Canon 0515C002 Specification

Canon 0515C002 Specification
Duplex Printing
XL & XXL Inks
Print 2-sided and cut your paper
usage by up to 50%.
Print up to double the amount
of photos and documents with
optional inks.
Wireless printing options at your fingertips.
Print Features
Print Speed11,12
Number of Nozzles
AirPrint,1 Duplex Printing, Auto Photo Fix II, Borderless Printing,2
Document Printing, Easy PhotoPrint+,3 Full HD Movie Print,4 Google
Cloud Print,5 Mopria Device Printing,6 My Image Garden,7 Photo Printing,
Canon PRINT app,8 PIXMA Cloud Link,9 Red-Eye Correction, Image
Cropping, Quiet Mode, Special Filters, Wireless Printing10
4" x 6" Borderless Photo: Approx. 44 seconds
ESAT (Black): Approx. 9.9 ipm
ESAT (Color): Approx. 5.7 ipm
Color: 1,152 / Pigment Black: 640 / Total: 1,792
Picoliter Size (Color)
2 and 5
Print Resolution13
Color: Up to 4800 x 1200 dpi
Pigment Black: Up to 600 x 600 dpi
Paper Sizes
4" x 6," 5" x 7," 8" x 10," Letter, Legal, U.S. #10 Envelope
Paper Tray Capacity
100 Sheets Plain Paper, or 20 Sheets of Photo Paper (4" x 6")
Copy Features
Borderless Copy, Fit-to-Page
Copy Speed11
FCOT (Color): Approx. 22 seconds
Scan Features
Auto Scan Mode,14 Network Scan, Wireless Scanning
Scanner Type
Scanning Method
Contact Image Sensor (CIS)
Scanning Resolution15
1200 x 2400 dpi (Optical), 19,200 x 19,200 dpi (Interpolated)
Maximum Color Depth
48-bit Input / 24-bit Output
Maximum Document Size
8.5" x 11.7"
General Features
Hybrid Ink System, 4-Color Cartridge System, CREATIVE PARK
PREMIUM,16 Wi-Fi LED, FastFront, Rated EPEAT Silver, Auto Power On/
Off, Quiet Mode, Canon PRINT app,8 PIXMA Cloud Link9
Standard Interface
Hi-Speed USB, PictBridge (Wireless LAN),17 Wireless LAN (IEEE 802.11b/g/n)10
17.7"(L) x 12.0"(W) x 6.0"(H) / 11.9 lbs.
Software (Windows®18/Mac®19)
Setup Software and User’s Guide CD-ROM, PIXMA MG3620 Printer
Driver, My Image Garden7 (Full HD Movie Print,4 CREATIVE PARK
PREMIUM,16 Special Filters, Image Correction/Enhance, and scanning are
accessed through My Image Garden), Quick Menu
OS Compatibility
Computer Operating Systems:
Windows:18 Windows® 8, Windows 8.1, Windows 7, Windows 7 SP1,
Windows Vista® SP1, Vista SP2, Windows XP SP3 32-bit
Mac:19 Mac OS® X v10.7.5-10.10
Mobile Operating Systems: iOS,® Android,™ Windows RT20 and Amazon
Fire devices21
1-Year limited warranty with InstantExchange Program.
1-Year toll-free U.S.-based technical phone support
For the name of the nearest dealer, call: 1-800-OK-CANON
Model No.
Compatible Inks
PIXMA MG3620 Black
Wireless Inkjet All-In-One Printer
PIXMA MG3620 White
Wireless Inkjet All-In-One Printer
PIXMA MG3620 Red
Wireless Inkjet All-In-One Printer
PG-240 XXL
PG-240 XL
CLI-241 XL
XXL Pigment Black Ink Cartridge
XL Pigment Black Ink Cartridge
Pigment Black Ink Cartridge
XL Color Ink Cartridge
Color Ink Cartridge
XL Combo Pack
specifications are subject to change without notice. all output images are simulated.
1 AirPrint functionality requires an iPad, iPhone 3GS or later, or iPod touch 3rd generation or later device running iOS 4.2 or later,
and an AirPrint-enabled printer connected to the same network as your iOS device. A printer connected to the USB port of
your Mac, PC, AirPort Base station, or Time Capsule is not supported.
2 Envelopes and High Resolution Paper are NOT supported for borderless printing.
3 Works edited by using this application cannot be displayed, edited, or printed without this application. Compatible with Android
device of 7 inches or more using Chrome (latest version compatible with your current version of Android OS), iOS Devices of 7
inches or more using Safari 5.1 or later, Windows PC (excluding RT) using Internet Explorer 10 or later of Microsoft Modern UI
version, Microsoft Internet Explorer 9 or later, Mozilla Firefox 31 or later, or Google Chrome version 36 or later, and with Mac
OS X 10.6.8 or later using Safari 5.1 or later.
4 “Full HD Movie Print” is available from “MOV” and “MP4” movie files created by select Canon EOS, PowerShot, and VIXIA
digital cameras and camcorders. Requires PC or Mac with Intel® processor and Canon ZoomBrowser EX 6.5 or later or Canon
ImageBrowser 6.5 or later for “MOV” files, or Canon ImageBrowser EX 1.0 or later for “MOV” or “MP4” files. Print quality is
determined by the video resolution. Function does not upscale video resolution.
5 Requires an Internet connection and Google account. Subject to Google Terms of Service. Certain exceptions may apply.
6 Requires Android mobile device with Android 4.4 operating system or later with the Mopria Print Service pre-loaded with that
device and the compatible PIXMA printer on the same wireless network. The Mopria experience is also available on Android 4.4
mobile devices with a download of the Mopria Print Service from Google Play.
7 To install using Windows® OS, .NET Framework 4 is required. Compatible still image formats are PDF (created using Canon PDF
Creator only), JPEG (Exif), TIFF, and PNG. Compatible video formats are MOV (from select Canon digital cameras only) and MP4
(from select Canon digital camcorders only).
8 Requires the Canon PRINT Inkjet/SELPHY app, available for free on the App Store and at Google Play. Compatible with iPad,
iPhone 3GS or later, and iPod touch 3rd generation or later devices running iOS 7.0 or later, and Android mobile devices running
Android 2.3.3 or later. Your device must be connected to the same working network with wireless 802.11 b/g/n capability as
your printer. Certain functions require an internet connection. For users of compatible Apple mobile devices, document printing
requires Apple AirPrint, which requires an AirPrint-enabled printer connected to the same network as your iOS device. A printer
connected to the USB port of your Mac, PC, AirPort Base station, or Time Capsule is not supported.
9 Requires an Internet connection.
10 Wireless printing requires a working network with wireless 802.11b/g or n capability. Wireless performance may vary based on
terrain and distance between the printer and wireless network clients.
11 Photo print speeds are based on the standard mode driver setting using photo test pattern(s) and select Canon Photo Paper.
Print speed is measured as soon as first page begins to feed into printer and will vary depending on system configuration,
interface, software, document complexity, print mode, types of paper used, and page coverage.
See for additional information.
12 ISO/IEC 24734, 24735 define the default print and copy speed measurement methods. Print speeds are the averages of ESAT
in Office Category Test for the default simplex mode, ISO/IEC 24734, excluding time to print the first set. Copy speed is the
average of FCOT, ISO/IEC 24735 Annex D. See for additional details.
13 Resolution may vary based on printer driver setting. Color ink droplets can be placed with a horizontal pitch of 1/4800 inch
at minimum.
14 “For network users, Auto Scan Mode is only available when scanning at a computer using My Image Garden software and
selecting the 1-click feature then “Save to PC.”
15 Optical resolution is a measure of maximum hardware sampling resolution, based on ISO 14473 standard.
16 CREATIVE PARK PREMIUM is a premium content service available exclusively to users only when all of the colors of genuine
Canon inks and all of the software that came with the printer are properly installed. Operation can only be guaranteed on a PC
with pre-installed Windows 8.1, Windows 8, Windows 7, Vista or XP.
17 DPS over IP compatible device required.
18 Operation can only be guaranteed on a PC with pre-installed Windows 8.1, Windows 8, Windows 7, Vista or XP.
19 Internet Connection required during software installation.
20 Requires a Windows RT compatible device and the Canon Easy-PhotoPrint app for Windows RT available for free in the
Windows Store.
21 Requires “Canon Print Plugin” available for free from the Amazon Appstore and an Amazon Fire Phone, Amazon Kindle Fire HD6
or HDX7 device or later running Fire OS 4.0 or later.
22 Warranty programs are subject to certain conditions and restrictions. See for details.
