User Manual
B9 Series & UD9 Series
CONTENTS
Introduction
1
Warnings & Safety Precautions
1
Features
2
Safety Information
2
Important Safety Precautions
3
Prepration
Stand Installation
4
Functional Overview
Front & Side Panel
5
Functions
6
Connections
7
Remote Control
8-10
Basic Operation
11
Menu Operation
12-18
Media Play
19
Network Setting
20
Instructions for Intelligent Platform Operation
21-24
Troubleshooting
25-27
INTRODUCTION
Thank you for choosing our product. To be able to make use of all application options we
recommend that you should read this operation manual carefully and preserve it for quick
access, if required.
Do not touch any parts in the set and do not make changes to any settings not described in
this operating manual.
The LED Screen is a high-tech product which consists of more than 9,00,000 control
elements. Any Non-active red, blue or green spots lines that might appear on the screen
occasionally have no effect on the performance of the screen or television and may disappear
over a short period of time.
WARNINGS AND SAFETY PRECAUTIONS
Warning:
– To prevent damage to the TV which may result in a fire or electrical shock hazard, do not
expose the TV set to rain or excessive moisture.
– Do not rub or strike the Active matrix LED with any thing hard as this may scratch, mark or
damage the active matrix LED permanently.
– For safety, do not place vessels or any container which contains fluids including water, on or
near the TV.
– Do not insert any objects in the ventilation slots.
Service:
– Do not remove the back cover of the set as this can expose you to very high voltage and
other hazards. If the set does not operate properly, unplug it and call THOMSON HD LED
TV customer care.
Location:
– Position the set so that no bright light or sunlight falls directly on the screen. Reflections on
the screen affects the picture quality & viewing television.
– Soft and indirect lighting is recommended for comfortable viewing.
– Care should be taken not to expose the set to any unnecessary vibration, moisture, dust or
heat.
– Adequate ventilation is essential to prevent set failure.Ensure that the set is placed in a
position to allow a free flow of air. Do not cover ventilation opening on the back cover. Do
not place the set in an enclosure or very close to walls.
– Avoid excessively warm locations to prevent possible damages to the set.
– Place the television on a solid and flat surface, if not wall mounted.
1
FEATURES
–
–
–
–
–
–
–
–
–
–
–
–
–
SMART LED TV
FHD / UHD 4K Resolution
Extra Slim Design
500000:1 Dynamic Contrast Ratio
HDMI Connectivity
Full Multimedia Interface
Seven Picture Modes
Five Sound Modes
178ox178o Viewing Angle
PC Connectivity
Dynamic Noise Reduction
LAN & Wi-Fi Connection for Internet
Web Browsing
SAFETY INFORMATION
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
High voltages are used in the operation of
this product. To reduce the risk of electric
shock, do not remove cover of the cabinet,
refer for servicing to qualified service personal.
If the LED TV require any changes or coarse adjustment, electric shocks
are imminent. Do not attempt to open, contact customer support for
needed overhual.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating & maintenance (servicing) instruction in the
literature accompanying the appliance.
Warning
The lightning flash with arrowhead symbol within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated dangerous voltage within the
products enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
2
IMPORTANT SAFETY PRECAUTIONS
- Read & keep this instruction manual.
- Keep these instructions.
- Heed all warnings & follow all instructions.
- Do not use this apparatus near water.
- Clean only with dry cloth.
- Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
- Do not install near any heat source such as radiators, heat registers, stoves or other
apparatus (including amplifiers) that produce heat.
- If the provided plug does not fit into your outlet, protect the power cord from being walked
on or pinched particularly at plugs, socket outlets and the point where they exit from the
apparatus.
- Only use attachments / accessories specified by the manufacturer.
- Use with the bracket or table stand specified by the manufacturer or sold
with the apparatus.
- Unplug this apparatus during lightning storms or when unused for long periods of time.
- To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
- The apparatus should be disconnected from the mains by placing the power / standby
switch in the standby position and unplugging the power cord of the apparatus from the
AC main outlet.
- The socket outlet should be installed near the equipment & should be easily accessible.
- This product should never be placed in a built-in installation such as a bookcase or rack
unless proper ventilation is provided or the manufacture’s instructions have been adhered to.
- The apparatus should not be exposed to dripping or splashing & objects filled with liquid,
such as vases, should be placed on the apparatus.
- Do not place any sources of danger on the apparatus (e.g. liquid filled objects, lighted
candles).
- Wall or ceiling mounting - The appliance should be mounted to a wall or ceiling only as
recommended by the manufacturer.
Servicing should be carried out by qualified service personnel only. To reduce the risk of
electric shock do not perform any servicing other than that contained in the operating
instructions.
3
PREPARATION
Stand Installation
The TV base will be separated with the TV unit. You should install the base before
you use the TV unit.
- Place the TV with its front side facing down on a cushioned flat surface.
- Place the base on the hinge of TV unit, with the base direction shown under
the base. (See the picture)
- Tighten the supplied screws to fix the TV stand securely in place.
(Screws - Provided with TV unit)
WARNING
- The TV stand may not be securely fixed in place after repeated tightening
and loosening of screws.
- During assembling and disassembling the TV stand, please use your hand
to support it. Failing to do so may cause the TV stand to fall and result in
personal injury / damage to the product.
- After installing the TV stand, please ensure that the screws are tightened
firmly. Failure to do so may cause the TV set to tip over or be damage.
4
FUNCTIONAL OVERVIEW
Front & Side Panel
1 Power Light
On Standby Mode, the light
turns red.
2 Infrared Remote Sensor
Receives the signals from the
remote control.
3 Power
Press to turn TV on or turn to
standby mode.
4 Menu
Press to display the setup menu on
the TV screen.
5 CH-, CH+
Press to select desired channels. or
press to select or adjust a menu item.
6 Vol-, Vol+
Press to adjust the volume level or Press
to select and adjust a menu item.
7 Input
Press to select source of viewing and
adjust all video input modes TV, AV,
HDMI, USB, YPbPr, VGA
5
FUNCTIONAL OVERVIEW
- LAN (Local Area Network)
For Internet connection
- USB
Insert USB
- HDMI input Terminal
Connect to equipment with HDMI output
- VGA(PC IN) Input Terminal
Connect to PC.
- PC / HDMI Analog Audio Input Terminal
Connect to equipment using HDMI-DVI
connection or PC with audio output.
- AV 1 & AV 2 In / YPBPR
Connect the video output jack of DVD or Set-top Box
- Antenna Input Terminal
Connect to equipment with antenna output or
wall antenna socket.
* Actual product specifications may differ from the above.
6
CONNECTIONS
You can connect DVD player, set-top box, computer, game console or other
equipment to the TV. To view external source images, press
to select the input
source.
Source
Connecting an AV Equipment with HDMI Connector
Connecting an AV Equipment with Composite Connector
Connecting an AV Equipment with VGA Connector
- If the external equipment has DVI output, you can connect it to the HDMI terminal using a HDMI-DVI cable.
In case of using the HDMI-DVI cable, connect analog audio signal to RGB/HDMI analog audio input terminal.
- Please refer to the user manual of the external equipment for more information on connection to the TV.
- Please disconnect all power supplies to the equipment & TV before connection.
- Compatibility of the TV set and external equipment is dependent on hardware compatibility of both.
7
REMOTE CONTROL
Installing the remote control batteries
- Open the battery cover.
- Insert batteries (2x AAA size batteries)
Place batteries with their terminals observing
the (+) & (-) indications.
- Replace the cover & press down until the lock
snaps closed. If the remote control is not used
for an extended period of time, remove the
batteries from the remote control as damage
may result due to electrolyte leakage from the
batteries.
Note: - The batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
- Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type.
- Risk of explosion if battery is replaced by an incorrect type. Dispose of batteries
according to the instructions.
- Do not dispose of batteries in a fire, danger of explosion.
- Batteries not covered under warranty.
- The remote may differ from the above picture.
FUNCTIONS
POWER
FREEZE
SOUND MODE
PICTURE MODE
Settings / FAV FAV+/Capture
Turns TV into STANDBY ON/OFF.
Select to freeze the scene still on the screen.
Different sound features.
Different picture features.
Press to open internet set-up.
Press to switch your favorite channels under TV menu.
Press this key to capture video image
P
- Navigates vertically Up/Down through the Menu/Sub Menus.
- To enter character/numbers in program name parameter.
P
- To navigate channel Up/Down through valid channels.
- Navigates horizontally Right/Left through the Menu/Sub menus.
- To enter in Menu/Sub menus & to adjust Vol +/-.
- To navigate the letter in program name parameter.
- To select the time.
- To select Source by right arrow key.
- Increase / Decrease the value of selected items & set the
parameter On/Off.
OK
EXIT
- To enter in sub menu.
- Enter to edit program name parameter.
Press to exit the OSD menu
8
REMOTE CONTROL
MENU
/ CH. LIST
VOL +/PA +/ECO Vision
To select menu OSD window and return to upper menu.
Change to cursor mode.
Select to increase or decrease volume.
Select to increase or decrease volume for power audio
This key provides the different power saving modes. The current mode is
displayed with ecovision symbol on the screen. In audio only mode display is off
& only audio is on. Press any key to exit audio only mode. Note: VOL+/-, PA+/- &
Mute can fuction even as panel is off. Note: Audio only mode is not available in
models 32” and above.
Turns sound OFF or ON
MUTE
Figures 0-9 are used to directly input channel number.
To select the source of viewing.
INPUT
Q. View
Click to open internet browser.
SUBTITLE / COPY
- Press this key to display sub title list.
- Press this key to rename channels in program edit function.
- Press this key to copy / paste from USB to USB in USB Mode.
- Press this key to switch On/Off internal speaker used in TV set.
MEDIA / SPEAKER - Press this key to swap channel in program edit function.
- Press this key to open media center.
ASPECT
SLEEP / DELETE
- Press this key to switch aspect ratio 16:9, 4:3, Zoom 1, Zoom 2, Auto scan
- Press this key to skip channel in program edit function.
- To set sleep timer except when in program edit menu or USB mode.
- To select sleep timer except when you want seen next program after
selected time, you can enjoy watch TV set.
- Press this key to save channels when manual tuning or delete channel
when editing TV program in program edit function.
- Press this key to STOP in USB mode
- Press this key to PLAY/PAUSE in USB mode
- Press this key to FAST REVERSE in USB MODE
- Press this key to FAST FORWARD in USB MODE
GOTO
- Press this key to select play time position
When playing the Photo or Video or Mp3 or Text, if you select ROOT key it will stop
playing & return to the current list in USB mode.
Press to open home page.
- Press this key to play the previous track.
- Press this key to play the next track.
9
REMOTE CONTROL
Power On/Off
Turning on the TV
- Plug the TV’s power cord into a wall outlet (after this step, the main unit will turn on
and enter stanby mode automatically).
- Press the (Power) button on the TV, or press the (Power) button on the remote
control. The TV will turn on.
Placing In Standby Mode
Your TV can be placed in Standby mode in order to reduce the power consumption.
The standby mode can be usefull when you wish to interrupt viewing temporarily
(during a meal, for example).
- Press the Power Button.
- To switch back on, simply press power button.
Remark: Do not leave your TV in standby mode for long periods of time. (When you
are away on holiday, for example). It is the best to unplug the set from the mains and
aerial.
Changing Programmes
Using the programme selection buttons on the remote control to change
programmes
To select a programme, press the corresponding programme selection button
remote control. For example, to select programme 8, press the “8” programme
selection button on the remote control.
Using the P+/- buttons to sequentially change programmes
Press P+/- buttons on the remote control or on the TV to sequentially seletct
the TV programmes available in you area.
Using the button to return to sequentially change programmes
To return to the previous viewed programme, press the
button on the remote
control.
10
BASIC OPERATION
Power On/Off
Volume Adjustment
To turn on the TV
To change the volume
- Connect the power play into the wall outlet.
The power indicator lights in red, indicating
that the TV is in Standby Mode.
- Press V+ to increase the sound volume level.
- Press V- to decrease the sound volume level.
To Mute the sound
-Press
The Power indicator lights turns off & the
TV turns on.
- Press
to temporarily turn off the sound.
- Press
or V+ to restore the sound to
previous level.
To turn off the TV
-Press
The power indicator lights in red & the
TV turns off to standby mode.
- You can decrease the sound volume by pressing
V- while the sound is muted.
- It takes approximately 10 sec. for the
picture to appear after the TV is turned on.
On-Screen Displays (OSD) Selection
& Adjustment
- The TV will switch to standby mode automatically if there is no signal input for 10
minutes.
- Press “MENU” to display the main menu.
- Press
to select a menu. The selected
menu page displays.
- Press
to set your selection.
- Press
to choose an item on the menu
page & press to set your selection.
- Press
to adjust an item value or choose
options.
- Press “MENU” to return to the menu, press
”MENU” again to exit.
- If the TV will not be used for a long periods
of time, unplug the TV from the wall outlet.
Channel Selection
To select channel
Press P+/- or Program Select buttons to select
the channel number directly.
The OSD menu screen will be closed automatically when no operation has been made
for the set OSD menu display time.
Input Source Selection
To select input “SOURCE”.
- Press
to select the desired input source,
then press
“enter” to enter. The selected
input source image displays.
INPUT Source : TV, AV-1, PC, HDMI , USB, YPbPr,
VGA
11
MENU OPERATION
CHANNEL :
Auto Tunning
: You can tuto tune all RF channels in ATV input source only.
ATV Manual Tunning
: Channel
: Color System
: Sound System
: Search
: Frequency
Program Edit
: 1
: Standard / Soft / User / Vivid/Natural/Sports/Lightness
S-00
O Delete
CH1
Auto/PAL/NTSC/SECAM
BG/DK/I/M
< >
62.25 MHz
MENU
ATV
Y Move
G Edit
ATV Manual Tunning
Contrast
Brightness
Hue
Sharpness
Saturation
ECO
back Light
Color Temperature
Aspect Ratio
Image Noise
Reduction
SOUND :
Standard / Music / Movie / News / User
Bass
Treble
Balance
AVC
Surround
SPDIF Output
Screen Off
TIME :
Date
Current Time
Off Time
On Time
Sleep Time
SETTING :
Menu Time
Blue Screen
HDMI CEC
Menu Opacity
Restore To Default
B Skip
: 0 - 100
: 0 - 100
: 0 - 100
: 0 - 100
: 0 - 100
: Off/Low/Middle/High
: 0 - 100
: Standard / Warm / Cool
: 16:9, 4:3, Zoom 1, Zoom 2
: Off/Weak/Middle/Strong
: 0 - 100
: 0 - 100
: 0 - 100
: Off / On
: Off / On
: PCM/RAQ/OFF
: Music Only
(Press Ok, Only Sound, No Picture
To exit, press any key.
: 2016 / 7 / 1
: 09:02:40
: Setting off Time Off / On
Hour 9 (0-23)
Minute 05 (0-59)
(Off Time must be more, than 1 minutes after the current time)
: Setting Boot Time OFF/ON
Hour
9
Minute
43
Source
ATV
(Schedule time must behind the current time)
: Off / 10 min / 20 min/ 30 min/ 60 min / 90 mibn /
120 min / 180 min / 240 min.
: Always / 5 Sec / 10 Sec / 15 Sec / 20 Sec / 30 Sec.
: Off / On
: Off / On
Stand by On : OFF / ON
ARC
: OFF / On
: 0 - 100
: >>>>
12
MENU OPERATION
Channel Setting (Use for TV)
At ATV input source, the first page showed is CHANNEL. At non ATV input source, the first page
is PICTURE as default. Currently press ENTER to get in sub menu, submenu highlight fixed on
press button key, the subtopic turns up with full screen.
Channel
Sound
Time
Setting
- Press the “MENU” button on the remote
control to enter the OSD menu. Then
press
buttons the “CHANNEL”.
- Press
buttons to select the desired item,
then press or ENTER to enter.
- Press
buttons on the remote control to
adjust desired item.
- Press the “MENU” button on the remote
control to return to upper menu.
Auto Tuning
ATV Manual Tuning
Program Edit
Select
Confirm
Exit
Note : CHANNEL can be only selected under ATV condition, others can’t be used.
- Auto Scan : Enter Auto, it shows the process of frequency & the number of channels.
Press to select country & Tune Type at first,
press to select start or cancel, then press OK
button to start or exit Auto Scan.
- TV Manual Tuning:
Storage To : Current storage space shows, the following
option are available : 1-200.
System : Default option depends on country selection.
The following option are available : BG, I, DK
Current CH : Current channel shows.
Search : Can be searched at full channel condition.
Frequency : Show the current frequency & follow
search or Fine-Tune to adjust.
NOTE : After tuning by hand, make sure to press red button for storage, otherwise all channels searched
would not be stored after switching condition.
13
MENU OPERATION
- Program edit :
There are 3 items in the Preference page : Skip, Type
Select : Select your channel name by moving the cursor.
Delete : Delete current channel, as follows :
Press UP/DOWN buttons to choose the channel which you want to delete, then
press RED button to delete the current channel.
GREEN Button(Optional) :
Modify current channel name, only used in ATV mode.
- At normal condition, press GREEN button to enter RENAME mode.
- At RENAME Mode :
MENU : Press to exit RENAME mode, back to normal.
EXIT : Press to exit menu.
UP/DOWN : Press to switch letters, numbers or signs.
LEFT/RIGHT : Press to switch left & right, can select by circle.
GREEN : Press to exit RENAME mode, return normal condition.
Yellow Button (Optional) :
Channel switching function, ATV available as default.
- At normal condition, enter SWAP mode, & current selected channel is mobile channel X.
- At SWAP mode :
MENU : Press to exit SWAP mode, turn to normal condition.
EXIT : Press to exit menu.
UP/DOWN : Choose switch channels.
YELLOW : If current selected channel is what selected before X, no any other action,
Otherwise, the current channel is channel Y, need to exchange X& Y condition. But the
channel number stays 1,2,3,...... order as before.
BLUE Button (Optional) :
Choose if skip the channel when CH+/- channel tuning.
At Non Skip channel, press BLUE button, & Skip the current channel
At skip channel, press blue button to cancel skip.
14
MENU OPERATION
Picture Setting
You can adjust picture effects here, such as contrast,
brightness & etc.
- Press the “MENU” button on the remote
control to enter the OSD menu.
Then press
buttons to select the “PICTURE”.
- Press
button to select the desired item to enter.
- Press
buttons on the remote control to adjust
desired item.
- Press the “MENU” button on the remote control
to return upper menu.
Picture Mode : Press
buttons to select. The following option are available.
“Standard, Mild, User, Dynamic”
Contrast : Adjust image contrast.
Brightness : Adjust image brightness.
Color : Adjust the color saturation.
Sharpness : Adjust the sharpness level of image.
Tint : Determines the tint of the screen (This is only available with NTSC).
Color Temperature : Adjust the color temperature level of image. The following option are
available, “Normal, Warm, User, Cool”.
RED/GREEN/BLUE : Press
buttons to adjust numeric size, Press MENU button to turn back
picture main menu.
Aspect Ratio : Press
buttons to select, 16:9, Zoom 1, Zoom 2, Panorama, 4:3
Noise Reduction : Press
buttons to select On/Off.
Color Temperature
You can select your favorite color temperature.
- Press the “MENU” button on the remote
control to enter the OSD menu. Then press
buttons to select the “PICTURE”
- Press
button to select the “Color Temperature”
- Press
buttons on the remote control to choose
color temp’s value.
- Press the “MENU” button on the remote
control to return to upper menu.
User : Adjust the color value.
Normal : Keep the original white color
Warm : Adjust the white color to a little bit red.
Cool : Adjust the white color to a little bit blue.
Remark : The changes you made will be stored automatically.
15
MENU OPERATION
PC Setting (Only for PC Mode)
The function only used in PC port to adjust PC position. Enter
the screen page with
buttons or ENTER button.
- When input PC source, you can go to PC to set up menu.
- Press the “MENU” button on the remote control to enter
the OSD menu. Then press
buttons to select the
“PICTURE SETUP” in main menu.
- You can press ENTER buttons to enter PC setup mode
after selecting PC setting , & the press
buttons to
select your desired item press
buttons to adjust.
- Press the “MENU” button on the remote control to
return to upper menu.
- In PC function operation will instruct more clear.
Auto Adjust : Press
buttons, TV system adjust by itself, it can adjust, H position, V position, Phase & so
on that can make the image in center & display best.
H. Position : Adjust Horizontal Position of the PC Screen.
V. Position : Adjust the Vertical Position of the PC Screen.
Size : Adjust the size of the PC Screen.
Phase : When necessary, adjust the pixel phase of the picture to avoid picture interference.
Sound Setting
You can customize different sound mode to get best effect.
- Press the “MENU” button on the remote
control to enter the OSD menu. Then press
buttons to select the “SOUND”
- Press
button to select the desired item
to enter.
- Press
buttons on the remote control to
increase or decrease the value of desired
item.
- Press the “MENU’ button on the remote
control to return to upper menu.
Sound Mode : Press
buttons to select one of the following options “Standard, Music, Movie,
Sports User”.
Treble : Adjust treble effect.
Bass : Adjust bass effect.
Balance : Adjust balance effect.
Auto Volume : (Auto volume control, when you turn on the TV, this feature allows the TV to
automatically adjust the sound output from level to the previous level of
last time when you turned off the TV) : On/Off.
Surround Sound : Select it to enter, then you can select Off or On.
SPDIF Output : Select it to enter, then you can select option PCM/RAW/OFF
For HD channel select only PCM
Music Only : Press OK (ENTER) only listen sound, no picture, to exit Press any key on remote control.
16
MENU OPERATION
Time Setting
You can set the TV’s time & you should set time if you use the automatic On/Off times.
Time
Clock
Off Time
On Time
Sleep Timer
Auto Sleep
09/NOV 04:19
13:57
13:58
Off
On
- Press the “MENU” button on the remote control to enter
the OSD menu.
Then press
buttons to select the “TIME”.
- Press
button to select the desired item to enter.
- Press
buttons on the remote control to adjust desired item.
- Press the “MENU” button on the remote control to upper menu.
Sleep Timer : Press
buttons to select your desired item (Off,
240 min., 180 min., 120 min., 90 min., 60 min., 30 min., & 10 min.)
Auto Sleep : Within 10 min. there is no signal, the TV will auto sleep
Clock
- Press the “MENU” button on the remote control to enter
the OSD menu.
Then press
buttons to select the “TIME”.
- Press
button to select CLOCK, then press ENTER button
to enter.
- Press
buttons to select the desired item.
- Press the “MENU” button on the remote control to return upper
menu.
Off Time
- Press the “MENU” button on the remote control to enter
the OSD menu.
Then press
buttons to select the “TIME”.
- Press
button to select Off Time, then press ENTER button to
enter.
- Press
buttons to select the desired item, then press
buttons on the remote control to set the time.
- Press the “MENU” button on the remote control to return upper
menu.
17
MENU OPERATION
On Time
- Press the “MENU” button on the remote control to enter
the OSD menu.
Then press
buttons to select the “TIME”.
- Press
button to select On Time, then press ENTER to enter.
- Press
buttons on the remote control to adjust desired item,
then press
buttons on the remote control to set the time.
- Press the “MENU” button on the remote control to return to
upper menu.
Option Setting (ADVANCE)
You can adjust the OSD language, OSD Duration
Option
OSD Language
OSD Duration
Blue
Restore Default
English
Off
Off
- Press the “MENU” button on the remote control to enter the
OSD menu, then press
buttons to select the “OPTION’
(advance).
- Press
button to select the desired item to enter.
- Press
button on the remote on the remote control to return
to upper menu.
OSD Lanugage : Press
buttons to select the OSD language.
Menu Time : Press
buttons to select your desired item
(Off, 5S, 10S, 15S, 30S, 45S, 60S, Always).
Blue Screen : If no signal is being received or the signal is very
weak, a blue screen automatically replaces the noisy picture
background. Press
buttons to select On/Off.
HDMI EDID Version : Default
HDMI CEC : Off / On
Standby : Off / On
ARC : Off / On
Restore Factory Default : Restore the default setting.
Note : Restore factory default will clear all the programs &
passwords
18
MEDIA PLAY
Remote Contoller Media
Button
Description
Stop / Playback
Play / Pause
Skip a scene or music
Go back to the previous or skip to the next
Press to select item
Press to confirm an action (For example:
copy, paste, etc.)
ENTER
Media Play
When selecting the USB input mode & input your USB, you can play the USB.
There are 4 items in the preference page : PHOTO, MUSIC, MOVIE, TEXT.
Move
Menu
Select
Exit
Note : Select the picture & press PLAY button to play after exiting music play mode.
When playing a movie you can press the “ENTER” button, then the function menu will
appear on the screen. You can select you desired item.
The supported file format of media playing:
File Type
Supported File Format
File Name
BMP / JPEG / PNG
.jpeg / .bmp
MUSIC
WMA / Mp3 / Mp4 / AAC
.mp3 / .wma
MOVIE
MPEG1 / MPEG2 / MPEG4 / RM / RMVB
.mpg / .dat / .vob
TXT
.txt
TEXT
Note : Not compatible with HDD. The file you played needs license for on external source
(customer should check this point) or it will not be played.
19
NETWORK SETTING
Establishing a wireless Internet connection
Settings
Network
Open Network Settings
Wireless
Make sure that you have the wireless router's SSID (name) and password settings before attempting to connect,
and then follow the directions on the screen.
If there is no wireless router found, select Add Network at the bottom
of the list and enter the network name (SSID).
Network Settings
Wireless Connection
If a wireless router has a WPS or PBC button, select Use WPS at the
bottom of the list and click the button. Then the TV is automatically
connected.
Select your wireless network.
XYZ
ABC
123
Checking the Internet connection status
Refresh
Settings
The image on your TV may differ from the image
above depending on your model and geographical area.
Network
Network Status
View the current network and Internet status.
INSTRUCTION FOR INTELLIGENT PLATFORM OPERATION
Basic Operations
09:31
Home
ATV
Press
key on the remote control to show the home page.
- Press
,
key to select an application.
- Press ”OK” key to run the application.
- Press “Return ” key to return to previous page.
HDMI
Browser
Media
Center
Application
Mall
41 NEW MESSAGE
Special Tips
The operations in smart mode are complicated. The user can
install Apps with different operation methods, & the operations
described in this manual are for reference only. Certain functions
are invalid from the remote control. For more convenient operation, please operate with USB mouse & keyboard.
Display Mode
If the signal from the system equals the standard signal mode, the screen is adjusted automatically. If the
signal from the system does not equal the standard signal mode, adjust the mode by referring to your
videocard user guide, otherwise there may be no video. For the display modes listed below, the screen image
has been optimized by manufacturer.
Resolution
Vertical Frequency (Hz)
Mode
1024x768
1366x768
800x600
60Hz
60Hz
60Hz
SVGA
XGA
WXGA
20
INSTRUCTIONS FOR INTELLIGENT PLATFORM OPERATION
Quick Start
Before using this device, please get familiar with the operations below for better experience.
Mouse Control ( not this button in the remote but an externally connected mouse)
- Click the mouse & release immediately.
- Press & hold, Click the mouse & hold for at least three seconds.
- Clicking the left mouse key has the same effect as pressing “OK” key on the remote control.
- Clicking the right mouse key the same effect as pressing “Return” key on the remote control.
Language input setting (IME)
Language : Select the system language, select Settings > IME > Language Setting, & press “OK” key.
press “
” key to select the desired language, & then press “OK” key.
Selecting Input Method : In the smart mode, select Settings > IME > Update Input Method, &
integarted “Android Keyboard” & “Google play in Input Method”, you can also download & install third party
input method.
Setting System Time : In the smart mode, select Settings > Date & Time > Set Date & Time
Automatically from the internet, press “OK” key & the system update the clock from the network
automatically, if the TV set isn’t connected to the network, you can set the system time manually.
Screenshot : Before screen shooting, please insert the USB mass storage device into the USB interface,
& press “SCREENSHOT” key. After screen shooting, the picture are saved in the “;\Pictures\Screenshots”
folder in the USB mass storage device.
Smart Appplications
Browser : You can use the browser to show text, video, audio & other information on the Internet. Before
accessing the Internet, please connect the internet, please connect your TV set to the internet refer to
“ Settings > Manage Networks” for details
1. Back to the previous webpage
3. Refresh the webpage
5. Close the current webpage window 9. Input option of URL
10. Menu option of browser
11. Option for viewing bookmark
7. Input box for URL
4. Webpage window of the browser
8 Option for adding a bookmark
2. Go forward to the next webpage
6. Add a new webpage window
- How to access web address? press
key to select the address bar, & type the web address in the
address bar, then select
icon in the input method, & press “OK” key to access the web address.
- How to save a page in the Bookmarks? Select the
icon the browser interface, & press “OK” key to enter
the browser tab & web address. Select Account, & press “OK” key. Press ”
” key to select the account for
storage, & then press “OK” key. Select OK, & then press “OK” key to add the bookmark.
- How to copy & paste the text in the web page? Place the cursor on the text to copied, press & hold the left
mouse key. When the pair of selecting cursors appears on the screen, drag the cursor to select the text.
Select copy on the screen, & click the left mouse key. Select the target position, press & hold the left mouse
key. Select the target position, press & hold the left mouse key, & click Paste in the popup dialog box.
21
INSTRUCTIONS FOR INTELLIGENT PLATFORM OPERATION
Playing setup, show/hide subtitle &
Play the previous video.
Select the speed of fast rewind
adjust the audio progress in this option.
Pause / Play the video
Set A-B repeat playing, set point A & point
Select the speed of fast forward
B, & the video will repeat between A & B.
Play the next video
A dual-screen display, start or off dual
Select the starting time point of watching
display function.
View the playing list
Select playing screen.
Show details of the video
Select dual display window display mode.
While playing press “OK” key to show the menu options as in the picture above, select an icon & press
“OK” key to perform the operation, you can press “Return” key to exit playing, or “
” keys
on the remote control to perform shortcut operation.
Settings
Manage Networks : In smart mode, select Network in settings, & press “OK” key to enter.
- Ethernet Setting : Before using wired network, connect one end of the network cable to the network interface of the
TV set & connect the other end to the router.
- Select Ethernet Setting & press “ ” key to enter.
- If the router setting enables obtaining IP address automatically, select The Automatic Acquisition IP
Address, press “OK” key & your TV will obtain the IP address automatically. If the router disables obtaining IP address
automatically, you can connect to the network in the following steps.
- Select IPv6, & press “OK” key to enable / disable IPv6.
- Select IP Address, & assign a valid gateway for the device.
- Select Default Gateway, & assign a valid gateway for the device.
- Select First DNS & Second DNS & assign a valid DNS server address for the device.
- Select Save, press “OK” key & the system prompts setup is successful.
Wireless Setting
- Select Wireless, & press “ ” key.
- Select Wi-Fi, & press “OK” key to enable wireless network. If the scanned network has the icon, it doesn’t require
password to connect, if the scanned network has the icon, you need to enter the valid password to access the network.
- Select a network in the list & press “OK” key.
- Select passwords type the password in the input box. Select connect & press “OK” key.
- If the router setting enables obtaining IP address automatically, select The automatic acquistion IP Address, press
“OK” key & your TV will obtain the IP address automatically. If the router disables obtaining IP address automatically, you
can connect to the network in the following steps.
- Select IP address, & assign a valid IP address for the device.
- Select Subnet Mask & assign a valid subnet mask for the device.
- Select Default Gateway & assign a valid gateway for the device.
- Select First DNS & Second DNS & assign a valid DNS server address for the devices.
- Select Save, press “OK” key & the system prompts setup is successful.
22
INSTRUCTIONS FOR INTELLIGENT PLATFORM OPERATION
Multimedia Player
In smart mode, select Multimedia in the main interface, & press
“OK” key to run. Select the file type from all, picture, song &
video in the left.
Playing files in local disk device :
Before playing files in the local disk, insert the USB mass storage
device into the USB interface. Select local disk device in the file
directory in the center, & press “OK” key to enter. Select Back in
the directory, press “OK” key to return to previous folder. Select
the target folder, press “Return” key to return to the desktop.
Attention :
- Non standard USB devices may not be recognized. In this case, please replace with a standard USB device.
- The stream media system has certain restrictions on the format of files. The viewing may be abnormal if it is
out of the system restriction.
- Do not remove the USB device while playing or the system or device may have problem. Before removing
USB device, please turn off power supply.
- The system supports standard USB 1.1, USB 2.0, USB 3.0 devices, such as USB mass storage devices & remoable hard drives.
- The maximum output current of the USB port of this device is 500 mA & self-protection will be enabled
if it is beyond this limit. Please use external power supply if an external device of higher current will be connected.
- The system is complicated, when it is reading or playing files, the screen may be still or certain functions may
be invalid due to the compatibility & stability of the USB device, in this case please turn off the device & reinitialize the system.
Media Player UI icon introduction
Picture Player Menu Options
Play the previous picture
Pause / Play lantern slide
Play the next picture
Zoom in the picture
Zoom out the picture
Rotate 90o left
Rotate 90o right
Show detail of the picture
Play the previous track
Pause / resume music playing
Play the next track
Set the repeat playing mode : All, Single, Random
View the playing list.
Show details of the music
Video Player Menu Options
23
INSTRUCTIONS FOR INTELLIGENT PLATFORM OPERATION
Connecting a Mobile Device : View a mobile device's screen by connecting the mobile device to your TV or
network.
Using Miracast (Screen Mirroring)
You can play media content saved on your mobile device on the TV's screen and share contents by connecting
with the mirroring function.
1. Launch the Miracast (Screen Mirroring) function on your mobile device. The mobile device searches for available devices to connect to.
2. Select the TV from the list. The TV connects to the mobile device.
If your mobile device does not find your TV, turn the TV and the mobile device off and then on and try again.
If there are multiple TVs, you can easily select any of different TV names in
Settings
Network
Device Name
Backup / Update : Backup or update the device.
Remark : Before resetting, please back up your personal data, which will be lost after reset.
About : View the Models, System Version, Memory Information.
E-mail : You can log in private or business e-mail account, & receive & send e-mail.
Apk Installer : The Apk installer helps users manage applications, & allows users to install or uninstall apps in local
disk.
Note : Select Settings > Application Manager > Settings to enable/disable Allow installation of non-market
apps & set Default Installation Location, or operate All applications.
- How to install an application ? Enter Apk Installer, select install & press “OK” key to enter, Select the path of the
target installation file in local disk, locate the istallation package in the right panel, & then press “OK” key.
- How to uninstall an application ? Select manage, & press “OK” key to enter. Select the application to be removed,
& press “OK” key. Select Uninstall, click “OK” key, & the system will uninstall the application automatically.
IMPORTANT STATEMENT ON NETWORK SERVICES
All contents & services obtained from this TV set belong to the third party & are protected by laws on copyright,
patent right, trademark right and / or other intellectual property right. The said contents & services are only for your
non-commercial purposes. It is not allowed to use any content or service without the authorization of the content
owner or the service provider. Our company will undertake no liability for any direct, indirect & accidental losses or
damages caused by you or a third party’s access to any content or service or any information or any third party
software through this set under any circumstances. Third party service may be changed, deleted or stopped
without prior notice. Our company neither implies nor guarantees the continuous availability of some service or
content within any period of time. Our company is not held responsible for services related to the said service &
content. Besides, we will not bear any liability for client service. Please directly contact relevant content & service
providers if you have any problem & service request concerning relevant service or content.
Note : This user manual is for reference only. Specifications are subject to change without notice.
If at any time in the future you should need to dispose of this product please note that, Waste electrical
products should not be disposed of with household waste. Please recycle where facilities exist. Check
with your Local Authority or retailer for recycling advice. (Waste Electrical & Electronic Equipment)
24
TROUBLESHOOTING
The TV Won't Connect to the Internet
When the TV has difficulties connecting to the Internet, these steps may help resolve the problem.
The problem
The TV cannot connect
to your network or apps
(for Internet compatible
models only).
The wireless network
connection failed.
Try this!
Make sure the TV has a network connection
Network Status ).
(
Settings
Network
Contact your Internet service provider.
Confirm your wireless modem/router is on and connected to the Internet.
Position your wireless router, modem router, or access point in a central location.
Avoid putting it in a corner.
The wireless network
signal is too weak.
The software update over
the Internet has failed.
Use a wireless repeater to get an instant boost in your wireless signal strength.
Place the repeater halfway between your wireless router and your TV.
The most common wireless technology, 802.11g (wireless-G), operates at a
frequency of 2.4 GHz. This frequency is widely used by many cordless phones,
microwave ovens, baby monitors, garage doors, and other wireless devices. Reduce
interference by not using or turning off wireless devices that use the 2.4 GHz
frequency. Instead, use devices that communicate via the 5.0 GHz frequency.
Check the network connection status
Status).
(
Settings
Network
Network
If the TV is not connected to a network, connect it to a network.
The upgrade stops if you already have the latest software version.
Other Issues
Use these procedures to resolve other issues that may occur.
The problem
The TV is hot.
The picture won’t display
in full screen.
Try this!
Watching TV for an extended period of time causes the panel to generate heat. The
heat from the panel is dissipated through internal vents running along the top of
the TV. The bottom, however, may feel hot to the touch after extended use. Children
watching TV need constant adult supervision to prevent them from touching the
TV. This heat, however, is not a defect and does not affect the TV's functionality.
HD channels will have black bars on either side of the screen when displaying
upscaled SD (4:3) content.
Black bars will appear at the top and bottom of the screen when you watch movies
that have aspect ratios different from your TV.
Adjust the picture size options on your external device or set the TV to full screen.
The "Mode Not
Supported" message
appears.
The output resolution of the attached device is not supported by the TV. Check
the TV's supported resolutions and adjust the external device’s output resolution
accordingly.
The Captions item in the
TV is grayed out.
When an external device is connected with an HDMI or Component cable, the
Caption is unavailable. Adjust the caption setting on the external device.
The TV smells of plastic.
This smell is normal and will dissipate over time.
25
TROUBLESHOOTING
Problem
Snowflake spots occur in
the TV images & there is
noise in accompanying
sound.
Possible Causes
- The antenna connector is loose, or the
cable damaged.
- The antenna type is improper.
- The antenna direction or position is
inaccurate.
- The signal is weak.
Solutions
- Check if the antenna plug is loose or the
cable is in good condition.
- Check the antenna type (VHF/UHF).
- Adjust the direction & position of the
antenna.
- Try to use signal enhancer.
There is neither display nor - The power plug is loose or the power
sound on the screen. The
supply is not connected.
indication light is not on.
- The power switch is not turned on.
- Check if the power line is connected.
- Press the “ ” button on the panel.
Dotted line or strip disturbance occurs in TV
images.
- The signal is disturbed by car, neon
light, electric hair dryer, etc..
- Do not use electric hair dryer aside the
TV set & adjust the antenna direction to
reduce disturbance.
Double images occur on
the TV screen.
- TV singals are reflected by surrounding
high mountains or mansions.
- The direction of the antenna is
inaccurate.
- Use high oriented antenna & use the
Fine Tune function of “TV”.
- Adjust the direction of the antenna.
The images are colorless.
- The color saturation is adjusted too low.
- Enter “PICTURE” setting to increase
color saturation.
The TV has no accompanying sound.
- The volume is set too low.
- The sound become mute.
- Adjust the volume to a proper degree.
- Press “MUTE” key on the remote control
to cancel mute mode.
There is no display on the
PC, with the prompt of “No
Signal Input”. The red indicator light is blinking.
- The signal connecting cable is loose
or falls off.
- Check if the signal connecting cable is
loose or falls off. Reconnect it.
Images displayed on the
PC deviate. The screen is
not full or is exceeded.
The display is fuzzy.
- The adjustment is improper.
- The display mode in inaccurate.
- Use automatic adjustment function.
- Enter “PC Image Mode” adjustment level
or vertical position.
- Use the recommended mode.
The remote control distance is short or out of
control.
- The remote control receiving window of
the machine is blocked by some object.
- The battery of the remote control is low.
- Remove the object to avoid blocking the
remote control receiving window.
- Replace the battery.
The browser cannot
access any link.
- Errors occur in network parameter
configuration.
- The network connection is improper.
- Network service is not activated.
- Ask the network administration to obtain
available IP address & other parameters.
- Check if the network connecting cable
is normally connected.
- Consult the network service provider.
Online video play is very
slow.
- The network bandwidth is low.
- Multiple films are buffered or other files
are downloaded at the same time.
Several PCs share one network.
- Please upgrade your network bandwidth
to a higher one.
- Please try to replace with other addressed to obtain better resources.
Machine is slow, system
crash, can’t operate the
machine.
- Too much to run the program.
- Disconnect the power supply first, &
- The external environment (such as
connect the power supply after about
lighting, static electricity, etc.) Interfere
1-2 minutes, then turn on the TV again.
with the normal work of the machine.
26
TROUBLESHOOTING
The problem
Try this!
The TV is tilted to the
side.
Remove the base stand from the TV and reassemble it.
The stand is wobbly or
crooked.
Make sure the indicator arrows on the stand and stand holder are properly aligned.
Check the cable connections and reconnect them.
There is an intermittent
loss of audio or video.
Loss of audio or video can be caused by using overly rigid or thick cables.
Make sure the cables are flexible enough for long term use. If you are mounting the
TV to a wall, we recommend using cables with 90-degree connectors.
There are small particles
on the TV's bezel.
This is part of the product’s design and is not a defect.
The TV is making a
popping noise.
The expansion and contraction of the TV's outer casing may cause a popping noise.
This does not indicate a product malfunction. The TV is safe to use.
The TV is making a
humming noise.
Your TV utilizes high-speed switching circuits and high levels of electrical current.
Depending on the TV's brightness level, the TV may seem slightly noisier than a
conventional TV.
Your TV has undergone strict quality control procedures that meet our demanding
performance and reliability requirements.
Some noise coming from the TV is considered normal and is not an acceptable
cause for an exchange or refund.
This Product falls under e-waste (Management and Handling) Rules, 2011.
For proper disposal method, visit our website www.thomsontv.in
27
thomsontv.in
Toll Free
1800-8438-777
THOMSON logo are trademarks of Technicolor (S.A.) or its affliates and are used under license by (Super Plastronics Pvt. Ltd.).
Any other product, service, company, trade or product name and logo referenced herein are neither endorsed nor sponsored
by Technicolor (S.A.) or its affliates.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
