RS-3 PRO
RS-1007 PRO
CAT IV Analog
Clamp meter
Series
Users Manual
• Mode d’emploi
• Bedienungshandbuch
• Manuale d’Uso
• Manual de uso
• Användarhandbok
English
RS-3 PRO
RS-1007 PRO
CAT IV Analog Clampmeter
Series
Users Manual
RS3RS1007_Rev001
© 2009 Amprobe Test Tools.
All rights reserved.
1
Limited Warranty and Limitation of Liability
Your Amprobe product will be free from defects in material and
workmanship for 1 year from the date of purchase. This warranty does not
cover fuses, disposable batteries or damage from accident, neglect, misuse,
alteration, contamination, or abnormal conditions of operation or handling.
Amprobe’s warranty obligation is limited, at Amprobe’s option, to refund
of the purchase price, free of charge repair, or replacement of a defective
product . Resellers are not authorized to extend any other warranty on
Amprobe’s behalf. To obtain service during the warranty period, return the
product with proof of purchase to an authorized Amprobe Test Tools Service
Center or to an Amprobe dealer or distributor. See Repair Section for details.
This warranty is your only remedy . All other warranties - whether express,
implied or statutory - including implied warranties of fitness for a particular
purpose or merchantability, are hereby excluded. Neither Amprobe nor its
parent company or affiliates shall be liable for any special, indirect, incidental
or consequential damages or losses, arising from any cause or theory. Since
some states or countries do not allow the exclusion or limitation of an
implied warranty or of incidental or consequential damages, this limitation of
liability may not apply to you.
Repair
All test tools returned for warranty or non-warranty repair or for calibration
should be accompanied by the following: your name, company’s name,
address, telephone number, and proof of purchase. Additionally, please
include a brief description of the problem or the service requested and
include the test leads with the meter. Non-warranty repair or replacement
charges should be remitted in the form of a check, a money order, credit card
with expiration date, or a purchase order made payable to Amprobe® Test
Tools.
In-Warranty Repairs and Replacement – All Countries
Please read the warranty statement and check your battery before requesting
repair. During the warranty period any defective test tool can be returned to
your Amprobe® Test Tools distributor for an exchange for the same or like
product. Please check the “Where to Buy” section on www.amprobe.com for
a list of distributors near you. Additionally, in the United States and Canada
In-Warranty repair and replacement units can also be sent to a Amprobe®
Test Tools Service Center (see below for address).
Non-Warranty Repairs and Replacement – US and Canada
Non-warranty repairs in the United States and Canada should be sent to a
Amprobe® Test Tools Service Center. Call Amprobe® Test Tools or inquire at
your point of purchase for current repair and replacement rates.
In USA
In Canada
Amprobe Test Tools
Amprobe Test Tools
Everett, WA 98203
Mississauga, ON L4Z 1X9
Tel: 888-993-5853
Tel: 905-890-7600
Fax: 425-446-6390
Fax: 905-890-6866
Non-Warranty Repairs and Replacement – Europe
European non-warranty units can be replaced by your Amprobe® Test Tools
distributor for a nominal charge. Please check the “Where to Buy” section on
www.amprobe.com for a list of distributors near you.
European Correspondence Address*
Amprobe® Test Tools Europe
Beha-Amprobe GmbH
In den Engematten 14
79286 Glottertal, Germany
Tel.: +49 (0) 7684 8009 – 0
*(Correspondence only – no repair or replacement available from this
address. European customers please contact your distributor.)
2
1
2
Analog Clamp Meter
Analog Clamp Meter
NEEDLE
LOCK
3
AMP
NEEDLE
LOCK
AMP
4
100
100
80
V A
80
V A
60
60
5
40
40
20
20
0
e ZERO
6
CAT IV 600V
COM W
Ve
0
CAT IV 600V
COM W
Ve
X
7
MAX
600V B
J
RS-3 PRO
X
MAX
600V B
J
RS-1007 PRO
RS-3 PRO
➊
➋
➌
➍
➎
➏
➐
e ZERO
RS-1007 PRO
Current jaws
Jaw opening lever
Function / Range selector wheel
Needle Lock
Volt – Amp needle - zero adjust, Ohms - ∞ adjust
(On side) Ohms zero adjust
Input jacks for Volts and Ohms
3
RS-3 PRO / RS-1007 PRO
CAT IV Analog Clampmeter Series
Contents
Symbols...................................................................................................................5
Safety Information.................................................................................................5
 Warnings and Precautions..........................................................................5
Unpacking and Contents.......................................................................................6
Introduction............................................................................................................6
Operation...............................................................................................................6
Measuring AC Voltage (See Fig. 1)..................................................................6
AC Current Measurement (See Fig. 2).............................................................6
Measuring Resistance /Continuity (See Fig. 3)................................................6
Maintenance and Repair ......................................................................................6
Battery Replacement (see Fig. 4) ....................................................................7
Fuse Replacement.............................................................................................7
Specifications..........................................................................................................7
4
Symbols

Battery

Refer to the manual
Double insulated
Dangerous Voltage
Alternating Current


Earth Ground

Conforms to relevant
Australian standards.

Complies with EU
directives

Do not dispose of this
product as unsorted
municipal waste.


Application around and removal from hazardous live
conductors is permitted


Underwriters
Laboratories.[Note:
Canadian and US.]
Safety Information
•
The RS-1007 Pro and RS-3 Pro Analog Clamp meters conform to
EN61010-1:2001; EN61010- 2-032:2002; CAT IV 600 V, class II and pollution
deg.2
•
This instrument is EN61010-1 certified for Installation Category IV (600V).
It is recommended for use in primary supply lines, overhead lines and
cable systems and distribution level and fixed installations, as well as lesser
installations.
•
Do not exceed the maximum overload limits per function (see
specifications) nor the limits marked on the instrument itself. Never apply
more than 600 V ac rms between the test lead and earth ground.
 Warnings and Precautions
•
Before and after hazardous voltage measurements, test the voltage
function on a known source such as line voltage to determine proper
meter functioning.
•
Disconnect the test leads from the test points before changing meter
functions.
•
Disconnected from the meter’s test leads before measuring current.
•
Inspect the Clampmeter, test leads and accessories before every use. Do
not use any damaged part.
•
Never ground yourself when taking measurements. Do not touch exposed
circuit elements or test probe tips.
•
Do not operate the instrument in an explosive atmosphere.
•
To reduce the risk of fire or electric shock, do not expose this product to
rain or moisture.
•
The meter is intended only for indoor use. To avoid electrical shock
hazard, observe the proper safety precautions when working with
voltages above 60 VDC, 42.4 Vpk, or 30 VAC rms. These voltage levels pose
a potential shock hazard to the user.
•
Before and after hazardous voltage measurements, test the voltage
function on a known source such as line voltage to determine proper
meter functioning.
•
Keep your hands/fingers behind the hand/finger barriers (of the meter
and the test leads) that indicate the limits of safe access of the hand-held
part during measurement.
•
Inspect test leads, connectors, and probes for damaged insulation or
exposed metal before using the instrument. If any defects are found,
replace them immediately.
•
This Clamp-on meter is designed to apply around or remove from uninsulated hazardous live conductors. Individual protective equipment must
be used if hazardous live parts of the installation could be accessible.
•
Exercise extreme caution when: measuring voltage >20 V // current >10
mA // AC power line with inductive loads // AC power line during electrical
storms // current, when the fuse blows in a circuit with open circuit voltage
>1000 V // servicing CRT equipment.
•
Remove test leads before opening the case to change the battery.
 CAUTION
•
For non-invasive ACA current measurements, clamp the jaws around only
one single conductor of a circuit for load current measurement. More than
1 conductor will cause false readings.
 CAUTION
•
Verify the needle lock is released before making measurements.
5
Unpacking and Contents
Your shipping carton should include:
1
RS-1007 Pro or RS-3 Pro
1
Test lead set
1
1.5V AAA battery (installed)
1
F 0.5 A 1000V Fuse (installed)
1
Users Manual
1
Carrying Case
If any of the items are damaged or missing, immediately return the complete
package to the place of purchase for an exchange.
Introduction
The RS-1007 Pro and RS-3 Pro Analog Clamp-On meters are manual ranging
1000 / 600 ACA and 600 V clamp meter. The features include AC voltage, AC
current, and Resistance test ranges. Both clampmeters have a mechanical
needle clamp to prevent needle damage during transportation.
Operation
Measuring AC Voltage (See Fig. 1)
 CAUTION
Remove clamp jaws from wire before connecting to or measuring voltage.
1. Rotate the meter scale wheel to appropriate V range.
2. Using the V A Zero screw (front panel), adjust the needle for ‘0’.
3. Connect the test leads: Red to + and Black to COM.
4. Connect the test probes to the circuit test points.
5. Read the needle location on the meter scale and, if necessary, correct any
overload (needle pegged) conditions.
AC Current Measurement (See Fig. 2)
 CAUTION
Disconnect test leads from circuit and meter if voltage was being tested.
1. Rotate the meter scale wheel to appropriate A range.
2. Using the V A Zero screw (front panel), adjust the needle for ‘0’.
3. Open spring-loaded clamp by pressing the lever on left side of meter.
4. Position clamp around one wire or conductor and release the clamp lever.
5. Read the needle location on the meter scale, and, if necessary, correct any
overload (needle pegged) conditions.
 CAUTION
Using Resistance or Continuity function in a live circuit will produce false
results and may damage the instrument. In most cases the suspected
component must be disconnected from the circuit to obtain an accurate
measurement reading.
Measuring Resistance /Continuity (See Fig. 3)
1. Rotate the meter scale wheel to Ω range.
2. Turn off power to the circuit being measured and discharge any capacitors
in the circuit.
3. Connect the test leads: Red to + and Black to COM.
4. Short the test leads and adjust Ω Zero knob for ‘0’ Ω.
5. Remove the short from the test leads.
6. Using the V A Zero screw, adjust the needle for ∞.
7. Connect the test probes across the resistance.
8. Read the needle location on the meter scale, and, if necessary, correct any
overload (needle pegged) conditions.
Maintenance and Repair
If there appears to be a malfunction during the operation of the meter, the
following steps should be performed in order to isolate the cause of the
problem:
1. Verify the needle lock is disengaged (all the way to the left). Needle
should move when meter is moved.
2. Check the battery and fuse (ohms range only).
3. Review the operating instructions for possible mistakes in operating
procedure.
4. Inspect and test the test leads for a broken or intermittent connection.
Except for the replacement of the fuse, battery or test probes, repair of the
multimeter should be performed only by a Factory Authorized Service Center
6
or by other qualified instrument service personnel. The front panel and case
can be cleaned with a mild solution of detergent and water. Apply sparingly
with a soft cloth and allow to dry completely before using. Do not use
aromatic hydrocarbons or chlorinated solvents for cleaning.
Battery Replacement (see Fig. 4)
 Warning
To prevent electrical shock or meter damage, disconnect the meter’s test
leads from any circuit and the meter, then turn the meter off before
removing the battery cover. Battery replacement should be performed in a
clean environment and with appropriate care taken to avoid contaminating
the meter’s interior components.
1. Remove the screw and lift the battery cover.
2. Remove the battery using the pull strap.
3. Replace the battery with the same type, 1.5 V AAA battery (NEDA-24A, IEC
LR03). Note polarity of the battery.
4. Replace the battery cover and screw.
Fuse Replacement
1. Remove the screw and lift the battery cover.
2. Remove the battery using the pull strap.
3. Remove the fuse using the pull strap.
4. Replace the fuse with F 0.5 A Fuse (FP500)
5. Replace the battery noting the polarity of the battery.
6. Replace the battery cover and screw.
Specifications
General
Display: Analog scales with clamping needle
Power Supply:
Volts / amps: powered by circuit under test
Ohms: 1.5 V AAA battery (ANSI/NEDA-24A, IEC LR03)
Low Battery: Below approx. 1.2 V
Environmental: Indoor operation; below 2000m (6,562ft)
Operating Temperature : -15°C to 50°C (5°F to 122°F) ; < 80%
Storage Temperature: -20ºC to 60ºC (-4ºF to 140ºF), < 80% R.H. (with battery
removed)
Temperature Coefficient: nominal 0.15 x (specified accuracy)/ºC @ 0ºC to 18ºC
or 28ºC to 40ºC (32°F to 64°F or 82°F to 104°F)
Dimension:
RS-1007 Pro: 261 x 102 x 41 mm (10.3 x 4.0 x 1.6 in.)
RS-3 Pro: 243 x 102 x 41 mm (10.3 x 4.0 x 1.6 in.)
Weight:
RS-1007 Pro: 0.474 kg (1.05 lb.)
RS-3 Pro: 0.455 kg (1.0 lb.)
Jaw opening / Conductor diameter:
RS-1007 PRO: 47mm (1.88") max
RS-3 PRO: 41mm (1.64") max
Safety LVD: Meets EN60101-1:2001; EN61010-2-032(2002), Category IV - 600
Volts ac; pollution degree : II; class 2
 EMC: EN 61326-1:2006 This product complies with requirements of the
following European Community Directives: 2004/108/EC (Electromagnetic
Compatibility) and 2006/95/EC (Low Voltage) as amended by 93/68/EEC (CE
Marking). However, electrical noise or intense electromagnetic fields in the
vicinity of the equipment may disturb the measurement circuit. Measuring
instruments will also respond to unwanted signals that may be present within
the measurement circuit. Users should exercise care and take appropriate
precautions to avoid misleading results when making measurements in the
presence of electronic interference.
Electrical
23ºC ± 5ºC (73ºF ± 9ºF) <75%RH
AC Voltage (50/60 Hz)
Ranges: 150 / 300 / 600 Vrms
Accuracy: ± 3% of Full Scale.
Input Impedance: 1.5 MΩ
7
OL Protection: 600 V ac rms
AC Amp (50/60 Hz)
Ranges:
RS-1007 Pro: 15 / 40 / 100 / 300 / 1000 Arms
RS-3 Pro: 6 / 15 / 40 / 100 /600 Arms
Accuracy: ± 3 % of Full Scale
Ohms
Range: 1000 ohms
25 Ohms mid-scale
Accuracy: ± 3 degrees of Arc
Open Circuit voltage: 1.5v
Short circuit Current:
58 mA
OL Protection: (F 0.5 A / 1000 V, size 6 x 32 mm IR fast blow ceramic)
8
B
Analog Clamp Meter
NEEDLE
LOCK
VOLT
150
125
V A
100
75
50
20
0
e ZERO
CAT IV 600V
COM W
Ve
X
MAX
600V B
J
Fig 1. Volts
Analog Clamp Meter
NEEDLE
LOCK
AMP
100
80
V A
60
40
20
0
e ZERO
CAT IV 600V
COM W
Ve
X
MAX
600V B
J
Fig 2. Amps
9
Analog Clamp Meter
NEEDLE
LOCK
Ω
0
5
V A
10
20
50
100
200
500
1k
e ZERO
CAT IV 600V
COM W
Ve
X
MAX
600V B
J
F 0.5A 1000V
+
1.5 V AAA
Fig 3. Ohms
Fig. 4 Battery Fuse
10
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
