Siemens SIMATIC NET CP 1243-1 DNP3, SIMATIC NET CP 1243-1 IEC, SIMATIC NET S7-1200 User manual

Siemens SIMATIC NET CP 1243-1 DNP3, SIMATIC NET CP 1243-1 IEC, SIMATIC NET S7-1200 User manual
CP 1243-1 DNP3, CP 1243-1 IEC
___________________
Preface
1
___________________
Application and properties
SIMATIC NET
S7-1200 - Telecontrol
CP 1243-1 DNP3,
CP 1243-1 IEC
Operating Instructions
2
___________________
Requirements for use
3
___________________
LEDs and connectors
Installation, connecting up,
4
___________________
commissioning
5
___________________
Configuration and operation
6
___________________
Diagnostics and upkeep
7
___________________
Technical specifications
A
___________________
Approvals
B
___________________
Dimension drawings
C
___________________
Documentation references
02/2014
C79000-G8976-C312-02
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Industry Sector
Postfach 48 48
90026 NÜRNBERG
GERMANY
C79000-G8976-C312-02
Ⓟ 02/2014 Technical data subject to change
Copyright © Siemens AG 2013 - 2014.
All rights reserved
Preface
Validity of this manual
This document contains information on the following telecontrol products:
● CP 1243-1 DNP3
Article number6GK7 243-1JX30-0XE0
Hardware product version 1
Firmware version V1.1
The CP 1243-1 DNP3 is the communications processor for connecting SIMATIC S7-1200
to control centers using the DNP3 protocol.
● CP 1243-1 IEC
Article number6GK7 243-1PX30-0XE0
Hardware product version 1
Firmware version V1.1
The CP 1243-1 IEC is the communications processor for connecting SIMATIC S7-1200 to
control centers using the IEC 60870-5 protocol.
Figure 1
CP 1243-1 DNP3
CP 1243-1 DNP3, CP 1243-1 IEC
Operating Instructions, 02/2014, C79000-G8976-C312-02
3
Preface
The CP 1243-1 IEC has the same outer design as the CP 1243-1 DNP3 apart from the
inscriptions for the product name, article number, firmware version and possibly hardware
product version.
At the top right behind the hinged cover of the module housing, you will see the hardware
product version printed as a placeholder "X" after the article number. If the printed text is, for
example, "X 2 3 4", "X" would be the placeholder for hardware product version 1.
Product names and abbreviations
In this document, you will find the following designations used for the product being
described here:
● CP
Simplified naming of the two following products:
– CP 1243-1 DNP3
– CP 1243-1 IEC
This short form is used in this manual if the property being described in the particular
context applies to both modules.
● DNP3-CP
Short form for the CP 1243-1 DNP3 (6GK7 243-1JX30-0XE0)
● IEC-CP
Short form for the CP 1243-1 IEC (6GK7 243-1PX30-0XE0)
Purpose of the manual
This manual describes the properties of both these modules and supports you when
installing and commissioning them.
The required configuration steps are described as an overview and there are explanations of
the relationship between firmware functions and configuration.
You will also find information about the diagnostics options of the device.
New in this issue
● Inclusion of the CP 1243-1 IEC
● New firmware version of the DNP3 CP with bugs fixed
Make sure that the DNP3 CP with firmware version V1.0 or V1.1 is compatible with the
firmware of the CPU, refer to the section Hardware requirements (Page 17).
● Editorial revision
As a supplement to the STEP 7 information system, note the information on the functions
and parameters in the section Notes on configuring individual functions (Page 42).
CP 1243-1 DNP3, CP 1243-1 IEC
4
Operating Instructions, 02/2014, C79000-G8976-C312-02
Preface
Replaced documentation
This manual replaces the manual release 07/2013.
Current manual release on the Internet
You will also find the current version of this manual on the Internet pages of Siemens
Industry Online Support in the directory of the relevant CP. This is located below the
directory with the following entry ID:
16514597 (http://support.automation.siemens.com/WW/view/en/16514597)
Required experience
To install, commission and operate the CP, you require experience in the following areas:
● Automation engineering
● Setting up the SIMATIC S7-1200
● SIMATIC STEP 7 Basic / Professional
● DNP3 protocol or protocol according to IEC 60870-5
Requirements for use of the module
You will find the requirements for using the module in the section Hardware requirements
(Page 17).
Sources of information and other documentation
You will find an overview of further reading and references in the Appendix of this manual.
SIMATIC NET glossary
Explanations of many of the specialist terms used in this documentation can be found in the
SIMATIC NET glossary.
You will find the SIMATIC NET glossary here:
● SIMATIC NET Manual Collection or product DVD
The DVD ships with certain SIMATIC NET products.
● On the Internet under the following entry ID:
50305045 (http://support.automation.siemens.com/WW/view/en/50305045)
CP 1243-1 DNP3, CP 1243-1 IEC
Operating Instructions, 02/2014, C79000-G8976-C312-02
5
Preface
License conditions
Note
Open source software
Read the license conditions for open source software carefully before using the product. The
acceptance of the disclaimers of liability and warranty it contains is a clear precondition of
the use of open source software.
You will find license conditions in the following documents on the supplied data medium:
● DOC_OSS-S7CMCP_74.pdf
● DOC_OSS-CP1243-1DNP3-IEC_76.pdf
Security information
Siemens provides automation and drive products with industrial security functions that
support the secure operation of plants or machines. They are an important component in a
holistic industrial security concept. With this in mind, our products undergo continuous
development. We therefore recommend that you keep yourself informed with respect to our
product updates. Please find further information and newsletters on this subject at:
http://support.automation.siemens.com.
To ensure the secure operation of a plant or machine it is also necessary to take suitable
preventive action (e.g. cell protection concept) and to integrate the automation and drive
components into a state-of-the-art holistic industrial security concept for the entire plant or
machine. Any third-party products that may be in use must also be taken into account.
Please find further information at: http://www.siemens.com/industrialsecurity
Training, Service & Support
You will find information on Training, Service & Support in the multi--language document
"DC_support_99.pdf" on the data medium supplied with the documentation.
CP 1243-1 DNP3, CP 1243-1 IEC
6
Operating Instructions, 02/2014, C79000-G8976-C312-02
Table of contents
