MICRO-EPSILON thicknessSENSOR User manual

MICRO-EPSILON thicknessSENSOR User manual
Operating Instructions
thicknessSENSOR
10/200
10/400
25/200
25/400
Sensor for thickness measurement
MICRO-EPSILON
MESSTECHNIK
GmbH & Co. KG
Königbacher Strasse 15
94496 Ortenburg / Germany
Phone +49 (0) 8542 / 168-0
Fax +49 (0) 8542 / 168-90
email [email protected]
www.micro-epsilon.com
Contents
1.
Safety......................................................................................................................................... 5
1.1
1.2
1.3
1.4
1.5
1.6
Symbols Used.................................................................................................................................................. 5
Warnings........................................................................................................................................................... 5
Notes on CE Marking....................................................................................................................................... 5
Intended Use.................................................................................................................................................... 6
Foreseeable Misuse.......................................................................................................................................... 6
Proper Environment.......................................................................................................................................... 6
2.
Laser Class................................................................................................................................ 7
3.
3.1
3.2
3.3
3.4
4.
4.1
4.2
5.
5.1
5.2
5.3
5.4
5.5
6.
6.1
6.2
Functional Principle.................................................................................................................. 8
Base Frame....................................................................................................................................................... 8
Sensors ............................................................................................................................................................ 9
Calibration Target.............................................................................................................................................. 9
Technical Data................................................................................................................................................ 10
Delivery.................................................................................................................................... 11
Unpacking /Included in Delivery.................................................................................................................... 11
Storage........................................................................................................................................................... 11
Mounting.................................................................................................................................. 12
General........................................................................................................................................................... 12
Error Influences ............................................................................................................................................. 12
5.2.1
Ambient Light................................................................................................................................ 12
5.2.2
Color Differences .......................................................................................................................... 12
5.2.3
Surface Roughness ...................................................................................................................... 12
5.2.4
Temperature Influences ................................................................................................................ 12
5.2.5
Movement Blurs ............................................................................................................................ 12
5.2.6
Optimizing the Measuring Accuracy ............................................................................................ 13
Mechanical Fastening, Dimensional Drawing................................................................................................ 14
Control and Display Elements........................................................................................................................ 18
Electrical Connections.................................................................................................................................... 18
5.5.1
Connection Possibilities................................................................................................................ 18
5.5.2
Pin Assignment.............................................................................................................................. 19
5.5.3
Power Supply................................................................................................................................ 19
5.5.4
Current Output............................................................................................................................... 19
5.5.5
Voltage Output............................................................................................................................... 20
5.5.6
Trigger, Master Function Inputs..................................................................................................... 20
5.5.7
Switching Outputs......................................................................................................................... 20
5.5.8
Connector and Sensor Cable....................................................................................................... 21
Operation................................................................................................................................. 22
6.5
6.6
Getting Ready for Operation.......................................................................................................................... 22
Operation Using Ethernet............................................................................................................................... 22
6.2.1
Requirements................................................................................................................................ 22
6.2.2
Access via Ethernet....................................................................................................................... 23
6.2.3
Measured Value Display with Web Browser................................................................................. 25
Home Menu.................................................................................................................................................... 26
Preferences Menu........................................................................................................................................... 27
6.4.1
Language Selection...................................................................................................................... 27
6.4.2
Sensors.......................................................................................................................................... 27
6.4.3
Measuring Rate............................................................................................................................. 28
6.4.4
Filter / Averaging / Error Handling Inside thicknessSENSOR...................................................... 29
6.4.5
Zeroing / Mastering....................................................................................................................... 31
6.4.6
Digital Interfaces............................................................................................................................ 32
6.4.6.1
Selection of Digital Interfaces...................................................................................... 32
6.4.6.2
Data Selection.............................................................................................................. 33
6.4.6.3
Ethernet Settings.......................................................................................................... 34
6.4.7
Analog Outputs............................................................................................................................. 35
6.4.7.1
Analog Output 1 and 2................................................................................................. 35
6.4.8
Digital Ports................................................................................................................................... 37
6.4.8.1
Digital Input.................................................................................................................. 37
6.4.8.2
Digital Outputs.............................................................................................................. 37
6.4.9
Output Data Rate........................................................................................................................... 38
6.4.10
Trigger Mode................................................................................................................................. 39
6.4.11
Load/Save Settings....................................................................................................................... 40
6.4.12
Manage Settings on PC................................................................................................................ 41
6.4.13
Extras............................................................................................................................................. 43
6.4.13.1 Language..................................................................................................................... 43
6.4.13.2 Factory Defaults........................................................................................................... 43
6.4.13.3 Reset of Controller....................................................................................................... 44
Measuring Menu............................................................................................................................................. 45
Help/Info Menu............................................................................................................................................... 47
7.
Software Support with MEDAQLib......................................................................................... 48
8.
Liability for Material Defects................................................................................................... 49
9.
Service, Repair ....................................................................................................................... 49
10.
Decommissioning, Disposal................................................................................................... 49
6.3
6.4
thicknessSENSOR
Appendix
A1
A2
Accessories............................................................................................................................. 50
Factory Defaults...................................................................................................................... 51
A 2.1
A 2.2
A 2.3
A 2.4
A 2.5
A 2.6
A 2.7
A 2.8
A 2.9
A 2.10
A 2.11
A 2.12
Home.............................................................................................................................................................. 51
Sensors........................................................................................................................................................... 51
Measuring Rate............................................................................................................................................... 51
Filter / Averaging / Error Handling inside thicknessSENSOR........................................................................ 51
Zeroing/Mastering.......................................................................................................................................... 51
Digital interfaces............................................................................................................................................. 51
Analog Outputs............................................................................................................................................... 51
Digital Ports..................................................................................................................................................... 52
Output Data Rate............................................................................................................................................ 52
Trigger Mode................................................................................................................................................... 52
Load/Save Settings......................................................................................................................................... 52
Extras.............................................................................................................................................................. 52
A3
Pin Assignment....................................................................................................................... 53
A4
A 4.1
A 4.2
A 4.3
A 4.4
A 4.5
A 4.6
ASCII Communication with the Sensor.................................................................................. 54
General........................................................................................................................................................... 54
Data Protocol.................................................................................................................................................. 54
Commands Overview..................................................................................................................................... 57
Commands..................................................................................................................................................... 58
A 4.4.1
Controller Information.................................................................................................................... 58
A 4.4.2
Search Sensor............................................................................................................................... 58
A 4.4.3
Sensor Information........................................................................................................................ 58
A 4.4.4
Read all Settings............................................................................................................................ 58
A 4.4.5
Language Setting.......................................................................................................................... 58
A 4.4.6
Synchronization............................................................................................................................. 59
A 4.4.7
Boot the Controller........................................................................................................................ 59
A 4.4.8
Triggering....................................................................................................................................... 59
A 4.4.8.1 Trigger Selection
A 4.4.8.2 Trigger Level
A 4.4.8.3 Number of Measured Values to be Output
A 4.4.8.4 Software Trigger Pulse
A 4.4.9
Ethernet......................................................................................................................................... 60
A 4.4.10 Setting the Measured Value Server............................................................................................... 60
A 4.4.11 Transmission Rate......................................................................................................................... 60
A 4.4.12 Save Parameters........................................................................................................................... 60
A 4.4.13 Load Parameters........................................................................................................................... 60
A 4.4.14 Factory defaults............................................................................................................................. 60
A 4.4.15 Measurement Mode...................................................................................................................... 61
A 4.4.16 Measuring Rate............................................................................................................................. 61
A 4.4.17 Measured Value Averaging Controller.......................................................................................... 61
A 4.4.18 Measured Value Averaging Sensor............................................................................................... 61
A 4.4.19 Mastering / Zeroing....................................................................................................................... 61
A 4.4.20 Selection Digital Output................................................................................................................ 61
A 4.4.21 Output Data Rate........................................................................................................................... 62
A 4.4.22 Scale Output Values...................................................................................................................... 62
A 4.4.23 Error Handling............................................................................................................................... 62
A 4.4.24 Data Selection for USB.................................................................................................................. 62
A 4.4.25 Data Selection for Ethernet........................................................................................................... 63
A 4.4.26 Function Selection Multi-function Input........................................................................................ 63
A 4.4.27 Activate Error Output, Switching Output 1.................................................................................... 63
A 4.4.28 Activate Error Output, Switching Output 2.................................................................................... 63
A 4.4.29 Limit Values................................................................................................................................... 64
A 4.4.30 Data Selection .............................................................................................................................. 64
A 4.4.31 Output Area................................................................................................................................... 64
A 4.4.32 Two-point Scaling.......................................................................................................................... 64
A 4.4.33 Send Command to Connected Sensor........................................................................................ 65
A 4.4.34 Laser off / Laser on........................................................................................................................ 65
A 4.4.35 Find thicknessSENSOR................................................................................................................ 65
Error Values via USB...................................................................................................................................... 65
Error Values via Ethernet................................................................................................................................ 65
thicknessSENSOR
Safety
1.
Safety
The handling of the system assumes knowledge of the instruction manual.
1.1
Symbols Used
The following symbols are used in this instruction manual.
Indicates a hazardous situation which results in minor or moderate injuries if not avoided.
NOTICE
Indicates a situation that may result in property damage if not
avoided.
Indicates a user action.
i
Indicates a tip for users.
Measure
1.2
Indicates hardware or a software button/menu.
Warnings
Avoid unnecessary laser radiation to be exposed to the human body.
Switch off the sensor for cleaning and maintenance.
Switch off the sensor for system maintenance and repair if the sensor is integrated
into a system.
Caution - use of controls or adjustments or performance of procedures other than those
specified may cause harm.
Connect the power supply and the display / output device in accordance with the safety
regulations for electrical equipment.
>>Risk of injury
>>Damage to or destruction of the sensors, the controller
The power supply must not exceed the specified limits.
>>Risk of injury
>>Damage to or destruction of the sensors, the controller
NOTICE
Avoid shocks and impacts to the sensors, the mechanics.
>>Damage to or destruction of the sensors, the controller
Do not clean the protective glass of the sensors with water.
>>Damage to the protective glass
1.3
Notes on CE Marking
The following apply to the thicknessSENSOR:
-- EU Directive 2014/30/EU,
-- EU Directive 2011/65/EU, “RoHS” Category 9
Products which carry the CE mark satisfy the requirements of the EU directives cited and
the European harmonized standards (EN) listed therein. The EU Declaration of Conformity is available to the responsible authorities according to EU Directive, article 10, at:
MICRO-EPSILON MESSTECHNIK
GmbH & Co. KG
Königbacher Straße 15
94496 Ortenburg / Germany
The sensor is designed for use in industrial environments and meets the requirements.
thicknessSENSOR
Page 5
1.4
Intended Use
-- The thicknessSENSOR is designed for use in industrial and laboratory applications. It
is used for
ƒƒ thickness measurement
ƒƒ quality monitoring and dimensional inspection
ƒƒ profile measurement
-- The sensor must only be operated within the limits specified in the technical data.
-- The sensor must be used in such a way that no persons are endangered or machines
and other material goods are damaged in the event of malfunction or total failure of
the controller.
-- Take additional precautions for safety and damage prevention in case of safety-related
applications.
1.5
Foreseeable Misuse
If the target/strip material flow has started, the calibration component holder may not be
retracted. Collision of the target/strip material with the calibration component holder.
During the reference measurement, the target/strip material flow may not be started.
Collision of the target/strip material with the calibration component holder.
1.6
Proper Environment
-- Protection class:
IP 65
-- Operating temperature:
0 ... 50 °C (+32 ... +122 °F) (non-condensing)
-- Storage temperature:
-20 ... 70 °C (-4 ... +158 °F) (non-condensing)
-- Humidity:
5 - 95 % (non-condensing)
-- Ambient pressure:
i
Atmospheric pressure
The protection class is limited to water (no penetrating liquids, detergents or similar
aggressive media). Use a protective housing in case of permanent exposure to
water.
Optical inputs are excluded from protection class. Contamination leads to impairment or
failure of the function.
thicknessSENSOR
Laser Class
2.
Laser Class
The sensors of the thicknessSENSOR operate with a semiconductor laser with a wavelength of 670 nm (visible/red).
The sensors fall within Laser Class 2. The lasers are pulsed, the maximum optical power
is ≤1 mW. The pulse frequency depends on the set measuring rate (0.25 ... 4 kHz). The
pulse duration of the peaks is regulated depending on the measuring rate and the reflectivity of the measurement object and can be 0.3 ... 3999.6 μs.
i
Do not look deliberately into the laser beam.
Close your eyes or
immediately turn away if
the laser beam hits the
eye.
Observe the laser protection regulations.
When operating the sensors, the relevant regulations in accordance with DIN EN 608251 (VDE 0837, Part 1 dated 07/2015) and the accident prevention instructions on laser
radiation (BGV B2 dated 01/1997) valid in Germany must be observed. Thereafter:
-- With class 2 laser devices, the eye is not endangered by random, brief exposure to
laser radiation, i.e. exposure times of up to 0.25 s.
-- Class 2 laser devices may therefore be used without further protective measures if
you do not intentionally look into the laser beam or in specularly reflected radiation for
more than 0.25 s.
-- Because the presence of the eyelid protective reflex should not normally be assumed,
one should deliberately close the eyes or turn away immediately if the laser beam hits
the eye.
Class 2 laser devices are not subject to notification and a laser protection officer is not
required.
LASERSTRAHLUNG
NICHT IN DEN STRAHL BLICKEN
LASER KLASSE 2
nach DIN EN 60825-1: 2015-07
P≤1mW; =670nm
LASER RADIATION
DO NOT STARE INTO THE BEAM
CLASS 2 LASER PRODUCT
IEC 60825-1: 2015-07
P≤1mW; =670nm
THIS PRODUCT COMPLIES WITH FDA
REGULATIONS 21CFR 1040.10 AND 1040.11
Fig. 2 Laser warning
symbol
Fig. 1 Laser warning signs
optoNCDT
optoNCDT
LASERSTRAHLUNG
NICHT IN DEN STRAHL BLICKEN
LASER KLASSE 2
nach DIN EN 60825-1: 2015-07
P≤1mW; =670nm
LASERSTRAHLUNG
NICHT IN DEN STRAHL BLICKEN
LASER KLASSE 2
nach DIN EN 60825-1: 2015-07
P≤1mW; =670nm
LASER RADIATION
DO NOT STARE INTO THE BEAM
CLASS 2 LASER PRODUCT
IEC 60825-1: 2015-07
P≤1mW; =670nm
THIS PRODUCT COMPLIES WITH FDA
REGULATIONS 21CFR 1040.10 AND 1040.11
LASER RADIATION
DO NOT STARE INTO THE BEAM
CLASS 2 LASER PRODUCT
IEC 60825-1: 2015-07
P≤1mW; =670nm
THIS PRODUCT COMPLIES WITH FDA
REGULATIONS 21CFR 1040.10 AND 1040.11
Fig. 3 Laser warning signs on the sensor
i
If both warning signs are hidden in the installed state, the user must ensure that
additional warning signs are fitted at the point of installation.
The operation of the laser is indicated by an LED on the sensor, see Chap. 5.4.
The housing of the laser-optical sensors may only be opened by the manufacturer, see
Chap. 8., see Chap. 9.
For repair and service purposes the sensors must always be sent to the manufacturer.
thicknessSENSOR
Page 7
Functional Principle
3.
Functional Principle
3.1
Base Frame
The sensor is used for the non-contact thickness measurement of non-transparent strips
and plates.
Upper beam
Sensor 2
Sensor 1
Target
Lower beam
Fig. 4 Schematic representation of the measuring machine
Sensor 2
Input
2
Controller
Input
1
SMR 1 Measurement SMR 2
object
The measuring method of the unit is based on double-sided thickness measurement,
consisting of two laser-optical sensors, which measure the target from opposite positions. The thickness of the target is calculated in the integrated controller.
Sensor 1
Fig. 5 Sensor arrangement for the thickness measurement
The thickness determination does not require any complex target support. The main
advantage is that vibrations of the target do not result in inaccurate measurement. The
positional tolerance of the target is determined from the working gap, the start of measuring range (SMR), see Fig. 5, and the measuring range (MR) of the laser sensors, see
Fig. 6.
Target in the MR,
measurement successful
Target
Positional tolerance
target
Working gap
MR
Target
Positional tolerance
target
Working gap
MR
Working gap
MR
Positional tolerance
target
Target
Target outside of the MR,
Target partly in the MR,
measurement unsuccessful measurement unsuccessful
No damage to the target/measuring machine
Fig. 6 Possible positions of the material to be measured and statements about the feasibility of thickness measurement
thicknessSENSOR
Page 8
Functional Principle
3.2
Do not look deliberately into the laser beam.
Close your eyes or
immediately turn away if
the laser beam hits the
eye.
Sensors
The two laser sensors measure without contact the thickness of the strips as they pass
between the two upper and lower belts of the measuring machine, see Fig. 4.
i
An air purge at the sensors reduces dust accumulation, etc. on the glass panes for
the laser and the receiver.
Laser beam output
Fig. 7 Lower belt with laser sensor
3.3
Calibration Target
For a reference measurement, a calibration target is used to detect deviations. The calibration target is 3.0 mm thick, it is attached to the upper belt if required and protrudes
into the measuring gap of the sensor. After the reference measurement, the calibration
target must be removed again.
Calibration Target
Fig. 8 Calibration target on the upper belt
i
thicknessSENSOR
Calibration measurement is recommended after temperature fluctuations, a mechanical shock of the thicknessSENSOR or after changing the target material.
Page 9
Functional Principle
3.4
Technical Data
thicknessSENSOR
10/200
Model
Measuring range
Working gap
Measuring width
Linearity (combined)
Measuring rate
Light source
Permissible ambient light
Light spot diameter max.
Protection class
Laser safety class
Temperature stability
Operating temperature
Storage temperature
Control inputs/outputs
Measurement value output
Vibration
Shock
Weight
Displays
Sensor
Controller
Operation
Web
interface
Power supply
Controller
Electromagnetic
compatibility (EMC)
thicknessSENSOR
10/400
thicknessSENSOR thicknessSENSOR
25/200
25/400
10 mm
46 mm
200 mm
±10 µm
10 mm
25 mm
25 mm
46 mm
71 mm
71 mm
400 mm
200 mm
400 mm
±10 µm
±40 µm
±40 µm
0.25 kHz / 0.5 kHz / 1 kHz / 2 kHz / 4 kHz
Semiconductor laser <1 mW, 670 nm (red)
10.000 lx
140 x 160 µm (±10 %) max.
390 x 500 µm (±10 %) max.
IP 65
Class 2 according to DIN EN 60825-1: 2015-07
± 0.03 % FSO/°C
0 ... +50 °C (+32 ... +122 °F) (non-condensing)
-20 ... +70 °C (-4 ... +158 °F) (non-condensing)
1 x trigger in / 1 x master / 2 x switching outputs
0 - 5 V, 0 - 10 V, ±5 V, ±10 V, 4 - 20 mA
Ethernet
2 g / 20 ... 500 Hz (according to IEC 60068-2-6)
15 g / 6 ms / 3 axes (according to IEC 60068-2-29)
3.3 kg
4.3 kg
3.5 kg
4.5 kg
3x color LEDs for power and status
Power i.o.
Selectable averages / data reduction / setup management / limit values
11 - 30 V DC, 24 V P< 5 W
Integrated signal processor, signal processing unit
EN 61 000-6-3 / DIN EN 61326-1 (class B)
EN 61 000-6-2 / DIN EN 61326-1
FSO = full scale output
thicknessSENSOR
Page 10
Delivery
4.
Delivery
4.1
Unpacking /Included in Delivery
1 thicknessSENSOR
1 instruction manual
x inspection report(s) of the ILD sensors
Carefully remove the sensor parts from the packaging and ensure furthermore that
the goods are forwarded in such a way that no damage can occur.
Check the delivery for completeness and shipping damage immediately after unpacking.
In case of damage or missing parts, please contact the manufacturer or supplier
immediately.
Optional accessories are available in the appendix, see Chap. A 1.
4.2
Storage
-- Storage temperature: -20 ... 70 °C (+32 ... +122 °F) (non-condensing)
-- Relative humidity:
thicknessSENSOR
5 ... 95 % (-4 ... +158 °F) (non-condensing)
Page 11
Mounting
5.
Mounting
5.1
General
The thicknessSENSOR achieves linearity in the micrometer range. For this reason, the
mechanical components and sensors are matched to one another. Insofar as is constructively possible, mechanical assemblies and individual parts which are not subject
to adjustment have been used. Such parts/assemblies which have to be adjusted for
functional reasons have been adjusted by Micro-Epsilon.
The commissioning does not require any adjustment work by the customer. The customer is responsible for providing a protective device to avoid a collision between the strip
material (target) and the thicknessSENSOR.
5.2
Error Influences
5.2.1
Ambient Light
Thanks to their integrated optical interference filters, the laser-optical sensors offer
outstanding performance in suppressing ambient light. However, ambient light disturbances can occur with shiny measurement objects and at a reduced measuring rate. In
these cases it is recommended to provide shielding against ambient light. This applies in
particular to measurement work performed in the vicinity of welding devices.
5.2.2
Color Differences
Because of intensity compensation, color difference of targets affect the measuring result
only slightly. However, such color differences are often combined with different penetration depths of the laser light into the material. Different penetration depths then result in
apparent changes of the measuring spot size. Therefore color changes in combination
with penetration depth changes may lead to measurement uncertainties.
5.2.3
Surface Roughness
In case of traversing measurements, surface roughnesses of 5 μm and more lead to an
apparent distance change (so-called surface noise). However, they can be dampened by
selecting a higher average.
5.2.4
Temperature Influences
When the sensor is commissioned, a warm-up time of at least 20 minutes is required to
achieve uniform temperature distribution in the sensor. If measurement is performed in
the μm accuracy range, the effect of temperature fluctuations on the sensor holder must
be considered. Due to the damping effect of the heat capacity of the sensor, sudden
temperature changes are only measured with delay.
5.2.5
Movement Blurs
If the objects being measured are fast moving and the measuring rate is low, it is possible that movement blurs may result. Therefore, always select a high measuring rate for
high-speed operations to prevent errors.
thicknessSENSOR
Page 12
Mounting
Optimizing the Measuring Accuracy
select
state
output
In case of rolled or polished metals that are
moved past the sensor, the sensor plane must
be arranged in the direction of the rolling or
grinding marks. The same arrangement must
be used for color strips.
laser off
in range
midrange
error
Grinding and rolling marks
Color strips Direction of movement
5.2.6
Fig. 9 Sensor arrangement for ground or striped
surfaces
In case of bore holes, blind holes and edges in
the surface of moving parts, the sensor must
be arranged in such a way that the edge does
not obscure the laser spot.
optoNCDT
≤
False (shadow)
optoNCDT
≤
Fig. 10 Sensor arrangement for holes and
edges
thicknessSENSOR
Page 13
Mounting
Mechanical Fastening, Dimensional Drawing
M6x1 - 6H
(4x fastening thread)
15 (.6)
0
45 (1.8)
105 (4.1)
135 (5.3)
10 (.4)
5.3
140 (.1)
0
0
(laser
25.5(1)
beam) 35(1.4)
40 (1.6)
70 (2.8)
410 (16.1)
427 (16.8)
0
25 (1)
115 (4.5)
70 (2.8)
55 (2.2)
42 (1.7)
20 (.8)
0
0
250 (.98)
35 (1.4)
93 (3.7)
(MR top) 75 (2.9)
(MR bottom) 65 (2.6)
47 (1.9)
38 (1.5)
70 (2.8)
3 (.1)
0
104 (4.1)
M6x1 - 6H
(4x fastening thread)
0
25 (1)
47 (1.9)
115 (4.5)
Fig. 11 Dimensional drawing thicknessSENSOR 10/200, dimensions in mm, not to scale
thicknessSENSOR
Page 14
15 (.6)
0
45 (1.8)
105 (4.1)
135 (5.3)
10
(.4)
Mounting
M6x1 - 6H
(4x fastening
thread)
140 (.1)
0
25 (1)
115 (4.5)
70 (2.8)
55 (2.2)
42 (1.7)
20 (.8)
0
610 (24)
627 (24.7)
0
(laser- 25.5 (1)
beam) 35 (1.4)
40 (1.6)
70 (2.8)
0
0
450 (17.7)
35 (1.4)
93 (3.7)
(MR top)75 (2.9)
(MR bottom)65 (2.6)
47 (1.9)
38 (1.5)
70 (2.8)
3 (.1)
0
104 (4.1)
M6x1 - 6H
(4x fastening
thread)
0
25 (1)
47
(1.9)
115
(4.5)
Fig. 12 Dimensional drawing thicknessSENSOR 10/400, dimensions in mm, not to scale
thicknessSENSOR
Page 15
M6x1 - 6H
(4x fastening thread)
15 (.6)
0
45 (1.8)
105 (4.1)
135 (5.3)
10
(.4)
Mounting
165 (6.5)
(MR bottom) 70 (2.8)
35 (1.4)
47 (1.9)
0
0
Laser
beam
25.5 (1)
35 (1.4)
40 (1.6)
70 (2.8)
410 (16.1)
427 (16.8)
0
25 (1)
115 (4.5)
250 (.98)
70 (2.8)
55 (2.2)
42 (1.7)
20 (.8)
0
0
38 (1.5)
70 (2.8)
118 (4.6)
(MR top) 95 (3.7)
3 (.1)
0
104 (4.1)
M6x1 - 6H
(4x fastening thread)
0
37.5 (1.5)
47 (1.9)
127.5 (5)
Fig. 13 Dimensional drawing thicknessSENSOR 25/200, dimensions in mm, not to scale
thicknessSENSOR
Page 16
15 (.6)
0
45 (1.8)
105 (4.1)
135 (5.3)
10
(.4)
Mounting
M6x1 - 6H
(4x fastening
thread)
165
(MR bottom) 70
47
0
610 (24)
627 (24.7)
0
(Laser- 25.5 (1)
(1.4)
beam) 35
40 (1.6)
70 (2.8)
25 (1)
0
115 (4.5)
70 (2.8)
55 (2.2)
42 (1.7)
20 (.8)
0
0
450 (17.7)
35 (1.4)
38 (1.5)
70 (2.8)
118
(MR top) 95
3 (.1)
0
104 (4.1)
M6x1 - 6H
(4x fastening
thread)
0
37.5 (1.5)
47 (1.9)
127.5 (5)
Fig. 14 Dimensional drawing thicknessSENSOR 25/400, dimensions in mm, not to scale
thicknessSENSOR
Page 17
Mounting
5.4
Control and Display Elements
LED State
Meaning
green
Target within the measuring range
yellow
Target within the midrange
red
Error, e.g. target outside the measuring
range, too low reflection
off
Laser switched off
LED state
LED Output Meaning
green
RS422 measured value output
yellow
RS422 and current output are switched off.
The RS422 and the current output can be
switched on.
The web interface can be switched on.
red
Measured value output current 4 ... 20 mA
off
Sensor off, no supply
LED
output
The Select key is disabled.
5.5
Electrical Connections
5.5.1
Connection Possibilities
Source
Cable/Supply
Terminal
SCD1420-x/THS
Ethernet
PC
PC1420-x/THS
Dig I/O, Analog out
PS 2020
PS2020
Fig. 15 Connection examples on ILD 1420
Different periphery devices can be connected to the 12-pin Analog Digital I/O 24
VDC connector, see Fig. 15. Power is supplied e.g. by the optionally available power
supply PS 2020, see A 1.
thicknessSENSOR
Page 18
Mounting
5.5.2
Pin Assignment
Pin Color sensor cable, explanation
Note
9
red
Operating voltage
11 ... 30 VDC,
typ. 24 VDC, P< 5 W
2
blue
GND, supply
Power supply ground
3
white
Trigger input
2
4
green
Master input
3
5
pink
Switching output 1
6
yellow
Switching output 2
7
black
GND, switching outputs
8
gray
Voltage output 1
10
violet
Voltage output 2
11
gray-pink GND, analog
1
brown
Current output 1
12
red-blue
Current output 2
Housing, shield
1
9
10
8
12
7
11
4
6
5
Solder side cable
connector
Connect to potential equalization
Fig. 16 Pin assignment of the 12-pin connector “Analog Digital I/O 24 VDC”
Please refer to the pin assignment diagram for further information, see Chap. A 3.
5.5.3
Power Supply
Nominal value: 24 V DC (11 ... 30 V, P < 5 W).
Switch on the power supply only after completing the wiring.
Connect the inputs “9” and “2” at the sensor with a 24V power supply.
Use the power supply unit for measurement devices only and not for drive units or similar sources of pulse interference at the same time.
Sensor
9
12-pin M12 cable connector
Sensor cable
9
red
+UB
2
blue
GND
11 ... 30
VDC
thickness
SENSOR
2
MICRO-EPSILON
recommends using the optionally
available power
supply PS2020 for
the sensor, see
chapter A 1.
Fig. 17 Power supply connection
5.5.4
Current Output
The sensor provides a current output of 4 ... 20 mA.
i
The current output may not be continuously operated in short-circuit operation without load resistor. Permanent short-circuit operation leads to thermal overload and
thus to the automatic overload cut-off of the output.
Connect the output 1 or 12 (brown or red-blue) and 11 (gray-pink) at
the sensor with a measurement device.
Sensor
12-pin M12 cable connector
Sensor cable
1 or 12
brown or
red-blue
I OUT1
IOUT2
11
gray-pink
GND
thickness
SENSOR
1/12
Iout
11
Fig. 18 Wiring for current output
thicknessSENSOR
Page 19
Mounting
5.5.5
Voltage Output
The sensor provides a voltage output. Variants: 0 ... 5 V, 0 ... 10 V, ±5 V, ±10 V.
Connect the output 8 or 10 (gray or violet) and 11 (black) at the sensor
with a measurement device.
Sensor
thickness
SENSOR
12-pin M12 cable connector
Sensor cable
8 or 10
gray or
violet
U OUT1
U OUT2
11
black
GND
8/10 Uout
11
Fig. 19 Wiring for voltage output
5.5.6
Trigger, Master Function Inputs
The inputs on the 12-pin M12 cable connector enable the triggering and zeroing/mastering functions. The function depends on the programming of the input.
-- Pin 3 Trigger input
-- Pin 4 Zeroing/Master input
Variant 1
+U B
Variant 2 Sensor cable
+U B
white resp.
green
blue
thickness
SENSOR
3/4
2
Low-level logic (LLL)
≤0.7 V: Low level
≥2.2 V: High level
High-level logic (HLL)
≤3.0 V: Low level
≥8.0 V: High level
Internal pull-down resistor, an open
input is detected as Low.
Fig. 20 Basic circuit for the function inputs
Connect the input to +UB to trigger the function.
5.5.7
Switching Outputs
The switching characteristic of the push-pull error outputs on the 12-pin M12 cable connector depends on the programming.
High-level logic (HLL)
≤3.0 V: Low level
(at Imax = 40 mA)
thickness +U B
SENSOR
5/6
≥+UB - 3V: High level
(at Imax = 40 mA)
Imax = 40 mA,
7
Fig. 21 Basic circuit for the error output
Switching characteristic
Description
Output active
(error)
Output passive
(no error)
Push-Pull
≤3.0 V (at Imax = 40 mA)
+ UB - 3V (at Imax = 40 mA)
Fig. 22 Switching characteristic for error output
Error output is activated e.g. when the measurement object is missing, it is too close/too
far or when no valid measurement value can be determined.
thicknessSENSOR
Page 20
Mounting
5.5.8
Connector and Sensor Cable
Never fall below the bending radius for the sensor cable of 30 mm (fixed) resp. 60
mm (dynamic).
i
Unused open cable ends must be insulated or bluntly cut to protect against short
circuits or sensor malfunctions.
Avoid excessive pull on the cables. If a cable of over 5m in length is used and it
hangs vertically without being secured, make sure that some form of strain relief is
provided close to the connector.
Connect the cable shield to the potential equalization (PE, protective earth conductor) on the evaluator (switching cabinet, PC housing) and avoid ground loops.
Never lay signal leads next to or together with power cables or pulse-loaded cables
(e.g. for drive units and solenoid valves) in a bundle or in cable ducts. Always use
separate ducts.
Recommended strand cross-section for self-made connection cables: ≥ 0.14 mm².
thicknessSENSOR
Page 21
Operation
6.
Operation
6.1
Getting Ready for Operation
Mount the thicknessSENSOR according to the installation instructions, see Chap.
5.3.
Connect the thicknessSENSOR to downstream display or monitoring units and to
the power supply.
The laser diode in the sensors is activated by the controller.
Once the operating voltage has been switched on, the thicknessSENSOR runs through
an initialization sequence. This is indicated by the momentary activation of all the LEDs.
The initialization takes up to 10 seconds.
The thicknessSENSOR typically requires a start-up time of 20 min for reproducible measurements.
If the LED Output is off, this means that there is no operating voltage
If the LED State is off, this means that the laser light source has been switched off.
i
The controller can only be operated via the web interface. The last setting applies.
6.2
Operation Using Ethernet
Dynamic web pages are generated in the thicknessSENSOR which contain the current
settings of the thicknessSENSOR and the peripherals. Operation is only possible while
there is an Ethernet connection to the thicknessSENSOR.
6.2.1
Requirements
You need a current web browser (e.g. Google Chrome or Mozilla Firefox) on a PC with
a network connection. Decide whether the thicknessSENSOR should be connected to a
network or directly to a PC.
The thicknessSENSOR is supplied as standard with a fixed IP address. If you do not
want a static IP address, you can enable DHCP (Dynamic Host Configuration Protocol)
for automatic IP addressing. The thicknessSENSOR is then assigned an IP address by
your DHCP serve, see Chap. 6.2.2.
If you have configured your browser so that it accesses the Internet via a proxy server,
please add the IP address of the thicknessSENSOR in the browser settings to the list of
addresses which should not be routed via the proxy server.
Parameters
Description
Address type
Static IP address (standard) or dynamic IP address (DHCP)
IP address
Static IP address of the controller (only active if DHCP has not been
selected)
Subnet mask
Subnet mask of the IP subnet
Gateway
Gateway to other subnets
Fig. 23 Ethernet basic settings
“Javascript” must be enabled in the browser so that measurement results can be displayed graphically.
thicknessSENSOR
Page 22
Operation
6.2.2
Access via Ethernet
Direct connection with PC, thicknessSENSOR with static IP address
(factory setting)
PC with static IP address
PC with DHCP
Connect the thicknessSENSOR (“Ethernet” socket) to the PC
using a direct Ethernet connection (LAN). Use a LAN cable with a
7-pin M12 cable connector and an RJ-45 connector.
The thicknessSENSOR needs a fixed IP
address to establish a direct connection.
Start the program
SensorFinder.
You will find this program on the supplied
CD.
Network
Controller with dynamic IP address, PC with
DHCP
Connect the thicknessSENSOR to a
switch using a direct Ethernet connection (LAN). Use a LAN cable with
a 7-pin M12 cable connector and an
RJ-45 connector.
Wait until Windows has
Enter the sensor in the DHCP server /
established a network
notify the sensor to your IT Department.
connection (connection
The sensor is assigned an IP address by
with limited connectivity).
your DHCP server. You can query this IP
Start the program
address with the program
SensorFinder.
SensorFinder.
You will find this program
Start the program
Click the Start Scan button. Select
on the supplied CD.
SensorFinder.
the required sensor from the list. To
change IP address settings, click on
Click the Start
You will find this program on the supplied
the Change IP... button.
Scan button. Select CD.
the required sensor
••Address type: static IP address
Click the Start Scan button. Select
1
from the list.
••IP address: 169.254.168.150
the required sensor from the list.
••Gateway: 169.254.1.1
Click on the Start
Click on the Start Browser button
••Subnet mask: 255.255.0.0
Browser button to
to connect the sensor to your standard
Click on the Change button to transmit
connect the sensor
browser.
the changes to the thicknessSENSOR.
to your standard
browser.
Click on the Start Browser button
to connect the sensor to your standard
browser. Alternatively, change the
IP settings according to the settings
on your PC (IP address ranges must
match).
1) It is assumed that the PC LAN connection uses e.g. the following IP address:
169.254.168.1.
Interactive web pages for programming the thicknessSENSOR and peripherals are now shown in the web browser.
Fig. 24 SensorFinder auxiliary program for finding sensors and starting the web interface
thicknessSENSOR
Page 23
Operation
Parallel operation with web browser and ASCII commands is possible; the last setting
applies. Do not forget to save.
Fig. 25 First interactive web page after calling the IP address
Use the upper navigation bar to access additional features (Preferences, Measuring and
Help/Info).
All settings in the web page are implemented immediately after pressing the Apply
button.
The appearance of the web pages can change depending on the functions and the
peripherals. Each page contains parameter descriptions and tips on completing the web
page.
Additional submenus can be accessed via the left-hand navigation column of the web
pages,
e.g. measuring rate or trigger mode.
i
When programming has been completed, store all settings permanently in a set of
parameters to ensure that these settings are available when the sensor is switched
on the next time.
Fig. 26 Menu structure in the Preferences tab
thicknessSENSOR
Page 24
Operation
6.2.3
Measured Value Display with Web Browser
“Javascript” must be enabled in the browser so that measurement results can be displayed
graphically.
Start the measured value display (Measuring) in the horizontal navigation bar.
5
6
4
7
8
3
2
1
9
10
Fig. 27 Display of the measurement and calculation results
1
Each curve can be deactivated and activated using the associated checkbox
(checkmark). The Autozero function starts or stops a relative measurement for the
thickness result.
2
Stop stops the diagram; data selection and zoom function are still possible. Save
creates a CSV file (separation with semicolon) to store the last (approx. 50000)
measured values. The file contains the accumulated measurement and calculation
results including time information. The file is stored in the download area under
Windows.
3
Averaging only affects the thickness result (thicknessSENSOR value); no averaging takes place in the laser sensors. The setting of the averaging can be carried
out in parallel in the Preferences menu.
4
For scaling the measured value axis (y-axis) of the graphic, you can either select
Auto (= autoscaling) or Manual (= manual setting).
Enable automatic scaling:
Select Automatic from the dropdown menu.
Enable manual scaling:
Select Manual from the drop-down
menu.
The lowest and highest value of the
scaling of the y-axis is automatically
displayed.
The y-axis can be scaled manually.
thicknessSENSOR
5
The master value is used to specify the thickness of a measurement object. Use the
Set master value button to set the thickness result to zero, for example, if you
want to make a differential measurement. The function is also used for a calibration
measurement, see Chap. 3.3.
6
The current values of the two laser sensors and the calculated thickness value
(thicknessSENSOR value) are displayed in the text boxes above the graphic.
Page 25
Operation
7
The zoom function scales the time axis during both the measurement and the
offline analysis.
8
Mouseover function. When moving the mouse over the graphic in stopped state,
curve points are marked with a circle symbol and the related values are displayed
in a text box above the graphic.
9
Scaling of the x-axis can be defined by means of an input field below the time axis.
10 Scaling of the x-axis: When the measurement is running, you can use the left slider
to enlarge (zoom) the total signal. If the diagram is stopped, you can also use the
right slider. The zoom window can also be moved with the mouse in the center of
the zoom window (arrow cross).
i
By letting the diagram display run in a separate tab or browser window, you do not
have to restart the display every time.
If the language is set to German, the measured values are stored with a comma as a
decimal separator, otherwise with a period.
NOTICE
Only a limited number of recorded measurements can be stored (about 50,000). If more
measured values are recorded, the oldest measured values are deleted.
i
6.3
With high data rates, only a reduced number of measured values are displayed in
the diagram!
Home Menu
Fig. 28 Start page screen
The Home menu is the first interactive web page after calling the IP address.
On the left side you can select the language from the Language selection dropdown menu, see Fig. 28. The language selection can also be made via the Preferences > Extras > Language menu, see 6.4.1.
The upper navigation bar can be used to access additional features (Preferences, see
Chap. 6.4, Measuring. and Help/Info, see Chap. 6.6.
thicknessSENSOR
Page 26
Operation
6.4
Preferences Menu
6.4.1
Language Selection
Go to the Preferences > Extras > Language menu.
This menu item allows you to change the language of the interactive web pages.
Language selection
System / English /
German
Language of the interactive web pages
The language selection can also be made via the Home > Language selection
menu, see Chap. 6.3.
6.4.2
Sensors
Go to the Preferences > Sensors menu.
Sensors
Sensor 1 /
Sensor 2
Peak selection
Connected sensor
ILD1420 SN xxxxxxxx
Controller reads the
serial numbers of
the sensors used.
A selection is not
possible.
Search for connected sensors
Search sensors
If no sensor is listed,
it is possible to
search for sensors.
Available peaks
Highest peak / first
peak / last peak
Submit peak
Selection of Available
the measure- measurement
ment task
tasks
Laser
Laser is ON.
Laser is OFF.
Defines which signal
is used in the array
signal for the evaluation. Highest peak:
Standard, peak with
the highest intensity.
First peak: Nearest
peak to sensor.
Last peak: Peak
furthest away from
sensor.
The selection of a
Standard / changing
surfaces / material with measurement task
loads a predefined
penetration
sensor configuration
Submit measurement
that produces the
task
best results for the
selected material.
Switches the laser
Switch off the laser
light source on or off
Switch on the laser
at the sensor on the
software side.
Fig. 29 Preferences - Sensors screen
Standard
Suitable for materials made of ceramic, metal or filled plastics
Changing surfaces
Suitable for circuit boards (PCB) or hybrid materials
Material with penetration Suitable for plastics (POM, Teflon), materials with strong
penetration depth of the laser
Fig. 30 Overview of measurement task selection - Available measurement tasks
Fields with a gray
background require a selection.
Value
Dark bordered
fields require the
specification of a
value.
thicknessSENSOR
Page 27
Operation
6.4.3
Measuring Rate
Go to the Preferences > Measuring rate menu.
The measuring rate indicates the number of measurements per second.
Select the required measurement frequency.
Measuring
rate
0.5 kHz / 1.0 kHz /
2.0 kHz / 4 kHz
Use a high measuring rate for bright and mat
measurement objects. Use a low measuring rate for
dark or shiny measurement objects (e.g. black painted surfaces) to improve the measurement result.
The measurement frequency is factory set to 2 kHz.
Fields with a gray
background require a selection.
Value
Dark bordered
fields require the
specification of a
value.
thicknessSENSOR
Page 28
Operation
6.4.4
Filter / Averaging / Error Handling Inside thicknessSENSOR
Go to the Preferences > Filter / Averaging / Error handling inside
thicknessSENSOR menu.
A number of filter types for measurement values are available. Filtering lowers the noise
of the measurement signal which results in a better resolution. Filter width is used to
specify the number of measurement values to which the filter applies.
Filter / Averaging
/ Error handling
inside thicknessSENSOR
Measured value
averaging
Error handling
in the case of no
valid measured
value
No averaging
Moving average
for N values
/ Recursive
average for N
values / Median filter for N
values
Error output, no
measurement /
Hold last valid
value / Hold
last valid value
forever
Number of values for
moving average
Number of values for
recursive average
Number of values for
median filter
2/4/
8 / 16 /
32 / 64
/ 128 /
256 /
512
If no valid measured value can
be determined, an error value
is output. If this impedes further processing, the last valid
measured value can be kept
for a number of measurement
cycles, i.e. output repeatedly.
Moving average:
The selectable filter width N for successive measured values is used to calculate and
issue the arithmetic average Mgl. Each new measured value is added, the first (oldest)
measured value is removed from the averaging, see Chap. 6.4.2.
N
MW (k)
M gl =
k=1
N
MW = measured value
N = averaging number
k = continuous index (in the window)
M gl = average or output value
Each new measured value is added, the first (oldest) measured value is removed from
the averaging (from the window) again. In this way, short settling times for measured
value jumps are achieved.
Example: N = 4
... 0, 1, 2, 2, 1, 3
2, 2, 1, 3
= M gl (n)
4
Fields with a gray
background require a selection.
Value
i
... 1, 2, 2, 1, 3, 4
2, 1, 3, 4
= M gl (n+1)
4
Measured values
Output value
Moving average in the controller of the thicknessSENSOR allows only potentials of
2 for the averaging number N. The highest averaging number is 1024.
Dark bordered
fields require the
specification of a
value.
thicknessSENSOR
Page 29
Operation
Application tips
-- Smoothing of measured values
-- The effect can be finely measured in comparison to the recursive averaging.
-- With uniform noise of the measured values without spikes
-- For a slightly rough surface, in which the
roughness is to be eliminated.
-- Also suitable for measured value jumps at
relatively short settling times.
Signal without averaging
Signal with averaging
Fig. 31 Moving average, N = 8
Recursive average
Formula:
MW = measured value
M rek (n) =
MW (n) + (N-1) x M rek (n-1)
N
N = averaging value, N = 1 ... 32768
n = measured value index
M rek = average or output value
The weighted value of each new measured value MW(n) is added to (n-1) times the previous average, see Chap. 6.4.2.
The recursive averaging enables very strong smoothing of the measured values, however it needs very long settling times for measured value jumps. The recursive average
shows low-pass behavior.
Application tips
-- Allows very strong smoothing of the measured values. Long settling times for measured value jumps (low-pass behavior)
-- Strong smoothing of noise without large
spikes
-- For static measurements, to smooth the
signal noise particularly strongly
-- For dynamic measurements on rough
target surfaces to eliminate the roughness,
e.g. paper roughness on paper webs
Signal without averaging
Signal with averaging
Fig. 32 Recursive average, N = 8
-- For the elimination of structures, e.g. parts
with uniform groove structures, knurled
turned parts or coarse milled parts
-- Not suitable for high-dynamic measurements
Median:
The median is formed from a preselected filter width N for measurement values. The incoming measured values are also sorted again after each measurement. Afterwards, the
average value is output as the median. If an even number is selected as filter width N, the
two average measurement values are added and divided by two, see Chap. 6.4.2.
3, 5, 7 or 9 readings are taken into account. This means that individual interference pulses can be suppressed. However, the smoothing of the measured value curves is not very
strong.
thicknessSENSOR
Page 30
Operation
Example: Median value from five measured values
... 0 1 2 4 5 1 3
Sorted measurement values: 1 2 3 4 5
Median (n) = 3
... 1 2 4 5 1 3 5
Sorted measurement values: 1 3 4 5 5
Median (n+1) = 4
Application tips
-- Smoothing of the measured value curve is
not very strong, used to eliminate outliers
-- Suppresses individual interference pulses
-- In short, strong signal peaks (spikes)
-- Also suitable for edge jumps (only minor
influence)
-- For rough, dusty or dirty environment, to
eliminate dirt or roughness
Signal without averaging
Signal with averaging
-- Further averaging can be used after the
median filter
Measured value
Measured value
Fig. 33 Median, N = 7
Position value
Fig. 34 Original profile
6.4.5
Position value
Fig. 35 Profile with median, N = 9
Zeroing / Mastering
Go to the Preferences > Zeroing / Mastering menu.
Zeroing / Mastering
Fields with a gray
background require a selection.
Value
Dark bordered
fields require the
specification of a
value.
thicknessSENSOR
Mastering is ACTIVE
Mastering is INACTIVE
Master value in mm
Reset master
value
Set master value
Reset zero setting and
mastering.
Activate zero setting and
mastering. Value range
for mastering: from -1024
to 1024 mm.
Value
Page 31
Operation
6.4.6
6.4.6.1
Digital Interfaces
Selection of Digital Interfaces
Go to the Preferences > Digital interfaces > Digital interface selection menu.
Digital
interfaces
Selection of
digital interfaces
Interface
Disabled
used for
data output
Ethernet transmission of measured values
Web diagram
i
No measured values
are output via the digital
interface.
Ethernet enables fast,
non-real-time data
transmission (packet-based data transfer).
The measurement device
can be configured via the
web interface or by ASCII
commands via a terminal program, see Chap.
6.4.6.3.
Go to Ethernet settings,
see Chap. 6.4.6.3.
The recorded measured
values are displayed in a
diagram on the Measuring web page, see Chap.
6.5.
The Ethernet interface is recommended for a measured value output with subsequent analysis without direct process control. If a real-time measured value output
is necessary for process control, the analog interfaces should be used.
Fields with a gray
background require a selection.
Value
Dark bordered
fields require the
specification of a
value.
thicknessSENSOR
Page 32
Operation
6.4.6.2
Data Selection
Go to the Preferences > Digital interfaces > Data selection menu.
Fig. 36 Digital interfaces - Data selection screen
Here you can select data for transmission via digital interfaces.
From the sum of all available data those which are required for further processing can
be selected. This data is then output one after the other in a defined sequence. You will
find information about the data format, the output sequence and more details in the
MEDAQLib instruction manual of MICRO-EPSILON, see Chap. 7.
i
The display and storage of additional values is not possible in the web diagram.
Please use the thicknessSENSOR tool, which is available on request.
thicknessSENSOR
Page 33
Operation
6.4.6.3
Ethernet Settings
Go to the Preferences > Digital interfaces > Settings Ethernet
menu.
Fig. 37 Ethernet settings screen
Ethernet
settings
IP settings
Ethernet
measured
value transfer
settings
Address type
Static IP address / DHCP
IP address
Value
Subnet mask
Value
Default gateway
Value
Transmission
type
Server/TCP
Port
Value
Values for IP address / gateway
/ subnet mask.
Only for static IP
address
The thicknessSENSOR provides the measured values as
a server (transmission type:
Server/TCP).
The thicknessSENSOR provides the measured values as a server (transmission type:
Server/TCP). A self-written program or a tool such as ICONNECT can be used as client.
You will find the documentation of the data format in the MEDAQLib instruction manual of
MICRO-EPSILON, see Chap. 7.
Fields with a gray
background require a selection.
Value
Dark bordered
fields require the
specification of a
value.
thicknessSENSOR
Page 34
Operation
6.4.7
Analog Outputs
Go to the Preferences > Analog outputs menu.
6.4.7.1
Analog Output 1 and 2
Fig. 38 Preferences - Analog outputs screen
You can adjust the output signal, the output value, the output area and the scaling
in this screen. After setting in the Filter / Averaging / Error handling inside thicknessSENSOR > Measured value averaging menu, see Chap. 6.4.4,
no averaging, you can select in the Analog outputs> Output signal menu
between Fixed output value, Sensor 1 value and Sensor 2 value, see
Fig. 39.
After setting in the Filter / Averaging / Error handling inside thicknessSENSOR > Measured value averaging menu, see chapter 6.4.4, an
averaging method or the median filter, you must set in the Analog output > Output
signal menu the thicknessSENSOR: value, see Fig. 39.
Fig. 39 Analog output - Output signal drop-down menu
In the Preferences > Analog outputs > Analog output > Output area
menu, you can select between analog output, current or voltage, see Fig. 40.
thicknessSENSOR
Page 35
Operation
Fig. 40 Analog output - Output area drop-down menu
In the Preferences > Analog outputs > Analog output > Scaling menu, you
can select between Standard scaling and Two-point scaling, see Fig. 41.
Fig. 41 Analog output - Scaling drop-down menu
Analog
output
1/2
Output signal 1
Fixed output value
Output
value
Min to
Max value in
V resp.
mA
Sensor 1/2: Measured value
Sensor 1/2: Intensity
Data source can
be a sensor signal,
the result of the
C-Box/2A of the
thicknessSENSOR,
or a fixed value
within the output
area.
Sensor 1/2: Shutter speed
Sensor 1/2: Reflectivity
thicknessSENSOR: Measured value
Output area
Inactive / 0V ... 5V / 0V ... 10V / -5V ... 5V /
-10V ... 10V / 4mA ... 20mA
Specification of
the analog output,
current or voltage
with selectable
value range.
Scaling
Standard scaling
Standard scaling
outputs the entire
measuring range
of the sensor/
controller.
Two-point scaling
Two-point scaling
requires the
indication of the
start and end
of the range;
value range: from
-1024 to 1024
mm.
Two-point
scaling
(displacement and
factor)
Start of range in mm Value
End of range in mm
Value
1) Only one measuring value can be transferred.
Fields with a gray
background require a selection.
Value
Dark bordered
fields require the
specification of a
value.
thicknessSENSOR
Page 36
Operation
6.4.8
Digital Ports
Go to the Preferences > Digital ports menu.
Under Digital input, see Chap. 6.4.8.1, you can configure the function input.
Under Digital outputs, see Chap. 6.4.8.2, you can configure the error outputs.
6.4.8.1
Digital Input
The digital input can be used for mastering the thicknessSENSOR measured values.
Digital input
6.4.8.2
Logic for digital input
Low-level logic
High-level logic
Selection of
the logic for
the digital
input
≤0.7 V: Low level
≥2.2 V: High level
≤3.0 V: Low level
≥8.0 V: High level
Digital Outputs
Select the function of the error outputs.
Fields with a gray
background require a selection.
Value
Dark bordered
fields require the
specification of a
value.
thicknessSENSOR
Page 37
Operation
Digital outputs
Error output 1/2
Type Sensor 1/2: Error output 1/2
Sensor 1/2: Measured value
Sensor 1/2: Intensity
Sensor 1/2: Shutter speed
Sensor 1/2: Reflectivity
thicknessSENSOR: Measured
value
Low level
High level
The value of the selected error output for
the selected sensor is
output.
Outputs the range
check result of measuring value / intensity
value / shutter speed
value / reflectivity value
for the selected sensor.
The allowed range is
specified by the upper
and lower limit input
fields.
Outputs the range
check result for the
thicknessSENSOR
measuring value. The
allowed range is specified by the upper and
lower limit input fields.
The level is always low
at the error output.
The level is always high
at the error output.
Submit error output 1 / 2
6.4.9
Output Data Rate
Go to the Preferences > Output data rate menu.
Fig. 42 Preferences - Output data rate screen
The reduction of the output data rate causes only every nth measured value to be output.
All other measured values are discarded. Any required averaging for n values must be
set separately, see Chap. 6.4.4.
Fields with a gray
background require a selection.
Value
Dark bordered
fields require the
specification of a
value.
thicknessSENSOR
Page 38
Operation
6.4.10 Trigger Mode
Go to the Preferences > Trigger mode menu.
Trigger mode
Selected
mode
No triggering
Level triggering
There is a continuous measured value
output as long as the selected level is
applied. The data output is stopped
afterwards. The trigger can be set to
high level / low level.
Edge triggering
The sensor outputs the previously
set number of measured values or
initiates a continuous measured
value output after the trigger
event. The trigger can be set to
rising edge / falling edge.
Software triggering
A measured value output is
started as soon as a software
command is triggered. The trigger
moment is defined more inexactly.
The sensor outputs the previously
set number of measured values or
initiates a continuous measured
value output after the trigger
event.
Fields with a gray
background require a selection.
Value
Dark bordered
fields require the
specification of a
value.
thicknessSENSOR
Page 39
Operation
Selected
mode
No triggering
Level triggering
Measured
value output at
High level
Low level
Rising edge
Edge triggering
Active
logic
Falling edge
Software triggering
High-level logic
(HLL)
Low-level logic
(LLL)
High-level logic
(HLL)
Low-level logic
(LLL)
Number of Value
measured
values
Active logic
The logic determines the level the trigger switches:
Low-level logic (LLL)
≤0.7 V Low level
≥2.2 V High level
High-level logic (HLL)
≤0.7 V Low level
≥8.0 V High level
Number of measured values
1...16382:
16383:
Number of measured values to be output after a trigger event
Start of an infinitely measured value output after a trigger event
0:
Stop of the trigger and ending an infinitely measured value output
i
For all measuring tasks, level or edge triggering and external synchronization cannot be combined.
6.4.11 Load/Save Settings
Go to the Preferences > Load/save settings menu.
Fig. 43 Preferences - Load/save settings screen
All settings on the controller, e.g. connected sensors and calculation functions, can be
permanently saved in user programs, so-called setups, in the controller.
Fields with a gray
background require a selection.
Value
i
After the programming, all settings must be permanently stored under a setup no.
(1 / 2 / 3 ... 8) in the controller, so that they are available again when the thicknessSENSOR is switched on the next time.
Dark bordered
fields require the
specification of a
value.
thicknessSENSOR
Page 40
Operation
Load/save settings
Save to setup
number
1 / 2 / 3 ... 8
Clicking this button
saves the settings in
the selected setup
file.
Load from
1/ 2 / 3 ... 8
setup number
Clicking this button
loads the settings
from the selected
setup file.
Load
All Settings
All Settings
Interface settings only
Interface settings
include the network
properties.
Measuring settings only
Measuring settings
only
6.4.12 Manage Settings on PC
Use this menu to save a backup copy of the settings to a PC or to restore saved settings
to the controller.
i
Save the controller settings before exporting or importing data, see Chap. 6.4.11.
Go to the Preferences > Load/save settings > Manage settings on PC
menu.
Fig. 44 Preferences - Manage settings on PC screen
Fields with a gray
background require a selection.
Value
Dark bordered
fields require the
specification of a
value.
thicknessSENSOR
Page 41
Operation
Export settings
If you want to save the settings, press the Export settings button, see Fig. 44.
The Open thicknessSENSOR_Settings.txt Windows dialog box opens, see Fig.
45.
Fig. 45 Open thicknessSENSOR_Settings.txt Windows dialog box
Select Save file.
The file is saved under your downloads.
Save this download (your setup file) under any path you choose.
All thicknessSENSOR settings are now saved in this file and can be loaded at any time
again.
Import settings
If you want to load or import the settings, press the Choose settings file button under Import settings, see Fig. 44.
The Choose file to upload Windows dialog box opens, see Fig. 46.
Select the appropriate parameter set file (*.txt) in the path you selected when exporting and confirm with Open.
Fig. 46 Choose file to upload Windows dialog box
The thicknessSENSOR settings are read from the (*.txt) file and sent to the thicknessSENSOR.
thicknessSENSOR
Page 42
Operation
6.4.13 Extras
6.4.13.1 Language
Go to the Preferences > Extras > Language menu.
Fig. 47 Preferences - Extras screen
The following menu options are available:
Extras
Language
Language
selection
System
English
German
Only applies for
display in this web
interface.
The language selection can also be made via the Home > Language selection
menu, see Chap. 6.2.3.
6.4.13.2 Factory Defaults
Go to the Preferences > Extras > Factory defaults menu.
The sensor is reset to the default setting. All setups are deleted and the default parameters are loaded.
Fields with a gray
background require a selection.
Value
Dark bordered
fields require the
specification of a
value.
thicknessSENSOR
Page 43
Operation
Make the following selection for factory defaults:
Intention
Checkbox
Only reset current setup
Meaning
Only the current setup is deleted and
the default parameters are loaded.
Keep interface settings
Only reset current setup
Current setup except interface settings is reset.
Keep interface settings
Only reset current setup
All setups are deleted and the default
parameters are loaded. The settings
for language, password and Ethernet
remain unchanged.
Keep interface settings
Overwrite all setups
All setups are deleted and the interface parameters are reset.
Confirm the selection by pressing the Factory defaults button.
6.4.13.3 Reset of Controller
Go to the Preferences > Extras > Reset of controller menu.
Make the following selection for reset of controller:
Intention
Checkbox
Meaning
Also reset connected sensors
Only the controller will be reset.
Also reset connected sensors
Controller and all connected sensors will
be reset.
Confirm the selection by pressing the Reset button.
The Reset button restarts the controller. The measurement is interrupted, unsaved
changes are lost.
thicknessSENSOR
Page 44
Operation
6.5
Measuring Menu
Go to the Measuring menu.
5
6
4
7
8
3
2
1
9
10
Fig. 48 Measuring menu - Measuring program screen
The left window shows the following functions:
1 Each curve can be deactivated and activated using the associated checkbox
(checkmark). The Autozero function starts or stops a relative measurement for the
thickness result.
2 Stop stops the diagram; data selection and zoom function are still possible. Save
creates a CSV file (separation with semicolon) to store the last approx. 50000
values. The file contains the accumulated measurement and calculation results
including time information. The file is stored in the download area under Windows.
3 Shows which measured value averaging has been selected, see Chap. 6.4.4. You
can also change the measured value averaging here and confirm with Submit.
The averaging method is automatically updated in the Filter / Averaging /
Error handling inside thicknessSENSOR menu, see Chap. 6.4.4.
4 For scaling the measured value axis (y-axis) of the graphic, you can either select
Auto (= autoscaling) or Manual (= manual setting).
Enable automatic scaling:
Enable manual scaling:
Select Automatic from the dropdown menu.
Select Manual from the drop-down
menu.
The lowest and highest value of the
scaling of the y-axis is automatically
displayed.
5
6
thicknessSENSOR
The y-axis can be scaled manually.
The master value is used to specify the thickness of a measurement object. Use
the Set master value button to set the thickness result to the required value,
for example, if you want to make a differential measurement. The function is also
used for a calibration measurement, see Chap. 3.3.
The current values of the two laser sensors and the calculated thickness value
(thicknessSENSOR value) are displayed in the text boxes above the graphic.
Page 45
Operation
7
8
The zoom function scales the time axis during both the measurement and the
offline analysis.
Mouseover function. When moving the mouse over the graphic in stopped state,
curve points are marked with a circle symbol and the related values are displayed
in a text box above the graphic.
9
Scaling of the x-axis can be defined by means of an input field below the time axis.
10 Scaling of the x-axis: When the measurement is running, you can use the left slider
to enlarge (zoom) the total signal. If the diagram is stopped, you can also use the
right slider. The zoom window can also be moved with the mouse in the center of
the zoom window (arrow cross).
If the language is set to German, the measured values are stored with a comma as a
decimal separator, otherwise with a period.
i
thicknessSENSOR
Only a limited number of recorded measurements can be stored (about 50000). If
more measured values are recorded, the oldest measured values are deleted.
Page 46
Operation
6.6
Help/Info Menu
This page contains information about the serial and version numbers and the MAC address of controller and the attached sensors and an address block.
Fig. 49 Help/Info menu - Section 1 - Info controller
Fig. 50 Help/Info menu - Section 2 - Info sensor 1
Fig. 51 Help/Info menu - Section 3 - Info sensor 2
Fig. 52 Help/Info menu - Section 4 - Info GUI
thicknessSENSOR
Page 47
Software Support with MEDAQLib
7.
Software Support with MEDAQLib
MEDAQLib offers you a documented driver DLL. Therewith you embed the thicknessSENSOR, in combination with
-- Ethernet card
-- USB
into an existing or a customized PC software.
MEDAQLib
-- contains a DLL, which can be imported into C, C++, VB, Delphi and many more
programs,
-- performs data conversions,
-- works independent of the used interface type,
-- is characterized by identical functions for the communication (commands),
-- provides a consistent transmission format for all MICRO-EPSILON sensors.
For C/C++ programmers MEDAQLib contains an additional header file and a library file.
You will find the latest driver routine and documentation at:
www.micro-epsilon.de/download
www.micro-epsilon.de/link/software/medaqlib
thicknessSENSOR
Page 48
Liability for Material Defects
8.
Liability for Material Defects
All components of the device have been checked and tested for functionality at the factory. However, if defects occur despite our careful quality control, MICRO-EPSILON or your
dealer must be notified immediately.
The liability for material defects is 12 months from delivery. Within this period, defective
parts, except for wearing parts, will be repaired or replaced free of charge, if the device
is returned to MICRO-EPSILON with shipping costs prepaid. Any damage that is caused
by improper handling, the use of force or by repairs or modifications by third parties is
not covered by the liability for material defects. Repairs are carried out exclusively by
MICRO-EPSILON.
Further claims can not be made. Claims arising from the purchase contract remain unaffected. In particular, MICRO-EPSILON shall not be liable for any consequential, special,
indirect or incidental damage. In the interest of further development, MICRO-EPSILON
reserves the right to make design changes without notification.
For translations into other languages, the German version shall prevail.
9.
Service, Repair
If the sensor, controller or sensor cable is defective:
-- If possible, save the current sensor settings in
a parameter set, see Chap. 6.4.11 to reload
them into the sensor/controller after the repair.
-- Please send us the affected parts for repair or
exchange.
If the cause of a fault cannot be clearly identified,
please send the entire measuring system to:
10.
MICRO-EPSILON MESSTECHNIK
GmbH & Co. KG
Königbacher Str. 15
94496 Ortenburg / Germany
Tel. +49 (0) 8542 / 168-0
Fax +49 (0) 8542 / 168-90
[email protected]
www.micro-epsilon.com
Decommissioning, Disposal
Remove the power supply and output cables from the thicknessSENSOR.
Incorrect disposal may cause harm to the environment.
Dispose of the device, its components and accessories, as well as the packaging
materials in compliance with the applicable country-specific waste treatment and
disposal regulations of the region of use.
thicknessSENSOR
Page 49
Appendix | Accessories
Appendix
A1
thicknessSENSOR
Accessories
PC1420-x/THS
Multifunction cable;
2, 5, 10 m;
drag-chain suitable
SCD1420-x/THS
Ethernet interface cable; 2, 5, 10 m;
drag-chain suitable
PS2020
Power supply for DIN
rail mounting,
input 230 VAC,
output 24 VDC/2.5 A
Page 50
Appendix | Factory Defaults
A2
Factory Defaults
A 2.1
Home
Language selection: System
A 2.2
Sensors
Sensor 1
Available peaks: Highest peak
Available measurement tasks: Standard
Laser is on
Sensor 2
Available peaks: Highest peak
Available measurement tasks: Standard
Laser is on
A 2.3
Measuring Rate
Measuring rate: 2.0 kHz
A 2.4
Filter / Averaging / Error Handling inside thicknessSENSOR
Measured value averaging: No averaging
Error handling in the case of no valid measured value: Error output, no measurement
A 2.5
Zeroing/Mastering
Mastering is inactive. (No master value set.)
A 2.6
Digital interfaces
Selection of digital interfaces
Interface used for data output: Ethernet transmission of measured values
Data selection
thicknessSENSOR: value: selected
Remaining data not selected
Ethernet settings
Address type: Static IP address
IP Address: 169.254.168.150
Subnet mask: 255.255.0.0
Default gateway: 169.254.1.1
Transmission type: SERVER/TCP
Port: 1024
A 2.7
Analog Outputs
Analog output 1
Output signal: thicknessSENSOR: value
Output area: 0 V...10 V
Scaling: Standard scaling
Analog output 2
Output signal: thicknessSENSOR: value
Output area: 0 V...10 V
Scaling: Standard scaling
thicknessSENSOR
Page 51
Appendix | Factory Defaults
A 2.8
Digital Ports
Digital input
Logic for digital input: Low-level logic
Digital outputs
Error output 1 Type: Low level
Error output 2 Type: Low level
A 2.9
Output Data Rate
Every 1-th measured value is output
Reducing applies to the following interfaces:
Analog: not selected
Ethernet data transfer: not selected
A 2.10 Trigger Mode
Selected mode: No triggering
A 2.11 Load/Save Settings
Save to setup number: 1
Load from setup number: 1
Load: All Settings
A 2.12 Extras
Language
Language selection: System
Factory defaults
Only reset current setup: not selected
Keep interface settings: not selected
Reset of controller
Also reset connected sensors: not selected
thicknessSENSOR
Page 52
thicknessSENSOR
4120218
4120219
4120220
4120221
thicknessSENSOR
PINK
YELLOW
BLACK
GRAY
BROWN
VIOLET
GRAY-PINK
RED-BLUE
5
6
7
8
1
10
11
12
Trigger Input
24V Digital Output 1
24V Digital Output 2
GND für Digital Outputs
0-10V Analog Output 1
4-20mA Analog Output 1
0-10V Analog Output 2
GND Analog Outputs
4-20mA Analog Output 2
SHIELD
WHITE
3
24V Master Input
Shield
GREEN
4
Shield
BLUE
2
0V Power supply
RED
9
24V Power supply
PCxx Multi function cable
SCxx Ethernet
PLC customer
PC customer
24V / 0.5A
customer
RJ45
Ethernet
+
AC
Master button E
-
AC
14
13
A3
Analog Digital I/O
Ethernet
Appendix | Pin Assignment
Pin Assignment
Page 53
Appendix | ASCII Communication with the Sensor
A4
ASCII Communication with the Sensor
A 4.1
General
The ASCII commands can be sent to the thicknessSENSOR via the USB or Ethernet
interfaces. All commands, inputs and error messages are in English. A command always
consists of the command name and zero or more parameters, which are separated by
spaces and are terminated with CR LF (corresponds to \r\n).
The echo is always active, i.e.:
-- In the case of a command for setting parameters, first the command name, then OK or
error and finally the prompt is returned as a response.
-- In the case of a command for reading parameters, first the command name, then the
parameter value and finally the prompt is returned as a response.
-- In the case of a command with a multi-line response, first the command name and in
the next lines the parameters are returned as a response.
A 4.2
Data Protocol
All values to be output at the same time are grouped together for transmission to a
frame. A maximum of 12 values/frame are possible. The measured values are transmitted
via TCP/IP with 32 bits and USB with a maximum of 18 data bits.
Structure of a measured value frame:
-- Sensor 1 Value
-- Sensor 1 Intensity
-- Sensor 1 Shutter
-- Sensor 1 Reflectivity
-- Sensor 2 Value
-- Sensor 2 Intensity
-- Sensor 2 Shutter
-- Sensor 2 Reflectivity
-- C-Box Value
-- C-Box Counter
-- C-Box Timestamp
-- C-Box Digital
With the Ethernet transmission a header and then a sequence of data frames is transmitted with each package.
The header consists of:
-- Preamble (32 bits): MEAS
-- Order number (32 bits)
-- Serial number (32 bits)
-- Flags1 (32 bits), see Fig. 53
-- Flags2 (32 bits), see Fig. 54, currently no function
-- Bytes per frame (16 bits) / Number of frames in the package (16 bits)
-- Frame counter (32 bits)
The data frames in the package are always complete (No frame can be distributed on
several packages). Each frame consists of his selected measured values (up to 12).
Each measured value has again 32 bits.
thicknessSENSOR
Page 54
Appendix | ASCII Communication with the Sensor
The valid value ranges for the thicknessSENSOR are as follows:
-- Via USB:
ƒƒ Sensor measured values and additional values depending on sensor, see also
instruction manual of optoNCDT 1420, Chapter 7.5.1.
ƒƒ C-Box measured values from 0 .. 131071, from 262073 … 262143 (18 bits) error
values
ƒƒ C-Box Counter from 0 .. 262143 (18 bits)
ƒƒ C-Box Timestamp from 0 .. 262143 (18 bits)
ƒƒ C-Box Digital from 0 .. 262143 (18 bits)
-- Via TCP/IP (Ethernet):
ƒƒ Sensor measured values and additional values depending on sensor, see also
instruction manual of optoNCDT 1420, Chapter 7.5.1.
However, an additional Hi Byte (0x00) is transmitted to comply with 32 bits.
ƒƒ C-Box measured values from INT_MIN (-2147483648) to INT_MAX (2147483647)-11,
INT_MAX-10 to INT_MAX are error values
ƒƒ C-Box Counter from INT_MIN to INT_MAX
ƒƒ C-Box Timestamp from INT_MIN to INT_MAX
ƒƒ C-Box Digital from INT_MIN to INT_MAX
Flag 1 Bits
Description
Flag 1 Bits
Description
0
Sensor 1 Value
11
Sensor 2 Intensity
1
unused
12
Sensor 2 Shutter
2
Sensor 2 Value
13
Sensor 2 Reflectivity
3
unused
14
C-Box Counter
4
C-Box Value
15
C-Box Timestamp
5 to 7
unused
16
C-Box Digital
8
Sensor 1 Intensity
17 to 30
unused
9
Sensor 1 Shutter
30 to 31
10
Sensor 1 Reflectivity
01 (fixed value, to distinguish
from C-Box, where it is 00)
Fig. 53 Description Flags 1 (Ethernet)
Flag bit Description
0 to 31
0
Fig. 54 Description Flags 2 (Ethernet)
Value
Port
Value range
Sensor 1 Value,
Sensor 2 Value,
C-Box Value
USB
0 ... 262072
Ethernet -INT_MAX ... INT_MAX -11
-2147483647 ... 2147483636
C-Box Counter,
C-Box Timestamp,
C-Box Digital
USB
0 ... 262143
Ethernet: -INT_MAX ... INT_MAX
-2147483647 ... 2147483647
Fig. 55 Valid value ranges (raw)
Value
Port
Value range
Sensor 1 Value,
Sensor 2 Value,
C-Box Value
USB
262073 ... 262143
Ethernet: INT_MAX -10 ... INT_MAX 2147483637 ... 2147483647
Fig. 56 Error ranges (raw)
thicknessSENSOR
Page 55
Appendix | ASCII Communication with the Sensor
Value
Port
C-Box
Value
USB
Value =
Calculation
[mm]
Digital * (C-Box Range Max - C-Box Range Min)
131072.0
Ethernet
C-Box
Timestamp
Unit
Value =
USB
Value =
[mm]
Digital
1.0e+006
Digital (Left shift by 8 bits)
Value =
Ethernet
+ C-Box Range Min
[s]
1.0e+006
[s]
Digital (unsigned int)
1.0e+006
C-BoxCounter
USB
Digital
without
Ethernet
Digital (unsigned int)
without
C-Box
Digital
, see Fig. 57
Fig. 57 Calculation of the values
thicknessSENSOR Digital
Bits
Description
0
Trigger IN (TRG IN)
Pin header input
1
Multi-function input (MF IN)
Pin header input
2
Laser ON (laser)
Pin header input
3
Switching output S1 (OUT S1)
Pin header output
4
Switching output S1 (OUT S2)
Pin header output
5
Multi-function output
Sensor1 output
6
Laser ON
Sensor1 output
7
Switching input 1
Sensor1 input
8
Switching input 2
Sensor1 input
9
Multi-function output
Sensor1 output
10
Laser ON
Sensor2 output
11
Switching input 1
Sensor2 input
12
Switching input 2
Sensor2 input
13 to 15 (or 31)
reserved (0)
Fig. 58 Description thicknessSENSOR Digital
During a restart or after a configuration change at the thicknessSENSOR, this initializes
the sensors and the measuring restarts.
thicknessSENSOR
Page 56
Appendix | ASCII Communication with the Sensor
A 4.3
thicknessSENSOR
Commands Overview
Group
Chapter
Short description
A 4.4.1
Chap. A 4.4.1
Controller information
A 4.4.2
Chap. A 4.4.2
Search sensor
A 4.4.3
Chap. A 4.4.3
Sensor information
A 4.4.4
Chap. A 4.4.4
Read all settings
A 4.4.5
Chap. A 4.4.5
Language setting
A 4.4.6
Chap. A 4.4.6
Synchronization
A 4.4.7
Chap. A 4.4.7
Boot the controller
A 4.4.8
Chap. A 4.4.8
Triggering
A 4.4.8.1
Chap. A 4.4.8.1
Trigger selection
A 4.4.8.2
Chap. A 4.4.8.2
Trigger level
A 4.4.8.3
Chap. A 4.4.8.3
Number of measured values to be output
A 4.4.8.4
Chap. A 4.4.8.4
Software trigger pulse
A 4.4.9
Chap. A 4.4.9
Ethernet
A 4.4.10
Chap. A 4.4.10
Setting the measured value server
A 4.4.11
Chap. A 4.4.11
Transmission rate
A 4.4.12
Chap. A 4.4.12
Save parameters
A 4.4.13
Chap. A 4.4.13
Load parameters
A 4.4.14
Chap. A 4.4.14
Factory defaults
A 4.4.15
Chap. A 4.4.15
Measurement mode
A 4.4.16
Chap. A 4.4.16
Measuring rate
A 4.4.17
Chap. A 4.4.17
Measured value averaging controller
A 4.4.18
Chap. A 4.4.18
Measured value averaging sensor
A 4.4.19
Chap. A 4.4.19
Mastering / Zeroing
A 4.4.20
Chap. A 4.4.20
Selection digital output
A 4.4.21
Chap. A 4.4.21
Output data rate
A 4.4.22
Chap. A 4.4.22
Scale output values
A 4.4.23
Chap. A 4.4.23
Error handling
A 4.4.24
Chap. A 4.4.24
Data selection for USB
A 4.4.25
Chap. A 4.4.25
Data selection for Ethernet
A 4.4.26
Chap. A 4.4.26
Function selection multi-function input
A 4.4.27
Chap. A 4.4.27
Activate error output, switching output 1
A 4.4.28
Chap. A 4.4.28
Activate error output, switching output 2
A 4.4.29
Chap. A 4.4.29
Limit values
A 4.4.30
Chap. A 4.4.30
Data selection
A 4.4.31
Chap. A 4.4.31
Output area
A 4.4.32
Chap. A 4.4.32
Two-point scaling
A 4.4.33
Chap. A 4.4.33
Send command to connected sensor
A 4.4.34
Chap. A 4.4.34
Laser off / Laser on
A 4.4.35
Chap. A 4.4.35
Find thicknessSENSOR
A 4.5
Chap. A 4.5
Error values via USB
A 4.6
Chap. A 4.6
Error values via Ethernet
Page 57
Appendix | ASCII Communication with the Sensor
A 4.4
Commands
A 4.4.1 Controller Information
GETINFO
Querying the controller information. Output see example:
->GETINFO
Name:
Serial:
Option:
Article:
MAC Address:
Version:
->
C-Box
10000001
000
2420072
00-0C-12-01-06-08
xxx.xxx.xxx.xx
A 4.4.2 Search Sensor
SCAN1
The controller searches for sensors connected to the Sensor 1 socket.
The SCAN2 command causes the controller to search for sensors connected to the
Sensor 2 socket.
A 4.4.3
Sensor Information
GETINFO1
Provides information about the sensor connected to the Sensor 1 socket.
Example of a response if an ILD2300 is connected:
->GETINFO1
Name: ILD2300
Serial: 11020009
Option:
001
Article: 2418004
MAC Address: 00-0C-12-01-06-08
Version: 004.093.087.02
Measuring range: 20 mm
...
Imagetype: User
->
If the sensor was not recognized by the thicknessSENSOR, the error E39 no sensor
found is output.
The GETINFO2 command provides information about the sensor connected to the Sensor 2 socket.
A 4.4.4
Read all Settings
PRINT [ALL]
Print is used to output all query commands, for each line a response with command
names in front.
-- ALL: Provides further information
A 4.4.5
Language Setting
LANGUAGE BROWSER|ENGLISH|GERMAN
Language of the displayed web pages.
-- BROWSER means default language
thicknessSENSOR
Page 58
Appendix | ASCII Communication with the Sensor
A 4.4.6
Synchronization
SYNC NONE|INTERNAL|EXTERNAL [LLL | HLL]
-- NONE: Sensors are not synchronized, the thicknessSENSOR runs with its own clock
and takes just available sensor values.
-- INTERNAL: thicknessSENSOR generates sync pulse
-- EXTERNAL: External sync pulse is looped through to the sensors
ƒƒ With an external triggering, you can switch between Low Level Logic (LLL) and High
Level Logic (HLL).
ƒƒ Low Level Logic (0 ... 0.7 to 2.8 ... 30)
ƒƒ High Level Logic (0 ... 3 to 8 ... 30)
A 4.4.7
Boot the Controller
RESET [ALL]
The thicknessSENSOR is restarted.
-- ALL: Also restart the sensors.
A 4.4.8
Triggering
A 4.4.8.1 Trigger Selection
TRIGGER NONE|EDGE|PULSE|SOFTWARE
Selection of the trigger mode
-- NONE: No triggering
-- EDGE: Flank triggering via TRG-IN (measured value output depends on TRIGGERCOUNT)
-- PULSE: Gate triggering via TRG-IN (continuous measured value output as long as
TRG-IN is active)
-- SOFTWARE: Triggering via the TRIGGERSW command (measured value output depends on TRIGGERCOUNT)
Default = NONE
A 4.4.8.2 Trigger Level
TRIGGERLEVEL HIGH|LOW LLL|HLL
Sets the active logic level and the switching threshold for the trigger input.
-- HIGH|LOW: active logic level
-- LLL|HLL: switching threshold
ƒƒ LLL = High Level Logic ==> LO = 0..0.7 Volt, HI = 8..30 Volt)
ƒƒ HLL = High Level Logic ==> LO = 0..3 Volt, HI = 8..30 Volt)
Default = HIGH LLL
A 4.4.8.3 Number of Measured Values to be Output
TRIGGERCOUNT 0|1...16382|INFINITE|16383
Determines how many measured values are output after a trigger event.
-- 1...16382: Number of measured values to be output after the trigger event
-- INFINITE|16383: Start of continuous measured value output after a trigger event
0: Stops the continuous measured value output
Default = 1
thicknessSENSOR
Page 59
Appendix | ASCII Communication with the Sensor
A 4.4.8.4 Software Trigger Pulse
TRIGGERSW
Generation of a software trigger. If SOFTWARE is not selected in the trigger selection, the
error message “E43 triggermode SOFTWARE disabled” is output.
If the command is sent again when the measured value output is active, the triggering is
stopped and the measured value output is terminated.
A 4.4.9
Ethernet
IPCONFIG DHCP|STATIC [<IP address> [<Netmask> [<Gateway>]]]
Setting of the Ethernet interface.
-- DHCP: IP address and gateway are automatically queried by DHCP. If no DHCP server
is available, a link-local address is searched for after approx. 30 seconds.
-- STATIC: Sets an IP address, the net mask and the gateway in the format xxx.xxx.xxx.
xxx
If the IP address, net mask and/or gateway are not stated, their values remain unchanged.
A 4.4.10 Setting the Measured Value Server
MEASTRANSFER SERVER/TCP [<PORT>]
For measured value output via Ethernet: currently only TCP server is provided.
-- The port is freely selectable between 1024 and 65535.
A 4.4.11 Transmission Rate
BAUDRATE <Baud rate>
Setting the interface baud rate to the PC. Possible variants: 115.200 (Default), 8.000.000,
4.000.000, 3.500.000, 3.000.000, 2.500.000, 2.000.000, 1.500.000, 921.600, 691.200,
460.800, 230.400, 9.600 Baud
A 4.4.12 Save Parameters
STORE 1|2|3|4|5|6|7|8
Save the current parameters under the specified number in the Flash. The data set which
was saved last will be loaded when the thicknessSENSOR is restarted.
A 4.4.13 Load Parameters
READ ALL|DEVICE|MEAS 1|2|3|4|5|6|7|8
Read the parameters under the specified number from the Flash. The volume of data to
be loaded must also be specified:
-- ALL: All parameters are loaded.
-- DEVICE: Only the basic device settings are loaded (interface parameters).
-- MEAS: Only the measurement settings are loaded (all properties for the measurement).
A 4.4.14 Factory defaults
SETDEFAULT [ALL] [NODEVICE]
Sets the default values (reset to factory setting).
-- ALL: All setups are deleted and the default parameters are loaded, otherwise only the
current setup is deleted.
-- NODEVICE: The IP address settings are temporarily retained.
thicknessSENSOR
Page 60
Appendix | ASCII Communication with the Sensor
A 4.4.15 Measurement Mode
MEASMODE SENSOR1VALUE|SENSOR12THICK|SENSOR12STEP
Set measurement mode, possible are:
-- SENSOR1VALUE: Measured value of sensor 1
-- SENSOR12THICK: The measured values of sensor 1 and sensor 2 are subtracted
from the measuring range and both results are added together. If the mastering is
active, both values are subtracted from the internal mastering offset.
-- SENSOR12STEP: Difference from measured value from sensor 1 minus measured
value from sensor 2.
A 4.4.16 Measuring Rate
MEASRATE x.xxx
Measurement frequency in kHz with three decimal places.
Only measuring rates that support the sensors are permitted. If the synchronization is deactivated, values between 0.400 and 80.000 are permitted.
A 4.4.17 Measured Value Averaging Controller
AVERAGE NONE|MOVING|RECURSIVE|MEDIAN [<Averaging depth>]
Output averaging of the thicknessSENSOR. The average acts on the thicknessSENSOR
measured value at all interfaces, also analog.
-- MOVING: Moving average (averaging depth of 2, 4, 8, 16, 32, 64, 128, 256 and 512
possible).
-- RECURSIVE: Recursive average (averaging depth of 2, 4, 8, ..., 32768 possible)
-- MEDIAN: Median (averaging depth of 3, 5, 7 and 9 possible)
A 4.4.18 Measured Value Averaging Sensor
AVERAGE1 NONE|MOVING|RECURSIVE|MEDIAN [<Averaging depth>]
Averaging in the sensors. The average always acts on all distance and difference values
to be output.
-- MOVING: Moving average 1
-- RECURSIVE: Recursive average 1
-- MEDIAN: Median 1
The AVERAGE2 NONE|MOVING|RECURSIVE|MEDIAN [<Averaging depth>] command sets the average of the sensor connected to the Sensor 2 socket.
A 4.4.19 Mastering / Zeroing
MASTERMV NONE|MASTER <Master value>
Mastering of the thicknessSENSOR.
-- NONE: Terminates the mastering
-- MASTER: Setting the current measured value as master value
ƒƒ Master value in millimeters (min: -1024.0 mm, max: 1024.0 mm)
ƒƒ If the master value is 0, the mastering function has the same function as the zero
setting.
A 4.4.20 Selection Digital Output
OUTPUT NONE|ETHERNET|HTTP|USB
Activates the data output at the desired interface.
-- NONE: No measured value output
-- ETHERNET: Output of measured values via Ethernet
-- HTTP: Output of measured values via the thicknessSENSOR web page
-- USB: Output of measured values via USB
1) Only those values which are also supported by the sensor are possible.
thicknessSENSOR
Page 61
Appendix | ASCII Communication with the Sensor
A 4.4.21 Output Data Rate
OUTREDUCE <Output reduction> ([ANALOG] [USB] [ETHERNET])|NONE
Reduces the measured value output for all available interfaces.
-- 1: Output of every measured value
-- 2 ... 1000: Output of each n-th measured value
A 4.4.22 Scale Output Values
OUTSCALE_RS422_USB STANDARD|(TWOPOINT <Minimum measured value> <Maximum
measured value>)
Sets the scaling of the C-BOXVALUE via USB.
The default scaling is for distance/level 0 to MR (Sensor1) and for thickness measurement 0 to MR (Sensor1) + MR (Sensor2) (MR = measuring range).
The minimum and maximum measured value must be indicated in millimeters. The available output area of the USB output is then spread between the minimum and maximum
measured value. The minimum and maximum measured value must be between -1024.0
and 1024.0 mm with four decimal places. The max value must be greater than the min
value.
A 4.4.23 Error Handling
OUTHOLD NONE|0|<Number>
Setting the behavior of the measured value output in case of error for the thicknessSENSOR measured value, not for the sensor values.
-- NONE: No holding the last measured value, output of error value.
-- 0: Infinite holding of the last measured value.
-- Number: Holding the last measured value over a number of measuring cycles; then an
error value (maximum 1024) is output.
A 4.4.24 Data Selection for USB
OUT_USB NONE|([SENSOR1VALUE][SENSOR1INTENSITY][SENSOR1SHUTTER][SENSOR1REFLECTIVITY][SENSOR2VALUE][SENSOR2INTENSITY][SENSOR2SHUTTER][SENSOR2REFLECTIVITY][C-BOXVALUE][C-BOXCOUNTER][C-BOXTIMESTAMP][C-BOXDIGITAL])
Setting which values are to be output via USB.
-- NONE: No output of a distance
-- SENSOR1VALUE: Measured value of Sensor 1
-- SENSOR1INTENSITY: Intensity of Sensor 1
-- SENSOR1SHUTTER: Shutter speed of Sensor 1
-- SENSOR1REFLECTIVITY: Reflectivity of Sensor 1
-- SENSOR2INTENSITY: Intensity of Sensor 2
-- SENSOR2VALUE: Measured value of Sensor 2
-- SENSOR2SHUTTER: Shutter speed of Sensor 2
-- SENSOR2REFLECTIVITY: Reflectivity of Sensor 2
-- C-BOXVALUE: Calculated value of thicknessSENSOR
-- C-BOXCOUNTER: Counter value of thicknessSENSOR
-- C-BOXTIMESTAMP: Timestamp of thicknessSENSOR
-- C-BOXDIGITAL: Digital inputs/outputs of thicknessSENSOR
thicknessSENSOR
Page 62
Appendix | ASCII Communication with the Sensor
A 4.4.25 Data Selection for Ethernet
OUT_ETH NONE|([SENSOR1VALUE][SENSOR1INTENSITY][SENSOR1SHUTTER][SENSOR1REFLECTIVITY][SENSOR2VALUE][SENSOR2INTENSITY][SENSOR2SHUTTER][SENSOR2REFLECTIVITY][C-BOXVALUE][C-BOXCOUNTER][C-BOXTIMESTAMP][C-BOXDIGITAL])
Setting which values are to be output via Ethernet.
-- NONE: No output of a distance
-- SENSOR1VALUE: Measured value of Sensor 1
-- SENSOR1INTENSITY: Intensity of Sensor 1
-- SENSOR1SHUTTER: Shutter speed of Sensor 1
-- SENSOR1REFLECTIVITY: Reflectivity of Sensor 1
-- SENSOR2VALUE: Measured value of Sensor 2
-- SENSOR2INTENSITY: Intensity of Sensor 2
-- SENSOR2SHUTTER: Shutter speed of Sensor 2
-- SENSOR2REFLECTIVITY: Reflectivity of Sensor 2
-- C-BOXVALUE: Calculated value of thicknessSENSOR
-- C-BOXCOUNTER: Counter value of thicknessSENSOR
-- C-BOXTIMESTAMP: Timestamp of thicknessSENSOR
-- C-BOXDIGITAL: Digital inputs/outputs of thicknessSENSOR
A 4.4.26 Function Selection Multi-function Input
MFIFUNC NONE|MASTER|SENSOR1|SENSOR2|SENSOR12 LLL|HLL
Function of the multi-function input, either mastering or output to one or both multi-function outputs (sensor).
-- NONE -> No function
-- MASTER -> C-Box mastering
-- SENSOR1 -> Multi-function output for sensor 1
-- SENSOR2 -> Multi-function output for sensor 2
-- SENSOR12 -> Multi-function output for sensor 1 and 2
-- LLL -> Low Level Logic input
-- HLL -> High Level Logic input
A 4.4.27 Activate Error Output, Switching Output 1
ERROROUT1 SENSOR1ERROROUT1|SENSOR1ERROROUT2|SENSOR2ERROROUT1|SENSOR2ERROROUT2|SENSOR1VALUE|SENSOR1INTENSITY|SENSOR1SHUTTER|SENSOR1REFLECTIVITY|SENSOR2VALUE|SENSOR2INTENSITY|SENSOR2SHUTTER|SENSOR2REFLECTIVITY|C-BOXVALUE|LOW|HIGH
Select the signal source for the switching output 1 (to the periphery).
The first four switch only one error output of the sensors.
The next nine monitor values from the thicknessSENSOR.
The last two switch the output to a level by command.
A 4.4.28 Activate Error Output, Switching Output 2
ERROROUT2 SENSOR1ERROROUT1|SENSOR1ERROROUT2|SENSOR2ERROROUT1|SENSOR2ERROROUT2|SENSOR1VALUE|SENSOR1INTENSITY|SENSOR1SHUTTER|SENSOR1REFLECTIVITY|SENSOR2VALUE|SENSOR2INTENSITY|SENSOR2SHUTTER|SENSOR2REFLECTIVITY|C-BOXVALUE|LOW|HIGH
Select the signal source for the switching output 2 (to the periphery).
The first four switch only one error output of the sensors.
The next nine monitor values from the sensors or the thicknessSENSOR.
The last two switch the output to a level by command.
thicknessSENSOR
Page 63
Appendix | ASCII Communication with the Sensor
A 4.4.29 Limit Values
ERRORLIMIT1 <Lower limit value><Upper limit value>
If a measured value or calculated value is to be monitored using ERROROUT1, the limits
can be set here.
The minimum and maximum measured value is processed with four decimal places.
ERRORLIMIT2 <Lower limit value><Upper limit value>
If a measured value or calculated value is to be monitored using ERROROUT2, the limits
can be set here.
The minimum and maximum measured value is processed with four decimal places.
A 4.4.30 Data Selection
ANALOGOUT1 SENSOR1VALUE|SENSOR1INTENSITY|SENSOR1SHUTTER|SENSOR1REFLECTIVITY|SENSOR2VALUE|SENSOR2INTENSITY|SENSOR2SHUTTER|SENSOR2REFLECTIVITY|C-BOXVALUE|FIXED [Value]
Selection of the signal to be output via the analog output1.
For FIXED, the voltage/current value is indicated with four decimal places.
ANALOGOUT2 SENSOR1VALUE|SENSOR1INTENSITY|SENSOR1SHUTTER|SENSOR1REFLECTIVITY|SENSOR2VALUE|SENSOR2INTENSITY|SENSOR2SHUTTER|SENSOR2REFLECTIVITY|C-BOXVALUE|FIXED [Value]
Selection of the signal to be output via the analog output2.
For FIXED, the voltage/current value is indicated with four decimal places.
A 4.4.31 Output Area
ANALOGRANGE1 NONE|0-5V|0-10V|-5-5V|-10-10V|4-20mA
-- NONE: No analog output (inactive)
-- 0 - 5 V: The analog output1 outputs a voltage of 0 to 5 volts.
-- 0 - 10 V: The analog output1 outputs a voltage of 0 to 10 volts.
-- -5 - 5 V: The analog output1 outputs a voltage of -5 to 5 volts.
-- -10 - 10 V: The analog output1 outputs a voltage of -10 to 10 volts.
-- 4 - 20 mA: The analog output1 outputs a current of 4 to 20 mA.
ANALOGRANGE2 NONE|0-5V|0-10V|-5-5V|-10-10V|4-20mA
-- NONE: No analog output (inactive)
-- 0 - 5 V: The analog output2 outputs a voltage of 0 to 5 volts.
-- 0 - 10 V: The analog output2 outputs a voltage of 0 to 10 volts.
-- -5 - 5 V: The analog output2 outputs a voltage of -5 to 5 volts.
-- -10 - 10 V: The analog output2 outputs a voltage of -10 to 10 volts.
-- 4 - 20 mA: The analog output2 outputs a current of 4 to 20 mA.
A 4.4.32 Two-point Scaling
ANALOGSCALE1 STANDARD|(TWOPOINT <Minimum measured value> <Maximum measured value>)
Setting the scaling of analog output1.
The standard scaling is for distances -MR/2 to MR/2, for thickness measurement 0 to 2 MR (MR =
measuring range), for intensity 0 to 100 %.
If the minimum and maximum measured value is ‘0’, standard scaling is used.
The minimum and maximum measured value must be indicated in millimeters (distance/thickness)
or % (intensity).
The available output area of the analog output is then spread between the minimum and maximum
values. The minimum and maximum measured value must be between -1024.0 and 1024.0 mm
with four decimal places.
The minimum and maximum measured value is processed with four decimal places.
ANALOGSCALE2 STANDARD|(TWOPOINT <Minimum measured value> <Maximum measured value>)
thicknessSENSOR
Page 64
Appendix | ASCII Communication with the Sensor
Setting the scaling of analog output2.
The standard scaling is for distances -MR/2 to MR/2, for thickness measurement 0 to 2
MR (MR = measuring range), for intensity 0 to 100 %.
If the minimum and maximum measured value is ‘0’, standard scaling is used.
The minimum and maximum measured value must be indicated in millimeters (distance/
thickness) or % (intensity).
The available output area of the analog output is then spread between the minimum
and maximum values. The minimum and maximum measured value must be between
-1024.0 and 1024.0 mm with four decimal places.
The minimum and maximum measured value is processed with four decimal places.
A 4.4.33 Send Command to Connected Sensor
TUNNEL1 <Command for Sensor 1>
The command is enclosed in quotation marks and is sent by the thicknessSENSOR with
a <CRLF> to the sensor connected to the Sensor 1 socket. The response of the sensor
is packaged and returned in quotation marks.
If no prompt is received, then the response is waited for up to 15000 ms and then an
error is returned.
If no sensor has been detected in the thicknessSENSOR, an error message is returned
immediately.
Example of a tunnel communication, the echo in the sensor is switched off:
Command:
TUNNEL1 „LASERPOW“<CRLF>
Response:
TUNNEL1 „LASERPOW FULL“<CRLF>->
Command:
TUNNEL1 „LASERPOW FULL“<CRLF>
Response:
TUNNEL1 „<CRLF>“<CRLF>->
Command:
TUNNEL1 „GETINFO“<CRLF>
Response:
TUNNEL1 „<CRLF><CRLF>Name:ILD2300<CRLF>Serial:1020004<CRLF>... “<CRLF>->
The TUNNEL2 command sends commands to the sensor connected to the Sensor 2
socket.
A 4.4.34 Laser off / Laser on
LASERPOW1 OFF|ON
Line for laser on/off. When the laser is enabled by a jumper between Laser ON and
GND, it can be switched via the LASERPOW1 OFF/ON command.
The LASERPOW2 command works in the same way and is addressed to the sensor connected to the Sensor 2 socket.
A 4.4.35 Find thicknessSENSOR
Search the thicknessSENSOR by using the Sensorfinder, see chapter 6.2.2.
A 4.5
262073
USB scaling underflow
262074
USB scaling overflow
262075
Too much data for this baud rate
262079
Measure value cannot be calculated
262080
Measure value cannot be examined, global error
A 4.6
thicknessSENSOR
Error Values via USB
Error Values via Ethernet
7ffffff8
Measure value cannot be calculated
7ffffff7
Measure value cannot be examined, global error
