SKM 2000

Instruction manual

Contents

Contents

Important safety instructions .......................................................................... 2

The SKM 2000 radio microphone

..................................................................... 3

Areas of application ........................................................................................ 3

The frequency bank system .......................................................................... 4

Delivery includes .................................................................................................. 5

Product overview ................................................................................................. 6 Overview of the SKM 2000 radio microphone ........................................... 6

Overview of the displays ................................................................................ 7

Putting the radio microphone into operation .............................................. 8 Inserting the batteries/accupack ................................................................. 8

Charging the accupack .................................................................................... 9 Changing the microphone head ................................................................. 10

Changing the color-coded protection ring ............................................... 11 Using the radio microphone

........................................................................... 11

Switching the radio microphone on/off ................................................... 12

Deactivating the lock mode temporarily ................................................. 13

Deactivating the RF signal .......................................................................... 14 Selecting a standard display ...................................................................... 14

Using the operating menu

............................................................................. 15

The buttons .................................................................................................... 15 Overview of the operating menu ............................................................... 15

Working with the operating menu ........................................................... 17

Synchronizing the radio microphone with a receiver .............................. 19

Cleaning the radio microphone

..................................................................... 20

If a problem occurs ...

....................................................................................... 21

Specifications

.................................................................................................... 22 For more detailed information on the individual sections of this instruction manual, visit the corresponding product page on our website at www.sennheiser.com. 1

2 Important safety instructions

Important safety instructions

• Read this instruction manual.

• Keep this instruction manual. Always include this instruction manual when passing the device on to third parties.

• Heed all warnings and follow all instructions.

• Clean the device only with a slightly damp cloth.

• Do not place the device near any heat sources such as radiators, stoves, or other devices (including amplifiers) that produce heat.

• Only use attachments/accessories specified by Sennheiser. • When replacement parts are required, only use replacement parts spec ified by Sennheiser or those having the same characteristics as the orig inal part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

• Refer all servicing to qualified service personnel.

Servicing is required if the device has been damaged in any way, liquid has been spilled, objects have fallen inside, the device has been exposed to rain or moisture, does not operate properly or has been dropped.

• WARNING: To reduce the risk of short circuits, do not use the device near water and do not expose it to rain or moisture.

Intended use

Intended use of the SKM 2000 radio microphone includes: • having read these instructions especially the chapter “Important safety instructions”, • using the device within the operating conditions and limitations described in this instruction manual.

“Improper use” means using the device other than as described in these instructions, or under operating conditions which differ from those described herein.

The SKM 2000 radio microphone

The SKM 2000 radio microphone

This radio microphone is part of the 2000 series. With this series, Sennheiser offers high-quality state-of-the-art RF transmission systems with a high level of operational reliability and ease of use. Transmitters and receivers permit wireless transmission with studio-quality sound.

Features of the 2000 series: • Optimized PLL synthesizer and microprocessor technology • HDX noise reduction system • Pilot tone squelch control • True diversity technology • Switching bandwidth of up to 75 MHz • Increased immunity to intermodulation and interferences in multi channel operation

Areas of application

The radio microphone can be combined with the EM 2000 or EM 2050 rack mount receiver. The receivers are available in the same UHF frequency ranges and are equipped with the same frequency bank system with factory-preset frequencies. An advantage of the factory-preset frequen cies is that • a transmission system is ready for immediate use after switch-on, • several transmission systems can be operated simultaneously on the preset frequencies without causing intermodulation interference.

Radio microphone SKM 2000 BK (black) NI (nickel) Interchange able microphone heads MMD 835-1 Receivers EM 2000 receiver MMD 845-1 MME 865-1 MMD 935-1 MMD 945-1 MMK 965-1 MD 9235

40 30 20 10 RF PEAK -10 0

B.Ch: 20.64

-20 -30 -40 AF

**2000**

543.200

EQ: P + 12dB

MHz

SKM2000 MUTE True Diversity Receiver EM 2000 True Diversity Receiver EM 2050 40 30 20 10 RF PEAK 0 -10 -20 -30 -40 AF

B.Ch: 20.64

**2000**

543.200

MHz

EQ: P + 12dB SKM2000 MUTE

EM 2050 twin receiver

40 30 20 10 RF PEAK -10 0

B.Ch: 20.64

-20 -30 -40 AF

**2000**

543.200

EQ: P + 12dB

MHz

SKM2000 MUTE

3

The SKM 2000 radio microphone

The frequency bank system

The radio microphone is available in 5 UHF frequency ranges with up to 3,000 transmission frequencies per frequency range: 500 Range Aw : 516 – 558 Range GBw : 606 – 678 Range Gw : 558 – 626 Range Bw : 626 – 698 600 700 Range Cw : 718 – 790 Range Dw : 790 – 865 800 Each frequency range (Aw–Dw, Gw, GBw) offers 26 frequency banks with up to 64 channels each: Channel

1

– frequency preset Channel

2

– frequency preset Frequency bank

1 ... 20

Channel

64

– frequency preset Channel

1

– freely selectable frequency Channel

2

– freely selectable frequency Frequency bank

U1 ... U6

Channel

64

– freely selectable frequency Each of the channels in the frequency banks “ 1 ” to “ 20 ” has been factory preset to a fixed transmission frequency (frequency preset). The factory preset frequencies within one frequency bank are intermodulation-free.

These frequencies cannot be changed.

For an overview of the frequency presets, please refer to the supplied frequency information sheet. Updated versions of the frequency informa tion sheet can be downloaded from the corresponding product page on our website at www.sennheiser.com.

The frequency banks “ U1 ” to “ U6 ” allow you to freely select and store transmission frequencies. It might be that these transmission frequencies are not intermodulation-free.

4

Delivery includes

Delivery includes

The packaging contains the following items: 1 SKM 2000 radio microphone 2 AA size batteries, 1.5 V 1 microphone clamp 8 color-coded identification rings 1 pouch 1 instruction manual 1 frequency information sheet 1 RF power information sheet You additionally require 1 microphone head.

5

Product overview

Product overview

Overview of the SKM 2000 radio microphone

쐃 Microphone head (interchangeable) 쐇 쐋 쐏 Body of radio microphone Battery compartment (not visible from outside) 쐄 쐂 쐆 쐊 Name and pick-up pattern of the microphone head Display panel, backlit in orange Infra-red interface Antenna Color-coded protection ring; (available in different colors) 쐎 Operation and battery status indicator, red LED: lit = ON flashing = LOW BATT 쐅 쐈 Charging contacts Multi-function switch: ( UP ) ( DOWN ) ( SET ) 쐉 ON/OFF button (serves as the ESC (cancel) key in the operating menu) 6

Product overview

Overview of the displays

After switch-on, the radio microphone displays the standard display “ Frequency/Name ”. For further illustrations and examples of the different

standard displays, refer to Seite 14. The display backlighting is automati-

cally reduced after approx. 20 seconds.

AF

543.200

**2000**

P MUTE

MHz Display 햲 Audio level “ AF ” 햳 햴 햵 햶 햷 햸 햹 Frequency Name Transmission icon Lock mode icon “ “ P ” (Pilot) MUTE ” Battery status Meaning Modulation of the radio microphone with peak hold function Current transmission frequency User selectable name RF signal is being transmitted Lock mode is activated Pilot tone transmission is activated Audio signal is muted Charge status: approx. 100% approx. 70% approx. 30% charge status is critical, the red LOW BATT LED 쐎 is flashing: 7

8 Putting the radio microphone into operation

Putting the radio microphone into operation

Inserting the batteries/accupack

For powering the radio microphone, you can either use two 1.5 V AA size batteries or the rechargeable Sennheiser BA 2015 accupack.

Unscrew the lower part of the radio microphone from the radio micro phone’s body 쐏 by turning it counterclockwise.

쐏 When unscrewing the radio microphone during operation, the muting function is automatically activated. “ MUTE ” appears on the display panel.

When screwing the lower part of the radio microphone back to the radio microphone’s body, the muting is canceled.

Slide back the lower part of the radio microphone as far as it will go.

Open the battery compartment cover 씈 .

Putting the radio microphone into operation Insert the batteries or the BA 2015 accupack as shown on the battery compartment cover. Observe correct polarity when inserting the batteries/accupack.

씈 Close the battery compartment cover 씈 .

Push the battery compartment into the radio microphone’s body.

Screw the lower part of the radio microphone back to the radio micro phone’s body 쐏 .

Charging the accupack

To charge the BA 2015 accupack (optional accessory) in the radio micro phone: Use the LA 2 charging adapter to insert the radio microphone into the L 2015 charger (both the charger and the charging adapter are avail able as optional accessories – information on accessories can be found on our web site at www.sennheiser.com).

The LA 2 charging adapter and L 2015 charger can only charge the radio microphone with the BA 2015 accupack installed. Standard batteries (primary cells) or individual rechargeable battery cells cannot be charged in this way.

9

Putting the radio microphone into operation

Changing the microphone head

Unscrew the microphone head 쐃 .

쐃 Do not touch the contacts of the radio microphone nor the contacts of the microphone head 쐃 . The contacts can become dirty or damaged if touched.

When unscrewing the microphone head 쐃 during operation, the muting function is automatically activated. “ MUTE ” appears on the display panel.

When screwing the microphone head back to the radio micro phone, the muting is canceled.

Screw the desired microphone head to the radio microphone.

10 The radio microphone is operational again.

Using the radio microphone

Changing the color-coded protection ring

The color-coded protection ring 쐊 prevents the multi-function switch 쐈 from accidental operation. Protection rings 쐊 in different colors are avail able as accessories. The protection rings allow you to clearly identify each radio microphone.

Remove the color-coded protection ring 쐊 as shown.

Put on a new protection ring 쐊 as shown.

Using the radio microphone

To establish a transmission link, proceed as follows: 1. Switch the receiver on (see the instruction manual of the receiver).

2. Switch the radio microphone on (see below).

The transmission link is established and the display backlighting of the receiver changes from red to orange.

11

Using the radio microphone

Switching the radio microphone on/off

To switch the radio microphone on (online operation): ON/OFF Briefly press the ON / OFF button 쐉 .

The red ON LED 쐎 lights up. The “ Frequency/Name ” standard display appears on the display panel. The transmission icon 햵 is displayed.The radio microphone transmits an RF signal. To switch the radio microphone on and to deactivate the RF signal on switch-on (offline operation): ON/OFF Keep the ON / OFF button 쐉 pressed until “ RF Mute Off?

” appears on the display panel.

Move the multi-function switch upwards/downwards.

“ RF Mute On?

” appears on the display panel.

Press the multi-function switch.

The transmission frequency is displayed but the radio micro phone does not transmit an RF signal. The transmission icon 햵 is not displayed. When the pilot tone function is acti vated on both radio microphone and receiver, “ RF Mute ” appears on the receiver’s display panel.

AF

543.200

**2000**

P MUTE

MHz 햵 Use this function to save battery power or to prepare a radio microphone for use during live operation without causing inter ference to existing transmission links.

12

Using the radio microphone To activate the RF signal : ON/OFF Briefly press the ON / OFF button.

“ RF Mute On?

” appears on the display panel.

Move the multi-function switch upwards/downwards.

“ RF Mute Off?

” appears on the display panel.

Press the multi-function switch.

The transmission icon 햵 is displayed again. The radio micro phone transmits an RF signal.

To switch the radio microphone off :

If necessary, deactivate the lock mode (see Seite 13).

ON/OFF Keep the ON / OFF button 쐉 pressed until “ OFF ” appears on the display panel. The red ON LED 쐎 goes off and the display panel turns off.

When in the operating menu, pressing the ON / OFF button 쐉 will cancel your entry (ESC function) and return you to the current standard display.

Deactivating the lock mode temporarily

You can activate or deactivate the automatic lock mode via the “ Auto Lock ” menu item. If the lock mode is activated, you have to temporarily deactivate it in order to be able to operate the radio microphone: ON/OFF Press the multi-function switch or the ON / OFF button.

“ Locked ” appears on the display panel.

Move the multi-function switch upwards/downwards.

“ Unlock?

” appears on the display panel.

Press the multi-function switch.

– When you are in the operating menu, the lock mode remains deactivated until you exit the operating menu.

– When one of the standard displays is shown, the lock mode is automatically activated after 10 seconds.

The lock mode icon 햶 flashes prior to the lock mode being activated again.

40 30 20 10 RF PEAK 0 -10 -20 -30 -40 AF

B.Ch: 20.64

**2000**

543.200

MHz

EQ: P + 12dB SKM2000 MUTE

13

Using the radio microphone

Deactivating the RF signal Deactivating the RF signal on switch-on

For information on deactivating the RF signal on switch-on, refer to the

chapter „Switching the radio microphone on/off“ auf Seite 12.

Deactivating the RF signal during operation

ON/OFF When one of the standard displays is shown on the display panel, briefly press the ON / OFF button.

“ RX Mute On?

” appears on the display panel.

Press the multi-function switch to confirm your selection.

Activating the RF signal

ON/OFF When one of the standard displays is shown on the display panel, briefly press the ON / OFF button.

“ RX Mute Off?

” appears on the display panel.

Press the multi-function switch to confirm your selection.

Selecting a standard display

Move the multi-function switch to select a standard display: Contents of the display Selectable standard display “ Frequency/Name ”

AF

543.200

**2000**

P MUTE

MHz “ Channel/Frequency ”

AF

B.Ch: 20.64

543.200

P MUTE

MHz “ Name/Channel ”

AF

**2000** B.Ch: 20.64

P MUTE

14

Using the operating menu

Using the operating menu

The buttons

Button Press the ON / OFF button ON/OFF Press the multi-function switch Move the multi-function switch Function of the button • Switches the radio microphone on and off • Cancels the entry and returns to the current standard display (ESC function) • Activates/deactivates the RF signal

(special function, see Seite 14)

• Changes from the current standard display to the operating menu • Calls up a menu item • Enters a submenu • Stores the settings and returns to the oper ating menu • Selects a standard display • Changes to the next/previous menu item • Changes the setting of a menu item

Overview of the operating menu Main menu „Menu” Sensitivity Frequency Preset Name Low Cut Auto Lock Advanced Exit Extended menu „Advanced” Tune RF Power Pilot Tone LCD Contrast Reset Software Revision Exit

15

Using the operating menu Display Function of the menu item

Main menu “Menu”

Sensitivity Frequency Preset Name Low Cut Auto Lock Advanced Exit Adjusts the sensitivity “ AF ” Changes the frequency bank and the channel Enters the transmitter name Activates/deactivates the low-cut filter Activates/deactivates the automatic lock mode Calls up the extended menu “ Advanced Menu ” Exits the operating menu and returns to the current standard display

Extended menu “Advanced Menu”

Tune RF Power Pilot Tone LCD Contrast Reset Software Revision Exit Sets the transmission frequencies for the frequency banks “ U1 ” to “ U6 ” Special function: Sets a channel and a transmission frequency for the frequency banks “ U1 ” to “ U6 ” Adjusts the transmission power Activates/deactivates the pilot tone transmission Adjusts the contrast of the display panel Resets the radio microphone Displays the current software revision Exits the extended menu “ Advanced Menu ” and returns to the main menu 16

Using the operating menu

Working with the operating menu

If the lock mode is activated, you have to deactivate it in order to

be able to work with the operating menu (siehe Seite 13).

By way of example of the “ Sensitivity ” menu, this section describes how to use the operating menu.

Changing from the current standard display to the operating menu

Press the multi-function switch. The current standard display is replaced by the main menu. The last selected menu item is displayed.

Selecting a menu item

Move the multi-function switch to change to the “ Sensitivity ” menu item.

The current setting of the selected menu item is displayed: Menu

Sensitivity

–12 dB

Changing and storing settings

Menu S e n s i t i v i t y –12 dB Call up “Sensitivity” S e n s i t i v i t y – 12 dB Select the desired setting S e n s i t i v i t y –36 dB Store the setting „Stored” Press the multi-function switch to call up the menu item .

Move the multi-function switch to adjust the input sensitivity.

Press the multi-function switch to store the setting.

17

Using the operating menu

Canceling an entry

ON/OFF Press the ON / OFF button to cancel the entry.

The current standard display appears on the display panel.

To subsequently return to the last edited menu item: Press the multi-function switch repeatedly until the last edited menu item appears.

Exiting a menu item

Change to the “ Exit ” menu item.

Menu

Exit

Confirm your selection.

You return to the next higher menu level.

To directly return to the current standard display: ON/OFF Press the ON / OFF button.

18

Synchronizing the radio microphone with a receiver

Synchronizing the radio microphone with a receiver

When synchronizing the radio microphone with a receiver, please observe the following: Only use a radio microphone and a receiver from the same frequency range (see the type plate on the radio microphone and the receiver).

Make sure that the desired frequencies are listed in the enclosed frequency information sheet.

Make sure that the desired frequencies are approved and legal in your country and, if necessary, apply for an operating license.

Synchronizing the radio microphone with the receiver – individual operation

Upon delivery, the radio microphone and the receiver are synchronized with each other. However, if you cannot establish a transmission link between radio microphone and receiver, you have to synchronize the channels of the devices.

For information on automatic synchronization of the radio microphone with the receiver (individual operation), refer to the instruction manual of the receiver. This information is marked with the icon.

Alternatively, you can set the channel on the radio microphone manually: Make sure that you set the radio microphone to the same frequency bank and the same channel as the receiver.

If you still cannot establish a transmission link, refer to the chapter „If a problem occurs ...“ auf Seite 21.

Synchronizing radio microphones with receivers – multi-channel operation

Combined with 2000 series receivers, 2000 series radio microphones can form transmission links that can be used in multi-channel systems. In order to ensure an intermodulation-free transmission, use the same frequency bank for all transmission links.

For information on automatic synchronization of radio microphones with receivers (multi-channel operation), refer to the instruction manual of your receiver. For more information on multi-channel operation, visit the corresponding product page at www.sennheiser.com.

19

Cleaning the radio microphone

Cleaning the radio microphone

CAUTION!

Liquids can damage the electronics of the radio micro phone!

Liquids entering the housing of the device can cause a short-circuit and damage the electronics.

Keep all liquids away from the radio microphone.

Use a slightly damp cloth to clean the radio microphone from time to time. Do not use any solvents or cleansing agents.

To clean the sound inlet basket of the microphone head: CAUTION!

Liquids will damage the microphone head!

Liquids will damage the microphone head.

Only clean the upper sound inlet basket.

Unscrew the upper sound inlet basket from the microphone head by turning it counterclockwise (see diagram).

Remove the foam insert.

To clean the sound inlet basket: – Use a slightly damp cloth to clean the upper sound inlet basket from the inside and outside.

OR – Scrub with a brush and rinse with clear water.

If necessary, clean the foam insert with a mild detergent or replace the foam insert.

Dry the upper sound inlet basket.

Dry the foam insert.

Reinsert the foam insert.

Replace the sound inlet basket on the microphone head and screw it tight.

You should also clean the contact rings of the microphone head from time to time: Wipe the contact rings of the microphone head with a dry cloth.

20

If a problem occurs ...

If a problem occurs ...

Problem Radio microphone cannot be operated, “ Locked ” appears on the display panel No operation indication No RF signal at the receiver RF signal available, no audio signal, “ MUTE ” appears on the display panel Audio signal has a high level of back ground noise / audio signal is distorted Possible cause Lock mode is activated Batteries are flat or accupack is flat Radio microphone and receiver are not on the same channel Radio microphone is out of range Possible solution Deactivate the lock mode

(siehe Seite 13).

Replace the batteries or recharge the accupack

(siehe Seite 8).

Synchronize the radio microphone with the

receiver (siehe Seite 19).

Set the radio microphone to the same channel as the receiver.

Check the squelch threshold setting on the receiver.

Reduce the distance between radio microphone and receiving antenna.

Increase the transmission power.

Activate the RF signal

(siehe Seite 14).

RF signal is deactivated (“ RF Mute “) Receiver’s squelch threshold is adjusted too high Radio microphone doesn’t transmit a pilot tone Radio microphone’s sensitivity is adjusted too low/ too high Reduce the squelch threshold setting on the receiver.

Activate or deactivate the pilot tone transmission.

Adjust the input sensitivity.

If a problem occurs that is not listed in the above table or if the problem cannot be solved with the proposed solutions, please contact your local Sennheiser partner for assistance. To find a Sennheiser partner in your country, search at www.sennheiser.com under “Service & Support”.

21

Specifications

Specifications

RF characteristics

Modulation Frequency ranges Transmission frequencies Switching bandwidth Nominal/peak deviation Frequency stability RF output power at 50 Ω Pilot tone squelch

AF characteristics

Compander system AF frequency response Signal-to-noise ratio (1 mV, peak deviation) THD Adjustment range of input sensitivity

Overall device

Temperature range Power supply Nominal voltage wideband FM 516–558, 558–626, 606–678, 626–698, 718–790, 790–865 MHz

(Aw to Dw, Gw, GBw, see Seite 4)

up to 3,000 frequencies, tuneable in steps of 25 kHz 20 frequency banks, each with up to 64 factory-preset channels 6 frequency banks, each with up to 64 user programmable channels up to 75 MHz ±24 kHz/±48 kHz ≤ ±15 ppm switchable: typ. 10 mW (Low) typ. 30 mW (Standard) typ. 50 mW (High) can be switched off Sennheiser HDX 80–18,000 Hz ≥ 120 dBA ≤ 0.9% 48 dB, adjustable in 6-dB steps – 10°C to +55°C 2 AA size batteries, 1.5 V or BA 2015 accupack 2.4 V 22

Specifications Power consumption: • at nominal voltage • with switched-off radio microphone Operating time Dimensions Weight (incl. batteries)

In compliance with

Europe typ. 180 mA (30 mW) ≤ 25 μ A typ.

8 hrs approx.

∅ 50 x 265 mm approx. 380 g EMC Radio Safety EN 301489-1/-9 EN 300422-1/-2 EN 60065 EN 62311 (SAR)

Approved by

Canada: USA: Industry Canada RSS 210 IC: 2099A-SKM2000 limited to 806 MHz FCC-Part 74 FCC-ID: DMOSKM2000/ limited to 698 MHz

Microphone heads

Microphone head Type MMD 835-1 dynamic MMD 845-1 dynamic MME 865-1 condenser Sensitivity Pick-up pattern 2.1 mV/Pa cardioid 1.6 mV/Pa super cardioid 1.6 mV/Pa super cardioid MMD 935-1 dynamic MMD 945-1 dynamic 2.5 mV/Pa cardioid 1.8 mV/Pa super cardioid MMK 965-1 externally polarized dual diaphragm condenser microphone MD 9235 dynamic 5.7 mV/Pa 1.8 mV/Pa cardioid/ super cardioid, switchable 1.8 mV/Pa cardioid Max. SPL 154 dB SPL 154 dB SPL 152 dB SPL 154 dB SPL 154 dB SPL 144 dB SPL 154 dB SPL 163 dB SPL 23

Sennheiser electronic GmbH & Co. KG

Am Labor 1, 30900 W www.sennheiser.com

Publ. 1 2 /1 6 , 549121

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
