This Owner's Guide provides specific operating
instructions for your model. Use your Beverage Cooler
only as instructed in this guide. These instructions are
not meant to cover every possible condition and situation
that may occur. Common sense and caution must be
practiced when installing, operating, and maintaining any
appliance.
lease read all instructions before using this Beverage
y iti on с
s is the safety alert symbol. It is used to alert
you to potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible injury
or death.
del and Seri
Record the model and serial numbers in the space
provided below. The serial plate is located on the upper
left wall inside the cabinet.
DANGER indicates an imminently hazardous situation
“which, if not avoided, will result in death or serious
‘injury.
ARNING indicates a potentially hazardous situation
“which, if not avoided, could result in death or serious
injury.
CAUTION indicates a potentially hazardous situation
“which, if not avoided, may result in minor or moderate
injury.
MPORTANT indicates installation, operation or
maintenance information which is important but not
hazard-related.
For Your Safety
Do not store or use gasoline, or other flammable
vapors and liquids in the vicinity of this or any other
appliance. Read product labels for flammability and
other warnings.
Ctric
The beverage cooler m
ust be plugged into
Amp, AC only electrical outlet. The power
cord of the appliance is equipped with a three-
prong grounding plug for your protection against
electrical shock hazards. It must be plugged
directly into a properly grounded three prong
receptacle. The receptacle must be installed in
accordance with local codes and ordinances.
Consult a qualified electrician. Avoid connecting
refrigerator to a Ground Fault Interruptor (GFI)
circuit. Do not use an extension cord or
adapter plug.
If the power cord is damaged, it should be
replaced by an authorized service technician to
prevent any risk.
Never unplug the appliance by pulling on the
power cord. Always grip the plug firmly, and
pull straight out from the receptacle to prevent
damaging the power cord.
Unplug the appliance before cleaning and before
replacing a light bulb to avoid electrical shock.
Performance may be affected if the voltage
varies by 10% or more. Operating the unit with
insufficient power can damage the compressor.
Such damage is not covered under your warranty.
Do not plug the appliance into an electrical outlet
controlled by a wall switch or pull cord to prevent
the appliance from being turned off accidentally.
e Destroy carton, plastic bags, and any exterior
wrapping material immediately after the wine
cooler is unpacked. Children should never use
these items to play. Cartons covered with rugs,
bedspreads, plastic sheets or stretch wrap may
become airtight chambers, and can quickly cause
suffocation.
e Remove all staples from the carton. Staples can
cause severe cuts, and destroy finishes if they
come in contact with other appliances or furniture.
e An empty, discarded appliance is a very dangerous
attraction to children.
e Remove the door(s) of any appliance that is not in
use, even if it is being discarded.
© Do not, under Де
any circumstances, |
cut, remove, e
or bypass the CL
grounding prong. /
Risk of child entrapment
Child entrapment and suffocation are not problems
of the past. Junked or abandoned appliances are still
dangerous — even if they will sit for “just a few days”. If
you are getting rid of your old appliance, please follow
the instructions below to help prevent accidents.
We strongly encourage responsible appliance recycling/
disposal methods. Check with your utility company or
visit www.recyclemyoldfridge.com for more information
on recycling your old appliance.
cooler:
e Remove doors.
e [eave shelves in place so children may not easily
climb inside.
e Have refrigerant removed by a qualified service
technician.
This Use & Care Guide provides general operating
instructions for your model. Use the appliance only as
e Wash any removable parts of the beverage cooler
interior, and exterior with mild detergent and warm
liance, follow these im ortant fi st steps.
appliance, follow t ‘mp г Р water. Wipe dry. Do not use harsh cleaners on these
Location surfaces.
e Choose a place that is near a grounded electrical e Do not use razor blades or other sharp instruments,
outlet. Do Not use an extension cord or an adapter which can scratch the appliance surface when
plug. removing adhesive labels. Any glue left from the tape
can be removed with a mixture of warm water and
mild detergent, or touch the residue with the sticky
side of tape already removed. Do not remove the
es For optimal performance, it is recommended
that you install the appliance where the ambient
temperature is between 70 and 78 degrees
fahrenheit. serial plate.
es Allow space around the unit for good air circulation. Important Safeguards: Do not store food in your wine
Leave a 2 inch space on the back and sides of the cooler as interior temperature may not get cool enough
wine cooler for adequate circulation. to prevent spoilage. In summer months or areas of high
humidity, the glass door may build up moisture. To
s Be sure the appliance stays in the upright position remove the moisture, wipe it away.
during transport.
e Keep the appliance from any hazardous or
combustible agents. 1. Place handle over the two mounting studs located at
top of door.
2. Use hex head screw driver or allen wrench to tighten
set screws from bottom to secure handle to door.
The exterior walls of the beverage cooler may become
quite warm as the compressor works to transfer heat
from the inside. Temperatures as much as 30° F
warmer than room temperature can be expected. For
this reason it is particularly important in hotter climates
to allow enough space for air circulation around your
appliance.
Mounting stud
Locate handle
Levelin a ——— _ Set screws
The beverage cooler must have all bottom corners resting
firmly on solid floor. The floor must be strong enough
to support a fully loaded beverage cooler. NOTE: Itis
Very Important for your appliance to be level in order to
function properiy. If the appliance is not leveled during
installation, the door may be misaligned and not close
or seal properiy, causing cooling, frost, or moisture
problems.
To Level You
After removing all interior and exterior packaging
materials, use a carpenter's level to level the beverage
cooler from front-to-back. Adjust the leveling legs in
front, V2 bubble higher, so that the door closes easily
when left halfway open.
The glass door can be opened from left to right and vice
versa. Should you desire to change the opening direction,
please follow these instructions.
All parts removed must be saved to do the
reinstallation of the door.
1. Remove top cap. Remove the three screws that hold
the upper hinge (right side) to the top of the cabinet.
See Fig. 1.
2. Carefully remove top hinge (See Fig. 1.), then lift the
door up off of bottom hinge and place it on a padded
surface to prevent scratching it. See Fig. 2.
3. Remove the three button plugs from the upper left
corner of the cabinet and transfer them to the holes
on the opposite side. Be sure to press the button
plugs firmly into the holes. See Fig. 1.
4. Remove three screws that hold the bottom hinge to
lower end of cabinet. Remove the three button plugs
from lower LH corner and transfer to holes where
bottom hinge was just removed. See Fig. 3.
5. Unscrew pins from both hinges and transfer to
threaded hole on opposite side. See Fig. 4. Re-install
bottom hinge in LH corner of cabinet using same
three screws removed in Step 4.
6. On bottom edge of door, transfer door stop bracket
and bushing to holes on opposite side. See Fig. 6.
7. On top edge of door, transfer the button plugs and
bushing to hole on opposite side. See Fig. 7.
Place bottom LH corner of door onto lower hinge,
then install top hinge to cabinet. Make sure door
is level and it seals properly against cabinet, then
securely fasten three screws. See Fig. 7. Snap top
cap back onto hinge.
Fig. 2
Button plugs
Fig. 3
e
e
м
Move pin to
opposite hole
(upper and
lower hinges)
Button plugs
Top cap
Screws
Hinge
Bushing
e Install the beverage cooler in
the coolest part of a dry and
ventilated room, out of direct
sunlight and away from heating
ducts or registers. Do not place
the beverage cooler next to heat-
producing appliances such as a
range, oven or dishwasher.
Level the beverage cooler so the door close tightly.
Do not over crowd the beverage cooler or block
cold air vents. Doing so causes the beverage cooler
to run longer and use more energy. Shelves should
not be lined with aluminum foil, wax paper or paper
toweling. Liners interfere with cold air circulation,
making the beverage cooler less efficient.
Wipe containers dry before placing them in the
beverage cooler. This cuts down on moisture build-up
inside the unit.
Organize the beverage cooler to reduce door
openings. Remove as many items as needed at one
time and close the door as soon as possible.
For best performance, allow 4 hours for the wine/beverage cooler to cool down completely. The wine/beverage cooler
will run continuously for the first several hours.
Press this button once to increase temperature 1° F/C.
17 Press this button once to decrease temperature 1° F/C.
1. The beverage cooler can be operated by adjusting the temperature control buttons (up arrow and down arrow)
to the various settings.
2. The new desired temperature will flash on the display for a few seconds and then switch back to the actual
temperature which will gradually change until setpoint is reached.
The temperature range MIN and MAX is 33° - 50°F (1° - 10°C).
emperature display
Temperature display
Light: This button turns the light ON and OFF.
Power: This buttons turns the power ON and OFF.
Press both Light and P
ower button's at the same time to change between Fahrenheit and Celsius temperatures.
e The default temperature for the beverage cooler is 41°F (5°C). The temperature after power failure will be the
temperature set before the power failure.
e 0 prolong the life of compressor, please wait for at least 5 minutes before the unit is restarted after power failure.
Failure display
e If"E" and "F" are displayed, please contact local service personnel for repair.
e If the temperature in the cooler is too low, it will display “Г.
e If the temperature in the cooler is too high, the screen will display "H” and will flash. Under this state, the buzzer
will buzz for 30 seconds. One minute later, the buzzer will continue to buzz for the next 30 seconds. After three
times, the alarm will not buzz any more. You can press any key to cancel sound alarm.
e Storing too many cans or bottles in the cooler may cause the temperature in the cooler to rise temporarily.
pressing the “Lig utton on the control panel. Press
> the button twice to keep the light on when the door is
Multi-position adjustable interior shelves can be moved to closed.
any position for larger or smaller packages. The shipping
spacers that stabilize the shelves for shipping should be Door Lock
removed and discarded. The Beverage Cooler comes This unit is equipped with a lock near the bottom of the
equipped with three glass shelves. door. Two keys are provided. Keep the keys out of reach
of children.
Interior Light (Some models)
The light comes on automatically when the door is
opened. The light can also be turned on and off by
rm ee
eee = =
== = : 6
Beverage Cooler
Handie
Control panel
Glass shelves
Glass door
Light switch
Adjustable legs
Chil be [LRT] +
e Before cleaning, turn the temperature control to OFF,
unplug the beverage cooler and remove the bottles.
e (lean your beberage cooler once every two months.
Inside: Wash inside surfaces of the beverage cooler with
a solution of two tablespoons of baking soda in one quart
(1.136 litres) warm water. Rinse and dry. Wring excess
water out of the sponge or cloth when cleaning in the
area of the controls, or any electrical parts.
Wash the removable parts with the baking soda solution
mentioned above, or mild detergent and warm water.
Rinse and dry. Never use metallic scouring pads,
brushes, abrasive cleaners, or alkaline solutions on any
surface. Do not wash removable parts in a dishwasher.
Outside: Wash the cabinet with warm water and mild
liquid detergent. Rinse well and wipe dry with a clean
e Be sure and protect the door gasket. It should be
kept clean at all times.
e If the plastic parts in the beverage cooler remain
contaminated by oil (animal or vegetable) for a long
period of time, they will age and crack easily. Please
clean them on a regular basis.
Vacation and
Vacations:
If the beverage cooler will not be used for several
months:
e Remove all wine bottles and unplug the power cord.
e (lean and dry the interior thoroughly.
e [eave the wine cooler door open slightly, blocking it
open if necessary, to prevent odor and mold growth.
Moving: When moving the beverage cooler, follow these
guidelines to prevent damage:
e Disconnect the power cord plug from the wall outlet.
e Remove wine bottles and clean the beverage cooler.
e Secure all loose items by taping them securely in
place to prevent damage.
e In a moving vehicle, secure the beverage cooler in an
upright position to prevent movement. Also, protect
the outside of the beverage cooler with a blanket or
similar item.
If leaving the beverage cooler door open while on |
vacation, make certain that children cannot climb inside |
“and become entrapped. |
10-944
9044 (United States)
0-265-8352 (Canada)
Visit our web site at
Beverage Cooler does
not run.
Appliance is plugged into a
circuit that has a ground fault
interrupt.
Temperature control is in the
OFF position.
Appliance may not be plugged
in, or plug may be loose.
House fuse blown or tripped
circuit breaker.
Power outage.
Use another circuit. If you are unsure about the outlet,
have it checked by a certified technician.
See Setting the Temperature Control section.
Ensure plug is tightly pushed into outlet.
Check/replace fuse with a 15 amp time-delay fuse. Reset
circuit breaker.
Check house lights. Call local Electric Company.
Beverage Cooler runs |e
too much e or ‘too o long.
Warm a air r entering the e appliance a causes it tor run more. Ne
| Open doors less often. (ss EA - |
e See “DOOR PROBLEMS” section. TA EA
“Turn control knob to a warmer setting. / Allow several | hours ©
- for the temperature to stabilize. ~~ e
ts emi pérature.
|* Room or outside weather i is — o It 5 ‘normal for the appliance to work harder under these Se
| net RR Do o
с » Appliance t has: recently b been
ce disconnected for: a à period of
| time. о o
5 е Doori is opened t too frequentiy e.
| ortoolong. — не SAN
“|e Door may be slightly open. Je
je Temperature a control is set too o °
| low SOS o
. e. Clean or change gasket. Leaks in 1 the door seal will cause. Ш
- с | oie > |
т e takes. + hours for the e Appliance t to cool | down n completely.
Interior temperature is
too cold.
Temperature control is set too
low.
Turn the contro! to a warmer setting. Allow several hours
for the temperature to stabilize.
Interior temperature is °
| warm. |
je Dooris opened too o frequent °
“| ortoo long. > e
ce e Door may not be seating
—| properly. - uu. ma
“|e Large amou nts of warm or “hot qe
“| food has been stored recently. 5
| | Арте has > recently been |
too y warm.
Temperatur re control is set too .
e o temperature to. stabilize.
mm — Open doors less often. —
|» Se "DOOR PROBLEMS" se
Hime” NN НЛНННН 1
Turn control to a colder setti ing. Allow several hours for re
Warm air entering the appliance causes it ctor run more.
Warm 1 food will cause Beverage Cooler t tor run more until
ne desi red d temperature is reached.
External surface tem-
perature is warm.
The external walls can be as
much as 30°F warmer than
room temperature.
This is normal while the compressor works to transfer heat
from inside the cabinet.
SOU ND AND I IOISE mes |
Louder sound levels
when wine cooler is
on.
Modern beverage coolers have
increased storage capacity and
more stable temperatures.
They require a high efficiency
compressor
This is normal. When the surrounding noise level is low,
you might hear the compressor running while it cools the
interior.
SOUND AND NOISE (continued)
Longer sound levels
when compressor
comes on.
e Appliance operates at higher
pressures during the start of the
ON cycle.
e This is normal. Sound will level off or disappear as refrig-
erator continues to run.
Fan runs when room _
45°.
- | or thermostat has act- — т | Th
Popping or cracking
sound when compres-
sor comes on.
e Metal parts undergo expansion
and contraction, as in hot water
pipes.
e This is normal. Sound will level off or disappear as Bever-
age Cooler continues to run.
Boiling or gurgling
Sm e. pet frigerar nt is crating
sound, like water boil- Sm
Vibrating or rattling
noise.
e Appliance is not level. It rocks
on the floor when it is moved
Signy:
e Level the unit. Refer to leveling instructions in the
“Installation” section.
Snapping sound.
NATER/MOISTURE JF FROST INSIDE BEVER/
AGE COO LE R
Moli istu re forms on
inside walls.
“Weather is hot and humid.
“Door may n not be seating.
properly.
W VATE R / MOISTURE JF FROST OUTSIDE BEVER/
¡GE COOLER
Moistu ire forms on
Je Door may not be seating
+ causing the cold a air
Cooler. from inside the beverage cooler
E to meet warm moist air from
LE С, “outside. LS
ODOR IN BEVERAGE COOLER
Odors i in Beverage e Interior needs to be cleaned.
Cooler. 22 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - = fé EE EEE EEE EEE EERE EERE.
Appliance. is not level. It rocks
on the floor. when it-is moved -
Your appliance is covered by a one year limited warranty. For one year from your original date of
purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove
to be defective in materials or workmanship when such appliance is installed, used and maintained in
accordance with the provided instructions.
Exclusions This warranty does not cover the following:
1. Products with original serial numbers that have been removed, altered or cannot be readily determined.
2. Product that has been transferred from its original owner to another party or removed outside the USA or
Canada.
Rust on the interior or exterior of the unit.
Products purchased “as-is” are not covered by this warranty.
Food loss due to any refrigerator or freezer failures.
Products used in a commercial setting.
Service calls which do not involve malfunction or defects in materials or workmanship, or for appliances
not in ordinary household use or used other than in accordance with the provided instructions.
Service calls to correct the installation of your appliance or to instruct you how to use your appliance.
Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves,
etc.,which are not a part of the appliance when it is shipped from the factory.
10. Service calls to repair or replace appliance light bulbs, air filters, water filters, other consumables, or
knobs, handles, or other cosmetic parts.
11. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip
charges, or mileage expense for service calls to remote areas, including the state of Alaska.
12. Damages to the finish of appliance or home incurred during installation, including but not limited to floors,
cabinets, walls, etc.
13. Damages caused by: services performed by unauthorized service companies; use of parts other than
genuine Electrolux parts or parts obtained from persons other than authorized service companies; or
external causes such as abuse, misuse, inadequate power supply, accidents, fires, or acts of God.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER'S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT
REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES, INCLUDING
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR
OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR. ELECTROLUX SHALL NOT
BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL
EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED
WARRANTY. SOME STATES AND PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES, OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE
LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.
XP
© ©
If You Need Keep your receipt, delivery slip, or some other appropriate payment record to establish the warranty period
Service should service be required. If service is performed, it is in your best interest to obtain and keep all receipts.
Service under this warranty must be obtained by contacting Electrolux at the addresses or phone
numbers below.
This warranty only applies in the USA and Canada. In the USA, your appliance is warranted by Electrolux Major Appliances
North America, a division of Electrolux Home Products, Inc. In Canada, your appliance is warranted by Electrolux Canada Corp.
Electrolux authorizes no person to change or add to any obligations under this warranty. Obligations for service and parts under
this warranty must be performed by Electrolux or an authorized service company. Product features or specifications as described
or illustrated are subject to change without notice.
USA Canada
1.800.944.9044 1.800.265.8352
Electrolux Major Appliances | y Electrolux Canada Corp.
North America
5855 Terry Fox Way
PO. Bon 17378 ЧР В LE Bb Mississauga, Ontario, Canada
Augusta, GA 30907 L5V 3E4
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
