Microwave
Solo Oven
Instruction
EM031M2EC-CHSS
Welcome to the world of
TOSHIBA
BEFORE OPERATING THIS PRODUCT,
READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
BE SURE TO SAVE THIS BOOKLIST FOR FUTURE REFERENCE
CONTENTS
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
IMPORTANT SAFETY INSTRUCTIONS
GROUNDING INSTRUCTIONS
UTENSILS
SETTING UP YOUR OVEN
OPERATION
MAINTENANCE
PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
1. Do not attempt to operate this oven with the door open since this can result
in harmful exposure to microwave energy. It is important not to
defeat or tamper with the safety interlocks.
2. Do not place any object between the oven front face and the door or allow
soil or cleaner residue to accumulate on sealing surfaces.
3. Do not operate the oven if it is damaged. It is particularly important
that the oven door closes properly and that there is no damage to the:
a. DOOR (bent)
b. HINGES AND LATCHES (broken or loosened)
c. DOOR SEALS AND SEALING SURFACE
4. The oven should not be adjusted or reparied by anyone except properly
qualified service personnel.
Specifications
Model:
EM031M2EC-CHSS
Rated Voltage:
120V~ 60Hz
Rated Input Power(Microwave):
1500W
Rated Output Power(Microwave):
1000W
Oven Capacity:
1.1 cu.ft.
Turntable Diameter:
12.4 inch
External Dimensions:
20.2X15.7X12.1 inch
Net Weight:
Approx. 32.0 Lbs
EN-2
IMPORTANT SAFETY
INSTRUCTIONS WARNING
To reduce the risk of burns, electric shock, fire, injury to persons or
exposure to excessive microwave oven energy when using your appliance, follow basic safety precautions, including the following:
1. Read all instructions before using the appliance.
2. Read and follow the specific: " PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY" found on page 2.
3. As with most cooking appliances, close supervision is necessary to reduce the risk
of a fire in the oven cavity.
4. To reduce the risk of fire in the oven cavity:
a. Do not overcook food. Carefully attend the appliance when paper, plastic, or other
combustible materials are placed inside the oven to facilitate cooking.
b. Remove wire twist-ties and metal handles from paper or plastic containers/ bags
before placing them in the oven.
c. If materials inside the oven ignite, keep the oven door closed. Turn the oven off,
and unplug the appliance. Disconnect the power cord, shut off power at the fuse
or circuit breaker panel.
d. Do not use the cavity for storage purposes. Do not leave paper products, cooking
utensils, or food in the cavity when not in use.
5. This oven must be grounded. Connect only to properly grounded outlet. See
"GROUNDING INSTRUCTIONS" found on page 6.
6. Install or locate this oven only in accordance with the installation instructions
provided.
7. Some products such as whole eggs and sealed containers-for example, closed glass
jars-are able to explode and should not be heated in the oven.
EN-3
IMPORTANT SAFETY
INSTRUCTIONS WARNING
8.
Use this appliance only for its intended uses as described in this manual. Do not
use corrosive chemicals or vapors in this appliance. This oven is specifically
designed to heat or cook or dry food. It is not designed for industrial or laboratory use.
9.
As with any appliance, close supervision is necessary when used by children.
10. Do not operate this oven if it has a damaged cord or plug, if it is not working
properly or if it has been damaged or dropped.
11. This microwave should be serviced only by qualified service personnel.
Contact nearest authorized service facility for examination, repair or adjustment.
12. Do not cover or block any openings on the oven.
13. Do not store or use this appliance outdoors.
14. Do not use this oven near water, for example, near a kitchen sink, in a wetbasement,
near a swimming pool, or similar locations.
15. Do not immerse cord or plug in water.
16. Keep cord away from heated surfaces.
17. Do not let cord hang over edge of table or counter.
18. When cleaning surfaces of door and oven that comes together on closing the door,
use only mild, nonabrasive soaps or detergents applied with a sponge of soft cloth.
19. This appliance is for private household use only.
EN-4
IMPORTANT SAFETY
INSTRUCTIONS WARNING
20. Liquids, such as water, coffee, or tea are able to be overheated beyond the
boiling point without appearing to be boiling. Visible bubbling or boiling when
the container is removed from the microwave oven is not always present. THIS
COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN THE
CONTAINER IS DISTURBED OR A SPOON OR OTHER UTENSIL IS INSERTED INTO
THE LIQUID.
a. Do not overheat the liquid.
b. Stir the liquid both before and halfway through heating it.
c. Do not use straight-sided containers with narrow necks.
d. After heating, allow the container to stand in the microwave oven for a short
time before removing the container.
e. Use extreme care when inserting a spoon or other utensil into the container.
SAVE THESE INSTRUCTIONS
EN-5
GROUNDING INSTRUCTIONS
DANGER
Electric Shock Hazard
Touching some of the internal components can cause serious personal injury or
death. Do not disassemble this appliance.
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric
current. To protect against electrical shock, this appliance is equipped with a cord
having a 3 prong grounding-type plug for insertion into a proper grounding-type
receptacle. DO NOT alter the plug for use in a 2-prong receptacle. If the plug will not
fit into a receptacle, have the proper receptacle installed by a qualified electrician.
CAUTION:
Do not insert your fingers into any gaps or holes; it may cause injuries.
WARNING
Three-pronged
(grounding) plug
Improper use of the grounding can result
in a risk of electric shock
EN-6
GROUNDING INSTRUCTIONS
Consult a qualified electrician or serviceman if the grounding instructions are not
completely understood or if doubt exists as to whether the appliance is properly
grounded. If it is necessary to use an extension cord, use only a 3-wire extension
cord that has a 3-pronged grounding plug , and a 3-slot receptacle that will accept
the plug on the appliance.The marked rating of the extension cord shall be equal to
or greater than the electrical rating of the appliance.
1. A short power-supply cord is provided to reduce the risks resulting from becom-
ing entangled in or tripping over a longer cord.
2. Longer cord sets or extension cords are available and may be used if care is
exercised in their use.
3. If a long cord sets or extension cord is used:
a. The marked electrical rating of the cord set or extension marked electrial
rating of the cord set or extension cord should be at least as great as the
electrical rating of the appliance.
b. The extension cord must be a grounding -type 3-wire cord.
c. The longer cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over unintentionally.
EN-7
GROUNDING INSTRUCTIONS
RADIO INTERFERENCE
Operation of the microwave oven may cause interference to your radio, TV or
similar equipment.
When there is interference, it may be reduced or eliminated by taking the following measures:
a. Clean door and sealing surface of the oven.
b. Reorient the receiving antenna of radio or television.
c. Relocate the microwave oven with respect to the receiver.
d. Move the microwave oven away from the receiver.
e. Plug the microwave oven into a different outlet so that microwave oven and
receiver are on different branch circuits.
EN-8
GROUNDING INSTRUCTIONS
UTENSILS
CAUTION
Electric Shock Hazard
Tightly-closed utensils could explode. Closed containers should be opened and
plastic pouches should be pierced before cooking.
See the instructions on "Materials you can use in microwave oven or to be avoided
in microwave oven." There may be certain non-metallic utensils that are not safe to
use for microwaving. If in doubt, you can test the utensil in question following the
procedure below.
SAVE THESE INSTRUCTIONS
HOUSEHOLD INDOOR USE ONLY
UTENSIL TEST:
1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the
utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave
cooking.
4. Do not exceed 1 minute cooking time.
EN-9
MATERIALS YOU CAN USE IN MICROWAVE OVEN
UTENSILS
REMARKS
Browning dish
Follow manufacturer’s instructions.The bottom of browning dish
must be at least 3/16 inch (5mm) above the turntable. Incorrect
usage may cause the turntable to break.
Dinnerware
Microwave-safe only. Follow manufacturer’s instructions. Do not
use cracked or chipped dishes.
Glass jars
Always remove lid. Use only to heat food until just warm. Most
glass jars are not heat resistant and may break.
Glassware
Heat-resistant oven glassware only. Make sure there is no metallic
trim. Do not use cracked or chipped dishes.
Oven cooking bags
Follow manufacturer’s instructions. Do not close with metal tie.
Make slits to allow steam to escape.
Paper plates and cups
Use for short–term cooking/warming only. Do not leave oven
unattended while cooking.
Paper towels
Use to cover food for reheating and absorbing fat. Use with
supervision for a short-term cooking only.
Parchment paper
Use as a cover to prevent splattering or a wrap for steaming.
Plastic
Microwave-safe only. Follow the manufacturer’s instructions.
Should be labeled "Microwave Safe". Some plastic cont ainers
soften, as the food inside gets hot. "Boiling bags" and tightly closed
plastic bags should be slit, pierced or vented as directed by
package.
Plastic wrap
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers
Microwave-safe only ( meat and candy thermometers).
Wax paper
Use as a cover to prevent splattering and retain moisture.
EN-10
MATERIALS TO BE AVOIDED IN MICROWAVE OVEN
UTENSILS
REMARKS
Aluminum tray
May cause arcing. Transfer food into microwave-safe dish.
Food carton with
metal handle
May cause arcing. Transfer food into microwave-safe dish.
Metal twist ties
May cause arcing and could cause a fire in the oven.
Paper bags
May cause a fire in the oven.
Plastic foam
Plastic foam may melt or contaminate the liquid inside when
exposed to high temperature.
Wood
Wood will dry out when used in the microwave oven and may
split or crack.
EN-11
SETTING UP YOUR OVEN
NAMES OF OVEN PARTS AND ACCESSORIES
Remove the oven and all materials from the ca rton and oven cavi ty. Your
oven comes with the following accessories:
Glass tra y
Turntable ring
Insrtuction Manual
1
1
1
A
F
E
D
C
B
G
A.
B.
C.
D.
E.
F.
G.
EN-12
Control panel
Turntable shaft
Turntable ring
Glass tray
Observation window
Oven Door
Safet y int erl ock syst em
SETTING UP YOUR OVEN
TURNTABLE INSTALLATION
Hub (underside)
Glass tray
Turntable shaft
Turntable ring
a. Never place the glass tray upside down. The glass tray should never be restricted.
b. Both glass tray and turntable ring must always be used during cooking.
c. All food and containers of food are always placed on the glass tray for cooking.
EN-13
SETTING UP YOUR OVEN
COUNTERTOP INSTALLATION
Remove all packing material and accessories. Examine the oven for any damage such as dents or
broken door. Do not install if oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not remove
the light brown Mica cover that is attached to the oven cavity to protect the magnetron.
INSTALLATION
1. Select a level surface that provide enough open space for the intake
and/or outlet vents.
12 inches(30cm )
3.0 inches(7.5cm )
OPEN
3.0 inches(7.5cm )
A minimum clearance of 3.0 inches (7.5cm) is required between the oven and any adjacent walls.
One side must be open.
(1) Leave a minimum clearance of 12 inches (30cm) above the oven.
(2) Do not remove the legs from the bottom of the oven.
(3) Blocking the intake and/or outlet openings can damage the oven.
(4) Place the oven as far away from radios and TV a s possible.
Operation of microwave oven may cause interference to your radio or TV reception.
EN-14
SETTING UP YOUR OVEN
INSTALLATION
2. Plug your oven into a standard household outlet. Be sure the voltage and
the frequency is the same as the voltage
WARNING
Do not install oven over a range cooktop or other heat-producing appliance. If installed near or over a heat source, the oven could be damaged
and the warranty would be avoid.
The accessible surface may
be hot during operation
EN-15
OPERATION
CONTROL PANEL AND FEATURES
(12)
(5)
(1)
(2)
(3)
(4)
(6)
(7)
(8)
(9)
(10)
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
Time Cook
Time Defrost
Power Level
Clock and Settings
Weight Defrost
Kitchen Timer
Auto Menu (Popcorn,Potato,Pizza,Frozen Vegetable,Bevereage amd Dinner Plate)
Number Pads
START/ +30 SEC
Stop/Cancel: STOP Cancel Hold 3 sec: Before cooking starts, press to clear all
previous settings. During cooking, press once to stop oven; press twice
to stop oven and clear all settings.
(11) Memory
(12) Display
EN-16
OPERATION
1.POWER LEVELS
Ten power levels are available.
Prior to cooking, press Power Level and "PL10" will display. Then press
number pads to select a different power level.
Level
10
9
8
7
6
5
4
3
2
1
Power
100%
90%
80%
70%
60%
50%
40%
30%
20%
10%
Display
PL10
PL 9
PL 8
PL 7
PL 6
PL 5
PL 4
PL 3
PL 2
PL 1
2.CLOCK SETTING
When the microwave oven is plugged into an outlet, "0:00" will display.
(1) Press Clock & Settings once, "00:00" will appear in the display.
(2) Press the number pads to enter the current clock time. For example, if the time is
now 10:12, press " 1, 0, 1, 2 " in order.
(3) Press Clock & Settings to finish clock setting, " : " will flash and the numbers will
appear as a clock time in the display.
NOTE:
If the numbers entered are not within the range between 1:00 to 12:59, the setting
will not be accepted until valid numbers are entered.
In the process of setting clock, if the
pad is pressed or if there is no operation
within 1 minute, the display will automatically return to the previous clock setting.
EN-17
OPERATION
3. KITCHEN TIMER
(1) Press Kitchen Timer once, "00:00" will appear in the display.
(2) Press the number pads to enter the time amount. The maximum amount of time
that can be entered is 99 minutes, 99 seconds.
(3) Press
to confirm setting, and the timer will start to count down.
(4) When the time amount elapses, the oven will beep 5 times.
Note:
The Kitchen Timer setting is different from the Clock setting; it is simply a timer.
During the Kitchen Timer function, no cooking function can be set into operation.
Kitchen Timer amount cannot be increased by pressing
.
Pressing
will cancel the Timer countdown.
4.MICROWAVE COOK
(1) Press Time Cook , "00:00" will appear in the display.
(2) Press number pads to enter the cooking time. The maximum cooking time is 99
minutes,99 seconds.
(3) Press Power Level, PL10 will flash. Press number pads 0 through 9 to select a
different power level if desired. See the POWER LEVEL table above.
(4) Press
to start cooking. The remaining cooking time will display.
Example : To cook the food with 50% microwave power for 15 minutes.
a.
b.
c.
d.
Press Time Cook , "00:00" will display.
Press "1, 5, 0, 0" in order for 15:00 to appear in the display.
Press Power Level , then press "5" to select 50% microwave power.
Press
to start cooking. Buzzer sounds once. The remaining cooking
time will display.
EN-18
OPERATION
NOTE:
In the process of setting, if the
pad is pressed or if there is no operation within
1 minute, the oven will automatically return to display the clock.
5.ONE TOUCH START
(1) Instant cooking at 100% power level and 1 to 6 minutes cooking time can be
started by pressing number pads 1 to 6. Press
to increase the cooking
time by 30 seconds with each press. The maximum cooking time is 99 minutes,
99 seconds.
(2) Instant cooking at 100% power level and 30 seconds cooking time can be
started by pressing
. Each repeated press will increase cooking time by 30
seconds. The maximum cooking time is 99 minutes, 99 seconds.
NOTE:
Time can also be added in 30 second increments by pressing
during Microwave Cooking, Time Defrost and Multi-stage Cooking.
Time cannot be added by pressing
during Weight Defrost and Kitchen Timer
functions.
6.TIME DEFROST
(1) Press Time Defrost , "dEF2" will appear in the display.
(2) Press the number pads to input the defrost time.
(3) The default microwave power is power level 3. If you want to change the power level,
level, press Power Level once, and PL3 will display; then press the number pad for
the desired power level.
(4) Press
to start defro cooking. And the remaining defrost time will display.
EN-19
OPERATION
7. WEIGHT DEFROST FUNCTION
(1) Press Weight Defrost once,"dEF1" will display.
(2) Press number pads to input weight to be defrosted.
Input the weight range between 4 to100 Oz.
(3) If the weight input is not between 4 to100 Oz, the input will be invalid. A beep
will sound and the unit will not work until valid numbers are entered.
(4) Press
displayed.
to start defrosting and the cooking time remaining will be
8. POPCORN
(1) Press Popcorn , "1.75" will appear in the display.
(2) Press Popcorn two more times to choose the weight, "3.0" and "3.5" will
display in order.
(3) Press
to cook. The remaining time will display. Oven beeps 5 times when
cooking finish.
9. POTATO
(1) Press Potato repeatedly until the number you wish appears in the display
"1", "2", "3" will display in order.
Press Once : 1 potato (approx. 8.0 oz)
Press Twice: 2 potatoes ( approx. 16.0 oz)
Press 3 Times: 3 po tatoes ( approx. 24.0 oz)
(2) Press
to cook. The remaining time will display. Oven beeps 5 times when
cooking finish.
10. FROZEN VEGETABLE
(1) Press Frozen Vegetable , "4.0" will appear in the display.
(2) Press Frozen Vegetable two more times to choose the weight, "8.0" and "16.0" will
display in order.
(3) Press
to cook. The remaining time will display. Oven beeps 5 times when
cooking finish.
EN-20
OPERATION
11. BEVERAGE
(1) Press Beverage , "1" will appear in the display.
(2) Press Beverage two more times to choose the weight, "2" and "3" will
display in order. One cup is about 4.0 Oz.
(3) Press
to cook. The remaining time will display. Oven beeps 5 times when
cooking finish.
12. DINNER PLATE
(1) Press Dinner Plate , "9.0" will appear in the display.
(2) Press Dinner Plate two more times to choose the weight, "12.0" and "18.0" will
display in order.
(3) Press
to cook. The remaining time will display. Oven beeps 5 times when
cooking finish.
13. PIZZA
(1) Press Pizza , "4.0" will appear in the display.
(2) Press Pizza two more times to choose the weight, "8.0" and "14.0" will
display in order.
(3) Press
to cook. The remaining time will display. Oven beeps 5 times when
cooking finish.
EN-21
OPERATION
14. MEMORY FUNCTION
(1) Press Memory to program and choose up to three cooking procedures.Each
procedure will be indicated by 1, 2 or 3 in the display.
(2) Press Memory until your desired procedure number appears in the display.
Press
to begin it. A maximum of two cooking stages can be set for each
procedure.
(3) To program a procedure, follow the steps listed below. Example: Cook food at
80% Power Level for 3 minutes and 20 seconds; save as memory 2.
a.
b.
c.
d.
Press Memory twice; screen displays 2.
Press Time Cook , then press "3" , "2" and "0" in order.
Press Power Level once, then press "8" for "PL 8" to display.
Press
to save the procedure. Oven beeps once.
Or press
twice directly to save and start cooking.
e. To choose the procedure from the memory list, press Memory twice.
Screen will display "2". Press
to run procedure.
NOTE:
Auto Menu cannot be set in Memory function.
15. TURN ON/OFF THE BUZZER SOUND
It is default that the buzzer sounds is open.In waiting state, long pressing on number
8 for 3 seconds, it sounds a long beep, turns off the sound.
When the sounds turn off, long pressing on 8 for 3 seconds, it sounds a long beep
and the sound turn off. All the buttons has no beep when they are pressed, including
the ending cooking sounds is turn off too.
Note: All m odels has m ute function and energy-saved function.
This function can work under lock function too.
EN-22
OPERATION
16.Muti-Stage Cooking
At most 2 stages can be set for cooking. If one stage is Defrost, it will automatically
set to be the first stage.
NOTE: Auto Menu cannot be set in Multi-stage Cooking.
EXAMPLE: 80% Power Level for 5 minutes followed by 60% Power Level for 10
minutes; saved as memory 3.
a. Press Memory 3 times; screen displays 3.
b. Press Time Cook, then press "5" , "0" and "0" to set first stage cook time.
c. Press Power Level once, then press "8" to choose 80% first stage cooking
power.
d. Press Time Cook again, then press "1", "0", "0" and "0" to set second stage
cook time.
e. Press Power Level again, then press "6" to choose 60% second stage cooking
power.
f . Press
to immediately start multi-stage cooking.
g. To choose the procedure from the memory list, press Memory three times.
Screen will display "3"; press
to run procedure.
NOTE:
If you do not want to save a particular multi-stage program as a procedure, do not
press Memory as the first step. Press
after programming both stages.
17.ENERGY SAVER MODE
(1) In standby mode, press the "
" once (less than 3 seconds to avoid
)
starti ng the child lock functi on to enter the Energy Saver mode.
(2) In child-locked mode, press the "
" once (less than 3 seconds)
and release to enter the Energy Saver Mode.
(3) Above operation is the only way to start the Energy Saver mode.
(4) The Energy Saver mode works only if the door is closed.
EN-23
OPERATION
18.LOCK FUNCTION
(1) To lock the microwave so that it cannot be operated by children or other
unintended users, press
pad for 3 seconds. You will hear a long beep.
"
" will display.
(2) To unlock, press
for 3 seconds, you will hear a long beep and "
"
will disappear.
19.INQUIRING FUNCTION
(1) When oven is cooking, press Clock Settings for the time of day to appear for
three seconds in the display.
(2) When oven is cooking, press Power Level pad for cooking power to
appear for three seconds in the display.
20.Cooking End Reminder Function
The oven will beep five times to alert the user that cooking time has ended.
21.
22.Other Specifications
(1)
must be pressed to continue cooking if the door is opened during cooking.
(2) A single beep sounds to indicate that a pad is correctly pressed; if pad is not
correctly pressed, no beep sounds.
EN-24
MAINTENANCE
TROUBLESHOOTING
Check your problem by using the chart below and try the solutions for each problem.
TROUBLE
Possible Cause
Possible Remedy
Oven will not start
a. Electrical cord for oven is not
plugged in.
b. Door is open.
c. Wrong operation is set.
a. Plug into the outlet.
b. Close the door and try again.
c. Check instructions
Arcing or sparking
a. Materials to be avoided in microwave
oven were used.
b. The oven is operated when empty.
c. Spilled food remains in the cavity.
a. Use microwave-safe cookware only.
b. Do not operate with oven empty.
c. Clean cavity with wet towel.
Unevenly cooked foods
a. Materials to be avoided in microwave
oven were used.
b. Food is not defrosted completely.
c. Cooking time, power level is not
suitable.
d. Food is not turned or stirred.
a. Use microwave-safe cookware only.
b. Completely defrost food.
c. Use correct cooking time, power
level.
d. Turn or stir food.
Overcooked foods
Cooking time,
power level is not suitable.
Use correct cooking time,
power level.
Undercooked foods
a. Materials to be avoided in microwave
oven were used.
b. Food is not defrosted completely.
c. Oven ventilation ports are restricted.
d. Cooking time, power level is not
suitable.
a. Use microwave-safe cookware only.
b. Completely defrost food.
c. Check to see that oven venti-lation
ports are not restricted.
d. Use correct cooking time, power
level
Improper defrosting
a. Materials to be avoided inmicrowaa. Use microwave-safe cookware only.
veoven were used.
b. Use correct cooking time, power
b. Cooking time, power level is not
level.
suitable.
c. Turn or stir food
c. Food is not turned or stirred.
Sensor cooked foods
not properly cooked
a. Cover or lid on food not vented.
b. Door opened before sensor-detect ed cooking time appears in display.
EN-25
a. Cover or lid over food must contain
vent hole for escaping steam.
b. Do not open door to stir orturn food
before sensor-detected cooking time
appears in display.
PN:16170000A68187
ONE YEAR LIMITED WARRANTY
This product carries a warranty stating that it will be free from defects in material and
workmanship for a period of one year from the date of purchase. This warranty is valid
for the original retail purchaser from the date of initial retail purchase and is not
transferable. Keep your original sales receipt.
IMPORTANT:
1. This warranty does not cover damages resulting from accident, misuse or abuse,
lack of reasonable care, the affixing of any attachments not provided with the
product, loss of parts, or subjecting the appliance to any but the specified
voltage. ( Read directions carefully. )
2. This warranty is void if this product is ever used for other than private household
purposes.
3. This warranty is void if this product is ever used outside of United States.
If service is required during the warranty period, properly pack your unit. We
recommend using the original carton and packing materials.
If additional assistance is needed, please contact customer assistance at:
[email protected]
855-204-5313
Midea America Corp
5 Sylvan Way,
Parsippany, NJ 07054
Midea America Corp. expressly disclaims all responsibility for consequential damages or
incidental losses caused by use of the appliance. Some states do not allow this exclusion
or limitation of incidental or consequential losses so the foregoing disclaimer may not
apply to you. This warranty gives you specific legal rights, and you may also have other
rights which may vary from state to state.
The serial number can be found on the back cabinet. We suggest that you record the
serial number of your unit in the space below for future reference
Model Number:_______________________
Serial Number:________________________
SAVE THIS FOR YOUR RECORDS
Made in China
EN-26
Customer Assistance: 855-204-533 13
Midea America Corp
5 Sylvan Way, Parsippany, NJ 07054

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
