Safe-T-Strap Re-Roof Cross Arm Strap Installation guide

Safe-T-Strap Re-Roof Cross Arm Strap Installation guide
COPYRIGHT© 1994 SAFE-T-STRAP
ALL RIGHTS RESERVED.NO PART OF THIS PUBLICATION MAY BE REPRODUCED, STORED IN A RETRIEVAL
SYSTEM, OR TRANSMITTED IN ANY FORM OR BY ANY MEANS, ELECTRONIC MECHANICAL, PHOTCOPYING,
RECORDING OR OTHERWISE, WITHOUT THE PRIOR WRITTEN PERMISSION OF SAFE-T-STRAP (A DIVISION OF
WEBTECH SAFETY PRODUCTS)
WARNING !!!!!
•
•
•
•
FAILURE TO READ AND UNDERSTAND THESE INSTALLATION PROCEDURES MAY RESULT IN SERIOUS
INJURED OR DEATH.
MAKE CERTAIN THAT THE SAFE-T-STRAP HAS NOT BEEN DAMAGED IN SHIPMENT PRIOR TO USE.
THE SAFE-T-STRAP IS AN ENGINEERED PRODUCT. IT MUST BE RETURNED TO THE ORIGINAL SUPPLIER
FOR REPAIR (IF REQUIRED).
SYNTHETIC STRAPS SHOULD NOT BE USED IN EXCESS OF 200 DEGREES FAHRENHEIT. AVOID DAMAGING
FROM WELDING SPARKS AND CORROSIVE CHEMICALS.
IMPORTANT
•
•
•
•
•
CAREFULLY READ AND FOLLOW ALL INSTALLATION INSTRUCTIONS AND ALL SPECIFICATIONS FOR USE
OF THE PRODUCT.
SAFE-T-STRAP IS A NON-REUSABLE FALL-ARREST SYSTEM AND WE ASSUME NO LIABILITY CONNECT
WITH ITS RE-USE
THE USER IS REMINDED BEFORE A SAFE-T-STRAP IS ATTACHED TO ANY MEMBER ON A PROJECT, THE
MEMBER SHALL BE SO FRAMED, FASTENED, TIED AND BRACED SO AS TO PROVIDE THE REQUIRED
STRENGTH AND RIGIDITY.
SAFE-T-STRAP MUST BE INSTALLED AS REQUIRED BY THE MANUFACTURER’S PROCEDURE UNDER THE
SUPERVISION OF A COMPETENT PERSON TRAINED IN IT’S PROPER INSTALLATION.
THE SAFE-T-STRAP IS A COMPONENT OF A FALL-ARREST SYSTEM. LOCATION OF INDIVIDUAL STRAPS
WILL VARY AND SPECIFIC PROCEDURES FOR INSTALLATION WILL BE REQUIRED TO ENSURE ADEQUATE
FALL PROTECTION FOR WORKERS.
THE SAFE-T-STRAP RE-ROOF ANCHOR IS FASTENED WITH 3 ¼ INCH FRAMING NAILS, OR 3 INCH COMMON NAILS.
A TOTAL OF 6 NAILS EACH SIDE MUST PENETRATE THROUGH THE STRAPS FOLDED STITCHED AREA, THROUGH
THE ROOF SHEATHING AND INTO A TRUSS OR RATHER. NAILS MUST BE HAMMERED IN PLACE SECURELY.
CAUTION: USER IS REMINDED THAT A LANYARD MUST BE CONNECTED BETWEEN THE WORKERS BELT AND THE
SAFE-T-STRAP
