Southwire 27285699, 27285601, 27282399, 27279905, 27280701, 27287203, 27280799, 27279999, 27282301 Specification

Southwire 27285699, 27285601, 27282399, 27279905, 27280701, 27287203, 27280799, 27279999, 27282301 Specification
Aluminum RHH, RHW, USE
Underground Service Entrance Cable. 600 Volt. AlumaFlex® Brand Aluminum Alloy (AA-8176)
Conductor. Cross-linked Polyethylene (XLP) Insulation. High Heat, Moisture, and Sunlight
Resistant. Also Rated THWN-2. Rated SIS in #8 – 4/0 AWG
APPLICATIONS
Southwire Type RHH or RHW-2 or USE-2 conductors are used with conduit as specified
in the National Electrical Code. When used as Type USE-2, conductors are suitable for
use as underground service entrance conductors for direct burial at conductor
temperatures not to exceed 90°C. When used as RHW-2 or USE-2, conductor
temperatures shall not exceed 90°C in wet or dry locations. Voltage rating for RHW-2 or
RHH or USE-2 conductors is 600 volts.
STANDARDS & REFERENCES
Southwire Type RHH or RHW-2 or USE-2 conductors comply with the following:
• ASTM B-800 and B-801
• UL 44 for RHH or RHW-2
• UL 854 for USE-2
• Federal Specification A-A-59544
• National Electrical Code, NFPA 70, 2011 Edition
• NEMA WC-70 Construction Requirements
• RoHS/Reach Compliant
CONSTRUCTION
Southwire Type RHH or RHW-2 or USE-2 conductors are AlumaFlex® Brand AA-8000
series aluminum alloy, compact stranded. The insulation is an abrasion, moisture, heat
and sunlight-resistant black cross-linked polyethylene (XLP). CT rated available upon
request sizes 1/0 and larger.
Conductor
Insulation
Nominal
Thickness
O.D. (mils)
(mils)
Size (AWG or kcmil) No. of strands
6
4
2
1
1/0
2/0
3/0
4/0
250
300
350
400
500
600
700
750
900
1000
7
7
6
18
18
18
18
18
22
35
35
35
35
58
58
58
58
58
60
60
60
80
80
80
80
80
95
95
95
95
95
110
110
110
110
110
283
333
388
459
496
536
583
635
710
760
806
849
926
1033
1100
1128
1222
1280
Net Wt.
Per
1000'
(lbs.)
60°C
75°C
90°C
44
64
93
124
149
180
218
266
322
377
431
484
590
718
829
876
1039
1138
40
55
75
85
100
115
130
150
170
190
210
225
260
285
310
320
355
375
50
65
90
100
120
135
155
180
205
230
250
270
310
340
375
385
425
445
60
75
100
115
135
150
175
205
230
255
280
305
350
385
420
435
480
500
Allowable Ampacities+
Standard
Package
AC
BCD
ABCD
CD
CD
ABC
BC
ABCD
CD
C
C
C
BC
N/A
N/A
C
N/A
N/A
+ Allowable Ampacities shown are for general use as specified by the National Electrical Code 2011 Edition, Section 310.15 and
Package Codes
240.4(D).
A-500'
Unless the equipment is marked for use at higher temperatures, the conductor ampacities shall be limited to the follwing per
B-2,500'
NEC 110.14(C): 60°C - When terminated to equipment for circuits rated 100 amperes or less marked for 14 through 1 AWG
C-1,000'
conductors. 75°C - When terminated to equipment for circuits rated over 100 amperes or marked for conductors larger than 1
D-5,000'
AWG. 90°C - THHN dry locations and THWN wet or dry locations for ampacity adjustment purposes using NEC section 310.15.
RECOMMENDED SAMPLE SPECIFICATIONS:
Conductors shall be UL-listed Type RHH or RHW-2 or USE-2, suitable for operation at 600 volts or less in wet or dry locations, including direct
burial in the earth. Conductors shall be Alumaflex® brand aluminum alloy, XLP insulated, as manufactured by Southwire Company or approved
equal.
Conductor
Size (AWG
No. of strands
or kcmil)
6
7
4
7
2
6
1
18
1/0
18
2/0
18
3/0
18
4/0
18
250
22
300
35
350
35
400
35
500
35
600
58
700
58
750
58
900
58
1000
58
BK-Black
Stock Numbers
Stock #:
Stock #:
Stock #:
Stock #:
Stock #:
Stock #:
Stock #:
Stock #:
Stock #:
Stock #:
Stock #:
Stock #:
Stock #:
Stock #:
Stock #:
Stock #:
Stock #:
Stock #:
BK:272799, GN:301572
BK:272807, GN:334680
BK:272823, WE:575240
BK:272831
BK:272849
BK:272856
BK:272864
BK:272872
BK:272880
BK:272898
BK:272906, GN:576086
BK:272914
BK:272922, BN:560674
BK:272930
BK:596530
BK:272955
N/A
N/A
Color Abbreviations
BN-Brown
WE- White
GN-Green
