Technical Data: VISTA902/V2
Product name:
VISTA902/V2
Series
VISTA
Type
fireplace
Style
modern
Combustible
wood
code:
01.93995.021
Dimensions WxHxD:
880x450x400 mm
Weight:
125 kg
Length of logs:
60 cm
Nominal performance:
14 kW
Minimum performance:
4,7 kW
Maximum performance:
16 kW
Capacity:
280 m³
Efficiency:
80 %
CO emissions (13% O2):
0,09 %
Dust particles:
39 (mg/Nm³)
Combustion system:
code_smoke_exhaust_-
Ø connection:
200 mm
Height of connection:
- mm
Location connection:
top connection
Minimum pression:
12 mbar
Flue gas volume:
10.4 g/s
Distance from flammable objects: front: 800 mm
Floor:
refractory bottom
Ashtray:
inclusive
Outside air connection:
inclusive
