Firmware User’s Manual
A1D-503-V9.02.27-AC
2018/01/29
Firmware User’s Manual V9.02.27
Table of Contents
Recommended PC Specifications
5
Preparation
6
Connect the Equipment .............................................................................6
Configure the IP Addresses .......................................................................6
Using DHCP server to assign IP addresses:..................................................... 6
Use the default IP address of a camera: ........................................................... 8
Manually adjust the IP address of the PC: ................................................................ 8
Manually adjust the IP addresses of multiple cameras: ........................................... 9
Access the Camera...................................................................................10
Using IPv6 to Access the Camera .......................................................................... 12
Live View
13
Login ..........................................................................................................13
Live View ...................................................................................................14
Setup
17
Access the Setup Page ............................................................................17
Host............................................................................................................18
Host................................................................................................................ 18
Serial Setting .................................................................................................. 19
GPS Position .................................................................................................. 20
Date & Time ...............................................................................................21
Network .....................................................................................................23
IP Address Filtering ........................................................................................ 23
Port Mapping .................................................................................................. 25
HTTPS ........................................................................................................... 27
IEEE 802.1X ................................................................................................... 28
SNMP Setting ................................................................................................. 30
RTP ................................................................................................................ 33
Network (ToS, UPnP, Bonjour, ONVIF) ........................................................... 34
Type of Service ....................................................................................................... 34
TM
UPnP
................................................................................................................... 34
2
www.acti.com
Firmware User’s Manual V9.02.27
Bonjour .................................................................................................................... 35
IP Settings .................................................................................................36
Connection Type ............................................................................................ 36
DNS ............................................................................................................... 38
DDNS ............................................................................................................. 39
Video & Audio ...........................................................................................42
Camera Options ............................................................................................. 42
Line Frequency ....................................................................................................... 42
High Frame Mode ................................................................................................... 43
Rotation ................................................................................................................... 43
Mounting Type ........................................................................................................ 44
Video Application Mode .......................................................................................... 45
Intelligent Video .............................................................................................. 46
Motion Detection ..................................................................................................... 46
Object Counting ...................................................................................................... 54
Heatmap and Dwell Time ........................................................................................ 59
Compression .................................................................................................. 62
Video .............................................................................................................. 65
Day/Night ................................................................................................................ 66
Image ...................................................................................................................... 67
Exposure / White Balance ...................................................................................... 68
OSD ........................................................................................................................ 71
Privacy Mask ........................................................................................................... 73
Audio .............................................................................................................. 75
Audio File ................................................................................................................ 76
Event ..........................................................................................................77
Event Server .................................................................................................. 77
Notification Server Configuration ............................................................................ 81
NVR Configuration .................................................................................................. 81
Event Configuration ........................................................................................ 82
Digital I/O ports ....................................................................................................... 83
Sound Detection ..................................................................................................... 84
Notification message............................................................................................... 85
Upload Video/snapshot and Audio .......................................................................... 86
RFID Card Configuration ................................................................................ 90
Maintenance ........................................................................................................... 90
LED Configuration .......................................................................................... 91
Event List ....................................................................................................... 92
Manual Event ................................................................................................. 96
3
www.acti.com
Firmware User’s Manual V9.02.27
System .......................................................................................................97
User Account .................................................................................................. 97
System Info .................................................................................................... 98
Factory Default ............................................................................................... 99
Firmware Upload .......................................................................................... 100
Firmware Upload from Local ................................................................................. 100
Firmware Upload from the Download Center ....................................................... 101
Save & Reboot ............................................................................................. 102
Logout .....................................................................................................103
Troubleshooting
104
4
www.acti.com
Firmware User’s Manual V9.02.27
Recommended PC Specifications
In order to configure or test the cameras, a PC with following basic specifications is needed:
CPU
Core 2 Duo 2.13 GHz or above
Memory
2 GB or above
Operating System

Windows 7

Windows 8, 8.1

Windows 10
Browser for Accessing
Firmware
Internet Explorer 11.0
Video Resolution
1024x768 or higher
5
www.acti.com
Firmware User’s Manual V9.02.27
Preparation
Connect the Equipment
To be able to connect to the camera firmware from your PC, both the camera and the PC have to
be connected to each other via Ethernet cable. At the same time, the camera has to have its own
power supply. In case of PoE cameras, you can use a PoE Injector or a PoE Switch between the
camera and the PC. The cameras that have the DC power connectors may be powered on by
using a power adaptor.
The Ethernet port LED or Power LED of the camera will indicate that the power supply for the
camera works normally.
Configure the IP Addresses
In order to be able to communicate with the camera from your PC, both the camera and the PC
have to be within the same network segment. In most cases, it means that they both should have
very similar IP addresses, where only the last number of the IP address is different from each
other. There are 2 different approaches to IP Address management in Local Area Networks – by
DHCP Server or Manually.
Using DHCP server to assign IP addresses:
If you have connected the computer and the camera into the network that has a DHCP server
running, then you do not need to configure the IP addresses at all – both the camera and the PC
would request a unique IP address from DHCP server automatically. In such case, the camera
will immediately be ready for the access from the PC. The user, however, might not know the IP
address of the camera yet. It is necessary to know the IP address of the camera in other to be
able to access it by using a Web browser.
The quickest way to discover the cameras in the network is to use the simplest network
search, built in the Windows system – just by pressing the “Network” icon, all the cameras of the
local area network will be discovered by Windows thanks to the UPnP function support of our
cameras.
6
www.acti.com
Firmware User’s Manual V9.02.27
In the example below, the camera model that had just been connected to the network is
displayed.
Double-click the left mouse button on the camera model to automatically launch the default
browser of the PC with the IP address of the target camera filled in the address bar of the browser
already.
If you work with our cameras regularly, then there is even a better way to discover the
cameras in the network – by using IP Utility. The IP Utility is a light software tool that can not
only discover the cameras, but also list lots of valuable information, such as IP and MAC
addresses, serial numbers, firmware versions, etc, and allows quick configuration of multiple
devices at the same time.
Search and download the latest IP Utility from http://www.acti.com/IP_Utility
Upon launching the IP Utility, there will be an instant report as follows:
You can quickly notice the camera model in the list. Click on the IP address to automatically
launch the default browser of the PC with the IP address of the target camera filled in the address
bar of the browser already.
7
www.acti.com
Firmware User’s Manual V9.02.27
Use the default IP address of a camera:
If there is no DHCP server in the given network, the user may have to assign the IP addresses to
both PC and camera manually to make sure they are in the same network segment.
When the camera is plugged into network and it does not detect any DHCP services, it will
automatically assign itself a default IP:
192.168.0.100
Whereas the default port number would be 80. In order to access that camera, the IP address of
the PC has to be configured to match the network segment of the camera.
Manually adjust the IP address of the PC:
In the following example, based on Windows 7, we will configure the IP address to 192.168.0.99
and set Subnet Mask to 255.255.255.0 by using the steps below:
1
3
2
4
8
www.acti.com
Firmware User’s Manual V9.02.27
Manually adjust the IP addresses of multiple cameras:
If there are more than 1 camera to be used in the same local area network and there is no DHCP
server to assign unique IP addresses to each of them, all of the cameras would then have the
initial IP address of 192.168.0.100, which is not a proper situation for network devices – all the IP
addresses have to be different from each other. The easiest way to assign cameras the IP
addresses is by using IP Utility:
With the procedure shown above, all the cameras will have unique IP addresses, starting from
192.168.0.101. In case there are 20 cameras selected, the last one of the cameras would have
the IP 192.168.0.120.
Later, by pressing the “Refresh” button of the IP Utility, you will be able to see the list of cameras
with their new IP addresses.
Please note that it is also possible to change the IP addresses manually by using the Web
browser. In such case, please plug in only one camera at a time, and change its IP address by
using the Web browser before plugging in the next one. This way, the Web browser will not be
confused about two devices having the same IP address at the same time.
9
www.acti.com
Firmware User’s Manual V9.02.27
Access the Camera
Now that the camera and the PC are both having their unique IP addresses and are under the
same network segment, it is possible to use the Web browser of the PC to access the camera.
You can use any of the browsers to access the camera, however, the full functionality is
provided only for Microsoft Internet Explorer.
The browser functionality comparison:
Functionality
Internet Explorer
Live Video
Yes
Live Video Area Resizable
Yes
PTZ Control
Yes
Capture the snapshot
Yes
Video overlay based configuration (Motion
Yes
Detection regions, Privacy Mask regions)
All the other configurations
Yes
When using Internet Explorer browser, the ActiveX control for video stream management will be
downloaded from the camera directly – the user just has to accept the use of such control when
prompted so. No other third party utilities are required to be installed in such case.
10
www.acti.com
Firmware User’s Manual V9.02.27
The following examples in this manual are based on Internet Explorer browser in order to
cover all functions of the camera.
Assuming that the camera’s IP address is 192.168.0.100, you can access it by opening the Web
browser and typing the following address into Web browser’s address bar:
http://192.168.0.100
Upon successful connection to the camera, the user interface called Web Configurator would
appear together with the login page. The HTTP port number was not added behind the IP
address since the default HTTP port of the camera is 80, which can be omitted from the address
for convenience.
Before logging in, you need to know the factory default Account and Password of the camera.
Account: Admin
Password: 123456
11
www.acti.com
Firmware User’s Manual V9.02.27
Using IPv6 to Access the Camera
The camera is IPv6-ready and has been assigned its unique static IPv6 address. The IPv6
address can be found under the System > Sytem Info menu (see System Info on page 98 for
more information).
To access the camera with the IPv6 address, type the IPv6 address enclosed in square brackets
on the web browser address bar. For example:
http://[fe80:0000:0000:0000:020f:7cff:fe0d:690c]
12
www.acti.com
Firmware User’s Manual V9.02.27
Live View
This section describes how to configure the IP camera. The administrator has unlimited access to
all settings, while the normal user can only view live video.
Login
Initially there exists only administrator’s account in
the camera (Account: Admin, Password: 123456)
– you have to use that account to log in. You can
later create normal user accounts with limited
access rights if necessary.
Feel free to choose your local language from the list
of languages or keep it as English. After pressing
“Login”, you will be able to access the user interface
of Web Configurator.
Upon successful login, you will be able to see the Live View page. In case of
Internet Explorer browser, you may be prompted to allow the installation of
ActiveX control from the camera. Press “Install” then. The live video will
appear shortly after that.
13
www.acti.com
Firmware User’s Manual V9.02.27
Live View
The live view will appear automatically with the default video resolution.
While being on the Live View page, the Live View icon appears as being pressed:
If you leave the Live View page, you can later return by pressing that button.
The buttons shown on the Live View page vary depending on the functions supported by the
camera.
If the resolution of the PC’s monitor is bigger than the resolution of the live video, you will be able
to see the whole size of the video immediately. If not, you will only see part of the video at first
and you would have to use the scroll bars to see the rest of the video area. In order to see the
whole video on your display, you can temporarily re-scale the video to better fit your screen by
pressing the digital zoom buttons:
- Enlarge the video size digitally
- Reduce the video size digitally
14
www.acti.com
Firmware User’s Manual V9.02.27
Notice: These digital zoom adjustments do not influence the actual video resolution of the camera.
Regardless of how large or small the video appears on the display after pressing the digital zoom
buttons, the actual video stream size of the camera is the same as before.
You can also digitally re-scale the video to fully match the size of your display with just 1 click:
- Full screen Mode
You may use ESC key from the keyboard to exit the full screen mode.
The cameras have triple stream capability – the Stream 1 is usually the high resolution stream
with the purpose of being recorded by NVR while Stream 2 and Stream 3 have lighter video
configuration for NVR live view purposes, to reduce the computing power of the NVR PC. The
streams can be configured under Web Configurator’s Setup page. To see how each of the stream
looks like, click the Stream (number) button and select the stream you want to view.
- Show the Stream 1 video
- Show the Stream 2 video
- Show the Stream 3 video
15
www.acti.com
Firmware User’s Manual V9.02.27
To capture the snapshots of the current live view, press the snapshot button. The snapshots are
saved in Pictures folder.
- Take a Snapshot
Cameras with audio function have the audio controls on Live View page.
- Speak to Camera
To speak to the camera, press the
button. If the camera is connected to a network video
recorder, the audio will be recorded with the video stream.
To adjust the volume level of the speakers connected to the PC that runs the Web Configurator in
order to hear the audio from the camera’s microphone or line-in device, use the audio controls as
below:
Audio Muted:
Audio level adjusted to the maximum:
This volume control appears on the user interface only when the Audio-in function of the camera
has been “Enabled” under Setup page.
16
www.acti.com
Firmware User’s Manual V9.02.27
Setup
The following chapters guide you through the Setup functions of the camera.
Access the Setup Page
To configure any of the camera settings, go to the Setup menu by pressing the following button
on Live View page:
- Go to Setup
The left side of the Setup page contains the list of Setup items.
Notice: The exact content of the menu list varies for each camera,
depending on the actual capabilities of each camera. This manual,
however, is designed to explain all the possible functions.
Several items in the Setup page are divided into groups, such as Network, IP Settings, etc. You
can expand the groups to see the sub-items by pressing the [+] button.
The following chapters of this manual explain each Setup item separately. The chapters are listed
in the same order as the list of Setup menu items.
17
www.acti.com
Firmware User’s Manual V9.02.27
Host
The section Host contains the controls for following functions:
Host
Serial Setting (as applicable)
GPS Position
Host
The function “Host” allows the administrator to define the name of the camera and preferred user
interface language.
There are two kinds of names – Host Name and Camera Name.
Host Name is used to identify the camera by a DHCP server. In some networks with very strict
security policy, it is required that all the network devices should have their host name, and when
the devices attempt to access the network by requesting an IP address from a DHCP server, the
DHCP server would check if the host name is among the allowed devices. On this page, it is
possible to edit the Host Name. To actually include the Host Name in DHCP discovery packet
sent from a camera, please go to IP Settings and make sure the device is in Dynamic IP
Address mode and “Use host name” is checked.
Camera Name is used to identify the device by Video Management System or by Software
Tools. Usually, upon installation of the camera, the actual installation location is used as an
easy-to-remember Camera Name, such as “Front Gate” or “Elevator 1”. In many cases the VMS
is able to modify the Camera Name directly via its own user interface without needing to access
Web Configurator.
Language selection under Host has the same purpose as the one on the login page of Web
Configurator.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
18
www.acti.com
Firmware User’s Manual V9.02.27
Serial Setting
The Serial Setting section allows the user to set the serial port configuration of the camera to
synchronize it with the serial port configurations of a Pan-Tilt (PT) device. This section is
displayed only when the camera model supports the serial port feature.
Serial Port Control: Select the serial port control that matches with the serial port configured on
the PT device. This function is equivalent to the DIP switch of the PT device.
Serial Port Baud Rate: Select the serial port baud rate that matches with the baud rate set on
the PT device.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not applied yet.
19
www.acti.com
Firmware User’s Manual V9.02.27
GPS Position
The GPS Position section allows users to manually set the GPS position of the camera and find
the location of the camera on the map when using a Network Video Recorder (NVR).
Check the Enabled box to enable this feature.
Find the camera location on google maps, for example, installed in the airport.
Copy the first GPS coordinates from the URL bar and paste it on Degree of Latitude. Copy the
second part of the GPS coordinates to Degree of Longitude.
Press Apply to save the changes.
20
www.acti.com
Firmware User’s Manual V9.02.27
Date & Time
Each video frame contains a time stamp. The accuracy of the time stamp is very important for
incident investigators. Therefore the clock of the camera has to be adjusted to most accurate time
possible.
The section Date & Time provides the options for adjusting the date
and time of the camera.
There are two ways to adjust the date and time – automatically by getting date and time
regularly from any of the NTP servers worldwide, or manually by selecting proper time zone,
date and time. The automatic way can be used only if the camera has an access to NTP servers.
If you are using an isolated Local Area Network without Internet access, you can only use Manual
date and time adjustment mode.
When choosing SNTP/NTP Server for automatic date and time updating, you can key in the IP
address of the NTP server and the time interval for automatic time synchronization. If you want to
key in the domain name of NTP server instead, please make sure the DNS server IP address has
been set under IP Settings; otherwise the camera will not be able to resolve the domain name of
the NTP server.
21
www.acti.com
Firmware User’s Manual V9.02.27
If all the cameras are getting the date and time from the same NTP Server, you can be most sure
that the video clips from different cameras can be well synchronized later for comparison
purposes.
To choose the most suitable NTP Server to synchronize date and time with, please refer to the
worldwide pool of NTP Servers: http://www.pool.ntp.org/en/
When choosing Set Manually mode, you can adjust the date and time by the select boxes.
Choose the appropriate Time Zone from the select box, too. If your location is not listed there,
then pick any of the listed zones which GMT is identical with your location.
For the countries with daylight saving policy, there is Day Light Saving function with two different
types:
Type 1 – define the starting or ending time of daylight saving period by the number of the week
in the month (First, Second, Third or Last week).
Type 2 – define the starting or ending time of daylight saving period by the exact date in the
month (1-31).
Whether to choose Type 1 or Type 2, please refer to the daylight saving policy of given country.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
22
www.acti.com
Firmware User’s Manual V9.02.27
Network
The section Network provides the list of network related functions
and services. The [+] mark before Network indicates that the list can be expanded by clicking on
it. Once expanded, the list can later be collapsed again by clicking on the [-] mark.
IP Address Filtering
By “IP Address Filtering” function it is possible to define which
devices (their IP addresses) are allowed to connect to this camera, and which devices are
forbidden to connect to this camera.
Check the box “Enabled” to activate the IP address filtering function and press Apply.
Below you can select either “Allowed” or “Blocked” list to add items there and Enable them with
the checkbox behind each row.
“Allowed” mode will refuse access to all IP addresses except the ones listed below.
“Blocked” mode will accept all incoming access except the IP addresses listed below.
23
www.acti.com
Firmware User’s Manual V9.02.27
Using Netmask (Subnet Mask) allows you to set filtering for a whole range of IP address at once,
without the need to enter all of them individually. If you are not sure about the function of Netmask,
then you should use 255.255.255.255, and it will affect only a single IP address per line of entry,
or use 255.255.255.0 to use the same setting for all IP addresses starting with the same three
numbers. .
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
Warning! Do not accidentally block your own IP address that you are connecting from; otherwise
you will not be able to access the camera any more to undo the changes. If this happens by
mistake, you can do the hardware reset – it will clear all the filtering rules.
24
www.acti.com
Firmware User’s Manual V9.02.27
Port Mapping
The section Port Mapping provides the list of services and protocols
that require their own port number for communication. By default, the camera already has all the
ports defined. On this page, the user can modify the port numbers in case there is a specific need
for that. Most often, the HTTP port is changed to something other than 80 in order to match with
easy-to-remember port forwarding rules of the router that acts as a bridge between local area
network and Internet.
NOTE: Some items appear only if the camera model supports the function.
Parameters
Description
HTTP port
Select the port assigned for HTTP protocol access.
HTTPS Port
Select the port assigned for HTTPS protocol access.
Search Server Port1
Select the first port used by server search applications to detect this IP
device (e.g. IP Utility).
Search Server Port2
Select the second port used by server search applications to detect this IP
device (e.g. IP Utility).
Control Server Port
Select the port used to support video control function by application
programs (e.g. NVR).
Streaming Server Port
Select the port used by this IP device for Video Streaming (TCP).
RTSP Server Port
Select the port assigned for RTSP protocol access.
25
www.acti.com
Firmware User’s Manual V9.02.27
Multicast Setting allows users to configure the IP addresses and ports for multicast video and
audio (supported models only) streams. Multicast is a protocol where a data stream is sent only
once and shared to requesting devices. This in turn saves network bandwidth. However, to use
this feature, network devices, such as routers and switches, should support IP multicast.
Parameters
Description
Stream 1
Refers to the video stream 1.
Stream 2
Refers to the video stream 2.
Stream 3
Refers to the video stream 3.
Audio
Refers to the audio stream.
NOTE: Appears only if the camera model supports audio input/output.
By Requests
When checked, the video or audio stream will be streamed only to a
particular receiver when that receiver sends a request or in the case of the
Network Video Recorder (NVR), selects to view or record the stream. If
unchecked, the video or audio stream will constantly be streamed to the
network whether there are devices viewing the video or not.
To save on network bandwidth, it is recommended to check this function.
Multicast IP
Set the multicast IP of the corresponding stream.
Network Port
Enter the assigned port for the corresponding stream.
Multicast TTL
Enter the multicast TTL (time-to-live) of the corresponding stream. This
value determines the time span (in seconds) when the packet is retained
in the network. When the time expires and no request is received, the
packet is then discarded.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet. New port settings will only take
effect after pressing System -> Save & Reboot.
26
www.acti.com
Firmware User’s Manual V9.02.27
HTTPS
HTTPS protocol allows creating a secure channel over an insecure
network in order to protect the data sent between the camera and its counterpart. Two things are
required to have a secure communication – encrypted data, and verified counterpart of the
communication. To make sure that the messages are being sent and received from true
counterpart, the certificate is needed.
There is an option to enable Secure Socket Layer (SSL) HTTPS security protocol aside from
the default Transport Layer Security (TLS).
There are two methods to create certificates – Certificate Signing Request (CSR) and
Self-Signed Certificate.
Certificate Signing Request (CSR) Management: User uses a signed certificate issued by
trusted Certification Authority (CA).
Certificate Management: User wants to use the certificate created and issued by the user
himself.
Press Create Self-Signed Certificate button and configure settings in the pop-up screen to
install the certificate.
Note that the new setting will only take effect after Save & Reboot.
27
www.acti.com
Firmware User’s Manual V9.02.27
IEEE 802.1X
IEEE 802.1X is an IEEE standard for port-based Network Access
Control. 802.1X authentication involves three parties: a supplicant, an authenticator, and an
authentication server.
The supplicant is a client device (such as an IP camera) that wishes to attach to the LAN/WLAN.
The authenticator is a network device, such as an Ethernet switch or wireless access point; and
the authentication server is typically a host running software supporting the RADIUS and EAP
protocols.
The authenticator acts like a security guard to a protected network. The supplicant (i.e., client
device) is not allowed access through the authenticator to the protected side of the network until
the supplicant’s identity has been validated and authorized. An analogy to this is providing a valid
passport at an airport before being allowed to pass through security to the terminal. With 802.1X
port-based authentication, the supplicant provides credentials, such as user name / password or
digital certificate, to the authenticator, and the authenticator forwards the credentials to the
authentication server for verification. If the authentication server determines the credentials are
valid, the supplicant (client device) is allowed to access resources located on the protected side
of the network.
Please enable IEEE 802.1x and configure settings on the screen below. Note that the new
setting will only take effect after “Save & Reboot”.
EAPOL Version V1 and V2 are the 802.1X communication types. CA certifacate is provided by
RADIUS Server. If there is a vaild CA certifacate exist already, there will be a Remove button
behind these items, in order to remove these items when necessary.
28
www.acti.com
Firmware User’s Manual V9.02.27
Base on the setting in RADIUS Server, There are two methods to set User Certificate.
When choosing Import User Certificate & User Private Key, the User name and User
password area created by user and set in RADIUS server. The User Certificate and Private
Key are provided by RADIUS Server. If CA certificate or private key exist already, there will be a
Remove button behind these items, in order to remove these items when necessary.
When choosing User Certificate by Certificate Signing Request (CSR), the Identity should be
set in RADIUS server.
The Common Name, Identity and User Certificate are provided from by in RADIUS server. If
there is a vaild User Certifacate exists already, there will be a Remove button behind these items,
in order to remove these items when necessary.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
29
www.acti.com
Firmware User’s Manual V9.02.27
SNMP Setting
The SNMP Setting item displays the SNMP configuration page.
SNMP provides an easy way to manage network devices. The main features are:
1. Monitoring device uptime
2. System detail description. (Ex: model name, model description and firmware version.)
3. Collect interface information. (Ex: MAC address, interface speed, local port.)
4. Measuring network interface throughput.
To use SNMP, just enable SNMP function in the camera (SNMP agents) and run SNMP
management software in server (NMS: Network Management Station) to connect to the devices.
The SNMP agent supports versions V1, V2 and V3. SNMP V1 is the initial implementation of
SNMP. SNMP V2 is proposed to enhance the performance of management, such as the
communication of server and devices, the confirmation of information delivery and receipt.
Primary additions in SNMP V3 concern security and remote configuration enhancements.
SNMP V1/V2 uses “Community” name as password to authenticate identity. “Read Community”
is the password for server to get information from devices. “Write Community” is the password for
server to edit values on devices. The default is “public” for Read Community and “write” for Write
Community. Of course, you can set any other password as your read/write community.
You can enable V1, V2 or both. Click “Apply” after you’ve completed setup.
The security method of SNMP V3 uses account/password for authentication. “Security Name” is
30
www.acti.com
Firmware User’s Manual V9.02.27
the account name to be used with your “Password”. The default security name is “public” and the
password must be at least 8 characters long. You also can set any other security name or
password. Click “Apply” after you’ve completed setup.
SNMP function is now enabled. You may now install and run the SNMP management software on
computer server.
SNMP Trap Usage:
SNMP traps enable notifications from devices. Devices may send message to the management
server whenever significant events occur such as cold start, warm start and authentication failure.
The manager will get the information immediately and take action if necessary.
Cold start means device reboot by power disconnection. Warm start means device reboot by
firmware without power disconnection. If there other parties attempt to connect to the device with
wrong security password under SNMP V1, V2 or V3 setting, the device will send an
authentication failure message to the management server.
To enable SNMP Trap function in the camera, type the IP address of the computer running the
SNMP management software and type trap community as password to allow server to get trap
message from device (Default is public). Select available traps and click “Apply”.
Camera’s SNMP offers following information:
Group
System
Interface
Address
Translation
IP
ICMP
Description
Provide general information about the managed device.
Ex: system description, system name.
Provide general information from the physical interfaces.
Ex: interface speed, MAC address.
Provide information about the mapping between network addresses and physical
addresses for each physical interface
Ex: The IP/MAC addresses to connect to the managed device.
Provide the status and operation of Network Layer (Layer 3).
Ex: the information and traffic flow of received/delivered package.
Provide the status and statistics of ICMP.
31
www.acti.com
Firmware User’s Manual V9.02.27
TCP
UDP
SNMP
Ex: amount of receive/error message of ICMP.
Provide the status and operation of Transport Layer (Layer 4) using TCP protocol.
Ex: TCP Local Port, incoming/outgoing TCP segments.
Provide the status and operation of Transport Layer (Layer 4) using UDP protocol.
Ex: UDP Local Port, in/out datagram.
Provide the related statistics through SNMP
32
www.acti.com
Firmware User’s Manual V9.02.27
RTP
The RTP section allows user to configure RTP Settings.
If the RTSP Authentication is “Enabled”, then the RTP streaming will require account name and
password authentication.
If the RTP B2 Frame is “Enabled” then the B2 frame is added to every video frame, containing
additional information, such as motion detection status on each frame, digital input and
digital output levels, passive infrared status, other video intelligence data, frame counter,
frame-rate mode and the frame-rate, bitrate, resolution, timestamp and much more. The
user side can operate with video data easily, including event management, storage consumption
estimation, image resizing for preview, etc.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
33
www.acti.com
Firmware User’s Manual V9.02.27
Network (ToS, UPnP, Bonjour, ONVIF)
The section Network contains the controls for following functions:
Type of Service
UPnP
Bonjour
Type of Service
The “Type of Service” provides 4 options to
define the priorities of how the data from the
camera should be handled by the routers that
support ToS concept. By the default, the ToS
priority is set as “Normal Service”.
For special priority arrangement, there are 3 more options:
Minimize Delay
Maximize Throughput
Maximize Reliability
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
UPnP
TM
The section UPnP
TM
provides the option to enable
or disable the Universal Plug and Play capability
TM
of the camera. Having the UPnP
enabled allows
the other network devices to seamlessly discover
it on the network for convenient identification and
access.
The Friendly Name is a human-readable name for the device that will be displayed when the
camera is found. By default, the serial number of the camera is used as a friendly name; however,
the user can modify the name according to the project needs.
34
www.acti.com
Firmware User’s Manual V9.02.27
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
Most of the Windows-based computers have the capability to discover the devices that support
TM
UPnP . Below is the example of Windows 7: by clicking on the Network icon of Windows 7, the
PC will discover the cameras instantly.
Bonjour
The section Bonjour provides the option to enable or
disable the ability of the camera to be discovered by
the other network devices using Bonjour protocol,
developed by Apple Inc. Both Bonjour and UPnP
serve the similar purpose – to discover devices
conveniently.
Similarly to UPnP, the human readable Friendly Name can be defined by the user. That name
will be displayed when the camera is found in the network. By default, the Friendly Name is the
serial number of the camera; however, the user can modify the name according to the project
needs.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
35
www.acti.com
Firmware User’s Manual V9.02.27
IP Settings
The section IP Settings provides the options to define how the
camera would obtain its IP address; and to which DNS server should the camera connect to, in
order to resolve domain names.
Connection Type
The sub-section Connection Type allows defining the method of
obtaining the IP address of the camera. By default, the camera is in Dynamic IP Address mode
and attempts to get the IP address from a DHCP server. If such attempt fails after several
seconds (for example the DHCP server does not exist), the camera will automatically assign itself
an IP address, listed under Static IP Address.
Host Name is used to identify the camera by a DHCP server. In some networks with very strict
security policy, it is required that all the network devices should have their host name, and when
the devices attempt to access the network by requesting an IP address from a DHCP server, the
DHCP server would check if the host name is among the allowed devices. On this page, it is
possible to edit the Host Name and enable or disable the use of host name.
Most installation projects include clear network topology and static IP addresses for each camera.
In such cases, you can change the camera to Static IP Address mode and modify the IP
Address, Subnet Mask and Gateway accordingly.
36
www.acti.com
Firmware User’s Manual V9.02.27
In some rare cases, the camera may be connected to the control center over Internet. Usually,
the most cost efficient way is to use ADSL connection with PPPoE. To avoid the unexpected
changes of IP addresses by Internet Service Provider upon the restart of the camera, it is
recommended to activate a DDNS service for such scenario, and let the control center connect to
the camera by the domain name instead. Please refer to the DDNS section for more details.
To set the camera in PPPoE mode, set the radio button to PPPoE and key in the User Name and
Password, provided by Internet Service Provider.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
New IP address settings will only take effect after pressing System -> Save & Reboot.
37
www.acti.com
Firmware User’s Manual V9.02.27
DNS
The section DNS allows setting up the Domain Name Service for
the camera. The camera will connect to the DNS server when there is a need to resolve a domain
name for sending data to.
The most common usage is the ftp or e-mail server in the Event Handler section is defined by
using domain names. Without having DNS service configured, the camera would not know how
to resolve the domain names of FTP or e-mail servers.
It is possible to configure both Primary and Secondary DNS servers. The Secondary DNS
Server will be used when the connection to the Primary DNS Server fails.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
38
www.acti.com
Firmware User’s Manual V9.02.27
DDNS
There are surveillance solutions that consist of single
cameras scattered over a wide territory, therefore each of those cameras should be connected to
the Internet in order to become accessible by Control Center. For example, the chain stores, bus
stops, currency exchange booths, etc.
In such cases, one of the practical networking solutions is to use DSL modem on camera site and
let the camera obtain the dynamic IP address from the Internet Service Provider through the DSL
modem using PPPoE connection, which is much more cost-effective than applying for static IP
address.
PPPoE Connection with Dynamic IP address
Internet
IP Camera
DSL Modem
Control Center
(NVR)
Video Stream from camera to NVR
Commands from NVR to camera’s IP address
However, there is one drawback in this solution – in order to do the remote surveillance from the
Control Center, the NVR Server in the Control Center has to know the address of the IP camera
at all times in order to get the video stream from the camera. If the camera’s network connection
has been reset for any reason, the camera will get a new IP address through DSL Modem, which
may be different from the previous one. NVR will not know about this change, and the connection
between the camera and NVR will fail.
There however exists a solution that makes sure the NVR can find the camera even if the camera
IP changes frequently. Our cameras support Dynamic DNS or DDNS service that allows
frequently changing IP be mapped to a certain unchangeable domain name. The mapping
database and its updating engine are hosted in one of the Dynamic DNS servers, most of which
offer basic services for free, such as www.dyndns.org.
How does it work? Look at the graph below.
39
www.acti.com
Firmware User’s Manual V9.02.27
Using Dynamic DNS
Internet
IP Camera
DSL Modem
Control Center
(NVR)
Camera notifies DDNS service when IP changed
NVR uses camera’s domain name to ask DDNS
DDNS tells the NVR what the camera’s IP is
Commands from NVR to camera’s IP address
DDNS Service
Video Stream from camera to NVR
Every time the IP camera gets an IP that is different from previous one, it notifies the public
DDNS Service about the change. The DDNS Service updates its database immediately, mapping
the assigned domain name (for example camera123.dyndns.org) to the new IP address. In NVR
settings, only the domain name (camera123.dyndns.org) is used to identify the camera. Every
time when NVR needs to connect to the camera, it asks from DDNS Service what the current
camera’s IP is. The DDNS Service instantly responds to NVR and tells it the camera’s IP. Now
NVR will use the IP of the camera to connect to the camera and the video stream from the
camera to NVR can be initiated.
As a result, NVR can always find the IP camera regardless of frequently changing IP address of
the camera. Since there are so many public DDNS Services available for free, the PPPoE-based
connection is really a good and low-cost solution for single-camera sites.
40
www.acti.com
Firmware User’s Manual V9.02.27
To activate DDNS, please check the “Enabled“. Select the service reference, input the Host
Name (the domain name given to the camera by DDNS service, User Name and Password of
the DDNS server account.
You will get the needed Host Name, User Name and Password information from the DDNS
service provider once you have registered an account there and requested a domain name for
your camera.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
41
www.acti.com
Firmware User’s Manual V9.02.27
Video & Audio
The section Video & Audio provides the options to adjust the video
quality, configure the streaming details of the camera, and audio settings (for Audio supported
cameras only), which will be described in the succeeding pages.
The default settings of the camera are sufficient for most environments and the video
adjustments are not necessary. The following sections explain the ways to configure the video
quality or streaming details in case it is required to do so.
The [+] mark before Video indicates that the list can be expanded by clicking on it. Once
expanded, the list can later be collapsed again by clicking on the [-] mark.
Camera Options
In general, the Camera Options submenu allows users to set the
Line Frequency, Mounting Type, Video Application Mode, High Frame Mode, and Rotation
properties of the camera. Depending on the camera type, the parameters on the Camera
Options screen may vary.
Line Frequency
Line Frequency is the function that adjusts the shutter speed options to match with the
frequence of artificial light source of given country. For example, in Europe the light frequency
(due to power supply frequency of lights) is 50Hz, that is 50 flashes per second. By setting line
frequency to 50Hz in such case, the shutter speed options will be proportional with light source
frequency, such as 1/25s, 1/50s, 1/100s, etc.
42
www.acti.com
Firmware User’s Manual V9.02.27
It is necessary to have the camera’s Line Frequency adjusted according to the power
frequency of the light source to avoid flickering effect.
The natural light source (sun light) is a seamless flow of light – the Line Frequency setting does
not matter for the cameras that are only exposed to natural light.
High Frame Mode
High Frame Mode (available in select models only) allows users to select the resolution with
60fps frame rate, where some video settings such as Exposure and White Balance, etc. will be
automatically configured. This configuration will be set as the video stream 1 and the original
configuration of stream 1 will now be video stream 2 and so on.
When any of the settings on this page have been modified, click the Apply button and reboot to
make the changes effective.
NOTE: High Frame Mode is enabled only if Rotation is disabled.
Rotation
Rotation (available in select models only) allows the camera view to rotate 90° or 270°. Also
known as the “Corridor” view, rotation provides longer vertical viewing angle where farther
objects can be seen with more details, while the horizontal viewing angle becomes narrower. This
function is useful when installing the camera along corridors or pathways. Examples are shown
below:
Rotation: Disabled
Rotation: 90°
43
www.acti.com
Firmware User’s Manual V9.02.27
To rotate the camera view, follow the procedures below:
1. Select the Rotation option.
2. Click the Apply button.
3. From the main menu, click System > Save & Reboot.
4. Click Apply to reboot the camera and apply the changes.
NOTE:

This feature is not available in PTZ cameras.

If Rotation is enabled, High Frame Mode is automatically disabled.
Mounting Type
Mounting Type (available in select models only) defines how the camera is mounted to display
the appropriate view. Options are: Wall, Ceiling, Ground, and Corner.
Select Wall, if the camera is mounted on the wall; Ceiling, if mounted on the ceiling; and Ground,
if the camera is placed on the ground facing up the sky.
Select Corner if the camera is mounted together with the corner mounting accessories (optional,
sold separately). The purpose of this option is to show the dewarped view of the two sides of the
corner in one horizontal view while removing the unwanted edge of the building on the view.
44
www.acti.com
Firmware User’s Manual V9.02.27
Video Application Mode
Video Application Mode (available in select models only) defines how you want the image to be
displayed on Live View. This parameter also defines the range of available frame rate and
resolution settings of the hemispheric camera. Options are the following:

Preview Mode (available in Q950 only)

Surveillance Mode
Both the Preview Mode and Surveillance Mode allow you to view the image as either dewarped
panorama or fisheye (see Stream Mode on Compression on page 62 to switch stream modes).
The only difference is the resolution range that each mode supports. With Preview Mode you
can select high resolution options (see camera spec for resolution details), while Surveillance
Mode only allows up to 1920x1080. The higher the resolution, objects appear bigger and closer.
See comparison below:
Preview Mode with Fisheye Stream
Surveillance Mode with Fisheye Stream
Preview Mode with Panorama Stream
Surveillance Mode with Panorama Stream
45
www.acti.com
Firmware User’s Manual V9.02.27
Intelligent Video
The Intelligent Video section allows users to configure the built-in
analytics of the camera. Features may vary depending on the camera model.
NOTE: Intelligent Video is not supported if the Video Application Mode is set to MultiView
Mode (see Video Application Mode on page 44).
Microsoft Internet Explorer browser is required to configure the camera built-in analytics.
For zoom and PTZ cameras, once the camera target view is changed, such as when zooming
in/out or scanning, the built-in analytics must be re-configured.
Motion Detection
The Motion Detection sub-section allows users to configure the video motion detection system
of the camera. Depending on the camera model, the motion detection configuration may vary.
Q950 Motion Detection
For Q950 model, the motion detection algorithm depends on the built-in PIR Motion Sensor.
By default, the PIR motion sensor is enabled.
Sensitivity is the parameter that helps us distinguish actual moving targets (people, vehicles)
from the slightly moving background, such as leaves of the trees waving in the wind. In order to
avoid false alarms, we might want the camera be able to ignore small motion. The higher is the
sensitivity level of the camera, the smaller shift of the object is needed to trigger the alarm. For
example, if the object within motion detection region has moved for about 1-3 pixels during two
46
www.acti.com
Firmware User’s Manual V9.02.27
video frames, then such small motion will be discarded by camera if the sensitivity is low, and will
still trigger an alarm if the sensitivity is high. In other words, you can think of sensitivity level as a
reversed speed limit – the smaller is the sensitivity, the faster are the objects allowed to move
without being detected.
The biggest challenge of motion detection configuration is to find the settings that do not produce
false alarms and at the same time do not miss any actual intrusions. The rule of thumb is: the
sensitivity should be as high as possible while not producing false alarms. The default
sensitivity level of the cameras is 70 (on a scale of 0-100) and it is a good setting for most
standard cases.
Trigger Interval is the time period from the beginning of the triggered event during which all
motion activities are ignored by the camera. This is designed to avoid needless repetitive
reporting of the same intrusion. Trigger interval 20 seconds would mean that when the event
happens, camera will take certain one-time actions and ignore the continuing activity in the
motion detection region for 20 seconds. When 20 seconds are over, the camera will produce a
new alarm if there are still action in the motion detection region, and take actions again.
47
www.acti.com
Firmware User’s Manual V9.02.27
Other Models Motion Detection
For most camera models, up to 10 different regions covering the whole camera view can be
configured for motion detection based on Stream 1.
Sensitivity is the parameter that helps us distinguish actual moving targets (people, vehicles)
from the slightly moving background, such as leaves of the trees waving in the wind. In order to
avoid false alarms, we might want the camera be able to ignore small motion. The higher is the
sensitivity level of the camera, the smaller shift of the object is needed to trigger the alarm. For
example, if the object within motion detection region has moved for about 1-3 pixels during two
video frames, then such small motion will be discarded by camera if the sensitivity is low, and will
still trigger an alarm if the sensitivity is high. In other words, you can think of sensitivity level as a
reversed speed limit – the smaller is the sensitivity, the faster are the objects allowed to move
without being detected.
The biggest challenge of motion detection configuration is to find the settings that do not produce
false alarms and at the same time do not miss any actual intrusions. The rule of thumb is: the
sensitivity should be as high as possible while not producing false alarms. The default
sensitivity level of the cameras is 70 (on a scale of 0-100) and it is a good setting for most
standard cases.
To configure or modify an existing configuration, click on “Setup” to define and adjust the motion
detection region or its parameters. Microsoft Internet Explorer browser is required to configure
the motion detection regions.
48
www.acti.com
Firmware User’s Manual V9.02.27
There are up to 10 independently configurable motion detection regions. Each motion detection
region has 5 configuration parameters:
Enabled or disabled
Size and shape of the region
Minimum size of the object to be detected
Location of the region
Trigger threshold
Trigger interval
Enabled or disabled
Each region can be enabled and disabled individually. By default, Region 1
is enabled while the other regions are disabled. Only the enabled region
appears on the video display.
Note that the number of the motion detection region is written within of the
region.
The motion detection area of Region 10 is automatically set as the whole area outside any of the
motion detection regions of 1 to 9.
Size and shape of the region
The size and shape of the motion detection region can be any shape defined by the users.
Regions may even be overlapping.
To configure a region, click once on a point where you want to set the region and continue to click
to draw the desired region.
For example, to configure Region 2, click “Setup” and “Enabled” of Region 2.
49
www.acti.com
Firmware User’s Manual V9.02.27
Click a starting point of the motion detection region on the screen. The yellow dot indicates the
starting point of the region. Continue clicking on the screen to mark the desired shape of the
region.
After completing the marked region, the region number and the detection size box appear.
Region Number
Detection Size
Motion Detection Region
The detection size box indicates the minimum size of the object to be identified as an “object”.
This feature is useful to avoid false alarms. For example, if the detection size is set to be the size
of a human or vehicle, motion detection will not be triggered even when a cat passes the motion
detection area.
It is recommended to keep the detection size as small as possible while not causing false alarms
by moving objects that are not humans or vehicles.
To resize the detection size, click on the box and drag its corners.
50
www.acti.com
Firmware User’s Manual V9.02.27
Alternatively, to resize or reshape the motion detection area, click on the motion detection area
and drag the corner points until the desired size or shape is achieved.
Location of the region
To move the location of the region, click on the motion detection region. With the corner points
showing, click the mouse within the region and drag the region to a desired location. The motion
detection regions may be overlapping.
Trigger threshold
Look at the moving object entering the area of motion detection: although moving quite slowly, it
caused motion activity – several pixel regions reported a motion that was faster than allowed
“speed limit” of sensitivity (70).
A 10% trigger threshold means, 10% of this motion detection area were filled with moving pixels
at that moment. By visual observation you can also see that the object standing inside the motion
detection region indeed covers about 10% of its size.
What if the object is really small but moves rather fast (gets triggered by the current sensitivity
level)? For example, we want to detect people but not the cat walking in the room. Although both
people and cat may move with the speed that will trigger motion, they have different size of
triggered pixels. For example, a human passing by the motion detection region will trigger 25% of
pixels in that region while the cat would trigger only 2%. Since we want to have a real alarm in
51
www.acti.com
Firmware User’s Manual V9.02.27
case of human or vehicle passing by while ignoring birds, cats, butterflies, mice, etc, we need a
filter that can define how many percent of triggered pixels will be considered as a real alarm. This
parameter is called trigger threshold. The default value of trigger threshold is 10%. It means,
only the objects that are bigger than 10% of the motion detection region size and move faster
than allowed by sensitivity level (70) will produce actual alarm.
How to choose the most optimal trigger threshold level? The rule of thumb, keep the trigger
threshold as small as possible while not causing false alarms by the moving objects that
are not humans or vehicles.
You can have different sensitivity level and trigger threshold level for each motion detection
region.
In order to understand all of the above even better, please refer to the table below containing four
possible combinations of settings using sensitivity level and trigger threshold percentage.
The objects listed in each cell will trigger an alarm under given settings:
Low threshold (0-5%)
Low sensitivity
(0-65)
Big and fast
High threshold (5-100%)
Big and fast
Small and fast
Big and fast
High sensitivity
(65-100)
Big and fast
Big and slow
Small and fast
Big and slow
Small and slow
The camera’s default sensitivity is 70 and threshold is 10%. By these default values, only
the rabbit and the turtle would trigger an alarm while the butterfly and the snail would be
ignored by the motion detection system.
52
www.acti.com
Firmware User’s Manual V9.02.27
Important: Please remember that changing the size of the motion detection region has an impact
on the threshold – the bigger is the size of the motion detection region the smaller should be the
threshold value if you want the same object size to trigger motion. For example, if you increase
the motion detection region to twice the previous size, please remember to reduce the threshold
to half its original value (from 10% to 5%). On the other hand, changing the location of the motion
detection region has no impact on threshold.
Trigger interval
Trigger interval is the time period from the beginning of the triggered event during which all
motion activities are ignored by the camera. This is designed to avoid needless repetitive
reporting of the same intrusion. Trigger interval 20 seconds would mean that when the even
happens, camera will take certain one-time actions and ignore the continuing activity in the
motion detection region for 20 seconds. When 20 seconds are over, the camera will produce a
new alarm if there are still action in the motion detection region, and take actions again.
There is one more item on the Motion Detection
configuration page which was not explained above –
the Profile of Motion Detection. Think of them as
Profile 1 (Runtime MD Profile) and Profile 2 (Event
MD Profile). It means that you can configure two independent groups of Motion Detection regions
with at most 10 regions in each group. Normally, the Profile 1 (Runtime MD Profile) is used as an
active profile of the camera. However, in some cases it is possible to let the camera switch to
Profile 2 by using the Event Handler system of the camera.
For example, you might want to have different motion detection parameters for day and night time.
Then the two profiles become really handy. In such case, remember to configure the motion
detection parameters for both profiles before moving on to configure the event response system.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
NOTE: For PTZ / Speed dome cameras, it is recommended to turn off motion detection when
scan and tour modes are enabled to avoid false motion alarm.
53
www.acti.com
Firmware User’s Manual V9.02.27
Object Counting
NOTE: Object Counting analytics is only available on dedicated People Counting Camera
models.
People Counting cameras count the number of objects, such as people, passing through a virtual
line on the video image. This feature is useful for retail businesses to survey and count the
number of people entering or leaving the store.
To use the Object Counting feature, the parameters on the Reporting Server, Location and
Object Counting pages must be configured.
The pages are used to configure the following:

Reporting Server: Defines where the counting data is saved. See Where to Save the
Counting Data? on page 55.

Location: Defines the exact location where the camera is installed. The information on
this page will be used to identify the camera and will appear on the Reporting Server
application. See How to Create the Camera Identity? on page 55.

Object Counting: Defines the virtual line for object counting and the schedule to send
reports. See How to Configure Object Counting? on page 56.
54
www.acti.com
Firmware User’s Manual V9.02.27
Where to Save the Counting Data?
The counting data or metadata, can be saved to a remote server which can be a PC; in Web
Configurator this is referred to as the reporting server. The metadata can then be pushed to the
“Reporting Server Application” or the “Market Application Suite (MAS)”.
To use the “Reporting Server Application”, download the pplication from www.acti.com and save it
on a computer.
To use the “MAS Server”, contact sales for details.
Check Server 1 or Server 2 to enable and configure the servers. Enter the computer “Network
Address”, “Network Port”, and “Account” and “Password” which will used to login to the
Reporting Server.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that have just been made but not applied yet.
How to Create the Camera Identity?
To easily identify the camera on the reporting server application, enter the camera details on the
Location page.
Details can be freely written based on the user needs and application. Since the retail
55
www.acti.com
Firmware User’s Manual V9.02.27
applications vary, two additional categories with Name and Setting parameters are provided for
flexibility; common application for this is to provide more detailed location information on the
report.
How to Configure Object Counting?
NOTE: The camera must be installed on the ceiling to accurately detect and count the moving
objects.
On the Object Counting page, a line appears on the upper left corner and a purple box on the
lower left corner for first-time configuration.
To configure or modify an existing configuration, click on “Setup” to adjust the line and define its
parameters. Click “Enabled” to enable Object Counting.
56
www.acti.com
Firmware User’s Manual V9.02.27
Size and Location of the Line
The size and location of the line can be any defined by the users. Click on the line and drag to the
location where you want to position it. To resize the line, click on the line drag its corners. The
crosshair indicates the cursor position.
Detection Size of Object
The purple box on the lower left corner indicates the detection size of the object. Any object which
is smaller than this box will not be counted. This feature is useful to avoid false alarms. For
example, if the detection size is set to be the size of a human, detection will not be triggered even
when a cat passes the line.
It is recommended to keep the detection size as small as possible while not causing false alarms.
Reverse Direction
The camera counts the objects that go in or out of the line. The line has “in” and “out” indicators,
“in” for inbound and “out” for outbound counting. The numbers that appear next to these
indicators are the counted values. Check “Reverse Direction” to reverse the in or out direction.
Counting Schedule
The camera can be set to count only on
specific time and days of the week. Check
the day(s) when to activate counting and set
the starting and ending time.
57
www.acti.com
Firmware User’s Manual V9.02.27
Send Counting Data to IVS Server
The camera can send the counting data to a Reporting Server (see Where to Save the
Counting Data? on page 55 on how to configure the Reporting Server). From the “Update live
counting data to IVS servers”, select how often will the data be sent to the reporting server; to
send data as soon as the counter is changed, select “Real-time”.
Regardless of the selected option, a Daily Counting Report will be sent every day to the
Reporting Server software application based on the time set on the Reporting Server (please
refer to the Reporting Server User’s Manual for more information about the configurations).
Below is an example of a live counting data on the Reporting Server, boxed with a dotted line.
Reporting Server
Up to two reporting servers can be configured for one camera.
The counting data can be sent to Server 1 or Server 2 or
select “all” to send to both servers as configured on the
Reporting Server page (see Where to Save the Counting Data? on page 55).
58
www.acti.com
Firmware User’s Manual V9.02.27
Heatmap and Dwell Time
NOTE: Heatmap and Dwell Time analytics are only available on dedicated Heatmap Camera
models.
The Heatmap function allows users to visually see the path within a predefined region where
people usually pass through. On the other hand, the Dwell Time function allows users to visually
see where people usually stay or dwell for a prolonged period of time. These features are useful
for retail businesses to survey and determine the area or the products that interest the public.
The images below show the results of Heatmap and Dwell Time as shown on the Market
Application Suite (MAS) Server.
59
www.acti.com
Firmware User’s Manual V9.02.27
How to Configure Heatmap or Dwell Time?
NOTE: The camera must be installed on the ceiling to accurately detect people.
On the Heatmap or Dwell Time page, click the Setup button. Click on the area on the live view to
draw a polygon to be the target Region of Interest (ROI), a yellow dot appears as the starting
point.
Then, define its parameters. Click “Enabled” to enable the function.
Background Image
Click Setup to capture the snapshot which will be used as background image of the heatmap or
dwell time report. The snapshot will be saved to the flash memory of the camera.
Click Get to view the snapshot.
Schedule
The camera can be set to activate the
function only on specific time and days of the
week. Check the day(s) when to activate
heatmap or dwell time and set the starting
and ending time.
Reporting Server
Up to two reporting servers can be configured for one camera. A reporting server can be a server
in a PC to save the data and another can be set to be the Market Application Suite (MAS) Server
(contact sales for details and configuration about MAS Servers).
60
www.acti.com
Firmware User’s Manual V9.02.27
The counting data can be sent to Server 1 or Server 2 or
select “all” to send to both servers as configured on the
Reporting Server page.
Check Server 1 or Server 2 to enable and configure the servers. Enter the computer “Network
Address”, “Network Port”, and “Account” and “Password” which will used to login to the
Reporting Server.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that have just been made but not applied yet.
How to Create the Camera Identity?
To easily identify the camera on the reporting server application, enter the camera details on the
Location page.
Details can be freely written based on the user needs and application. Since the retail
applications vary, two additional categories with Name and Setting parameters are provided for
flexibility; common application for this is to provide more detailed location information on the
report.
61
www.acti.com
Firmware User’s Manual V9.02.27
Compression
The Compression section allows the user to define the compression settings of the video
streams individually. The purpose of compression is to reduce the bandwidth and VMS storage
consumption.
Usually the stream 1 is configured to be the best quality stream for NVR recording purposes while
the stream 2 and 3 are configured to be with the basic quality for the live view of NVR or mobile
device, to minimize the computing power of NVR used for video decoding.
Parameters
Encoder Type
Stream Mode
Description
There are two encoder types available: H.264 (High Profile) and
MJPEG.
This item defines how the video is streamed. The options available
vary depending on the selected Video Application Mode (see
Camera Options on page 42). Stream 3 usually follows the stream
mode setting of Stream 1. Possible options are:
 Panorama View: Edges of image is dewarped to display flat
image on screen.
 Fisheye View: Image looks as if the scene is viewed from a
fish’s eye.
 ePTZ: This stream allows you to do digital pan-tilt-zoom or
change the viewing direction of the target view. This option is
only available on Stream 2 and 3 and if Video Application
62
www.acti.com
Firmware User’s Manual V9.02.27
H.264 Profile
Resolution
Frame Rate
Video Bit Rate Mode
(only for H.264)
Mode is set to ePTZ.
 MultiView Mode: If the Video Application Mode is set to
MultiView, the Stream Mode setting will automatically be set
to MultiView Mode as well.
NOTE: Not available in all models.
This item is available only if the Encoder Type is H.264.
The H.264 Profile defines the video compression scheme: High
Profile, Main Profile, and Baseline. These schemes vary from least
compressed, Baseline, to most compressed, High Profile. By
default, the H.264 Profile is High Profile, which provides the most
compression with the best video quality, but more computing power.
Some third-party video management system has longer latency or
takes more time to decode High Profile compression scheme, in this
case, you can select Main Profile or Baseline. In order to get the
same video quality, you can select a higher bit rate with lower
compression; this is the same as having a lower bit rate with a High
Profile. For example, a video on High Profile with 2M bit rate will have
the same video quality as a video with Baseline Profile at 3.5M bit
rate.
Depending on the camera model, the number of available resolutions
may be different. The default resolution setting of the camera may not
necessarily be the maximum resolution of the camera. If the user
wants to use the maximum resolution, it is possible to do it here. The
maximum possible resolution of the stream 2 will be smaller than
stream 1 and so on.
Defines the amount of frames per second.
Under “Constant Bit Rate” mode (CBR), the camera keeps the stable
bitrate regardless of the complexity of the scene. Under this mode,
the video quality may vary if the bit rate value is set too low. It is easier
to do storage and network bandwidth consumption estimations under
this mode compared to Variable Bit Rate mode.
Under “Variable Bit Rate” mode (VBR), the camera will keep the video
quality stable while the bit rate may occasionally go up or down,
depending on the complexity of the scene.
Defines the upper limit of the bitrate (only available under CBR
mode). The bitrate will be floating slightly under that limit. For
example, if the limit is set as 2M, the bitrate will be floating around
1.6~2.0 Mbps.
Video Max Bit Rate
(only for H.264)
If the Video Max Bit Rate is chosen as
“Unlimited”, then the “Video Bit Rate”
selection box will appear that defines
the bit rate level.
63
www.acti.com
Firmware User’s Manual V9.02.27
Video Bit Rate
(only for H.264)
Under CBR mode, when Video Max Bit Rate is chosen “Unlimited”,
the user can define the AVERAGE bit rate. For example, if the Video
Bit Rate is chosen 2M, then occasionally, the actual bit rate may go
below or beyond 2M, but in the long run, the average bit rate will be
very close to 2M. This mode allows the most accurate storage
estimations, however, while planning the bandwidth, please consider
the occasional peaks of bit rate.
H.264 Compression:
Quality
Under VBR mode, the bit rate will be
floating while the video quality will
be stable and follows the quality
standard set by the user. The user
can choose either “High”, “Medium” or “Low” quality. The higher is the
quality level, the more bit rate the camera will use to achieve the
target quality.
MJPEG Compression:
The user can define the quality with the numeric scale from 1 to 100.
The default MJPEG quality is 60. The higher is the quality level, the
more bit rate the camera will use to achieve the target quality.
GOP 1 I-frame
(only for H.264)
Under VBR mode it is possible to adjust the GOP length - that is the
occurrence rate of I-frames. By default, there is one I-frame per
second. For example, in case of 30fps, there will be 1 I-frame and 29
P-frames every second by default. When the GOP is changed to “1
I-frame per 5 seconds”, then there will be one I-frame, followed by 149
P-frames. In case of the static scenes, long GOP can further minimize
the bandwidth and storage consumption.
After changing any of the items above, scroll down the screen and press Apply to save the
changes. The Reset button undoes the changes that had just been made but not Applied yet.
64
www.acti.com
Firmware User’s Manual V9.02.27
Video
The section is also named Video. The Video section is divided into
tabs. The functionality of each tab is explained separately below.
Upon opening the section named Video, the live view of the Stream 1 of the camera will appear.
Usually, Stream-1 is configured to be high quality video with maximum resolution and frame rate
for recording purposes while Stream-2 is usually a moderate quality stream for live view purposes
of the VMS, to reduce VMS computing power during video decoding of multiple channels.
65
www.acti.com
Firmware User’s Manual V9.02.27
Day/Night
The section Day/Night allows user to control the switching between day mode and
night mode. This section will be displayed only for day/night models.
Parameters
Day/Night mode
IR LED Control
Description
There are three modes:
Auto: The camera will automatically switch between day mode (color)
and night mode (black/white) under certain exposure level, defined by
user at “Switch from Day mode to Night mode”.
Day: The camera always stays in day mode (color) regardless of
exposure level.
Night: The camera always stays in night mode (black/white)
regardless of exposure level.
This feature is visible only in cameras with built-in IR LED.
There are two modes:
Auto: The built-in IR LED will be turned on automatically upon day to
night switch and turned off upon night to day switch.
Disabled: The IR LED will be off regardless of day and night mode.
Zoom cameras have adaptive IR profile, which means that when IR
LED Control is set to “Auto” (default setting), the IR LED
automatically adapts to the required IR LED power as the camera is
zoomed in or out.
IR LED Strength Level
This feature is visible only in fixed and vari-focal lens cameras with
adaptive IR profile and when IR LED Control is set to “Auto”.
The scale of 1~10 allows the user to manually define the power level
of the IR LED. The higher the value, the brighter the IR LED is. Set
the IR LED Strength Level according to the installation environment
requirement, or set it to “OFF” to turn off the IR LED.
Switch from Day mode
to Night mode
The scale of 0~100 allows user define the exposure level at which the
day to night switch should happen. The higher is the value, the darker
the environment has to be to trigger the day to night switch.
66
www.acti.com
Firmware User’s Manual V9.02.27
The section Image allows user to control certain parameters of a video frame.
Parameters
Brightness
Contrast
Saturation
Digital Noise
Reduction
3D Noise Reduction
Edge Enhancement
WDR
Description
Select the Brightness value (0~100). The higher the value, the
brighter the image.
Select the Contrast value (0~100). The higher the value, the
difference between light and dark areas becomes more prominent.
Dark color becomes darker while light color becomes brighter.
Select the Saturation value (0~100). Saturation makes colors appear
more vivid.
Select the Digital Noise Reduction option (OFF, 1~4). Digital noise
reduction value reduces noise on the video (especially in low light)
which makes the image look smoother and clearer.
Enable this feature for smooth and clear image. Disable this feature if
the scene contains extreme details that may be smoothed over with
3DNR.
Select the Edge Enhancement value. The higher the value, the
sharper the image.
Choose the WDR level from following options: Disabled, low, medium,
high, highest.
NOTE: WDR is disabled and will not appear on screen if Exposure
Mode is set to “Manual”. See Exposure / White Balance on page 68.
This feature provides a clear image even when the camera is installed
Defogging
in a foggy environment. Select the Defogging level: Disabled, Low,
Medium, High, and Highest. Wherein “Low” is ideal for a slightly foggy
environment and “Highest” for the foggiest environment.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not applied yet. The button “Restore image
settings to default” is a quick way of restoring factory default image settings without needing to
reset the whole camera to factory default.
67
www.acti.com
Firmware User’s Manual V9.02.27
Exposure / White Balance
The section Exposure / White Balance allows the user to configure
Exposure (shutter, iris and gain control) and White Balance settings. In most cases, the default
settings are sufficient and no adjustment is needed. Some options will only appear under certain
Exposure / White balance modes. Each mode is described in detail below.
Exposure Mode - Auto
In Auto Exposure Mode, you control the image brightness by configuring the AE Reference
Target and Slowest Auto Shutter.
Exposure Mode - Manual
When the lighting conditions are stable 24 hours a day, the advanced users may consider using
manual exposure mode, to further fine tune the image quality in order to fulfill the special project
requirements. Please note that in most cases, it is highly recommended to keep the camera in
Auto Exposure mode and let the intelligent system of the camera find the best possible exposure
settings instead.
In manual exposure mode, the user can directly manually adjust the signal Exposure Gain,
Shutter Speed, and even on select models, the IRIS Control (I-series zoom cameras only).
NOTE: Day/Night mode and WDR function are disabled in manual exposure mode (see Video
on page 65).
White balance refers to the capability of the camera to understand what “true white color is”.
When the camera knows the true white color, then the rest of the colors will be accurate, too.
While human eye can easily adapt to different lighting sources (even mixed sources, such as sun
light through the window and indoor lights turned on at the same time), the camera has to
68
www.acti.com
Firmware User’s Manual V9.02.27
understand what is the dominant light source in given scene and what is the “white color” of such
light source.
By default the camera is in auto white balance mode and attempts to recognize the light source
and its color spectrum automatically and adjusts the image accordingly. This function works
continuously in the background. It is re-evaluated for each frame, to make sure if there is any
change in dominant light source (e.g. the user closes the curtains to block the sun light and turns
on the indoor lights).
In most cases the auto white balance works perfectly and the user does not have to adjust
anything! In some rare installation cases, especially when there are no white color objects in the
field of view, and the light sources are mixed, the camera may have difficulty to identify the true
white color to fine tune the rest of the colors.
In such cases, the installer can “help” the camera to understand the true colors by placing a white
object (for example a piece of white paper) in front of the camera to cover the whole field of view
and wait a few seconds – the auto white balance system will adjust the colors until the white
paper will really look white on the display. At that moment, the user can freeze these white
balance settings by pressing the Hold button. After pressing that button, the White Balance will
switch from Auto mode to Manual mode, together with the color values captured at the moment of
Hold. The user can now remove the white object from the field of view, and the colors will stay
correct for given scene.
For advanced users, there is also an option to switch from Auto mode to Manual mode of White
Balance directly and input the R Gain and B Gain values manually.
The camera will automatically control shutter speed, auto iris (if available) and signal gain to
achieve the target level set by the user. If the auto iris does not exist or is already opened to a
maximum size, and the image is still darker than the user defined target, it will further slow down
the shutter speed within the allowed range (set by user under Slowest Auto Shutter Speed) and
increase the signal gain.
69
www.acti.com
Firmware User’s Manual V9.02.27
AE Reference Target (Auto Exposure reference target) can be considered as the “Target
Brightness on Sensor”. The camera will use several internal parameters to achieve best quality
with reference to this. The higher this value, the brighter the overall scene, however, there
may be more noise at night in such case. The range of AE Reference Target is 1~255.
Slowest Auto Shutter Speed is the user defined threshold for slowest allowed speed of auto
shutter. For example, if by default the shutter speed would vary between 1/5s ~ 1/2000s
depending on the lighting conditions, then setting the Slowest Auto Shutter Speed to 1/30s would
narrow down the auto shutter range to work between 1/30s ~ 1/2000s. The purpose of allowing
user to define the threshold for slowest speed is to avoid motion blur caused by too slow shutter
at night.
It is also important to know that very high shutter speed is not recommended for indoor solutions
with artificial light that flashes with certain frequency, as it may produce flickering effect,
regardless of Exposure mode.
In extreme low light conditions, the shutter speed is slown down to get more light into one image,
but not slower than the user defined threshold.
If the exposure time extends beyond the interval between frames (too slow shutter), (i.e. 1/30
second), then the frame rate will be automatically reduced. Longer time in this value gives
clearer images at night for slow moving objects, but more motion blur for fast moving
objects.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
70
www.acti.com
Firmware User’s Manual V9.02.27
OSD
The section OSD (or OSD / Privacy Mask as shown in some cameras) allows users to
add text to the upper or lower left corner of the video. This function is called Text Overlay
or On-Screen Display (OSD). It is possible to display the camera name, date and time, IP
address or any custom text as Text Overlay. The text is kept as small as possible and is not
resizable. The text can be read normally when the video is enlarged on the display to 1:1 ratio.
The purpose of having the text so small is to provide sufficient legal evidence while blocking the
smallest possible area of the video to avoid valuable video evidence being blocked by text
overlay. The text will be embedded into video and cannot be removed later upon playback or
export.
It is possible to define up to 3 regions of text. If more than 1 region of text is enabled and
positioned in the same location, then the texts will appear one below another, row by row.
In the example above, one region of text was enabled with blue color and 50% transparency,
located on the lower left corner and containing the text of “Office View“ together with current date.
The date would automatically change every day, according to the camera date and time settings.
The result of the example configuration would look like this (Live View page, 1:1 scale):
71
www.acti.com
Firmware User’s Manual V9.02.27
Below is the list of characters with special meaning that can be used in the text field:
Parameters
%YYYY
%YY
%MM
%DD
%hh
%mm
%ss
%H
%C
%X
%N
Description
Year in four-digit format. For example, 2008
Year in two-digit format. For example, 08
Month in two-digit format. For example, 01 for January, 12 for December
Date in two-digit format. 01~31
Hour in two-digit format. 00~23. Note that only 24-hour indication is
supported.
Minutes in two-digit format. 00~59
Seconds in two-digit format. 00~59
a hyphen, "-"
a colon, ":"
a slash, "/"
show Camera Name (It might be truncated if exceeds max OSD length)
The OSD configured on Stream 1 can be enabled or disabled separately for the other streams.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet. The result of the example
configuration would look like this (Live View page, 1:1 scale):
72
www.acti.com
Firmware User’s Manual V9.02.27
Privacy Mask
Privacy Mask allows users to cover up some sensitive areas of the video that
should not be captured by the camera, such as manager’s computer screen or bathroom
entrance. It is possible to configure several independent regions for masking. Microsoft Internet
Explorer browser is required to configure the Privacy Mask. The privacy masks will be
embedded into video and cannot be removed later upon playback or export.
To use Privacy Mask on hemispheric cameras, the following configurations must be set first:
Video & Audio Menu
Camera Options
Compression (Stream 1)
Submenu
Setting
Video Application Mode
Preview
Encoder Type
H.264
Stream Mode
Fisheye
Resolution
Maximum Resolution
(varies per camera model)
Up to 8 regions of privacy masks can be set up. The privacy mask is applied to all three (3) video
streams.
73
www.acti.com
Firmware User’s Manual V9.02.27
To create a privacy mask, do the following:
1. Select a target Region number, then check Setup.
2. A box appears on the screen. Use the upper bar to drag the region you want to cover with the
mask. The region may be resized by dragging the white box on the lower right corner.
3. Check Enabled.
4. Click Apply to save and apply the changes. The marked area is has a black mask covering
the view.
5. Repeat the above procedures to create more masks.
74
www.acti.com
Firmware User’s Manual V9.02.27
Audio
The section Audio is available only for audio-supported models. The
user interface for audio control looks like as below:
Parameters
Audio In
Audio In Level
Audio Out Volume
Audio Format
Description
The option “Enabled” would activate incoming audio (either line in or
built-in microphone). The option “Disabled” would turn off the incoming
audio. In such case, the video stream is captured without audio.
For vehicle-support models, use this function to adjust the sensitivity
level of audio input.
The audio out volume level can be adjusted in the scale of 0-100. It will
influence the volume level of the speakers connected to the camera.
Choose the compression format of audio: PCM, G.711A (A-law) or
G.711U (µ-law).
To adjust the volume level of the speakers connected to the PC that runs the Web Configurator in
order to hear the audio from the camera’s microphone or line-in device, go to Live View page and
use the audio controls there:
Audio Muted:
Audio level adjusted to the maximum:
This volume control appears in user interface only when the Audio-in function of the camera has
been “Enabled”.
75
www.acti.com
Firmware User’s Manual V9.02.27
Audio File
This function is available only in cameras that have audio out function. In this section, users can
upload a preferred audio file which can be played when an event is triggered (see Event List on
page 92 to configure the event).
Click Browse to find the preferred audio file and click Apply to save the changes.
Note that only the following audio format is supported:

WAV file

PCM, 16 bit, 8KHz sampling rate

Maximum file size is 256KB
NOTE: If you need to modify audio file to suit the above requirements, use an audio tool, such as
Audacity to convert the file. Refer to the tool documentation for instructions.
If no other file is uploaded, the camera will play the default audio which is saved in the camera
flash memory. If the uploaded audio file exceeds the required length, the upload will be
unsuccessful, and still the default audio file will be used.
A factory reset will remove the uploaded file from the camera but will still retain the default audio
file.
76
www.acti.com
Firmware User’s Manual V9.02.27
Event
This section describes how to setup the Event Handler, which deals with how the IP devices
respond to situations. Each IP device can have a maximum of 10 Event Rules. Each rule includes
one single trigger, and one or many responses. Several types of responses are available. And
there are multiple external servers for the device to interact with.
When setting up Event Handler, there are four types of settings. Event Server, Event
Configuration, Event Rules and Manual Event
Click the
item before Event to expand the list.
Event Server
Event servers define whom the device may interact with. They can be other servers or devices
on the network, or even the camera itself. Event Configuration sets up a list of what to tell the
other party during interaction. Event list lays down the rules and conditions about when to initiate
which responses from which triggers. The options available for Event rules are selected from
the event servers and event configurations.
Event servers are classified as FTP servers, SMTP servers and HTTP servers. Click an event
type button to display its screen.
NOTE: Please contact a sales representative for information regarding Notification Server
Configuration.
77
www.acti.com
Firmware User’s Manual V9.02.27
FTP Server
FTP servers can receive snapshot or video uploads that are issued as part of the response from
event handlers. You may setup one FTP server.
To setup FTP servers, make sure to enter the network address of FTP server, the Network (FTP)
port, the User Name and Password of FTP account, Connection mode (Passive or Active) and
Connection time before timeout.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
78
www.acti.com
Firmware User’s Manual V9.02.27
SMTP Server
SMTP servers can send email upon request from the IP device. The email can be a simple
subject and text email, or attached with snapshot / video. You may setup two SMTP servers. The
device will first attempt to send the message via the Primary email SMTP server. If the first
attempt fails (after the Max connecting time), the device will attempt to send via the secondary
SMTP server. If the device sends email successfully via the primary SMTP server, then it will not
use the secondary SMTP server.
To setup SMTP servers, make sure to enable the SMTP account. Select the SMTP Server from
the list of common SMTP servers on Network Address or choose “Others” to type the server
manually. Then, select the proper Authentication Type. There are many types available. The
default is Login. We recommend you to use Auto Detection. Available authentication types
include: Auto Detection, None, Login, Plain, Cram MD5, Digest MD5 and PoP Relay. Enter the
Network (SMTP server) Port number, User Name, Password, the email address displayed as
sender (can be different than the user name), and Max Connection time before timeout (in
seconds).
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
79
www.acti.com
Firmware User’s Manual V9.02.27
HTTP Server
HTTP CGI servers are programs that run on web sites or many devices. They can be custom
programmed to perform a large variety of actions based upon the input. You can define which
CGI server to connect to here, and the user / password required to log into the target server. The
actual message / command is setup in the Notification messages / URL commands section. You
may define two separate CGI servers.
IP devices are also CGI servers. This means that IP devices can now issue commands to each
other, which creates endless possibilities for highly coordinated response. The IP device can also
give a loopback command to itself, in effect changing almost all possible settings dynamically. For
detail on the commands used to control the cameras, please contact your customer
representative.
An example will help you gain a better sense of how to utilize this unique function. Camera A is a
fixed camera that looks at a corridor leading to the main hall. It has a motion detection window
located near the point where the corridor arrives at the large hall. Camera B is a PTZ camera
located in the hall, which is usually left on auto-tour patrol. When motion activity in the motion
detection region triggers MD1 in Camera A, this then in turn activates an event rule in Camera A
that gives out a command to Camera B. Camera B would then swivel to the preset point where
the corridor leads into the entrance and switch to higher bit rate to temporarily provide clearer
image. After the event ends, Camera B will go back to its normal routine in lower bit rate.
To setup HTTP servers, make sure to enable the HTTP server, enter the user name, the user
password, Network (HTTP Server) address, Network (HTTP Server) port number and Max
connection time before timeout (in seconds).
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
80
www.acti.com
Firmware User’s Manual V9.02.27
Notification Server Configuration
Notification Server Configuration is used to setup specialized mobile notification service (for a fee)
for project-based requirements. For more information, contact the “Customer Help Desk” or any
sales representative.
NVR Configuration
The NVR Configuration is used to setup the NVR. Enable the function, enter the user name, the
user password, Network (HTTP Server) address, Network (HTTP Server) port number and Max
connection time before timeout (in seconds). For registration details, contact the “Customer Help
Desk” or any sales representative to assist you.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
81
www.acti.com
Firmware User’s Manual V9.02.27
Event Configuration
Event configurations are the responses to be performed when an event is triggered. For most
types of responses, you can create several different preset responses, then mix and match in
event rules.
The configurable responses are classified as Digital I/O ports, Notification messages, Upload
Video/Snapshot and Audio and Send URL Commands.
NOTE: Digital I/O ports appear only for the camera models that support this function.
82
www.acti.com
Firmware User’s Manual V9.02.27
Digital I/O ports
Digital input/output ports (select models only) are used to connect digital input (DI) and digital
output (DO) devices. DI is a trigger device like a switch or sensor (e.g. “panic button”), which
when pressed or triggered, notifies the camera to perform specific actions or the DO device to
respond. DO’s can be alarms or lights, etc.
The Digital I/O Ports page displays the number of available DI and DO ports on the camera,
which varies depending on camera model.
DI: To configure the digital input device, define the active level and trigger interval of the DI. The
default Active Level is “0”, which means the DI device remains inactive unless triggered. A good
example is a “panic button”, which always stays in inactive mode “0” until the button is pressed;
when the button is pressed, its active level becomes “1” which means the DI is triggered. Active
level “1” returns back to “0” (inactive mode) after the specified Interval. The Interval is the
duration of time when the trigger remains in active mode which is also the minimum time interval
between the previous trigger and the next. For example, if the interval is set to “5 seconds”, the DI
will not respond if the “panic button” is pressed within 3 seconds after the previous trigger. To
issue another trigger, press the button after 5 seconds from the previous trigger.
DO: To configure the digital output device, define the active level and response interval. The
default Active Level is “1”, which means the DO will turn to active mode and respond once
triggered. The duration of its response will last according to the set Interval. A good example is
an alarm siren, wherein the siren will start sounding only when it is triggered by an event or
another device like a DI. The siren will stop sounding once the set interval time elapsed.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not yet applied or saved.
83
www.acti.com
Firmware User’s Manual V9.02.27
Sound Detection
Sound detection is available on cameras with Audio in capability and is shown on the user
interface only if the Audio In function is enabled in Audio setup menu (see Audio on page 75).
Sound detection is used to trigger the camera or another camera to perform specific actions or a
digital output device, such as alarms or lights, etc. to respond.
Check the Enabled box to enable Sound Detection.
The Trigger Interval refers to the time interval of the first detected sound to the next detected
sound. For example, if trigger interval is set at 5 (seconds), the next sound detection is triggered
only after 5 seconds. If the next sound is detected 3 seconds after the first sound, the trigger is
not activated.
To set the range or loudness of sound, set the Trigger Threshold. This helps define which sound
is considered loud enough to be a trigger. For example, the sound of blowing wind should not be
considered, while the sound of a door creaking is a cause for alarm. The red line on the Activity
graph shows the threshold set at 15%. The blue graph shows the sound activity. If the blue graph
exceeds the red line, sound is triggered.
How to choose the most optimal trigger threshold level? The rule of thumb, keep the trigger
threshold as small as possible while not causing false alarms.
After changing any of the items above, press Apply to save the changes.
84
www.acti.com
Firmware User’s Manual V9.02.27
Notification message
*Pre-requisites: SMTP server / HTTP CGI server setup.
*Pre-requisites: SMTP server / HTTP CGI server setup.
Notification messages may be sent to either an email or a HTTP CGI server. If sent to a CGI
server, it works the same as an URL command, but it does not allow a second message at end of
event. You may configure up to three preset massages. You can configure a message, but
disable it. This will allow you to keep the settings without using it, which will be useful in testing
and troubleshooting.
To setup Notification Messages, make sure to enable the message and then determine what type
of message to send (HTTP CGI or email).
If you are sending to CGI server, you need to enter the CGI path, the URL command itself, and an
optional message.
If you are sending email, please enter the recipient E-Mail address, the email subject, and the
body message.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
85
www.acti.com
Firmware User’s Manual V9.02.27
Upload Video/snapshot and Audio
*Pre-requisites: SMTP server / FTP server / HTTP CGI server setup.
IP devices may send video recording / snapshots to your chosen server upon event. Video will be
in .RAW format, while snapshots will be .JPG files. You can define up to three groups of settings
to upload video/snapshot. Snapshots can be sent to E-mail, FTP and HTTP CGI servers, while
videos can be uploaded to FTP, HTTP CGI servers, and local storage (for select models). If Audio
in is enabled in device, the uploaded video will include audio.
The parameters needed to setup this function are different for each task combination (snapshot /
ftp or video / HTTP… etc), and are explained below:
UI
Enable
Upload Media
Snapshot
Type
Upload Media to
Upload Period
Image during
Upload Period
Video
Email
FTP
CGI
Y
Y
Y
Y
Y
Y
Pre-Buffer Time
Image File Name
Y
Upload Path
FTP CGI Local
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
CGI Path &
Y
Program
E-Mail Recipients
Y
Subject
Y
Video Source
Y
Y
Y
Y
Y
Y
86
Y
www.acti.com
Firmware User’s Manual V9.02.27
Upload Video/snapshot and Audio checkbox: this decides if this rule is in effect, or disabled.
Sometimes it is useful to keep the settings for troubleshooting purposes, but keep them as
disabled.
Upload Media to: these define the task at hand, and change the field that needs to be filled out.
Upload Period: IP device will provide video/snapshots for the number of seconds here. It will
stop uploading video/snapshot at the end of this period. If you have video management software
recording from this camera at the same time, the normal recording through NVR will not be
affected, and goes on throughout the event period and afterwards. But the special upload session
will end as the event ends.
Image during Upload Period: This is used only by snapshots. This tells the camera how many
snapshots it should attempt to capture during the Upload Time. If this value is set to 0, then the IP
device will attempt to capture as many snapshots as possible. Depending upon the device
loading, the number of snapshots taken may not reach the number you specified.
Pre-Buffer Time: This is only used by video. If this is set to more than 0, then the IP device will
start to buffer video in its internal memory. The maximum pre buffer is 10 seconds. When an
event requires video upload, the IP device will first upload the video taken right before the event
then keep uploading until it reaches the upload time.
Image File Name/ Upload Path: You will need to specify rule for file names and upload paths
(upload path is not needed for Email. Just put a slash “/” in the field). The rules contain flexible
parameters. A sample rule and corresponding filename will look like this:
Front_Door_%YYYY_%MM_%[email protected]%hh%mm%ss
[email protected]
Upload Path folders may also be named dynamically. For the IP device to create folders on FTP
and HTTP CGI servers properly, your FTP/CGI account will need to have permission to create
folders. For syntax on auto naming, please see online help or the inset box at the end of this
section.
The symbol “%” cannot be the first character in filename or upload path. Please use either an
alphabet or a number as the starting character. For Upload Path, be sure to start and end eith a
backslash“\”. An example will be : \Backgate%MM%DD\
87
www.acti.com
Firmware User’s Manual V9.02.27
CGI path & Program: Some CGI servers may require special info and settings. Please refer to
CGI server designer for this section. IP devices do not allow upload of Snapshots / Video into
their embedded CGI servers.
E-Mail Recipient / Subject: When uploading video/ snapshots via email, these fields are
required.
Video Source: Choosing the video source from video 1 or video 2.
Auto Naming Rules for Files and Folders:
To properly track images and videos, a well thought out naming rule is necessary. There are a
number of automatic variables available to design a proper naming system, which may be used
both on files and folders.
Symbol
%YYYY
Description
Example
4 digits for year
2009 for year 2009
the last 2 digits of 4 digits year
09 for year 2009
%MM
two digits for month. 01~12
01 for January
%DD
two digits for date. 01~31
01 for the 1st day of a month
%hh
two digits for hour. 00~23
%mm
two digits for minute. 00~59
%ss
two digits for second. 00~59
%W
a space character. ' '
''
%N
camera name
camera-1
%YY
File serial counter. It starts from 1 in
%Y
every uploading task. The counter will
be increased by 1 for next uploading
1,2,3,4,5,...
file.
Example
1. Entrance-%YYYY-%MM-%[email protected]%hh%mm%ss for time 2009/06/05 22:50:30.
The full name is [email protected]
2. X_%w-%N_TEST%Y for camera name is 'my-camera' and three successive uploaded files.
The full names of these three files are
X_ -my-camera_TEST1, X_ -my-camera_TEST2, X_ -my-camera_TEST3
88
www.acti.com
Firmware User’s Manual V9.02.27
Send URL commands
*Pre-requisites: HTTP CGI server setup.
*Pre-requisites: SMTP server / HTTP CGI server setup.
URL commands can be sent to HTTP CGI servers upon event. This provides the possibility of
highly intelligent response upon event. IP devices and many other devices also have embedded
CGI servers that may be controlled.
When Event Handler sends an URL command, it will send one set of command when the event is
trigged, and another as the event becomes inactive. Depending on the CGI design, the URL
commands may be able to be stringed together, and multiple commands may be issued in a
single line.
An example would be when the access control device at the entrance detects an entry, this
device provides a DI signal to the PTZ camera, and triggers an event. This event then sends a
loopback command to the PTZ Camera itself (by setting its own IP as the HTTP CGI server). The
PTZ Camera then moves to a preset location, stays until the event is over, and then moves back
to another location. At the same time it moves to the pre-set location, it increases the bitrate from
1M to 3M, and the frame rate from 4 fps to 8 fps. The bitrate / fps changes are reverted at the end
of event.
89
www.acti.com
Firmware User’s Manual V9.02.27
RFID Card Configuration
RFID Cards can be managed in the Web Configurator. A Black List and a White List page list the
authorized and unauthorized RFID cards. Type the RFID information such as the User Name
(employee name) and Serial Number of the RFID in the corresponding list, Black List for
unauthorized and White List for authorize. Click the Enabled box to apply black and white list
filter.
At the time of writing this document, up to 300 RFID cards each can be listed on Black List and
White List page.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
Maintenance
The Maintenance page allows users to remove, export, or upload batches of RFID cards to Black
List or White List.
Remove: Removes the selected card list.
Export: A window pops out to show the list of cards from the Black List or White List.
90
www.acti.com
Firmware User’s Manual V9.02.27
Upload: Click the button and select the file to upload the card list to either the Black List or White
List.
Press the Test button to test an RFID card.
LED Configuration
Up to 10 LED Profiles can be configured on the camera. These LED profiles can be used to
respond to a particular event. For example, a valid RFID card was read, this can trigger the LED
to light as a certain color at specific length of time.
Name: Predefined names have been assigned to each profile. Users can change the name to be
more meaningful.
Repeats: To define how many times the LED profile will display when triggered.
Color / Dwell Time: Select the color and the duration to light up the LED. Up to 3 LED colors can
be configured in one profile. For example, when an RFID card is detected, the LED lights up red
for 1 second, then changes to blue for another second and then goes to green.
Click Test to test the configuration.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
91
www.acti.com
Firmware User’s Manual V9.02.27
Event List
You may define a maximum of 10 Event rules, which will be shown in abbreviated form in the
Event List panel. It will display under each Event ID, the days of the week it will be active, the
start time and duration of the active period, the type of the source of trigger, and the actions used
in the response. If the row is grayed out, this means the rule is currently not enabled and stays
inactive.
You may start creating a new event by clicking the event ID number in the list, for example “2”.
There are several parts to the Event rule:
When is it active?
You may choose to enable the rule or not. The settings will be kept in internal memory even if the
event rule is disabled. Select the days in a weekly cycle in which this rule and schedule is active.
Determine the start time and duration of the active period. For example, a rule that lets motion
detection trigger snapshot uploads to FTP would only take place after 19:00 each day for 12
hours. Outside of this time the rule will not be active.
In the example below, the event handler rule is active 24 hours a day, 7 days a week.
92
www.acti.com
Firmware User’s Manual V9.02.27
How is it triggered?
Events may be triggered by one of the several sources.
Scheduler: You can trigger an event based on the set schedule. For example, in the example
below, the schedule is set for an alarm to sound at 4:00, and will sound once every 5 minutes
within the next 10 minutes.
DIs: For selected models only, the IP device may be triggered by Digital Input. Select the digital
input and make sure to configure it on the Event Configuration page
Motion: You may trigger the event if one or many Motion Detection regions encounter a motion
trigger. Trigger from any of them will initiate the event. The duration of event will be the same as
the MD trigger length, or the Trigger interval time, defined in the Motion Detection section on
Video Adjust page. In the example below, Motion Detection region 1 is used as the event trigger.
You may also ask the event to be repeatedly triggered during this scheduled time. The interval is
determined in minutes. You may use this with email / FTP upload to take snapshots at regular
intervals.
Sound Detection: The event may be triggered when sound is detected. This feature is available
on cameras with Audio in capabilities only. The Sound Detection must be configured first to use
this feature.
Switch to Night mode: This is available to selected models only. When camera changes
between day and night modes, the embedded event handler will notice this change, and may act
upon this information.
Potential uses include changing the motion detection profile to another set of Event MD
parameters. By having two sets of parameters each optimized for day and night, this provide
better overall accuracy in both day and night conditions. Some night time only MD regions may
also be activated this way. The event period will end when the camera returns to day mode,
which will then reset the camera to the original settings.
93
www.acti.com
Firmware User’s Manual V9.02.27
Device boots successfully: This will trigger the event responses once the device boots up. You
can use this to create a notification system that keeps record of when the device has been
rebooted via email.
Reboot device: This triggers the event response when the device is shut down via web UI “Save
and Reboot”. Use this to keep record of when was the device setting edited. Note that this will not
take effect when the device is unplugged, as this is not normal shutdown.
Fail to write storage (with storage card only): Trigger occurs when there is an error in writing
data to the memory card.
Remove storage media (with storage card only): Trigger occurs when the memory card is
suddenly removed from the device.
Tamper: The event is triggered when the camera is tampered with. For example, the camera is
sprayed with paint, etc.
RFID Card Detection: The event is triggered when any of the following is checked:

Detect RFID card: When an RFID card is detected.

Hit RFID black list: When a card under the Black List is detected.

Hit RFID white list: When a card under the White List is detected.
To use this feature, the RFID card must be configured first. See RFID Card Configuration on
page 90.
What responses will occur?
Available responses vary depending on what triggered the event.
Digital Output (selected models only): This is a useful link to other devices. Click to include this
in the response for this rule.
Send notification Message: Select from the three pre-defined messages which you’ve setup in
the Event Configuration section. You may enable multiple messages at the same time. For
sending Email, please limit the recipient to one per event rule. If you need to send email to more
than one recipient, please use separate event rules triggered by the same trigger.
94
www.acti.com
Firmware User’s Manual V9.02.27
Upload video/snapshots: Select which of the event configurations to include in this response
set. If you are sending email via upload video and sending notification message at the same time,
the system will automatically merge the two emails into one. The subject and image will be based
upon the Upload snapshot Event configuration enabled, but the message in the body text will be
based upon the Notification messages.
In general, please stick to the “one email per event rule” limit for best performance.
Change Motion Detection Profile: This will switch the profile of the selected Motion Detection
region from Runtime profile to Event profile. The profile will return to runtime settings at the end of
this event. You may program one motion detection region to be disabled at runtime, but enable it
with event handler under some circumstances.
Send URL command: Select the URL command to include in the response set. Two different
commands will be sent at the time when the event is triggered and un-triggered. For example,
going to a preset point, if the device is a PTZ camera, and there are preset points already
configured in PTZ setup page, then you may include this in the response section of the event rule
by using Send URL Command method. It is possible to let the camera return to another preset
point at the end of the event.
Change Day / Night Mode (selected models only): For some models, you may force the Camera
into Day or Night mode. The camera will return to its previous setting (whether auto or forced day/
night) upon the end of the event.
Send Message to the Notification Server: This function works only if Notification Server has
been activated (see Notification Server Configuration on page 81).
Send Message to the NVR: This function works only if an NVR has been configured in NVR
Configuration (on page 81). When an event is triggered, a notification will be sent to the NVR.
Play the audio file: This function plays the audio file configured in
Audio File (on poage 76)
when the event is triggered. Define the duration of audio file playback.
LED Indicator Profiles: This function is available only on Q950 cameras. When an event is
triggered, the LED on the camera will lit up according to the LED profile selected. See LED
Configuration on page 91.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
95
www.acti.com
Firmware User’s Manual V9.02.27
Manual Event
You may select one event in the Manual Event area below the event list to be triggered via web
user interface.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
Once selected, the trigger button on the video display screen will show as clickable. Click to
trigger the selected event. This is useful during event rule testing.
The live view panel would look like this:
96
www.acti.com
Firmware User’s Manual V9.02.27
System
The section System provides the list of functions that help manage the
camera. The [+] mark before System indicates that the list can be expanded by clicking on it.
Once expanded, the list can later be collapsed again by clicking on the [-] mark.
User Account
The section User Accounts allows doing following user management
tasks:
1. Change the account name or password of the Root account that has a full access to the
camera.
2. Create up to 10 common users that only have an access for live view and PTZ control.
3. Enable/disable the option of seeing the live view without needing user name and password
(anonymous login), which is especially convenient function for camera installers on the field.
For security reasons, account name and password is always required when entering Setup
page of Web Configurator or when trying to access camera or change settings by URL
commands.
After changing any of the items above, press Apply to save the changes. The Reset button
undoes the changes that had just been made but not Applied yet.
97
www.acti.com
Firmware User’s Manual V9.02.27
System Info
The section System Info provides the full information about camera
status, settings and log. This information is very helpful while doing the camera configuration,
maintenance or troubleshooting.
The Server Report is a convenient way of exporting the full list of camera related information in a
text format, so that it can be sent to the technical support team for faster service.
98
www.acti.com
Firmware User’s Manual V9.02.27
Factory Default
The section Factory Default allows the camera settings be reset to the
original factory settings.
If you want to keep network settings and restore other settings to factory default, please select
the first option. If you select the second one instead, all the settings would be removed during
factory default. You will have to use factory default IP setting to connect to this camera.
99
www.acti.com
Firmware User’s Manual V9.02.27
Firmware Upload
The section Firmware Upload allows remote upgrade or downgrade of
camera firmware. The upgrade to newer version is usually done in order to gain new functions or
fix existing bugs or limitations while downgrade to older version is used mostly for integration
purposes where the newly purchased camera model comes with the newer firmware version than
supported by a third party video management system of a given project.
Firmware uploading can be done in two ways, choose to download and select the firmware image
manually or use auto-upgrade function through “Firmware Upload from the Download Center” so
that the camera will connect to internet and find the latest firmware image automatically.
Firmware Upload from Local
To upload the firmware manually, download the firmware image file, which contains the file
extension “.upg”, from the website. Choose “Firmware Upload from Local” and press the Apply
button.
Click Browse to select the downloaded firmware image file. Click the Apply button to start the
upload.
Once the process is finished, you will get an “OK” message and the system will reboot itself.
100
www.acti.com
Firmware User’s Manual V9.02.27
Firmware Upload from the Download Center
To upgrade the firmware automatically, choose “Firmware Upload from the Download Center” and
press the Apply button. The camera will automatically search the latest firmware version. Click
the Upload button to start the upload. Once the process is finished, you will get an “OK” message
and the system will reboot itself.
If the camera found the running version is already the latest one, a message will pop up and
firmware upload is not needed.
If the camera failed to connect to the internet or the DNS server is not set correctly, a warning
message will pop up, please examine your IP address setting and the DNS server settings.
101
www.acti.com
Firmware User’s Manual V9.02.27
Save & Reboot
The Save & Reboot section allows saving the settings and
rebooting the camera remotely. This is critical because some settings might not take effect before
save & reboot.
102
www.acti.com
Firmware User’s Manual V9.02.27
Logout
Clicking this item allows you to log out of the IP device. Be sure to logout
this IP device once you have completed all the tasks via Web Configurator.
103
www.acti.com
Firmware User’s Manual V9.02.27
Troubleshooting
Although the default settings of the camera are ideal for 90% of the cases, there may be some
rare cases when the settings need to be adjusted or the device has to be examined. The
following section provides easy troubleshooting solutions for most cases. In some occasions, the
unexpected symptoms may be the result of selecting the product that is not suitable for given
environment.
For more detailed explanations and instructions of each situation, please refer to the complete
Troubleshooting Guide at http://www.acti.com/kb/detail.asp?KB_ID=KB20130130001
Image Quality Troubleshooting
Problem
Solution
Motion blur
Increase shutter speed
Blurry image
Auto Focus: Refocus button; Manual focus: adjust manually
Too narrow DoF
Reduce aperture size, widen the viewing angle, install camera farther from objects
Vari-focal lens: widen the viewing angle; Zoom lens: press the zoom-out button; Fixed
Too narrow viewing
lens: replace it with wide angle fixed lens or choose another model with wide angle
angle
lens
Increase video resolution; zoom-in (zoom lens) or adjust lens to telephoto position
Objects too small
(vari-focal); Install the camera closer to target; Change to the lens with longer focal
length; Change the camera model with higher resolution or longer focal length
Use Auto Exposure Mode and increase AE Reference Target; set the Slowest Auto
Underexposed
Shutter Speed to slowest possible (1/5s); Add external light source to illuminate the
area the camera is shooting
Overexposed
Use Auto Exposure Mode and reduce AE Reference Target if necessary
Enable DNR; Enlarge the aperture; Lower AE Reference Target in Auto Exposure
Noise
mode; Lower the Exposure Gain in Manual Exposure mode; Lower video resolution;
Add extra visible or IR lights
Blocking & mosaic
Increase the bitrate
Wrong
Manually correct the colors by using white paper “Hold” button in Auto White Balance
colors
color rolling
or
mode; Adjust the camera’s position or viewing direction; Adjust the light source
Make sure there is sufficient light; Make sure the Day/Night Mode and IR LED Control
are both in Auto mode; Make sure that the “Switch from Day mode to Night mode” does
Black image
NOT have the most extreme value – 100; Manual iris: open the iris by rotating the ring
towards “O”; Remove the protective cap of the lens during installation
104
www.acti.com
Firmware User’s Manual V9.02.27
Make sure the dome or bullet cover is tightly mounted; Reduce the AE reference target
IR light reflection
in Auto Exposure mode; Reduce the Exposure Gain in Manual Exposure mode
Streaming Quality Troubleshooting
In auto exposure mode, set the Slowest Auto Shutter Speed to be not slower than the
Frame Rate Too
interval of frames; In manual exposure mode, set the Shutter Speed to be not slower
Low at Night
than the interval of frames
Use dual stream (stream 1 for recording, stream 2 for live view); Lower the bitrate;
Lower the resolution (if acceptable for user); Check the cable quality; Make sure to use
Latency
industrial grade switches and routers; Check the NVR server & client PC requirements
from NVR manual
Jitter
Use the NVR that has the video smoothening algorithm for live view and playback
Use the Playback function of NVR – use frame-by-frame validation of jitter-looking
sections, to see if any frames are dropped; To troubleshoot the data switch/router and
Dropped Frames
VMS computer, you may also ask for assistance from technical support team of
camera manufacturer
105
www.acti.com
Copyright © 2017, ACTi Corporation All Rights Reserved
7F, No. 1, Alley 20, Lane 407, Sec. 2, Ti-Ding Blvd., Neihu District, Taipei, Taiwan 114, R.O.C.
TEL : +886-2-2656-2588
FAX : +886-2-2656-2599
Email: [email protected]
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
