Friedrich FSHSW18A3A, FSHSW12A1A, FSHSW24A3A, FSHSW09A1A Operating instructions

Friedrich FSHSW18A3A, FSHSW12A1A, FSHSW24A3A, FSHSW09A1A Operating instructions
R
Models
Indoor Unit
FSHSW09A1A FSHSW12A1A
FSHSW18A3A FSHSW24A3A
Content
Operation Notices
Precautions............................................................................................................ 1
Parts name ............................................................................................................ 9
Screen Operation Guide
Buttons on remote controller ............................................................................... 11
Introduction for icons on display screen .............................................................. 11
Introduction for buttons on remote controller .......................................................12
Function introduction for combination buttons ..................................................... 14
Replacement of batteries in remote controller ..................................................... 14
Emergency operation .......................................................................................... 15
Maintenance
Clean and maintenance....................................................................................... 15
Malfunction
Malfunction analysis ............................................................................................ 18
Installation Notice
Installation dimension diagram ............................................................................ 21
Safety precautions for installing and relocating the unit ...................................... 22
Tools for installation ............................................................................................. 23
Selection of installation location .......................................................................... 23
Requirements for electric connection .................................................................. 24
Installation
Installation of indoor unit...................................................................................... 25
Check after installation ........................................................................................ 30
Test and operation
Test operation ...................................................................................................... 30
Attachment
Pipe expanding method
......................................................................... 31
................................................................................... 33
This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
If it needs to install, move or maintain the air conditioner, please contact dealer or local service center
to conduct it at first. Air conditioner must be installed, moved or maintained by appointed unit. Otherwise, it may cause serious damage or personal injury or death.
Explanation of Symbols
DANGER
Indicates a hazardous situation that, if not avoided, will
result in death or serious injury.
WARNING
Indicates a hazardous situation that, if not avoided, could
result in death or serious injury.
CAUTION
Indicates a hazardous situation that, if not avoided, may
result in minor or moderate injury.
NOTICE
Indicates important but not hazard-related information,
used to indicate risk of property damage.
Indicates a hazard that would be assigned a signal word
WARNING or CAUTION.
Exception Clauses
Manufacturer will bear no responsibilities when personal injury or
property loss is caused by the following reasons.
1.Damage to product due to improper use or misuse of the product.
2.Alter, change, maintain or use the product with other equipment without abiding
by the instruction manual of manufacturer.
3.After verification, the defect of product is directly caused by corrosive gas.
4.After verification, defects are due to improper operation during transportation of
product.
5.Operate, repair, maintain the unit without abiding by instruction manual or related
regulations.
6.After verification, the problem or dispute is caused by the quality specification or
performance of parts and components that produced by other manufacturers.
7.The damage is caused by natural disasters, improper installation environment or
force majeure.
Precautions
WARNING
Operation and Maintenance
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
Do not connect air conditioner to multi-purpose socket.
Otherwise, it may cause fire hazard.
Do disconnect power supply when cleaning air
conditioner. Otherwise, it may cause electric shock.
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Do not spray water on indoor unit. It may cause electric
shock or malfunction.
After removing the filter, do not touch fins.
Do not use fire or hair dryer to dry the filter to avoid
deformation or fire hazard.
1
Precautions
WARNING
Maintenance must be performed by qualified
professionals. Otherwise, it may cause personal injury
or damage.
Do not repair air conditioner by yourself. It may cause
electric shock or damage. Please contact dealer when
you need to repair air conditioner.
Do not extend fingers or objects into air inlet or air
outlet. It may cause personal injury or damage.
Do not block air outlet or air inlet. It may cause
malfunction.
Do not spill water on the remote controller, otherwise the
remote controller may be broken.
When below phenomenon occurs, please turn off air
conditioner and disconnect power immediately, and then
contact the dealer or qualified professionals for service.
● Power cord is overheating or damaged.
● There’s abnormal sound during operation.
● Circuit break trips off frequently.
● Air conditioner gives off burning smell.
● Indoor unit is leaking.
If the air conditioner operates under abnormal conditions,
it may cause malfunction, electric shock or fire hazard.
When turning on or turning off the unit by emergency
operation switch, please press this switch with an insulating
object other than metal.
Do not step on top panel of outdoor unit, or put heavy
objects. It may cause damage or personal injury.
2
Precautions
WARNING
Attachment
Installation must be performed by qualified professionals.
Otherwise, it may cause personal injury or damage.
Must follow the electric safety regulations when installing
the unit.
According to the local safety regulations, use qualified
power supply circuit and circuit break.
Do install the circuit break. If not, it may cause malfunction.
An all-pole disconnection switch having a contact separation
of at least 3mm in all poles should be connected in fixed
wiring.
Including an circuit break with suitable capacity, please
note the following table. Air switch should be included
magnet buckle and heating buckle function, it can protect
the circuit-short and overload.
Air Conditioner should be properly grounded. Incorrect
grounding may cause electric shock.
Don't use unqualified power cord.
Make sure the power supply matches with the requirement
of air conditioner. Unstable power supply or incorrect wiring
may result in electric shock, fire hazard or malfunction.
Please install proper power supply cables before using the
air conditioner.
Properly connect the live wire, neutral wire and
grounding wire of power socket.
Be sure to cut off the power supply before proceeding
any work related to electricity and safety.
3
Precautions
WARNING
Do not power before finishing installation.
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
The temperature of refrigerant circuit will be high, please
keep the interconnection cable away from the copper
tube.
The appliance shall be installed in accordance with
national wiring regulations.
Installation must be performed in accordance with the
requirement of NEC and CEC by authorized personnel
only.
Air conditioner must be properly grounding with specialized
grounding device by a professional. Please make sure it is
always grounded effectively, otherwise it may cause electric
shock.
The yellow-green wire in air conditioner is grounding
wire, which can't be used for other purposes.
The grounding resistance should comply with national
electric safety regulations.
All wires of indoor unit and outdoor unit should be
connected by a professional.
4
Precautions
WARNING
Caution: This equipment is not intended for use during
construction. The use of equipment during construction
could result in premature failure of the components and
/or system and is in violation of our standard warranty
guidelines and may result in the suspension or
termination of the warranty.
Ensure that proper N.E.C. code is followed.
If you need to relocate the air conditioner to another
place, only the qualified person can perform the work.
Otherwise, it may cause personal injury or damage.
Select a location which is out of reach for children and
far away from animals or plants.If it is unavoidable,
please add the fence for safety purpose.
The indoor unit should be installed close to the wall.
Instructions for installation and use of this product are
provided by the manufacturer.
FCC WARNING
WARNING: Changes or modifications to this unit not
expressly approved by the party responsible for
compliance could void the user’s authority to operate
the equipment.
FCC STATEMENT
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions :
5
Precautions
FCC STATEMENT
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received,including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions,may cause harmful
interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and
receiver.
● Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
● Consult the dealer or an experienced radio/TV
technician for help.
6
Precautions
IC STATEMENT
This device complies with Industry Canada licenceexempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause
interference, and (2) this device must accept any
interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie
Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le
fonctionnement.
This equipment complies with FCC’s and IC’s RF
radiation exposure limits set forth for an uncontrolled
environment. The antenna(s) used for this transmitter
must be installed and operated to provide a separation
distance of at least 20 cm from all persons and must
not be collocated or operating in conjunction with any
other antenna or transmitter. Installers must ensure that
20cm separation distance will be maintained between
the device (excluding its handset) and users.
Cet appareil est conforme aux limites d’exposition au
rayonnement RF stipulées par la FCC et l’IC pour une
utilisation dans un environnement non contrôlé. Les
7
Precautions
IC STATEMENT
antennes utilisées pour cet émetteur doivent être
installées et doivent fonctionner à au moins 20 cm de
distance des utilisateurs et ne doivent pas être placées
près d’autres antennes ou émetteurs ou fonctionner
avec ceux-ci. Les installateurs doivent s’assurer qu’une
distance de 20 cm sépare l’appareil (à l’exception du
combiné) des utilisateurs.
Working temperature range
Maximum cooling
Maximum heating
Indoor side DB/WB(°F/°C) Outdoor side DB/WB(°F/°C)
80/66.9(26.7/19.4)
115/75(46.1/23.9)
80/-(26.7/-)
75/64.9(23.9/18.3)
NOTICE:
● The operating temperature range (outdoor temperature) for cooling only unit is
-0.4°F( -18 )~ 115°F (46.1 ); for heat pump unit is-0.4°F(-20 )~115°F( 46.1 ).
8
Parts Name
Indoor Unit
air inlet
panel
aux.button
horizontal louver
air outlet
remote controller
(Display content or position may be different from above
graphics, please refer to actual products)
NOTICE:
Actual product may be different from above graphics, please refer to actual
products.
9
Parts name
Display
heating
indicator
temp.
indicator
display
cooling
indicator
receiver
window
power
indicator
drying
indicator
Display content or position may be different from above graphics, please refer to actual
products.
10
Buttons on remote controller
On/Off button
2
Mode button
3
Fan button
4
▲/
5
Swing button
6
Sleep button
7
Temp button
5
8
Surge button
7
9
button
9
10 Timer button
2
4
3
6
8
10
12
11
▲
1
1
button
11 Dry button
12 Light button
Introduction for buttons on remote controller
Temp. display type
:Set temp.
:Indoor ambient temp.
:Outdoor ambient temp.
Set fan speed
Surge mode
Send signal
Operation mode
Child lock
health function
ventilation operation
46℉ heating function
Set temperature
Sleep mode
Light function
Hold function
Dry mode
Set time
TIMER ON /TIMER OFF
Auto mode
Cool mode
Dry mode
Fan mode
Heat mode
NOTICE:
Up & down swing
“
” This is a general remote controller. Some models have this function while some
do not. Please refer to the actual models.
11
Introduction for buttons on remote controller
Note:
● Once power is supplied to unit, unit will chime.
Operation indicator " " is ON (red indicator, the colour is different for different
models). After that, you can operate the air conditioner by using remote controller.
● In operation mode, button presses on the remote will cause the " " to blink. This
means that the remote is sending signals to the unit. The air conditioner responds
to button presses with a chiming sound.
● In stand-by mode, set temperature and clock icon will be displayed on the display
of remote controller (If timer on, timer off and light functions are set, the corresponding icons will be displayed on the display of remote controller at the same
time); Under on status, the display will show the corresponding set function icons.
1
On/Off button
2
Mode button
Press this button to turn on the unit. Press this button again to turn off the unit.
Each time you press this button, a mode is selected in a sequence that goes from
AUTO, COOL, DRY, FAN, and HEAT , as the following:
AUTO
COOL
DRY
3
Fan button
4
▲/
FAN
HEAT*
This button is used for setting Fan Speed in the sequence that goes from AUTO,
, to
, then back to Auto.
Note:
● In DRY mode fan speed is set only to low speed, for maximum dehumidification.
button
▲
Press ▲ /
button to increase/decrease set temperature. In AUTO mode, set
temperature is not adjustable. When setting Timer On or Timer Off, press "▲"
or " " button to adjust the time.
▲
▲
12
Introduction for buttons on remote controller
5 Swing button
Press this button to set up & down swing angle.
6
Sleep button
7
Temp button
Under Cool or Heat mode, press this button to turn on Sleep function. Press this
button again to cancel Sleep function. Under Fan、Dry and Auto modes, this
function is unavailable.
Press this button, you can see indoor set temperature, indoor ambient temperature
on indoor unit’s display. The setting on remote controller is selected circularly as below:
no display
Note:
● Outdoor temperature display is not available for some models. At that time, indoor
unit receives "
" signal, while it displays indoor set temperature.
8
Surge button
Under COOL or HEAT mode, press this button to activate / deactivate the Surge function.
Note: Not applicable for this unit.
Hold ° button
9
Press this button to start Hold ° function and " " will be displayed on the remote
controller. After this function is set, the remote controller will send the detected
ambient temperature to the controller and the unit will automatically adjust the
indoor temperature according to the detected temperature. Press this button again
to close Hold ° function and " " will disappear. When Hold ° function is turned on,
the remote controller should be put within the area where indoor unit can receive the
signal sent by the remote controller.
10
Timer button
● Under ON status, press this button to set timer OFF; Under OFF status, press
this button to set timer ON.
● Press this button once and the characters of HOUR ON (OFF) will flash to be
displayed. Meanwhile, press "▲" button or " " button to adjust timer setting (time
will change quickly if holding "▲" or " " button). Time setting range is 0.5~24hours.
Press this button again to confirm timer setting and the characters of HOUR ON
(OFF)will stop flashing.
If the characters are flashing but you haven’t press timer button,timer setting
status will be quit after 5s.If timer is confirmer, press this button again to cancel
timer.
▲
▲
11
Dry button
Press this button in COOL or DRY mode to turn on Dry function.
When this function is started up, indoor fan will still operate at low fan speed for a
while after turning off the unit by remote controller.
13
Introduction for buttons on remote controller
12 Light button
Press this button to turn on the display's light and press this button again to turn
off the display's light.
Function introduction for combination buttons
Combination of "▲" and " " buttons: Remote Control lock
▲
Press "▲" and " " buttons simultaneously 3s to lock or unlock the keypad. If the remote
controller is locked, is displayed. In this case, pressing any button, blinks
three times.
▲
Combination of "MODE" and " " buttons:
About switch between F° and C°
▲
▲
At unit OFF, press "MODE" and "
" buttons simultaneously to switch between ℃ and ℉.
Combination of "TEMP" and "TIMER" buttons:
Energy-saving Function
Press "TEMP" and "TIMER" simultaneously in COOL mode to start energy-saving function.
Indoor unit displays "SE". Repeat the operation to quit the function.
Combination of "TEMP" and "TIMER" buttons:
About 46° F Heating Function
Press "TEMP" and "TIMER" simultaneously in HEAT mode to start 46° F Heating Function
indoor unit displays" " and a selected temperature of "46° F ".
(8° C if Celsius is adopted). Repeat the operation to quit the function.
Replacement of batteries in remote controller
1. Press the back side of remote controller marked
the cover of battery box along the arrow direction.
2. Replace two 7# (AAA 1.5V) dry batteries, and
make sure the position of "+" polar and "-" polar
are correct.
3. Reinstall the cover of battery box.
14
signal sender
battery
reinstall
remove
Cover of battery box
Emergency operation
If remote controller is lost or damaged, please use aux. button to turn on or
turn off the air conditioner. The operation in details is as below:
air conditioner. When the air conditioner is turned on, it will operate under
auto mode.
panel
aux. button
WARNING:
Use insulated object to press the auto button
Clean and Maintenance
WARNING
■ Turn off the air conditioner and disconnect the power before cleaning the air
conditioner to avoid electric shock.
■ Do not wash the air conditioner with water to avoid electric shock.
■ Do not use volatile liquid to clean the air conditioner.
■ Do not use liquid or corrosive detergent clean the appliance and do not splash
water or other liquid onto it, otherwise, it may damage the plastic components,
even cause electric shock.
Clean surface of indoor unit
When the surface of indoor unit is dirty, it is recommended to use a soft dry cloth
or wet cloth to wipe it.
NOTICE:
● Do not remove the panel when cleaning it.
15
Clean and maintenance
1
Open panel
3
Pull panel out from below to
locked position.
● Use vacuum or clean filter in
sink with water.
● If filter is very soiled, use hot
water (113°F) to clean and
disinfect. Allow filter to dry
before placing back in unit.
2
Pull filter down to remove
careful to not get dust and
dirt into the coil.
4
panel cover tightly.
WARNING
operation environment, clean frequency can be increased.
16
Troubleshooting
General troubleshooting
Please check below items before asking for maintenance. If the issue still
Issue
Check items
Solution
● Whether it's interfered severely ● Pull out the plug. Reinsert
(such as static electricity, stable the plug after about 3min, and
voltage)?
then turn on the unit again.
Indoor unit
can’t receive
remote
controller’s
signal or
remote
controller
has no
action.
● Whether remote controller is
within the signal receiving
range?
● Signal receiving range is 8m.
● Whether there are obstacles?
● Remove obstacles.
● Whether remote controller is
● Select proper angle and point
the remote controller at the repointing at the receiving
ceiving window on indoor unit.
window?
● Is sensitivity of remote contro- ● Check the batteries. If the
ller low; fuzzy display and no
power of batteries is too low,
display?
please replace them.
● Check whether remote cont● No display when operating
roller appears to be damaged.
remote controller?
If yes, replace it.
● Fluorescent lamp in room?
No air
emitted
from
indoor
unit
● Take the remote controller
close to indoor unit.
Turn off the fluorescent lamp
and then try it again.
● Air inlet or air outlet of indoor
unit is blocked?
● Eliminate obstacles.
● Under heating mode, indoor
temperature is reached to set
temperature?
● After reaching to set temperature, indoor unit will stop blowing out air.
● Heating mode is turned on just ● In order to prevent blowing
out cold air, indoor unit will be
now?
started after delaying for several minutes, which is a normal phenomenon.
17
Malfunction analysis
Phenomenon
Air conditioner can’t
operate
Mist is emitted from
indoor unit’s
air outlet
Set temperature can’t
be adjusted
Cooling
(heating)
effect is
not good.
Check items
Solution
● Power failure?
● Wait until power recovery.
● Is plug loose?
● Reinsert the plug.
● Circuit break trips off or
fuse is burnt out?
● Ask professional to replace
circuit break or fuse.
● Wiring has malfunction?
● Ask professional to replace it.
● Unit has restarted immediately
● Wait for 3min, and then turn
after stopping operation?
on the unit again.
● Whether the function setting
for remote controller is
correct?
● Reset the function.
● Indoor temperature and humidity is high?
● Because indoor air is cooled
rapidly. After a while, indoor
temperature and humidity will
be decrease and mist will
disappear.
● Unit is operating under auto
mode?
● Temperature can’t be adjusted under auto mode.
Please switch the operation
mode if you need to adjust
temperature.
● Your required temperature
exceeds the set temperature
range?
● Set temperature range:
16℃ ~30℃(61~86°F).
● Voltage is too low?
● Wait until the voltage
resumes normal.
● Filter is dirty?
● Clean the filter.
● Set temperature is in proper
range?
● Adjust temperature to proper
range.
● Door and window are open?
● Close door and window.
18
Malfunction analysis
Phenomenon
Odours are
emitted
Check items
Solution
● Whether there’s odour source, ● Eliminate the odour source.
such as furniture and cigarette,
● Clean the filter.
etc.
Air conditioner ● Whether there’s interference,
such as thunder, wireless
operates normally suddenly devices, etc.
“Water
flowing”
noise
Cracking
noise
● Air conditioner is turned on or
turned off just now?
● Air conditioner is turned on or
turned off just now?
19
● Disconnect power, put back
power, and then turn on the
unit again.
● The noise is the sound of
refrigerant flowing inside
the unit, which is a normal
phenomenon.
● This is the sound of friction
caused by expansion and/or
contraction of panel or other
parts due to the change of
temperature.
Malfunction analysis
Error Code
● If an error is present, lights will flash and an error code should be displayed.
Error code
U8
E5
E6
E8
H6
Troubleshooting
It can be eliminated after restarting the unit. If not, please
It can be eliminated after restarting the unit. If not, please
It can be eliminated after restarting the unit. If not, please
It can be eliminated after restarting the unit. If not, please
It can be eliminated after restarting the unit. If not, please
C5
F0
F1
F2
Note:
service.
WARNING
■ If any of the below errors occur, please turn off air conditioner and contact a
certified Technician.
● There’s abnormal sound during operation.
● Air switch trips off frequently.
● Air conditioner gives off burning smell.
● Indoor unit is leaking.
Do not repair product yourself. Please contact a certified HVAC company.
■ If the air conditioner operates under abnormal conditions, it may cause
20
At least 5.9in
Space to the ceiling
Installation dimension diagram
Space to the wall
At least 5.9in
At least 5.9in
Space to the wall
Sp
e
ac
to
le
the
8in
11
on
cti
tru
s
ob
At least
At
t
as
21
Safety precautions for installing and relocating the unit
To ensure safety, please be mindful of the following precautions.
Warning
When installing or relocating the unit, be sure to keep the refrigerant
circuit free from air or substances other than the specified refrigerant.
Any presence of air or other foreign substance in the refrigerant circuit will cause
system pressure rise or compressor rupture, resulting in injury.
Only qualified technicians, should install, move or service this equipment.
Please follow the units nameplate and installation instruction to ensure safe
and accurate operation of product.
If there is a need to recover refrigerant during installation, ensure system is
running in cooling mode. Fully close high pressure service valve (Liquid valve)
and allow to pump-down for 30-40 seconds, then fully close the low pressure
service valve (Gas valve) and immediately remove power from unit. Do not
exceed 1 minute in pump-down otherwise system contamination or breakage
can occur.
Ensure unit is leak free by applying 500psig of dry nitrogen and check all flares
with a liquid bubble solution. Watch carefully for small bubbles indicating a leak.
Do not install unit in a area where corrosive gases or flammable gases exist.
Otherwise premature failure of product can occur, or fire.
Do not use supply (power) cords or extension cords with equipment. This
product must be installed by a certified installer. Wired per NEC codes.
Follow local and national codes for interconnection between indoor and
outdoor units.
22
Tools for installation
1 Level
2 Screw driver
3 Impact drill
4 Drill
5 Pipe expander
6 Torque wrench
7
8 Pipe cutter
9 Leakage detector
10 Vacuum pump
11
12
14 Measuring tape
13
Note:
●
●
Selection of installation location
Indoor unit
Basic requirement
23
Requirements for electric connection
Safety precaution
1. Follow local and national electrical codes when wiring.
2. Ensure proper wire sizing.
3. Follow wiring diagrams
4. Be sure to disconnect power before performing installation or maintenance.
5. Refrigerant can operate at very high temperatures. Please be sure to keep wires
separate from piping.
Grounding requirement
1. Ensure proper grounding
2. Yellow/Green wire is reserved for Ground only
3. Grounding should comply with Local and National codes
24
Installation of indoor unit
Step one: choosing installation location
Provide recommendation to customer for the most ideal location to install unit.
Step two: install wall-mounting frame
1. When hanging wall mounting plate, be sure to set level, once level is set mark
all locations for mounting screws.
Drill holes and use appropriate mounting hardware. (Example: Wall Anchors,
Self Tapping Screws or other)
3. Affix wall mounting plate and ensure no flex from the wall surface to guarantee
secure mounting.
Step three: open piping hole
1. Choose the position of piping hole according to the direction of outlet pipe. The
position of piping hole should be a little lower than the wall-mounted frame,
shown as below.
QC:
QB:
Wall
Space
to the
wall
above
6in
Mark in the middle of it
Left
Φ2.1in
Rear piping hole
Level meter
Wall
Wall
Space
to the
wall
above
6in
Space
to the
wall
above
6in
Left
Φ2.1in
Rear piping hole
Right
Φ2.1in
Rear piping hole
QD:
Wall
Space
to the
wall
above
6in
Mark in the middle of it
Level meter
Wall
Space
to the
wall
above
6in
Right
Φ2.1in
Rear piping hole
QE:
Mark in the middle of it
Left
Φ2.1in
Rear piping hole
Level meter
Wall
Wall
Space
to the
wall
above
6in
Space
to the
wall
above
6in
Right
Φ2.1in
Rear piping hole
Mark in the middle of it
Left
Φ2.7in
Rear piping hole
Level meter
Wall
Space
to the
wall
above
6in
Right
Φ2.7in
Rear piping hole
2. Open a piping hole with the diameter of Φ2.1in or Φ2.7in on the selected outlet pipe
position.In order to drain smoothly, slant the piping hole on the wall slightly
downward to the outdoor side with the gradient of 5-10°.
25
Installation of indoor unit
Indoor
Note:
outdoor
● Dust prevention is recommended
when drilling hole for piping.
● It is recommended to purchase a
PVC sleeve to protect piping in the
wall. (Supplied by after-market
suppliers)
Φ2.1in/
Φ2.7in
5-10
Step four: outlet pipe
2. Choose which locations piping
must go, if left, right or bottom cut
off ABS plate to access.
1. The pipe can be led out in the
direction of right, rear right, left or
rear left.
left
right
left
rear right
rear left
right
cut off
the hole
1. Position flare and fitting together.
2. Tighten flare by hand.
3. Use torque wrench to finalize
mechanical connection between flare and
fitting.
26
pipe joint
union nut
pipe
Installation of indoor unit
open-end
wrench
union nut
torque wrench
pipe
Hex nut diameter Tightening torque (N.m)
15~20
1/4''
30~40
3/8''
45~55
1/2''
60~65
5/8''
70~75
3/4''
indoor pipe
4. Wrap the indoor pipe and joint of connection pipe with insulating pipe, and
then wrap it with tape.
insulating pipe
Step six: install drain hose
1. Connect the drain hose to the outlet pipe of
indoor unit.
drain hose
outlet pipe
2. Bind the joint with tape.
outlet
pipe
tape
drain hose
drain hose
Note:
● Add insulating pipe in the indoor
drain hose in order to prevent
condensation.
insulating pipe
Step seven: connect wire of indoor unit
screw
1. Open the panel, remove the screw
on the wiring cover and then take
down the cover.
wiring cover
27
Installation of indoor unit
2. Ensure that power wires are routed through
the proper opening behind the unit.
cable-cross
hole
power connection
wire
3. Remove wire strain relief. Connect each wire to the corresponding terminal.
Tighten the terminals to ensure solid connections.
09K
12K 18K 24K :
N(1)
2
3
green
white black red
(brown) (yellow(blue)
green)
Outdoor unit connection
4.Put wiring cover back and then tighten the screw.
5.Close the panel.
Note:
● All wiring should be done by a certified technician.
for a new one. Avoid extending the wire by yourself.
installation.
● For the air conditioner without plug, an circuit break must be installed in the line.
The circuit break should be all-pole parting and the contact parting distance
should be more than 3mm.
28
Installation of indoor unit
Step eight: bind up pipe
1. Combine pipes, wires and drain line
in a UV rated line set covering
system.
indoor and
indoor unit
gas
pipe
connection pipe
drain hose
band
outdoor power cord
indoor power cord
liquid pipe
band
3. Bind them evenly.
4. The liquid pipe and gas pipe should
be bound separately at the end.
drain hose
2. Be sure to allow for extra line set,
wire and drain to connect to outdoor
unit.
Be sure that drain pipe is routed at
the bottom of the binded pipe. To
ensure proper drainage.
Step nine: hang the indoor unit
1. Put the bound pipes in the wall pipe and then make them pass through the wall
hole.
2. Hang the indoor unit on the wall-mounting frame.
3. Stuff the gap between pipes and wall hole with sealing gum.
4. Fix the wall pipe.
indoor
wall pipe
upper hook
outdoor
sealing gum
lower hook of
wall-mounting frame
Note:
● Do not bend the drain hose too excessively in order to prevent blocking.
29
Check after installation
Items to be checked
Possible malfunction
The unit may drop, shake or emit noise.
Have you done the refrigerant leakage
test?
(heating) capacity.
It may cause condensation and water
dripping.
Is water drained well?
It may cause condensation and water
dripping.
Is the voltage of power supply according to the voltage marked on the
nameplate?
It may cause malfunction or damaging
the parts.
Is electric wiring and pipeline installed
correctly?
It may cause malfunction or damaging
the parts.
Is the unit grounded securely?
It may cause electric leakage.
Does the power cord follow the speci-
It may cause malfunction or damaging
the parts.
Is there any obstruction in the air inlet
and outlet?
(heating) capacity.
The dust and sundries caused during
installation are removed?
It may cause malfunction or damaging
the parts.
The gas valve and liquid valve of
connection pipe are open completely?
(heating) capacity.
Is the inlet and outlet of piping hole
been covered?
It may cause insufficient cooling
(heating) capacity or waster eletricity.
Test operation
1. Preparation of test operation
● The client approves the air conditioner.
● Specify the important notes for air conditioner to the client.
2. Method of test operation
● Put through the power, press ON/OFF button on the remote controller to start
operation.
● Press MODE button to select AUTO, COOL, DRY, FAN and HEAT to check
whether the operation is normal or not.
● If the ambient temperature is lower than 16℃(61°F) , the air conditioner can’t
start cooling.
30
Configuration of connection pipe
1. Standard length of connection pipe
● 15ft, 22.5ft,24ft
2.Min. length of connection pipe is 9Ft.
3.Max. length of connection pipe.
Max. length of connection pipe
Cooling
capacity
5000Btu/h
7000Btu/h
9000Btu/h
12000Btu/h
18000Btu/h
Max. length
of connection pipe
Unit: ft
Cooling
capacity
24000Btu/h
45
28000Btu/h
45
36000Btu/h
45
42000Btu/h
60
48000Btu/h
75
Max. length
of connection pipe
75
90
90
90
90
4. Additional refrigerant may be required when extending the line-set.
● After the line-set has been extended 33ft past standard length of 25ft,
adding additional 5ml of refrigerant oil for each additional 16ft.
● The calculation method of additional refrigerant charging amount (on the basis
of liquid pipe):
Additional refrigerant charge amount = extended length of liquid line x
required additional amount per foot.
● Basing on the length of standard pipe, add refrigerant according to the
requirement as shown in the table. The additional refrigerant charging amount
per foot is different according to the diameter of liquid pipe. See the
following sheet.
31
Additional refrigerant charging amount for R410A
Diameter of connection pipe
Outdoor unit throttle
Liquid pipe(mm)
Gas pipe(mm)
Φ6
Φ9.52 or Φ12
15
20
Φ6 or Φ9.52
Φ16 or Φ19
15
50
Φ12
Φ19 or Φ22.2
30
120
Φ16
Φ25.4 or Φ31.8
60
120
Φ19
_
250
250
Φ22.2
_
350
350
Cooling only(g/m) Cooling and heating(g/m)
32
Pipe expanding method
Note:
Improper pipe expanding is the main cause of refrigerant leakage. Please expand
the pipe according to the following steps:
A: Cut the pipe
E: Expand the port
● Expand the port with expander.
the distance of indoor unit and
outdoor unit.
● Cut the required pipe with pipe cutter.
hard
mold
expander
pipe
pipe
pipe cutter
leaning
uneven
Note:
● "A" is different according to the
diameter, please refer to the sheet
below:
burr
A(in)
Outer diameter
B: Remove the burrs
● Remove the burrs with shaper and
prevent the burrs from getting into
the pipe.
pipe
shaper
downwards
Max
Min
(1/4")Φ6-6.35
0.05
0.03
(3/8")Φ9.52
0.06
0.04
(1/2")Φ12-12.7
0.07
0.04
(5/8")Φ15.8-16
0.94
0.09
F: Inspection
● Check the quality of expanding port.
If there is any blemish, expand the
port again according to the steps
above.
C: Put on suitable insulating pipe
D: Put on the union nut
● Remove the union nut on the indoor
connection pipe and outdoor valve;
install the union nut on the pipe.
smooth surface
improper expanding
union pipe
leaning
pipe
the length is equal
33
damaged
surface
crack
uneven
thickness
Friedrich Air Conditioning Co.
10001 Reunion Place, Suite 500 • San Antonio, Texas 78216
1.800.541.6645
www.friedrich.com
66129933950
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
