Technical Data: ROCK350WB
Product name:
ROCK350WB
Series
ROCK
Type
freestanding
Style
modern
Combustible
wood
code:
01.90476.000
Dimensions WxHxD:
510x745x375 mm
Weight:
125 kg
Length of logs:
35 cm
Nominal performance:
7 kW
Minimum performance:
2.3 kW
Maximum performance:
9 kW
Capacity:
140 m³
Efficiency:
80
CO emissions (13% O2):
0.06 %
Dust particles:
34.6 (mg/Nm³)
Ø connection:
150 mm
Height of connection:
610 mm
Location connection:
connection on top or rear
Minimum pression:
12 mbar
Flue gas volume:
5.2 g/s
Distance from flammable objects: behind: 250 mm
Distance from flammable objects: side:
400 mm
Distance from flammable objects: front:
800 mm
Heat shield:
optional
Floor:
refractory bottom with ash hatch
Ashtray:
inclusive
Outside air connection:
inclusive
Fan flow:
- m³/h
Electrical connection:
-V
Max. connections:
-
Ø connection:
- mm
Thermostat:
code_thermostat_-
