Dovre VIN35TBE9 Datasheet

Dovre VIN35TBE9  Datasheet
http://dovre.be
Technical Data: VIN35TBE9
Product name:
VIN35TBE9
Series
VINTAGE
Type
freestanding
Style
modern
Combustible
wood
code:
01.90449.077
Dimensions WxHxD:
535x800x445 mm
Weight:
140 kg
Length of logs:
35 cm
Nominal performance:
7 kW
Minimum performance:
2.2999999999999998 kW
Maximum performance:
9 kW
Capacity:
140 m³
Efficiency:
83 %
CO emissions (13% O2):
0.05 %
Dust particles:
16 (mg/Nm³)
Ø connection:
150 mm
Height of connection:
660 mm
Location connection:
connection on top or rear
Minimum pression:
12 mbar
Flue gas volume:
4.9000000000000004 g/s
Distance from flammable objects: behind: 100 mm
Distance from flammable objects: side:
500 mm
Distance from flammable objects: front:
800 mm
Heat shield:
inclusive
Floor:
refractory bottom with ash hatch
Ashtray:
inclusive
e-mail:
yes
Outside air connection:
inclusive
