On/Off Outlet
Owner’s Manual
Contents
Getting Started
Insteon Wall Outlet
4
On/Off Outlet
Buttons
Tools Needed for Installation
Disconnect Power
Installation Timeline
Installation
Installation Diagrams
End-of-Run Outlet
Middle-of-Run Outlet
Switched Outlet
Insteon Links
Understanding Linking
Adding to the Insteon Hub
Software-Only Features
Beep on Button Press
6
10
11
12
15
17
19
Blink on Traffic
Disable Local Programming
Error Blink
LED Brightness
Local Programming
Flow Chart
LED Brightness
RF Beacon
Load Sense
Soft Factory Reset
Factory Reset
Factory Reset
Appendix
Specifications
Troubleshooting
Certifications and Warnings
Product Warranty
20
23
24
25
26
28
30
33
35
36
Getting Started
Everything you need to quickly get up and running.
3
Insteon Wall Outlet
On/Off Outlet
Buttons
Tap to turn the upper outlet on or off.
Status LEDs
On
Upper
Outlet
Upper
Tamper
Resistant
Off
On/Off &
Set Buttons
See sections on Basic Linking and
Local Programming for additional set
button functions.
Tap to turn the lower outlet on or off.
Lower
Outlet
Tamper
Resistant
Tools Needed for Installation
Lower
See sections on Basic Linking and
Local Programming for additional set
button functions.
Disconnect Power
Phillips Screwdriver
Flathead Screwdriver
Voltage Detector
Wire Cutter / Stripper
Always disconnect power before
installation. Contact Insteon
Support when uncertain about
installation.
1-866-243-8022
4
Installation Timeline
Unbox and read instructions
Disconnect Power
Remove the old outlet
Reconnect Power
Identify Line wire
Disconnect Power
Connect the outlet wires to
the junction box wires
Carefully install the outlet into
the junction box
Reconnect Power
Test the outlet by tapping a
set button to turn on
Install wall plate
5
Installation
Disconnect Power
1
Turn off power to your outlet at the
electrical service panel.
ON
Remove the Old Outlet
2
ON
1
or
Circuit Breakers
Remove the old outlet and disconnect
the wires.
2
Fuse Panel
½”
12mm
Reconnect Power
3
Turn on power at the circuit breaker.
ON
ON
Identify Line
4
Use a voltage detector to identify the
line wire. Line will be energized.
ON
ON
ON
ON
ON
or
ON
ON
ON
Circuit Breakers
Fuse Panel
6
Installation
Wire-In the Outlet
5
Turn off power at the circuit breaker. Connect the Outlet wires to the identified wires in the junction box.
Verify that the wire nuts are secure and that no exposed copper wire is visible. Additional wiring diagrams
can be found in the Installation Diagrams section.
Neutral
Ground
Line
Install the Outlet
6
Mount the Outlet into the junction box.
Reconnect Power
7
Turn power on to the outlet at the circuit
breaker panel.
ON
ON
ON
ON
ON
ON
ON
or
ON
ON
ON
Circuit Breakers
Fuse Panel
7
Installation
Test the Outlet
8
Test your Outlet by tapping one of the
set buttons to turn On and Off.
Install Wall Plate
9
Complete installation by reattaching
your wall plate. For the best look, us an
INSTEON Screwless Wall Plate.
On
Off
Installation of your Wall Outlet is
now complete.
8
Installation Diagrams
Use the installation diagrams in this section to help you wire
your Wall Outlet.
9
End-of-Run Outlet
Line
Neutral
Ground
10
Middle-of-Run Outlet
Line
Neutral
Ground
11
Switched Outlet
Without Insteon Wall Switch
Replacing a switched outlet requires removing the wall switch from
the circuit. The wall switch can be replaced by an Insteon Wall
Switch or Keypad if control is still desired.
Neutral
Line
Ground
Line
Neutral
Ground
12
Switched Outlet
With Insteon Wall Keypad
Line
Neutral
Ground
Line
Neutral
Ground
13
ChapterLinks
Insteon
Title
Chapterdevices
Insteon
explanation
can stand alone and function as a local switch or dimmer,
but their real power comes when they are connected together to form a
control system. Most Insteon devices can control one another and be the
recipient of control. The process of associating multiple Insteon devices to
one another is called Linking.
14
Understanding Linking
Links are One-Way
When linking Insteon devices, the links that
are created are one-way.
Links Remember a Device’s State
The current state of the controlled device is
stored in the link: On, off or dimmed.
NEW
NEW
75%
A
B
Switch A will turn Switch B on and off but
Switch B cannot turn Switch A on or off.
X
Controllers
Insteon devices that can turn other devices on
or off are called controllers.
NEW
Switch
Lamp Dimmer
The switch will turn on the Lamp Dimmer to
75% brightness.
X
Responders
Insteon devices that receive the command of a
controller are called responders.
NEW
a
b
c
d
Sensors, Switches, Keypads and the
Hub are common controllers.
X
Switches, Keypads, Plug-In Modules and
LED Bulbs are common responders.
X
15
Understanding Linking
Controller-Only
Some devices, like sensors, can only control
other devices.
Responder-Only
Some devices cannot control other devices;
these devices only receive Insteon commands.
NEW
Motion Sensor
NEW
Dimmer Switch
The Motion Sensor will turn on the Switch
but the switches cannot control the Motion
X
Sensor.
Grouping Devices
You may want to group together two
devices, for example, in a virtual-three way
configuration. For Insteon, this is called Cross
Linking.
LED Bulb
Some devices can only link as
responders to devices and scenes.
X
Use Cross Linking
To Cross Link, simply turn on the devices and
perform the linking process twice, once in
each direction.
NEW
Load
A
B
To mirror Switch A and B so that they each
control one another and the connected
load, Cross Linking is necessary.X
Dimmer Switch
NEW
A
B
Link Switch A to Switch B and repeat to link
Switch B to Switch A.
X
16
Adding to the Insteon Hub
1
Tap the Add a Device button.
iOS
Android
Open the drawer by
swiping from the right
side of your iOS device
Navigate to All Devices
from Rooms on your
Android device
2
Windows Phone
Navigate to All Devices
from Rooms on your
Windows Phone device
When prompted, press and hold one
of the set buttons on your Wall Outlet
until the device beeps.
Your Wall Outlet is now added to
your Insteon Hub.
17
Chapter Title Features
Software-Only
Chapter
Most
Insteon
explanation
devices contain features that can only be enabled, disabled
or modified using Insteon control software such as HouseLinc and an
Insteon PowerLine Modem.
18
Software-Only Features
Beep on Button Press
The Wall Outlet will beep every time one of its
buttons are tapped. By default, this feature is
disabled.
Disable Local Programming
Prevents changing any settings using the set
button or tap-and-hold programming.
Blink on Traffic
The Wall Outlet LED will blink if it detects
Insteon communication. By default, this
feature is disabled.
Error Blink
The Wall Outlet LED will blink red once if one
or more responders do not acknowledge
a message and will blink green once if all
responders successfully acknowledge a
message. By default, this feature is enabled.
19
Software-Only Features
LED Brightness
Adjust the brightness of the status LEDs from
full bright to off.
20
Chapter
Local
Programming
Title
Chapter explanation
Encompassing
all on-device programming options, use the local
programming to set local properties.
properties and
For factory
the bestreset.
experience,
For the use
best
experience,
software
for use
managing
software
device
for managing
properties.
device properties.
21
Navigating the Chart
To move right, press and
hold the set button
Status LED
blinks green
Status LED doubleblinks green
To move down,
tap the set button
Status LED
blinks red
Status LED
double-blinks red
Features
Linking Mode
Multi-Linking Mode
Unlinking Mode
Multi-Unlinking Mode
Readies the module for linking to another Insteon device. As linking is directional,
the first device placed into linking mode will become the controller in the controller/
responder relationship. The second device will become the responder. The device
automatically exits linking mode after a link has been made with another Insteon
device.
Readies the module for linking to multiple Insteon devices. The device will remain
in linking mode for 4 minutes or until the device’s set button is tapped. This mode
is very usefully for manually creating scenes.
Allows the removal of links from the Insteon device. The device will automatically
exit unlinking mode after a link has been removed from another Insteon device.
Allows the removal of multiple links from the Insteon device. The device will stay in
unlinking mode for 4 minutes or until the device’s set button is tapped.
22
Flow Chart
Linking Mode
Press
Unlinking Mode
Select
Tap
Tap
Multi-Linking
Mode
Press
Press
Exit
Multi-Unlinking
Mode
Select
Press
Exit
Tap
Tap
Exit
Exit
23
LED Brightness
Upper set button only
For a bright status
LED, make sure the
upper LED is green.
Linking Mode
Unlinking Mode
Press
Press
Status LED
Brightness
Press
Status LED
Brightness
Bright
Bright
For a dim status
LED, make sure the
upper LED is red.
Linking Mode
Unlinking Mode
Press
Dim
Dim
RF Beacon
Upper or lower set button
Tap 4x
RF Beacon
Mode
Quickly
Exit
Tap
24
Load Sense
Enable
Linking Mode
Tap 3x
Quickly
Enable Load
Sense
Load Sense
Disable
Linking Mode
Tap 2x
Quickly
Disable Load
Sense
25
Soft Factory Reset
Upper and lower set buttons
A Soft Factory Reset will erase all device
settings including any links made with the top
and bottom outlets. If On/Off Outlet does not
respond, attempt the Alternate Factory Reset.
Linking Mode
Press
Unlinking Mode
Tap 2x
Quickly
Soft Factory
Reset
Press & Hold
Reset
Tap
Exit
26
Chapter Reset
Factory
Title
Chapter
A
factoryexplanation
reset will erase all links stored in the device’s database as well as
any customized properties.
27
Factory Reset
Alternate Procedure
Factory Reset will erase all device
settings including any links made
with the top and bottom outlets
1
2
Press and hold the upper set
button.
Turn off power to your outlet at the
electrical service panel.
ON
ON
or
Circuit Breakers
Fuse Panel
An assistant will be required to turn
power on and off at the service panel.
3
Have your assistant turn power on
to the outlet at the circuit breaker
panel while continuing to press
and hold the set button.
4 Wait for the Outlet to emit a long
beep. When the beep ends,
release the set button. The switch
will double beep.
LONG
ON
ON
ON
ON
ON
ON
ON
or
ON
ON
ON
Circuit Breakers
Fuse Panel
Your Wall Outlet has been restored
to factory settings.
28
Appendix
Everything else you might need to know about your Insteon product.
29
Specifications
General
Brand:
Insteon
FCC ID
SBP26632
Industry Canada
Manufacturer Product No.:
Patent No.:
UPC:
Warranty:
5202A-26632
2663-222 White
2663-223 Ivory
2663-224 Almond
2663-225 Light Almond
2663-226 Black
2663-227 Brown
2663-228 Grey
Protected under US and Foreign Patents
(see www.insteon.com/patents)
813922013801 White
813922013818 Ivory
813922013825 Almond
813922013832 Light Almond
813922013849 Black
813922013856 Brown
813922013863 Grey
2 years, limited
Operation
Local Control
Setup Memory
Status LED
Yes
Non-volatile EEPROM
Red/Green LEDs
Insteon Features
Insteon Device Category
0x02
Insteon Device Subcategory
0x39
Insteon ID
1
Insteon Links
417
Insteon Messages Repeated
Yes
Insteon Minimum Receive Level
10 mV
Insteon Minimum Transmit Level
3.2 Vpp into 5 Ohms
30
Insteon Powerline Device
Insteon Powerline Frequency
Yes
131.65 KHz
Insteon RF Device
Yes
Maximum Controlled Scenes
400
Maximum Scene Memberships
400
RF Beacon
Yes
Radio Frequency
Radio Frequency Range
915.0 MHz US/Canada
Up to 250 feet
Software Configurable
Yes
Beep on Button Press
Yes, Software configurable
Mechanical
Beeper
Dimensions
Depth into Electrical Box
Enclosure Material
Mounting
Operating Environment
Operating Humidity Range
Operating Temperature Range
Set Button
Storage Temperature Range
Weight
Yes
4.1” H x 1.73” W x 1.6” D
104mm H x 44mm W x 40mm D
1.3”
33mm
UV stabilized plastic
Single or multi-gang junction boxes
Indoors
0-90% relative humidity
32º to 104º F
0º to 40º C
Yes
-4º to 158º F
-20º to 70º C
4.5 oz
128 g
31
Electrical
Power Consumption
<0.4 Watts
Supply Voltage
120 Volts AC, 50/60 Hertz, single phase
Maximum Load
600W Incandescent
15A All Other Loads
Surge Resistance
Surges over 1000 volts
Power Connector
NEMA 5-15R
Certification
FCC ID Part 15B & 15C
IC RSS-210 Issue 8
UL-498 Safety standard for receptacles
CSA C22.2 #42 Including sections 131-135
for tamper-resistant outlets
UL-244A, CAN/CSA C22.2#14 Standard for solid-state
controls for appliances
32
Troubleshooting
The LED lights on the Wall Outlet are not illuminated
It is possible that your outlet is not getting power or that the status LEDs have been disabled.
Try this:
•
Check to make sure power is flowing to your Insteon Wall Outlet. If your outlet was just installed, make
sure the circuit breaker controlling the switch has been turned on. It is also advisable to verify the wire
connections in the junction box are secure and not showing any bare wire.
•
If the outlet works and the connected device can be controlled, use software or the Local Programming
Flowchart to change the behavior of the status LED. The status LED brightness can be dimmed to the
point that it appears off. The Insteon Hub and other central controller software allow setting of this device
property.
Unable to add the Wall Outlet to a scene as a controller or a responder
If the device has power, something is likely interfering with the Insteon signal. Large appliances, power strips and
some electronic devices may generate powerline noise.
Try this:
•
Check to see if you have connected your Wall Outlet downstream of a GFCI outlet. GFCI outlets often
unintentionally filter out the Insteon powerline signal. If testing the GFCI outlet disconnects power to your
Wall Outlet, investigate alternative wiring options.
•
Large appliances like refrigerators or air conditioners may be generating powerline noise that is disrupting
the Insteon signal. If the issue only appears to happen when one of these large appliances is running, install
a noise filter at that device. If you are uncertain of the device generating the noise, disconnect the potentially
offending devices from power and test your Wall Outlet again. If the issue is resolved, install noise filters at
each offending appliance.
•
Some small electronics devices that include an AC/DC power supply can generate substantial electrical
noise, in some cases, enough to disrupt an entire house of Insteon devices. Search your home for speaker
docks, small stereos, etc. and disconnect them from power to perform testing. If removing these devices
from your powerline resolves the Insteon issue, install a noise filter at each offending small electronic
appliance.
•
Your Wall Outlet may be too far from another Insteon device to receive a signal. Try locating a Range
Extender or other Dual-Band Insteon device between the location of your Wall Outlet and the next nearest
Insteon device.
The Wall Outlet is slow to respond to commands from a controller
This issue most likely lies with the controller, not the Wall Outlet; the controller is most likely repeating commands
not acknowledged by an Insteon device that has been removed from the network. The repeated commands are
slowing down the Insteon network, resulting in a delayed response from the Wall Outlet.
Try this:
•
Consider if you have removed any Insteon devices from you network that were part of the slow-to-respond
scene. If so, the links to these devices need to be removed from the controller. Use software to examine the
database of the controller or if you know the modules that were removed, manually remove their links using
the standard unlinking procedure.
•
If you are unable to identify the missing devices, perform a factory reset on the controller. This will remove
all links from the controller’s database but will also require that you reconfigure the device’s scenes and
properties.
33
Troubleshooting
The connected light turned on by itself
There must be a device in your Insteon network that is unexpectedly linked to the Wall Outlet.
Try this:
•
Use software to examine the Wall Outlet’s links. If you can identify the stray controller, remove the link.
•
If you are unable to identify the unexpected controller, perform a factory reset on the Wall Outlet. This will
remove all links from the module’s database but will also require that you reconfigure the device’s scenes
and properties.
Using a controller, the Wall Outlet will turn off but not turn on
Most likely, the Wall Outlet was linked to the controller with the load set to Off
Try this:
•
Make sure the Wall Outlet’s connected load is on and then re-link the device to your Insteon controller. This
link will overwrite the previous “off” link.
The Wall Outlet does not respond to button taps or controller links
A power surge or excessive powerline noise may have caused the outlet to unexpectedly stop responding.
Try this:
•
Temporarily disconnect your outlet from power by turning power off at the electrical service panel. Wait
about 10 seconds and then restore power. Test the outlet to see if the load will turn on or off.
•
While unusual, the Wall Outlet may require a factory reset to restore normal operation. Follow the procedure
outlined in Local Programming to reset the device to factory settings. You will be required to reconfigure the
device’s scenes and properties after the reset.
After installing the Wall Outlet, the switch produces a long, continuous beep
Your Wall Outlet has been wired incorrectly and will not function.
Try this:
•
Turn off power and verify the wire connections in the junction box are secure, not showing any bare wire
and labeled correctly. The color of wire in your junction box may differ from the installation diagrams and
it is possible that the function of the wire is incorrect for its color. Use a voltage detector or multi-meter to
properly identify line and neutral. If you are unable to do so, contact an electrician.
34
Certifications and Warnings
This product is not designed or approved for use on powerlines other than 120VAC, 50Hz or 60Hz, single
phase. Attempting to use this product on unapproved powerlines may have hazardous consequences.
•
Use only indoors or in outdoor rated box
•
This product may feel warm during operation. The amount of heat generated is within approved limits and
poses no hazards. To minimize heat buildup, ensure the area surrounding this product is as clear of clutter
as possible.
•
Each Insteon product is assigned a unique Insteon I.D., which is printed on the product’s label.
•
To reduce the risk of overheating and possible damage to other equipment, do not use this product to
control loads in excess of the specified maximum(s) or, install in locations with electricity specifications
which are outside of the product’s specifications. If this device supports dimming, please note that dimming
an inductive load, such as a fan or transformer, could cause damage to the dimmer, the load bearing
device, or both. If the manufacturer of the load device does not recommend dimming, use a non-dimming
Insteon device. USER ASSUMES ALL RISKS ASSOCIATED WITH DIMMING AN INDUCTIVE LOAD.
The digital circuitry of this device has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15B of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in residential installations. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio and television reception. However, there is no guarantee that interference will not occur in
a particular installation. If this device does cause such interference, which can be verified by turning the device
off and on, the user is encouraged to eliminate the interference by one or more of the following measures: •
Re-orient or relocate the receiving antenna of the device experiencing the interference • Increase the distance
between this device and the receiver • Connect the device to an AC outlet on a circuit different from the one that
supplies power to the receiver • Consult the dealer or an experienced radio/TV technician.
WARNING: Changes or modifications to this device not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Cet appareil a été testé et s’avère conforme aux restrictions relatives aux équipements numériques de classe B,
d’après l’article 15 des règlements du Conseil supérieur de l’audiovisuel américain (FCC). Ces restrictions ont
été instaurées pour offrir une protection raisonnable contre les interférences nuisibles au sein d’une installation
résidentielle. Cet appareil génère, utilise et peut émettre des fréquences radio et s’il n’est pas installé selon les
instructions, peut nuire aux radiocommunications. Toutefois, rien ne garantit que des parasites ne surviendront
pas dans une installation particulière. Si cet appareil cause des interférences nuisibles à la réception du
téléviseur ou de la radio, ce que vous pouvez déterminer en ouvrant et en fermant votre appareil, nous vous
invitons à essayer l’une des mesures correctives suivantes : • Réorientez l’antenne de réception installée sur
l’appareil qui manifeste les parasites.
• Éloignez l’appareil du composant qui reçoit les ondes. • Branchez l’appareil dans une prise de courant CA
différente de celle du composant qui reçoit les ondes. • Au besoin, consultez votre marchand électronique ou un
technicien spécialisé dans le service des radios/téléviseurs pour des suggestions supplémentaires.
35
Product Warranty
Limited Warranty
Seller warrants to the original consumer purchaser of this product that, for a period of two years from the date
of purchase, this product will be free from defects in material and workmanship and will perform in substantial
conformity to the description of the product in this Owner’s Manual. This warranty shall not apply to defects or
errors caused by misuse or neglect. If the product is found to be defective in material or workmanship, or if the
product does not perform as warranted above during the warranty period, Seller will either repair it, replace it,
or refund the purchase price, at its option, upon receipt of the product at the address below, postage prepaid,
with proof of the date of purchase and an explanation of the defect or error. The repair, replacement, or refund
that is provided for above shall be the full extent of Seller’s liability with respect to this product. For repair or
replacement during the warranty period, call 866-243-8022 with the Model # and Revision # of the device to
receive an RMA# and send the product, along with all other required materials to:
Insteon
ATTN: Receiving
16542 Millikan Ave.
Irvine, CA 92606-5027
Limitations
The above warranty is in lieu of and Seller disclaims all other warranties, whether oral or written, express or
implied, including any warranty or merchantability or fitness for a particular purpose. Any implied warranty,
including any warranty of merchantability or fitness for a particular purpose, which may not be disclaimed
or supplanted as provided above shall be limited to the two-year of the express warranty above. No other
representation or claim of any nature by any person shall be binding upon Seller or modify the terms of the
above warranty and disclaimer.
Home automation devices have the risk of failure to operate, incorrect operation, or electrical or mechanical
tampering. For optimal use, manually verify the device state. Any home automation device should be viewed as
a convenience, but not as a sole method for controlling your home.
In no event shall Seller be liable for special, incidental, consequential, or other damages resulting from
possession or use of this device, including without limitation damage to property and, to the extent permitted by
law, personal injury, even if Seller knew or should have known of the possibility of such damages. Some states
do not allow limitations on how long an implied warranty lasts and/or the exclusion or limitation of damages, in
which case the above limitations and/or exclusions may not apply to you. You may also have other legal rights
that may vary from state to state.
Protected under U.S. and foreign patents (see www.insteon.com/patents)
© 2014 Insteon
Rev 12.01.14
36
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
