Ceramic Glass Hob
User manual
C21RJAN
C21RJAN_EU_DG68-01160A-00_EN.indd 1
1/25/2019 5:54:15 PM
Contents
Contents
Using this manual
3
Residual heat indicator
The following symbols are used in this User Manual:
Model name & serial number
3
3
Hob use
Safety instructions
3
Disposing of the packaging material
Proper disposal of your old appliance
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
7
7
7
Installing the hob
8
Safety instructions for the installer
Connecting to the outlet
Connecting to the mains power supply
Installing into the countertop
Parts and features
Cooking zones
Components
Control panel
The key features of your appliance
Safety shutoff
8
8
9
10
11
11
11
11
12
12
Initial cleaning
Using suitable cookware
Using the touch buttons
Switching the appliance on
Temperature control
Switching the appliance off
Switching a cooking zone off
Using the child safety lock
Timer
Setting the safety shutoff
Countdown timer
Locking and unlocking the control panel
Cleaning and care
Hob
To avoid damaging your appliance
13
13
13
13
14
14
14
15
15
15
16
16
16
17
18
18
19
Warranty and service
20
FAQs and troubleshooting
Service
20
21
Technical data
Technical data
Cooking zones
Product information
21
21
21
22
2 English
C21RJAN_EU_DG68-01160A-00_EN.indd 2
1/25/2019 5:54:16 PM
Safety instructions
Please take the time to read this owner’s manual, paying particular attention to the
safety information contained in the following section, before using your appliance.
Keep this manual for future reference.
If transferring ownership of the appliance, please remember to pass the manual on
to the new owner.
The safety aspects of this appliance comply with all accepted technical and safety
standards. However, as manufacturers we also believe it is our responsibility to
familiarize you with the following safety instructions.
The following symbols are used in this User Manual:
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or property
damage.
CAUTION
To reduce the risk of fire, explosion, electric shock, or personal injury when using
your hob, follow these basic safety precaution.
NOTE
Useful tips, recommendations, or information that helps users manipulate the
product.
Model name & serial number
Both the model name and the serial number are labeled underneath the hob base.
For later use, write down the information or attach the additional product label
(located on the top of the product) onto the current page.
Model Name
Serial Number
WARNING
Children should be supervised to ensure that they do not play
with the appliance.
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
The means for disconnection must be incorporated in the fixed
wiring in accordance with the wiring rules.
English 3
C21RJAN_EU_DG68-01160A-00_EN.indd 3
1/25/2019 5:54:16 PM
Using this manual
Using this manual
Safety instructions
Safety instructions
This Appliance should be allowed to disconnection from the
supply after installation. The disconnection may be achieved by
having the plug accessible or by incorporating a switch in the
fied wiring in accordance with the wiring rules.
The appliance is not intended to be operated by means of an
external timer or separate remote-control system.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified pesons in
order to avoid a hazard.
The appliance must not be installed behind a decorative door in
order to avoid overheating.
The method of fixing stated is not to depend on the use of
adhesives since they are not considered to be a reliable fixing
means.
WARNING: If the surface is cracked, switch off the appliance to
avoid the possibility of electric shock.
CAUTION: The cooking process has to be supervised. A short
term cooking process has to be supervised continuously.
WARNING: The appliance and its accessible parts become hot
during use. Care should be taken to avoid touching heating
elements. Children less than 8 years of age shall be kept away
unless continuously supervised.
During use the appliance becomes hot. Care should be taken to
avoid touching heating elements inside the hob.
WARNING: Unattended cooking on a hob with fat or oil can be
dangerous and may result in a fire.
NEVER try to extinguish a fire with water, but switch off the
appliance and then cover flame e.g. with a lid or a fire blanket.
WARNING: Accessible parts may become hot during use. Young
children should be kept away.
WARNING: Danger of fire: Do not store items on the cooking
surfaces.
A steam cleaner is not to be used.
WARNING: Use only hob guards designed by the manufacturer
of the cooking appliance or indicated by the manufacturer
of the appliance in the instructions for use as suitable or hob
guards incorporated in the appliance. The use of inappropriate
guards can cause accidents.
Metallic objects such as knives, forks, spoons and lids should
not be placed on the hob surface since they can get hot.
After use, switch off the hob element by its control and do not
rely on the pan detector.
The surfaces are liable to get hot during use.
4 English
C21RJAN_EU_DG68-01160A-00_EN.indd 4
1/25/2019 5:54:16 PM
CAUTION
Be sure the appliance is properly installed and grounded by a
qualified technician.
The appliance should be serviced only by qualified service
personnel. Repairs carried out by unqualified individuals may
cause injury or serious malfunction. If your appliance is in need
of repair, contact your local service centre. Failure to follow
these instructions may result in damage and void the warranty.
Flush - mounted appliances may be operated only after they
have been installed in cabinets and workplaces that conform
to the relevant standards. This ensures sufficient protection
against contact for electrical units as required by the essential
safety standards.
If your appliance malfunctions or if fractures, cracks or splits
appear:
• switch off all cooking zones;
• disconnect the hob from the mains supply; and
• contact your local service centre.
If the hob cracks, turn the appliance off to avoid the possibility
of electric shock. Do not use your hob until the glass surface
has been replaced.
Do not use the hob to heat aluminium foil, products wrapped
in aluminium foil or frozen foods packaged in aluminium
cookware.
Liquid between the bottom of the pan and the hob can produce
steam pressure. Which may cause the pan to jump.
Always ensure that the hotplate and the base of the pan are
kept dry.
The cooking zones will become hot when you cook.
English 5
C21RJAN_EU_DG68-01160A-00_EN.indd 5
1/25/2019 5:54:16 PM
Safety instructions
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not
be made by children unless they are older than 8 and supervised.
Keep the appliance and its cord out of reach of children less
than 8 years.
Safety instructions
Always keep small children away from the appliance.
Keep all packaging materials well out of the reach of children,
as packaging materials can be dangerous to children.
Safety instructions
This appliance is to be used only for normal cooking and frying
in the home. It is not designed for commercial or industrial use.
Never use the hob for heating the room.
Take care when plugging electrical appliances into mains
sockets near the hob. Mains leads must not come into contact
with the hob.
Overheated fat and oil can catch fire quickly. Never leave
surface units unattended when preparing foods in fat or oil, for
example, when cooking chips.
Users with Pacemakers and Active Heart Implants must
keep their upper body at a minimum distance of 30 cm from
induction cooking zones when turned on. If in doubt, you
should consult the manufacturer of your device or your doctor.
(Induction hob model only)
Do not attempt to repair, disassemble, or modify the appliance
yourself.
Always turn the appliance off before cleaning.
Clean the hob in accordance with the cleaning and care
instructions contained in this manual.
Keep pets away from the appliance because pets may step on
the controls of the appliance, causing an malfunction.
Turn the cooking zones off after use.
Always keep the control panels clean and dry.
Never place combustible items on the hob, it may cause fire.
There is the risk of burns from the appliance if used carelessly.
Cables from electrical appliances must not touch the hot surface
of the hob or hot cookware.
Do not use the hob to dry clothes.
6 English
C21RJAN_EU_DG68-01160A-00_EN.indd 6
1/25/2019 5:54:17 PM
Disposing of the packaging material
Correct Disposal of This Product (Waste Electrical & Electronic
Equipment)
WARNING
All materials used to package the appliance are fully recyclable. Sheet and hard
foam parts are appropriately marked. Please dispose of packaging materials and
old appliances with due regard to safety and the environment.
WARNING
Before disposing of your old appliance, make it inoperable so that it cannot be a
source of danger. To do this, have a qualified technician disconnect the appliance
from the mains supply and remove the mains lead.
The appliance may not be disposed of in the household rubbish.
Information about collection dates and public refuse disposal sites is available
from your local refuse department or council.
For information on Samsung’s environmental commitments and product specific
regulatory obligations e.g. REACH visit: samsung.com/uk/aboutsamsung/
samsungelectronics/corporatecitizenship/data_corner.html
English 7
C21RJAN_EU_DG68-01160A-00_EN.indd 7
1/25/2019 5:54:17 PM
Safety instructions
Proper disposal of your old appliance
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates
that the product and its electronic accessories (e.g. charger,
headset, USB cable) should not be disposed of with other
household waste at the end of their working life. To prevent
possible harm to the environment or human health from
uncontrolled waste disposal, please separate these items from
other types of waste and recycle them responsibly to promote
the sustainable reuse of material resources.
Household users should contact either the retailer where
they purchased this product, or their local government office,
for details of where and how they can take these items for
environmentally safe recycling.
Business users should contact their supplier and check the
terms and conditions of the purchase contract. This product
and its electronic accessories should not be mixed with other
commercial wastes for disposal.
Installing the hob
WARNING
Be sure the new appliance is installed and grounded only by qualified personnel.
Please observe this instruction. The warranty will not cover any damage that may
occur as a result of improper installation.
Technical data is provided at the end of this manual.
Safety instructions for the installer
•
Installing the hob
•
•
•
•
•
•
•
•
With respect to fire protection, this appliance corresponds to EN 60335 - 2 - 6.
This type of appliance may be installed with a high cupboard or wall on one side.
Drawers may not be fitted underneath the hob.
The installation must guarantee shock protection.
The kitchen unit in which the appliance is fitted must satisfy the stability
requirements of DIN 68930.
For protection against moisture, all cut surfaces are to be sealed with a suitable
sealant.
On tiled work surfaces, the joints in the area where the hob sits must be
completely filled with grout.
On natural, artificial stone, or ceramic tops, the snap action springs must be
bonded in place with a suitable artificial resin or mixed adhesive.
Ensure that the seal is correctly seated against the work surface without any gaps.
Additional silicon sealant must not be applied; this would make removal more
difficult when servicing.
The hob must be pressed out from below when removed.
Connecting to the outlet
Before connecting, check that the nominal voltage of the appliance, that is, the
voltage stated on the rating plate, corresponds to the available supply voltage. The
rating plate is located on the lower casing of the hob.
The heating element voltage is AC 230 V~. This appliance is equipped with a cord
that includes a grounding wire and a grounding plug. The plug must be plugged
into an outlet that is properly installed and grounded.
WARNING
Once the hob is connected to the mains supply, check that all cooking zones are
ready for use by briefly switching each on in turn at the maximum setting with
suit- able cookware.
NOTE
When the hob is powered on for the first time, all displays light and the child
safety lock is activated.
8 English
C21RJAN_EU_DG68-01160A-00_EN.indd 8
1/25/2019 5:54:17 PM
Connecting to the mains power supply
Before connecting, check that the nominal voltage of the appliance, that is, the
voltage stated on the rating plate, corresponds to the available supply voltage. The
rating plate is located on the lower casing of the hob.
WARNING
02
03
L
04
01
220-240 V~
03
Blue
02
Brown
04
Green/Yellow
N
WARNING
For correct supply connection, follow the wiring diagram attached near the
terminals.
Installing the hob
Shut off power to circuit before connecting wires to circuit.
The heating element voltage is AC 230 V~. The appliance also works perfectly on
networks with AC 220 V~ or AC 240 V~. The hob is to be connected to the mains
using a device that allows the appliance to be disconnected from the mains at all
poles with a contact opening width of at least 3 mm, eg. automatic line protecting
cut - out, earth leakage trips or fuse.
1N~ (16A)
01
WARNING
The cable connections must be made in accordance with regulations and the
terminal screws tightened securely.
WARNING
Once the hob is connected to the mains supply, check that all cooking zones are
ready for use by briefly switching each on in turn at the maximum setting with
suitable cookware.
WARNING
Pay attention (conformity) to phase and neutral allocation of house connection and
appliance (connection schemes); otherwise, components can be damaged.
Warranty does not cover damage resulting from improper installation.
WARNING
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
English 9
C21RJAN_EU_DG68-01160A-00_EN.indd 9
1/25/2019 5:54:18 PM
Installing the hob
Installing into the countertop
NOTE
•
•
•
Make a note of the serial number on the appliance rating plate prior to
installation. This number will be required in the case of requests for service
and is no longer accessible after installation, as it is on the original rating
plate on the underside of the appliance.
Pay special attention to the minimum space and clearance requirements.
Secure the brackets at both sides with the provided screws before mounting
the hob onto the brackets.
Installing the hob
G
10 English
C21RJAN_EU_DG68-01160A-00_EN.indd 10
1/25/2019 5:54:18 PM
Parts and features
Control panel
Cooking zones
01 02
03
04
05
06
07
01
02
01
Single cooking zone 1800 W (183 mm)
02
Single cooking zone 1200 W (148 mm)
03
Control panel
Timer button
02
Timer indicator
03
Heat settings and residual heat indicator
04
Lock button
05
Timer setting buttons
06
Heat setting buttons
07
On/Off button
Parts and features
03
01
Components
Installation Brackets
Screws
English 11
C21RJAN_EU_DG68-01160A-00_EN.indd 11
1/25/2019 5:54:19 PM
Parts and features
The key features of your appliance
•
•
•
•
•
Parts and features
•
•
Ceramic glass cooking surface: The appliance has a ceramic glass cooking
surface and four rapid - response cooking zones. The hob’s powerful radiant
heater elements significantly shorten the amount of time required for the
zones to heat up.
Touch buttons: Your appliance is operated using touch buttons.
Easy cleaning: The advantage of the ceramic glass cooking surface and the
control button is their accessibility for cleaning. The smooth, flat surface is
easy to clean.
On/Off button: The On/Off button provides the appliance with a separate
mains switch. Touching this button switches the power supply on or off
completely.
Control and function indicators: Digital displays and indicators provide
information about settings and activated functions, as well as the presence of
residual heat in the various cooking zones.
Safety shutoff: A safety shutoff ensures that cooking zones switch off
automatically after a period of time if the setting has not been changed.
Residual heat indicator: An icon for residual heat appears in the display if the
cooking zone is so hot that there is a risk of burning.
Digital displays
The four display fields are assigned to the four cooking zones.
They show the following information:
•
the appliance has been switched on,
•
to
•
residual heat,
•
the child lock is activated; and
error message, the button has been touched for longer than 10 seconds.
•
•
selected heat settings,
error message, when the Hob is overheated because of abnormal
operation.
Safety shutoff
If one of the cooking zones is not switched off or the heat setting is not adjusted
after an extended period of time, that particular cooking zone will automatically
switch itself off.
Any residual warmth will be indicated with
(for “hot”) in the digital displays
corresponding to the particular cooking zones.
The cooking zones switch themselves off at the following times.
Cooking setting
Switch off
1-2
After 6 hours
3-4
After 5 hours
5-6
After 3 hours
7-9
After 1 hour
NOTE
•
•
If the Hob is overheated because of abnormal operation,
will be
displayed. And the Hob will be switched off.
Should one or more of the cooking zones switch off before the indicated time
has elapsed, see the section FAQs and troubleshooting on page 20.
12 English
C21RJAN_EU_DG68-01160A-00_EN.indd 12
1/25/2019 5:54:20 PM
Parts and features
Hob use
Other reasons why a cooking zone will switch itself off
Initial cleaning
•
•
All cooking zones will immediately switch themselves off if liquid boils over
and lands on the control panel.
The automatic shutoff will also be activated if you place a damp cloth on
the control panel. In both of these instances, the appliance will need to be
switched on again using the On/Off button after the liquid or the cloth has
been removed.
Residual heat indicator
When an individual cooking zone or the hob is turned off, the presence of residual
heat is shown with an
(for “hot”) in the digital display of the appropriate
cooking zones. Even after the cooking zone has been switched off, the residual
heat indicator goes out only after the cooking zone has cooled.
You can use the residual heat for thawing or keeping food warm.
WARNING
As long as the residual heat indicator is illuminated, there is a risk of burns.
•
If the power supply is interrupted, the
symbol will go out and information
about residual heat will no longer be available. However, it may still be
possible to burn yourself. This can be avoided by always taking care when
near the hob.
WARNING
Do not use caustic or abrasive cleaners. The surface could be damaged.
Using suitable cookware
Better pans produce better results.
•
You can recognise good pans by their bases. The base should be as thick and
flat as possible.
•
When buying new pans, pay particular attention to the diameter of the base.
Manufacturers often give only the diameter of the upper rim.
•
Pots with aluminium or copper bases can cause metallic discolouration on
the ceramic glass surface. The discolouration is very difficult or impossible to
remove.
•
Do not use pans which have damaged bases with rough edges or burrs.
Permanent scratching can occur if these pan are slid across the surface.
•
When cold, pan bases are normally bowed slightly inwards (concave). They
should never be bowed outwards (convex).
•
If you wish to use a special type of pan, for example, a pressure cooker, a
simmering pan, or a wok, please observe the manufacturer’s instructions.
English 13
C21RJAN_EU_DG68-01160A-00_EN.indd 13
1/25/2019 5:54:20 PM
Hob use
•
Wipe the ceramic glass surface with a damp cloth and ceramic cooktop glass
cleaner.
Hob use
Switching the appliance on
Energy saving tips
NOTE
You can save valuable energy by observing the following points.
•
•
1.
Touch the Lock button for
approximately 3 seconds.
2.
The appliance is switched on using the
On/Off button. Touch the On/Off
button.
Always position pots and pans before
switching on the cooking zone.
Dirty cooking zones and pan bases
increase power consumption.
•
•
•
Hob use
•
•
When possible, position the lids
firmly on the pots and pans to cover
completely.
Switch the cooking zones off before
the end of the cooking time to use the
residual heat for keeping foods warm
or for thawing.
The base of the pan should be the same
size as the cooking zone.
Using a pressure cooker reduces
cooking times by up to 50 %.
The digital displays will show
.
NOTE
After the On/Off button has been actuated to switch on your appliance, a
heat setting must be selected within approximately 10 seconds. Otherwise, the
appliance will switch itself off for safety reasons.
Temperature control
For setting and adjusting the power
level (
to
) for cooking, touch the
corresponding cooking zone’s
,
buttons.
The first time
is pressed, the heat level
Using the touch buttons
is set to .
The first time
To operate the touch button, touch the desired button with the tip of your pointed
finger until the relevant displays illuminate or go out, or until the desired function
is activated.
Ensure that you are touching only one button when operating the appliance. If
your finger is too flat on the panel, an adjacent button may be actuated as well.
is set to .
Use the
button to increase the heat
setting and the
button to decrease.
is pressed, the heat level
14 English
C21RJAN_EU_DG68-01160A-00_EN.indd 14
1/25/2019 5:54:22 PM
Switching the appliance off
Using the child safety lock
To completely switch off the appliance, use
the On/Off button.
Touch the On/Off button.
You can use the child safety lock to safeguard against unintentionally turning on
a cooking zone and activating the cooking surface. The Lock button can be used
only when the power is on.
Switching the child safety lock on
1.
Touch the Lock button for
approximately 3 seconds.
An acoustic signal will sound as
confirmation.
2.
Touch any Heat setting buttons.
NOTE
•
After switching off a single cooking zone or the entire cooking surface, the
presence of residual heat will be indicated in the digital displays of the
corresponding cooking zones in the form of an
•
•
If more than one button is pressed for longer than 10 seconds,
in the heat setting display. To reset, touch the On/Off button.
will appear in the displays, indicating
the child safety lock has been activated.
will show
Switching a cooking zone off
Hob use
•
(for “hot”).
If the heat setting is at
and you want to turn the burner off, the
button
can be touched one additional time, and the heat setting will go to zero.
For faster adjustment, keep your finger on the
or
button until the
required value is obtained.
Switching the child safety lock off
To switch off a cooking zone, return the
setting to
by using the control panel’s
heat setting and touch the
or
button.
Touch the Lock button for approximately
3 seconds.
An acoustic signal will sound as
confirmation.
English 15
C21RJAN_EU_DG68-01160A-00_EN.indd 15
1/25/2019 5:54:23 PM
Hob use
Timer
There are two ways to use the timer:
Using the timer as a safety shutoff
If a specific time is set for a cooking zone, the cooking zone will shut itself off once
this period of time has elapsed. This function can be used for multiple cooking
zones simultaneously.
To display the time remaining for any of the cooking zones, use the Timer
button. The corresponding control indicator will begin to blink slowly. The settings
are reset using the Timer setting buttons (
or
). After the set period of time
has elapsed, the cooking zone automatically switches itself off, an acoustic signal
sounds as confirmation and the timer display indicates.
NOTE
The countdown timer cannot be used if a cooking zone has been switched on.
To make the settings more quickly, touch any of the Timer setting buttons (
) until the desired value is reached.
If the
button is touched first, the time setting will begin at 99 minutes;
if the
button is touched first, the time setting will begin at 1 minute.
Setting the safety shutoff
Countdown timer
The cooking zone(s) for which you want to apply the safety shutoff must be
switched on.
For the countdown timer to be used, the appliance must be switched on but all the
cooking zones must be switched off.
1. Touch the Timer
button.
will appear in the timer display.
2. Set the desired period of time using the Timer setting buttons (
or
).
The countdown timer function is now activated and the remaining time
appears in the timer display.
To adjust the remaining time, touch the Timer
button and then change the
setting using the Timer setting buttons (
or
).
Using the timer to count down
Using the Timer
button, select the
cooking zone for which the safety
shutoff time is to be set. After the
first active cooking zone is selected,
touching the Timer
button will cause
the corresponding indicator to flash
slowly. For example, the front left
indicator corresponds to the front left
cooking zone.
will appear in the
timer display.
The next active cooking zone is selected
by touching the Timer
button again.
2.
Use the Timer setting buttons (
or
) to set the desired amount of time,
for example, 15 minutes, after which
the cooking zone will automatically
switch itself off. The safety shutoff is
now activated.
Hob use
1.
or
16 English
C21RJAN_EU_DG68-01160A-00_EN.indd 16
1/25/2019 5:54:24 PM
Locking and unlocking the control panel
At any stage during the cooking process, the control panel, with the exception of
the On/Off button, can be locked in order to prevent the settings from being
changed unintentionally, for example, by wiping over the panel with a cloth.
•
•
Suggested settings for cooking specific foods
The figures in the table below are guidelines. The heat settings required for
various cooking methods depend on a number of variables, including the quality
of the cookware being used and the type and amount of food being cooked.
Touch the Lock button for
approximately 3 seconds.
The indicator in the Lock button will
illuminate. The buttons are now locked.
To unlock the buttons, touch the Lock
button again for approximately 3
seconds. The indicator in the Lock
button will turn off.
Switch setting
Cooking method
9
Warming
Sautéing
Frying
Warming large amounts of liquid,
boiling noodles, searing meat, (browning
goulash,braising meat)
7
Intensive
Frying
Steak, sirloin, hash browns, sausages,
pancakes / griddle cakes
6
Frying
Schnitzel / chops, liver, fish, rissoles, fried
eggs
Boiling
Cooking up to 1.5 l liquid, potatoes,
vegetables
8
5
4
3
Examples for Use
Steaming and stewing of small amounts of
vegetables, boiling rice and milk dishes
1
Melting
Melting butter, dissolving gelatine, melting
chocolate
NOTE
•
•
The heat settings indicated in the table above are provided only as guidelines
for your reference.
You will need to adjust the heat settings according to specific cookware and
foods.
English 17
C21RJAN_EU_DG68-01160A-00_EN.indd 17
1/25/2019 5:54:24 PM
Hob use
2
Steaming
Stewing
Boiling
Cleaning and care
Hob
WARNING
Cleaning agents must not come into contact with a heated ceramic glass surface:
All cleaning agents must be removed with adequate amounts of clean water after
cleaning because they can have a caustic effect when the surface becomes hot.
Do not use any aggressiv cleaners such as grill or oven sprays, scouring pads or
abrasive pan cleaners.
NOTE
Clean the ceramic glass surface after each use when it is still warm to the
touch. This will prevent spillage from becoming burnt onto the surface. Remove
scales, watermarks, fat drippings and metallic discolouration with the use of a
commercially available ceramic glass or stainless steel cleaner.
Stubborn soiling
1.
2.
3.
To remove food that has boiled over
and stubborn splashes, use a glass
scraper.
Place the glass scraper at an angle to
the ceramic glass surface.
Remove soiling by scraping with the
blade.
NOTE
Glass scrapers and ceramic glass cleaners
are available from specialty retailers.
Light soiling
1.
2.
3.
Cleaning and care
4.
Wipe the ceramic glass surface with a damp cloth.
Rub dry with a clean cloth. Remnants of cleaning agent must not be left on the
surface.
Thoroughly clean the entire ceramic glass cooking surface once a week with a
commercially available ceramic glass or stainless steel cleaner.
Wipe the ceramic glass surface using adequate amounts of clean water and
rub dry with a clean lint - free cloth.
18 English
C21RJAN_EU_DG68-01160A-00_EN.indd 18
1/25/2019 5:54:24 PM
To avoid damaging your appliance
Problem dirt
1.
Remove burnt-on sugar, melted plastic,
aluminium foil or other materials with
a glass scraper immediately and while
still hot.
•
•
•
WARNING
There is a risk of burning yourself when the
glass scraper is used on a hot cooking zone:
2.
Clean the hob as normal when it has
cooled down.
NOTE
•
•
•
•
English 19
C21RJAN_EU_DG68-01160A-00_EN.indd 19
1/25/2019 5:54:25 PM
Cleaning and care
If the cooking zone on which something has
melted has been allowed to cool, warm it up
again for cleaning.
Scratches or dark blemishes on the ceramic
glass surface, caused, for example, by a
pan with sharp edges, cannot be removed.
However, they do not impair the function of
the hob.
•
Do not use the hob as a work surface or for storage.
Do not operate a cooking zone if there is no pan on the hob or if the pan is
empty.
Ceramic glass is very tough and resistant to temperature shock, but it is
not unbreakable. It can be damaged by a particularly sharp or hard object
dropping onto the hob.
Do not use pans made of cast iron or which have damaged bases with rough
edges or burrs. Scratching may occur if these pans are slid across the surface.
Do not place pans on the hob frame. Scratching and damage to the finish may
occur.
Avoid spilling acidic liquids, for example, vinegar, lemon juice and descaling
agents, onto the hob frame, since such liquids can cause dull spots.
If sugar or a preparation containing sugar comes into contact with a hot
cooking zone and melts, it should be cleaned off immediately with a kitchen
scraper while it is still hot. If allowed to cool, it may damage the surface when
removed.
Keep all items and materials that could melt, for example, plastics, aluminium
foil and oven foils, away from the ceramic glass surface. If something of this
nature melts onto the hob, it must be removed immediately with a scraper.
Warranty and service
FAQs and troubleshooting
A fault may result from a minor error that you can correct yourself with the help
of the following instructions. Do not attempt any further repairs if the following
instructions do not help in each specific case.
WARNING
Repairs to the appliance are to be performed only by a qualified service technician.
Improperly effected repairs may result in considerable risk to the user. If your
appliance needs repair, please contact your customer service centre.
What should I do if, after the cooking zones have been switched off, residual
warmth is not indicated in the display?
Check for the following possibility:
•
The cooking zone was only briefly used and therefore did not become hot
enough. If the cooking zone is hot, please call the customer service centre.
What should I do if the cooking zone will not switch on or off?
This could be due to one of the following possibilities:
•
The control panel is partially covered by a damp cloth or liquid.
•
The child safety lock is on.
What should I do if the cooking zones are not functioning?
Check for the following possibilities:
•
The fuse in the house wiring (fuse box) is intact. If the fuses trip a number of
times, call an authorised electrician.
•
The appliance is properly switched on.
•
The control indicators in the control panel are illuminated.
•
The cooking zone is switched on.
•
The cooking zones are set at the desired heat settings.
What should I do if the cooking zones will not switch on?
Warranty and service
Check for the following possibilities:
•
A period of more than 10 seconds has elapsed between when the On/Off
button was actuated and the desired cooking zone switches on (see the
section Switching the appliance on on page 14).
•
The control panel is partially covered by a damp cloth or liquid.
What should I do if the display except for
suddenly disappears?
What should I do if the
display is illuminated?
Check for the following:
•
The control panel is partially covered by a damp cloth or liquid. To reset, press
the On/Off button.
What does it mean when the burner does not glow red?
•
The selected temperature of the cooking zone is maintained by a sensor
that cycles the zone on and off, so the surface cooking area will not always
glow red. If you select a low heat setting, the heat will cycle on and off more
frequently than at higher settings. The heat also cycles on and off at the
highest setting.
the residual warmth indicator
This could be a result of one of two possibilities:
•
The On/Off button was accidentally actuated.
•
The control panel is partially covered by a damp cloth or liquid.
20 English
C21RJAN_EU_DG68-01160A-00_EN.indd 20
1/25/2019 5:54:25 PM
Warranty and service
Technical data
Service
Technical data
Before calling for assistance or service, please check the section FAQs and
troubleshooting on page 20.
If you still need help, follow the instructions below.
Appliance dimensions
Is it a technical fault?
If so, please contact your customer service centre.
Always prepare in advance for the discussion. This will ease the process of
diagnosing the problem and also make it easier to decide if a customer service
visit is necessary.
Please take note of the following information.
•
•
What form does the problem take?
Under what circumstances does the problem occur?
When calling, please know the model and serial number of your appliance. This
information is provided on the rating plate as follows:
•
•
Model description
S / N code (15 digits)
When do you incur costs even during the warranty period?
•
If you could have remedied the problem yourself by applying one of the
solutions provided in the section FAQs and troubleshooting on page 20.
•
If the customer service technician has to make several service calls because he
was not provided with all of the relevant information before his visit and as a
result, for example, has to make additional trips for parts. Preparing for your
phone call as described above will save you the cost of these trips.
Worktop cut - out
dimensions
Width
288 mm
Depth
505 mm
Height
50 mm
Width
273 mm
Depth
490 mm
Corner radius
3 mm
220-240 V ~ 50/60 Hz
Connection voltage
2.75-3.25 kW
Maximum connected load power
Weight
Net
4.25 kg
Gross
5.65 kg
Cooking zones
Position
Diameter
Power
Front
148 mm
1100-1300 W
Rear
183 mm
1650-1950 W
Technical data
English 21
C21RJAN_EU_DG68-01160A-00_EN.indd 21
1/25/2019 5:54:25 PM
Technical data
Memo
Product information
Supplier’s name
Samsung Electronics co. Ltd.
Model identification
C21RJAN
Type of hob
Built-In
Heating technology
Radiant cooking zones
Number of cooking zones and/or areas
2
For circular cooking zones or area:
diameter of useful surface area per
electric heated cooking zone (Ø)
Ø 15.0 cm, Ø 18.5 cm
Energy consumption per cooking zone or
area calculated per kg (EC electric cooking)
Energy consumption for the hob
calculated per kg (EC electric hob)
Ø 15.0 cm : 191.4 Wh/kg
Ø 18.5 cm : 198.2 Wh/kg
194.8 Wh/kg
* Data determined according to standard EN 60350-2 and Commission Regulations
(EU) No 66/2014.
Energy saving tips
•
•
•
Always position pots and pans before switching on the cooking zone.
Dirty cooking zones and pan bases increase power consumption.
Using a pressure cooker reduces cooking time.
Technical data
22 English
C21RJAN_EU_DG68-01160A-00_EN.indd 22
1/25/2019 5:54:25 PM
Memo
C21RJAN_EU_DG68-01160A-00_EN.indd 23
1/25/2019 5:54:25 PM
QUESTIONS OR COMMENTS?
COUNTRY
CALL
OR VISIT US ONLINE AT
AUSTRIA
0800-SAMSUNG (0800-7267864)
[Only for KNOX customers] 0800 400848
[Only for Premium HA] 0800-366661
[Only for Dealers] 0810-112233
[Only for E-Store] 0800 100 232
www.samsung.com/at/support
BELGIUM
02-201-24-18
www.samsung.com/be/support (Dutch)
www.samsung.com/be_fr/support (French)
DENMARK
707 019 70
www.samsung.com/dk/support
FINLAND
030-6227 515
www.samsung.com/fi/support
FRANCE
01 48 63 00 00
www.samsung.com/fr/support
GERMANY
06196 77 555 77
www.samsung.com/de/support
ITALIA
800-SAMSUNG (800.7267864)
www.samsung.com/it/support
CYPRUS
8009 4000 only from landline, toll free
GREECE
80111-SAMSUNG (80111 726 7864) only from land line
(+30) 210 6897691 from mobile and land line
www.samsung.com/gr/support
www.samsung.com/be_fr/support
LUXEMBURG
261 03 710
NETHERLANDS
088 90 90 100
www.samsung.com/nl/support
NORWAY
21629099
www.samsung.com/no/support
PORTUGAL
808 207 267
www.samsung.com/pt/support
SPAIN
0034902172678
www.samsung.com/es/support
SWEDEN
0771 726 786
www.samsung.com/se/support
SWITZERLAND
0800 726 78 64 (0800-SAMSUNG)
www.samsung.com/ch/support (German)
www.samsung.com/ch_fr/support (French)
UK
0330 SAMSUNG (7267864)
www.samsung.com/uk/support
IRELAND (EIRE)
0818 717100
www.samsung.com/ie/support
DG68-01160A-00
C21RJAN_EU_DG68-01160A-00_EN.indd 24
1/25/2019 5:54:25 PM
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
