12 Number Memory
User’s Guide
Interference Information
Base Layout
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference; and (2) This device must accept any
interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
Privacy of Communications may not be ensured when using this product.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna (that is, the antenna for radio or television that is
“receiving” the interference).
• Reorient or relocate and increase the separation between the telecommunications equipment and
receiving antenna.
• Connect the telecommunications equipment into an outlet on a circuit different from that to which
the receiving antenna is connected.
If these measures do not eliminate the interference, please consult your dealer or an experienced
radio/television technician for additional suggestions. Also, the Federal Communications Commission
has prepared a helpful booklet, “How To Identify and Resolve Radio/TV Interference Problems.” This
booklet is available from the U.S. Government Printing Office, Washington, D.C. 20402. Please specify
stock number 004-000-00345-4 when ordering copies.
Notice: The changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Hearing Aid Compatibility (HAC)
display
FCC RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 20
centimeters between the radiator and your body. This transmitter must not be co-located or
operated in conjunction with any other antenna or transmitter.
THE LIGHTNING
FLASH AND ARROW
HEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
“DANGEROUS
VOLTAGE” INSIDE
THE PRODUCT.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR
BACK). NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
SEE MARKING ON BOTTOM / BACK OF PRODUCT
Introduction
CAUTION: When using telephone equipment, there are basic
safety instructions that should always be followed. Refer to the
IMPORTANT SAFETY INSTRUCTIONS provided with this product
and save them for future reference.
Your telephone equipment is approved for connection to the Public Switched Telephone
Network and is in compliance with parts 15 and 68, FCC Rules and Regulations and the Technical
Requirements for Telephone Terminal Equipment published by ACTA.
1 Notification to the Local Telephone Company
On the bottom of this equipment is a label indicating, among other information, the US number
and Ringer Equivalence Number (REN) for the equipment. You must, upon request, provide this
information to your telephone company.
The REN is useful in determining the number of devices you may connect to your telephone line
and still have all of these devices ring when your telephone number is called. In most (but not
all) areas, the sum of the RENs of all devices connected to one line should not exceed 5. To be
certain of the number of devices you may connect to your line as determined by the REN, you
should contact your local telephone company.
A plug and jack used to connect this equipment to the premises wiring and telephone network
must comply with the applicable FCC Part 68 rules and requirements adopted by the ACTA. A
compliant telephone cord and modular plug is provided with this product. It is designed to be
connected to a compatible modular jack that is also compliant. See installation instructions for
details.
Notes
• This equipment may not be used on coin service provided by the telephone company.
• Party lines are subject to state tariffs, and therefore, you may not be able to use your own
telephone equipment if you are on a party line. Check with your local telephone company.
• Notice must be given to the telephone company upon permanent disconnection of your
telephone from your line.
• If your home has specially wired alarm equipment connected to the telephone line, ensure the
installation of this product does not disable your alarm equipment. If you have questions about
what will disable alarm equipment, consult your telephone company or a qualified installer.
US Number is located on the cabinet bottom.
REN Number is located on the cabinet bottom.
2 Rights of the Telephone Company
Should your equipment cause trouble on your line which may harm the telephone network,
the telephone company shall, where practicable, notify you that temporary discontinuance of
service may be required. Where prior notice is not practicable and the circumstances warrant
such action, the telephone company may temporarily discontinue service immediately. In case
of such temporary discontinuance, the telephone company must: (1) promptly notify you of
such temporary discontinuance; (2) afford you the opportunity to correct the situation; and (3)
inform you of your right to bring a complaint to the Commission pursuant to procedures set
forth in Subpart E of Part 68, FCC Rules and Regulations.
The telephone company may make changes in its communications facilities, equipment,
operations or procedures where such action is required in the operation of its business and not
inconsistent with FCC Rules and Regulations. If these changes are expected to affect the use or
performance of your telephone equipment, the telephone company must give you adequate
notice, in writing, to allow you to maintain uninterrupted service.
Visit our website at: www.uniden.com
Volume
You may adjust the handset and speakerphone volume independently with the
VOL ( - or + ) buttons. Both handset receiver volume level and speakerphone volume
level are saved in memory.
speaker
button
VOL (+/-)
buttons
ringer
volume
switch
delete
button
menu
button
store
button
redial/pause
button
*tone
button
flash/exit
button
Short Glossary of Terminology Used in this Manual
Hook switch. The part of the phone that pops up to activate the phone line when the
handset is lifted from the base.
Off-hook. A term used to describe the phone in its active mode when the handset is off
of the base cradle or when the speaker button is pressed.
On-hook. A term used to describe the phone in an inactive mode.
Before You Begin
dial
button
Make sure your package includes the following items:
Your Caller ID phone uses 4 AA-size alkaline batteries for receiving and storing Caller ID
records and for storing the numbers you use for memory dialing, pulse dialing, and redial.
IMPORTANT: You will have approximately 90 seconds to replace
the batteries before the memories stored are lost. Please read the
instructions before replacing the batteries and have the batteries ready
to be inserted beforehand.
1. Disconnect the telephone line cord and remove the desk
stand from the back of the base.
2. Release latch or the battery compartments and remove
cover.
3. Insert 4 AA-size alkaline batteries as shown on the
diagram in the battery compartments.
4. Snap the battery compartment door back into place and
replace the desk stand.
5. Connect the line cord and check your memory locations.
NOTE: If the low battery icon appears in the display, you need to replace
the batteries. It is important that you replace the batteries as soon as
possible in order to maintain Caller ID operation.
Installing the Phone
Your phone should be placed on a level surface, such as a desk or table top, or you can
mount it on a wall.
Connecting the Handset
1. Connect one end of the coiled handset cord to the jack on the handset.
2. Plug the other end of the coiled handset cord to the jack on the base.
3. Place the handset in the cradle.
Base
Handset
Desk stand
(might be
attached to the
base)
Telephone Jack Requirements
To use this phone, you need an RJ11C type modular telephone jack,
which might look like the one pictured here, installed in your home.
If you don’t have a modular jack, call your local phone company to
find out how to get one installed.
2-Wire
Telephone Line
Cord
Wall plate
Modular
telephone
line jack
Important Installation Information
•
•
•
•
•
CAUTION: Disconnect the phone cord from the wall outlet
before installing or replacing the batteries.
Never install telephone wiring during a lightning storm.
Never touch uninsulated telephone wires or terminals, unless the telephone line
has been disconnected at the network interface.
Use caution when installing or modifying telephone lines.
Never install telephone jacks in wet locations unless the jack is specifically
designed for wet locations.
Temporarily disconnect any equipment connected to the phone, such as faxes,
other phones, or modems.
1. Connect one end of the straight telephone line cord to the jack on the back of the base.
2. Connect the other end to a wall phone jack.
3. Set the ringer volume switch located at the back of the base to
the desired loudness.
OFF - Telephone will not ring.
LO - Sound will be lowest.
HI - Sound will be loudest.
NOTE: The unit is properly installed if you pick up the
handset and hear the dial tone. Otherwise, recheck
all installation steps.
Wall Mounting
Your speakerphone can also be mounted on a wall plate (not included).
NOTE: To prevent the handset from falling out
of the cradle while the phone is hanging on
the wall, you must switch both the handset
hook and the desk stand to their wall-mount
positions.
• On the front of the base, pull the handset hook out of
the slot. Rotate hook 180 degrees and flip it from front
to back. Slide it back into the slot.
• Turn the base over. Press in on the tabs and remove
the desk stand from the back of the base.
• Rotate the stand 180 degrees, and insert the hooks
marked WALL into the notches marked WALL. Press
in on the tabs and snap the stand into place.
• Connect the telephone line cord to the wall jack and
the phone. If desired, wrap any excess cord around
the cord hooks as shown.
• Place the mounting slots over the pins on the wall
plate, and slide the base down to lock it into place.
Telephone Basics
You can use the telephone by speaking into and listening through the handset, or by
using the speakerphone.
Receiving a Phone Call
Model 1360
Printed in China
Uniden America Corporation
Ft. Worth, TX
1. Lift the handset or press the speaker button to answer the call.
2. Replace the handset in the cradle or press the speaker button to hang up.
Adjusting the Speakerphone Volume
While using the speakerphone, you can adjust the speaker volume by pressing the
VOL ( - or + ) buttons. The screen displays SPK volume level.
NOTE: Both handset receiver and speakerphone volume return to the
default setting (low) if the unit's power is reset.
Redial
Use the mute button to interrupt a phone conversation to talk privately with someone
else in the room. A conversation can be muted while using the speakerphone or
handset.
1. Press the mute button. The mute indicator illuminates.
2. Press mute again to turn it off.
NOTE: Switching from speakerphone to handset cancels mute.
Flash
Press flash/exit to activate special features of your telephone network, such as call
transfer, or special services from your local telephone company, such as call waiting.
Temporary Tone Dialing
If you have pulse (rotary) service and want to access customer calling services (such
as telebanking and long distance services) that require tone dialing, you can use this
feature to temporarily change from pulse to tone service.
After dialing the telephone number and connecting to the customer calling service,
1. Press and release the *tone button.
2. When you hang up, the telephone automatically returns to pulse dialing mode.
Speakerphone Basics
Location
Your phone features a speakerphone for ease of use and convenience during a phone
conversation. At any time during a conversation, you can lift the handset to stop using
the speakerphone. Likewise, when you are using the handset, press the speaker button
and place the handset in the cradle to switch to the speakerphone.
For best speakerphone performance, avoid the following:
• Areas with high background noise. (The microphone might pick up these sounds and
prevent the speakerphone from going into the receiving mode when you finish talking.)
• Surfaces affected by vibration.
• Recessed areas such as in a corner, under a cupboard, or next to a cabinet, which can
generate an echo effect.
Speakerphone Use
NEEDS Battery Door on bottom
and Strain Relief on bracket
Handset Cord
While using the handset, you can adjust the speaker volume by pressing the
VOL ( - or + ) buttons. The screen displays REC (Handset Receiver) volume.
Mute
# button
Connecting the Telephone Line
Parts Checklist
Adjusting the Handset Receiver Volume
You may redial the last number you called by pressing the redial button after you hear a
dial tone.
NOTE: The redial feature holds the last number (up to 32 digits) that you
dialed in memory. If you pressed any other numbers after dialing the
phone number (for example, when accessing a voice-menu system) then
those numbers are also dialed.
IMPORTANT: If you are not going to use the telephone for more than 30
days, remove the batteries because they may leak and damage the unit.
CAUTION:
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Equipment Approval Information
review (3/4)
buttons
Installing and Replacing the Batteries
Licensed under US Patent 6,427,009.
WARNING: TO
PREVENT FIRE OR
ELECTRICAL SHOCK
HAZARD, DO NOT
EXPOSE THIS
PRODUCT TO RAIN
OR MOISTURE.
memory store
buttons
1. Lift the handset or press the speaker button. Wait for a dial tone.
2. Dial the telephone number you want to call.
3. Replace the handset in the cradle, or press the speaker button to hang up.
mute
button
This telephone system meets FCC standards for Hearing Aid Compatibility.
Licensing
Making a Phone Call
Note the following guidelines when using the speakerphone:
• The speakerphone works similar to a two-way radio in that you can only listen or talk
at one time.
• Stay reasonably close to the phone so that you can be clearly heard by the person to
whom you are talking.
• You can adjust the speaker volume by pressing the VOL ( - or + ) buttons.
• The speakerphone indicator light comes on when the speakerphone is in use.
Caller ID (CID) Features
IMPORTANT: In order to use all of the features of this telephone, you
must subscribe to two separate services available from your local
telephone company: the standard Name/Number Caller ID Service
to know who is calling when the phone rings and Caller ID with Call
Waiting Service to know who is calling while you are on the phone.
CID Summary Screen
The Summary Screen shows the current time, date, and number of new calls to review. It
is displayed until any button is pressed.
NOTE: The number of new calls is displayed until all new calls have been
reviewed.
Receiving and Storing CID Calls
This units receives and displays information transmitted by your local company. This
information can include the phone number,date, and time ;or the name , phone number,
date, and time. The unit can store up to 75 calls for later review. When the memory is full,
a new call automatically replaces the oldest call in memory. The screen displays NEW for
calls received that have not been reviewed. The screen displays REPT for calls received
more than once which have not been reviewed.
Reviewing CID Records
• Press the review 3 or 4buttons to view the call records.
• Press the review 4 button to scroll through the call records from the most recent to
the oldest.
• Press the review 3 button to scroll through the call records from the oldest to the
newest.
• When all of the records have been viewed, The screen displays START/END.
Deleting CID Records
• To delete the record shown in the display, press the delete button once.
• To delete all records while reviewing, press and hold the delete button for about
three seconds. The screen displays DELETE ALL?. Press delete again to complete.
Dialing Back
When reviewing Caller ID records, you can dialback the numbers on the display by
pressing the dial button.
NOTE: If the screen displays PICKUP PHONE, no other changes to
the number can be made. The information sent from the telephone
company is known to be a valid number for dialing back (used only
in very limited areas). Once you pickup the phone, the number is
automatically dialed.
If You Programmed Your Local Area Code
1. Use the review 3 or 4 buttons to display the number you want to dial.
2. Press the dial button.
• If you see a number with seven digits (i.e. 555-1234), then the call is from within your
area code. However, this does not guarantee the call is a local call.
• If you see a number with 11 digits (i.e. 1-234-555-1234), then the call is not from
within your area code.
NOTE: A timer (10 seconds on-hook and 3 seconds off-hook) located in
the upper right side of the display will start, letting you know how much
time is left until the unit returns to the Summary Screen.
3. If you are at on-hook and the screen displays PICKUP OR ADJ, you can adjust the
phone number format by pressing the dial button. If the phone is off-hook and the
screen displays ADJUST, you can adjust the phone number format by pressing the
dial button. For example, sometimes a 7-digit local number cannot be dialed because
it requires a 10-digit or 11-digit format. Press the dial button repeatedly to scroll
through the 7, 10, and 11-digit numbers.
7-digits: 7-digit telephone number (i.e. 555-5555)
10-digits: 3-digit area code + 7-digit telephone number (i.e. 425-555-5555)
11-digits: long distance code 1 + 3-digit area code + 7-digit telephone number (i.e. 1-425-555-5555)
4. To dial the displayed number, and the phone is on-hook, pick up the handset or press
the speaker button before the timer reaches 0. If the phone is off-hook, wait until the
time reaches 0. The screen displays NOW DIALING and the number is dialed.
If You Did Not Program Your Local Area Code
1. Use the review 3 or 4 buttons to display the number you want to dial. You will only
see 10-digit numbers (i.e. 234- 555-1234).
2. See steps 2 through 4 in the previous section to complete the dialback process.
Setting Up the Caller ID Menu
You should not plug the telephone into the modular jack while setting up the Caller ID
menu.
1. Press the menu button to enter the menu feature configuration mode.
# 1. >ENG FRA ESP (CID language default English)
# 2. CONTRAST (default level is 3)
# 3. LOCAL AREA CODE
# 4. TONE PULSE (Default is tone dialing).
2. Press the menu button to scroll through the 4 menu screens.
3. Use the 3 or 4 buttons to select the desired setting.
NOTE: You have 20 seconds following an entry before the phone returns
to the Summary Screen.
Display Language
This adjustment allows you to display the Caller ID prompts in English, French, or Spanish.
1. Press the menu button until the screen displays ENG FRA ESP.
2. Use the review 3 or 4 buttons to select ENG, FRA or ESP.
3. Press the menu button again to save.
Contrast
This adjustment allows you to adjust the contrast of the display.
1. Press the menu button until the screen displays CONTRAST.
2. Use the review 3 or 4 buttons to select level 1, 2, 3, 4, or 5.
3. Press the menu button again to save.
Local Area Code
The telephone uses the programmed area codes to determine the number format to
display when a valid Caller ID signal is received. Numbers that match the local area code
are displayed as seven digits and are used for dialing back previous numbers. Entering
your local area code will also help you immediately know if the call is local or long
distance when viewing the CID records in the display.
NOTE: If you make a mistake and want to start over again, press the
delete button to erase all of the digits.
1. Press the menu button until the screen displays LOCAL AREA CODE.
2. Use the number keys to enter the Local Area Code you want.
3. Press the menu button to save.
Dialing Mode
This adjustment allows you to select tone (touch-tone) or pulse (rotary) dialing.
1. Press the menu button until the screen displays TONE PULSE.
2. Press the review 3 or 4buttons to show the current dialing mode. The default is
TONE dialing.
3. To change the dialing mode, press the review 3 or 4 buttons. The display alternates
between the two modes.
4. Press the menu button again to save.
NOTE: The phone will exit Set Up after 20 seconds if no buttons are
pressed.
REMINDER: The time and date are programmed automatically when the
first Caller ID record is successfully received after set up.
Memory
You may store information in any of the following memory locations: 0 to 9, A, B, and C .
See “Storing a Pause in Memory” and “Temporary Tone Dialing” for more information.
Storing a Name and Number in Memory
1. Press the store button. The screen displays LOCATION?.
2. Press the desired memory location (0-9, A, B, C).
NOTE: You may select memory locations by pressing review 3 or 4
buttons to scroll through the memory locations or press the 0 - 9, A, B, C.
3. Press the store button again to confirm the memory location.
NOTE: If necessary, to erase existing memories, or if you make a mistake,
use the delete button.
4. Use the number keys to enter the telephone number (up to 32 digits) and press the
store button to save. (The unit will not dial a phone number in this mode.) The cursor
automatically moves to the text line for name entry.
5. Use the number keys to enter the name of the person associated with the telephone
number you just entered. More than one letter is stored in each of the number keys.
For example, to enter the name BILL SMITH, press the 2 key twice for the letter B. Press
the 4 key 3 times for the letter I. Press the 5 key 3 times for the letter L.
NOTE: The flashing cursor automatically moves to the next position or
you may press the review3 or 4 buttons to move the cursor to the next
position.
Press the 5 key 3 times for the second letter L. Press the arrow key (4) two times to
insert a space, and press the 7 key 4 times for the letter S. Press the 6 key once for the
letter M. Press the 4 key 3 times for the letter I. Press the 8 key for the letter T. Press the
4 key twice for the letter H.
6. Press the store button to save the name.
7. To enter another name and number in a different memory location, return to step 1
and repeat the process.
Changing a Stored Number
Repeat the storage sequence under “Storing A Name and Number in Memory”, and use
the delete button to delete the old number before entering the new number.
Erasing a Stored Number
1. Press the store button.
2. Press the memory location (0-9, A, B, C) to be erased.
3. Press the delete button.
Copying Caller ID Memories to User Memory
1. Press the review 3 or 4 buttons to view the caller number and name you want to
copy.
2. Press the store button.
3. Press the memory location (0-9, A, B, C). The number flashes if there is a number
already stored in the memory location.
4. Press the store button to enter the edit mode, and then press the store button again
to edit the name.
NOTE: You may select a different memory location by pressing review 3
or 4 buttons to scroll through the memories or press a number key
(0-9, A, B, C).
5. Press the store button to confirm and save, and wait for three seconds to exit.
NOTE: If the name you want to enter is longer than 12 characters, only
the first 12 characters will be copied into memory.
Storing a Redial Number to Memory
1. Press the store button.
2. Press any key (0-9, or quick call buttons A, B, or C) for the memory location. If there is
a number already stored in the memory location it will appear on the display. Use the
review 3 or 4 button to select a different location.
3. Press the store button again to confirm.
4. Press the redial button, and then press the store button again.
5. Enter name, if necessary, and then press the store button to confirm.
NOTE: If you want to edit the number, press the store button again
within three seconds. When you are finished, wait three seconds to exit.
Dialing a Number Stored in Memory While On-hook
1. Press the dial button.
2. To select a memory, press any number key (0-9, A, B, C). The number in that memory
location displays.
NOTE: You may select a different memory location by pressing review
3 or 4 buttons to scroll through the memories or press a number key
(0-9, A, B, C).
3. Press the speaker button, or pick up the handset to dial the displayed number.
Dialing a Number Stored in Memory
1. Lift the handset, or press the speaker button.
2. Press the dial button then press a memory location button.
Cascade Dialing
This process allows you to dial a succession of stored numbers from separate memory
locations. This is useful when you must dial several sequences of numbers, such as with
frequent calls via a telephone company long distance provider.
For example
Memory location
Local access number of long distance company 6
Authorization code (ID) 7
Long distance phone number 8
1. Pick up the handset or press speaker.
2. Press dial button, then press number “6” for the memory location.
3. Press dial button, then press number “7” for the memory location.
4. Press dial button, then press number “8” for the memory location.
5. The number dials automatically.
Storing a Pause in Memory
The redial button has dual functionality and becomes a pause button when the store
button is pressed first. It is valid only when storing a number into memory locations.
Use the redial/pause button to insert a pause when a delay is needed in an automatic
dialing sequence. For example, when you must dial a 9 to get an outside line or when
you enter codes to access your long distance company.
Pre-Dialing
1. With the handset on the cradle, enter the telephone number you wish to call. The
telephone number shows in the display.
2. Lift the handset or press the speaker button and the number automatically dials.
NOTE: Use the delete button to delete an incorrectly entered number.
Caller ID Display Messages
The following special messages indicate the status of a message or the unit:
BLOCKED CALL
The caller of the incoming call is registered as “Private Number” and their Caller ID information is withheld.
CALL WAITING
Indicates a call is waiting on the line.
Battery power level is low.
NO CALLS
The caller memory is empty.
START/END
You are at the beginning or the end of the Caller ID memory log.
UNKNOWN CALLER The incoming call does not have Caller ID service or their service
area is not linked to yours. If the screen displays UNKNOWN
CALLER along with a calling number, the name information for
that number was not available.
Troubleshooting Tips
No Dial Tone
• Check all cabling to make sure that all connections are secure and not damaged.
• Check hook switch: Does it fully extend when handset is lifted from cradle?
No Display
• Replace the batteries.
• Check for proper battery installation.
No Information is Shown After the Phone Rings
• Are you subscribed to Caller ID service from your local telephone company?
• Be sure to wait until the second ring before answering.
Phone Dials in Pulse with Tone Service
• Make sure TONE PULSE is set to TONE DIAL.
Phone Won’t Dial Out with Pulse Service
• Make sure TONE PULSE is set to PULSE DIAL.
Phone Does Not Ring
• Make sure ringer switch is set to LO or HI.
• You may have too many extension phones on your line. Try unplugging some
extension phones.
• Check for dial tone. See Troubleshooting Tips for No Dial Tone.
Incoming Voice Volume Low
• Are other phones off hook at same time? If so, this is normal condition as volume
drops when additional phones are used at once.
• Check the handset receiver or speaker volume.
Memory Dialing
• Make sure you entered the numbers correctly into memory.
General Product Care
To keep your phone working and looking good, follow these guidelines:
• Avoid putting it near heating appliances and devices that generate electrical noise
(for example, motors or fluorescent lamps).
• DO NOT expose to direct sunlight or moisture.
• Avoid dropping and other rough treatment to the unit.
• Clean with a soft cloth.
• Never use a strong cleaning agent or abrasive powder because this will damage the
finish.
• Retain the original packaging in case you need to ship it at a later date.
Service
If trouble is experienced with this equipment, for repair or warranty information, please
contact customer service at 1-800-297-1023. If the equipment is causing harm to the
telephone network, the telephone company may request that you disconnect the
equipment until the problem is resolved.
This product may be serviced only by the manufacturer or its authorized service agents.
Changes or modifications not expressly approved by Uniden America Corporation could
void the user’s authority to operate this product. For instructions on how to obtain
service, refer to the warranty included in this guide or call customer service at 1-800297-1023.
Or refer inquiries to:
Uniden America Service
4700 Amon Carter Blvd.
Forth Worth, TX 76155
Attach your sales receipt to the booklet for future reference or jot down the date this
product was purchased or received as a gift. This information will be valuable if service
should be required during the warranty period.
Purchase Date
Name of Store
Industry Canada (I.C.) Notice
Terminal equipment
NOTICE: This equipment meets the applicable Industry Canada Terminal Equipment
Technical Specifications. This is confirmed by the registration number. The abbreviation,
IC, before the registration number signifies that registration was performed based on a
Declaration of Conformity indicating that Industry Canada technical specifications were
met. It does not imply that Industry Canada approved the equipment.
NOTICE: The Ringer Equivalence Number (REN) for this terminal equipment is marked
on the equipment itself. The REN assigned to each terminal equipment provides
an indication of the maximum number of terminals allowed to be connected to a
telephone interface. The termination on an interface may consist of any combination
of devices subject only to the requirement that the sum of the Ringer Equivalence
Numbers of all the devices does not exceed five.
One-year limited warranty
IMPORTANT: Evidence of original purchase is required for warranty service.
WARRANTOR: UNIDEN AMERICA CORPORATION (“Uniden”) ELEMENTS OF WARRANTY:
Uniden warrants, for one year, to the original retail owner, this Uniden Product to be free
from defects in materials and craftsmanship with only the limitations or exclusions set
out below.
WARRANTY DURATION: This warranty to the original user shall terminate and be of no
further effect 12 months after the date of original retail sale. The warranty is invalid if
the Product is (A) damaged or not maintained as reasonable or necessary, (B) modified,
altered, or used as part of any conversion kits, subassemblies, or any configurations
not sold by Uniden, (C) improperly installed, (D) serviced or repaired by someone other
than an authorized Uniden service center for a defect or malfunction covered by this
warranty, (E) used in any conjunction with equipment or parts or as part of any system
not manufactured by Uniden, or (F) installed or programmed by anyone other than as
detailed by the owner’s manual for this product.
STATEMENT OF REMEDY: In the event that the product does not conform to this
warranty at any time while this warranty is in effect, warrantor will either, at its option,
repair or replace the defective unit and return it to you without charge for parts,
service, or any other cost (except shipping and handling) incurred by warrantor or
its representatives in connection with the performance of this warranty. Warrantor,
at its option, may replace the unit with a new or refurbished unit. THE LIMITED
WARRANTY SET FORTH ABOVE IS THE SOLE AND ENTIRE WARRANTY PERTAINING TO
THE PRODUCT AND IS IN LIEU OF AND EXCLUDES ALL OTHER WARRANTIES OF ANY
NATURE WHATSOEVER, WHETHER EXPRESS, IMPLIED OR ARISING BY OPERATION OF LAW,
INCLUDING, BUT NOT LIMITED TO ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. THIS WARRANTY DOES NOT COVER OR PROVIDE
FOR THE REIMBURSEMENT OR PAYMENT OF INCIDENTAL OR CONSEQUENTIAL DAMAGES.
Some states do not allow this exclusion or limitation of incidental or consequential
damages so the above limitation or exclusion may not apply to you.
LEGAL REMEDIES: This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state. This warranty is void outside the
United States of America and Canada. PROCEDURE FOR OBTAINING PERFORMANCE OF
WARRANTY: If, after following the instructions in the owner’s manual you are certain that
the Product is defective, pack the Product carefully (preferably in its original packaging).
The Product should include all parts and accessories originally packaged with the
Product. Include evidence of original purchase and a note describing the defect that
has caused you to return it. The Product should be shipped freight prepaid, by traceable
means, to warrantor at:
Uniden America Service
4700 Amon Carter Blvd.
Fort Worth, TX 76155
Uniden® is a registered trademark of Uniden America Corporation.
The pictures in this manual are used for examples only. Your actual phone may not look
exactly like the pictures.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
