Axiom Pro
Quick Start Guide
Axiom Pro
Quick Installation
Windows XP/Vista Users
Quick Start Guide
1
1
Axiom Pro is a class-compliant device that offers basic functionality on Windows XP
and Vista systems without having to install additional drivers. You can simply connect
Axiom Pro to your computer, switch on the computer and the controller, and be
ready to go.1
However, M-Audio strongly recommends that Windows users install the Axiom Pro
drivers from the included CD-ROM or (if Internet access is available) the most recent
drivers from the M-Audio website. These drivers add functionality and allow you to:
(1) use Axiom Pro with more than one application at the same time, (2) use long system
exclusive (SysEx) commands, and (3) simultaneously use other class-compliant USB
devices with audio capabilities.
The M-Audio driver installation procedure for Windows is described in section two of
this guide.
Mac OS X Users
The class-compliant drivers built into Mac OS X provide full support for all features of
Axiom Pro. This means that no additional M-Audio drivers are necessary (or available)
when using Axiom Pro on Mac OS X—simply connect the controller keyboard to the
computer using the supplied USB cable, configure your audio software and start making
music.
M-Audio HyperControl TM
An important new feature in the Axiom Pro line of controllers is the support of M-Audio’s
HyperControl system. HyperControl allows for bi-directional communication between
Axiom Pro and your audio software, keeping your keyboard and software synchronized
at all times. Furthermore, HyperControl gives you “out of the box” control over many
host applications (such as Pro Tools, Logic Pro, Reason, and Cubase) and automatically
configures knobs, buttons, and other controls to work with your software.
Since HyperControl integration varies from one application to another, the installation
and usage of HyperControl Mode is covered in separate User Guides for each
supported application. To learn more about how to install, configure and use
HyperControl, see the application-specific HyperControl User Guide on the included
CD-ROM, or the Axiom Pro support pages on www.m-audio.com.
The HyperControl installation files for applications supported at time of print are
included on the Axiom Pro CD-ROM. Check www.m-audio.com for HyperControl
installation files for additional applications and updates.
AxiomPro_QSG.indd 1
11/14/08 11:29:24 AM
2
Quick Start Guide
1
Axiom Pro
I MPORTANT:
hen using Axiom Pro class-compliant (i.e., without installing drivers) in Windows,
W
the computer will search for the M-Audio DFU (device firmware upgrade tool)
and display a Found New Hardware Wizard. The M-Audio DFU is a component
of Axiom Pro that is enabled when the M-Audio drivers are installed, but is not
necessary for class-compliant operation. You have the following options:
A. C
ancel the Found New Hardware Wizard and start using Axiom Pro
immediately.
he Found New Hardware Wizard will appear every time your computer
T
detects that the device is connected (e.g. upon computer or device restart, or
disconnecting/reconnecting Axiom Pro).
B. F
ollow the Found New Hardware Wizard until it gives the option not to be
prompted to install this hardware again.
Windows Vista Users:
• Select “Don’t show this message again for this device” in the first screen
that appears.
• Click “Continue” in the confirmation screen that follows.
Windows XP Users:
• In the first screen, select ”No, not this time” and click “Next”
• In the second screen, select “Install the software automatically” and click
“Next”
• Finally, make sure the check box labeled “Don’t prompt me again to
install this software” is active, then click Finish.
C. Install the M-Audio drivers as described in the “Installation Instructions for
Windows XP and Vista” section of this Quick Start Guide. After these drivers
have been installed, the Found New Hardware Wizard for the M-Audio DFU
will no longer be displayed.
NOTE: M-Audio strongly recommends that Windows XP and Vista users
install the Axiom Pro drivers by following the instructions in the following
section of this guide.
AxiomPro_QSG.indd 2
11/14/08 11:29:24 AM
Axiom Pro
Quick Start Guide
Installation Instructions for
Windows XP and Vista
3
2
Please make sure that Axiom Pro is disconnected from your computer when
the M-Audio drivers are being installed. The following instructions will indicate when you
should connect the controller keyboard to your computer.
1.We recommend that you download the most recent drivers by going to the
Support > Drivers & Updates page at www.m-audio.com. This ensures that you have
the newest drivers available. If you do not have Internet access, insert the Axiom Pro
CD-ROM into your computer to install the drivers that came with your controller.
2.
<
If you are installing drivers from the Axiom Pro CD-ROM, the computer will
automatically display the interactive install screen when the CD-ROM is inserted. If
your computer fails to launch this application, you can manually start it by clicking
on Start > My Computer 2 > Axiom Pro. Next, select “Axiom Pro Driver Installer”
from the menu and click “Install.”
<
If you are installing drivers from www.m-audio.com, simply double-click the file once
it has finished downloading.
Follow the driver installer’s on-screen direction prompts.
3.At various points in this installation process, you may be notified that the driver being
installed has not passed Windows Logo Testing, or asked whether the program you wish
to run is a trusted application. Click “Continue Anyway” (Windows XP) 1 or “Install”
(Windows Vista) 2 to proceed with installation.
1
2
2
If you are using Windows Vista, “My Computer” will be labeled “Computer” in this step.
AxiomPro_QSG.indd 3
11/14/08 11:29:24 AM
4
Quick Start Guide
Axiom Pro
4. Click “Finish” once the installer has completed the installation.
5.Use the provided USB cable to connect Axiom Pro to an available USB port on your
computer.
6.Make sure that the power switch on the back of the keyboard is in the “on” position.
If you are using a Windows Vista computer, your Axiom Pro is now ready to use. If
you are using Windows XP, proceed to steps 7-10.
7.Windows XP will identify the new device and will ask if you want to search the
Internet for a driver. Select “No, not this time,” and click “Next” to continue. 3
3
8.Windows XP will display a Found New Hardware Wizard. Select “Install the
software automatically,” and click “Next” to continue. 4
4
9.Once the Wizard has completed, click “Finish.” You may be presented with a second
Found New Hardware Wizard. If so, then repeat steps 7-9.
10. W
hen the installation is complete, you will see a message stating “Your new
hardware is installed and ready to use.”
AxiomPro_QSG.indd 4
11/14/08 11:29:25 AM
Axiom Pro
Quick Start Guide
5
3
Software Setup and Configuration
Hosted Mode
When using Axiom Pro in “hosted” mode (i.e., with a computer), you may need to set up
your music software to send and receive MIDI data from Axiom Pro. This process varies
from application to application, but is usually done through a “Preferences” or “Setup”
menu. Refer to your software’s documentation to learn how to do this.
You may also need to configure the application’s MIDI tracks and/or HyperControl
integration to send and receive signals from the correct input and output ports of
Axiom Pro. The controller will appear as four input ports and two output ports:
MIDI Input sources (as seen in your music software)
3
• Axiom Pro 61 4 USB A In
The various controls (keys, pads, buttons, knobs, etc.) of Axiom Pro generate
MIDI data on this port by default, and selecting this port within your music
software will allow you to record this data. In most cases, this port should be
selected to record your performances.
• Axiom Pro 61 HyperControl In
This port is reserved for HyperControl data only. To learn more about
HyperControl, see the application-specific HyperControl User Guide on the
included CD-ROM, or the Axiom Pro support pages on www.m-audio.com.
• Axiom Pro 61 MIDI In
This corresponds to the hardware MIDI Input port on the back of the keyboard.
•
AxiomPro_QSG.indd 5
xiom Pro 61 USB B In
A
This corresponds to USB MIDI port B within the Axiom Pro keyboard. If you
have configured any of the Axiom Pro controls to transmit data on this port,
you will need to select “Axiom Pro 61 USB B In” within you music software to
record the data generated by these controls. Please see the Axiom Pro User
Guide to learn how this port can be selected and when it can be used.
11/14/08 11:29:25 AM
6
Quick Start Guide
Axiom Pro
“MIDI Output” destinations (as seen in your music software) 3
•
Axiom Pro 61 MIDI Out
This corresponds to the hardware MIDI Output port on the back of the
keyboard.
•
Axiom Pro 61 HyperControl Out
This port is reserved for HyperControl data only. To learn more about
HyperControl, see the application-specific HyperControl User Guide on the
included CD-ROM, or the Axiom Pro support pages on www.m-audio.com.
Mac OS X 10.4 (Tiger) users:
Please note that in Mac OS X 10.4, Axiom Pro port names are listed
numerically (i.e., “Port 1”, “Port 2”, etc.) rather than by name (“USB A In”,
“HyperControl In”, etc.) The following table indicates how the numbers
map to Axiom Pro ports within your software
3
MIDI Input Sources
Axiom Pro 61 Port 1
Axiom Pro 61 USB A In
Axiom Pro 61 Port 2
Axiom Pro 61 HyperControl In
Axiom Pro 61 Port 3
Axiom Pro 61 MIDI In
Axiom Pro 61 Port 4
Axiom Pro 61 USB B In
MIDI Output Sources
Axiom Pro 61 Port 1
Axiom Pro 61 MIDI Out
Axiom Pro 61 Port 2
Axiom Pro 61 HyperControl Out
These MIDI port names will display the corresponding number of keys, based on
the Axiom Pro model you use: 25, 49 or 61.
4
Standalone Mode
When using Axiom Pro in standalone mode (i.e., without a computer), you must connect
an optional 9V DC, 500mA power supply to the power socket on the back of the
keyboard. This power supply can be purchased from the M-Audio webstore
(http://store.m-audio.com).
Next, connect the MIDI Output port of Axiom Pro to your external device’s MIDI Input
port. The “Connection Diagram” section of the Axiom Pro User Guide (located on the
Axiom Pro CD-ROM) covers this subject in detail.
AxiomPro_QSG.indd 6
11/14/08 11:29:25 AM
Axiom Pro
Quick Start Guide
7
For additional information about using Axiom Pro, please refer to the User Guide found
on the Axiom Pro CD-ROM. To learn more about how to install, configure and use
HyperControl, see the HyperControl User Guide for your specific audio application
found on the included CD-ROM, or the Axiom Pro support pages on
www.m-audio.com.
The HyperControl installation files for applications supported at time of print are
included on the Axiom Pro CD-ROM. Check www.m-audio.com for HyperControl
installation files for additional applications and updates.
Additional Information and Support
4
The M-Audio website (www.m-audio.com) contains the latest drivers as well
as useful links to forums, news stories, FAQs, and technical support. We
recommend checking this site regularly to ensure you have the latest drivers and most
up-to-date information about your M-Audio products.
Warranty
Warranty Terms
5
M-Audio warrants products to be free from defects in materials and workmanship, under
normal use and provided that the product is owned by the original, registered user. Visit
www.m-audio.com/warranty for terms and limitations applying to your specific product.
Warranty Registration
Immediately registering your new M-Audio product entitles you to full warranty coverage
and helps M-Audio develop and manufacture the finest quality products available.
Register online at www.m-audio.com/register to receive FREE product updates and for
the chance to win M-Audio giveaways.
AxiomPro_QSG.indd 7
11/14/08 11:29:25 AM
8
Quick Start Guide
Axiom Pro
ESD and Fast Transient may cause the unit to temporarily malfunction. Switch off and on
again to restore normal operation.”
WARNING: This product contains chemicals, including lead, known to the State of
California to cause cancer, and birth defects or other reproductive harm. Wash hands
after handling.
Axiom Pro
Tested to comply with
FCC standards
FOR HOME OR STUDIO USE
© 2008 Avid Technology, Inc. All rights reserved. Product features, specifications,
system requirements and availability are subject to change without notice. Avid,
M-Audio, HyperControl and Axiom Pro are either trademarks or registered trademarks
of Avid Technology, Inc. All other trademarks contained herein are the property of their
respective owners.
AxiomPro_QSG.indd 8
11/14/08 11:29:27 AM
M-Audio USA
M-Audio Germany
Technical Support
Technical Support
5795 Martin Rd., Irwindale, CA 91706
web. . . . . . . . . . . . . . . www.m-audio.com/tech
tel (pro products) . . . . . . . . . . . (626) 633-9055
tel (consumer products). . . . . . . (626) 633-9066
fax (shipping). . . . . . . . . . . . . . (626) 633-9032
Sales
e-mail. . . . . . . . . . . . . . . . [email protected]
tel. . . . . . . . . . . . . . . . . . . 1(866) 657-6434
fax . . . . . . . . . . . . . . . . . . . (626) 633-9070
Web. . . . . . . . . . . . . . . . . www.m-audio.com
M-Audio U.K.
Kuhallmand 34, D-74613 Ohringen, Germany
email . . . . . . . . . . . . . . . [email protected]
tel. . . . . . . . . . . . . . . +49 (0)7941 - 9870030
tel. . . . . . . . . . . . . . . +49 (0)7941 - 98 70070
Sales
e-mail. . . . . . . . . . . . . . . . . [email protected]
tel. . . . . . . . . . . . . . . . +49 (0)7941 98 7000
fax . . . . . . . . . . . . . . . +49 (0)7941 98 70070
Web. . . . . . . . . . . . . . . . . . www.m-audio.de
M-Audio Canada
1400 St-Jean Baptiste Ave. #150, Quebec City,
Quebec G2E 5B7, Canada
Avid Technology | M-Audio
Pinewood Studios, Pinewood Road
Iver Heath, Bucks, SL0 0NH
Technical Support
Technical Support
e-mail. . . . . . . . . . . . . . [email protected]
tel (Mac and PC support). . . +44 (0)1753 658630
e-mail. . . . . . . . . . . . [email protected]
tel. . . . . . . . . . . . . . . . . . . . (418) 872-0444
fax . . . . . . . . . . . . . . . . . . . (418) 872-0034
Sales
Sales
tel. . . . . . . . . . . . . . . . +44 (0) 1753 659 590
Web. . . . . . . . . . . . . . . . . www.maudio.co.uk
e-mail. . . . . . . . . . . . [email protected]
tel. . . . . . . . . . . . . . . . . . . . (866) 872-0444
fax . . . . . . . . . . . . . . . . . . . (418) 872-0034
Web. . . . . . . . . . . . . . . . . . . www.m-audio.ca
Benelux
M-Audio Japan
Technical Support
Belgium tel. . . . . . . . . . . . . . +32 22 54 88 93
Holland tel . . . . . . . . . . . . . +31 35 625 0097
M-Audio France
Avid Technology K.K. | M-Audio
4F ATT Bldg. 2-11-7 Akasaka, Minato-ku Tokyo
107-0052 Japan
製品をお持ちのお客様|Customer Support &
Avid Technology | M-Audio
Pinewood Studios, Pinewood Road
Iver Heath, Bucks, SL0 0NH
Technical Support
Renseignements Commerciaux
tel. . . . . . . . . . . . . . . . . . . . 0 810 001 105
email . . . . . . . . . . . . . . . . . . [email protected]
Assistance Technique
PC . . . . . . . . . . . . . . . . . . . 0 820 000 731
Mac. . . . . . . . . . . . . . . . . . . 0 820 391 191
e-mail (PC). . . . . . . . . . . . . [email protected]
email (Mac). . . . . . . . . . . . . . . [email protected]
fax . . . . . . . . . . . . . . . . +33 (0)1 72 72 90 52
Web. . . . . . . . . . . . . . . . . エムオーディオ/アビッドテクノロジー株式会社
〒107-0052 東京都港区赤坂 2-11-7 ATT新館ビル4F
online . . . . . . . . .http://www.m-audio.jp/support
tel . . . . . . . . . . . . . . . . . . . . 03-3505-4034
製品をお持ちでないお客様|Pre Sales
e-mail . . . . . . . . . . . . . . . . [email protected]
tel . . . . . . . . . . . . . . . . . . . . 03-3505-7963
fax . . . . . . . . . . . . . . . . . . . 03-3505-3417
Web . . . . . . . . . . . . . . . . . . . www.m-audio.jp
www.m-audio.com
MP12-22225A0
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
