Zebra MC75 Owner's manual

Zebra MC75 Owner's manual
MC75 Enterprise Digital Assistant
Integrator Guide
MC75 Enterprise Digital Assistant
Integrator Guide
72E-103078-04
Rev. A
April 2015
ii
MC75 Integrator Guide
© 2015 ZIH Corp
No part of this publication may be reproduced or used in any form, or by any electrical or mechanical means,
without permission in writing from Zebra. This includes electronic or mechanical means, such as photocopying,
recording, or information storage and retrieval systems. The material in this manual is subject to change
without notice.
The software is provided strictly on an “as is” basis. All software, including firmware, furnished to the user is on
a licensed basis. Zebra grants to the user a non-transferable and non-exclusive license to use each software
or firmware program delivered hereunder (licensed program). Except as noted below, such license may not be
assigned, sublicensed, or otherwise transferred by the user without prior written consent of Zebra. No right to
copy a licensed program in whole or in part is granted, except as permitted under copyright law. The user shall
not modify, merge, or incorporate any form or portion of a licensed program with other program material, create
a derivative work from a licensed program, or use a licensed program in a network without written permission
from Zebra. The user agrees to maintain Zebra’s copyright notice on the licensed programs delivered
hereunder, and to include the same on any authorized copies it makes, in whole or in part. The user agrees not
to decompile, disassemble, decode, or reverse engineer any licensed program delivered to the user or any
portion thereof.
Zebra reserves the right to make changes to any software or product to improve reliability, function, or design.
Zebra does not assume any product liability arising out of, or in connection with, the application or use of any
product, circuit, or application described herein.
No license is granted, either expressly or by implication, estoppel, or otherwise under any Zebra, intellectual
property rights. An implied license only exists for equipment, circuits, and subsystems contained in Zebra
products.
Revision History
Changes to the original manual are listed below:
Change
Date
Description
-01 Rev. A
06/13/08
Initial Release.
-02 Rev. A
12/15/08
Add re-boot after installing SIM card. Correct MC75 COM Port Definitions.
-03 Rev. A
02/15/10
Add support for OEM versions 02.35.000 and 02.35.001. Correct cold boot process.
Add DCR7X00-200R accessory.
-04 Rev. A
04/02/15
Zebra rebranding.
iii
iv
MC75 Integrator Guide
Table of Contents
Revision History.................................................................................................................................... iii
About This Guide
Introduction ...........................................................................................................................................
Documentation Set ...............................................................................................................................
Configurations.......................................................................................................................................
Software Versions
Chapter Descriptions ............................................................................................................................
Notational Conventions.........................................................................................................................
Related Documents and Software ........................................................................................................
Service Information...............................................................................................................................
xiii
xiii
xiv
xiv
xvii
xvii
xviii
xviii
Chapter 1: Getting Started
Introduction ..........................................................................................................................................
Unpacking the MC75 ...........................................................................................................................
Accessories .........................................................................................................................................
Getting Started .....................................................................................................................................
Installing the SIM Card ...................................................................................................................
Installing the Main Battery ..............................................................................................................
Charging the Battery ......................................................................................................................
Charging the Main Battery and Memory Backup Battery .........................................................
Charging Spare Batteries .........................................................................................................
Charging Temperature .............................................................................................................
Powering On the MC75 ..................................................................................................................
Calibrating the Screen ...................................................................................................................
Checking Battery Status ................................................................................................................
Resetting the MC75 .............................................................................................................................
Performing a Warm Boot ...............................................................................................................
Performing a Cold Boot ..................................................................................................................
Performing a Clean Boot ................................................................................................................
Waking the MC75 ................................................................................................................................
Locking the MC75 ................................................................................................................................
1-1
1-1
1-2
1-3
1-4
1-5
1-6
1-6
1-7
1-7
1-8
1-8
1-8
1-8
1-8
1-8
1-9
1-9
1-10
viii
MC75 Integrator Guide
Micro Secure Digital (microSD) Card ................................................................................................... 1-10
Removing the Screen Protector ........................................................................................................... 1-11
Replacing the Main Battery .................................................................................................................. 1-12
Chapter 2: Accessories
Introduction ..........................................................................................................................................
Single Slot USB/Serial Cradle .............................................................................................................
Setup ..............................................................................................................................................
Charging the MC75 Battery ...........................................................................................................
Charging the Spare Battery ...........................................................................................................
Battery Charging Indicators ...........................................................................................................
Charging Temperature .............................................................................................................
Four Slot Ethernet Cradle ....................................................................................................................
Setup ..............................................................................................................................................
Daisychaining Ethernet Cradles .....................................................................................................
Bandwidth Considerations when Daisychaining ......................................................................
Ethernet Cradle Drivers .................................................................................................................
Charging and Communication .......................................................................................................
LED Charging Indicators ................................................................................................................
Charge LED .............................................................................................................................
Speed LED ...............................................................................................................................
Link LED ..................................................................................................................................
Charging Temperature .............................................................................................................
Four Slot Charge Only Cradle .............................................................................................................
Setup ..............................................................................................................................................
Charging Temperature .............................................................................................................
Wall Mount Bracket ..............................................................................................................................
VCD7X00 Vehicle Cradle ....................................................................................................................
Requirements .................................................................................................................................
Connector Ports .............................................................................................................................
Connector Pin-Outs .................................................................................................................
Mounting the Cradle .......................................................................................................................
Power Connection ..........................................................................................................................
Serial Device Connection ...............................................................................................................
Charging the MC75 Battery ...........................................................................................................
Removing the MC75 ................................................................................................................
Charging the Spare Battery ...........................................................................................................
Battery Charging Indicators ...........................................................................................................
Charging Temperature .............................................................................................................
Four Slot Battery Charger ....................................................................................................................
Battery Shim Installation ................................................................................................................
Spare Battery Charging .................................................................................................................
Battery Charging Indicators ...........................................................................................................
Charging Temperature .............................................................................................................
Magnetic Stripe Reader (MSR) ............................................................................................................
Attaching and Removing the MSR .................................................................................................
Using the MSR ...............................................................................................................................
Debit Card Reader ...............................................................................................................................
Getting Started ...............................................................................................................................
2-1
2-2
2-2
2-2
2-3
2-3
2-4
2-5
2-5
2-5
2-6
2-6
2-8
2-9
2-9
2-9
2-9
2-9
2-10
2-10
2-10
2-11
2-13
2-13
2-13
2-14
2-14
2-15
2-17
2-17
2-18
2-18
2-19
2-20
2-21
2-21
2-21
2-22
2-22
2-23
2-23
2-23
2-25
2-25
Table of Contents
Installation ......................................................................................................................................
Removal ...............................................................................................................................................
Credit Card Transactions ...............................................................................................................
Debit Card Transactions ................................................................................................................
Keypad ...........................................................................................................................................
Display Messages ....................................................................................................................
Check the DCR Battery Level ........................................................................................................
Charging the MC75 ..............................................................................................................................
Key Injection ..................................................................................................................................
Maintenance ..................................................................................................................................
Snap-on Mobile Payment Module with Chip and PIN ..........................................................................
Installation ......................................................................................................................................
Removal ...............................................................................................................................................
Credit Card Transactions ...............................................................................................................
Debit Card Transactions ................................................................................................................
Chip and PIN Transactions ............................................................................................................
Keypad .....................................................................................................................................
Display Messages ..........................................................................................................................
Headset ...............................................................................................................................................
Cables ..................................................................................................................................................
Setup ..............................................................................................................................................
Battery Charging ............................................................................................................................
LED Charge Indications .................................................................................................................
Charging Temperature .............................................................................................................
Communication Setup ....................................................................................................................
ix
2-25
2-25
2-26
2-26
2-27
2-28
2-28
2-29
2-29
2-29
2-30
2-30
2-30
2-31
2-31
2-32
2-32
2-33
2-34
2-36
2-36
2-37
2-37
2-37
2-37
Chapter 3: ActiveSync
Introduction ..........................................................................................................................................
Installing ActiveSync ............................................................................................................................
Mobile Computer Setup .......................................................................................................................
USB Configuration ...............................................................................................................................
Setting Up an ActiveSync Connection on the Host Computer .............................................................
Synchronization with a Windows Mobile 6 Device .........................................................................
3-1
3-1
3-2
3-2
3-3
3-4
Chapter 4: Application Deployment for Mobile 6
Introduction ..........................................................................................................................................
Security ................................................................................................................................................
Application Security .......................................................................................................................
Digital Signatures ...........................................................................................................................
Locking Down a Mobile Computer ...........................................................................................
Installing Certificates ................................................................................................................
Device Management Security ........................................................................................................
Remote API Security ......................................................................................................................
Packaging ............................................................................................................................................
Deployment ..........................................................................................................................................
Installation Using ActiveSync .........................................................................................................
Installation Using Storage Card .....................................................................................................
Installation Using AirBEAM ............................................................................................................
4-1
4-1
4-1
4-1
4-2
4-3
4-3
4-3
4-4
4-4
4-4
4-4
4-5
x
MC75 Integrator Guide
MSP 3.X .........................................................................................................................................
Image Update ................................................................................................................................
Creating a Splash Screen ..............................................................................................................
XML Provisioning .................................................................................................................................
Creating an XML Provisioning File .................................................................................................
XML Provisioning vs. RegMerge and Copy File ............................................................................
RegMerge ................................................................................................................................
CopyFiles .................................................................................................................................
Storage ................................................................................................................................................
Random Access Memory ...............................................................................................................
Volatile File Storage (Cache Disk) ...........................................................................................
Persistent Storage .........................................................................................................................
Application Folder ..........................................................................................................................
Symbol Configuration Manager ...........................................................................................................
File Types ......................................................................................................................................
User Interface ................................................................................................................................
Menu Functions .......................................................................................................................
Parameter State Indicators ......................................................................................................
Window Status Bar ..................................................................................................................
File Deployment .............................................................................................................................
Enterprise Mobility Developer Kits .......................................................................................................
4-5
4-5
4-6
4-6
4-7
4-7
4-7
4-8
4-8
4-9
4-9
4-9
4-9
4-9
4-10
4-10
4-10
4-11
4-11
4-12
4-12
Chapter 5: MC7506/96 - GSM Configuration
Introduction ..........................................................................................................................................
Quick Startup Steps .............................................................................................................................
MC7506/96 Service Verification ..........................................................................................................
Ensuring Network Coverage ..........................................................................................................
Configuring a Data Connection ......................................................................................................
Establishing a Data Connection .....................................................................................................
Ending a Data Connection .............................................................................................................
MC7506/96 Settings ............................................................................................................................
Phone .............................................................................................................................................
Sounds .....................................................................................................................................
Security ....................................................................................................................................
Services .........................................................................................................................................
Call Barring (Call Blocking) ......................................................................................................
Caller ID ...................................................................................................................................
Call Forwarding ........................................................................................................................
Call Waiting ..............................................................................................................................
Voice Mail and Text Messages ................................................................................................
Fixed Dialing ............................................................................................................................
Network ..........................................................................................................................................
Changing Networks Manually ..................................................................................................
Viewing Available Networks .....................................................................................................
Setting Preferred Networks ......................................................................................................
Phone Info ......................................................................................................................................
Network Time Synchronization ............................................................................................................
Enhanced Operator Name String ........................................................................................................
Service Provider Name Display ...........................................................................................................
5-1
5-1
5-3
5-3
5-4
5-5
5-7
5-8
5-8
5-8
5-9
5-10
5-10
5-11
5-11
5-12
5-12
5-13
5-13
5-14
5-14
5-15
5-16
5-17
5-17
5-17
Table of Contents
Chapter 6: MC7508/98 - CDMA Configuration
Introduction ..........................................................................................................................................
Quick Startup Steps .............................................................................................................................
CDMA Phone Activation ......................................................................................................................
Verizon Wireless Activation ...........................................................................................................
Sprint Activation .............................................................................................................................
Manual Activation ...........................................................................................................................
Activation Test ...............................................................................................................................
Establishing a Data Connection ...........................................................................................................
CDMA Settings ....................................................................................................................................
Phone .............................................................................................................................................
Location Settings ...........................................................................................................................
Data Settings .................................................................................................................................
Sprint Data Settings .................................................................................................................
Verizon Wireless Data Settings ...............................................................................................
Additional Service provider Data Settings ................................................................................
System Settings .............................................................................................................................
Sprint System ...........................................................................................................................
Verizon System ........................................................................................................................
Additional Service Provider System .........................................................................................
Version Information ........................................................................................................................
Services .........................................................................................................................................
Call Barring (Call Blocking) ......................................................................................................
Caller ID ...................................................................................................................................
Call Forwarding ........................................................................................................................
Call Waiting ..............................................................................................................................
Voice Mail and Short Message Service (SMS) ........................................................................
Network Time Synchronization ............................................................................................................
xi
6-1
6-1
6-2
6-2
6-3
6-3
6-5
6-6
6-7
6-7
6-8
6-8
6-8
6-10
6-10
6-11
6-11
6-12
6-13
6-13
6-14
6-14
6-14
6-14
6-15
6-15
6-15
Chapter 7: Wireless Applications
Introduction .......................................................................................................................................... 7-1
Signal Strength Icon ............................................................................................................................ 7-2
Turning the WLAN Radio On and Off .................................................................................................. 7-3
Chapter 8: Maintenance and Troubleshooting
Introduction ..........................................................................................................................................
Maintaining the MC75 ..........................................................................................................................
Battery Safety Guidelines ....................................................................................................................
Cleaning ...............................................................................................................................................
Materials Required .........................................................................................................................
Cleaning the MC75 ........................................................................................................................
Housing ....................................................................................................................................
Display .....................................................................................................................................
Scanner Exit Window ...............................................................................................................
Connector ................................................................................................................................
Cleaning Cradle Connectors ..........................................................................................................
Cleaning Frequency .......................................................................................................................
Troubleshooting ...................................................................................................................................
8-1
8-1
8-2
8-3
8-3
8-3
8-3
8-3
8-3
8-3
8-4
8-4
8-5
xii
MC75 Integrator Guide
MC75 .............................................................................................................................................
Bluetooth Connection .....................................................................................................................
Single Slot USB/Serial Cradle ........................................................................................................
Four Slot Ethernet Cradle ..............................................................................................................
Vehicle Cradle ................................................................................................................................
Four Slot Spare Battery Charger ...................................................................................................
Cables ............................................................................................................................................
Magnetic Stripe Reader .................................................................................................................
Appendix A: Technical Specifications
Technical Specifications ......................................................................................................................
MC75 ...................................................................................................................................................
MC75 COM Port Definitions ...........................................................................................................
MC75 Pin-Outs ..............................................................................................................................
MC75 Accessory Specifications ..........................................................................................................
Single Slot USB/Serial Cradle ........................................................................................................
Four Slot Ethernet Cradle ..............................................................................................................
Four Slot Charge Only Cradle ........................................................................................................
Four Slot Battery Charger ..............................................................................................................
Magnetic Stripe Reader .................................................................................................................
Vehicle Cradle ................................................................................................................................
Appendix B: Bluetooth Configuration
Glossary
Index
8-5
8-7
8-8
8-9
8-9
8-10
8-10
8-11
A-1
A-1
A-4
A-5
A-6
A-6
A-6
A-7
A-7
A-8
A-9
About This Guide
Introduction
This Integrator Guide provides information about setting up and configuring MC75 and accessories.
NOTE
Screens and windows pictured in this guide are samples and can differ from actual screens.
Documentation Set
The documentation for the MC75 is divided into guides that provide information for specific user needs.
• MC75 Quick Start Guide - describes how to get the MC75 up and running.
• MC75 User Guide - describes how to use the MC75.
• MC75 Integrator Guide - describes how to set up the MC75 and accessories.
• Windows Mobile® 6 Applications User Guide - describes how to use Microsoft developed applications.
• Application Guide - describes how to use Zebra developed sample applications.
• Enterprise Mobility Developer Kit (EMDK) Help File - provides API information for writing applications.
xiv
MC75 Integrator Guide
Configurations
This guide covers the following configurations:
Configuration
Radios
Display
Memory
Data Capture
Operating
System
Keypads
MC7506
WPAN: Bluetooth 3.5” VGA
WWAN: HSDPA Color
GPS
128 MB RAM/
256 MB Flash
1D laser
scanner, 2D
imager
Windows
Mobile 6.1
Professional
Numeric,
AZERTY,
QWERTY or
QWERTZ
MC7508
WPAN: Bluetooth 3.5” VGA
WWAN: EVDO
Color
GPS
128 MB RAM/
256 MB Flash
1D laser
scanner, 2D
imager
Windows
Mobile 6.1
Professional
Numeric,
AZERYTY,
QWERTY or
QWERTZ
MC7596
WLAN:
802.11a/b/g
WPAN: Bluetooth
WWAN: HSDPA
GPS
3.5” VGA
Color
128 MB RAM/
256 MB Flash
1D laser
scanner, 2D
imager 1D laser
scanner with
2MP camera, 2D
imager with 2MP
camera
Windows
Mobile 6.1
Professional
Numeric,
DSD,
AZERYTY,
QWERTY or
QWERTZ
WLAN:
802.11a/b/g
WPAN: Bluetooth
WWAN: EVDO
GPS
3.5” VGA
Color
1D laser
scanner, 2D
imager,1D laser
scanner with
2MP camera, 2D
imager with 2MP
camera
Windows
Mobile 6.1
Professional
Numeric,
AZERYTY,
QWERTY or
QWERTZ
MC7598
or 128 MB
RAM/512 MB
Flash
128 MB RAM/
256 MB Flash
or 128 MB
RAM/512 MB
Flash
Software Versions
This guide covers various software configurations and references are made to operating system or software
versions for:
• Adaptation Kit Update (AKU) version
• OEM version
• Phone version
• BTExplorer version
• Fusion version
• Phone version.
AKU Version
To determine the Adaptation Kit Update (AKU) version:
Tap Start > Settings > System tab > About icon > Version tab.
About This Guide
The second line lists the operating system version and the build number. The last part of the build number
represents the AKU number. For example, Build 18165.0.5.0 indicates that the device is running AKU version
0.5.0.
OEM Version
To determine the OEM software version:
Tap Start > Settings > System tab > System Information icon > System tab.
MC75
BTExplorer Software
To determine the BTExplorer software version:
• Tap BTExplorer icon > Show BTExplorer.
•
If the New Connection window appears, tap Cancel.
• Tap Menu > About.
BTExplorer icon
xv
xvi
MC75 Integrator Guide
Fusion Software
To determine the Fusion software version:
Tap Signal Strength icon > Wireless Status > Versions.
Signal Strength icon
Phone Software
To determine the Phone software version:
Tap Start > Phone > Menu > Options > Version Information tab.
About This Guide
MC7506/96
xvii
MC7508/98
Chapter Descriptions
Topics covered in this guide are as follows:
• Chapter 1, Getting Started provides information on MC75 configurations and accessories, charging the
battery, and resetting.
• Chapter 2, Accessories describes the accessories available for the MC75 and how to set up power
connections and battery charging capabilities, where applicable.
• Chapter 3, ActiveSync provides instructions on installing ActiveSync and setting up a partnership between
the MC75 and a host computer.
• Chapter 4, Application Deployment for Mobile 6 provides information for provisioning and deploying
applications to the MC75.
• Chapter 5, MC7506/96 - GSM Configuration explains how to verify MC7506/96 service on an Enhanced Data
rates for Global Evolution (EDGE) wireless network and establish settings.
• Chapter 6, MC7508/98 - CDMA Configuration explains how to configure MC7508/98 service on an CDMA
wireless network and establish settings.
• Chapter 7, Wireless Applications describes how to configure the wireless LAN connection.
• Chapter 8, Maintenance and Troubleshooting includes instructions on cleaning and storing the MC75, and
provides troubleshooting solutions for potential problems during MC75 operation.
• Appendix A, Technical Specifications includes tables listing the technical specifications for the MC75 and its
accessories.
• Appendix B, Bluetooth Configuration provides registry settings required for configuring the use of the
Bluetooth stack.
Notational Conventions
The following conventions are used in this document:
• “MC75” refers to all configurations of the MC75XX mobile computer.
xviii
MC75 Integrator Guide
• Italics are used to highlight the following:
• chapters and sections in this and related documents
• dialog box, window, and screen names
• drop-down list and list box names
• check box and radio button names
• icons on a screen.
• Bold text is used to highlight the following:
• key names on a keypad
• button names on a screen.
• Bullets (•) indicate:
• action items
• lists of alternatives
• lists of required steps that are not necessarily sequential.
• Sequential lists (e.g., those that describe step-by-step procedures) appear as numbered lists.
Related Documents and Software
The following documents provide more information about the MC75.
• MC75 Quick Start Guide, p/n 72-103079-xx
• MC75 Windows Mobile 6 Regulatory Guide, p/n 72-103080-xx
• MC75 User Guide, p/n 72E-103077-xx
• Microsoft® Applications for Mobile and CE 6 User Guide, p/n 72E-108299-01-xx
• Application Guide, p/n 72E-68901-xx
• Enterprise Mobility Developer Kits (EMDKs), available at: http://www.zebra.com/support.
• Latest ActiveSync software, available at: http://www.microsoft.com.
For the latest version of this guide and all guides, go to: http://www.zebra.com/support.
Service Information
If you have a problem with your equipment, contact Zebra support for your region. Contact information is available
at: http://www.zebra.com/support.
When contacting Zebra support, please have the following information available:
• Serial number of the unit
• Model number or product name
• Software type and version number
Zebra responds to calls by e-mail, telephone or fax within the time limits set forth in support agreements.
About This Guide
xix
If your problem cannot be solved by Zebra Support, you may need to return your equipment for servicing and will
be given specific directions. Zebra is not responsible for any damages incurred during shipment if the approved
shipping container is not used. Shipping the units improperly can possibly void the warranty.
If you purchased your business product from a Zebra business partner, contact that business partner for support.
xx
MC75 Integrator Guide
Chapter 1 Getting Started
Introduction
This chapter provides information about the MC75, accessories, charging the MC75, and resetting the MC75.
Unpacking the MC75
Carefully remove all protective material from the MC75 and save the shipping container for later storage and
shipping. Verify that you received the following equipment:
• MC75
• Lithium-ion battery
• Battery cover/strap assembly
• Tethered stylus
• Protective overlay, installed on display window
• Regulatory Guide
• Quick Start Guide.
Inspect the equipment. If any equipment is missing or damaged, contact the Zebra support immediately. See
Service Information on page xviii for contact information.
1-2
MC75 Integrator Guide
Accessories
Table 1-1 lists the accessories available for the MC75.
Table 1-1 MC75 Accessories
Accessory
Part Number
Description
Cradles
Single Slot USB/Serial
Cradle
CRD7X00-1000RR
Charges the MC75 main battery and a spare battery.
Synchronizes the MC75 with a host computer through
either a serial or a USB connection.
Four Slot Ethernet Cradle
CRD7000-4000ER
Charges the MC75 main battery and connects the MC75
with an Ethernet network.
Four Slot Charge Only
Cradle
CRD7X00-4000CR
Charges up to four MC75 devices.
VCD7000 Vehicle Cradle
VCD7X00-P000R
Installs in a vehicle and charges the MC75 main battery
and a spare battery. Provides serial data communication
between an MC75 and an external device.
Four Slot Spare Battery
Charger
SAC7X00-4000CR
Charges up to four MC75 spare batteries. Includes an
MC75 shim.
Serial Charging Cable
25-102776-01R
Provides power to the MC75 and serial communication
with a host computer.
USB Charging Cable
25-102775-01R
Provides power to the MC75 and USB communication
with a host computer.
Charge Only Cable
25-95214-02R
Provides power to the MC75.
Auto Charge Cable
25-70979-02R
Charges the MC75 using a vehicle’s cigarette lighter.
DEX Cable
25-76793-01R
Connects the MC75 to a vending machine.
Modem Dongle
MDM9000-100R
Provides modem connectivity to the MC75.
Modem Inverter Cables
25-70924-03R
Connects the MC75 to the modem dongle.
O’Neil Printer Cable
25-91519-01R
Printer cable for O’Neil printers.
Zebra Printer Cable
25-91518-01R
Printer cable Zebra Road Warrior printers.
Zebra Printer Cable
25-91515-01R
Printer cable for Zebra QL printers.
MSR7000-100R
Snaps on to the MC75 and adds magstripe read
capabilities.
Chargers
Cables
Miscellaneous
Magnetic Stripe Reader
(MSR)
Getting Started
1-3
Table 1-1 MC75 Accessories (Continued)
Accessory
Part Number
Description
Debit Card Reader
DCR7X00-100R
Allows easy data capture with the swipe of a magnetic
stripe card and personal identification number (PIN) entry
using a numeric keypad.
Snap-on Mobile Payment
Module with Chip and PIN
DCR7X00-200R
Allows easy data capture with magnetic stripe cards, EMV
compliant Chip and PIN cards and personal identification
number (PIN) entry using a numeric keypad.
Biometric Attachment
MC7XFPR-01R
Contains a finger print reader.
Biometric Attachment
MC7XFPSCR-01R
Contains a finger print reader, a contact smart card reader
and a contactless smart card reader.
Spare 3600 mAh
lithium-ion battery
BTRY-MC7XEAB00
Replacement 3600 mAh battery.
Spare 4800 mAh
lithium-ion battery
BTRY-MC7XEAB0H
Optional 4800 mAh battery.
Battery Kit for 3600 mAh
battery
BTRY-KT-1R5X-MC7XR
Replacement 3600 mAh battery and battery door.
Battery Kit for 4800 mAh
battery
BTRY-KT-2R5X-MC7XR
Replacement 4800 mAh battery and battery door.
Headset
50-11300-050R
Use in noisy environments.
Belt Mounted Rigid Holster
SG-MC70011110-01R
Clips onto belt to hold the MC75 when not in use.
Fabric Holster
SG-MC7521215-01R
Soft holder for added protection.
Stylus
Stylus-00002-03R
Replacement stylus (3-pack).
Wall Mounting Kit
8710-050006-01R
Use for wall mounting the four slot cradles.
Screen Protector
KT-67525-01R
Package of 3 screen protectors.
Software
-
Enterprise Mobility Developer Kits (EMDKs), available at:
http://www.zebra.com/support.
Getting Started
To start using the MC75 for the first time:
• Install the SIM card (MC7506 and MC7596 only).
• Install the main battery and cover assembly.
• Charge the MC75.
• Power on the MC75.
• Configure the MC75.
Charge the main battery before or after it is installed. Use one of the spare battery chargers to charge the battery
(out of the MC75), or one of the cradles to charge the battery installed in the MC75.
1-4
MC75 Integrator Guide
Installing the SIM Card
NOTE
MC7506 and MC7596 configurations only.
GSM phone service requires a Subscriber Identification Module (SIM) card, or smart card. Obtain this card from the
phone service provider. The card fits into the MC75 and can contain the following information:
• Mobile phone service provider account details.
• Information regarding service access and preferences.
• Contact information, which can be moved to Contacts on the MC75.
• Any additional services to which you have subscribed.
NOTE
For more information about SIM cards, refer to the mobile phone service provider's documentation.
To install the SIM card:
1.
Press the red Power button to suspend the MC75.
2.
Remove the battery cover and the battery.
3.
Lift the SIM cover using the stylus tip.
SIM Cover
Figure 1-1 Lifting the SIM Cover
4.
Insert the SIM card, as shown in Figure 1-2, with the cut edge of the card facing out and the contacts facing
down.
Figure 1-2 Inserting the SIM Card
Getting Started
5.
Lower the SIM cover and using the stylus slide it in place.
6.
Install the battery. See Installing the Main Battery on page 1-5 for more information.
7.
After completing initial MC75 setup or after replacing a SIM card:
a.
Press the red Power button.
b.
On the Today screen, tap Wireless Manager.
c.
Ensure Phone is on.
d.
Press the red Power button to suspend the MC75.
e.
Perform a warm boot. See Performing a Warm Boot on page 1-8.
f.
Make a call to verify cellular connection.
1-5
For detailed information about WWAN activation and settings, refer to Chapter 2, Accessories.
NOTE
Installing the Main Battery
NOTE
The MC75 ships with a 3600 mAh battery. An optional 4800 mAh battery is available.
To install the main battery.
1.
Insert the battery, top first, into the battery compartment in the back of the MC75.
NOTE
2.
Position the battery correctly, with the battery charging contacts on top of the charging contacts in the battery
compartment.
Press the battery down into the battery compartment until the battery release latch snaps into place.
Battery
Battery Cover Latch
Battery Cover
Release Latch
Figure 1-3 Inserting the Battery
3.
With the battery cover latches open, insert the cover, bottom first, then press down on the top of the cover.
4.
Close the battery cover latches on either side of the battery cover.
5.
Insert the handstrap through the handstrap slot, then tighten and press down to secure.
1-6
MC75 Integrator Guide
Handstrap
Handstrap Slot
Figure 1-4 Inserting the Handstrap
The MC75 powers up after inserting the battery and replacing the battery cover.
Charging the Battery
CAUTION
Ensure that you follow the guidelines for battery safety described in Battery Safety Guidelines on page 8-2.
Charging the Main Battery and Memory Backup Battery
Before using the MC75 for the first time, charge the main battery until the amber Charging/Battery Status LED
remains lit (see Table 1-2 on page 1-7 for charge status indications). To charge the MC75, use a cable or a cradle
with the appropriate power supply. For information about the accessories available for the MC75, see Chapter 2,
Accessories.
The MC75 is equipped with a memory backup battery which automatically charges from the fully-charged main
battery. When using the MC75 for the first time, the backup battery requires approximately 36 hours to fully charge.
This is also true any time the backup battery is discharged, which occurs when the main battery is removed for
several hours. The backup battery retains RAM data in memory for at least 15 minutes (at room temperature) when
the MC75's main battery is removed. When the MC75 reaches a very low battery state, the combination of main
battery and backup battery retains RAM data in memory for at least 48 hours.
To charge the main battery, use either a charging cable or a cradle. For cable and cradle setup and charging
procedures see Chapter 2, Accessories.
• Single Slot USB/Serial Cradle
• Four Slot Ethernet Cradle
• Four Slot Charge Only Cradle
• Vehicle Cradle.
To charge the main battery:
1.
Connect the charging accessory to the appropriate power source.
2.
Insert the MC75 into a cradle or attach to a cable. The MC75 begins charging. The Charging/Battery Status
LED blinks amber while charging, then turns solid amber when fully charged. See Table 1-2 for charging
indications.
The 3600 mAh battery fully charges in approximately five hours and the 4800 mAh battery charges in
approximately seven hours.
Getting Started
1-7
Scan/Decode Charging/Battery Radio Status
Status LED
LED
LED
Figure 1-5 LED Indicators
Table 1-2 LED Charge Indicators
Charging/Battery
Status LED
Indication
Off
MC75 is not charging.
MC75 is not inserted correctly in the cradle or connected to a power source.
Charger/cradle is not powered.
Slow Blinking Amber
(1 blink every 2 seconds)
MC75 is charging.
Solid Amber
Charging complete.
Note: When the battery is initially inserted in the MC75, the amber LED flashes
once if the battery power is low or the battery is not fully inserted.
Fast Blinking Amber
(2 blinks/second)
Charging error, e.g.:
• Temperature is too low or too high.
• Charging has gone on too long without completion (typically eight hours).
Single Blink Amber (when
Power button pressed)
Battery depleted.
Blinking Amber (when
Power button pressed)
Battery over-temperature condition.
Charging Spare Batteries
See Chapter 2, Accessories for information on using accessories to change spare batteries.
Charging Temperature
Charge batteries in temperatures from 0°C to 40°C (32°F to 104°F). Note that at temperatures above 35°C (95°F),
charging is intelligently controlled by the MC75 and the charging accessory in order to ensure safe operation and
optimize long-term battery life.
To accomplish this, for small periods of time, the MC75 or accessory alternately enables and disables battery
charging to keep the battery at acceptable temperatures. The MC75 or accessory indicates when charging is
disabled due to abnormal temperatures via its LED. See Table 1-2.
1-8
MC75 Integrator Guide
Powering On the MC75
Press the Power button to turn on the MC75. If the MC75 does not power on, perform a warm boot. See Resetting
the MC75 on page 1-8.
When turning the MC75 on for the first time, the splash screen displays for about a minute as the MC75 initializes
its flash file system, then the calibration window appears. Note that these windows also appear upon cold boot.
NOTE
When the MC75 powers up after inserting a battery for the first time, the device boots and powers on
automatically.
Calibrating the Screen
To calibrate the screen so the cursor on the touch screen aligns with the tip of the stylus:
1.
Remove the stylus from its holder on the back of the MC75.
2.
Carefully press and briefly hold the tip of stylus on the center of each target that appears on the screen.
3.
Repeat as the target moves around the screen, then tap the screen to continue.
Checking Battery Status
To check the charge status of the main battery or backup battery in the MC75, tap Start > Settings > System tab >
Power icon to display the Power window.
To save battery power, tap the Advanced tab and set the MC75 to turn off after a specified number of minutes.
Resetting the MC75
There are three reset functions, warm boot, cold boot and clean boot. A warm boot restarts the MC75 by closing all
running programs. A cold boot also restarts the MC75, and also initializes some drivers. Data saved in flash
memory or a memory card is not lost. A clean boot resets the MC75 to factory defaults.
Perform a warm boot first. If the MC75 still does not respond, perform a cold boot.
Performing a Warm Boot
Hold down the Power button for approximately five seconds. As soon as the MC75 starts to perform a warm boot
release the Power button.
Performing a Cold Boot
To perform a cold boot:
1.
Simultaneously press the Power button and the 1 and 9 keys.
2.
The MC75 initializes.
Getting Started
1-9
Performing a Clean Boot
CAUTION
A clean boot should only be performed by an authorized system administrator. You must connect the
MC75 to AC power during a clean boot.
Removing AC power from the MC75 during a clean boot may render the MC75 inoperable.
A clean boot resets the MC75 to the factory default settings. All data in the Application folder is retained. You must
download the Clean Boot Package file from the Support Central web site (http://www.zebra.com/support) and
install on the MC75.
To perform a clean boot:
1.
Download the Clean Boot Package from the Support Central web site (http://www.zebra.com/support). Follow
the instructions included in the package for installing the package onto the MC75.
2.
Simultaneously press the Power button and the 1 and 9 keys.
3.
Immediately, as soon as the device starts to boot and before the splash screen is visible, press and hold the
right scan button.
4.
Insert the MC75 into a powered cradle.
5.
The MC75 updates and then re-boots.
6.
Calibrate the screen.
Waking the MC75
The wake-up conditions define what actions wake up the mobile computer after it has gone into suspend mode.
The mobile computer can go into suspend mode by either pressing the Power button or automatically by Control
Panel time-out settings. These settings are configurable and the factory default settings are shown in Table 1-3 are
subject to change/update.
Table 1-3 Wake-up Default Settings
Condition for Wake-up
Power Button
Automatic Time-out
AC power is applied.
No
Yes
Mobile computer is inserted into a cradle.
No
Yes
Mobile computer is removed from a cradle.
No
Yes
Mobile computer is connected to a USB device.
No
Yes
Mobile computer is disconnected from a USB device.
No
Yes
A key is pressed.
No
Yes
The scan triggered is pressed.
No
Yes
The screen is touched.
No
No
Audio Jack
No
No
1 - 10 MC75 Integrator Guide
Table 1-3 Wake-up Default Settings
Condition for Wake-up
Power Button
Automatic Time-out
Audio Btn
No
No
Bluetooth communication
Yes
Yes
Incoming phone call
Yes
Yes
Locking the MC75
Use the Device Lock feature to prevent use of the device. Note that when locked, the MC75 does not respond to
screen or keypad input.
To lock the device, tap the Device unlocked icon on the Today screen. The icon changes to locked.
Figure 1-6 Device Locked/Unlocked Icons
To unlock the device and free it for use, tap Unlock.
Figure 1-7 Unlock Window
Tap Unlock on the Unlock window or press the * key.
Micro Secure Digital (microSD) Card
The microSD card slot provides secondary non-volatile storage. The slot is located on the side of the MC75 (see
Figure 1-8). Refer to the documentation provided with the card for more information, and follow the manufacturer’s
recommendations for use.
Getting Started 1 - 11
CAUTION
Follow proper ESD precautions to avoid damaging the SD card. Proper ESD precautions include, but
are not limited to, working on an ESD mat and ensuring that the operator is properly grounded.
To install the microSD card:
1.
Power off the MC75.
2.
Remove the memory card cover on the side of the MC75 by loosening the two captive screws.
Figure 1-8 Card Installation
3.
Insert the card with the card contacts facing up and the cut corner on the left, until you feel a click.
4.
Replace the memory card cover and tighten the screws.
To remove an microSD card:
1.
Power off the MC75.
2.
Remove the memory card cover by loosening the screws.
Figure 1-9 Card Removal
3.
Carefully press and release the card to eject it.
4.
Remove the card from the card slot.
5.
Replace the memory card cover and tighten the screws.
Removing the Screen Protector
A screen protector is applied to the MC75. Zebra recommends using this to minimize wear and tear. Screen
protectors enhance the usability and durability of touch screen displays.
To remove the screen protector, lift the corner using a thin plastic card, such as a credit card, then carefully lift it off
the display.
1 - 12 MC75 Integrator Guide
Lift Screen Protector
Corner
Figure 1-10 Removing the Screen Protector
!
CAUTION
NOTE
Do not use a sharp object to remove the protector. Doing so can damage the display.
Not using a screen protector can affect warranty coverage. To purchase replacement protectors, contact your
local account manager or Zebra. These include screen protector installation instructions. Part number:
KT-67525-01R Screen Protector 3/pk.
Replacing the Main Battery
1.
Press the red Power button to suspend the MC75.
2.
Loosen the handstrap.
3.
Open the battery cover latches on either side of the battery cover.
Battery Cover Latch
Figure 1-11 Removing the Battery Cover
4.
Lift the top of the battery cover and remove.
5.
Press the battery release latch on the bottom of the battery to unlock, and lift the battery out of the well.
6.
Insert the replacement battery, top first, into the battery compartment in the back of the MC75.
7.
Press the battery down into the battery compartment until the battery release latch snaps into place.
NOTE
Position the battery correctly, with the battery charging contacts on top of the charging contacts in the battery
compartment.
Getting Started 1 - 13
8.
With the battery cover latches open, insert the cover, bottom first, then press down on the top of the cover.
9.
Close the battery cover latches on either side of the battery cover.
10. Insert the handstrap through the handstrap slot, then tighten and press down to secure.
The MC75 powers up after inserting the battery and replacing the battery cover.
1 - 14 MC75 Integrator Guide
Chapter 2 Accessories
Introduction
MC75 accessories, listed below, provide a variety of product support capabilities.
• Four Slot Ethernet Cradle - Charges the MC75 main battery and connects the MC75 with an Ethernet
network.
• Four Slot Charge Only Cradle - Charges up to four MC75 devices.
• Single Slot USB/Serial Cradle - Charges the MC75 main battery and a spare battery. Synchronizes the MC75
with a host computer through a USB or serial connection.
• Vehicle Cradle - Provides secure mounting of the MC75 in a vehicle. Charges the MC75 and a spare battery.
Provides a serial port for data communication between an MC75 and an external device.
• Four Slot Battery Charger - Charges spare standard and high capacity batteries.
• Auto Charge Cable - Plugs into a vehicle cigarette lighter to charge the MC75 while on the road.
• Charge Only Cable - Provides power to the MC75.
• DEX Cable - Enables the transmission of data between the MC75 and a customer's inventory system at the
time of delivery.
• Modem Inverter Cable - Connects the MC75 to the modem dongle.
• Modem Dongle - Provides modem connectivity.
• Printer Cables - Connects the MC75 to a printer.
• Serial Cable - Provides serial communication from cradle with a host computer.
• Serial Charging Cable - Provides power to the MC75 and serial communication with a host computer.
• USB Cable - Provides USB communication from cradle with a host computer.
• USB Charging Cable - Provides power to the MC75 and USB communication with a host computer.
• Belt Mounted Rigid Holster - Holds the MC75 when not in use.
• Belt Mounted Fabric Holster - Provides additional protection for the MC75.
• Headset - Used in noisy environments.
2-2
MC75 Integrator Guide
• Magnetic Stripe Reader - Snaps on to the MC75 and adds magstripe read capabilities.
• Debit Card Reader - Snaps onto the bottom of the MC75 to allow easy data capture with the swipe of a
magnetic stripe card and personal identification number (PIN) entry using a numeric keypad.
• Snap-on Mobile Payment Module with Chip and PIN - snaps onto the bottom of the MC75 mobile computer
to allow easy data capture with magnetic stripe cards, EMV compliant Chip and PIN cards and personal
identification number (PIN) entry using a numeric keypad.
Single Slot USB/Serial Cradle
This section describes how to set up and use a Single Slot USB/Serial cradle with the MC75. For USB
communication setup procedures see Chapter 3, ActiveSync.
The Single Slot USB/Serial Cradle:
• Provides 5.4 VDC power for operating the MC75.
• Synchronizes information between the MC75 and a host computer. See Chapter 3, ActiveSync for
information on setting up a partnership between the MC75 and a host computer.
• Charges the MC75’s battery.
• Charges a spare battery.
Setup
Power Port
USB Port
Power Supply
Figure 2-1 Single Slot USB/Serial Cradle Power and USB Connections
Charging the MC75 Battery
Connect the cradle to power. Insert the MC75 into the MC75 slot to begin charging.
Accessories
2-3
Charging/Battery Status LED
Figure 2-2 MC75 Battery Charging
Charging the Spare Battery
Spare Battery
Spare Battery
Charging LED
Figure 2-3 Spare Battery Charging
Battery Charging Indicators
The Single Slot USB/Serial Cradle charges the MC75’s main battery and a spare battery simultaneously.
The MC75’s Charge LED indicates the status of the battery charging in the MC75. See Table 1-2 on page 1-7 for
charging status indications.
The spare battery charging LED on the cradle indicates the status of the spare battery charging in the cradle. See
Table 2-1 for charging status indications.
The 3600 mAh battery fully charges in approximately five hours and the 4800 mAh battery fully charges in
approximately seven hours.
2-4
MC75 Integrator Guide
Charging Temperature
Charge batteries in temperatures from 0°C to 40°C (32°F to 104°F). Charging is intelligently controlled by the
MC75.
To accomplish this, for small periods of time, the MC75 or accessory alternately enables and disables battery
charging to keep the battery at acceptable temperatures. The MC75 or accessory indicates when charging is
disabled due to abnormal temperatures via its LED. See Table 1-2 on page 1-7 and Table 2-1.
Table 2-1
Spare Battery LED Charging Indicators
Spare Battery LED
(on cradle)
Indication
Slow Blinking Amber
Spare battery is charging.
Solid Amber
Spare battery is fully charged.
Fast Blinking Amber
Charging error.
Off
Not charging.
Accessories
2-5
Four Slot Ethernet Cradle
This section describes how to set up and use a Four Slot Ethernet cradle with the MC75.
The Four Slot Ethernet cradle:
• Provides 5.4 VDC power for operating the MC75.
• Connects the MC75 (up to four) to an Ethernet network.
• Simultaneously charges up to four MC75s.
You cannot ActiveSync using the Four Slot Ethernet cradle. To ActiveSync with a host computer, use the SIngle
Slot USB/Serial cradle, USB Charging cable or Serial Charging cable.
Setup
Connect the Ethernet cradle to a power source and to an Ethernet switch, router, or hub, or a port on the host
device.
Ethernet Port 1
Power Port
Ethernet Port
Ethernet Switch,
Router, or Hub
Connection
Figure 2-4 Four Slot Ethernet Cradle Connection
Daisychaining Ethernet Cradles
Daisychain up to seven Ethernet cradles to connect several cradles to an Ethernet network. Use either a straight or
crossover cable. Daisychaining more than four Ethernet cradles can lead to reduction in bandwidth.
To daisychain more than one Ethernet cradle:
1.
Connect power to each Ethernet cradle to daisychain.
2.
Connect an Ethernet cable to Port 1 of the first cradle as shown in Figure 2-4.
3.
Connect a second Ethernet cable between Port 2 of the first cradle, and Port 1 of the second cradle.
4.
Connect additional cradles as described in Step 3.
2-6
MC75 Integrator Guide
Speed LED
Link LED
Ethernet Port 1
Ethernet Port 2
Figure 2-5 Daisychaining Four Slot Ethernet Cradles
Bandwidth Considerations when Daisychaining
Each cradle added to the daisychain impacts the bandwidth provided to the inserted MC75s, particularly when the
MC75s attempt to send and receive at data rates that exceed the bandwidth provided to the chain (typically 100
Mbps). If an MC75 in a daisychained cradle does not use its bandwidth, that bandwidth is allocated to other
inserted MC75s.
Table 2-2 shows available bandwidth, based on 100 Mpbs, for the maximum number of daisychained cradles, with
each attempting transmission at the maximum data rate.
Table 2-2 Daisychaining Bandwidth
Daisychained Cradles
Bandwidth Allocation For Each
Ethernet Cradle (bits/sec)
Bandwidth Allocation For Each
Mobile Computer (bits/sec)
Cradle 1
100,000,000
20,000,000
Cradle 2
20,000,000
4,000,000
Cradle 3
4,000,000
800,000
Cradle 4
800,000
160,000
Cradle 5
160,000
32,000
Cradle 6
32,000
6,400
Cradle 7
6,400
1,280
* The maximum bandwidth capacity for the mobile computer is 12,000,000 bits/sec.
** Depending on the application, allocated bandwidth may not be adequate.
Note: 100 Mbps is the theoretical maximum. This rate is never actually achieved in any Ethernet installation.
Ethernet Cradle Drivers
The MC75 includes Ethernet cradle drivers that initiate automatically when you place the MC75 in a properly
connected Four Slot Ethernet cradle. After inserting the MC75, configure the Ethernet connection:
1.
Tap Start > Settings > Connections tab >WiFi icon. The Configure Network Adapters window appears.
Accessories
JEDI WiFi Driver
Figure 2-6 Configure Network Adapters Window
2.
In the My network card connects to: drop-down list, select the appropriate connection.
3.
In the Tap an adapter to modify settings: list, select USB/Ethernet Series Adapter.
Figure 2-7 IP Address Tab
4.
In the IP address window, select the appropriate radio button:
• Use server-assigned IP address
or
• Use specific IP address. Enter the IP address, Subnet mask, and Default gateway, as needed.
5.
Tap the Name Servers tab.
2-7
2-8
MC75 Integrator Guide
Figure 2-8 Name Servers Tab
6.
Enter the appropriate DNS, Alt DNS, WINS, and Alt WINS server addresses.
7.
Tap ok.
Figure 2-9 Adapters Dialog Box
8.
Tap ok to confirm the setup.
9.
Tap ok to exit.
Charging and Communication
Insert the MC75 into a slot to begin charging.
Accessories
Speed LED
2-9
Link LED
Figure 2-10 MC75 Battery Charging
LED Charging Indicators
Charge LED
The MC75’s charge LED shows the status of the battery charging in the MC75. See Table 1-2 on page 1-7 for
charging status indications.
The 3600 mAh battery fully charges in approximately five hours and the 4800 mAh battery fully charges in
approximately seven hours.
Speed LED
The cradle’s green Speed LED lights to indicate that the transfer rate is 100 Mbps. When it is not lit it indicates that
the transfer rate is 10Mbps.
Link LED
The cradle’s yellow Link LED blinks to indicate activity, or stays lit to indicate that a link is established. When it is
not lit it indicates there is no link.
Charging Temperature
Charge batteries in temperatures from 0°C to 40°C (32°F to 104°F). Charging is intelligently controlled by the
MC75.
To accomplish this, for small periods of time, the MC75 or accessory alternately enables and disables battery
charging to keep the battery at acceptable temperatures. The MC75 or accessory indicates when charging is
disabled due to abnormal temperatures via its LED. See Table 1-2 on page 1-7.
2 - 10 MC75 Integrator Guide
Four Slot Charge Only Cradle
This section describes how to set up and use a Four Slot Charge Only cradle with the MC75.
The Four Slot Charge only cradle:
• Provides 5.4 VDC power for operating the MC75.
• Simultaneously charges up to four MC75s.
You cannot ActiveSync using the Four Slot Charge Only cradle. To ActiveSync with a host computer, use the
Single Slot USB/Serial cradle, USB Charging cable or Serial Charging cable.
Setup
Connect the Four Slot Charge Only cradle to a power source.
Figure 2-11 Four Slot Charge Only Cradle Connection
Charging Temperature
Charge batteries in temperatures from 0°C to 40°C (32°F to 104°F). Charging is intelligently controlled by the
MC75.
To accomplish this, for small periods of time, the MC75 or accessory alternately enables and disables battery
charging to keep the battery at acceptable temperatures. The MC75 or accessory indicates when charging is
disabled due to abnormal temperatures via its LED. See Table 1-2 on page 1-7.
Accessories 2 - 11
Wall Mount Bracket
Use the optional Wall Mount Bracket to mount a four slot cradle to a wall. To attach the Wall Mount Bracket:
1.
Use the Wall Mount Bracket as a template and mark the locations of the four mounting screws.
NOTE
Use fasteners appropriate for the type of wall and the Wall Mount Bracket mounting slots. The Wall Mount
Bracket mounting slots are designed for a fastener with a #8 pan head.
2.
Mount the fasteners to the wall. The screw heads should protrude about a half of an inch from the wall.
3.
Slip the Wall Mount Bracket over the screw heads and slide the bracket down over the screw heads.
4.
Tighten the screws to secure the bracket to the wall.
Mounting Tab (2)
Mounting Screw (4)
Mounting Slot
Figure 2-12 Wall Mount Bracket
To mount a four slot cradle:
1.
Screw the supplied fasteners into the bottom of the four slot cradle. The screw heads should protrude about a
quarter of an inch from the cradle.
Four Slot
Cradle Bottom
Mounting Screw (2)
Figure 2-13 Cradle Mounting Screws
2.
Align the Wall Mount Bracket mounting tabs with the mounting slots in the back of the four slot cradle. Slip the
two mounting tabs into mounting slots.
2 - 12 MC75 Integrator Guide
3.
Swing the four slot cradle down onto the mounting bracket and align the mounting screws so that they fit into
the screw slots.
Wall Mount
Bracket
Screw Slots
Power Supply
Well
Figure 2-14 Wall Mount Bracket
4.
Tighten the mounting screws to secure the four slot cradle to the bracket.
Figure 2-15 Mounting Screws
5.
Connect power (see Figure 2-4 on page 2-5). The power supply should be located in the power supply well.
Accessories 2 - 13
VCD7X00 Vehicle Cradle
This section describes how to set up and use a VCD7X00 vehicle cradle with the MC75.
Once installed in a vehicle, the cradle:
• holds the MC75 securely in place
• provides power for operating the MC75
• provides a serial port for data communication between an MC75 and an external device (e.g., a printer)
• re-charges the battery in the MC75
• re-charges a 3600 mAh or 4800 mAh battery.
Requirements
For mounting:
• four #8-32 self-locking nuts
• four #8 washers
• a drill with a #6 drill bit (.204”).
For power connection:
• power input cable (included), p/n 25-61987-01R
• UL Listed in-line fuse rated 250V, 5A (included), must be used if not connecting to vehicle’s fuse panel
• in-line fuse holder (included), must be used if not connecting to vehicle’s fuse panel.
For serial connection:
• DB9 female serial cable (some devices may require null modem).
For communication:
• an MC75
• host computer setup and MC75 setup (as determined by the application you are using).
Connector Ports
There are two connection ports on the bottom of the vehicle cradle:
Table 2-3 Vehicle Cradle Connection Ports
Ports
Function
Serial
Standard RS 232 port used for direct connection to the serial device using a serial cable.
Power
Used for connecting to vehicle power using the power input cable.
2 - 14 MC75 Integrator Guide
Connector Pin-Outs
Table 2-4 Power Input Cable
Pin
Signal
1
Chassis ground (Black Wire)
2
Chassis ground (Bare Wire)
3
V+ (Red Wire)
4
V+ (Red Wire)
1
Connector on Power Cable
Table 2-5 Serial Cable
Pin
Signal
Pin
Signal
1
DCD
5
GND
2
RxD
6
DSR
3
TxD
7
RTS
4
DTR
8
CTS
5
GND
9
5V_OUT
CAUTION
Connector on Serial Cable
ROAD SAFETY - Do not use the MC75 while driving. Park the vehicle first. Always ensure the MC75 is
fully inserted into the cradle. Do not place it on the seat or where it can break loose in a collision or
sudden stop. Lack of proper insertion may result in property damage or personal injury. Zebra is not
responsible for any loss resulting from the use of the products while driving. Remember: Safety comes
first.
Mounting the Cradle
CAUTION
1.
Select a mounting location for the cradle. It should be flat, and must provide adequate support for the cradle.
NOTE
2.
Only mount the Vehicle Cradle in a vertical position with the release level at the top or in a horizontal position
with the MC75 display facing up. Never mount the vehicle cradle on the side or upside down or on a wall that
can be subject to impact or collision of greater than 40Gs, in accordance with SAE J1455 Section 4.10.3.5
If using the GPS functionality of the MC75 mobile computer, ensure that the vehicle cradle is positioned so that
the MC75 has a clear unobstructed view of the sky.
Prepare the mounting surface to accept four #8-32 studs, using the mounting template below. Drill four holes
with a #6 drill bit.
Accessories 2 - 15
1.2”
3.05 cm
1.5”
3.81 cm
Figure 2-16 Vehicle Cradle Mounting Template
3.
Position the cradle on the mounting surface.
4.
Fasten it using four #8 washers and four #8-32 self-locking nuts.
Do not install a VCD7000 Vehicle Cradle on or near an air bag cover plate or within an aerobic zone. Also, do
not install it in a location that affects vehicle safety or driveability.
CAUTION
Power Connection
Please read all of the following instructions before beginning.
WARNING!
A properly trained technician must perform the power connection. Improper connection can damage
your vehicle, cradle or MC75. Refer to the vehicle’s Owner’s Manual for instructions for removing
power.
To connect the cradle to power:
CAUTION
1.
When setting up connection for this cradle, only use the power input cable provided with this cradle.
Locate the vehicle power source.
NOTE
The ideal location for connecting the vehicle cradle power input cable would be an accessory output in your
vehicle’s fuse panel. The vehicle cradle should be added to a circuit with a maximum load capacity for the
cradle and the original circuit. Refer to the vehicle’s Owner’s Manual for identification of the circuit.
If a fused output is not available, the vehicle cradle must be installed with the provided in-line fuse holder and
UL Listed 5A fuse. The fuse protects the vehicle from an electrical short on the power line to the cradle.
To use the cradle to charge the MC75 and spare battery when the vehicle’s ignition is off, connect the cradle to
unswitched power. This will affect the vehicle’s battery charge.
2 - 16 MC75 Integrator Guide
2.
Route the power input cable from the cradle’s power port to the connection point for the vehicle’s power
source.
CAUTION
3.
The means of routing and securing the power input cable from the cradle through to the vehicle power
source is extremely important. Hazards associated with improper wiring can be severe. To avoid
unintentional contact between the wire and any sharp edges, provide the cable with proper bushings and
clamping where it passes through openings. If the wire is subjected to sharp surfaces and excess engine
vibration, the wiring harness insulation can wear away, causing a short between the bare wire and chassis.
This can start a fire.
To avoid any mishaps, all wiring should be routed away from moving parts, high temperature areas and any
contaminants.
When using the supplied in-line fuse holder (which must be used if not connecting to vehicle’s fuse panel):
a.
Ensure the fuse holder contains a 5A UL Listed slow-blow fuse.
b.
Splice the fuse holder to the end of the red V+ wire, as shown above. Make the distance from the fuse to
the power connection point as short as possible.
Ground
Wire (black)
Shield Wire
(bare wire)
5A Fuse and
Fuse Holder
V+ Power (red)
Figure 2-17 Vehicle Cradle Power Connection
4.
Prepare the cable termination.
a.
Red wire: connect to a +12/24 V vehicle power source.
b.
Black wire and Shield wire: connect to vehicle ground wire or chassis ground.
NOTE
5.
How the cable terminates depends on the vehicle. If the vehicle has a power output connector, then you must
attach a mating connector to the end of the power cable. You may be able to connect to a fuse panel with a
simple blade terminal or commercially available connector. Consult the vehicle Owner’s Manual for information
on how to access the power supply in the vehicle.
Connect the power input cable into the power port on the cradle.
To see if the cradle has power, insert the MC75. The Charging LED on the MC75 blinks slowly to indicate charging
and turns solid amber when the battery is completely charged. See Table 1-2 on page 1-7 for other indications.
Accessories 2 - 17
Serial Device Connection
The MC75 has a serial port on the bottom. When the MC75 is inserted into the cradle, it connects to the cradle’s
serial port. The MC75 can then use the cradle’s serial port to communicate with an external device.
To Serial Port of
Serial Device
Figure 2-18 Vehicle Cradle Serial Connection
To provide serial communications between an MC75 and a serial device, connect one end of the 9-pin serial cable
into the serial port on the cradle, and the other end into the serial port on the serial device.
NOTE
Some devices may require a null modem serial cable.
To begin communication:
1.
Insert the MC75 into the cradle.
2.
To initiate communication, make appropriate selections on the MC75, as determined by the application you are
using.
CAUTION
Removing the MC75 during data communication disrupts communication between the MC75 and the
attached device.
Charging the MC75 Battery
Insert the MC75 into the vehicle cradle to begin charging. A click indicates that the MC75 button release locking
mechanism is enabled and the MC75 is locked in place.
2 - 18 MC75 Integrator Guide
Release Lever
Figure 2-19 MC75 Battery Charging
CAUTION
Ensure the MC75 is fully inserted in the cradle. Lack of proper insertion may result in property damage or
personal injury. Zebra is not responsible for any loss resulting from the use of the products while driving.
Removing the MC75
To remove the MC75, hold back the release lever on the cradle and pull the MC75 up and out of the cradle.
Release Lever
Figure 2-20 Removing the MC75
Charging the Spare Battery
Insert a spare battery to begin charging:
1.
Lift the battery release lever.
Accessories 2 - 19
Battery Release Lever
Figure 2-21 Inserting the Spare Battery
2.
Insert the spare battery in the spare battery charging slot in the cradle with the charging contacts facing up and
to the rear of the cradle.
3.
Release the battery release lever. The battery release lever locks the spare battery into place.
To remove a spare battery, hold back the battery release lever and lift the battery from the spare battery slot.
Battery Release Lever
Figure 2-22 Removing the Spare Battery
Battery Charging Indicators
The Vehicle Cradle charges the MC75’s main battery and a spare battery simultaneously.
The MC75’s charge LED indicates the status of the battery charging in the MC75. See Table 1-2 on page 1-7 for
charging status indications.
The spare battery charging LED on the cradle indicates the status of the spare battery charging in the cradle. See
Table 2-6 for charging status indications.
The 3600 mAh battery fully charges in approximately five hours and the 4800 mAh battery fully charges in
approximately seven hours.
2 - 20 MC75 Integrator Guide
Table 2-6
Vehicle Cradle Spare Battery LED Charging Indicators
Spare Battery LED
(on cradle)
Indication
Slow Blinking Amber
Spare battery is charging.
Solid Amber
Spare battery is fully charged.
Fast Blinking Amber
Charging error.
Off
Not charging.
Charging Temperature
Charge batteries in temperatures from 0°C to 40°C (32°F to 104°F). Charging is intelligently controlled by the
MC75.
To accomplish this, for small periods of time, the MC75 or accessory alternately enables and disables battery
charging to keep the battery at acceptable temperatures. The MC75 or accessory indicates when charging is
disabled due to abnormal temperatures via its LED. See Table 1-2 on page 1-7 and Table 2-6.
Accessories 2 - 21
Four Slot Battery Charger
This section describes how to use the Four Slot Battery Charger to charge up to four MC75 spare batteries.
Battery Shim Installation
Before charging a spare battery, snap the MC75 shim into the battery slot as shown in Figure 2-23.
Figure 2-23 Spare Battery Shim Installation
NOTE
To purchase additional shims, contact your local account manager or Zebra. Part number: KT-76490-01R.
Spare Battery Charging
1.
Connect the charger to a power source.
2.
Insert the spare battery into a spare battery charging well and gently press down on the battery to ensure
proper contact.
2 - 22 MC75 Integrator Guide
Spare Battery
Spare Battery
Charging LEDs (4)
Figure 2-24 Four Slot Spare Battery Charger
Battery Charging Indicators
An amber LED is provided for each battery charging well. See Table 2-7 for charging status indications. The 3600
mAh battery fully charges in approximately five hours and the 4800 mAh battery fully charges in approximately
seven hours.
Charging Temperature
Charge batteries in temperatures from 0°C to 40°C (32°F to 104°F). Charging is intelligently controlled by the
charger in order to ensure safe operation and optimize long-term battery life.
To accomplish this, for small periods of time, the charger alternately enables and disables battery charging to keep
the battery at acceptable temperatures. The charger indicates when charging is disabled due to abnormal
temperatures via its LED. See Table 2-7.
Table 2-7
Spare Battery LED Charging Indicators
LED
Indication
Off
No spare battery in slot; spare battery not placed correctly; cradle is not powered.
Fast Blinking Amber
Error in charging; check placement of spare battery.
Slow Blinking Amber
Spare battery is charging.
Solid Amber
Charging complete.
Accessories 2 - 23
Magnetic Stripe Reader (MSR)
This section describes how to set up and use the snap-on MSR with the MC75. The MSR snaps on to the bottom
of the MC75 and removes easily when not in use.
When attached to the MC75, the MSR allows the MC75 to capture data from magnetic stripe cards. To download
sample MSR data capture software, visit http://www.zebra.com/support.
Attaching and Removing the MSR
To attach, slide the MSR onto the bottom of the MC75 and snap it in place.
Card Reader Slot
Figure 2-25 MSR Installation
To remove the MSR open the arms and pull the MSR from the MC75.
Using the MSR
The MSR3000 sample application illustrates how an application handles MSR inputs (refer to Zebra Applications
User’s Guide).
To use the MSR:
1.
Attach the MSR to the MC75.
2.
Power on the MC75.
3.
Tap Start > MC75 Demo > Test Apps > MSR MC75 or MSR Cameo to start the sample application.
4.
Swipe the magnetic stripe card through the MSR, with the magnetic stripe on the card facing down. Swipe the
card in either direction, from left to right or from right to left. For best results, gently press down on the card
while swiping to ensure contact with the bottom of the reader.
2 - 24 MC75 Integrator Guide
Figure 2-26 Magnetic Stripe Card Swiping
Accessories 2 - 25
Debit Card Reader
The DCR7X00-100R Debit Card Reader (DCR) snaps onto the bottom of the MC75 mobile computer to allow easy
data capture with the swipe of a magnetic stripe card and personal identification number (PIN) entry using a
numeric keypad.
Getting Started
When using the DCR for the first time, charge the DCR in a cradle for a minimum of three hours.
Installation
1.
Align the DCR with the bottom of the MC75 and push up until the locking tabs snap into place.
Figure 2-27 Installation
2.
Pull on the DCR to ensure it is securely connected to the MC75.
Removal
To remove the DCR from the MC75, push in the bottom of the two locking tabs and pull the DCR from the MC75.
2 - 26 MC75 Integrator Guide
Figure 2-28 Removal
Credit Card Transactions
Launch a transaction application on the MC75. In the application, select Credit Card transaction.
Swipe the credit card through the magnetic stripe reader (MSR) slot, orienting the magnetic stripe as shown. Data
encoded on the credit card is captured and, depending on the application, may display in an application data field.
Figure 2-29 Swipe Card
NOTE
Swipe the card in either direction, from left to right, or right to left. For best results, gently press down on the
card while swiping to ensure contact with the bottom of the slot.
Debit Card Transactions
Launch a transaction application on the MC75. In the application, select Debit Card transaction.
Swipe the debit card through the MSR slot, orienting the magnetic stripe as shown. Data encoded on the debit card
is captured and, depending on the application, may display in an application data field.
Accessories 2 - 27
Figure 2-30 Swipe Card
NOTE
Swipe the card in either direction, from left to right, or right to left. For best results, gently press down on the
card while swiping to ensure contact with the bottom of the slot.
Turn the MC75 over and present the DCR keypad to the customer. The customer enters their PIN following the
instructions on the DCR display.
Figure 2-31 Enter PIN on DCR
Keypad
The back of the DCR contains a display and a numeric keypad for entering data.
Figure 2-32 DCR Keypad
2 - 28 MC75 Integrator Guide
Table 2-8 Keypad Key Descriptions
Key
Description
Numeric
Used to enter PIN.
Cancel
Cancels the current transaction.
Clear
Clears the entered data.
Enter
Submits the entered data.
Display Messages
The follow messages may appear on the DCR display:
ENTER PIN - A PIN is required to complete the transaction.
PIN ERR - The entered PIN is not between 4 and 12 characters.
CANCELED - The transaction was cancelled by the user.
COMPLETE - The transaction was completed.
KEYCLEAR - The DCR was tampered with or the battery completely discharged. The DCR must have the key
re-injected. See your system administrator.
BATT OK - Battery is significantly charged.
BATT LOW - Battery charge is low. Re-charge as soon as possible.
STAND BY - DCR is performing a firmware check. This occurs if it has been powered off for more than 24 hours.
Check the DCR Battery Level
When the DCR is not used for extended periods of time or in storage it must be charged periodically to maintain the
battery charge. Zebra recommends charging the DCR once every three months.
If the DCR battery fully discharges the debit function will be inoperable but the MSR will still function for credit card
transactions. Return the DCR for service.
NOTE
While the DCR is being used in normal operation (application is accessing the DCR port), the DCR charges
from the MC75.
To check the battery level:
1.
Remove the DCR from the MC75.
2.
Press and hold the 5 key until the battery status displays on the DCR display.
• BATT OK - Battery is significantly charged
Accessories 2 - 29
• BATT LOW - Battery charge is low.
If BATT LOW displays, charge the DCR for approximately three hours.
To charge the DCR, place it in a cradle or connect it to a charging cable. The DCR also charges when connected to
the MC75 and the transaction application is running.
Figure 2-33 Charging the DCR
Charging the MC75
You can charge the MC75 while the DCR is attached. Place the MC75 with the DCR into a cradle to charge the
MC75.
Figure 2-34 Charging the MC75 with the DCR Attached
NOTE
If you are going to replace the MC75 battery, remove the DCR from the MC75 before replacing the battery.
Key Injection
If the DCR was tampered with or the battery has completely discharged. “KEYCLEAR” displays on the DCR
display. The key must be re-injected into the DCR. For key loading instructions see your system administrator or
contact customer service.
Maintenance
There are no serviceable part in the DCR. Do not tamper with the device. If the DCR is opened the key will be
cleared.
2 - 30 MC75 Integrator Guide
Snap-on Mobile Payment Module with Chip and PIN
The DCR7X00-200R Snap-on Mobile Payment Module with Chip and PIN smart card reader snaps onto the
bottom of the MC75 mobile computer to allow easy data capture with magnetic stripe cards, EMV compliant Chip
and PIN cards and personal identification number (PIN) entry using a numeric keypad. This guide describes how to
install and use the module.
Installation
NOTE
1.
The module only functions when attached to the MC70/MC75.
Align the module with the bottom of the MC75 and push up until the locking tabs snap into place.
Figure 2-35 Attach Module to MC75
2.
Pull on the module to ensure it is securely connected to the MC75.
Removal
To remove the module from the MC75, push in the bottom of the two locking tabs and pull the module from the
MC75.
Figure 2-36 Press Latches In to Lock
Accessories 2 - 31
Credit Card Transactions
NOTE
Credit Card transactions will function without an encryption key injected but will not function if a tamper event
occurs.
Launch a transaction application on the MC75. In the application, select Credit Card transaction.
Swipe the credit card through the magnetic stripe reader (MSR) slot, orienting the magnetic stripe as shown. Data
encoded on the credit card is captured and, depending on the application, may display in an application data field.
Figure 2-37 Swipe Card
NOTE
Swipe the card in either direction, from left to right, or right to left. For best results, gently press down on the
card while swiping to ensure contact with the bottom of the slot.
Debit Card Transactions
NOTE
Debit Card transactions will only function with an encryption key injected. It will not function if a tamper event
occurs.
Launch a transaction application on the MC75. In the application, select Debit Card transaction.
Swipe the debit card through the MSR slot, orienting the magnetic stripe as shown. Data encoded on the debit card
is captured and, depending on the application, may display in an application data field.
Figure 2-38 Swipe Card
NOTE
Swipe the card in either direction, from left to right, or right to left. For best results, gently press down on the card while
swiping to ensure contact with the bottom of the slot.
Turn the MC75 over and present the keypad to the customer. The customer enters their PIN following the instructions on the display.
2 - 32 MC75 Integrator Guide
Figure 2-39 Enter PIN
Chip and PIN Transactions
NOTE
Chip and PIN transactions will function without an encryption key injected but will not function if a tamper event
occurs.
Launch a transaction application on the MC75. In the application, select Chip and PIN transaction.
Customer inserts the Chip and Pin card into the slot, orienting the card with the contacts facing down and toward
the DCR keypad.
Figure 2-40 Insert Card
Customer turns the MC75 over, and enters their PIN following the instructions on the display.
Customer removes the card when transaction is complete.
Keypad
The back of the module contains a display and a numeric keypad for entering data.
Accessories 2 - 33
Figure 2-41 Keypad
Table 2-9 Keypad Button Descriptions
Key
Description
Numeric
Used to enter PIN.
Cancel (Red)
Cancels the current transaction.
Clear (Yellow)
Clears the entered data.
Enter (Green)
Submits the entered data.
Display Messages
After connecting the module to the MC70/MC75 and an application opens the COM port, the following displays:
.
Figure 2-42 Display
Line 1 indicates the model number and the firmware version. The firmware version displays after the model
number. In this example the firmware version is 0.09.
Line 2 indicates the keyload code. Each characters of the keyload code represents a different key type.
2 - 34 MC75 Integrator Guide
Table 2-10 Keyload Codes
Display
Operating Status
D
D
D
-
M
M
-
M
M
-
M
M
-
M
M
-
Normal
d
d
d
-
m
m
-
m
m
-
m
m
m
m
Return to key injection facility.
Return to Zebra for service.
* * * * *
Blank display
The follow messages may appear on the display:
Table 2-11 Display Messages
Message
Description
Line 1:
Line 2: Enter PIN
Instructs the user to enter their PIN.
Line 1: PIN
Line 2: ENT to Accept
Displays “*” as PIN is entered and instructs the user to press enter key
when done.
Headset
Use the headset to communicate via Voice-over-IP (VoIP) or for audio playback. To connect the headset, remove
the plug from the headset jack at the top of the MC75 and insert the headset connector. Contact a Zebra
representative for compatible headsets.
For best performance, Zebra recommends a 2.5 mm jack headset, p/n 50-11300-050R.
Accessories 2 - 35
Figure 2-43 Headset Connection
2 - 36 MC75 Integrator Guide
Cables
This section describes how to set up and use the cables. The cables are available with a variety of connection
capabilities.
The following MC75 communication/charge cables are available:
• Serial (RS232) Charge cable (9-pin D female with power input receptacle)
• USB Client Charge cable (standard-A connector and a barrel receptacle for power)
• Auto charge cable
• DEX cable
• Modem inverter cable
• Charge only cable.
The following printer cables are available directly from Zebra.
• O’Neil Printer cable
• Zebra Printer cable.
Figure 2-44 Cables (MC75 Connector)
The communication/charge cables:
• Provide the MC75 with operating and charging power.
• Synchronize information between the MC75 and a host computer. With customized or third party software, it
can also synchronize the MC75 with corporate databases.
• Provide serial connection through the serial pass-through port for communication with a serial device, such
as a host computer. For communication setup procedures, see Communication Setup on page 2-37.
• Provide USB connection through the USB pass-through port for communication with a USB device, such as
a host computer. For communication setup procedures, see Communication Setup on page 2-37.
Dedicated printer cables provide communication with a printer.
Setup
The MC75 communication/charge cables can connect with a serial/USB device, such as a printer or host computer,
through its serial or USB port.
Accessories 2 - 37
Battery Charging
The communication/charge cables can charge the MC75 battery and supply operating power.
To charge the MC75 battery:
1.
Connect the communication/charge cable power input connector to the approved power source.
2.
Slide the bottom of the MC75 into the connector end of the communication/charge cable and gently press in
until it latches into the MC75. The MC75 amber Charge LED indicates the MC75 battery charging status. The
3600 mAh battery fully charges in approximately five hours and the 4800 mAh battery fully charges in
approximately seven hours. See Table 1-2 on page 1-7 for charging status indications.
3.
When charging completes, remove the cable by gently pulling the MC75 and the cable apart.
LED Charge Indications
The amber Charge LED on the MC75 indicates battery charging status. See Table 1-2 on page 1-7 for charging
status indications.
Charging Temperature
Charge batteries in temperatures from 0°C to 40°C (32°F to 104°F). Charging is intelligently controlled by the
MC75.
To accomplish this, for small periods of time, the MC75 alternately enables and disables battery charging to keep
the battery at acceptable temperatures. The MC75 indicates when charging is disabled due to abnormal
temperatures via its LED. See Table 1-2 on page 1-7.
Communication Setup
To connect an MC75 communication/charge cable to a serial or USB device:
1.
Connect the serial/USB end of the MC75 communication/charge cable to the communication port of the
device.
2.
Connect the MC75 connector end of the cable to the MC75. For more information on communication setup
procedures, see Chapter 3, ActiveSync.
2 - 38 MC75 Integrator Guide
Chapter 3 ActiveSync
Introduction
To communicate with various host devices, install Microsoft ActiveSync (version 4.5 or higher) on the host
computer. Use ActiveSync to synchronize information on the mobile computer with information on the host
computer. Changes made on the mobile computer or host computer appear in both places after synchronization.
NOTE
When a mobile computer with Windows Mobile 6 is connected to a host computer and an ActiveSync
connection is made, the WLAN radio (if applicable) is disabled. This is a Microsoft security feature to prevent
connection to two networks at the same time.
ActiveSync software:
• Allows working with mobile computer-compatible host applications on the host computer. ActiveSync
replicates data from the mobile computer so the host application can view, enter, and modify data on the
mobile computer.
• Synchronizes files between the mobile computer and host computer, converting the files to the correct
format.
• Backs up the data stored on the mobile computer. Synchronization is a one-step procedure that ensures the
data is always safe and up-to-date.
• Copies (rather than synchronizes) files between the mobile computer and host computer.
• Controls when synchronization occurs by selecting a synchronization mode, e.g., set to synchronize
continually while the mobile computer is connected to the host computer, or set to only synchronize on
command.
• Selects the types of information to synchronize and control how much data is synchronized.
Installing ActiveSync
To install ActiveSync on the host computer, download version 4.5 or higher from the Microsoft web site at
http://www.microsoft.com. Refer to the installation included with the ActiveSync software.
3-2
MC75 Integrator Guide
Mobile Computer Setup
NOTE
Microsoft recommends installing ActiveSync on the host computer before connecting the mobile computer.
The mobile computer can be set up to communicate either with a USB connection. Chapter 2, Accessories
provides the accessory setup and cable connection information for use with the mobile computer. The mobile
computer communication settings must be set to match the communication settings used with ActiveSync.
1.
On the mobile computer tap Start > Programs > ActiveSync icon. The ActiveSync window appears.
Figure 3-1 ActiveSync Window
2.
Tap Menu > Connections.
3.
Select the connection type from the drop-down list.
4.
Tap OK to exit the Connections window and tap OK to exit the ActiveSync window.
5.
Proceed with installing ActiveSync on the host computer and setting up a partnership.
USB Configuration
To configure the USB connection for ActiveSync:
1.
Tap Start > Settings > System > USBConfig icon.
ActiveSync
Figure 3-2 USBConfig Window
2.
Ensure that the USB Client Mode radio button is selected.
3.
In the drop-down list, select ActiveSync.
4.
Tap Ok.
Setting Up an ActiveSync Connection on the Host Computer
To start ActiveSync:
1.
Select Start > Programs > Microsoft ActiveSync on the host computer. The ActiveSync Window displays.
Figure 3-3 ActiveSync Window
NOTE
2.
Assign each mobile computer a unique device name. Do not try to synchronize more than one mobile
computer to the same name.
In the ActiveSync window, select File > Connection Settings. The Connection Settings window appears.
3-3
3-4
MC75 Integrator Guide
Figure 3-4 Connection Settings Window
3.
Select the appropriate check box for the type of connection used.
4.
Select the Show status icon in Taskbar check box.
5.
Select OK to save any changes made.
Synchronization with a Windows Mobile 6 Device
NOTE
When a mobile computer with Windows Mobile 6 is connected to a host computer and an ActiveSync
connection is made, the WLAN radio (if applicable) is disabled. This is a Microsoft security feature to prevent
connection to two networks at the same time.
To synchronize with a Windows Mobile 6 device:
1.
If the Get Connected window does not appear on the host computer, select Start > All Programs > Microsoft
ActiveSync.
Figure 3-5 Synchronization Setup Wizard Window
2.
Click Next.
ActiveSync
Figure 3-6 Synchronization Directly With a Server Window
3.
Select the check box to synchronize with a server running Microsoft Exchange if applicable.
4.
Click Next.
Figure 3-7 Synchronization Option Window
5.
Select the appropriate settings and click Next.
3-5
3-6
MC75 Integrator Guide
Figure 3-8 Wizard Complete Window
6.
Click Finish.
Figure 3-9 ActiveSync Connected Window
During the first synchronization, information stored on the mobile computer is copied to the host computer. When
the copy is complete and all data is synchronized, the mobile computer can be disconnect from the host computer.
NOTE
The first ActiveSync operation must be performed with a local, direct connection. Windows Mobile retains
partnerships information after a cold boot.
For more information about using ActiveSync, start ActiveSync on the host computer, then see ActiveSync Help.
Chapter 4 Application Deployment for
Mobile 6
Introduction
This chapter describes new features in Windows Mobile 6 including new security features, how to package
applications, and procedures for deploying applications onto the MC75.
Security
The MC75 implement a set of security policies that determine whether an application is allowed to run and, if
allowed, with what level of trust. To develop an application, you must know the security configuration of the device,
and how to sign an application with the appropriate certificate to allow the application to run (and to run with the
needed level of trust).
Application Security
Application security controls the applications that can run on the MC75.
• Trusted - All applications must be digitally signed by a certificate on the MC75.
• Prompted - User is prompted to allow unsigned applications to run.
• Open - All applications run.
Developers can include their own certificates and provision the device to “trusted.”
Digital Signatures
Digital signatures provide a way to authenticate the author of EXEs, DLLs, and packages. Digitally signed
applications give users confidence that an application comes from where they think it comes from. For example, if
an end-user downloads an update package from the internet that is digitally signed with Zebra's software
certificate, they are assured that the package is authentic and that it was created by Zebra. By enforcing the use of
digital signatures, users can also prevent malicious applications from executing on the MC75. For example, users
can provision the MC75 to only execute “trusted” applications (digitally signed).
Zebra ships all Windows Mobile 6 based products in an “open” state, which means all signed and unsigned
applications should work. However, customers can still reconfigure their MC75s to operate in the “trusted” mode.
4-2
MC75 Integrator Guide
This means that only applications signed with a certificate from the Privileged Execution Trust Certificate Store can
run.
To support the broadest number of deployments, third-party software developers should perform the following
when releasing software for a Windows Mobile 6 devices:
• Sign all their EXEs & DLLs with their private key
• Provide the corresponding public certificate to end-users so that it can be installed into Privileged Execution
Trust Certificate Store.
If the software is installed via a .CAB file, developer should also:
• Sign the .CAB file with their private key
• Provide the corresponding public certificate to end-users so that it can be installed into SPC Certificate Store.
Locking Down a Mobile Computer
Like most configuration options in Windows Mobile 6, security settings are set via XML provisioning. For example,
to enforce the “trusted” model and only allow applications signed with a privileged certificate to run, use the
following provisioning document:
<wap-provisioningdoc>
<characteristic type=”SecurityPolicy”>
<!-- Disallow unsigned apps -->
<parm name= “4102” value= “0”/>
<!-- No Prompt -->
<parm name= “4122” value= “1”/>
</characteristic>
</wap-provisioningdoc>
For more information on various security options, refer to the Security Policy Settings topic in the latest Windows
Mobile documentation.
Application Deployment for Mobile 5.0
4-3
Installing Certificates
Use XML provisioning to query and delete certificates from certificate stores. To add a new certificate the Privileged
Execution Trust Certificate Store, use the following sample provisioning document:
<wap-provisioningdoc>
<characteristic type= “CertificateStore”>
<characteristic type= “Privileged Execution Trust Authorities”>
<characteristic type= “657141E12FA45786F6A57CA6464032D4B3A55475”>
<parm name= “EncodedCertificate” value= “
This is sample text. This is sample text. This is sample text. This is sample text.
This is sample text. This is sample text. This is sample text. This is sample text.
This is sample text. This is sample text. This is sample text. This is sample text. = “/>
</characteristic>
</characteristic>
</characteristic>
</wap-provisioningdoc>
To create your own provisioning document with real certificate information:
1.
Obtain a certificate from a security provider such as VeriSign.
2.
Double-click on the certificate file (.CER) to open it.
3.
Click on the Details tab and locate the Thumbprint field.
4.
Copy the contents of the Thumbprint field and replace the value in the XML example above.
5.
Click the Copy to File… button.
6.
Click Next to start the Certificate Export Wizard.
7.
Select Base-64 encoded X.509 (.CER) and then click Next.
8.
Set the File Name to CertOutput.xml and click Next.
9.
Click Finish to export the certificate.
10. Open the exported file, CertOutput.xml, in a text editor (i.e., NotePad).
11. Copy the contents of the file (excluding the first line, last line, and CR/LF) and replace the value of the
“EncodedCertificate” parameter in the xml example above.
Device Management Security
You can control access to certain device settings and security levels, such as installing applications and changing
security settings. Refer to the Windows Mobile Version 6 Help file for information on device management security.
Remote API Security
The Remote API (RAPI) enables applications that run on a desktop to perform actions on a remote device. RAPI
provides the ability to manipulate the file system on the remote device, including the creation and deletion of files
and directories. By default, Zebra ships with RAPI in the restricted mode. Certain tools, such as RAPIConfig, may
4-4
MC75 Integrator Guide
not work properly. Refer to the Windows Mobile Version 6 Help file for finding information on Remote API security
policies.
Packaging
NOTE
Applications compiled for Windows Mobile 6 are not backward-compatible with previous versions.
Packaging combines an application's executable files into a single file, called a package. This makes it easier to
deploy and install an application to the MC75. Package new applications and updates, such as new DLL files, as
CAB files, then deploy them to Mobile 6 devices. Refer to the Microsoft Windows Mobile 6 Help file for information
on CAB files.
Deployment
To install applications onto the MC75, developers package the application and all required files into a CAB file, then
load the file onto the MC75 using one of the following options:
• Microsoft ActiveSync 4.1 or higher
• Storage Card
• MSP 3.X
• AirBEAM
• Image Update (for updating the operating system).
Refer to the Microsoft Windows Mobile 6 Help file for information on CAB files.
Installation Using ActiveSync
To install an application package:
• Connect the MC75 to a host computer using ActiveSync. See Chapter 3, ActiveSync for more information.
• Locate the package file on the host computer.
• In ActiveSync on the host computer, open Explorer for the MC75.
• Copy the CAB file from the host computer to the \temp directory on the MC75.
• On the MC75, navigate to the \temp directory.
• Tap on the application CAB file. The application installs on the MC75.
Installation Using Storage Card
To install an application package:
• Copy the package CAB file to a storage card using an appropriate storage card reader.
• Install the storage card into the MC75. See Micro Secure Digital (microSD) Card on page 1-10 for more
information.
• On the MC75, open File Explorer.
Application Deployment for Mobile 5.0
4-5
• Open the Storage Card directory.
• Tap the package CAB file. The application installs on the MC75.
Installation Using AirBEAM
The AirBEAM Smart Client provides backward-compatible legacy AirBEAM functionality and backward-compatible
legacy MSP 2.x Level 2 Agent functionality.
Refer to the AirBEAM Smart Windows CE Client Product Reference Guide, p/n 72-63060-01, for instructions for
AirBEAM Smart client.
MSP 3.X
The MSP 3 Client Software is a set of software components that come pre-installed on the MC75. The MSP 3
Client software consists of the following components:
The RD Client provides support for MSP 3 Staging functionality, provides support for the MSP 3 Legacy Staging
process, and provides support for backward-compatible legacy MSP 2.x Legacy Staging functionality.
The MSP 3 Agent provides MSP 3 Provisioning functionality and Control functionality when used with MSP 3.2
Control Edition.
Refer to the Mobility Services Platform 3.2 User’s Guide, p/n 72E-100158-06, for instructions for using the Rapid
Deployment and MSP3 Agent clients.
Image Update
Windows Mobile 6 contains an Image Update feature that updates all operating system components. All updates
are distributed as update packages. Update packages can contain either partial or complete updates for the
operating system. Zebra distributes the update packages on the Support Central Web Site,
http://www.zebra.com/support.
To update an operating system component, copy the update package to the MC75 using one of a variety of
transports, including ActiveSync, an microSD memory card, or MSP. Then, initiate the update using one of the
following methods:
• Double-tap the package file in File Explorer (similar to extracting a CAB file)
• Perform a special boot sequence that initiates the update.
NOTE
The MC75 must have at least 5 MB of free space to perform an OS update.
To initiate an update:
1.
Go to the Support Central web site, http://www.zebra.com/support.
2.
Download the appropriate update package.
3.
Copy the update package to either the \temp directory on the MC75, or to a storage card.
4.
Connect the MC75 to AC power. See Chapter 2, Accessories.
5.
Simultaneously press the Power button and the 1 and 9 keys.
6.
Immediately, as soon as the device starts to boot and before the splash screen is visible, press and hold the
right scan button.
4-6
MC75 Integrator Guide
7.
The Update Loader application first looks for a file on a storage card. If it does not find it, it looks in the \temp
directory.
When it finds the appropriate file, it loads the package onto the MC75. A progress bar displays until the update
completes.
8.
The MC75 re-boots.
9.
The calibration screen appears.
NOTE
When initiating an update via a boot sequence, the update loader looks for updates first on the root of an
installed microSD card and then in the \temp folder on the MC75’s persistent storage volume. A response file,
pkgs.lst, indicates which files to update. In most cases, Zebra provides this pkgs.lst file with the update and
you should only modify it when updating a splash screen partition. See Creating a Splash Screen for more
information.
Creating a Splash Screen
Use a bitmap file to create a customized splash screens for the MC75. Use Image Update with a bitmap file, rather
than a package file, to update the splash screen.
To create a custom splash screen:
1.
Create a .bmp file using a graphic program with the following specifications:
• Size: 592 x 480.
• Colors: 16 bits per pixel (65536 colors) for color displays.
2.
Modify the bitmap file and save.
To load the splash screen on the MC75:
1.
Create a text file named pkgs.lst which contains the name of the bmp file. For example, mysplash.bmp.
2.
Copy the bmp file and the pkgs.lst file to one of the following:
• SD card root directory
• MC75’s \temp directory
• MC75’s \Windows directory.
3.
If using an SD card, insert the SD card into the MC75.
4.
Perform a cold boot.
5.
Press the trigger or side scan button for 5 seconds while booting to invoke the Update Loader and install the
splash screen.
XML Provisioning
To configure the settings on an MC75, use XML provisioning. To install an XML provisioning file on the MC75,
create a Cabinet Provisioning File (CPF). A CPF file is similar to a CAB file and contains just one file: _setup.xml.
Like a CAB file, the CPF extension is associated with WCELoad.EXE. Opening a CPF extracts the XML code and
uses it to provision and configure the MC75. The user receives an e-mail notification indicating success or failure.
XML provisioning provides the ability to configure various features of the MC75 (i.e., registry and file system).
However, some settings require security privileges. To change registry settings via a CPF file, you must have
Application Deployment for Mobile 5.0
4-7
certain privileges (roles). Some registry keys require you to simply be an Authenticated User, while other registry
keys require you to be a Manager. Refer to the Microsoft Windows Mobile 6 Help file, Metabase Settings for
Registry Configuration Service Provider section, for the default role settings in Windows Mobile 6.
For those registry settings that require the Manager role, the CPF file must be signed with a privileged certificate
installed on the device. Refer to the Microsoft Windows Mobile 6 Help file and the Windows Mobile 6 SDK for
instructions and sample test certificates.
Creating an XML Provisioning File
To create a .cpf file:
1.
Create a valid provisioning XML file named _setup.xml using an XML editor or the tools supplied with Visual
Studio 2005. (For example, use the SampleReg.xml sample created in the RegMerge section and rename it
_setup.xml.) Ensure the file contains the required parameters for the operation. Refer to the Microsoft Windows
Mobile 6 Help file for information.
2.
In the Windows Mobile 6 tools directory on the desktop computer (typically \Program Files\Windows CE
Tools\wce500\Windows Mobile 6 Pocket PC SDK\Tools), run the Makecab.exe utility, using the following
syntax to create a .cpf file from the _setup.xml file:
MakeCab.exe /D COMPRESS=OFF _setup.xml myOutCpf
NOTE
COMPRESS=OFF is required for backward compatibility with Pocket PC.
3.
Optionally, use the Authenticode tools to sign the .cpf file.
4.
Tap the filename to install.
5.
Certain applications and settings require a cold boot to take affect. In these cases, cold boot the MC75. Refer
to the Windows Mobile Version 6 Help file for more information.
XML Provisioning vs. RegMerge and Copy File
Prior to Windows Mobile 6, Zebra used two drivers (RegMerge and CopyFiles) to update the registry and to copy
files during a cold boot. With Mobile 6, Zebra recommends using XML provisioning instead. RegMerge and
CopyFiles are supported for backward compatibility but Zebra may eliminate support in the future. The following
sections provide examples of how RegMerge and CopyFiles were used, and how to perform the same function
using XML provisioning.
RegMerge
RegMerge.dll is a built-in driver that allows updating the registry during a clean boot. RegMerge runs very early in
the boot process and looks for registry files (.reg files) in certain Flash File System folders (i.e., \Application) during
a clean boot. It then merges the registry changes into the system registry located in RAM.
The following example uses RegMerge to set a registry key:
SampleReg.reg
[HKEY_LOCAL_MACHINE\Hardware\DeviceMap\Backlight]
“BacklightIntensity”=dword:00000036
The following example uses XML provisioning to perform the same task:
4-8
MC75 Integrator Guide
SampleReg.xml
<wap-provisioningdoc>
<characteristic type= “Registry”>
<characteristic type= “HKLM\Hardware\DeviceMap\Backlight”>
<parm name= “BacklightIntensity” value= “54” datatype= “integer” />
</characteristic>
</characteristic>
</wap-provisioningdoc>
CopyFiles
CopyFiles copies files from one folder to another on a clean boot. During a clean boot CopyFiles looks for files with
a .CPY extension in the root of the Application FFS partition. These files are text files containing the source and
destination for the desired files to copy, separated by “>”.
The following example uses CopyFiles to copy a file from the \Application folder to the \Windows folder:
SampleCpy.cpy
\Application\example.txt > \Windows\example.txt
The following example uses XML provisioning to perform the same task:
SampleCpy.xml
<wap-provisioningdoc>
<characteristic type= “FileOperation”>
<characteristic type= “\Windows” translation= “filesystem”>
<characteristic type= “MakeDir”/>
<characteristic type= “example.txt” translation= “fileystem”>
<characteristic type= “Copy”>
<parm name= “Source” value= “\Application\example.txt” translation= “filesystem”/>
</characteristic>
</characteristic>
</characteristic>
</characteristic>
</wap-provisioningdoc>
Storage
Mobile 6 contains three types of file storage:
• Random Access Memory (RAM)
• Persistent Storage
• Application folder.
Application Deployment for Mobile 5.0
4-9
Random Access Memory
Executing programs use RAM to store data. Data stored in RAM is lost upon a warm boot. RAM also included a
volatile file storage area called Cache Disk.
Volatile File Storage (Cache Disk)
Windows Mobile 6 memory architecture uses persistent storage for all files, registry settings, and database objects
to ensure data is retained even after a power failure. Persistent storage is implemented using Flash memory
technology which is generally slower than volatile RAM memory. In certain situations the speed of the operation is
more important than the integrity of the data. For these situations, Zebra has provided a small volatile File Storage
volume, accessed as the Cache Disk folder. Disk operations to the Cache Disk folder are much faster than to any
of the persistent storage volumes, but data is lost across warm boots and power interruptions. Note that a backup
battery powers RAM memory, including the Cache Disk, when you remove the main battery for a short period of
time.
The MC75 uses the Cache Disk for temporary data that can be restored from other sources, for example, for
temporarily “caching” HTML web pages by a browser or generating formatted files to send to a printer. Both
situations benefit from the increased speed of the cache disk, but you can restore the data if needed.
DO NOT use the Cache Disk as a method to improve application performance. Analyze applications that perform
slower in persistent storage to optimize disk access. Common areas for optimization include minimizing the
number of reads and writes to a file, removing unneeded debug logging, and minimizing file flushing or closing
files.
Persistent Storage
Windows Mobile 6 protects all data and applications from power-related loss. Because Windows Mobile 6 mounts
the entire file system and registry in persistent storage (rather than using RAM), MC75 devices provide a reliable
storage platform even in the absence of battery power.
Persistent storage provides application developers with a reliable storage system available through the standard
file system and registry APIs. Persistent storage is optimized for large reads and writes; therefore, applications
reading and writing data in large chunks tend to outperform those applications reading and writing small blocks of
data. Data in persistent storage is lost upon a clean boot.
Persistent storage contains all the directories under the root directory except for Application, Cache Disk, and
Storage Card (if a storage card is installed). Persistent storage is approximately 60 MB (formatted).
Application Folder
The Application folder is a super-persistent storage that is persistent even after a clean boot. Accessing data in the
Application folder is slower than accessing persistent storage. The Application folder is used for deployment and
device-unique data. For example, network profiles can be stored in the Application folder so that connection to the
network is available after a cold boot. The Application folder is approximately 20 MB (formatted).
Symbol Configuration Manager
Symbol Configuration Manager (SCM) is a utility that runs on the development computer and is used to create
configuration files. These files, when deployed to an MC75, set configuration parameters for that device. The
configurable options for a MC75 are defined in an XML file that is available on the Support Central
(http://www.zebra.com/support) for that MC75. SCM is also available on Support Central.
SCM eliminates the potential user errors that occur when manually editing registry settings.
4 - 10 MC75 Integrator Guide
File Types
SCM uses three types of files:
• Symbol Configuration Template (.SCT) files are XML files that define the configurable parameters for a
device.
• Registry Configuration Service Provider XML files for device provisioning.
• CAB Provisioning Format (.CPF) file which is a .CAB archive that contains the provisioning XML. This file is
downloaded to the MC75 and merged upon a cold boot.
User Interface
SCM's user interface consists of a tree control on the left side of the window which displays all the configuration
categories, and a data grid table on the right which displays all the configurable controls for the selected category.
Figure 4-1 shows the main window for a device’s .sct file.
Figure 4-1 Main SCM Window
Menu Functions
Use the main menu to access the program functionality described in Table 4-1.
Table 4-1 SCM Menu Functions
Menu Item
Description
File Menu
Open Config File
Open a saved configuration file (.SCD).
Save Config Changes
Save changes to the currently loaded configuration file.
Restore All Defaults
Restore all parameter values to the default state. The default values are stored in a
Symbol Configuration template file (i.e., MC75w.sct).
Application Deployment for Mobile 5.0 4 - 11
Table 4-1 SCM Menu Functions (Continued)
Menu Item
Description
Export Changes to .xml
Export the changed parameter values to an XML file.
Export Changes to .cpf
Export the changed parameter values to an CPF file.
Export all to .xml
Export all the parameter values to an XML file.
Export all to .cpf
Export all the parameter values to an CPF file.
Exit
Exit Symbol Configuration Manager.
Device Menu
Device type
Change the current device type template. Each template (available from the Support
Central) must reside in the SCM directory.
Help Menu
About
Display the About dialog which shows the application version.
Parameter State Indicators
The first column of the data table displays parameter state indicators. The state indicators display one of the states
in Table 4-2 for a particular parameter:
Table 4-2 Parameter Status Indicators
Icon
Indicator
Description
Modified
This parameter was changed from its initial factory setting.
Invalid
This parameter is not valid for the selected device type. This can occur when a
configuration file for one type of device is loaded and the device type is changed using
the Device menu. Values marked “invalid” are not included in an exported.
Window Status Bar
The SCM status bar found on the bottom right corner of the window contains the items in Table 4-3 from left to
right:
Table 4-3 Window Status Bar Items
Status Bar Item
Description
Invalid Count
Number of parameters not valid for the selected device.
Modified Count
Number of parameters modified from the factory defaults.
Device Type
Device type - version.
4 - 12 MC75 Integrator Guide
Figure 4-2 Sample Status Bar
The sample status bar in Figure 4-2 shows that the current configuration file contains 1 Invalid Parameter and 2
Modified Parameters.
File Deployment
The CPF file created by the SCM export function must be deployed to the MC75.
1.
Optionally, use the Authenticode tools to sign the .cpf file.
2.
Make the .cpf file read-only, then copy it to the MC75.
3.
Tap the filename to install.
4.
Certain applications and settings require a cold boot to take affect. In these cases, cold boot the MC75. Refer
to the Windows Mobile Version 6 Help file for more information.
Enterprise Mobility Developer Kits
The Enterprise Mobility Developer Kit (EMDK) family of products allows you to write applications that take
advantage of the capture, move and manage capabilities of the MC75. Go to the Support Central
(http://www.zebra.com/support) to download the appropriate developer kit.
Chapter 5 MC7506/96 - GSM Configuration
Introduction
This chapter explains how to verify MC7506 and MC7596 service on an Global System for Mobile communications
(GSM) wireless network and establish settings.
GSM networks deliver mobile voice and data services, such as Short Message Service (SMS)/Text Messaging,
with full roaming capabilities across the world. High-speed Downlink Packet Access (HSDPA) enabled networks
offer Internet-based content and packet-based data services. This enables services such as internet browsing,
e-mail on the move, powerful visual communications, multimedia messages, and location-based services.
When using the MC75 as a phone, services can include speed dialing, call tracking, voice mail, call forwarding,
conference calling, and caller ID, depending on the type of service.
Also use the integrated phone as a modem to connect the MC75 to an ISP or work network. The GSM enabled
MC75 can connect to the Internet or work network using Cellular Line, or using the modem specified by the mobile
phone service provider.
NOTE
Before using an MC75 on a wireless network, first select a provider, establish a voice and data-enabled service
plan, and configure the MC75 (where applicable). Refer to the MC75 User Guide for information on how to use
the phone and services.
Quick Startup Steps
To use the MC75 for phone and data connections:
1.
Install the MC75 main battery. See Installing the Main Battery on page 1-5.
2.
Fully charge the main battery and backup battery. See Charging the Battery on page 1-6.
3.
Press the red Power button to suspend the MC75.
4.
Remove the battery.
5.
Lift the SIM cover using the stylus tip.
5-2
MC75 Integrator Guide
SIM Cover
Figure 5-1 Lifting the SIM Cover
6.
Insert the SIM card, as shown in Figure 5-2, with the cut edge of the card facing out and the contacts facing
down.
Figure 5-2 Inserting the SIM Card
7.
Lower the SIM cover and use the stylus to slide it in place.
8.
Replace the battery and battery cover.
9.
Press the red Power button.
10. Tap Start > Phone > Menu > Options > Network tab and verify that the service provider appears in the Current
network: field. If the service provider name does not appear see Chapter 8, Maintenance and Troubleshooting
for more information.
11. Make a call to verify connection.
12. Start the MC75.
13. Ensure network coverage (page 5-3).
14. Configure a data connection (page 5-4).
NOTE
Data connection configuration is pre-packaged with T-Mobile service. Other service providers may require data
connection configuration.
15. Configure settings (page 5-8).
16. Use the phone.
MC7506/96 - GSM Configuration
5-3
MC7506/96 Service Verification
MC7506/96 phone and data services require a live SIM card, obtained from a service provider, installed in the
MC75 phone. The SIM card has embedded circuitry on one side of its surface which, when inserted into an MC75
phone, provides phone service. The SIM card provides a phone number, determines the features or services
available to the subscriber, and identifies the subscriber to the network.
In addition to SIM card installation, the MC75 may require various settings to operate as a phone with data
connection features.
Ensuring Network Coverage
1.
Ensure an activated SIM card, from the phone service provider, is installed in the MC75.
NOTE
2.
The SIM card must be enabled to connect to the network.
Verify active phone and data services by tapping
the dialog box.
to display the Phone dialog. The Carrier name appears in
Figure 5-3 Connectivity Dialog
3.
Verify SIM card functionality:
a.
Tap Start > Settings > Personal tab > Phone icon > Network tab.
Figure 5-4 Phone Settings Window - Network Tab
5-4
MC75 Integrator Guide
b.
Ensure the service provider’s network appears in the Current network: field.
c.
If the network does not appear, tap Find Network. If the network still does not appear, verify that the SIM
card was installed correctly. If it was, and no network appears, contact the service provider.
Configuring a Data Connection
A data connection allows Internet access across a wireless network.
To set up a new data connection:
1.
Acquire an Access Point Name (APN) from the service provider.
2.
Tap Start > Settings > Connections tab > Connections icon > Tasks tab.
Figure 5-5 Connections Window
3.
Under My ISP select Add a new modem connection.
Figure 5-6 Connections Window - Make New Connection
4.
Enter a connection name in the Enter a name for the connection: text box.
5.
Select Cellular Line (GPRS) from the Select a modem: drop-down list.
6.
Tap Next.
MC7506/96 - GSM Configuration
Figure 5-7 Connections Window - Access Point Name
7.
Enter the APN from the service provider in the Access point name: text box.
8.
Tap Next.
Figure 5-8 Connections Window - User Name & Password
9.
Enter a username in the User name text box, if required by the service provider.
10. Enter a password in the Password text box, if required by the service provider.
11. Enter a domain name in the Domain text box, if required by the service provider.
12. Tap Finish.
13. Tap ok to exit Connections.
Establishing a Data Connection
1.
Ensure a SIM card is installed in the MC75.
2.
Configure a GPRS data connection. See Configuring a Data Connection on page 5-4.
3.
Tap the connectivity icon
,
or
at the top of the screen.
5-5
5-6
MC75 Integrator Guide
Figure 5-9 Connectivity Dialog Box
4.
Tap Settings.
5.
Tap Connections icon.
6.
Tap Managing existing connections.
7.
Tap and hold on the data connection until a menu appears.
Figure 5-10 Data Connection
8.
Select Connect.
Figure 5-11 Connecting Using GPRS
MC7506/96 - GSM Configuration
9.
5-7
If the SIM card is protected with a Personal Identification Number (PIN), a dialog box pops up requesting the
appropriate PIN to unlock the SIM card. In this case, enter the PIN and tap ok.
NOTE
Place emergency calls at any time, without entering a PIN or a SIM card.
10. When a connection is established, launch Internet Explorer to browse the Internet or launch an applicable
application.
Ending a Data Connection
To cancel a data connection in progress, tap Cancel in the Connecting... dialog window.
To end an established data connection:
1.
Tap,
,
or
to display the Connectivity dialog box.
Figure 5-12 Connectivity Dialog Box
2.
Tap Disconnect.
NOTE
Tapping Disconnect during an active data transfer (e.g., downloading a web page) automatically reconnects
the connection. You cannot disconnect the connection until the data transfer is complete.
5-8
MC75 Integrator Guide
MC7506/96 Settings
Use the Phone Settings window to customize settings, such as the ring type and ring tone for incoming calls,
security options, and other options depending on the type of service.
Phone
Use the Phone tab to customize ring type, ring tone, keypad tone, and security options.
Tap Start > Settings > Personal tab > Phone icon > Phone tab
or
Start > Phone > Menu > Options > Phone tab.
Figure 5-13 MC75 Phone Window - Phone Tab
Sounds
1.
Phone Number automatically displays on the Phone tab when a live SIM card is installed.
2.
Select a ring type from the Ring type: drop-down list. The ring type changes the way the MC75 rings when you
receive an incoming call. Regardless of the ring type selected, a dialog box appears on the MC75’s display for
incoming calls.
3.
Select a ring tone for incoming calls from the Ring tone: drop-down list. To hear a sample of the selected ring
tone, tap
NOTE
4.
. Tap
to end the ring tone.
To use custom .wav, .mid, or .wma files as ring tones, use ActiveSync on the host computer to copy the file to
the /Windows/Rings folder on the MC75. Then select the sound from the ring tone list.
Select a keypad tone from the Keypad: drop-down list. This selection determines the tone that sounds when
entering a phone number on the keypad.
Select Short tones or Long tones to specify the duration of the sound when you press a number on the keypad.
Select Off to disable tones.
NOTE
Turning off sounds saves power and prolongs battery life.
MC7506/96 - GSM Configuration
5-9
Security
Enabling a PIN
NOTE
Place emergency calls at any time, without requiring a PIN or a SIM card.
To require a PIN when using the phone:
1.
From the Phone tab (Figure 5-13), select the Require PIN when phone is used check box under Security.
Figure 5-14 Enter PIN
2.
Use the touch keypad to enter a four to eight digit PIN.
3.
Tap Enter to enable the PIN and return to the Phone tab.
Changing a PIN
CAUTION
If you enter an incorrect PIN, the message “SIM PIN incorrect: Try again” appears. After three consecutive
incorrect attempts, the SIM card is blocked. The phone does not allow you to attempt to enter your PIN
again and you must obtain a PIN Unblock Key from your service provider.
1.
From the Phone tab (Figure 5-13), tap Change PIN.
2.
Use the touch keypad to enter the current PIN.
3.
Tap Enter.
4.
Use the touch keypad to enter a new four to eight digit PIN.
5.
Tap Enter.
6.
Reenter the new PIN for confirmation and tap Enter.
7.
Tap ok to confirm the change.
Disabling a PIN
1.
From the Phone tab (Figure 5-13), deselect the Require PIN when phone is used check box.
2.
Use the touch keypad to enter the current PIN.
3.
Tap Enter.
5 - 10 MC75 Integrator Guide
4.
Tap ok to confirm the change.
5.
Tap ok to exit settings.
Services
Use the Services tab to configure settings for subscribed phone services. For example, block certain types of
incoming and/or outgoing calls (page 5-10), disclose the caller’s identity when making outgoing calls (page 5-11),
forward incoming calls to a different phone number (page 5-11), receive notification of incoming calls when a phone
session is in use (page 5-12), and set up voice mail and short message service (page 5-12).
1.
Tap Start > Settings > Personal tab > Phone icon > Services tab.
or
Start > Phone > Menu > Options > Services tab.
Figure 5-15 MC75 Phone Window - Services Tab
2.
Select a service from the list and tap Get Settings... .
3.
Change services settings as follows.
Call Barring (Call Blocking)
Use call barring to block certain types of incoming and/or outgoing calls. Select the type of incoming and/or
outgoing calls to block.
Figure 5-16 Call Barring/Call Blocking
MC7506/96 - GSM Configuration 5 - 11
Caller ID
Enable caller ID to reveal the identity of the person making an outgoing call. Select the Everyone radio button to
always display the caller ID. Select the No one radio button to prevent the caller’s identity from appearing to others.
Figure 5-17 Caller ID
Call Forwarding
NOTE
Call Forwarding may not be available on all networks. Check with your service provider for availability.
Use call forwarding to forward incoming calls to a different phone number.
• To forward all calls to a different phone number:
• select the Forward all incoming phone calls check box.
• enter the phone number to receive forwarded calls in the To: text box.
• To forward incoming calls to a different phone number based on a specific situation, select one or more of the
check boxes under Forward phone calls only if:.
• No answer: enter the phone number to receive forwarded calls only when the phone cannot be answered.
Then select a time period from the Forward after: drop-down list. Options are 5, 10, 15, 20, 25, and 30
seconds.
• Unavailable: enter the phone number to receive forwarded calls only when the phone is turned off or the
user is unreachable.
• Busy: enter the phone number to receive forwarded calls only when the line is busy.
5 - 12 MC75 Integrator Guide
Figure 5-18 Call Forwarding
Call Waiting
NOTE
Call Waiting may not be available on all networks. Check with your service provider for availability.
Call waiting notifies you of an incoming call when the phone is in a phone session. Select the Notify me radio button
to enable call waiting. Select the Do not notify me radio button to disable call waiting.
Figure 5-19 Call Waiting
Voice Mail and Text Messages
To use voice mail and send short messages, enter the voice mail and/or text message phone number in the
appropriate text boxes.
MC7506/96 - GSM Configuration 5 - 13
Figure 5-20 Voice Mail and Text Messages
Fixed Dialing
Use Fixed Dialing to restrict the phone to dial only the phone number(s) or area code(s) specified in a Fixed Dialing
list.
1.
Select Fixed Dialing and tap Get Settings.
Figure 5-21 Fixed Dialing Window
2.
Select the Enable fixed dialing check box.
3.
To add a number to the list, tap Menu > Add.
4.
Enter the phone number or area code to restrict and tap Done.
5.
Repeat steps 3 and 4 to add more numbers, and tap Done twice when complete.
6.
Enter PIN2 and tap Done.
Network
Use the Network tab to view available networks, determine the order in which the phone accesses another network
if the current network is unavailable, and specify whether to change networks manually or automatically. The
current network remains active until it’s changed, the signal is lost, or the SIM card is changed.
The network the MC75 currently uses appears in the Current network: field at the top of the window.
5 - 14 MC75 Integrator Guide
Changing Networks Manually
1.
Tap Start > Settings > Personal tab > Phone icon > Network tab
or
Start > Phone > Menu > Options > Network tab.
Figure 5-22 MC75 Phone Window - Network Tab
2.
From the Network selection drop-down list, select Manual.
Figure 5-23 Choose Network
3.
From the Choose Network window, select the network to use.
4.
Tap OK.
Viewing Available Networks
To view all wireless networks available:
1.
Tap Start > Settings > Personal tab > Phone icon > Network tab.
or
Start > Phone > Options > Network tab.
MC7506/96 - GSM Configuration 5 - 15
Figure 5-24 MC75 Phone Window - Network Tab
2.
Tap Find Network.
Figure 5-25 Choose Network
3.
From the Choose Network window, select the network to use.
4.
Tap OK.
Setting Preferred Networks
Set networks in a preferred order of access. Setting preferred networks allows the MC75 to access a second
preferred network if the first is unavailable.
1.
Tap Start > Settings > Personal tab > Phone icon > Network tab
or
Start > Phone > Menu > Options > Network tab.
Figure 5-26 MC75 Phone Window - Network Tab
5 - 16 MC75 Integrator Guide
2.
Tap Set Networks to view all available networks.
Figure 5-27 Preferred Networks
3.
Select the preferred networks by tapping one or more check boxes.
4.
Tap Move Up and Move Down, as necessary, to place the selected networks in the preferred order.
5.
Tap ok to send the new settings to the network.
6.
From the Network tab, select Automatic from the Network selection drop-down list.
7.
Tap ok to exit settings.
Phone Info
Use the Phone Info tab to view hardware and software information about the phone.
1.
Tap Start > Settings > Personal tab > Phone icon > Phone Info tab
or
Start > Phone > Menu > Options > Phone Info tab.
Figure 5-28 MC75 Phone Window - Phone Info Tab
2.
Tap ok to exit settings.
MC7506/96 - GSM Configuration 5 - 17
Network Time Synchronization
The MC75 can be configured to synchronize the clock with the time from the carrier network. A registry key on the
MC75 has to be created to enable this feature.
Using a registry editor, navigate to the following:
[HKEY_LOCAL_MACHINE\SOFTWARE\Symbol\RIL\RHA\HC25]
Create the following key:
“SyncSystemTime”=dword:00000001
where:
dword:0 = disabled
dword:1 = enabled
After setting the registry key, warm boot the MC75.
Enhanced Operator Name String
The MC75 is enabled to download and display the name of the GSM network currently logged in to. Four registry
keys on the MC75 have to be edited to disable this feature.
Using a registry editor, navigate to each of the following:
[HKEY_LOCAL_MACHINE\Software\Microsoft\RIL]
[HKEY_LOCAL_MACHINE\Software\Microsoft\RIL\Configurations\GSM_HC25]
[HKEY_LOCAL_MACHINE\Comm\Cellular\Ril]
[HKEY_LOCAL_MACHINE\Comm\Cellular\Ril\Configurations\GSM_HC25]
Edit the following key:
“EonsEnable”=dword:1
where:
dword:0 = disabled
dword:1 = enabled (default)
After setting the registry key, warm boot the MC75.
Service Provider Name Display
The reg key (“UseServiceProviderName”) originally was used to fix the dual-line SIM card issue with value 2. But
for the Italian Post, the value 1 should be used to show the virtual carrier name (Poste Mobile).
[HKEY_LOCAL_MACHINE\Software\Microsoft\RIL]
“UseServiceProviderName”=dword:1
5 - 18 MC75 Integrator Guide
where:
dword:0 = Display provider name
dword:1 - Display service provider name (default)
dword:2 - Display both provider and service provider name
Chapter 6 MC7508/98 - CDMA Configuration
Introduction
This chapter explains how to activate an MC7508 or MC7598 on a Code Division Multiple Access (CDMA) wireless
network and establish settings.
CDMA is a form of wireless multiplexing in which data (e.g., Short Message Service) can be sent over multiple
frequencies simultaneously, optimizing the use of available bandwidth. In an CDMA system data is broken into
packets, each of which are given a unique identifier, so that they can be sent out over multiple frequencies and
then re-built in the correct order by the receiver.
When using the MC75 as a phone, services can include speed dialing, call tracking, voice mail, call forwarding,
conference calling and caller ID, depending on the type of service.
The integrated phone in the MC75 can also be used as a modem to connect the MC75 to an ISP or work network.
The MC75 can connect to the Internet or work network using Cellular Line, or using the modem specified by the
mobile phone service provider.
NOTE
Before the MC75 can be used on a CDMA wireless network, a provider must be selected, a voice and
data-enabled service plan must be established and the MC75 must be properly configured (where applicable).
Refer to the MC75 User Guide for information on how to use the phone and services.
Quick Startup Steps
To start using the MC75 for phone and data connections:
1.
Install the main battery (Installing the Main Battery on page 1-5).
2.
Charge the main battery and backup battery (Charging the Battery on page 1-6).
3.
Start the MC75 (see Powering On the MC75 on page 1-8).
4.
Activate the phone (CDMA Phone Activation on page 6-2).
5.
Configure settings (CDMA Settings on page 6-7).
6.
Use the phone.
6-2
MC75 Integrator Guide
CDMA Phone Activation
CDMA phone service is available from a number of service providers including Sprint®, Verizon Wireless®, Alltel,
Bell Mobility and Telus. In addition to service activation for each provider, various settings may be required for the
MC75 to operate as a phone. There can be different Activation Wizards depending upon the carrier. Verizon
Wireless and Sprint use an automatic activation processes. All other carriers use the manual activation process.
Verizon Wireless Activation
The Activation Wizard allows automatic activation. To activate the MC75 using the automated service, the MC75
attempts to call the network on a special number that automatically downloads the phone number and identification
codes from the network.
Verizon Wireless automatically downloads the provisioning data. This process is invisible to the user and occurs
once, after account activation, during the first data connection attempt.
NOTE
After an MC75 is provisioned for Verizon Wireless service, it is strongly recommended that no other service
provider loads are downloaded to the MC75 and no changes are made to any of the provisioning information.
To activate the phone using the Verizon Wireless automated service:
1.
Ensure the MC75 is in a strong signal area.
2.
The Activation Wizard automatically starts whenever the phone is turned on. If the wizard does not appear, tap
Start > Phone > Menu > Activation Wizard... .
Figure 6-1 Verizon Activation Wizard
3.
Tap Auto to connect to the Verizon Wireless Network to automate activation. Automated activation provides all
required codes and identification numbers over the network. No additional activation setup is required.
4.
Tap Finish to close the Activation Wizard.
NOTE
5.
If activation was not successful, contact the service provider.
The phone can be used in approximately four hours, depending on the network provider load.
MC7508/98 - CDMA Configuration
6-3
Sprint Activation
To activate the phone using Sprint service:
1.
Ensure the MC75 is in a strong signal area.
2.
The Activation Wizard automatically starts whenever the phone is turned on. If the wizard does not appear, tap
Start > Phone > Menu > Activation Wizard... .
Figure 6-2 One Touch Activation Wizard
3.
Tap Yes. Automatic provisioning begins.
Figure 6-3 Provisioning in Process
NOTE
4.
If activation was not successful, contact the service provider.
Tap OK to close the application.
Manual Activation
To activate the phone:
1.
Ensure the MC75 is in a strong signal area.
2.
The Activation Wizard automatically starts whenever the phone is turned on. If the wizard does not appear, tap
Start > Phone > Menu > Activation Wizard... .
6-4
MC75 Integrator Guide
1.
Tap Manual.
2.
Enter the 6-digit activation code from your service provider.
3.
Tap Next >.
Figure 6-4 Activation Wizard - MDN and MSID
4.
Enter the MDN and MSID. The MDN and MSID are the area code and phone number received from the service
provider.
5.
Tap Next >.
Figure 6-5 Activation Wizard - Confirmation
6.
Verify that the MDN and MSIN numbers entered are correct, tap Yes to confirm.
MC7508/98 - CDMA Configuration
Figure 6-6 Activation Wizard - Activation Complete
NOTE
7.
If activation was not successful, contact the service provider.
Tap Finish to complete activation. The phone can be used in approximately four hours.
Activation Test
Approximately four hours after activation is completed, test the service.
1.
Tap Start > Phone.
Figure 6-7 Phone Window - Example
2.
Ensure the carrier name displays on the window.
3.
Make a voice call to ensure activation was successful.
NOTE
If activation was not successful, contact the service provider.
6-5
6-6
MC75 Integrator Guide
Establishing a Data Connection
NOTE
Ensure that you have data service activated with your service provider.
A data connection allows Internet access across a wireless network. Data connection is pre-packaged with service
accounts.
To verify active data service:
1.
Tap Start > Internet Explorer.
2.
In the address bar, enter a URL for a web site.
3.
Tap
to display the Connectivity dialog. The dialog box displays the data connection information.
Figure 6-8 Data Connection
MC7508/98 - CDMA Configuration
6-7
CDMA Settings
Use the Phone Settings window to customize CDMA phone settings, such as the ring type and ring tone for
incoming calls and other options depending on the type of service.
Phone
Use the Phone tab to customize ring type, ring tone and keypad tone when entering phone numbers.
1.
Tap Start > Settings > Personal tab > Phone icon > Phone tab.
or
Start > Phone > Menu > Options > Phone tab.
Figure 6-9 Phone Window - Phone Tab
2.
Phone and voicemail phone numbers automatically display when phone service is activated.
3.
Select a ring type from the Ring type: drop-down list. The ring type changes the way the MC75 rings to notify
the user of an incoming call. Regardless of the ring type selected, a dialog box appears on the display for
incoming calls.
4.
Select a ring tone for incoming calls from the Ring tone: drop-down list. To hear a sample of the selected ring
tone, tap
NOTE
5.
. Tap
to end the ring tone.
To use custom .wav, .mid or .wma files as ring tones, use ActiveSync on the host PC to copy the file to the
/Windows/Rings folder on the MC75. Then, select the sound from the ring tone list.
Select a keypad tone from the Keypad: drop-down list. This selection determines the tone that sounds when
entering a phone number on the keypad.
a.
Select Short Tones for a tone that sounds only for one or two seconds.
b.
Select Long Tones for a continuous sound for as long as the number on the keypad is pressed.
c.
Select Off to disable tones.
6.
Tap Other Settings... to set additional sounds and notifications for the MC75.
7.
Select the Notify me when voice privacy is unavailable check box to receive a message when dialing.
6-8
MC75 Integrator Guide
8.
Tap ok to exit settings.
NOTE
Turning off sounds saves power and prolongs battery life.
Location Settings
Use the Location tab to allow the network to detect the position of the MC7595’s radio.
1.
Tap Start > Settings > Personal tab > Phone icon > Location Settings tab.
or
Start > Phone > Menu > Options > Location Settings tab.
Figure 6-10 Phone Window - Location Tab (Typical)
2.
Select the Location ON radio button to allow the network to detect the position of the MC75’s radio.
or
Select the 911 Only button to turn off location detection, hiding the location of the radio from all but 911
emergency service.
3.
Tap ok to confirm Location ON or 911 Only.
4.
Tap ok again to exit settings.
Data Settings
Sprint Data Settings
Use the Data Settings tab to reset connection settings for PCS Vision and update the Vision profile, and to start
IP-based Over-The-Air (IOTA) provisioning.
1.
Tap Start > Settings > Personal tab > Phone icon > Data Settings tab.
or
Start > Phone > Menu > Options > Data Settings tab.
MC7508/98 - CDMA Configuration
Figure 6-11 Phone Window - Sprint Data Tab
2.
Tap Repair Connectiod to reset PCS Vision connection settings.
Figure 6-12 Reset Connection Settings Dialog
3.
Tap Yes.
Figure 6-13 Reset Connection Completed Dialog
4.
Tap ok.
5.
Tap Provision to manually start IP-based Over-The-Air (IOTA) provisioning.
6-9
6 - 10 MC75 Integrator Guide
IOTA is used to provision various data elements such as Wireless Application Protocol (WAP) configuration
parameters and roaming lists to the MC75 over-the-air. It is also used to provision other elements such as
applications and firmware.
6.
Tap ok to exit.
Verizon Wireless Data Settings
Use the Data tab to reset connection settings for national access.
1.
Tap Start > Settings > Personal tab > Phone icon > Data Settings tab.
or
Start > Phone > Menu > Options > Data Settings tab.
Figure 6-14 Phone Window - Verizon Data Tab
2.
Tap Repair Connectoid to reset connection settings for National Access.
3.
Tap Yes.
4.
Tap ok.
5.
Tap ok to exit settings.
Additional Service provider Data Settings
Use the Data tab to reset connection settings for the 3G connection.
1.
Tap Start > Settings > Personal tab > Phone icon > Data Settings tab.
or
Start > Phone > Menu > Options > Data Settings tab.
MC7508/98 - CDMA Configuration 6 - 11
Figure 6-15 Phone Window - Data Tab
2.
Tap Reset Connection to reset connection settings for the 3G connection.
3.
Tap Yes.
4.
Tap ok.
5.
Tap ok to exit settings.
System Settings
Use the System Settings tab to select roaming options.
Tap Start > Settings > Personal tab > Phone icon > System Settings tab.
or
Tap Start > Phone > Menu > Options > System tab.
Sprint System
Sprint
Figure 6-16 Phone Window - System Settings Tab - Sprint
1.
Roaming:
6 - 12 MC75 Integrator Guide
• Select the Automatic radio button to allow the phone to automatically seek a roaming network where the
Sprint Nationwide PCS Network is not available. Automatic roaming is available where Sprint implemented
roaming with other wireless carriers.
• Select the Sprint radio button to allow the phone to automatically seek a roaming network within the Sprint
Nationwide PCS Network only.
• Select Roaming Only radio button to allow the phone to automatically seek a roaming network.
2.
Select the Enable Call Guard alert when roaming check box to control roaming charges by receiving a reminder
when a roaming call is made or received. When a roaming call is made or received, Roaming rate applies for
this call. Press OK to dial. appears on the MC75 display screen.
3.
Tap ok to exit settings.
Verizon System
Figure 6-17 Phone Window - System Settings Tab - Verizon
1.
System Select allows the user to change the system roaming preference of the radio in order to control the
type of network the radio can lock onto for service.
• Select the Automatic radio button to allow the radio to lock onto networks based on the provisioning of the
radio.
• Select the Automatic A or Automatic B radio button to allow the radio to lock onto an A or B network carrier,
respectively, if no other network can be found that matches the radio's provisioning.
• Select the Home Only radio button to prevent the radio from locking on any network that is considered a
roaming network.
2.
Voice Privacy allows the user to enable or disable voice privacy.
• Select the Enhanced radio button to trigger the network to use voice privacy whenever the current network
supports it. When in a call, if network privacy is being used, a voice privacy icon is displayed in the user
interface.
• Select the Standard radio button to prevent voice privacy from being used when in a call.
3.
Tap ok to exit settings.
MC7508/98 - CDMA Configuration 6 - 13
Additional Service Provider System
Figure 6-18 Phone Window - System Settings Tab - Additional
1.
System Select allows the user to change the system roaming preference of the radio in order to control the
type of network the radio can lock onto for service.
• Select the Automatic radio button to allow the radio to lock onto networks based on the provisioning of the
radio.
• Select the Home Only radio button to prevent the radio from locking on any network that is considered a
roaming network.
2.
Voice Privacy allows the user to enable or disable voice privacy.
• Select the Enhanced radio button to trigger the network to use voice privacy whenever the current network
supports it. When in a call, if network privacy is being used, a voice privacy icon is displayed in the user
interface.
• Select the Standard radio button to prevent voice privacy from being used when in a call.
3.
Tap ok to exit settings.
Version Information
Use the Version Information tab to view phone number and version information.
1.
Tap Start > Settings > Personal tab > Phone icon > Version Information tab.
or
Start > Phone > Menu > Options > Version Information tab.
6 - 14 MC75 Integrator Guide
Figure 6-19 Phone Window - Version Information Tab
2.
Tap ok to exit settings.
Services
Depending on the type of subscribed phone services, the following services may be available: call barring, caller
ID, call forwarding, call waiting, voice mail and Short Message Service (SMS).
Call Barring (Call Blocking)
Call barring blocks certain types of incoming and/or outgoing calls. This service is setup when an account is
opened with the service provider.
Caller ID
Caller ID provides a way for people to know the identity of the person making an outgoing call. To disable caller ID
and block the outgoing phone number:
1.
Enter *67 on the phone keypad.
2.
Enter the phone number to call.
NOTE
*67, followed by the phone number, must be entered on a call-by-call basis to block the outgoing phone
number.
Call Forwarding
NOTE
Call Forwarding may not be available on all networks. Check with your service provider for availability.
Use call forwarding to forward incoming calls to a different phone number. To enable call forwarding and send calls
to another phone number:
1.
Enter *72 on the phone keypad.
2.
Enter the area code and phone number of the phone to accept the forwarded calls.
3.
Tap Talk.
4.
A beep sounds indicating activation.
5.
Tap End.
MC7508/98 - CDMA Configuration 6 - 15
To disable call forwarding:
1.
Enter *73 (Verizon Wireless) on the phone keypad.
2.
Tap Talk.
3.
A beep sounds indicating deactivation.
4.
Tap End.
Call Waiting
NOTE
Call Waiting may not be available on all networks. Check with your service provider for availability.
Call waiting notifies the user of an incoming call when the phone is in a phone session. This service is setup when
an account is opened with the service provider.
Voice Mail and Short Message Service (SMS)
This service is setup when an account is opened with the service provider.
Network Time Synchronization
The MC75 can be configured to synchronize the clock with the time from the carrier network. A registry key on the
MC75 has to be created to enable this feature.
Using a registry editor, navigate to the following:
[HKEY_LOCAL_MACHINE\SOFTWARE\Symbol\RIL\RHA\MC5725]
Create the following key:
“SyncSystemTime”=dword:00000001
where:
dword:0 = disabled
dword:1 = enabled
After setting the registry key, warm boot the MC75.
6 - 16 MC75 Integrator Guide
Chapter 7 Wireless Applications
Introduction
Wireless Local Area Networks (LANs) allow mobile computers to communicate wirelessly and send captured data
to a host device in real time. Before using the MC75 on a WLAN, the facility must be set up with the required
hardware to run the wireless LAN and the MC75 must be configured. Refer to the documentation provided with the
access points (APs) for instructions on setting up the hardware.
802.11d is enabled by default. When enabled, the AP must be configured the same in order to connect.
To configure the MC75, a set of wireless applications provide the tools to configure and test the wireless radio in
the MC75. Refer to the Wireless Fusion Enterprise Mobility Suite User Guide for Version X.XX for information on
configuring wireless profiles; where X.XX is the Fusion version. Go to http://www.zebra.com/support for the latest
version of this guide. See Software Versions on page xiv to determine the Fusion version on the MC75.
The Wireless Application menu on the task tray provides the following wireless applications:
• Find WLANs
• Manage Profiles
• Manage Certs
• Manage PACs
• Options
• Wireless Status
• Wireless Diagnostics
• Log On/Off
• Enable/Disable Radio.
Tap the Signal Strength icon to display the Wireless Applications menu.
7-2
MC75 Integrator Guide
Figure 7-1 Wireless Applications Menu
Signal Strength Icon
The Signal Strength icon in the task tray indicates the MC75’s wireless signal strength as follows:
Table 7-1 Signal Strength Icons Descriptions
Icon
None
Status
Action
Excellent signal strength
Wireless LAN network is ready to use.
Very good signal strength
Wireless LAN network is ready to use.
Good signal strength
Wireless LAN network is ready to use.
Fair signal strength
Wireless LAN network is ready to use. Notify the network
administrator that the signal strength is only “Fair”.
Poor signal strength
Wireless LAN network is ready to use. Performance may not be
optimum. Notify the network administrator that the signal strength is
“Poor”.
Out-of-network range (not
associated)
No wireless LAN network connection. Notify the network
administrator.
No wireless LAN network card
detected
No wireless LAN network card detected, Wireless LAN disabled or
radio disabled. Notify the network administrator.
No wireless LAN network card
detected or Wireless LAN
disabled
No wireless LAN network card detected or Wireless LAN disabled or
radio disabled. Notify the network administrator.
Wireless Applications
Turning the WLAN Radio On and Off
To turn the WLAN radio off tap the Signal Strength icon and select Disable Radio.
Figure 7-2 Disable Radio
To turn the WLAN radio on tap the Signal Strength icon and select Enable Radio.
Figure 7-3 Enable Radio
7-3
7-4
MC75 Integrator Guide
Chapter 8 Maintenance and Troubleshooting
Introduction
This chapter includes instructions on cleaning and storing the MC75, and provides troubleshooting solutions for
potential problems during MC75 operation.
Maintaining the MC75
For trouble-free service, observe the following tips when using the MC75:
• Do not scratch the screen of the MC75. When working with the MC75, use the supplied stylus or
plastic-tipped pens intended for use with a touch-sensitive screen. Never use an actual pen or pencil or other
sharp object on the surface of the MC75 screen.
Zebra recommends using a screen protector, p/n KT-67525-01R.
• The touch-sensitive screen of the MC75 is glass. Do not drop the MC75 or subject it to strong impact.
• Protect the MC75 from temperature extremes. Do not leave it on the dashboard of a car on a hot day, and
keep it away from heat sources.
• Do not store or use the MC75 in any location that is dusty, damp, or wet.
• Use a soft lens cloth to clean the MC75. If the surface of the MC75 screen becomes soiled, clean it with a soft
cloth moistened with a diluted window-cleaning solution.
• Periodically replace the rechargeable battery to ensure maximum battery life and product performance.
Battery life depends on individual usage patterns.
8-2
MC75 Integrator Guide
• A screen protector is applied to the MC75. Zebra recommends using this to minimize wear and tear. Screen
protectors enhance the usability and durability of touch screen displays. Benefits include:
• Protection from scratches and gouges
• Durable writing and touch surface with tactile feel
• Abrasion and chemical resistance
• Glare reduction
• Keeping the device’s screen looking new
• Quick and easy installation.
Battery Safety Guidelines
• The area in which the units are charged should be clear of debris and combustible materials or chemicals.
Particular care should be taken where the device is charged in a non commercial environment.
• Follow battery usage, storage, and charging guidelines found in the user's guide.
• Improper battery use may result in a fire, explosion, or other hazard.
• To charge the mobile device battery, the battery and charger temperatures must be between +32°F and
+104°F (0°C and +40°C)
• Do not use incompatible batteries and chargers. Use of an incompatible battery or charger may present a risk
of fire, explosion, leakage, or other hazard. If you have any questions about the compatibility of a battery or a
charger, contact Zebra support.
• For devices that utilize a USB port as a charging source, the device shall only be connected to products that
bear the USB-IF logo or have completed the USB-IF compliance program.
• To enable authentication of an approved battery, as required by IEEE1725 clause 10.2.1, all batteries will
carry a Zebra hologram. Do not fit any battery without checking it has the Zebra authentication hologram.
• Do not disassemble or open, crush, bend or deform, puncture, or shred.
• Severe impact from dropping any battery-operated device on a hard surface could cause the battery to
overheat.
• Do not short circuit a battery or allow metallic or conductive objects to contact the battery terminals.
• Do not modify or remanufacture, attempt to insert foreign objects into the battery, immerse or expose to water
or other liquids, or expose to fire, explosion, or other hazard.
• Do not leave or store the equipment in or near areas that might get very hot, such as in a parked vehicle or
near a radiator or other heat source. Do not place battery into a microwave oven or dryer.
• Battery usage by children should be supervised.
• Please follow local regulations to promptly dispose of used re-chargeable batteries.
• Do not dispose of batteries in fire.
• Seek medical advice immediately if a battery has been swallowed.
• In the event of a battery leak, do not allow the liquid to come in contact with the skin or eyes. If contact has
been made, wash the affected area with large amounts of water and seek medical advice.
• If you suspect damage to your equipment or battery, contact Zebra support to arrange for inspection.
Maintenance & Troubleshooting
8-3
Cleaning
CAUTION
Always wear eye protection.
Read warning label on compressed air and alcohol product before using.
If you have to use any other solution for medical reasons please contact Zebra for more information.
WARNING!
Avoid exposing this product to contact with hot oil or other flammable liquids. If such exposure
occurs, unplug the device and clean the product immediately in accordance with these guidelines.
Materials Required
• Alcohol wipes
• Lens tissue
• Cotton tipped applicators
• Isopropyl alcohol
• Can of compressed air with a tube.
Cleaning the MC75
Housing
Using the alcohol wipes, wipe the housing including keys and in-between keys.
Display
The display can be wiped down with the alcohol wipes, but care should be taken not to allow any pooling of liquid
around the edges of the display. Immediately dried the display with a soft, non-abrasive cloth to prevent streaking.
Scanner Exit Window
Wipe the scanner exit window periodically with a lens tissue or other material suitable for cleaning optical material
such as eyeglasses.
Connector
1.
Remove the main battery from mobile computer. See Installing the Main Battery on page 1-5.
2.
Close battery door.
3.
Dip the cotton portion of the cotton tipped applicator in isopropyl alcohol.
4.
Rub the cotton portion of the cotton tipped applicator back-and-forth across the connector on the bottom of the
MC75. Do not leave any cotton residue on the connector.
5.
Repeat at least three times.
6.
Use the cotton tipped applicator dipped in alcohol to remove any grease and dirt near the connector area.
7.
Use a dry cotton tipped applicator and repeat steps 4 through 6.
8-4
MC75 Integrator Guide
8.
Spray compressed air on the connector area by pointing the tube/nozzle about ½ inch away from the surface.
CAUTION: Do not point nozzle at yourself and others, ensure the nozzle or tube is away from your face.
9.
Inspect the area for any grease or dirt, repeat if required.
Cleaning Cradle Connectors
To clean the connectors on a cradle:
1.
Remove the DC power cable from the cradle.
2.
Dip the cotton portion of the cotton tipped applicator in isopropyl alcohol.
3.
Rub the cotton portion of the cotton tipped applicator along the pins of the connector. Slowly move the
applicator back-and-forth from one side of the connector to the other. Do not let any cotton residue on the
connector.
4.
All sides of the connector should also be rubbed with the cotton tipped applicator.
5.
Spray compressed air in the connector area by pointing the tube/nozzle about ½ inch away from the surface.
CAUTION: do not point nozzle at yourself and others, ensure the nozzle or tube is pointed away from your
face.
6.
Ensure that there is no lint left by the cotton tipped applicator, remove lint if found.
7.
If grease and other dirt can be found on other areas of the cradle, use lint free cloth and alcohol to remove.
8.
Allow at least 10 to 30 minutes (depending on ambient temperature and humidity) for the alcohol to air dry
before applying power to cradle.
If the temperature is low and humidity is high, longer drying time is required. Warm temperature and dry
humidity requires less drying time.
Cleaning Frequency
The cleaning frequency is up to the customer’s discretion due to the varied environments in which the mobile
devices are used. They may be cleaned as frequently as required. However when used in dirty environments it
may be advisable to periodically clean the scanner exit window to ensure optimum scanning performance.
Maintenance & Troubleshooting
8-5
Troubleshooting
MC75
Table 8-1 Troubleshooting the MC75
Problem
MC75 does not turn
on.
Cause
Solution
Lithium-ion battery
not charged.
Charge or replace the lithium-ion battery in the MC75.
Lithium-ion battery
not installed
properly.
Ensure battery is installed properly. See Installing the Main
Battery on page 1-5.
System crash.
Perform a warm boot. If the MC75 still does not turn on, perform
a cold boot. See Resetting the MC75 on page 1-8.
Battery failed.
Replace battery. If the MC75 still does not operate, perform a
warm boot, then a cold boot. See Resetting the MC75 on page
1-8.
MC75 removed from
cradle while battery
was charging.
Insert MC75 in cradle. The 3600 mAh battery fully charges in less
than six hours.
Extreme battery
temperature.
Battery does not charge if ambient temperature is below 0°C
(32°F) or above 40°C (104°F).
Cannot see characters
on display.
MC75 not powered
on.
Press the Power button.
During data
communication, no
data transmitted, or
transmitted data was
incomplete.
MC75 removed from
cradle or
disconnected from
host computer
during
communication.
Replace the MC75 in the cradle, or reattach the communication
cable and re-transmit.
Incorrect cable
configuration.
See the system administrator.
Communication
software was
incorrectly installed
or configured.
Perform setup. Refer to the MC75 Integrator Guide for details.
Volume setting is low
or turned off.
Adjust the volume. Adjust the volume. Refer to the MC75 User
Guide.
Rechargeable
lithium-ion battery did
not charge.
No sound.
8-6
MC75 Integrator Guide
Table 8-1 Troubleshooting the MC75 (Continued)
Problem
MC75 shuts off.
Tapping the window
buttons or icons does
not activate the
corresponding feature.
A message appears
stating that the MC75
memory is full.
MC75 keeps powering
down to protect
memory contents.
Cause
Solution
MC75 is inactive.
The MC75 turns off after a period of inactivity. If the MC75 is
running on battery power, set this period from 1 to 5 minutes, in
one-minute intervals. If the MC75 is running on external power,
set this period to 1, 2, 5, 10, 15, or 30 minutes.
Check the Power window by selecting Start > Settings > System
tab and tapping the Power icon. Select the Advanced tab and
change the setting for a longer delay before the automatic shutoff
feature activates.
Battery is not
inserted properly.
Insert the battery properly. See Installing the Main Battery on
page 1-5.
Battery is depleted.
Replace the battery.
Screen is not
calibrated correctly.
Re-calibrate the screen. See Calibrating the Screen on page 1-8.
The system is not
responding.
Warm boot the system. See Resetting the MC75 on page 1-8.
Too many files
stored on the MC75.
Delete unused memos and records. If necessary, save these
records on the host computer (or use an SD card for additional
memory).
Too many
applications installed
on the MC75.
Remove user-installed applications on the MC75 to recover
memory. Select Start > Settings > System tab and tap the
Remove Programs icon. Select the unused program and tap
Remove.
The MC75’s battery
is low.
Recharge the battery.
The internal
Bluetooth radio is
powered on for a
long time.
Because this mode requires battery power, power it off when not
needed. Using the SetDeviceState() API (refer to the SMDK Help
File), set the Bluetooth to D4 power state.
Maintenance & Troubleshooting
8-7
Table 8-1 Troubleshooting the MC75 (Continued)
Problem
The MC75 does not
accept scan input.
Cannot connect to
service provider.
Cause
Solution
Scanning application
is not loaded.
Load a scanning application on the MC75. See the system
administrator.
Unreadable bar
code.
Ensure the symbol is not defaced.
Distance between
exit window and bar
code is incorrect.
Place the MC75 within proper scanning range.
MC75 is not
programmed for the
bar code.
Program the MC75 to accept the type of bar code being scanned.
MC75 is not
programmed to
generate a beep.
If the MC75 does not beep on a good decode, set the application
to generate a beep on good decode.
Battery is low.
If the scanner stops emitting a laser beam upon a trigger press,
check the battery level. When the battery is low, the scanner
shuts off before the MC75 low battery condition notification.
Note: If the scanner is still not reading symbols, contact the
distributor or Zebra.
SIM not installed
properly.
Re-install SIM card.
Bluetooth Connection
Table 8-2 Troubleshooting Bluetooth Connection
Problem
MC75 cannot find
any Bluetooth
devices nearby.
When trying to
connect a Bluetooth
phone and MC75,
the phone thinks a
previously paired
MC75 is used.
Cause
Solution
Too far from other
Bluetooth devices.
Move closer to the other Bluetooth device(s), within a range
of 10 meters.
The Bluetooth device(s)
nearby are not turned on.
Turn on the Bluetooth device(s) to find.
The Bluetooth device(s)
are not in discoverable
mode.
Set the Bluetooth device(s) to discoverable mode. If needed,
refer to the device’s user documentation for help.
The phone remembers
the name and address of
the MC75 it last paired
with via the Bluetooth
radio.
Manually delete the pairing device and name from the phone.
Refer to the phone’s user documentation for instructions.
8-8
MC75 Integrator Guide
Single Slot USB/Serial Cradle
Table 8-3 Troubleshooting the Single Slot USB/Serial Cradle
Symptom
LEDs do not light
when MC75 or
spare battery is
inserted.
MC75 battery is not
charging.
Spare battery is not
charging.
During data
communication, no
data transmits, or
transmitted data
was incomplete.
Possible Cause
Action
Cradle is not receiving
power.
Ensure the power cable is connected securely to both the
cradle and to AC power.
MC75 is not seated
firmly in the cradle.
Remove and re-insert the MC75 into the cradle, ensuring it
is firmly seated.
Spare battery is not
seated firmly in the
cradle.
Remove and re-insert the spare battery into the charging
slot, ensuring it is firmly seated.
MC75 was removed
from cradle or cradle
was unplugged from AC
power too soon.
Ensure cradle is receiving power. Ensure MC75 is seated
correctly. Confirm main battery is charging under Start >
Settings > System > Power. The 3600 mAh capacity battery
fully charges in less than five hours.
Battery is faulty.
Verify that other batteries charge properly. If so, replace the
faulty battery.
The MC75 is not fully
seated in the cradle.
Remove and re-insert the MC75 into the cradle, ensuring it
is firmly seated.
Ambient temperature of
the cradle is too warm.
Move the cradle to an area where the ambient temperature
is between 0oC and 35oC.
Battery not fully seated
in charging slot.
Remove and re-insert the spare battery in the cradle,
ensuring it is firmly seated.
Battery inserted
incorrectly.
Re-insert the battery so the charging contacts on the battery
align with the contacts on the cradle.
Battery is faulty.
Verify that other batteries charge properly. If so, replace the
faulty battery.
Ambient temperature of
the cradle is too warm.
Move the cradle to an area where the ambient temperature
is between 0oC and 35oC.
MC75 removed from
cradle during
communication.
Replace MC75 in cradle and retransmit.
Incorrect cable
configuration.
See the system administrator.
Communication
software is not installed
or configured properly.
Perform setup as described in Chapter 3, ActiveSync.
Maintenance & Troubleshooting
8-9
Four Slot Ethernet Cradle
Table 8-4 Troubleshooting the Four Slot Ethernet Cradle
Symptom
Battery is not
charging.
During
communication, no
data was transmitted,
or transmitted data
was incomplete.
Cause
Solution
MC75 removed from the
cradle too soon.
Replace the MC75 in the cradle. The 3600 mAh capacity
battery fully charges in less than five hours. Tap Start >
Settings > System > Power to view battery status.
Battery is faulty.
Verify that other batteries charge properly. If so, replace the
faulty battery.
MC75 is not inserted
correctly in the cradle.
Remove the MC75 and reinsert it correctly. Verify charging is
active. Tap Start > Settings > System > Power to view battery
status.
Ambient temperature of
the cradle is too warm.
Move the cradle to an area where the ambient temperature is
between 0oC and 35oC.
MC75 removed from
cradle during
communication.
Replace MC75 in cradle and retransmit.
MC75 has no active
connection.
An icon is visible in the status bar if a connection is active.
Vehicle Cradle
Table 8-5 Troubleshooting the Vehicle Cradle
Symptom
Possible Cause
Action
MC75 battery
charging LED does
not light up.
Cradle is not receiving
power.
Ensure the power input cable is securely connected to the
cradle’s power port.
MC75 battery is not
recharging.
MC75 was removed from
the cradle too soon.
Replace the MC75 in the cradle. The 3600 mAh capacity
battery fully charges in less than five hours.
Battery is faulty.
Replace the battery.
MC75 is not placed
correctly in the cradle.
Remove the MC75 from the cradle, and re-insert correctly. If
the battery still does not charge, contact customer support.
The MC75 battery charging LED slowly blinks amber when
the MC75 is correctly inserted and charging.
Ambient temperature of
the cradle is too warm.
Move to an area where the ambient temperature is between
0oC and 35oC.
8 - 10 MC75 Integrator Guide
Table 8-5 Troubleshooting the Vehicle Cradle
Symptom
Possible Cause
No data transmitted,
or transmitted data
was incomplete.
Action
MC75 removed from
cradle during
communication.
Replace MC75 in cradle and retransmit.
No null modem cable
was used.
Some external devices require a null modem cable.
Retransmit using a null modem cable.
Incorrect cable
configuration.
See the system administrator.
Cable missing or
disconnected.
Re-connect cable.
Four Slot Spare Battery Charger
Table 8-6 Troubleshooting the Four Slot Spare Battery Charger
Symptom
Possible Cause
Action
Battery not charging.
Battery was removed
from the charger or
charger was unplugged
from AC power too soon.
Re-insert the battery in the charger or re-connect the charger’s
power supply. The 3600 mAh capacity battery fully charges in
less than five hours.
Battery is faulty.
Verify that other batteries charge properly. If so, replace the
faulty battery.
Battery contacts not
connected to charger.
Verify that the battery is seated in the battery well correctly with
the contacts facing down.
Ambient temperature of
the cradle is too warm.
Move the cradle to an area where the ambient temperature is
between 0oC and 35oC.
Cables
Table 8-7 Troubleshooting the Cables
Symptom
MC75 battery is
not charging.
Possible Cause
Action
MC75 was
disconnected from AC
power too soon.
Connect the power cable correctly. Confirm main battery is charging
under Start > Settings > System > Power. The 3600 mAh capacity
battery fully charges in less than five hours.
Battery is faulty.
Verify that other batteries charge properly. If so, replace the faulty
battery.
The MC75 is not fully
attached to power.
Detach and re-attach the power cable to the MC75, ensuring it is
firmly connected.
Maintenance & Troubleshooting 8 - 11
Table 8-7 Troubleshooting the Cables (Continued)
Symptom
During data
communication,
no data
transmits, or
transmitted data
was
incomplete.
Possible Cause
Action
Cable was
disconnected from
MC75 during
communications.
Re-attach the cable and retransmit.
Incorrect cable
configuration.
See the system administrator.
Communication
software is not installed
or configured properly.
Perform setup as described in the Chapter 3, ActiveSync.
Magnetic Stripe Reader
Table 8-8 Troubleshooting the Magnetic Stripe Reader
Symptom
MSR does not read
card.
MC75 battery is not
charging.
During data
communication, no
data transmits, or
transmitted data was
incomplete.
Possible Cause
Action
MSR removed from
MC75 during card swipe.
Reattach MSR to MC75 and reswipe the card.
Faulty magnetic stripe
on card.
See the system administrator.
MSR application is not
installed or configured
properly.
Ensure the MSR application is installed on the MC75.
Ensure the MSR application is configured correctly.
MC75 was removed
from MSR or MSR was
unplugged from AC
power too soon.
Ensure MSR is receiving power. Ensure MC75 is attached
correctly. Confirm main battery is charging under Start >
Settings > System > Power. The 3600 mAh capacity battery
fully charges in less than five hours.
Battery is faulty.
Verify that other batteries charge properly. If so, replace the
faulty battery.
The MC75 is not fully
attached to the MSR.
Detach and re-attach the MSR to the MC75, ensuring it is
firmly connected.
MC75 detached from
MSR during
communications.
Reattach MC75 to MSR and retransmit.
Incorrect cable
configuration.
See the system administrator.
Communication software
is not installed or
configured properly.
Perform setup as described in Chapter 3, ActiveSync.
8 - 12 MC75 Integrator Guide
Appendix A Technical Specifications
Technical Specifications
The following tables summarizes the intended operating environment and technical hardware specifications for the
MC75 and accessories.
MC75
Table A-1 MC75 Technical Specifications
Item
Description
Physical Characteristics
Dimensions
Length: 17.9 cm (7.06 in.)
Width: 8.4 cm (3.30 in.)
Depth: 4.4 cm (1.74 in.)
Weight (inc. standard battery)
422 grams (14.89 oz)
Display
Transflective color 3.5” VGA with backlight, TFT-LCD, 65K colors,
480 W x 640 L (VGA size)
Touch Panel
Glass analog resistive touch
Backlight
LED backlight
Main Battery
Rechargeable Lithium Ion 3.7V, 3600 mAh Smart Battery
Backup Battery
NiMH battery (rechargeable) 15 mAh 2.4V (not user-accessible)
Expansion Slot
User accessible microSD slot (with secure cover).
Network Connections
Ethernet (via cradle)
High-speed USB, host or client, Bluetooth
Note 1: Total output power can be either USB or serial or a combination of both that cannot exceed 200 mA.
A-2
MC75 Integrator Guide
Table A-1 MC75 Technical Specifications (Continued)
Item
Description
Notification
Vibrator and audible alert
Keypad Options
26 key numeric, 26 key Direct Store Delivery (DSD) numeric
44 key QWERTY, 44 key AZERTY, 44 key QWERTZ
Audio
Speaker, receiver, microphone, headset jack, software support for full duplex
record and playback (stereo)
Performance Characteristics
CPU
Intel® XScale™ Bulverde PXA270 processor at 624MHz
Operating System
Microsoft® Windows Mobile™ 6
Memory
128MB RAM/256MB FLASH
Interface/Communications
RS-232, USB 1.1
Output Power (Note 1)
USB: 5 VDC @ 200 mA max.
Serial: 5 VDC @ 200 mA max.
User Environment
Operating Temperature
-10°C to 50°C (14°F to 122°F)
Storage Temperature
-20°C to 70°C (-4°F to 158°F)
Charging Temperature
32°F to 104°F / 0° C to 40° C
Humidity
95% non-condensing
Drop Specification
4 ft. drop to concrete, 6 drops per 6 sides over operating temperature range.
5 ft. drop to concrete, 2 drops per 6 sides at ambient temperature 23°C (73°F).
Electrostatic Discharge (ESD)
+/-15kVdc air discharge, +/-8kVdc direct discharge, +/-8kVdc indirect discharge
Sealing
IP54
Wireless WAN Data and Voice Communications
Wireless Wide Area Network
(WWAN) radios
MC7506 and MC7596:
MC7508 and MC7598:
GPS
Tri-Band HSDPA (850, 1900 and 2100 MHz)
Quad-Band Edge (850, 900, 1800 and 1900 MHz)
CDMA: EVDO Rev A (800 and 1900 MHz)
Integrated Assisted-GPS (A-GPS)
Wireless LAN Data and Voice Communications
Wireless Local Area Network
(WLAN) radio
Tri-mode IEEE® 802.11a/b/g
Data Rates Supported
1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps
Note 1: Total output power can be either USB or serial or a combination of both that cannot exceed 200 mA.
Technical Specifications
A-3
Table A-1 MC75 Technical Specifications (Continued)
Item
Description
Operating Channels
Chan 8-169 (5040 – 5845 MHz) (4920 – 4980 MHz) Japan only
Chan 1-13 (2412-2472 MHz) Chan 14 (2484 MHz) Japan only
Actual operating frequencies depend on regulatory rules and certification
agency
Security
WPA2, WPA, WEP (40 or 128 bit), TKIP, TLS, TTLS (MS-CHAP), TTLS
(MS-CHAP v2), TTLS (CHAP), TTLS-MD5, TTLS-PAP, PEAP-TLS, PEAP
(MS-CHAP v2), AES, LEAP
Spreading Technique
Direct Sequence Spread Spectrum (DSSS) and Orthogonal Frequency Division
Multiplexing (OFDM)
Antenna
Internal for WLAN, Bluetooth and GPS, external for WWAN
Voice Communication
Integrated Voice-over-IP ready (P2P, PBX, PTT), Wi-Fi™-certified, IEEE
802.11a/b/g direct sequence wireless LAN
Wireless PAN Data and Voice Communications
Bluetooth
Class II, v 2.0 EDR; on-board chip antenna.
Data Capture Specifications
Options
2D imager, 1D linear, color camera
Linear 1D Scanner (SE950) Specifications
Optical Resolution
0.005 in. minimum element width
Roll
+/- 30° from vertical
Pitch Angle
+/- 65° from normal
Skew Tolerance
+/- 60° from normal
Ambient Light
Sunlight: 8,000 ft. candles (86,112 Lux)
Artificial Light: 450 ft. candles (4,844 Lux)
Shock
2,000 +/- 5% G
Scan Rate
50 (+/- 6) scans/sec (bidirectional)
Scan Angle
46.5° (typical)
Laser Power
1.0 mW nominal
2D Imager Engine (SE4400) Specifications
Field of View
Horizontal - 32.2°
Vertical - 24.5°
Optical Resolution
640 H x 480 V pixels (gray scale)
Roll
360°
Note 1: Total output power can be either USB or serial or a combination of both that cannot exceed 200 mA.
A-4
MC75 Integrator Guide
Table A-1 MC75 Technical Specifications (Continued)
Item
Description
Pitch Angle
+/- 60° from normal
Skew Tolerance
+/- 50° from normal
Ambient Light
Total darkness to 9,000 ft. candles (96,900 Lux)
Shock
2,000 +/- 5% G
Focal Distance from Front of
Engine
Near: 5 inches
Far: 9 inches
Aiming Element (VLD)
650 nm +/- 5 nm
Illumination Element (LED)
635 nm +/- 20 nm
Camera Specifications
Resolution
2 Mega pixel with auto focus and flash
Note 1: Total output power can be either USB or serial or a combination of both that cannot exceed 200 mA.
MC75 COM Port Definitions
Table A-2 MC75 COM Port Definitions
COM Port
Definition
COM0
Available
COM1
Accessory port
COM2
Available
COM3
IRComm
COM4
Raw IrDA
COM5
BTVCOM
COM6
USBVCOM
BTS6
Bluetooth (Radio I/O)
COM7
Available
COM8
GPSId (GPSMux)
COM9
BTVCOM
Technical Specifications
MC75 Pin-Outs
Pin 1
Figure A-1 External Connector
Table A-3 External Connector Pin-Outs
Pin
Description
1
Power Gnd
2
CRADLE_DETECT
3
RS232_DCD/TRIGGER
4
USB_D-
5
USB_D+
6
USB_Gnd
7
USB_Vbus
8
USB_ID
9
RS232_TXD
10
RS232_RXD
11
RS232_RTS
12
RS232_CTS
13
RS232_DTR
14
RS232_DSR
15
External_5.0V_Out
16
External DC In_5.4V
A-5
A-6
MC75 Integrator Guide
MC75 Accessory Specifications
Single Slot USB/Serial Cradle
Table A-4 Single Slot USB/Serial Cradle Technical Specifications
Feature
Description
Dimensions
Length: 14.54 cm (5.72 in.)
Width: 11.05 cm (4.35 in.)
Height: 9.10 cm (3.58 in.)
Weight
196 g (6.9 oz)
Input Power
12 VDC
Power Consumption
30 watts
Interface
USB, Serial
Operating Temperature
0°C to 50°C (32°F to 122°F)
Storage Temperature
-40°C to 70°C (-40°F to 158°F)
Charging Temperature
0°C to 40°C (32°F to 104°F)
Humidity
5% to 95% non-condensing
Drop
76.2 cm (30.0 in.) drops to vinyl tiled concrete at room temperature
Electrostatic Discharge (ESD)
+/- 15 kV air
+/- 8 kV contact
Four Slot Ethernet Cradle
Table A-5 Four Slot Ethernet Cradle Technical Specifications
Feature
Description
Dimensions
Length: 46.78 cm (18.42 in.)
Width: 11.00 cm (4.33 in.)
Height: 13.70 cm (5.39 in.)
Weight
1079 g (2.38 lb)
Input Power
12 VDC
Power Consumption
100 watts
Interface
Ethernet
Operating Temperature
0°C to 50°C (32°F to 122°F)
Storage Temperature
-40°C to 70°C (-40°F to 158°F)
Technical Specifications
Table A-5 Four Slot Ethernet Cradle Technical Specifications (Continued)
Feature
Description
Charging Temperature
0°C to 40°C (32°F to 104°F)
Humidity
5% to 95% non-condensing
Drop
76.2 cm (30.0 in.) drops to vinyl tiled concrete at room temperature
Electrostatic Discharge (ESD)
+/- 15 kV air
+/- 8 kV contact
Four Slot Charge Only Cradle
Table A-6 Four Slot Charge Only Cradle Technical Specifications
Feature
Description
Dimensions
Length: 46.78 cm (18.42 in.)
Width: 11.00 cm (4.33 in.)
Height: 13.70 cm (5.39 in.)
Weight
1079 g (2.38 lb)
Input Power
12 VDC
Power Consumption
100 watts
Operating Temperature
0°C to 50°C (32°F to 122°F)
Storage Temperature
-40°C to 70°C (-40°F to 158°F)
Charging Temperature
0°C to 40°C (32°F to 104°F)
Humidity
5% to 95% non-condensing
Drop
76.2 cm (30.0 in.) drops to vinyl tiled concrete at room temperature
Electrostatic Discharge (ESD)
+/- 15 kV air
+/- 8 kV contact
Four Slot Battery Charger
Table A-7 Four Slot Battery Charger Technical Specifications
Feature
Description
Dimensions
Length: 21.00 cm (8.27 in.)
Width: 15.50 cm (6.10 in.)
Height: 3.47 cm (1.37 in.)
Weight
386 g (13.6 oz)
Input Power
12 VDC
A-7
A-8
MC75 Integrator Guide
Table A-7 Four Slot Battery Charger Technical Specifications (Continued)
Feature
Description
Power Consumption
30 watts
Operating Temperature
0°C to 50°C (32°F to 122°F)
Storage Temperature
-40°C to 70°C (-40°F to 158°F)
Charging Temperature
0°C to 40°C (32°F to 104°F)
Humidity
5% to 95% non-condensing
Drop
76.2 cm (30.0 in.) drops to vinyl tiled concrete at room temperature
Electrostatic Discharge (ESD)
+/- 15 kV air
+/- 8 kV contact
Magnetic Stripe Reader
Table A-8 Magnetic Stripe Reader (MSR) Technical Specifications
Feature
Description
Dimensions
Length: 7.87 cm (3.1 in.)
Width: 8.38 cm (3.3 in.)
Height: 3.56 cm (1.4 in.)
Weight
48 g (1.7 oz)
Interface
Serial with baud rate up to 19,200
Format
ANSI, ISO, AAMVA, CA DMV, user-configurable generic format
Swipe Speed
5 to 50 in. (127 to 1270 mm) /sec, bi-directional
Decoders
Generic, Raw Data
Mode
Buffered, unbuffered
Track Reading Capabilities
Tracks 1 and 3: 210 bpi
Track 2: 75 and 210 bpi, autodetect
Operating Temperature
0°C to 50°C (32°F to 122°F)
Storage Temperature
-40°C to 70°C (-40°F to 158°F)
Humidity
5% to 95% non-condensing
Drop
1.22 m (4 ft.) drops to concrete
Electrostatic Discharge (ESD)
+/- 15 kV air
+/- 8 kV contact
Technical Specifications
Vehicle Cradle
Table A-9 Vehicle Cradle Technical Specifications
Feature
Description
Dimensions
Length: 11.00 cm (4.33 in.)
Width:9.50 cm (3.74 in.)
Height: 20.50 cm (8.07 in.)
Weight
567 g (20 oz)
Input Power
12/24 VDC
Power Consumption
25 watts
Operating Temperature
0°C to 50°C (32°F to 122°F)
Storage Temperature
-40°C to 70°C (-40°F to 158°F)
Charging Temperature
0°C to 40°C (32°F to 104°F)
Humidity
10% to 95% non-condensing
Drop
76.2 cm (30.0 in.) drops to vinyl tiled concrete at room temperature
Electrostatic Discharge (ESD)
+/- 15 kV air
+/- 8 kV contact
A-9
A - 10 MC75 Integrator Guide
Appendix B Bluetooth Configuration
The MC75 supports both the Microsoft Bluetooth stack and the StoneStreet One Bluetooth stack. Only one
Bluetooth stack can be used at a time. By default, the StoneStreet One Bluetooth stack is enabled. A registry key
on the MC75 can be modified to disable the StoneStreet One stack and enable the Microsoft stack.
Using a registry editor, navigate to the following:
[HKEY_LOCAL_MACHINE\Software\SymbolBluetooth
Edit the following key:
“SSStack”=dword:1
where:
0 = disable StoneStreet One stack and enable Microsoft stack
1 = enable StoneStreet One stack and disable Microsoft stack (default)
After setting the registry key, warm boot the MC75.
B-2
MC75 User Guide
Glossary
A
ActiveSync. ActiveSync is a data synchronization program developed by Microsoft for use with Windows Mobile operating
systems.
AFH. Adaptive Frequency Hopping
AKU. (Adaptation Kit Update) Updates to the Windows Mobile operating system.
API. (Application Programming Interface) An interface by means of which one software component communicates with or
controls another. Usually used to refer to services provided by one software component to another, usually via software
interrupts or function calls
ASCII. American Standard Code for Information Interchange. A 7 bit-plus-parity code representing 128 letters, numerals,
punctuation marks and control characters. It is a standard data transmission code in the U.S.
AZERTY. A standard keyboard commonly used on French keyboards. “AZERTY” refers to the arrangement of keys on the
top row of keys.
B
Bar Code. A pattern of variable-width bars and spaces which represents numeric or alphanumeric data in machine-readable
form. The general format of a bar code symbol consists of a leading margin, start character, data or message character,
check character (if any), stop character, and trailing margin. Within this framework, each recognizable symbology uses
its own unique format. See Symbology.
Bit. Binary digit. One bit is the basic unit of binary information. Generally, eight consecutive bits compose one byte of data.
The pattern of 0 and 1 values within the byte determines its meaning.
Bits per Second (bps). Bits transmitted or received.
Bluetooth. A wireless protocol utilizing short-range communications technology facilitating data transmission over short
distances.
Glossary - 2
MC75 Integrator Guide
boot or boot-up. The process a computer goes through when it starts. During boot-up, the computer can run self-diagnostic
tests and configure hardware and software.
bps. See Bits Per Second.
Byte. On an addressable boundary, eight adjacent binary digits (0 and 1) combined in a pattern to represent a specific
character or numeric value. Bits are numbered from the right, 0 through 7, with bit 0 the low-order bit. One byte in
memory is used to store one ASCII character.
C
CDRH. Center for Devices and Radiological Health. A federal agency responsible for regulating laser product safety. This
agency specifies various laser operation classes based on power output during operation.
CDRH Class 1. This is the lowest power CDRH laser classification. This class is considered intrinsically safe, even if all laser
output were directed into the eye's pupil. There are no special operating procedures for this class.
CDRH Class 2. No additional software mechanisms are needed to conform to this limit. Laser operation in this class poses
no danger for unintentional direct human exposure.
Character. A pattern of bars and spaces which either directly represents data or indicates a control function, such as a
number, letter, punctuation mark, or communications control contained in a message.
Codabar. A discrete self-checking code with a character set consisting of digits 0 to 9 and six additional characters: (“-”, “$”,
“:”, “/”, “,”, “+”).
Code 128. A high density symbology which allows the controller to encode all 128 ASCII characters without adding extra
symbol elements.
Code 3 of 9 (Code 39). A versatile and widely used alphanumeric bar code symbology with a set of 43 character types,
including all uppercase letters, numerals from 0 to 9 and 7 special characters (“-”, “.”, “/”, “+”, “%”, “$” and space). The
code name is derived from the fact that 3 of 9 elements representing a character are wide, while the remaining 6 are
narrow.
Code 93. An industrial symbology compatible with Code 39 but offering a full character ASCII set and a higher coding
density than Code 39.
Cold Boot. A cold boot restarts the mobile computer and initializes some drivers.
COM port. Communication port; ports are identified by number, e.g., COM1, COM2.
Cradle. A cradle is used for charging the terminal battery and for communicating with a host computer, and provides a
storage place for the terminal when not in use.
D
DCP. See Device Configuration Package.
Glossary - 3
Decode. To recognize a bar code symbology (e.g., UPC/EAN) and then analyze the content of the specific bar code
scanned.
Decode Algorithm. A decoding scheme that converts pulse widths into data representation of the letters or numbers
encoded within a bar code symbol.
Depth of Field. The range between minimum and maximum distances at which a scanner can read a symbol with a certain
minimum element width.
Device Configuration Package. The Device Configuration Package provides the flash partitions, Terminal Configuration
Manager (TCM) and the associated TCM scripts. With this package hex images that represent flash partitions can be
created and downloaded to the mobile computer.
Discrete 2 of 5. A binary bar code symbology representing each character by a group of five bars, two of which are wide.
The location of wide bars in the group determines which character is encoded; spaces are insignificant. Only numeric
characters (0 to 9) and START/STOP characters may be encoded.
E
EAN. European Article Number. This European/International version of the UPC provides its own coding format and
symbology standards. Element dimensions are specified metrically. EAN is used primarily in retail.
EMDK. Enterprise Mobility Developer’s Kit.
ESD. Electro-Static Discharge
F
FHSS (Frequency Hopping Spread Spectrum). A method of transmitting radio signals by rapidly switching a carrier among
many frequency channels, using a pseudorandom sequence known to both transmitter and receiver.
File Transfer Protocol (FTP). A TCP/IP application protocol governing file transfer via network or telephone lines. See
TCP/IP.
Flash Memory. Flash memory is nonvolatile, semi-permanent storage that can be electronically erased in the circuit and
reprogrammed.
H
Hard Reset. See Cold Boot.
Hz. Hertz; A unit of frequency equal to one cycle per second.
Host Computer. A computer that serves other terminals in a network, providing such services as computation, database
access, supervisory programs and network control.
Glossary - 4
MC75 Integrator Guide
I
IDE. Intelligent drive electronics. Refers to the solid-state hard drive type.
IEC. International Electrotechnical Commission. This international agency regulates laser safety by specifying various laser
operation classes based on power output during operation.
IEC (825) Class 1. This is the lowest power IEC laser classification. Conformity is ensured through a software restriction of
120 seconds of laser operation within any 1000 second window and an automatic laser shutdown if the scanner's
oscillating mirror fails.
IEEE Address. See MAC Address.
Input/Output Ports. I/O ports are primarily dedicated to passing information into or out of the terminal’s memory. Series
9000 mobile computers include Serial and USB ports.
Interleaved 2 of 5. A binary bar code symbology representing character pairs in groups of five bars and five interleaved
spaces. Interleaving provides for greater information density. The location of wide elements (bar/spaces) within each
group determines which characters are encoded. This continuous code type uses no intercharacter spaces. Only
numeric (0 to 9) and START/STOP characters may be encoded.
Internet Protocol Address. See IP.
I/O Ports. interface The connection between two devices, defined by common physical characteristics, signal
characteristics, and signal meanings. Types of interfaces include RS-232 and PCMCIA.
IP. Internet Protocol. The IP part of the TCP/IP communications protocol. IP implements the network layer (layer 3) of the
protocol, which contains a network address and is used to route a message to a different network or subnetwork. IP
accepts “packets” from the layer 4 transport protocol (TCP or UDP), adds its own header to it and delivers a “datagram”
to the layer 2 data link protocol. It may also break the packet into fragments to support the maximum transmission unit
(MTU) of the network.
IP Address. (Internet Protocol address) The address of a computer attached to an IP network. Every client and server
station must have a unique IP address. A 32-bit address used by a computer on a IP network. Client workstations have
either a permanent address or one that is dynamically assigned to them each session. IP addresses are written as four
sets of numbers separated by periods; for example, 204.171.64.2.
IPX/SPX. Internet Package Exchange/Sequential Packet Exchange. A communications protocol for Novell. IPX is Novell’s
Layer 3 protocol, similar to XNS and IP, and used in NetWare networks. SPX is Novell's version of the Xerox SPP
protocol.
ISM. Industry Scientific and Medical
K
Key. A key is the specific code used by the algorithm to encrypt or decrypt the data. Also see, Encryption and Decrypting.
Glossary - 5
L
LASER. Light Amplification by Stimulated Emission of Radiation.The laser is an intense light source. Light from a laser is
all the same frequency, unlike the output of an incandescent bulb. Laser light is typically coherent and has a high energy
density.
laser scanner. A type of bar code reader that uses a beam of laser light.
LCD. See Liquid Crystal Display.
LED Indicator. A semiconductor diode (LED - Light Emitting Diode) used as an indicator, often in digital displays. The
semiconductor uses applied voltage to produce light of a certain frequency determined by the semiconductor's particular
chemical composition.
Light Emitting Diode. See LED.
Liquid Crystal Display (LCD). A display that uses liquid crystal sealed between two glass plates. The crystals are excited
by precise electrical charges, causing them to reflect light outside according to their bias. They use little electricity and
react relatively quickly. They require external light to reflect their information to the user.
M
MC. Mobile Computer.
MDN. Mobile Directory Number. The directory listing telephone number that is dialed (generally using POTS) to reach a
mobile unit. The MDN is usually associated with a MIN in a cellular telephone -- in the US and Canada, the MDN and
MIN are the same value for voice cellular users. International roaming considerations often result in the MDN being
different from the MIN.
MIN. Mobile Identification Number. The unique account number associated with a cellular device. It is broadcast by the
cellular device when accessing the cellular system.
Mobile Computer. In this text, mobile computer refers to the MC75 wireless computer. It can be set up to run as a
stand-alone device, or it can be set up to communicate with a network, using wireless radio technology.
N
Nominal. The exact (or ideal) intended value for a specified parameter. Tolerances are specified as positive and negative
deviations from this value.
NVM. Non-Volatile Memory.
Glossary - 6
MC75 Integrator Guide
O
Open System Authentication. Open System authentication is a null authentication algorithm.
P
PAN. Personal area network. Using Bluetooth wireless technology, PANs enable devices to communicate wirelessly.
Generally, a wireless PAN consists of a dynamic group of less than 255 devices that communicate within about a 33-foot
range. Only devices within this limited area typically participate in the network.
PING. (Packet Internet Groper) An Internet utility used to determine whether a particular IP address is online. It is used to
test and debug a network by sending out a packet and waiting for a response.
Q
QWERTY. A standard keyboard commonly used on North American and some European keyboards. “QWERTY” refers to
the arrangement of keys on the top row of keys.
QWERTZ. A standard keyboard commonly used on German keyboards. “QWERTZ” refers to the arrangement of keys on
the top row of keys.
R
RAM. Random Access Memory. Data in RAM can be accessed in random order, and quickly written and read.
RF. Radio Frequency.
ROM. Read-Only Memory. Data stored in ROM cannot be changed or removed.
Router. A device that connects networks and supports the required protocols for packet filtering. Routers are typically used
to extend the range of cabling and to organize the topology of a network into subnets. See Subnet.
RS-232. An Electronic Industries Association (EIA) standard that defines the connector, connector pins, and signals used to
transfer data serially from one device to another.
S
Scanner. An electronic device used to scan bar code symbols and produce a digitized pattern that corresponds to the bars
and spaces of the symbol. Its three main components are: 1) Light source (laser or photoelectric cell) - illuminates a bar
code,; 2) Photodetector - registers the difference in reflected light (more light reflected from spaces); 3) Signal
conditioning circuit - transforms optical detector output into a digitized bar pattern.
Glossary - 7
SDK. Software Development Kit
Shared Key. Shared Key authentication is an algorithm where both the AP and the MU share an authentication key.
Soft Reset. See Warm Boot.
Space. The lighter element of a bar code formed by the background between bars.
Specular Reflection. The mirror-like direct reflection of light from a surface, which can cause difficulty decoding a bar code.
Start/Stop Character. A pattern of bars and spaces that provides the scanner with start and stop reading instructions and
scanning direction. The start and stop characters are normally to the left and right margins of a horizontal code.
Subnet. A subset of nodes on a network that are serviced by the same router. See Router.
Subnet Mask. A 32-bit number used to separate the network and host sections of an IP address. A custom subnet mask
subdivides an IP network into smaller subsections. The mask is a binary pattern that is matched up with the IP address
to turn part of the host ID address field into a field for subnets. Default is often 255.255.255.0.
Substrate. A foundation material on which a substance or image is placed.
Symbol. A scannable unit that encodes data within the conventions of a certain symbology, usually including start/stop
characters, quiet zones, data characters and check characters.
Symbol Aspect Ratio. The ratio of symbol height to symbol width.
Symbol Height. The distance between the outside edges of the quiet zones of the first row and the last row.
Symbol Length. Length of symbol measured from the beginning of the quiet zone (margin) adjacent to the start character
to the end of the quiet zone (margin) adjacent to a stop character.
Symbology. The structural rules and conventions for representing data within a particular bar code type (e.g. UPC/EAN,
Code 39, PDF417, etc.).
T
TCP/IP. (Transmission Control Protocol/Internet Protocol) A communications protocol used to internetwork dissimilar
systems. This standard is the protocol of the Internet and has become the global standard for communications. TCP
provides transport functions, which ensures that the total amount of bytes sent is received correctly at the other end.
UDP is an alternate transport that does not guarantee delivery. It is widely used for real-time voice and video
transmissions where erroneous packets are not retransmitted. IP provides the routing mechanism. TCP/IP is a routable
protocol, which means that all messages contain not only the address of the destination station, but the address of a
destination network. This allows TCP/IP messages to be sent to multiple networks within an organization or around the
world, hence its use in the worldwide Internet. Every client and server in a TCP/IP network requires an IP address, which
is either permanently assigned or dynamically assigned at startup.
Telnet. A terminal emulation protocol commonly used on the Internet and TCP/IP-based networks. It allows a user at a
terminal or computer to log onto a remote device and run a program.
Terminal. See Mobile Computer.
Glossary - 8
MC75 Integrator Guide
Terminal Emulation. A “terminal emulation” emulates a character-based mainframe session on a remote non-mainframe
terminal, including all display features, commands and function keys. The VC5000 Series supports Terminal Emulations
in 3270, 5250 and VT220.
TFTP. (Trivial File Transfer Protocol) A version of the TCP/IP FTP (File Transfer Protocol) protocol that has no directory or
password capability. It is the protocol used for upgrading firmware, downloading software and remote booting of diskless
devices.
Tolerance. Allowable deviation from the nominal bar or space width.
Transmission Control Protocol/Internet Protocol. See TCP/IP.
Trivial File Transfer Protocol. See TFTP.
U
UDP. User Datagram Protocol. A protocol within the IP protocol suite that is used in place of TCP when a reliable delivery
is not required. For example, UDP is used for real-time audio and video traffic where lost packets are simply ignored,
because there is no time to retransmit. If UDP is used and a reliable delivery is required, packet sequence checking and
error notification must be written into the applications.
UPC. Universal Product Code. A relatively complex numeric symbology. Each character consists of two bars and two
spaces, each of which is any of four widths. The standard symbology for retail food packages in the United States.
V
Visible Laser Diode (VLD). A solid state device which produces visible laser light.
W
Warm Boot. A warm boot restarts the mobile computer by closing all running programs. All data that is not saved to flash
memory is lost.
Index
A
accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
auto charge cable . . . . . . . . . . . . . . . . . . . . . . . . 1-2
cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2, 2-36
communication/charge cables . . . . . . . . . . . . . 2-36
battery charging . . . . . . . . . . . . . . . . . . . . . 2-37
LED indicators . . . . . . . . . . . . . . . . . . . . . . 2-37
DEX cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
EMDK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
four slot Ethernet cradle . . . . . . . . . . . . 1-2, 2-1, 2-5
four slot spare battery charger . . . . . . . . . . .1-2, 2-1
headset . . . . . . . . . . . . . . . . . . . . . . . . 1-3, 2-1, 2-34
holster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
magnetic stripe reader . . . . . . . . . . . . . . . . . . . . 1-2
MMC . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-10, 2-34
modem cable . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
modem inverter cable . . . . . . . . . . . . . . . . . . . . . 1-2
mounting bracket . . . . . . . . . . . . . . . . . . . . . . . 2-11
MSR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2, 2-23
installation . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
magnetic stripe reading . . . . . . . . . . . . . . . 2-23
O’Neil printer cable . . . . . . . . . . . . . . . . . . . . . . . 1-2
rigid holster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
SD card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
SIM card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
single slot USB serial cradle . . . . . . . . . . . . .2-1, 2-2
spare battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . A-6
stylus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
USB charger cable . . . . . . . . . . . . . . . . . . . . . . . 1-2
USB cradle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
vehicle cradle . . . . . . . . . . . . . . . . . . . 1-2, 2-1, 2-13
wall mounting kit, cradle . . . . . . . . . . . . . . . . . . . 1-3
Zebra printer cable . . . . . . . . . . . . . . . . . . . . . . . 1-2
zebra printer cable . . . . . . . . . . . . . . . . . . . . . . . 1-2
activation
CDMA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Sprint CDMA . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Verizon CDMA . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
ActiveSync . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
deploying CAB files . . . . . . . . . . . . . . . . . . . . . . 4-4
installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
setting up a connection . . . . . . . . . . . . . . . . . . . . 3-3
AirBEAM
deploying CAB files . . . . . . . . . . . . . . . . . . . . . . 4-5
APN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
application deployment . . . . . . . . . . . . . . . . . . . . 4-1, 4-4
CAB files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
application folder . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
application packaging . . . . . . . . . . . . . . . . . . . . . . . . 4-4
application security . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
auto charge cable . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
B
backup battery
charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
battery
charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
check status . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
removing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
battery chargers
communication/charge cables . . . . . . . . . . . . . 2-36
battery charging . . . . . . . . . . . . . . . . . . . . . 2-37
LED indicators . . . . . . . . . . . . . . . . . . . . . . 2-37
battery charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
communication/charge cables . . . . . . . . . . . . . 2-37
battery charging . . . . . . . . . . . . . . . . . . . . . 2-37
four slot Ethernet cradle . . . . . . . . . . . . . . . . . . . 2-8
single slot cradle . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
spare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
vehicle cradle . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
Index - 2
MC75 Integrator Guide
bluetooth
troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7
boot
clean . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
cold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
warm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
bullets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xviii
C
CAB files . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4, 4-7, 4-10
deployment via ActiveSync . . . . . . . . . . . . . . . . . 4-4
deployment via AirBEAM . . . . . . . . . . . . . . . . . . 4-5
deployment via image update . . . . . . . . . . . . . . . 4-5
deployment via storage card . . . . . . . . . . . . . . . . 4-4
cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2, 2-36
auto charge cable . . . . . . . . . . . . . . . . . . . . . . . . 1-2
charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-36
communication . . . . . . . . . . . . . . . . . . . . . . . . . 2-36
communication setup . . . . . . . . . . . . . . . . . . . . 2-37
DEX cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-5
setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-36
troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . 8-10
USB charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
cache disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
calibrating the screen . . . . . . . . . . . . . . . . . . . . . . . . 1-8
call barring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
call blocking See call barring . . . . . . . . . . . . . . . . . . 5-10
call forwarding . . . . . . . . . . . . . . . . . . . . . . . . .5-11, 6-14
call waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-12, 6-15
caller id . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-11, 6-14
CDMA
activate Sprint . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
activate Verizon . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
activate Verizon automated . . . . . . . . . . . . . . . . 6-2
data connection . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
settings
data, Sprint . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
data, Verizon . . . . . . . . . . . . . . . . . . . . . . . 6-10
location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
phone info . . . . . . . . . . . . . . . . . . . . . . . . . . 6-13
provisioning . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
services . . . . . . . . . . . . . . . . . . . . . . .6-14, 6-15
system, Sprint . . . . . . . . . . . . . . . . . . . . . . . 6-11
system, Verizon . . . . . . . . . . . . . . . . .6-12, 6-13
test activation . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
changing a PIN for phone use . . . . . . . . . . . . . . . . . . 5-9
charging
communication/charge cables . . . . . . . . . . . . . 2-37
four slot Ethernet cradle . . . . . . . . . . . . . . . . . . . 2-8
single slot cradle . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
spare batteries . . . . . . . . . . . . . . . . . . . . . . 1-7, 2-21
vehicle cradle . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
charging temperature . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
clean boot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
cold boot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
communication
charge cables . . . . . . . . . . . . . . . . . . . . . . . . . . 2-36
communication setup
communication/charge cables . . . . . . . . . . . . . . 2-37
communication/charge cables
battery charging . . . . . . . . . . . . . . . . . . . . . . . . . 2-37
communication setup . . . . . . . . . . . . . . . . . . . . 2-37
LED indicators . . . . . . . . . . . . . . . . . . . . . . . . . . 2-37
configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiv, 1-3
conventions
notational . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvii
copyfile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
cpf file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7, 4-10
cradles
daisychaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Ethernet drivers . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
four slot Ethernet . . . . . . . . . . . . . . . . . . 1-2, 2-1, 2-5
charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
charging indicators . . . . . . . . . . . . . . . . . . . . 2-9
setup . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5, 2-10
four slot spare battery charger . . . . . . . . . . . . . . 2-1
charging . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
charging indicators . . . . . . . . . . . . . . . . . . . 2-22
setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
mounting bracket . . . . . . . . . . . . . . . . . . . . . . . . 2-11
single slot USB serial . . . . . . . . . . . . . . . . . 2-1, 2-2
charging indicators . . . . . . . . . . . . . . . . . . . . 2-3
setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
troubleshooting . . . . . . . . . . . . . . . . . . 8-8, 8-9, 8-10
vehicle . . . . . . . . . . . . . . . . . . . . . . . . . 1-2, 2-1, 2-13
charging . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
charging indicators . . . . . . . . . . . . . . . . . . . 2-19
setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
creating cpf file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
SCM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
creating splash screen . . . . . . . . . . . . . . . . . . . . . . . . 4-6
D
data capture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiv
data connection . . . . . . . . . . . . . . . . . . . . . . . . . 5-4, 6-6
deployment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1, 4-4
CAB files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
DEX cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
digital signatures . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
disabling PIN for phone use . . . . . . . . . . . . . . . . . . . . 5-9
Index - 3
phone info . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16
PIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
services . . . . . . . . . . . . . . . . . . . 5-10, 5-11, 5-12
sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
disconnecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xiv
E
EDA configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
EMDK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xviii, 4-12
enabling PIN for phone use . . . . . . . . . . . . . . . . . . . . 5-9
enhanced operator name string . . . . . . . . . . . . . . . . 5-17
Enterprise Mobility Developer Kit . . . . . . . . . . xviii, 4-12
enterprise mobility developer kit . . . . . . . . . . . . . . . . 1-3
EONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-17
ESD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Ethernet cradle . . . . . . . . . . . . . . . . . . . . . . . . . .1-2, 2-1
F
file deployment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
flash file system
copyfile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
regmerge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
four slot Ethernet cradle . . . . . . . . . . . . . . . . . . . . . . 2-5
charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
charging indicators . . . . . . . . . . . . . . . . . . . . . . . 2-9
daisychaining . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
link indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5, 2-10
speed indicator . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
four slot spare battery charger . . . . . . . . . . . . . . .1-2, 2-1
charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
charging indicators . . . . . . . . . . . . . . . . . . . . . . 2-22
setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
shim installation . . . . . . . . . . . . . . . . . . . . . . . . 2-21
troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . 8-10
G
GPRS
data connection . . . . . . . . . . . . . . . . . . . 5-2, 5-4, 5-5
data disconnect . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
registry file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
settings
services . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
WAN configuration . . . . . . . . . . . . . . . . . . . . . . . 5-4
GSM
access point name . . . . . . . . . . . . . . . . . . . . . . . 5-4
configure GPRS data connection . . . . . . . . .5-2, 5-4
ensuring network coverage . . . . . . . . . . . . . .5-2, 5-3
GPRS data connection . . . . . . . . . . . . . . . . . . . . 5-5
settings
networks . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-13
phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
H
hard reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8, 1-9
headset . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3, 2-1, 2-34
holster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
I
image update
deploying CAB files . . . . . . . . . . . . . . . . . . . . . . . 4-5
information, service . . . . . . . . . . . . . . . . . . . . . . . . . .xviii
installing battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
internet
disconnecting GPRS . . . . . . . . . . . . . . . . . . . . . . 5-7
via GPRS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
wireless connection . . . . . . . . . . . . . . . . . . . 5-4, 6-6
K
keypads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiv
L
lithium-ion battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
locking EDA . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10, 4-2
M
magnetic stripe reader . . . . . . . . . . . . . . . . . . . 1-2, 2-23
installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
magnetic stripe reading . . . . . . . . . . . . . . . . . . . 2-23
troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . 8-11
main battery
charging . . . . . . . . . . . . . . . . . . . . . . . . . 1-3, 1-6, 6-1
installing . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3, 6-1
maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiv
MMC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10, 2-34
modem cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Monarch printer cable . . . . . . . . . . . . . . . . . . . . . . . 2-36
mounting bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
MSR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2, 2-23
installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
magnetic stripe reading . . . . . . . . . . . . . . . . . . . 2-23
troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . 8-11
multi media card . . . . . . . . . . . . . . . . . . . . . . . 1-10, 2-34
Index - 4
MC75 Integrator Guide
N
network
configuring GPRS WAN . . . . . . . . . . . . . . . . . . . 5-4
GSM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-13
network coverage, GSM . . . . . . . . . . . . . . . . . . .5-2, 5-3
O
O’Neil printer cable . . . . . . . . . . . . . . . . . . . . . . . . . 2-36
operating environment . . . . . . . . . . . . . . . . . . . . . . . . A-1
operating system . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xiv
P
packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
persistent storage . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
phone
activation . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2, 6-3
phone activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
phone security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
phone settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
PIN, changing for phone . . . . . . . . . . . . . . . . . . . . . . 5-9
PIN, disabling for phone use . . . . . . . . . . . . . . . . . . . 5-9
PIN, enabling for phone use . . . . . . . . . . . . . . . . . . . 5-9
pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-5
powering on EDA . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
provisioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
R
radios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xiv
RAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
random access memory . . . . . . . . . . . . . . . . . . . . . . 4-9
RAPI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
regmerge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
remote API . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
removing main battery . . . . . . . . . . . . . . . . . . . . . . . 1-12
reset
hard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-8, 1-9
soft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
rigid holster . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3, 2-1
RS232 charge cable . . . . . . . . . . . . . . . . . . . . . . . . 2-36
S
SCM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
file deployment . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
file types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
parameter indicators . . . . . . . . . . . . . . . . . . . . . 4-11
user interface . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
XML provisioning . . . . . . . . . . . . . . . . . . . . . . . 4-10
screen
calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
splash window . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
SD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
SDK
See EMDK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
secure digital card . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
device management . . . . . . . . . . . . . . . . . . . . . . 4-3
digital signatures . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
locking device . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
remote API . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
serial charge cable . . . . . . . . . . . . . . . . . . . . . . . . . . 2-36
service information . . . . . . . . . . . . . . . . . . . . . . . . . . .xviii
service provider name display . . . . . . . . . . . . . . . . . 5-17
services, CDMA
call barring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
call forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
call waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-15
caller id . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
SMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-15
voice mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-15
services, GSM
call barring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
call forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
call waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
caller id . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
text messages . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
voice mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
settings
CDMA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1, 6-7
GSM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
GSM/GPRS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
shim installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
short message service . . . . . . . . . . . . . . . . . . . . . . . 6-15
SIM card
accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
install . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
network access . . . . . . . . . . . . . . . . . . . . . . . . . 5-13
single slot USB serial cradle . . . . . . . . . . . . . . . . . . . 2-2
charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
charging indicators . . . . . . . . . . . . . . . . . . . . . . . 2-3
troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . 8-8
SMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-15
soft reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
spare battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
spare battery charger . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
charging indicators . . . . . . . . . . . . . . . . . . . . . . 2-22
setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
splash screen
Index - 5
creating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Sprint phone activation . . . . . . . . . . . . . . . . . . . . . . . 6-3
starting EDA . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3, 1-8
starting the mobile computer . . . . . . . . . . . . . . . . . . . 6-1
storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
application folder . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
cache disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
persistent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
volatile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
storage card
deploying CAB files . . . . . . . . . . . . . . . . . . . . . . . 4-4
strap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
stylus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1, 1-3
subscriber identification module . . . . . . . . . . . . . . . . 1-4
suspend . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
Symbol configuration manager . . . . . . . . . . . . . . . . . 4-9
file deployment . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
file types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
parameter indicators . . . . . . . . . . . . . . . . . . . . . 4-11
user interface . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
XML provisioning . . . . . . . . . . . . . . . . . . . . . . . 4-10
T
technical specifications . . . . . . . . . . . . . . . . . . . . . . . A-1
accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-6
temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
text messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7
cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10
EDA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
four slot Ethernet cradle . . . . . . . . . . . . . . . . . . . 8-9
four slot spare battery charger . . . . . . . . . . . . . 8-10
MSR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-11
single slot USB serial cradle . . . . . . . . . . . . . . . . 8-8
vehicle cradle . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
U
