LG PH3 Owner's manual
ENGLISH
SIMPLE MANUAL
Portable
Bluetooth Speaker
MODEL
PH3 / PH3G / PH3O
*MFL69669621*
www.lg.com
Safety Information
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR
BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the product.
WARNING:
yy To prevent fire or electric shock hazard, do not expose this product to rain or moisture.
yy Do not install this equipment in a confined space such as a book case or similar unit.
yy This unit contains magnets which can be harmful to some kind of object
(Ex : Magnetic card, Pacemaker etc..).
3
CAUTION:
yy The apparatus should not be exposed to water (dripping or splashing) and no objects filled
with liquids, such as vases, should be placed on the apparatus.
yy No naked flame sources, such as lighted candles, should be placed on the apparatus.
yy It is recommended that you use the 5 V AC adapter (more than 1.8 A) with this device.
If you do not use the recommended adapter, charging is unavailable or charging time may
differ.
yy To avoid fire or electric shock, do not open the unit. contact to qualified personnel only.
y
y Do not leave the unit in a place near the heating appliances or subject to direct sunlight,
moisture, or mechanical shock.
yy To clean the unit, use a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth lightly
moistened with a mild detergent solution. Do not use strong solvents such as alcohol, benzine,
or thinner, as these might damage the surface of the unit.
yy Do not use volatile liquids such as insecticide spray near the unit. Wiping with strong pressure
may damage the surface. Do not leave rubber or plastic products in contact with the unit for a
long period of time.
yy Do not place the unit over the vehicle’s air bag. When the air bag deploys, it may result in injury.
Before using in the car, fix the unit.
yy Do not use the handsfree function during driving a car.
yy Do not leave the unit on an unstable place such as high shelves. it may fall down because of
the vibration of the sound.
yy Do not use high voltage products around this product. (ex. Electrical swatter) This product may
malfunction due to electrical shock.
4
CAUTION when using this product in environments of low humidity.
yy It may cause static electricity in environments of low humidity.
yy It is recommended to use this product after touching any metal object which conducts
electricity.
NOTICE: For safety marking information including product identification and supply ratings, please
refer to the main label on the bottom or the other surface of the product.
This device is equipped with a portable battery or accumulator.
Safety way to remove the battery or the battery from the equipment: Remove the old battery
or battery pack, follow the steps in reverse order than the assembly. To prevent contamination
of the environment and bring on possible threat to human and animal health, the old battery or
the battery put it in the appropriate container at designated collection points. Do not dispose
of batteries or battery together with other waste. It is recommended that you use local, free
reimbursement systems batteries and accumulators. The battery should not be exposed to
excessive heat such as sunshine, fire or the like.
5
IMPORTANT SAFETY
INSTRUCTIONS
1.
2.
3.
4.
5.
6.
7.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the third prong are provided for
your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
6
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused
for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such as power-supply cord
or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has been
dropped.
7
Industry Canada Statement
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the
following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
CAN ICES-3 (B)/NMB-3 (B)
IC Radiation Exposure Statement
This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment.
This equipment should be installed and operated with minimum distance 20 cm (7.8 inches)
between the antenna & your body.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE
CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS
COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
8
WARNING
[For product having the wireless function using 5 GHz frequency bands]
(i) the device for operation in the band 5150–5250 MHz is only for indoor use to reduce the
potential for harmful interference to co-channel mobile satellite systems;
(ii) for devices with detachable antenna(s), the maximum antenna gain permitted for devices
in the bands 5250-5350 MHz and 5470-5725 MHz shall be such that the equipment
still complies with the e.i.r.p. limit;
(iii) for devices with detachable antenna(s), the maximum antenna gain permitted for devices
in the band 5725-5850 MHz shall be such that the equipment still complies with the e.i.r.p.
limits specified for point-to-point and non-point-to-point operation as appropriate; and
(iv) the worst-case tilt angle(s) necessary to remain compliant with the e.i.r.p. elevation mask
requirement set forth in Section 6.2.2(3) shall be clearly indicated.(devices operating in
the band 5250-5350 MHz with a maximum e.i.r.p. greater than 200 mW)
(v) High-power radars are allocated as primary users (i.e. priority users) of the bands
5250–5350 MHz and 5650–5850 MHz and that these radars could cause interference
and/or damage to LE-LAN devices.
9
White : Full Charged
Red : Charging
Portable input
PORT.IN
PORT.IN
AC Adapter
(Not supplied)
Power
Power On / Off . . . . . . . . . . . . . . . . . . . . . .
Bluetooth
To pair your mobile device, select LG PH3 (xx) from
device list.
When successfully paired, Bluetooth LED will turn on.
Hold
Play / Pause . . . . . . . . . . . . . . . . . . . . . . . .
Press
Playback
Controls
Forward Skip . . . . . . . . . . . . . . . . . . . . . . .
Press
X2
Backward Skip . . . . . . . . . . . . . . . . . . . . . .
Press
X3
Mood LED
light Controls
Candle mode / (Blue, Pink, White)
Color mode / Healing mode (Auto
Color Change) . . . . . . . . . . . . . . . . . . . . . .
Press
10
Specification
Important Notice
Power Supply:
--5 V 0 1.8 A (AC Adapter)
--Built-in rechargeable battery
Power consumption:
--2.5 W
Dimensions (W x H x D):
Approx. 90.5 mm X 123.5 mm X 91 mm
Net Weight: Approx. 0.38 kg
Operating Temperature: 5 °C to 35 °C
Operating Humidity: 5 % to 60 %
Battery Life:
-- Approx. 10 hours. (Varies by volume level
and audio content.)
yy Design and specifications are subject
to change without notice.
yy Fully charge the device before using
for the first time.
yy It is recommended that you use the
5 V AC adapter (more than 1.8 A)
with this unit.
button for
yy Press and hold the
more than 1 second to turn on or off
the unit.
yy Bluetooth connection using the TV,
PC or dongle is not supported.
yy Resetting
-- In case that the unit freezes due to
malfunction, press the RESET hole
using and object like a thin pin.
For more information, download the online owner’s manual. http://www.lg.com
11
LG Customer Information Center
1-888-542-2623
CANADA
Register your product Online!
www.lg.com
