INSTRUCTION MANUAL
Thank you for your purchase of this Citizen watch.
Before using the watch, read this instruction manual carefully to ensure
correct use.
After reading the manual, store it in a safe place for future reference.
Be sure to visit the Citizen website at http://www.citizenwatch-global.com/ .
Here you will find a variety of information such as electronic setting guides,
answers to frequently asked questions, Eco-Drive recharging information and
more.
To check the movement number
Engraving position example
A case number—4 alphanumeric characters and 6 or
more alphanumeric characters—is engraved on the
case back. (Figure on the right)
The first 4 characters of the case number represent
the movement number of the watch. In the example The engraving position may
on the right, “
” is the movement number. differ depending on watch
model.
1
Safety precautions — IMPORTANT
This manual contains instructions that should be strictly followed at all times
not only for optimal use, but to prevent any injuries to yourself, other persons or
property. We encourage you to read the entire booklet (especially, pages 74 to 85)
and understand the meaning of the following symbols:
■ Safety advisories are categorized and depicted in this manual as follows:
2
DANGER
Highly likely to cause death or serious injury.
WARNING
Can cause serious injury or death.
CAUTION
Can or will cause minor or moderate injury or damage.
Safety precautions
■ Important instructions are categorized and depicted in this manual as follows:
(Following symbols are examples of Pictograms.)
Warning (caution) symbol followed by prohibited matters.
Warning (caution) symbol followed by instructions that should be
followed or precautions that should be observed.
3
Features
Satellite Wave-GPS
Receives location and time
information sent from GPS satellites
and adjusts the time and calendar on
the watch automatically.
Light-Level Indicator
Indicates current power generation
amount in 7 levels.
It can be used as a reference for
choosing a good charging place.
4
* “Eco-Drive” is an original technology of Citizen.
• Eco-Drive
Never needs a new battery.
This watch is fueled by light.
• World time
Indicates the time around the
world by choosing one of 40
time zones.
• ±5-second average monthly
accuracy
Keeps high accuracy without
time signal reception.
• Perpetual calendar
No need for monthly and
leap-year date correction until
February 28, 2100.
CONTENTS
7
Setting the world time. . . . . . .
24
11
Charging your watch. . . . . . . . . 12
Receiving time
information . . . . . . . . . . . . . . .
34
Before using this watch . . . . . . .
Band adjustment. . . . . . . . . . . . . . . 8
Protective stickers. . . . . . . . . . . . . . 8
How to use a specially designed
crown/button. . . . . . . . . . . . . . . . 9
Component identification. . . .
Checking the current power
reserve and power generation
amount . . . . . . . . . . . . . . . . . . . . . . 18
Obtaining location information
from satellite signal. . . . . . . . . . . 31
Setting the time zone
manually. . . . . . . . . . . . . . . . . . . . . 33
Checking the previous
reception result of the satellite
signal. . . . . . . . . . . . . . . . . . . . . . . . 42
Switching daylight saving time
and standard time. . . . . . . . . . 44
5
CONTENTS
Information on satellite signal
reception. . . . . . . . . . . . . . . . . . 46
Checking and adjusting leap
second setting . . . . . . . . . . . . . 52
Checking and adjusting the
rollover number setting. . . . . 55
Adjusting the time and calendar
manually. . . . . . . . . . . . . . . . . . 58
Checking and correcting the
reference position. . . . . . . . . . 62
Troubleshooting. . . . . . . . . . . .
6
66
Eco-Drive watch handling
precautions. . . . . . . . . . . . . . .
74
Water resistance. . . . . . . . . . . . 76
Precautionary items and usage
limitations . . . . . . . . . . . . . . . . 78
Specifications . . . . . . . . . . . . . .
86
Before using this watch
After unpacking, the following must be done before using the watch:
1 Checking the current power reserve (page 12)
2 Setting the world time (page 24)
3 Receiving the satellite signal (page 46)
This watch has a rechargeable cell which is charged by
exposing the dial to light.
Expose the dial to direct sunlight regularly to charge the
watch.
For details of charging, see pages 12.
• Especially, satellite signal reception is power-consuming.
Be sure to keep your watch sufficiently charged.
7
Before using this watch
Band adjustment
We recommend seeking the assistance of an experienced watch technician
for sizing of your watch. If adjustment is not done correctly, the bracelet may
unexpectedly become detached leading to loss of your watch or injury.
Consult your nearest authorized Citizen service center.
Protective stickers
Be sure to remove any protective stickers that may be on your watch (case back,
band, clasp, etc.). Otherwise, perspiration or moisture may enter the gaps between
the protective stickers and the parts, which may result in a skin rash and/or
corrosion of the metal parts.
8
Before using this watch
How to use a specially designed crown/button
Some models are equipped with a specially designed crown and/or push button to
prevent accidental operation.
Screw down crown/button
Unlock the crown/button prior to operate your watch.
Unlock
Lock
Screw down
crown
Rotate the crown
counterclockwise until
it releases from the case.
Push the crown in to the
case. With gentle pressure
towards the case, rotate
the crown clockwise to
secure it to the case. Be
sure to tighten firmly.
Screw down
push button
Rotate the locking screw
counterclockwise, and
loosen until it stops.
Rotate the locking screw
clockwise, and tighten
firmly.
9
Before using this watch
Recessed button
Use a thing with a thin end to press and release the button.
• Metal objects may cause marring or scratching of
the button.
10
Component identification
RX-TME/RX-GPS:
Reception-in-progress
indication
OK/NO: Reception
result indication
Button
Minute
hand
Hour hand
Function hand
• Day indication
• Power reserve level
scale (5 levels)
• Daylight saving time
(SMT ON/OFF)
Place name/
time zone
Crown
Date
indication
Button
Second
hand
• The illustrations in this instruction manual may differ from the actual appearance
of your watch.
• A solar cell is under the dial.
11
Charging your watch
This watch has a rechargeable cell which is charged by
exposing the dial to light, such as direct sunlight or fluorescent
lamps (refer to page 16 for charging guidelines).
For optimal performance, be sure to:
• Put the watch in a location where the dial is exposed to bright
light such as by the window even when it is not used.
• Expose its dial to direct sunlight for 5 or 6 hours at least
every half-a-month.
• Avoid leaving it in dark places for long periods of time.
12
Charging your watch
CAUTION
• This watch contains a large-capacity rechargeable cell for performing powerconsuming satellite signal reception. This large capacity cell takes more time to
charge than those found in other Eco-Drive watches.
• If the surrounding temperature falls below 0°C (32°F) or exceeds 40°C (104°F),
the “Charge suspension temperature detection function” will activate and
charging will not be possible.
• Do not charge the watch at a high temperature (about 60°C (140°F) or higher)
as doing so may cause movement malfunction.
• If the watch is obscured from light by long sleeves frequently, supplemental
charging may be needed to ensure continual operation.
• The watch stops charging automatically after finishing (overcharging prevention
function). The function prevents damage to performance of the watch and
rechargeable cell due to overcharging.
13
Charging your watch
When the watch reaches a low charge state
(insufficient charge warning function)
When the power reserve becomes low, the second hand
moves once every two seconds. This is the insufficient charge
warning function. Be sure to fully charge your watch as
outlined on page 16.
• When the watch is sufficiently charged, the second hand
will move normally.
• If you do not charge the watch for 5 days or longer after the insufficient charge
warning movement has begun, the watch will be depleted of all power and stop.
CAUTION
• If you do not charge the watch for 30 days after it has stopped, recharging will
not be possible (over discharge detection function).
Consult your nearest authorized Citizen service center if no hands start to move
even after charging a stopped watch for one day or more exposing to direct
sunlight.
14
Charging your watch
During the insufficient charge warning state
The time and date is indicated correctly.
Operations below are available:
• Checking power generation amount
• Setting the world time
• Adjusting the time and calendar manually
You cannot execute operations other than above such as obtainment of location
information or reception of satellite signals.
15
Charging your watch
Charging time by environment
Below are the approximate charging times when exposing to light continuously.
Please use this table as a reference only.
Environment
Illuminance (lx)
Outdoors (sunny)
Outdoors
(cloudy)
20 cm (8 inches)
away from a
fluorescent lamp
(30 W)
100 000
Interior lighting
Charging time (approx.)
To start working
To become fully
To work for one day normally when the charged when the cell
cell is discharged
is discharged
3 minutes
4.5 hours
30 hours
10 000
25 minutes
45 hours
300 hours
3 000
1.5 hours
160 hours
1040 hours
500
7.5 hours
−
−
• Exposing to direct sunlight is recommended to charge your watch. A fluorescent
lamp or interior lighting does not have sufficient illumination to charge the
rechargeable cell efficiently.
16
Charging your watch
Power save function
The hour, minute, and second hands stop automatically to save power as 3 days
passed after stopping power generation.
• The watch is still running internally to keep the time and calendar correctly even
after the power save function has activated.
• The power save function does not activate when the position of the crown is
or .
• The power save status ends and the hands return to indicate the current time as
the watch is operated or the dial is exposed to light and power generation starts.
Duration without additional charging after charging the watch fully
About 2 years in normal use.
• When receiving time signals every 6 days.
• The watch will keep running internally for up to 7 years with the power save
function.
17
Charging your watch
Checking the current power reserve and power generation amount
Always care about the current power reserve and charging environment of the
watch to be sure it is charged sufficiently.
Indication of power generation
amount in levels
Indication of power reserve
in levels
0
1
4
2
3
2
3
1
Function hand
4
0
6
18
5
Hour, minute and
second hands
Charging your watch
1 Push the crown in to position .
2 Press and release the upper right button
.
3 Press and release the upper right button
to
The power reserve and power generation amount at the
moment of pressing the button are indicated in levels.
• Power reserve level: page 20
• Level of power generation amount: page 22
finish the procedure.
The hands returns to current time indication.
• They returns to current time indication automatically
in about 10 seconds.
19
Charging your watch
Indication of power reserve in levels
Level
4
3
2
1
0
Power reserve
level scale
Duration
(approx.)
Meaning
24 - 19 months 19 - 14 months 14 - 5 months
5 months 5 days
Power reserve
Power reserve is OK.
is sufficient.
Insufficient
Power reserve
charge warning
is getting low.
has started.
OK for normal use
20
5 days or
shorter
Charge immediately.
Charging your watch
CAUTION
• At the level 0, the second hand starts to move once every two seconds
(insufficient charge warning function, page 14). Some functions become
unavailable while the function is activated. For details, see page 15.
• The function hand points to “OFF” and does not indicate the level of power
reserve when temperature of the watch is too high or too low.
(non-chargeable state)
Check it again at a location of suitable temperature.
21
Charging your watch
Indication of power generation amount in levels
The level of power generation amount means power being generated by the solar
cell represented in 7 levels (0 - 6).
Level
6
5
4
3
2
1
0
Level scale
of power
generation
amount
Meaning
22
Sufficient power
generation for
charging.
Charge in a brighter location where the level of power
generation amount reaches “5” or “6”.
Charging your watch
CAUTION
• The level of power generation amount indicated is that of the moment you
engage this function. The level indication does not reflect any change in power
generation after engaging this function.
• The level may vary even under the same brightness due to the entry angle
of light to the dial of the watch or other elements. The level may also vary
depending on difference of models.
• The indication level “6” of power generation amount corresponds to generation
in cloudy outdoors (about 10 000 lx illuminance) or a brighter location.
• Use the level of power generation shown as general reference only.
23
Setting the world time
This watch can indicate the time around the world according to which of 40 time
zones (offsets from UTC—Coordinated Universal Time) is chosen.
You can set offsets from UTC through any of the two ways below.
Method
What to set
Obtaining location information A time zone is set automatically and time and
from satellite signal (page 31) calendar are adjusted based on the chosen zone.
Setting the time zone manually
A time zone is chosen manually.
(page 33)
• Daylight saving time information is not contained in the satellite signal. Adjust the
setting manually before and after the daylight saving time period (page 44).
24
Setting the world time
How to read indication of the world time setting
The watch has 40 time zone markers with several representative area names. A time
zone is set by pointing the second hand at one of the markers.
Time zone markers
Second hand
In the illustration on the left, the second hand
points to 28 seconds and time zone setting is
“+11.5”.
• Time zones are represented by offsets from
UTC.
• Time zone markers and area names may
differ from the illustration in some models.
Representative area
names
25
Setting the world time
Table of time zones and representative places
• Countries or regions may change time zones for various reasons.
(Based on information as of January 2015)
26
Time zone
Second hand
Area name
0
0 sec.
LON
London
Representative area
+1
2 sec.
PAR
Paris
+2
4 sec.
ATH
Athens
+3
6 sec.
RUH
Riyadh
+3.5
7 sec.
—
Tehran
+4
8 sec.
DXB
Dubai
+4.5
9 sec.
—
Kabul
+5
10 sec.
KHI
Karachi
+5.5
12 sec.
DEL
Delhi
+5.75
13 sec.
—
Kathmandu
Setting the world time
Time zone
Second hand
Area name
Representative area
+6
14 sec.
DAC
Dhaka
+6.5
15 sec.
—
Yangon
+7
16 sec.
BKK
Bangkok
+8
18 sec.
+8.75
20 sec.
—
Eucla
+9
21 sec.
TYO
Tokyo
+9.5
23 sec.
ADL
Adelaide
+10
25 sec.
SYD
Sydney
+10.5
26 sec.
—
+11
27 sec.
NOU
+11.5
28 sec.
—
+12
29 sec.
AKL
+12.75
31 sec.
—
BJS (HKG) Beijing/Hong Kong
Lord Howe Island
Noumea
Norfolk Island
Auckland
Chatham Islands
27
Setting the world time
28
Time zone
Second hand
Area name
+13
+14
-12
-11
-10
-9.5
-9
-8
-7
-6
-5
-4.5
-4
-3.5
32 sec.
34 sec.
36 sec.
38 sec.
40 sec.
41 sec.
42 sec.
44 sec.
46 sec.
48 sec.
50 sec.
51 sec.
52 sec.
53 sec.
TBU
—
—
MDY
HNL
—
ANC
LAX
DEN
CHI
NYC
—
SCL
—
Representative area
Nuku‘alofa
Kiritimati
Baker Island
Midway
Honolulu
Marquesas Islands
Anchorage
Los Angeles
Denver
Chicago
New York
Caracas
Santiago
St. John’s
Setting the world time
Time zone
Second hand
Area name
Representative area
-3
54 sec.
RIO
Rio de Janeiro
-2
56 sec.
FEN
Fernando de Noronha
-1
58 sec.
PDL
Azores
29
Setting the world time
• The offsets in the table are based on the standard time.
• When choosing a time zone for a country or area that observes summer time
during the summer period, first apply its time zone then activate the summer
time setting (page 44).
30
Setting the world time
Obtaining location information from satellite signal
It is recommended to receive the satellite signals outdoors with the wide-open sky.
For details, see “Information on satellite signal reception” (page 46).
A time zone is set automatically by obtaining location information and time and
calendar are consequently adjusted based on the chosen zone.
• It may take 30 seconds - 2 minutes to obtain location information.
1 Push the crown in to position .
2 Press and hold the upper right button
until the second hand points “RX-GPS”
(about 4 seconds).
The current time zone setting is indicated and
signal reception starts.
31
Setting the world time
After finishing the reception, the second hand indicates the new setting and returns to
indicate the second.
• To cancel the reception, press and hold any button until the second hand returns
to indicate the second.
About obtaining location information
The time zone may not set appropriately when location information is obtained in
a border of time zones, even if the information is correct.
• You can also execute time zone setting manually. (page 33)
32
Setting the world time
Setting the time zone manually
1 Pull the crown out to position
.
The second hand indicates the current time zone and
the function hand indicates the daylight saving time
setting (page 44).
2 Rotate the crown to choose a time zone.
Time indication changes.
• See also “How to read indication of the world time
setting” on page 25 and “Table of time zones and
representative areas” on page 26 for time zone
setting.
3 Push the crown in to position
procedure.
to finish the
The second hand returns to indicate the second.
33
Receiving time information
It is recommended to receive the satellite signals outdoors with the wide-open sky.
For details, see “Information on satellite signal reception” (page 46).
You can use the three types of reception below to receive time information. You can also
check the result of the previous reception (success or fail). (page 42)
Type
Time reception
(page 36)
Leap second reception
(page 38)
Automatic time reception
(page 40)
34
Use
Time required (approx.)
Normal reception for time
3 - 30 seconds
and calendar adjustment
Reception when the leap
second has been updated
36 seconds - 13 minutes
Reception executed
automatically when some 3 - 30 seconds
conditions are fulfilled.
Receiving time information
• Location information is not obtained while receiving time information. Execute
world time setting (page 24) beforehand.
35
Receiving time information
Time reception (time required: about 3 - 30 seconds)
Reception for time and calendar adjustment.
• It may take more time for reception when difference in time is large or calendar
was set manually.
1 Push the crown in to position .
2 Press and hold the lower right button
until
the second hand points “RX-TME” (about 2 seconds).
The previous reception result is first indicated and
signal reception starts.
• To cancel the reception, press and hold any button
until the second hand returns to normal movement.
36
Receiving time information
After finishing reception, the second hand indicates the reception result (page 42)
for 2 seconds and returns to normal movement.
When the time or calendar is incorrect even after successful reception
Check the settings of world time (page 24) and daylight saving time (page 44).
If the time or calendar is still incorrect after that, execute leap second reception
(page 38). The leap second may be updated.
• Daylight saving time information is not contained in the satellite signal.
37
Receiving time information
Leap second reception (time required: about 36 seconds - 13 minutes)
Reception to be executed when the leap second has been updated.
• You can also execute leap second setting manually. (page 52)
1 Push the crown in to position .
2 Press and hold the lower right button
7 seconds.
for
Reception starts after the second hand points “RX-TME”
and turn fully around to points “RX-TME” again.
• To cancel the reception, press and hold any button
until the second hand returns to normal movement.
38
Receiving time information
After finishing reception, the second hand indicates the reception result (page 42)
for 2 seconds and returns to normal movement.
When the time or calendar is incorrect even after successful reception
Check the settings of world time (page 24) and daylight saving time (page 44).
• Daylight saving time information is not contained in the satellite signal.
39
Receiving time information
Automatic time reception
The watch starts time reception automatically when the conditions below are
fulfilled:
• The watch has not received satellite signals for 6 or more days.
• The watch dial is being exposed to strong direct sunlight for 20 seconds or more.
• The time on it is between 6:00AM and 6:00PM.
• The second hand does not move in two-second interval (page 14).
40
Receiving time information
About automatic time reception
Automatic time reception may be delayed in the following cases:
• The second hand started to move once every two seconds (insufficient charge
warning) after the last time reception.
Automatic time reception is executed 6 days or more after the insufficient charge
warning stopped by charging the watch.
• Time zone setting was changed.
Automatic time reception is executed 6 days or more after the moment of the
changing of the setting.
41
Receiving time information
Checking the previous reception result of the satellite signal
1 Push the crown in to position .
2 Press and release the lower right button
The previous reception result is indicated.
OK
Reception was successful.
NO
Reception failed.
.
• The indication shows the result of the last reception,
regardless types of received information or
information of location or time.
42
Receiving time information
3 Press and release the lower right button
to finish the procedure.
The hands returns to current time indication.
• They returns to current time indication automatically in about 10 seconds.
About the reception result
The previous reception result is stored for 6 days and “NO” is indicated after that.
43
Switching daylight saving time and standard time
Daylight saving time is a system adopted in some countries/areas to gain an extra
daylight during summer.
This watch can display the daylight saving time or the standard time according to
the area selected for world time.
• Daylight saving time information is not contained in the satellite signal. Adjust
the setting manually before and after the daylight saving time period.
• The daylight saving time period varies depending on the country or area.
• The daylight saving time rules may change depending on the country or area.
44
Switching daylight saving time and standard time
1 Pull the crown out to position
.
The second hand indicates the current world time
setting and the function hand indicates the current
daylight saving time setting.
2 Press and release the lower right button
SMT ON
The daylight saving time is
indicated.
.
SMT OFF
The standard time is indicated.
• Each time you press the button, ON and OFF changes
alternately.
3 Push the crown in to position
procedure.
to finish the
The second hand returns to indicate the second.
45
Information on satellite signal reception
This watch receives time information from satellites to indicate the time and
calendar.
It also obtains location information from them to indicate time appropriate in the
area where it is actually used.
For receiving the satellite signal
Satellite signal reception is power-consuming. Be sure your watch has a sufficient
charge before executing reception.
• This watch keeps moving in average monthly accuracy of ±5 seconds even
without receiving the satellite signal.
• Use the function to see the result of the previous reception (success or fail) (page
42) effectively to try to execute reception in best frequency.
46
Information on satellite signal reception
Cautions regarding receiving the satellite signal
Do not perform signal reception while operating a vehicle as doing so is
extremely dangerous.
• If the second hand is moving once every two seconds (insufficient charge warning
function), you cannot perform satellite signal reception. Charge the watch
sufficiently before attempting signal reception.
• Even when this watch receives the signal successfully, the accuracy of the
displayed time will be dependent on the reception environment and internal
processing.
47
Information on satellite signal reception
• The automatic correction feature of this watch is supported until 28/2/2100.
• Summer time information is not contained in the satellite signal. Adjust the
setting manually before and after the summer time period. (page 44)
48
Information on satellite signal reception
When receiving the satellite signal
As shown in the picture below, make sure you are in an area with few surrounding
trees, buildings, or other objects which may obstruct the satellite signal. Face the
dial towards the sky and perform signal reception.
• For successful reception there should be
a clear view of the sky as depicted in the
illustration when attempting to receive
the satellite signal.
• Reception may fail due to the positions
of satellites when you try to receive their
signals.
49
Information on satellite signal reception
Receiving signals indoors near a window
Place the watch near a window with a wide view of the sky and orient the dial in an
obliquely upward direction to the sky.
• Signal reception from some satellites is required
for obtaining location information. It is possible
that location information cannot be obtained
while time information can be received in the
same place.
Outdoor signal reception is recommended for
obtaining location information.
• It may be difficult to receive satellite signals
through special types of window glass.
50
Information on satellite signal reception
Poor reception areas
It may be difficult to receive the satellite signal under certain environmental
conditions or in certain areas.
Areas with obstructions above the watch
• Indoors or underground
• Areas surrounded by tall buildings or trees
• When the weather is cloudy or rainy, or
during a thunderstorm
etc.
Nearby objects which emit magnetism or
electrical interference
• High-voltage electric cables, railway lines /
overhead cables, airports, and transmission
facilities.
• Electrical appliances and OA equipment
• Mobile telephones in the process of calling/
transmitting
• Mobile telephone base stations
etc.
51
Checking and adjusting leap second setting
This watch displays the time by applying the leap second to the International
Atomic Time information received from satellites.
The leap second may be applied once per some years and the leap second setting on the
watch must be adjusted each time it applied.
• The leap second setting can be adjusted by executing leap second reception (page
38). It can also be set manually.
You can find a list of leap seconds at the homepage of IERS (INTERNATIONAL
EARTH ROTATION & REFERENCE SYSTEMS SERVICE).
http://hpiers.obspm.fr/eop-pc/earthor/utc/TAI-UTC_tab.html
52
Checking and adjusting leap second setting
1 Pull the crown out to position
.
The second hand points to the 0 second.
2 Press and hold upper right button
2 seconds or more.
for
Using 0 minute/second position as the starting point,
the minute and second hands indicate the leap second
setting.
When the leap second setting is When the leap second setting is
“-36 seconds”
“-65 seconds”
The hands point to “0 minute
36 seconds”.
The hands point to “1 minute 5
seconds”.
53
Checking and adjusting leap second setting
3 Turn the crown to adjust the setting if the leap
second is not correct.
• Adjustable range is from 0 to ‒90 seconds.
4 Push the crown in to position
procedure.
54
to finish the
Checking and adjusting the rollover number setting
In order for this watch to correctly process the week information* received from
the satellite, a rollover number for each time period is set. The rollover numbers are
normally updated automatically.
If the rollover number setting is incorrect, the time and date may not be indicated
accurately. Check the rollover number setting and adjust it if it is incorrect.
* Called “Week number”. Weeks are represented with numbers from 0 to 1023 (approx. 20year cycle).
55
Checking and adjusting the rollover number setting
1 Pull the crown out to position
The second hand points to 0 second.
.
2 Press and hold upper right button
2 seconds or more.
for
The second and minute hands indicate the leap second
setting.
3 Press and hold the upper right button
7 seconds or more.
for
The second hand indicates the current rollover number
setting.
Rollover number
56
0 1 2 3 4 5
Checking and adjusting the rollover number setting
4 Turn the crown to adjust the setting if it is not
correct.
• Adjustable range is from “0” to “5”.
• See the table below and set the correct rollover
number.
5 Push the crown in to position
procedure.
Time period (Coordinated Universal Time, GMT)
22/8/1999 (Sun) 0:00 –
7/4/2019 (Sun) 0:00 –
21/11/2038 (Sun) 0:00 –
7/7/2058 (Sun) 0:00 –
20/2/2078 (Sun) 0:00 –
6/10/2097 (Sun) 0:00 – 22/5/2117 (Sat) 23:59
to finish the
Rollover number
0
1
2
3
4
5
57
Adjusting the time and calendar manually
• Execute world time setting (page 24) beforehand.
1 Pull the crown out to position .
2 Press and hold the upper right button
until
the second hand points to the 30 seconds position.
3 Pull the crown out to position .
The second hand points to 0 second.
4 Press and release the lower right button
repeatedly to change the hand/indication to be
corrected.
• Each time you press the button, the target changes as
follows:
Minute hand → hour hand → date → year/month → day
→ (back to the top)
• The hands and indications slightly moves when
selected to show they become adjustable.
58
Adjusting the time and calendar manually
5 Rotate the crown to adjust the hand/indication.
• Year and month are indicated with the second hand.
Set them referring to the next page.
• The function hand rotates 5 times for each change of
date.
• When you rotate the crown quickly a few times, the
hand/indication will move continuously. To stop the
rapid movement, rotate the crown in either direction.
6 Repeat steps 4 and 5.
7 Push the crown in to position
in accordance
with a reliable time source to finish the procedure.
The second hand starts moving from 0 second.
59
Adjusting the time and calendar manually
Month and year indications
Set the year and month with the position of the second hand.
“Month” corresponds to one of the 12
zones shown in the figure below.
Each number means month.
Years since leap year:
0 (Leap year)
12
11
1
10
2
9
3
8
7
60
4
6
“Year” corresponds to the years since
leap year and indicated with markers in
the zone of each month.
5
Years since leap year: 1
Years since leap year: 2
Years since leap year: 3
0
1
2
3
Adjusting the time and calendar manually
Actual year
Years since leap
year
Second hand position
—
2016 2020 2024
0 (Leap year)
Hour marker
—
2017 2021 2025
1
1st min. marker
—
2018 2022 2026
2
2nd min. marker
2015 2019 2023 2027
3
3rd min. marker
Examples: Position of the second hand
when setting September 2015
You can find that the years since leap
year of 2015 is “3” from the table and
the second hand must be set to the 3rd
minute marker of September zone.
61
Checking and correcting the reference position
If the time or calender is not shown correctly even after proper reception of the
time signal, check whether the reference position is correct.
• If the hands and indication do not reflect the correct reference position, the time
and calendar will not be indicated accurately even if the satellite signal is received.
What is the reference position?
The base position of all hands and calendar to
properly indicate the various functions of this watch.
• Position of the hour hand: 0 hour
• Position of the minute hand: 0 minute
• Position of the second hand: 0 second
• Position of date: midway between 31 and 1
• Position of day: S (Sunday)
62
Correct reference positions
Checking and correcting the reference position
1 Pull the crown out to position .
2 Press and hold the lower right button
4 seconds.
for
The hands and date start to move to the current
reference positions stored in memory.
• Release the button as the hands start to move.
• Some hands shows special movement to adjust their
position.
3 Check the current reference position.
Refer to the figure on the previous page.
Correct
Wrong
Push the crown in to position and press and
to finish the
release the lower right button
procedure.
Proceed to step 4 in the next page and correct
the reference position.
63
Checking and correcting the reference position
4 Press and release the lower right button
The function hands move slightly.
.
5 Press and release the lower right button
repeatedly to change the hand/indication to be
corrected.
• Each time you press the button, the target changes as
follows:
Date/day → hour hand → minute hand →
second hand → (back to the top)
• The hands slightly moves when selected to show they
become adjustable.
6 Rotate the crown to adjust the hand/indication.
• When you rotate the crown quickly a few times, the
hand/indication will move continuously. To stop the
rapid movement, rotate the crown in either direction.
64
Checking and correcting the reference position
7 Repeat steps 5 and 6.
8 Push the crown in to position .
9 Press and release the lower right button
finish the procedure.
to
• The watch returns automatically to the time
indication as about 2 minutes passed without any
operation.
65
Troubleshooting
If you have a problem with your watch, check the items below.
Symptom
Remedies
Page
When the second hand moves once every two
seconds, the watch cannot receive the signal. Charge
the watch.
15
Avoiding places where the satellite signal may be
obstructed and objects which emit noise. Face the
dial towards the sky and start reception.
51
Remove the watch from your wrist and try again.
−
It may sometimes be difficult to receive the signal
due to the influence of mobile telephone base
stations or transmission facilities. Move away from
any base stations and transmission facilities.
51
Problems with satellite signal reception
Reception is
unsuccessful.
66
Troubleshooting
Symptom
Remedies
Page
Problems with satellite signal reception (continued)
Reception is
unsuccessful.
The correct time
and calendar are
not indicated after
successful reception.
If the remedies above do not solve the problems,
consult your nearest Customer Service Center.
−
Check the world time setting.
24
Check the daylight saving time setting.
44
Execute leap second reception if the time and
calendar is still incorrect even after executing time
reception.
38
Check and adjust the settings of leap second and
rollover number.
Check and correct the reference position.
52,55
62
67
Troubleshooting
Symptom
Remedies
Page
Charging may be stopped (non-chargeable state).
Check it again at a location of suitable temperature.
21
Charge the watch.
12
Movement of a hand seems strange
The power reserve is not
indicated.
The second hand moves
once every two seconds.
The second hand does not
move.
No hands move.
68
Push the crown in to position
.
−
Push the crown in to position
release the upper right button
and press and
.
58
Charge the watch in direct sunlight until the
second hand moves normally.
16
If the remedies above do not solve the problems,
consult your nearest Customer Service Center.
−
Troubleshooting
Symptom
Remedies
Page
Time/calendar is abnormal.
Check the world time setting.
24
Check the daylight saving time setting.
44
Receive the satellite signal to adjust the time and
Time/calendar is incorrect.
calendar.
Time is incorrect even
though the world time
setting is correct and
reception of the satellite
signal succeeded.
34
Check and correct the reference position.
62
Adjust the time and calendar manually.
58
Check the daylight saving time setting.
44
Check and correct the leap second setting.
52,55
Check and correct the reference position.
62
69
Troubleshooting
Symptom
Remedies
Page
Charging and other problems
The watch does not
work even though it is
charged.
70
If the surrounding temperature falls below 0°C (32°F)
or exceeds 40°C (104°F), the “Charge suspension
temperature detection function” will activate and
charging will not be possible.
If the “Over discharge detection function” is activated,
charging is not possible. If the watch does not work
after exposing the dial to direct sunlight for more than
one day, it is possible that the rechargeable cell has over
discharged. Consult your nearest Customer Service
Center.
13
14
Troubleshooting
Symptom
Remedies
Page
Charge the watch for 2 to 3 days in direct sunlight. If
the second hand starts moving once every two seconds
the watch is being charged correctly. Continue charging
even when the second hand starts moving normally. If
no change can be seen, consult your nearest Customer
Service Center.
−
Charging and other problems (continued)
The watch stops
immediately after it is
charged.
71
Troubleshooting
Resetting the watch — All Reset
When the watch does not work properly, you can reset all the settings. If the power
reserve is insufficient, charge the watch first.
Be sure to perform the following operations after All Reset.
1.Correct the reference positions.
After the All Reset, the watch is in the reference position adjustment mode.
Refer to step 4 and after on page 64.
2 Set the world time.
Obtaining location information: See page 24.
When you set it manually, execute also time and calendar setting
(page 34 or 58).
72
Troubleshooting
1 Pull the crown out to position .
2 Press and hold buttons and at the same
time for 3 seconds or more and release them.
As you release the buttons, the hands move slightly to
indicate that reset completed.
The setting values after All Reset
January of leap year (5-second position)
Calendar
Time zone (offset) 0 (LON), London
World time
Daylight saving time OFF at all time zones
Leap seconds
No change after All Reset
Rollover number
73
Eco-Drive watch handling precautions
<Always Make Sure to Recharge Frequently>
• For optimal performance, your watch should remain fully charged.
• L ong sleeves may inhibit light transmission to your watch.
This may result in your watch loosing charge. In these cases supplemental charging
may be necessary.
• When you take off the watch, place it in a bright location to ensure optimal performance.
CAUTION
Recharging Precautions
• Do not charge the watch at a high temperature (about 60°C (140°F)
or higher) as doing so may cause the movement to malfunction.
Examples:
• Charging the watch too close to a light source which generates
a large amount of heat such as an incandescent lamp or halogen
lamp.
* When charging under an incandescent lamp, be sure to leave 50
cm (20 inches) or more between the lamp and the watch to avoid
exposing the watch to excessive heat.
• Charging the watch in a location where the temperature may
become extremely high such as on the dashboard of a vehicle.
74
Eco-Drive watch handling precautions
<Replacement of Rechargeable Cell>
t5IJTXBUDIVUJMJ[FTBTQFDJBMSFDIBSHFBCMFDFMMUIBUEPFTOPUSFRVJSFQFSJPEJDBMSFQMBDFNFOU
)PXFWFSQPXFSDPOTVNQUJPONBZJODSFBTFBGUFSVTJOHUIFXBUDIGPSBOVNCFSPGZFBSTEVF
UPXFBSPGJOUFSOBMDPNQPOFOUTBOEEFUFSJPSBUJPOPGPJMT5IJTNBZDBVTFTUPSFEQPXFSUP
CFEFQMFUFEBUBGBTUFSSBUF'PSPQUJNBMQFSGPSNBODF XFSFDPNNFOEIBWJOHZPVSXBUDI
JOTQFDUFEFWFSZZFBSTGPSQSPQFSPQFSBUJPOBOEDPOEJUJPODIFDL
WARNING
Handling of Rechargeable Cell
WARNING
Use Only the Specified Battery
t5IFSFDIBSHFBCMFDFMMTIPVMEOFWFSCFSFNPWFEGSPNUIFXBUDI
*GGPSBOZSFBTPOJUCFDPNFTOFDFTTBSZUPSFNPWFUIFSFDIBSHFBCMFDFMMGSPNUIFXBUDI LFFQ
PVUPGUIFSFBDIPGDIJMESFOUPQSFWFOUBDDJEFOUBMTXBMMPXJOH
*GUIFSFDIBSHFBCMFDFMMJTBDDJEFOUBMMZTXBMMPXFE DPOTVMUBEPDUPSJNNFEJBUFMZ
t%POPUEJTQPTFPGUIFSFDIBSHFBCMFDFMMXJUIPSEJOBSZHBSCBHF1MFBTFGPMMPXUIFJOTUSVDUJPOT
PGZPVSNVOJDJQBMJUZSFHBSEJOHDPMMFDUJPOPGCBUUFSJFTUPQSFWFOUUIFSJTLPGGJSFPS
FOWJSPONFOUBMDPOUBNJOBUJPO
t/FWFSVTFBCBUUFSZPUIFSUIBOUIFSFDIBSHFBCMFDFMMTQFDJGJFEGPSVTFJOUIJTXBUDI
"MUIPVHIUIFXBUDITUSVDUVSFJTEFTJHOFETPUIBUJUXJMMOPUPQFSBUFXIFOBOPUIFSUZQFPG
CBUUFSZJTJOTUBMMFE JGBDPOWFOUJPOBMXBUDICBUUFSZPSPUIFSUZQFPGCBUUFSZJTJOTUBMMFEJO
UIFXBUDIBOEUIFXBUDIJTSFDIBSHFE UIFSFJTUIFSJTLPGPWFSDIBSHJOHXIJDINBZDBVTFUIF
CBUUFSZUPSVQUVSF
5IJTDBODBVTFEBNBHFUPUIFXBUDIBOEJOKVSZUPUIFXFBSFS
8IFOSFQMBDJOHUIFSFDIBSHFBCMFDFMM BMXBZTNBLFTVSFUPVTFUIFEFTJHOBUFESFDIBSHFBCMF
75
DFMM
Water resistance
WARNING
Water Resistance
• Refer to the watch dial and/or the case back for the indication of the water resistance of your
watch. The following chart provides examples of use for reference to ensure that your watch is
used properly. (The unit “1bar” is roughly equal to 1 atmosphere.)
• WATER RESIST(ANT) ××bar may also be indicated as W.R.××bar.
• Non-water resistant models are not designed to come into contact with any moisture. Take
care not to expose a watch with this rating to any type of moisture.
• Water resistance for daily use (to 3 atmospheres) means the watch is water resistant for
occasional accidental splashing.
Name
Specification
Non water-resistant
—
Everyday use water-resistant
watch
WATER RESIST
Water-resistant to 3 atmospheres
W. R. 5 bar
Water-resistant to 5 atmospheres
W. R. 10/20 bar
Water-resistant to 10 or 20
atmospheres
Upgraded everyday use waterresistant watch
76
Indication
Dial or Case back
Non water-resistant
Water resistance
• Upgraded water-resistance for daily use (to 5 atmospheres) means that the watch may be worn
while swimming, but is not to worn while skin diving.
• Upgraded water-resistance for daily use (to 10/20 atmospheres) means that the watch may be
worn while skin diving, but not while scuba or saturated diving using helium gas.
Water-related use
Minor exposure Swimming and
to water (washing general washing
face, rain, etc.)
work
Skin diving,
marine sports
Scuba diving
Saturation diving
using an air tank using helium gas
Operate the crown
or button when
the watch is wet
NO
NO
NO
NO
NO
NO
OK
NO
NO
NO
NO
NO
OK
OK
NO
NO
NO
NO
OK
OK
OK
NO
NO
NO
77
Precautionary items and usage limitations
CAUTION
To Avoid Injury
• Be particularly careful when wearing your watch while holding a small child, to avoid injury.
• Be particularly careful when engaged in strenuous exercise or work, to avoid injury to yourself
and others.
• Do not wear your watch while in a sauna or other location where your watch may become
excessively hot, since there is the risk of burns.
• Be careful when putting on and taking off your watch, since there is a risk of damaging your
fingernails, depending on the manner in which the band is fastened.
• Take off your watch before going to bed.
78
Precautionary items and usage limitations
CAUTION
Precautions
• Always use the watch with the crown pushed in (normal position). If the crown is of the screw
lock-type, make sure it is securely locked.
• Do not operate the crown or any push buttons when the watch is wet. Water may enter the
watch causing damage to vital components.
• If water enters the watch or the watch fogs up and does not clear up even after a long time,
consult your dealer or customer support center for inspection and/or repair.
• Even if your watch has a high level of water resistance, please be careful of the following.
- If your watch is immersed in sea water, rinse thoroughly with fresh water and wipe with a
dry cloth.
- Do not pour water from a tap directly onto your watch.
- Take off your watch before taking a bath.
• If seawater enters the watch, place the watch in a box or plastic bag and immediately take it in
for repair. Otherwise, pressure inside the watch will increase, and parts (crystal, crown, push
button, etc.) may come off.
79
Precautionary items and usage limitations
CAUTION
<Band>
When Wearing Your Watch
• Leather bands and rubber (urethane) bands will deteriorate over time due to perspiration dirt.
Because of the natural materials, leather band will be worn, deformed, and discolored over
time. It is recommended to replace the band periodically.
• The durability of a leather band may be affected when wet (fading, peeling of adhesive), owing
to the properties of the material. Moreover, wet leather may cause a rash.
• Do not stain a leather band with substances containing volatile materials, bleach, alcohol
(including cosmetics). Discoloration and premature aging may be occurred. Ultraviolet light
such as direct sunlight may cause discoloration or deformation.
• It is recommended to take off the watch if it gets wet, even if the watch itself is water-resistant.
• Do not wear the band too tightly. Try to leave enough space between the band and your skin
to allow adequate ventilation.
• The rubber (urethane) band may be stained by dyes or soil present in or on clothing or other
accessories. Since these stains may not be removable, caution is required when wearing
your watch with items that tend to easily transfer color (articles of clothing, purses, etc.). In
addition, the band may be deteriorated by solvents or moisture in the air. Replace with a new
one when it has lost elasticity or become cracked.
80
CAUTION
When Wearing Your Watch Precautionary
(continued) items and usage limitations
• Please request adjustment or repair of the band in the following cases:
- You notice an abnormality with the band due to corrosion.
- The pin of the band is protruding.
• We recommend seeking the assistance of an experienced watch technician for sizing of your
watch. If adjustment is not done correctly, the bracelet may unexpectedly become detached
leading to loss of your watch or injury. Consult your nearest authorized Citizen service center.
<Temperature>
• The watch may stop or the function of the watch may be impaired in extremely high or low
temperature. Do not use the watch in places where the temperature is outside the operating
temperature range as stated in the specifications.
<Magnetism>
• Analog quartz watches are powered by a step motor that uses a magnet. Subjecting the watch
to strong magnetism from the outside can cause the motor to operate improperly and prevent
the watch from keeping time accurately.
Do not allow the watch to come into close proximity to magnetic health devices (magnetic
necklaces, magnetic elastic bands, etc.) or the magnets used in the latches of refrigerator
doors, clasps used in handbags, the speaker of a cell phone, electromagnetic cooking devices
and so on.
81
Precautionary items and usage limitations
<Strong Shock>
• Avoid dropping the watch or subjecting it to other strong impact. It may cause malfunctions
and/or performance deterioration as well as damage to the case and bracelet.
<Static Electricity>
• The integrated circuits (IC) used in quartz watches are sensitive to static electricity. Please
note the watch may operate erratically or not at all if exposed to intense static electricity.
<Chemicals, Corrosive Gasses and Mercury>
• If paint thinner, benzene or other solvents or products containing these solvents (including
gasoline, nail-polish remover, cresol, bathroom cleaners and adhesives, water repellent, etc.)
are allowed to come into contact with the watch, they may discolor, dissolve or crack the
materials. Be careful when handling these chemicals. Contact with mercury such as that used
in thermometers may also cause discoloration of the band and case.
<Protective Stickers>
• Be sure to remove any protective stickers that may be on your watch (case back, band, clasp,
etc.). Otherwise, perspiration or moisture may enter the gaps between the protective stickers
and the parts, which may result in a skin rash and/or corrosion of the metal parts.
82
Precautionary items and usage limitations
CAUTION
Always Keep Your Watch Clean
• Rotate the crown while it is pressed in fully and press the buttons periodically so they do not
become stuck due to accumulations of foreign matter.
• The case and band of the watch come into direct contact with the skin. Corrosion of the metal
or accumulated foreign matter may result in black residue coming from the bracelet when
exposed to moisture or perspiration. Be sure to keep your watch clean at all times.
• Be sure to periodically clean the bracelet and case of your watch to remove accumulated
dirt and foreign matter. In rare circumstances, accumulated dirt, foreign matter may cause
irritation with the skin. If you notice this, discontinue wearing the watch and consult your
physician.
• Be sure to periodically clean foreign matter and accumulated materials from the metal band,
synthetic rubber strap (polyurethane) and/or metal case using a soft brush and mild soap. Be
careful not to allow moisture on the case if your watch is not water resistant.
• Leather bands may become discolored by perspiration or dirt. Always keep your leather band
clean by wiping with a dry cloth.
83
Precautionary items and usage limitations
Caring for Your Watch
• Wipe any dirt or moisture such as perspiration from the case and crystal with a soft cloth.
• For metallic, plastic or synthetic rubber (polyurethane) band, clean it with soap and a soft
toothbrush. Be sure to thoroughly rinse the band after cleaning to remove any soap residue.
• For a leather band, wipe off dirt using a dry cloth.
• If you will not be using your watch for an extended period of time, carefully wipe off any
perspiration, dirt or moisture and store in a proper location, avoiding locations subject to
excessively high or low temperatures and high humidity.
<When Luminous Paint is used for your watch>
The paint on the dial and hands helps you with reading the time in a dark place. The
luminous paint stores light (daylight or artificial light) and glows in a dark place.
It is free from any radioactive substance or any other material harmful to a human body or
environment.
• The light emission will appear bright at first and then diminish as time passes.
• The duration of the light (“glow”) will vary depending on the brightness, types of and
distance from a light source, exposure time, and the amount of the paint.
• The paint may not glow and/or may dissipate quickly if exposure to light was not sufficient.
84
• If you will not be using your watch for an extended period of time, carefully wipe off any
perspiration, dirt or moisture and store in a proper location, avoiding locations subject to
excessively high or low temperatures and high humidity.
Precautionary items and usage limitations
<When Luminous Paint is used for your watch>
The paint on the dial and hands helps you with reading the time in a dark place. The
luminous paint stores light (daylight or artificial light) and glows in a dark place.
It is free from any radioactive substance or any other material harmful to a human body or
environment.
• The light emission will appear bright at first and then diminish as time passes.
• The duration of the light (“glow”) will vary depending on the brightness, types of and
distance from a light source, exposure time, and the amount of the paint.
• The paint may not glow and/or may dissipate quickly if exposure to light was not sufficient.
85
Specifications
Model
Type
Analog solar-powered watch
Average monthly accuracy: ±5 seconds when worn at normal operating
temperatures between +5°C (41°F) and +35°C (95°F)
Operating
temperature range
‒10°C (14°F) to +60°C (140°F)
Display functions
Maximum run time
from full charge
Battery
86
F150
Timekeeping
accuracy
(without reception)
• Time: Hours, minutes, seconds
• Calendar: Date, day
• Power reserve: 5 levels
• Power generation amount:
7 levels
• When fully charged, the watch runs without additional charging
in normal use: Approximately 2 years
(When saving power: Approximately 7 years)
• Power reserve upon insufficient charge warning function:
Approximately 5 days
Rechargeable cell (lithium button cell), 1pc.
Specifications
Additional
functions
• Solar power function
• Overcharging prevention function
• Insufficient charge warning function
(two-second interval movement)
• Over discharge detection function
• Charge suspension temperature
detection function
• Uncharged state indication function
• Power reserve indication (in five
levels)
• Light-Level Indicator (power
generation amount indication
function in seven levels)
• Power save function
• Satellite signal reception function
• Location information obtainment
function
• Confirming reception status
(RX-TME/RX-GPS)
• Indicating the result of the last
reception (OK/NO)
• World time (40 time zones (27
place names))
• Daylight saving time (SMT ON/
OFF)
• Perpetual calendar
(until February 28th, 2100)
• Antimagnetic feature/
Impact detection function/
Automatic hand correction function
(for hour, minute and second hands)
Specifications and contents of this booklet are subject to change without prior
notice.
87
European Union directives conformance statement
Hereby, CITIZEN WATCH CO.,LTD. declares that
this product is in compliance with the essential requirements
and other relevant provisions of directive 1999/5/EC and all
other relevant EU directives.
You can find your product’s Declaration of Conformity at
“http://www.citizenwatch-global.com/ ”.
Model No.CC30*
Cal.F150
CTZ-A8183
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
