TRENDnet User’s Guide

Table of Contents

TRENDnet User’s Guide

Contents

Introduction ........................................................................................................... 5

Features ......................................................................................................................... 5

Package Contents .......................................................................................................... 5

Hardware Feature .......................................................................................................... 6

System Concept...................................................................................................... 7

Product Benefit .............................................................................................................. 8

Installation Considerations ............................................................................................ 8

Installation ..................................................................................................................... 9

Configuration ................................................................................................................. 9

Applications ......................................................................................................... 10

Router AP Mode (Gateway + Access Point + WDS) ..................................................... 10

AP Mode (including Access Point + WDS) .................................................................... 10

WDS Mode (Pure WDS) ............................................................................................... 11

CPE Mode .................................................................................................................... 12

Client Bridge + Universal Repeater Mode ................................................................... 12

CPE + AP Mode (Router Client + Access Point) ............................................................ 12

Web Management Interface Instructions ............................................................. 13

AP Mode Configuration ........................................................................................ 13

External Network Connection...................................................................................... 14

Network Requirement ................................................................................................. 14

Configure LAN IP ...................................................................................................... 14

Wireless LAN Network ................................................................................................. 16

Wireless General Setup ............................................................................................ 16

Wireless Advanced Setup ......................................................................................... 16

Create Virtual AP (VAP) ............................................................................................ 20

Virtual AP Setup ....................................................................................................... 21

Wireless MAC Filter Setup........................................................................................ 23

Wireless Network Expansion ................................................................................... 24

System Status .............................................................................................................. 24

System Overview ...................................................................................................... 24

© Copyright 2012TRENDnet. All Rights Reserved.

Table of Contents

Associated Clients Status ......................................................................................... 25

Show WDS Link Status ............................................................................................. 26

Extra Information ..................................................................................................... 26

Event Log .................................................................................................................. 28

WDS Mode Configuration..................................................................................... 29

External Network Connection ..................................................................................... 29

Network Requirement ............................................................................................. 29

Configure LAN IP ...................................................................................................... 29

Wireless Network Expansion ....................................................................................... 30

General Setup .......................................................................................................... 30

Wireless Advanced Setup......................................................................................... 31

WDS Setup ............................................................................................................... 34

System Status .............................................................................................................. 34

System Overview ..................................................................................................... 34

WDS List ................................................................................................................... 35

Extra Information ..................................................................................................... 36

Event Log .................................................................................................................. 37

CPE Mode Configuration ...................................................................................... 38

External Network Connection ..................................................................................... 38

Network Requirement ............................................................................................. 38

Configure WAN Setup .............................................................................................. 39

Configure DDNS Setup ............................................................................................. 41

Configure LAN Setup ................................................................................................ 41

Access Point Association ............................................................................................. 42

Configure Wireless General Setting ......................................................................... 42

Configure Wireless Advanced Setting ...................................................................... 43

Site Survey ............................................................................................................... 43

Create Wireless Profile ............................................................................................ 44

Access Control List ....................................................................................................... 45

IP Filter Setup ........................................................................................................... 45

MAC Filter Setup ...................................................................................................... 46

Parental Control Setup ............................................................................................. 47

2

TRENDnet User’s Guide

QoS Setup ................................................................................................................. 48

Resource Sharing ......................................................................................................... 50

DMZ .......................................................................................................................... 50

Virtual Server (Port Forwarding) .............................................................................. 51

System Status .............................................................................................................. 53

Overview .................................................................................................................. 53

Station Statistics ....................................................................................................... 54

Extra Info .................................................................................................................. 55

QoS Plot .................................................................................................................... 57

Event Log .................................................................................................................. 57

CPE + AP Mode Configuration .............................................................................. 58

External Network Connection...................................................................................... 58

Network Requirement ............................................................................................. 58

Configure WAN Setup .............................................................................................. 59

Configure DDNS Setup ............................................................................................. 60

Configure LAN Setup ................................................................................................ 61

Access Point Association .............................................................................................. 62

Configure Wireless General Setting ......................................................................... 62

Wireless Advanced Setup ......................................................................................... 63

Site Survey ................................................................................................................ 66

Create Wireless Profile ............................................................................................. 66

Wireless LAN Network Creation .................................................................................. 68

Repeater AP Setup ................................................................................................... 68

Wireless MAC Filter Setup........................................................................................ 70

Access Control List ....................................................................................................... 70

IP Filter Setup ........................................................................................................... 70

MAC Filter Setup ...................................................................................................... 71

Parental Control Setup ............................................................................................. 72

QoS Setup ................................................................................................................. 73

Resource Sharing ......................................................................................................... 75

DMZ .......................................................................................................................... 75

© Copyright 2012TRENDnet. All Rights Reserved.

Table of Contents

Virtual Server (Port Forwarding) .............................................................................. 76

System Status ........................................................................................................... 77

Overview .................................................................................................................. 77

Associated Clients Status ......................................................................................... 79

Remote AP ............................................................................................................... 80

Extra Info .................................................................................................................. 80

QoS Plot ................................................................................................................... 82

Event Log .................................................................................................................. 82

Client Bridge + Universal Repeater Configuration ................................................ 82

External Network Connection ..................................................................................... 83

Network Requirement ............................................................................................. 83

Configure LAN IP ...................................................................................................... 83

Access Point Association ............................................................................................. 84

Configure Wireless General Setting ......................................................................... 84

Wireless Advanced Setup......................................................................................... 85

Site Survey ............................................................................................................... 89

Create Wireless Profile ............................................................................................ 89

Wireless LAN Network Creation .................................................................................. 90

Repeater AP Setup ................................................................................................... 90

Wireless MAC Filter Setup ....................................................................................... 93

System Status .............................................................................................................. 93

System Overview ..................................................................................................... 93

Associated Clients Status ......................................................................................... 95

Remote AP ............................................................................................................... 95

Extra Information ..................................................................................................... 95

Event Log .................................................................................................................. 97

Router AP Mode Configuration ............................................................................ 98

External Network Connection ..................................................................................... 98

Network Requirement ............................................................................................. 98

Configure WAN Setup .............................................................................................. 99

Configure DDNS Setup ........................................................................................... 101

Configure LAN Setup .............................................................................................. 101

3

TRENDnet User’s Guide

Wireless LAN Network Creation ................................................................................ 102

Wireless General Setup .......................................................................................... 102

Wireless Advanced Setup ....................................................................................... 103

Create Virtual AP (VAP) .......................................................................................... 107

Wireless MAC Filter Setup...................................................................................... 110

Wireless Network Expansion ..................................................................................... 111

Access Control List ..................................................................................................... 112

IP Filter Setup ......................................................................................................... 112

MAC Filter Setup .................................................................................................... 113

Parental Control Setup ........................................................................................... 113

QoS Setup ............................................................................................................... 115

Resource Sharing ....................................................................................................... 117

DMZ ........................................................................................................................ 117

Virtual Server (Port Forwarding) ............................................................................ 117

System Status ............................................................................................................ 118

Overview ................................................................................................................ 118

Associated Clients .................................................................................................. 120

Show WDS Link....................................................................................................... 121

Extra Info ................................................................................................................ 121

QoS Plot .................................................................................................................. 123

Event Log ................................................................................................................ 123

System Management ......................................................................................... 123

Configure Management ......................................................................................... 123

Configure System Time .......................................................................................... 125

Configure UPnP ...................................................................................................... 126

Configure SNMP Setup ........................................................................................... 126

Backup / Restore and Reset to Factory .................................................................. 127

Firmware Upgrade ................................................................................................. 128

Network Utility ....................................................................................................... 128

Reboot .................................................................................................................... 129

Mounting bracket installation ............................................................................ 129

Package contents ....................................................................................................... 129

Install mounting triangle............................................................................................ 129

© Copyright 2012TRENDnet. All Rights Reserved.

Table of Contents

Wall mount bracket ................................................................................................... 130

Pole mount bracket ................................................................................................... 130

Installing brackets ...................................................................................................... 130

Appendix ............................................................................................................ 131

WEB GUI Valid Characters ......................................................................................... 131

MCS Data Rate ........................................................................................................... 139

System Manager Privileges ........................................................................................ 140

Windows TCP/IP Settings .......................................................................................... 141

Enabling UPnP in Windows XP ................................................................................... 142

Specification .............................................................................................................. 144

Limited Warranty ....................................................................................................... 145

4

TRENDnet User’s Guide

Introduction

The N300 Wireless 12dBi Outdoor 5GHz PoE Access Point, model TEW-

676APBO, provides high speed point-to-point building connectivity. It supports a variety of installation scenarios with Access Point, Router Access Point,

Wireless Distribution System (WDS), Customer Premises Equipment (CPE), and

Repeater modes.

An IP-66/67 weather rating and rugged aluminum housing ensures the highest level of protection against extreme weather. An outdoor mounting kit is included and weatherproof LED indicators expedite product installation and troubleshooting.

No need to install this access point nears a power source—PoE technology transmits both power and data over an Ethernet cable. Support for the latest wireless security protocols ensures the highest level of network protection.

Install this access point with TRENDnet’s Outdoor Lightning Arrestor Kit, model

TEW-ASAL1, to protect your entire network from catastrophic lightning strikes.

Features

PoE compliant device

1 x 10/100Mbps PoE Auto-MDIX LAN port

1 x reset button

LED indicators: Power, WLAN, LAN, Internal high powered 12dBi patch antenna (polarization: V30

°

, H30

°

)

Compliant with 802.11n/a technology (5 GHz spectrum) with data rates up to 300Mbps

• Rugged IP66/67 rated weather proof aluminum housing

• Supports Router Access Point (AP), Access Point (AP), Wireless Distribution

System (WDS), Customer Premises Equipment (CPE), Client Bridge +

Repeater, and CPE + AP modes

• Multiple SSID or Virtual Access Points with Layer 2 VLAN client isolation

Access restriction with Internet Access Control, MAC, and IP filtering

Universal Plug and Play (UPnP) for auto discovery and support for device configuration of Internet applications

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

Complete wireless security with WPA/WPA2-RADIUS, WPA /WPA2-PSK, and

WEP

Multiple pass-through sessions for popular VPN applications (IPSec, L2TP, and PPTP)

Quality of Service technology: IEEE 802.11p COS, IEEE 802.11q Tag VLAN priority control and Wi-Fi Multimedia (WMM)

Supports IEEE 802.11f IAPP (Inter Access Point Protocol), IEEE 802.11h

(Transmission Power Control) and IEEE 802.11d (Multi-country roaming)

• Easy setup via Web browser using the latest versions of Internet Explorer,

FireFox, and Safari

Supports SNMP (v2c and v3), Telnet, SSH, and HTTP/HTTPS management

Surface mounting hardware

• Electrical ground cable

3-year limited warranty

Package Contents

The standard package contents

TEW-676APBO

• Multi-Language Quick Installation Guide

• CD-ROM (User’s Guide)

PoE Injector &Power cord (All in one type)

Mounting Kit

• Grounding wire

Waterproof kit

5

TRENDnet User’s Guide

Hardware Feature

Front Panel

Housing -

IP 66/67 housing

© Copyright 2012TRENDnet. All Rights Reserved.

Housing

Bottom Panel

TEW-676APBO

LAN/WLAN/PWR

LEDs

PoE Port

Reset Button

LED

o

LAN –

Turns on when there is a LAN connection and blinks when data is running through the LAN port. o

WLAN –

Turns on when wireless is enabled and blinks during wireless transmission occur. o

PWR –

Indicates the unit is powered on.

Reset Button (unscrew cap)

o

Reboot –

Press and hold the reset button for 2 seconds to restart the unit.

All LEDs except PWR will turn off before the unit turns back on. eless transmission occur. o

Reset –

Press and hold the reset button for more than 10 seconds to

PoE Port (unscrew cap)

– Connect the network cable that is connected to the provided PoE injector to power and configure the unit. restore the unit back to factory default settings.

6

TRENDnet User’s Guide

System Concept

The TEW-676APBO is not only designed and used as a traditional outdoor AP, but also with rich features tailored for WISP applications. The two-level management capability and access control ease WISP and owners to maintain and manage wireless network in a more controllable fashion. Main applications are listed as follows with illustration:

Wireless CPE for Multi Dwelling Unit/Multi-Tenant Unit(MDU/MTU) complexes including apartments, dormitories, and office complexes.

Outdoor Access Point for school campuses, enterprise campuses, or manufacture plants.

Indoor Access Point for hotels, factories, or warehouses where industrial grade devices are preferred.

Public hotspot operation for café, parks, convention centers, shopping malls, or airports.

Wireless coverage for indoor and outdoor grounds in private resorts, home yards, or gulf course communities.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

7

TRENDnet User’s Guide

Product Benefit

The

The

N300 Wireless 12dBi Outdoor 5GHz PoE Access Point

is the point of connection to Wireless Outdoor Network for service provider deploying last mile services to business or residential broadband subscribers.. Network administrators can create multiple subscriber service tier using per-subscriber rate limiting features, and manage centrally. TEW-676APBO outdoor bridge utilizes a 200mW output Tx Power to connect to the WiFi mesh or WDS infrastructure and provides the subscriber with an Ethernet connection for a local access.

N300 Wireless 12dBi Outdoor 5GHz PoE Access Point

can be used for nine different purposes in six different modes, the Router AP mode , AP mode, the WDS mode, the CPE mode, Client Bridge + Universal Repeater mode and CPE + AP mode,

Installation Considerations

There are a number of factors that can impact the range of wireless devices.

1.

Adjust your wireless devices so that the signal is traveling in a straight path, rather than at an angle. The more material the signal has to pass through the more signal you will lose.

2.

Keep the number of obstructions to a minimum. Each obstruction can reduce the range of a wireless device. Position the wireless devices in a manner that will minimize the amount of obstructions between them.

3.

Building materials can have a large impact on your wireless signal. In an indoor environment, try to position the wireless devices so that the signal passes through less dense material such as dry wall. Dense materials like metal, solid wood, glass or even furniture may block or degrade the signal.

4.

Antenna orientation can also have a large impact on your wireless signal. Use the wireless adapter’s site survey tool to determine the best antenna orientation for your wireless devices.

5.

Interference from devices that produce RF (radio frequency) noise can also impact your signal. Position your wireless devices away from anything that generates RF noise, such as microwaves, radios and baby monitors.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

If you are still experiencing low or no signal consider repositioning the wireless devices or installing additional access points. The use of higher gain antennas may also provide the necessary coverage depending on the environment.

8

TRENDnet User’s Guide

Installation

1.

Unscrew the black cap covering the PoE port of the TEW-676APBO

2.

Install the waterproof kit and insert one end of an Ethernet cable through the kit.

TEW-676APBO

3.

Connect the Ethernet cable to the

PoE

port of the TEW-676APBO

7.

Connect the other end of the Ethernet cable to the LAN port of your network.

8.

Plug the power cord into the injector. Then connect the plug into a power outlet.

Configuration

1.

Open a web browser, type the IP address of the Access Point and then press

Enter

.

The default IP address is

192.168.10.100.

4.

Tighten and secure the seal nut of the waterproof kit.

5.

Connect the other end of the Ethernet cable to the

P+DATA Out

port on the PoE injector.

2.

Enter the

Username

and

Password

and click

OK

. By default the Username:

root

and

Password:

root

.

3.

Click the

Wizard

button and follow the setup wizard instructions. Click

Finish

to complete installation.

6.

Using another Ethernet cable, connect one end to the

DATA IN

port of the injector.

© Copyright 2012TRENDnet. All Rights Reserved.

9

TRENDnet User’s Guide

Applications

TEW-676APBO is multiple mode system which can be configured either as a wireless gateway or an access point as desired. It also can be used as a WDS link for Ethernet network expansion. This section depicts different applications on

Router AP Mode

,

AP

Mode

,

WDS Mode

,

CPE Mode

,

Client Bridge + Universal Repeater Mode

and

CPE + AP

Mode

.

Router AP Mode (Gateway + Access Point + WDS)

Example 1 :

Router AP without WDS

It can be deployed as a gateway with wireless Access Point

NAT

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

Remote Bass

WDS

:

Example 2 :

Router AP with WDS

It can be deployed as a gateway with wireless Access Point and provides

WDS link for network extension.

AP Mode (including Access Point + WDS)

An access point can be either a main, relay or remote base station. A main base station is typically connected to a wired network via the Ethernet port. A relay base station relays data between main base stations and relay stations or remote base stations with clients. A remote base station is the end point to accept connections from wireless clients and pass data upwards to a network wirelessly.

Example 1 :

Access Point without WDS

It can be deployed as a tradition fixed wireless Access Point

10

TRENDnet User’s Guide

Example 2 :

Access Point with WDS

It can be deployed as a tradition fixed wireless Access Point and provides

WDS link to expand network

Main

WDS

Main

Remote

WDS

Remote

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

WDS Mode (Pure WDS)

An access point can be either a main, relay or remote base station. A main base station is typically connected to a wired network via the Ethernet port. A relay base station relays data between main base stations and relay stations or remote base stations with clients. A remote base station is the end point to accept connections from wireless clients and pass data upwards to a network wirelessly. In this mode, it can support single or multiple WDS links and no wireless clients

can

associate with it.

Example 1 :

Point-to-Point

WDS

Main

Example 2 :

Point-to-Multi-Point

11

TRENDnet User’s Guide

Main Base

Station

WIFI WAN

Example 3 :

Multi-Point Repeating bridge

Inter

NA

LAN

CPE Mode

It can be used as an Outdoor Customer Premises Equipment (CPE) to receive wireless signal over last mile application, helping WISPs deliver wireless broadband

Internet service to residents and business customers. In the CPE mode, TEW-

676APBO is a gateway enabled with NAT and DHCP Server functions. The wired clients connected to TEW-676APBO are in different subnet from those connected to

Main Base Station, and, in CPE mode, it does not accept wireless association from wireless clients.

Main Base

Station

WIFI WAN

NA

T

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

Client Bridge + Universal Repeater Mode

It can be used as an Client Bridge + Universal Repeater to receive wireless signal over last mile applications, helping WISPs deliver wireless broadband Internet service to new residential and business customers. In this mode, TEW-676APBO is enabled with DHCP Server functions. The wired clients of TEW-676APBO are in

the same subnet

from Main Base Station and it

accepts

wireless connections from client devices.

CPE + AP Mode (Router Client + Access Point)

It can be used as an Outdoor Customer Premised Equipment(CPE) to receive wireless signal over the last mile, helping WISPs deliver wireless broadband Internet service to new residential and business customers. In this mode, theTEW-676APBO is a gateway with NAT and DHCP Server functions. The wireless and wired clients of

TEW-676APBO are on the

different subnet

from Main Base Station and it

accepts

wireless connections from client devices.

12

TRENDnet User’s Guide

Web Management Interface Instructions

TEW-676APBO supports web-based configuration. Upon the completion of hardware installation, TEW-676APBO can be configured through a PC/NB by using its web browser such as Internet Explorer version 6.0.

Default IP Address :

192.168.10.100

Default IP Netmask :

255.255.255.0

Default User Name and Password :

root/root

The default user name and password for both root manager account and admin manager account are as follows:

Mode

Router

AP

CPE AP WDS

UR +

CB

CPE + AP

Management

Account

Root Root Admin Root Root Root Root Admin

User Name

root root admin root root root Root admin

Password

default default admin default default default default admin

Step

IP Segment Set-up for Administrator's PC/NB

Set the IP segment of the administrator's computer to be in the same range as

TEW-676APBO for accessing the system. Do not duplicate the IP Address used here with IP Address of TEW-676APBO or any other device within the network

Example of Segment :

The valid range is 1 ~ 254 and 192.168.10.254 shall be avoided because it is already assigned to TEW-676APBO . 192.168.10.10 is used in the example below.

IP Address : 192.168.10.10

IP Netmask : 255.255.255.0

Launch Web Browser

Launch web browser to access the web management interface of system by

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

 entering the default IP Address, http://192.168.10.254

, in the URL field, and then press

Enter

.

System Login

The system manager Login Page then appears.

Enter “

root

” as

User name

and “

root

” as

Password

, and then click OK to login to the system; the root manager account is used as an example here.

Login Success

System Overview page will appear after successful login.

AP Mode Configuration

When AP mode is chosen, the system can be configured as an Access Point. This section provides detailed explanation for users to configure in the AP mode with help of illustrations. In the AP mode, functions listed in the table below are also available from the Web-based GUI interface.

Option System Wireless Utilities Status

Operating Mode General Setup Profiles Settings

System

Overview

Firmware

Upgrade

Functions

LAN Advanced Setup Clients

Management Virtual AP Network Utility WDS Status

Time Server

SNMP

WDS Setup

AP Mode Functions

Reboot Extra Info

Event Log

13

TRENDnet User’s Guide

External Network Connection

Network Requirement

Normally, TEW-676APBO connects to a wired LAN and provides a wireless connection point to associate with wireless client as shown in Figure 3-1. Then, Wireless clients could access to LAN or Internet by associating themselves with TEW-676APBO set in AP mode.

Configure LAN IP

Here are the instructions to setup the local IP Address and Netmask.

Please click on

System -> LAN

and follow the below setting.

Mode :

Check either “Static IP” or “Dynamic IP” button as desired to set up the system IP of LAN port .

Static IP :

The administrator can manually setup the LAN IP address when static IP is available/ preferred.

IP Address :

The IP address of the LAN port; default IP address is

192.168.2.254

IP Netmask :

The Subnet mask of the LAN port; default Netmask is

255.255.255.0

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

IP Gateway :

The default gateway of the LAN port; default Gateway is

192.168.2.1

Dynamic IP :

This configuration type is applicable when the TEW-676APBO is connected to a network with the presence of a DHCP server; all related IP information will be provided by the DHCP server automatically.

Hostname :

The Hostname of the LAN port

DNS :

Check either “No Default DNS Server” or “Specify DNS Server IP” button as desired to set up the system DNS.

Primary :

The IP address of the primary DNS server.

Secondary:

The IP address of the secondary DNS server.

802.1d Spanning Tree

The spanning tree network protocol provides a loop free topology for a bridged LAN between LAN interface and 4 WDS interfaces from wds0 to wds3. The Spanning

Tree Protocol, which is also referred to as STP, is defined in the IEEE Standard

802.1d. The Spanning tree always enabled on TEW-676APBO. Below Figures depict a loop for a bridged LAN between LAN and WDS link

Click

Save

button to save your changes. Click

Reboot

button to activate your changes

14

TRENDnet User’s Guide

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

WDS

LOOP

Remote Base Station

WDS

WDS

B locked by

Spanning Tree Protocol

Remote Base Station

WDS

LOOP

Remote Base Station

WDS

B locked by

Spanning Tree Protocol

Base Station

WDS

Remote Base Station

15

TRENDnet User’s Guide

Wireless LAN Network

The network manager can configure related wireless settings,

General Settings,

Advanced Settings, Virtual AP(VAP) Setting, Security Settings

and

MAC Filter Settings

.

Wireless General Setup

The administrator can change the data transmission, channel and output power settings for the system. Please click on

Wireless -> General Setup

and follow the below setting.

MAC Address :

The MAC address of the Wireless interface is displayed here.

Band Mode :

Select an appropriate wireless band; bands available are

801.11a

or

802.11a/n mixed mode

.

AP Isolation :

Select

Enable

, all clients will be isolated from each VAP, that means different VAP's clients can not reach to each other.

Transmit Rate Control :

Select the desired rate from the drop-down list; the options are auto or ranging from

6

to

54Mbps

only for

802.11a

mode.

Tx Power :

You can adjust the output power of the system to get the appropriate coverage for your wireless network. Specify digit numbers between

1

to

100

(the

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

unit is %) for your environment. If you are not sure which setting to choose, then keep the default setting,

100

%.

When

Band Mode

select in

802.11a only mode

, the

HT(High Throughput)

settings should be hidden immediately.

HT TxStream

/

RxStream :

By default, it's

2

.

Operating Mode :

By default, it's Mixed Mode.

Mixed Mode :

In this mode packets are transmitted with a preamble

 compatible with the legacy 802.11a/g, the rest of the packet has a new format.

In this mode the receiver shall be able to decode both the Mixed Mode packets and legacy packets.

Green Field :

In this mode high throughput packets are transmitted without a legacy compatible part.

Channel Bandwidth :

The "

20/40

” MHz option is usually best. The other option is available for special circumstances.

Guard Interval :

Using “

Auto

” option can increase throughput. However, it can also

 increase error rate in some installations, due to increased sensitivity to radiofrequency reflections. Select the option that works best for your installation.

MCS :

This parameter represents transmission rate. By default (Auto) the fastest possible transmission rate will be selected. You have the option of selecting the speed if necessary. (Refer to

Appendix C. MCS Data Rate

)

Reverse Direction Grant(RDG) :

Disable or enable reserve direction grant. Default is enabled.

A-MSDU :

Aggregated Mac Service Data Unit. Select

Enable

to allow aggregation for multiple MSDUs in one MPDU Default is disabled.

Auto Block ACK :

Disable or enable auto block ACK. Default is enabled.

Decline BA Request :

Disable or enable decline BA request. Default is disabled.

Change these settings as described here and click

Save

button to save your changes.

Click

Reboot

button to activate your changes. The items in this page are for AP's RF general settings and will be applied to

all VAPs

and

WDS Links

.

Wireless Advanced Setup

To achieve optimal wireless performance, it is necessary to tweak advance setting per requirements properly, not necessary higher the better or lower.

The administrator can change the RTS threshold and fragmentation threshold settings for the system. Please click on

Wireless -> Advanced Setup

and follow the below setting.

16

TRENDnet User’s Guide

Short Slot :

By default, it’s “

Enable

” for reducing the slot time from the standard

20

microseconds

to the

9

microsecond

short slot time

Slot time is the amount of time a device waits after a collision before retransmitting a packet. Reducing the slot time decreases the overall back-off, which increases throughput. Back-off, which is a multiple of the slot time, is the random length of time a station waits before sending a packet on the LAN. For a sender and receiver own right of the channel the shorter slot time help manage shorter wait time to retransmit from collision because of hidden wireless clients or other causes. When collision sources can be removed sooner and other senders attempting to send are listening the channel(CSMA/CA) the owner of the channel should continue ownership and finish their transmission and release the channel. Then, following ownership of the channel will be sooner for the new pair due to shorter slot time.

However, when long duration of existing collision sources and shorter slot time exist the owners might experience subsequent collisions. When adjustment to longer slot time can’t improve performance then RTS/CTS could supplement and help improve performance.

Extra Slot Time :

Slot time is in the range of

1~255

and set in unit of

microsecond

.

The default value is

9

microsecond.

ACK Timeout :

ACK timeout is in the range of

1~255

and set in unit of

microsecond

.

The default value is

32

microsecond.

All data transmission in 802.11b/g request an “Acknowledgement” (ACK) send by

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

receiving radio. The transmitter will resend the original packet if correspondent ACK failed to arrive within specific time interval, also refer to as “ACK Timeout”.

ACK Timeout is adjustable due to the fact that distance between two radio links may vary in different deployment. ACK Timeout makes significant influence in performance of long distance radio link. If ACK Timeout is set too short, transmitter will start to “Resend” packet before ACK is received, and throughputs become low due to excessively high re-transmission.

ACK Timeout is best determined by distance between the radios, data rate of average environment. The Timeout value is calculated based on round-trip time of packet with a little tolerance, So, if experiencing re-transmissions or poor performance the ACK Timeout could be made longer to accommodate.

Beacon Interval :

Beacon Interval is in the range of

20

~

1024

and set in unit of

millisecond

. The default value is

100

msec.

Access Point (AP) in IEEE 802.11 will send out a special approximated 50-byte frame, called “Beacon”. Beacon is broadcast to all the stations, provides the basic information of AP such as SSID, channel, encryption keys, signal strength, time stamp, support data rate.

All the radio stations received beacon recognizes the existence of such AP, and may proceed next actions if the information from AP matches the requirement. Beacon is sent on a periodic basis, the time interval can be adjusted.

By increasing the beacon interval, you can reduce the number of beacons and associated overhead, but that will likely delay the association and roaming process because stations scanning for available access points may miss the beacons. You can decrease the beacon interval, which increases the rate of beacons. This will make the association and roaming process very responsive; however, the network will incur additional overhead and throughput will go down.

DTIM Interval :

The DTIM interval is in the range of

1

~

255

. The default is

1

.

DTIM is defined as

Delivery Traffic Indication Message

. It is used to notify the wireless stations, which support power saving mode, when to wake up to receive multicast frame. DTIM is necessary and critical in wireless environment as a mechanism to fulfill power-saving synchronization.

A DTIM interval is a count of the number of beacon frames that must occur before the access point sends the buffered multicast frames. For instance, if DTIM Interval is set to 3, then the Wi-Fi clients will expect to receive a multicast frame after receiving three Beacon frame. The higher DTIM interval will help power saving and possibly decrease wireless throughput in multicast applications.

17

TRENDnet User’s Guide

Fragment Threshold :

The Fragment Threshold is in the range of

256

~

2346

byte.

The default is

2346

byte.

Each Wi-Fi packet can be divided into smaller packets, marked with a sequential fragment number and re-assemble in the receiving ends. The purpose is to make a short frame, instead of long frame, transmitting by radio in a heavy noisy environment. Because of sending smaller frames, corruptions are much less likely to occur. The pros is obvious, the cons is the overhead for transmission. So, in a clean environment, higher fragment threshold can be an option to increase throughput.

Fragmentation will be triggered by setting the Fragment Threshold, usually in Bytelength. Only when the frame size is over the Threshold, fragmentation will take place automatically.

RTS Threshold :

TRTS Threshold is in the range of

1~2347

byte. The default is

2347

byte.

The main purpose of enabling RTS by changing RTS threshold is to reduce possible collisions due to hidden wireless clients. RTS in AP will be enabled automatically if the packet size is larger than the Threshold value. By default, RTS is disabled in a normal environment supports non-jumbo frames.

Short Preamble :

By default, it’s “

Enable

”. To

Disable

is to use Long 128-bit

Preamble Synchronization field.

The preamble is used to signal "here is a train of data coming" to the receiver. The short preamble provides 72-bit Synchronization field to improve WLAN transmission efficiency with less overhead.

Tx Burst :

By default, it’s “

Enable

”. To

Disable

is to deactivate Tx Burst.

With TX burst enabled, AP will send many packets in a burst, without collision detection and RTS/CTS for each packet. TX Burst have better throughput but cause interference with other APs in channel.

Pkt_Aggregate :

By default, it's “

Enable

Increase efficiency by aggregating multiple packets of application data into a single transmission frame. In this way, 802.11n networks can send multiple data packets with the fixed overhead cost of just a single frame.

WMM :

By default, it's “

Disable

”. To

Enable

is to use WMM and the WMM parameters should appears.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

Queue

WMM Parameters of Access Point :

This affects traffic flowing from the access point to the client station

Data

Transmitted

AP to Clients

Priority Description

AC_BK Background. Low

High throughput. Bulk data that requires maximum throughput and is not time-sensitive is sent to this queue (FTP data, for example).

AC_BE Best Effort Medium Medium throughput and delay. Most traditional IP

AC_VI Video

AC_VO Voice

Configuring QoS options consists of setting parameters on existing queues for different types of wireless traffic. You can configure different minimum and maximum wait times for the transmission of packets in each queue based on the requirements of the media being sent. Queues automatically provide minimum transmission delay for Voice, Video, multimedia, and mission critical

18

TRENDnet User’s Guide

applications, and rely on best-effort parameters for traditional IP data.

As an Example, time-sensitive Voice & Video, and multimedia are given effectively higher priority for transmission (lower wait times for channel access), while other applications and traditional IP data which are less timesensitive but often more data-intensive are expected to tolerate longer wait times.

Aifsn

: The Arbitration Inter-Frame Spacing Number specifies a wait time

(in milliseconds) for data frames

CWmin

: Minimum Contention Window. This parameter is input to the algorithm that determines the initial random back-off wait time

("window") for retry of a transmission. The value specified here in the

Minimum Contention Window is the upper limit (in milliseconds) of a range from which the initial random back-off wait time is determined.

CWmax

: Maximum Contention Window. The value specified here in the

Maximum Contention Window is the upper limit (in milliseconds) for the doubling of the random back-off value. This doubling continues until either the data frame is sent or the Maximum Contention Window size is reached. Once the Maximum Contention Window size is reached, retries will continue until a maximum number of retries allowed is reached. Valid values for the "cwmax" are 1, 3, 7, 15, 31, 63, 127, 255, 511, or 1024. The value for "cwmax" must be higher than the value for "cwmin".

Txop

: Transmission Opportunity is an interval of time when a WME AP has the right to initiate transmissions onto the wireless medium (WM).

This value specifies (in milliseconds) the Transmission Opportunity (TXOP) for AP; that is, the interval of time when the WMM AP has the right to initiate transmissions on the wireless network.

ACM :

Admission Control Mandatory, ACM only takes effect on AC_VI and

AC_VO. When you do not click Checkbox, it means that the ACM is controlled by the connecting AP. If you click Checkbox, it means that the

Client is in charge.

AckPolicy :

Acknowledgment Policy, WMM defines two ACK policies:

Normal ACK

and

No ACK

. Click “

Checkbox

” indicates “

No ACK

When the no acknowledgment (No ACK) policy is used, the recipient does not acknowledge received packets during wireless packet exchange. This policy is suitable in the environment where communication quality is fine and interference is weak. While the No ACK policy helps improve transmission efficiency, it can cause increased packet loss when communication quality deteriorates. This is because when this policy is

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

 used, a sender does not retransmit packets that have not been received by the recipient.

When the Normal ACK policy is used, the recipient acknowledges each received unicast packet.

WMM Parameters of Station :

This affects traffic flowing from the client station to the access point.

Aifsn

: The Arbitration Inter-Frame Spacing Number specifies a wait time

(in milliseconds) for data frames

CWmin

: Minimum Contention Window. This parameter is input to the algorithm that determines the initial random backoff wait time

("window") for retry of a transmission. The value specified here in the Minimum Contention Window is the upper limit (in milliseconds) of a range from which the initial random backoff wait time is determined.

CWmax

: Maximum Contention Window. The value specified here in the

Maximum Contention Window is the upper limit (in milliseconds) for the doubling of the random backoff value. This doubling continues until either the data frame is sent or the Maximum Contention Window size is reached. Once the Maximum Contention Window size is reached, retries will continue until a maximum number of retries allowed is reached. Valid values for the "cwmax" are 1, 3, 7, 15, 31, 63, 127, 255, 511, or 1024. The value for "cwmax" must be higher than the value for "cwmin".

Txop

: Transmission Opportunity is an interval of time when a WME AP has the right to initiate transmissions onto the wireless medium (WM).

This value specifies (in milliseconds) the Transmission Opportunity (Txop) for AP; that is, the interval of time when the WMM AP has the right to initiate transmissions on the wireless network.

ACM :

Admission Control Mandatory, ACM only takes effect on AC_VI and

AC_VO. When you do not click Checkbox, it means that the ACM is controlled by the connecting AP. If you click Checkbox, it means that the

Client is in charge.

19

TRENDnet User’s Guide

Queue

Data

Transmitted

Clients to AP

Priority Description

AC_BK

AC_BE

Background. Low

High throughput. Bulk data that requires maximum throughput and is not time-sensitive is sent to this queue (FTP data, for example).

Best Effort Medium Medium throughput and delay. Most traditional IP

AC_VI Video

AC_VO Voice

Click

Save

button to save your changes. Click

Reboot

button to activate your changes.

The items in this page are for AP's RF advanced settings and will be applied to

all VAPs

and

WDS Links

.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

Create Virtual AP (VAP)

The TEW-676APBO support broadcasting multiple SSIDs, allowing the creation of Virtual

Access Points, partitioning a single physical access point into

7

logical access points, each of which can have a different set of security, VLAN Tag(ID) and network settings.

Figure

3-2

shows multiple SSIDs with different security type and VLAN settings.

Sales Network

VLA

N #1

W

SSID 1

Engineer Network

Market Network

Guest Network

Accounting Network

VLA

N #2

VLA

N #3

VLA

N #4

E

WPA-

PSK/TKIP

WPA-

PSK/AES

WPA2-

PSK/TKIP

WPA2-

PSK/AES

SSID 2

SSID 3

SSID 4

VLA

N #5

SSID 5

Multiple SSIDs with different Security Type and VLAN Tag

20

TRENDnet User’s Guide

Virtual AP Overview

The administrator can view all of the Virtual AP's settings via this page.

Please click on

Wireless -> Virtual AP Setup

and the Virtual AP Overview Page appears.

VAP :

Indicate the system's Virtual AP.

ESSID :

Indicate the ESSID of the respective Virtual AP

MAC Address :

The MAC address of the VAP Interface is displayed here. When you enable AP and reboot system, the MAC address will display here.

Status :

Indicate the Status of the respective Virtual AP. The

Primary AP

always on.

Security Type :

Indicate an used security type of the respective Virtual AP.

MAC Filter :

Indicate an used MAC filter of the respective Virtual AP.

Edit :

Click

Edit

button to configure Virtual AP's settings, including security type and

MAC Filter.

Virtual AP Setup

For each Virtual AP, administrators can configure SSID, VLAN tag(ID), SSID broadcasting,

Maximum number of client associations, security type settings.

Click

Edit

button on the Edit column, and then a Virtual AP setup page appears.

© Copyright 2012TRENDnet. All Rights Reserved.

VAP0

VAP1

TEW-676APBO

Enable AP :

By default, it’s “

Disable

” for VAP1 ~ VAP6.

The Primary AP always enabled

.

Select “

Enable

” to activate VAP or click “

Disable

” to deactivate this function

ESSID :

Extended Service Set ID, When clients are browsing for available wireless networks, this is the SSID that will appear in the list. ESSID will determine the service type available to AP's clients associated with the specified VAP.

Client Isolation :

Select

Enable

, all clients will be isolated from each other, that means all clients cannot reach to other clients. Below Figures depict Client Isolation and AP Isolation

Cllent Isolation

VAP2

AP Isolation

Hidden SSID :

By default, it’s “

Disable

.

Enable this option to stop the SSID broadcast in your network. When disabled, people could easily obtain the SSID information with the site survey software and get access to the network if security is not turned on. When enabled, network security is enhanced. It’s suggested to enable it after AP security settings are archived and setting of AP clients could make to associate to it.

Maximum Clients :

The default value is

32

. You can enter the number of wireless clients that can associate to a particular SSID. When the number of client is set to 5, only 5 clients at most are allowed to connect to this VAP.

VLAN Tag(ID) :

By default, it’s selected “

Disable

”.

This system supports tagged Virtual LAN(VLAN). A valid number of

1

to

4094

can be entered after it’s enabled. If your network utilize VLANs you could tie a VLAN Tag to a specific SSID, and packets from/to wireless clients belonging to that SSID will be tagged with that VLAN Tag. This enables security of wireless applications by applying VLAN Tag.

21

TRENDnet User’s Guide

Security Type :

Select the desired security type from the drop-down list; the options are

Disable

,

WEP

,

WPA-PSK

,

WPA2-PSK

,

WPA-Enterprise

,

WPA2-Enterprise

and

WEP 802.1X

.

Disable :

Data are unencrypted during transmission when this option is selected.

WEP :

Wired Equivalent Privacy(WEP) is a data encryption mechanism based on a 64-bit or 128-bit shared key.

TEW-676APBO

Cipher Suite :

By default, it is

AES

. Select either AES or TKIP cipher suites

Pre-shared Key :

Enter the pre-shared key; the format shall go with the selected key type.

Group Key Update Period :

By default, it is

3600

seconds. This time interval for rekeying GTK, broadcast/multicast encryption keys, in seconds. Entering the time-length is required.

WPA-Enterprise (or WPA2-Enterprise):

The RADIUS authentication and encryption will be both enabled if this is selected.

Authentication Method :

Enable the desire option among

OPEN

,

SHARED

or

WEPAUTO

.

Key Index : Key index is used to designate the WEP key during data transmission. 4 different WEP keys can be entered at the same time, but only

 one is chosen.

WEP Key # :

Enter

HEX

or

ASCII

format WEP key value; the system supports up to 4 sets of WEP keys.

Key Length

64-bit

128-bit

10 characters

26 characters

WPA-PSK (or WPA2-PSK) :

Hex

5 characters

ASCII

13 characters

WPA (or WPA2) Algorithms, allows the system accessing the network by using the WPA-PSK protected access.

© Copyright 2012TRENDnet. All Rights Reserved.

WPA General Settings :

Cipher Suite :

By default, it is AES. Select either AES or TKIP cipher suites

Group Key Update Period :

By default, it’s

3600

seconds. This time interval for rekeying GTK, broadcast/multicast encryption keys, in seconds. Entering the time-length is required.

PMK Cache Period :

By default, it's 10 minutes. Set

WPA2

PMKID cache timeout period, after time out, the cached key will be deleted.

Pre-Authentication :

By default, it's “Disable”. To Enable is use to speed up roaming before pre-authenticating IEEE 802.1X/EAP part of the full RSN authentication and key handshake before actually associating with a new AP.

Radius Server Settings :

IP Address :

Enter the IP address of the Authentication RADIUS server.

Port :

By default, it’s

1812

.

The port number used to communicate with RADIUS server.

Shared secret :

A secret key used between system and RADIUS server. Supports

8

to

64

characters.

22

TRENDnet User’s Guide

Session Timeout :

The Session timeout is in the range of

0

~

60

seconds

. The default is

0

to disable re-authenticate service.

Amount of time before a client will be required to re-authenticate.

WEP 802.1X :

When WEP 802.1x Authentication is enabled, please refer to the following Dynamic WEP and RADIUS settings to complete configuration.

TEW-676APBO

Wireless MAC Filter Setup

Continue

Virtual AP Setup

section. For each Virtual AP setting, the administrator can allow or reject clients to access each Virtual AP.

Radius Server Settings :

IP Address :

Enter the IP address of the Authentication RADIUS server.

Port :

By default, it’s

1812

.

The port number used to communicate with RADIUS server.

Shared secret :

A secret key used between system and RADIUS server. Supports

8

to

64

characters.

Session Timeout :

The Session timeout is in the range of

0

~

60

seconds

. The default is

0

to disable re-authenticate service.

Amount of time before a client will be required to re-authenticate.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes

© Copyright 2012TRENDnet. All Rights Reserved.

MAC Filter Setup :

By default, it’s “

Disable

”. Options are

Disable, Only Deny List

MAC or Only Allow List MAC

.

Two ways to set MAC filter rules :

Only Allow List MAC

.

The wireless clients in the “

Enable

” list will be

allowed

to access the Access Point;

All others or clients in the “

Disable

” list will be

denied

.

Only Deny List MAC

.

The wireless clients in the “

Enable

” list will be

denied

to access the Access Point; All others or clients in the “

Disable

” list will be

allowed

.

Add a station MAC :

Enter MAC address (e.g. aa:bb:cc:00:00:0a) and click “

Add

” button, then the MAC address should display in the “

Enable

” List.

There are a maximum of

20

clients allowed in this “Enable” List. The MAC addresses of the wireless clients can be added and removed to the list using the

Add

and

Remove

buttons

.

Click

Reboot

button to activate your changes

23

TRENDnet User’s Guide

Wireless Network Expansion

The administrator could create WDS Links to expand wireless network. When WDS is enabled, access point functions as a wireless bridge and is able to communicate with other access points via WDS links.

A WDS link is bidirectional and both side must support WDS. Access points know each other by MAC Address. In other words, each access point needs to include MAC address of its peer. Ensure all access points are configured with the same channel and own same security type settings.

Remote Bass Station

WDS

SSID:

Please click on

Wireless -> WDS Setup

and follow the below setting.

TEW-676APBO

Security Type :

Option is “

Disable

”, “

WEP

”, “

TKIP

”or “

AES

” from drop-down list.

Needs the same type to build WDS links. Security type takes effect when WDS is enabled.

WEP Key :

Enter

5 / 13 ASCII

or

10 / 26 HEX

format WEP key.

TKIP Key :

Enter

8

to

63 ASCII

or

64 HEX

format TKIP key.

AES Key :

Enter

8

to

63 ASCII

or

64 HEX

format AES key.

WDS MAC List

Enable :

Click

Enable

to create WDS link.

WDS Peer's MAC Address :

Enter the MAC address of WDS peer.

Description :

Description of WDS link.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes

System Status

This section breaks down into subsections of

System Overview

,

Associated Clients

Status

,

WDS Link Status

,

Extra Information

and

Event Log

.

System Overview

Display detailed information of

System, Network, LAN and Wireless

in the System

Overview page.

System :

Display the information of the system.

© Copyright 2012TRENDnet. All Rights Reserved.

System Name :

The name of the system.

Operating Mode :

The mode currently in service.

Location :

Deployed geographical location.

24

TRENDnet User’s Guide

Description :

A description of the system.

Firmware Version :

The current installed firmware version.

Firmware Date :

The build time of installed firmware.

Device Time :

The current time of the system.

System Up Time :

The time period that system has been in service since last reboot.

Network Information :

Supports Static or Dynamic modes on the LAN interface.

TEW-676APBO

Wireless Information :

Display total received and transmitted statistics on available

Virtual AP.

IP Address :

The management IP of system. By default, it’s 192.168.2.254.

IP Netmask :

The network mask. By default, it’s 255.255.255.0.

IP Gateway :

The gateway IP address and by default, it’s 192.168.2.1.

Primary DNS :

interface.

The primary DNS server in service.

Secondary DNS :

The secondary DNS server in service.

LAN Information :

Display total received and transmitted statistics on the LAN

MAC Address :

The MAC address of the Wireless port.

Channel :

The current channel on the Wireless port.

Rate :

The current Bit Rate on the Wireless port.

Receive bytes :

The total received packets in bytes on the Wireless port.

Receive packets :

The total received packets on the Wireless port.

Transmit bytes :

The total transmitted packets in bytes on the Wireless port.

Transmit packets :

The total transmitted packets on the Wireless port.

Associated Clients Status

It displays ESSID, on/off Status, Security Type, total number of wireless clients associated with all Virtual AP.

MAC Address :

The MAC address of the LAN port.

Receive bytes :

The total received packets in bytes on the LAN port.

Receive packets :

The total received packets of the LAN port.

Transmit bytes :

The total transmitted packets in bytes of the LAN port.

Transmit packets :

The total transmitted packets of the LAN port.

© Copyright 2012TRENDnet. All Rights Reserved.

25

TRENDnet User’s Guide

TEW-676APBO

VAP Information :

Highlights key VAP information.

VAP :

Available VAP from Primary AP to VAP6.

ESSID :

Display name of ESSID for each VAP.

MAC Address :

Display MAC address for each VAP.

Status :

On/Off

Security Type :

Display chosen security type; WEP, WPA/WPA2-PSK,

WPA/WPA2-Enterprise.

Clients :

Display total number of wireless connections for each VAP.

VAP Clients :

Display all associated clients on each Virtual AP.

MAC Address :

MAC address of associated clients

Signal Strength ANT0/ANT1 :

Signal Strength of from associated clients.

Bandwidth :

Channel bandwidth of from associated clients

Idle Time :

Last inactive time period in seconds for a wireless connection.

Connect Time :

Total connection time period in seconds for a wireless

 connection.

Disconnect :

Click “

Delete

” button to manually disconnect a wireless client in a

Virtual AP.

Show WDS Link Status

Peers MAC Address, antenna 0/1 received signal strength, phy mode and channel bandwidth for each WDS are available.

© Copyright 2012TRENDnet. All Rights Reserved.

MAC Address :

Display MAC address of WDS peer.

Signal Strength ANT0/ANT1 :

Indicate the signal strength of the respective WDS links.

Phy Mode :

Indicate the phy mode of the respective WDS linked.

BandWidth :

Indicate the channel bandwidth of the respective WDS linked.

MCS :

Indicate the MCS of the respective WDS linked.

SGI :

Indicate the SGI (Short Guard Interval) of the respective WDS linked. “1” indicate the Short Guard Interval, “0” indicate the Long Guard Interval.

Extra Information

Users could pull out information such as Route table, ARP table, MAC table, Bridge table or STP available in the drop-down list from system. The “Refresh” button is used to retrieve latest table information.

Route table information :

Select “

Route table information

” on the drop-down list to display route table.

26

TRENDnet User’s Guide

TEW-676APBO could be used as a L2 or L3 device. It doesn’t support dynamic routing protocols such as RIP or OSPF. Static routes to specific hosts, networks or default gateway are set up automatically according to the IP configuration of system's interfaces. When used as a L2 device, it could switch packets and, as L3 device, it’s capable of being a gateway to route packets inward and outward.

TEW-676APBO

ARP table Information :

Select “

ARP Table Information

” on the drop-down list to display ARP table.

ARP associates each IP address to a unique hardware address (MAC) of a device. It is important to have a unique IP address as final destination to switch packets to.

Bridge table information :

Select “

Bridge Table information

” on the drop-down list to display bridge table.

Bridge table will show Bridge ID and STP's Status on the each Ethernet bridge and its attached interfaces, the Bridge Port should be attached to some interfaces (e.g. eth2, ra0~ra6 and wds0~wds3).

This table displays local MAC addresses associated with wired or wireless interfaces, but also remember non-local MAC addresses learned from wired or wireless interfaces.

Ageing timers will be reset when existing MAC addresses in table are learned again or added when new MAC addresses are seen from wired or wireless interfaces as well. When time runs out for a particular entry, it will be pruned from the table. In that situation, switching packet to that particular MAC address will be dropped.

Bridge STP Information :

Select “

Bridge STP Information

” on the drop-down list to display a list of bridge STP information.

Bridge MAC information :

Select “

Bridge MACs Information

” on the drop-down list to display MAC table.

© Copyright 2012TRENDnet. All Rights Reserved.

27

TRENDnet User’s Guide

TEW-676APBO

Event Log

The Event log displays system events when system is up and running. Also, it becomes very useful as a troubleshooting tool when issues are experienced in system.

© Copyright 2012TRENDnet. All Rights Reserved.

Time :

The date and time when the event occurred.

Facility :

It helps users to identify source of events such “System” or “User”

Severity :

Severity level that a specific event is associated such as “info”, “error”,

“warning”, etc.

Message :

Description of the event.

Click

Refresh

button to renew the log, or click

Clear

button to clear all the record.

28

TRENDnet User’s Guide

WDS Mode Configuration

Please refer to illustrations of the section 1.3 for possible applications in the WDS mode.

This section provides detailed explanation for users to configure in the WDS mode with help of illustrations. In the WDS mode, functions listed in the table below are also available from the Web-based GUI interface.

Option

Functions

System

Operating

LAN

Management

Time Server

SNMP

Wireless

General Setup

Advanced Setup

WDS Setup

Utilities

Profiles Settings

Firmware

Network Utility

Reboot

Status

System

WDS Status

Extra Info

Event Log

WDS Mode Functions

External Network Connection

Network Requirement

You could expand your Ethernet network via WDS link. In this mode, the TEW-676APBO connects directly to a wired LAN, and wirelessly bridges to a remote access point via a

WDS link as shown in Figure 4-1. In the mode, it can’t associate with any wireless clients.

WDS

Point to Point network Configuration

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

Configure LAN IP

Here are the instructions for how to setup the local IP Address and Netmask.

Please click on

System -> LAN

and follow the below setting.

Mode :

Check either “Static IP” or “Dynamic IP” button as desired to set up the system IP of LAN port .

Static IP :

The administrator can manually setup the LAN IP address when

 static IP is available/ preferred.

IP Address :

The IP address of the LAN port; default IP address is

192.168.2.254

IP Netmask :

The Subnet mask of the LAN port; default Netmask is

255.255.255.0

IP Gateway :

The default gateway of the LAN port; default Gateway is

192.168.2.1

Dynamic IP :

This configuration type is applicable when the TEW-676APBO is connected to a network with the presence of a DHCP server; all related IP information will be provided by the DHCP server automatically.

Hostname :

The Hostname of the LAN port

DNS :

Check either “No Default DNS Server” or “Specify DNS Server IP” button as desired to set up the system DNS.

Primary :

The IP address of the primary DNS server.

Secondary :

The IP address of the secondary DNS server.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes

29

TRENDnet User’s Guide

Wireless Network Expansion

The network manager can configure related wireless settings,

General Settings,

Advanced Settings

and

WDS Settings

.

General Setup

The administrator can change the data transmission, channel and output power settings for the system. Please click on

Wireless -> General Setup

and follow the below setting.

TEW-676APBO

MAC Address :

The MAC address of the Wireless interface is displayed here.

Band Mode :

Select an appropriate wireless band; bands available are

801.11a

or

802.11a/n mixed mode

.

Transmit Rate Control :

Select the desired rate from the drop-down list; the options are auto or ranging from

6

to

54Mbps

only for

802.11a

mode.

Tx Power :

You can adjust the output power of the system to get the appropriate coverage for your wireless network. Specify digit number between

1

to

100

(the unit is %) for your environment. If you are not sure which setting to choose, then keep the default setting,

100

%.

When

Band Mode

select in

802.11a only mode

, the

HT(High Throughput)

settings should be hidden immediately.

HT TxStream

/

RxStream :

By default, it's

2

.

© Copyright 2012TRENDnet. All Rights Reserved.

Operating Mode :

By default, it's Mixed mode

Mixed Mode :

In this mode packets are transmitted with a preamble compatible with the legacy 802.11a/g, the rest of the packet has a new format.

In this mode the receiver shall be able to decode both the Mixed Mode packets and legacy packets.

Green Field :

In this mode high throughput packets are transmitted without a legacy compatible part.

Channel Bandwidth :

The "

20/40

” MHz option is usually best. The other option is available for special circumstances.

Guard Interval :

Using “

Auto

” option can increase throughput. However, it can also increase error rate in some installations, due to increased sensitivity to radiofrequency reflections. Select the option that works best for your installation.

MCS :

This parameter represents transmission rate. By default (Auto) the fastest possible transmission rate will be selected. You have the option of selecting the speed if necessary. (Refer to

Appendix C. MCS Data Rate

)

Reverse Direction Grant(RDG) :

Disable or enable reserve direction grant. Default is enabled.

A-MSDU :

Aggregated Mac Service Data Unit . Select

Enable

to allow aggregation for multiple MSDUs in one MPDU Default is disabled.

Auto Block ACK :

Disable or enable auto block ACK. Default is enabled.

Decline BA Request :

Disable or enable decline BA request. Default is disabled.

Change these settings as described here and click

Save

button to save your changes.

Click

Reboot

button to activate your changes. The items in this page are for AP's RF general settings and will be applied to

all WDS Links

.

30

TRENDnet User’s Guide

Wireless Advanced Setup

To achieve optimal wireless performance, it is necessary to tweak advance setting per requirements properly, not necessary higher the better or lower.

The administrator can change the RTS threshold and fragmentation threshold settings for the system. Please click on

Wireless -> Advanced Setup

and follow the below setting.

Short Slot :

By default, it’s “

Enable

” for educing the slot time from the standard

20

microseconds

to the

9

microsecond

short slot time

Slot time is the amount of time a device waits after a collision before retransmitting a packet. Reducing the slot time decreases the overall back-off, which increases throughput. Back-off, which is a multiple of the slot time, is the random length of time a station waits before sending a packet on the LAN. For a sender and receiver own right of the channel the shorter slot time help manage shorter wait time to retransmit from collision because of hidden wireless clients or other causes. When collision sources can be removed sooner and other senders attempting to send are listening the channel (CSMA/CA) the owner of the channel should continue ownership and finish their transmission and release the channel. Then, following ownership of the channel will be sooner for the new pair due to shorter slot time.

However, when long duration of existing collision sources and shorter slot time exist the owners might experience subsequent collisions. When adjustment to longer slot time can’t improve performance then RTS/CTS could supplement and help

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

improve performance.

Extra Slot Time :

Slot time is in the range of

1~255

and set in unit of

microsecond

.

The default value is

9

microsecond.

ACK Timeout :

ACK timeout is in the range of

1~255

and set in unit of

microsecond

.

The default value is

32

microsecond.

All data transmission in 802.11b/g request an “Acknowledgement” (ACK) send by receiving radio. The transmitter will resend the original packet if correspondent ACK failed to arrive within specific time interval, also refer to as “ACK Timeout”.

ACK Timeout is adjustable due to the fact that distance between two radio links may vary in different deployment. ACK Timeout makes significant influence in performance of long distance radio link. If ACK Timeout is set too short, transmitter will start to “Resend” packet before ACK is received, and throughputs become low due to excessively high re-transmission.

ACK Timeout is best determined by distance between the radios, data rate of average environment. The Timeout value is calculated based on round-trip time of packet with a little tolerance, So, if experiencing re-transmissions or poor performance the ACK Timeout could be made longer to accommodate.

Beacon Interval :

Beacon Interval is in the range of

20

~

1024

and set in unit of

millisecond

. The default value is

100

msec.

Access Point (AP) in IEEE 802.11 will send out a special approximated 50-byte frame, called “Beacon”. Beacon is broadcast to all the stations, provides the basic information of AP such as SSID, channel, encryption keys, signal strength, time stamp, support data rate.

All the radio stations received beacon recognizes the existence of such AP, and may proceed next actions if the information from AP matches the requirement. Beacon is sent on a periodic basis, the time interval can be adjusted.

By increasing the beacon interval, you can reduce the number of beacons and associated overhead, but that will likely delay the association and roaming process because stations scanning for available access points may miss the beacons. You can decrease the beacon interval, which increases the rate of beacons. This will make the association and roaming process very responsive; however, the network will incur additional overhead and throughput will go down.

DTIM Interval :

The DTIM interval is in the range of

1

~

255

. The default is

1

.

DTIM is defined as

Delivery Traffic Indication Message

. It is used to notify the wireless stations, which support power saving mode, when to wake up to receive multicast frame. DTIM is necessary and critical in wireless environment as a

31

TRENDnet User’s Guide

 mechanism to fulfill power-saving synchronization.

A DTIM interval is a count of the number of beacon frames that must occur before the access point sends the buffered multicast frames. For instance, if DTIM Interval is set to 3, then the Wi-Fi clients will expect to receive a multicast frame after receiving three Beacon frame. The higher DTIM interval will help power saving and possibly decrease wireless throughput in multicast applications.

Fragment Threshold :

The Fragment Threshold is in the range of

256

~

2346

byte.

The default is

2346

byte.

Each Wi-Fi packet can be divided into smaller packets, marked with a sequential fragment number and re-assemble in the receiving ends. The purpose is to make a short frame, instead of long frame, transmitting by radio in a heavy noisy environment. Because of sending smaller frames, corruptions are much less likely to occur. The pros is obvious, the cons is the overhead for transmission. So, in a clean environment, higher fragment threshold can be an option to increase throughput.

Fragmentation will be triggered by setting the Fragment Threshold, usually in Bytelength. Only when the frame size is over the Threshold, fragmentation will take place automatically.

RTS Threshold :

TRTS Threshold is in the range of

1~2347

byte. The default is

2347

byte.

The main purpose of enabling RTS by changing RTS threshold is to reduce possible collisions due to hidden wireless clients. RTS in AP will be enabled automatically if the packet size is larger than the Threshold value. By default, RTS is disabled in a normal environment supports non-jumbo frames.

Short Preamble :

By default, it’s “

Enable

”. To

Disable

is to use Long 128-bit

Preamble Synchronization field.

The preamble is used to signal "here is a train of data coming" to the receiver. The short preamble provides 72-bit Synchronization field to improve WLAN transmission efficiency with less overhead.

Tx Burst :

By default, it’s “

Enable

”. To

Disable

is to deactivate Tx Burst.

With TX burst enabled, AP will send many packets in a burst, without collision detection and RTS/CTS for each packet. TX Burst have better throughput but cause interference with other APs in channel.

Pkt_Aggregate :

By default, it's “

Enable

Increase efficiency by aggregating multiple packets of application data into a single transmission frame. In this way, 802.11n networks can send multiple data packets

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

with the fixed overhead cost of just a single frame.

WMM :

By default, it's “

Disable

”. To

Enable

is to use WMM and the WMM parameters should appears.

Queue

WMM Parameters of Access Point :

This affects traffic flowing from the access point to the client station

Data

Transmitted

AP to Clients

Priority Description

AC_BK Background. Low

High throughput. Bulk data that requires maximum throughput and is not time-sensitive is sent to this queue (FTP data, for example).

AC_BE Best Effort Med Medium throughput and delay. Most traditional IP

AC_VI Video

AC_VO Voice

Configuring QoS options consists of setting parameters on existing queues for different types of wireless traffic. You can configure different minimum and maximum wait times for the transmission of packets in each queue based on the requirements of the media being sent. Queues automatically provide

32

TRENDnet User’s Guide

minimum transmission delay for Voice, Video, multimedia, and mission critical applications, and rely on best-effort parameters for traditional IP data.

As an Example, time-sensitive Voice & Video, and multimedia are given effectively higher priority for transmission (lower wait times for channel access), while other applications and traditional IP data which are less timesensitive but often more data-intensive are expected to tolerate longer wait times.

Aifsn

: The Arbitration Inter-Frame Spacing Number specifies a wait time

(in milliseconds) for data frames

CWmin

: Minimum Contention Window. This parameter is input to the algorithm that determines the initial random backoff wait time

("window") for retry of a transmission. The value specified here in the

Minimum Contention Window is the upper limit (in milliseconds) of a range from which the initial random backoff wait time is determined.

CWmax

: Maximum Contention Window. The value specified here in the

Maximum Contention Window is the upper limit (in milliseconds) for the doubling of the random backoff value. This doubling continues until either the data frame is sent or the Maximum Contention Window size is reached. Once the Maximum Contention Window size is reached, retries will continue until a maximum number of retries allowed is reached. Valid values for the "cwmax" are 1, 3, 7, 15, 31, 63, 127, 255, 511, or 1024. The value for "cwmax" must be higher than the value for "cwmin".

Txop

: Transmission Opportunity is an interval of time when a WME AP has the right to initiate transmissions onto the wireless medium (WM).

This value specifies (in milliseconds) the Transmission Opportunity (TXOP) for AP; that is, the interval of time when the WMM AP has the right to initiate transmissions on the wireless network.

ACM :

Admission Control Mandatory, ACM only takes effect on AC_VI and

AC_VO. When you do not click Checkbox, it means that the ACM is controlled by the connecting AP. If you click Checkbox, it means that the

Client is in charge.

AckPolicy :

Acknowledgment Policy, WMM defines two ACK policies:

Normal ACK

and

No ACK

. Click “

Checkbox

” indicates “

No ACK

When the no acknowledgment (No ACK) policy is used, the recipient does not acknowledge received packets during wireless packet exchange. This policy is suitable in the environment where communication quality is fine and interference is weak. While the No ACK policy helps improve transmission efficiency, it can cause increased packet loss when

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

Queue

AC_BK communication quality deteriorates. This is because when this policy is used, a sender does not retransmit packets that have not been received by the recipient.

When the Normal ACK policy is used, the recipient acknowledges each received unicast packet.

Data Transmitted

Clients to AP

Priority Description

Background. Low

High throughput. Bulk data that requires maximum throughput and is not time-sensitive is sent to this queue (FTP data, for example).

AC_BE Best Effort

AC_VI Video

AC_VO Voice

WMM Parameters of Station :

This affects traffic flowing from the client station to the access point.

Aifsn

: The Arbitration Inter-Frame Spacing Number specifies a wait time

(in milliseconds) for data frames

CWmin

: Minimum Contention Window. This parameter is input to the algorithm that determines the initial random backoff wait time ("window") for retry of a transmission.

The value specified here in the Minimum Contention Window is the upper limit (in milliseconds) of a range from which the initial random backoff wait time is determined.

CWmax

: Maximum Contention Window. The value specified here in the Maximum

Contention Window is the upper limit (in milliseconds) for the doubling of the random backoff value. This doubling continues until either the data frame is sent or the

Maximum Contention Window size is reached. Once the Maximum Contention Window size is reached, retries will continue until a maximum number of retries allowed is reached. Valid values for the "cwmax" are 1, 3, 7, 15, 31, 63, 127, 255, 511, or 1024. The value for "cwmax" must be higher than the value for "cwmin".

Txop

: Transmission Opportunity is an interval of time when a WME AP has the right to initiate transmissions onto the wireless medium (WM). This value specifies (in

33

TRENDnet User’s Guide

milliseconds) the Transmission Opportunity (Txop) for AP; that is, the interval of time when the WMM AP has the right to initiate transmissions on the wireless network.

ACM :

Admission Control Mandatory, ACM only takes effect on AC_VI and AC_VO. When you do not click Checkbox, it means that the ACM is controlled by the connecting AP. If you click Checkbox, it means that the Client is in charge.

Change these settings as described here and click

Save

button to save your changes.

Click

Reboot

button to activate your changes. The items in this page are for AP's RF advanced settings and will be applied to

all WDS Links

.

WDS Setup

The administrator could create WDS Links to expand wireless network. When WDS is enabled, access point functions as a wireless bridge and is able to communicate with other access points via WDS links.

A WDS link is bidirectional and both side must support WDS. Access points know each other by MAC Address. In other words, each access point needs to include MAC address of its peer. Ensure all access points are configured with the same channel and own same security type settings.

TEW-676APBO

 enabled.

WEP Key :

Enter

5 / 13 ASCII

or

10 / 26 HEX

format WEP key.

TKIP Key :

Enter

8

to

63 ASCII

or

64 HEX

format TKIP key.

AES Key :

Enter

8

to

63 ASCII

or

64 HEX

format AES key.

WDS MAC List

Enable :

Click

Enable

to create WDS link.

WDS Peer's MAC Address :

Enter the MAC address of WDS peer.

Description :

Description of WDS link.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes

System Status

This section breaks down into subsections of

System Overview

,

WDS Link Status

,

Extra

Information

and

Event Log

.

System Overview

Detailed information on

System

,

Network

,

LAN Information

and

Wireless Information

can be reviewed via this page.

System :

Display the information of the system.

Security Type :

Option is “

Disable

”, “

WEP

”, “

TKIP

” or “

AES

” from drop-down list.

Needs the same type to build WDS links. Security type takes effect when WDS is

© Copyright 2012TRENDnet. All Rights Reserved.

System Name :

The name of the system.

Operating Mode :

The mode currently in service.

34

TRENDnet User’s Guide

Location :

The reminding note on the geographical location of the system.

Description :

The reminding note of the system.

Firmware Version :

The current firmware version installed.

Firmware Date :

The build time of the firmware installed.

Device Time :

The current time of the system.

System Up Time :

The time period that system has been in service since last reboot.

Network Information :

Display the information of the Network.

TEW-676APBO

Receive packets :

The total received packets of the LAN port.

Transmit bytes :

The total transmitted packets in bytes of the LAN port.

Transmit packets :

The total transmitted packets of the LAN port.

Wireless Information :

Display the detailed receive and transmit statistics of

Wireless interface.

Mode :

Supports Static or Dynamic modes on the LAN interface.

IP Address :

The management IP of system. By default, it’s 192.168.2.254.

IP Netmask :

The network mask. By default, it’s 255.255.255.0.

IP Gateway :

The gateway IP address and by default, it’s 192.168.2.1.

Primary DNS :

The primary DNS server in service.

Secondary DNS :

The secondary DNS server in service.

LAN Information :

Display total received and transmitted statistics on the LAN interface.

MAC Address :

The MAC address of the Wireless port.

Channel :

The current channel on the Wireless port.

Rate :

The current Bit Rate on the Wireless port.

Receive bytes :

The total received packets in bytes on the Wireless port.

Receive packets :

The total received packets of the Wireless port.

Transmit bytes :

The total transmitted packets in bytes of the Wireless port.

Transmit packets :

The total transmitted packets of the Wireless port.

WDS List

Peers MAC Address, antenna 0/1 received signal strength, phy mode and channel bandwidth for each WDS are available.

MAC Address :

The MAC address of the LAN port.

Receive bytes :

The total received packets in bytes on the LAN port.

© Copyright 2012TRENDnet. All Rights Reserved.

35

TRENDnet User’s Guide

MAC Address :

Display MAC address of WDS peer.

Signal Strength ANT0/ANT1 :

Indicate the signal strength of the respective WDS links.

Phy Mode :

Indicate the phy mode of the respective WDS linked.

BandWidth :

Indicate the channel bandwidth of the respective WDS linked.

MCS :

Indicate the MCS of the respective WDS linked.

SGI :

Indicate the SGI (Short Guard Interval) of the respective WDS linked. “1” indicate the Short Guard Interval, “0” indicate the Long Guard Interval.

Extra Information

Users could pull out information such as Route table, ARP table, MAC table, Bridge table or STP available in the drop-down list from system. The “Refresh” button is used to retrieve latest table information.

TEW-676APBO

ARP table Information :

Select “

ARP Table Information

” on the drop-down list to display ARP table.

ARP associates each IP address to a unique hardware address (MAC) of a device. It is important to have a unique IP address as final destination to switch packets to.

Bridge table information :

Select “

Bridge Table information

” on the drop-down list to display bridge table.

Bridge table will show Bridge ID and STP's Status on the each Ethernet bridge and its attached interfaces, the Bridge Port should be attached to some interfaces (e.g. eth2, ra0 and wds0~wds3).

Route table information :

Select “

Route table information

” on the drop-down list to display route table.

TEW-676APBO could be used as a L2 or L3 device. It doesn’t support dynamic routing protocols such as RIP or OSPF. Static routes to specific hosts, networks or default gateway are set up automatically according to the IP configuration of system's interfaces. When used as a L2 device, it could switch packets and, as L3 device, it’s capable of being a gateway to route packets inward and outward.

Bridge MAC information :

Select “

Bridge MACs Information

” on the drop-down list to display MAC table.

This table displays local MAC addresses associated with wired or wireless interfaces, but also remember non-local MAC addresses learned from wired or wireless interfaces.

Ageing timers will be reset when existing MAC addresses in table are learned again or added when new MAC addresses are seen from wired or wireless interfaces as well. When time runs out for a particular entry, it will be pruned from the table. In that situation, switching packet to that particular MAC address will be discontinued.

© Copyright 2012TRENDnet. All Rights Reserved.

36

TRENDnet User’s Guide

Bridge STP Information :

Select “

Bridge STP Information

” on the drop-down list to display a list of bridge STP information.

TEW-676APBO

Event Log

The Event log displays system events when system is up and running. Also, it becomes very useful as a troubleshooting tool when issues are experienced in system.

© Copyright 2012TRENDnet. All Rights Reserved.

Time :

The date and time when the event occurred.

Facility :

It helps users to identify source of events such “System” or “User”

Severity :

Severity level that a specific event is associated such as “info”, “error”,

“warning”, etc.

Message :

Description of the event.

Click

Refresh

button to renew the log, or click

Clear

button to clear all the record.

37

TRENDnet User’s Guide

CPE Mode Configuration

When CPE mode is chosen, the system can be configured as a Customer Premises

Equipment(CPE). This section provides detailed explanation for users to configure in the

CPE mode with help of illustrations. In the CPE mode, functions listed in the table below are also available from the Web-based GUI interface.

OPTION System Wireless Advance Utilities Status

Operating

Mode

General

Setup

DMZ

Profiles

Settings

System

Overview

WAN

LAN

Wireless

Profile

Site

Survey

IP Filter

Firmware

Upgrade

Station

Statistics

Extra Info

Functions

DDNS

Management

Virtual

Server

Parental

Control

Reboot QoS Plot

Event Log

Time Server QoS

UPNP

SNMP

CPE Mode Functions

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

External Network Connection

Network Requirement

It can be used as an Outdoor Customer Premises Equipment (CPE) to receive wireless signal over last mile application, helping WISPs deliver wireless broadband Internet service to residents and business customers. In the CPE mode, TEW-676APBO is a gateway enabled with NAT and DHCP Server functions. The wired clients connected to

TEW-676APBO are in

different

subnet from those connected to Main Base Station, and, in CPE mode, it

does not

accept wireless association from wireless clients.

Main

WIFI WAN

N

A

CPE mode network configuration

38

TRENDnet User’s Guide

Configure WAN Setup

There are three connection types for the WAN port :

Static IP

,

Dynamic IP

,

PPPoE

and

PPTP

.

Please click on

System -> WAN

and follow the below setting.

TEW-676APBO

Dynamic IP :

Please consult with WISP for correct wireless settings to associate with WISP AP before a dynamic IP, along with related IP settings including DNS can be available from DHCP server. If IP Address is not assigned, please double check with your wireless settings and ensure successful association. Also, you may go to “

WAN Information

” in the Overview page to click

Release

button to release IP address and click

Renew

button to renew IP address again.

Hostname :

The Hostname of the WAN port

Mode :

By default, it’s “

Static IP

”. Check “Static IP”, “Dynamic IP”, “PPPoE” or

“PPTP”to set up system WAN IP.

Static IP :

Users can manually setup the WAN IP address with a static IP provided by WISP.

IP Address :

The IP address of the WAN port; default IP address is

192.168.1.254

IP Netmask :

The Subnet mask of the WAN port; default Netmask is

255.255.255.0

IP Gateway :

The default gateway of the WAN port; default Gateway is

192.168.1.1

© Copyright 2012TRENDnet. All Rights Reserved.

PPPoE :

To create wireless PPPoE WAN connection to a PPPoE server in network.

User Name :

Enter User Name for PPPoE connection

Password :

Enter Password for PPPoE connection

Reconnect Mode :

Always on

– A connection to Internet is always maintained.

On Demand

– A connection to Internet is made as needed.

Manual

– Click the “

Connect

” button on “

WAN Information

” in the

Overview page to connect to the Internet.

Idle Time :

Time to last before disconnecting PPPoE session when it is idle. Enter preferred Idle Time in minutes. Default is “

0

”, indicates disabled. When Idle time is disabled, the “

Reconnect Mode

” will turn out

Always on

MTU :

By default, it’s

1492

bytes. MTU stands for Maximum Transmission

Unit. Consult with WISP for a correct MTU setting.

39

TRENDnet User’s Guide

PPTP :

The Point-to-Point Tunneling Protocol (PPTP) mode enables the implementation of secure multi-protocol Virtual Private Networks (VPNs) through public networks.

TEW-676APBO

DNS :

Check “No Default DNS Server” or “Specify DNS Server IP” radial button as desired to set up system DNS.

Primary :

The IP address of the primary DNS server.

Secondary :

The IP address of the secondary DNS server.

MAC Clone :

The MAC address is a 12-digit HEX code uniquely assigned to hardware as identification. Some ISPs require you to register a MAC address in order to access to Internet. If not, you could use default MAC or clone MAC from a PC.

(CPE+AP

Mode does not support MAC Clone function)

IP Address :

The IP address of the WAN port

IP Netmask :

The Subnet mask of the WAN port

PPTP Server IP Address :

The IP address of the PPTP server

User Name :

Enter User Name for PPTP connection

Password :

Enter Password for PPTP connection

Reconnect Mode :

Always on

– A connection to Internet is always maintained.

On Demand

– A connection to Internet is made as needed.

Manual

– Click the “

Connect

” button on “

WAN Information

” in the

Overview page to connect to the Internet.

Idle Time :

Time to last before disconnecting PPPoE session when it is idle. Enter preferred Idle Time in minutes. Default is “

0

”, indicates disabled. When Idle time is disabled, the “

Reconnect Mode

” will turn out

Always on

MTU :

By default, it’s

1460

bytes. MTU stands for Maximum Transmission

Unit. Consult with WISP for a correct MTU setting.

MPPE Encryption :

Microsoft Point-to-Point Encryption (MPPE) encrypts data in Point-to-Point Protocol(PPP)-based dial-up connections or Pointto-Point Tunneling Protocol (PPTP) virtual private network (VPN) connections.

128

-

bit

key (strong) and

40

-

bit

key (standard) MPPE encryption schemes are supported. MPPE provides data security for the

PPTP connection that is between the VPN client and the VPN server.

© Copyright 2012TRENDnet. All Rights Reserved.

Keep Default MAC Address :

Keep the default MAC address of WAN port on the system.

Clone MAC Address :

If you want to clone the MAC address of the PC, then click the

Clone MAC Address

button. The system will automatically detect your

PC's MAC address.

Manual MAC Address :

Enter the MAC address registered with your ISP.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes

40

TRENDnet User’s Guide

Configure DDNS Setup

Dynamic DNS allows you to map domain name to dynamic IP address.

Please click on

System -> DDNS Setup

and follow the below setting.

Configure LAN Setup

TEW-676APBO

Here are the instructions for how to setup the local IP Address and Netmask.

Please click on

System -> LAN

and follow the below setting.

Enabled:

By default, it’s “

Disable

.

The mapping domain name won’t change when dynamic IP changes. The beauty of it is no need to remember the dynamic WAP IP while accessing to it.

Service Provider:

Select the preferred Service Provider from the drop-down list including

dyndns

,

dhs

,

ods

and

tzo

Hostname:

Host Name that you register to Dynamic-DNS service and export.

User Name & Password:

User Name and Password are used to login DDNS service.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes.

LAN IP :

The administrator can manually setup the LAN IP address.

IP Address :

The IP address of the LAN port; default IP address is

192.168.2.254

IP Netmask :

The Subnet mask of the LAN port; default Netmask is

255.255.255.0

DHCP Setup :

Devices connected to the system can obtain an IP address automatically when this service is enabled.

© Copyright 2012TRENDnet. All Rights Reserved.

DHCP :

Check

Enable

button to activate this function or

Disable

to deactivate this service.

Start IP / End IP:

Specify the range of IP addresses to be used by the DHCP server when assigning IP address to clients. The default range IP address is

192.168.2.10 to 192.168.2.70, the netmask is 255.255.255.0

DNS1 IP :

Enter IP address of the first DNS server; this field is required.

DNS2 IP :

Enter IP address of the second DNS server; this is optional.

WINS IP :

Enter IP address of the Windows Internet Name Service (WINS)

41

TRENDnet User’s Guide

 server; this is optional.

Domain :

Enter the domain name for this network.

Lease Time :

The IP addresses given out by the DHCP server will only be valid for the duration specified by the lease time. Increasing the time ensure client operation without interruptions, but could introduce potential conflicts.

Lowering the lease time will avoid potential address conflicts, but might cause more interruptions to the client while it will acquire new IP addresses from the

DHCP server. Default is

86400

seconds

Click

Save

button to save your changes. Click

Reboot

button to activate your changes

Access Point Association

Configure Wireless General Setting

The administrator can change the data transmission, channel and output power settings for the system. Please click on

Wireless -> General Setup

and follow the below setting.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

Band Mode :

Select an appropriate wireless band; bands available are

801.11a

or

802.11a/n mixed mode

.

Tx Power :

You can adjust the output power of the system to get the appropriate coverage for your wireless network. Specify digit number between

1

to

100

(the unit is %) for your environment. If you are not sure of which setting to choose, then keep the default setting,

100

%.

When

Band Mode

select in

802.11a only mode

, the

HT(High Throughput) Physical

Mode and 11n Configuration

settings should be hidden immediately.

Operating Mode :

By default, it's Mixed Mode.

Mixed Mode :

In this mode packets are transmitted with a preamble

 compatible with the legacy 802.11a/g, the rest of the packet has a new format.

In this mode the receiver shall be able to decode both the Mixed Mode packets and legacy packets.

Green Field :

In this mode high throughput packets are transmitted without a legacy compatible part.

Channel Bandwidth :

The "

Auto

” MHz option is usually best. The other option is available for special circumstances.

Guard Interval :

Using “

Auto

” option can increase throughput. However, it can also increase error rate in some installations, due to increased sensitivity to radiofrequency reflections. Select the option that works best for your installation.

MCS :

This parameter represents transmission rate. By default (Auto) the fastest possible transmission rate will be selected. You have the option of selecting the speed if necessary. (Refer to

Appendix C. MCS Data Rate

)

MPDU Enable :

Check

Enable

button to activate this function, and

Disable

to deactivate.

A-MPDU

: A-MPDU (Aggregated Mac Protocol Data Unit) allows the transmissions of multiple Ethernet frames to a single location as burst of up to 64kbytes This is performed on the hardware itself. Select “Manual” to set “MPDU Density”

MPDU Density :

Minimum separation of MPDUs in an A-MPDU.

0 1 2 3 4 5 6 7

No Restriction ¼ µs ½ µs 1 µs 2 µs 4 µs 8 µs 16 µs

A-MSDU :

Aggregated Mac Service Data Unit, A-MSDU. Select

Enable

to allows aggregation for multiple MSDUs in one MPDU. Default is disabled.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes.

42

TRENDnet User’s Guide

Configure Wireless Advanced Setting

To achieve optimal wireless performance, it is necessary to tweak advance setting per requirements properly, not necessary higher the better or lower.

The administrator can change the RTS threshold and fragmentation threshold settings for the system. Please click on

Wireless -> Advanced Setup

and follow the below setting.

TEW-676APBO

Synchronization field.

The preamble is used to signal "here is a train of data coming" to the receiver. The short preamble provides 72-bit Synchronization field to improve WLAN transmission efficiency with less overhead.

Tx Burst :

By default, it’s “

Enable

”. To

Disable

is to deactivate Tx Burst.

With TX burst enabled, AP will send many packets in a burst, without collision detection and RTS/CTS for each packet. TX Burst have better throughput but cause interference with other APs in channel.

WMM :

By default, it's “

Disable

”.

Select Enable, the packets with QoS WMM will have higher priority.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes.

Site Survey

Use this tool to scan and locate WISP Access Points and select one to associate with.

Please click on

Wireless -> Site Survey

. Below depicts an example for site survey.

Fragment Threshold :

The Fragment Threshold is in the range of

256

~

2346

byte.

The default is

2346

byte.

Each Wi-Fi packet can be divided into smaller packets, marked with a sequential fragment number and re-assemble in the receiving ends. The purpose is to make a short frame, instead of long frame, transmitting by radio in a heavy noisy environment. Because of sending smaller frames, corruptions are much less likely to occur. The pros is obvious, the cons is the overhead for transmission. So, in a clean environment, higher fragment threshold can be an option to increase throughput.

Fragmentation will be triggered by setting the Fragment Threshold, usually in Bytelength. Only when the frame size is over the Threshold, fragmentation will take place automatically.

RTS Threshold :

RTS Threshold is in the range of

1~2347

byte. The default is

2347

byte.

The main purpose of enabling RTS by changing RTS threshold is to reduce possible collisions due to hidden wireless clients. RTS in AP will be enabled automatically if the packet size is larger than the Threshold value. By default, RTS is disabled in a normal environment supports non-jumbo frames.

Short Preamble :

By default, it’s “

Auto

”. To

Disable

is to use Long 128-bit Preamble

© Copyright 2012TRENDnet. All Rights Reserved.

ESSID : Available

Extend Service Set ID of surrounding Access Points.

MAC Address :

MAC addresses of surrounding Access Points.

Signal :

Received signal strength of all found Access Points.

Channel :

Channel numbers used by all found Access Points.

Security :

Security type by all found Access Points.

Band :

Wireless band used by all found Access Points.

Network Type :

Network type used by all found Access Points.

Select :

Click “

Select

” to configure settings and associate with chosen AP.

43

TRENDnet User’s Guide

Create Wireless Profile

The administrator can configure station profiles via this page.

Please click on

Wireless -> Wireless Profile

and follow the below setting.

TEW-676APBO

MAC Address :

The MAC address of the Wireless Station is displayed here.

Profile Name :

Set different profiles for quick connection uses.

ESSID :

Assign Service Set ID for the wireless system.

Security Type :

Select an appropriate security type for association, the Security

Type can be selected in “

NONE

”, “

OPEN

”, “

SHARED

”, “

WPA-PSK

”, or “

WPA2-PSK

” from drop-down list; the type needs to be the same as that associated access point.

OPEN / SHARED :

OPEN and SHARED require the user to set a WEP key to exchange data.

Key Index :

key index is used to designate the WEP key during data transmission. 4 different WEP keys can be entered at the same time, but only one is chosen.

WEP Key # :

Enter

HEX

or

ASCII

format WEP key value; the system supports up to 4 sets of WEP keys.

Key Length Hex ASCII

64-bit

128-bit

10 characters

26 characters

5 characters

13 characters

WPA-PSK (or WPA2-PSK) :

WPA (or WPA2) Algorithms, allows the system accessing the network by using the WPA-PSK protected access.

Cipher Suite :

Select the desired cipher suite from the drop-down list; the options are

AES

and

TKIP

Pre-shared Key :

Enter the information for pre-shared key; the key can be either entered as a 256-bit secret in

64 HEX

digits format, or

8 to 63 ASCII

characters.

© Copyright 2012TRENDnet. All Rights Reserved.

44

TRENDnet User’s Guide

Profile List :

The user can manage the created profiles for home, work or public areas. Below depict an example for Profile List

TEW-676APBO

Click ”

Edit

” an exist profile on the Profile List. The field of System Configuration and Security Policy will display profile's content. Edit profile's content and then click “

Save

” button to save the profile.

Click “

Delete

” to remove profile.

Click and Select a profile from list, then click the “

Connect

” button to connecting to the wireless network with the profile setting. After clicking

Connect

” button, the system should be jump to

Station Statistic Page

, you can verify connecting status on

Station Statistic Page

.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes

Access Control List

IP Filter Setup

Allows to create deny or allow rules to filter ingress or egress packets from specific source and/or to destination IP address on wired (LAN) or Wireless (WAN) ports. Filter rules could be used to filter unicast or multicast packets on different protocols as shown in the IP Filter Setup. Important to note that IP filter rules has precedence over Virtual server rules.

Please click on

Advance -> IP Filter Setup

and follow the below setting.

© Copyright 2012TRENDnet. All Rights Reserved.

Source Address/Mask :

Enter desired source IP address and netmask; i.e.

192.168.2.10/32.

Source Port :

Enter a port or a range of ports as

start:end

; i.e. port 20:80

Destination Address/Mask :

Enter desired destination IP address and netmask; i.e.

192.168.1.10/32

Destination Port :

Enter a port or a range of ports as

start:end

; i.e. port 20:80

In/Out :

Applies to Ingress or egress packets

Protocol :

Supports

TCP

,

UDP

or

ICMP

.

Listen :

Click

Yes

radial button to match TCP packets only with the SYN flag.

Active :

Deny

to drop and

Pass

to allow per filter rules

Interface :

The interface that a filter rule applies

Click “

Save

” button to add IP filter rule. Total of

20

rules maximum allowed in the IP

Filter List. All rules can be edited or removed from the List. Click

Reboot

button to activate your changes.

When you create rules in the IP Filter List, the prior rules maintain higher priority. To allow limited access from a subnet to a destination network manager needs to create allow rules first and followed by deny rules. So, if you just want one IP address to access

45

TRENDnet User’s Guide

the system via telnet from your subnet, not others, the Example 1 demonstrates it, not rules in the Example 2.

Example 1 :

Create a higher priority rule to allow IP address 192.168.2.2 Telnet access from LAN port first, and deny Telnet access from remaining IP addresses in the same subnet.

1

2

Source

Rule

IP/Mask Port

192.168.2.2/

32

192.168.2.0/

24

Destination

IP/Mask

192.168.2.254/

32

192.168.2.254/

32

Port

22

22

I/O

In

In

Protocol

TCP

TCP

L Act

n Pass

Side

n Deny LAN

Example 2 :

All Telnet access to the system from the IP addresses of subnet

192.168.2.x works with the rule 1 of Example 2. The rule 2 won’t make any difference.

LAN

Source Destination

Rule

IP/Mask Port IP/Mask Port

I/O Protocol L Action Side

192.168.2.254

/32

22 In TCP n Deny LAN

192.168.2.254

/32

22 In TCP n pass LAN

MAC Filter Setup

Allows to create MAC filter rules to allow or deny unicast or multicast packets from limited number of MAC addresses. Important to note that MAC filter rules have precedence over IP Filter rules.

Please click on

Advance -> MAC Filter Setup

and follow the below setting.

TEW-676APBO

MAC Filter Rule :

By default, it’s “

Disable

”. Options are

Disabled

,

Only Deny List

MAC

or

Only Allow List MAC

. Click

Save

button to save your change.

Two ways to set the MAC Filter List:

Only Allow List MAC

.

The wireless clients in the MAC Filter List will be

allowed

to access to Access Point;

All others will be denied.

Only Deny List MAC

.

The wireless clients in the MAC Filter List will be

denied

to access to Access Point;

All others will be allowed.

MAC Address :

Enter MAC address (e.g. aa:bb:cc:00:00:0a) and click “

Add

” button, then the MAC address should display in the MAC Filter List.

There are a maximum of

20

clients allowed in this MAC Filter List. The MAC addresses of the wireless clients can be added and removed to the list using the

Add

and

Delete

buttons

.

Click

Reboot

button to activate your changes

© Copyright 2012TRENDnet. All Rights Reserved.

46

TRENDnet User’s Guide

Parental Control Setup

Parental Control allows you to block or allow specific kinds of Internet usage and traffic, such as Internet access, designated services, and websites.

Main

WIFI WAN LAN

Please click on

Advance -> Parental Control

and follow the below setting.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

Rules :

control can be managed by a rule. Use the settings on this screen to establish an access policy.

Comment :

Enter a descriptive name for this rule for identifying purposes.

MAC Address :

Enter MAC address in valid MAC address

 format(xx:xx:xx:xx:xx:xx) and click “

Add

” button to add in the MAC group of each rule. Click “

Remove

” button can remove MAC address in the group of each rule. There are

10

MAC address maximum allowed in each rule.

Local / Destination IP :

Specify local(LAN)/ destination IP addresses range required for this rule. If you specify local IP addresses range from 192.168.1.1 to 192.168.2.254. The matches a range of local IP addresses include every single IP address from the first to the last, so the example above includes everything from 192.168.1.1 to 192.168.2.254.

Protocol :

Select

Any

or specify protocol(

TCP

,

UDP

,

ICMP

,

URL Blocking

and

47

TRENDnet User’s Guide

Application

) from drop-down list. When you select

ICMP

or

Layer 7

Application

, the Local(LAN)/ Destination Port cannot used.

If you want to block websites with specific URL address or using specific keywords, enter each URL or keyworks in the “

URL Blocking

” field and click

Add

” button to add in the URL Blocking list of each rule. Click “

Remove

” button can remove URL or keywords.

Local Port :

Specify local port(LAN port) range required for this rule

Destination Port :

Specify destination port range required for this rule

Active :

Check

Enable

button to activate this rule, and

Disable

to deactivate.

Click “

Add

” button to add control rule to List. There are

10

rules maximum allowed in this Control List. All rules can be removed or edited on the List. Click

Reboot

button to activate your changes.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

QoS Setup

Quality of Service (QoS) refers to both a network's ability to deliver data with minimum delay, and the networking methods used to control the use of bandwidth. Without QoS, all traffic data is equally likely to be dropped when the network is congested. This can cause a reduction in network performance and make the network inadequate for timecritical application such as video-on-demand.

A classifier groups traffic into data flows according to specific criteria such as the source address, destination address, source port number, destination port number or incoming port number. For example, you can configure a classifier to select traffic from the same protocol port (such as FTP) to form a flow.

Shaping

WAN

NAT

LAN

Download: 1024K

Upload: 256K

Download: 512K

Upload: 256K

Download: 2048K

Upload: 1024K

48

TRENDnet User’s Guide

Please click on

Advance -> QoS

and follow the below setting.

Rules :

Use the rules to define the classifiers. After you define the rules, you can specify action to act upon the traffic that matches the rules

Comment :

Enter a descriptive name for this rule for identifying purposes.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

MAC Address :

Enter MAC address in valid MAC address format(xx:xx:xx:xx:xx:xx) and click “

Add

” button to add in the MAC group of each rule. Click “

Remove

” button can remove MAC address in the group of each rule. There are

10

MAC address maximum allowed in each rule.

Local / Destination IP :

Specify local(LAN)/ destination IP addresses range required for this rule. If you specify local IP addresses range from 192.168.1.1 to 192.168.2.254. The matches a range of local IP addresses include every single IP address from the first to the last, so the example above includes everything from 192.168.1.1 to 192.168.2.254.

DSCP Class

: Differentiated services code point, DSCP. Select Any or specify classify traffic from drop-down list.

The Per-Hop Behavior (PHB) is indicated by encoding a 6-bit value—called the

Differentiated Services Code Point (DSCP)—into the 8-bit Differentiated

Services (DS) field of the IP packet header. Below depicts class for DSCP.

BE :

Default

PHB, which is typically best-effort traffic

EF :

Expedited Forwarding

PHB, dedicated to low-loss, low-latency traffic

AF :

Assured Forwarding

PHB, which gives assurance of delivery under conditions. The AF behavior group defines four separate AF classes.

Within each class, packets are given a drop precedence (high, medium or low). The combination of classes and drop precedence yields twelve separate DSCP encodings from

AF11

through

AF43

(see table)

DROP Precedence

Low Drop

Class 1

AF11

Class 2

AF21

Class 3

AF31

Class 4

AF41

Medium Drop

High Drop

AF12

AF13

AF22

AF23

AF32

AF33

AF42

AF43

Protocol :

Select

Any

or specify protocol(

TCP

,

UDP

,

ICMP

,

Application

) from

 drop-down list. When you select

ICMP

or

Layer 7 Application

, the Local/

Destination Port cannot used.

Local Port :

Specify local port(LAN port) range required for this rule

Destination Port :

Specify destination port range required for this rule

Action :

After configuring rule, a policy rule ensures that a traffic flow gets the requested treatment in the network.

Remark DSCP :

Specify a new DSCP class, if you want to replace or remark the

DSCP

49

TRENDnet User’s Guide

Bandwidth :

Click “

Enable

” to activate function, and click “

Disable

” to deactivate function

Upload / Download :

Specify the bandwidth in kilobit per second (Kbps). Enter a number between

8

to

8192

, default upload is

128

Kbps, download is

1024

Kbps.

Click “

Add

” button to add QoS rule to List. There are

10

rules maximum allowed in this

QoS List. All rules can be removed or edited on the List. Click

Reboot

button to activate your changes.

When you create rules on the QoS List, the previous rules have higher priority. . Below depict the examples for explaining priority of QoS setup.

Example 1 :

On this setting, the FTP has

1024

Kbps upload and

8196

Kbps download on

192.168.2.10

. The remaining IP address and other remaining

 protocol of IP address 192.168.2.10 only can use total bandwidth

512

Kbps bandwidth. Because rule 1's priority is higher than rule 2

Example 2 :

On this setting, the FTP has

512

Kbps upload and

512

Kbps download on

192.168.2.10

Because rule 1's priority is higher than rule 2

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

Resource Sharing

DMZ

DMZ is commonly work with the NAT functionality as an alternative of Virtual

Server(Port Forwarding

)

while wanting all ports of DMZ host visible to Internet users.

Virtual Server rules have precedence over the DMZ rule. In order to use a range of ports available to access to different internal hosts Virtual Server rules are needed.

Main

WIFI WAN LAN

Please click on

Advance -> DMZ

and follow the below setting.

DMZ

DMZ :

By default, it’s

Disable

”.

Check

Enable

radial button to enable DMZ.

IP Address :

Enter IP address of DMZ host and only one DMZ host is supported.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes.

50

TRENDnet User’s Guide

Virtual Server (Port Forwarding)

“Virtual Server” can also referred to as “Port Forward” as well and used interchangeably.

Resources in the network can be exposed to the Internet users in a controlled manner including on-line gaming, video conferencing or others via Virtual Server setup. Don’t repeat ports’ usage to avoid confusion.

Suppose you want to assign ports 21-25 to one FTP, Telnet and SMTP server (A in the example), and port 80 to another (B in the example). You assign the LAN IP addresses and the ISP assigns the WAN IP address. The NAT network appears as a single host on the Internet.

WIFI WAN

A

B

Main

LAN

Please click on

Advance -> Virtual Server

and follow the below setting.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

Virtual Server :

By Default, It’s “

Disable

.

Check

Enable

radial button to enable

Virtual Server.

Description :

Enter appropriate message for resource sharing via Virtual Server.

Private IP :

Enter corresponding IP address of internal resource to share.

Protocol Type :

Select appropriate sessions, TCP or UDP, from shared host via multiple private ports.

Private Port :

A port or a range of ports may be specified as

start:end

; i.e. port

20:80

Public Port :

A port or a range of ports may be specified as

start:end

; i.e. port 20:80

.

Click “

Add

” button to add Virtual Server rule to List. Total of maximum

20

rules are allowed in this List. All rules can be edited or removed from the List. Click

Reboot

button to activate your changes.

While creating multiple Virtual Server rules, the prior rules have higher priority. The

Virtual server rules have precedence over the DMZ one while both rules exist. Example 1 and 2 demonstrate proper usage of DMZ and Virtual Server rules.

Example 1 :

All connections should be redirected to

192.168.2.12

while DMZ is enabled. Since Virtual Server rules have precedence over the DMZ rule all connections to TCP port 22 will be directed to TCP port 22 of 192.168.2.10 and remaining connections to port TCP

20~80

will be redirected to port TCP

20~80

of

192.168.2.11

51

TRENDnet User’s Guide

DMZ Enabled : 192.168.2.12

Rule Protocol Private IP

1

2

TCP

TCP

192.168.2.10

192.168.2.11

Private Port

22

20:80

Public Port

22

20:80

Example 2 :

All connections should be redirected to

192.168.2.12

while DMZ is enabled. Since Virtual Server rules have precedence over the DMZ rule all other connections to TCP port

20~80

will be redirected to port

20~80

of

192.168.2.11

.

The rule 2 won’t take effect.

DMZ Enabled : 192.168.2.12

Rule Protocol Private IP

1

2

TCP

TCP

192.168.2.11

192.168.2.10

Private Port

20:80

22

Public Port

20:80

22

TEW-676APBO

© Copyright 2012TRENDnet. All Rights Reserved.

52

TRENDnet User’s Guide

System Status

This section breaks down into subsections of

System Overview

,

Station Statistics

,

Extra

Information

and

Event Log

.

Overview

Detailed information on

System

,

WAN Information

,

LAN Information

and

DHCP Server

Status

can be reviewed via this page.

System :

Display the information of the system.

TEW-676APBO

WAN Information :

Display the information of the WAN interface.

System Name :

The name of the system.

Operating Mode :

The mode currently in service.

Location :

The reminding note on the geographical location of the system.

Description :

The reminding note of the system.

Firmware Version :

The current firmware version installed.

Firmware Date :

The build time of the firmware installed.

Device Time :

The current time of the system.

System Up Time :

The time period that system has been in service since last reboot.

© Copyright 2012TRENDnet. All Rights Reserved.

The WAN port specified

Dynamic IP

, the Release and Renew button will be showup, click

Release

button to release IP address of WAN port,

Renew

button to renew

IP address through DHCP server.

The WAN port specified

PPPoE

or

PPTP

, and the

Connect

and

DisConnect

button will be show up. Click “

Connect

” button to assigned IP address from PPPoE or PPTP server, “

DisConnect

” button to release IP address of WAN port.

Mode :

Supports Static, Dynamic, PPPoE and PPTP modes.

Reconnect Mode :

The current reconnect mode of the PPPoE or PPTP.

MAC Address :

The MAC address of the WAN port.

IP Address :

The IP address of the WAN port.

IP Netmask :

The IP netmask of the WAN port.

IP Gateway :

The gateway IP address of the WAN port.

Primary DNS :

The primary DNS server in service.

Secondary DNS :

The secondary DNS server in service.

Receive bytes :

The total received packets in bytes on the WAN port.

Receive packets :

The total received packets of the WAN port.

Transmit bytes :

The total transmitted packets in bytes of the WAN port.

Transmit packets :

The total transmitted packets of the WAN port.

53

TRENDnet User’s Guide

LAN Information :

Display total received and transmitted statistics on the LAN interface.

TEW-676APBO

IP Address :

IP addresses to LAN devices by DHCP server.

MAC Address :

MAC addresses of LAN devices.

Expired In :

Shows how long the leased IP address will expire.

Station Statistics

Link information, Transmit and Receive Statistics for the connection with AP, Below depicts an example for Station Statistics.

MAC Address :

The MAC address of the LAN port.

IP Address :

The IP address of the LAN port.

IP Netmask :

The IP netmask of the LAN port.

Receive bytes :

The total received packets in bytes on the LAN port.

Receive packets :

The total received packets of the LAN port.

Transmit bytes :

The total transmitted packets in bytes of the LAN port.

Transmit packets :

The total transmitted packets of the LAN port.

DHCP Server Status :

Users could retrieve DHCP server and DHCP clients’ IP/MAC address via this field.

© Copyright 2012TRENDnet. All Rights Reserved.

54

TRENDnet User’s Guide

Link Status :

Status :

Shows the current link status. It should be “

Connected

” or

Disconnected

”.

ESSID :

Shows the current SSID, which must be the same on the wireless client and AP in order for communication to be established.

BSSID :

Shows the associated BSSID, which can be used to identify the wireless

 access point.

Extra Info :

Shows the current link status of extra information. It should be

Link is Up

” or “

Link is Down

”,

Channel :

Shows current channel and central channel, its corresponding frequency.

Link Speed(Mbps) :

The data transfer speed adopted by this network.

(measured in Mbits per second)

Link Quality :

Shows the link quality of the system with an access point.

Signal Strength ANT0/ANT1 :

Shows the wireless signal strength of the connection between system and an access point.

HT Status :

Channel BandWidth :

Shows the current channel bandwidth used for

 communication. It should be “

20

” or “

40

Guard Interval :

Shows the current GI used for communication. It should be

short

” or “

long

”.

MCS :

Shows the current GI used for communication. It should be between

0

to

15

or

32

.

Transmit Statistics

Frames Transmitted Successfully:

The number of successfully transmitted

 frames.

Frames Transmitted Successfully Without Retry:

The number of successfully transmitted frames without any retry.

Frames Transmitted Successfully After Retry(s):

The number of successfully

 transmitted frames with one or more retries.

Frames Fail To Receive ACK After All Retries:

The number of unsuccessfully transmitted frame with many retries.

RTS Frames Successfully Receive CTS:

The number of successful received CTS

(Clear To Send) response after this TEW-676APBO sends out the RTS (Request

To Send) message.

RTS Frames Fail To Receive CTS:

The number of unsuccessful received CTS

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

 response after this TEW-676APBO sends out the RTS message.

Receive Statistics

Frames Received Successfully:

The number of successful received frames.

Frames Received With CRC Error:

The number of received frames with CRC

(Cyclical Redundancy Checking) error.

Frames Dropped Due To Out-of-Resource:

The number of dropped frames.

Duplicate Frames Received:

The number of duplicate frames.

Extra Info

Users could pull out information such as Route table, ARP table, MAC table, Bridge table or STP available in the drop-down list from system. The “Refresh” button is used to retrieve latest table information.

55

TRENDnet User’s Guide

Netstat Information :

Select “

NetStatus Information

” on the drop-down list, the connection track list should

NetStatus will show all connection track on the system, the information include

Protocol

,

Live Time

,

Status

,

Source/Destination IP address

and

Port

.

Route table information :

Select “

Route table information

” on the drop-down list to display route table.

TEW-676APBO could be used as a L2 or L3 device. It doesn’t support dynamic routing protocols such as RIP or OSPF. Static routes to specific hosts, networks or default gateway are set up automatically according to the IP configuration of system's interfaces. When used as a L2 device, it could switch packets and, as L3 device, it’s capable of being a gateway to route packets inward and outward.

TEW-676APBO

but also remember non-local MAC addresses learned from wired or wireless interfaces.

Ageing timers will be reset when existing MAC addresses in table are learned again or added when new MAC addresses are seen from wired or wireless interfaces as well. When time runs out for a particular entry, it will be pruned from the table. In that situation, switching packet to that particular MAC address will be discontinued.

Bridge STP Information :

Select “

Bridge STP Information

” on the drop-down list to display a list of bridge STP information.

ARP table Information :

Select “

ARP Table Information

” on the drop-down list to display ARP table.

ARP associates each IP address to a unique hardware address (MAC) of a device. It is important to have a unique IP address as final destination to switch packets to.

Bridge table information :

Select “

Bridge Table information

” on the drop-down list to display bridge table.

Bridge table will show Bridge ID and STP's Status on the each Ethernet bridge and its attached interfaces, the Bridge Port should be attached to some interfaces.

Bridge MAC information :

Select “

Bridge MACs Information

” on the drop-down list to display MAC table.

This table displays local MAC addresses associated with wired or wireless interfaces,

© Copyright 2012TRENDnet. All Rights Reserved.

56

TRENDnet User’s Guide

QoS Plot

The QoS Plot show graphs which continuously represents the current data traffic on each QoS rule. The chart scale and throughput dimension (bps, Kbps, Mbps) changes dynamically according to the mean throughput value. The statistics is updated automatically every

5

seconds. The throughput statistics of QoS can be updated manually using the

Refresh

button.

Event Log

The Event log displays system events when system is up and running. Also, it becomes very useful as a troubleshooting tool when issues are experienced in system.

TEW-676APBO

Time :

The date and time when the event occurred.

Facility :

It helps users to identify source of events such “System” or “User”

Severity :

Severity level that a specific event is associated such as “info”, “error”,

“warning”, etc.

Message :

Description of the event.

Click

Refresh

button to renew the log, or click

Clear

button to clear all the record.

© Copyright 2012TRENDnet. All Rights Reserved.

57

TRENDnet User’s Guide

CPE + AP Mode Configuration

When CPE+AP mode is chosen, the system can be configured as a Customer Premises

Equipment(CPE). This section provides detailed explanation for users to configure in the

CPE+AP mode with help of illustrations. In the CPE+AP mode, functions listed in the table below are also available from the Web-based GUI interface.

OPTION System Wireless Advance

Operating Mode General Setup DMZ

Utilities

Profiles

Settings

Status

System

Overview

Functions

WAN

LAN

DDNS

Advanced

Setup

Repeater AP

Setup

Wireless

Profile

IP Filter

MAC Filter

Virtual Server

Firmware

Upgrade

Network

Utility

Reboot

Station

Statistics

Extra Info

QoS Plot

Management

Time Server

UPNP

SNMP

Site Survey Parental Control

QoS

CPE+AP Mode Functions

Event Log

TEW-676APBO

External Network Connection

Network Requirement

It can be used as an Outdoor Customer Premises Equipment (CPE) to receive and repeat wireless signal over last mile application, helping WISPs deliver wireless broadband

Internet service to residents and business customers. In the CPE+AP mode, TEW-

676APBO is a gateway enabled with NAT and DHCP Server functions. The wired and wireless clients connected to TEW-676APBO are in

different

subnet from those connected to Main Base Station, and, in CPE+AP mode, it

accepts

wireless connections from wireless client devices.

SSID: Repeater_Main_AP

Main

CPE+AP mode network configuration

© Copyright 2012TRENDnet. All Rights Reserved.

58

TRENDnet User’s Guide

Configure WAN Setup

There are three connection types for the WAN port :

Static IP

,

Dynamic IP

,

PPPoE

and

PPTP

,

Please click on

System -> WAN

and follow the below setting.

TEW-676APBO

release IP address and click

Renew

button to renew IP address again.

Hostname :

The Hostname of the WAN port

Mode :

By default, it’s “

Static IP

”. Check “Static IP”, “Dynamic IP”, “PPPoE” or

“PPTP”to set up system WAN IP.

Static IP :

Users can manually setup the WAN IP address with a static IP

 provided by WISP.

IP Address :

The IP address of the WAN port; default IP address is

192.168.1.254

IP Netmask :

The Subnet mask of the WAN port; default Netmask is

255.255.255.0

IP Gateway :

The default gateway of the WAN port; default Gateway is

192.168.1.1

Dynamic IP :

Please consult with WISP for correct wireless settings to associate with WISP AP before a dynamic IP, along with related IP settings including DNS can be available from DHCP server. If IP Address is not assigned, please double check with your wireless settings and ensure successful association. Also, you may go to “

WAN Information

” in the Overview page to click

Release

button to

© Copyright 2012TRENDnet. All Rights Reserved.

PPPoE :

To create wireless PPPoE WAN connection to a PPPoE server in network.

User Name :

Enter User Name for PPPoE connection

Password :

Enter Password for PPPoE connection

Reconnect Mode :

Always on

– A connection to Internet is always maintained.

On Demand

– A connection to Internet is made as needed.

Manual

– Click the “

Connect

” button on “

WAN Information

” in the

Overview page to connect to the Internet.

Idle Time :

Time to last before disconnecting PPPoE session when it is idle. Enter preferred Idle Time in minutes. Default is “

0

”, indicates disabled. When Idle time is disabled, the “

Reconnect Mode

” will turn out

Always on

MTU :

By default, it’s

1492

bytes. MTU stands for Maximum Transmission

Unit. Consult with WISP for a correct MTU setting.

PPTP :

The Point-to-Point Tunneling Protocol (PPTP) mode enables the implementation of secure multi-protocol Virtual Private Networks (VPNs) through public networks.

59

TRENDnet User’s Guide

TEW-676APBO

Secondary :

The IP address of the secondary DNS server.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes

Configure DDNS Setup

Dynamic DNS allows you to map domain name to dynamic IP address.

Please click on

System -> DDNS Setup

and follow the below setting.

IP Address :

The IP address of the WAN port

IP Netmask :

The Subnet mask of the WAN port

PPTP Server IP Address :

The IP address of the PPTP server

User Name :

Enter User Name for PPTP connection

Password :

Enter Password for PPTP connection

Reconnect Mode :

Always on

– A connection to Internet is always maintained.

On Demand

– A connection to Internet is made as needed.

Manual

– Click the “

Connect

” button on “

WAN Information

” in the

Overview page to connect to the Internet.

Idle Time :

Time to last before disconnecting PPPoE session when it is idle. Enter preferred Idle Time in minutes. Default is “

0

”, indicates disabled. When Idle time is disabled, the “

Reconnect Mode

” will turn out

Always on

MTU :

By default, it’s

1460

bytes. MTU stands for Maximum Transmission

Unit. Consult with WISP for a correct MTU setting.

MPPE Encryption :

Microsoft Point-to-Point Encryption (MPPE) encrypts data in Point-to-Point Protocol(PPP)-based dial-up connections or Pointto-Point Tunneling Protocol (PPTP) virtual private network (VPN) connections.

128

-

bit

key (strong) and

40

-

bit

key (standard) MPPE encryption schemes are supported. MPPE provides data security for the

PPTP connection that is between the VPN client and the VPN server.

DNS :

Check “No Default DNS Server” or “Specify DNS Server IP” radial button as desired to set up system DNS.

Primary :

The IP address of the primary DNS server.

© Copyright 2012TRENDnet. All Rights Reserved.

Enabled:

By default, it’s “

Disable

.

The mapping domain name won’t change when dynamic IP changes. The beauty of it is no need to remember the dynamic WAP IP while accessing to it.

Service Provider:

Select the preferred Service Provider from the drop-down list including

dyndns

,

dhs

,

ods

and

tzo

Hostname:

Host Name that you register to Dynamic-DNS service and export.

User Name & Password:

User Name and Password are used to login DDNS service.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes

60

TRENDnet User’s Guide

Configure LAN Setup

Here are the instructions for how to setup the local IP Address and Netmask.

Please click on

System -> LAN

and follow the below setting.

TEW-676APBO

LAN IP :

The administrator can manually setup the LAN IP address.

IP Address :

The IP address of the LAN port; default IP address is

192.168.2.254

IP Netmask :

The Subnet mask of the LAN port; default Netmask is

255.255.255.0

DHCP Setup :

Devices connected to the system can obtain an IP address automatically when this service is enabled.

© Copyright 2012TRENDnet. All Rights Reserved.

DHCP :

Check

Enable

button to activate this function or

Disable

to deactivate this service.

Start IP / End IP:

Specify the range of IP addresses to be used by the DHCP server when assigning IP address to clients. The default range IP address is

192.168.2.10 to 192.168.2.70, the netmask is 255.255.255.0

DNS1 IP :

Enter IP address of the first DNS server; this field is required.

DNS2 IP :

Enter IP address of the second DNS server; this is optional.

WINS IP :

Enter IP address of the Windows Internet Name Service (WINS) server; this is optional.

Domain :

Enter the domain name for this network.

Lease Time :

The IP addresses given out by the DHCP server will only be valid for the duration specified by the lease time. Increasing the time ensure client operation without interruptions, but could introduce potential conflicts.

Lowering the lease time will avoid potential address conflicts, but might cause more interruptions to the client while it will acquire new IP addresses from the

DHCP server. Default is

86400

seconds

Click

Save

button to save your changes. Click

Reboot

button to activate your changes

61

TRENDnet User’s Guide

Access Point Association

Configure Wireless General Setting

The administrator can change the data transmission, channel and output power settings for the system. Please click on

Wireless -> General Setup

and follow the below setting.

Band Mode :

Select an appropriate wireless band; bands available are

801.11a

or

802.11a/n mixed

mode.

Transmit Rate Control :

Select the desired rate from the drop-down list; the options are auto or ranging from

6

to

54

Mbps for

802.11a

Tx Power :

You can adjust the output power of the system to get the appropriate coverage for your wireless network. Specify digit number between

1

to

100

(the unit is %) for your environment. If you are not sure of which setting to choose, then keep the default setting,

100

%.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

When

Band Mode

select in

802.11a only mode

, the

HT(High Throughput) Physical

Mode and 11n Configuration

settings should be hidden immediately.

Operating Mode :

By default, it's Mixed Mode.

Mixed Mode :

In this mode packets are transmitted with a preamble

 compatible with the legacy 802.11a/g, the rest of the packet has a new format.

In this mode the receiver shall be able to decode both the Mixed Mode packets and legacy packets.

Green Field :

In this mode high throughput packets are transmitted without a

 legacy compatible part.

Channel Bandwidth :

The "

Auto

” MHz option is usually best. The other option is available for special circumstances.

Guard Interval :

Using “

Auto

” option can increase throughput. However, it can also increase error rate in some installations, due to increased sensitivity to radiofrequency reflections. Select the option that works best for your installation.

MCS :

This parameter represents transmission rate. By default (Auto) the fastest possible transmission rate will be selected. You have the option of selecting the speed if necessary. (Refer to

Appendix C. MCS Data Rate

)

MPDU Enable :

Check

Enable

button to activate this function, and

Disable

to deactivate.

A-MPDU

: A-MPDU (Aggregated Mac Protocol Data Unit) allows the transmissions of multiple Ethernet frames to a single location as burst of up to 64kbytes This is performed on the hardware itself. Select “Manual” to set “MPDU Density”

MPDU Density :

Minimum separation of MPDUs in an A-MPDU.

0 1 2 3 4 5 6 7

No Restriction ¼ µs ½ µs 1 µs 2 µs 4 µs 8 µs 16 µs

A-MSDU :

Aggregated Mac Service Data Unit, A-MSDU. Select

Enable

to allows aggregation for multiple MSDUs in one MPDU. Default is disabled.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes.

62

TRENDnet User’s Guide

Wireless Advanced Setup

To achieve optimal wireless performance, it is necessary to tweak advance setting per requirements properly, not necessary higher the better or lower.

The administrator can change the RTS threshold and fragmentation threshold settings for the system. Please click on

Wireless -> Advanced Setup

and follow the below setting.

Short Slot :

By default, it’s “

Enable

” for educing the slot time from the standard

20

microseconds

to the

9

microsecond

short slot time

Slot time is the amount of time a device waits after a collision before retransmitting a packet. Reducing the slot time decreases the overall back-off, which increases throughput. Back-off, which is a multiple of the slot time, is the random length of time a station waits before sending a packet on the LAN. For a sender and receiver own right of the channel the shorter slot time help manage shorter wait time to retransmit from collision because of hidden wireless clients or other causes. When collision sources can be removed sooner and other senders attempting to send are listening the channel(CSMA/CA) the owner of the channel should continue ownership and finish their transmission and release the channel. Then, following ownership of the channel will be sooner for the new pair due to shorter slot time.

However, when long duration of existing collision sources and shorter slot time exist the owners might experience subsequent collisions. When adjustment to longer slot time can’t improve performance then RTS/CTS could supplement and help improve performance.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

Extra Slot Time :

Slot time is in the range of

1~255

and set in unit of

microsecond

.

The default value is

9

microsecond.

ACK Timeout :

ACK timeout is in the range of

1~255

and set in unit of

microsecond

.

The default value is

32

microsecond.

All data transmission in 802.11b/g request an “Acknowledgement” (ACK) send by receiving radio. The transmitter will resend the original packet if correspondent ACK failed to arrive within specific time interval, also refer to as “ACK Timeout”.

ACK Timeout is adjustable due to the fact that distance between two radio links may vary in different deployment. ACK Timeout makes significant influence in performance of long distance radio link. If ACK Timeout is set too short, transmitter will start to “Resend” packet before ACK is received, and throughputs become low due to excessively high re-transmission.

ACK Timeout is best determined by distance between the radios, data rate of average environment. The Timeout value is calculated based on round-trip time of packet with a little tolerance, So, if experiencing re-transmissions or poor performance the ACK Timeout could be made longer to accommodate.

Beacon Interval :

Beacon Interval is in the range of

20

~

1024

and set in unit of

millisecond

. The default value is

100

msec.

Access Point (AP) in IEEE 802.11 will send out a special approximated 50-byte frame, called “Beacon”. Beacon is broadcast to all the stations, provides the basic information of AP such as SSID, channel, encryption keys, signal strength, time stamp, support data rate.

All the radio stations received beacon recognizes the existence of such AP, and may proceed next actions if the information from AP matches the requirement. Beacon is sent on a periodic basis, the time interval can be adjusted.

By increasing the beacon interval, you can reduce the number of beacons and associated overhead, but that will likely delay the association and roaming process because stations scanning for available access points may miss the beacons. You can decrease the beacon interval, which increases the rate of beacons. This will make the association and roaming process very responsive; however, the network will incur additional overhead and throughput will go down.

DTIM Interval :

The DTIM interval is in the range of

1

~

255

. The default is

1

.

DTIM is defined as

Delivery Traffic Indication Message

. It is used to notify the wireless stations, which support power saving mode, when to wake up to receive multicast frame. DTIM is necessary and critical in wireless environment as a mechanism to fulfill power-saving synchronization.

63

TRENDnet User’s Guide

A DTIM interval is a count of the number of beacon frames that must occur before the access point sends the buffered multicast frames. For instance, if DTIM Interval is set to 3, then the Wi-Fi clients will expect to receive a multicast frame after receiving three Beacon frame. The higher DTIM interval will help power saving and possibly decrease wireless throughput in multicast applications.

Fragment Threshold :

The Fragment Threshold is in the range of

256

~

2346

byte.

The default is

2346

byte.

Each Wi-Fi packet can be divided into smaller packets, marked with a sequential fragment number and re-assemble in the receiving ends. The purpose is to make a short frame, instead of long frame, transmitting by radio in a heavy noisy environment. Because of sending smaller frames, corruptions are much less likely to occur. The pros is obvious, the cons is the overhead for transmission. So, in a clean environment, higher fragment threshold can be an option to increase throughput.

Fragmentation will be triggered by setting the Fragment Threshold, usually in Bytelength. Only when the frame size is over the Threshold, fragmentation will take place automatically.

RTS Threshold :

TRTS Threshold is in the range of

1~2347

byte. The default is

2347

byte.

The main purpose of enabling RTS by changing RTS threshold is to reduce possible

Queue

Data

Transmitted

Clients to AP

Priority Description

AC_BK Background. Low

High throughput. Bulk data that requires maximum throughput and is not time-sensitive is sent to this queue (FTP data, for example).

AC_BE

AC_VI

Best Effort

Video

Medium

High

Medium throughput and delay. Most traditional

IP data is sent to this queue

Minimum delay. Time-sensitive video data is automatically sent to this queue

AC_VO Voice High

Time-sensitive data like VoIP and streaming media are automatically sent to this queue collisions due to hidden wireless clients. RTS in AP will be enabled automatically if the packet size is larger than the Threshold value. By default, RTS is disabled in a normal environment supports non-jumbo frames.

Short Preamble :

By default, it’s “

Enable

”. To

Disable

is to use Long 128-bit

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

Preamble Synchronization field.

The preamble is used to signal "here is a train of data coming" to the receiver. The short preamble provides 72-bit Synchronization field to improve WLAN transmission efficiency with less overhead.

Tx Burst :

By default, it’s “

Enable

”. To

Disable

is to deactivate Tx Burst.

With TX burst enabled, AP will send many packets in a burst, without collision detection and RTS/CTS for each packet. TX Burst have better throughput but cause interference with other APs in channel.

Pkt_Aggregate :

By default, it's “

Enable

Increase efficiency by aggregating multiple packets of application data into a single transmission frame. In this way, 802.11n networks can send multiple data packets with the fixed overhead cost of just a single frame.

WMM :

By default, it's “

Disable

”. To

Enable

is to use WMM and the WMM parameters should appears.

WMM Parameters of Access Point :

This affects traffic flowing from the access point to the client station

Configuring QoS options consists of setting parameters on existing queues for different types of wireless traffic. You can configure different minimum and maximum wait times for the transmission of packets in each queue based on

64

TRENDnet User’s Guide

the requirements of the media being sent. Queues automatically provide minimum transmission delay for Voice, Video, multimedia, and mission critical applications, and rely on best-effort parameters for traditional IP data.

As an Example, time-sensitive Voice & Video, and multimedia are given effectively higher priority for transmission (lower wait times for channel access), while other applications and traditional IP data which are less timesensitive but often more data-intensive are expected to tolerate longer wait times.

Aifsn

: The Arbitration Inter-Frame Spacing Number specifies a wait time

(in milliseconds) for data frames

CWmin

: Minimum Contention Window. This parameter is input to the algorithm that determines the initial random backoff wait time

("window") for retry of a transmission. The value specified here in the

Minimum Contention Window is the upper limit (in milliseconds) of a range from which the initial random backoff wait time is determined.

CWmax

: Maximum Contention Window. The value specified here in the

Maximum Contention Window is the upper limit (in milliseconds) for the doubling of the random backoff value. This doubling continues until either the data frame is sent or the Maximum Contention Window size is reached. Once the Maximum Contention Window size is reached, retries will continue until a maximum number of retries allowed is reached. Valid values for the "cwmax" are 1, 3, 7, 15, 31, 63, 127, 255, 511, or 1024. The value for "cwmax" must be higher than the value for "cwmin".

Txop

: Transmission Opportunity is an interval of time when a WME AP has the right to initiate transmissions onto the wireless medium (WM).

This value specifies (in milliseconds) the Transmission Opportunity (TXOP) for AP; that is, the interval of time when the WMM AP has the right to initiate transmissions on the wireless network.

ACM :

Admission Control Mandatory, ACM only takes effect on AC_VI and

AC_VO. When you do not click Checkbox, it means that the ACM is controlled by the connecting AP. If you click Checkbox, it means that the

Client is in charge.

AckPolicy :

Acknowledgment Policy, WMM defines two ACK policies:

Normal ACK

and

No ACK

. Click “

Checkbox

” indicates “

No ACK

When the no acknowledgment (No ACK) policy is used, the recipient does not acknowledge received packets during wireless packet exchange. This policy is suitable in the environment where communication quality is fine and interference is weak. While the No ACK policy helps improve

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

 transmission efficiency, it can cause increased packet loss when communication quality deteriorates. This is because when this policy is used, a sender does not retransmit packets that have not been received by the recipient.

When the Normal ACK policy is used, the recipient acknowledges each received unicast packet.

WMM Parameters of Station :

This affects traffic flowing from the client station to the access point.

Aifsn

: The Arbitration Inter-Frame Spacing Number specifies a wait time

(in milliseconds) for data frames

CWmin

: Minimum Contention Window. This parameter is input to the algorithm that determines the initial random backoff wait time

("window") for retry of a transmission. The value specified here in the

Minimum Contention Window is the upper limit (in milliseconds) of a range from which the initial random backoff wait time is determined.

CWmax

: Maximum Contention Window. The value specified here in the

Maximum Contention Window is the upper limit (in milliseconds) for the doubling of the random backoff value. This doubling continues until either the data frame is sent or the Maximum Contention Window size is reached. Once the Maximum Contention Window size is reached, retries will continue until a maximum number of retries allowed is reached. Valid values for the "cwmax" are 1, 3, 7, 15, 31, 63, 127, 255, 511, or 1024. The value for "cwmax" must be higher than the value for "cwmin".

Txop

: Transmission Opportunity is an interval of time when a WME AP

 has the right to initiate transmissions onto the wireless medium (WM).

This value specifies (in milliseconds) the Transmission Opportunity (Txop) for AP; that is, the interval of time when the WMM AP has the right to initiate transmissions on the wireless network.

ACM :

Admission Control Mandatory, ACM only takes effect on AC_VI and

AC_VO. When you do not click Checkbox, it means that the ACM is controlled by the connecting AP. If you click Checkbox, it means that the

Client is in charge.

Change these settings as described here and click

Save

button to save your changes.

Click

Reboot

button to activate your changes. The items in this page are for AP's RF

65

TRENDnet User’s Guide

advanced settings and will be applied to

Repeater AP

.

Site Survey

Use this tool to scan and locate WISP Access Points and select one to associate with.

Please click on

Wireless -> Site Survey

. Below depicts an example for site survey.

TEW-676APBO

ESSID : Available

Extend Service Set ID of surrounding Access Points.

MAC Address :

MAC addresses of surrounding Access Points.

Signal :

Received signal strength of all found Access Points.

Channel :

Channel numbers used by all found Access Points.

Security :

Security type by all found Access Points.

Band :

Wireless band used by all found Access Points.

Network Type :

Network type used by all found Access Points.

Select :

Click “

Select

” to configure settings and associate with chosen AP.

Create Wireless Profile

The administrator can configure station profiles via this page.

Please click on

Wireless -> Wireless Profile

and follow the below setting.

MAC Address :

The MAC address of the Wireless Station is displayed here.

Profile Name :

Set different profiles for quick connection uses.

ESSID :

Assign Service Set ID for the wireless system.

Lock to AP MAC :

This allows the station to always maintain connection to a particular AP with a specific MAC address. This is useful as sometimes there can be few identically named SSID's (AP's) with different MAC addresses. With AP lock on, the station will lock to MAC address and not roam between several Access Points with the same ESSID.

Channel/Frequency :

Select the desired channel range.

Security Type :

Select the desired security type from the drop-down list; the options are “

NONE

” “

OPEN

”, “

SHARED

”, “

WPA-PSK

” and “

WPA2-PSK

”.

OPEN / SHARED :

OPEN and SHARED require the user to set a WEP key to exchange data.

© Copyright 2012TRENDnet. All Rights Reserved.

66

TRENDnet User’s Guide

TEW-676APBO

64-bit

Key Length

128-bit

10 characters

26 characters

Hex

5 characters

ASCII

13 characters

Key Index :

key index is used to designate the WEP key during data transmission. 4 different WEP keys can be entered at the same time, but only one is chosen.

WEP Key # :

Enter

HEX

or

ASCII

format WEP key value; the system supports up to 4 sets of WEP keys.

WPA-PSK (or WPA2-PSK) :

WPA (or WPA2) Algorithms, allows the system accessing the network by using the WPA-PSK protected access.

Cipher Suite :

Select the desired cipher suite from the drop-down list; the options are

AES

and

TKIP

Pre-shared Key :

Enter the information for pre-shared key; the key can be either entered as a 256-bit secret in

64 HEX

digits format, or

8 to 63 ASCII

characters.

Profile List :

The user can manage the created profiles for home, work or public areas. Below depict an example for Profile List

Click “”

Edit

” an exist profile on the Profile List. The field of System

Configuration and Security Policy will display profile's content. Edit profile's content and then click “

Save

” button to save the profile.

Click “

Delete

” to remove profile.

Click and Select a profile from list, then click the “

Connect

” button to connecting to the wireless network with the profile setting. After clicking

Connect

” button, the system should be jump to

Remote AP Page

, you can verify connecting status on

Remote AP Page

.

Change these settings as described here and click

Save

button to save your changes.

Click

Reboot

button to activate your changes

© Copyright 2012TRENDnet. All Rights Reserved.

67

TRENDnet User’s Guide

Wireless LAN Network Creation

The network manager can configure related wireless settings,

Repeater AP Setup,

Security Settings,

and

MAC Filter Settings

.

Repeater AP Setup

Administrators can configure ESSID, SSID broadcasting, Maximum number of client associations, security type settings and MAC Filter settings.

TEW-676APBO

archived and setting of AP's clients could make to associate to it.

Maximum Clients :

The default value is

32

. You can enter the number of wireless clients that can associate to a particular SSID. When the number of client is set to 5, only 5 clients at most are allowed to connect to this Repeater AP.

Security Type :

Select the desired security type from the drop-down list; the options are

Disable

,

WEP

,

WPA-PSK

,

WPA2-PSK

,

WPA-Enterprise

,

WPA2-Enterprise

and

WEP 802.1X

.

Disable :

Data are unencrypted during transmission when this option is selected.

WEP :

Wired Equivalent Privacy(WEP) is a data encryption mechanism based on a 64-bit or 128-bit shared key.

Key Length

64-bit

128-bit

Hex

10 characters

26 characters

ASCII

5 characters

13 characters

Enable Repeater AP :

By default, it’s “

En

able

” for repeater AP. Select “

Enable

” to activate Repeater AP or click “

Disable

” to deactivate this function

ESSID :

Extended Service Set ID, When clients are browsing for available wireless networks, this is the SSID that will appear in the list. ESSID will determine the service type available to AP's clients associated with the specified AP.

Client Isolation :

By default, it’s “

Disable

.

Select “

Enable”

, all clients will be isolated from each other, which means they can’t reach each other.

Hidden SSID :

By default, it’s “

Disable

.

Enable this option to stop the SSID broadcast in your network. When disabled, people could easily obtain the SSID information with the site survey software and get access to the network if security is not turned on. When enabled, network security is enhanced. It’s suggested to enable it after AP security settings are

© Copyright 2012TRENDnet. All Rights Reserved.

Authentication Method :

Enable the desire option among

OPEN

,

SHARED

or

WEPAUTO

.

Key Index :

key index is used to designate the WEP key during data transmission. 4 different WEP keys can be entered at the same time, but only one is chosen.

WEP Key # :

Enter

HEX

or

ASCII

format WEP key value; the system supports up to 4 sets of WEP keys.

68

TRENDnet User’s Guide

WPA-PSK (or WPA2-PSK) :

WPA (or WPA2) Algorithms, allows the system accessing the network by using the WPA-PSK protected access.

Cipher Suite :

By default, it is

AES

. Select either AES or TKIP cipher suites

Pre-shared Key :

Enter the pre-shared key; the format shall go with the selected key type.

Group Key Update Period :

By default, it is

3600

seconds. This time interval for rekeying GTK, broadcast/multicast encryption keys, in seconds. Entering the time-length is required.

WPA-Enterprise (or WPA2-Enterprise):

The RADIUS authentication and encryption will be both enabled if this is selected.

TEW-676APBO

• interval for rekeying GTK, broadcast/multicast encryption keys, in seconds. Entering the time-length is required.

PMK Cache Period :

By default, it's 10 minutes. Set

WPA2

PMKID cache timeout period, after time out, the cached key will be deleted.

Pre-Authentication :

By default, it's “Disable”. To Enable is use to speed up roaming before pre-authenticating IEEE 802.1X/EAP part of the full RSN authentication and key handshake before actually associating with a new AP.

Radius Server Settings :

IP Address :

Enter the IP address of the Authentication RADIUS server.

Port :

By default, it’s

1812

.

The port number used to communicate with RADIUS server.

Shared secret :

A secret key used between system and RADIUS server. Supports

8

to

64

characters.

Session Timeout :

The Session timeout is in the range of

0

~

60

seconds

. The default is

0

to disable re-authenticate service.

Amount of time before a client will be required to re-authenticate.

WEP 802.1X :

When WEP 802.1x Authentication is enabled, please refer to the following Dynamic WEP and RADIUS settings to complete configuration.

WPA General Settings :

Cipher Suite :

By default, it is AES. Select either AES or TKIP cipher suites

Group Key Update Period :

By default, it’s

3600

seconds. This time

© Copyright 2012TRENDnet. All Rights Reserved.

Radius Server Settings :

IP Address :

Enter the IP address of the Authentication RADIUS

• server.

Port :

By default, it’s

1812

.

The port number used to communicate with RADIUS server.

69

TRENDnet User’s Guide

Shared secret :

A secret key used between system and RADIUS server. Supports

8

to

64

characters.

Session Timeout :

The Session timeout is in the range of

0

~

60

seconds

. The default is

0

to disable re-authenticate service.

Amount of time before a client will be required to re-authenticate.

Change these settings as described here and click

Save

button to save your changes.

Click

Reboot

button to activate your changes

Wireless MAC Filter Setup

Continue

6.3.1 Repeater AP Setup

section, the administrator can allow or reject clients to access Repeater AP.

TEW-676APBO

Add a station MAC :

Enter MAC address (e.g. aa:bb:cc:00:00:0a) and click “

Add

” button, then the MAC address should display in the “

Enable

” List.

There are a maximum of

20

clients allowed in this “Enable” List. The MAC addresses of the wireless clients can be added and removed to the list using the

Add

and

Remove

buttons

.

Click

Reboot

button to activate your changes

Access Control List

IP Filter Setup

Allows to create deny or allow rules to filter ingress or egress packets from specific source and/or to destination IP address on wired (LAN) or Wireless (WAN) ports. Filter rules could be used to filter unicast or multicast packets on different protocols as shown in the IP Filter Setup. Important to note that IP filter rules has precedence over Virtual server rules.

Please click on

Advance -> IP Filter Setup

and follow the below setting.

MAC Filter Setup :

By default, it’s “

Disable

”. Options are

Disable, Only Deny List

MAC or Only Allow List MAC

.

Two ways to set MAC filter rules :

Only Allow List MAC

.

The wireless clients in the “

Enable

” list will be

allowed

to access the Access Point;

All others or clients in the “

Disable

” list will be

denied

.

Only Deny List MAC

.

The wireless clients in the “

Enable

” list will be

denied

to access the Access Point; All others or clients in the “

Disable

” list will be

allowed

.

© Copyright 2012TRENDnet. All Rights Reserved.

70

TRENDnet User’s Guide

Source Address/Mask :

Enter desired source IP address and netmask; i.e.

192.168.2.10/32.

Source Port :

Enter a port or a range of ports as

start:end

; i.e. port 20:80

Destination Address/Mask :

Enter desired destination IP address and netmask; i.e.

192.168.1.10/32

Destination Port :

Enter a port or a range of ports as

start:end

; i.e. port 20:80

In/Out :

Applies to Ingress or egress packets

Protocol :

Supports

TCP

,

UDP

or

ICMP

.

Listen :

Click

Yes

radial button to match TCP packets only with the SYN flag.

Active :

Deny

to drop and

Pass

to allow per filter rules

Interface :

The interface that a filter rule applies

Click “

Save

” button to add IP filter rule. Total of

20

rules maximum allowed in the IP

Filter List. All rules can be edited or removed from the List. Click

Reboot

button to activate your changes.

When you create rules in the IP Filter List, the prior rules maintain higher priority. To allow limited access from a subnet to a destination network manager needs to create allow rules first and followed by deny rules. So, if you just want one IP address to access the system via telnet from your subnet, not others, the Example 1 demonstrates it, not rules in the Example 2.

Example 1 :

Create a higher priority rule to allow IP address 192.168.2.2 Telnet access from LAN port first, and deny Telnet access from remaining IP addresses in the same subnet.

Example 2 :

All Telnet access to the system from the IP addresses of subnet

192.168.2.x works with the rule 1 of Example 2. The rule 2 won’t make any difference.

Rule

1

2

Source

IP/Mask

192.168.10.0/

24

192.168.10.2/

32

Destination

IP/Mask

192.168.10.254/3

2

192.168.10.254/3

2

Port

22

22

In/

Out

In

In

Prot.

TCP

TCP

Listen

n n

Action

Deny pass

Side

LAN

LAN

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

MAC Filter Setup

Allows to create MAC filter rules to allow or deny unicast or multicast packets from limited number of MAC addresses. Important to note that MAC filter rules have precedence over IP Filter rules.

Please click on

Advance -> MAC Filter Setup

and follow the below setting.

MAC Filter Rule :

By default, it’s “

Disable

”. Options are

Disabled

,

Only Deny List

MAC

or

Only Allow List MAC

. Click

Save

button to save your change.

Two ways to set the MAC Filter List:

Only Allow List MAC

.

The wireless clients in the MAC Filter List will be

allowed

to access to Access Point;

All others will be denied.

Only Deny List MAC

.

The wireless clients in the MAC Filter List will be

denied

to access to Access Point;

All others will be allowed.

1

2

Source

Rule

IP/Mask

192.168.2.2/3

2

192.168.2.0/2

4

Destination

IP/Mask Port

In/

Out

Protocol Listen

192.168.2.254/32 22 In

192.168.2.254/32 22 In

TCP

TCP n n

Action

Pass

Deny

Side

LAN

LAN

71

TRENDnet User’s Guide

MAC Address :

Enter MAC address (e.g. aa:bb:cc:00:00:0a) and click “

Add

” button, then the MAC address should display in the MAC Filter List.

There are a maximum of

20

clients allowed in this MAC Filter List. The MAC addresses of the wireless clients can be added and removed to the list using the

Add

and

Delete

buttons

.

Click

Reboot

button to activate your changes

Parental Control Setup

Parental Control allows you to block or allow specific kinds of Internet usage and traffic, such as Internet access, designated services, and websites.

N

Main

WIFI WAN

Please click on

Advance -> Parental Control

and follow the below setting.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

Rules :

control can be managed by a rule. Use the settings on this screen to establish an access policy.

Comment :

Enter a descriptive name for this rule for identifying purposes.

MAC Address :

Enter MAC address in valid MAC address

 format(xx:xx:xx:xx:xx:xx) and click “

Add

” button to add in the MAC group of each rule. Click “

Remove

” button can remove MAC address in the group of each rule. There are

10

MAC address maximum allowed in each rule.

Local / Destination IP :

Specify local(LAN)/ destination IP addresses range required for this rule. If you specify local IP addresses range from 192.168.1.1 to 192.168.2.254. The matches a range of local IP addresses include every single IP address from the first to the last, so the example above includes everything from 192.168.1.1 to 192.168.2.254.

Protocol :

Select

Any

or specify protocol(

TCP

,

UDP

,

ICMP

,

URL Blocking

and

Application

) from drop-down list. When you select

ICMP

or

Layer 7

72

TRENDnet User’s Guide

Application

, the Local(LAN)/ Destination Port can not used.

If you want to block websites with specific URL address or using specific keywords, enter each URL or keyworks in the “

URL Blocking

” field and click

Add

” button to add in the URL Blocking list of each rule. Click “

Remove

” button can remove URL or keywords.

Local Port :

Specify local port(LAN port) range required for this rule

Destination Port :

Specify destination port range required for this rule

Active :

Check

Enable

button to activate this rule, and

Disable

to deactivate.

Click “

Add

” button to add control rule to List. There are

10

rules maximum allowed in this Control List. All rules can be removed or edited on the List. Click

Reboot

button to activate your changes.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

QoS Setup

Quality of Service (QoS) refers to both a network's ability to deliver data with minimum delay, and the networking methods used to control the use of bandwidth. Without QoS, all traffic data is equally likely to be dropped when the network is congested. This can cause a reduction in network performance and make the network inadequate for timecritical application such as video-on-demand.

A classifier groups traffic into data flows according to specific criteria such as the source address, destination address, source port number, destination port number or incoming port number. For example, you can configure a classifier to select traffic from the same protocol port (such as FTP) to form a flow.

WAN

192.168.1.x

LAN

192.168.2.x

Download: 1024K

Download: 512K

192.168.2.x

192.168.2.x

Download: 2048K

73

TRENDnet User’s Guide

:

N

Main

WIFI WAN LAN

Please click on

Advance -> QoS

and follow the below setting.

Down:

1024Kbps p: 12Kbps

Down:

2048Kbps

Up:1024Kbp

A

B

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

Rules :

Use the rules to define the classifiers. After you define the rules, you can specify action to act upon the traffic that matches the rules

Comment :

Enter a descriptive name for this rule for identifying purposes.

MAC Address :

Enter MAC address in valid MAC address

 format(xx:xx:xx:xx:xx:xx) and click “

Add

” button to add in the MAC group of each rule. Click “

Remove

” button can remove MAC address in the group of each rule. There are

10

MAC address maximum allowed in each rule.

Local / Destination IP :

Specify local(LAN)/ destination IP addresses range required for this rule. If you specify local IP addresses range from 192.168.1.1 to 192.168.2.254. The matches a range of local IP addresses include every single IP address from the first to the last, so the example above includes everything from 192.168.1.1 to 192.168.2.254.

DSCP Class

: Differentiated services code point, DSCP. Select Any or specify classify traffic from drop-down list.

The Per-Hop Behavior (PHB) is indicated by encoding a 6-bit value—called the

Differentiated Services Code Point (DSCP)—into the 8-bit Differentiated

Services (DS) field of the IP packet header. Below depicts class for DSCP.

BE :

Default

PHB, which is typically best-effort traffic

EF :

Expedited Forwarding

PHB, dedicated to low-loss, low-latency traffic

AF :

Assured Forwarding

PHB, which gives assurance of delivery under conditions. The AF behavior group defines four separate AF classes.

Within each class, packets are given a drop precedence (high, medium or low). The combination of classes and drop precedence yields twelve separate DSCP encodings from

AF11

through

AF43

DROP Precedence

Low Drop

Medium Drop

High Drop

Class 1 Class 2 Class 3

AF11

AF12

AF13

AF21

AF22

AF23

AF31

AF32

AF33

Class 4

AF41

AF42

AF43

74

TRENDnet User’s Guide

Rule

1

2

Source IP

192.168.2.10

Destination

IP

DSCP Protocol Remark

ANY

ANY

FTP

ANY

NO

NO

Bandwidth

(Up/Down)

1024/8196

512/512

Protocol :

Select

Any

or specify protocol from drop-down list. When you select

ICMP

or

Layer 7 Application

, the Source/ Destination Port cannot be used.

Local Port :

Specify local port(LAN port) range required for this rule

Destination Port :

Specify destination port range required for this rule

Action :

After configuring rule, a policy rule ensures that a traffic flow gets the requested treatment in the network.

Rule

1

Source IP

Destination

IP

DSCP Protocol Remark

ANY ANY NO

Bandwidth

(Up/Down)

512/512

2 192.168.2.10 ANY FTP NO 1024/8196

Remark DSCP :

Specify a new DSCP class, if you want to replace or remark the

DSCP

Bandwidth :

Click “

Enable

” to activate function, and click “

Disable

” to deactivate function

Upload / Download :

Specify the bandwidth in kilobit per second (Kbps). Enter a number between

8

to

8192

, default upload is

128

Kbps, download is

1024

Kbps.

Click “

Add

” button to add QoS rule to List. There are

10

rules maximum allowed in this

QoS List. All rules can be removed or edited on the List. Click

Reboot

button to activate your changes.

When you create rules on the QoS List, the previous rules have higher priority. . Below depict the examples for explaining priority of QoS setup.

Example 1 :

On this setting, the FTP has

1024

Kbps upload and

8196

Kbps download on

192.168.2.10

. The remaining IP address and other remaining protocol of IP address 192.168.2.10 only can use total bandwidth

512

Kbps

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

 bandwidth. Because rule 1's priority is higher than rule 2

Example 2 :

On this setting, the FTP has

512

Kbps upload and

512

Kbps download on

192.168.2.10

Because rule 1's priority is higher than rule 2

Resource Sharing

DMZ

DMZ is commonly work with the NAT functionality as an alternative of Virtual

Server(Port Forwarding

)

while wanting all ports of DMZ host visible to Internet users.

Virtual Server rules have precedence over the DMZ rule. In order to use a range of ports available to access to different internal hosts Virtual Server rules are needed.

N

SSID: Repeater

Main

WIFI WAN LAN

Please click on

Advance -> DMZ

and follow the below setting.

75

TRENDnet User’s Guide

TEW-676APBO

Please click on

Advance -> Virtual Server

and follow the below setting.

DMZ :

By default, it’s

Disable

”.

Check

Enable

radial button to enable DMZ.

IP Address :

Enter IP address of DMZ host and only one DMZ host is supported.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes.

Virtual Server (Port Forwarding)

“Virtual Server” can also referred to as “Port Forward” as well and used interchangeably.

Resources in the network can be exposed to the Internet users in a controlled manner including on-line gaming, video conferencing or others via Virtual Server setup. Don’t repeat ports’ usage to avoid confusion.

Suppose you want to assign ports 21-25 to one FTP, Telnet and SMTP server (A in the example), and port 80 to another (B in the example). You assign the LAN IP addresses and the ISP assigns the WAN IP address. The NAT network appears as a single host on the Internet.

Main

Base

St ti

SSID:

WIFI WAN

N

SSID: Repeater

LAN

B

A

© Copyright 2012TRENDnet. All Rights Reserved.

Virtual Server :

By Default, It’s “

Disable

.

Check

Enable

radial button to enable

Virtual Server.

Description :

Enter appropriate message for resource sharing via Virtual Server.

Private IP :

Enter corresponding IP address of internal resource to share.

Protocol Type :

Select appropriate sessions, TCP or UDP, from shared host via multiple private ports.

Private Port :

A port or a range of ports may be specified as

start:end

; i.e. port

20:80

Public Port :

A port or a range of ports may be specified as

start:end

; i.e. port 20:80

.

Click “

Add

” button to add Virtual Server rule to List. Total of maximum

20

rules are allowed in this List. All rules can be edited or removed from the List. Click

Reboot

button to activate your changes.

While creating multiple Virtual Server rules, the prior rules have higher priority. The

Virtual server rules have precedence over the DMZ one while both rules exist. Example 1 and 2 demonstrate proper usage of DMZ and Virtual Server rules.

Example 1 :

All connections should be redirected to

192.168.2.12

while DMZ is enabled. Since Virtual Server rules have precedence over the DMZ rule all

76

TRENDnet User’s Guide

connections to TCP port 22 will be directed to TCP port 22 of 192.168.2.10 and remaining connections to port TCP

20~80

will be redirected to port TCP

20~80

of

192.168.2.11

DMZ Enabled : 192.168.2.12

Rule Protocol Private IP

1

2

TCP

TCP

192.168.2.10

192.168.2.11

Private Port

22

20:80

Public Port

22

20:80

Example 2 :

All connections should be redirected to

192.168.2.12

while DMZ is enabled. Since Virtual Server rules have precedence over the DMZ rule all other connections to TCP port

20~80

will be redirected to port

20~80

of

192.168.2.11

.

The rule 2 won’t take effect.

DMZ Enabled : 192.168.2.12

Rule Protocol Private IP

1

2

TCP

TCP

192.168.2.11

192.168.2.10

Private Port

20:80

22

Public Port

20:80

22

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

System Status

This section breaks down into subsections of

System Overview

,

Associated Clients

Status, Remote AP

,

Extra Information

and

Event Log

.

Overview

Detailed information on

System

,

WAN Information

,

LAN Information

,

Wireless

Information

and

DHCP Server Status

can be reviewed via this page.

System :

Display the information of the system.

System Name :

The name of the system.

Operating Mode :

The mode currently in service.

Location :

The reminding note on the geographical location of the system.

Description :

The reminding note of the system.

Firmware Version :

The current firmware version installed.

Firmware Date :

The build time of the firmware installed.

Device Time :

The current time of the system.

System Up Time :

The time period that system has been in service since last reboot.

WAN Information :

Display the information of the WAN interface.

77

TRENDnet User’s Guide

TEW-676APBO

LAN Information :

Display total received and transmitted statistics on the LAN interface.

The WAN port specified

Dynamic IP

, the Release and Renew button will be showup, click

Release

button to release IP address of WAN port,

Renew

button to renew

IP address through DHCP server.

MAC Address :

The MAC address of the LAN port.

IP Address :

The IP address of the LAN port.

IP Netmask :

The IP netmask of the LAN port.

Receive bytes :

The total received packets in bytes on the LAN port.

Receive packets :

The total received packets of the LAN port.

Transmit bytes :

The total transmitted packets in bytes of the LAN port.

Transmit packets :

The total transmitted packets of the LAN port.

Wireless Information :

Display the detailed receive and transmit statistics of

Wireless interface.

The WAN port specified

PPPoE

or

PPTP

, and the

Connect

and

DisConnect

button will be show up. Click “

Connect

” button to assigned IP address from PPPoE or PPTP server, “

DisConnect

” button to release IP address of WAN port.

Mode :

Supports Static, Dynamic, PPPoE and PPTP modes.

Reconnect Mode :

The current reconnect mode of the PPPoE or PPTP.

MAC Address :

The MAC address of the WAN port.

IP Address :

The IP address of the WAN port.

IP Netmask :

The IP netmask of the WAN port.

IP Gateway :

The gateway IP address of the WAN port.

Primary DNS :

The primary DNS server in service.

Secondary DNS :

The secondary DNS server in service.

© Copyright 2012TRENDnet. All Rights Reserved.

AP MAC Address :

The MAC address of the Repeater AP.

Station MAC Address :

The MAC address of the Wireless Client Station.

Channel :

The current channel on the Wireless port.

AP Rate :

The current Bit Rate on the Repeater AP.

78

TRENDnet User’s Guide

Station Rate :

The current Bit Rate on the Wireless Client Station.

Receive bytes :

The total received packets in bytes on the Wireless port.

Receive packets :

The total received packets on the Wireless port.

Transmit bytes :

The total transmitted packets in bytes on the Wireless port.

Transmit packets :

The total transmitted packets on the Wireless port.

DHCP Server Status :

Users could retrieve DHCP server and DHCP clients’ IP/MAC address via this field.

TEW-676APBO

Associated Clients Status

It displays ESSID, on/off Status, Security Type, total number of wireless clients associated with Repeater AP.

IP Address :

IP addresses to LAN devices by DHCP server.

MAC Address :

MAC addresses of LAN devices.

Expired In :

Shows how long the leased IP address will expire.

© Copyright 2012TRENDnet. All Rights Reserved.

AP Information :

Highlights key Repeater AP information.

AP :

Available Repeater AP.

ESSID :

Display name of ESSID for Repeater AP.

MAC Address :

Display MAC address for Repeater AP.

Status :

On/Off

Security Type :

Display chosen security type; WEP, WPA/WPA2-PSK,

WPA/WPA2-Enterprise.

Clients :

Display total number of wireless connections on Repeater AP.

Repeater AP Clients :

Display all associated clients.

MAC Address :

MAC address of associated clients

Signal Strength ANT0/ANT1 :

Signal Strength of from associated clients.

Bandwidth :

Channel bandwidth of from associated clients

Idle Time :

Last inactive time period in seconds for a wireless connection.

Connect Time :

Total connection time period in seconds for a wireless

 connection.

Disconnect :

Click “

Delete

” button to manually disconnect a wireless client in a

Repeater AP.

79

TRENDnet User’s Guide

Remote AP

SSID, MAC address, antenna 0/1 received signal strength and channel bandwidth for associated AP are available.

TEW-676APBO

Extra Info

Users could pull out information such as Route table, ARP table, MAC table, Bridge table or STP available in the drop-down list from system. The “Refresh” button is used to retrieve latest table information.

ESSID :

Shows the current ESSID, which must be the same on the wireless client and

AP in order for communication to be established.

MAC Address :

Display MAC address of associated AP.

Signal Strength ANT0/ANT1 :

Shows the wireless signal strength of the connection between system and an access point.

BandWidth :

Shows the current channel bandwidth used for communication. It should be “20” or “40”

© Copyright 2012TRENDnet. All Rights Reserved.

Netstat Information :

Select “

NetStatus Information

” on the drop-down list, the connection track list should show-up, the list can be updated using the Refresh button.

NetStatus will show all connection track on the system, the information include

80

TRENDnet User’s Guide

Protocol

,

Live Time

,

Status

,

Source/Destination IP address

and

Port

.

Route table information :

Select “

Route table information

” on the drop-down list to display route table.

TEW-676APBO could be used as a L2 or L3 device. It doesn’t support dynamic routing protocols such as RIP or OSPF. Static routes to specific hosts, networks or default gateway are set up automatically according to the IP configuration of system's interfaces. When used as a L2 device, it could switch packets and, as L3 device, it’s capable of being a gateway to route packets inward and outward.

TEW-676APBO

Bridge MAC information :

Select “

Bridge MACs Information

” on the drop-down list to display MAC table.

This table displays local MAC addresses associated with wired or wireless interfaces, but also remember non-local MAC addresses learned from wired or wireless interfaces.

Ageing timers will be reset when existing MAC addresses in table are learned again or added when new MAC addresses are seen from wired or wireless interfaces as well. When time runs out for a particular entry, it will be pruned from the table. In that situation, switching packet to that particular MAC address will be discontinued.

ARP table Information :

Select “

ARP Table Information

” on the drop-down list to display ARP table.

ARP associates each IP address to a unique hardware address (MAC) of a device. It is important to have a unique IP address as final destination to switch packets to.

Bridge STP Information :

Select “

Bridge STP Information

” on the drop-down list to display a list of bridge STP information.

Bridge table information :

Select “

Bridge Table information

” on the drop-down list to display bridge table.

Bridge table will show Bridge ID and STP's Status on the each Ethernet bridge and its attached interfaces, the Bridge Port should be attached to some interfaces.

© Copyright 2012TRENDnet. All Rights Reserved.

81

TRENDnet User’s Guide

QoS Plot

The QoS Plot show graphs which continuously represents the current data traffic on each QoS rule. The chart scale and throughput dimension (bps, Kbps, Mbps) changes dynamically according to the mean throughput value. The statistics is updated automatically every

5

seconds. The throughput statistics of QoS can be updated manually using the

Refresh

button.

Event Log

The Event log displays system events when system is up and running. Also, it becomes very useful as a troubleshooting tool when issues are experienced in system.

Time :

The date and time when the event occurred.

Facility :

It helps users to identify source of events such “System” or “User”

Severity :

Severity level that a specific event is associated such as “info”, “error”,

“warning”, etc.

Message :

Description of the event.

Click

Refresh

button to renew the log, or click

Clear

button to clear all the record.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

Client Bridge + Universal Repeater Configuration

When Client Bridge+Universal Repeater mode is activated, the system can be configured as an

Access Point

and

Client Station

simultaneously. This section provides information in configuring the Client Bridge+Universal Repeater mode with graphical illustrations.

TEW-676APBO provides functions as stated below where they can be configured via a user-friendly web based interface.

Option System Wireless Utilities Status

Operating

Mode

General Setup Profiles Settings

System

Overview

LAN Clients

Functions

Management

Time Server

SNMP

Advanced Setup Firmware Upgrade

Repeater AP

Setup

Network Utility

Wireless Profile

Site Survey

Reboot

Remote AP

Extra Info

Event Log

Client Bridge+Universal Repeater Mode Functions

82

TRENDnet User’s Guide

External Network Connection

Network Requirement

It can be used as an Client Bridge or Universal Repeater to receive and repeat wireless signal over last mile applications, helping WISPs deliver wireless broadband Internet service to new residential and business customers. In this mode, TEW-676APBO is enabled with DHCP Server functions. The wired clients of TEW-676APBO are in

the same

subnet from Main Base Station and it

accepts

wireless connections from wireless client devices.

SSID:

Repeater_Main_AP

Main

Client Bridge + Universal Repeater mode network Configuration

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

Configure LAN IP

Here are the instructions for how to setup the local IP Address and Netmask.

Please click on

System -> LAN

and follow the below setting.

Mode :

Check either “Static IP” or “Dynamic IP” button as desired to set up the system IP of LAN port .

Static IP :

The administrator can manually setup the LAN IP address when static IP is available/ preferred.

IP Address :

The IP address of the LAN port; default IP address is

192.168.2.254

IP Netmask :

The Subnet mask of the LAN port; default Netmask is

255.255.255.0

83

TRENDnet User’s Guide

IP Gateway :

The default gateway of the LAN port; default Gateway is

192.168.2.1

Dynamic IP :

This configuration type is applicable when the TEW-676APBO is connected to a network with the presence of a DHCP server; all related IP information will be provided by the DHCP server automatically.

Hostname :

The Hostname of the LAN port

DNS :

Check either “No Default DNS Server” or “Specify DNS Server IP” button as desired to set up the system DNS.

Primary :

The IP address of the primary DNS server.

Secondary :

The IP address of the secondary DNS server.

DHCP Setup :

Devices connected to the system can obtain an IP address automatically when this service is enabled.

TEW-676APBO

Lease Time :

The IP addresses given out by the DHCP server will only be valid for the duration specified by the lease time. Increasing the time ensure client operation without interruptions, but could introduce potential conflicts.

Lowering the lease time will avoid potential address conflicts, but might cause more interruptions to the client while it will acquire new IP addresses from the

DHCP server. Default is

86400

seconds

Click

Save

button to save your changes. Click

Reboot

button to activate your changes

Access Point Association

Configure Wireless General Setting

The administrator can change the data transmission, channel and output power settings for the system. Please click on

Wireless -> General Setup

and follow the below setting.

DHCP :

Check

Enable

button to activate this function or

Disable

to deactivate this service.

Start IP / End IP:

Specify the range of IP addresses to be used by the DHCP server when assigning IP address to clients. The default range IP address is

192.168.2.10 to 192.168.2.70, the netmask is 255.255.255.0

DNS1 IP :

Enter IP address of the first DNS server; this field is required.

DNS2 IP :

Enter IP address of the second DNS server; this is optional.

WINS IP :

Enter IP address of the Windows Internet Name Service (WINS) server; this is optional.

Domain :

Enter the domain name for this network.

© Copyright 2012TRENDnet. All Rights Reserved.

84

TRENDnet User’s Guide

Band Mode :

Select an appropriate wireless band; bands available are

801.11a

or

802.11a/n mixed

mode.

Transmit Rate Control :

Select the desired rate from the drop-down list; the options are auto or ranging from

6

to

54

Mbps for

802.11a

Tx Power :

You can adjust the output power of the system to get the appropriate coverage for your wireless network. Specify digit number between

1

to

100

(the unit is %) for your environment. If you are not sure of which setting to choose, then keep the default setting,

100

%.

When

Band Mode

select in

802.11a only mode

, the

HT(High Throughput) Physical

Mode and 11n Configuration

settings should be hidden immediately.

Operating Mode :

By default, it's Mixed Mode

Mixed Mode :

In this mode packets are transmitted with a preamble

 compatible with the legacy 802.11a/g, the rest of the packet has a new format.

In this mode the receiver shall be able to decode both the Mixed Mode packets and legacy packets.

Green Field :

In this mode high throughput packets are transmitted without a legacy compatible part.

Channel Bandwidth :

The "

Auto

” MHz option is usually best. The other option is available for special circumstances.

Guard Interval :

Using “

Auto

” option can increase throughput. However, it can also increase error rate in some installations, due to increased sensitivity to radiofrequency reflections. Select the option that works best for your installation.

MCS :

This parameter represents transmission rate. By default (Auto) the fastest possible transmission rate will be selected. You have the option of selecting the speed if necessary. (Refer to

Appendix C. MCS Data Rate

)

MPDU Enable :

Check

Enable

button to activate this function, and

Disable

to deactivate.

A-MPDU :

A-MPDU (Aggregated Mac Protocol Data Unit) allows the transmissions of multiple Ethernet frames to a single location as burst of up to 64kbytes This is performed on the hardware itself. Select “Manual” to set “MPDU Density”

MPDU Density :

Minimum separation of MPDUs in an A-MPDU.

0 1 2 3 4 5 6 7

No Restriction ¼ µs ½ µs 1 µs 2 µs 4 µs 8 µs 16 µs

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

A-MSDU :

Aggregated Mac Service Data Unit, A-MSDU. Select

Enable

to allow aggregation for multiple MSDUs in one MPDU. Default is disabled.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes.

The items in this page are for AP's RF general settings and will be applied to

Repeater AP

Wireless Advanced Setup

To achieve optimal wireless performance, it is necessary to tweak advance setting per requirements properly, not necessary higher the better or lower.

The administrator can change the RTS threshold and fragmentation threshold settings for the system. Please click on

Wireless -> Advanced Setup

and follow the below setting.

Short Slot :

By default, it’s “

Enable

” for educing the slot time from the standard

20

microseconds

to the

9

microsecond

short slot time

Slot time is the amount of time a device waits after a collision before retransmitting a packet. Reducing the slot time decreases the overall back-off, which increases throughput. Back-off, which is a multiple of the slot time, is the random length of time a station waits before sending a packet on the LAN. For a sender and receiver own right of the channel the shorter slot time help manage shorter wait time to retransmit from collision because of hidden wireless clients or other causes. When collision sources can be removed sooner and other senders attempting to send are listening the channel(CSMA/CA) the owner of the channel should continue

85

TRENDnet User’s Guide

 ownership and finish their transmission and release the channel. Then, following ownership of the channel will be sooner for the new pair due to shorter slot time.

However, when long duration of existing collision sources and shorter slot time exist the owners might experience subsequent collisions. When adjustment to longer slot time can’t improve performance then RTS/CTS could supplement and help improve performance.

Extra Slot Time :

Slot time is in the range of

1~255

and set in unit of

microsecond

.

The default value is

9

microsecond.

ACK Timeout :

ACK timeout is in the range of

1~255

and set in unit of

microsecond

.

The default value is

32

microsecond.

All data transmission in 802.11b/g request an “Acknowledgement” (ACK) send by receiving radio. The transmitter will resend the original packet if correspondent ACK failed to arrive within specific time interval, also refer to as “ACK Timeout”.

ACK Timeout is adjustable due to the fact that distance between two radio links may vary in different deployment. ACK Timeout makes significant influence in performance of long distance radio link. If ACK Timeout is set too short, transmitter will start to “Resend” packet before ACK is received, and throughputs become low due to excessively high re-transmission.

ACK Timeout is best determined by distance between the radios, data rate of average environment. The Timeout value is calculated based on round-trip time of packet with a little tolerance, So, if experiencing re-transmissions or poor performance the ACK Timeout could be made longer to accommodate.

Beacon Interval :

Beacon Interval is in the range of

20

~

1024

and set in unit of

millisecond

. The default value is

100

msec.

Access Point (AP) in IEEE 802.11 will send out a special approximated 50-byte frame, called “Beacon”. Beacon is broadcast to all the stations, provides the basic information of AP such as SSID, channel, encryption keys, signal strength, time stamp, support data rate.

All the radio stations received beacon recognizes the existence of such AP, and may proceed next actions if the information from AP matches the requirement. Beacon is sent on a periodic basis, the time interval can be adjusted.

By increasing the beacon interval, you can reduce the number of beacons and associated overhead, but that will likely delay the association and roaming process because stations scanning for available access points may miss the beacons. You can decrease the beacon interval, which increases the rate of beacons. This will make the association and roaming process very responsive; however, the network will incur additional overhead and throughput will go down.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

DTIM Interval :

The DTIM interval is in the range of

1

~

255

. The default is

1

.

DTIM is defined as

Delivery Traffic Indication Message

. It is used to notify the wireless stations, which support power saving mode, when to wake up to receive multicast frame. DTIM is necessary and critical in wireless environment as a mechanism to fulfill power-saving synchronization.

A DTIM interval is a count of the number of beacon frames that must occur before the access point sends the buffered multicast frames. For instance, if DTIM Interval is set to 3, then the Wi-Fi clients will expect to receive a multicast frame after receiving three Beacon frame. The higher DTIM interval will help power saving and possibly decrease wireless throughput in multicast applications.

Fragment Threshold :

The Fragment Threshold is in the range of

256

~

2346

byte.

The default is

2346

byte.

Each Wi-Fi packet can be divided into smaller packets, marked with a sequential fragment number and re-assemble in the receiving ends. The purpose is to make a short frame, instead of long frame, transmitting by radio in a heavy noisy environment. Because of sending smaller frames, corruptions are much less likely to occur. The pros is obvious, the cons is the overhead for transmission. So, in a clean environment, higher fragment threshold can be an option to increase throughput.

Fragmentation will be triggered by setting the Fragment Threshold, usually in Bytelength. Only when the frame size is over the Threshold, fragmentation will take place automatically.

RTS Threshold :

TRTS Threshold is in the range of

1~2347

byte. The default is

2347

byte.

The main purpose of enabling RTS by changing RTS threshold is to reduce possible collisions due to hidden wireless clients. RTS in AP will be enabled automatically if the packet size is larger than the Threshold value. By default, RTS is disabled in a normal environment supports non-jumbo frames.

Short Preamble :

By default, it’s “

Enable

”. To

Disable

is to use Long 128-bit

Preamble Synchronization field.

The preamble is used to signal "here is a train of data coming" to the receiver. The short preamble provides 72-bit Synchronization field to improve WLAN transmission efficiency with less overhead.

Tx Burst :

By default, it’s “

Enable

”. To

Disable

is to deactivate Tx Burst.

With TX burst enabled, AP will send many packets in a burst, without collision detection and RTS/CTS for each packet. TX Burst have better throughput but cause interference

86

TRENDnet User’s Guide

 with other APs in channel.

Pkt_Aggregate :

By default, it's “

Enable

Queue

Data Transmitted

AP to Clients

Priority Description

AC_BK

AC_BE

Background.

Best Effort

Low

Medium

High throughput. Bulk data that requires maximum throughput and is not time-sensitive is sent to this queue (FTP data, for example).

Medium throughput and delay.

Most traditional IP data is sent to this queue

AC_VI Video High

Minimum delay. Time-sensitive video data is automatically sent to this queue

AC_VO Voice High

Time-sensitive data like VoIP and streaming media are automatically sent to this queue

Increase efficiency by aggregating multiple packets of application data into a single transmission frame. In this way, 802.11n networks can send multiple data packets with the fixed overhead cost of just a single frame.

WMM :

By default, it's “

Disable

”. To

Enable

is to use WMM and the WMM parameters should appears.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

WMM Parameters of Access Point :

This affects traffic flowing from the access point to the client station

Configuring QoS options consists of setting parameters on existing queues for different types of wireless traffic. You can configure different minimum and maximum wait times for the transmission of packets in each queue based on the requirements of the media being sent. Queues automatically provide minimum transmission delay for Voice, Video, multimedia, and mission critical applications, and rely on best-effort parameters for traditional IP data.

As an Example, time-sensitive Voice & Video, and multimedia are given effectively higher priority for transmission (lower wait times for channel access), while other applications and traditional IP data which are less timesensitive but often more data-intensive are expected to tolerate longer wait times.

Aifsn

: The Arbitration Inter-Frame Spacing Number specifies a wait time

(in milliseconds) for data frames

CWmin

: Minimum Contention Window. This parameter is input to the algorithm that determines the initial random backoff wait time

("window") for retry of a transmission. The value specified here in the

Minimum Contention Window is the upper limit (in milliseconds) of a range from which the initial random backoff wait time is determined.

87

TRENDnet User’s Guide

Queue

Data

Transmitted

Clients to AP

Priority Description

AC_BK Background. Low

High throughput. Bulk data that requires maximum throughput and is not time-sensitive is sent to this queue (FTP data, for example).

AC_BE Best Effort Medium Medium throughput and delay. Most traditional IP

AC_VI Video

AC_VO Voice

CWmax

: Maximum Contention Window. The value specified here in the

Maximum Contention Window is the upper limit (in milliseconds) for the doubling of the random backoff value. This doubling continues until either the data frame is sent or the Maximum Contention Window size is reached. Once the Maximum Contention Window size is reached, retries will continue until a maximum number of retries allowed is reached. Valid values for the "cwmax" are 1, 3, 7, 15, 31, 63, 127, 255, 511, or 1024. The value for "cwmax" must be higher than the value for "cwmin".

Txop

: Transmission Opportunity is an interval of time when a WME AP has the right to initiate transmissions onto the wireless medium (WM).

This value specifies (in milliseconds) the Transmission Opportunity (TXOP) for AP; that is, the interval of time when the WMM AP has the right to initiate transmissions on the wireless network.

ACM :

Admission Control Mandatory, ACM only takes effect on AC_VI and

AC_VO. When you do not click Checkbox, it means that the ACM is controlled by the connecting AP. If you click Checkbox, it means that the

Client is in charge.

AckPolicy :

Acknowledgment Policy, WMM defines two ACK policies:

Normal ACK

and

No ACK

. Click “

Checkbox

” indicates “

No ACK

When the no acknowledgment (No ACK) policy is used, the recipient does not acknowledge received packets during wireless packet exchange. This policy is suitable in the environment where communication quality is fine and interference is weak. While the No ACK policy helps improve transmission efficiency, it can cause increased packet loss when communication quality deteriorates. This is because when this policy is

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

 used, a sender does not retransmit packets that have not been received by the recipient.

When the Normal ACK policy is used, the recipient acknowledges each received unicast packet.

WMM Parameters of Station :

This affects traffic flowing from the client station to the access point.

Aifsn

: The Arbitration Inter-Frame Spacing Number specifies a wait time

(in milliseconds) for data frames

CWmin

: Minimum Contention Window. This parameter is input to the algorithm that determines the initial random back off wait time

("window") for retry of a transmission. The value specified here in the

Minimum Contention Window is the upper limit (in milliseconds) of a range from which the initial random back off wait time is determined.

CWmax

: Maximum Contention Window. The value specified here in the

Maximum Contention Window is the upper limit (in milliseconds) for the doubling of the random backoff value. This doubling continues until either the data frame is sent or the Maximum Contention Window size is reached. Once the Maximum Contention Window size is reached, retries will continue until a maximum number of retries allowed is reached. Valid values for the "cwmax" are 1, 3, 7, 15, 31, 63, 127, 255, 511, or 1024. The value for "cwmax" must be higher than the value for "cwmin".

Txop

: Transmission Opportunity is an interval of time when a WME AP

 has the right to initiate transmissions onto the wireless medium (WM).

This value specifies (in milliseconds) the Transmission Opportunity (Txop) for AP; that is, the interval of time when the WMM AP has the right to initiate transmissions on the wireless network.

ACM :

Admission Control Mandatory, ACM only takes effect on AC_VI and

AC_VO. When you do not click Checkbox, it means that the ACM is controlled by the connecting AP. If you click Checkbox, it means that the

Client is in charge.

Change these settings as described here and click

Save

button to save your changes.

Click

Reboot

button to activate your changes. The items in this page are for AP's RF advanced settings and will be applied to

Repeater AP

.

88

TRENDnet User’s Guide

Site Survey

Use this tool to scan and locate WISP Access Points and select one to associate with.

Please click on

Wireless -> Site Survey

. Below depicts an example for site survey.

TEW-676APBO

Create Wireless Profile

The administrator can configure station profiles via this page.

Please click on

Wireless -> Wireless Profile

and follow the below setting.

ESSID : Available

Extend Service Set ID of surrounding Access Points.

MAC Address :

MAC addresses of surrounding Access Points.

Signal :

Received signal strength of all found Access Points.

Channel :

Channel numbers used by all found Access Points.

Security :

Security type by all found Access Points.

Band :

Wireless band used by all found Access Points.

Network Type :

Network type used by all found Access Points.

Select :

Click “

Select

” to configure settings and associate with chosen AP.

© Copyright 2012TRENDnet. All Rights Reserved.

MAC Address :

The MAC address of the Wireless Station is displayed here.

Profile Name :

Set different profiles for quick connection uses.

ESSID :

Assign Service Set ID for the wireless system.

Lock to AP MAC :

This allows the station to always maintain connection to a particular AP with a specific MAC address. This is useful as sometimes there can be few identically named SSID's (AP's) with different MAC addresses. With AP lock on, the station will lock to MAC address and not roam between several Access Points with the same ESSID.

Channel/Frequency :

Select the desired channel range.

Security Type :

Select the desired security type from the drop-down list; the options are “

NONE

” “

OPEN

”, “

SHARED

”, “

WPA-PSK

” and “

WPA2-PSK

”.

OPEN / SHARED :

OPEN and

89

TRENDnet User’s Guide

SHARED require the user to set a WEP key to exchange data.

Key Index :

key index is used to designate the WEP key during data transmission. 4 different WEP keys can be entered at the same time, but only one is chosen.

WEP Key # :

Enter

HEX

or

ASCII

format WEP key value; the system supports up to 4 sets of WEP keys.

WPA-PSK (or WPA2-PSK) :

WPA (or WPA2) Algorithms, allows the system accessing the network by using the WPA-PSK protected access.

Cipher Suite :

Select the desired cipher suite from the drop-down list; the options are

AES

and

TKIP

Pre-shared Key :

Enter the information for pre-shared key; the key can be either entered as a 256-bit secret in

64 HEX

digits format, or

8 to 63 ASCII

characters.

Profile List :

The user can manage the created profiles for home, work or public areas. Below depict an example for Profile List

TEW-676APBO

Configuration and Security Policy will display profile's content. Edit profile's content and then click “

Save

” button to save the profile.

Click “

Delete

” to remove profile.

Click and Select a profile from list, then click the “

Connect

” button to connecting to the wireless network with the profile setting. After clicking

Connect

” button, the system should be jump to

Remote AP Page

, you can verify connecting status on

Remote AP Page

.

Change these settings as described here and click

Save

button to save your changes.

Click

Reboot

button to activate your changes

Key Length Hex ASCII

64-bit 10 characters 5 characters

128-bit 26 characters 13 characters

Wireless LAN Network Creation

The network manager can configure related wireless settings,

Repeater AP Setup,

Security Settings,

and

MAC Filter Settings

.

Repeater AP Setup

Administrators can configure ESSID, SSID broadcasting, Maximum number of client associations, security type settings and MAC Filter settings.

Click “”

Edit

” an exist profile on the Profile List. The field of System

© Copyright 2012TRENDnet. All Rights Reserved.

90

TRENDnet User’s Guide

Enable Repeater AP :

By default, it’s “

En

able

” for repeater AP. Select “

Enable

” to activate Repeater AP or click “

Disable

” to deactivate this function

ESSID :

Extended Service Set ID, When clients are browsing for available wireless networks, this is the SSID that will appear in the list. ESSID will determine the service type available to AP's clients associated with the specified AP.

Client Isolation :

By default, it’s “

Disable

.

Select “

Enable”

, all clients will be isolated from each other, which means they can’t reach each other.

Hidden SSID :

By default, it’s “

Disable

.

Enable this option to stop the SSID broadcast in your network. When disabled, people could easily obtain the SSID information with the site survey software and get access to the network if security is not turned on. When enabled, network security is enhanced. It’s suggested to enable it after AP security settings are archived and setting of AP's clients could make to associate to it.

Maximum Clients :

The default value is

32

. You can enter the number of wireless clients that can associate to a particular SSID. When the number of client is set to 5,

Key Length Hex ASCII

64-bit 10 characters 5 characters

128-bit

26 characters 13 characters only 5 clients at most are allowed to connect to this Repeater AP.

Security Type :

Select the desired security type from the drop-down list; the options are

Disable

,

WEP

,

WPA-PSK

,

WPA2-PSK

,

WPA-Enterprise

,

WPA2-Enterprise

and

WEP 802.1X

.

Disable :

Data are unencrypted during transmission when this option is selected.

WEP :

Wired Equivalent Privacy(WEP) is a data encryption mechanism based on a 64-bit or 128-bit shared key.

TEW-676APBO

Authentication Method :

Enable the desire option among

OPEN

,

SHARED

or

WEPAUTO

.

Key Index :

key index is used to designate the WEP key during data transmission. 4 different WEP keys can be entered at the same time, but only one is chosen.

WEP Key # :

Enter

HEX

or

ASCII

format WEP key value; the system supports up to 4 sets of WEP keys.

WPA-PSK (or WPA2-PSK) :

WPA (or WPA2) Algorithms, allows the system accessing the network by using the WPA-PSK protected access.

Cipher Suite :

By default, it is

AES

. Select either AES or TKIP cipher suites

Pre-shared Key :

Enter the pre-shared key; the format shall go with the selected key type.

Group Key Update Period :

By default, it is

3600

seconds. This time interval for rekeying GTK, broadcast/multicast encryption keys, in seconds. Entering the time-length is required.

WPA-Enterprise (or WPA2-Enterprise):

The RADIUS authentication and encryption will be both enabled if this is selected.

© Copyright 2012TRENDnet. All Rights Reserved.

91

TRENDnet User’s Guide

TEW-676APBO

following Dynamic WEP and RADIUS settings to complete configuration.

WPA General Settings :

Cipher Suite :

By default, it is AES. Select either AES or TKIP cipher suites

Group Key Update Period :

By default, it’s

3600

seconds. This time interval for rekeying GTK, broadcast/multicast encryption keys, in seconds. Entering the time-length is required.

PMK Cache Period :

By default, it's 10 minutes. Set

WPA2

PMKID cache timeout period, after time out, the cached key will be deleted.

Pre-Authentication :

By default, it's “Disable”. To Enable is use to speed up roaming before pre-authenticating IEEE 802.1X/EAP part of the full RSN authentication and key handshake before actually

 associating with a new AP.

Radius Server Settings :

IP Address :

Enter the IP address of the Authentication RADIUS server.

Port :

By default, it’s

1812

.

The port number used to communicate with RADIUS server.

Shared secret :

A secret key used between system and RADIUS server. Supports

8

to

64

characters.

Session Timeout :

The Session timeout is in the range of

0

~

60

seconds

. The default is

0

to disable re-authenticate service.

Amount of time before a client will be required to re-authenticate.

WEP 802.1X :

When WEP 802.1x Authentication is enabled, please refer to the

© Copyright 2012TRENDnet. All Rights Reserved.

Radius Server Settings :

IP Address :

Enter the IP address of the Authentication RADIUS server.

Port :

By default, it’s

1812

.

The port number used to communicate with RADIUS server.

Shared secret :

A secret key used between system and RADIUS server. Supports

8

to

64

characters.

Session Timeout :

The Session timeout is in the range of

0

~

60

seconds

. The default is

0

to disable re-authenticate service.

Amount of time before a client will be required to re-authenticate.

92

TRENDnet User’s Guide

Wireless MAC Filter Setup

Continue

7.3.1 Repeater AP Setup

section, the administrator can allow or reject clients to access Repeater AP.

TEW-676APBO

System Status

This section breaks down into subsections of

System Overview

,

Associated Clients

Status

,

Remote AP

,

Extra Information

and

Event Log

.

System Overview

Display detailed information of

System, Network, LAN and Wireless

in the System

Overview page.

System :

Display the information of the system.

MAC Filter Setup :

By default, it’s “

Disable

”. Options are

Disable, Only Deny List

MAC or Only Allow List MAC

.

Two ways to set MAC filter rules :

Only Allow List MAC

.

The wireless clients in the “

Enable

” list will be

allowed

to access the Access Point;

All others or clients in the “

Disable

” list will be

denied

.

Only Deny List MAC

.

The wireless clients in the “

Enable

” list will be

denied

to access the Access Point; All others or clients in the “

Disable

” list will be

allowed

.

Add a station MAC :

Enter MAC address (e.g. aa:bb:cc:00:00:0a) and click “

Add

” button, then the MAC address should display in the “

Enable

” List.

There are a maximum of

20

clients allowed in this “Enable” List. The MAC addresses of the wireless clients can be added and removed to the list using the

Add

and

Remove

buttons

.

Click

Reboot

button to activate your changes

© Copyright 2012TRENDnet. All Rights Reserved.

System Name :

The name of the system.

Operating Mode :

The mode currently in service.

Location :

The reminding note on the geographical location of the system.

Description :

The reminding note of the system.

Firmware Version :

The current firmware version installed.

Firmware Date :

The build time of the firmware installed.

Device Time :

The current time of the system.

System Up Time :

The time period that system has been in service since last reboot.

93

TRENDnet User’s Guide

Network Information :

Display the information of the Network.

TEW-676APBO

Mode :

Supports Static or Dynamic modes on the LAN interface.

IP Address :

The management IP of system. By default, it’s 192.168.2.254.

IP Netmask :

The network mask. By default, it’s 255.255.255.0.

IP Gateway :

The gateway IP address and by default, it’s 192.168.2.1.

Primary DNS :

The primary DNS server in service.

Secondary DNS :

The secondary DNS server in service.

LAN Information :

Display the detailed receive and transmit statistics of LAN interface.

AP MAC Address :

The MAC address of the repeater AP.

Station MAC Address :

The MAC address of the Wireless Client Station.

Channel :

The current channel on the Wireless port.

AP Rate :

The current Bit Rate on the Repeater AP.

Station Rate :

The current Bit Rate on the Wireless Client Station.

Receive bytes :

The total received packets in bytes on the Wireless port.

Receive packets :

The total received packets on the Wireless port.

Transmit bytes :

The total transmitted packets in bytes on the Wireless port.

Transmit packets :

The total transmitted packets on the Wireless port.

DHCP Server Status :

Users could retrieve DHCP server and DHCP clients’ IP/MAC address via this field.

MAC Address :

The MAC address of the LAN port.

Receive bytes :

The total received packets in bytes on the LAN port.

Receive packets :

The total received packets of the LAN port.

Transmit bytes :

The total transmitted packets in bytes of the LAN port.

Transmit packets :

The total transmitted packets of the LAN port.

Wireless Information :

Display the detailed receive and transmit statistics of

Wireless interface.

© Copyright 2012TRENDnet. All Rights Reserved.

IP Address :

IP addresses to LAN devices by DHCP server.

MAC Address :

MAC addresses of LAN devices.

Expired In :

Shows how long the leased IP address will expire.

94

TRENDnet User’s Guide

Associated Clients Status

It displays ESSID, on/off Status, Security Type, total number of wireless clients associated with Repeater AP.

TEW-676APBO

Remote AP

SSID, MAC address, antenna 0/1 received signal strength and channel bandwidth for associated AP are available.

AP Information :

Highlights key Repeater AP information.

AP :

Available Repeater AP.

ESSID :

Display name of ESSID for Repeater AP.

MAC Address :

Display MAC address for Repeater AP.

Status :

On/Off

Security Type :

Display chosen security type; WEP, WPA/WPA2-PSK,

WPA/WPA2-Enterprise.

Clients :

Display total number of wireless connections on Repeater AP.

Repeater AP Clients :

Display all associated clients.

MAC Address :

MAC address of associated clients

Signal Strength ANT0/ANT1 :

Signal Strength of from associated clients.

Bandwidth :

Channel bandwidth of from associated clients

Idle Time :

Last inactive time period in seconds for a wireless connection.

Connect Time :

Total connection time period in seconds for a wireless

 connection.

Disconnect :

Click “

Delete

” button to manually disconnect a wireless client in a

Repeater AP.

© Copyright 2012TRENDnet. All Rights Reserved.

Extra Information

ESSID :

Shows the current ESSID, which must be the same on the wireless client and

AP in order for communication to be established.

MAC Address :

Display MAC address of associated AP.

Signal Strength ANT0/ANT1 :

Shows the wireless signal strength of the connection between system and an access point.

BandWidth :

Shows the current channel bandwidth used for communication. It should be “20” or “40”

Users could pull out information such as Route table, ARP table, MAC table, Bridge table or STP available in the drop-down list from system. The “Refresh” button is used to retrieve latest table information.

Route table information :

Select “

Route table information

” on the drop-down list to display route table.

TEW-676APBO could be used as a L2 or L3 device. It doesn’t support dynamic

95

TRENDnet User’s Guide

routing protocols such as RIP or OSPF. Static routes to specific hosts, networks or default gateway are set up automatically according to the IP configuration of system's interfaces. When used as a L2 device, it could switch packets and, as L3 device, it’s capable of being a gateway to route packets inward and outward.

TEW-676APBO

Ageing timers will be reset when existing MAC addresses in table are learned again or added when new MAC addresses are seen from wired or wireless interfaces as well. When time runs out for a particular entry, it will be pruned from the table. In that situation, switching packet to that particular MAC address will be discontinued.

ARP table Information :

Select “

ARP Table Information

” on the drop-down list to display ARP table.

ARP associates each IP address to a unique hardware address (MAC) of a device. It is important to have a unique IP address as final destination to switch packets to.

Bridge table information :

Select “

Bridge Table information

” on the drop-down list to display bridge table.

Bridge table will show Bridge ID and STP's Status on the each Ethernet bridge and its attached interfaces, the Bridge Port should be attached to some interfaces. (e.g. eth2, ra0 and apcli0).

Bridge STP Information :

Select “

Bridge STP Information

” on the drop-down list to display a list of bridge STP information.

Bridge MAC information :

Select “

Bridge MACs Information

” on the drop-down list to display MAC table.

This table displays local MAC addresses associated with wired or wireless interfaces, but also remember non-local MAC addresses learned from wired or wireless interfaces.

© Copyright 2012TRENDnet. All Rights Reserved.

96

TRENDnet User’s Guide

TEW-676APBO

Event Log

The Event log displays system events when system is up and running. Also, it becomes very useful as a troubleshooting tool when issues are experienced in system.

© Copyright 2012TRENDnet. All Rights Reserved.

Time :

The date and time when the event occurred.

Facility :

It helps users to identify source of events such “System” or “User”

Severity :

Severity level that a specific event is associated such as “info”, “error”,

“warning”, etc.

Message :

Description of the event.

Click

Refresh

button to renew the log, or click

Clear

button to clear all the record.

97

TRENDnet User’s Guide

Router AP Mode Configuration

When Router AP mode is chosen, the system can be configured as a Router with Access

Point and WDS function. This section provides detailed explanation for users to configure in the Router AP mode with help of illustrations. In the Router AP mode, functions listed in the table below are also available from the Web-based GUI interface.

OPTION System Wireless Advance Utilities Status

Operating

Mode

General Setup DMZ

Profiles

Settings

System

Overview

WAN Advanced Setup IP Filter

Functions

LAN

DDNS

Managemen

Time Server

Virtual AP Setup MAC Filter

WDS Setup

Virtual

Parental l

QoS

UPNP

SNMP

Router AP Mode Functions

© Copyright 2012TRENDnet. All Rights Reserved.

Firmware

Upgrade

Network l

Reboot

Station

Statistics

Extra Info

QoS Plot

Event Log

TEW-676APBO

External Network Connection

Network Requirement

It can be used as an Router AP with WDS function. In this mode, TEW-676APBO is a gateway enabled with NAT and DHCP Server functions. The wireless clients connected to

TEW-676APBO are in

different

subnet from those connected to Internet.

Remote Bass Station

WDS

WAN WLAN

Router AP mode network configuration

98

TRENDnet User’s Guide

Configure WAN Setup

There are three connection types for the WAN port :

Static IP

,

Dynamic IP

,

PPPoE

and

PPTP

.

Please click on

System -> WAN

and follow the below setting.

TEW-676APBO

IP Netmask :

The Subnet mask of the WAN port; default Netmask is

255.255.255.0

IP Gateway :

The default gateway of the WAN port; default Gateway is

192.168.1.1

Dynamic IP :

Please consult with WISP for correct wireless settings to associate with WISP AP before a dynamic IP, along with related IP settings including DNS can be available from DHCP server. If IP Address is not assigned, please double check with your wireless settings and ensure successful association. Also, you may go to “

WAN Information

” in the Overview page to click

Release

button to release IP address and click

Renew

button to renew IP address again.

Hostname :

The Hostname of the WAN port

Mode :

By default, it’s “

Static IP

”. Check “Static IP”, “Dynamic IP”, “PPPoE” or

“PPTP”to set up system WAN IP.

Static IP :

Users can manually setup the WAN IP address with a static IP provided by WISP.

IP Address :

The IP address of the WAN port; default IP address is

192.168.1.254

© Copyright 2012TRENDnet. All Rights Reserved.

PPPoE :

To create wireless PPPoE WAN connection to a PPPoE server in network.

User Name :

Enter User Name for PPPoE connection

Password :

Enter Password for PPPoE connection

Reconnect Mode :

Always on

– A connection to Internet is always maintained.

On Demand

– A connection to Internet is made as needed.

Manual

– Click the “

Connect

” button on “

WAN Information

” in the

Overview page to connect to the Internet.

Idle Time :

Time to last before disconnecting PPPoE session when it is idle. Enter preferred Idle Time in minutes. Default is “

0

”, indicates disabled. When Idle time is disabled, the “

Reconnect Mode

” will turn out

Always on

MTU :

By default, it’s

1492

bytes. MTU stands for Maximum Transmission

Unit. Consult with WISP for a correct MTU setting.

99

TRENDnet User’s Guide

PPTP :

The Point-to-Point Tunneling Protocol (PPTP) mode enables the implementation of secure multi-protocol Virtual Private Networks (VPNs) through public networks.

TEW-676APBO

DNS :

Check “No Default DNS Server” or “Specify DNS Server IP” radial button as desired to set up system DNS.

Primary :

The IP address of the primary DNS server.

Secondary :

The IP address of the secondary DNS server.

MAC Clone :

The MAC address is a 12-digit HEX code uniquely assigned to hardware as identification. Some ISPs require you to register a MAC address in order to access to Internet. If not, you could use default MAC or clone MAC from a PC.

IP Address :

The IP address of the WAN port

IP Netmask :

The Subnet mask of the WAN port

PPTP Server IP Address :

The IP address of the PPTP server

User Name :

Enter User Name for PPTP connection

Password :

Enter Password for PPTP connection

Reconnect Mode :

Always on

– A connection to Internet is always maintained.

On Demand

– A connection to Internet is made as needed.

Manual

– Click the “

Connect

” button on “

WAN Information

” in the

Overview page to connect to the Internet.

Idle Time :

Time to last before disconnecting PPPoE session when it is idle. Enter preferred Idle Time in minutes. Default is “

0

”, indicates disabled. When Idle time is disabled, the “

Reconnect Mode

” will turn out

Always on

MTU :

By default, it’s

1460

bytes. MTU stands for Maximum Transmission

Unit. Consult with WISP for a correct MTU setting.

MPPE Encryption :

Microsoft Point-to-Point Encryption (MPPE) encrypts data in Point-to-Point Protocol(PPP)-based dial-up connections or Pointto-Point Tunneling Protocol (PPTP) virtual private network (VPN) connections.

128

-

bit

key (strong) and

40

-

bit

key (standard) MPPE encryption schemes are supported. MPPE provides data security for the

PPTP connection that is between the VPN client and the VPN server.

© Copyright 2012TRENDnet. All Rights Reserved.

Keep Default MAC Address :

Keep the default MAC address of WAN port on the system.

Clone MAC Address :

If you want to clone the MAC address of the PC, then click the

Clone MAC Address

button. The system will automatically detect your

PC's MAC address.

Manual MAC Address :

Enter the MAC address registered with your ISP.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes

100

TRENDnet User’s Guide

Configure DDNS Setup

Dynamic DNS allows you to map domain name to dynamic IP address.

Please click on

System -> DDNS Setup

and follow the below setting.

TEW-676APBO

Configure LAN Setup

Here are the instructions for how to setup the local IP Address and Netmask.

Please click on

System -> LAN

and follow the below setting.

Enabled:

By default, it’s “

Disable

.

The mapping domain name won’t change when dynamic IP changes. The beauty of it is no need to remember the dynamic WAP IP while accessing to it.

Service Provider:

Select the preferred Service Provider from the drop-down list including

dyndns

,

dhs

,

ods

and

tzo

Hostname:

Host Name that you register to Dynamic-DNS service and export.

User Name & Password:

User Name and Password are used to login DDNS service.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes

© Copyright 2012TRENDnet. All Rights Reserved.

LAN IP :

The administrator can manually setup the LAN IP address.

IP Address :

The IP address of the LAN port; default IP address is

192.168.2.254

IP Netmask :

The Subnet mask of the LAN port; default Netmask is

255.255.255.0

DHCP Setup :

Devices connected to the system can obtain an IP address automatically when this service is enabled.

101

TRENDnet User’s Guide

DHCP :

Check

Enable

button to activate this function or

Disable

to deactivate this service.

Start IP / End IP:

Specify the range of IP addresses to be used by the DHCP server when assigning IP address to clients. The default range IP address is

192.168.2.10 to 192.168.2.70, the netmask is 255.255.255.0

DNS1 IP :

Enter IP address of the first DNS server; this field is required.

DNS2 IP :

Enter IP address of the second DNS server; this is optional.

WINS IP :

Enter IP address of the Windows Internet Name Service (WINS) server; this is optional.

Domain :

Enter the domain name for this network.

Lease Time :

The IP addresses given out by the DHCP server will only be valid for the duration specified by the lease time. Increasing the time ensure client operation without interruptions, but could introduce potential conflicts.

Lowering the lease time will avoid potential address conflicts, but might cause more interruptions to the client while it will acquire new IP addresses from the

DHCP server. Default is

86400

seconds

Click

Save

button to save your changes. Click

Reboot

button to activate your changes

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

Wireless LAN Network Creation

The network manager can configure related wireless settings,

General Settings,

Advanced Settings, Virtual AP(VAP) Setting, Security Settings,

and

MAC Filter Settings

.

Wireless General Setup

The administrator can change the data transmission, channel and output power settings for the system. Please click on

Wireless -> General Setup

and follow the below setting.

102

TRENDnet User’s Guide

MAC Address :

The MAC address of the Wireless interface is displayed here.

Band Mode :

Select an appropriate wireless band; bands available are

801.11a

or

802.11a/n mixed

mode.

AP Isolation :

Select

Enable

, all clients will be isolated from each VAP, that means different VAP's clients can not reach to each other.

Transmit Rate Control :

Select the desired rate from the drop-down list; the options are auto or ranging from

6

to

54Mbps

only for

802.11a

mode.

Tx Power :

You can adjust the output power of the system to get the appropriate coverage for your wireless network. Specify digit numbers between

1

to

100

(the unit is %) for your environment. If you are not sure which setting to choose, then keep the default setting,

100

%.

When

Band Mode

select in

802.11a only mode

, the

HT(High Throughput)

settings should be hidden immediately.

HT TxStream

/

RxStream :

By default, it's

2

.

Operating Mode :

By default, it's Mixed Mode.

Mixed Mode :

In this mode packets are transmitted with a preamble

 compatible with the legacy 802.11a/g, the rest of the packet has a new format.

In this mode the receiver shall be able to decode both the Mixed Mode packets and legacy packets.

Green Field :

In this mode high throughput packets are transmitted without a legacy compatible part.

Channel Bandwidth :

The "

20/40

” MHz option is usually best. The other option is available for special circumstances.

Guard Interval :

Using “

Auto

” option can increase throughput. However, it can also increase error rate in some installations, due to increased sensitivity to radiofrequency reflections. Select the option that works best for your installation.

MCS :

This parameter represents transmission rate. By default (Auto) the fastest possible transmission rate will be selected. You have the option of selecting the speed if necessary. (Refer to

Appendix C. MCS Data Rate

)

Reverse Direction Grant(RDG) :

Disable or enable reserve direction grant. Default is enabled.

A-MSDU :

Aggregated Mac Service Data Unit. Select

Enable

to allow aggregation for

 multiple MSDUs in one MPDU Default is disabled.

Auto Block ACK :

Disable or enable auto block ACK. Default is enabled.

Decline BA Request :

Disable or enable decline BA request. Default is disabled.

Change these settings as described here and click

Save

button to save your changes.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

Click

Reboot

button to activate your changes. The items in this page are for AP's RF general settings and will be applied to

all VAPs

and

WDS Links

.

Wireless Advanced Setup

To achieve optimal wireless performance, it is necessary to tweak advance setting per requirements properly, not necessary higher the better or lower.

The administrator can change the RTS threshold and fragmentation threshold settings for the system. Please click on

Wireless -> Advanced Setup

and follow the below setting.

Short Slot :

By default, it’s “

Enable

” for educing the slot time from the standard

20

microseconds

to the

9

microsecond

short slot time

Slot time is the amount of time a device waits after a collision before retransmitting a packet. Reducing the slot time decreases the overall back-off, which increases throughput. Back-off, which is a multiple of the slot time, is the random length of time a station waits before sending a packet on the LAN. For a sender and receiver own right of the channel the shorter slot time help manage shorter wait time to retransmit from collision because of hidden wireless clients or other causes. When collision sources can be removed sooner and other senders attempting to send are listening the channel(CSMA/CA) the owner of the channel should continue ownership and finish their transmission and release the channel. Then, following ownership of the channel will be sooner for the new pair due to shorter slot time.

However, when long duration of existing collision sources and shorter slot time exist

103

TRENDnet User’s Guide

 the owners might experience subsequent collisions. When adjustment to longer slot time can’t improve performance then RTS/CTS could supplement and help improve performance.

Extra Slot Time :

Slot time is in the range of

1~255

and set in unit of

microsecond

.

The default value is

9

microsecond.

ACK Timeout :

ACK timeout is in the range of

1~255

and set in unit of

microsecond

.

The default value is

32

microsecond.

All data transmission in 802.11b/g request an “Acknowledgement” (ACK) send by receiving radio. The transmitter will resend the original packet if correspondent ACK failed to arrive within specific time interval, also refer to as “ACK Timeout”.

ACK Timeout is adjustable due to the fact that distance between two radio links may vary in different deployment. ACK Timeout makes significant influence in performance of long distance radio link. If ACK Timeout is set too short, transmitter will start to “Resend” packet before ACK is received, and throughputs become low due to excessively high re-transmission.

ACK Timeout is best determined by distance between the radios, data rate of average environment. The Timeout value is calculated based on round-trip time of packet with a little tolerance, So, if experiencing re-transmissions or poor performance the ACK Timeout could be made longer to accommodate.

Beacon Interval :

Beacon Interval is in the range of

20

~

1024

and set in unit of

millisecond

. The default value is

100

msec.

Access Point (AP) in IEEE 802.11 will send out a special approximated 50-byte frame, called “Beacon”. Beacon is broadcast to all the stations, provides the basic information of AP such as SSID, channel, encryption keys, signal strength, time stamp, support data rate.

All the radio stations received beacon recognizes the existence of such AP, and may proceed next actions if the information from AP matches the requirement. Beacon is sent on a periodic basis, the time interval can be adjusted.

By increasing the beacon interval, you can reduce the number of beacons and associated overhead, but that will likely delay the association and roaming process because stations scanning for available access points may miss the beacons. You can decrease the beacon interval, which increases the rate of beacons. This will make the association and roaming process very responsive; however, the network will incur additional overhead and throughput will go down.

DTIM Interval :

The DTIM interval is in the range of

1

~

255

. The default is

1

.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

DTIM is defined as

Delivery Traffic Indication Message

. It is used to notify the wireless stations, which support power saving mode, when to wake up to receive multicast frame. DTIM is necessary and critical in wireless environment as a mechanism to fulfill power-saving synchronization.

A DTIM interval is a count of the number of beacon frames that must occur before the access point sends the buffered multicast frames. For instance, if DTIM Interval is set to 3, then the Wi-Fi clients will expect to receive a multicast frame after receiving three Beacon frame. The higher DTIM interval will help power saving and possibly decrease wireless throughput in multicast applications.

Fragment Threshold :

The Fragment Threshold is in the range of

256

~

2346

byte.

The default is

2346

byte.

Each Wi-Fi packet can be divided into smaller packets, marked with a sequential fragment number and re-assemble in the receiving ends. The purpose is to make a short frame, instead of long frame, transmitting by radio in a heavy noisy environment. Because of sending smaller frames, corruptions are much less likely to occur. The pros is obvious, the cons is the overhead for transmission. So, in a clean environment, higher fragment threshold can be an option to increase throughput.

Fragmentation will be triggered by setting the Fragment Threshold, usually in Bytelength. Only when the frame size is over the Threshold, fragmentation will take place automatically.

RTS Threshold :

TRTS Threshold is in the range of

1~2347

byte. The default is

2347

byte.

The main purpose of enabling RTS by changing RTS threshold is to reduce possible collisions due to hidden wireless clients. RTS in AP will be enabled automatically if the packet size is larger than the Threshold value. By default, RTS is disabled in a normal environment supports non-jumbo frames.

Short Preamble :

By default, it’s “

Enable

”. To

Disable

is to use Long 128-bit

Preamble Synchronization field.

The preamble is used to signal "here is a train of data coming" to the receiver. The short preamble provides 72-bit Synchronization field to improve WLAN transmission efficiency with less overhead.

Tx Burst :

By default, it’s “

Enable

”. To

Disable

is to deactivate Tx Burst.

With TX burst enabled, AP will send many packets in a burst, without collision detection and RTS/CTS for each packet. TX Burst have better throughput but cause interference with other APs in channel.

104

TRENDnet User’s Guide

Pkt_Aggregate :

By default, it's “

Enable

Increase efficiency by aggregating multiple packets of application data into a single transmission frame. In this way, 802.11n networks can send multiple data packets

Priority Description

AC_BK

AC_BE

AC_VI

Background.

Best Effort

Video

Low

Medium

High

High throughput. Bulk data that requires maximum throughput and is not time-sensitive is sent to this queue (FTP data, for example).

Medium throughput and delay.

Most traditional IP data is sent to this queue

Minimum delay. Time-sensitive video data is automatically sent to this queue

AC_VO Voice High

Time-sensitive data like VoIP and streaming media are automatically sent to this queue with the fixed overhead cost of just a single frame.

WMM :

By default, it's “

Disable

”. To

Enable

is to use WMM and the WMM parameters should appears.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

WMM Parameters of Access Point :

This affects traffic flowing from the access point to the client station

Configuring QoS options consists of setting parameters on existing queues for different types of wireless traffic. You can configure different minimum and maximum wait times for the transmission of packets in each queue based on the requirements of the media being sent. Queues automatically provide minimum transmission delay for Voice, Video, multimedia, and mission critical applications, and rely on best-effort parameters for traditional IP data.

As an Example, time-sensitive Voice & Video, and multimedia are given effectively higher priority for transmission (lower wait times for channel access), while other applications and traditional IP data which are less timesensitive but often more data-intensive are expected to tolerate longer wait times.

Aifsn

: The Arbitration Inter-Frame Spacing Number specifies a wait time

(in milliseconds) for data frames

CWmin

: Minimum Contention Window. This parameter is input to the algorithm that determines the initial random backoff wait time

("window") for retry of a transmission. The value specified here in the

Minimum Contention Window is the upper limit (in milliseconds) of a range from which the initial random backoff wait time is determined.

CWmax

: Maximum Contention Window. The value specified here in the

105

TRENDnet User’s Guide

Maximum Contention Window is the upper limit (in milliseconds) for the doubling of the random backoff value. This doubling continues until either the data frame is sent or the Maximum Contention Window size is reached. Once the Maximum Contention Window size is reached, retries will continue until a maximum number of retries allowed is reached. Valid values for the "cwmax" are 1, 3, 7, 15, 31, 63, 127, 255, 511, or 1024. The value for "cwmax" must be higher than the value for "cwmin".

Txop

: Transmission Opportunity is an interval of time when a WME AP has the right to initiate transmissions onto the wireless medium (WM).

This value specifies (in milliseconds) the Transmission Opportunity (TXOP) for AP; that is, the interval of time when the WMM AP has the right to initiate transmissions on the wireless network.

ACM :

Admission Control Mandatory, ACM only takes effect on AC_VI and

AC_VO. When you do not click Checkbox, it means that the ACM is controlled by the connecting AP. If you click Checkbox, it means that the

Client is in charge.

AckPolicy :

Acknowledgment Policy, WMM defines two ACK policies:

Normal ACK

and

No ACK

. Click “

Checkbox

” indicates “

No ACK

When the no acknowledgment (No ACK) policy is used, the recipient does not acknowledge received packets during wireless packet exchange. This policy is suitable in the environment where communication quality is fine and interference is weak. While the No ACK policy helps improve transmission efficiency, it can cause increased packet loss when communication quality deteriorates. This is because when this policy is used, a sender does not retransmit packets that have not been received by the recipient.

When the Normal ACK policy is used, the recipient acknowledges each received unicast packet.

WMM Parameters of Station :

This affects traffic flowing from the client station to the access point.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

Queue

Data

Transmitted

Clients to AP

Priority Description

AC_BK Background. Low

High throughput. Bulk data that requires maximum throughput and is not time-sensitive is sent to this queue (FTP data, for example).

AC_BE Best Effort Medium Medium throughput and delay. Most traditional IP

AC_VI Video

AC_VO Voice

Aifsn

: The Arbitration Inter-Frame Spacing Number specifies a wait time

(in milliseconds) for data frames

CWmin

: Minimum Contention Window. This parameter is input to the algorithm that determines the initial random backoff wait time

("window") for retry of a transmission. The value specified here in the

Minimum Contention Window is the upper limit (in milliseconds) of a range from which the initial random backoff wait time is determined.

CWmax

: Maximum Contention Window. The value specified here in the

Maximum Contention Window is the upper limit (in milliseconds) for the doubling of the random backoff value. This doubling continues until either the data frame is sent or the Maximum Contention Window size is reached. Once the Maximum Contention Window size is reached, retries will continue until a maximum number of retries allowed is reached. Valid values for the "cwmax" are 1, 3, 7, 15, 31, 63, 127, 255, 511, or 1024. The value for "cwmax" must be higher than the value for "cwmin".

Txop

: Transmission Opportunity is an interval of time when a WME AP has the right to initiate transmissions onto the wireless medium (WM).

This value specifies (in milliseconds) the Transmission Opportunity (Txop) for AP; that is, the interval of time when the WMM AP has the right to initiate transmissions on the wireless network.

ACM :

Admission Control Mandatory, ACM only takes effect on AC_VI and

AC_VO. When you do not click Checkbox, it means that the ACM is controlled by the connecting AP. If you click Checkbox, it means that the

Client is in charge.

106

TRENDnet User’s Guide

Click

Save

button to save your changes. Click

Reboot

button to activate your changes.

The items in this page are for AP's RF advanced settings and will be applied to

all VAPs

and

WDS Links

.

Create Virtual AP (VAP)

The TEW-676APBO support broadcasting multiple SSIDs, allowing the creation of Virtual

Access Points, partitioning a single physical access point into

7

logical access points, each of which can have a different set of security and network settings.

Figure 8-2

shows multiple SSIDs with security type settings.

WEP

NAT

WPA-PSK/TKIP

WPA2-PSK/AES

WPA-Enterprise/TKIP

WAN WAN

Multiple SSIDs with different Security Type

Virtual AP Overview

The administrator can view all of the Virtual AP's settings via this page.

Please click on

Wireless -> Virtual AP Setup

and the Virtual AP Overview Page appears.

TEW-676APBO

VAP :

Indicate the system's Virtual AP.

ESSID :

Indicate the ESSID of the respective Virtual AP

MAC Address :

The MAC address of the VAP Interface is displayed here. When you enable AP and reboot system, the MAC address will display here.

Status :

Indicate the Status of the respective Virtual AP. The

Primary AP

always on.

Security Type :

Indicate an used security type of the respective Virtual AP.

MAC Filter :

Indicate an used MAC filter of the respective Virtual AP.

Edit :

Click

Edit

button to configure Virtual AP's settings, including security type and

MAC Filter.

© Copyright 2012TRENDnet. All Rights Reserved.

107

TRENDnet User’s Guide

Virtual AP Setup

For each Virtual AP, administrators can configure SSID, SSID broadcasting, Maximum number of client associations, security type settings.

Click

Edit

button on the Edit column, and then a Virtual AP setup page appears.

Enable AP :

By default, it’s “

Disable

” for VAP1 ~ VAP6.

The Primary AP always enabled

.

Select “

Enable

” to activate VAP or click “

Disable

” to deactivate this function

ESSID :

Extended Service Set ID, When clients are browsing for available wireless networks, this is the SSID that will appear in the list. ESSID will determine the service type available to AP's clients associated with the specified VAP.

Client Isolation :

Select

Enable

, all clients will be isolated from each other, that means all clients can not reach to other clients. Below Figures depict Client Isolation and AP Isolation

© Copyright 2012TRENDnet. All Rights Reserved.

VAP0

TEW-676APBO

Hidden SSID :

By default, it’s “

Disable

.

Enable this option to stop the SSID broadcast in your network. When disabled, people could easily obtain the SSID information with the site survey software and get access to the network if security is not turned on. When enabled, network security is enhanced. It’s suggested to enable it after AP security settings are archived and setting of AP clients could make to associate to it.

Maximum Clients :

The default value is

32

. You can enter the number of wireless clients that can associate to a particular SSID. When the number of client is set to 5, only 5 clients at most are allowed to connect to this VAP.

VAP1

VAP2

Cllent Isolation

AP Isolation

108

TRENDnet User’s Guide

Security Type :

Select the desired security type from the drop-down list; the options are

Disable

,

WEP

,

WPA-PSK

,

WPA2-PSK

,

WPA-Enterprise

,

WPA2-Enterprise

and

WEP 802.1X

.

Disable :

Data are unencrypted during transmission when this option is

 selected.

WEP :

Wired Equivalent Privacy(WEP) is a data encryption mechanism based on a 64-bit or 128-bit shared key.

TEW-676APBO

Cipher Suite :

By default, it is

AES

. Select either AES or TKIP cipher suites

Pre-shared Key :

Enter the pre-shared key; the format shall go with the selected key type.

Group Key Update Period :

By default, it is

3600

seconds. This time interval for rekeying GTK, broadcast/multicast encryption keys, in seconds. Entering the time-length is required.

WPA-Enterprise (or WPA2-Enterprise):

The RADIUS authentication and encryption will be both enabled if this is selected.

Authentication Method :

Enable the desire option among

OPEN

,

SHARED

or

WEPAUTO

.

Key Index : Key index is used to designate the WEP key during data transmission. 4 different WEP keys can be entered at the same time, but only

 one is chosen.

WEP Key # :

Enter

HEX

or

ASCII

format WEP key value; the system supports up to 4 sets of WEP keys.

Key Length

64-bit

128-bit

Hex

10 characters

26 characters

ASCII

5 characters

13 characters

WPA-PSK (or WPA2-PSK) :

WPA (or WPA2) Algorithms, allows the system accessing the network by using the WPA-PSK protected access.

© Copyright 2012TRENDnet. All Rights Reserved.

WPA General Settings :

Cipher Suite :

By default, it is AES. Select either AES or TKIP cipher

• suites

Group Key Update Period :

By default, it’s

3600

seconds. This time interval for rekeying GTK, broadcast/multicast encryption keys, in seconds. Entering the time-length is required.

PMK Cache Period :

By default, it's 10 minutes. Set

WPA2

PMKID cache timeout period, after time out, the cached key will be deleted.

Pre-Authentication :

By default, it's “Disable”. To Enable is use to speed up roaming before pre-authenticating IEEE 802.1X/EAP part of the full RSN authentication and key handshake before actually associating with a new AP.

Radius Server Settings :

IP Address :

Enter the IP address of the Authentication RADIUS

109

TRENDnet User’s Guide

• server.

Port :

By default, it’s

1812

.

The port number used to communicate with RADIUS server.

Shared secret :

A secret key used between system and RADIUS server. Supports

8

to

64

characters.

Session Timeout :

The Session timeout is in the range of

0

~

60

seconds

. The default is

0

to disable re-authenticate service.

Amount of time before a client will be required to re-authenticate.

WEP 802.1X :

When WEP 802.1x Authentication is enabled, please refer to the following Dynamic WEP and RADIUS settings to complete configuration.

TEW-676APBO

Wireless MAC Filter Setup

Continue

Virtual AP Setup

section. For each Virtual AP setting, the administrator can allow or reject clients to access each Virtual AP.

Radius Server Settings :

IP Address :

Enter the IP address of the Authentication RADIUS server.

Port :

By default, it’s

1812

.

The port number used to communicate with RADIUS server.

Shared secret :

A secret key used between system and RADIUS server. Supports

8

to

64

characters.

Session Timeout :

The Session timeout is in the range of

0

~

60

seconds

. The default is

0

to disable re-authenticate service.

Amount of time before a client will be required to re-authenticate.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes

© Copyright 2012TRENDnet. All Rights Reserved.

MAC Filter Setup :

By default, it’s “

Disable

”. Options are

Disable, Only Deny List

MAC or Only Allow List MAC

.

Two ways to set MAC filter rules :

Only Allow List MAC

.

The wireless clients in the “

Enable

” list will be

allowed

to access the Access Point;

All others or clients in the “

Disable

” list will be

denied

.

Only Deny List MAC

.

The wireless clients in the “

Enable

” list will be

denied

to access the Access Point; All others or clients in the “

Disable

” list will be

allowed

.

Add a station MAC :

Enter MAC address (e.g. aa:bb:cc:00:00:0a) and click “

Add

” button, then the MAC address should display in the “

Enable

” List.

There are a maximum of

20

clients allowed in this “Enable” List. The MAC addresses of the wireless clients can be added and removed to the list using the

Add

and

Remove

buttons

.

Click

Reboot

button to activate your changes

110

TRENDnet User’s Guide

Wireless Network Expansion

The administrator could create WDS Links to expand wireless network. When WDS is enabled, access point functions as a wireless bridge and is able to communicate with other access points via WDS links.

A WDS link is bidirectional and both side must support WDS. Access points know each other by MAC Address. In other words, each access point needs to include MAC address of its peer. Ensure all access points are configured with the same channel and own same security type settings.

Remote Bass Station

WDS

WAN WLAN

Please click on

Wireless -> WDS Setup

and follow the below setting.

TEW-676APBO

Security Type :

Option is “

Disable

”, “

WEP

”, “

TKIP

”or “

AES

” from drop-down list.

Needs the same type to build WDS links. Security type takes effect when WDS is enabled.

WEP Key :

Enter

5 / 13 ASCII

or

10 / 26 HEX

format WEP key.

TKIP Key :

Enter

8

to

63 ASCII

or

64 HEX

format TKIP key.

AES Key :

Enter

8

to

63 ASCII

or

64 HEX

format AES key.

WDS MAC List

Enable :

Click

Enable

to create WDS link.

WDS Peer's MAC Address :

Enter the MAC address of WDS peer.

Description :

Description of WDS link.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes

The

System Overview

page appears upon the completion of reboot.

© Copyright 2012TRENDnet. All Rights Reserved.

111

TRENDnet User’s Guide

Access Control List

IP Filter Setup

Allows to create deny or allow rules to filter ingress or egress packets from specific source and/or to destination IP address on wired (LAN) or Wireless (WAN) ports. Filter rules could be used to filter unicast or multicast packets on different protocols as shown in the IP Filter Setup. Important to note that IP filter rules has precedence over Virtual server rules.

Please click on

Advance -> IP Filter Setup

and follow the below setting.

TEW-676APBO

Listen :

Click

Yes

radial button to match TCP packets only with the SYN flag.

Active :

Deny

to drop and

Pass

to allow per filter rules

Interface :

The interface that a filter rule applies

Click “

Save

” button to add IP filter rule. Total of

20

rules maximum allowed in the IP

Filter List. All rules can be edited or removed from the List. Click

Reboot

button to activate your changes.

When you create rules in the IP Filter List, the prior rules maintain higher priority. To allow limited access from a subnet to a destination network manager needs to create allow rules first and followed by deny rules. So, if you just want one IP address to access the system via telnet from your subnet, not others, the Example 1 demonstrates it, not rules in the Example 2.

Example 1 :

Create a higher priority rule to allow IP address 192.168.2.2 Telnet access from LAN port first, and deny Telnet access from remaining IP addresses in the same subnet.

Example 2 :

All Telnet access to the system from the IP addresses of subnet

192.168.2.x works with the rule 1 of Example 2. The rule 2 won’t make any difference.

Source Address/Mask :

Enter desired source IP address and netmask; i.e.

192.168.2.10/32.

Source Port :

Enter a port or a range of ports as

start:end

; i.e. port 20:80

Destination Address/Mask :

Enter desired destination IP address and netmask; i.e.

192.168.1.10/32

Destination Port :

Enter a port or a range of ports as

start:end

; i.e. port 20:80

In/Out :

Applies to Ingress or egress packets

Protocol :

Supports

TCP

,

UDP

or

ICMP

.

© Copyright 2012TRENDnet. All Rights Reserved.

112

TRENDnet User’s Guide

MAC Filter Setup

Allows to create MAC filter rules to allow or deny unicast or multicast packets from limited number of MAC addresses. Note, the MAC filter rules have precedence over IP

Filter rules.

Please click on

Advance -> MAC Filter Setup

and follow the below setting.

TEW-676APBO

Parental Control Setup

Parental Control allows you to block or allow specific kinds of Internet usage and traffic, such as Internet access, designated services, and websites.

Station

NAT

WDS

WAN

SSID:

MSN

WLAN

Please click on

Advance -> Parental Control

and follow the below setting.

MAC Filter Rule :

By default, it’s “

Disable

”. Options are

Disabled

,

Only Deny List

MAC

or

Only Allow List MAC

. Click

Save

button to save your change.

Two ways to set the MAC Filter List:

Only Allow List MAC

.

The wireless clients in the MAC Filter List will be

allowed

to access to Access Point;

All others will be denied.

Only Deny List MAC

.

The wireless clients in the MAC Filter List will be

denied

to access to Access Point;

All others will be allowed.

MAC Address :

Enter MAC address (e.g. aa:bb:cc:00:00:0a) and click “

Add

” button, then the MAC address should display in the MAC Filter List.

There are a maximum of

20

clients allowed in this MAC Filter List. The MAC addresses of the wireless clients can be added and removed to the list using the

Add

and

Delete

buttons

.

Click

Reboot

button to activate your changes

© Copyright 2012TRENDnet. All Rights Reserved.

113

TRENDnet User’s Guide

TEW-676APBO

Application

) from drop-down list. When you select

ICMP

or

Layer 7

Application

, the Local(LAN)/ Destination Port can not used.

If you want to block websites with specific URL address or using specific keywords, enter each URL or keyworks in the “

URL Blocking

” field and click

Add

” button to add in the URL Blocking list of each rule. Click “

Remove

” button can remove URL or keywords.

Rules :

control can be managed by a rule. Use the settings on this screen to establish an access policy.

Comment :

Enter a descriptive name for this rule for identifying purposes.

MAC Address :

Enter MAC address in valid MAC address

 format(xx:xx:xx:xx:xx:xx) and click “

Add

” button to add in the MAC group of each rule. Click “

Remove

” button can remove MAC address in the group of each rule. There are

10

MAC address maximum allowed in each rule.

Local / Destination IP :

Specify local(LAN)/ destination IP addresses range required for this rule. If you specify local IP addresses range from 192.168.1.1 to 192.168.2.254. The matches a range of local IP addresses include every single IP address from the first to the last, so the example above includes everything from 192.168.1.1 to 192.168.2.254.

Protocol :

Select

Any

or specify protocol(

TCP

,

UDP

,

ICMP

,

URL Blocking

and

© Copyright 2012TRENDnet. All Rights Reserved.

Local Port :

Specify local port(LAN port) range required for this rule

Destination Port :

Specify destination port range required for this rule

Active :

Check

Enable

button to activate this rule, and

Disable

to deactivate.

Click “

Add

” button to add control rule to List. There are

10

rules maximum allowed in this Control List. All rules can be removed or edited on the List. Click

Reboot

button to activate your changes.

114

TRENDnet User’s Guide

QoS Setup

Quality of Service (QoS) refers to both a network's ability to deliver data with minimum delay, and the networking methods used to control the use of bandwidth. Without QoS, all traffic data is equally likely to be dropped when the network is congested. This can cause a reduction in network performance and make the network inadequate for timecritical application such as video-on-demand.

A classifier groups traffic into data flows according to specific criteria such as the source address, destination address, source port number, destination port number or incoming port number. For example, you can configure a classifier to select traffic from the same protocol port (such as FTP) to form a flow.

Shaping

WAN

Download: 1024K

Upload: 256K

Download: 512K

Upload: 256K

Download: 2048K

Upload: 1024K

192.168.1.254

LAN

NAT

Please click on

Advance -> QoS

and follow the below setting.

© Copyright 2012TRENDnet. All Rights Reserved.

Remote Bass

Station

WDS

TEW-676APBO

Down: 1024Kbps

Up: 512Kbps

SSID: Main_AP

WAN

NAT

WLAN

Down: 2048Kbps

Up: 1024Kbps

115

TRENDnet User’s Guide

Rules :

Use the rules to define the classifiers. After you define the rules, you can specify action to act upon the traffic that matches the rules

Comment :

Enter a descriptive name for this rule for identifying purposes.

MAC Address :

Enter MAC address in valid MAC address format(xx:xx:xx:xx:xx:xx) and click “

Add

” button to add in the MAC group of

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

 each rule. Click “

Remove

” button can remove MAC address in the group of each rule. There are

10

MAC address maximum allowed in each rule.

Local / Destination IP :

Specify local(LAN)/ destination IP addresses range required for this rule. If you specify local IP addresses range from 192.168.1.1 to 192.168.2.254. The matches a range of local IP addresses include every single IP address from the first to the last, so the example above includes everything from 192.168.1.1 to 192.168.2.254.

DSCP Class

: Differentiated services code point, DSCP. Select Any or specify classify traffic from drop-down list.

The Per-Hop Behavior (PHB) is indicated by encoding a 6-bit value—called the

Differentiated Services Code Point (DSCP)—into the 8-bit Differentiated

Services (DS) field of the IP packet header. Below depicts class for DSCP.

BE :

Default

PHB, which is typically best-effort traffic

EF :

Expedited Forwarding

PHB, dedicated to low-loss, low-latency traffic

AF :

Assured Forwarding

PHB, which gives assurance of delivery under conditions. The AF behavior group defines four separate AF classes.

Within each class, packets are given a drop precedence (high, medium or low). The combination of classes and drop precedence yields twelve separate DSCP encodings from

AF11

through

AF43

(see table)

DROP Precedence

Low Drop

Class 1

AF11

Class 2

AF21

Class 3

AF31

Class 4

AF41

Medium Drop

AF12 AF22 AF32 AF42

High Drop

AF13 AF23 AF33 AF43

Protocol :

Select

Any

or specify protocol from drop-down list. When you select

ICMP

or

Layer 7 Application

, the Source/ Destination Port can not used.

Local Port :

Specify local port(LAN port) range required for this rule

Destination Port :

Specify destination port range required for this rule

Action :

After configuring rule, a policy rule ensures that a traffic flow gets the requested treatment in the network.

Remark DSCP :

Specify a new DSCP class, if you want to replace or remark the

DSCP

Bandwidth :

Click “

Enable

” to activate function, and click “

Disable

” to deactivate function

Upload / Download :

Specify the bandwidth in kilobit per second (Kbps). Enter

116

TRENDnet User’s Guide

a number between

8

to

8192

, default upload is

128

Kbps, download is

1024

Kbps.

Click “

Add

” button to add QoS rule to List. There are

10

rules maximum allowed in this

QoS List. All rules can be removed or edited on the List. Click

Reboot

button to activate your changes.

When you create rules on the QoS List, the previous rules have higher priority. . Below depict the examples for explaining priority of QoS setup.

Example 1 :

On this setting, the FTP has

1024

Kbps upload and

8196

Kbps download on

192.168.2.10

. The remaining IP address and other remaining protocol of IP address 192.168.2.10 only can use total bandwidth

512

Kbps bandwidth. Because rule 1's priority is higher than rule 2

Example 2 :

On this setting, the FTP has

512

Kbps upload and

512

Kbps download on

192.168.2.10

Because rule 1's priority is higher than rule 2

Resource Sharing

DMZ

DMZ is commonly work with the NAT functionality as an alternative of Virtual

Server(Port Forwarding

)

while wanting all ports of DMZ host visible to Internet users.

Virtual Server rules have precedence over the DMZ rule. In order to use a range of ports available to access to different internal hosts Virtual Server rules are needed.

Remote Bass

WDS

SSID:

192..2.x

DMZ

WAN

NAT

WLAN

Please click on

Advance -> DMZ

and follow the below setting.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

DMZ :

By default, it’s

Disable

”.

Check

Enable

radial button to enable DMZ.

IP Address :

Enter IP address of DMZ host and only one DMZ host is supported.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes.

Virtual Server (Port Forwarding)

“Virtual Server” can also referred to as “Port Forward” as well and used interchangeably.

Resources in the network can be exposed to the Internet users in a controlled manner including on-line gaming, video conferencing or others via Virtual Server setup. Don’t repeat ports’ usage to avoid confusion.

Suppose you want to assign ports 21-25 to one FTP, Telnet and SMTP server (A in the example), and port 80 to another (B in the example). You assign the LAN IP addresses and the ISP assigns the WAN IP address. The NAT network appears as a single host on the Internet.

Remote Bass

WDS

SSID:

B

WAN

A

NAT

WLAN

117

TRENDnet User’s Guide

Please click on

Advance -> Virtual Server

and follow the below setting.

TEW-676APBO

remaining connections to port TCP

20~80

will be redirected to port TCP

20~80

of

192.168.2.11

Example 2 :

All connections should be redirected to

192.168.2.12

while DMZ is enabled. Since Virtual Server rules have precedence over the DMZ rule all other connections to TCP port

20~80

will be redirected to port

20~80

of

192.168.2.11

.

The rule 2 won’t take effect.

System Status

This section breaks down into subsections of

System Overview

,

Associated Clients

Status

,

WDS Link Status

,

Extra Information

and

Event Log

.

Overview

Detailed information on

System

,

WAN Information

,

LAN Information

,

Wireless

Information

and

DHCP Server Status

can be reviewed via this page.

System :

Display the information of the system.

Virtual Server :

By Default, It’s “

Disable

.

Check

Enable

radial button to enable

Virtual Server.

Description :

Enter appropriate message for resource sharing via Virtual Server.

Private IP :

Enter corresponding IP address of internal resource to share.

Protocol Type :

Select appropriate sessions, TCP or UDP, from shared host via multiple private ports.

Private Port :

A port or a range of ports may be specified as

start:end

; i.e. port

20:80

Public Port :

A port or a range of ports may be specified as

start:end

; i.e. port 20:80

Click “

Add

” button to add Virtual Server rule to List. Total of maximum

20

rules are allowed in this List. All rules can be edited or removed from the List. Click

Reboot

button to activate your changes.

While creating multiple Virtual Server rules, the prior rules have higher priority. The

Virtual server rules have precedence over the DMZ one while both rules exist. Example 1 and 2 demonstrate proper usage of DMZ and Virtual Server rules.

Example 1 :

All connections should be redirected to

192.168.2.12

while DMZ is enabled. Since Virtual Server rules have precedence over the DMZ rule all connections to TCP port 22 will be directed to TCP port 22 of 192.168.2.10 and

© Copyright 2012TRENDnet. All Rights Reserved.

System Name :

The name of the system.

Operating Mode :

The mode currently in service.

Location :

The reminding note on the geographical location of the system.

Description :

The reminding note of the system.

Firmware Version :

The current firmware version installed.

Firmware Date :

The build time of the firmware installed.

Device Time :

The current time of the system.

System Up Time :

The time period that system has been in service since last reboot.

118

TRENDnet User’s Guide

WAN Information :

Display the information of the WAN interface.

TEW-676APBO

MAC Address :

The MAC address of the WAN port.

IP Address :

The IP address of the WAN port.

IP Netmask :

The IP netmask of the WAN port.

IP Gateway :

The gateway IP address of the WAN port.

Primary DNS :

The primary DNS server in service.

Secondary DNS :

The secondary DNS server in service.

Receive bytes :

The total received packets in bytes on the WAN port.

Receive packets :

The total received packets of the WAN port.

Transmit bytes :

The total transmitted packets in bytes of the WAN port.

Transmit packets :

The total transmitted packets of the WAN port.

LAN Information :

Display total received and transmitted statistics on the LAN interface.

The WAN port specified

Dynamic IP

, the Release and Renew button will be showup, click

Release

button to release IP address of WAN port,

Renew

button to renew

IP address through DHCP server.

The WAN port specified

PPPoE

or

PPTP

, and the

Connect

and

DisConnect

button will be show up. Click “

Connect

” button to assigned IP address from PPPoE or PPTP server, “

DisConnect

” button to release IP address of WAN port.

MAC Address :

The MAC address of the LAN port.

IP Address :

The IP address of the LAN port.

IP Netmask :

The IP netmask of the LAN port.

Receive bytes :

The total received packets in bytes on the LAN port.

Receive packets :

The total received packets of the LAN port.

Transmit bytes :

The total transmitted packets in bytes of the LAN port.

Transmit packets :

The total transmitted packets of the LAN port.

Wireless Information :

Display the detailed receive and transmit statistics of

Wireless interface.

Mode :

Supports Static, Dynamic, PPPoE and PPTP modes.

Reconnect Mode :

The current reconnect mode of the PPPoE or PPTP.

© Copyright 2012TRENDnet. All Rights Reserved.

119

TRENDnet User’s Guide

TEW-676APBO

Associated Clients

It displays ESSID, on/off Status, Security Type, total number of wireless clients associated with all Virtual AP.

MAC Address :

The MAC address of the Wireless Port.

Channel :

The current channel on the Wireless port.

Rate :

The current Bit Rate on the Wireless port.

Receive bytes :

The total received packets in bytes on the Wireless port.

Receive packets :

The total received packets on the Wireless port.

Transmit bytes :

The total transmitted packets in bytes on the Wireless port.

Transmit packets :

The total transmitted packets on the Wireless port.

DHCP Server Status :

Users could retrieve DHCP server and DHCP clients’ IP/MAC address via this field.

IP Address :

IP addresses to LAN devices by DHCP server.

MAC Address :

MAC addresses of LAN devices.

Expired In :

Shows how long the leased IP address will expire.

© Copyright 2012TRENDnet. All Rights Reserved.

VAP Information :

Highlights key VAP information.

VAP :

Available VAP from Primary AP to VAP6.

ESSID :

Display name of ESSID for each VAP.

MAC Address :

Display MAC address for each VAP.

Status :

On/Off

Security Type :

Display chosen security type; WEP, WPA/WPA2-PSK,

WPA/WPA2-Enterprise.

Clients :

Display total number of wireless connections for each VAP.

VAP Clients :

Display all associated clients on each Virtual AP.

MAC Address :

MAC address of associated clients

Signal Strength ANT0/ANT1 :

Signal Strength of from associated clients.

Bandwidth :

Channel bandwidth of from associated clients

Idle Time :

Last inactive time period in seconds for a wireless connection.

Connect Time :

Total connection time period in seconds for a wireless

 connection.

Disconnect :

Click “

Delete

” button to manually disconnect a wireless client in a

Virtual AP.

120

TRENDnet User’s Guide

Show WDS Link

Peers MAC Address, antenna 0/1 received signal strength, phy mode and channel bandwidth for each WDS are available.

TEW-676APBO

Extra Info

Users could pull out information such as Route table, ARP table, MAC table, Bridge table or STP available in the drop-down list from system. The “Refresh” button is used to retrieve latest table information.

MAC Address :

Display MAC address of WDS peer.

Signal Strength ANT0/ANT1 :

Indicate the signal strength of the respective WDS links.

Phy Mode :

Indicate the phy mode of the respective WDS linked.

BandWidth :

Indicate the channel bandwidth of the respective WDS linked.

MCS :

Indicate the MCS of the respective WDS linked.

SGI :

Indicate the SGI (Short Guard Interval) of the respective WDS linked. “1” indicate the Short Guard Interval, “0” indicate the Long Guard Interval.

© Copyright 2012TRENDnet. All Rights Reserved.

121

TRENDnet User’s Guide

Netstat Information :

Select “

NetStatus Information

” on the drop-down list, the connection track list should show-up, the list can be updated using the Refresh button.

NetStatus will show all connection track on the system, the information include

Protocol

,

Live Time

,

Status

,

Source/Destination IP address

and

Port

.

Route table information :

Select “

Route table information

” on the drop-down list to display route table.

TEW-676APBO could be used as a L2 or L3 device. It doesn’t support dynamic routing protocols such as RIP or OSPF. Static routes to specific hosts, networks or default gateway are set up automatically according to the IP configuration of system's interfaces. When used as a L2 device, it could switch packets and, as L3 device, it’s capable of being a gateway to route packets inward and outward.

ARP table Information :

Select “

ARP Table Information

” on the drop-down list to display ARP table.

ARP associates each IP address to a unique hardware address (MAC) of a device. It is important to have a unique IP address as final destination to switch packets to.

TEW-676APBO

Bridge MAC information :

Select “

Bridge MACs Information

” on the drop-down list to display MAC table.

This table displays local MAC addresses associated with wired or wireless interfaces, but also remember non-local MAC addresses learned from wired or wireless interfaces.

Ageing timers will be reset when existing MAC addresses in table are learned again or added when new MAC addresses are seen from wired or wireless interfaces as well. When time runs out for a particular entry, it will be pruned from the table. In that situation, switching packet to that particular MAC address will be discontinued.

Bridge STP Information :

Select “

Bridge STP Information

” on the drop-down list to display a list of bridge STP information.

Bridge table information :

Select “

Bridge Table information

” on the drop-down list to display bridge table.

Bridge table will show Bridge ID and STP's Status on the each Ethernet bridge and its attached interfaces, the Bridge Port should be attached to some interfaces e.g. ra0 ~ra6 and wds0~wds3).

© Copyright 2012TRENDnet. All Rights Reserved.

122

TRENDnet User’s Guide

QoS Plot

The QoS Plot show graphs which continuously represents the current data traffic on each QoS rule. The chart scale and throughput dimension (bps, Kbps, Mbps) changes dynamically according to the mean throughput value. The statistics is updated automatically every 5 seconds. The throughput statistics of QoS can be updated manually using the

Refresh

button.

TEW-676APBO

System Management

Configure Management

Administrator could specify geographical location of the system via instructions in this page. Administrator could also enter new Root and Admin passwords and allow multiple login methods.

Please click

System -> Management

and follow the below settings.

Event Log

The Event log displays system events when system is up and running. Also, it becomes very useful as a troubleshooting tool when issues are experienced in system.

Time :

The date and time when the event occurred.

Facility :

It helps users to identify source of events such “System” or “User”

Severity :

Severity level that a specific event is associated such as “info”, “error”,

“warning”, etc.

Message :

Description of the event.

Click

Refresh

button to renew the log, or click

Clear

button to clear all the record.

© Copyright 2012TRENDnet. All Rights Reserved.

123

TRENDnet User’s Guide

System Information

System Name :

Enter a desired name or use the default one.

Description :

Provide description of the system.

Location :

Enter geographical location information of the system. It helps administrator to locate the system easier.

The system supports

two

management accounts, root and admin. The network manager is assigned with full administrative privileges, when logging in as

root

user, to manage the system in all aspects. While logging in as an

admin

user, only subset of privileges is granted such as basic maintenance. For example, root user can change passwords for both root and admin account, and admin user can only manage its own. For more information about covered privileges for these two accounts, please refer to

Appendix

D. Network manager Privileges

.

Root Password :

Log in as a root user and is allowed to change its own, plus admin user’s password.

New Password :

Enter a new password if desired

Check New Password :

Enter the same new password again to check.

Admin Password :

Log in as a admin user and is allowed to change its own,

New Password :

Enter a new password if desired

Check New Password :

Enter the same new password again to check.

Admin Login Methods :

Only

root

user can enable or disable system login methods and change services port.

Enable HTTP :

Check to select HTTP Service.

HTTP Port :

The default is 80 and the range is between 1 ~ 65535.

Enable HTTPS :

Check to select HTTPS Service

HTTPS Port :

The default is 443 and the range is between 1 ~ 65535.

Enable Telnet :

Check to select Telnet Service

Telnet Port :

The default is 23 and the range is between 1 ~ 65535.

Enable SSH :

Check to select SSH Service

SSH Port :

Please The default is 22 and the range is between 1 ~ 65535.

Ping Watchdog :

The ping watchdog sets the TEW-676APBO Device to continuously

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

ping a user defined IP address (it can be the internet gateway for example). If it is unable to ping under the user defined constraints, the TEW-676APBO device will automatically reboot. This option creates a kind of "fail-proof" mechanism.

Ping Watchdog is dedicated for continuous monitoring of the particular connection to remote host using the Ping tool. The Ping works by sending ICMP “echo request” packets to the target host and listening for ICMP “echo response” replies. If the defined number of replies is not received, the tool reboots the device.

Enable Ping Watchdog :

control will enable Ping Watchdog Tool.

IP Address To Ping :

specify an IP address of the target host which will be monitored by Ping Watchdog Tool.

Ping Interval :

specify time interval (in seconds) between the ICMP “echo requests” are sent by the Ping Watchdog Tool. Default is

300

seconds.

Startup Delay :

specify initial time delay (in seconds) until first ICMP “echo requests” are sent by the Ping Watchdog Tool. The value of Startup Delay should be at least

60

seconds as the network interface and wireless

 connection initialization takes considerable amount of time if the device is rebooted. Default is

300

seconds.

Failure Count To Reboot :

specify the number of ICMP “echo response” replies. If the specified number of ICMP “echo response” packets is not received continuously, the Ping Watchdog Tool will reboot the device.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes

Without a valid certificate, users may encounter the following problem in IE7 when they try to access system's WMI ( https://192.168.2.254

). There will be a “Certificate Error”, because the browser treats system as an illegal website.

124

TRENDnet User’s Guide

TEW-676APBO

Configure System Time

System time can be configured via this page, and manual setting or via a NTP server is supported.

Please click on

System -> Time Server

and follow the below setting.

Click “

Continue to this website

” to access the system's WMI. The system's Overview page will appear.

© Copyright 2012TRENDnet. All Rights Reserved.

Local Time :

Display the current system time.

NTP Client :

To synchronize the system time with NTP server.

Enable :

Check to select NTP client.

Default NTP Server :

Select the NTP Server from the drop-down list.

Time Zone :

Select a desired time zone from the drop-down list.

Daylight saving time :

Enable or disable Daylight saving.

Click

Save

button to save your changes. Click

Reboot

button to activate your changes

125

TRENDnet User’s Guide

Configure UPnP

Universal Plug and Play(UPnP) is an architecture to enable pervasive peer-to-peer network connectivity between PCs, intelligent devices and appliances when UPnP is supported. UPnP works on TCP/IP network to enable UPnP devices to connect and access to each other, very well adopted in home networking environment.

TEW-676APBO

Configure SNMP Setup

SNMP is an application-layer protocol that provides a message format for communication between SNMP managers and agents. By enabling SNMP function, the administrator can obtain the system information remotely.

Please click on

System -> SNMP Setup

and follow the below setting.

UPnP :

By default, it’s “

Disable

”. Select “

Enable

” or “

Disable”

of UPnP Service.

Click

Save

button to save changes and click

Reboot

button to activate changes

For UPnP to work in Windows XP, the “TEW-676APBO” must be available in “

My

Network Places

, as shown here: (your specific model may vary)

TEW-675APBO/TEW-

676APBO

If these devices are not available, you should verify that the correct components and services are loaded in Windows XP. Please refer to

Appendix E. Using UPnP on Windows

XP

© Copyright 2012TRENDnet. All Rights Reserved.

SNMP v2c Enable:

Check to enable SNMP v2c.

ro community :

Set a community string to authorize read-only access.

rw community :

Set a community string to authorize read/write access.

SNMP v3 Enable:

Check to enable SNMP v3.

SNMPv3 supports the highest level SNMP security.

126

TRENDnet User’s Guide

SNMP ro user :

Set a community string to authorize read-only access.

SNMP ro password :

Set a password to authorize read-only access.

SNMP rw user :

Set a community string to authorize read/write access.

SNMP rw password :

Set a password to authorize read/write access.

SNMP Trap :

Events such as cold start, interface up & down, and association & disassociation will report to an assigned server.

TEW-676APBO

Backup / Restore and Reset to Factory

Backup current configuration, restore prior configuration or reset back to factory default configuration can be executed via this page.

Please click on

Utilities -> Profile Setting

and follow the below setting.

Save Settings to PC :

Click

Save

button to save the current configuration to a local disk.

Community :

Set a community string required by the remote host computer that will receive trap messages or notices send by the system.

IP :

Enter the IP addresses of the remote hosts to receive trap messages.

Click

Save

button to save changes and click

Reboot

button to activate.

© Copyright 2012TRENDnet. All Rights Reserved.

Load Settings from PC :

Click

Browse

button to locate a configuration file to restore, and then click

Upload

button to upload.

Reset To Factory Default :

Click

Default

button to reset back to the factory default settings and expect

Successful

loading message

.

Then, click

Reboot

button to activate.

127

TRENDnet User’s Guide

Firmware Upgrade

Firmware is the main software image that system needs to respond to requests and to manage real time operations. Firmware upgrades are sometimes required to include new features or bugs fix. It takes around

2 minutes

to upgrade due to complexity of firmware. To upgrade system firmware, click

Browse

button to locate the new firmware, and then click

Upgrade

button to upgrade.

TEW-676APBO

Network Utility

The administrator can diagnose network connectivity via the PING and TRACEROUTE utility.

Please click on

Utilities -> Network Utility

and follow the below setting

© Copyright 2012TRENDnet. All Rights Reserved.

Ping :

This utility will help ping other devices on the network to verify connectivity.

Ping utility, using ICMP packets, detects connectivity and latency between two network nodes. As result of that, packet loss and latency time are available in the

Result

field while running the PING test.

Destination IP/Domain :

Enter desired domain name, i.e. www.google.com

, or

IP address of the destination, and click

ping

button to proceed. The ping result will be shown in the

Result

field.

128

TRENDnet User’s Guide

Count :

By default, it’s 5 and the range is from 1 to 50. It indicates number of connectivity test.

Traceroute :

Allows tracing the hops from the TEW-676APBO device to a selected outgoing IP address. It should be used for the finding the route taken by ICMP packets across the network to the destination host. The test is started using the

Start

button, click

Stop button to stopped test

Destination Host :

Specifies the Destination Host for the finding the route

 taken by ICMP packets across the network.

MAX Hop :

Specifies the maximum number of hops( max time-to-live value) traceroute will probe.

Reboot

This function allows user to restart system with existing or most current settings when changes are made. Click

Reboot

button to proceed and take around three minutes to complete.

Mounting bracket installation

Package contents

Install mounting triangle

A reminder will be available for remaining time to complete. If power cycle is necessary, please wait till completion of the reboot process.

TEW-676APBO

© Copyright 2012TRENDnet. All Rights Reserved.

Align the mounting triangle to the back of the access point. Securely tighten the mounting triangle by using the M5x10 screws and washers.

129

TRENDnet User’s Guide

Wall mount bracket Installing brackets

TEW-676APBO

Position the provided mounting bracket to the desired location and mount as shown in the above image using the provided wood screws and plugs.

Pole mount bracket

Align the access point with the mount triangle installed with either the wall or pole mount. Using the provided M6x12 bolts tighten both mounts together as shown in the above image.

Insert and fasten the provided U-clamps to the pole as shown in the above image using the provided screw washers, spring washers and nuts.

© Copyright 2012TRENDnet. All Rights Reserved.

130

TRENDnet User’s Guide

Appendix

WEB GUI Valid Characters

Block Field

LAN

IP Address

IP Netmask

IP Gateway

Primary DNS

Secondary DNS

Hostname

WAN

Manual MAC Address

IP Address

IP Netmask

IP Gateway

© Copyright 2012TRENDnet. All Rights Reserved.

Appendix

Valid Characters

IP Format; 1-254

128.0.0.0 ~ 255.255.255.252

IP Format; 1-254

IP Format; 1-254

IP Format; 1-254

Length : 32

0-9, A-Z, a-z

~ ! @ # $ % ^ * ( ) _ + - { } | : < > ? [ ] / ; ` , . =

12 HEX chars

IP Format; 1-254

128.0.0.0 ~ 255.255.255.252

IP Format; 1-254

131

TRENDnet User’s Guide

Hostname

DDNS

User name

Password

MTU

Idle Time

Primary DNS

Secondary DNS

Hostname

User Name

Password

© Copyright 2012TRENDnet. All Rights Reserved.

Length : 32

0-9, A-Z, a-z

~ ! @ # $ % ^ * ( ) _ + - { } | : < > ? [ ] / ; ` , . =

Length : 32

0-9, A-Z, a-z

~ ! @ # $ % ^ * ( ) _ + - { } | : < > ? [ ] / ; ` , . =

Appendix

576 ~ 1492 for PPPoE; 1400 ~ 1460 for PPTP

0 ~ 60 minutes

IP Format; 1-254

IP Format; 1-254

Length : 32

0-9, A-Z, a-z

@ - _ .

Length : 32

0-9, A-Z, a-z

~ ! @ # $ % ^ * ( ) _ + - { } | : < > ? [ ] / ; ` , . =

132

TRENDnet User’s Guide

DHCP Server

Start IP

End IP

DNS1 IP

DNS2 IP

WINS IP

Domain

Block

Management

Lease Time

Field

System Name/ Location

Description

© Copyright 2012TRENDnet. All Rights Reserved.

IP Format; 1-254

IP Format; 1-254

IP Format; 1-254

IP Format; 1-254

IP Format; 1-254

Length : 32

0-9, A-Z, a-z

~ ! @ # $ % ^ * ( ) _ + - { } | : < > ? [ ] / ; ` , . =

Appendix

600 ~ 99999999

Valid Characters

Length : 32

0-9, A-Z, a-z

Space

~ ! @ # $ % ^ * ( ) _ + - { } | : < > ? [ ] / ; ` , . =

32 chars

133

TRENDnet User’s Guide

Password

SNMP

HTTP/ HTTPS Port

Telnet/ SSH Port

RO/RW community

RO/RW user

RO/RW password

Community

© Copyright 2012TRENDnet. All Rights Reserved.

Length : 4 ~ 30

0-9, A-Z, a-z

~ ! @ # $ % ^ * ( ) _ + - { } | : < > ? [ ] / ; ` , . =

Appendix

1 ~ 65535

1 ~ 65535

Length : 32

0-9, A-Z, a-z

~ ! @ # $ % ^ * ( ) _ + - { } | : < > ? [ ] ; ` , . =

Length : 31

0-9, A-Z, a-z

~ ! @ # $ % ^ * ( ) _ + - { } | : < > ? [ ] ; ` , . =

Length : 8 ~ 32

0-9, A-Z, a-z

~ ! @ # $ % ^ * ( ) _ + - { } | : < > ? [ ] ; ` , . =

Length : 32

0-9, A-Z, a-z

~ ! @ # $ % ^ * ( ) _ + - { } | : < > ? [ ] ; ` , . =

134

TRENDnet User’s Guide

General Setup

Wireless Profile

IP

Tx Power

Profile Name

ESSID

Advanced Setup

Block

WEP Key

Pre-shared Key

Beacon Interval

Date Beacon Rate

Fragment Threshold

RTS Threshold

Field

© Copyright 2012TRENDnet. All Rights Reserved.

IP Format; 1-254

1-100 %

32 chars

Length : 31

Space

0-9, A-Z, a-z

~ ! @ # $ % ^ * ( ) _ + - { } | : < > ? [ ] / ; ` , . =

Appendix

10, 26 HEX chars or 5, 13 ASCII chars

8 ~ 63 ASCII chars; 64 HEX chars

20 ~ 1024

1 ~ 255

256 ~ 2346

1 ~ 2347

Valid Characters

135

TRENDnet User’s Guide

Virtual AP Setup

ESSID

WDS Setup

Maximum Clients

VLAN ID

WEP Key

Group Key Update Period

PMK Cache Period

Pre-Shared Key

Radius Server IP

Radius Port

Shared Secret

Session Timeout

WEP Key

© Copyright 2012TRENDnet. All Rights Reserved.

Length : 31

Space

0-9, A-Z, a-z

~ ! @ # $ % ^ * ( ) _ + - { } | : < > ? [ ] / ; ` , . =

Appendix

1 ~ 32

1 ~ 4094

10, 26 HEX chars or 5, 13 ASCII chars

>=60 seconds

> 0 minute

8 ~ 63 ASCII chars; 64 HEX chars

IP Format; 1-254

1 ~ 65535

8 ~ 64 characters

>= 60 seconds; 0 is disable

10, 26 HEX chars or 5, 13 ASCII chars

136

TRENDnet User’s Guide

IP Filter

TKIP Key

AES Key

Peer's MAC Address

Description

Source Address

MAC Filter

Virtual Server

DMZ

QoS/

Source Mask

Source Port

Destination Address

Destination Mask

Destination Port

MAC address

Description

Private IP

Private/ Public Port

IP Address

Comment

© Copyright 2012TRENDnet. All Rights Reserved.

8 ~ 63 ASCII chars; 64 HEX chars

8 ~ 63 ASCII chars; 64 HEX chars

12 HEX chars

32 chars

IP Format; 1-254

0 ~ 32

1 ~ 65535

IP Format; 1-254

0 ~ 32

1 ~ 65535

MAC Format; 12 HEX chars

32 chars

IP Format; 1-254

1 ~ 65535

IP Format; 1-254

32 chars

Appendix

137

TRENDnet User’s Guide

Parental Control

MAC Address

Local/ Destination IP

Local/ Destination Port

Upload & Download

© Copyright 2012TRENDnet. All Rights Reserved.

MAC Format; 12 HEX chars

IP Format; 1-254

1 ~ 65535

Appendix

8 ~ 8192 digital number

138

TRENDnet User’s Guide

MCS Data Rate

The table below shows the relationships between the variables that allow for the maximum data rate

Note :

When MCS=32, only Short Guard Interval option is supported, Channel Bandwidth=20 is not supported. If Channel Bandwidth=40, the HT duplicate 6Mbps.

When MCS=0~7(One Tx Stream), Guard Interval and Channel Bandwidth are supported

When MCS=8~15(Two Tx Stream), Guard Interval and Channel Bandwidth are supported

Data Rate (Mb/s)

MCS Index Modulation

Channel Bandwidth = 20 Channel Bandwidth = 40

9

10

11

12

13

14

15

6

7

4

5

8

0

1

2

3

QPSK

QPSK

16-QAM

16-QAM

64-QAM

64-QAM

64-QAM

BPSK

QPSK

QPSK

16-QAM

16-QAM

64-QAM

64-QAM

64-QAM

BPSK

Long Guard Interval

6.5

13.0

19.5

26.0

26.0

39.0

52.0

78.0

104.0

39.0

52.0

58.5

65.0

13.0

117.0

130.0

Short Guard Interval Long Guard Interval Short Guard Interval

7.2 13.5 15.0

14.4

21.7

28.9

27.0

40.5

54.0

30.0

45.0

60.0

28.9

43.3

57.8

86.7

115.6

43.3

57.8

65.0

72.2

14.4

130.0

114.4

81.0

108.0

121.5

135.0

27.0

54.0

81.0

108.0

162.0

216.0

243.0

270.0

60.0

90.0

120.0

180.0

240.0

90.0

120.0

135.0

157.5

30.0

270.0

300.0

© Copyright 2012TRENDnet. All Rights Reserved.

Appendix

139

TRENDnet User’s Guide

System Manager Privileges

There are two system management accounts for maintaining the system; namely, the

root

and

admin

accounts are with different levels of privileges. The root manager account is empowered with full privilege to Read & Write while the admin manager account is Read only.

The following table display CPE admin account’s privileges.

Main Menu Sub Menu Group Admin Privilege

Operating

WAN

Read

Read

System

Wireless

Advance

LAN

DDNS

Time Server

UPNP

SNMP

General

Advanced

Site Survey

DMZ

IP Filter

MAC Filter

Virtual Server

Parental l

Read & Write

Read & Write

Read & Write

Read & Write

Read

Read

Read

Read

Read

Read

Read

Read

Read

© Copyright 2012TRENDnet. All Rights Reserved.

Administrator

QoS

Management

System

Root

Admin

Login

Ping

Profile

Settings

System

Network

Backup

Settings

Restore

Reset f l

TEW-676APBO

Read

Read

Read

Read & Write

Read

Read

Read & Write

Read

Read

Read

Read & Write

Read & Write

140

TRENDnet User’s Guide

Windows TCP/IP Settings

Windows XP

1.

Click

Start -> Settings -> Control Panel

, and then “

Control Panel

” window appears. Click on “

Network Connections

”, and then “

Network Connections

” window appears.

TEW-676APBO

3.

In “

Local Area Connection Properties

” window, select “

Internet Protocol

(TCP/IP)

” and click on

Properties

button.

2.

Click right on “

Local Area Connection

”, and select

Properties

.

© Copyright 2012TRENDnet. All Rights Reserved.

4.

Select “Use the following IP address”, and type in

IP address : 192.168.2.100

Subnet mask : 255.255.255.0

141

TRENDnet User’s Guide

TEW-676APBO

Enabling UPnP in Windows XP

1.

Open the “

Add/Remove Programs

control panel, and then click on “

Add/Remove

Windows Components

in the sidebar. Scroll down and find “

Networking Services

, highlight it, and then click

Details

.

2.

In the “

Networking Services

” window, ensure that the “

Internet Gateway Device

and “

UPnP User Interface

options are checked. If they are not, check it to enable them, as shown below, and click OK to continue.

© Copyright 2012TRENDnet. All Rights Reserved.

142

TRENDnet User’s Guide

3.

Next, in the “

Control panel

”, open the “

Administrative Tools

and then open

Services

. Scroll down until you find the “

SSDP Discovery Interface

. If the Status is not

Started

, double-click on

SSDP Discovery Interface

to open the service properties. Change the startup type to

Automatic

, then close the properties. Now, right-click on

SSDP Discovery Services

, and choose

Start

from the pop-up menu. The

SSDP Discovery Service will then be running and start each time you boot.

4.

After enabling UPnP and starting the SSDP Discovery Service, it may take few minutes for the “TEW-675APBO/ TEW-676APBO” to be discovered and appear in your “

My Network Places

.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

143

TRENDnet User’s Guide

Specification

Hardware

Standards

LED Indicator

Antenna

PoE

Dimension (L x W x H)

Weight

Power Consumption

Management

Wind Speed Support

Waterproof

Temperature

Wired: IEEE 802.3u (100Base-TX)

Wireless: IEEE 802.11a/n (5 GHz)

Power, LAN, WLAN (wireless activity)

12dBi patch antenna (polarization: V30

°

, H30

°

)

1 x 10/100Mbps RJ-45 PoE port, Passive only (non-

802.3af compliant)

215 x 122 x 66 mm ( 8.5 x 4.8 x 2.6 in)

1kg (2.2lbs)

15 Watts (max.)

Web browser (HTTP/HTTPS), SNMP (v2c and 3),

Telnet, SSH

210 km/hr

IP66/67 compliant

Operating: -20° ~ 60°C (-4°F ~ 140°F)

Storage: 0° ~ 60°C (32°F ~ 140°F)

Max. 95% (non-condensing)

PoE power injector DC output: 48VDC, 0.4A

FCC

Humidity

Power

Certifications

Wireless

Frequency

Modes

5.725 ~ 5.845 GHz

Router, Access Point + WDS, WDS, CPE, Client Bridge

+ Repeater, CPE + Access Point

7

Virtual Access Points

Associated Clients (max)

224 (AP Mode), 32 (Repeater Mode)

*Coverage

Modulation Technique

5km line-of-sight

802.11a: OFDM with BPSK, QPSK, QAM and 64QAM

802.11n: BPSK, QPSK, 16-QAM, 64-QAM

Data Rate (auto-fallback)

802.11a: up to 54Mbps

Security

802.11a/n: up to 300Mbps

64/128/152-bit WEP, WPA /WPA2-PSK, WPA/WPA2-

RADIUS for AP/CPE mode, WEP/WPA2-PSK for WDS mode

Output Power

Receiving Sensitivity

MAC filter (20 entries) and IP filter (20 entries)

Up to 26dBm (FCC)

802.11a: -91dBm (typical) @ 6Mpbs

© Copyright 2012TRENDnet. All Rights Reserved.

Channels

TEW-676APBO

802.11a/n: -68dBm (typical) @ 300Mbps

FCC: 149,153,157,161,165

144

TRENDnet User’s Guide

Limited Warranty

TRENDnet warrants its products against defects in material and workmanship, under normal use and service, for the following lengths of time from the date of purchase.

TEW-676APBO – 3 Years Warranty

AC/DC Power Adapter, Cooling Fan, and Power Supply carry 1 year warranty.

If a product does not operate as warranted during the applicable warranty period,

TRENDnet shall reserve the right, at its expense, to repair or replace the defective product or part and deliver an equivalent product or part to the customer. The repair/replacement unit’s warranty continues from the original date of purchase. All products that are replaced become the property of TRENDnet. Replacement products may be new or reconditioned. TRENDnet does not issue refunds or credit. Please contact the point-of-purchase for their return policies.

TRENDnet shall not be responsible for any software, firmware, information, or memory data of customer contained in, stored on, or integrated with any products returned to

TRENDnet pursuant to any warranty.

There are no user serviceable parts inside the product. Do not remove or attempt to service the product by any unauthorized service center. This warranty is voided if (i) the product has been modified or repaired by any unauthorized service center, (ii) the product was subject to accident, abuse, or improper use (iii) the product was subject to conditions more severe than those specified in the manual.

Warranty service may be obtained by contacting TRENDnet within the applicable warranty period and providing a copy of the dated proof of the purchase. Upon proper submission of required documentation a Return Material Authorization (RMA) number will be issued. An RMA number is required in order to initiate warranty service support for all TRENDnet products. Products that are sent to TRENDnet for RMA service must have the RMA number marked on the outside of return packages and sent to TRENDnet prepaid, insured and packaged appropriately for safe shipment. Customers shipping from outside of the USA and Canada are responsible for return shipping fees. Customers shipping from outside of the USA are responsible for custom charges, including but not limited to, duty, tax, and other fees.

© Copyright 2012TRENDnet. All Rights Reserved.

TEW-676APBO

WARRANTIES EXCLUSIVE

: IF THE TRENDNET PRODUCT DOES NOT OPERATE AS

WARRANTED ABOVE, THE CUSTOMER’S SOLE REMEDY SHALL BE, AT TRENDNET’S

OPTION, REPAIR OR REPLACE. THE FOREGOING WARRANTIES AND REMEDIES ARE

EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED,

EITHER IN FACT OR BY OPERATION OF LAW, STATUTORY OR OTHERWISE, INCLUDING

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

TRENDNET NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR

IT ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION MAINTENANCE

OR USE OF TRENDNET’S PRODUCTS.

TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND

EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST

OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S MISUSE, NEGLECT,

IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS TO REPAIR OR

MODIFY, OR ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE, OR BY

ACCIDENT, FIRE, LIGHTNING, OR OTHER HAZARD.

LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW TRENDNET ALSO

EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY, WHETHER BASED IN

CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR INCIDENTAL, CONSEQUENTIAL,

INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS OF REVENUE OR

PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATE, OR OTHER FINANCIAL

LOSS ARISING OUT OF OR IN CONNECTION WITH THE SALE, INSTALLATION,

MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF THE POSSIBILITY

OF SUCH DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT, OR REFUND

OF THE PURCHASE PRICE PAID, AT TRENDNET’S OPTION. THIS DISCLAIMER OF LIABILITY

FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED HEREIN SHALL FAIL

OF ITS ESSENTIAL PURPOSE.

Governing Law

: This Limited Warranty shall be governed by the laws of the state of

California.

Some TRENDnet products include software code written by third party developers.

These codes are subject to the GNU General Public License ("GPL") or GNU Lesser

General Public License ("LGPL").

Go to http://www.trendnet.com/gpl or http://www.trendnet.com

Download section and look for the desired TRENDnet product to access to the GPL Code or LGPL Code.

145

TRENDnet User’s Guide

These codes are distributed WITHOUT WARRANTY and are subject to the copyrights of the developers. TRENDnet does not provide technical support for these codes. Please go to http://www.gnu.org/licenses/gpl.txt

or http://www.gnu.org/licenses/lgpl.txt

for specific terms of each license.

PWP05202009v2

© Copyright 2012TRENDnet. All Rights Reserved.
