WASSP CDX OPERATORS MANUAL

QUICKSTART GUIDE

CDX OPERATORS MANUAL

WASSP CDX OPERATORS MANUAL

WASSP CDX is control, visualisation, data management and data processing application for use with the WASSP DRX ‘Black Box’ multibeam transceiver.

This manual provides the basic information to operate WASSP CDX.

DOCUMENT REVISION HISTORY

REVISION DATE

March 2016

April 2016

April 2016

July 2016

September 2016

REASON FOR CHANGE

Compilation

Update Tides

Typos corrected

Updates for V2

Addition of 6.0 Tools and Utilities

VERSION

1.0

1.1

1.2

2.0

3.0

RELATED DOCUMENTS

»

WASSP CDX Operators Manual – For the latest version of this manual go to wassp.com

»

WASSP DRX Installation Manual – For the latest version of this manual go to wassp.com

»

WASSP DRX Utilities Operators Manual – Manual describing utility applications shipped with WASSP DRX.

Further documentation, FAQs, updated specifications and WASSP CDX Operators manual can be found at wassp.com

General Notices

WASSP Ltd. reserves the right to change the contents of this manual and any system specifications without notice.

Contact WASSP Ltd. regarding copying or reproducing this manual.

Support information

If you require maintenance or repair, contact your local dealer. You can also contact

WASSP Ltd. using the following address: wassp.com/support/ .

If you need information about WASSP products, visit wassp.com

.

On the website you will also find a list of WASSP dealers and distributors.

Warnings, Cautions, and Notes

Warnings, cautions, and notes are indicated by the following icons throughout this manual:

CAUTION indicates that if the instruction is not heeded, the action may result in equipment damage or software corruption.

NOTE indicates a TIP or additional information that could be helpful while performing a procedure.

Page 2 of 66

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

CDX OPERATORS MANUAL

CONTENTS

1 System Configuration

1.1. System Overview

1.2. Installation

2 Application Overview

2.1. Quick Access Bar

3 System Set Up

3.1. Device setup

3.1.1. Wireless Server

3.2. DRX Processing Configuration

3.2.1. DRX Information

3.2.2. Sound Velocity

3.2.3. IMS Control

3.2.4. Filter Setup

3.2.5. Tides

3.3. UI Preferences

3.3.1. Languages

3.3.2. Depth

3.3.3. Speed

3.3.4. Position

3.3.5. Temperature

3.3.6. Long Distance

3.3.7. Short Distance

3.3.8. Night Mode

3.3.9. Multi Display

3.3.10. Zoom Control

3.3.11. Nav Bar

3.4. Layout

4 Display Panel Settings

4.1. Sonar

4.1.1. Sonar Configurations Options

4.1.2. Sonar CSM

4.2. Sounder

4.2.1. Sounder Configuration Options

4.2.2. Sounder CSM

4.3. Chart

4.3.1. Charting Cartography

4.3.2. Chart Configuration Options

4.3.3. 2D Chart CSM

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

5

37

38

43

44

32

32

33

36

45

45

51

30

30

30

31

29

29

29

29

28

28

28

29

17

18

24

27

9

10

10

11

5

6

8

15

15

16

Page 3 of 66

CDX OPERATORS MANUAL

4.3.4. 3D Chart CSM

4.3.5. Database

5 Tools

5.1. Marks

5.2. Profile Tool

6 Tools and Utilities

6.1. Data Manager

6.1.1. Data Manager Record

6.2. Data Manager Replay

7 Appendix

FIGURES

Figure 1. DRX Recommended System

Figure 2. Application Overview

Figure 3. Seafloor inaccuracies due to incorrect sound velocity

Figure 4. Sonar Gain and Dynamic Range Control

Figure 5. Sounder Gain and Dynamic Range Control

Figure 6. Simplified Wireless Configuration

GLOSSARY

Term

CSM

DHCP

DRX

GbE

IMU

LAN

Pan

RTK GPS

Zoom

Description

Content Sensitive Menu.

Dynamic Host Configuration Protocol, for automatically providing IP addresses.

‘Black Box’ smart transceiver that interfaces to devices and sensors to make up the

WASSP sounder system.

Gigabit Ethernet.

Inertial Motion Unit/Motion Sensor, typically for roll, pitch and heave.

Local Area Network.

Refers to horizontal and vertical scrolling of the Display panel.

Real Time Kinematic GPS, used for high quality positioning.

Refers to changing the scale of the Display panel.

16

34

5

8

39

61

57

58

60

60

60

61

63

52

53

57

Page 4 of 66

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

CDX OPERATORS MANUAL

1 SYSTEM CONFIGURATION

1.1. SYSTEM OVERVIEW

Details on WASSP system configuration can be seen in the DRX Installation Manual, with a typical configuration shown below.

USER PC

WASSP CDX

Data Manager

Satellite

Compass

GPS / Heading

IMU

Roll / Pitch /

Heave

WASSP

Transducer

Figure 1. DRX Recommended System

DC Power

9-32V DC

WASSP CDX is connected to DRX over gigabit Ethernet. The Ethernet link is used for all communication between WASSP CDX running on PC or other devices and the DRX.

This link is used for control of the DRX and for the DRX to supply data for visualisation, management and post processing to WASSP CDX .

DRX also serves DRX SETUP WEBPAGES for DRX configuration. This is described in the

DRX Installation manual.

The Ethernet connection can be connected either directly using crossover cable or auto crossover (DRX supports auto MDI/MDI-X) OR via a network switch if supporting multiple clients or running the DRX on vessel LAN (local area network).

If there is a DHCP server on the LAN the DRX will be assigned an appropriate IP address by the DHCP server. If there is no DHCP server, the DRX will fall through to Zeroconfiguration assignment in block 169.254.0.0/16. Any connected device will need to be assigned an appropriate IP address on the same subnet as the DRX, either via DHCP server, Zero-configuration or fixed IP.

The Data Manager application bundled with the WASSP CDX Install Package is used for recording DRX data, exporting to various formats and data playback to supported applications including WASSP CDX .

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 5 of 66

CDX OPERATORS MANUAL

1.2. INSTALLATION

WASSP CDX can be installed on any device that meets the minimum spec described in

“Appendix A - PC SPEC” on page 63.

1. From WINDOWS START run WASSP CDX SETUP

CDX OPERATORS MANUAL

Select FINISH

Select NEXT

Select INSTALL

Page 6 of 66

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

2. You may now run the WASSP CDX Application.

WASSP CDX

installer will also install various utilities including:

»

Data Manager; For data record, export and playback

»

Patch Test; For automated Patch Test to calculate roll offset

»

Location Server; For own-vessel navigation data in wireless mode

»

Find My DRX; For identifying DRXs on the network

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 7 of 66

2 APPLICATION OVERVIEW

1

1A

1B

1C

2

CDX OPERATORS MANUAL

4

3 5 6

Figure 2. Application Overview

1

2

3

Page 8 of 66

HOME BAR

DISPLAY

PANELS

CONTEXT

SENSITIVE

MENU (CSM)

Provides configuration options for the Display

Panels, Layout, Tools, System Setup and User

Preferences. The HOME bar is accessed through the HOME button.

1A: Quick Access Bar:

See “2.1. Quick Access Bar” on page 9.

1B: Display Panel Setup:

See “4 Display Panel Settings” on page 32.

1C: Configuration of CDX ( UI PREFERENCES ), DRX ( DRX

PROCESSING ) and system setup ( DEVICE SETUP ).

See “3

System Set Up” on page 10.

Display panels are associated with specific data types for visualisation and control. Typical examples are Charting for bathymetric display and Sonar for multibeam swath data.

Display panels available will depend on data available to

CDX. Display panels are configured in LAYOUTS , 1A

Set up and configuration of the specific Display Panels accessed through right-click on any panel.

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

CDX OPERATORS MANUAL

4

INFORMATION

DISPLAY

Optional Display Panel information overlay enabled from

CSMs. Information Display Panels can be selected and dragged to any position within the Display Panel.

5

CONTROL

TOOLS

Optional Display Panel control overlay enabled from CSMs.

6

TOOL BARS

Optional general data display tools enabled from CSMs.

NOTE: CDX will expose functionality that is available to the user. All functionality described in the manual may not be available depending on DRX model and feature licensing.

Disabled controls indicate that the data may be enabled through upgrade or feature licensing.

2.1. QUICK ACCESS BAR

The QUICK ACCESS BAR is used to access top level options.

DAY / NIGHT button. Used for display brightness configured in layout, 1A.

See “3.3.8. Night Mode” on page 29

for full control.

LAYOUTS button

see “3.4. Layout” on page 31

for Display Panel selection.

TRANSMIT button. DRX control to transmit. Ping rate will be determined by selected range.

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 9 of 66

CDX OPERATORS MANUAL

3 SYSTEM SET UP

3.1. DEVICE SETUP

For full details on network configuration see DRX Installation Manual.

1. After installing the

WASSP CDX

on your PC, start the DRX and run

WASSP CDX

.

2. WASSP CDX will automatically select the DRX as long as the network has been correctly configured.

3. To manually select the DRX you wish to connect to:

From the HOME bar, under

CONFIGURATION select DEVICE

SETUP .

4. The

DEVICE SETUP

page displays the current (or previous) connection.

Press the CHANGE button and a drop-down list of available connections will be displayed.

5. Select your desired connection.

6. The connection indicator will display the following depending on the current status of the connection:

»

GREEN: Connected

»

AMBER: Connection is being changed

»

RED: No Connection

Page 10 of 66

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

CDX OPERATORS MANUAL

NOTE: Other WASSP data servers such as Data Manager can also be selected as a DRX Server.

For information on recording and playing back data files see

“6 Tools and Utilities” on page 60.

3.1.1. Wireless Server

WASSP CDX can be configured to be used in a wireless configuration for remote mapping being transmitted from a TENDER to the PRIMARY vessel. The mapping data from the TENDER will be transmitted to the PRIMARY vessel real-time as well as off-line when the TENDER goes out of wireless range for a period of time.

A typical wireless configuration can be seen in

“Appendix B - Simplified Wireless

Configuration” on page 64.

Setting up CDX for wireless connectivity consists of:

»

Setting up the TENDER vessel

»

Configuring

PRIMARY

vessel for receiving own vessel navigation data

»

Setting up the PRIMARY vessel

Setting up the ‘Tender’ vessel

1. Open %APPDATA%/WASSP/G3/UI file location.

2. Create a text file and name it wirelessip

3. In the TENDER wirelessip text file enter the IP address of the PRIMARY WASSP CDX installation.

4. Open WASSP CDX on the Tender computer.

From the HOME bar, under

CONFIGURATION select DEVICE

SETUP .

5. Under WIRELESS SERVER

WIRELESS .

enable

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 11 of 66

6. Set MODE to TENDER .

CDX OPERATORS MANUAL CDX OPERATORS MANUAL

3. Set the BAUDRATE.

Configuring the ‘Primary’ Vessel for receiving own vessel navigation data

The LOCATION SERVER enables WASSP CDX to display own vessel position and heading.

1. From WINDOWS START launch LOCATION SERVER.

4. Select START SERVER to start the server.

2. Set COMPORTSTR to the comport that is used for the

Primary’s heading and location port.

Page 12 of 66

Setting up the ‘Primary’ vessel

1. Open %APPDATA%/WASSP/G3/UI file location.

2. Create a text file and name it wirelessip

3. In the PRIMARY wirelessip text file enter the IP address of the TENDER WASSP CDX installation.

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 13 of 66

4. Open WASSP CDX on the Primary computer.

From the HOME BAR , under

CONFIGURATION select DEVICE

SETUP .

5. Under WIRELESS SERVER enable

WIRELESS.

CDX OPERATORS MANUAL CDX OPERATORS MANUAL

3.2. DRX PROCESSING CONFIGURATION

3.2.1. DRX Information

The DRX PROCESSING menu is used for monitoring DRX status and configuring DRX specific processing and control options.

From the HOME bar, under

CONFIGURATION select DRX

PROCESSING .

6. Set

MODE

to

PRIMARY.

7. In the LOCATION SERVER section the running location server will be automatically selected.

If there is more than one location server on the network, the CHANGE button allows selection of the appropriate Location Server.

DRX information displays general status information. This information is specific to the DRX or data server that CDX is connected to.

Page 14 of 66

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 15 of 66

CDX OPERATORS MANUAL

3.2.2. Sound Velocity

Sound velocity input is required to compensate for range inaccuracies caused by sound speed variations. These changes can occur both seasonally and with geographical areas especially in coastal areas where sound velocity will be impacted by both temperature and water salinity differences.

Sound velocity in water is affected by both temperature and salinity and can either be measured directly or derived from temperature and salinity. This value should be adjusted regularly, depending on the operating environment, as It will have a direct impact on mapping accuracy.

The sound velocity control allows for both direct and derived values. Sound velocity compensation can be calculated using appropriate sound velocity, sound velocity profile or temperature and salinity sensors. The more accurate the sound velocity the more accurate the mapping.

The visual effect of incorrect sound velocity is that a flat seafloor will either curve up or curve down. This representation will indicate soundings that are too shallow or too deep with the affect being accentuated toward the edges of the swath.

Sound velocity measurements can be manually reckoned using the sonar display,

see

“4.1. Sonar” on page 32

or the profile tool, accessed through the Chart CSM,

see

“4.3.3. 2D Chart CSM” on page 51.

To do this:

»

Known flat sea floor should be run over

»

If the sea floor appears to be curving upwards at the edges (smile), the sound velocity value should be increased

»

If the sea floor appears to be curving downwards at the edges (frown), the sound velocity value should be decreased

Sound Velocity set too low

Actual Sea Floor

Sound Velocity set too high

Figure 3. Seafloor inaccuracies due to incorrect sound velocity

Click on the drop down menu and select the option you wish to tune:

MANUAL

SOUND VELOCITY; MANUAL WATER

SALINITY AND TEMPERATURE; MANUAL

WATER SALINITY or EXTERNAL SOUND

SPEED SENSOR.

Page 16 of 66

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

CDX OPERATORS MANUAL

MANUAL SOUND VELOCITY ; used if sound velocity is known.

MANUAL WATER SALINITY AND

TEMPERATURE ; if temperature and salinity are known, these will be used to derive sound velocity in DRX.

MANUAL WATER SALINITY ; can be used if DRX has a temperature input and the manual salinity will be used to derive sound velocity.

NOTE: The default value for the salinity of sea water is 35ppt. This value should not be changed unless the actual salinity of the surrounding water is known. If in fresh water, the value should be set to 1.

NOTE: Temperature input into DRX may be direct from transducers with temperature sensors built in or from external temperature sensor.

EXTERNAL SOUND SPEED SENSOR ; used if an external sound speed sensor is connected directly to the DRX. Refer to DRX installation manual for configuring sensors connected to the DRX.

3.2.3. IMS Control

IMS CONTROL is used for managing interfering acoustic equipment.

Manual mode allows basic control of operating center frequency and can be used to manually adjust frequency to avoid acoustic equipment operating in the same frequency band as DRX.

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 17 of 66

CDX OPERATORS MANUAL

3.2.4. Filter Setup

DRX FILTERS allow adjustment of signal processing filters to optimise the data and display when operating in an environment with noise, clutter and other interference impacting the data quality.

These filters are split into

ACOUSTIC DISPLAY

for filters impacting sonar and sounder displays and SEAFLOOR for filters impacting Bathymetry on charting displays.

1. From the HOME bar, under

CONFIGURATION select DRX

PROCESSING .

2. Select FILTERS .

CDX OPERATORS MANUAL

3. ACOUSTIC DISPLAY: ECHO

AVERAGING

Applies to Sonar and Sounder data.

Purpose;

Reduction of clutter and false targets.

Rejects small targets or fast changing data accentuating slow moving targets.

Disadvantage;

»

Small targets will be lost

»

Display is out of calibration for target strength

Example; OFF

Example;

LOW

Example; MEDIUM

Example; HIGH

Page 18 of 66

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 19 of 66

CDX OPERATORS MANUAL

4. ACOUSTIC DISPLAY: CLUTTER

Applies to Sonar and Sounder data. Clutter is a threshold control to remove return signals below a specified level.

Purpose;

To clean the display of speckle by removing data below the specified threshold level. Allows stronger targets to be more easily identified.

Disadvantages;

»

Removes targets dependent on threshold set

»

Threshold is relative to noise level so targets may be lost with increased depth

Example; -6dB

Example; +6dB

Example; +16dB

Example; +30dB

Page 20 of 66

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

CDX OPERATORS MANUAL

5. SEAFLOOR: NOISE FILTER

Applies to Bathymetry charting data.

Purpose;

To remove single ping tracking errors through averaging.

Disadvantages;

»

Small objects on a changeable seafloor may be missed

»

Objects during high mapping speeds may be missed

Example; OFF

Example; ON

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 21 of 66

6. SEAFLOOR: TRACKING

Applies to Bathymetry charting data.

Purpose;

To prevent seafloor tracking artifacts such as fish schools and interfering sources such as sounders.

Disadvantages;

»

A very changeable seafloor may not be tracked effectively

»

Tracking while traveling at higher speeds may be compromised

Example; OFF

CDX OPERATORS MANUAL CDX OPERATORS MANUAL

Disadvantages;

»

Good seafloor data may not be tracked

»

Seafloor line on the Sonar display will be interrupted when aeration is detected

»

Bathymetry will have gaps or be smoothed when aeration is identified

Example;

OFF

Example; LOW

Example; HIGH

7. SEAFLOOR: AERATION

Applies to Bathymetry charting data.

Aeration will occur due to air bubbles across the transducer face. This will occur due to poor transducer installation, but also due to sea conditions, vessel speed, vessel traveling astern etc. This can affect the entire swath or smaller areas.

Purpose;

To prevent aeration and other anomalies causing discontinuity in return signal strength from introducing poor seafloor tracking.

Page 22 of 66

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

Example; MEDIUM

Doc: CDX Operators Manual

Version: 2.0 July 2016

Example;

HIGH

wassp.com

Page 23 of 66

CDX OPERATORS MANUAL

3.2.5. Tides

Tidal height offset can be configured to be applied as a depth correction in the DRX. This will depend on the tide option set in the TIDES menu.

1. From the HOME bar, under

CONFIGURATION

select

DRX

PROCESSING .

2. Select TIDES

TIDE MODE will provide you with the following options:

DISABLED, AUTO,

MANUAL (STATION) or MANUAL (OFFSET) .

UTC OFFSET is used to correct UTC time to local time. The Offset should include any daylight savings.

CDX OPERATORS MANUAL

3.2.5.3. Tide Mode Disabled

No tidal offset will be applied as a correction to seafloor data in the DRX.

3.2.5.4. Tide Mode Auto

Tidal offset will be selected based on local tide station using time and position data. The value will be applied to the DRX periodically.

UTC OFFSET should entered to apply correct local time for the tide station.

Page 24 of 66

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 25 of 66

3.2.5.5. Tide Mode Manual (Station)

Tidal offset will be applied based on a manually selected tide station. The value will be applied to the DRX periodically.

UTC OFFSET should entered to apply correct local time for the tide station.

CDX OPERATORS MANUAL CDX OPERATORS MANUAL

3.3. UI PREFERENCES

This provides WASSP CDX user preference options.

From the HOME bar, under

CONFIGURATION select UI PREFERENCES .

3.2.5.6. Tide Mode Manual (Offset)

The manually set tidal offset will be applied to the DRX.

This provides the following unit preference options:

Page 26 of 66

NOTE: TIDE VALUE will give the tide value currently being applied to the

DRX.

NOTE: If UTC OFFSET for local time is incorrect, this will result in incorrect tidal height being calculated.

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 27 of 66

3.3.1. Languages

This provides language options.

Hit APPLY for the language to be applied.

3.3.2. Depth

This will provide depth options in METERS ,

FATHOMS or FEET .

3.3.3. Speed

This will provide speed options in KNOTS,

MILES PER HOUR, KILOMETERS PER HOUR or METERS PER SECOND.

Page 28 of 66

CDX OPERATORS MANUAL

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

CDX OPERATORS MANUAL

3.3.4. Position

This will provide position options in

DECIMAL DEGREES; DECIMAL DEGREES

(SIGNED); DEGREES, DECIMAL MINUTES or DEGREES, MINUTES, SECONDS.

3.3.5. Temperature

This will provide temperature options in

CELSIUS or FAHRENHEIT .

3.3.6. Long Distance

This will provide distant options in

NAUTICAL MILES, KILOMETERS, METERS or FEET.

3.3.7. Short Distance

This will provide distant options in METERS or FEET.

3.3.8. Night Mode

Tick the check box to enable

NIGHT

MODE.

Use the slider control to adjust brightness level.

NOTE: Switching Night Mode on and off is available from the Home Menu

Quick Access Bar.

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 29 of 66

CDX OPERATORS MANUAL

3.3.9. Multi Display

Enable this check box when using dual displays.

Below is an example of the Layout Option when Multidisplay is not enabled (see

“3.4.

Layout” on page 31

).

Below is an example of the Layout Option when Multidisplay is enabled (see

“3.4.

Layout” on page 31

).

CDX OPERATORS MANUAL

3.4. LAYOUT

Panel layout can be configured using the LAYOUT section of the HOME bar.

From the HOME bar, select LAYOUTS.

With MULTIDISPLAY disabled.

Allows layout selection options for a single display configuration. Layout selection will depend on the features enabled.

With MULTIDISPLAY enabled.

Allows layout selection options for a dual display configuration. Layout selection will depend on the features enabled.

3.3.10. Zoom Control

Tick the check box to enable the display

ZOOM

control. The zoom control tool will appear at the top right of the active panel and applies to this active panel.

NOTE: The active Display Panel is the panel that is currently selected. To switch active panel, click in the panel.

3.3.11. Nav Bar

The Nav Bar, when active, will appear docked to the side of the display. The Nav Bar shows general vessel information.

Page 30 of 66

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 31 of 66

CDX OPERATORS MANUAL

4 DISPLAY PANEL SETTINGS

Display Panels are configured through the CSMs and/or DISPLAY SETTINGS configuration controls.

Typically the CSMs cover the most commonly accessed items but will also allow direct access to the HOME bar through the DISPLAY SETTINGS option on the CSM.

NOTE: All Display Panel configuration options are accessible through the

CSM and the CSM SETTINGS option.

4.1. SONAR

The Sonar Display Panel shows the water column and seafloor profile below the transducer.

Information display

Raw Sonar

Data

Seafloor Line Transducer Position Zoom Tool

CDX OPERATORS MANUAL

4.1.1. Sonar Configurations Options

From the HOME bar, under DISPLAY

SETTINGS select SONAR when there is a Sonar Display Panel. This provides the following options:

1

Port

INFORMATION

DISPLAY

ZOOM &

PAN CONTROL

Starboard

Supplies following information at the cursor:

»

Depth

»

Target Strength

The sonar panel can be zoomed in and out.

AUTO ZOOM

allows the display to be auto zoomed to optimum depth to show the seafloor and water column. AUTO ZOOM can be enabled from the CSM.

See “4.1.1.3. Display” on page 35.

Manual zoom of displayed depth and range can be controlled using the mouse wheel or ZOOM tool.

See “3.3.10. Zoom Control” on page 30

and select the + and – controls as required.

Page 32 of 66

NOTE - Touch control for zoom is available.

The Sonar panel can be panned in depth and Port/Starboard .

To pan left-click the cursor and drag.

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

2

3

1

2

GAIN

RANGE

3

DISPLAY

GAIN

,

DYNAMIC RANGE

and

DISPLAY COLOUR are used to optimize the sonar display to the user preference.

See “4.1.1.1. Gain” on page 34.

DRX control for setting ping / transmit range for the system.

See

“4.1.1.2. Range” on page 35.

Controls for display settings.

See “4.1.1.3. Display” on page 35.

DISPLAY COLOUR allows colour palette selection.

SEAFLOOR LINE allows seafloor line to be overlaid on the sonar data.

AUTO ZOOM allows the display to be auto zoomed to fit the Display

Panel or user controlled display zoom.

FILTERS allows adjustment of signal processing filters to optimise the data and display when operating in an environment with noise, clutter and other interference impacting the data quality.

See “3.2.4.

Filter Setup” on page 18.

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 33 of 66

CDX OPERATORS MANUAL

4.1.1.1. Gain

GAIN

,

DYNAMIC RANGE

and

DISPLAY COLOUR are used to optimize the sonar display to the user preference. This is done by selecting the dynamic range to display, the colour scale used across the displayed dynamic range and the gain level to view within the available dynamic range.

Gain Control

Full

Dynamic

Range

Display

Dynamic

Range

Figure 4. Sonar Gain and Dynamic Range Control

Gain

The gain level can be adjusted using the slider bar.

The histogram display alongside this slider indicates the spread of target strength returns.

Display Colour Scale

Dynamic Range

The display dynamic range can be adjusted by selecting from the available options.

Page 34 of 66

CDX OPERATORS MANUAL

4.1.1.2. Range

DRX control for setting ping / transmit range. Range can be adjusted manually using the scroll bar or automatically by selecting AUTO RANGE . AUTO RANGE will determine optimum range based on seafloor depth.

4.1.1.3. Display

DISPLAY COLOUR will provide the option to use various colour scales for the display.

SEAFLOOR LINE displays the seafloor line when enabled.

AUTO ZOOM allows the display to be auto zoomed to optimum depth to show the seafloor and water column.

FILTERS allows adjustment of signal processing filters to optimise the data and display when operating in an environment with noise, clutter and other interference impacting the data quality.

See “3.2.4. Filter Setup” on page 18

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 35 of 66

4.1.2. Sonar CSM

Accessed by right-clicking in the Sonar

Display Panel.

CDX OPERATORS MANUAL CDX OPERATORS MANUAL

4.2. SOUNDER

The Sounder Display Panel shows the traditional sounder echogram display for each of the active beams selected.

The display may show single beam, triple beam or quint beam modes in the Display

Panel. Below shows the typical triple beam display.

Information

Display

Grid Overlay

Current

Ping Data

Exit History Zoom Tool

SEAFLOOR LINE Allows seafloor line to be overlaid on the sonar data.

AUTO ZOOM

Allows the display to be auto zoomed to fit the Display Panel or user controlled display zoom.

CURSOR INFO Displays the Information display as an overlay on the Display Panel.

SHOW BEAMS Shows the Sounder beams overlaid on the Sonar panel.

See “4.2.1.3.

Sounder Options” on page 41.

SETTINGS

Page 36 of 66

This option will display the

32.

SONAR Menu.

See “4.1. Sonar” on page

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

Current Depth Echogram History Data

INFORMATION

DISPLAY

Range Scale

Supplies following information at the cursor:

»

Position and depth

»

Beam details

»

Target Strength

The sounder panel can be zoomed in and out.

AUTO ZOOM allows the display to be auto zoomed to optimum depth to show the seafloor and water column. AUTO ZOOM can be enabled from the CSM.

See “4.2.1.2. Display” on page 40.

Manual zoom of displayed depth and range can be controlled using the mouse wheel or ZOOM tool.

See “3.3.10. Zoom Control” on page 30

and select the + and – controls as required.

ZOOM &

PAN CONTROL NOTE: Touch control for zoom is available.

The Sounder panel can be panned to view history:

»

Left-click cursor and drag to see history in pan mode

»

On pan the EXIT HISTORY control will appear

»

To exit pan mode click on

EXIT HISTORY

The Sounder panel can be panned in depth. To pan in depth, leftclick cursor and drag.

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 37 of 66

Page 38 of 66

CDX OPERATORS MANUAL

4.2.1. Sounder Configuration Options

From the HOME bar, select

SOUNDER when there is a

Sounder Display Panel.

This provides the following options:

1

2

3

4

5

1

GAIN

2

RANGE

GAIN and DYNAMIC RANGE and DISPLAY COLOUR are used to optimize the Sounder display to the user preference.

See “4.2.1.1. Gain” on page 39.

DRX control for setting ping / transmit range for the system.

See

“4.1.1.2. Range” on page 35.

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

CDX OPERATORS MANUAL

3

DISPLAY

Controls for display settings.

See “4.2.1.2. Display” on page 40.

DISPLAY COLOUR allows colour palette selection.

SEAFLOOR LINE allows seafloor line to be overlaid on the sonar data.

AUTO ZOOM allows the display to be auto zoomed to fit the

Display Panel or user controlled display zoom.

GRID OVERLAY overlays a grid on the Echogram display.

ADVANCE option allows for advancing the Echogram scroll at the required rate.

4

5

SOUNDER

OPTIONS

Allows independent configuration of each sounder beam.

See

“4.2.1.3. Sounder Options” on page 41.

FILTERS

Allows adjustment of signal processing filters to optimise the data and display when operating in an environment with noise, clutter and other interference impacting the data quality.

See “3.2.4. Filter

Setup” on page 18.

4.2.1.1. Gain

GAIN

,

DYNAMIC RANGE

and

DISPLAY COLOUR are used to optimize the sounder display to the user preference. This is done by selecting the dynamic range to display, the colour scale used across the displayed dynamic range and the gain level to view within the available dynamic range.

Gain Control

Full

Dynamic

Range

Display

Dynamic

Range

Figure 5. Sounder Gain and Dynamic Range Control

Display Colour Scale

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 39 of 66

Gain

The gain level can be adjusted using the slider bar.

Dynamic Range

The display dynamic range can be adjusted by selecting from the available options.

CDX OPERATORS MANUAL CDX OPERATORS MANUAL

ADVANCE option allows for advancing the

Echogram scroll at the required rate.

4.2.1.3. Sounder Options

SOUNDER OPTIONS allows independent configuration of each sounder beam.

The sounder beams are equivalent to a set of independent single beam sounders which can be used at any angle across the multibeam swath. This can be depicted on the sonar view.

4.2.1.2. Display

DISPLAY COLOUR will provide the option to use various colour scales for the display.

SEAFLOOR LINE displays the seafloor line when enabled.

AUTO ZOOM allows the display to be auto zoomed to optimum depth to show the seafloor and water column.

GRID OVERLAY

overlays a grid on the

Echogram display.

Page 40 of 66

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

The SOUNDER MODE is used to display

1, SINGLE BEAM, 3, TRIPLE BEAM, or 5

QUINT BEAM, beams in the sounder

Display Panel.

SINGLE BEAM will just display beam B3

TRIPLE BEAM will display beams B2, B3 and B4

QUINT BEAM will display beams B1, B2,

B3, B4 and B5

Individual beam configuration is carried out through the beam selection. Each beam can be configured independently if default operations need to be changed.

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 41 of 66

1. Select the beam to configure from the BEAM NUM options.

The option to the right shows BEAM 3 selected (Beam 3 is typically the Nadir beam).

2. For the selected beam set the angle off of Nadir from the

BEAM ANGLE options.

NOTE: 0

Nadir, S is Starboard side of Nadir

3. o

is Nadir, P is angle Port side of

For the selected beam set the width from the BEAM WIDTH options.

CDX OPERATORS MANUAL CDX OPERATORS MANUAL

4.2.2. Sounder CSM

Accessed by right-clicking in the Sounder

Display Panel.

BEAM NUM

AUTO ZOOM

Allows selection of an individual beam. Control is available when

SOUNDER MODE is SINGLE BEAM and allows any beam to be selected for display.

Allows the display to be auto zoomed to fit the Display Panel or user controlled display zoom.

CURSOR INFO Displays the Information display as an overlay on the Display Panel.

BOTTOM LOCK

DROPMARK

SETTINGS

BOTTOM LOCK

mode displays the bottom as a straight line, no matter how the bottom contour may change.

Fish and other water column targets are relative to this flat bottom line.

Places a mark at the cursor position. To modify or delete this mark, right-click on the symbol and a sub menu will appear.

Click on Edit to modify the name or colour.

See “5.1. Marks” on page 57.

.

This option will display the SOUNDER Menu.

See “4.2. Sounder” on page 37.

Page 42 of 66

NOTE: BEAM WIDTH and BEAM ANGLE off Nadir will determine seafloor coverage of the beam.

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 43 of 66

4.3. CHART

The Chart display overlays Bathymetry data and optionally backscatter data, real time on chart cartography layers.

Information

Display

Mapped

Bathymetry

Heading

Line

Vessel Vessel

Track

Chart

Cartography

Colour

Tool

Zoom

Tool

Measure

Profile

Tool

INFORMATION

DISPLAY

Supplies following information at the cursor:

»

Depth

»

Position

The Chart panel can be ranged in and out.

Manual zoom of range can be controlled using the mouse wheel or

ZOOM tool,

see “3.3.10. Zoom Control” on page 30

. Select the + and – controls as required.

ZOOM

&

PAN CONTROL

NOTE: Touch control for zoom is available.

The 2D Chart panel can be panned to display different geographical areas. To pan the chart, left-click cursor and drag.

NOTE: To re-center on the vessel use the CSM

The 3D Chart panel can be orientated; left-click the cursor and drag.

CDX OPERATORS MANUAL

4.3.1. Charting Cartography

Charting cartography supported currently includes:

»

Navionics Gold/Navionics+

»

Navionics Platinum

Navionics charting on SD card will be automatically detected and loaded into WASSP

CDX .

NOTE: Navionics charting needs to be registered over the internet on first use. Registration will be automatically carried out by WASSP CDX and will require an internet connection. Once registered no internet connection is required.

4.3.2. Chart Configuration Options

From the HOME bar, select

CHART when there is a 2D or 3D

Display Panel. This provides the following options:

1

2

5

6

7

3

4

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 45 of 66

CDX OPERATORS MANUAL

1

2

DISPLAY

3

CHART

CHART

LAYERS

Controls for mapping options

»

MAPPING : To enable or disable Bathymetry being saved to the database and displayed on the chart

»

BEST BEAM : To optimise overlapping Bathymetry selection

»

COLOUR TOOL : Used to select Bathymetry colour display.

See “4.3.2.1. Colour Tool” on page 46.

Display options on the chart

»

2D CHART

: Enable/disable display of the chart cartography

»

3D CHART : Enable/disable display of the cartography

»

3D SWATH : Enable/disable the vessel swath display

»

3D DEPTH LINE : Enable/disable the vessel depth line display

Used to enable or disable specific chart layers.

See “4.3.2.2. Chart

Layers” on page 47.

4

5

TRACK

OPTIONS

Used to set up vessel track on the 2D Chart.

See “4.3.2.3. Track

Options” on page 48.

BACK

SCATTER

Used to access the Backscatter setup and configuration options for overlay on the chart.

See “4.3.2.4. Backscatter” on page 48.

6

DATABASE

Used to set up the Mapping Database.

See “4.3.3. Database” on page 46.

7

FILTERS

Allows adjustment of signal processing filters to optimise the data and display when operating in an environment with noise, clutter and other interference impacting the data quality.

See “3.2.4. Filter

Setup” on page 18.

4.3.2.1. Colour Tool

The COLOUR TOOL allows colour range to be set on the Bathymetry.

With AUTO COLOURS enabled the colour range will be assigned automatically, centered around the current depth at the vessel.

The colour range around depth at vessel can be adjusted using the slider. This will other condense or extend the colour range for a specific depth range.

Page 46 of 66

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

CDX OPERATORS MANUAL

With AUTO COLOURS disabled the colour range will be controlled by the user.

The colour range can be condensed or extended using the slider bars to apply between two user specified depths.

4.3.2.2. Chart Layers

By selecting

CHART LAYERS

, specific charting cartography layers can be enabled or disabled.

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 47 of 66

CDX OPERATORS MANUAL

4.3.2.3. Track Options

By selecting

TRACK

, the following options are available:

TRACK enables or disables display of the track on the 2D Chart display.

COLOUR allows track colour selection.

DELETE TRACK will permanently delete the track.

4.3.2.4. Backscatter

Backscatter overlay displays seafloor surface reflectivity as the seafloor target strength compensated for reflection angle due to slope, beam angle, and other losses.

For optimum performance the backscatter calibration routine should be run to compensate for system characteristics.

SHOW BACKSCATTER shows the backscatter overlay on the chart.

Backscatter will show instead of Bathymetry when enabled.

Backscatter overlay displays seafloor reflectivity, represented by colour change.

CDX OPERATORS MANUAL

The backscatter control allows setting the backscatter colour range.

To change the colour range drag the minimum and maximum indicators on the slider controls.

The histogram alongside the colour range controls indicates the actual spread of backscatter intensity currently displayed in the panel.

The backscatter display can either be shown as greyscale or colour scale using the COLOUR TABLE selection.

The display range can be automatically adjusted to be optimal for the data by using the SCALE COLOURS TO VIEW button. This selects the colour range to fit the intensity histogram.

Page 48 of 66

NOTE: Backscatter CALIBRATE process should be run prior to using the

Backscatter overlay.

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 49 of 66

CDX OPERATORS MANUAL

CALIBRATE : Backscatter calibration is run to compensate for system characteristics that may cause artefacts on the backscatter display. Specifically this compensates for the transducer beam pattern variance from the nominal. Calibration requires:

»

10 – 50m depth

»

Flat seafloor with consistent seafloor type

»

Calm conditions

»

At least 200m straight run

To run the Backscatter calibration:

1. Enable SHOW BACKSCATTER.

2. Line up for the calibration run and begin the calibration run.

3. Hit the CALIBRATION button:

• A line across the swath will indicate

Calibration routine has started.

• The Backscatter data will adjust dynamically during the calibration run.

• A 2nd line across the swath will indicate when the calibration data collection has completed.

4. Once completed the Backscatter will be adjusted to compensated levels.

5. Pressing cancel at any point during the calibration run will stop the data collection process and disregard the data.

Page 50 of 66

CDX OPERATORS MANUAL

4.3.3. 2D Chart CSM

To access the 2D CSM, right-click on the

Display Panel:

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

CENTER ON

VESSEL

Centers the chart on the vessel position. This mode will be disabled if the chart is panned.

Toggles between NU (North Up) and HU (Head Up) chart display.

MODE

COLOUR TOOL

Displays the COLOUR TOOL .

See “4.3.2.1. Colour Tool” on page

46

.

SHOW PROFILE Enables the Profile tool.

See “5.2. Profile Tool” on page 58.

CURSOR INFO Displays the Information display as an overlay on the Display Panel.

DROP MARK

Places a mark at the cursor position. To modify or delete this mark, right-click on the symbol and a sub menu will appear.

See “5.1. Marks” on page 57

.

MARK VESSEL Places a mark at the vessel position.

START

MEASURE

SETTINGS

Starts / Stops the Measure on the PROFILE tool.

See “5.2. Profile Tool” on page 58.

This option will display the CHART Menu.

See “4.3.1. Chart

Configuration Options” on page 46

.

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 51 of 66

4.3.4. 3D Chart CSM

To access the 3D CSM, right-click on the

Display Panel:

CDX OPERATORS MANUAL CDX OPERATORS MANUAL

4.3.5. Database

The Mapping Database is used for all WASSP CDX data storage.

DATABASE is used to set up the Mapping Database. Bathymetric data from the DRX will be saved to the database you select.

4.3.5.1. To create a Database

1. From the HOME bar, under DISPLAY

SETTINGS , select CHART .

2. Select DATABASE .

CENTER ON

VESSEL

MODE

SCALE

COLOUR

TOOL

Centers the chart on the vessel position.

Toggles between NU (North Up), HU (Head Up) and FREE ROTATE which allows user orientation of Vessel and chart; left-click the sursor and drag.

Scale options allow the vertical scale of the 3D display to be changed whilst horizontal scale remains the same. This will accentuate seafloor features.

Displays the COLOUR TOOL .

See “4.3.2.1. Colour Tool” on page 46

.

CURSOR INFO Displays the Information display as an overlay on the Display Panel.

RESET VIEW

This will reset view to its native resolution.

SETTINGS

This option will display the CHART Menu.

See “4.3. Chart” on page

44

.

NOTE: 3D Chart control is bound to the 2D control which means that display control on 2D will impact the 3D display.

NOTE: Cursor info only displays depth at the cursor on mapped Bathymetry.

Page 52 of 66

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 53 of 66

3. Under the PATH , click on the dots.

4. This will open a

BROWSE FOR

FOLDER window. Select the folder where the database is to be stored.

5. Type in a name for the database.

CDX OPERATORS MANUAL CDX OPERATORS MANUAL

4.3.5.2. To Select a Database

Bathymetric data will be recorded to the currently selected database.

4. From the HOME bar, under DISPLAY

SETTINGS , select CHART .

5. Select DATABASE .

6. Select high resolution 0.3M

option or low resolution 0.6M

option.

7. Click CREATE .

NOTE: There will be no mapping recorded beyond the max depth stated in the dropdown.

Page 54 of 66

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 55 of 66

6. The user can switch to use a different database using the SWITCH button.

All databases under the currently selected PATH will be available to select.

See “4.3.3. Database” on page

46.

7. Select appropriate database.

CURRENT DATABASE

will indicate the currently selected database name and storage resolution

CDX OPERATORS MANUAL CDX OPERATORS MANUAL

5 TOOLS

5.1. MARKS

The

MARKS setting can be accessed from CSMs in Charting and Sounder Display Panels and by right-clicking on a MARK and selecting EDIT.

The MARK setting can be used to:

»

Select MARK ICON

»

Select MARK COLOUR

»

Edit MARK NAME

NOTE: Only databases under the select Path will be shown in the database selection list. Change PATH to view databases stored in other locations.

There are colour options for each mark. To change colour, click on the colour box you require e.g. yellow:

Page 56 of 66

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 57 of 66

CDX OPERATORS MANUAL

5.2. PROFILE TOOL

The profile tool can be used to measure the distance between two points and to give a profile of the seafloor between those two points.

To enable or disable display of the profile tool click on PROFILE option in the appropriate CSM.

CDX OPERATORS MANUAL

2. Drag the START

MEASURE

Indicator to required start position and leftclick to lock Start position.

End Measure

Indicator

3. Drag the

END

MEASURE

Indicator to required finish position and leftclick to lock End position.

Profile Line

Start Measure

Indicator

4. The measure and profile will be dynamically updated on the profile tool.

5. The START MEASURE INDICATOR and

END MEASURE Indicator can be selected by hovering over, left-click and drag to a new position for profiling.

6. To remove the Measure tool from the

Panel select STOP MEASURE on the CSM.

PROFILE TOOL will be displayed. Mousing over the Profile Tool will display depth and distances.

To select the measure area that will be profiled:

1. Select

START MEASURE

from the CSM.

Page 58 of 66

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 59 of 66

CDX OPERATORS MANUAL

6 TOOLS AND UTILITIES

6.1. DATA MANAGER

DATA MANAGER is used for recording and replaying data from the

DRX. DATA MANAGER can also be used for exporting recorded data into different file formats for offline processing.

DATA MANAGER is installed with CDX but is launched as an independent application.

6.1.1. Data Manager Record

1. Click on the RECORD tab.

CDX OPERATORS MANUAL

5. Select the location that you want to store your files to by clicking on

BROWSE under SAVE

LOCATION.

6. Click on RECORD to start recording and STOP to stop recording.

7. When recording there are some options:

»

‘ Include Sonar Display Data ’ will record Sonar data as well as bathymetric data. This will result in medium size files.

»

‘ Include Diagnostics Data ’ will record the full raw data useful for technician analysis. However, it will result in very large files.

»

REC SNIPPET will record enough full raw data for a short period of time. This data is useful for technician analysis of issues without recording overly large files.

6.2. DATA MANAGER REPLAY

1. Click on the

REPLAY tab.

2. Connect to the DRX that you want to

Record data from.

3. Click on the SCAN button to view DRXs on the network.

4. Select the DRX and click OK.

Page 60 of 66

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 61 of 66

CDX OPERATORS MANUAL

2. Click on START

SERVER.

This allows

Data Manager to be available to client applications such as

CDX.

3. Once a client application is successfully connected the connection icon will display green.

4. A playback file can be selected using the

OPEN FILE button.

5. PLAYBACK

CONTROLS can then be used to control the playback.

NOTE: In Replay mode Data Manager appears as a DRX to client applications

and can be selected in DEVICE SETUP in CDX. See “3.1. Device setup” on page 10.

CDX OPERATORS MANUAL

7 APPENDIX

APPENDIX A - PC SPEC

OS

CPU

Base Frequency

Cores/Threads

Memory

Graphics

Screen Resolution

HDD/SDD

Network

Ethernet

Wi-Fi

MINIMUM

Windows 7, 8.1, 10

2GHz

2/4

4GB

DirectX 11

1024x768

250GB

GbE

802.11ac

RECOMMENDED

Windows 8.1, 10

2GHz

4/4

8GB

DirectX 11

FHD - 1920x1080

2TB

GbE

802.11ac

Example of WASSP supported PCs:

»

Low end PCs

• Intel NUC5i3RYK

»

Tablets

• ToughPad FZ-GI

• Microsoft Surface Pro 4

»

Ruggedised PCs

• ADLINK MXE-5400

Page 62 of 66

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 63 of 66

CDX OPERATORS MANUAL

APPENDIX B - SIMPLIFIED WIRELESS CONFIGURATION

GPS Compass

GPS Compass

IMU

DRX

Transducer

WASSP CDX

Figure 6. Simplified Wireless Configuration

WASSP CDX

CDX OPERATORS MANUAL

Page 64 of 66

wassp.com

Doc: CDX Operators Manual

Version: 2.0 July 2016

Doc: CDX Operators Manual

Version: 2.0 July 2016

wassp.com

Page 65 of 66

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
