BSH Home Appliances Group
Dryer Electrical Supply Grounding
Instructions for 3-Wire Power Cord
2018-08
Mike Peebles
BSH Dryer Electrical Supply Grounding Instructions for 3-Wire Power Cord
Dryer Installation Manual:
Current Dryer installation manuals have the following instructions for installing a 3-Wire Power Cord.
Alternate Grounding Method:
As BSH condensate dryers have no internal Neutral, the following installation is permitted IF ALL instructions are
completed and confirmed.
1. Neutral wire of 3-Wire cord (usually white or middle
conductor) can be connected directly to PE as
shown.
2. BEFORE plugging power cord into the receptacle,
the continuity between the Neutral (center) pin of the
power cord and the metal frame of the appliance
MUST be confirmed.
Use of a self-energized circuit tester must be used.
3. A 4-conductor cord must be used when the appliance is installed where
grounding through the Neutral conductor is prohibited! Grounding through the
Neutral conductor is prohibited for (1) new branch-circuit installations, (2)
mobile homes, (3) recreational vehicles, and (4) areas where local codes
prohibit grounding through the Neutral conductors.
Page 2
2018-08-13 Dryer Electrical Supply Grounding Instructions for 3-Wire Power Cord
NEMA
10-30P
Plug
Continuity
tester
8001013017 (9507)
$
$
%
PD[FP
PLQFPPD[FP
$
PD[FP
&
&
&
*8001013017*
