Anker Ergonomic Wireless Vertical Mouse User manual

Anker Ergonomic Wireless Vertical Mouse User manual
Wireless Vertical Mouse
The Anker vertical ergonomic optical mouse is designed to
reduce forearm twisting and the resulting repetitive stress and
pain. The vertical "handshake" position encourages a neutral
wrist and arm alignment for greater comfort and better health.
No finger contortions are needed to operate the easy-to-reach
buttons. The thumb rest has been reshaped to provide even
more comfort over earlier versions, and two next / last page
buttons boost your productivity.
=" Ergonomic — scientific design encourages healthy neutral wrist
and arm positions for smoother movement and less overall
» Wireless — plug in the nano receiver and free yourself from
« Attractive — sleek and simple design
=" Responsive — optical tracking, scroll wheel, and added next /
last page buttons help boost your productivity
Package Contents
1 Anker Vertical Mouse
1 Instruction manual
12.46 USB receiver
Product dimensions 62x 124 x 68 mm
Product weight 102g
DPI 800 / 1200 / 1600DPI
Working voltage 3V
Working current 10mA
Number of buttons 6 (including the scroll wheel)
Lifelong clicks 1 million
Battery type 2 AAA batteries (not included)
Supported system Windows 10 / 8 / 7 / Vista / XP /
Linux, Mac OS X
Identification of Parts
O Scroll Wheel
O Left Button
O Right Button
O DPI Switch Button
O Next Page Button
O Previous Page Button
O LED bar
1. DPI Switch Button: Press this button to adjust the DPI levels
between 800, 1200, and 1600 DPI.
2. Previous Page: Press this button to go back to the previous
page while web browsing.
› 2
3. Next Page: Press this button to go to the next page while web
4. LED bar:
a. When adjusting DPI to the first level (800 DPI), the red LED
bar will blink once; when adjusting to the second level, the
red LED bar will blink twice, etc.
b. When the battery is running low, the LED bar will turn red and
blink every time you move the mouse.
1. Insert 2 AAA batteries (not included) into the battery slot.
2. Remove the nano receiver from the bottom of the mouse, and
insert it into the computer's USB port. The driver will
automatically install.
3. Press any button to activate the mouse.
4. Press the DPI switch to shift to the DPI level appropriate to
your environment. (This step is optional.)
Note: The mouse will enter sleep mode after 8 minutes of being
idle. Please press any button to activate the mouse again.
» 3
Our company provides customers with a warranty of 18
MONTHS from the date of purchase.
Contact Us
For any inquiries or comments concerning our products, please
send an email to [email protected] and we will respond as
soon as possible. If there is a quality related issue with the
product, you may request a REPLACEMENT OR REFUND by
submitting a request at
We're only able to provide after-sales service for purchases made
directly from Anker. If you purchased through a different retailer,
please contact them for any exchange or refund requests.
» 4
Tel: 1-800-988-7973(US)
Service time: Mon - Fri 9:00 — 5:00 PST
Tel: 400-0550-036 (CN)
Service time: Mon — Fri 9:00 — 17:30 CST
Email: [email protected]
