Hidden Door Sensor
Owner’s Manual
Contents
Getting Started
Hidden Door Sensor
4
Device Overview
Tools Needed for Installation
Test Your Location First
Install in a Window Frame
Installation
Link First
6
Locate the Hole
Drill the Hole
Test the Fit
Using the Spacer
Insteon Links
Linking to the Insteon Hub
Linking to Control Another Device
Already Installed Linking
Multi-Linking or Making a Scene
Unlinking a Device
Multi-Unlinking or Removing a Scene
Local Programming
Local Programming
Factory Reset
Factory Reset
Software-Only Features
Enable Group 1 & 2 Broadcast
7
9
10
11
13
14
15
18
21
23
Disable Local Programming
Disable LED and Beeper
Adjust Heartbeat Interval
Low Battery Warning
Appendix
Specifications
Troubleshooting
Certifications and Warnings
Product Warranty
24
26
29
30
32
Getting Started
Everything you need to quickly get up and running.
3
Hidden Door Sensor
Device Overview
Tools Needed for Installation
Model: 2845-222
Model: 2845-222
Door Sensor
Door Sensor
Contact
Plunger
Set
Button
Status
LED
Power Drill
Battery Isolation Tab
AAA Battery
(Remove before first use)
(Included)
Model: 2845-222
Door Sensor
3/4-inch Spade or Auger Drill Bit
Spacer
Spacer Screw
Test Your Location First
Test your desired location first. Hold the
Door Sensor in it’s intended location and try
linking to your Hub or responder. If linking is
unsuccessful, try repositioning the sensor or
add a Range Extender.
Phillips Screwdriver
Install in a Window Frame
If installing in a window frame, Door Sensor
works best with casement windows.
Follow the same installation steps. Insteon
recommends using Open/Close Sensor
(2843-222) for sash windows.
Door Sensor
Model: 2845-222
X
X
4
Installation
Unbox and read instructions
Test linking in the intended
location
Link with all devices you wish
to control
Drill a mounting hole and test
fit the sensor
Install Door Sensor and
secure with a screw
Oops. Forgot to link a device?
See Already Installed Linking.
5
Installation
Link First
1
As installing Door Sensor obscures its
set button, perform any linking now
before you install the sensor.
Locate the Hole
2
Find a location for Door Sensor in
either the hinge-side of the door frame
or the hinge-side of the door itself.
Higher is better for wireless range but
low will still work.
X
X
For linking instructions, turn to Page 9.
?
If you skip linking now, you can link
later using Five-Tap linking.
Drill the Hole
3
Place masking tape over any surfaces
that may be marred by the drill chuck
and drill a 4-inch deep, ¾-inch diameter
hole. If drilling into the door, have an
assistant hold the door steady.
Test the Fit
4
Clean out any wood shavings with a
vacuum and test fit the sensor. When
ready, insert the sensor into the hole
and fasten with the included screw.
Installation of your Door Sensor is
now complete.
6
Using the Spacer
Slide the spacer over Door Sensor to
increase the thickness of the collar. Fasten
with the screw provided.
Model: 2845-222
Door Sensor
If the gap between your door and door
frame is too wide to depress the contact
plunger, try using the spacer.
7
Insteon Links
Insteon devices can stand alone and function as a local switch or dimmer,
but their real power comes when they are connected together to form a
control system. Most Insteon devices can control one another and be the
recipient of control. The process of associating multiple Insteon devices to
one another is called Linking.
8
Linking to the Insteon Hub
1
From Rooms, navigate to All Devices.
2
Tap the Add button.
All Devices
Rooms
All Devices
Check-In
Favorites
Back Door
Bathroom
Bedroom
Bathroom
Bedroom
Hallway
Font Door
Garage Door
Garage Light
Kitchen
Living Room
Outside
Motion Sensor
Outside Lights
72º
72º
Select Door Sensor from the list of
devices.
4
When prompted, press and hold the
set button on your Door Sensor until
the device beeps.
Add Device
Thermostat
Door Sensor
Open/Close
Sensor
Model: 2845-222
LED Bulb
Door Sensor
3
Add
Your Door Sensor is now added
to your Insteon Hub.
9
Linking to Control Another Device
On your Door Sensor, press and
hold the set button until the device
beeps.
Adjust your responder to the desired
state: On, off, or brightness level if
dimming, and then press and hold the set
button until the device double-beeps.
Model: 2845-222
Door Sensor
2
®
Model: 2845-222
Door Sensor
1
®
Your Insteon controller will now
control your On/Off Module.
10
Already Installed Linking
Link Hidden Door Sensor without removing from your door frame
1
If Your Door Is Already Open
If Your Door Is Closed
Open your door and press and release
Door Sensor’s contact plunger twice. After
a pause, Door Sensor will beep.
Press and release Door Sensor’s contact
plunger twice then hold the contact
plunger until Door Sensor beeps.
OR
?
Once in linking mode, you can open
or close the door without exiting
linking mode.
?
You can cycle between Linking and
Unlinking by repeating the Five-Tap
Linking process.
Linking
Unlinking
Exit
11
Already Installed Linking
Link Hidden Door Sensor without removing from your door frame
Adjust your responder to the desired
state: On, off, or brightness level
if dimming, and then press and
hold the set button until the device
double-beeps.
Model: 2845-222
Door Sensor
2
®
®
Your Insteon controller will now
control your On/Off Module.
12
Multi-Linking or Making a Scene
On your Door Sensor, press and
hold the set button until the device
beeps then tap the set button.
Adjust your scene members to
their desired state: On, off, or
brightness level if dimming.
2
Model: 2845-222
Door Sensor
1
50%
72%
Lamp 1
Lamp 2
30%
ON
Lamp 3
Appliance
A
B
One at a time, press and hold the
set button on each scene member
until it double-beeps.
4
Tap the set button on your Door
Sensor to finish building your scene.
Model: 2845-222
Door Sensor
3
ONCE
®
Your Door Sensor will now control
your scene.
13
Unlinking a Device
2
Press and hold the set button
again until the device beeps .
Press and hold the controlled
device’s set button until the device
double-beeps.
Model: 2845-222
Door Sensor
3
Model: 2845-222
Model: 2845-222
Door Sensor
On your Door Sensor, press and
hold the set button until the device
beeps.
Door Sensor
1
X
®
®
Your Door Sensor will no longer
control your Insteon device.
14
Multi-Unlinking or Removing a Scene
3
Tap the set button.
2
Press and hold the set button
again until the device beeps.
4
Press and hold the controlled
device’s set button until the device
double-beeps.
Model: 2845-222
Model: 2845-222
Door Sensor
Model: 2845-222
Door Sensor
On your Door Sensor, press and
hold the set button until the device
beeps.
Door Sensor
1
®
15
Multi-Unlinking or Removing a Scene
Tap the set button on your Door
Sensor to exit Multi-Unlinking
mode.
Model: 2845-222
Door Sensor
®
X
®
Model: 2845-222
Door Sensor
5
®
Your Door Sensor will no longer
control your Insteon responders.
16
Local Programming
Encompassing all on-device programming options, use the local
programming to set local properties.
properties and
For factory
the bestreset.
experience,
For the use
best
experience,
software
for use
managing
software
device
for managing
properties.
device properties.
17
NEW
Local Programming
About the Flow Chart
Local Programming is a visual representation
of the device’s settings. Many device features
can be configured using the flow chart. Some
devices have more options than others but the
programming wheel presents even the most
complicated devices with a straightforward,
navigable path.
Navigation
720P
$
RADIO
RADIO
a
1: 3 0
MANUAL
INSTEON
Owner’s Manual
INSTEON
Quick Start Guide
iOS
This device complies with FCC
Rules and Industry Canada
license-exempt RSS standard(s).
Operation is subject to the
following two conditions: (1) this
device may not cause harmful
interference, and (2) this device
must accept any interference,
including interference that may
cause undesired operation of
the device.
BUSINESS REPLY MAIL
This device complies with FCC
Rules and Industry Canada
license-exempt RSS standard(s).
Operation is subject to the
following two conditions: (1) this
device may not cause harmful
interference, and (2) this device
must accept any interference,
including interference that may
cause undesired operation of
the device.
ATTN: INSTEON
16542 MILLIKAN AVE
IRVINE CA 92606
INSTEON
Documentation
ALWAYS ON
720P
$
RADIO
RADIO
a
1: 3 0
MANUAL
INSTEON
Owner’s Manual
INSTEON
Quick Start Guide
iOS
This device complies with FCC
Rules and Industry Canada
license-exempt RSS standard(s).
Operation is subject to the
following two conditions: (1) this
device may not cause harmful
interference, and (2) this device
must accept any interference,
including interference that may
cause undesired operation of
the device.
BUSINESS REPLY MAIL
ATTN: INSTEON
16542 MILLIKAN AVE
IRVINE CA 92606
INSTEON
Documentation
ALWAYS ON
This device complies with FCC
Rules and Industry Canada
license-exempt RSS standard(s).
Operation is subject to the
following two conditions: (1) this
device may not cause harmful
interference, and (2) this device
must accept any interference,
including interference that may
cause undesired operation of
the device.
To move right, press and
hold the set button
To move down, tap the set
button
X
Status LED blinks green
Status LED double-blinks
green
Status LED blinks red
Status LED double-blinks
red
Local Programming Features
Linking Mode
Readies the module for linking to another Insteon module. As linking is directional,
the first device placed into linking mode will become the controller in the controller/
responder relationship. The second device will become the responder. The device
automatically exits linking mode after a link has been made with another Insteon device.
Multi-Linking Mode
Readies the module for linking to multiple Insteon modules. The module will remain in
linking mode for 4 minutes or until the module’s set button is tapped. This mode is very
usefully for manually creating scenes.
Unlinking Mode
Multi-Unlinking Mode
Allows the removal of links from the Insteon module. The device will automatically exit
unlinking mode after a link has been removed from another Insteon device.
Allows the removal of multiple links from the Insteon module. The device will stay in
unlinking mode for 4 minutes or until the device’s set button is tapped.
18
Local Programming
Model: 2845-222
Door Sensor
Linking Mode
Press
Unlinking
Mode
Press
Exit
Tap
Tap
Multi-Linking
Mode
Press
Exit
MultiUnlinking
Mode
Press
Exit
Tap
Tap
Exit
Exit
19
Factory Reset
A factory reset will erase all links stored in the device’s database as well as
any customized properties.
20
Factory Reset
1
Remove Door Rensor from the
door frame and take out the
sensor’s battery.
2
Press and hold the set button
while reinstalling the battery.
Door Sensor
Model: 2845-222
Door Sensor
Model: 2845-222
Door Sensor
Model: 2845-222
Model: 2845-222
Door Sensor
3
Continue to hold the set button
until the long beep stops. Let
go and Door Sensor will emit a
double-beep.
LONG
Door Sensor
Model: 2845-222
Your Door Sensor has been
restored to factory settings.
21
Software-Only Features
Most Insteon devices contain features that can only be enabled, disabled
or modified using Insteon control software such as HouseLinc and an
Insteon PowerLine Modem.
22
Software-Only Features
Enable Group 1 & 2 Broadcast
When enabled, Door Sensor will send a
separate On for opening and for closing.
Useful if you want a device to turn on when
the door closes, like a bathroom fan.
Prevents changing any settings using the set
button or tap-and-hold programming.
Group 2 ON
Model: 2845-222
Door Sensor
Group 1 ON
Disable Local Programming
X
Disable LED and Beeper
Adjust Heartbeat Interval
Customize the duration of time between
sensor check-ins; by default, the sensor will
broadcast it’s state once every 24 hours.
Model: 2845-222
Door Sensor
The status LED will not blink when the
sensor is triggered and the beeper will not
respond to button presses.
Door Sensor
Model: 2845-222
23
Software-Only Features
Low Battery Warning
Enable or disable a low battery broadcast
that can trigger events with software.
24
Appendix
Everything else you might need to know about your Insteon product.
25
Specifications
General
Available Colors
Brand
FCC ID
White
Insteon
SPB28452
Industry Canada
5202A-28452
Product Number.
2845-222 US
2845-422 EU
2845-522 AUS/NZ
Patent
UPC
Warranty
Protected under US and Freign Patents (see www.insteon.com/
patents)
813922013092 US
813922013603 EU
813922013610 AUS/NZ
2 years, limited
Operation
Audio Alert
Operation Modes
Operational Gap
Setup Memory
Status LED
Beeper, can be disabled through software
Insteon only
Direct contact with contact plunger required
Non-volatile EEPROM
Red/Green LED
Insteon Features
Insteon Addresses
Insteon Device Category
Insteon Device Subcategory
Insteon ID
Insteon Links
400
0x10
0x11 US
0x14 EU
0x15 AUS/NZ
1
417
Insteon Messages Repeated
No
Insteon Powerline Device
No
Insteon RF Device
Yes
Maximum Controlled Scenes
2
26
Specifications
Maximum Scene Memberships
1
Multi-Link Support
Yes
Multi-Unlink Support
Yes
Phase Detect Beacon
No
Radio Frequency
Radio Frequency Range
915 MHz US
869.85 MHz EU
921 MHz AUS/NZ
150 feet
Scene Commands Supported as
Controller
On
Scene Commands Supported as
Responder
None
Software Configurable
Off
Yes
Mechanical
Switch Type
Momentary mechanical switch
Dimensions
0.75” diameter, 3.4” length
15.9mm diameter, 87mm length
Enclosure Material
Mounting
Operating Environment
Operating Humidity Range
Operating Temperature Range
Set Button
Storage Temperature Range
Weight
Plastic
0.75” diameter, 3.1” deep hole in door frame or door
19mm diameter, 79mm deep hole in door frame or door
Indoors
0-90% relative humidity, non-condensing
-40º to 104º F
-40º to 40º C
1, recessed. Requires removal of sensor to access
-40º to 104º F
-40º to 40º C
0.64 oz
20g
27
Specifications
Electrical
Battery Type
AAA
Battery Life
6 months
Certification
N/A, Battery-powered device
Power Consumption
Supply Voltage
60μA
1.5V DC (AAA Battery)
X10 Features (Powerline Only)
X10 Support
No
28
Troubleshooting
Door Sensor won’t link to other Insteon Devices
Your Door Sensor may be out of range of a dual-band Insteon device or your network may be powerline-only.
Try this:
•
If your Insteon network lacks any dual-band devices, add a Range Extender or other dual-band Insteon
device near your Door Sensor to bridge the Insteon RF and powerline networks.
•
Door Sensor must be placed within 100’ of a dual-band device. Radio interference and building
construction may reduce range. Relocate a dual-band device or add a Range Extender to increase RF
coverage.
Status LED flashes rapidly after triggering Door Sensor’s contact plunger
While you can only see the Status LED when Door Sensor is removed from the door frame, this blinking
indicates that Door Sensor may have not received acknowledgment from one or more linked devices.
Try this:
•
If you have removed any Insteon devices from your network that were previously controlled by Door Sensor,
unlink them from Door Sensor. If the removed device is no longer available, use software to remove the link
from Door Sensor’s link table or perform a factory reset to clear all links.
•
Door Sensor may be on the fringe of your Insteon RF network. Add an additional Insteon dual-band device
or Range Extender near Door Sensor for improved RF and powerline signal bridging.
Status LED does not flash when the set button is tapped or when the contact plunger is depressed
Your Door Sensor’s battery may be low and require replacement.
Try this:
•
Remove Door Sensor from the retention collar and try a different AAA battery.
Hidden Door Sensor makes a hissing noise when installing a new battery
A faint hissing noise can often be heard when removing the battery isolation tab or installing a new battery.
Try this:
•
This is normal operating behavior for Hidden Door Sensor. The noise is part of the startup diagnostics
performed by the sensor..
29
Certifications and Warnings
This device complies with FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference, including interference that may cause undesired operation of the device.
Le present appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts
de licence. L’exploitation est autorise aux deux conditions suivantes: (1) l’appareil ne doit pas produire de
brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radiolectrique subi, mme si le brouillage est
susceptible d’en compromettre le fonctionnement.
Changes or modifications to this unit voids the user’s authority to operate this product and the manufacturer’s
warranty.
The digital circuitry of this device has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15B of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in residential installations. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio and television reception. However, there is no guarantee that interference will not occur in a
particular installation. If this device does cause such interference, which can be verified by turning the device off
and on, the user is encouraged to eliminate the interference by one or more of the following measures:
- Re-orient or relocate the receiving antenna of the device experiencing the interference
- Increase the distance between this device and the receiver
- Connect the device to an AC outlet on a circuit different from the one that supplies power to the receiver
- Consult the dealer or an experienced radio/TV technician
WARNING: Changes or modifications to this device not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
DECLARATION OF CONFORMITY
Hereby, Insteon declares that this device is in compliance with the essential requirements and other relevant
provisions of the following Directives:
1) Electromagnetic Compatibility Directive 2004/108/EC
2) Hazardous Substance Directive 2005/95/EC
Technical data and copies of the original Declaration of Conformity are available and can be obtained from
Insteon; 16542 Millikan Ave, Irvine, CA, USA.
User Information for Consumer Products Covered by EU Directive 2002/96/EC on Waste Electric and Electronic
Equipment (WEEE)
This document contains important information for users with regards to the proper disposal and recycling of
Insteon products. Consumers are required to comply with this notice for all electronic products bearing the
following symbol:
Environmental Information for Customers in the European Union
European Directive 2002/96/EC requires that the equipment bearing this symbol on the product and/or its
packaging must not be disposed of with unsorted municipal waste. The symbol indicates that this product
should be disposed of separately from regular household waste streams.
30
Certifications and Warnings
It is your responsibility to dispose of this and other electric and electronic equipment via designated collection
facilities appointed by the government or local authorities. Correct disposal and recycling will help prevent
potential negative consequences to the environment and human health.
For more detailed information about the disposal of your old equipment, please contact your local authorities,
waste disposal service, or the shop where you purchased the product.
DECLARATION OF CONFORMITY TO R&TTE DIRECTIVE 1999/5/EC for the European Community, Switzerland,
Norway, Iceland and Liechtenstein
Product category: general consumer (category 3).
English: This equipment is in compliance with the essential requirements and other relevant provisions of the
European R&TTE Directive 1999/5/EC
Deutsch [German]: Dieses Gerät entspricht den grundlegenden Anforderungen und den weiteren
entsprechenden Vorgaben der Richtlinie 1999/5/EU.
Nederlands [Dutch]: Dit apparaat voldoet aan de essentiele eisen en andere van toepassing zijnde bepalingen
van de Richtlijn 1999/5/EC.
Svenska [Swedish]: Denna utrustning står I överensstämmelse med de väsentliga egenskapskrav och övriga
relevanta bestämmelser som framgår av direktiv 1999/5/EG.
Français [French]: Cet appareil est conforme aux exigences essentielles et aux autres dispositions pertinentes de
la Directive 1999/5/EC
Español [Spanish]: Este equipo cumple con los requisitos esenciales asi como con otras disposiciones de la
Directiva 1999/5/CE.
Português [Portuguese]: Este equipamento está em conformidade com os requisitos essenciais e outras
provisões relevantes da Directiva 1999/5/EC. Italiano [Italian]: Questo apparato é conforme ai requisiti essenziali
ed agli altri principi sanciti dalla Direttiva 1999/5/CE.
Norsk [Norwegian]: Dette utstyret er i samsvar med de grunnleggende krav og andre relevante bestemmelser i
EU-direktiv 1999/5/EF.
Suomi [Finnish]:Tämä laite tÿttää direktiivin 1999/5/EY olennaiset vaatimukset ja on siinä asetettujen muiden
laitetta koskevien määräysten mukainen. Dansk [Danish]: Dette udstyr er i overensstemmelse med de væsentlige
krav og andre relevante bestemmelser i Direktiv 1999/5/EF.
Polski [Polish]: Urządzenie jest zgodne z ogólnymi wymaganiami oraz szczególnymi warunkami okreslonymi
Dyrektywą UE: 1999/5/EC
31
Product Warranty
Limited Warranty
Seller warrants to the original consumer purchaser of this product that, for a period of two years from the date
of purchase, this product will be free from defects in material and workmanship and will perform in substantial
conformity to the description of the product in this Owner’s Manual. This warranty shall not apply to defects or
errors caused by misuse or neglect. If the product is found to be defective in material or workmanship, or if the
product does not perform as warranted above during the warranty period, Seller will either repair it, replace it,
or refund the purchase price, at its option, upon receipt of the product at the address below, postage prepaid,
with proof of the date of purchase and an explanation of the defect or error. The repair, replacement, or refund
that is provided for above shall be the full extent of Seller’s liability with respect to this product. For repair or
replacement during the warranty period, call 866-243-8022 with the Model # and Revision # of the device to
receive an RMA# and send the product, along with all other required materials to:
Insteon
ATTN: Receiving
16542 Millikan Ave.
Irvine, CA 92606-5027
Limitations
The above warranty is in lieu of and Seller disclaims all other warranties, whether oral or written, express or
implied, including any warranty or merchantability or fitness for a particular purpose. Any implied warranty,
including any warranty of merchantability or fitness for a particular purpose, which may not be disclaimed
or supplanted as provided above shall be limited to the two-year of the express warranty above. No other
representation or claim of any nature by any person shall be binding upon Seller or modify the terms of the
above warranty and disclaimer.
Home automation devices have the risk of failure to operate, incorrect operation, or electrical or mechanical
tampering. For optimal use, manually verify the device state. Any home automation device should be viewed as
a convenience, but not as a sole method for controlling your home.
In no event shall Seller be liable for special, incidental, consequential, or other damages resulting from
possession or use of this device, including without limitation damage to property and, to the extent permitted by
law, personal injury, even if Seller knew or should have known of the possibility of such damages. Some states
do not allow limitations on how long an implied warranty lasts and/or the exclusion or limitation of damages, in
which case the above limitations and/or exclusions may not apply to you. You may also have other legal rights
that may vary from state to state.
Protected under U.S. and foreign patents (see www.insteon.com/patents)
© Copyright 2013 Insteon
Rev 07.06.15
32
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
