S12ZVL Smallest Integrated LIN Slave MCU
 System in a Package - Highly integrated part which is ideal for space
constrained applications such as Actuators, Sensors, LIN nodes etc.
 Low System Cost – Directly powered by Battery. Integrated LIN Phy, EVDD
and NGPIOs reduce system, qualification and manufacturing cost.
 High Reliability – High immunity to EMI and ESD stresses, LIN 2.x
compliant with +/- 8kV ESD capability.
 Enablement – Supported by comprehensive hardware and software system
(free low-level drivers to enterprise 3rd party tools) which reduces
development costs and time to market.
S12Z
32MHz Bus
MagniV™
Directly powered by Car
Battery
Integrated LIN Transceiver
High Voltage
Analog
LIN Physical
Layer
High Voltage
Input
8 – 32 kB
12V VREG
12V/70mA, 170mA w ext
ballast
RAM
1 kB
EVDD
1ch 5V/20mA (source)
Core
S12Z
NGPIO
3ch 5V/25mA (sink)
Speed
32 MHz
Timer
6ch + 2ch 16bit
ADC
10ch 10bit
SPI/SCI/IIC
2/1/1
HVI
1
Packages
32LQFP, 32QFN, 48LQFP
LIN Phy
1
Op Range
5.5V – 18V
Part Numbers
32LQFP
32QFN-EP
48LQFP
S9S12ZVL32F0MLC
S9S12ZVLS3F0MFM
S9S12ZVL32F0MLF
S9S12ZVL16F0MLC
S9S12ZVLS1F0MFM
S9S12ZVL16F0MLF
S9S12ZVL8F0MLC
S9S12ZVLS8F0MFM
S9S12ZVL8F0MLF
TM
IPLL
IRC
XOSCLCP
SRAM
(ECC)
1KB
Safe Assure™
Analog
Timers
Comm.
Interfaces
HMI
Ultra-Reliable Industrial
10bit ADC
6ch TIM0
1x LIN Phy
GPIO
1x EVDD
2ch TIM1
2x SPI
KWU
15 Year Longevity
3x NGPIO
Temp
Sense
API
1x IIC
IRQ
RTI
1x SCI
PWM
Targeted Applications
Flash
CPMU
VSUP Sense
Fast ADC
S12ZVL
System
Flash
(ECC)
32KB
EEPROM
(ECC)
128B
DBG
BDC
Memories
12V VREG
•LIN nodes
•LIN switch panel / user interface
•LIN actuators, sensors
•HVAC
•Lighting controls
•Ambient lighting
•Seat positioning
•Ultrasonic Sensors
Sensor
LIN Phy
VREG
HVI
EVDD
S12ZVL
ADC
Off
Board
Switche
s
Dials
GPIO
Enablement Tools
• Evaluation Boards / Hardware
• TRK-S12ZVL
• Reference Solutions
• Ultrasonic distance measurement
• LIN RGB LED
• CodeWarrior, Cosmic
• LIN drivers
Switch Panel
12V Battery
Voltage
On Board
Switches
NGPIO
LED
Backlight
CLICK FOR
KEA
3
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
•
The MC9S12ZVL-Family is an automotive 16-bit
microcontroller family using the 180nm NVM + UHV
technology that offers the capability to integrate 40V
analog components.
•
The particular differentiating features of this family are the
enhanced S12Z core and the integration of “high-voltage”
analog modules, including the voltage regulator (VREG)
and a Local Interconnect Network (LIN) physical layer.
•
It’s primarily targeted at LIN nodes, ultrasonic sensors,
switchpanel and lighting.
Confidential and Proprietary
TM
4
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
•
System in a Package - Highly integrated part which is ideal for
space constrained applications such as Actuators, Sensors, LIN
nodes etc.
•
Low System Cost – Directly powered by Battery. Integrated LIN
Phy, EVDD and NGPIOs reduce system, qualification and
manufacturing cost.
•
High Reliability – High immunity to EMI and ESD stresses, LIN
2.x compliant with +/- 8kV ESD capability.
•
Enablement – Supported by comprehensive hardware and
software system (free low-level drivers to enterprise 3rd party
tools) which reduces development costs and time to market.
Confidential and Proprietary
TM
5
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
• S12Z-core
(up to 32MHz bus frequency)
compatible within MagniV
• On chip 12V Vreg with Supply-capability:
•
70mA total (170mA with ext. Ballast)
• LIN-PHY,
LIN2.x / J2602 compliant
• On chip RC Oscillator; trimmed to +/- 1,3%
tolerance over full temperature range
• Robust 12V inputs Vsup-sense & HVI (with
ADC)
• 1x E-Vdd (20mA source capability)
• 1-3x N-GPIO (25 mA sink capability)
• 5x5mm footprint 32QFN-package optional
• ASIL-A compliancy
MagniV™
Directly powered
by Car Battery
Integrated LIN
Transceiver
Safe Assure™
Ultra-Reliable
Industrial
15 Year Longevity
Fast ADC
Confidential and Proprietary
TM
6
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
Product Name
S12ZVL
Package
S12ZVLS
48-LQFP
Flash memory (ECC)
32-LQFP
32-QFN
32 / 16 / 8 kB
EEPROM (ECC)
32 / 16 kB
128B
RAM (ECC)
1kB
SCI / SPI / IIC
2/1/1
LIN-PHY
1
HVI
1
V reg
12V/70mA; extendable to 170mA with ext. Ballast
Timer
6ch + 2ch (16 Bit)
PWM
8ch 8 Bit (or 4ch 16Bit)
ADC
10ch 10Bit
eVdd (5V/20mA)
N-GPIOs (5V / 25mA)
6ch 10Bit
1ch (source)
3ch (sink)
1ch (sink)
Temperature options
3ch (sink)
C/V/M
Confidential and Proprietary
TM
7
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
LIN-Sensors
Product Function
• Hooking up sensors into
automotive LIN-Network
(with signal preconditioning
Market Requirements
• LIN-PHY, 12V-Vreg, MCU
• Small formfactor (QFN)
• ADC, SPI
LIN-switchpanels
LIN-Actuator
Product Function
• Reading multiple switchpositions and feeding into
LIN-network
Product Function
• Converting LINcommand into an activity
(eg driving LEDs)
Market Requirements
• LIN-PHY, 12V-Vreg, MCU
• Multiple GPIOs, LED
drive
• ADC
Market Requirements
• LIN-PHY, 12V-Vreg, MCU
• Drivers (3x25mA drive
strength in case of RGBLED)
• ADC
Confidential and Proprietary
TM
8
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
Confidential and Proprietary
TM
9
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
Confidential and Proprietary
TM
10
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
Confidential and Proprietary
TM
11
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
S12ZVL Module Details
S12ZVL_ Introduction
Confidential and Proprietary
TM
12
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
MCU Core
and Memories
S12Z CPU
16-bit, 32b MAC,
linear addressing
Harvard architec.
compatible
within MagniV
S12Z 32MHz Bus
8-32KB
Flash (ECC)
128B
EEPROM
(ECC)
1kB
RAM
(ECC)
EEPROM
Flash (8-32kB)
4 byte
eraseable
100k program/
erase cycles
512B erasable
10k p/e cycles
Can be used for
Data (parameter,
config, calibr.)
Confidential and Proprietary
TM
13
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
•
The S12Z CPU is a revolutionary high-speed core, with code size and
execution efficiencies over the S12X
•
CPU. The S12Z CPU also provides a linear memory map eliminating the
inconvenience and performance impact of page swapping.
•
Harvard Architecture - parallel data and code access
•
3 stage pipeline
•
32-Bit wide instruction and databus
•
32-Bit ALU
•
24-bit addressing (16 MByte linear address space)
•
Instructions and Addressing modes optimized for C-Programming &
Compiler
•
Optimized address path so it is capable to run at 50MHz without Flash
wait states
Confidential and Proprietary
TM
14
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
Flash
• On-chip flash memory on the MC9S12ZVL-Family
• • Up to 32 KB of program flash memory
• — Automated program and erase algorithm
• — Protection scheme to prevent accidental program or erase
EEPROM
• • Up to 128 bytes EEPROM
• — 16 data bits plus 6 syndrome ECC (error correction code) bits allow single bit error
correction
• and double fault detection
• — Erase sector size 4 bytes
• — Automated program and erase algorithm
• — User margin level setting for reads
SRAM
• • Up to 1 KB of general-purpose RAM with ECC
• — Single bit error correction and double bit error detection code based on 16-bit data
words
Confidential and Proprietary
TM
15
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
Digital
Components
MCU Core
and Memories
2 UARTs
One linked to LIN Phy, 2nd
as independant Test Intf.
SPI, IIC
Serial link to other Ics,
e.g sensors,…
or indep. test Interface
Up to 23 Wakeup pins
Combined with Analog
Input pins and HV pins
2 Timer modules
6ch / 16Bit + 2ch / 16Bit
8ch PWM
Configurable to 8ch / 8Bit
or 4ch / 16Bit
NGPIO (PP1/3/5)
SCI 1
SCI 0
SPI
IIC
G BDM KWU Win
Wdog
P BDC
I TIM 16b
O 6+2ch
PWM 8ch 8b
or 4ch 16b
1#
EVDD
S12Z 32MHz Bus
8-32KB
Flash (ECC)
128B
EEPROM
(ECC)
1kB
RAM
(ECC)
1-3#
NGPIO
1-3# 5V / 25mA sink
Eg. for RGB-LED
External Supply
5V / 20mA switchable for
local (same PCB), over
current protected. Eg.
Sensor supply
Confidential and Proprietary
TM
16
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
Timer (TIM0 and TIM1)
•
Two independent timer modules with own 16-bit free-running counter
and with 8-bit precision prescaler
— 6 x 16-bit channels Timer module (TIM0) for input capture or output
compare
— 2 x 16-bit channels Timer module (TIM1) for input capture or output
compare
Pulse Width Modulation Module (PWM)
•
Up to eight channel x 8-bit or up to four channel x 16-bit pulse width
modulator
— Programmable period and duty cycle per channel
— Center-aligned or left-aligned outputs
— Programmable clock select logic with a wide range of frequencies
Confidential and Proprietary
TM
17
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
Serial Communication Interface Module (SCI)
• Full-duplex or single-wire operation
• Standard mark/space non-return-to-zero (NRZ) format
• Selectable IrDA 1.4 return-to-zero-inverted (RZI) format with programmable pulse
widths
• Baud rate generator by a 16-bit divider from the bus clock
• Programmable character length
• Programmable polarity for transmitter and receiver
• Active edge receive wakeup
• Break detect and transmit collision detect supporting LIN
Serial Peripheral Interface Module (SPI)
• Configurable 8- or 16-bit data size
• Full-duplex or single-wire bidirectional
• Double-buffered transmit and receive
• Master or slave mode
• MSB-first or LSB-first shifting
• Serial clock phase and polarity options
Confidential and Proprietary
TM
18
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
Inter-IC Module (IIC)
•
Multi-master operation
•
Software programmable for one of 256 different serial clock frequencies
•
Broadcast mode support
•
10-bit address support
•
Modes of Operation: Normal, wait and stop mode
Confidential and Proprietary
TM
19
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
5V Analogue
Components
Digital
Components
MCU Core
and Memories
On chip RC
OSC
factorytrimmed to +/1.3% , meets
LIN -needs
Pierce
Osc.
SCI 1
SCI 0
SPI
IIC
G BDM KWU Win
Wdog
P BDC
I TIM 16b
O 6+2ch
PWM 8ch 8b
or 4ch 16b
1#
EVDD
RCosc.
+/-1.3%
Temp
Sense
10-Bit
LBADC
10Bit List Based ADC
up to 10 ext. Ch.+7 int. Ch
(temp sense, supply mon.,
HVI, int. Ref. Voltages)
Executes command list &
write result directly to RAM
(DMA)
Phase Locked Loop
generates the VCOCLK
by multiplying the
reference clock
by a 2, 4, 6,... 126, 128
PLL
S12Z 32MHz Bus
8-32KB
Flash (ECC)
128B
EEPROM
(ECC)
1kB
RAM
(ECC)
1-3#
NGPIO
Confidential and Proprietary
TM
20
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
Analog-to-Digital Converter Module (ADC)
•
10-bit resolution
•
Up to 10 external channels & 8 internal channels
•
Left or right aligned result data
•
Continuous conversion mode
•
Programmers model with list based command and result storage
architecture
•
ADC directly writes results to RAM, preventing stall of further
conversions
•
Internal signals monitored with the ADC module
•
Vrh, Vrl, (Vrl+Vrh)/2, Vsup monitor, Vbg, TempSense
•
External pins can also be used as digital I/O
Confidential and Proprietary
TM
21
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
•
ADC
Block Diagram
Confidential and Proprietary
TM
22
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
Internal RC Oscillator (IRC)
•
1 MHz internal RC oscillator with +/-1.3% accuracy over rated
temperature range
Main External Oscillator (XOSCLCP)
•
Amplitude controlled Pierce oscillator using 4 MHz to 20 MHz crystal
— Current gain control on amplitude output
— Signal with low harmonic distortion
— Low power
— Good noise immunity
— Eliminates need for external current limiting resistor
— Transconductance sized for optimum start-up margin
Confidential and Proprietary
TM
23
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
•
Clock Source
Diagram
Confidential and Proprietary
TM
24
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
Digital
Components
5V Analogue
Components
MCU Core
and Memories
High-Voltage
Components
LIN Physical
Layer
LIN2.2 and SAE
J2602 compliant
+/- 8kV ESD
capability
Pierce
Osc.
LIN-PHY
SCI 1
SCI 0
SPI
IIC
G BDM KWU Win
Wdog
P BDC
I TIM 16b
O 6+2ch
PWM 8ch 8b
or 4ch 16b
1#
EVDD
1-3#
NGPIO
RCosc.
+/-1.3%
Temp
Sense
10-Bit
LBADC
PLL
S12Z 32MHz Bus
Voltage Regulator
8-32KB
Flash (ECC)
128B
EEPROM
(ECC)
1kB
RAM
(ECC)
1 HV Input
VSUP
sense
70, or up to 170mA
with ext. Ballast
VREG
5V/70mA total supply or
170mA with external ballast
for more current and lower
power dissipation
Supply sensing
Monitoring supply voltage
(sense after protection)
Packaging Options
32-LQFP and 48-LQFP
32-QFN 5x5mm
Confidential and Proprietary
TM
25
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
Supply Voltage Sensor (BATS)
•
Monitoring of supply (VSUP) voltage
•
Internal ADC interface from an internal resistive divider
•
Generation of low or high voltage interrupts
On-Chip Voltage Regulator system (VREG)
•
Voltage regulator
— Linear voltage regulator directly supplied by VSUP
— Low-voltage detect on VSUP
— Power-on reset (POR)
— Low-voltage reset (LVR) for VDDX domain
— External ballast device support to extend current capability and reduce internal power
dissipation
— Capable of supplying both the MCU internally plus external components
— Over-temperature protection and interrupt
•
Internal voltage regulator
— Linear voltage regulator with bandgap reference
— Low-voltage detect on VDDA
— Power-on reset (POR) circuit
— Low-voltage reset for VDD domain
Confidential and Proprietary
TM
26
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
LIN physical layer transceiver
•
Compliant with LIN Physical Layer 2.2 specification
•
Compliant with the SAE J2602-2 LIN standard
•
Standby mode with glitch-filtered wake-up
•
Slew rate selection optimized for the baud rates: 10.4kBit/s, 20kBit/s and
Fast Mode (up to
250kBit/s)
•
Switchable 34kΩ/330kΩ pull-ups
•
Current limitation for LIN Bus pin falling edge
•
Over-current protection
•
LIN TxD-dominant timeout feature monitoring the LPTxD signal
•
Automatic transmitter shutdown in case of an over-current or TxDdominant timeout
•
Fulfills the OEM “Hardware
Confidential and Proprietary
TM
27
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
•
Block Diagram
Confidential and Proprietary
TM
28
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
LIN Modes of Operation
The LIN Physical Layer can operate in the following four modes:
1. Shutdown Mode
The LIN Physical Layer is fully disabled. No wake-up functionality is available.
The internal pullup resistor is replaced by a high ohmic one (330 kΩ) to maintain
the LIN Bus pin in the recessive state. All registers are accessible.
2. Normal Mode
The full functionality is available. Both receiver and transmitter are enabled.
3. Receive Only Mode
The transmitter is disabled and the receiver is running in full performance mode.
4. Standby Mode
Confidential and Proprietary
TM
29
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
2 UARTs
One linked to LIN Phy, 2nd
as independant Test Intf.
SPI, IIC
Serial link to other Ics,
e.g sensors,…
or indep. test Interface
Up to 23 Wakeup pins
Combined with Analog
Input pins and HV pins
2 Timer modules
6ch / 16Bit + 2ch / 16Bit
8ch PWM
Configurable to 8ch / 8Bit
or 4ch / 16Bit
LIN Physical
Layer
16-bit, 32b MAC,
linear addressing
Harvard architec.
compatible
within MagniV
LIN2.2 and SAE
J2602 compliant
+/- 8kV ESD
capability
Pierce
Osc.
LIN-PHY
SCI 1
SCI 0
SPI
IIC
G BDM KWU Win
Wdog
P BDC
I TIM 16b
O 6+2ch
PWM 8ch 8b
or 4ch 16b
1#
EVDD
NGPIO (PP1/3/5)
S12Z CPU
1-3#
NGPIO
RCosc.
+/-1.3%
On chip RC
OSC
factorytrimmed to +/1.3% , meets
LIN -needs
Temp
Sense
10-Bit
LBADC
PLL
S12Z 32MHz Bus
8-32KB
Flash (ECC)
128B
EEPROM
(ECC)
5V / 20mA switchable for
local (same PCB), over
current protected. Eg.
Sensor supply
High Voltage
Input
12V Input for
Switch Monitoring
Routable to ADC
5V Analogue
Components
MCU Core
and Memories
High-Voltage
Components
10Bit List Based ADC
up to 10 ext. Ch.+7 int. Ch
(temp sense, supply mon.,
HVI, int. Ref. Voltages)
Executes command list &
write result directly to RAM
(DMA)
Phase Locked Loop
generates the VCOCLK
by multiplying the
reference clock
by a 2, 4, 6,... 126, 128
Voltage Regulator
1kB
RAM
(ECC)
1 HV Input
VSUP
sense
70, or up to 170mA
with ext. Ballast
VREG
1-3# 5V / 25mA sink
Eg. for RGB-LED
External Supply
Digital
Components
EEPROM
Flash (8-32kB)
4 byte
eraseable
100k program/
erase cycles
512B erasable
10k p/e cycles
Can be used for
Data (parameter,
config, calibr.)
5V/70mA total supply or
170mA with external ballast
for more current and lower
power dissipation
Supply sensing
Monitoring supply voltage
(sense after protection)
Packaging Options
32-LQFP and 48-LQFP
32-QFN 5x5mm
Confidential and Proprietary
TM
30
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
The following resets sources are available:
•
Power on reset (POR)
•
Low voltage reset (LVR)
•
External pin reset
•
Clock monitor reset
•
COP watchdog reset
Confidential and Proprietary
TM
31
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
S12ZVL Use Cases
S12ZVL_ Introduction
Confidential and Proprietary
TM
32
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
LIN Bus
Pierce
Osc.
LIN-PHY
SCI 1
SCI 0
SPI
IIC
RCosc.
+/-1.3%
10-Bit
ADC
5V Analogue
Components
MCU Core
and Memories
High-Voltage
Components
Dials
PLL
S12Z 32MHz Bus
G BDM KWU Win
Wdog
P BDC
I TIM 16b
O 6+2ch
PWM 8ch 8b
or 4ch 16b
1#
E-Vdd
Temp
Sense
Digital
Components
1-3#
NGPIO
8-32KB
Flash (ECC)
128B
EEPROM
(ECC)
1kB
RAM
(ECC)
HV Input
Off-board
Switches
On-board
Switches
Vsup
sense
70, or up to 170mA
with ext. Ballast
Vreg
LED
Backlight
Battery
Voltage
Wakeup
TM
Confidential and Proprietary
33
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
igital
Components
5V Analogue
Components
MCU Core
and Memories
High-Voltage
Components
LIN Bus
Pierce
Osc.
LIN-PHY
SCI 1
SCI 0
SPI
IIC
RCosc.
+/-1.3%
10-Bit
ADC
PLL
Rain /
Light
Sensor
ASIC
S12Z 32MHz Bus
G BDM KWU Win
Wdog
P BDC
I TIM 16b
O 6+2ch
PWM 8ch 8b
or 4ch 16b
1#
E-Vdd
Temp
Sense
1-3#
NGPIO
8-32KB
Flash (ECC)
128B
EEPROM
(ECC)
1kB
RAM
(ECC)
HV Input
Vsup
sense
70, or up to 170mA
with ext. Ballast
Vreg
Automotive Voltage
http://www.bmw.com/com/en/insights/technology
/technology_guide/articles/rain_sensor.html
5V Supply
Confidential and Proprietary
TM
34
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
Digital
Components
5V Analogue
Components
MCU Core
and Memories
High-Voltage
Components
VDDS
Verpolschutz
VDDX
BCTL
LIN Master
VSUP
S12ZVL16/32
Vreg
LIN_In
SCI0
Temp
Sense
S12Z
Flash
RAM
EEPROM
GPIO
IRC
PLL
BDM
Ext. Osc
COP
LIN
PHY
ADC
10bit
VDDX
PWM
3x16bit
RTI
3x20mA
RGB LED
Confidential and Proprietary
TM
35
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
Product summary page
•
www.freescale.com/S12ZVL
Application notes:
•
AN5122: LIN Driver with the MagniV Family
•
AN5082: MagniV in 24 V Applications
•
AN4842: LIN Enabled RGB LED Lighting Application
Confidential and Proprietary
TM
36
Freescale, the Freescale logo, AltiVec, C-5, CodeTEST, CodeWarrior, ColdFire, C-Ware, the Energy Efficient Solutions logo, mobileGT, PowerQUICC, QorIQ, StarCore
and Symphony are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. BeeKit, BeeStack, ColdFire+, CoreNet, Flexis, Kinetis, MXC, Platform in a
Package, Processor Expert, QorIQ Qonverge, Qorivva, QUICC Engine, SMARTMOS, TurboLink, VortiQa and Xtrinsic are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
TM
www.Freescale.com
© 2014 Freescale Semiconductor, Inc. | External Use
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
