Installation in a Partitioned
Environment
AIX
REFERENCE
86 A2 90EM 00
ESCALA
AIX 5L
ESCALA
AIX 5L
Installation in a Partitioned Environment
AIX
Software
August 2004
BULL CEDOC
357 AVENUE PATTON
B.P.20845
49008 ANGERS CEDEX 01
FRANCE
REFERENCE
86 A2 90EM 00
The following copyright notice protects this book under Copyright laws which prohibit such actions as, but not
limited to, copying, distributing, modifying, and making derivative works.
Copyright
Bull SAS 1992, 2004
Printed in France
Suggestions and criticisms concerning the form, content, and presentation of this
book are invited. A form is provided at the end of this book for this purpose.
To order additional copies of this book or other Bull Technical Publications, you
are invited to use the Ordering Form also provided at the end of this book.
Trademarks and Acknowledgements
We acknowledge the right of proprietors of trademarks mentioned in this book.
AIX® is a registered trademark of International Business Machines Corporation, and is being used under licence.
UNIX® is a registered trademark in the United States of America and other countries licensed exclusively through
the Open Group.
Linux® is the registered trademark of Linus Torvalds in the U.S. and other countries
The information in this document is subject to change without notice. Bull will not be liable for errors contained
herein, or for incidental or consequential damages in connection with the use of this material.
About This Book
The AIX Installation in a Partitioned Environment guide provides system administrators with
complete information about how to perform such tasks as installing, maintaining, and
updating AIX in a partition using CD–ROM, tape, and network installation. It also covers
such topics as system backup, dump management, storage management, and remote
management. This publication is also available on the ”Hypertext Library for AIX 5.3”
CD-ROM that is shipped with the operating system.
Content of This Book
This edition of this book contains no technical changes. The content is identical to the
previous edition.
Highlighting
The following highlighting conventions are used in this book:
Bold
Identifies commands, subroutines, keywords, files, structures,
directories, and other items whose names are predefined by the
system. Also identifies graphical objects such as buttons, labels, and
icons that the user selects.
Italics
Identifies parameters whose actual names or values are to be supplied
by the user.
Monospace
Identifies examples of specific data values, examples of text similar to
what you might see displayed, examples of portions of program code
similar to what you might write as a programmer, messages from the
system, or information you should actually type.
Case–Sensitivity in AIX
Everything in the AIX operating system is case–sensitive, which means that it distinguishes
between uppercase and lowercase letters. For example, you can use the ls command to list
files. If you type LS, the system responds that the command is ”not found.” Likewise, FILEA,
FiLea, and filea are three distinct file names, even if they reside in the same directory. To
avoid causing undesirable actions to be performed, always ensure that you use the correct
case.
ISO 9000
ISO 9000 registered quality systems were used in the development and manufacturing of
this product.
Preface iii
Related Publications
The following publications contain related information:
• Hardware Management Console Installation and Operations Guide
iv
•
AIX 5L Version 5.3 Installation Guide and Reference
•
AIX 5L Version 5.3 System Management Guide: Operating System and Devices
•
AIX 5L Version 5.3 System Management Guide: Communications and Networks
•
AIX 5L Version 5.3 Commands Reference
•
AIX 5L Version 5.3 Files Reference
•
AIX 5L Version 5.3 General Programming Concepts: Writing and Debugging Programs
•
AIX 5L Version 5.3 System User’s Guide: Operating System and Devices
•
AIX 5L Version 5.3 System User’s Guide: Communications and Networks
AIX Installation in a Partitioned Environment
Contents
About This Book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Content of This Book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Highlighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Case–Sensitivity in AIX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ISO 9000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Related Publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
iii
iii
iii
iii
iii
iv
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
v
Chapter 1. Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
List of Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Documentation Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuring Online Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-1
1-2
1-3
1-6
Chapter 2. Overview of Partitioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Managed System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Logical Partitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dynamic Logical Partitioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Affinity Logical Partitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Working with Logical Partitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Full System Partition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Partition Roadmap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
When to Implement Logical Partitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Server Consolidation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mixed Production and Test Environments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Consolidation of Multiple Versions of the Same Operating System . . . . . . . . . . .
Partition Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-1
2-1
2-1
2-2
2-2
2-2
2-3
2-3
2-4
2-4
2-4
2-4
2-4
Chapter 3. Logical Partition Scenarios and Recommendations . . . . . . . . . . . . .
Overview of AIX Installation Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Introduction to Network Installation Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation Scenarios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Migrating to AIX 5.3 and Configuring Partition Support . . . . . . . . . . . . . . . . . . . . .
First AIX System in Your Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing a Partition Using Alternate Disk Installation . . . . . . . . . . . . . . . . . . . . . . .
Advanced Installation Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-1
3-1
3-2
3-4
3-4
3-4
3-5
3-5
Chapter 4. Installing AIX in a Partitioned Environment . . . . . . . . . . . . . . . . . . . . .
Configure an Initial Partition as a NIM Master to Use NIM to Install the Remaining
Partitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1. Activate the Master_LPAR (Perform this Step in the HMC Interface) . . . . . . .
2. Configure NIM Master and Initiate Installation of Partitions (Perform These Steps
in the AIX Environment) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3. Activate and Install Partitions (Perform These Steps in the HMC Interface) . .
4. Log in to Your Partition (Perform This Step in the AIX Environment) . . . . . . . .
4-1
Preface
4-2
4-2
4-3
4-3
4-6
4-8
v
Use a Separate AIX System as a NIM Master to Use NIM to Install Each Partition
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1. Configure NIM Master and Initiate Installation of Partitions (Perform These Steps
in the AIX Environment) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. Activate and Install Partitions (Perform These Steps in the HMC Interface) . .
3. Log in to Your Partition (Perform This Step in the AIX Environment) . . . . . . . .
Installing AIX using the CD–ROM device to install a partition with an HMC . . . . . .
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1. Activate and install the partition (perform these steps in the HMC interface) .
2. Manage Your Partition (Perform This Step in the AIX Environment) . . . . . . . .
Installing AIX using the CD–ROM device to install a partition without an HMC . . . .
1. Prepare your system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. Boot from the AIX product CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3. Set and verify BOS installation settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4. Manage Your Partition (Perform This Step in the AIX Environment) . . . . . . . .
Migrate a System to the AIX 5.3 Partition–Ready State . . . . . . . . . . . . . . . . . . . . . . .
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1. Migrate the System to AIX 5.3 (Perform These Steps in the AIX
Environment) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. Manage Your Migrated System (Perform This Step in the AIX Environment)
Update an Existing NIM Environment to the Latest AIX Recommended
Maintenance Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1. Update Your NIM Environment to the Latest Recommended Maintenance Level
(Perform These Steps in the AIX Environment) . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. Manage Your Partition (Perform This Step in the AIX Environment) . . . . . . . .
vi
4-8
4-9
4-9
4-12
4-14
4-14
4-15
4-15
4-19
4-19
4-19
4-20
4-20
4-22
4-22
4-22
4-22
4-24
4-25
4-25
4-25
4-26
Chapter 5. System Backup, Dump, and Storage Management . . . . . . . . . . . . . .
System Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Creating a System Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using CD Media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using Tape Media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing a System Backup Using NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System Dump Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5-1
5-1
5-2
5-2
5-3
5-3
5-3
5-5
5-8
Chapter 6. Remote Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Remote Management From the HMC to AIX Partitions . . . . . . . . . . . . . . . . . . . . . . . .
6-1
6-2
Chapter 7. Hints and Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Naming Your Operating System Host Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Network Adapter Communication Between Partitions and the HMC . . . . . . . . . . . . .
Shutting Down a Partition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using AIX to Shut Down a Partition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the HMC Interface to Shut Down a Partition . . . . . . . . . . . . . . . . . . . . . . . . .
7-1
7-1
7-2
7-3
7-3
7-3
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
X-1
AIX Installation in a Partitioned Environment
Chapter 1. Getting Started
This chapter helps you get started with installing and configuring an ESCALA managed
system environment. The following information is included in the chapter:
• ESCALA Roadmap
• ESCALA Materials – List of ESCALA materials
• Documentation Overview – Brief description of the printed and softcopy documentation
shipped including targeted audience
• Configuring Online Documentation – How to install and view the online documentation
The ESCALA Roadmap helps you locate marketing, service, and customer task information.
The roadmap guides you through the tasks and the publications that document those tasks.
Figure 1. The ESCALA Roadmap This flow chart shows marketing, service, and customer
tasks. The roadmap guides you through the tasks and the publications that document those
tasks. The specific tasks shown in the flow chart are planning, hardware installation,
configuring partitions, configuring full system partitions, installing and configuring the
operating system, installing and configuring applications, and using the system.
Getting Started
1-1
List of Materials
Based on your order request, the ESCALA shipment may include the following materials:
CD–ROM Media:
• AIX 5.3 CDs
• AIX 5L Bonus Pack
• AIX 5L Expansion Pack
• AIX 5L Documentation CD
Documentation:
• eServer ESCALA Installation Guide
• eServer Hardware Management Console for ESCALA Installation and Operations Guide
• AIX Installation in a Partitioned Environment
1-2 AIX Installation in a Partitioned Environment
• AIX 5L Version 5.3 Installation Guide and Reference
• AIX 5L Version 5.3 Release Notes
• System Unit Safety Information
Documentation Overview
This section provides descriptions, and target audience information for the ESCALA and AIX
5L documentation libraries. Some of the documentation may only be available in printed
form or in softcopy form. Based on the documentation content, the books are divided into
the following categories: Planning, Installing and Configuring, and Using the System.
Note: Starting with ESCALA Power 5 models, the Harware Documentation is provided only
on softcopy on a CD–ROM shipped with the systems.
Table 1. Planning
Documentation
Title
Description
Audience
Type
Site Preparation for
Racks Systems
Contains information
to help plan for site
preparation tasks,
such as
floor–planning,
electrical needs, air
conditioning, and
other site–planning
considerations.
Marketing, system
administrators
softcopy
Planning for
Partitioned–System
Operations
Describes planning
System
considerations for
administrators
partitioned systems,
including information
on dynamic
partitioning and
Capacity Upgrade on
Demand.
printed and softcopy
Hardware
Management
Console Installation
and Operations
Guide
Provides information
on how to install,
configure, and use a
Hardware
Management
Console (HMC).
Logical partition
(LPAR) tasks, such
as configuring and
managing partitions
on multiple host
servers, are
included.
printed and softcopy
System
administrators
Getting Started
1-3
Table 2. Installing and Configuring
Documentation
Title
Description
Hardware Installation Provides information
Guide
on how to install
system hardware,
cable the system,
and verify
operations.
Audience
Type
Service personnel
printed and softcopy
Planning for
Partitioned–System
Operations
Describes planning
System
considerations for
administrators
partitioned systems,
including information
on dynamic
partitioning and
Capacity Upgrade on
Demand.
printed and softcopy
Hardware
Management
Console Installation
and Operations
Guide
Provides information
on how to install,
configure, and use a
Hardware
Management
Console (HMC).
Logical partition
(LPAR) tasks, such
as configuring and
managing partitions
on multiple host
servers, are
included.
System
administrators
printed and softcopy
AIX Installation in a
Partitioned
Environment
(this book)
Provides information
on how to install the
AIX operating
system in an LPAR
environment.
System
administrators
printed and softcopy
AIX Operating
System Installation:
Getting Started
Provides information
on how to install and
configure the AIX
operating system on
a standalone system
using a CD–ROM
device.
System
administrators
printed and softcopy
1-4 AIX Installation in a Partitioned Environment
Documentation
Title
Description
Audience
Type
AIX 5L Installation
Guide and
Reference
Provides information
on installing the AIX
5L operating system
on standalone
systems, as well as
on client systems
using the Network
Installation
Management (NIM)
interface.
System
administrators
printed and softcopy
AIX 5L
Documentation CD
AIX documentation
System
library (system
administrators
management guides,
user guides,
application
programmer guides,
commands and files
references, AIX man
pages, and so on).
softcopy
Table 3. Using the System
Documentation
Title
Description
Audience
Type
Hardware
Management
Console Installation
and Operations
Guide
Provides information
on how to install,
configure, and use a
Hardware
Management
Console (HMC).
Logical partition
(LPAR) tasks, such
as configuring and
managing partitions
on multiple host
servers, are
included.
System
administrators
printed and softcopy
Hardware User’s
Guide
Provides using,
problem
determination, and
service processor
information.
System
administrators
printed and softcopy
Diagnostic
Information for
Multiple Bus
Systems
Combines operating
instructions for
hardware diagnostic
programs with
common MAPs and
SRNs (Service
Request Numbers).
Service personnel
printed and softcopy
Getting Started
1-5
Documentation
Title
Description
Audience
Type
Hardware
Management
Console
Maintenance Guide
Contains MAPs,
removal and
replacement, error
code, and parts
information to help
diagnose and repair
the system.
Service personnel
printed and softcopy
Adapters Information Provides information
for Multiple Bus
about adapters that
Systems
are attached to or
used within the
system.
System
administrators
printed and softcopy
System Unit Safety
Information
Contains the English
version of safety
notices, as well as
translations of those
safety notices into
other languages.
System
administrators,
service personnel
printed and softcopy
AIX 5L
Documentation CD
AIX documentation
System
library (system
administrators
management guides,
user guides,
application
programmer guides,
commands and files
references, AIX man
pages, and so on).
softcopy
Configuring Online Documentation
The AIX online documentation is delivered on the following CD-ROM:
– 86 X2 32EM: Hypertext Library. Full Set for AIX 5.3
Instructions for installing the Hypertext Library are contained in the CD-ROM booklet and
must be scrupulously followed.
The Hypertext Library comes with a set of tools called The Hypertext Library Utilities. This
set of tools contains a Search function allowing to search for information through the entire
Library and a Multi-Print capability allowing to print several documents with a single click in
the Search Results window, plus features allowing to create and manage notes through the
entire Library and to add (or remove) user documentation to the Library.
The Hypertext Library and the Hypertext Library Utilities have both a graphical and
character interface.
The contents of the Hypertext Library and the Hypertext Library Utilities are described in the
Hypertext Library home page.
1-6 AIX Installation in a Partitioned Environment
Chapter 2. Overview of Partitioning
Partitioning your system is similar to partitioning a hard drive. When you partition a hard
drive, you divide a single physical hard drive so that the operating system recognizes it as a
number of separate logical hard drives. You have the option of dividing the system’s
resources by using the Hardware Management Console (HMC) to partition your system. On
each of these divisions, called partitions, you can install an operating system and use each
partition as you would a separate physical system.
Managed System
A managed system is a system that is physically attached to and managed by the HMC.
The HMC can perform tasks that affect the entire managed system, such as powering the
system on and off. You can also create partitions and partition profiles within each managed
system. These partitions and partition profiles define the way that you configure and operate
your partitioned system.
Logical Partitions
A logical partition (LPAR) is the division of a computer’s processors, memory, and hardware
resources into multiple environments so that each environment can be operated
independently with its own operating system and applications. The number of logical
partitions that can be created depends on the system’s processor model and resources
available. Typically, partitions are used for different purposes, such as database operation,
client/server operations, Web server operations, test environments, and production
environments. Each partition can communicate with the other partitions as if each partition
is a separate machine.
Beginning with AIX 5.1, the AIX operating system supports partitioned environments.
Although the AIX installation concepts are the same, the ability to configure and manage a
partitioned environment with the AIX operating system is available in AIX 5.2. This guide
assumes the reader has some familiarity with partition management. For more information
about partition management, refer to the Hardware Management Console Installation and
Operations Guide.
A logical partition must contain a minimum set of resources, as follows:
• 1 GB of available system memory
• One available system processor
• One boot device on an assigned I/O slot
• One available network adapter (for error reporting)
• Any other adapters you may need on an assigned I/O slot
Processors, memory, and I/O slots can be allocated to any partition, regardless of their
location. However, if you attempt to activate a partition, but the resources you specified are
not available at the time, partition activation fails. It is important to keep track of your
system’s resources to avoid activation failures. PCI slots are assigned individually to
partitions, and memory can be allocated in 256 MB increments. The granularity of the
resources that can be assigned to partitions is very fine, providing flexibility to create
systems with just the desired amount of resources. Each partition runs its own copy of the
AIX operating system and is isolated from any activity in other partitions. Software failures
Overview of Partitioning
2-1
do not propagate through the system, and the hardware facilities and microcode isolate the
resources.
Dynamic Logical Partitioning
Dynamic logical partitioning provides the ability to logically attach and detach a managed
system’s resources to and from a logical partition’s operating system without rebooting.
For more information on dynamic logical partitioning, see the following:
• The Reassigning Partition Resources Dynamically section in the Hardware Management
Console Installation and Operations Guide.
• The Dynamic Reconfiguration section in the AIX 5L Version 5.3 General Programming
Concepts: Writing and Debugging Programs.
• The Dynamic Reconfiguration Safe and Aware Programs section in the AIX 5L Version
5.3 General Programming Concepts: Writing and Debugging Programs.
Affinity Logical Partitions
Some systems have the ability to create affinity logical partitions. Check your hardware
specifications to see if your managed system is capable of using affinity logical partitions.
An affinity logical partition is a special type of logical partition that uses system resources
that are in close physical proximity to each other. When creating an affinity logical partition,
the HMC automatically determines which system resources are to be used, based on their
physical location to each other. The system resources that are automatically managed by
the HMC are processors and memory. The user determines the I/O requirements for each of
these partitions. The HMC then creates a profile for each affinity logical partition and a
system profile for the managed system.
Working with Logical Partitions
The logical partition resource allocation provides the ability to select individual components
to be added to a partition without dependencies between these resources. The slots can be
freely allocated in any I/O drawer on the system. Other devices may be required for specific
application requirements. It is a good idea to configure more PCI slots in the partition than
are required for the number of adapters. This provides flexibility by allowing additional
adapters to be hot–plugged into the empty slots that are part of an active partition. Because
each partition requires its own separate boot device, the system must have at least one
boot device and associated adapter per partition.
There are a few differences in how AIX runs within a logical partition, as opposed to how it
runs on a standalone server:
• In order for AIX to run inside a logical partition, AIX calls the Hypervisor in place of its
traditional direct access to the hardware and address–mapping facilities.
• Some direct–access calls are presented for diagnostic purposes, and alternate return
codes for Run–Time Abstraction Services (RTAS) calls are used whenever an illegal
operation is issued.
• No physical console exists on the partition. While the physical serial ports on the system
can be assigned to the partitions, they can only be in one partition at a time. To provide
an output for console messages and also for diagnostic purposes, the firmware
implements a virtual tty that is seen by AIX as a standard tty device. Its output is sent to
the HMC. The AIX diagnostics subsystems use the virtual tty as the system console.
• Certain platform operations are constrained in LPARs. For example, in non–LPAR
systems, platform firmware updates can be performed from AIX by a root user. Because
2-2
AIX Installation in a Partitioned Environment
firmware updates can affect all partitions in an LPAR system, the LPAR administrator can
specify that a particular partition (or no partition) has this authority. Within that partition,
firmware updates work in the same way as they do for non–LPAR systems.
Apart from these considerations, AIX runs within a partition the same way it runs on a
standalone server. No differences are observed either from the application or the
administrator’s point of view. Third–party applications need only be certified for a level of
AIX that runs in a partition, and not for the LPAR environment itself.
Full System Partition
A special partition called the Full System Partition assigns all of your managed system’s
resources to one large partition. The Full System Partition is similar to the traditional,
non–partitioned method of operating a system. Because all resources are assigned to this
partition, no other partitions can be started when the Full System Partition is running.
Likewise, the Full System Partition cannot be started while other partitions are running. It is
recommended that you choose to use either the Full System Partition or create other
partitions. It is not recommended that you switch between these two options frequently,
because your I/O usage might be affected.
Partition Roadmap
Use the following illustration to help you locate information about understanding, planning
for, and configuring partitions, as well as information about installing the AIX operating
system.
Figure 2. Partition Roadmap This illustration shows the logical partition concepts and the
books that contain this information. The Hardware Management Console Installation and
Operations Guide contains information about understanding LPAR, planning LPAR, and
configuring LPAR. The AIX 5L Version 5.3 AIX Installation in a Partitioned Environment
guide contains information about installing AIX in an LPAR (such as CD installation and
Network Installation Management installation); and additional considerations for running in
LPAR (such as remote management, dump devices, system backup and restore, and
system maintenance).
Overview of Partitioning
2-3
When to Implement Logical Partitions
A logically partitioned environment adds to a portfolio of solutions that can provide better
management, improved availability, and more efficient use of resources. This section
provides some scenarios where a logically partitioned environment brings significant
benefits, as well as other scenarios where it may not be appropriate.
Server Consolidation
A server with sufficient processing capacity that is capable of being partitioned can address
the need for server consolidation by logically subdividing the server into a number of
separate smaller systems. In this way the application–isolation needs can be met in a
consolidated environment, with the additional benefits of reduced floor space, a single point
of management, and easier redistribution of resources as workloads change.
Mixed Production and Test Environments
Generally, production and test environments should be isolated from each other. Partitioning
enables separate partitions to be allocated for the production and test systems, eliminating
the need to purchase additional hardware and software. When testing has been completed,
the resources allocated to the test partition can be returned to the production partition or
elsewhere as required. It might be that the test environment later becomes the production
environment, and extra resources can then be added to the partition. As new projects are
developed, they can be built and tested on the same hardware on which they will eventually
be deployed.
Consolidation of Multiple Versions of the Same Operating System
Starting with AIX 5.1, different versions of AIX can exist within different LPARs in the same
system. This enables a single system to have different versions of the operating system
installed to accommodate multiple application requirements. Furthermore, an LPAR can be
created to test applications under new versions of the operating system prior to upgrading
the production environments. Instead of having a separate server for this function, a
minimum set of resources can be temporarily used to create a new LPAR where the tests
are performed. When the partition is no longer needed, its resources can be incorporated
back into the other LPARs.
Partition Security
System administrators can install a system with the Controlled Access Protection Profile
(CAPP) and Evaluation Assurance Level 4+ (EAL4+) option during a base operating system
(BOS) installation. A system with this option has restrictions on the software that is installed
during BOS installation, plus network access is restricted.
Beginning in AIX 5L Version 5.2 with the 5200–01 Recommended Maintenance package,
the CAPP/EAL4+ technology runs on POWER4 processor (p630, p650, and p690)
hardware platforms that support logical partition configuration. Peripherals that are
supported are terminals and printers, hard disks and CD–ROM drives as storage devices,
and streamers and floppy disk drives as backup devices. Supported network connector
types are Ethernet and Token Ring.
For more information on the Controlled Access Protection Profile and Evaluation Assurance
Level 4+ technology, refer to the AIX 5L Version 5.3 Security Guide and the Hardware
Management Console Installation and Operations Guide.
2-4
AIX Installation in a Partitioned Environment
Chapter 3. Logical Partition Scenarios and
Recommendations
This chapter provides an overview of the AIX installation process and various installation
scenarios you can use. Because the managed system may be the first AIX system in your
environment (or the first AIX 5.1 system in an AIX 4.3 environment), this information and
accompanying recommendations will help guide you on decisions about installation,
maintenance, and system backup.
Overview of AIX Installation Process
Due to the physical configuration of a managed system, use of the Network Installation
Management (NIM) environment to install AIX is recommended. The following table
compares how different forms of media proceed through the AIX installation process:
Steps
CD–ROM
Product
Media
NIM
mksysb on
CD–R or
DVD–RAM
mksysb on tape
Booting
Boot image is
stored and
retrieved from
CD.
Boot image is
stored on NIM
server. Boot
image is
retrieved from
network by
firmware.
Boot image is
stored and
retrieved from
CD–R or DVD.
Boot image is
stored and
retrieved from
the first image on
tape.
Making BOS
Installation
Choices
Manually step
through the
BOS menu
selections for
disks, kernel,
language, and
so on.
Perform
nonprompted
installation using
a bosinst.data
file to answer the
BOS menu
questions.
Manually
proceed through
the BOS menu
selections for
disks.
Manually
proceed through
the BOS menu
selections for
disks and other
choices.
Executing
Commands
During
Installation
CD–file
system is
mounted and
commands
are executed.
SPOT file
system is NFS
mounted and
commands are
run from the
SPOT.
CD–file system
is mounted and
commands are
executed.
Command files
are retrieved
from second
image on tape to
RAM–file system
in memory.
Logical Partition Scenarios and Recommendations
3-1
Installing
Product
Images
Installation
images stored
on CD in a file
system.
Installation
images are
stored in
LPP_Source,
which is NFS
mounted during
installation.
Backup image is
stored on CD–R
or DVD–RAM in
a file system.
Backup image is
stored and
retrieved from
fourth image on
tape.
Rebooting
System and
Logging into
System
Use
Configuration
Assistant (or
Installation
Assistant) to
accept license
agreements,
set paging
space, and so
on.
No Configuration
Assistant (or
Installation
Assistant). Boot
to login prompt.
No Configuration
Assistant (or
Installation
Assistant). Boot
to login prompt.
No Configuration
Assistant (or
Installation
Assistant). Boot
to login prompt.
Introduction to Network Installation Management
This section provides an introduction to the NIM environment and the operations you can
perform to manage the installation of the Base Operating System (BOS) and optional
software on one or more machines. NIM gives you the ability to install and maintain not only
the AIX operating system, but also any additional software and fixes that may be applied
over time. NIM also allows you to customize the configuration of machines both during and
after installation. NIM eliminates the need for access to physical media, such as tapes and
CD–ROMs, because the media is a NIM resource on a server. System backups can be
created with NIM, and stored on any server in the NIM environment, including the NIM
master. Use NIM to restore a system backup to the same partition or to another partition.
Before you begin configuring the NIM environment, you should already have the following:
• NFS and TCP/IP installed
• TCP/IP configured correctly
• Name resolution configured
For any installation procedure, you need a software source to install from, such as the AIX
product CD–ROM. The AIX product CD–ROM contains boot images used to boot the
system from the CD–ROM, installation images, and the installation commands used to
install the installation images, as shown in the following illustration:
Figure 3. An example of an AIX product CD–ROM This illustration shows an AIX product
CD–ROM contains boot images used to boot the system from the CD–ROM, installation
images, and the installation commands used to install the installation images.
3-2
AIX Installation in a Partitioned Environment
In the NIM environment, the software source is separated into two NIM resources, the
LPP_Source and the SPOT. The LPP_Source is a directory on your NIM server. When the
LPP_Source is created, installation images are copied from the product CD–ROM to the
LPP_Source directory, as shown in the following illustration:
Figure 4. An example of an LPP_Source resource. This illustration shows that when an
LPP_Source resource is created, installation images are copied from the product CD–ROM
to the LPP_Source directory.
The product CD–ROM also contains boot images that enable the system to boot from the
CD–ROM and installation commands that are used to install the installation images. This
equivalent NIM resource is called the SPOT (Shared Product Object Tree). The SPOT is a
directory that contains the installation commands that are used to install the installation
images from the LPP_Source onto a system. The SPOT is also used to build the necessary
boot images to boot a client system. Separate boot images exist for each type of adapter
(Ethernet, token ring, and so on).
Figure 5. An example of a SPOT resource. This illustration shows that a SPOT resource
contains the installation commands used to install the installation images from the
LPP_Source resource onto a system. The SPOT is also used to build the necessary boot
images to boot a client system.
Logical Partition Scenarios and Recommendations
3-3
Scripts are available that configure the NIM environment for you and create the resources
necessary to perform a mksysb installation. The nim_master_setup script creates an
LPP_Source and SPOT resource for you and defines the resources in the NIM environment.
The nim_master_setup script will also copy the update images from your update CD to the
LPP_Source and then install the update images into the SPOT resource.
In addition to the LPP_Source and SPOT resources, several NIM resources can help
customize the BOS installation process and basic network configuration. The following table
shows all the NIM resources that are created with the nim_master_setup script:
NIM Resource
Name Given
Description
spot*
520spot_res
Commands used during installation. The network boot
images are built from the SPOT.
lpp_source
520lpp_res
Directory containing installation images.
mksysb
generic_sysb
System backup image
bosinst_data
bosinst_ow
Answers questions asked during the BOS installation,
which allows for a non–prompted new and complete
overwrite installation.
resolv_conf
resolv_res
Provides the domain name and name server
information.
res_group
basic_res_grp
Used by the nim_clients_setup script to allocate the
bosinst_data, mksysb, lpp_source, spot, and
resolv_conf to install the client partitions.
* Required resource for installation
Each partition you install will be defined in the NIM environment as a standalone system
resource, also referred to as a NIM client. The nim_clients_setup script allows you to
define the partitions as NIM clients and initiates a BOS installation on the NIM clients.
Installation Scenarios
This section contains several scenarios for installing AIX.
Migrating to AIX 5.3 and Configuring Partition Support
In this scenario, you are adding a managed system to an existing environment of systems
running AIX 5.1. The managed system is the first system in your environment that requires
AIX 5.3. If you have a system available to use as a NIM master, or you already have a NIM
master, perform the following steps:
1. Migrate the system to AIX 5.3. For the procedure, refer to Migrate a System to the AIX
5.3 Partition–Ready State on page 4-22.
2. Configure the system to be a NIM master. You will use the NIM master to install the
system backup on your partitions. If you do not have an available system to use as a AIX
5.3 NIM master, refer to Configure an Initial Partition as a NIM Master to Use NIM to
Install the Remaining Partitions on page 4-2.
First AIX System in Your Environment
In this scenario, the managed system is the first AIX system in your environment, and you
do not have another system with a graphics adapter available. In this case, you must use
the HMC as both your software and hardware console.
If you do not have a great deal of experience using AIX, use the procedure described in
Configure an Initial Partition as a NIM Master to Use NIM to Install the Remaining Partitions
on page 4-2. This procedure will create a NIM master on one of the partitions and use its
system image to install the other partitions.
3-4
AIX Installation in a Partitioned Environment
NIM enables you to install and customize your logically partitioned environment. Using the
NIM environment enables you to perform future installation and maintenance tasks more
efficiently.
Installing a Partition Using Alternate Disk Installation
You can clone an existing disk image to another disk or disks without using NIM. You may
want to do this if your network is not fully set up, or if you are not sure about your network
configuration. However, you may choose to use NIM at a later time.
You can use the alt_disk_install command to clone a system image to another disk, but
you must use the –O option to remove references in the object data manager (ODM) and
device (/dev) entries to the existing system. The –O flag tells the alt_disk_install command
to call the devreset command, which resets the device database. The cloned disk can now
be booted as if it were a new system.
An example of this scenario is as follows:
1. Boot the managed system as a Full System Partition so you have access to all the disks
in the managed system.
2. Configure the system and install the necessary applications.
3. Run the alt_disk_install command to begin cloning the rootvg on hdisk0 to hdisk1,
as follows:
# /usr/sbin/alt_disk_install –O –B –C hdisk1
The cloned disk ( hdisk1 ) will be named altinst_rootvg by default.
4. Rename the cloned disk ( hdisk1 ) to alt1, so you can repeat the operation with
another disk.
# /usr/sbin/alt_disk_install –v alt1 hdisk1
5. Run the alt_disk_install command again to clone to another disk and rename the
cloned disk, as follows:
# /usr/sbin/alt_disk_install –O –B –C hdisk2
# /usr/sbin/alt_disk_install –v alt2 hdisk2
6. Repeat steps 3 through 5 for all of the disks that you want to clone.
7. Use the HMC to partition the managed system with the newly cloned disks. Each
partition you create will now have a rootvg with a boot image.
8. Boot the partition into SMS mode. Use the SMS MultiBoot menu to configure the first
boot device to be the newly installed disk. Exit the SMS menus and boot the system.
For a full description of alternate disk installation, see the alt_disk_install man page and
the AIX 5L Version 5.3 Installation Guide and Reference.
Advanced Installation Options
You can use several other scenarios to install your partitions by using some AIX advanced
functions. These procedures are documented in the
/usr/lpp/bos/README.PARTITION_INSTALL file.
Some installation scenarios covered are the following:
• Preparing an existing root volume group (rootvg) to move to a managed system
• Using the devreset command to rebuild the device ODM database and reset all devices
to default configurations
Logical Partition Scenarios and Recommendations
3-5
3-6
AIX Installation in a Partitioned Environment
Chapter 4. Installing AIX in a Partitioned Environment
This chapter contains procedures to install the AIX operating system in a partitioned
environment. For more information on concepts and the considerations involved when
performing a base operating system installation of AIX, refer to the AIX 5L Version 5.3
Installation Guide and Reference. For more information on concepts and the requirements
involved when using the Network Installation Management (NIM) environment to install and
maintain AIX, you can also refer to the AIX 5L Version 5.3 Installation Guide and Reference.
For instructions on how to create a partition and allocate I/O resources to a partition, see the
Hardware Management Console Installation and Operations Guide. To help you keep track
of the LPAR environment system resources, see the tracking worksheets in the Hardware
Management Console Installation and Operations Guide.
Note: For the installation method that you choose, ensure that you follow the sequence of
steps as shown. Within each procedure, you must use AIX to complete some
installation steps, while other steps are completed using the HMC interface.
Table 6. AIX Installation Procedures and Considerations
Installation Procedure
Considerations
Configure an Initial Partition as a
NIM Master to Use NIM to Install
the Remaining Partitions on page
4-2
• NIM environment offers the most flexibility and
customization options for installation and
management.
• NIM environment allows for multiple installations
at the same time.
• The nim_master_setup and nim_clients_setup
scripts provide a way to set up the NIM
environment.
• Requires one LPAR with approximately 1.5 GB of
disk space dedicated as the NIM master partition.
Use a Separate AIX System as a
NIM Master to Use NIM to Install
Each Partition on page 4-8
• You need not dedicate an LPAR as the NIM
master.
• NIM environment offers the most flexibility and
customization options for installation and
management.
• NIM environment allows for multiple installations
at the same time.
• The nim_master_setup and nim_clients_setup
scripts provide a way to set up the NIM
environment.
• Requires an available AIX 5.2 system that can be
used as the NIM master.
Installing AIX in a Partitioned Environment
4-1
Installing AIX using the CD–ROM
device to install a partition with an
HMC on page 4-14
• You need not set up the NIM environment.
• Installing AIX from CD can be time–consuming.
• No convenient way to do systems management
functions.
• More work required on Hardware Management
Console (HMC) to activate and deactivate LPARs.
Installing AIX using the CD–ROM
device to install a partition without
an HMC on page 4-19
• You need not set up the NIM environment.
• Installing AIX from CD can be time–consuming.
• No convenient way to do systems management
functions.
Migrate a System to the AIX 5.2
• Some applications on the pre–migrated operating
Partition–Ready State on page 4-22
system may not be certified or compatible with
AIX 5.2.
• For currently available applications, see
http://www–1.ibm.com/servers/aix/products/ibms
w/list/
Update an Existing NIM
Environment to the Latest AIX
Recommended Maintenance Level
on page 4-25
The nim_update_all script provides a one–step
method to update an existing NIM environment and
its resources created with the nim_master_setup
script to the latest recommended maintenance
level.
Configure an Initial Partition as a NIM Master to Use NIM to
Install the Remaining Partitions
In this procedure, you will set up an initial logical partition as a NIM master and server. This
procedure refers to this initial logical partition as the Master_LPAR. It is assumed that AIX is
already installed and configured for network communication in the Master_LPAR. Make sure
your network environment is already defined and working correctly before configuring the
NIM environment.
After you verify the correct level of the AIX operating system has been installed on the
Master_LPAR, as the root user, you will set up the NIM environment using the
nim_master_setup script. The nim_master_setup script automatically installs the
bos.sysmgt.nim.master file set, configures the NIM master, and creates the required
resources for installation, including a mksysb system backup.
Note: The nim_master_setup script uses the rootvg volume group and creates an
/export/nim file system, by default. You can change these defaults using the
volume_group and file_system options. The nim_master_setup script also allows
you to optionally not create a generic system backup, if you plan to use a mksysb
image from another system.
You will then use the nim_clients_setup script to define your NIM clients, allocate the
installation resources, and initiate a NIM BOS installation on the clients. Then using the
HMC, you will activate the client partitions and configure them to boot off the network.
Prerequisites
Before you begin this procedure, you should have already performed the following tasks:
• Use the HMC to create the Master_LPAR logical partition and partition profile. Be sure
the Master_LPAR partition has a network adapter, enough hard–disk space for the NIM
resources, and an assigned CD device. Set the boot mode for the Master_LPAR partition
to be Normal mode. After you have successfully created the partition and partition profile,
leave the partition in the Ready state. Do not activate the partition yet.
4-2
AIX Installation in a Partitioned Environment
• Use the HMC to create logical partitions and partition profiles for each NIM client. Be
sure each LPAR has a network adapter assigned. Set the boot mode for each partition to
be SMS mode. After you have successfully created the partitions and partition profiles,
leave the partitions in the Ready state. Do not activate the partitions yet.
• Configure AIX for network communication on the Master_LPAR. If AIX is not currently
installed on any of the disks in the system, then refer to Installing AIX using the
CD–ROM device to install a partition with an HMC on page 4-14 for the procedure.
1. Activate the Master_LPAR (Perform this Step in the HMC Interface)
After you have successfully created the Master_LPAR, it is in the Ready state.
Use the HMC to activate the Master_LPAR partition, as follows:
__ Step 1.
To activate the Master_LPAR, do the following:
a. Select the Master_LPAR partition.
b. Right–click on the partition to open the menu.
c. Select Activate. The Activate Partition menu opens with a selection of partition
profiles. Be sure the correct partition profile is highlighted.
d. Select Open terminal at the bottom of the menu to open a virtual terminal (vterm)
window.
e. Select OK. A vterm window opens for the partition. After several seconds, the login
prompt displays in the vterm window.
2. Configure NIM Master and Initiate Installation of Partitions (Perform
These Steps in the AIX Environment)
__ Step 1.
Run the oslevel command as follows:
# oslevel
Output similar to the following displays:
5200
. The oslevel command reports the maintenance level of the operating system
using a subset of all filesets installed on your system. If the output from the oslevel
command does not show the expected OS level, see Migrate a System to the AIX
5.3 Partition–Ready State on page 4-22 for information about migrating the AIX
operating system to the correct OS level.
__ Step 2.
Verify network configuration by running the following commands:
# smitty mktcpip
. Select the Network Interface and press Enter.
. Confirm or enter your host name, IP address, name server, domain name, default
gateway, as well as ring speed or cable type. Press Enter. You can also test the
network status by using the following netstat command options:
# netstat –C
. The –C flag shows the routing table information. Check to make sure your gateway
information is correct.
# netstat –D
. The –D flag shows the number of packets received, transmitted, and dropped in
the communications subsystem. Check to make sure the network device is
sending and receiving packet information.
Installing AIX in a Partitioned Environment
4-3
__ Step 3.
Insert the AIX 5L for POWER Version 5.3 Volume 1 in the CD device.
Run the nim_master_setup command as follows:
# nim_master_setup
. This command configures the NIM environment on the AIX system by installing the
bos.sysmgt.nim.master fileset, configuring the NIM environment, and creating
the boot, nim_script, resolv_conf, bosinst_data, LPP_Source, and SPOT
resources. If you plan to use a mksysb image from another system, the –B flag is
used to prevent creating the mksysb resource. The nim_master_setup script uses
the /dev/cd0 device as the default device. You can specify an alternate location
using the –a device= full_path_name option.
. The nim_master_setup script uses the rootvg volume group and creates an
/export/nim file system, by default. You can change these defaults by using the
volume_group and file_system options.
Note: The output from the nim_master_setup script is stored in the
/var/adm/ras/nim.setup log file.
__ Step 4.
If you are adding new client machines that cannot be resolved on the name
server, edit the /etc/hosts file to add the IP addresses and client host
names.
__ Step 5.
There are two ways to define the client systems and initiate the BOS
Installation. The first method uses the SMIT interface to define the clients
and then uses the nim_clients_setup script to initiate the installation. The
second method allows you to manually edit the client.defs file and then use
the nim_clients_setup script to define the clients with this file and then
initiate the installation. This section describes both methods:
. Use SMIT and the nim_clients_setup script, as follows:
a. Run the smitty nim_mkclient fast path and the nim_clients_setup script to
define the client partitions in the NIM environment.
# smitty nim_mkclient
. Select Add a NIM Client.
. Enter a host name and press Enter.
Define a Machine
Type or select a value for the entry field.
Press Enter AFTER making all desired changes.
* Host Name of Machine
(Primary Network Install Interface)
[
[Entry Fields]
lpar1 ]
. If a menu prompts you for the Type of Network Attached to Primary Network
Install Interface, select the network adapter from the list and press Enter.
. In the Define a Machine menu, supply the necessary information by typing in
the entry fields or using the F4 key to open a selection menu. Verify all
information is correct, especially the Hardware Platform Type (chrp), Kernel
to Use for Network Boot (mp), and Network Type. Press Enter when you are
finished.
4-4
AIX Installation in a Partitioned Environment
Define a Machine
Type or select values in entry fields.
Press Enter AFTER making all desired changes.
[TOP]
* NIM Machine Name
* Machine Type
* Hardware Platform Type
Kernel to use for Network Boot
Primary Network Install Interface
*
Cable Type
*
NIM Network
*
Network Type
*
Ethernet Type
*
Subnetmask
*
Default Gateway Used by Machine
*
Default Gateway Used by Master
*
Host Name
Network Adapter Hardware Address
[Entry Fields]
[lpar1]
[standalone]
[chrp]
[mp]
bnc
[ent–Network1]
ent
Standard
[]
[]
[]
lpar1
[0]
+
+
b. Repeat for each client partition. Use the F3 key to return to the previous menu,
and change the information for each client.
c. Run the nim_clients_setup script as follows:
# nim_clients_setup
The nim_clients_setup command creates a NIM machine group with the
clients you just defined using the SMIT interface, then allocates the
LPP_Source, SPOT, mksysb, bosinst.data, and resolv.conf resources, and
finally initiates a NIM mksysb installation. The NIM mksysb installation uses the
generic_sysb resource that was created with the nim_master_setup script. If
you want to use another mksysb image, use the –m mksysb_path option, and
the script defines and uses it to install the partitions. The path must be local to
the master.
. Use a text editor to manually edit the client.defs file and use the
nim_clients_setup script, as follows:
a. Use the vi editor to customize the /export/nim/client.defs file as follows:
# vi /export/nim/client.defs
. Edit the client.defs file according to your environment. For more
information, see the instructions and examples in the client.defs file. When
you are finished editing the client.defs file, save it and exit the vi editor.
b. Run the nim_clients_setup script to define the client partitions in the NIM
environment as follows:
# nim_clients_setup –c
. The –c option specifies using the client.defs file for your client definitions.
The nim_clients_setup command creates a NIM machine group with all the
resources created from the nim_master_setup script and initiates a NIM
mksysb installation. If you want to use another mksysb image, use the –m
mksysb_path option, and the script defines and uses it to install the
partitions. The path must be local to the master.
Installing AIX in a Partitioned Environment
+
+
+
4-5
3. Activate and Install Partitions (Perform These Steps in the HMC
Interface)
__ Step 1.
To activate the partitions, do the following:
a. Select the partition (or partition profile) you want to activate.
b. Right–click on the partition (or partition profile) to open the menu.
c. Select Activate. The Activate Partition menu opens with a selection of partition
profiles. Select a partition profile that is set to boot to the SMS menus.
d. Select Open terminal at the bottom of the menu to open a virtual terminal (vterm)
window.
e. Select OK. A vterm window opens for each partition. After several seconds, the
System Management Services (SMS) menu opens in the vterm window.
__ Step 2.
In the SMS menu on the vterm window, do the following:
a. Press the 6 key to select 6 Multiboot.
Version RHxxxx_xxxxxx
(c) Copyright IBM Corp. 2001 All rights reserved.
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Utilities
1
2
3
4
5
7
8
Password Utilities NOT available in LPAR mode
Display Error Log
Remote Initial Program Load Setup
SCSI Utilities
Select Console NOT available in LPAR mode
6 MultiBoot
Select Language
OK Prompt
.––––––.
|X=Exit|
‘––––––’
===>
6
b. Press the 4 key to select 4 Select Boot device.
c. Press the 3 key to select 3 Configure 1st boot device.
Version RHxxx_xxxxxx
(c) Copyright IBM Corp. 2001 All rights reserved.
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Select Boot Devices
1
2
4
5
6
7
Display Current Settings
Restore Default Settings
3 Configure 1st Boot Device
Configure 2nd Boot Device
Configure 3rd Boot Device
Configure 4th Boot Device
Configure 5th Boot Device
.––––––.
|X=Exit|
‘––––––’
===>
3
d. Select the network adapter from the list of available devices.
e. Press the x key until you return to the Utilities menu.
f. Press the 3 key to select 3 Remote Initial Program Load Setup.
4-6
AIX Installation in a Partitioned Environment
Version RHxxxx_xxxxxx
(c) Copyright IBM Corp. 2001 All rights reserved.
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Utilities
1
2
4
5
6
7
8
Password Utilities NOT available in LPAR mode
Display Error Log
3 Remote Initial Program Load Setup
SCSI Utilities
Select Console NOT available in LPAR mode
MultiBoot
Select Language
OK Prompt
.––––––.
|X=Exit|
‘––––––’
===>
3
g. Press the 1 key to select 1. IP Parameters.
h. Type the appropriate information for Client IP Address, Server IP Address,
Gateway IP Address, and Subnet Mask. Press the x key to exit to the Network
Parameters menu.
Version RHxxxx_xxxxxx
(c) Copyright IBM Corp. 2001 All rights reserved.
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
IP Parameters
1.
2.
3.
4.
Client IP Address
Server IP Address
Gateway IP Address
Subnet Mask
[000.000.000.000]
[000.000.000.000]
[000.000.000.000]
[255.255.255.000]
.––––––.
|X=Exit|
‘––––––’
===>
i. Press the 2 key to select 2 Adapter Parameters.
j. Select the network device you want to use and press Enter. If a menu prompts for
further configuration of the network device, select the appropriate settings. When
you are finished, press Enter to exit to the Network Properties menu.
k. Press the x key to exit to the previous menu.
l. Press the 3 key to select 3 PING Test.
m. Select the network adapter for the ping test and press Enter.
n. If another menu displays the network adapter configuration information, press the x
key to exit to the previous menu.
o. Press the x key to exit to the previous menu.
p. Press the e key to execute the ping operation.
Installing AIX in a Partitioned Environment
4-7
Version RHxxx_xxxxxx
(c) Copyright IBM Corp. 2001 All rights reserved.
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Ping IP Address
1.
2.
3.
4.
Client IP Address
Server IP Address
Gateway IP Address
Subnet Mask
[000.000.000.000]
[000.000.000.000]
[000.000.000.000]
[255.255.255.000]
.–––––––––.
|E=Execute|
‘–––––––––’
===>
e
.––––––.
|X=Exit|
‘––––––’
– If the ping operation does not return successfully, return to the 1. IP
Parameters menu selection to make sure all information is correctly entered.
Also, check the 2 Adapter Parameters selection to make sure the network
adapter configuration is correct according to your network. You may also want
to make sure the network adapter is functioning correctly.
– If the ping operation returns successfully, proceed with the network boot. Press
the x key until you exit the SMS menus and begin the network boot.
4. Log in to Your Partition (Perform This Step in the AIX Environment)
When the installation has completed and the system has rebooted, the vterm window
displays a login prompt.
At this point, you may want to perform several common system–administration procedures.
The following table lists where to find information about performing these procedures.
Procedure
Location
Partition Backup and Storage
Management
System Backup, Dump, and Storage Management
on page 5-1
Remote System Management
Remote Management on page 6-1
User and Group Management
AIX 5L Version 5.3 System Management Guide:
Operating System and Devices
Software Installation
AIX 5L Version 5.3 Installation Guide and Reference
Performance Management
AIX 5L Version 5.3 Performance Management Guide
Printer Configuration
AIX 5L Version 5.3 Guide to Printers and Printing
Use a Separate AIX System as a NIM Master to Use NIM to
Install Each Partition
In this procedure, you will use a separate system running AIX 5.3 as a NIM master and
server, to use NIM to install your logical partitions. As with any NIM environment, you must
make sure your network environment is already defined and working correctly.
After the correct level of the AIX operating system has been installed on this separate
system, as the root user, you will set up the NIM environment using the nim_master_setup
script. The nim_master_setup script automatically installs the bos.sysmgt.nim.master
fileset from your media, configures the NIM master, and creates a generic system backup
that will be used to install the partitions, as well as the SPOT and LPP_Source resources.
Note: The nim_master_setup script uses the rootvg volume group and creates an
/export/nim file system, by default. You can change these defaults using the
volume_group and file_system options. The nim_master_setup script also allows
4-8
AIX Installation in a Partitioned Environment
you to optionally not create a generic system backup, if you plan to use a mksysb
image from another system to install your partitions.
You will then define your clients using SMIT or using the NIM clients.def file, then use the
nim_clients_setup script to allocate the installation resources, and initiate a NIM BOS
installation on the clients. Then using the HMC, you will activate the partitions and configure
them to boot off the network.
Prerequisites
Before you begin this procedure, you should have used the HMC to create partitions and
partition profiles for each partition that you want to install. Be sure each partition has a
network adapter assigned. Set the boot mode for each partition to be SMS mode. After you
have successfully created the partitions and partition profiles, leave the partitions in the
Ready state. Do not activate the partitions yet.
1. Configure NIM Master and Initiate Installation of Partitions (Perform
These Steps in the AIX Environment)
__ Step 1.
Run the oslevel command as follows:
# oslevel
Output similar to the following displays:
5200
. The oslevel command reports the maintenance level of the operating system
using a subset of all filesets installed on your system. If the output from the oslevel
command does not show the expected OS level, see Migrate a System to the AIX
5.3 Partition–Ready State on page 4-22 for information about migrating the AIX
operating system to the correct OS level.
__ Step 2.
Verify network configuration by running the following commands:
# smitty mktcpip
. Select the Network Interface and press Enter.
. Confirm or enter your host name, IP address, name server, domain name, default
gateway, as well as ring speed or cable type. Press Enter. You can also test the
network status by using the following netstat command options:
# netstat –C
. The –C flag shows the routing table information. Check to make sure your gateway
information is correct.
# netstat –D
. The –D flag shows the number of packets received, transmitted, and dropped in
the communications subsystem. Check to make sure the network device is
sending and receiving packet information.
__ Step 3.
Insert the AIX 5L for POWER Version 5.3 Volume 1 in the CD device.
Run the nim_master_setup command as follows:
# nim_master_setup
. This command configures the NIM environment on the AIX system by installing the
bos.sysmgt.nim.master fileset, configuring the NIM environment, and creating
the boot, nim_script, resolv_conf, bosinst_data, LPP_Source, and SPOT
resources. If you plan to use a mksysb image from another system, the –B flag is
used to prevent creating the mksysb resource. The nim_master_setup script uses
the /dev/cd0 device as the default device. You can specify an alternate location
using the –a device= full_path_name option.
Installing AIX in a Partitioned Environment
4-9
. The nim_master_setup script uses the rootvg volume group and creates an
/export/nim file system, by default. You can change these defaults by using the
volume_group and file_system options.
Note: The output from the nim_master_setup script is stored in the
/var/adm/ras/nim.setup log file.
__ Step 4.
If you are adding new client machines that cannot be resolved on the name
server, edit the /etc/hosts file to add the IP addresses and client host
names.
__ Step 5.
There are two ways to define the client systems and initiate the BOS
Installation. The first method uses the SMIT interface to define the clients
and then uses the nim_clients_setup script to initiate the installation. The
second method allows you to manually edit the client.defs file and then use
the nim_clients_setup script to define the clients with this file and then
initiate the installation. This section describes both methods:
. Use SMIT and the nim_clients_setup script, as follows:
a. Run the smitty nim_mkclient fast path and the nim_clients_setup script to
define the client partitions in the NIM environment.
# smitty nim_mkclient
. Select Add a NIM Client.
. Enter a host name and press Enter.
Define a Machine
Type or select a value for the entry field.
Press Enter AFTER making all desired changes.
* Host Name of Machine
(Primary Network Install Interface)
[
[Entry Fields]
lpar1 ]
. If a menu prompts you for the Type of Network Attached to Primary Network
Install Interface, select the network adapter from the list and press Enter.
. In the Define a Machine menu, supply the necessary information by typing in
the entry fields or using the F4 key to open a selection menu. Verify all
information is correct, especially the Hardware Platform Type (chrp), Kernel
to Use for Network Boot (mp), and Network Type. Press Enter when you are
finished.
4-10 AIX Installation in a Partitioned Environment
Define a Machine
Type or select values in entry fields.
Press Enter AFTER making all desired changes.
[TOP]
* NIM Machine Name
* Machine Type
* Hardware Platform Type
Kernel to use for Network Boot
Primary Network Install Interface
*
Cable Type
*
NIM Network
*
Network Type
*
Ethernet Type
*
Subnetmask
*
Default Gateway Used by Machine
*
Default Gateway Used by Master
*
Host Name
Network Adapter Hardware Address
[Entry Fields]
[lpar1]
[standalone]
[chrp]
[mp]
bnc
[ent–Network1]
ent
Standard
[]
[]
[]
lpar1
[0]
b. Repeat for each client partition. Use the F3 key to return to the previous menu,
and change the information for each client.
c. Run the nim_clients_setup script as follows:
# nim_clients_setup
The nim_clients_setup command creates a NIM machine group with the
clients you just defined using the SMIT interface, then allocates the
LPP_Source, SPOT, mksysb, bosinst.data, and resolv.conf resources, and
finally initiates a NIM mksysb installation. The NIM mksysb installation uses the
generic_sysb resource that was created with the nim_master_setup script. If
you want to use another mksysb image, use the –m mksysb_path option, and
the script defines and uses it to install the partitions. The path must be local to
the master.
. Use a text editor to manually edit the client.defs file and use the
nim_clients_setup script, as follows:
a. Use the vi editor to customize the /export/nim/client.defs file as follows:
# vi /export/nim/client.defs
. Edit the client.defs file according to your environment. For more
information, see the instructions and examples in the client.defs file. When
you are finished editing the client.defs file, save it and exit the vi editor.
b. Run the nim_clients_setup script to define the client partitions in the NIM
environment as follows:
# nim_clients_setup –c
. The –c option specifies using the client.defs file for your client definitions.
The nim_clients_setup command creates a NIM machine group with all the
resources created from the nim_master_setup script and initiates a NIM
mksysb installation. If you want to use another mksysb image, use the –m
mksysb_path option, and the script defines and uses it to install the
partitions. The path must be local to the master.
Installing AIX in a Partitioned Environment 4-11
+
+
+
+
+
2. Activate and Install Partitions (Perform These Steps in the HMC
Interface)
__ Step 1.
To activate the partitions, do the following:
a. Select the partition (or partition profile) you want to activate.
b. Right–click on the partition (or partition profile) to open the menu.
c. Select Activate. The Activate Partition menu opens with a selection of partition
profiles. Select a partition profile that is set to boot to the SMS menus.
d. Select Open terminal at the bottom of the menu to open a virtual terminal (vterm)
window.
e. Select OK. A vterm window opens for each partition. After several seconds, the
System Management Services (SMS) menu opens in the vterm window.
__ Step 2.
In the SMS menu on the vterm window, do the following:
a. Press the 6 key to select 6 Multiboot.
Version RHxxxx_xxxxxx
(c) Copyright IBM Corp. 2001 All rights reserved.
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Utilities
1
2
3
4
5
7
8
Password Utilities NOT available in LPAR mode
Display Error Log
Remote Initial Program Load Setup
SCSI Utilities
Select Console NOT available in LPAR mode
6 MultiBoot
Select Language
OK Prompt
.––––––.
|X=Exit|
‘––––––’
===>
6
b. Press the 4 key to select 4 Select Boot device.
c. Press the 3 key to select 3 Configure 1st boot device.
Version RHxxx_xxxxxx
(c) Copyright IBM Corp. 2001 All rights reserved.
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Select Boot Devices
1
2
4
5
6
7
Display Current Settings
Restore Default Settings
3 Configure 1st Boot Device
Configure 2nd Boot Device
Configure 3rd Boot Device
Configure 4th Boot Device
Configure 5th Boot Device
.––––––.
|X=Exit|
‘––––––’
===>
3
d. Select the network adapter from the list of available devices.
e. Press the x key until you return to the Utilities menu.
f. Press the 3 key to select 3 Remote Initial Program Load Setup.
4-12 AIX Installation in a Partitioned Environment
Version RHxxxx_xxxxxx
(c) Copyright IBM Corp. 2001 All rights reserved.
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Utilities
1
2
4
5
6
7
8
Password Utilities NOT available in LPAR mode
Display Error Log
3 Remote Initial Program Load Setup
SCSI Utilities
Select Console NOT available in LPAR mode
MultiBoot
Select Language
OK Prompt
.––––––.
|X=Exit|
‘––––––’
===>
3
g. Press the 1 key to select 1. IP Parameters.
h. Type the appropriate information for Client IP Address, Server IP Address,
Gateway IP Address, and Subnet Mask. Press the x key to exit to the Network
Parameters menu.
Version RHxxxx_xxxxxx
(c) Copyright IBM Corp. 2001 All rights reserved.
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
IP Parameters
1.
2.
3.
4.
Client IP Address
Server IP Address
Gateway IP Address
Subnet Mask
[000.000.000.000]
[000.000.000.000]
[000.000.000.000]
[255.255.255.000]
.––––––.
|X=Exit|
‘––––––’
===>
i. Press the 2 key to select 2 Adapter Parameters.
j. Select the network device you want to use and press Enter. If a menu prompts for
further configuration of the network device, select the appropriate settings. When
you are finished, press Enter to exit to the Network Properties menu.
k. Press the x key to exit to the previous menu.
l. Press the 3 key to select 3 PING Test.
m. Select the network adapter for the ping test and press Enter.
n. If another menu displays the network adapter configuration information, press the x
key to exit to the previous menu.
o. Press the x key to exit to the previous menu.
p. Press the e key to execute the ping operation.
Installing AIX in a Partitioned Environment 4-13
Version RHxxx_xxxxxx
(c) Copyright IBM Corp. 2001 All rights reserved.
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Ping IP Address
1.
2.
3.
4.
Client IP Address
Server IP Address
Gateway IP Address
Subnet Mask
[000.000.000.000]
[000.000.000.000]
[000.000.000.000]
[255.255.255.000]
.–––––––––.
|E=Execute|
‘–––––––––’
===>
e
.––––––.
|X=Exit|
‘––––––’
– If the ping operation does not return successfully, return to the 1. IP
Parameters menu selection to make sure all information is correctly entered.
Also, check the 2 Adapter Parameters selection to make sure the network
adapter configuration is correct according to your network. You may also want
to make sure the network adapter is functioning correctly.
– If the ping operation returns successfully, proceed with the network boot. Press
the x key until you exit the SMS menus and begin the network boot.
3. Log in to Your Partition (Perform This Step in the AIX Environment)
When the installation has completed and the system has rebooted, the vterm window
displays a login prompt.
Procedure
Location
Partition Backup and Storage
Management
System Backup, Dump, and Storage Management
on page 5-1
Remote System Management
Remote Management on page 6-1
User and Group Management
AIX 5L Version 5.3 System Management Guide:
Operating System and Devices
Software Installation
AIX 5L Version 5.3 Installation Guide and Reference
Performance Management
AIX 5L Version 5.3 Performance Management Guide
Printer Configuration
AIX 5L Version 5.3 Guide to Printers and Printing
Installing AIX using the CD–ROM device to install a partition
with an HMC
This information contains procedures to install the AIX operating system. For more
information on concepts and considerations involved when performing a base operating
system installation of AIX, or concepts and requirements involved when using the Network
Installation Manager (NIM) to install and maintain AIX, refer to the AIX 5L Installation Guide
and Reference.
Note: For the installation method that you choose, ensure that you follow the sequence of
steps as shown. Within each procedure, you must use AIX to complete some
installation steps, while other steps are completed using the HMC interface.
In this procedure, you will perform a New and Complete Base Operating System Installation
on a logical partition using the partition’s CD–ROM device. This procedure assumes that
there is an HMC attached to the managed system.
4-14 AIX Installation in a Partitioned Environment
Prerequisites
Before you begin this procedure, you should have already used the HMC to create a
partition and partition profile for the client. Assign the SCSI bus controller attached to the
CD–ROM device, a network adapter, and enough disk space for the AIX operating system
to the partition. Set the boot mode for this partition to be SMS mode. After you have
successfully created the partition and partition profile, leave the partition in the Ready state.
For instructions about how to create a logical partition and partition profile, refer to the
Creating logical partitions and partition profiles article on the ESCALA Power 5 Hardware
CD–ROM.
1. Activate and install the partition (perform these steps in the HMC
interface)
__ Step 1.
Activate the partition, as follows:
a. Insert the AIX 5L Volume 1 CD into the CD device of the managed system.
b. Right–click on the partition to open the menu.
c. Select Activate. The Activate Partition menu opens with a selection of partition
profiles. Be sure the correct profile is highlighted.
d. Select Open a terminal window or console session at the bottom of the menu to
open a virtual terminal (vterm) window.
e. Select Advanced to open the Advanced options menu.
f. For the Boot mode, select SMS.
g. Select OK to close the Advanced options menu.
h. Select OK. A vterm window opens for the partition.
__ Step 2.
In the SMS menu on the vterm, do the following:
a. Press the 5 key and press Enter to select 5. Select Boot Options.
PowerPC Firmware
Version SF220_001
SMS 1.5 (c) Copyright IBM Corp. 2000, 2003 All rights reserved.
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Main Menu
1.
2.
3.
4.
5.
Select Language
Setup Remote IPL (Initial Program Load)
Change SCSI Settings
Select Console
Select Boot Options
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Navigation Keys:
X = eXit System Management
Services
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Type the number of the menu item and press Enter or select Navigation Key:
5
b. Press the 2 key and press Enter to select 2. Select Boot Devices.
c. Press the 1 key and press Enter to select 1. Select 1st Boot Device.
d. Press the 3 key and press Enter to select 3. CD/DVD.
e. Select the media type that corresponds to the CD–ROM device and press Enter.
Installing AIX in a Partitioned Environment 4-15
f. Select the device number that corresponds to the CD–ROM device and press
Enter. The CD–ROM device is now the first device in the Current Boot Sequence
list.
g. Press the ESC key until you return to the Configure Boot Device Order menu.
h. Press the 2 key to select 2. Select 2nd Boot Device.
i. Press the 5 key and press Enter to select 5. Hard Drive.
j. If you have more than one hard disk in your partition, determine which hard disk
you will use to perform the AIX installation. Select the media type that corresponds
to the hard disk and press Enter.
k. Select the device number that corresponds to the hard disk and press Enter.
l. Press the x key to exit the SMS menu. Confirm that you want to exit SMS.
__ Step 3.
Boot from the AIX 5L Volume 1, as follows:
a. Select console and press Enter.
b. Select language for BOS Installation menus, and press Enter to open the Welcome
to Base Operating System Installation and Maintenance menu.
c. Type 2 to select Change/Show Installation Settings and Install in the Choice
field and press Enter.
Welcome to Base Operating System
Installation and Maintenance
Type the number of your choice and press Enter.
Choice is indicated by >>>.
1 Start Install Now with Default Settings
2 Change/Show Installation Settings and Install
3 Start Maintenance Mode for System Recovery
88 Help ?
99 Previous Menu
>>> Choice [1]: 2
__ Step 4.
Verify or Change BOS Installation Settings, as follows:
a. Type 1 in the Choice field to select the System Settings option.
b. Type 1 for New and Complete Overwrite in the Choice field and press Enter.
Note:
The installation methods available depend on whether your disk has a previous
version of AIX installed.
c. When the Change Disk(s) screen displays, you can change the destination disk for
the installation. If the default shown is correct, type 0 in the Choice field and press
Enter. To change the destination disk, do the following:
i. Type the number for each disk you choose in the Choice field and press Enter.
Do not press Enter a final time until you have finished selecting all disks. If you
must deselect a disk, type its number a second time and press Enter.
ii. When you have finished selecting the disks, type 0 in the Choice field and
press Enter. The Installation and Settings screen displays with the selected
disks listed under System Settings.
d. If needed, change the primary language environment. Use the following steps to
change the primary language used by this installation to select the language and
cultural convention you want to use.
4-16 AIX Installation in a Partitioned Environment
Note:
Changes to the primary language environment do not take effect until after the
Base Operating System Installation has completed and your system is rebooted.
i. Type 2 in the Choice field on the Installation and Settings screen to select the Primary
Language Environment Settings option.
ii. Select the appropriate set of cultural convention, language, and keyboard options. Most
of the options are a predefined combination, however, you can define your own
combination of options.
– To choose a predefined Primary Language Environment, type that number in the
Choice field and press Enter.
– To configure your own primary language environment, do the following:
1. Select MORE CHOICES.
2. Select Create Your Own Combination.
3. When the Set Primary Cultural Convention screen displays, type the number in the
Choice field that corresponds to the cultural convention of your choice and press
Enter.
4. When the Set Primary Language screen displays, type the number in the Choice
field that corresponds to your choice for the primary language and press Enter.
5. When the Set Keyboard screen displays, type the number in the Choice field that
corresponds to the keyboard attached to the system and press Enter.
• After you have made all of your selections, verify that the selections are correct. Press
Enter to confirm your selections and to begin the BOS Installation. The system
automatically reboots after installation is complete.
__ Step 5.
Switch the partition to Normal Mode, as follows:
a. Right–click on the partition profile to open the menu. Be sure the correct
partition profile is highlighted.
b. Select Properties.
c. Select the Settings tab.
d. For the Boot Mode, select Normal.
e. Select OK to close the Properties menu.
f. Right–click on the partition to open the menu.
g. Select Restart Partition.
h. Select Immediate for the Restart Options.
i. Confirm that you want to restart the partition.
j. When the partition has restarted, right–click on the partition to open the menu.
k. Select Open terminal window to open a virtual terminal (vterm) window.
__ Step 6.
Complete the BOS Installation, as follows:
a. Type vt100 as the terminal type.
Installing AIX in a Partitioned Environment 4-17
Set Terminal Type
The terminal is not properly initialized. Please enter a terminal type
and press Enter. Some terminal types are not supported in
non–English languages.
ibm3101
ibm3151
ibm3161
ibm3162
ibm3163
ibm3164
ibmpc
lft
88
99
Help ?
Exit
>>> Choice []:
tvi912
tvi920
tvi925
tvi950
vs100
vt100
vt320
sun
vt330
vt340
wyse30
wyse50
wyse60
wyse100
wyse350
+–––––––––––––––––––––––Messages––––––––––––––––––––––––
| If the next screen is unreadable, press Break (Ctrl–c)
| to return to this screen.
|
|
vt100
b. In the License Agreement menu, select Accept License Agreements.
c. Select yes to ACCEPT Installed License Agreements.
d. Press F10 (or Esc+0) to exit the License Agreement menu.
e. In the Installation Assistant main menu, select Set Date and Time.
Installation Assistant
Move cursor to desired item and press Enter.
Set Date and Time
Set root Password
Configure Network Communications
Install Software Applications
Using SMIT (information only)
F1=Help
F9=Shell
F2=Refresh
F10=Exit
F3=Cancel
Enter=Do
F8=Image
f. Set the correct date, time, and time zone. Press the F3 (or Esc+3) key to return
to the Installation Assistant main menu.
g. Select Set root Password. Set a root password for the partition.
h. Select Configure Network Communications. Select TCP/IP Startup. Select
from the Available Network Interfaces and press Enter. Enter the appropriate
network information in the Minimum Configuration and Startup menu and press
Enter. Use the F3 (or Esc+3) key to return to the Installation Assistant main
menu.
i. Exit the Installation Assistant by typing F10 (or Esc+0).
j. The vterm window displays a login prompt.
4-18 AIX Installation in a Partitioned Environment
2. Manage Your Partition (Perform This Step in the AIX Environment)
When the installation has completed and the system has rebooted, the vterm window
displays a login prompt.
At this point, you may want to perform several common system–administration procedures.
The following table lists where to find information about performing these procedures.
Procedure
Location
Partition Backup and Storage
Management
System Backup, Dump, and Storage Management
on page 5-1
Remote System Management
Remote Management on page 6-1
User and Group Management
AIX 5L Version 5.3 System Management Guide:
Operating System and Devices
Software Installation
AIX 5L Version 5.3 Installation Guide and Reference
Performance Management
AIX 5L Version 5.3 Performance Management Guide
Printer Configuration
AIX 5L Version 5.3 Guide to Printers and Printing
Installing AIX using the CD–ROM device to install a partition
without an HMC
This information contains procedures to install the AIX operating system. For more
information on concepts and considerations involved when performing a base operating
system installation of AIX, or concepts and requirements involved when using the Network
Installation Manager (NIM) to install and maintain AIX, refer to the AIX 5L Installation Guide
and Reference.
In this procedure, you will use the system’s built–in CD–ROM device to perform a New and
Complete Base Operating System Installation on the standalone system.
1. Prepare your system
• There must be adequate disk space and memory available. AIX 5.3 requires 128 MB of
memory and 2.2 GB of physical disk space. For additional release information, see the
AIX 5.3 Release Notes.
• Make sure your hardware installation is complete, including all external devices. See the
documentation provided with your system unit for installation instructions.
• If your system needs to communicate with other systems and access their resources,
make sure you have the information in the following worksheet before proceeding with
installation:
Table 10. Network Configuration Information Worksheet
Network Attribute
Value
Network Interface
(For example: en0, et0)
Host Name
IP Address
_______.________.________.________
Network Mask
_______.________.________.________
Nameserver
_______.________.________.________
Domain Name
Gateway
_______.________.________.________
Installing AIX in a Partitioned Environment 4-19
2. Boot from the AIX product CD
1. Insert the AIX Volume 1 CD into the CD–ROM device.
2. Make sure all external devices attached to the system (such as CD–ROM drives, tape
drives, DVD drives, and terminals) are turned on. Only the CD–ROM drive from which
you will install AIX should contain the installation media.
3. Power on the system.
4. When the system beeps twice, press F5 on the keyboard (or 5 on an ASCII terminal). If
you have a graphics display, you will see the keyboard icon on the screen when the
beeps occur. If you have an ASCII terminal (also called a tty terminal), you will see the
word keyboard when the beeps occur. Note:
If your system does not boot using the F5 key (or the 5 key on an ASCII terminal), refer
to your hardware documentation for information about how to boot your system from an
AIX product CD.
5. Select the system console by pressing F1 (or 1 on an ASCII terminal) and press Enter.
6. Select the English language for the base operating system (BOS) Installation menus by
typing a 1 in the Choice field. Press Enter to open the Welcome to Base Operating
System Installation and Maintenance screen.
7. Type 2 to select 2 Change/Show Installation Settings and Install in the Choice field
and press Enter.
Welcome to Base Operating System
Installation and Maintenance
Type the number of your choice and press Enter.
Choice is indicated by >>>.
1 Start Install Now with Default Settings
2 Change/Show Installation Settings and Install
3 Start Maintenance Mode for System Recovery
88 Help ?
99 Previous Menu
>>> Choice [1]:
2
3. Set and verify BOS installation settings
1. In the Installation and Settings screen, verify the installation settings are correct by
checking the method of installation (new and complete overwrite), the disk or disks you
want to install, the primary language environment settings, and the advanced options.
2. To change the System Settings, which includes the method of installation and disk where
you want to install, type 1 in the Choice field and press Enter.
Installation and Settings
Either type 0 and press Enter to install with current settings, or type the
number of the setting you want to change and press Enter.
1
System Settings:
Method of Installation.............New and Complete Overwrite
Disk Where You Want to Install.....hdisk0
>>> Choice [0]:
1
3. Type 1 for New and Complete Overwrite in the Choice field and press Enter. The
Change Disk(s) Where You Want to Install screen now displays.
4-20 AIX Installation in a Partitioned Environment
Change Disk(s) Where You Want to Install
Type one or more numbers for the disk(s) to be used for installation and press
Enter. To cancel a choice, type the corresponding number and Press Enter.
At least one bootable disk must be selected. The current choice is indicated
by >>>.
Name
1
2
3
>>>
0
66
77
88
99
hdisk0
hdisk1
hdisk2
Location Code
04–B0–00–2,0
04–B0–00–5,0
04–B0–00–6,0
Size(MB)
4296
4296
12288
VG Status
none
none
none
Bootable
Yes
Yes
Yes
Continue with choices indicated above
Disks not known to Base Operating System Installation
Display More Disk Information
Help ?
Previous Menu
>>> Choice [0]:
4. In the Change Disk(s) Where You Want to Install screen:
a. Select hdisk0 by typing a 1 in the Choice field and press Enter. The disk will now
be selected as indicated by >>>. To unselect the destination disk, type the number
again and press Enter.
b. To finish selecting disks, type a 0 in the Choice field and press Enter. The
Installation and Settings screen displays with the selected disks listed under System
Settings.
5. Change the Primary Language Environment Settings to English (United States). Use the
following steps to change the Cultural Convention, Language, and Keyboard to English.
a. Type 2 in the Choice field on the Installation and Settings screen to select the
Primary Language Environment Settings option.
b. Type the number corresponding to English (United States) as the Cultural Convention
in the Choice field and press Enter.
c. Select the appropriate keyboard and language options.
6. Verify that the selections are correct in the Overwrite Installation Summary screen, as
follows:
Overwrite Installation Summary
Disks: hdisk0
Cultural Convention: en_US
Language: en_US
Keyboard: en_US
64 Bit Kernel Enabled: No
JFS2 File Systems Created: No
Desktop: CDE
Enable System Backups to install any system:
Yes
Optional Software being installed:
>>> 1
88
99
Continue with Install
Help ?
Previous Menu
>>> Choice [1]:
7. Press Enter to begin the BOS installation. The system automatically reboots after
installation is complete.
Installing AIX in a Partitioned Environment 4-21
4. Manage Your Partition (Perform This Step in the AIX Environment)
When the installation has completed and the system has rebooted, the vterm window
displays a login prompt.
At this point, you may want to perform several common system–administration procedures.
The following table lists where to find information about performing these procedures.
Procedure
Location
Partition Backup and Storage
Management
System Backup, Dump, and Storage Management
on page 5-1
Remote System Management
Remote Management on page 6-1
User and Group Management
AIX 5L Version 5.3 System Management Guide:
Operating System and Devices
Software Installation
AIX 5L Version 5.3 Installation Guide and Reference
Performance Management
AIX 5L Version 5.3 Performance Management Guide
Printer Configuration
AIX 5L Version 5.3 Guide to Printers and Printing
Migrate a System to the AIX 5.3 Partition–Ready State
Use this procedure to migrate a separate system from AIX 5.1 or earlier to AIX 5.3. You
could then make a system backup (mksysb) of this system, and install this mksysb to a
partition or partitions on your managed system.
Prerequisites
Before you begin this procedure, you should have already performed the following tasks:
• There must be adequate disk space and memory available. AIX 5.3 requires 128 MB of
memory and 2.2 GB of physical disk space. For additional release information, see the
AIX 5L Version 5.3 Release Notes.
• Create a backup of the system. For instructions on how to create a system backup, refer
to the AIX 5L Version 5.3 Installation Guide and Reference.
• If the system you are installing must communicate with other systems and access their
resources, determine the following information for this host: network interface, IP
address, host name, and route to the network.
1. Migrate the System to AIX 5.3 (Perform These Steps in the AIX
Environment)
__ Step 1.
Turn the system unit power switch from Off (0) to On (|). The system
begins booting from the installation media.
__ Step 2.
Select the console. If you have more than one console, each might display
a screen that directs you to press a key to identify your system console.
The system console is the keyboard and display device used for installation
and system administration. A different key is specified for each console
displaying this screen. If this screen displays, press the specified key only
on the device to be used as the system console. Press a key on one
console only.
__ Step 3.
Select the language you prefer to use for installation instructions.
__ Step 4.
When the Welcome to Base Operating System Installation and
Maintenance screen displays, select Change/Show Installation Settings
and Install to verify the installation and system settings.
__ Step 5.
Verify the settings for Migration Installation, by following these steps:
4-22 AIX Installation in a Partitioned Environment
a. Select Migration as the Method of Installation. Select the disk or disks you want to
install.
1
System Settings:
Method of Installation.............Migration
Disk Where You Want to Install.....hdisk0...
b. Select Primary Language Environment Settings (AFTER Install).
c. Select Advanced Options and press Enter. To learn about the advanced options
available, type 88 and press Enter in the Advanced Options menu to use the Help
menu.
d. After you have made all of your selections, verify that the selections are correct
and start the migration installation process.
e. When the Migration Confirmation menu displays, follow the menu instructions to
list system information or to continue with the migration.
Migration Confirmation
Either type 0 and press Enter to continue the installation, or type the
number of your choice and press Enter.
1
2
3
4
List the saved Base System configuration files which will not be
merged into the system. These files are saved in /tmp/bos.
List the filesets which will be removed and not replaced.
List directories which will have all current contents removed.
Reboot without migrating.
Acceptance of license agreements is required before using system.
You will be prompted to accept after the system reboots.
>>> 0
88
Continue with the migration.
Help ?
+–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
WARNING: Selected files, directories, and filesets (installable options)
from the Base System will be removed. Choose 2 or 3 for more information.
>>> Choice[0]:
__ Step 6.
After the migration is complete, the system reboots. If the Set Terminal
Type menu displays, type vt100 for the terminal type.
Set Terminal Type
The terminal is not properly initialized. Please enter a terminal type
and press Enter. Some terminal types are not supported in
non–English languages.
ibm3101
ibm3151
ibm3161
ibm3162
ibm3163
ibm3164
ibmpc
lft
88
99
Help ?
Exit
>>> Choice []:
__ Step 7.
tvi912
tvi920
tvi925
tvi950
vs100
vt100
vt320
sun
vt330
vt340
wyse30
wyse50
wyse60
wyse100
wyse350
+–––––––––––––––––––––––Messages––––––––––––––––––––––––
| If the next screen is unreadable, press Break (Ctrl–c)
| to return to this screen.
|
|
vt100
In the License Agreement menu, select Accept License Agreements.
Installing AIX in a Partitioned Environment 4-23
__ Step 8.
Select yes to ACCEPT Installed License Agreements.
__ Step 9.
Press F10 (or Esc+0) to exit the License Agreement menu.
__ Step 10.
Verify the settings in the Installation Assistant.
Installation Assistant
Move cursor to desired item and press Enter.
Set Date and Time
Set root Password
Configure Network Communications
Install Software Applications
Using SMIT (information only)
F1=Help
F9=Shell
F2=Refresh
F10=Exit
F3=Cancel
Enter=Do
F8=Image
__ Step 11.
Press F10 (or Esc+0) to exit the Installation Assistant.
__ Step 12.
When the login prompt displays, log in as the root user to perform system
administration tasks.
2. Manage Your Migrated System (Perform This Step in the AIX
Environment)
When the installation has completed and the system has rebooted, the terminal window
displays a login prompt.
At this point, you may want to perform several common system–administration procedures.
The following table lists where to find information about performing these procedures.
Procedure
Location
Partition Backup and Storage
Management
System Backup, Dump, and Storage Management
on page 5-1
Remote System Management
Remote Management on page 6-1
User and Group Management
AIX 5L Version 5.3 System Management Guide:
Operating System and Devices
Software Installation
AIX 5L Version 5.3 Installation Guide and Reference
Performance Management
AIX 5L Version 5.3 Performance Management Guide
Printer Configuration
AIX 5L Version 5.3 Guide to Printers and Printing
4-24 AIX Installation in a Partitioned Environment
Update an Existing NIM Environment to the Latest AIX
Recommended Maintenance Level
Use this procedure to update an existing NIM environment that was created with the
nim_master_setup script to the latest recommended maintenance level of AIX.
Prerequisites
Before you begin this procedure, you should have already created a backup of the system.
For instructions on how to create a system backup, refer to the AIX 5L Version 5.3
Installation Guide and Reference.
1. Update Your NIM Environment to the Latest Recommended
Maintenance Level (Perform These Steps in the AIX Environment)
__ Step 1.
Insert the latest AIX update CD into the CD–ROM drive.
__ Step 2.
Update the bos.rte.install fileset by using the geninstall command as
follows:
# geninstall –d /dev/cd0 bos.rte.install
__ Step 3.
Run the install_all_updates script, as follows:
# install_all_updates –d /dev/cd0
. The install_all_updates script will first check if your system is at the latest known
recommended maintenance level.
. If your system is not at the latest known recommended maintenance level, then the
install_all_updates script updates the system to the latest maintenance level of
AIX. Note:
The output from the install_all_updates script is in the
/var/adm/ras/install_all_updates.log log file.__ Step 4.
After the update is complete, the system will instruct you to reboot the system.
Reboot the system by using the shutdown command as follows:
# shutdown –Fr__ Step 5.
Run the nim_update_all script to update the NIM
resources that were created by the nim_master_setup script, as follows:
# nim_update_all
Output similar to the following displays:
Installing AIX in a Partitioned Environment 4-25
############################## NIM update all
##############################
#
#
# During script execution, NIM client and resource updating times
#
# may vary. To view the install log at any time during nim_update_all,
#
# run the command: tail –f /var/adm/ras/nim.update in a separate screen.
#
#
#
###########################################################################
###
NSORDER=local,bind
Adding updates to lpp_res lpp_source....done
Updating spot_res using updated lpp_source lpp_res....done
Attempting to replace mksysb resource generic_sysb...
Removing old mksysb resource generic_sysb....done
Creating image.data file....done
Checking /export/nim space requirement...
Generating list of client objects in NIM environment...
Note:
The nim_update_all script will use the device /dev/cd0 by
default. The output from the nim_update_all script is shown in the
/var/adm/ras/nim.update log file.
__ Step 6.
A new generic system backup (mksysb) will be created and will replace
the existing generic mksysb, unless the –B flag is specified. All clients in
the environment will be updated, unless the –u flag is specified.
2. Manage Your Partition (Perform This Step in the AIX Environment)
When the installation has completed and the system has rebooted, the terminal window
displays a login prompt.
At this point, you may want to perform several common system–administration procedures.
The following table lists where to find information about performing these procedures.
Procedure
Location
Partition Backup and Storage
Management
System Backup, Dump, and Storage Management
on page 5-1
Remote System Management
Remote Management on page 6-1
User and Group Management
AIX 5L Version 5.3 System Management Guide:
Operating System and Devices
Software Installation
AIX 5L Version 5.3 Installation Guide and Reference
Performance Management
AIX 5L Version 5.3 Performance Management Guide
Printer Configuration
AIX 5L Version 5.3 Guide to Printers and Printing
4-26 AIX Installation in a Partitioned Environment
Chapter 5. System Backup, Dump, and Storage
Management
Most system backup, dump, and storage–management solutions depend on I/O devices.
On a partitioned system, I/O devices (such as tape or CD–ROM) are not always available to
all partitions. This chapter offers recommended solutions to minimize transfer of I/O devices
among partitions.
System Backup
A system backup is a copy of the root volume group (rootvg) of your system and is often
referred to as a mksysb, in reference to the command used to create the system backup.
The root volume group contains the following:
• Startup commands
• Base Operating System commands and files
• System configuration information
• Optional software products
All mounted JFS (Journaled File Systems) and JFS2 (Enhanced Journaled File Systems) in
the rootvg are backed up. Paging space and logical volume information is saved so that the
rootvg will be recreated as it was when the system backup is reinstalled. If there are JFS or
JFS2 file systems that are not to be backed up, you can use an exclude list or you can
unmount them before the backup is made.
The following table describes the methods you can use to back up a system.
Table 14. System Backup Methods
Backup Method
Considerations
NIM*
Allows fast backup and recovery of a partition. Because all images
are backed up to one system (NIM master), you should also back up
that system and images to other physical media (tape, CD–RW,
DVD–RAM).
mkcd command
Allows creation of a bootable system backup to CD–ROM or
DVD–RAM. You can provide an existing mksysb image from another
partition if the backup device is not available at the partition being
backed up.
The mkcd –r command allows backup (not bootable) of images and
files to a CD–RW or DVD–RAM.
mksysb
command with a
tape device
Creates a bootable backup only on the partition the drive is
connected to. Must boot from CD or tape to reinstall.
Remote tape drives are supported with Sysback (for more
information, see http://sysback.services.ibm.com).
* Recommended Method
For more information regarding system backups, refer to the AIX 5L Version 5.3 Installation
Guide and Reference. Other options offered during backup creation are excluding file or
directories, as well as creating map files so that the system is restored to exactly the same
physical partitions on the disk.
System Backup, Dump, and Storage Management
5-1
Creating a System Backup
You can create a system backup by using one of the following methods:
Using NIM
With the NIM environment, you can create a system backup that is a selectable resource.
That selectable resource can be used to reinstall the partition on which it was created, or it
can be cloned to another partition. Because of its flexibility, NIM is the recommended
method to back up and reinstall your partitions.
To use NIM to create a system backup, do the following:
1. If your partitions were installed with NIM, go to step 5.
2. On your NIM master, to determine whether your partition is already defined as a NIM
client, type:
# lsnim –t standalone
3. If the target partition is not already a NIM client, configure it by running the following on
the target partition:
# smitty niminit
4. On your NIM master, run the following to define the target partition (the partition to be
backed up) as a NIM client:
# smitty nim_mkmac
5. On your NIM master, type the following to open the Define a Resource menu:
# smitty nim_mkres
6. Select mksysb and type the appropriate information. This menu defines the mksysb
resource and also creates the system backup image.
Note: Be sure to change the CREATE system backup image? selection to yes.
Define a Resource
Type or select values in entry fields.
Press Enter AFTER making all desired changes.
* Resource Name
* Resource Type
* Server of Resource
* Location of Resource
[/export/nim/mksysb/P1_backup]
Comments
Source for Replication
–OR–
System Backup Image Creation Options:
CREATE system backup image?
NIM CLIENT to backup
PREVIEW only?
IGNORE space requirements?
EXPAND /tmp if needed?
Create MAP files?
Number of BLOCKS to write in a single output
(leave blank to use system default)
Use local EXCLUDE file?
(specify no to include all files in backup)
–OR–
EXCLUDE_FILES resource
(leave blank to include all files in backup)
5-2
AIX Installation in a Partitioned Environment
[Entry Fields]
[P1_backup]
mksysb
[master]
[]
[]
yes
[system1]
no
no
no
no
[]
no
[]
Using CD Media
If you have a CD–RW or DVD–RAM connected to one of your partitions, you can create
bootable system backups. You can use the mkcd command to create a bootable image on
or mount a mksysb image to another partition or system that has the device to create and
burn the bootable image. Therefore, the device can be assigned to only one partition when
creating backup CDs from multiple partitions. To reinstall the systems, you must assign a
CD device to the partition being reinstalled.
To create a backup to CD media, do the following:
1. Type:
# smitty mkcd
– You are asked whether you are using an existing mksysb image. If you want a
backup of this partition, answer No to this question.
– If you do use an existing mksysb image (possibly from another partition), answer
yes. You must enter the location (including the image name) of the existing mksysb.
2. If you want to save the bootable CD image to burn later, answer no to the Create the CD
or DVD now? selection.
To burn the CD or DVD at a later time (or to burn additional media), run the following:
# burn_cd /dev/cd1 /mkcd/cd_images/
cd_image_12510
The image name cd_image_12510 includes the process ID. The process ID displays when
the mkcd command executes.
For further information about creating system backups on CD or DVD, see the AIX 5L
Version 5.3 Installation Guide and Reference, as well as the
/usr/lpp/bos.sysmgt/mkcd.README.txt file.
Using Tape Media
If you have a tape drive assigned to your partition, you can create a system backup to tape.
To create a backup to tape, type the following:
smitty mksysb
If you want to back up to a file, you can use a separate file system (ensure that you exclude
that file system when you create the backup) or a file in a user volume group. For further
information about creating a root volume group backup to tape or file, see the AIX 5L
Version 5.3 Installation Guide and Reference.
Installing a System Backup Using NIM
You can use the NIM environment to install a system backup onto one or more of your
partitions. NIM is recommended because of its flexibility and customizing options for
installation and system management. Also, NIM allows for multiple installations at the same
time. When you install a system backup onto a partition other than the original partition, you
are cloning a partition system image onto a target partition.
Before you can use NIM to install a system backup, make sure that the following conditions
are met:
• Your network environment must be working correctly. The NIM master must be
configured correctly, and the lpp_source, SPOT, and mksysb resources must be defined.
Refer to either Use a Separate AIX System as a NIM Master to Use NIM to Install Each
Partition on page 4-8 or Configure an Initial Partition as a NIM Master to Use NIM to
Install the Remaining Partitions on page 4-2 for instructions on setting up NIM in a
partitioned environment.
• The target partitions might not contain the same hardware devices or adapters. If this is
the case, then the mksysb, SPOT, and lpp_source resources will be needed to install the
needed device support.
System Backup, Dump, and Storage Management
5-3
• Because NIM configures TCP/IP at the end of an installation, it is recommended that a
bosinst_data resource be allocated for cloning mksysb installations with the
RECOVER_DEVICES field set to no. This action prevents the BOS installation process
from attempting to configure the devices as they were on the source machine of the
mksysb.
1. To use a mksysb resource to install a NIM client, enter the smit nim_bosinst fast path.
2. Select a target for the operation.
Select a TARGET for the operation
Move cursor to desired item and press Enter.
lpar1
lpar2
lpar3
machines
machines
machines
standalone
standalone
standalone
3. Select mksysb as the installation TYPE.
4. Select the mksysb to use for the installation.
5. Select the SPOT to use for the installation.
6. The Install the Base Operating System on Standalone Clients panel looks similar to the
following:
Install the Base Operating System on Standalone Clients
Type or select values in entry fields.
Press Enter AFTER making all desired changes.
[TOP]
* Installation Target
* Installation TYPE
* SPOT
LPP_SOURCE
MKSYSB
BOSINST_DATA to use during installation
IMAGE_DATA to use during installation
RESOLV_CONF to use for network configuration
Customization SCRIPT to run after installation
Customization FB Script to run at first reboot
ACCEPT new license agreements?
Remain NIM client after install?
[MORE...35]
[Entry Fields]
lpar1
mksysb
520spot_res
[]
520mksysb
[]
[]
[]
[]
[]
[no]
[yes]
7. Select a bosinst_data resource to perform a non–prompted installation. Select the
bosinst_ow resource for a new and complete overwrite installation.
8. Select a resolv_conf resource to establish network configuration for the client partition.
9. Set the Accept new License Agreements field to yes.
The Install the Base Operating System on Standalone Clients menu looks similar to the
following:
5-4
AIX Installation in a Partitioned Environment
+
+
+
+
+
+
+
Install the Base Operating System on Standalone Clients
Type or select values in entry fields.
Press Enter AFTER making all desired changes.
[TOP]
* Installation Target
[Entry Fields]
lpar1
* Installation TYPE
mksysb
* SPOT
520spot_res
LPP_SOURCE
MKSYSB
[]
520mksysb
BOSINST_DATA to use during installation
+
IMAGE_DATA to use during installation
RESOLV_CONF to use for network configuration
+
Customization SCRIPT to run after installation
Customization FB Script to run at first reboot
ACCEPT new license agreements?
+
Remain NIM client after install?
PRESERVE NIM definitions for resources on
this target?
[
bosinst_ow
]
[]
[
resolv_res
]
[]
[]
[
+
+
+
yes
]
[yes]
[yes]
+
+
FORCE PUSH the installation?
[no]
+
Initiate reboot and installation now?
–OR–
Set bootlist for installation at the
next reboot?
[yes]
+
[no]
+
[]
+
[]
+
Additional BUNDLES to install
–OR–
Additional FILESETS to install
(bundles will be ignored)
[MORE...20]
10.Press Enter to install the NIM client.
11. If the client partition being installed is not already a running, configured NIM client, NIM
will not automatically reboot the machine over the network for installation. If the client
was not rebooted automatically from SMIT, initiate a network boot from the client to
install it. For instructions on how to do this procedure, refer to 2. Activate and Install
Partitions (Perform These Steps in the HMC Interface) on page 4-12.
System Dump Management
If your machine has more than 4 GB of real memory, a dedicated dump device is created at
installation time. Otherwise, the /dev/hd6 paging space is used as the dump device. If a
system crash occurs and paging space was used as the dump device, the dump is copied
to the /var/adm/ras/vmcore. n file by default, where n is a sequence number. If there is not
enough space to perform the copy, the user is prompted during reboot to save the dump to
some other media.
To avoid losing a dump due to a lack of a tape drive configured to the partition, always
create a separate dump device that is the same size as your paging space, given that
paging space is currently your dump device.
To verify your dump device, type smitty dump, and select Show Current Dump Devices.
If paging space is your dump device, the output will be similar to the following:
System Backup, Dump, and Storage Management
5-5
COMMAND STATUS
Command: OK
stdout: yes
stderr: no
Before command completion, additional instructions may appear below.
primary
secondary
copy directory
forced copy flag
always allow dump
dump compression
/dev/hd6
/dev/sysdumpnull
/var/adm/ras
TRUE
FALSE
OFF
To create and change to a dedicated dump device, do the following:
1. Determine the size of the hd6 paging space (in logical partitions) by running the
following:
# lsvg –l rootvg
The output will be similar to the following:
rootvg:
LV NAME
hd5
hd6
hd8
hd4
hd2
hd9var
hd3
hd1
hd10opt
TYPE
boot
paging
jfslog
jfs
jfs
jfs
jfs
jfs
jfs
LPs
2
53
1
9
130
2
8
1
5
PPs
2
53
1
9
130
2
8
1
5
PVs
1
1
1
1
1
1
1
1
1
LV STATE
closed/syncd
open/syncd
open/syncd
open/syncd
open/syncd
open/syncd
open/syncd
open/syncd
open/syncd
MOUNT POINT
N/A
N/A
N/A
/
/usr
/var
/tmp
/home
/opt
In the preceding example, the paging space is 53 LPs (logical partitions) in size.
2. To create a dump logical volume, type:
smitty mklv
When you are prompted for the volume group, type rootvg.
3. In the next menu, fill in the Logical volume NAME and the Number of LOGICAL
PARTITIONS fields. Type dump for Logical Volume TYPE. Press Enter after you make
your selections.
5-6
AIX Installation in a Partitioned Environment
Add a Logical Volume
Type or select values in entry fields.
Press Enter AFTER making all desired changes.
Logical volume NAME
* VOLUME GROUP name
* Number of LOGICAL PARTITIONS
#
PHYSICAL VOLUME names
+
Logical volume TYPE
POSITION on physical volume
+
RANGE of physical volumes
+
MAXIMUM NUMBER of PHYSICAL VOLUMES
#
to use for allocation
Number of COPIES of each logical
+
partition
Mirror Write Consistency?
+
Allocate each logical partition copy
+
on a SEPARATE physical volume?
RELOCATE the logical volume during
+
reorganization?
Logical volume LABEL
MAXIMUM NUMBER of LOGICAL PARTITIONS
#
Enable BAD BLOCK relocation?
+
SCHEDULING POLICY for reading/writing
+
logical partition copies
Enable WRITE VERIFY?
+
File containing ALLOCATION MAP
Stripe Size?
+
[Entry Fields]
[dumplv]
rootvg
[53]
[hdisk0]
[dump]
middle
minimum
[]
1
active
yes
yes
[]
[512]
yes
parallel
no
[]
[Not Striped]
4. To change the primary dump device, type:
smitty dumpchgp
You will be prompted for the new dump device.
Change Primary Dump Device
Type or select values in entry fields.
Press Enter AFTER making all desired changes.
[Entry Fields]
[/dev/dumplv]
* Primary dump device
5. To validate your dump devices, type the following:
smitty dump
Select Show Current Dump Devices. The output will be similar to the following:
System Backup, Dump, and Storage Management
5-7
COMMAND STATUS
Command: OK
stdout: yes
stderr: no
Before command completion, additional instructions may appear below.
primary
secondary
copy directory
forced copy flag
always allow dump
dump compression
/dev/dumplv
/dev/sysdumpnull
/var/adm/ras
TRUE
FALSE
OFF
Storage Management
If you have multiple mksysb images stored on a NIM master (or on some other partition),
you can use the mkcd –r command to store them to CD–R or DVD–RAM. The images to be
written to CD–R or DVD–RAM must be in one directory structure, so that a directory can be
passed to the mkcd command as the starting point of the backup.
Use the mkcd command as follows:
mkcd {–d
[–D] [–L]
cd_device
} [–r
directory
] [–R | –S] [–I
cd_image_dir
]
Where:
–d
Specifies the CD–R or DVD–RAM device
–S
Indicates to stop the backup before burning the image (image can be
burned at a later time)
–r
Specifies the directory from which to create your CD image
–l
Specifies the directory in which to write the CD image
–R
Saves the CD images (use this flag if you want to burn multiple copies)
–D
Enables debugging for the mkcd command
–L
Creates final CD images that are DVD–sized (up to 4.38 GB)
For example, to back up the stored mksysb images in the /export/nim/mksysbs directory
to a DVD–RAM device (/dev/cd1), and use a temporary file system mounted on the
/largefilesystem directory to use as temporary CD image storage, type the following:
# mkcd –d /dev/cd1 –r /export/nim/mksysbs –I /largefilesystem –L
To verify the mksysb, run the following commands:
# mount –o ro /dev/cd0/mnt
# cd /mnt
# ls
5-8
AIX Installation in a Partitioned Environment
Chapter 6. Remote Management
This chapter discusses how you can use the Hardware Management Console (HMC) to
manage your system remotely. For information about how you can remotely manage
partitions through the command line on the HMC, see the Hardware Management Console
Installation and Operations Guide.
Each of the following system–management methods can be performed using the HMC
interface or from the command line.
• Use the HMC client to remotely manage any AIX partition or system. All AIX plug–ins on
the AIX system can be managed remotely from the HMC client, provided that the
Web–based System Manager framework version is compatible. The operating system
checks each plug–in for compatibility with the Web–based System Manager framework.
If it is not compatible for that plug–in, a message displays, indicating that the plug–in
cannot be managed by the client.
• Use an AIX partition or system to remotely manage an HMC. All HMC plug–ins on the
HMC server may be managed remotely from the AIX system, provided that the AIX
system is at a compatible Web–based System Manager framework version. Otherwise,
an error message displays indicating that the AIX system cannot manage the HMC
server.
• Use Web–based System Manager Remote Client to remotely manage an HMC server.
For instructions on how to install the Remote Client, refer to the AIX 5L Version 5.3
Web–based System Manager Administration Guide. All HMC plug–ins on the HMC
server may be managed remotely from the Remote Client, provided that the Remote
Client is at a compatible Web–based System Manager framework version. Otherwise, an
error message displays, indicating that the Remote Client cannot manage the HMC
server. The only plug–in that is an exception is the Service Agent plug–in.
• Use an HMC client remotely manage another HMC client. All HMC plug–ins on the HMC
server may be managed remotely from the HMC client. The only plug–in that is an
exception is the Service Agent plug–in.
Note: When remotely managing the HMC, the command–line tasks you can perform are
limited to configuration tasks.
For more information on remote management, see either of the following readme files:
• /usr/websm/readme.html
• /usr/websm/readme.txt
Remote Management
6-1
Remote Management From the HMC to AIX Partitions
After the partition is configured on the network, you can add the partition as a host in the
HMC interface, as follows:
1. Select Console –> Add –> Hosts.
Figure 6. Adding a host using the console menu. This illustration shows how to
navigate from the console menu to the hosts selection. To add the partition as a host in
the HMC interface, select Console from the menu bar, then select Add, and then select
Hosts.
2. Type the host name of the partition to add. The host will be added to the list.
After the partition is configured on the network, you can open an xterm window to connect to
the partition within the HMC interface by selecting Console –> Open Terminal. Enter either
the host name or the IP address of the system.
6-2 AIX Installation in a Partitioned Environment
Figure 7. Opening an xterm window. This illustration shows how to open an xterm window
to connect to a partition. To open an xterm window in the HMC interface, select Console
from the menu bar, and then select Open Terminal. Enter the host name or IP address of
the system.
Remote Management
6-3
6-4 AIX Installation in a Partitioned Environment
Chapter 7. Hints and Tips
This chapter provides hints and tips to help you when working with AIX in a partitioned
environment.
Naming Your Operating System Host Name
Each partition, including the Full System Partition, must have a unique host name that can
be resolved. Host names cannot be reused between the Full System Partition and the
logical partitions.
If the host name of the partition must be changed, before changing the host name of the
partition, do the following:
1. If your system’s level of AIX is earlier than the 5100–02 maintenance package level,
skip this step and go to step 2.
/usr/sbin/rsct/bin/runact –c IBM.ManagementServer SetRTASPollingInterval
Seconds=0
2. Run the following command:
/usr/sbin/rsct/bin/lsrsrc IBM.ManagementServer Hostname
If the partition is managed by multiple HMCs, multiple entries might exist, because each
HMC has its own entry. The output will be similar to the following:
resource 1:
Hostname=”hmc1.mydomain.mycompany.com”
3. For each entry, remove the resource using the host name shown. For example, run the
following command:
/usr/sbin/rsct/bin/rmrsrc –s ’Hostname=”hmc1.mydomain.mycompany.com”’
IBM.ManagementServer
You can verify that all entries have been removed by running Step 2 again.
4. Run the following command:
/usr/sbin/rsct/bin/rmcctrl –z
5. Change the host name of the partition.
6. After the host name has been changed, run the following command:
/usr/sbin/rsct/bin/rmcctrl –A
For information on updating the partition information on the HMC, see the Hardware
Management Console Installation and Operations Guide.
Hints and Tips
7-1
Network Adapter Communication Between Partitions and the
HMC
After a partition has been started, it uses the network adapter to communicate with the
HMC. Both the HMC and the partition must be configured so they can use the network
adapters to communicate with each other. The partition must be configured to identify the
HMC (or HMCs) on the network. It is recommended that the network be configured using a
Domain Name Service (DNS) server.
You can use either fully qualified host names or short host names to identify partitions and
HMCs. However, it is recommended that each partition and HMC be identified using a fully
qualified host name, as this identification ensures unique naming of all the partitions and the
HMC in the network. Fully qualified host names cannot be more than 100 bytes in length.
The HMC and partitions can also be configured using a short host name, where the domain
name is not defined. This is typically done in a private or test network. If the HMC is defined
using a short host name, you must perform extra network configuration steps to ensure
correct communications between the partitions and the HMC. If you use short host names
rather than fully qualified host names, make sure that the short host names are unique and
that the mappings to IP addresses are properly specified.
The search order between the local /etc/hosts file and the DNS can be specified using the
/etc/netsvc.conf file or /etc/irs.conf file.
The following examples illustrate the scenarios supported:
• If you are using DNS and your partition and the HMC are using fully qualified host
names, then no additional network configuration is required.
• If you are using DNS and your partition is using a short host name, such as
partition_1 and the HMC is also using a short host name, such as hmc123, both
must be added to the local /etc/hosts file, as shown in the following:
[email protected]_1
–> cat /etc/hosts
127.0.0.1
loopback localhost
9.3.3.151
9.3.3.152
partition_1.mydomain.mycompany.com partition_1
hmc123.mydomain.mycompany.com hmc123
Note: You must include the fully qualified host name in addition to the short name when a
DNS is present.
• If you are not using DNS and your partition is using a fully qualified host name, such as
partition_1.mydomain.mycompany.com, and the HMC is also using a fully
qualified host name, such as hmc123.mydomain.mycompany.com, both must be
added to the local /etc/hosts file, as shown in the following:
[email protected]_1.mydomain.mycompany.com
–> cat /etc/hosts
127.0.0.1
loopback localhost
9.3.3.151
9.3.3.152
partition_1.mydomain.mycompany.com
hmc123.mydomain.mycompany.com
• If you are not using DNS and your partition is using a short host name, such as
partition_1 and the HMC is also using a short host name, such as hmc123, both
must be be added to the local /etc/hosts file, as shown in the following:
7-2 AIX Installation in a Partitioned Environment
[email protected]_1
–> cat /etc/hosts
127.0.0.1
loopback localhost
9.3.3.151
9.3.3.152
partition_1
hmc123
• Your HMC is using a short host name, such as hmc123, and you would like to use both a
fully qualified host name and a short host name for the HMC. In order for your partition to
correctly communicate with the HMC, you must specify the short host name before the
fully qualified host name in the partition’s /etc/hosts file, as shown in the following:
[email protected]_1.mydomain.mycompany.com
–> cat /etc/hosts
127.0.0.1
loopback localhost
9.3.3.151
9.3.3.152
partition_1.mydomain.mycompany.com
hmc123 hmc123.mydomain.mycompany.com
Shutting Down a Partition
This section provides information about how to shut down a partition by using the HMC and
by using AIX.
Using AIX to Shut Down a Partition
When a partition is up, it is in the Running state. To use AIX to shut down a partition, do the
following:
1. To restart AIX, on the AIX command prompt, type shutdown –Fr.
The partition eventually changes to the Starting state, and the operator panel values
display, which indicates AIX is now rebooting.
2. When the reboot is issued within AIX, the partition will boot according to the contents of
the bootlist. To check the order of the boot devices, type bootlist –m normal –o
3. To shut down AIX, on the AIX command prompt, type shutdown –F.
The partition will eventually change to the Ready state. You have now shut down AIX and its
partition.
To start AIX, on the HMC, select Activate. When you select Activate, the HMC uses the
boot mode selection in the partition profile.
Using the HMC Interface to Shut Down a Partition
To use the HMC to shut down a partition, do the following:
1. Select the partition you want to shut down.
2. Right–click on the partition to open the menu.
3. Select Operating System Reset.
4. Select Hard Reset. This action sends a halt signal indicating which instance of AIX is to
be shut down. If a vterm window was open while the hard reset was done, the vterm
window remains open. The partition will then be in the Ready state.
To activate the partition, select the partition and press the right mouse button. Select
Activate. When you select Activate, the HMC uses the boot mode selection in the partition
profile.
Closing a vterm window does not shut down a partition. However, closing the window logs
you off that session and kills any processes that you are running from that vterm window.
Hints and Tips
7-3
7-4 AIX Installation in a Partitioned Environment
Index
A
about this book, iii
affinity logical partitions
Hardware Management Console (HMC), 2-2
overview, 2-2
AIX, shutting down, 7-3
alternate disk installation, 3-5
considerations, 5-1
installing using NIM, 5-3
system, 5-1
to CD, 5-3
to tape, 5-3
using NIM, 5-2
C
communication between HMC and Partitions, 7-2
configuring online documentation, 1-6
consolidation of multiple versions of the same
operating system, 2-4
creating a system backup, 5-2
D
migrating a system to the AIX 5.2
partition–ready state, 4-22
overview, 3-1
procedures, 4-1, 4-14, 4-19
using a separate AIX system as a NIM master,
4-8
using the CD to manually install a logical
partition, 4-14, 4-19
ISO 9000, iii
L
logical partition
consolidation of multiple versions of the same
operating system, 2-4
minimum resources, 2-1
mixed production and test environments, 2-4
overview, 2-1
roadmap, 2-3
scenarios, 3-1
server consolidation, 2-4
when to implement, 2-4
working with, 2-2
LPP_Source directory, 3-2
documentation, online
configuring, 1-6
viewing from the CD, 1-6
documentation overview, documentation web site,
1-3
dumps, system
logical volume, 5-5
managing, 5-5
M
G
naming your OS host, 7-1
Network Adapter Communication Between
Partitions and the HMC, 7-2
Network Installation Management, introduction, 3-2
NIM, see Network Installation Management, 3-2
NIM resources
bosinst_data, 3-2
LPP_Source, 3-2
mksysb, 3-2
resolv_conf, 3-2
resource group, 3-2
SPOT, 3-2
Getting Started, 1-1
affinity logical partitions, 2-2
communicating with partitions, 7-2
managing AIX partitions, 6-2
managing remotely with AIX partition, 6-1
managing remotely with client, 2-1, 6-1
managing with an HMC client, 6-1
Network Adapter Communication, 7-2
partitioning with, 2-1
shutting down a partition, 7-3
working with logical partitions, 2-2
H
highlighting used, iii
host name, naming, 7-1
I
installation scenarios, 3-4
installing a system backup, using NIM, 5-3
installing AIX
configuring an initial LPAR as a NIM master,
4-2
considerations, 4-1, 4-14, 4-19
in a partitioned environment, 4-1, 4-14, 4-19
materials list, 1-2
mkcd, 5-3
mkcd command, 5-1
mksysb command, 5-1
N
O
online documentation, 1-3
overview, documentation, 1-3
overview of AIX installation process, 3-1
overview of partitions
Adding Your Managed System to an <F0>, 3-5
affinity, 2-2
affinity logical partitions, 2-2
dynamic logical partitioning, 2-2
First AIX System in Your Environment, 3-4
full system, 2-3
full system partition, 2-3
Index
X-1
Installing a Partition Using Alternate Disk
Installation, 3-5
logical, 2-1
logical partitions, 2-1
managed system, 2-1
Migrating to AIX 5.1 and Configuring Partition
Support, 3-4
roadmap, 2-3
when to implement, 2-4
working with, 2-2
P
publications
online, 4-14
related, 1-3, 4-14
R
readme
mkcd, 5-3
Web–based System Manager, 6-1
related publications, iv
remote management, 6-1
from the Hardware Management Console
(HMC), 6-2
X-2
AIX Installation in a Partitioned Environment
to AIX partitions, 6-2
Roadmap, Partition, 1-1
S
scenarios, logical partition, 3-1
security, Controlled Access Protection Profile and
Evaluation Assurance Level 4+, 2-4
shutting down a logical partition, 7-3
shutting down a partition
using AIX, 7-3
using the HMC, 7-3
SP environment, 3-5
storage management, 5-8
Sysback, 5-1
system backup, 5-1
system backup, dump and storage management,
5-1
system dump management, 5-5
system, managed, 2-1
U
updating NIM, updating an existing NIM
environment, 4-25
Technical publication remarks form
Title :
ESCALA AIX 5L AIX Installation in a Partitioned Environment
Reference Nº :
86 A2 90EM 00
Date:
August 2004
ERRORS IN PUBLICATION
SUGGESTIONS FOR IMPROVEMENT TO PUBLICATION
