32LV560H
40LV560H
43LV560H
49LV560H
55LV560H
Lodging Guest Interactive Pro:Centric
®
TVs
Commercial Mode Setup Guide
Note: Selected features shown in this guide may not be available on all models.
EXPERIENCED INSTALLER
EZ-Manager Wizard pages 12 – 19
Custom Master TV Setup pages 33 – 35
Cloning Procedures
Preliminary
P/N: 206-4316 (Draft A.2)
© Copyright 2017 LG Electronics U.S.A., Inc.
2
For Customer Support/Service, please call:
1-888-865-3026
The latest product information and documentation is available online at:
www.lg.com/us/business
MODEL and SERIAL NUMBER
The model and serial numbers of this TV are located on the back of the cabinet. For future reference, LG suggests that you record those numbers here:
Model No._________________ Serial No._______________
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
WARNING:
This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
Wash hands after handling
.
NOTE TO CABLE/TV INSTALLER:
This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the National Electrical Code
(U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of the cable entry as practical.
REGULATORY INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
Do not attempt to modify this product in any way without written authorization from LG Electronics U.S.A., Inc.
Unauthorized modification could void the user’s authority to operate this product.
COMPLIANCE:
The responsible party for this product’s compliance is: LG Electronics U.S.A., Inc.
1000 Sylvan Avenue, Englewood Cliffs, NJ 07632, USA • Phone: 1-201-816-2000
Marketed and Distributed in the United States by LG Electronics U.S.A., Inc.
1000 Sylvan Avenue, Englewood Cliffs, NJ 07632
© Copyright 2017 LG Electronics U.S.A., Inc.
206-4316 Draft A.2
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources, such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where it exits from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer or sold with the apparatus.
When a cart is used, use caution when moving the cart/ apparatus combination in order to avoid injury from tip-over.
PORTABLE CART WARNING
13. Refer all servicing to quali fi ed service personnel.
Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
14. Never touch this apparatus or antenna during a thunder or lightning storm.
15. Do not apply pressure on or scratch the TV panel during handling. Do not press against the TV panel with your hand or a sharp object such as a nail, pencil, or pen.
16. Power Cord
Caution: Check the TV specifications in the Owner’s
Manual to determine power requirements.
Periodically examine the cord of your appliance, and if its appearance indicates damage or deterioration, unplug it, discontinue use of the appliance, and have the cord replaced with an exact replacement part by an authorized servicer.
Protect the power cord from physical or mechanical abuse, such as twisting, kinking, or pinching or being closed in a door or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the appliance.
Do not use a damaged or loose power cord. Be sure to grasp the plug when unplugging the power cord. Do not pull on the power cord to unplug the TV.
Do not stick metal objects or any other conductive material into the power cord. Do not touch the end of the power cord while it is plugged in.
Do not connect too many appliances to the same AC power outlet as this could result in fire or electric shock. Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in the TV to direct air conditioning.
fi re or electric shock.
18. Outdoor Use/Wet Location
Warning: To reduce the risk of fi re or electrical shock, do not expose this product to rain, moisture or other liquids.
Do not touch the TV with wet hands. Do not install this product near fl ammable objects such as gasoline or candles or expose
Do not expose to dripping or splashing and do not place objects fi lled with liquids, such as vases, cups, etc., on or over the apparatus (e.g., on shelves above the unit).
19. Grounding
(Except for devices that are not grounded) Ensure that you connect the earth ground wire to prevent possible electric shock (i.e., a TV with a three-prong grounded AC plug must be connected to a three-prong grounded AC outlet). If grounding methods are not possible, have a quali fi ed electrician install a separate circuit breaker. Do not try to ground the unit by connecting it to telephone wires, lightning rods, or gas pipes.
20. Disconnect Device
The power plug is the disconnecting device. The power plug must remain readily accessible.
As long as this unit is connected to the AC wall outlet, it is not disconnected from the AC power source even if the unit is turned off.
(Continued on next page)
206-4316 Draft A.2
3
IMPORTANT SAFETY INSTRUCTIONS
(Continued from previous page)
21. Outdoor Antenna Grounding
If an outside antenna or cable system is connected to the product, follow the precautions below.
An outdoor antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits or where it can come into contact with such power lines or circuits as death or serious injury can occur.
Be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges.
Article 810 of the National Electrical Code (NEC) in the U.S.A. provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna-discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
Antenna Grounding According to NEC, ANSI/NFPA 70
Ground Clamp
Electric Service
Equipment
22. Cleaning
Antenna Lead in Wire
Antenna Discharge Unit
(NEC Section 810-20)
Grounding Conductor
(NEC Section 810-21)
Ground Clamps
Power Service Grounding
Electrode System (NEC
Art 250, Part H)
When cleaning, unplug the power cord and wipe gently with a soft cloth to prevent scratching. Do not spray water or other liquids directly on the TV as electric shock may occur. Do not clean with chemicals such as alcohol, thinners or benzene.
23. Transporting Product
Make sure the TV is turned off and unplugged and that all cables have been removed. It may take two or more people to carry larger TVs. Do not press against or put stress on the front panel of the TV.
24. Ventilation
Install the TV where there is proper ventilation. Do not install in a con fi ned space such as a bookcase. Do not cover the TV with cloth or other materials (e.g., plastic) while it is plugged in. Do not install in excessively dusty places.
25. If you smell smoke or other odors coming from the TV or hear strange sounds, unplug the power cord, and contact an authorized service center.
26. Keep the product away from direct sunlight.
27. When mounting a TV on the wall, make sure that none of the electrical cabling bears any of the weight of the TV. Install in accordance with the manufacturer’s instructions.
28.
Do not install this product on a wall if it could be exposed to oil or oil mist. This may damage the product and cause it to fall.
29. Do not allow an impact shock or any objects to fall into the product, and do not drop objects onto the screen.
30. Do not touch the ventilation openings, as they may become hot while the TV is operating. This does not affect the performance of the product or cause defects in the product.
31. Do not use high voltage electrical equipment near the TV
(e.g., a bug zapper). This may result in product malfunction.
32.
Dot Defect
This panel is an advanced product that contains millions of pixels. In a very few cases, you could see fi ne dots on the screen while you are viewing the TV. Those dots are deactivated pixels and do not affect the performance and reliability of the TV.
33. Generated Sound
“Cracking”: A cracking noise that occurs while the TV is on or when it is turned off is generated by plastic thermal contraction due to temperature and humidity. This noise is common for products where thermal deformation is required.
Electrical circuit humming/panel buzzing: A low level noise is generated from a high-speed switching circuit, which supplies a large amount of current to operate a product. It varies depending on the product. This generated sound does not affect the performance and reliability of the product.
34. If the TV feels cold to the touch, there may be a small “ fl icker” when it is turned on. This is normal; there is nothing wrong with the TV. Some minute dot defects may be visible on the screen, appearing as tiny red, green, or blue spots. However, they have no adverse effect on the TV’s performance. Avoid touching the screen or holding your fi nger(s) against it for long periods of time. Doing so may produce some temporary distortion effects on the screen.
35.
Displaying a still image for a prolonged period of time may cause image burn-in. Avoid displaying a fi xed image on the
TV screen for an extended length of time.
4 206-4316 Draft A.2
Table of Contents
Safety Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . 3 – 4
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Commercial Mode Overview . . . . . . . . . . . . . . . . . . . . . 6 – 9
Setup Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Pass-through Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
FTG Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Determining the TV Operating Mode . . . . . . . . . . . . . . . . 9
Pro:Centric Operation . . . . . . . . . . . . . . . . . . . . . . . . 10 – 11
Pro:Centric Interactive Menu Features . . . . . . . . . . . . . . 10
Pro:Centric Interactive Menu Navigation . . . . . . . . . . . . 10
Pro:Centric Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
EZ-Manager Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . 12 – 19
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Initiate Configuration or Exit the EZ-Manager Wizard . . 12
TV Configuration Options. . . . . . . . . . . . . . . . . . . . . . . . . . 13
Zone and Room Number Assignments . . . . . . . . . . . . . . 14
Configure Pro:Centric Settings . . . . . . . . . . . . . . . . . . . . 15
USB Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Ez Download Utility . . . . . . . . . . . . . . . . . . . . . . . . . . 20 – 22
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Accessing and Using the Ez Download Utility . . . . . . . . 20
Installer Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 – 32
Accessing the Installer Menu . . . . . . . . . . . . . . . . . . . . . 23
Using the Installer Menu . . . . . . . . . . . . . . . . . . . . . . . . . 24
Exiting the Installer Menu and Activating Settings . . . . . 24
Detailed Descriptions of Installer Menu Items . . . . . . . . 27
Custom Master TV Setup . . . . . . . . . . . . . . . . . . . . . . 33 – 35
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Clonable TV Setup Menu Features . . . . . . . . . . . . . . . . 33
Custom Master TV Setup Procedure . . . . . . . . . . . . . . . 34
Cloning Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . 36 – 39
Exporting a Clone File . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Importing a Clone File. . . . . . . . . . . . . . . . . . . . . . . . . . . 37
FTG File Manager Utilities Overview . . . . . . . . . . . . 40 – 45
Creating an FTG Configuration File . . . . . . . . . . . . . . . . 40
FTG File Manager Main Screen . . . . . . . . . . . . . . . . . . . 42
FTG Channel Map Configuration Utility . . . . . . . . . . . . . 43
FTG Channel Map Editor . . . . . . . . . . . . . . . . . . . . . . . . 44
FTG Installer Menu Configuration Utility. . . . . . . . . . . . . 45
IP Environment Setup . . . . . . . . . . . . . . . . . . . . . . . . 46 – 49
Accessing the IP Environment Menu . . . . . . . . . . . . . . . 46
Configuring the Network Connection . . . . . . . . . . . . . . . 46
Network Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Pro:Centric Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
References
Updating TV/PTC Software using a USB Memory
Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Downloading a Splash Screen Image using a USB
Memory Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Power Consumption Settings. . . . . . . . . . . . . . . . . . . . . . . 52
TV Aux Input Configuration . . . . . . . . . . . . . . . . . . . . . . . . 53
Auto Input(s) Sensing Feature . . . . . . . . . . . . . . . . . . . 54 – 55
Restoring Factory Defaults on the TV(s) . . . . . . . . . . . . . . 56
Using the TV Zoning Feature . . . . . . . . . . . . . . . . . . . . 57 – 59
LV560H Rear and Side Jack Panels . . . . . . . . . . . . . . . . . 60
External Stereo Speaker Setup . . . . . . . . . . . . . . . . . . . . . 61
Installer Remote Control Typical Key Functions . . . . . . . . 62
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63 – 64
General Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . 63
Commercial Mode Check . . . . . . . . . . . . . . . . . . . . . . . . .64
Glossary of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Document Revision History / Open Source Software
Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Back Cover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Notes
• Installer Menu content is intended for use primarily by quali fi ed TV electronics technicians.
• Refer to the applicable Owner’s Manual and/or Easy Setup Guide for additional information on TV installation, speci fi cations, maintenance, and safety instructions.
• Design and speci fi cations subject to change without prior notice. This document provides examples of typical TV displays. Your displays may vary from those shown in this document.
206-4316 Draft A.2
5
6
Commercial Mode Overview
This document describes how to set up LV560H Pro:Centric ® TVs for Commercial Mode operation. LG commercial TV functionality is based on “ownership” of the Channel Map; that is, the Channel Map resides in the TV’s CPU or Protocol Translator Card (PTC) or it resides externally from the TV (i.e., in a device from the solution provider).
These TV models are capable of Free-To-Guest (FTG) Mode operation via the TV CPU. Alternatively, the
TV can be configured for Pass-through Mode (default). When in Pass-through Mode, these TV models also allow external control via the TV’s MPI port.
Setup Checklist
Note: This document provides information specific to Commercial Mode operation. Refer to the Owner’s
Manual and/or Easy Setup Guide for information on TV installation and hardware and cable connections.
Installation
__ Unpack TV and all accessories.
__ Install batteries in the Installer Remote.
__ Install TV on VESA mount or stand.
Note: It may be advisable to make all cable connections before installing on VESA mount or stand, as appropriate.
Hardware Connections
__ Install any additional hardware as appropriate to your institution, LAN, etc.
Cable Connections
__ Make all rear jack panel connections, as appropriate.
Commercial Mode Setup
__ Complete appropriate procedures as described in this document for Commercial Mode operation.
Pass-through Mode
This mode allows you to configure individual TVs for Pro:Centric and/or FTG Mode operation. This mode also allows external control via the MPI port on the TV rear jack panel.
There are two methods for configuring individual TVs that are currently in Pass-through Mode: either using the EZ-Manager Wizard or the Custom Master TV Setup procedure as described in this document.
EZ-Manager Wizard
When the TV is in a factory default state, the EZ-Manager Wizard provides automated or manual options for con fi guring essential items for Pro:Centric operation and also provides an option for using a USB memory device to con fi gure the TV. Use the Installer Remote to make selections and complete each step.
See “EZ-Manager Wizard” on pages 12 to 19 for detailed information.
Custom Master TV Setup
The Custom Master TV Setup procedure enables you to create a customized Master TV Setup for
Pass-through Mode or FTG Mode configuration purposes. Use the Installer Remote to con fi gure Installer
Menu items as required for TV operation and set up TV features (Channel, Picture, Audio, etc.). See
“Custom Master TV Setup” on pages 33 to 35 for detailed information.
206-4316 Draft A.2
Commercial Mode Overview (Cont.)
Installer Menu
To create a Master TV Setup, you will need to know how to access the commercial controller (PTC) Installer Menu and make changes to the default values as required. If necessary, familiarize yourself with the Installer Menu and how to make and save changes. Refer to pages 23 to 32 for information on accessing the Installer Menu and for detailed descriptions of the Installer Menu items.
TV Setup Menus
On-screen setup menus control the features of the TV. Use the
Installer Remote to access the TV setup menus, and set the TV features to the desired configuration for the end user.
Cloning
Cloning refers to the process of using a Master TV Setup to configure a Target TV. The Master TV’s clonable setup menu features should be configured as part of the Master TV Setup.
If there are features in the Master TV’s setup—channel icons or labels, digital font options, etc.—that are not set or that are set incorrectly, those features also will not be set or will be set incorrectly in the Target TVs. Refer to pages 36 to 39 for detailed information on cloning requirements and procedures.
External MPI Control
To control the TV using an external MPI control device, you must use the TV’s MPI port for communication purposes.
Note: These TV models are not equipped with MPI card slots.
FTG Mode
In this mode, the TV’s CPU is con fi gured with an FTG Channel
Map, and the CPU controls and restricts the tuning operation of the TV based on this FTG Channel Map. The FTG Channel Map enables the decryption of each Pro:Idiom ® encrypted channel and also provides logical channel mapping of physical RF channels
(analog and digital) and Aux inputs. In addition, in these models,
FTG Mode provides the option to select either logical or physical tuning (see note below) during configuration.
Note: Logical channel mapping of physical RF channels eliminates dash tuning (for example, physical 19-3 can be mapped to logical channel 9). Physical channel tuning requires that you include the dash when direct entering channel numbers.
PTC INSTALLER MENU xxLV560H
CPU CTV
000 INSTALLER SEQ 000
UPN 000-000-000-000
PTC V#.##.###
ASIC D279
CPU V#.##.##.##
Typical Installer Menu
PICTURE AUDIO CHANNEL TIME
LOCK OPTION INPUT
TV Setup Menus
MY MEDIA
206-4316 Draft A.2
7
8
Commercial Mode Overview (Cont.)
FTG Mode Features
FTG Mode provides the following features:
• Logical or physical tuning of physical RF channels and Aux inputs.
• Mapping of RF channels with minor (program) numbers up to 999.
• FTG Channel Map of up to 600 channels.
• Start Channel set for RF or Aux input delivered content.
• Pro:Centric data delivery over RF or IP.
• TV Zoning option for location-speci fi c con fi guration.
LG’s FTG File Manager PC software enables you to create an FTG Con fi guration (.tlx) fi le, which may be used to con fi gure the CPU for FTG Mode. FTG File Manager utilities enable you to create/edit an FTG
Channel Map and con fi gure Installer Menu settings. You can also create a Clone (.tlx) fi le from a Master TV
Setup that may be used to con fi gure the CPU for FTG Mode.
In this mode, the TV’s CPU must be con fi gured with an FTG Channel Map and FTG Installer Menu settings using one of the following processes:
• Local: Con fi gure an individual LV560H TV via its USB port using a USB memory device / “.tlx” fi le. The fi le may be either a Clone fi le (see “Cloning Procedures” on pages 36 to 39) or an FTG Con fi guration fi le (see “FTG File Manager Utilities Overview” on pages 40 to 45).
• Remote: Con fi gure all LV560H TVs at the site using a Pro:Centric server head end device (Example:
PCS200S). Refer to the Pro:Centric Server Admin Client User Guide for further information.
While the TV is in FTG Mode:
• Users can still access the Installer Menu using an LG Installer Remote; however, all Installer Menu items will be read-only.
• Any FTG con fi guration changes must be made using a “.tlx” fi le (typically edited in the FTG File Manager).
The FTG File Manager’s FTG Channel Map Con fi guration and FTG Installer Menu Con fi guration Utilities enable you to make changes, respectively, to the FTG Channel Map and FTG Installer Menu settings as necessary. See information on local con fi guration in this document or refer to documentation for the server for information on remote management.
• If it becomes necessary to restore the TV to Pass-through Mode, there are several options that will enable you to do so. See Reference section, “Restoring Factory Defaults on the TV(s),” for further information.
Pages 40 to 45 provide overviews of the utilities that comprise the FTG File Manager. Refer to the
Free-To-Guest (FTG) File Manager User Guide for further information on the FTG File Manager.
Remote Management in FTG Mode
When the TV is configured for FTG Mode, remote management of the FTG Channel Map and FTG
Installer Menu settings is provided by a Pro:Centric server, via a Clone/Con fi guration (.tlx) file loaded on the Pro:Centric Admin Client. See the Pro:Centric Server Admin Client User Guide for further information.
206-4316 Draft A.2
Commercial Mode Overview (Cont.)
Determining the TV Operating Mode
To determine the operating mode of the TV, press MENU SETTINGS on the Installer Remote. The menu displayed depends on the operating mode. See examples below.
If the Function Menu appears, the TV is in a mode (FTG, PPV, etc.) that does not allow the end user to change the fundamental TV setup. If the TV setup menus appear, the TV is in Pass-through Mode.
ABC
ASPECT RATIO
16:9
Just Scan
Set By Program
4:3
Zoom
Move OK
Function Menu
Indicates the TV is not in Pass-through
Mode . While the TV is in this mode,
Installer Menu settings can be accessed as read-only.
PICTURE AUDIO CHANNEL TIME
TV Setup Menus
Shows that the TV is in
Pass-through Mode .
LOCK OPTION INPUT MY MEDIA
206-4316 Draft A.2
9
Pro:Centric Operation
Pro:Centric Interactive Menu Features
LG’s Pro:Centric application enables guests to locate and select television entertainment using an interactive channel guide, check the daily weather, and view hotel and surrounding amenities via custom billboards and points-of-interest maps.
Pro:Centric application features include:
• Portal and information screens/pages (including a “Welcome” page) that include branding logos.
• An optional customized user interface (custom “skins”).
• Billboards and points-of-interest maps that can be customized to focus on hotel amenities, local attractions and businesses, restaurants, news, events, etc.
• An optional Weather billboard that includes a local radar map, current conditions, and a four day forecast.
• An interactive channel guide that provides a channel list with channel icons. An electronic program guide (EPG) is an optional feature that displays up to three days of programming information viewable by channel and time.
• Video spooling that enables the hotel to deliver a video fi le to guest TVs for promotion and information purposes.
The Pro:Centric server Admin Client web editor/content wizard is provided for customer con fi guration of portal messages and billboards/maps.
Note: Customized content is typically de fi ned by the service integrator and/or hotel administrators. LG does not provide hotel-speci fi c content.
Pro:Centric Interactive Menu Navigation
An LG Pro:Centric-capable TV remote control provides access to both interactive menus and regular TV features. Press PORTAL on the remote to access the interactive menus.
Note: Interactive menu options may vary, depending on Pro:Centric features enabled for the site. The following are default interactive menus.
Channel Guide
Shows available TV networks and logical channels. When available, EPG data provides additional channel and program information.
Information
Typically displays information on hotel amenities, for example, restaurants, in-room dining, business centers, facilities, etc., as well as information on local weather and attractions.
Help
Provides help for navigating the interactive menus.
Watch TV
Removes the interactive menu from the screen and returns to the previously tuned TV channel.
10 206-4316 Draft A.2
Pro:Centric Operation (Cont.)
Pro:Centric Setup
Administration and management options for the Pro:Centric server are described in detail in the
Pro:Centric Server Admin Client User Guide . This document describes only those settings that must be speci fi ed on the TVs to enable Pro:Centric remote management and/or the Pro:Centric application.
• Remote management (TV E-Z Installation): The Pro:Centric Admin Client provides remote management facilities for downloading splash screen image and software/firmware updates as well as facilities for downloading a Clone/Configuration (.tlx) file for FTG Mode configuration.
• Pro:Centric application: The application, which operates in conjunction with FTG and PPV Modes, comprises the Pro:Centric interactive menus/features described on the previous page. Pro:Centric application settings are managed via the Pro:Centric Admin Client.
The Pro:Centric server settings can be con fi gured using one of the methods described below.
TV in Factory Default State
When the TV is in a factory default state, the EZ-Manager Wizard provides automated or manual options for con fi guring the Pro:Centric server settings.
The EZ-Manager Wizard also provides a USB con fi guration option that enables you to con fi gure a TV for
FTG Mode using a Clone/Configuration (.tlx) fi le stored on a USB memory device. The “.tlx” fi le incorporates
FTG Installer Menu settings, including Installer Menu items 098 PRO:CENTRIC and 119 DATA CHANNEL, which are used to set up the TV’s Pro:Centric feature.
Refer to “EZ-Manager Wizard” on pages 12 to 19 for further information on the EZ-Manager Wizard options.
Note: If Pro:Centric data delivery will be over IP and there is a Domain Name System (DNS) server at the site, you can create a “procentric.local” DNS entry for the Pro:Centric server that will enable automated
Pro:Centric IP con fi guration via the EZ-Manager. If there is no DNS entry for procentric.local, you will need to manually enter the Pro:Centric server IP address and port number during con fi guration.
TV in Pass-through Mode
If the TV is in Pass-through Mode, either:
• Set Installer Menu items 098 PRO:CENTRIC and 119 DATA CHANNEL to the appropriate values.
See Installer Menu information on pages 23 to 32 for further details. Also, as necessary, refer to “Custom
Master TV Setup” on pages 33 to 35 and/or cloning information on pages 36 to 39.
• Con fi gure the appropriate Pro:Centric server settings in the IP Environment / Pro:Centric Menu. You must use this option, in particular, if you wish to con fi gure IP settings for the Pro:Centric server. See
“Accessing the IP Environment Menu” on page 46 and “Pro:Centric Setup” on pages 48 to 49 for further information.
Note: When the TV is in either Pass-through Mode or FTG Mode, you can also leave Installer Menu item
119 DATA CHANNEL set to its default value (255) to enable the TV’s Data Channel Auto Search feature to set the DATA CHANNEL value. See item 119 description on page 31 for additional information.
TV in FTG Mode
If the TV is in FTG Mode, use the FTG File Manager software to update Installer Menu items #98 Pro:Centric and #119 Data Channel (along with their af fi liated fi elds). Then, transfer the FTG Installer Menu settings to the TV. Refer to the FTG Mode overview on pages 7 to 8 for further information on FTG Mode operation and con fi guration. Also, see note above regarding the option to use the TV’s Data Channel Auto Search feature to set the DATA CHANNEL value.
206-4316 Draft A.2
11
EZ-Manager Wizard
The primary purpose of the EZ-Manager Wizard is to guide you through the process (automated or manual) of configuring the essential Installer Menu items for Pro:Centric operation. The wizard will appear on the screen each time the TV is turned ON, until one of its configuration methods has been completed or the wizard is exited. Use the Installer Remote to make selections and complete each wizard step.
While the EZ-Manager Wizard is intended primarily for Pro:Centric-related con fi guration, the wizard also offers Zoning as well as USB con fi guration options.
• LV560H TVs support the TV Zoning feature, which enables location-speci fi c settings (see
Reference section, “Using the TV Zoning Feature,” for further information). The EZ-Manager
Wizard enables you to set the TV Zone # in the TV as part of the con fi guration process.
• The EZ-Manager Wizard also enables you to access the TV’s standard TV Manager / USB
Download Menu as part of the con fi guration process, if desired, to perform USB con fi guration and/or update functions.
Caution: Do NOT unplug the TV power cord or remove the antenna cable or, if applicable, the LAN cable during the con fi guration process, as doing so will interrupt the current step and may corrupt the con fi guration data.
Before You Begin
• If you plan to create a Master TV Setup using the procedure described on pages 33 to 35, be sure to exit the EZ-Manager Wizard in order to avoid setting modes that may restrict the custom setup procedure. See also “Initiate Con fi guration or Exit the EZ-Manager Wizard” below.
• If it has been completed or exited and therefore does not display, the EZ-Manager Wizard can be reactivated; however, this requires that you restore the TV to a factory default condition. See
Reference section, “Restoring Factory Defaults on the TV(s),” for further information.
• Each wizard step is allotted a time frame after which the wizard proceeds without user interaction.
If the Pro:Centric server is con fi gured on the system and if no location-speci fi c settings are required in the TV, for example, TV Zone, Label, and/or Room Number settings, you can simply turn ON the TV, and once initiated, the wizard will proceed through each of the con fi guration steps with no further user interaction.
• If any of the con fi guration steps fails, you will see a “Diagnostics” screen with an indication of the failure. You will then have the opportunity to reinitiate the con fi guration process from the previous screen or exit the EZ-Manager Wizard.
Initiate Con
fi
guration or Exit the EZ-Manager Wizard
The Welcome screen provides a brief introduction to the EZ-Manager wizard.
EZ-Manager Wizard
Welcome to LG’s EZ-Manager Wizard
• Use the EZ-Manager Wizard to con fi gure the TV for Pro:Centric operation or to con fi gure the TV using a USB memory device.
Select ‘Next’ to continue.
• If a Pro:Centric server will not be installed and/or you do not wish to use the EZ-Manager Wizard to con fi gure this TV, you may exit the wizard.
Select ‘No Pro:Centric’ to disable the Pro:Centric feature of this TV, or select ‘Exit’ to quit.
This setup wizard will start automatically in 10 seconds.
No Pro:Centric Exit Next
Note: If there is no user action in this screen within 10 seconds, the wizard will proceed to the fi rst con fi guration step. Once the wizard has proceeded, it is not possible to return to the Welcome screen; however, if you simply wish to exit the wizard, you can do so by selecting the
“Exit” option from the subsequent screen(s).
12 206-4316 Draft A.2
EZ-Manager Wizard (Cont.)
From the Welcome screen, you have the following options:
• To proceed with the EZ-Manager Wizard, use the arrow keys on the Installer Remote to select/ highlight Next , and then press OK . Then, continue to the “TV Con fi guration Options” section below.
• To exit the wizard, but retain the use of the Pro:Centric remote management feature on this TV
(i.e., Installer Menu item 119 DATA CHANNEL set to 255) in the future, use the arrow keys on the
Installer Remote to select/highlight Exit , and then press OK . In the con fi rmation pop-up window, select OK , and then press OK once more on the Installer Remote.
• If you do not intend to install a Pro:Centric server on this system and you do not wish to use the wizard’s Zoning or USB con fi guration options, exit the wizard as follows: Use the arrow keys on the Installer Remote to select/highlight No Pro:Centric , and then. This will disable the Pro:Centric feature of this TV (i.e., Installer Menu item 119 DATA CHANNEL will be set to 0). In the con fi rmation pop-up window, select OK , and then press OK once more on the Installer Remote.
TV Con
fi
guration Options
From the TV Con fi guration Options screen, you can choose how to proceed with the con fi guration of this TV (assuming you do not opt to exit the wizard, which you may also do at any time).
Note: If you intend to use the Zoning feature on the TV for location-speci fi c con fi guration purposes, select the “Zone & Room Number” option from this screen and assign the appropriate TV Zone # in the TV BEFORE you continue with additional con fi guration.
Z
EZ-Manager Wizard
1 2 3 4
TV Configuration Options
• To con fi gure the TV for Pro:Centric operation, select ‘Next’.
• To set the optional Zoning feature, select ‘Zone & Room Number’.
• To con fi gure the TV using a USB memory device, select ‘USB Con fi guration’.
Note: If there is no user action in this screen within one minute, the wizard will automatically continue to the next con fi guration step.
This setup wizard will continue automatically in 60 seconds.
USB Configuration Zone & Room Number Exit Next
Use the Left/Right arrow keys on the Installer Remote to navigate between options on this screen.
Each time you select/highlight one of the following options, the screen text and fi elds will change in accordance with your selection.
• To continue with Pro:Centric con fi guration, select Next (default) and press OK on the Installer
Remote. Refer to “Con fi gure Pro:Centric Settings” on pages 15 to 18 for additional information.
• To set the Zoning feature on this TV, select Zone & Room Number . See “Zone and Room
Number Assignments” on the following page for further information.
• To access the TV Manager / USB download options, select USB Con fi guration . See “USB
Con fi guration” on pages 18 to 19 for further information.
Note: If you choose to exit the EZ-Manager Wizard from this point on, you will have the option to save any settings made by selecting Save and Exit in the exit con fi rmation pop-up window. Or, you can exit the wizard without saving any settings by simply selecting OK in the con fi rmation pop-up window.
206-4316 Draft A.2
13
EZ-Manager Wizard (Cont.)
Zone and Room Number Assignments
You may complete one or more of the fi elds in the Zone, Label, and Room Number screen or leave them at their default settings (Zone) or blank (Label and Room Number), as desired; however, if you intend to use the Zoning feature on this TV, you MUST specify the appropriate value in the Zone fi eld as described below. See also Reference section, “Using the TV Zoning Feature,” for further information.
Note: The Zoning feature is only applicable for TVs that will be con fi gured using a “.tlx” fi le (local or remote con fi guration).
Z
EZ-Manager Wizard
1 2 3 4
Zone, Label, and Room Number
• If creating Zones for Installer Menu settings and/or Channel Mapping, select the appropriate Zone # (0-8) based on the Zone in which this TV is installed. (See Commercial Mode Setup Guide for more information.)
• Select a Label and/or use the alphanumeric keypad on the remote to input the Room Number.
• When done, select ‘Next’ to continue.
1 2 3
Q.MENU
TV DVD
INPUT
MARK
Zone Label Room Number
4 5 6
0 -----
7 8 9
VOL
CC
TIMER
DELETE
MUTE
CH
P
A CHAR/
NUM
0
DEL
PORTAL INFO GUIDE
Exit USB Configuration Zone & Room Number Next
1. Complete the appropriate fi eld(s) as described below. Use the Left/Right arrow keys on the
Installer Remote to navigate between each of the fi elds.
• Zone: Enables you to set a TV Zone # so that the TV can be con fi gured with Installer Menu and/or Setup Menu settings intended only for the assigned Zone. The Installer Menu and/ or Setup Menu settings may be provided in a Clone/Con fi guration (.tlx) fi le. If the TV is being con fi gured for FTG Mode, the TV Zone # setting also allows the TV to omit channels that have been restricted in the FTG Channel Map.
To change the TV Zone from its default value (0), navigate to the Zone fi eld at the left of the screen, and use the Up/Down arrow keys to specify the desired TV Zone # (1–8).
• Label: Allows you to select a North, South, East, or West text label for this TV. In the Label fi eld, use the Up/Down arrow keys to select the applicable label.
• Room Number: Allows you to specify the number of the room—up to 16 characters—in which the TV is located. In the Room Number fi eld, you can use the number keys on the Installer
Remote to direct enter a room number. Use the Dash key on the Installer Remote as necessary to toggle between number and letter characters in the Room Number fi eld. Also, you can use the Flashback key on the Installer Remote to delete characters in this fi eld.
2. When you are ready to continue, select the appropriate option, as follows:
• To proceed to the next EZ-Manager screen, use the arrow keys to select Next , and then press OK on the Installer Remote. Continue to the “Con fi gure Pro:Centric Settings” section on the following page.
• To use a USB memory device to complete the con fi guration, select USB Con fi guration . See
“USB Con fi guration” on pages 18 to 19 for further information
14 206-4316 Draft A.2
EZ-Manager Wizard (Cont.)
Con
fi
gure Pro:Centric Settings
Once you select “Next” from the TV Con fi guration Options screen, the Searching for Pro:Centric
Server screen is displayed.
Note: Select the “Back” button, where available, to check previous settings, as necessary.
Z
EZ-Manager Wizard
1 2 3 4
Searching for Pro:Centric Server...
It may take 1 min 32 second(s).
This step automatically searches for the Pro:Centric server.
If there is no Pro:Centric Server installed, you do not need to continue with this procedure. Please select either ‘Exit’ or ‘Manual Pro:Centric’.
Status : Tuning channel 49
TV is now searching all of the channels for the data channel...
Back Exit Manual Pro:Centric
You have the following options:
• You can allow the EZ-Manager Wizard to proceed with a series of automated steps to con fi gure the TV for Pro:Centric operation and then to look for the Pro:Centric application and maintenance
(E-Z Installation) fi les to download. In this case, the wizard uses a search algorithm to determine the Data Channel and the Pro:Centric Application Mode to set in the TV.
Continue with the “Automated Pro:Centric Con fi guration” subsection below.
• If you already know the settings (i.e., Data Channel and Pro:Centric Application Mode) that need to be con fi gured in order for the TV to connect to the Pro:Centric server and/or if the Pro:Centric server is not yet installed, you may expedite the setup process by entering this data manually.
Continue with the “Manual Pro:Centric Con fi guration” subsection on the following page.
Automated Pro:Centric Con fi guration
Note: If the server is not yet con fi gured on the system, use the manual con fi guration option to con fi gure the Pro:Centric operation. See also note below.
Note: If Pro:Centric data delivery will be over IP and there is a DNS server at the site, you can create a “procentric.local” DNS entry for the Pro:Centric server that will enable automated
Pro:Centric IP con fi guration via the EZ-Manager. If there is no DNS entry for procentric.local, you must use the manual con fi guration option to con fi gure the Pro:Centric IP operation.
Once the Pro:Centric data channel is found (a Pro:Centric Server Was Found screen will be displayed) and the Pro:Centric Application Mode is determined, the wizard will advance to the
Processing the Pro:Centric Con fi guration screen, which shows the progress of the data downloads (see example on following page). Note that some steps may require a few minutes.
If the process is successful, no further user interaction is required, though, in some instances, where the option (for example “Next”) is available, you may manually move forward to subsequent steps within the wizard to speed up the process.
(Continued on next page)
206-4316 Draft A.2
15
EZ-Manager Wizard (Cont.)
(Continued from previous page)
EZ-Manager Wizard
1 2 3 4
Processing the Pro:Centric Configuration...
Downloading the maintenance files takes several minutes.
Please wait...
20%
Retrieving files from data channel 75
Application files
Maintenance files
– Updating Configuration File
GEM app downloaded
In progress...
Warning - Do not remove AC power or the signal cables during these steps
Note: If, after completing the search, the TV is unable to fi nd the Pro:Centric data channel (while the
Searching for Pro:Centric Server screen is on display), the wizard will stop and show a Diagnostics screen that enables you to manually return to the previous screen (to reinitiate the con fi guration) or exit the wizard.
When the Pro:Centric Con fi guration is complete, an EZ-Manager Con fi guration Complete screen is displayed, and after 10 seconds, the wizard exits, and the TV turns OFF.
EZ-Manager Wizard
1 2 3 4
EZ-Manager Configuration Complete
The TV will turn off in 3 second(s).
Pro:Centric Application
Maintenance Files
Installed Components
GEM application downloaded
LV560H_Config.tlx
Reboot Turn Off
Note: With the EZ-Manager Con fi guration Complete screen on display, you can also manually turn off or reboot the TV. If desired, select Turn Off or Reboot , respectively, and then press OK on the
Installer Remote.
Manual Pro:Centric Con fi guration
1. With the Searching for Pro:Centric Server screen on display, use the Left/Right arrow keys on the Installer Remote to select Manual Pro:Centric at the bottom right of the screen, and then press OK .
In the Pro:Centric Manual Con fi guration screen (see examples on following page), you will be able to con fi gure the appropriate Pro:Centric settings in the TV. Use the Up/Down arrow keys on the Installer Remote to navigate between fi elds.
2. In the Pro:Centric Mode fi eld, use the Left/Right arrow keys to select the appropriate Pro:Centric
Application Mode—FLASH, GEM, or Con fi guration Only.
(Continued on next page)
16 206-4316 Draft A.2
EZ-Manager Wizard (Cont.)
(Continued from previous page)
Note: For remote management only, select Con fi guration Only . The TV will search for TV
E-Z Installation data downloads; however, Pro:Centric application data will not be downloaded, i.e., Installer Menu item 098 PRO:CENTRIC will be set to 0.
EZ-Manager Wizard
1 2 3 4
Pro:Centric Manual Configuration
Pro:Centric Mode
Media Type
< Configuration Only >
RF
1 Data Channel
Signal Strength
Signal Quality
0%
0%
No signal
Back Exit Next
Pro:Centric Manual Configuration Screen with RF
Media Fields
Note: By default, the Pro:Centric Manual Con fi guration screen initially shows RF con fi guration fi elds.
EZ-Manager Wizard
1 2 3 4
Pro:Centric Manual Configuration
Pro:Centric Mode Configuration Only
Media Type
Address
Port
255 255
0
255 255
Back Exit Next
Pro:Centric Manual Configuration Screen with IP
Media Fields
3. Refer to the appropriate subsection below, depending on the Pro:Centric server con fi guration, to complete the remaining fi elds.
RF Con fi guration a) In the Media Type fi eld, use the Left/Right arrow keys to select RF . b) In the Data Channel fi eld, either key in or use the Left/Right arrow keys to select the RF channel number that will be used by the Pro:Centric server as its data channel. The Data
Channel value can be set from 1 to 135.
*
IP Con fi guration a) In the Media Type fi eld, use the Left/Right arrow keys to select IP .
Note: When you select “IP” as the Media Type, the default Data Channel and Signal
Strength/Quality fi elds are replaced with (IP) Address and Port fi elds.
b) In the Address and Port fi elds, either key in or use the Left/Right arrow keys to select the appropriate values for the Pro:Centric server IP address and port number. The IP address must match the IPv4 multicast address and the port number must match the port number that is set in the Pro:Centric server.
(Continued on next page)
* PCS150R and later Pro:Centric servers do not support HRC or IRC cable channel frequencies.
206-4316 Draft A.2
17
EZ-Manager Wizard (Cont.)
(Continued from previous page)
4. Once all fi elds are completed as required, you have two options:
• To save the data entered and exit the wizard, use the arrow keys to select Exit and then press OK . In the subsequent pop-up con fi rmation window, select Save and Exit , and then press OK once more. The Pro:Centric application and/or E-Z Installation data will be downloaded to the TV at a later time. This option is useful, in particular, if the Pro:Centric server has not yet been con fi gured.
• To initiate a real-time download of Pro:Centric application and/or E-Z Installation data, use the arrow keys to select Next , and then press OK (see also note below).
Note: With RF con fi guration, Pro:Centric server data must be present on the RF channel selected as the TV’s Data Channel in order for you to select “Next” (you will see a “Data channel found” message below the Signal Quality indicator). With IP con fi guration, Pro:Centric server data must be present via the wired LAN cable connection in order for you to select
“Next” (you will see a “IP server found” message below the Port fi eld).
If you opt to initiate a real-time download in the last step, the EZ-Manager Wizard will proceed with the Pro:Centric application and/or E-Z Installation data downloads (see Processing the Pro:Centric
Con fi guration screen example on page 16). When the Pro:Centric con fi guration is complete, an
EZ-Manager Con fi guration Complete screen (see example on page 16) is displayed, and after
10 seconds, the wizard exits, and the TV turns OFF.
Note: With the EZ-Manager Con fi guration Complete screen on display, you also have the option to manually turn off or reboot the TV. If desired, select Turn Off or Reboot , respectively, and then press OK on the Installer Remote.
USB Con
fi
guration
The TV Manager / USB download options enable you to download con fi guration or software fi les individually from a USB memory device to the TV. You can also use the Ez Download utility available from the menu to select one of each type of fi le to be downloaded at one time using one process.
Each of the USB download functions requires that you have the appropriate fi le(s) loaded on a
USB memory device. If you wish to perform a software update or download a splash screen image, the software/image fi le(s) must be stored in a folder named “LG_DTV” in the root directory of the USB device. Clone/Con fi guration (.tlx) fi les should simply be stored in the root directory of the USB device.
The procedure below assumes that the desired fi le(s) is/are already loaded onto the USB device.
For further information on TV Manager / USB download options and fi le requirements, and/or for information on creating Clone/Con fi guration (.tlx) fi les, refer to the appropriate section(s) in this document.
Before You Begin
• If you intend to use the Zoning feature on this TV, make sure to assign the appropriate TV Zone # in the EZ-Manager’s Zone, Label, and Room Number screen BEFORE continuing with USB
Con fi guration. See “TV Con fi guration Options” on page 13 for further information.
(Continued on next page)
18 206-4316 Draft A.2
EZ-Manager Wizard (Cont.)
(Continued from previous page)
• Ensure the USB device to be used has been formatted with FAT format.
• When creating fi les to be downloaded, avoid using special characters (?, &, @, etc.) in fi lenames.
• Refer to “Ez Download Utility” on pages 20 to 22 for further information on the Ez Download utility.
• Refer to “Custom Master TV Setup” on pages 33 to 35 for information on creating a Clone (.tlx) file, and/or refer to “Creating an FTG Con fi guration File” on pages 40 to 41 for information on creating a FTG Con fi guration (.tlx) fi le for FTG Mode con fi guration.
• See Reference section, “Downloading a Splash Screen Image using a USB Memory Device,” for splash screen image guidelines.
• See Reference section, “Updating TV/PTC Software using a USB Memory Device,” for further information on software updates.
USB Con fi guration via EZ-Manager Wizard
With either the TV Con fi guration Options or the Zone, Label, and Room Number screen on display, proceed as follows to con fi gure the TV using the USB memory device.
1. Insert the USB memory device with the appropriate fi le(s) into the TV’s USB port.
2. Use the arrow keys on the Installer Remote to select USB Con fi guration , and then press OK .
You will be redirected to the TV Manager / USB download options.
TV Manager
USB
Diagnostics
Previous
Ez Download
Logo Image Download
Update TV Software
Update PTC Software
Import Clone File
Note: You can press on the Installer Remote at any time to return to the EZ-Manager Wizard.
OK
3. Select the appropriate option from the TV Manager, and initiate the desired download(s).
Update progress will be displayed on the screen. Do NOT remove the USB device while updates are in progress. When the update process is complete, the TV will reboot. Upon restart, depending on the type of update(s) completed, either the EZ-Manager TV Configuration
Options screen will be redisplayed (software and/or splash screen image updates only) or the
TV will tune according to the Start Channel setting in the Installer Menu (TV configured with
Clone/Configuration file).
Note: If the TV Configuration Options screen is redisplayed (software and/or splash screen image updates only), you can either proceed with configuration via the EZ-Manager Wizard or exit the EZ-Manager Wizard, as required.
4. Remove the USB memory device, and verify that the appropriate configuration/update(s) is/ are resident on the TV.
206-4316 Draft A.2
19
Ez Download Utility
The Ez Download utility, available from the TV Manager, enables you to select multiple fi les at one time from the fi les loaded on a USB memory device. You may use this utility to download any one or all of the following to a TV:
• One Clone or FTG Con fi guration (.tlx) fi le
• One TV CPU software update
• One PTC software update
• One splash screen image
Before You Begin
• Ensure the USB device has been formatted with FAT format.
• Software update and splash screen image fi les must be stored in a folder named “LG_DTV” in the root directory of the USB memory device. Clone/Con fi guration (.tlx) fi les should simply be stored in the root directory of the USB device.
• If the EZ-Manager Wizard appears on the screen when you turn ON the TV, you can use the wizard’s “USB Con fi guration” option to access the Ez Download utility (see “TV Con fi guration
Options” and/or “USB Con fi guration” on pages 13 and 18, respectively, as necessary).
• If the TV is currently in Pass-through Mode and you intend to use the TV Zoning feature for location-speci fi c con fi guration purposes, make sure to assign the appropriate TV Zone # in the
TV when directed to do so in the procedure below.
• When creating fi les to be downloaded, avoid using special characters (?, &, @, etc.) in fi lenames.
• Refer to “Custom Master TV Setup” on pages 33 to 35 for information on creating a Clone (.tlx) file, and/or refer to “Creating an FTG Con fi guration File” on pages 40 to 41 for information on creating an FTG Con fi guration (.tlx) fi le for FTG Mode con fi guration.
• See Reference section, “Downloading a Splash Screen Image using a USB Memory Device,” for splash screen image guidelines.
• See Reference section, “Updating TV/PTC Software using a USB Memory Device,” for further information on software updates.
Caution: Do not unplug the TV power cord or remove the USB memory device during a data download, as doing so may cause the TV to malfunction or harm the
USB device, respectively.
Accessing and Using the Ez Download Utility
1. If it is not ON already, turn ON the TV.
2. The next step depends on whether the EZ-Manager Wizard appears on the screen when you turn ON the TV:
• If the wizard is displayed, you can complete the Ez Download utility via the wizard, as indicated above (see “Before You Begin”). However, to continue with this procedure and access the Ez
Download utility from the TV menus, exit the EZ-Manager Wizard. Then, continue with step 3.
• If the wizard is not displayed, go directly to step 3.
(Continued on next page)
20 206-4316 Draft A.2
Ez Download Utility (Cont.)
(Continued from previous page)
3. If the TV is currently in Pass-through Mode, you would like to transfer
(import) a “.tlx” fi le to the TV via the Ez Download utility, and you intend to use the TV Zoning feature, assign the appropriate TV Zone # in the TV at this time. See Reference section, “Using the TV Zoning Feature,” for further information.
Note: In order for the proper location-speci fi c TV Zone pro fi le data to be applied, the Zone designation must be assigned in the Target TV(s) BEFORE you continue with the Ez Download utility.
4. Insert the USB memory device with the appropriate fi le(s) into the TV’s
USB port.
5. To access the TV Manager from the TV menus:
• Press MENU SETTINGS on the Installer Remote to display the TV setup menus (TV is in Pass-through Mode) or the Function Menu (TV is not in Pass-through Mode).
• Use the arrow navigation keys to select/highlight either the Option menu icon from the TV setup menus or the Lock menu icon from the
Function Menu. Then, press the number “ 7 ” key a total of seven times.
6. With the TV Manager / USB download options on display, use the Up/
Down arrow keys to select Ez Download , and then press OK .
The Ez Download utility screen contains a listing of the CPU (EPK),
PTC, and LOGO (splash screen image) fi les stored in the LG_DTV folder and the TLX (Clone/Con fi guration) fi les stored in the root directory on the USB device.
Note: Press on the Installer Remote, as necessary, to exit the Ez
Download utility and/or the TV Manager. If you accessed the TV
Manager via the EZ-Manager Wizard, you will be returned to the last screen on display before you selected the “USB Con fi guration” option.
If you accessed the TV Manager via the TV menus, you will be returned to program viewing.
7. To select or de-select a fi le, respectively, use the Up/Down arrows on the Installer Remote to highlight the fi lename, and press OK to add or remove the checkmark at the left of the fi lename.
Note: The utility will only allow you to select one of each fi le type for downloading. For example, if there are two TLX fi les in the Ez Download list, you can only select one or the other of those two fi les.
Note: After the Ez Download utility is run, a fi le is automatically created and stored on the USB device that was used. The fi le, which will have a “.dzm” extension, maintains a history of the fi le(s) previously used with the Ez Download utility. The next time(s) you use this USB device with the Ez Download utility, the fi le(s) selected for the last download will be pre-selected for the current download, thus facilitating the process of con fi guring additional TVs of this model using the same USB device.
206-4316 Draft A.2
TV Manager
USB
Diagnostics
Ez Download
Logo Image Download
Update TV Software
Update PTC Software
Import Clone File
Previous OK
Note: TV Manager / Diagnostics is for service use only.
Ez Download
[TLX] xxLV560H-UA00001.TLX
[LOGO] Splash Image 1920 X 1080
[EPK] xxLV560H_CPU_SW.epk
Previous
[ TV Software Version ]
Current : ##.##.##.## (CPU)
#.##.###
EPK : ##.##.##.##
[ Forced Update Option ]
SPI Boot
LG Boot Logo
Apply
OK
Updating EPK File... 50 %
Do not remove the USB from the port! Do not unplug!
xxLV560H-UA00001.tlx
Splash Image 1920 x 1080 ProC.jpg
xxLV560H_CPU_SW.epk
(Continued on next page)
21
Ez Download Utility (Cont.)
(Continued from previous page)
8. The fi elds at the right of the screen will change depending on the currently highlighted fi le.
Select the appropriate option(s) for each fi le, as applicable.
• For software and splash screen image fi les: The fi elds at the right of the screen show the TV software versions and any available Forced Update options. Do not select any Forced Update options unless you have been speci fi cally instructed to do so or have previous experience with
Expert Software Updates.
• For Clone/Con fi guration (.tlx) fi les: If an FTG Channel Map is included in the selected Clone/
Con fi guration (.tlx) fi le, a Channel Tuning / Channel Banner Display fi eld at the right of the screen enables you to choose the format for the channel tuning/banner display. Press the green button on the Installer Remote to select Logical tuning, or press the yellow button on the Installer Remote to select Physical tuning. A checkmark will appear at the left of the selected option. Logical tuning is selected by default.
Note: If the selected “.tlx” fi le does not include an FTG Channel Map, the message, “No
Channel Map in TLX fi le,” will be displayed at the right of the screen.
9. When you are ready to continue, use the arrow keys on the Installer Remote to select Apply , and then press OK .
Update progress will be shown in a new window. Do NOT remove the USB device while updates are in progress. When the Ez Download process is complete, an overview of the results will brie fl y be displayed and then, the TV will reboot.
10. Remove the USB memory device, and verify that the appropriate configuration/update(s) is/are resident on the TV.
Note: If you updated the TV configuration with a Clone/Con fi guration file, upon restart, the TV tunes according to the Start Channel setting in the Installer Menu. If a Start Channel is speci fi ed, the TV will tune to that channel, though in the case of FTG Mode con fi guration, a channel banner will only be displayed if the Start Channel is included in the FTG Channel Map (depending on your selection in step 8, the channel banner will display either the Start Channel’s logical channel number or physical RF channel number). Otherwise, the TV will either return to the last channel tuned (TV in Pass-through Mode) or tune to the fi rst channel in the FTG Channel Map (TV in FTG
Mode). In the latter case, remember that the channels in the FTG Channel Map are always arranged in logical order, regardless of your selection in step 8.
22 206-4316 Draft A.2
Use the Installer Menu to set up, change, or view operational settings. This section describes how to access, use, and exit the Installer Menu from the TV itself. However, you should also refer to the Installer Menu descriptions in this document if you are con fi guring the TV using an FTG
Con fi guration (.tlx) fi le created using LG’s FTG File Manager software.
Refer to the table on pages 25 and 26 for brief descriptions of Installer Menu items. More detailed descriptions follow the table listing.
Accessing the Installer Menu
1. Turn ON the TV.
If the EZ-Manager Wizard appears on the screen when you turn ON the TV, exit the wizard.
2. Using an Installer Remote, press MENU SETTINGS repeatedly until the on-screen display of the TV setup menus (if the TV is in Pass-through Mode) or the Function Menu (if the TV is not in Pass-through Mode) no longer toggles, and then press the Installer Menu entry sequence
(e.g., 9 8 7 6 ) + OK to access the Installer Menu.
Note: The default Installer Menu entry sequence is “9876”; however, if Installer Menu item 000
INSTALLER SEQUENCE has been modi fi ed, the entry sequence may be one of three additional options. See Installer Menu detailed descriptions for further information.
The Installer Menu opens with item 000 INSTALLER SEQ 000.
PTC INSTALLER MENU xxLV560H
CPU CTV
000 INSTALLER SEQ 000
UPN 000-000-000-000
PTC V#.##.###
ASIC D279
CPU V#.##.##.##
Typical Installer Menu
The Installer Menu header will vary depending on the TV you are setting up. In the Installer Menu footer, you can see the current software versions of the TV, as indicated.
PTC Version CPU Version
Note: If the password (entry sequence) is not entered or registered correctly, you will see the message “ENTER PASSWORD 0000” at the top of the screen instead of the Installer Menu header. Once you re-enter the correct password (e.g., press 9-8-7-6 + OK), the Installer Menu will display.
Note: If the TV is not in Pass-through Mode, the Installer Menu is accessible as read-only. Also, the TV Zone # will be indicated in the Installer Menu header under the con fi guration mode indicator described on the following page.
206-4316 Draft A.2
Installer Menu
23
Installer Menu (Cont.)
As part of the Installer Menu header (in all modes), two 3-character acronyms are displayed to indicate the TV’s current con fi guration mode. The table below lists all possible mode identi fi ers for these TV models.
Acronym
CPU-CTV
CPU-FTG
CPU-P:C
MPI-EXT
PTC-CTV
Description
Pass-through Mode with Channel Map in CPU
FTG Mode via CPU
Application Tuning Mode via CPU
External MPI Control
Pass-through Mode with Channel Map in PTC
Using the Installer Menu
Refer to the table starting on the next page for an overview of the available Installer Menu items, including their item numbers, functions, value ranges, and default values.
Installer Menu items not relevant to these TV models are not present in the Installer Menu; therefore, some numbers are missing. For example, item 006 will not appear. In addition, items that are dependent on other Installer Menu item settings will not be initially accessible. For example, item 046
STRT AUX SRCE will not display in the Installer Menu unless item 004 STRT CHANNEL is set to 0.
See Installer Menu detailed descriptions for further information.
Navigation within the Installer Menu
Use the Up/Down arrow keys on the Installer Remote to sequence through the available menu items, or access an item directly by keying in the item number and then pressing MENU SETTINGS . For example, to access the SLEEP TIMER option, which is item 015, press 0-1-5 + MENU SETTINGS.
Changing Installer Menu Settings
To change an Installer Menu item value, use the Left/Right arrow keys on the Installer Remote, or enter a valid value directly. To save the new setting, press OK , or use the Up/Down arrow keys to navigate to a new Installer Menu item if you have additional items to edit. Note that invalid values will not be saved.
Exiting the Installer Menu and Activating Settings
After you have adjusted all required Installer Menu item settings, press OK once on the Installer
Remote to save your changes; then, press OK again to exit the Installer Menu. Any changes you make will be stored in non-volatile memory.
Note: Each time you exit the Installer Menu in Pass-through Mode, all V-Chip (Parental Control) settings in the TV are reset to their default values; that is, the Lock System, if previously enabled from the Lock setup menu, will now be disabled, and the individual Parental Control settings will be restored to default values.
Caution: Installer Menu settings may affect options available from the TV setup menus or the Function Menu.
24 206-4316 Draft A.2
Installer Menu (Cont.)
Installer Menu Items 000 through 071
Item Function
000 INSTALLER SEQ
001 POWER MANAGE
002 AC ON
003 BAND/AFC
004 STRT CHANNEL
005 CHAN LOCK
007 STRT VOLUME
008 MIN VOLUME
009 MAX VOLUME
010 MUTE DISABLE
011 KEY DEFEAT
015 SLEEP TIMER
016 EN TIMER
017 ALARM
020 FEATURE LEVEL
021 V-CHIP
022 MAX BLK HRS
023 CAPTION LOCK
028 CH. OVERIDE
029 OLD OCV
030 ACK MASK
031 POLL RATE
032 TIMING PULSE
035 HDMI1 ENABLE
039 REAR AUX EN.
041 SIMPLINK EN
042 AUTO INPUTS
046 STRT AUX SRCE
047 AUX STATUS
053 DIS. CH-TIME
069 EN. CH-T COL.
070 FOR. CH-TIME
071 BCK. CH-TIME
Value Range
0 – 3
0 – 7
0 – 3
0 – 3
0 – 127, 255
0 / 1
0 – 63, 255
0 – 63
0 – 63
0 / 1
0 / 1
0 / 1
0 / 1
0 / 1
0, 16 – 24
0 / 1
0 – 99
0 / 1
0 / 1
0 / 1
0 / 1
20 – 169
186 – 227
0 – 2
0 / 1
0 – 3
0 – 255
1, 3 – 5, 7, 255
0 / 1
0 / 1
0 / 1
0 – 7
0 – 7
1
1
0
0
255
0
0
1
2
2
255
0
63
0
0
1
0
1
0
1
12
0
1
0
0
94
207
Default Value
0
0
0
1
255
0
Brief Description of Function
Leave default set to 0.
Selects the number of hours of inactivity allowed before the TV automatically turns itself OFF. Set to 0 to disable Power Management.
Set to 1 to enable TV to turn ON when AC power is applied. Set to 2 or 3 to enable Instant ON when AC power is applied. (See detailed descriptions.)
Selects Tuning Band: 0=Broadcast, 1=CATV, 2=HRC, 3=IRC
Channel tuned when TV is turned ON. (Set to 255 to tune to channel tuned before TV turned OFF.)
If set to 1, cannot tune from current channel.
Volume level when TV is turned ON. (Set to 255 to use volume level before TV turned OFF.)
Sets minimum allowable volume setting.
Sets maximum allowable volume setting.
Set to 1 to disable Mute Function.
If set to 1, dome button menu navigation functions on display panel are not available.
Set to 1 to enable Sleep Timer.
Set to 1 to enable On/Off Timers.
Set to 1 to enable Alarm.
Determines an additional IR code scheme to which the TV will respond.
Set to 1 to enable V-Chip (Parental Control) functions.
Sets number of V-Chip blocking hours.
Set to 1 to retain caption setting set before TV turned OFF.
If set to 0, users can only tune to channels that are included in the PTC
Channel Map. (See detailed descriptions.)
Set to 1 to remap the PTC’s direct tune channels for Aux inputs from 13x to 9x.
If set to 1, enables ACK feature of MPI.
Selects poll rate for MPI.
Sets baud rate for MPI.
Set to 0 to disable HDMI 1. Set to 1 (DTV Mode) or 2 (PC Mode), as applicable, to enable HDMI 1.
Set to 1 to enable display panel AV input jack.
Determines the status of the SIMPLINK feature. (See detailed descriptions.)
Determines the Aux inputs for which auto-sensing is enabled. (See detailed descriptions.)
Sets the starting Aux source (if item 004 STRT CHANNEL is set to 0).
Set to 1 for MPI Aux source to be reported as a channel number instead of
Channel 0.
Set to 1 to disable the TV’s native Channel-Time display.
Set to 1 to enable custom color for MPI display characters.
Chooses custom foreground color for MPI display characters.
Chooses custom background color for MPI display characters.
206-4316 Draft A.2
25
Installer Menu (Cont.)
Installer Menu Items 073 through 122
Item Function
073 CH NOT AVBLE
075 REVERT CH
078 UPN MSB
079 UPN MSB-1
080 UPN MSB-2
081 UPN LSB
082 CHKSM ERROR
083 HANDSHK TIME
084 PERMANENT BLK
086 V. MUTE TIME
087 REAR RGB EN.
088 EN NOISE MUTE
090 KEY LOCK
091 HDMI2 ENABLE
092 HDMI3 ENABLE
094 SAP MENU EN
096 DEF. ASP. RATIO
097 AUDIO OUTPUT
098 PRO:CENTRIC
099 BACK LIGHTING
102 ATSC BAND
103 ATSC TUNE MODE
104 START MINOR CH
106 ASP RATIO LOCK
107 BANNER SELECT
116
117
VIDEO MUTE EN
FACT DEFAULT
119 DATA CHANNEL
121
122
UPDATE TIME HR
UPDATE TIME MN
Value Range
0 / 1
0 / 1
0 – 255
0 – 255
0 – 255
0 – 255
0 / 1
0 – 5
0 / 1
0 – 50
0, 1, 17
0 / 1
0 / 1
0 – 2
0 – 2
0 / 1
0 – 4
0 – 9
0 – 2
1 – 202, 255
0 – 4
0 / 1
0 – 255
0 / 1
0 / 1
0 / 1
0 / 1
0 – 135, 253,
255
0 – 23, 128
0 – 59
Default Value
0
0
0
0
0
0
1
5
0
0
1
1
0
1
1
1
2
7
0
255
4
1
0
0
1
0
0
255
128
0
Brief Description of Function
If set to 1 and item 028 CH. OVERIDE is set to 0, a “CHANNEL NOT
AVAILABLE” message is displayed if user attempts to direct tune a channel that is not included in the channel lineup.
If set to 1 and loss of MPI communication occurs, TV tunes to Start Channel.
User programmable number, most significant byte.
User programmable number, most significant byte - 1.
User programmable number, most significant byte - 2.
User programmable number, least significant byte.
Enforces rigid MPI checksum.
Relaxes MPI timing to be compatible with PC-based Windowscontrolled systems.
Removes block hours setting for Parental Control and makes block permanent.
Use to extend the normal video mute time during channel change.
Set to 0 to disable RGB input. Set to 1 to enable RGB input. Set to 17 for
Auto Configure.
(Analog channels only) If set to 1, audio is muted if no signal is present.
If set to 1, all display panel dome/power button functions are locked. IR is still functional.
Set to 0 to disable HDMI 2. Set to 1 (DTV Mode) or 2 (PC Mode), as applicable, to enable HDMI 2.
Set to 0 to disable HDMI 3. Set to 1 (DTV Mode) or 2 (PC Mode), as applicable, to enable HDMI 3.
Set to 1 to enable feature on Function Menu.
Sets default aspect ratio at power up. See detailed descriptions and item 106.
Set as required in accordance with external audio equipment connected to the
TV. See detailed descriptions.
Set to 0 to disable Pro:Centric operation. Set to 1 for Flash Mode. Set to 2 for
GEM (Java Application) Mode.
Sets the level of the TV picture back lighting. (See detailed descriptions.)
Selects ATSC band.
Set to 1 (default) for Physical Channel scan. Set to 0 for Virtual Channel scan.
Selects Minor Start Channel. Set to 0 for NTSC.
To retain set aspect ratio on power cycle, set to 1. Set to 0 for default ratio on power cycle.
Selects the type of banner to display during channel change.
(Analog channels only) If set to 1, video mutes (blank screen) when no signal is present.
Set to 1 to restore the factory default settings of all Installer Menu items.
Set to 0 to disable. Set from 1 to 135 to match the RF channel number used by the Pro:Centric server as its data channel. Set to 255 to use Auto Search to find the Pro:Centric RF channel. (See detailed descriptions.)
Sets the Wake For Update hour. The value “128” is displayed as “OFF.” Directly entering 128 turns the Wake For Update feature OFF.
Sets the minute for Wake For Update.
26 206-4316 Draft A.2
Installer Menu (Cont.)
Detailed Descriptions of Installer Menu Items
000 - INSTALLER SEQUENCE
Speci fi es entry sequence to the Installer Menu.
0 = 9876
2 = 1478
1 = 4321
3 = 3698
001 - POWER MANAGE (Power Management)
Energy saving feature. Determines the number of hours, in the range 1 to 7, of inactivity allowed, either at the TV control panel or from the remote, before the TV automatically turns itself OFF. If set to 0, Power Management is disabled.
002 - AC ON (AC Power Switchable)
If set to 1, this allows the TV to turn ON when AC power is applied. Pressing the POWER button is not necessary. This is desirable if the TV is plugged into a switched AC outlet (i.e., a set-top box). Set to 2 or 3 to enable the Instant ON feature (see additional information below). Set to 0 (default) for standard TV turn ON/OFF operation.
The Instant ON feature allows the TV to turn ON when AC power is applied, but with video and audio muted (Muted ON). The TV retains its ON status while appearing to be OFF. Pressing the
POWER button toggles Off/On the video and audio mutes, so that the TV appears to turn ON instantly.
• If this item is set to 2, the TV will reboot and, if applicable (i.e., item 119 DATA CHANNEL set from 1 to 135 or 253), check for and download any available updates from the Pro:Centric server at every turn OFF. This setting is not recommended if the TV will be con fi gured with a resident application.
• If this item is set to 3, the TV will not reboot to check for and download updates at turn OFF, with the following exception: the fi rst time the TV is turned OFF after this item is set to 3, the
TV will reboot and initiate an update event (Data Channel Auto
Search and/or check for and download of updates—see also paragraph below). This setting is recommended if the TV will be con fi gured with a resident application. In this mode, the standard check for and download of updates is under application control.
Refer to your site-speci fi c documentation for further information on con fi guring the TV with a resident application.
When this item is set to 2 or 3, the TV also will reboot and initiate an update event once every 24 hours. During the update event, the TV, as applicable, performs a Data Channel Auto Search (item
119 set to 255) and/or checks for and downloads any available updates from the Pro:Centric server (item 119 set from 1 to 135 or
253). The time at which this event occurs depends on the setting of item 121 UPDATE TIME HR. See item 119 and 121 descriptions for further information. Once the update cycle is complete, the TV completes the reboot and resumes its Muted ON state.
Note: If set to 1, the TV does not respond to ON/OFF commands from either the remote or the display panel, and the SLEEP TIMER is also nonfunctional.
003 - BAND/AFC (Band/Automatic Frequency Control)
There are four possible settings for this option:
0 = Broadcast
2 = HRC
1 = CATV (default)
3 = IRC
If some channels were not found by Auto Tuning (Channel
Search), select the appropriate Band setting here, and add the channels using the Channel Edit option in the Channel Menu.
004 - STRT CHANNEL (Start Channel)
If active, this function allows you to determine the initial Major
Start Channel number when the TV is turned ON. This feature is useful for an in-house information channel, since the TV would always select that channel when it is turned ON. If set to 255, the last channel tuned before the TV was turned OFF will be the channel tuned when the TV is turned ON again.
0 = Aux
1 – 125 = Major CH #
126 = Map to Major CH 3
127 = Map to Major CH 4
255 = Last Channel
Note: For a digital Start Channel, always remember to set item
104 to the Minor Start Channel number.
Note: 126 and 127 are mapped only in SONIFI PPV Mode.
Note: If setting this item to 0 (Aux), make sure to also set item 046
STRT AUX SRCE to the appropriate value.
005 - CHAN LOCK (Channel Lock)
Channel Lock is ideal if the system must always be on the same channel. Changing channels with the Channel Up/Down or keypad numbers is impossible. Channel Lock is inactive if set to 0 (default).
Generally, this feature is used in connection with item 004 STRT
CHANNEL where the Start Channel may, for example, be set to
3 or 4. If the Start Channel is 3, then the TV will remain locked on channel 3.
NOTE: For items 007, 008, and 009
For legacy reasons, the scale used is 0 – 63. The PTC software will translate this to the 0 – 100 scale used by the TV.
To translate a TV volume level to the Installer Menu value, use the following formula:
Installer Value = TV Value x 63
100
Enter only the whole number (disregard fractions).
007 - STRT VOLUME (Start Volume)
This function allows the Installer to determine the initial volume level setting when the TV is turned ON. This feature is useful for an in-house information channel, since the TV will always select that volume level when it is turned ON. The range of values is 0 to 63, 255. If set to 255, the last volume level before the TV was turned OFF will be the current volume level when the TV is turned
ON again.
206-4316 Draft A.2
27
Installer Menu (Cont.)
008 - MIN VOLUME (Minimum Volume)
This function determines the minimum volume level allowable with the Volume (VOL) Up/Down control. In this way, for example, someone cannot set the volume too low to hear. The value range is from 0 to 63. The factory default is 0, which provides the full range of volume control, if item 009 MAX VOLUME is set to 63. It is recommended to set the same value on every TV.
Note: The minimum volume level cannot have a value setting higher than the maximum volume level (described below).
020 - FEATURE LEVEL
Determines an additional IR code scheme to which the TV will respond, allowing for the use of unique IR codes based on “bed number” in a multi-TV single room installation. First determine the
IR mode; then select the bed number.
Values
0
16 – 24
IR Mode
Disabled
Multi-code Remote
Bed #
N/A
1 – 9
Note: For further information, see documentation for the accessory package that includes the multi-code remote.
009 - MAX VOLUME (Maximum Volume)
This function determines the maximum volume level allowable with the Volume (VOL) Up/Down control. In this way, for example, someone cannot set the volume level high enough to disturb others. The value range is 0 to 63, with 63 as the default, which gives the user the full range of volume control, if item 008 MIN VOLUME is set to
0. It is recommended to set the same value on every TV.
Note: The maximum volume level cannot have a value setting lower than the minimum volume level (described above).
021 - V-CHIP (Parental Control)
Set to 1 to activate V-Chip (Parental Control) and have it available to the end user to fi lter and control or otherwise restrict programming content that can appear. Set to 0 to turn the V-Chip feature
Off (not available to user); no programming restrictions can be set.
010 - MUTE DISABLE
Enables or disables sound mute function. If set to 1, sound cannot be muted. If set to 0, sound can be muted.
022 - MAX BLK HRS (Maximum Block Hours)
Sets hours from 0 to 99 for the maximum V-Chip (Parental Control) block hours. Default setting is for 12 blocking hours.
Note: This item is not available in the Installer Menu when item
084 PERMANENT BLK is set to 1.
011 - KEY DEFEAT
If set to 1, Key Defeat is enabled, which means that end users cannot access or navigate within the on-screen menu(s) from the display panel; i.e., dome button menu navigation functions will not be available. Set to 0 to disable Key Defeat. Note that all IR features remain functional regardless of this setting; users can always access the TV menus by pressing MENU SETTINGS on the remote.
Note: The dome button is only available on 55LV560H models.
On other LV560H models, a power button at the bottom of the display turns the TV ON or OFF.
015 - SLEEP TIMER
If set to 1, the Sleep Timer feature may be used. If set to 0, the
Sleep Timer is not available.
016 - EN TIMER (Enable On/Off Timers)
If set to 1, the Timer function is available to the end user and enabled continuously. Set to 0 to disable On/Off timers.
Note: The TV clock must be set in order for timers to be used.
017 - ALARM
Gives the installer the option of making the Alarm function available to the end user. If set to 1, the Alarm function is available to the end user. Set to 0 to disable the Alarm function.
Note: The TV clock must be set before the Alarm function will work.
023 - CAPTION LOCK
If set to 0, captions are OFF when the TV is turned ON. Set to 1 to use the caption setting con when the TV is turned ON.
in the PTC Channel Map.
is restricted.
030 - ACK MASK
MPI Communication Parameter. When set to 1, enables ACK feature of MPI.
fi gured before the TV was turned OFF
028 - CH. OVERIDE (Channel Override)
This item either allows or restricts tuning of channels that are NOT
If set to 1, end users can tune channels that are not in the PTC Channel Map by direct keypad entry. If set to 0, users are restricted to only the channels that are in the
PTC Channel Map. In the case of CPU-CTV Mode, there are no channels in the PTC Channel Map; therefore, direct keypad entry is not available. Also, when this item is set to 0, the PTC Channel
Map (PTC-CTV Mode)/CPU channel lineup (CPU-CTV Mode) is locked, and user access to channel settings in the TV setup menus
Note: This item is not applicable when the TV is in FTG Mode.
029 - OLD OCV (On Command Video™)
Set to 1 to remap the PTC’s direct tune channels for Aux inputs from 13x to 9x. This allows 2-digit only tuning systems (i.e., legacy
OCV) to direct tune Aux inputs. See also Reference section, “TV
Aux Input Con fi guration.”
28 206-4316 Draft A.2
Installer Menu (Cont.)
031 - POLL RATE
MPI Communication Parameter. Selects poll rate for MPI. Step size of 16 ms. Changing from default may affect communication via MPI.
047 - AUX STATUS
Set to 1 for MPI Aux source to be reported as a channel number instead of channel 0. Set to 0 to disable Aux identi fi cation change.
Controls MPI status channel response for Aux inputs.
032 - TIMING PULSE
MPI Communication Parameter. Sets baud rate for MPI. Step size of 4.3 uS. Changing from default may affect communication via
MPI.
053 - DIS. CH-TIME (Disable Channel-Time Display)
Set to 1 to disable the TV’s native Channel-Time display when a custom channel label/channel information will be provided by the
MPI command. Set to 0 to enable the TV’s native Channel-Time display.
035 - HDMI1 ENABLE
Set to 1 to enable HDMI 1 input in DTV Mode. Set to 2 to enable
HDMI 1 input in PC Mode. Set to 0 to disable display panel HDMI
1 input.
069 - EN. CH-T COL. (Enable Display Characters Custom Color)
Set to 1 to enable custom color for MPI display characters. Set to
0 to disable custom color for MPI display characters.
039 - REAR AUX EN. (Rear Aux Enable)
Set to 1 to enable display panel rear Aux (AV) input. Set to 0 to disable display panel rear Aux (AV) input.
041 - SIMPLINK EN
Set to 0 to disable the SIMPLINK feature. Set to 1 to enable
SIMPLINK functionality without enabling remote control access to the SIMPLINK Menu. Set to 2 to enable both SIMPLINK functionality and SIMPLINK Menu access, though note that the Speaker menu option will be inaccessible/grayed out. Set to 3 to enable all aspects of SIMPLINK feature and SIMPLINK Menu. If a home theater device is connected to the TV, users can select either the
TV or HT (home theater) speaker.
Note: When both this item and item 042 AUTO INPUTS are enabled in the Installer Menu, HDMI inputs will be detected by
SIMPLINK, but the Auto Input(s) Sensing Feature will not function.
042 - AUTO INPUTS
Determines the Aux inputs for which auto-sensing is enabled. Set to 0 to disable auto-sensing for all available inputs. Set to 255 to enable auto-sensing for all available inputs. For information on options for individual input settings, see Reference section, “Auto
Input(s) Sensing Feature.”
Note: In order for auto-sensing to be enabled for an input, that input must also be enabled in the Installer Menu. For example, to enable auto-sensing for HDMI 1, item 035 HDMI1 ENABLE must also be set to 1 or 2. Also, see note above regarding TV operation when both this item and item 041 SIMPLINK EN are enabled.
070 - FOR. CH-TIME (Display Characters Foreground Color)
Set the foreground color for MPI display characters according to the following color chart:
0 = Black
1 = Blue
2 = Green
3 = Cyan
4 = Red
5 = Violet
6 = Yellow
7 = White
If the foreground and background colors for the display characters are the same, the background will be transparent.
Note: This item and item 071 BCK. CH-TIME also apply to the
“Channel Not Available” message if item 073 CH NOT AVBLE is set to 1 (enabled).
Note: Items 070 FOR. CH-TIME and 071 BCK. CH-TIME are only available in the Installer Menu when item 069 EN. CH-T COL. is set to 1.
071 - BCK. CH-TIME (Display Characters Background Color)
See description for item 070 FOR. CH-TIME above. The color chart is the same for both items.
073 - CH NOT AVBLE (Channel Not Available)
If set to 1 and item 028 CH. OVERIDE is set to 0, a “CHANNEL
NOT AVAILABLE” message is displayed when a user attempts to direct tune a channel that is not included in the channel lineup.
Note:
Mode.
This item is not available in the Installer Menu when item
028 CH. OVERIDE is set to 1.
Note: This item is only applicable when the TV is in PTC-CTV
046 - STRT AUX SRCE (Start Aux Source)
Sets the starting Aux source. When turned ON, the TV will tune to starting Aux source if item 004 STRT CHANNEL is set to 0.
1 = AV
5 = HDMI 2
3 = HDMI 1
7 = HDMI 3
4 = RGB
255 = Last Aux
Note: Above is applicable only if all Aux sources are enabled.
Note: This item is not available in the Installer Menu unless item
004 STRT CHANNEL is set to 0.
075 - REVERT CH (Revert to Start Channel)
If set to 1 and loss of MPI communication occurs, TV automatically tunes to the speci fi ed Start Channel.
Note: This item is not available in the Installer Menu when item
004 STRT CHANNEL is set to 255.
078 - UPN MSB (UPN Most Signi fi cant Byte)
User programmable number, most signi fi cant byte readable by
MPI command. Note: Not linked to serial number.
206-4316 Draft A.2
29
Installer Menu (Cont.)
079 - UPN MSB-1 (UPN Most Signi fi cant Byte-1)
User programmable number, most signi fi cant byte-1 readable by
MPI command. Note: Not linked to serial number.
090 - KEY LOCK
If set to 1, Key Lock is enabled, which means that all display panel dome/power button functions will be locked, i.e., non-functional.
Set to 0 to disable Key Lock. Note that all IR features remain functional regardless of this setting.
080 - UPN MSB-2 (UPN Most Signi fi cant Byte-2)
User programmable number, most signi fi cant byte-2 readable by
MPI command. Note: Not linked to serial number.
081 - UPN LSB (UPN Least Signi fi cant Byte)
User programmable number, least signi fi cant byte readable by
MPI command. Note: Not linked to serial number.
091 - HDMI2 ENABLE
Set to 1 to enable HDMI 2 input in DTV Mode. Set to 2 to enable
HDMI 2 input in PC Mode. Set to 0 to disable display panel HDMI
2 input.
082 - CHKSM ERROR (Checksum Error)
Enforces rigid MPI checksum validation. Set to 1 for validation.
Set to 0 to disable (does not check checksum on MPI async port).
SPI is always checked.
092 - HDMI3 ENABLE
Set to 1 to enable HDMI 3 input in DTV Mode. Set to 2 to enable
HDMI 3 input in PC Mode. Set to 0 to disable display panel HDMI
3 input.
083 - HANDSHK TIME (Handshake Time)
Adds an additional delay to the handshake time which is 64 msec, thus relaxing MPI timing requirements to be compatible with PC- based Windows controlled systems. Range is 0 - 5.
(Timeout = 25.5MS + [25.5 MS* Handshake time].)
094 - SAP MENU EN (2nd Audio Program)
Set to 1 to enable SAP feature on Function Menu, if Function
Menu is available (i.e., TV is not in Pass-through Mode). Set to
0 to disable SAP feature on Function Menu, if Function Menu is available.
084 - PERMANENT BLK (Permanent Block)
Allows Lock (Parental Control) blocking schemes to be permanent by disabling the blocking hours function. Set to 1 to install Parental
Control restrictions permanently. Set to 0 for user-speci control of blocking schemes.
fi ed hours
086 - V. MUTE TIME (Video Mute Time)
Use to extend the normal video mute time during channel change.
For example, you may wish to extend the normal video mute time to prevent the display of encrypted video (i.e., from a Pro:Idiom encrypted channel) that has not yet been decrypted. When set to
0, the normal video mute time is not extended. Set from 1 to 50 to increase the normal video mute time in 100 ms step increments up to a maximum of 5 seconds (e.g., the value of 25 represents 2.5 seconds, or 25 x 100 ms = 2.5 seconds).
096 - DEF. ASP. RATIO (Default Aspect Ratio)
Selects default aspect ratio at power up:
0 = Set By Program
2 = 16:9 (default)
4 = Zoom
1 = 4:3
3 = Just Scan
Note: This item is not available in the Installer Menu unless item
106 ASP RATIO LOCK is set to 0.
087 - REAR RGB EN. (Rear RGB Enable)
Controls access to rear RGB input on TV. Set to 0 to disable RGB input. Set to 1 to enable RGB input. Set to 17 to initiate a onetime automatic con is accessed. fi guration after an AC power cycle; otherwise, automatic adjustment will be performed each time the RGB input
088 - EN NOISE MUTE (Enable Noise Mute)
Applicable for analog channels only. If set to 1, audio mutes if no signal is present.
097 - AUDIO OUTPUT
Determines availability and signal type/level ( fi xed speaker, variable speaker, or fi xed line level [ampli fi er]) of the audio output to be used by external audio equipment connected to the
SPEAKER OUT / LINE OUT jack on the TV. Set to 0 to disable audio output. Otherwise, see the table below and set as required in accordance with audio equipment. See also Reference section,
“External Stereo Speaker Specifications.”
Value
Speaker Output 1
2
3
4
5
6
Line Output
7
8
9
Status
Fixed 0.01 Watts
Fixed 0.03 Watts
Fixed 0.05 Watts
Fixed 0.10 Watts
Fixed 0.20 Watts
Fixed 0.50 Watts
Fixed 1.00 Watt (default)
Control with volume
Fixed line level (typically 400 mVrms ±
100 mVrms @10K Ω ) output
30 206-4316 Draft A.2
Installer Menu (Cont.)
098 - PRO:CENTRIC
Selects the Pro:Centric Application Mode. Set to 0 (default) to disable the Pro:Centric application. Set to 1 for Flash Mode. Set to 2 for GEM (Java Application) Mode.
In order to retrieve the Pro:Centric application, when enabled (for
Flash or GEM Mode), the TV must be turned OFF/ON two times.
Once you exit the Installer Menu, turn OFF the TV for at least one minute. When you turn the TV back ON, the TV will start the appropriate library based on the setting of this item. Wait until TV programming appears on the display, and then turn the TV back
OFF, this time for a few minutes, to initiate the application download. When you turn the TV back ON, press the PORTAL key on the Installer Remote, and verify that the Pro:Centric application appears on the display.
Note: This item is not available in the Installer Menu when item
119 DATA CHANNEL is set to 0.
099 - BACK LIGHTING
Sets the TV screen brightness at power up. Default setting is 255.
• 1 (dimmest picture) – 100 (brightest picture) Static Back Lighting
• 101 (dimmest picture) – 200 (brightest picture) Dynamic Back
Lighting: The TV automatically controls back lighting depending upon the picture level of the current program.
• 201 Automatic Static Back Lighting: The TV automatically controls back lighting by using Intelligent Sensor to detect the level of ambient lighting.
• 202 Automatic Dynamic Back Lighting: The TV automatically controls back lighting by using Intelligent Sensor to detect the level of ambient lighting and depending upon the picture level of the current program.
If set to 201 or 202, back lighting can be controlled via the Picture settings in the TV setup menus. However, each time the TV is turned ON, Picture Mode (set in Picture Menu) is defaulted to
Intelligent Sensor. If Picture Mode is manually set to a static option
(Vivid, Standard, etc.) during a viewing session, Intelligent Sensor is temporarily disabled.
If set to 255, back lighting is controlled via the Picture settings in the TV’s setup menus.
102 - ATSC BAND
Sets up TV to receive different types of incoming signals.
0 = Broadcast
3 = IRC
1 = CATV
4 = Same as NTSC
2 = HRC
103 - ATSC TUNE MODE
Sets ATSC tuning mode. Default set to 1 for Physical Channel scan. Set to 0 for Virtual Channel scan.
104 - START MINOR CHANNEL
Sets Minor Start Channel number at power up. 0 = NTSC. If not
0, number selected is the digital channel’s Minor Start Channel number.
Note: This item is not available in the Installer Menu when item
004 STRT CHANNEL is set to 0 or 255.
106 - ASP RATIO LOCK (Aspect Ratio Lock)
Set to 1 to retain previous aspect ratio with power off. Set to 0 to retain default aspect ratio with power off. See item 096 DEF. ASP.
RATIO above.
107 - BANNER SELECT
Selects the type of banner to display during channel change.
Set to 1 for channel label display, plus channel information (full banner). Set to 0 for channel label display only (small banner).
116 - VIDEO MUTE EN (Video Mute Enable)
Applicable for analog channels only. If set to 1, video mutes
(blank screen) when no signal is present.
117 - FACT DEFAULT (Factory Default)
Set to 1 and press OK to restore the factory default settings of all
Installer Menu items. Once complete, the value returns to 0.
Caution: If set to 1, this clears all Installer Menu custom settings and restores the factory default settings. It also clears the channel lineup, including any assigned channel icons and custom text labels.
Note: See also Reference section, “Restoring Factory Defaults on the TV(s),” for further information.
119 - DATA CHANNEL
Set to 0 to disable. Set from 1 to 135 to match the RF channel number that will be used by the Pro:Centric server as its data channel. If left at the default value (255), the TV’s Data Channel
Auto Search feature will be enabled (see additional information below).
*
Data Channel Auto Search feature: When this item is set to 255
(default) once every 24 hours, the TV will initiate a search of 10 prede fi ned channels (10, 20, 30, ... 100) and then, if necessary, perform a complete search of the RF channels (1 to 135) in an attempt to fi nd the RF channel used by the Pro:Centric server as its data channel. If the Pro:Centric RF channel is found, the DATA
CHANNEL value will be changed from 255 to match the server’s
RF channel number. The time at which the Auto Search occurs depends on the setting of item 121 P:C RF WAKE HR. See item
121 description for further information.
* PCS150R and later Pro:Centric servers do not support HRC or IRC cable channel frequencies.
206-4316 Draft A.2
31
Installer Menu (Cont.)
Note: Pro:Centric updates are downloaded from the Pro:Centric server to the TV when the TV is turned OFF. While Pro:Centric updates are in progress, it is not possible to turn ON the TV.
Note: The Data Channel is automatically set to “253” if Media
Type is set to “IP” either in the EZ-Manager Wizard or in the IP
Environment / Pro:Centric Menu on the TV (see “EZ-Manager
Wizard” on pages 12 to 19 or “Pro:Centric Setup” on pages 48 to
49, respectively) or if Installer Menu item #119 Data Channel is set to “IP Address” in the FTG File Manager, which is used to con fi gure TV CPUs for FTG Mode operation. It is not possible to change the value to “253” directly in the Installer Menu.
121 - UPDATE TIME HR
Based on the settings of this item and item 122 UPDATE TIME MN, the Wake For Update feature wakes the TV once daily to check for and, if applicable, download updates from the Pro:Centric server.
Set the Wake For Update hour from 0 to 23. This item uses the
24-hour clock format. The value “128” (default) is displayed as
“OFF.” Directly entering 128 resets the default value (OFF) for this item, though note that this setting does not mean the TV will not initiate update events—see additional information below.
Under standard TV OFF/ON operating conditions (i.e., item 002 AC
ON is set to 0), a Wake For Update event occurs when the TV is
OFF and causes the TV’s CPU to temporarily turn ON, perform the update cycle, and then turn back OFF, all while the TV appears to be OFF. If item 002 AC ON is set to 2 or 3 for Instant ON, then the
TV’s CPU is always ON and Wake For Update occurs when the TV is in its Muted ON state (i.e., the TV only appears to be OFF). The
Wake For Update event causes the TV’s CPU to reboot in order to perform the update cycle and then return to its Muted ON state.
See also description for item 002.
If this item is set to 128 (OFF), the time at which a Data Channel
Auto Search (item 119 set to 255) and/or an Instant ON update
(item 002 set to 2 or 3) occurs is determined as follows: The TV initiates the search and/or checks for updates at 2:00 AM (if the
TV clock is set) or after two hours of elapsed time from when AC power was applied (if the TV clock is not set). If the TV display is ON when a Wake For Update event is to occur, the update will take place the next time the TV is turned OFF.
Note: This item is not available in the Installer Menu when item
119 DATA CHANNEL is set to 0, except when item 002 AC ON is set to 2 or 3 for Instant ON.
Note: The TV clock must be set in order for a Wake For Update event to occur at the precise time of day in accordance with item
121 and item 122 settings.
122 - UPDATE TIME MN
Set the Wake For Update minute from 0 to 59. See also description for item 121 UPDATE TIME HR above.
Note: This item is not available in the Installer Menu unless item
121 UPDATE TIME HR is set from 0 to 23.
Note: The TV clock must be set in order for a Wake For Update event to occur at the precise time of day in accordance with item
121 and item 122 settings.
32 206-4316 Draft A.2
Custom Master TV Setup
This section describes how to create a customized Master TV Setup for cloning purposes when the TV is in Pass-through Mode. All cloning (export and import) processes on the TV are performed via USB memory device / “.tlx” fi le. The Master TV Setup may be exported to a Clone (.tlx) file, which can then be used (i.e., imported) to configure either TVs that are to remain in Pass-through
Mode or TVs that are to be configured for FTG Mode.
Cloning requirements and procedures are described in detail on pages 36 to 39.
Note: You can also use the FTG File Manager to create an FTG Con fi guration (.tlx) fi le for FTG
Mode con fi guration/cloning purposes, if desired (see pages 40 to 41). However, it is not possible to customize TV setup menu settings in the FTG File Manager. If you wish to include customized
TV setup menu settings in the TV con fi guration, in addition to the channel lineup and Installer
Menu settings, perform the Master TV Setup procedure to create a Clone (.tlx) con fi guration fi le.
Before You Begin
• It is recommended that you disconnect all Aux inputs if you intend to run Auto Tuning (Channel
Search). Under certain conditions, Auto Tuning is disabled if there is an Aux input active.
• A Clone (.tlx) fi le comprises Installer Menu settings, IP Environment Menu settings (with the exception of unique TV attributes and settings), and all TV sources’ (analog, digital, AV, HDMI, etc.) clonable setup menu settings. See also “Clonable TV Setup Menu Features” list below.
• If the “.tlx” fi le (either a Clone or FTG Con fi guration fi le) to be imported on the Target TV(s) contains an FTG Channel Map, the Target TV(s) will be con fi gured for FTG Mode, though as part of the import process, you will have the option to select either logical or physical channel tuning. If you would like the Target TV(s) to remain in Pass-through Mode, the “.tlx” fi le should not include an FTG Channel Map.
Clonable TV Setup Menu Features
Channel
Auto Tuning (Channel Lineup)
Tuning
Edit
Channel
Mode
Audio
Sound
Sound
Volume
Out
AV Sync Adjust
Sound
Time
Clock
− Clock Mode (Auto/Manual)
− Time Zone
− Daylight Saving
Option
Language
Caption
Light
Note: Some menu options vary between analog and digital channels and Aux inputs.
206-4316 Draft A.2
33
Custom Master TV Setup (Cont.)
Custom Master TV Setup Procedure
1. Turn ON the TV.
The next step depends on whether the EZ-Manager Wizard appears on the screen when you turn ON the TV:
• If the wizard is displayed, the TV is in the required factory default state. Exit the wizard, and then continue with step 2.
• If the wizard is not displayed, restore the TV to a factory default condition before continuing with this procedure. See Reference section, “Restoring Factory Defaults on the TV(s),” as necessary, for further information.
2. Set Installer Menu items.
This step provides speci fi c instruction only on the Installer Menu items that should be set on a Master TV. Refer to pages 23 to 32 for detailed information on all Installer Menu items.
a) Use the Installer Remote to access the Installer Menu (see
“Accessing the Installer Menu” on page 23 for further information). b) Set Installer Menu item 003 BAND/AFC , as appropriate.
• Broadcast: Set to 0.
• HRC: Set to 2.
• CATV: Set to 1 (default).
• IRC: Set to 3. c) Set any other Installer Menu items that affect your TV programming network to the required con fi guration. For example, enable/disable
Aux inputs, set a Start Channel, etc.
d) After you have adjusted all Installer Menu item settings as required, and if you do not need to con fi gure any IP Environment settings (see note below) press OK once on the Installer Remote to save your changes; then, press OK again to exit the menu.
Note: If you intend to con fi gure settings in the IP Environment Menu, which is accessible from the Installer Menu, you can proceed directly to step 3. All Installer Menu settings will be saved automatically when you access the IP Environment Menu.
3. Con fi gure IP Environment settings.
Note: You cannot return directly to the Installer Menu from the IP
Environment Menu; thus, you may wish to set all Installer Menu items as needed before you access the IP Environment Menu. Otherwise, you will need to reaccess the Installer Menu to set additional items.
Navigate to Installer Menu item 119 DATA CHANNEL, and press
2 5 3 + MENU SETTINGS to launch the IP Environment Menu. Then, complete network con fi guration as required. See “IP Environment
Setup” on pages 46 to 49 for further information.
PTC INSTALLER MENU xxLV560H
CPU CTV
000 INSTALLER SEQ 000
UPN 000-000-000-000
PTC V#.##.###
ASIC D279
CPU V#.##.##.##
Typical Installer Menu
003 BAND/AFC 001
Adjust the value for this
Installer Menu item, as required.
(Continued on next page)
34 206-4316 Draft A.2
Custom Master TV Setup (Cont.)
(Continued from previous page)
4. Set up TV features.
On-screen setup menus control the features of the TV. Press MENU
SETTINGS on the Installer Remote to access the TV setup menus, and then set Channel, Picture, Audio, Time, etc. options to the desired configurations. See “Clonable TV Setup Menu Features” list on page 33 and also notes below.
Note: If you intend to use the TV Zoning feature, make sure to assign the appropriate TV Zone # at this time as described in
Reference section, “Using the TV Zoning Feature.”
Note: If desired and if appropriate, you can run Auto Tuning (see step 5) prior to completing this step.
5. (Optional) Run Auto Tuning.
If you are creating a Master TV Setup for cloning purposes and you want the Target TV(s) to remain in Pass-through Mode, do
NOT run Auto Tuning. If you export a Master TV Setup that includes an auto-tuned/edited channel lineup, thereby creating a Clone (.tlx) file with an FTG Channel Map, and then import the Clone file on a
Target TV, this will put the Target TV in FTG Mode.
Note: When you import a Clone/Configuration (.tlx) file that contains an FTG Channel Map on a Target TV (for FTG Mode configuration), you will have the option to select either logical or physical channel tuning. For either selection, the channel sequence will be based on the order in which the channels appear in FTG Channel Map. You can view and/or edit the channel sequence in the FTG File Manager, as required.
a) Use the Installer Remote to access the Channel Menu. Then, select Auto Tuning and follow the on-screen instructions to search for all available analog and digital channels.
b) Use the Channel Edit option in the Channel Menu to edit the channel lineup, as necessary. Add/delete channels per your system requirements.
6. Verify the TV setup.
Make sure the TV features are set per your requirements. Also, if applicable, verify that the channel lineup is correct.
The Master TV Setup is now ready to be saved (exported) to a USB memory device. See “Cloning Procedures” on pages 36 to 39.
PICTURE AUDIO CHANNEL TIME
LOCK OPTION INPUT MY MEDIA
Use the TV setup menus to set the TV features to the desired configuration for the end user.
CHANNEL
• Auto Tuning
• Manual Tuning
• Channel Edit
• Channel Label
Move OK
(Optional) Use Channel Menu options to run Auto Tuning, edit channels, and select channel icons.
206-4316 Draft A.2
35
Cloning Procedures
Cloning typically refers to the process of using a Master TV Setup to configure a
Target TV. This section describes how to save (export) a Master TV Setup and then transfer (import) it to a Target TV using a USB memory device / Clone (.tlx) fi le.
You can also create an FTG Con fi guration (.tlx) fi le using the FTG File Manager and then use the Import Clone File procedure to transfer the con fi guration to Target TVs.
Refer to “Creating an FTG Con fi guration File” on pages 40 to 41, as necessary.
Exporting a Clone File
This section describes how to export Master TV Setup con fi guration to a
USB memory device / Clone (.tlx) fi le.
Before You Begin
• Ensure the USB device has been formatted with FAT format.
• If the TV is NOT already in FTG Mode, complete the Custom Master TV
Setup procedure (see pages 33 to 35).
• If you would like the Target TV(s) to remain in Pass-through Mode after the
Clone fi le is imported, ensure the Master TV does not have an auto-tuned/ edited channel lineup; otherwise, importing the exported fi le will result in the
Target TV(s) being con fi gured for FTG Mode.
• If you intend to use the TV Zoning feature, make sure to assign the appropriate TV Zone # as described in Reference section, “Using the TV
Zoning Feature,” BEFORE performing the procedure below.
• It is not possible to clone a Master TV’s clock. Either set a Target TV’s clock manually, or use the Auto Clock setting in the TV setup menus.
Caution: Do not unplug the TV power cord or remove the USB memory device while exporting is in progress, as doing so may cause the TV to malfunction or harm the USB device, respectively.
Export Clone File Procedure
1. Ensure the Master TV is set up completely and turned ON.
2. Insert the USB memory device into the USB port on the Master TV.
3. Press MENU SETTINGS on the Installer Remote to display the TV setup menus (TV is in Pass-through Mode) or the Function Menu (TV is already in FTG Mode).
4. Use the arrow navigation keys to select/highlight either the Option menu icon from the TV setup menus or the Lock menu icon from the Function
Menu. Then, press the number “ 7 ” key a total of seven times to access the
TV Manager.
5. To gain access to the “Export Clone File” option in the TV Manager, key in the following number sequence on the Installer Remote: 9 8 7 6 .
6. Use the Up/Down arrow keys to select Export Clone File , and then press OK .
TV Manager
USB
Diagnostics
Ez Download
Logo Image Download
Update TV Software
Update PTC Software
Import Clone File
Export Clone File
Previous OK
Note: TV Manager / Diagnostics is for service use only.
Export Clone File
Select the fi le name and press OK to start xxLV560H-UA00001.TLX
Previous OK
Export Clone File... 25 %
Do not remove the USB from the port! Do not unplug!
xxLV560H-UA00001.tlx
(Continued on next page)
36 206-4316 Draft A.2
Cloning Procedures (Cont.)
(Continued from previous page)
7. In the Export Clone File window, to differentiate this Clone fi le from other LV560H Clone fi les, you can use the Up/Down arrow keys to change the last fi ve digits of the fi lename. Press OK when you are ready to continue.
Export progress will be shown in a new window. Do NOT remove the USB device while exporting is in progress. When the export process is complete, the TV Manager will reappear on the screen.
8. Press on the Installer Remote to exit the TV Manager, and remove the USB memory device from the Master TV.
Note: If the Master TV has a channel lineup, during the export process, logical channel numbers are automatically assigned in ascending order, starting with 0 (zero), to the physical RF channels of the TV channel lineup to create an FTG Channel Map. See also note below.
Note: If the exported Clone file is to be used for FTG Mode configuration (i.e., it contains an FTG Channel Map), it is highly recommended that you open the file in the
FTG File Manager—BEFORE transferring (importing) the file to any Target TVs—to verify FTG Channel Map and FTG Installer Menu settings. This will also enable you to confirm channels and add channel attributes, labels, etc.
Importing a Clone File
This section describes how to transfer (import) a Clone or FTG Con fi guration (.tlx) fi le from a USB memory device to a TV using the TV Manager “Import Clone File” option. The “.tlx” fi le may be created either from a Master TV Setup that was saved (exported) from a Master TV or in the FTG
File Manager.
Before You Begin
• Ensure the USB device has been formatted with FAT format.
• Avoid using special characters, such as ?, &, @, etc., in the Clone/Con fi guration (.tlx) fi lename.
• If the EZ-Manager Wizard appears on the screen when you turn ON the Target TV, you can use the wizard’s “USB Con fi guration” option to access the TV Manager and complete the import procedure (see “TV Con fi guration Options” and/or “USB Con fi guration” on pages 13 and 18, respectively, as necessary).
• You may also use the Ez Download utility to import the Clone/Con fi guration (.tlx) fi le. See “Ez
Download Utility” on pages 20 to 22 for further information.
• If the Target TV is currently in Pass-through Mode and you intend to use the TV Zoning feature— i.e., the Clone/Con fi guration (.tlx) fi le you are importing contains an FTG Channel Map and/or
FTG pro fi le(s) with TV Zone assignments—make sure to assign the appropriate TV Zone # in the
TV when directed to do so in the procedure below. See Reference section, “Using the TV Zoning
Feature,” for further information.
• If you would like the Target TV(s) to remain in Pass-through Mode after the Clone/Con fi guration
(.tlx) fi le is imported, ensure the “.tlx” fi le does not contain an FTG Channel Map; otherwise, the import procedure will result in the Target TV(s) being con fi gured for FTG Mode.
(Continued on next page)
206-4316 Draft A.2
37
Cloning Procedures (Cont.)
(Continued from previous page)
• If a Clone (.tlx) fi le (exported Master TV Setup) contains an FTG Channel Map, the physical RF channels in the FTG Channel Map have been assigned logical channel numbers (see “Exporting a
Clone File” above). When you import the Clone fi le with the FTG Channel Map on the Target TV(s), you will have the option to select either logical or physical channel tuning. Even if you select physical channel tuning, the (list of) physical RF channels in the FTG Channel Map will remain in logical order.
• If an FTG Con fi guration (.tlx) fi le (created in the FTG File Manager) contains an FTG Channel
Map, each logical channel number in the FTG Channel Map has been assigned a physical RF channel or an Aux input (the latter designated by 130-0 through 137-0—see also Reference section, “TV Aux Input Con fi guration”).
Note: When you import the FTG Con fi guration fi le on the Target TV(s), you will have the option to select either logical or physical channel tuning. If you select physical channel tuning, the physical
RF channels and Aux inputs in the FTG Channel Map will remain in logical order.
• If the Clone/Con fi guration (.tlx) fi le was edited/created in the FTG File Manager, it may contain multiple zoned FTG Installer Menu pro fi les for different TV models. Make sure it includes the appropriate Installer Menu pro fi le(s) for the Target TV(s) before performing the procedure below.
Caution: Do not unplug the TV power cord or remove the USB memory device while importing is in progress, as doing so may cause the TV to malfunction or harm the
USB device, respectively.
Import Clone File Procedure
1. Turn ON the Target TV.
2. The next step depends on whether the EZ-Manager Wizard appears on the screen when you turn ON the TV:
• If the wizard is displayed, you can complete the import procedure via the wizard, as indicated above (see “Before You Begin”). However, to continue with this procedure and access the
“Import Clone File” option from the TV menus, exit the EZ-Manager Wizard. Then, continue with step 3.
• If the wizard is not displayed, go directly to step 3.
3. If applicable (see also “Before You Begin” above), make sure to assign the appropriate Zone designation in the Target TV at this time.
Note: In order for the proper location-speci fi c TV Zone pro fi le data to be applied, the Zone designation must be assigned in the Target TV(s) BEFORE importing is initiated.
4. Insert the USB memory device with the Clone/Con fi guration (.tlx) fi le into the USB port on the
Target TV.
5. Press MENU SETTINGS on the Installer Remote to display the TV setup menus (TV is in
Pass-through Mode) or the Function Menu (TV is already in FTG Mode).
(Continued on next page)
38 206-4316 Draft A.2
Cloning Procedures (Cont.)
(Continued from previous page)
6. Use the arrow navigation keys to select/highlight either the Option menu icon from the TV setup menus or the Lock menu icon from the
Function Menu. Then, press the number “ 7 ” key a total of seven times to access the TV Manager.
7. Use the Up/Down arrow keys to select Import Clone File , and then press OK .
8. In the Import Clone File window, use the Up/Down arrow keys to select the “.tlx” fi le you want to import.
Note: Filenames of exported Clone fi les are comprised of the TV model and a fi ve-digit number, for example, xxLV560H-UA00001.TLX.
9. If the Clone/Con fi guration (.tlx) fi le includes an FTG Channel Map, select the desired Channel Tuning / Channel Banner Display option at the right side of the Import Clone File window:
• Press the green button on the Installer Remote to select
Logical tuning, or
• Press the yellow button on the Installer Remote to select
Physical tuning.
A checkmark will appear at the left of the selected option. Logical tuning is selected by default.
Note: If the “.tlx” fi le does not include an FTG Channel Map, the message, “No Channel Map in TLX fi le,” will be displayed at the right of the screen.
10. Press OK on the Installer Remote when you are ready to continue.
Import progress will be shown in a new window. Do NOT remove the
USB device while importing is in progress. When the import process is complete, an “Updating Complete” window will brie fl y be displayed, and then, the TV will reboot.
11. Remove the USB memory device from the Target TV, and verify that the appropriate configuration is now resident on the Target TV.
TV Manager
USB
Diagnostics
Previous
Import Clone File
Note: If the Target TV was previously in Pass-through Mode and the Clone/Con fi guration
(.tlx) fi le that was imported contained an FTG Channel Map, the Target TV CPU is now in FTG Mode. Upon restart, the TV tunes according to the Start Channel setting in the
Installer Menu. If a Start Channel is speci fi ed, the TV will tune to that channel, though, in the case of FTG Mode con fi guration, a channel banner will only be displayed if the Start
Channel is included in the FTG Channel Map (depending on your selection in step 9, the channel banner will display either the Start Channel’s logical channel number or physical
RF channel number). Otherwise, the TV will either return to the last channel tuned (TV in Pass-through Mode) or tune to the fi rst channel in the FTG Channel Map (TV in FTG
Mode). If the latter, remember that the channels in the FTG Channel Map are always arranged in logical order, regardless of your selection in step 9.
Ez Download
Logo Image Download
Update TV Software
Update PTC Software
Import Clone File xxLV560H-UA00001.TLX
Do not remove the USB from the port! Do not unplug!
xxLV560H-UA00001.tlx
OK
Note: TV Manager / Diagnostics is for service use only.
Previous
Updating Clone File... 50 %
Channel Tuning /
Channel Banner Display
Logical
Physical
OK
206-4316 Draft A.2
39
FTG File Manager Utilities Overview
This section provides an overview of the FTG File Manager, which is used for FTG Mode configuration.
FTG File Manager software is available online at: www.lg.com/us/business/display-solutions/ftg.
Creating an FTG Con
fi
guration File
The procedure below describes how to use the FTG File Manager utilities (see sample screens on pages
42 to 45) to create an FTG Con fi guration (.tlx) fi le that can be saved to a USB memory device. In order to enable decryption of Pro:Idiom encrypted channels, it is recommended that you create or view/ edit an FTG Con fi guration fi le using the FTG File Manager.
Note: There is also an option to save (export) FTG Con fi guration from a TV, which may be desirable or required if you want to save customized TV setup menu settings to the FTG Con fi guration fi le and/or if you do not know the RF channels at the site. See “Exporting a Clone File” on pages 36 to 37 for further information.
This procedure provides an overview of the steps required to create an FTG Configuration (.tlx) file.
Refer to the Free-To-Guest (FTG) File Manager User Guide for further information.
1. Install (if necessary) and launch the FTG File Manager (v1.3.9 or later) on the PC that will be used to create the FTG Configuration (.tlx) file.
2. You have a number of options:
• To view and/or base a new FTG Con fi guration fi le on an existing FTG Con fi guration (.tlx) fi le, click the Open button in the TLX File command section of the FTG File Manager main screen, and select/ double-click on the desired “.tlx” file.
A list of the file’s contents will be displayed in the TLX File Contents window. Either double-click on an individual item to copy it or click the Copy All button directly above the TLX File Contents window to automatically copy all the contents of the opened file to the FTG Configuration List and, if applicable,
Setup Menu List. Note, though, that while TV setup menu settings can be included in the new FTG
Configuration file, the TV setup menu settings are not available for editing.
Edit the configuration of the items in the FTG Configuration List as well as the FTG Configuration
List itself and/or the Setup Menu List, as necessary, to create a new file. Then, proceed to step 3 when you are ready to continue.
• To open an existing FTG Con fi guration (.rml) fi le created in the FTG Device Con fi guration Application to use its FTG Channel Map and/or FTG Installer Menu settings, click File and then Open from the
FTG File Manager menu bar, and select/double-click on the desired “.rml” fi le.
Edit channels and/or settings as necessary. Then, proceed to step 3 when you are ready to continue.
• Create a new FTG Channel Map using the FTG Channel Map Editor in the FTG Channel Map
Con fi guration Utility. Up to 600 channels can be defined in the FTG Channel Map.
When you are ready to continue, click Con fi gure and then FTG File Manager from the FTG File
Manager menu bar to return to the FTG File Manager main screen, and then proceed to step 3.
Note: To remove an individual item from the FTG Configuration List or the Setup Menu List, click on/ highlight the item to be removed, and then click the Remove Item button directly above the applicable
“List” window. To clear both the current FTG Configuration List and Setup Menu List contents, click the
Clear button in the List command section of the FTG File Manager main screen.
(Continued on next page)
40 206-4316 Draft A.2
FTG File Manager Utilities Overview (Cont.)
(Continued from previous page)
Note: To clear the current TLX File Contents, click the New button in the TLX File command section of the FTG File Manager main screen (above the TLX File Contents window).
3. To add an FTG Channel Map to the FTG Configuration List, click will copy the current mapped channels to the FTG Configuration List.
under FTG Channel Map. This
Note: If you make any change(s) in the FTG Channel Map Configuration Utility to the current data to be included in the FTG Configuration List, you will need to recopy the FTG Channel Map to the FTG
Configuration List.
4. (Optional) Load default FTG Installer Menu settings for the TV. In the Installer Menu Templates section of the FTG File Manager main screen:
• If it is not already selected, click the down arrow at the right of the Region fi eld, and select North
America . Then, click the down arrow at the right of the Chassis fi eld, and select the appropriate chassis from the drop-down list of available models.
• Click the Load button.
• Use the FTG Installer Menu Con fi guration Utility to modify settings, if necessary. Then, return to the
FTG File Manager main screen.
5. If you wish to change the Zone assignment for the current FTG Installer Menu settings, click on the down arrow at the right of the Zone fi eld (below the FTG Installer Menu Settings fi eld), and select the appropriate Zone (0–8).
Note: See Reference section, “Using the TV Zoning Feature,” for further information on the Zoning feature and setting the Zone # in the TV(s).
6. To add FTG Installer Menu settings to the FTG Configuration List, click under FTG Installer Menu
Settings. This will copy the selected model settings to the FTG Con fi guration List.
Note: If you make any change(s) in the FTG Installer Menu Configuration Utility to the current data to be included in the FTG Configuration List, you will need to recopy the FTG Installer Menu settings to the FTG Configuration List.
Note: Above both the FTG Con fi guration List and Setup Menu List windows, an Edit Zone fi eld enables you to change the Zone assignment for each LV560H Installer Menu and/or Setup Menu pro fi le, if desired. Select/highlight the desired pro fi le, and then click on the down arrow at the right of the applicable Edit Zone fi eld to select the appropriate Zone.
7. Click the Save button in the List command section of the FTG File Manager main screen to save the
FTG Configuration List and, if present, Setup Menu List contents to an FTG Configuration (.tlx) file on the PC’s hard drive for later use.
In the Save As pop-up window, name the file (avoid using special characters, such as ?, &, @, etc.) and click Save . The default folder path is C:\Program Files\Zenith\FTG\TLX. Note that the FTG
Configuration file will have a “.tlx” file extension.
Note: To remove an individual item from the FTG Con fi guration List or the Setup Menu List before saving the new fi le, click on/highlight the item to be removed, and then click the Remove Item button directly above the applicable window. To clear both the current FTG Con fi guration List and Setup Menu
List contents, click the Clear button in the List command section of the FTG File Manager main screen.
8. Transfer the FTG Configuration (.tlx) file to a USB memory device, and proceed to “Importing a Clone
File” on pages 37 to 39 to transfer the FTG Configuration file to an LV560H TV.
206-4316 Draft A.2
41
FTG File Manager Utilities Overview (Cont.)
FTG File Manager Main Screen
The FTG File Manager main screen enables you to compile, modify, and save FTG Configuration (.tlx) files. It also allows you to change the Zone assignment for each Installer Menu profile, if desired (see
Reference section, “Using the TV Zoning Feature,” for further information).
FTG CONFIGURATION LIST
Data to be saved in FTG
Configuration (.tlx) file. Edit profile
Zone assignments as required.
CLEAR/SAVE
FTG Configuration and Setup Menu List options.
NEW/OPEN
TLX File options.
Filename of opened FTG
Configuration (.rml) file created using FTG Device
Configuration Application.
Copy FTG Channel Map to and from FTG
Configuration List.
Copy FTG Installer Menu settings to and from FTG
Configuration List. Assign
Zone as applicable.
Load default FTG Installer
Menu for LV560H chassis.
SETUP MENU LIST
Data to be saved in FTG
Configuration file.
TLX FILE CONTENTS
Data contained in opened
FTG Configuration (.tlx) file.
Note: The data referenced in the FTG Con fi guration List is only a snapshot of the current FTG Channel Map and FTG Installer Menu settings when copied to the list. If you make any change(s) to the current data to be included in the FTG Con fi guration List, you will need to recopy
Channel Map and Installer Menu settings to the FTG Con fi guration List.
42 206-4316 Draft A.2
FTG File Manager Utilities Overview (Cont.)
FTG Channel Map Con
fi
guration Utility
The FTG Channel Map Configuration Utility enables you to create, view, edit, and print a Logical
Channel Map.
Filename of opened FTG
Configuration (.rml) file created using FTG Device Configuration
Application.
EDIT/ADD MAP
Click to open the FTG
Channel Map Editor to create or edit an FTG Channel Map
(see next page).
PRINT MAP
Click to display a printable
FTG Channel Map Report. The report can also be exported as an HTML or Text file.
206-4316 Draft A.2
43
FTG File Manager Utilities Overview (Cont.)
FTG Channel Map Editor
The FTG Channel Map Editor shows a single Logical Channel’s data and the FTG Channel Map.
LOGICAL CHANNEL MAPPING
Select a Logical Channel number. Then, assign the RF, Major, and Minor channel numbers to complete the mapping.
CUSTOM CHANNEL LABELS/ICONS
Enter custom labels and select icons by name on menu or by number.
SET CHANNEL ATTRIBUTES
Check/select Encrypted, OSD, or Blank Video.
ZONE RESTRICTION
Set Zone restriction(s) per channel. See
Reference section,
“Using the TV Zoning
Feature,” for further information.
44
ADD
After defining a new
Logical Channel, click to add channel to the FTG
Channel Map.
UPDATE
After editing an existing
Logical Channel’s data, click to commit the changes in the FTG Channel Map.
EXIT
Click to exit editor and return to FTG Channel
Map Configuration Utility.
DELETE
Click to remove highlighted channel from FTG Channel
Map.
206-4316 Draft A.2
FTG File Manager Utilities Overview (Cont.)
FTG Installer Menu Con
fi
guration Utility
CONFIGURATION SETTINGS
Select tabs for categories of Installer
Menu items to set up TV.
Filename of opened FTG Configuration
(.rml) file created using FTG Device
Configuration Application.
Notes:
• The Pro:Centric tab enables you to set up Pro:Centric-speci fi c parameters. Refer to the Free-To-
Guest (FTG) File Manager User Guide for further information.
• LAN and Hospital parameters are not applicable for these TV models.
206-4316 Draft A.2
45
IP Environment Setup
The IP Environment Menu enables you to set up the network features of the TV. With the exception of Network Connection settings, the IP
Environment settings are editable (with the Installer Remote) only if the TV is in Pass-through Mode and read-only when the TV is not in
Pass-through Mode. Also, if you intend to create a Master TV Setup for cloning purposes (see Master TV Setup procedure on pages 33 to
35), all IP Environment settings, with the exception of the Network
Connection settings, may be cloned.
Accessing the IP Environment Menu
1. Use the Installer Remote to access the Installer Menu (see
“Accessing the Installer Menu” on page 23 for further information).
2. Navigate to Installer Menu item 119 DATA CHANNEL, and press
2 5 3 + MENU SETTINGS to launch the IP Environment Menu
(see example at right).
Use the Up/Down arrow keys on the Installer Remote to select the desired menu option and then press OK . Refer to the following sections for information on each of the IP Environment setup options.
When you have completed your IP Environment con fi guration as required , press EXIT or on the Installer Remote to exit the IP
Environment Menu.
Con
fi
guring the Network Connection
This option enables you to set up the TV’s wired network connection.
1. With the IP Environment Menu on display, use the arrow keys on the Installer Remote to select Network Connection .
Then, press OK .
The fi rst of a series of Network Setting windows will be displayed on the screen.
2. If not already done, connect the appropriate cable between the
TV and the network. Then, use the arrow keys on the Installer
Remote to select Start Connection and press OK .
3. By default, the TV is con fi gured for DHCP. If con fi gured, the
DHCP server will assign an IP address to the TV once the TV successfully connects to the network, and a “Wired network is connected” message will be displayed at the top of the next
Network Setting screen (see example at right).
• If no further network con fi guration is required, use the arrow keys on the Installer Remote to select Complete and press
OK to return to the IP Environment Menu.
• If a DHCP server is not con fi gured and/or if you wish to set static IP con fi guration data for the TV, continue with step 4.
4. Use the arrow keys on the Installer Remote to select Set
Expert from the Network Setting screen, and then press OK .
46
IP Environment
• Network Connection
• Network Status
• Pro:Centric
• MAC Address: CC:2D:8C:87:8B:70
Move OK
Note: When you enter the IP Environment
Menu, the Installer Menu is exited. If you are also in the process of updating Installer Menu items, you may wish to set all items as needed before you access the IP Environment Menu.
Otherwise, you will need to reaccess the
Installer Menu to set additional items.
Network Setting
Connect a LAN cable to the back of TV.
Setting your network will enable network-related features on the TV.
Previous
Network Setting
Start Connection
Next
Previous i Wired network is connected.
For detailed settings, select [Set Expert].
Set Expert Complete
(Continued on next page)
206-4316 Draft A.2
IP Environment Setup (Cont.)
(Continued from previous page)
The next Network Setting window will enable you to specify the IP and DNS con fi guration for this TV. Auto settings will be selected by default. Use the arrow keys to select the appropriate options, and specify the con fi guration data for the IP and DNS modes. When all fi elds are completed, select
OK on the screen and press OK on the Installer Remote.
Note: You can specify a static DNS server with an autocon fi gured IP address but not vice versa.
The TV will attempt to connect to the network and you will see a progress screen that indicates status as each network element is con fi rmed. When the network is connected successfully, a “Wired network is connected” message will be displayed at the right of the screen, along with the network con fi guration data (see example at right below).
5. Select Complete (if not already selected), and then press OK on the Installer Remote to return to the IP Environment Menu.
Note: If the network connection is not successful, the progress screen will identify the network element in which the connection failed. Check your cabling and/or, if necessary, press on the
Installer Remote to verify the con fi guration data.
Network Status
This option enables you to check the status of the network connection.
1. With the IP Environment Menu on display, use the arrow keys on the Installer Remote to select Network Status .
Then, press OK .
The TV will display a status screen as it con fi rms each of the network elements—TV, Gateway, DNS, and Internet
(see example at right). If the network is connected successfully, a “Wired network is connected” message will be displayed at the right of the screen, along with the network con fi guration data.
Note: If a problem is detected, the status screen will identify the network element in which the connection failed.
Check cabling and/or con fi guration data, as necessary.
If the status screen is still on display, you can select Test and press OK to recheck the network status.
2. When the status screen shows that the network is connected, select Complete (if not already selected) and press OK on the Installer Remote to return to the IP
Environment Menu.
Note: If you wish to cancel the status check while it is in progress, select “Close” or press to return to the IP Environment Menu.
206-4316 Draft A.2
Network Setting
Select the IP setting mode.
IP Auto Setting
0 . 0 . 0 . 0
• Subnet Mask
255 . 255 . 0 . 0
0 . 0 . 0 . 0
DNS Mode
• DNS Server
DNS Auto Setting
0 . 0 . 0 . 0
OK
Previous Next
Network Status
TV
Gateway
DNS
Internet
Setting
Auto mode
Wired network is connected.
MAC Address : CC:2D:8C:87:8B:70
IP Address : 10.2.3.4
Subnet Mask : 255.255.255.0
Gateway : 10.10.10.10
DNS Server : 10.5.6.7
Test Complete
47
IP Environment Setup (Cont.)
Pro:Centric Setup
Pro:Centric options enable you to con fi gure the TV with the appropriate settings to connect to the Pro:Centric server. Use the
Up/Down arrow keys on the Installer Remote to navigate between fi elds.
1. With the IP Environment Menu on display, use the arrow keys on the Installer Remote to select Pro:Centric . Then, press OK .
2. Select/highlight the Media Type fi eld, and use the Left/Right arrow keys to select either RF or IP , as applicable.
Note: If the Media Type has already been set in the EZ-Manager
Wizard, the speci fi ed value will be re fl ected in this fi eld.
3. Refer to the appropriate subsection below to con fi gure the TV’s
Pro:Centric settings to match those of the Pro:Centric server.
While the Pro:Centric application itself is an additional feature
(see step 4), the appropriate Pro:Centric server con fi guration must be completed to enable TV E-Z Installation (splash screen, con fi guration, and software/ fi rmware) data downloads and, if con fi gured, the Pro:Centric application download.
Note: For those fi elds that permit direct entry of numerical values (for example, Server IP, Port Number, Data Channel, etc.), once you key in the maximum number of digits allowed in the highlighted fi eld, the next available fi eld will be highlighted.
RF Con fi guration
For TVs in Pass-through Mode or FTG Mode, if the Data
Channel is left at its default value (255), the TV’s Data Channel
Auto Search feature will be enabled. See Installer Menu item 119
DATA CHANNEL description on page 31 for further information.
To set the Data Channel manually, use the arrow keys on the
Installer Remote to select/highlight the Data Channel fi eld, and then either key in or use the Left/Right arrow keys to select the
RF channel number that will be used by the Pro:Centric server as its data channel. The Data Channel value can be set from 0
(disabled) to 135.
*
Note: If the Data Channel has already been set in the Installer
Menu (Installer Menu item 119) or in the EZ-Manager Wizard, the speci fi ed channel will appear in this fi eld. If you change the
Data Channel in this menu, Installer Menu item 119 will now show the value you entered here.
IP Environment
Move OK
Configuration Only
• Pro:Centric
Server IP
• MAC Address: CC:2D:8C:87:8B:70
Port Number
0 0
RF
0
0
Data Channel
Update Event
Update Time
12 AM
255
Off
00
0
Close
Note: Options that are initially grayed out/inaccessible in the Pro:Centric Menu are dependent upon other settings in the display. For example, if “RF” is selected in the Media Type fi eld, the Data Channel fi eld is accessible.
(Continued on next page)
* PCS150R and later Pro:Centric servers do not support HRC or IRC cable channel frequencies.
48 206-4316 Draft A.2
IP Environment Setup (Cont.)
(Continued from previous page)
IP Con fi guration
In the Server IP and Port Number fi elds, either key in or use the Left/Right arrow keys to select the appropriate values for the Pro:Centric server IP address and port number. The IP address must match the IPv4 multicast address and the port number must match the port number that is set in the Pro:Centric server.
Note: If the server IP address and port number have already been set in the EZ-Manager
Wizard, the speci fi ed data will be re fl ected in the fi elds displayed.
Note: Setting the Media Type to “IP” automatically sets the Data Channel fi eld to “253.” You cannot alter this setting unless you revert Media Type to “RF.” Also, it is not possible to direct enter “253” in the Data Channel fi eld.
4.
Select/highlight the Mode fi eld, and use the Left/Right arrow keys to select the appropriate
Pro:Centric Application Mode setting— Con fi guration Only , FLASH , or GEM . If the Pro:Centric
Mode is set to “Con fi guration Only,” Pro:Centric application data will not be downloaded.
Note: If the mode has already been set in the Installer Menu (item 098 PRO:CENTRIC) or in the EZ-Manager Wizard, the speci fi ed mode will be re fl ected in this fi eld. If you change the mode in this menu, Installer Menu item 098 will now re fl ect the value you selected here.
5. In the Update Event fi eld, use the Left/Right arrow keys to select On or Off , as required.
Based on the Update Time settings, the Wake For Update feature wakes the TV once daily to check for, and if applicable, download updates from the Pro:Centric server. See Installer Menu item
121 UPDATE TIME HR description on page 32 for additional information on Wake For Update functionality.
If you set Update Event to “On,” specify the appropriate Wake For Update time in the Update
Time fi elds, as desired. Note that the Update Time set in this menu is based on a 12-hour clock.
Ensure the AM/PM speci fi cation is set accordingly.
6. Once all fi elds are completed as required, either select Close and then press OK on the Installer
Remote or press to return to the IP Environment Menu.
206-4316 Draft A.2
49
Reference: Updating TV/PTC Software using a USB Memory Device
This section describes how to update TV (CPU) and/or PTC software using the TV Manager “Update TV Software” and/or “Update PTC Software” option(s), respectively, though you may also use the Ez Download utility to update software, if desired. See “Ez Download Utility” on pages 20 to 22 for further information.
Before You Begin
• Software update fi les must be stored in a folder named “LG_DTV” in the root directory of the USB memory device.
• Ensure the USB device has been formatted with FAT format.
Update the TV/PTC Software
Note: You can check the TV/PTC software versions by accessing the Installer
Menu with the Installer Remote. See “Accessing the Installer Menu” on page
23 for further information. PTC and CPU versions are displayed in the Installer
Menu footer.
Note for TV CPU Software Update only: If the TV detects a later version of software on the USB device, it will automatically display a dialog from which you can start the software update immediately. Otherwise, you can close the dialog, and access the TV Manager as described below.
1. Turn ON the TV, and then insert the USB memory device into the TV’s USB port.
2. Press MENU SETTINGS on the Installer Remote to display the TV setup menus (TV is in Pass-through Mode) or the Function Menu (TV is not in
Pass-through Mode).
3. Use the arrow navigation keys to select/highlight either the Option menu icon from the TV setup menus or the Lock menu icon from the Function
Menu. Then, press the number “ 7 ” key a total of seven times to access the
TV Manager.
4. Use the Up/Down arrow keys to select Update TV Software or Update PTC
Software , as applicable, and then press OK .
5. In the next window (TV Software Update or Update PTC Software depending on your selection in step 4—see also screen samples at right), use the Up/
Down arrow keys to select/highlight the update fi le to download. Then, press
OK .
Note: Do not select Forced Update options unless you have been speci fi cally instructed to do so or have previous experience with Expert Software Updates.
Software update progress will be displayed in a new window. Do NOT remove the USB device until the software update is complete. When the software update is complete, an “Updating complete” window will brie fl y be displayed and then, the TV will reboot.
TV Manager
USB
Previous
Ez Download
Logo Image Download
Update TV Software
Update PTC Software
Import Clone File i TV Software Update (Expert)
[ Current TV Software Version Information ]
EPK : ##.##.##
The following software files are found in the memory card.
Select the file you want to download to this TV or press EXIT to cancel the update.
EPK: ##.##.##
[Forced Update Option]
SPI Boot
LOGO Image xxLV560H_CPU_SW
OK
TV Manager
USB
Previous
Ez Download
Logo Image Download
Update TV Software
Update PTC Software
Import Clone File
Update PTC Software xxLV560H_PTC_SW.txt
OK
Previous OK
Note: TV Manager / Diagnostics is for service use only.
50 206-4316 Draft A.2
Reference: Downloading a Splash Screen Image using a USB Memory
Device
This section describes how to download a splash screen image using the TV
Manager “Logo Image Download” option, though you may also use the Ez Download utility to download the splash screen image, if desired. See “Ez Download
Utility” on pages 20 to 22 for further information.
Splash Screen Image File Guidelines
• The splash screen image must be a baseline (not progressive) JPEG.
• The image should be no larger than 1 MB.
• The maximum resolution allowed for a 32LV560H splash screen image is 1360 x 768 pixels (HD).
• The maximum resolution allowed for an 40/43/49/55LV560H splash screen image is 1920 x 1080 pixels (FHD).
• Avoid using special characters, such as ?, &, @, etc., in the splash screen image fi le name.
Before You Begin
• The splash screen image fi le must be stored in a folder named “LG_DTV” in the root directory of the USB memory device.
• Ensure the USB device has been formatted with FAT format.
Download the Splash Screen Image
1. Turn ON the TV, and then insert the USB memory device into the TV’s USB port.
2. Press MENU SETTINGS on the Installer Remote to display the TV setup menus (TV is in Pass-through Mode) or the Function Menu (TV is not in
Pass-through Mode).
3. Use the arrow navigation keys to select/highlight either the Option menu icon from the TV setup menus or the Lock menu icon from the Function
Menu. Then, press the number “ 7 ” key a total of seven times to access the
TV Manager.
4. Use the Up/Down arrow keys to select Logo Image Download , and then press OK .
5. In the Logo Image Download window, use the Up/Down arrow keys to select the image fi le to download, and then press OK .
Logo image update progress will be displayed in a new window. Do NOT remove the USB device until the splash screen image update is complete.
When the image update is complete, an “Updating complete” window will brie fl y be displayed, and then the TV will reboot. During the reboot, you should see the new splash screen.
TV Manager
USB
Previous
Ez Download
Logo Image Download
Update TV Software
Update PTC Software
Import Clone File
Logo Image Download
Splash-Image-JPEG
OK
Previous OK
Note: TV Manager / Diagnostics is for service use only.
206-4316 Draft A.2
51
Reference: Power Consumption Settings
The following tables assume that Installer Menu item 099 BACK LIGHTING is set as shown below
(default value is 255).
32LV560H 40LV560H
Item 099
Back Lighting
(Static)
Power
Consumption
(Watts)
Percent
Savings
Power
Consumption
(Watts)
Percent
Savings
43LV560H
Power
Consumption
(Watts)
Percent
Savings
49LV560H 55LV560H
Power
Consumption
(Watts)
Percent
Savings
Power
Consumption
(Watts)
Percent
Savings
100
30
20
10
1
90
80
70
60
50
40
24.7 0%
23.1 6%
22.2 10%
21.7 12%
21.0 15%
20.1 19%
19.3 22%
17.2 30%
14.6 41%
12.2 51%
9.7 61%
51.2 0%
47.5 7%
45.3 12%
44.0 14%
42.3 17%
40.3 21%
38.3 25%
33.2 35%
26.9 47%
21.1 59%
15.4 70%
52.5 0%
48.7 7%
46.5 11%
45.2 14%
43.5 17%
41.7 21%
39.6 25%
34.5 34%
28.1 46%
22.2 58%
16.4 69%
59.4 0%
54.8 8%
52.2 12%
50.8 14%
49.1 17%
46.7 21%
44.3 25%
38.5 35%
30.7 48%
23.9 60%
17.0 71%
81.9 0%
75.1 8%
71.1 13%
68.6 16%
65.2 20%
62.0 24%
58.0 29%
49.2 40%
37.2 55%
26.6 68%
16.1 80%
32LV560H 40LV560H
Item 099
Back Lighting
(Dynamic)
Power
Consumption
(Watts)
Percent
Savings
Power
Consumption
(Watts)
Percent
Savings
43LV560H
Power
Consumption
(Watts)
Percent
Savings
49LV560H
Power
Consumption
(Watts)
Percent
Savings
55LV560H
Power
Consumption
(Watts)
Percent
Savings
200
190
180
170
160
150
140
130
120
110
101
24.7 0%
23.1 6%
22.2 10%
21.6 13%
21.0 15%
20.1 19%
19.3 22%
17.2 30%
14.6 41%
12.1 51%
9.7 61%
51.4 0%
47.7 7%
45.6 11%
44.2 14%
42.5 17%
40.6 21%
38.6 25%
33.5 35%
27.0 47%
21.3 59%
15.5 70%
52.9 0%
49.1 7%
46.9 11%
45.6 14%
43.8 17%
41.9 21%
39.8 25%
34.7 34%
28.5 46%
22.4 58%
16.6 69%
59.6 0%
55.1 8%
52.3 12%
51.0 14%
50.1 16%
46.8 21%
44.5 25%
38.7 35%
31.2 48%
24.2 59%
17.3 71%
82.3 0%
75.5 8%
71.4 13%
68.8 16%
65.5 20%
62.3 24%
58.3 29%
49.5 40%
37.4 55%
26.8 67%
16.4 80%
Note: Values are results of controlled experiments under laboratory conditions.
52 206-4316 Draft A.2
Reference: TV Aux Input Con
fi
guration
DIRECT ACCESS
Tuning *
Installer
Menu
Item 029
OLD OCV
= 0
Installer
Menu
Item 029
OLD OCV
= 1
131-0 91-0
Aux
Input
AV
(Rear)
TV
Input
Mode
Item
ENABLE
Installer Menu
Function
MPI DATA
STATUS TYPE
0x41 SOURCES
ENABLED (R/W)
Value
Enable
Bit
Label
DATA STATUS
TYPE 0xD2
CURRENT AV
SOURCE (R)
MPI DATA
DATA STATUS
TYPE 0x0D
AUX SOURCE (R)
Value Value Description
Installer
Menu Item
046 START
AUX SRCE
(Start Aux
Source)
Value
1 Rear Video (Aux) 1 1
132-0
133-0
134-0
135-0
92-0
93-0
94-0
95-0
HDMI2
HDMI1
RGB
HDMI3
CV
DTV
PC
DTV
PC
PC
DTV
PC
39
91
REAR AUX
EN
HDMI2
ENABLE
35
87
92
HDMI1
ENABLE
REAR RGB
EN
HDMI3
ENABLE
1
1
2
1
2
1
1
2
2
3
4
5
S-Video Rear
Front
Computer
SVGA Rear
Computer
NTSC Rear
Computer
2
3
4
5
0
0
2
0
2
2
0
2
VIDEO
VIDEO
COMPUTER
VIDEO
COMPUTER
COMPUTER
VIDEO
COMPUTER
5
3
4
7
* Use Installer Remote to enter channel number indicated based on OLD OCV Installer Menu setting.
206-4316 Draft A.2
53
Reference: Auto Input(s) Sensing Feature
This section provides detailed settings information for Installer Menu item 042 AUTO INPUTS. To disable auto-sensing for all available Aux inputs, set item 042 to 0. To enable auto-sensing for all available Aux inputs, set item 042 to 255. For speci fi cations on all other available settings (i.e., settings for individual inputs), refer to the table on the following page.
Note: When both item 042 AUTO INPUTS and item 041 SIMPLINK EN are enabled in the Installer Menu,
HDMI inputs will be detected by SIMPLINK, but the Auto Input(s) Sensing Feature will not function.
In the Installer Menu, an informational code is displayed at the right of each Auto Inputs value, for example:
PTC INSTALLER MENU xxLV560H
CPU CTV
042 AUTO INPUTS 241 7654XXX0
UPN 000-000-000-000
PTC V#.##.###
ASIC D279
CPU V#.##.##.##
AUTO INPUTS Display Code
This example illustrates Installer Menu item 042 value
241, which enables auto-sensing for all available Aux inputs. The input #s in the display code (7, 6, 5, 4, 0 in this example) identify the enabled Aux inputs. See table below for a listing of the LV560H Aux inputs and their corresponding display code input #s. The table on the following page shows the display codes for all item 042 values.
Each code consists of eight characters that identify the Aux input(s) for which auto-sensing is enabled.
The following table identi fi es the Installer Menu display code Input # for each Aux input that is available on the LV560H TV models. The table also identi fi es the Installer Menu item associated with each Aux input.
Remember that in order for auto-sensing to be enabled for an input, that input must also be enabled in the
Installer Menu.
Installer Menu
Display Code
Input #
0
4
6
7
5
Aux
Input
AV
RGB
HDMI 1
HDMI 2
HDMI 3
Item
Installer Menu
Function
039
087
035
091
092
REAR AUX EN
REAR RGB EN
HDMI1 ENABLE
HDMI2 ENABLE
HDMI3 ENABLE
54 206-4316 Draft A.2
Reference: Auto Input(s) Sensing Feature (Cont.)
Item 042
Value
128
129
144
145
080
081
096
097
112
113
160
161
176
001
016
017
032
033
048
049
064
065
177
192
193
208
209
224
225
240
241
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
AV
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
RGB
Disabled
Enabled
Enabled
Disabled
Disabled
Enabled
Enabled
Disabled
Disabled
Enabled
Enabled
Disabled
Disabled
Enabled
Enabled
Disabled
Disabled
Enabled
Enabled
Disabled
Disabled
Enabled
Enabled
Disabled
Disabled
Enabled
Enabled
Disabled
Disabled
Enabled
Enabled
X = Aux input source is Disabled or Not Available (i.e., on this TV model)
D = Auto-sensing for input is Disabled
Input # = Auto-sensing for input is Enabled
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled
HDMI 2
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled
Inputs
HDMI 1
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
Disabled
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled
Disabled
Disabled
Enabled
Enabled
Enabled
Enabled
Disabled
Disabled
Disabled
Disabled
Enabled
Enabled
Enabled
HDMI 3
Disabled
Disabled
Disabled
Enabled
Enabled
Enabled
Enabled
Disabled
Disabled
Enabled
Disabled
Disabled
Disabled
Disabled
Enabled
Enabled
Enabled
Enabled
Installer Menu
Display
DDDDXXX0
DDD4XXXD
DDD4XXX0
DD5DXXXD
DD5DXXX0
DD54XXXD
DD54XXX0
D6DDXXXD
D6DDXXX0
D6D4XXXD
D6D4XXX0
D65DXXXD
D65DXXX0
D654XXXD
D654XXX0
7DDDXXXD
7DDDXXX0
7DD4XXXD
7DD4XXX0
7D5DXXXD
7D5DXXX0
7D54XXXD
7D54XXX0
76DDXXXD
76DDXXX0
76D4XXXD
76D4XXX0
765DXXXD
765DXXX0
7654XXXD
7654XXX0
206-4316 Draft A.2
55
Reference: Restoring Factory Defaults on the TV(s)
This section describes how to restore all factory defaults or just the Installer Menu factory defaults either on a single TV that is currently in Pass-through or FTG Mode or on multiple TVs that are currently in FTG Mode.
Restore All Factory Defaults
This section describes how to restore a single TV, regardless of its mode, to a factory default condition.
The following procedure requires that you contact LG technical support to obtain a prede fi ned value/ password for Installer Menu item 117 FACT DEFAULT that enables access to initiate a factory “IN-STOP” process, which restores all factory defaults. This procedure will also reactivate the EZ-Manager Wizard.
1. Use the Installer Remote to access the TV’s Installer Menu.
2. Navigate to Installer Menu item 117 FACT DEFAULT, and key in the value provided by technical support.
Then, press OK .
3. At the prompt for con fi rmation, key in the password provided by technical support. This will initiate the
IN-STOP that restores the factory defaults on the TV.
Installer Menu Item 117 FACT DEFAULT
If the TV is currently in Pass-through Mode, you can set Installer Menu item 117 FACT DEFAULT to 1 to restore the Installer Menu factory defaults and clear the PTC Channel Map, including any assigned channel icons and custom text labels. Note, however, that if a complete restoration of the TV’s factory defaults is required, see “Restore All Factory Defaults” above.
Additional FTG Mode Options
There are two additional options for restoring Pass-through Mode/Installer Menu factory defaults on TVs that are in FTG Mode. The fi rst enables you to restore a single TV to Pass-through Mode, while the second enables you to restore multiple TVs to Pass-through Mode at one time. However, both options require that you create a “Zero Mapped Channels” FTG Con fi guration (.tlx) fi le, i.e., an FTG Con fi guration fi le with no data. Refer to the Free-To-Guest (FTG) File Manager User Guide for further information.
• Using a USB memory device, import a “Zero Mapped Channels” FTG Con fi guration (.tlx) fi le on the TV.
Refer to “Importing a Clone File” on pages 37 to 39 for further information on the import procedure.
• If your system uses a Pro:Centric server for remote management, use the Pro:Centric Admin Client to load a “Zero Mapped Channels” FTG Con fi guration (.tlx) fi le on the Pro:Centric server. Refer to the
Pro:Centric Server Admin Client User Guide for further information.
56 206-4316 Draft A.2
Reference: Using the TV Zoning Feature
This section describes the TV Zoning feature available with the LV560H model TVs. The TV Zoning feature enables you to create localized con fi gurations for TVs in selected locations, or “Zones,” within the installation environment, for example, a hotel lobby, fi tness center, restaurant, etc. This feature is primarily intended for use when the TV is con fi gured for FTG Mode operation. However, selected elements of TV
Zoning (Installer Menu and Setup Menu pro fi le Zone assignments) may also be used with TV cloning processes using a USB memory device / “.tlx” fi le.
Refer to the appropriate section(s) below for further information on the TV Zoning feature and how to set the
TV Zone # in a TV that is currently in Pass-through Mode.
Using the TV Zoning Feature with FTG Mode via CPU Con
fi
guration
The FTG File Manager may be used to create an FTG Con fi guration (.tlx) fi le that contains multiple
Installer Menu and Setup Menu pro fi les, each with its own Zone assignment. Up to nine unique Zones can be designated for LV560H FTG Installer Menu and/or Setup Menu pro fi les. Zone restrictions can also be placed on individual channels in the FTG Channel Map. Thus, for example, you may create an FTG
Installer Menu and/or Setup Menu pro fi le to speci fi cally con fi gure a TV in the hotel lobby and also restrict the channels that are available to be tuned on that TV.
The TV Zone # must be set appropriately on each TV in order for the TVs to be con fi gured correctly. See
“Set the TV Zone # in the TV” on the following page, and set the TV Zone # in all the TVs in a select area, so that the TVs are con fi gured with corresponding FTG Installer Menu and/or Setup Menu settings and/or can omit channels that have been restricted in the FTG Channel Map. TV Zone 0 is the default TV Zone #.
The following subsections brie fl y describe how to assign Zone designations in the FTG File Manager.
Refer to the Free-To-Guest (FTG) File Manager User Guide for further information.
FTG Installer Menu Pro fi le Zone Assignments
The FTG File Manager main screen enables you to change the Zone assignment (default = Zone 0) for each Installer Menu pro fi le to be included in an FTG Con fi guration (.tlx) fi le. For example, you may wish to create one LV560H Installer Menu pro fi le for the hotel lobby and another LV560H Installer Menu pro fi le for the fi tness center, both of which are different from the FTG Installer Menu pro fi le used for standard guest rooms. The Zoning feature enables you to save multiple LV560H FTG Installer Menu pro fi les, each with its own Zone assignment, in one FTG Con fi guration (.tlx) fi le. If each TV in the aforementioned locations
(Zones) has had its TV Zone # set appropriately, as described in the procedure on the following page or via the EZ-Manager Wizard, the TV(s) will only be con fi gured by the Installer Menu pro fi le that matches its(their) Zone setting.
In the FTG File Manager main screen, you can also edit the Zone assignment for each Installer Menu pro fi le and/or Setup Menu pro fi le already present in the FTG Con fi guration List and Setup Menu List windows.
Note: See also the FTG File Manager main screen overview on page 42. In addition, note that Setup
Menu pro fi les cannot be created in the FTG File Manager; they must be saved (exported) from a TV.
FTG Channel Map Zone Restrictions
The FTG Channel Map Editor in the FTG File Manager’s FTG Channel Map Con fi guration Utility enables you to place Zone restrictions on individual channels that may be prohibited or deemed unsuitable for selected locations. In the FTG Channel Map Editor, one or more Zone restrictions (1–8) may be placed on each channel that is to be restricted. For example, if you wish to restrict a channel from Zones 2 and 4, select both “Zone 2” and “Zone 4” in the Zone Restriction section of the FTG Channel Map Editor screen when de fi ning or editing that channel.
206-4316 Draft A.2
57
Reference: Using the TV Zoning Feature (Cont.)
Note: While a channel can be restricted from up to eight Zones, a TV can only ever be in (set for) one
Zone. See also the FTG Channel Map Editor overview on page 44.
At the same time, keep in mind that the TV Zone designations are not mutually exclusive. That is, you may opt to place Zone restrictions on selected channels in the FTG Channel Map, but at the same time, you can choose to con fi gure all TVs at the site with the same Installer Menu and/or Setup Menu settings. For example, an FTG Con fi guration (.tlx) fi le being used to con fi gure the TVs at a site may contain multiple
Installer Menu and Setup Menu pro fi les with different Zone assignments, as well as an FTG Channel Map with Zone restrictions on several channels. Each TV that still has the default TV Zone 0 setting will only be con fi gured by the Installer Menu and/or Setup Menu pro fi le(s) with a Zone 0 assignment. If, on the other hand, the TV Zone # is set to 1, the TV will fi rst look in the fi le for the LV560H Installer Menu and/or Setup
Menu pro fi le(s) with a Zone 1 designation. If none of the LV560H Installer Menu and/or Setup Menu pro fi les has a Zone 1 designation, the TV will then look for the LV560H the pro fi le(s) with a Zone 0 designation. For the FTG Channel Map con fi guration, when the TV Zone # is set to 0, the TV will ignore any Zone restrictions
(1–8) that may be placed on channels in the FTG Channel Map. However, when the TV Zone # is set to 1, the TV will omit any channels that have been restricted from Zone 1 in the FTG Channel Map.
Using the TV Zoning Feature with Cloning Con
fi
guration
A location-speci fi c con fi guration / Clone (.tlx) fi le may be saved (exported) from a Master TV and then be used to con fi gure Target TVs. For example, if the TV Zone # in the Master TV is set to 3 before the Clone fi le export is initiated, the Master TV’s Installer Menu and Setup Menu pro fi les will be saved with the TV
Zone 3 assignment. In order to con fi gure the Target TVs with the Zone 3 Installer Menu and Setup Menu pro fi les exported from the Master TV, you must set the TV Zone # accordingly in the Target TVs before importing the Clone fi le. See “Set the TV Zone # in the TV” below. Also, see “Cloning Procedures” on pages 36 to 39 for additional information on the cloning processes. TV Zone 0 is the default TV Zone #.
Set the TV Zone # in the TV
You can set the TV Zone # in the EZ-Manager Wizard (see “EZ-Manager Wizard” on pages 12 to 19) or, if the TV is in Pass-through Mode, via the TV’s setup menus as described below. Note that the following procedure can only be performed while the TV is in Pass-through Mode. You will also be able to specify a
Label (North, South, East, West) and Room Number for this TV, if desired.
1. Turn ON the TV.
2. Press MENU SETTINGS on the Installer Remote, and use the arrow navigation keys to select/highlight the OPTION menu option. Then, press OK .
3. Use the Up/Down arrows to select Zone & Room Number , and then press OK .
4. In the Zone, Label, and Room Number pop-up window, complete the appropriate fi elds as described below. Use the Left/Right arrow keys on the Installer Remote to navigate between each of the fi elds.
• Zone: Enables you to set a TV Zone # so that the TV can be con fi gured with Installer Menu and/or
Setup Menu settings intended only for the assigned Zone. The Installer Menu and/or Setup Menu settings may be provided in a Clone/Con fi guration (.tlx) fi le. If the TV is being con fi gured for FTG
Mode, the TV Zone # setting also allows the TV to omit channels that have been restricted in the
FTG Channel Map (see “FTG Channel Map Zone Restrictions” on previous page).
(Continued on next page)
58 206-4316 Draft A.2
Reference: Using the TV Zoning Feature (Cont.)
(Continued from previous page)
To change the TV Zone, navigate to the Zone fi eld, and use the Up/Down arrow keys to specify the desired TV Zone # (0–8).
• Label: Allows you to select a North, South, East, or West text label for this TV. Use the Up/Down arrow keys to select the applicable label.
• Room Number: Allows you to specify the number of the room—up to 16 characters—in which the TV is located. You can use the number keys on the Installer Remote to direct enter a room number. Use the Dash key on the Installer Remote as necessary to toggle between number and letter characters in the Room Number fi eld. Also, you can use the Flashback key on the Installer Remote to delete characters in this fi eld.
5. When you have completed the fi elds as necessary, select OK , and then press OK on the Installer
Remote to close the window and return to the Option Menu.
6. Press MENU SETTINGS to return to program viewing.
OPTION
• Language
• Caption
• Standby Light
• DivX/(R) VOD
: Off
: Off
• Set ID
• Demo Mode
: 1
• Zone & Room Number
• Eject
Move OK
Z
Change a room number
Zone, Label, and Room Number
• If creating Zones for Installer Menu settings and/or Channel Mapping, select the appropriate Zone # (0-8) based on the Zone in which this TV is installed. (See Commercial Mode Setup Guide for more information.)
• Select a Label and/or use the alphanumeric keypad on the remote to input the Room Number.
Zone
0
Label
-----
Room Number
7
CHAR/
NUM
1
4
2
5
8
0
3
6
9
DEL
Q.MENU
TV DVD
INPUT
MARK
CC
VOL TIMER
DELETE
MUTE
CH
P
A
PORTAL INFO GUIDE
OK
206-4316 Draft A.2
59
Reference: LV560H Rear and Side Jack Panels
OPTICAL DIGITAL AUDIO OUT
Use for amps and home theater systems.
Note: When the TV is OFF, this port is not enabled.
SPEAKER OUT
LINE OUT
(3.5 mm jack) Connect external audio
( fi xed speaker, variable speaker, or fi xed line level [ampli fi er]) equipment. See
Reference section, “External Stereo
Speaker Setup,” for further information.
RGB IN (PC)
Connection for RGB output from PC.
LAN
SPEAKER OUT
LINE OUT
OPTICAL
DIGITAL
AUDIO OUT
1
RGB IN (PC)
IN
MPI
L R
SERVICE
ONLY
VIDEO L/MONO -AUDIO- R
AV IN/AUDIO IN (RGB DVI)
SERVICE ONLY
Restricted to service updates.
AV IN/AUDIO IN (RGB DVI)
Connect composite audio/video output from external device, or connect audio for RGB or DVI device.
LAN
Use for network connection
(i.e., for Pro:Centric data).
HDMI IN 1
Connection for HDMI/DVI output from external device.
MPI
When the TV is in Pass-through Mode, the MPI function enables an external MPI control device
(i.e., VOD/PPV STB, etc.) to control the TV.
RESET
UPDATE
ANTENNA /
CABLE IN
RESET
Initiates a hardware reset and turns the TV OFF.
UPDATE
Restricted to software updates.
ANTENNA/CABLE IN
Connect to Antenna/CATV.
Side Jack Panel
USB IN
Insert USB memory device for software updates, cloning purposes,
FTG Mode configuration, picture/ music entertainment, etc., as applicable.
HDMI IN 2 & 3
Connection for HDMI output from external device.
60 206-4316 Draft A.2
Reference: External Stereo Speaker Setup
The SPEAKER OUT / LINE OUT 3.5 mm stereo jack on the LV560H rear panel provides stereo speaker signal outputs ( fi xed speaker, variable speaker, or fi xed line level [ampli fi er]) for external audio equipment.
Set Installer Menu item 097 AUDIO OUTPUT as required in accordance with external audio equipment connected to the TV. Also, refer to the following diagram for pinout details.
Caution: Do NOT insert a mono plug, as this may damage the TV.
SPEAKER OUT
LINE OUT
1 3
2
1 LEFT (Tip)
2 RIGHT (Ring)
3 GROUND (Sleeve)
206-4316 Draft A.2
61
Reference: Installer Remote Control Typical Key Functions
The LG Installer Remote is supplied with and dedicated to operate the TV. The LG Installer Remote illustrated below shows typical remote control functions and is provided for reference only. This Installer Remote may vary from the Installer Remote supplied with the TV.
(POWER)
Turns the TV ON or OFF
Numbers (0 - 9) & DASH
Use to enter a channel or program number.
Dash is used for sub-channel numbers such as 2-1, 2-2, etc.
FLASHBK (FLASHBACK)
Returns to the previously tuned channel or input.
VOLUME UP/DOWN
Increases/decreases sound level.
CC
Activates subtitles.
TIMER
Sets the amount of time before the TV automatically turns itself OFF.
MUTE
Switches sound ON or OFF.
CHANNEL/PAGE UP/DOWN
Changes channels based on channels in the channel lineup. Moves to previous or next screen in Pro:Centric channel guide.
DVD/USB buttons
Use to control DVD player or view USB memory device content.
Accesses the AV devices connected to the
HDMI ports of the TV. Opens the SIMPLINK
Menu (when Installer Menu item 041
SIMPLINK EN is set to 2 or 3).
(PIP/SWAP options N/A for these TV models)
SAP
Analog Mode: Selects MTS sound (Mono,
Stereo, or SAP). DTV Mode: Changes audio language, if additional languages are available. *
62
Q.MENU
TV DVD
INPUT
MARK
1
.,; @
2 abc
3 def
4 ghi
5 jkl
6 mno
7 pqrs
8 tuv
9 wxyz
0
FLASHBK
CHAR/NUM
CC
VOL
TIMER
DELETE
MUTE
CH
P
A
G
E
PORTAL INFO GUIDE
OK
ENTER
MENU
SETTINGS
EXIT
PIP PIPCH+ PIPCH-
SWAP PIP INPUT SAP
TV/DVD
Select the remote’s operating mode:
TV or DVD.
INPUT
Displays available Aux inputs.
(Q. MENU/MARK options N/A for these TV models)
Arrows (Up/Down/Left/Right) & OK/ENTER
Use to navigate on-screen menus, direct tune channels, and adjust TV settings.
MENU SETTINGS
Displays and removes the TV setup menus (or, if applicable, the Function Menu).
PORTAL
Displays and removes the Pro:Centric interactive menu.
INFO
Displays channel information.
GUIDE
Displays and removes the Pro:Centric channel guide/EPG.
(RETURN)
Returns one level to the previous menu/ display.
EXIT
Clears all on-screen displays and returns to program viewing.
Color buttons access special functions in some menus.
* SAP notes:
• If SAP is selected and no SAP is provided, sound may not be heard on channel.
• Each channel may have its own SAP setting.
• Each time digital channels are tuned, the TV attempts to locate the default audio program language. If the default audio program language is not available, the
TV will use the fi
206-4316 Draft A.2
Troubleshooting
General Troubleshooting
Some Quick and Easy Tips for Resolving Problems
Installation
Symptom
Cannot direct enter channel number.
Possible Cause(s)
(TV in Pass-through Mode) Installer
Menu item 028 CH. OVERIDE is set to
0, i.e., disabled (recommended setting).
(TV in FTG Mode) The channel entered is not included in the FTG Channel Map.
Possible Solution(s)
If Installer Menu item 028 CH. OVERIDE is set to 0, only channels that are active in the TV’s channel lineup can be selected. Set CH. OVERIDE to 1 to allow access for direct keypad entry to all channels.
Channel access is restricted to channels included in the FTG
Channel Map. If necessary, make changes to the FTG Channel
Map using the FTG File Manager.
Picture Reception and Sound
Symptom
No picture.
Possible Cause(s)
TV is turned OFF.
Normal picture, poor or no sound.
Antenna/cable not connected.
Connections incorrect.
MPI not connected.
Encrypted program.
Wrong tuning band.
Audio muted.
Broadcast problem.
Possible Solution(s)
• Turn TV ON.
• Power failure?
Connect antenna/cable signal to TV.
Check connections on TV.
If applicable, connect MPI cable to MPI device.
Try another channel.
Adjust Installer Menu settings.
Press MUTE or use Volume Up key to increase sound level.
Try a different channel.
Erratic Operation
Symptom
Installer Menu setup.
Installer Remote
Symptom
Remote doesn’t work.
Possible Cause(s)
Wrong Installer Menu settings.
Possible Solution(s)
Adjust Installer Menu settings as required.
Possible Cause(s)
Remote not in TV Mode.
Not aimed at IR remote sensor.
Remote too far from IR receiver or
IR path is obstructed.
MPI not connected.
Weak batteries.
Wrong battery polarity.
Too much light in room.
Wrong Installer Remote.
Possible Solution(s)
Use MODE key to select “TV”; puts remote into TV Mode.
Point remote at IR receiver on TV.
Move remote closer to IR receiver on TV, darken room, and/or remove obstructions.
If applicable, connect MPI cable to MPI device.
Replace batteries.
Check that “+” and “-” match in battery compartment.
Dim room light.
Requires compatible LG Installer Remote. Contact your LG dealer.
206-4316 Draft A.2
63
Troubleshooting (Cont.)
Commercial Mode Check
Use this flowchart to determine whether the TV is currently in Commercial Mode.
Press POWER on
Installer Remote.
TV turned
ON?
No
Yes
TV connected to AC
Power?
Bad
TV
Yes
No
Leave the TV set ON, and press MENU
SETTINGS on the
Installer Remote.
Plug into AC
Power outlet.
Function
Menu on display?
No
Press MENU
SETTINGS repeatedly as if to access the
Installer Menu.
Yes
TV is in
Commercial Mode.
On-screen menu display no longer toggles?
Yes
TV is in
Commercial Mode.
No
TV is not in Commercial
Mode. Call Technical
Support for assistance.
64 206-4316 Draft A.2
Glossary of Terms
Channel Lineup
Channels set in the TV memory, via Auto
Tuning/manual editing.
Cloning
The process of capturing a Master TV
Setup and transferring it to a Target TV using a USB memory device.
Commercial Mode
A mode of operation that provides a broad range of commercial TV features based on control (settings) provided by the PTC and/ or an MPI control device.
CPU
The TV’s Central Processing Unit.
Responsible for the presentation of video and audio from content received via the
TV’s tuner or Aux inputs.
E-Z Installation
Enables splash screen image and TV con fi guration and fi rmware fi le downloads to selected TV models from a Pro:Centric server. Managed and administered via the
Pro:Centric Admin Client.
EZ-Manager Wizard
Lodging model TV con fi guration wizard that provides con fi guration options for
Pro:Centric operation as well as an option for using a USB memory device to con fi gure a TV.
FTG Channel Map
Typically refers to a logical channel mapping of physical RF channels. This allows digital channels, like analog channels, to be tuned without requiring the dash key.
Also, channels (analog or digital) can be arranged in any order that seems logical for customer tuning/viewing.
FTG Mode
LG commercial TV mode that enables decryption of Pro:Idiom encrypted channels and logical channel mapping. TVs may be con fi gured locally using LG’s proprietary PC software or remotely using an applicable head end device.
Function Menu
Available via Installer Remote “MENU” key.
Indicates the TV is not in Pass-through
Mode. Restricts menu options to a subset of the TV setup menus, allowing users to retain functional control, while disabling setup options.
Installer Menu
De fi nes commercial TV functionality based on the parameters set.
LG Free-To-Guest (FTG)
Refers to a particular commercial mode of operation within an LG TV. See also FTG
Mode.
Logical Channel Number
A number assigned to either a physical or virtual channel number in a Logical Channel
Map.
Major Channel Number
Typically, the RF channel number assigned to a digital video stream.
Master TV
A TV whose Channel Map and Installer
Menu and TV setup menu settings have been con fi gured as a Master TV Setup for cloning purposes.
Pro:Centric Application
LG content delivery and communication interface that provides interactive entertainment, weather, amenities, etc. information for end users. (Powered by Pro:Centric server.)
Pro:Centric Admin Client
Web editor/content wizard provided for service provider and customer con fi guration of Pro:Centric application and management elements.
Pro:Idiom
Zenith proprietary security software that unlocks access to premium content to help assure rapid, broad deployment of HDTV and other high-value digital content.
PTC
Protocol Translator Card. The commercial controller (microprocessor) of the commercial TV.
Minor Channel Number
A sub-channel or program number assigned to the content embedded in the digital video stream.
MPI
Multiple Protocol Interface. An MPI port or, for some TV models, an MPI card slot provides external control options for solution providers.
Pass-through Mode
The TV’s factory default mode of operation.
TVs can be con fi gured for stand-alone use or as Master TVs for cloning purposes, and/or TVs may be controlled externally in this mode.
USB Memory Device
A USB fl ash drive or USB storage device, etc. that can be used for TV con fi guration purposes (typically cloning or FTG Mode con fi guration) or for updating TV software.
Virtual Channel Number
An alias (virtual) channel number provided in the data stream, by the broadcaster, of a digital broadcast channel to be displayed by consumer TVs in place of the physical channel number. The major number is the same as the original analog channel number and the minor number is the nth program available in that digital video stream.
Physical Channel Number
The major channel number assigned to represent a speci fi c 6 MHz RF band as speci fi ed by either the broadcast or CATV channel plan. See CEA (formerly EIA) or
NCTA speci fi cations for further information.
Target TV
A TV to which a Master TV Setup will be transferred.
TV Setup Menus
Available via Installer Remote “MENU” key in Pass-through Mode only. Menus provide access to setup and functional features of the TV.
206-4316 Draft A.2
65
Document Revision History / Open Source Software Notice
Document Revision History
Date
March 2017
Description
Draft A.2: New document
Product documentation is available online at: www.lg.com/us/business .
Open Source Software Notice
To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this product, please visit http://opensource.lge.com. In addition to the source code, all referenced license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon e-mail request to opensource@ lge.com. This offer is valid for three (3) years from the date on which you purchased the product.
66 206-4316 Draft A.2
