Fiberglass Ceiling Tiles (15mm, Lay-in)
Installation & Maintenance Instructions
Installation Instructions
Tools Required for Installation
Safety glasses, dust mask (NIOSH approved), tape measure, utility
knife, fine-blade power saw or hand saw
Caution

Use protective eyewear at all times

Make sure the worksite is properly ventilated
Acclimatization
For best results, the jobsite should have the HVAC operational before
installation, during installation, and after installation. Room
temperatures must be between 32°-120° Fahrenheit (0°-49°
Centigrade); relative humidity should not exceed 95%.
Maintenance Instructions
Fiberglass (15mm, Lay-in) Collection
Remove any loose dirt or dust by either gently brushing or using a
vacuum cleaner with the appropriate attachments (those used for
cleaning upholstery or walls). Only clean in one direction, so as to avoid
rubbing dust into the surface. You may also clean using a lightlydampened cloth or sponge (i.e. using a minimal amount of water).
Installation & Maintenance Questions
Questions about installation & maintenance can be sent via email to
[email protected] or via mail to: Halstead C&W Corp., 29 Oakwood
Ave., Norwalk, CT 06850 USA (postage to be paid by sender)
Remove tiles from the packaging for proper acclimatization to room
temperature. Tiles should be stored in the room of installation for a
minimum of 24 hours before installation. TopTile™ Acoustical Tiles
are for INTERIOR installations only. Failure to follow these important
steps will void the warranty.
New Drop Ceilings vs. Replacement Ceilings

Start at Step 1 for installation of new drop ceiling

Start at Step 2 for ceiling tile replacement using existing grid
system
Step 1 – Installation of Ceiling Grid System
Follow the Ceiling Grid Manufacturer’s installation instructions.
Step 2 – Installation of Ceiling Tiles
Angle the tiles up through the open spaces in the grid system;
straighten and lower into place so that they rest flat on the tees. Cut
the perimeter panels with a utility knife for flexible material, or use a
fine blade power saw or hand saw to cut most rigid panels. The cutedge should rest on the wall angle. Make the cut-outs for fixtures and
vents prior to installation of the panels.
©2015 Halstead C&W Corp.
Last Revised: October 6, 2015
