Service Manual
Welch Allyn Spot Vital Signs LXi
Service Manual
ii
Welch Allyn Spot Vital Signs LXi
Copyright 2008 Welch Allyn. All rights are reserved. No one is permitted to reproduce or duplicate, in any
form, this manual or any part thereof without permission from Welch Allyn.
Welch Allyn assumes no responsibility for any injury to anyone, or for any illegal or improper use of the
product, that may result from failure to use this product in accordance with the instructions, cautions,
warnings, or statement of intended use published in this manual.
Welch Allyn®, Spot Vital Signs®, SureBP® Technology, and SureTemp® are registered trademarks of Welch
Allyn.
Braun ThermoScan® is a registered trademark of the Braun Company.
LNCS™ is a trademark of, and SET®, LNOP®, and Masimo® are registered trademarks of, Masimo
Corporation. Possession or purchase of a Masimo SpO2-equipped device does not convey any express or
implied license to use the device with unauthorized sensors or cables which would, alone or in
combination with this device, fall within the scope of one or more of the patents relating to this device.
Nellcor® and Oxi-Max® are registered trademarks of Nellcor Puritan Bennett Inc.
Software in this product is Copyright 2008 Welch Allyn or its vendors. All rights are reserved. The software
is protected by United States of America copyright laws and international treaty provisions applicable
worldwide. Under such laws, the licensee is entitled to use the copy of the software incorporated with
this instrument as intended in the operation of the product in which it is embedded. The software may not
be copied, decompiled, reverse-engineered, disassembled, or otherwise reduced to human-perceivable
form. This is not a sale of the software or any copy of the software; all right, title, and ownership of the
software remain with Welch Allyn or its vendors.
For information about any Welch Allyn product, call Welch Allyn Technical Support:
USA +1 800 535 6663
+ 1 315 685 4560
Australia +61 2 9638 3000
Canada +1 800 561 8797
China +86 21 6327 9631
European Call Center +353 46 90 67790
France + 331 6009 3366
Germany +49 7477 9271 70
Japan +81 3 3219 0071
Latin America +1 305 669 9003
Netherlands +31 157 505 000
Singapore +65 6419 8100
South Africa +27 11 777 7555
United Kingdom +44 207 365 6780
Sweden +46 85 853 6551
Reorder #4500-89
Manual Material No. 704432 Rev. C
Welch Allyn
4341 State Street Road
Skaneateles Falls, NY
13153 USA
Printed in USA
EC
REP
European Regulatory Manager
Welch Allyn Ltd.
Navan Business Park
Dublin Road
Navan, County Meath, Republic of Ireland
Tel.: +353 46 90 67700
Fax: +353 46 90 67755
Directions for Use
Contents
iii
Contents
Safety Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
General Warnings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Blood Pressure Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Temperature Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SpO2 Warnings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
General Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Blood Pressure Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Temperature Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
SpO2 Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Electrostatic Discharge (ESD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Safety Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Button Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Connection Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Agency Symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Purpose and Scope. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Other Applicable Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Contents Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Possible Attachments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Technical Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Field Replacement Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Service Loaners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Service Intervals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Spot Vital Signs LXi Configurations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Display Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Braun ThermoScan PRO 4000 Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Blood Pressure Hose and Cuff . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Thermometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
SpO2 Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Wireless Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Quick Reference Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
AC Power Transformer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Standby Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Functional Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Self Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Internal Configuration Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
iv
Contents
Welch Allyn Spot Vital Signs LXi
Functional Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Blood Pressure Functional Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature Functional Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Masimo SpO2 Functional Check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Nellcor SpO2 Functional Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28
28
29
32
32
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voltage Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Blood Pressure Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuration Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
33
34
34
34
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Error Codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery Voltage Check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Window Display Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Blood Pressure Calibration Check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature Functional Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Masimo SpO2 Functional Check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Nellcor SpO2 Functional Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Functional Testing Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Current Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Noise Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Button Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interface Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pneumatic Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Over Pressure Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wireless Radio Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Work Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
37
39
40
40
40
41
41
41
41
42
42
42
43
43
43
44
46
Disassembly and Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Tool list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Key Pad Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
SpO2 Circuit Board Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Masimo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Nellcor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Blood Pressure Circuit Board Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
LCD Inverter Ballast Board Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
LCD Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Pump Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
RS232-Communication Circuit Board Disassembly . . . . . . . . . . . . . . . . . . . . . . 56
Fan and Power Circuit Board Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Thermometry Circuit Board Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
SureTemp Plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Braun ThermoScan PRO 4000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Directions for Use
Contents
v
Technical Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
System Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Battery System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Battery Charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
“CPU I/O” Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
CPU Core Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
+5V Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Clock/Calendar Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Mod F NIBP Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
SpO2 and Thermometer Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
LCD Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
External Load (RS-232) Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
SureTemp Plus Thermometer Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Braun ThermoScan PRO 4000 Thermometer Interface . . . . . . . . . . . . . . . . 63
SpO2 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Wireless Radio Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
FCC Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
FCC RF Exposure Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
IC Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Key Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Bar Code Scanner Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
3800 LR-13 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
4600SF031C Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Output Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Printer Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
InterconnectDiagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Field Replaceable Units. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Blood Pressure Accuracy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Temperature Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
SpO2 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Masimo Sensor Accuracy Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Masimo Patents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Nellcor Sensor Accuracy Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Nellcor Patents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Mechanical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Patents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Environmental. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Wireless Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Mechanical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Configuration Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Guidance and Manufacturer’s Declaration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
vi
Contents
Welch Allyn Spot Vital Signs LXi
Maintenance and Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Spot Vital Signs LXi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Blood Pressure Cuff . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Blood Pressure Hose and Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SureTemp Plus Thermometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braun ThermoScan PRO 4000 Thermometer . . . . . . . . . . . . . . . . . . . . . . .
SpO2 Sensors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wireless Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Printer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Spot Vital Signs LXi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braun ThermoScan PRO 4000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Printer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Spot Vital Signs LXi Firmware Upgrade CD . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Spot Vital Signs LXi Wireless Radio Configuration CD . . . . . . . . . . . . . . . . . . . .
Product Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
85
85
85
85
86
86
87
87
87
88
88
89
89
90
90
90
Repair Test Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
General Unit Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A-D Noise Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leak Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inflation Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dump Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pneumatic Accuracy Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Valve Control Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voltage Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Blank Mode Current Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Back Light (Idle) Current Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Valve/Pump Mode Current Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interface Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature Option Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accuracy Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature Probe Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SpO2 Option Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SpO2 Functional Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SpO2 Mode Current Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fail Safe Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Over Pressure Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Over 15 mmHg. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
91
91
91
91
91
91
92
92
92
92
92
92
92
92
93
93
93
93
93
93
93
Supplies and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Blood Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Pulse Oximetry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Masimo Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Nellcor Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Miscellaneous. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Service Contracts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Directions for Use
Contents
vii
Miscellaneous Mounting Accessories . . . . . . . . . . . . . . . . . . . . . . . . 101
Wall Mount Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mobile Stand Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wireless Mounting Accessory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Printer Mounting Accessory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Scanner Mounting Accessory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
101
103
105
106
107
Warranty 109
Spot Vital Signs LXi. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
viii
Contents
Welch Allyn Spot Vital Signs LXi
1
1
Safety Summary
Introduction
All users of the Spot Vital Signs LXi must read and understand the safety summary, and
all additional specific warnings and cautions located throughout the documentation.
Warnings and Cautions
Familiarize all operating personnel with the general safety information in this summary.
Specific warnings and cautions are also found throughout this manual.
General Warnings
A warning statement in this manual identifies a condition or practice, which if not
corrected or discontinued immediately, could lead to patient injury, illness, or death.
These warnings pertain entirely to Spot Vital Signs LXi .
WARNING The information in this manual is a comprehensive guide to the
operation of Spot Vital Signs LXi. For best results, read this manual thoroughly
before using the device.
WARNING Spot Vital Signs LXi is designed for medical clinician use. Although
this manual may illustrate medical spot-check techniques, only a trained clinician
who knows how to take and interpret a patient’s vital signs should use this
device.
WARNING Spot Vital Signs LXi is not intended for use in environments that are
without health care practitioner supervision.
WARNING Spot Vital Signs LXi is not intended for continuous monitoring. Do
not leave the device unattended while taking measurements on a patient.
WARNING To ensure data integrity, save readings and clear the Spot Vital Signs
LXi display between patients.
WARNING The Spot Vital Signs LXi is not defibrillator proof.
WARNING Spot Vital Signs LXi is not intended for use during patient transport.
WARNING This device is not suitable for use in the presence of a flammable
anesthetic mixture with air or oxygen or nitrous oxide. An explosion may result.
2
Safety Summary
Welch Allyn Spot Vital Signs LXi
WARNING To ensure patient safety, use only accessories and supplies (i.e.,
cuffs, hoses, temperature probes, SpO2 sensors, etc.) recommended for or
supplied with Spot Vital Signs LXi. Using unapproved accessories with Spot Vital
Signs LXi can affect patient and/or operator safety.
WARNING Take care to prevent water or other fluid from entering any
connectors on the device. Should this occur, dry the connectors with warm air.
Check the accuracy of all operating functions.
WARNING Every three months, inspect the blood pressure cuff, SpO2 cable,
and other accessories for fraying or other damage. Replace as necessary.
WARNING Do not use Spot Vital Signs LXi on patients who are on heart/lung
machines.
WARNING Electric shock hazard. There are no user-serviceable parts inside Spot
Vital Signs LXi other than battery replacement (see “Battery Replacement” on
page 88). An operator may only perform maintenance procedures specifically
described in this manual. For service, refer the device to an Authorized Service
Center.
WARNING This device is not intended for hand-held use during operation.
WARNING Do not autoclave.
WARNING This device complies with current required standards for
electromagnetic interference and should not present problems to other
equipment or be affected by other devices. As a precaution, avoid using this
device in close proximity to other equipment.
WARNING Welch Allyn is not responsible for the integrity of any mounting
installation. Welch Allyn recommends that the customer contact their Biomedical
Engineering Department or maintenance service to ensure professional
installation for safety and reliability of any mounting accessory.
WARNING The Spot Vital Signs LXi consists of high-quality precision parts.
Protect it from severe impact and shock. A qualified service technician must
check any Spot Vital Signs LXi that is dropped or damaged for proper operation
prior to further use. Do not use the Spot Vital Signs LXi if you notice any signs of
damage. Contact the Welch Allyn Customer Service Department for assistance.
WARNING Do not use an SpO2 finger clip sensor and a blood pressure cuff
simultaneously on the same limb. Doing so may result in inaccurate pulse rate
and perfusion readings.
WARNING All signal input and output (I/O) connectors are intended for
connection of only devices complying with IEC 60601-1, or other IEC standards
(for example, IEC 60950) as appropriate to the device. Connecting additional
devices to the Spot LXi may increase leakage currents. To maintain operator and
patient safety, it is necessary to consider the requirements of IEC 60601-1-1.
WARNING For proper patient electrical isolation, use only a Welch Allyn power
supply (4500-101A) to charge Spot Vital Signs LXi and its attached peripheral
devices. Do not use an external charger while the printer or weight scale is
attached to Spot LXi.
Service Manual
Safety Summary
3
Blood Pressure Warnings
These warnings pertain to the Spot Vital Signs LXi blood pressure feature.
WARNING Spot Vital Signs LXi is not intended to measure BLOOD PRESSURE
on neonatal patients. The AAMI SP10:2002 standard defines neonates as children
28 days or less of age if born at term (37 weeks gestation or more); otherwise up
to 44 gestational weeks.
WARNING To ensure pediatric blood pressure accuracy and safety, the Child
Reusable Two-Piece Blood Pressure Cuff (4500-01), Infant Durable One-Piece
Cuff (5082-82-4MQ), and the Infant Disposable One-Piece Cuff (5082-92-4MQ)
are the smallest cuffs approved for use with young children and infants. The
child’s arm must fit within the range markings on the cuff.
WARNING Avoid compression of the blood pressure hose or cuff tubing of Spot
Vital Signs LXi. This may cause system errors to occur in the device.
WARNING Patients who are experiencing moderate to severe arrhythmias may
give inaccurate blood pressure measurements.
WARNING Spot Vital Signs LXi does not operate effectively on patients who are
experiencing convulsions or tremors.
WARNING Use only Welch Allyn blood pressure cuffs and/or hoses. Using other
manufacturers’ blood pressure cuffs and/or hoses may produce inaccurate blood
pressure readings.
WARNING When several blood pressure measurements are taken on the same
patient, regularly check the cuff site and extremity for possible ischemia, purpura,
and/or neuropathy.
WARNING Do not allow a blood pressure cuff to remain on the patient more
than 10 minutes when inflated above 10 mmHg. This may cause patient distress,
disturb blood circulation, and contribute to injury of peripheral nerves.
WARNING Do not place the cuff on any extremity that is used for intravenous
infusions or any area where circulation is compromised.
WARNING Excessive cuff tightness may cause venous congestion and
discoloration of the limb.
WARNING Wrapping the cuff too loosely (preventing proper inflation) may result
in errors.
WARNING Do not change the connector(s) on the blood pressure cuff tubing of
this device to luer type. Luer type connectors are commonly used in intravenous
infusion systems. Using the luer connectors on blood pressure cuff tubing
creates the risk that the blood pressure tubing could be mistakenly connected to
a patient's intravenous line, resulting in the introduction of air into the patient's
circulatory system.
4
Safety Summary
Welch Allyn Spot Vital Signs LXi
Temperature Warnings
These warnings pertain to the Spot Vital Signs LXi temperature feature.
SureTemp® Plus
These warnings are specific to the SureTemp Plus thermometer option.
WARNING Use only Welch Allyn probe covers. Using other manufacturers’
probe covers or no probe cover may produce temperature measurement errors
and/or inaccuracy.
WARNING Always use a probe cover whenever coming into contact with a
patient.
WARNING Long-term continuous monitoring beyond three to five minutes is
not recommended in any mode.
WARNING Oral/axillary probes (blue ejection button at top of probe) and blue
removable probe wells are used for taking oral and axillary temperatures only.
Rectal probes (red ejection button) and red removable probe wells are used for
taking rectal temperatures only. Use of the probe at the wrong site will result in
temperature errors. Use of the incorrect removable probe well could result in
patient cross-contamination.
WARNING The thermometer connectors and probe are not waterproof. Do not
immerse or drip fluids on these items. Should this occur, dry the connectors and
probe with warm air. Check all functions for proper operation and accuracy.
WARNING Do not take an axillary temperature through patient’s clothing. Direct
probe cover to skin contact is required.
WARNING Do not autoclave.
WARNING Use Welch Allyn single-use disposable probe covers to limit patient
cross-contamination.
WARNING Incorrect insertion of probe can cause bowel perforation.
WARNING Washing hands greatly reduces the risk of cross-contamination and
nosocomial infection.
WARNING To ensure optimal accuracy, always confirm that the correct mode is
selected.
Service Manual
Safety Summary
5
Braun Thermoscan PRO 4000
These warnings are specific to the Braun ThermoScan PRO 4000 thermometer option.
WARNING Keep the probe window clean, dry, and undamaged at all times to
ensure accurate measurements. To protect the probe window, always keep the
thermometer in the storage cover while transporting or when not in use.
WARNING Only use Braun ThermoScan probe covers with this thermometer.
Using other manufacturer’s probe covers or no probe cover may produce
temperature measurement errors and/or inaccuracies. If the thermometer is used
without a probe cover attached, clean the lens (see “Braun ThermoScan PRO
4000 Thermometer” on page 86).
WARNING Do not autoclave.
WARNING The thermometer is not waterproof. Do not immerse or drip fluids
on it. Should this occur, dry the thermometer with warm air. Check for proper
operation and accuracy.
SpO2 Warnings
These warnings pertain to the Spot Vital Signs LXi SpO2 feature.
WARNING Only use Spot Vital Signs LXi with Masimo or Nellcor SpO2 option
with Masimo or Nellcor brand sensors and accessories, respectively. Using the
wrong or unapproved sensors or cables may cause improper performance.
WARNING The SpO2 sensor and extension cables are intended for use only for
pulse oximetry measurements. Do not attempt to connect these cables to a PC
or any similar device.
WARNING Before using, carefully read the sensor Directions for Use, including
all warnings, cautions, and instructions.
WARNING Do not use a damaged sensor or pulse oximetry cable or a sensor
with exposed optical components.
WARNING Incorrect application or a long duration of use of an SpO2 sensor may
cause tissue damage. Inspect the sensor site periodically as directed in the
sensor’s Directions for Use.
WARNING Certain ambient environmental conditions, sensor application errors,
and certain patient conditions may affect SpO2 readings and pulse signal.
WARNING Do not immerse the sensor or patient cables in water, solvents, or
cleaning solutions (the sensors and connections are not waterproof). Do not use
irradiation, steam, or ethylene oxide for sterilization.
WARNING The SpO2 in the Spot Vital Signs LXi device is not intended for use
as an apnea monitor.
WARNING Consider the SpO2 an early warning device. As a trend toward
patient deoxygenation is indicated, use laboratory instruments to analyze blood
samples to completely understand the patient’s condition.
6
Safety Summary
Welch Allyn Spot Vital Signs LXi
WARNING Tissue damage can be caused by incorrect application or duration of
use of a Nellcor OxiMax sensor. Inspect the sensor site as directed in the sensor
Directions for Use.
WARNING Do not use the sensors during magnetic resonance imaging (MRI)
scanning. Induced current could potentially cause burns. The MS board pulse
oximeter may affect the MRI image, and the MRI unit may affect the accuracy of
the oximetry measurements.
WARNING Carefully route patient cabling to reduce the possibility of patient
entanglement or strangulation.
WARNING Failure to cover the Nellcor OxiMax sensor site with opaque material
in high ambient light conditions may result in inaccurate measurements.
General Cautions
A caution statement in this manual identifies a condition or practice, which if not
corrected or discontinued immediately, could lead to equipment failure, equipment
damage, or data loss.
These cautions pertain to the entire Spot Vital Signs LXi device.
Caution If the accuracy of any measurement is in question, check the patient’s
vital sign(s) with an alternate method and then check to verify the device is
functioning properly.
Caution Place the device on a secure surface or use one of the optional
mounting accessories.
Caution Do not place fluids on or near the device.
Caution It is recommended that the device is used within stated operating
temperature ranges (see “Environmental” on page 79). The device will not meet
its performance specifications if used outside these temperatures ranges.
Caution Always unplug the AC power transformer from the outlet before
moving the mobile stand to a new location.
Caution The basket has a three-pound weight limit. Take care not to exceed
this limit.
Caution Only use a 9V battery with the Healthometer scale. Remove and
discard the wall mounted power supply.
Caution When using the Healthometer scale, remove the two hex nuts on the
RS-232 cable, as supplied, before screwing the cable into the scale base.
Service Manual
Safety Summary
7
Blood Pressure Cautions
These cautions pertain to the Spot Vital Signs LXi blood pressure feature.
Caution Minimize extremity and cuff motion during blood pressure readings.
Caution If the blood pressure cuff is not at heart level, note the difference in
reading due to the hydrostatic effect. Add the value of 1.80 mmHg (.2 kPa) to the
displayed reading for every inch (2.5 cm) above heart level. Subtract the value of
1.80 mmHg (.2 kPa) from the displayed reading for every inch (2.5 cm) below
heart level.
Caution Proper blood pressure cuff size and placement is essential to the
accuracy of the blood pressure determination. See Reusable Two-Piece Cuff
Measurements or Durable One-Piece Cuff Measurements of the Directions for
Use for sizing information.
Caution The position and physiologic condition of the subject can affect a blood
pressure reading.
Temperature Cautions
These cautions pertain to the Spot Vital Signs LXi temperature feature.
Caution The SureTemp Plus feature only operates with the probe well in place.
Caution Do not use alkaline batteries in the Braun ThermoScan PRO 4000.
Caution Biting the probe tip may result in damage to the probe.
SpO2 Cautions
These cautions pertain to the Spot Vital Signs LXi SpO2 feature.
Caution The pulse oximeter is calibrated to determine the percentage of
arterial oxygen saturation of functional hemoglobin. Significant levels of
dysfunctional hemoglobin such as carboxyhemoglobin or methemoglobin may
affect the accuracy of the measurement.
Caution Some sensors may not be appropriate for a particular patient. If at
least 10 seconds of perfusion pulses cannot be observed for a given sensor,
change sensor location or sensor type for perfusion to resume.
Caution Physiological conditions, medical procedures, or external agents that
may interfere with the pulse oximeter’s ability to detect and display
measurements include dysfunctional hemoglobin, arterial dyes, low perfusion,
dark pigment, and externally applied coloring agents such as nail polish, dye, or
pigmented cream.
Caution When selecting a sensor, consider the patient’s weight and activity
level, the adequacy of perfusion, the available sensor sites, the need for sterility,
and the anticipated duration of monitoring.
8
Safety Summary
Welch Allyn Spot Vital Signs LXi
Electrostatic Discharge (ESD)
Electrostatic discharge is a sudden current flowing from a charged object to another
object or to ground. Electrostatic charges can accomulate on common items such as
foam drinking cups, cellophane tape, synthetic clothing, untreated foam packaging
material, and untreated plastic bags and work folders, to name only a few.
Electronic components and assemblies, if not properly protected against ESD, can be
permanently damaged or destroyed when near or in contact with electrostatically charged
objects. When you handle components or assemblies that are not in protective bags and
you are not sure whether they are static-sensitive, assum that they are static-sensitive
and handle them accordingly.
•
Perform all service procedures in a static-protected environment. Always use
techniques and equipment designed to protect personnel and equipment from
electrostatic discharge.
•
Remove static-sensitive components and assemblies from their static-shielding bags
only at static-safe workstations - a properly grounded table and grounded floor mat and only when you are wearing a grounded wrist strap (with a resistor of at least 1
megohm in series) or other grounding device.
•
Use only grounded tools when inserting, adjusting, or removing static-sensitive
components and assemblies.
•
Remove or insert static-sensitive components and assemblies only with monitor
power turned off.
•
Insert and seal static-sensitive components and assemblies into their original staticshielding bags before removing them from static-protected areas.
Always test your ground strap, bench mat, conductive work surface, and ground cord
before removing components and assemblies fromtheir protective bags and before
beginning any disassembly or assembly procedures.
Service Manual
Safety Summary
Symbols
The following symbols are associated with the Spot Vital Signs LXi.
Safety Symbols
Identifies information within the
manual to avoid injury.
Caution: consult accompanying
documents
Identifies information within the
manual to avoid equipment failure.
Pb
Internally Powered, Lead Acid
Battery
Handle with Care
Transport Temperature
Storage Humidity
Recycle
Class II Equipment
IPXØ
Equipment is not protected against
the ingress of liquid.
Type BF Equipment
On/Off
Recycle the product separate from
other disposables, see “Product
Disposal” on page 90.
Non-ionizing radiation (RF
transmitter)
Mode of Operation: Continuous
DC Power In
Button Symbols
Navigation Buttons
Blood Pressure
Select
MEM
Memory
Power On/Off
Connection Symbols
USB Connection
Serial Port Connection
9
10
Safety Summary
Welch Allyn Spot Vital Signs LXi
Agency Symbols
CERTIFIED TO:
CAN/CSA STD C22.2 NO. 601.1
C
US
166292
CONFORMS TO:
UL STD 60601-1
IEC 60601-1
The CE mark on this product indicates that it has been tested to and conforms with
the provisions noted within the 93/42/EEC Medical Device Directive.
0297
EC
REP
European Regulatory Manager
Welch Allyn Ltd.
Navan Business Park
Dublin Road
Navan, County Meath, Republic of Ireland
Tel.: +353 46 90 67700
Fax: +353 46 90 67755
11
2
Overview
Purpose and Scope
The Spot Vital Signs LXi Service Manual is intended as a reference for maintenance and
repair to the field replaceable unit (FRU) level and are listed on page 71. This manual
provides the technical qualified service person with troubleshooting information, repair
procedures, and calibration and performance verification instructions. A technical
overview of the Spot Vital Signs LXi subsystems is provided as an introduction to the
device’s circuitry and pneumatics.
This manual is intended for the technical qualified service person. Service training classes
on Welch Allyn’s products are available. Contact Welch Allyn Technical Service for
information.
Other Applicable Documents
The Spot Vital Signs LXi Directions for Use manual is also available. Refer to this
document for information other than maintenance and repair.
Welch Allyn 9600 Plus Calibration Tester Directions for Use - for all models.
Braun ThermoScan PRO 4000 User’s Guide - for models 450E0, 45NE0, 45ME0.
Masimo Directions for Use - for models 45MT0, 45ME0.
Nellcor Directions for Use - for models 45NT0, 45NE0.
12
Overview
Welch Allyn Spot Vital Signs LXi
Contents Checklist
Unpack the Spot Vital Signs LXi and any applicable accessories and then inspect for
missing items. Retain the shipping materials in the event of shipping damage or for
return, if necessary, to Welch Allyn for repair or warranty service. Report any signs of
shipping damage to the carrier. Report any missing or damaged items to the Welch Allyn
Service Center near you.
All Spot Vital Signs LXi devices include the following components:
Spot Vital Signs LXi Device. This device automatically measures and displays blood
pressure, pulse rate, and temperature.
Directions for Use Manual. Read this manual thoroughly before using Spot Vital Signs
LXi. Save this manual for reference.
Warranty Card. This card validates the Spot Vital Signs LXi warranty. Fill out the warranty
card and mail it today.
Blood Pressure Cuff. One cuff with connectors. Other size cuffs are available separately.
Blood Pressure Hose. Latex-free pressure hose with connectors to attach various sizes of
blood pressure cuffs to the Spot Vital Signs LXi.
AC Power Transformer and Cord Assembly. Provides power to the Spot Vital Signs LXi
and charges the internal battery.
Quick Reference Card. Attach this quick operating guide to the device handle, mobile
stand, or wall mount.
Possible Attachments
Spot Vital Signs LXi may include the following items based on the model and accessories
purchased:
SureTemp Plus Temperature Probe, Well, and Covers. One oral temperature probe
(blue ejection button and well) and one box of 25 single-use, disposable probe covers.
Braun ThermoScan PRO 4000 Thermometer and Covers. One ear thermometer; one
box of 20 single-use, disposable probe covers; one rechargeable battery pack; and
one lock release pin.
Barcode Scanner and Mounting Bracket. Attach these items on the basket of the
mobile stand or wall mount.
Pulse Oximetry (SpO2). The finger clip SpO2 sensor and extension cable are for use
with adult and pediatric patients. Other sensors are available separately.
Printer. Attach to the basket of the mobile stand or wall mount. The printer comes with a
roll of paper. Rolls of paper and labels are available separately.
Service Manual
Overview
13
Service
Caution Unauthorized repairs will void the warranty.
A Welch Allyn Service Center must perform all repairs on products under warranty.
Qualified electronics personnel or a Welch Allyn Service Center should repair products out
of warranty.
Technical Assistance
If you have an equipment problem that you cannot resolve, call the Welch Allyn Service
Center nearest you for assistance. Technical service telephone support is available on
normal business days.
If you are advised to return a product to Welch Allyn for repair or routine maintenance,
schedule the repair with the service center nearest you.
Before returning a product for repair, you must obtain authorization from Welch Allyn.
Service personnel will give you a Service Notification number. Please note this number on
the outside of your shipping box. Returns without a Service Notification number will not
be accepted for delivery.
Field Replacement Units
Included with the Service Manual is a complete list of field replacement units. Order
spare parts from your local Welch Allyn Service Center.
Service Loaners
Service loaners are provided, on request, if a Welch Allyn Service Center provides repair
service. Loaners for products repaired while under the original warranty, or while under
service contract, are provided free of charge and are shipped within 48 hours of
notification of need.
For service repairs outside of warranty or contract, loaners are available for a nominal
charge and shipment is subject to availability. Loaners are shipped pre-paid; however, this
charge is added to the service charges.
Service Intervals
Verify Spot Vital Signs LXi on an annual basis for blood pressure, temperature, and SpO2
accuracy.
14
Overview
Welch Allyn Spot Vital Signs LXi
Spot Vital Signs LXi Configurations
Table 1. Available Versions of Spot Vital Signs LXi
REF
Description
450T0
SureBP with SureTemp Plus Thermometer
450E0
SureBP with Braun ThermoScan PRO 4000 Thermometer
45MT0
SureBP with Masimo SpO2 and SureTemp Plus Thermometer
45ME0
SureBP with Masimo SpO2 and Braun ThermoScan PRO 4000 Thermometer
45NT0
SureBP with Nellcor SpO2 and SureTemp Plus Thermometer
45NE0
SureBP with Nellcor SpO2 and Braun ThermoScan PRO 4000 Thermometer
Controls
Figure 1. Spot Vital Signs LXi Front Panel with SureTemp Plus Thermometer
SureTemp Plus
thermometer:
remove the probe to
take a temperature.
BP
SYS
127
73
4 WEST
mmHg
DIA
mmHg
TEMP
985
SpO2
%
AM
Reading
01
F
PULSE
/min
Removable probe
well: store the
temperature probe
here when not in use;
remove to clean or
replace to eliminate
cross-contamination.
62
Patient ID 0123456789
Weight
Pain
Clear
Height
Respiration
Send/Next Reading
Enter
Probe cover
storage area:
storage space for one
box of probe covers.
Navigation button: move
throughout the options in
the Navigation Window or
to increase/decrease
parameter units.
Select button:
accepts the current
option.
Power button: controls
power to the device.
Charging LED: indicates
when device is plugged in and
charging the battery.
Blood Pressure Start/Stop button:
initiates a new blood pressure cycle.
Pressing again aborts an active blood
pressure measurement.
Memory button:
recalls up to 50 most
recent readings.
Service Manual
Overview
15
Figure 2. Spot Vital Signs LXi Front Panel with Braun ThermoScan PRO 4000 Thermometer
BP
SYS
127
73
Braun ThermoScan PRO 4000
thermometer: store the probe
covers toward the back of the
thermometer housing; remove the
thermometer to access the covers.
4 WEST
mmHg
DIA
AM
Reading
01
mmHg
TEMP
985
SpO2
PULSE
%
/min
62
Patient ID 0123456789
Weight
Height
Respiration
F
Pain
Clear
Send/Next Reading
Enter
BR
AUn
Navigation button: move
throughout the options in
the Navigation Window or
to increase/decrease
parameter units.
Memory button:
recalls up to 50 most
recent measurements.
Charging LED: indicates
when device is plugged in
and charging the battery.
Power button: controls
power to the device.
Charging LED: indicates
the thermometer battery
is charging.
Select button:
accepts the current
option.
Blood Pressure Start/Stop button:
initiates a new blood pressure cycle.
Pressing again aborts an active blood
pressure measurement.
16
Overview
Welch Allyn Spot Vital Signs LXi
Display Window
Note
1.
Before using Spot Vital Signs LXi for the first time, you must program an initial
configuration screen.
Press the Power button. The display window shows the initial configuration screen.
Figure 3. Initial Configuration Screen
Change Local Defaults Menu
Model No.: 45NTO
Serial No. 2005040004
Language:
BP Units:
Temperature Units:
Height Units:
Weight Units:
Date Format:
Date:
Time Format:
Time:
Select
2. Use the Select button to access the options and accept the entries, and use the
Navigation buttons to move through the menu.
3. The word “Exit” appears at the bottom of the list after you have programmed all
items in the menu. You must program all items before you can start to use the device.
4. Scroll to Exit and press the Select button to save the entries.
Service Manual
Overview
17
The liquid crystal display (LCD) may indicate any of the following: systolic blood pressure
(mmHg or kPa), diastolic blood pressure (mmHg or kPa), MAP (mmHg or kPa),
temperature (°F or °C), temperature mode, pulse rate, pulse signal level, SpO2 percent,
department location, date, time, record number, height (in or cm), weight (lb or kg),
respiration rate, pain level, connectivity signal strength, and battery charge level.
Figure 4. Display Window
Connectivity indicator: shows the
status of Spot LXi sending a wireless
reading.
Reading sent: indicates a
successful wireless send reading
attempt.
Reading not sent: indicates an
unsuccessful wireless send reading
attempt.
X
Systolic and Diastolic
display: if MAP is turned on,
the screen toggles between
the systolic and diastolic
values, and the word “MAP”
and the MAP value.
{
BP
SYS
mmHg
DIA
mmHg
127
73
SpO2 display: shows the
percent saturation of arterial
hemoglobin. For devices with
SpO2 only.
Navigation Window:
shows menu options, error
messages, or temperature
conversion.
Clock: shows the current time.
4 WEST
Reading number indicator:
shows what reading the device is
on. Spot Vital Signs LXi retains
up to 50 readings in memory.
AM
Reading
01
Battery level indicator: shows
the battery charge level.
{ 985
{
62
TEMP
Temperature display and
indicator: shows the
temperature in Fahrenheit or
Celsius.
Location identifier: shows
where the device belongs. If no
location is entered, this area
displays the date.
SpO2
{
F
%
PULSE
/min
Patient ID 0123456789
Weight
Pain
Height
Clear
Respiration
Send/Next Reading
Thermometer probe setting
indicators: shows temperature
mode. For devices with SureTemp
Plus thermometer only.
Thermometer probe setting
indicators: shows Monitor
Mode. For devices with SureTemp
Plus thermometer only.
Out-of-range indicator: shows
the patient’s temperature reading
above or below the measurement
range limits. For devices with
SureTemp Plus thermometer only.
Enter
Pulse Signal Bar Graph: shows
the strength of the pulses detected.
Pulse display: shows the pulse
rate.
Clinician ID icons:
The figure icon signifies that Spot
Vital Signs LXi requires the clinician to
enter the Clinician ID.
The check mark signifies Spot Vital
Signs LXi has recorded the Clinician
ID.
For devices with a bar code scanner
only.
18
Overview
Welch Allyn Spot Vital Signs LXi
Connections
Use the following instructions to connect the blood pressure hose, thermometer probe,
and optional attachments to the Spot Vital Signs LXi.
Figure 5. Spot Vital Signs LXi Side and Rear Panel Connections
Icon ID label
CTIONS
ort
56
MAT: 7039
SureTemp Plus thermometer
connection port (for units
with SureTemp Plus only)
SpO2 cable connection port
(for units with SpO2 only)
II
I
Port I for external
device connection
Blood pressure hose
connection port
DC power connection port
USB connection for PC
(behind plug)
Port II for external
device connection
Battery door
Mobile stand or wall
mount screw connection
Service Manual
Overview
19
Braun ThermoScan PRO 4000 Lock
Press the lock tab toward the Braun ThermoScan PRO 4000 thermometer until it clicks. To
release the housing, insert the lock release pin into the lock release hole until the lock tab
snaps back.
Figure 6. Spot Vital Signs LXi with Braun ThermoScan PRO 4000 Lock
Lock release pin
Lock tab
Lock release hole
Blood Pressure Hose and Cuff
Identify and have available the Spot Vital Signs LXi, blood pressure cuff, and the blood
pressure hose.
1.
Inspect the blood pressure hose; notice that one end has a single, gray connector
fitting and the other end has two white fittings.
2. Squeeze the side tabs on the gray connector and completely push the blood pressure
hose connector into the blood pressure hose connection port until it clicks into place
(see Figure 5 on page 18).
3. Twist the white connectors on the blood pressure hose and cuff connectors together.
20
Overview
Welch Allyn Spot Vital Signs LXi
Thermometer
Spot Vital Signs LXi is available with either the SureTemp Plus thermometer or the Braun
ThermoScan PRO 4000 thermometer.
SureTemp Plus
SureTemp Plus is available with two probes and matching wells; one for oral/axillary
temperatures (blue ejection button and probe well) and one for rectal temperatures (red
ejection button and probe well).
WARNING Always use a probe cover whenever coming into contact with a
patient.
Caution The SureTemp Plus feature only operates with the probe well in place.
1.
Align the probe well with the tabs facing up and down into the round opening of the
SureTemp Plus housing on the right side of Spot Vital Signs LXi. Push it into place.
2. Align the temperature probe connector with the SureTemp Plus thermometer
connection port on the back of the Spot Vital Signs LXi (see Figure 5 on page 18). You
can only insert the connector into the port one way.
3. Press the tab on the connector and push it until it clicks into place.
4. Insert the temperature probe into the probe well.
Braun ThermoScan PRO 4000
Caution Do not use alkaline batteries in the Braun ThermoScan PRO 4000
thermometer.
1.
Open the package of rechargable batteries and follow the installation guide provided.
2. Open the box of probe covers as directed on the box and slide the box into the metal
guides toward the back of the thermometer housing with the opening at the top and
perforation facing forward.
3. Hold the Braun thermometer at a 45° angle then insert the probe and the top of the
thermometer into the housing.
4. Lower the bottom portion of the thermometer into the housing until it snaps into
place. If you do not properly seat the thermometer, it could fall out of the holder and
become damaged.
5. Slide the thermometer housing into the thermometer slot on the right side of the
Spot Vital Signs LXi device.
6. Push the lock tab forward to prevent the thermometer housing from falling out of
Spot Vital Signs LXi (see Figure 6 on page 19).
To release the lock, insert the lock release pin into the lock release hole.
Service Manual
Overview
21
SpO2 Sensor
Spot Vital Signs LXi is available with a wide variety of SpO2 sensors and ships with a
reusable finger clip sensor.
1.
Align the shape and pin configuration of the extension cable connector to the SpO2
cable connection port on the left side of the Spot Vital Signs LXi device.
2. Push the connector firmly into the SpO2 cable connection port until you hear it click
into place (see Figure 5 on page 18).
3. Align the opposite end of the extension cable to the sensor cable connector and
firmly push them together.
Note
Use only Masimo or Nellcor SpO2 sensors and accessories with the Spot Vital
Signs LXi with Masimo or Nellcor configurations, respectively.
Wireless Radio
CTIO NS
ort
MAT: 70395
6
The Spot Vital Signs LXi
identifies which serial port to
use after activating the
Wireless Radio in the
internal configuration mode.
II
I
Only use Welch Allyn
Wireless Radio
PO
LIN WER
CO K
MM
Quick Reference Card
Attach the Quick Reference Card to the Spot Vital Signs LXi handle, mobile stand, or wall
mount using the supplied plastic cable tie.
22
Overview
Welch Allyn Spot Vital Signs LXi
AC Power Transformer
Note
To assure proper electrical isolation, replace the AC power transformer/charger
using only the Welch Allyn specified part.
The operator can use the Spot Vital Signs LXi with AC or battery power (after charging the
battery).
1.
Insert the round transformer connector into the AC power connection port on the
back of the Spot Vital Signs LXi (see Figure 5 on page 18).
2. Insert the line cord into the line connector on the transformer then plug the power
cord on the transformer into the AC main power source to charge the battery.
Battery
Charge the battery for 6 hours before initial use. Charge the device an additional hour if it
includes a Braun ThermoScan PRO 4000 thermometer. If there is an external printer,
connect the printer to the Spot Vital Signs LXi, enable it in the Internal Configuration
Mode (see “Initial Configuration Screen” on page 16 if this is the first time you power on
the device and then Table 7 on page 27), and then charge the Spot Vital Signs LXi for an
additional 4 hours.
While Spot Vital Signs LXi is charging, the charging LED (~) flashes and the battery level
indicator segments on the display continuously sequence. When the battery is fully
charged, the charging LED is solid and the battery level indicator is steady with all
segments continuously shown on the display.
If the device includes a Braun ThermoScan PRO 4000 thermometer, the charging LED
below the thermometer will illuminate orange as it is charging. When the battery is fully
charged, the LED will power off.
If the device has an external printer, the charging LED on the printer will flash orange and
green when Spot Vital Signs LXi is plugged into the AC main power source.
Note
There is no hazard associated with leaving the battery in the device, even if the
device is not used for long periods of time.
Standby Mode
The Standby Mode conserves battery power. The device goes into Standby Mode if it is
not used for two minutes. Press any button to bring the Spot Vital Signs LXi out of
Standby Mode.
23
3
Functional Overview
This functional verification procedure helps to confirm the proper operation of the Spot
Vital Signs LXi and options. This procedure supports the requirements of routine
preventative maintenance. It is not necessary to disassemble the Spot Vital Signs LXi to
perform this procedure.
For the calibration procedures, see “Calibration” on page 33. If the Spot Vital Signs LXi
fails certain functional tests or a circuit board is replaced, the device may require
calibration. It is necessary to disassemble the Spot Vital Signs LXi for calibration.
Always perform this functional verification procedure after performing any calibration. This
procedure contains additional tests that are not included in calibration procedures.
Self Test
The Spot Vital Signs LXi performs a self-test each time the device is powered on. Press
the Power button to turn the device on or off. Upon each power up, the display lights up,
a beep sounds, and the Spot Vital Signs LXi displays the model and serial numbers. If the
internal self-check is successful, the display shows its normal functions (see Figure 4 on
page 17) with all values blank, and the device is ready for operation. If the self-check fails,
an error code is shown in the Navigation Window (see “Error Codes” on page 37).
Spot Vital Signs LXi automatically powers off when not used for 30 minutes.
24
Functional Overview
Welch Allyn Spot Vital Signs LXi
Internal Configuration Mode
You can change several device operating parameters in the Internal Configuration Mode.
When changed, these settings become the default power-up settings. You will also see
non-changeable device configurations for technical service purposes.
To Enter the Internal Configuration Mode:
1.
Turn the Spot Vital Signs LXi off.
2. Press and hold the Select and Power buttons for 5 seconds. The device enters the
Internal Configuration Mode and the Configuration Menu screen appears on the
display.
Figure 7. Internal Configuration Mode Menu
Configuration Menu
Version
Numbers
Manual
Parameters
Battery
External
Devices
Location
Identifier
Save Readings
Date/Time
Buttons
Lockout
Blood Pressure
Defaults
Temperature
Event Log
Contrast
Select
3. Use the Navigation buttons to move through the menu options and then press the
Select button to access the options or accept a change. See the following tables for
descriptions of the menu options.
4. Press the Power button to exit the Internal Configuration Mode.
Service Manual
Functional Overview
25
Table 2. Configuration Menu Options
Setting
Description
Version Numbers*
Displays the software and hardware version numbers in the Spot Vital Signs LXi device.
Battery*
Displays the battery level.
Location Identifier
Allows the entry of the device’s location (e.g., the department name). Follow the
display prompts and use the Navigation and Select buttons to enter up to 10
characters.
Date/Time
Changes the date and time formats or updates the actual date and time. See Table 3,
“Date/Time Menu Options” for available settings.
Blood Pressure
Changes the blood pressure options. See Table 4, “Blood Pressure Menu Options” for
available settings.
Temperature
Changes the temperature options. See Table 5, “Temperature Menu Options” for
available settings.
Contrast
Changes the Display Contrast options. Use the left/right navigation buttons to adjust.
Manual Parameters
Changes the manual parameters defaults. See Table 6, “Manual Parameters Menu
Options” for available settings.
External Devices
Enables or disables available external devices. See Table 7, “External Devices Menu
Options” for available settings.
Save Readings
Saves the current patient reading at a preselected time interval or upon request. See
Table 8, “Save Readings Menu Options” for available settings.
Buttons Lockout
Secures Spot Vital Signs LXi so unauthorized people cannot use the device or access
data without enacting the proper key sequence. To override the buttons lockout feature,
simultaneously press the Left Navigation button and the Select button.
Defaults
Allows the user to select the default settings for the device and reset the unit to the
default settings. See Table 9, “Change Local Defaults Options” for available settings.
Event Log*
Displays the recent button presses, errors, measurements, measurement sites, battery
state changes, and patient reading send events.
* Displayed information only; operator cannot change.
Table 3. Date/Time Menu Options
Setting
Description
Date Format
Displays the date in one of the following styles:
• mm/dd/yyyy example: July 16, 2005 = 07/16/2005
• dd/mm/yyyy example: 16 July 2005 = 16/07/2005
Date
Changes the date on the Display Window and in patient readings. If a location is
entered (see “Location Identifier “ in Table 2, “Configuration Menu Options”), the date
will not appear on the Display Window; the location will.
Time Format
Displays the time in one of the following styles:
• 12-hour example: 5:00 PM
• 24-hour example: 17:00
Time
Changes the time on the Display Window.
26
Functional Overview
Welch Allyn Spot Vital Signs LXi
Table 4. Blood Pressure Menu Options
Setting
Description
BP Calibration Check
Prepares the Spot Vital Signs LXi for calibration. Only qualified personnel should verify
the Spot Vital Signs LXi blood pressure calibration. For more details, see “Blood
Pressure Calibration” on page 34.
Blood Pressure Units
mmHg or kPa.
Mean Arterial Pressure (MAP) On or off.
Table 5. Temperature Menu Options
Setting
Description
Temperature Units
Fahrenheit (°F) or Celsius (°C).
Temperature Mode
SureTemp Plus models only: Oral, Pediatric Axillary, Adult Axillary, and Last Mode. In
Last Mode the device takes the next temperature in the mode in which the previous
temperature was measured. Rectal Mode is available only when the rectal probe (red
ejection button) and probe well are attached.
Table 6. Manual Parameters Menu Options
Setting
Description
Height
On or off.
Height Units
Inches (in) or centimeters (cm).
Height Default
Changes the default patient height displayed in the Navigation Window.
Weight
On or off. Even if weight is enabled here, if weight scale is enabled in the External
Devices Menu, you cannot manually enter the weight.
Weight Units
Pounds (lb) or kilograms (kg).
Weight Default
Changes the default patient weight displayed in the Navigation Window.
Respiration
On or off.
Pain Level
On or off.
Service Manual
Functional Overview
27
Table 7. External Devices Menu Options
Setting
Description
Information System
On or off. You must enable this option to send patient readings wired or wirelessly.
Barcode Patient ID
On or off. You must enable this option to send patient readings wirelessly.
Barcode Clinician ID
On or off. You must enable this option to require mandatory sign in of a clinician.
Mandatory Sign In
Yes or no. You must enable this option to require the sign-in of the clinician.
Clear on Send/Save:
Yes or no. You must enable this option to clear the Clinician ID after after sending or
saving the measurements.
Clear on Power Cycle:
Yes or No. You must enable this option to clear the Clinician ID after powering the Spot
Vital Signs LXi off.
Weight Scale
On or off. Spot Vital Signs LXi connects to a scale and the weight shows on the display
window (see “Technical Overview” on page 61 for scale details).
Wireless Module
None or DPAC. You must enable DPAC to send patient readings wirelessly. The
wireless radio is available as an accessory only with Welch Allyn Connex.
Printer
On or off.
Printer Paper
Plain or labels. Only available if the Printer is enabled.
Table 8. Save Readings Menu Options
Setting
Description
Save Mode
Manual or automatic. If automatic, Spot Vital Signs LXi saves readings at a preselected
time interval. For either option, Spot Vital Signs LXi automatically saves the measured
parameters into memory before automatically powering off when not used for 30
minutes.
Auto Save Interval
Changes the amount of time before automatically saving the current patient reading.
Only available if Automatic Save Mode is enabled.
Reading Full Action
Auto Overwrite, Ask Overwrite, Do not Overwrite. Spot Vital Signs LXi can save 50
patient readings in memory. Upon reaching reading 51, the device may automatically
overwrite reading 1, ask the user if he/she wants to overwrite reading 1, or disable the
ability to take another reading until at least one reading is erased.
Table 9. Change Local Defaults Options
Setting
Description
Language
English, Dansk, Nederlands, Suomi, Français, Deutsch, Italiano, Norsk, Español,
Português, Svenska, or Chinese.
BP Units
mmHg or kPa.
Temperature Units
Fahrenheit (°F) or Celsius (°C).
Height Units
Inches (in) or centimeters (cm).
Weight Units
Pounds (lb) or kilograms (kg).
Date Format
Displays the date in one of the following styles:
• mm/dd/yyyy example: July 16, 2005 = 07/16/2005
• dd/mm/yyyy example: 16 July 2005 = 16/07/2005
Time Format
Displays the time in one of the following styles:
• 12-hour example: 5:00 PM
• 24-hour example: 17:00
28
Functional Overview
Welch Allyn Spot Vital Signs LXi
Functional Verification
Blood Pressure Functional Check
Note
When replacing the NIBP board see “To initialize the NIBP board” on page 34 for
instructions.
The calibration check is a simple, yet valuable test to determine that the unit is sensing
pressure accurately. Verify the pressure measurement accuracy of the Welch Allyn Spot
Vital Signs LXi with an accurate, calibrated pressure meter or sphygmomanometer.
To perform the functional check:
Have the following equipment available:
• Accurate, calibrated pressure meter or
sphygmomanometer
• 4” tubing with an inside diameter of
approximately .250” (quantity 3 each)
• T-connector
• Bulb and valve (5088-01)
• Female fittings (12P524-1) (quantity 2 each)
1.
Disconnect the blood pressure cuff from the blood pressure tubing.
2. Attach two pieces of the 4” tubing to the T-connector. Verify that the tubing is
positioned perpendicular to each other.
3. Attach the pressure meter or sphygmomanometer to one of the tubes and the bulb
and value assembly to the second tube.
4. Push a female fitting into the third piece of 4” tubing and connect the opposite end of
the tubing to the T-connector.
5. Twist the blood pressure tubing fitting that connects to the right blood pressure cable
connection port to the female fitting and connect the opposite end of the blood
pressure tubing to the blood pressure cable connection port. Verify that all
connections are tight.
Figure 8. Blood Pressure Calibration Tubing Connections
Right blood
pressure cable
connection
Bulb and valve
Right female
fitting
T-connector
4” tubing
Accurate, calibrated
pressure meter or
sphygmomanometer
Service Manual
Functional Overview
29
6. Enter the Internal Configuration Mode (see “Internal Configuration Mode” on
page 24).
7.
Press the Navigation button to highlight “Blood Pressure” on the display and press
the Select button.
8. Press the Navigation button to highlight “BP Calibration Check” on the display and
press the Select button.
9. Press the Select button to close the valve.
10. Verify that the pressure meter is on and the thumb screw valve is closed. Inflate the
device manually to about 250 mmHg.
11. Drop the pressure to 200 mmHg, wait 15 seconds for stabilization, and take a
reading.
12. Repeat for 150 mmHg, 50 mmHg, and 0 mmHg (all measuring downscale).
If the calibration at any point is outside of ±3 mmHg, call Welch Allyn Technical
Service for assistance.
Temperature Functional Check
The 9600 Plus Calibration Tester takes approximately 20 minutes to heat to the lowest
setting. When testing several thermometers at all three temperatures, it is
recommended to test all probes at one Calibration Set Point Temperature before
proceeding to the next Calibration Set Point Temperature.
To further expedite testing start at the lowest Calibration Set Point Temperature. The 9600
Plus Calibration Tester does not have an internal fan, this causes a longer cool down time
than warm up time.
Refer to the 9600 Plus Calibration Tester Directions for Use manual for specific
information regarding the LCD window or the control buttons.
1.
Choose the proper mains plug insert and slide it over the two prongs in the power
converter.
Figure 9. Power Adapter and Mains Plug Inserts
Two prongs in the
power adapter
US
UK
AUS
EU
2. Plug the power adapter into the 9600 Plus Calibration Tester (Figure 9) and the
opposite end into a wall outlet.
3. Place the 9600 Plus Calibration Tester on a level surface away from sunlight, drafts,
and other sources of heat or cold.
30
Functional Overview
Welch Allyn Spot Vital Signs LXi
4. Observe the Set Point Mode in the upper left hand corner of the LCD display. If the
unit displays a "D", it is in Default Mode and will heat to the lowest Set Point
Temperature. If you do not want to conduct testing at this Set Point Temperature,
press and hold the Temperature Selection button to select the desired setting. The
temperature display will flash before staying on continuously to indicate the 9600 Plus
Calibration Tester has stabilized and is ready for use.
Welch Allyn SureTemp Plus Thermometers
Caution Store thermometers for testing in the same room as the 9600 Plus
Calibration Tester for approximately 30 minutes prior to testing to allow for
thermal accommodation.
To begin functional verification of the SureTemp Plus thermometer:
1.
Remove the probe from the probe well and clean it with either a 70% isopropyl
alcohol solution, a 10% chlorine bleach solution, or a non-staining disinfectant. Let
the probe air dry. Do not apply a probe cover.
2. Place the thermometer in Monitor Mode, refer to the thermometer’s Operator's
Manual.
3. Insert the probe into the Thermistor Device Port.
Figure 10. 9600 Plus Calibration Tester with the Welch Allyn SureTemp Plus Thermometer
4. Wait for approximately one minute or until temperature on the thermometer is stable
for ten seconds. Compare the thermometer's temperature reading to the 9600 Plus
Calibration Set Point Temperature. If the temperatures are within ±0.1° C (±0.2° F),
the thermometer is within calibration.
5. Test all available thermometers for calibration verification at the current Calibration Set
Point Temperature. Proceed to the next Calibration Set Point Temperature, see
“Changing the Calibration Set Point Temperature” on page 32.
Service Manual
Functional Overview
31
Braun ThermoScan Pro 4000
Caution Store thermometers for testing in the same room as the 9600 Plus
Calibration Tester for approximately 30 minutes prior to testing to allow for
thermal accommodation.
To begin functional verification of the Braun ThermoScan PRO 4000 thermometer:
1.
Clean the probe tip with a cotton swab slightly moistened with isopropyl alcohol,
remove excess alcohol with a clean cotton swab, and let air dry for 5 minutes.Do not
use any chemical other than alcohol to clean the probe window.
2. Place the Braun ThermoScan Pro 4000 in Calibration Mode using the following steps.
a.
Push and release the I/O MEM button to turn the product on. The display shows
symbols and functions. The Braun ThermoScan Pro 4000 performs an automatic
self check. After a few seconds you hear a beep and see three dashed lines, a
sound symbol, and ° C or ° F on the display.
b. Push the I/O MEM button again and keep it pressed for the following steps:
•
After approx. 3 seconds the “OFF” symbol flashes on the display (keep
pressing the button).
•
When you hear a beep, release the button immediately.
•
The Braun TheromScan Pro 4000 is now in calibration check mode and the
display is flashing and showing the “CAL” symbol.
3. Apply a new probe cover. Place the probe firmly into the Ear Device Port.
Figure 11. 9600 Plus Calibration Tester with the Braun ThermoScan Pro 4000
4. Wait approximately three seconds, press the thermometer Start button, and watch for
the "Exac Temp" light to flash.
5. Leave the thermometer in the 9600 Plus Calibration Tester until you hear a beep.
6. Remove the Pro 4000 Thermometer from the 9600 Plus Calibration Tester and read
the temperature in the thermometer’s display. If the temperatures are within ±0.2° C
(±0.4° F), the thermometer is within calibration.
7.
Wait one full minute before taking another reading with the same thermometer.
Repeated measurements in short sequence may cause higher readings.
32
Functional Overview
Welch Allyn Spot Vital Signs LXi
8. The device will exit CAL mode after four minutes.
9. Test all available thermometers for calibration verification at the current Calibration Set
Point Temperature. Proceed to the next Calibration Set Point Temperature, see
“Changing the Calibration Set Point Temperature”.
Changing the Calibration Set Point Temperature
To scroll from one set point to the next, press and hold the Temperature Selection button
until a beep is heard. The newly selected set point appears in the upper left corner of the
LCD display. The device’s current temperature is displayed, starts to flash, and continues
flashing until the cavity reaches the equilibrium at the new set point.
Masimo SpO2 Functional Check
Use the Masimo Tester to perform to functionally check the Masimo sensors.
1.
Orient the Masimo Tester such that the mini-D connector mates with the SpO2
connector on Spot Vital Signs LXi.
2. Power on Spot Vital Signs LXi and confirm the SpO2 reading in the Display Window is
81%± 3% and the pulse reading is 61 bpm ± 1 bpm.
3. Place the thumb and index finger on the gray buttons on either side of the Masimo
Tester connector, press the buttons firmly, and gently pull to remove the tester.
There is no way to change the functionality of the SpO2 module. If the SpO2 is out of
calibration, contact Technical Service.
Nellcor SpO2 Functional Check
Use a Nellcor-approved SpO2 simulator (SRC-MAX ) to check the SpO2 functionality.
1.
Orient the simulator such that the connector mates with the SpO2 connector on Spot
Vital Signs LXi.
2. Power on Spot Vital Signs LXi and confirm the SpO2 reading in the Display Window is
81%± 3% and the pulse reading is 61 bpm ± 1 bpm.
3. Place the thumb and index finger on either side of the simulator connector, press the
buttons firmly, and gently pull to remove the simulator.
There is no way to change the functionality of the SpO2 module. If the SpO2 is not
functioning properly, contact Technical Service.
33
4
Calibration
This chapter provides procedures to perform all adjustments required to calibrate the Spot
Vital Signs LXi to conform to Welch Allyn specifications. Calibration requires qualified
personnel to open the device housing.
WARNING Electric shock hazard. There are no user-serviceable parts inside Spot
Vital Signs LXi other than battery replacement (see “Battery Replacement” on
page 88). An operator may only perform maintenance procedures specifically
described in this manual. For service, refer the device to an Authorized Service
Center.
Note
Always disconnect the sealed lead-acid battery in the Spot Vital Signs LXi before
performing any calibration function.
Gather the tools listed on page 47 to have available during the procedures.
Connections
1.
Connect the blood pressure pneumatic tubing to the Spot Vital Signs LXi and to the
test station.
2. Connect the USB cable to the Spot Vital Signs LXi and the computer.
3. Start the Spot Vital Signs LXi repair software on the computer.
4. Connect the power supply to the Spot Vital Signs LXi.
Figure 12. Connect Diagram
NOTE: If the
DPAC wireless
module is not
supported, the
DPAC wireless
module,
ethernet
cable, and the
wireless
router is not
necessary.
34
Calibration
Welch Allyn Spot Vital Signs LXi
Voltage Calibration
1.
Follow the steps in “Connections” on page 33.
2. Adjust the power supply to 5.6 Vdc ±0.1 Vdc and power on Spot Vital Signs LXi.
3. Select Calibrate > Voltage in the repair software. The Spot Vital Signs LXi display
window goes blank.
4. Read the voltage on the digital multi-meter (DMM) connected to the power supply.
5. Type the voltage reading in the Actual Voltage field and click the Calibration button.
6. Click the Ok button to accept the inputs. Click the Ok button to answer the question
in the text dialog box “Are you sure you want to make changes permanent?”
7.
Enter your initials in the Calibration Signature field to complete the voltage calibration.
Blood Pressure Calibration
Note
When replacing the NIBP board initialize the new board with the repair tool prior
to powering on the device.
To initialize the NIBP board
1.
Open the repair tool (Version 3.0 or greater) and click Calibrate -> Reset Defaults.
The Reset Defaults window displays.
2. Click Reset ->Initialize -> OK.
To calibrate the blood pressure function
1.
Follow the steps in “Connections” on page 33.
2. Adjust the power supply to 6.5 Vdc (± .25 Vdc).
3. Enter the “Internal Configuration Mode” on page 24. Use the Navigation and Select
buttons to select Blood Pressure > BP Calibration Check.
4. Set the test station volume to 500 cc and use the Spot Vital Signs LXi Navigation and
Select buttons to close valve (the Window Display shows “Open Valve”).
5. Click the Calibrate Zero button.
6. Use the bulb and the calibrated digital pressure meter to manually inflate the device
to 200 mmHg and enter the pressure meter reading from Spot Vital Signs LXi in the
Calibration Gain text field.
7.
Click the Ok button to accept the inputs. Click the Ok button to answer the question
in the text dialog box “Are you sure you want to make changes permanent?”
8. Enter your initials in the Calibration Signature field to complete the blood pressure
calibration.
Configuration Calibration
1.
Follow the steps in “Connections” on page 33.
Service Manual
Calibration
35
2. Power on Spot Vital Signs LXi.
3. Select Unit > Configuration in the Spot Vital Signs LXi Repair Software.
4. Verify the settings are correct and click the Ok button.
If any of the settings are incorrect click the correct button to change the settings.
If you update the Spot Vital Signs LXi clock in this menu, the device clock resets itself
to match the PC clock. You may manually set the time in the “Internal Configuration
Mode” on page 24.
36
Calibration
Welch Allyn Spot Vital Signs LXi
37
5
Troubleshooting
This chapter provides helpful information in troubleshooting the Spot Vital Signs LXi.
Error Codes
The following tables of error codes provide a quick reference of the descriptions and
probable causes of error codes.
Table 10. General Error Codes
Code
Description
Corrective Action
C12
Device outside operating temperature
range.
Change ambient temperature.
C13
Low battery level.
Charge battery.
E30
Internal malfunction.
Contact Technical Service.
E31
Internal malfunction.
Contact Technical Service.
E32
Internal malfunction.
Contact Technical Service.
E33
Internal malfunction.
Contact Technical Service.
E38
Date and time not set.
Set date and time (see “Date/Time Menu Options” on
page 25)
E42
Internal malfunction.
Contact Technical Service.
E44
Internal malfunction.
Contact Technical Service.
E45
Internal malfunction.
Contact Technical Service.
Table 11. Blood Pressure Error Codes
Code
Description
Corrective Action
C01
Blood pressure reading cancelled by user.
Retake blood pressure reading.
C02
Unable to release cuff pressure.
Check tubing for kinks and connection integrity.
C03
Inflation too quick.
Check tubing and connections.
C04
Air leak.
Check blood pressure cuff and tubing connections.
C05
Unable to determine blood pressure.
Check connections; restrict patient movement.
C06
Unable to determine blood pressure.
Check connections; restrict patient movement.
C07
Internal NIBP error.
Device will power down.
E10
Cuff pressure limits exceeded.
Device will power down.
E11
Cuff pressure duration exceeded.
Device will power down.
38
Troubleshooting
Welch Allyn Spot Vital Signs LXi
Table 11. Blood Pressure Error Codes
Code
Description
Corrective Action
E20
Internal NIBP error.
Device will power down.
Table 12. SureTemp Plus Temperature Error Codes
Code
Description
Corrective Action
C22
Temperature time limit exceeded.
Remove probe from patient.
E0.1
Probe heater error.
Retake reading. If problem persists, replace probe.
E0.2
Thermometer probe or device malfunction. Replace probe. If problem persists, contact Technical Service.
E0.4
Probe is over temperature.
If problem persists, contact Technical Service.
E0.5
Unable to determine temperature.
Retake reading. If problem persists, replace probe.
E0.6
Probe data error.
Retake reading. If problem persists, replace probe.
E0.7
Broken thermometer probe.
Replace probe.
E0.8
Cannot read the probe’s configuration
information.
Contact Technical Service.
E0.8
Temperature module data error.
Contact Technical Service to return the device.
E0.8
Cannot read the device’s Error Log.
This problem will correct itself. If it persists, contact
Technical Service.
E0.9
Broken thermometer probe.
Replace probe.
E4.0
Internal temperature malfunction.
Retake temperature. If problem persists, contact Technical
Service.
E4.1
Internal temperature malfunction.
Retake temperature. If problem persists, contact Technical
Service.
E4.2
Internal temperature malfunction.
If problem persists, contact Technical Service.
E4.3
Internal temperature malfunction.
If problem persists, contact Technical Service.
E4.4
Temperature malfunction.
Restart device. If problem persists, contact Technical Service.
E4.5
Temperature malfunction.
Restart device. If problem persists, contact Technical Service.
E4.6
Temperature malfunction.
Restart device. If problem persists, contact Technical Service.
E4.7
Cannot initialize thermometer.
If problem persists, contact Technical Service.
E4.8
Thermometer needs to be calibrated.
Contact Technical Service.
E4.9
Probe well missing or installed improperly. Reinstall probe well.
E5.0
Temperature heater error.
If problem persists, contact Technical Service.
E5.2
Heatsink failsafe failure.
If problem persists, contact Technical Service.
A^!
Device outside operating temperature
range.
Change ambient temperature.
Av!
Device outside operating temperature
range.
Change ambient temperature.
b^
Internal temperature malfunction.
Contact Technical Service.
bv
Internal temperature malfunction.
Contact Technical Service.
Service Manual
Troubleshooting
Table 13. SpO2 Error Codes
Code
Description
Corrective Action
C8
Faulty SpO2 sensor.
Replace sensor.
C9
SpO2 time limit exceeded.
Remove sensor from patient.
E7
Internal SpO2 error.
Retake reading.
Table 14. SpO2 Error Codes
Code
Description
Corrective Action
C8
Faulty SpO2 sensor.
Replace sensor.
C9
SpO2 time limit exceeded.
Remove sensor from patient.
E7
Internal SpO2 error.
Retake reading.
Table 15. Wireless Radio Errors
LED
LED Color
Function
Power
Off
Bridge is not receiving power.
Red
Bridge failed its Power On Self Test (POST) and is not configured for
wireless communication.
Amber
Bridge passed its POST but is not configured for wireless
communication.
Green
Bridge passed its POST and is configured for wireless communication.
Off
Bridge is not receiving power.
Red
Bridge is searching for an Access Point.
Green
Wireless network and MAC have associated with an Access Point.
Off
No power or no wireless TCP session is established and no physical
serial connection is detected.
Red
No wireless TCP sesion is established; a physical connection is detected.
Blinking Red
A physical serial connection was detected and there is serial traffic
present on that connection, but no wireless TCP session is established.
Amber
A wireless TCP connection is established but no physical serial
connection is detected (i.e. no serial cable is attached to the Bridge).
Blinking Green
A wireless TCP session is established, a physical serial connection is
detected, and the Bridge is transmitting or receiving data across the
wired serial port.
Green
A wireless TCP session is established, a physical serial connection is
detected, but there is n o active data movement across the wired serial
port.
Link
Comm
Battery Voltage Check
1.
Follow the steps in “Connections” on page 33.
39
40
Troubleshooting
Welch Allyn Spot Vital Signs LXi
2. Set the power supply to 6.5 Vdc (+0/-0.25 Vdc).
3. Use a DMM to check the battery voltage. If the voltage is less than 6.0 Vdc, charge
the battery.
To charge the battery, place the battery back into the Spot Vital Signs LXi and connect
the charger for 8 hours. Let the device sit idle for one day and recheck the battery
voltage. If the voltage is below 6.0 Vdc, replace the battery (see “Battery
Replacement” on page 88).
4. Power on Spot Vital Signs LXi. If the device does not power on:
a.
Verify the power supply is connected to the device and turned on.
b. Change the main PCB (see “Disassembly and Repair” on page 47).
c.
Change the display PCB (see “LCD Inverter Ballast Board Disassembly” on
page 55).
Window Display Check
Watch the Spot Vital Signs LXi window display during power on and verify the LCD
segments light up for one to two seconds before the device goes into its normal
operating mode. If the device has any LCD segments that do not light, change the
window display (see “LCD Disassembly” on page 55).
Blood Pressure Calibration Check
Note
When replacing the NIBP board see “To initialize the NIBP board” on page 34 for
instructions.
Perform two or three blood pressure cycles to verify proper cuff inflation/deflation and the
readings. If Spot Vital Signs LXi does not inflate or deflate properly perform the following
procedure.
1.
Open the Spot Vital Signs LXi housing (see “Disassembly and Repair” on page 47).
2. Check Spot Vital Signs LXi for pinched tubing and reroute if necessary. Re-run the
blood pressure cycle to confirm the problem is fixed.
3. Power off Spot Vital Signs LXi and enter the Internal Configuration Mode (see
“Internal Configuration Mode” on page 24).
4. Use the Navigation and Select buttons to select Blood Pressure > BP Calibration
Check.
5. Verify the valve on Spot Vital Signs LXi is closed (the menu choice shows “Open
Valve”).
6. Use the bulb to manually inflate the device to 250 mmHg and confirm Spot Vital Signs
LXi meets the leak test specification (see “Leak Test” on page 91).
Temperature Functional Check
Use the 9600 Plus Caligration Tester to check the SureTemp Plus or Braun ThermoScan
PRO 4000 thermometer accuracy (see “Temperature Functional Check” on page 29).
Service Manual
Troubleshooting
41
Masimo SpO2 Functional Check
Use the Masimo Tester to check the functionality of the SpO2 module of Spot Vital Signs
LXi (see “Masimo SpO2 Functional Check” on page 32).
Nellcor SpO2 Functional Check
Use a Nellcor approved simulator to check the functionality of the SpO2 module of Spot
Vital Signs LXi (see “Nellcor SpO2 Functional Check” on page 32).
Functional Testing Procedures
Perform the functional testing procedures in this section before returning Spot Vital Signs
LXi into service.
Verify you are using a calibrated pressure meter with an accuracy of better than ±3 mmHg
and that the calibration certificate is traceable to NIST.
Subtract the rated accuracy of the pressure measurement standard from the ±3 mmHg
rated accuracy of Spot Vital Signs LXi. This is the pass/fail criteria to determine if the
device is within calibration. If the differences between Spot Vital Signs LXi and the
pressure measurement standard are within the pass/fail criteria at all specified pressures
then the device is within calibration.
1.
Follow the steps in “Connections” on page 33.
2. Enter the “Internal Configuration Mode” on page 24. Use the Navigation and Select
buttons to select Blood Pressure > BP Calibration Check.
3. Connect to the 500 cc cylinder.
4. Select Test > Calibration in the repair software. The dialog box displays the device
manometer reading, battery reading, and valve and pump status.
5. Use the Navigation and Select buttons to select Blood Pressure > BP Calibration
Check.
6. Verify the valve on Spot Vital Signs LXi is closed (the menu choice shows “Open
Valve”).
7.
Use the hand bulb to verify Spot Vital Signs LXi is within calibration specification at
the target pressures of 250±5 mmHg, 150 ±5 mmHg, 50 ±5 mmHg, and 0 mmHg
with each reading within ±3 mmHg of the target pressure except for the 0 mmHg
reading which is within ±1.0 mmHg.
8. Set the power supply to 5.6 Vdc (+0.3/-0.0 Vdc). Verify the voltage reading meets the
specification (see “Voltage Calibration” on page 92).
After completing this test, return the power suppy to 6.5 Vdc (+0/-0.25 Vdc).
Current Test
1.
Follow the steps in “Connections” on page 33.
2. Power off Spot Vital Signs LXi and then power on in normal mode.
42
Troubleshooting
Welch Allyn Spot Vital Signs LXi
3. Select Test > Current Levels in the Spot Vital Signs LXi Repair Software. Use the
reading from the current meter and record the following current levels:
a.
Sleep State
b. Patient DAQ Mode
c.
Valve Pump Mode
The test result is a pass or fail result.
4. Select Ok to exit the dialog box.
Noise Levels
1.
Follow the steps in “Connections” on page 33.
2. Select Test > Noise Levels in the Spot Vital Signs LXi Repair Software and press the
Test button to retrieve Spot Vital Signs LXi’s internal pressure channel noise level. The
test result is a pass or fail result.
3. Select Ok to exit the dialog box.
Button Test
1.
Follow the steps in “Connections” on page 33.
2. Select Test > Button Test in the Spot Vital Signs LXi Repair Software and press each
button on Spot Vital Signs LXi while verifying that the computer acknowledges each
button in the “Test Buttons” display.
3. Select Ok to exit the dialog box.
Interface Test
1.
Follow the steps in “Connections” on page 33.
2. Select Test > Display > all on in the Spot Vital Signs LXi Repair Software to confirm
the Window Display shows all of the segments.
3. Select all off in the Spot Vital Signs LXi Repair Software to confirm the Window
Display clears all of the segments.
4. Select Test Pattern in the Spot Vital Signs LXi Repair Software to confirm the
Window Display shows a checkerboard pattern.
5. Select Normal in the Spot Vital Signs LXi Repair Software to confirm the Window
Display returns to the normal display.
6. Select on in the backlight Spot Vital Signs LXi Repair Software to confirm the Window
Display backlight comes on.
7.
Select off in the backlight Spot Vital Signs LXi Repair Software to confirm the Window
Display backlight goes out.
8. Select annunciator to confirm the buzzer of Spot Vital Signs LXi is on. Select Ok to
exist the test and turn the buzzer off.
Service Manual
Troubleshooting
43
9. Select Ok to exit the dialog box.
Pneumatic Tests
1.
Follow the steps in “Connections” on page 33.
2. Attach the test system to the 100 cc cylinder. Select Test > Pneumatic > Leak Test.
The software tests for leaks and provides a Pass or Fail indication.
3. Attach the test system to the 500 cc cylinder. Select Dump Test . The software tests
for the dump speed and provides a Pass or Fail indication.
4. Attach the test system to the 250 cc cylinder. Select Inflation Test. The software
tests for the inflation time and provides a Pass or Fail indication.
5. Attach the test system to the 100 cc cylinder. Select Valve Control Test. The
software tests for valve control and provides a Pass or Fail indication.
6. Select Ok to exit the dialog box.
Temperature Test
See “Temperature Functional Check” on page 29 to test either the SureTemp Plus or the
Braun ThermoScan PRO 4000 thermometer.
Over Pressure Test
1.
Disconnect and close the test volume tubing.
2. Select Unit > Status in the Spot Vital Signs LXi repair software.
3. Click the Log Status Information box in the lower right corner of the pop-up.
Immediately initiate a BP cycle on the UUT.
4. Pump the hand bulb until an E10 error occurs.
5. Uncheck the Log Status Information box and click OK to close the pop-up.
6. Scroll to the column title Over pressure, and then scroll down to the first entry of
“Yes” in the column.
7.
Scroll right to see the pressure value listed in the row that had “Yes” to determine the
value that triggered the E10 error. Verify Spot Vital Signs LXi displays an E10 error
condition when the pressure is between 296 mmHg and 329 mmHg.
44
Troubleshooting
Welch Allyn Spot Vital Signs LXi
Wireless Radio Test
1.
Connect a null modem to Spot Vital Signs LXi Port 1. Connect a serial cable to the PC
and the null modem.
2. Connect the other null modem to Spot Vital Signs LXi Port 2. Connect the Wireless
Radio to the null modem. Connect the USB cable to the USB port on both the PC and
the Spot Vital Signs LXi.
CTIONS
ort
MAT: 703956
II
I
3. Press the Power button to turn the Spot Vital Signs LXi off and press again to power
on. Verify the Wireless Radio light status (Power = green, Link = green, Comm =
flashing red).
LED
LED Color
Function
Power
Off
Bridge is not receiving power.
Red
Bridge failed its Power On Self Test (POST) and is not configured for
wireless communication.
Amber
Bridge passed its POST but is not configured for wireless communication.
Green
Bridge passed its POST and is configured for wireless communication.
Off
Bridge is not receiving power.
Red
Bridge is searching for an Access Point.
Green
Wireless network and MAC have associated with an Access Point.
Off
No power or no wireless TCP session is established and no physical serial
connection is detected.
Red
No wireless TCP sesion is established; a physical connection is detected.
Blinking Red
A physical serial connection was detected and there is serial traffic present
on that connection, but no wireless TCP session is established.
Amber
A wireless TCP connection is established but no physical serial connection
is detected (i.e. no serial cable is attached to the Bridge).
Blinking Green
A wireless TCP session is established, a physical serial connection is
detected, and the Bridge is transmitting or receiving data across the wired
serial port.
Green
A wireless TCP session is established, a physical serial connection is
detected, but there is n o active data movement across the wired serial port.
Link
Comm
Service Manual
Troubleshooting
45
4. At the computer, click Start - Run. Type CMD in the text box. The computer displays a
DOS prompt.
5. Type PING XXX.XXX.X.X (XXX.XXX.X.X is the Static IP address - located on the print
out under the radio settings) and press Enter.
RADIO CONFIGURATION UTILITY
Serial Number: 20051100248 / Model Number: 45NT0
--------------------------------------------------------------------------Current Radio Settings
LAN Information
DHCP Enabled:
Static IP Address:
Subnet Mask:
Default Gateway Address:
Primary DNS:
Security Information
Wireless Security Mode:
Authentication Type:
Channel:
False
192.168.0.3
255.255.255.0
192.168.0.1
192.168.0.1
Disabled
Auto
0x01
6. Verify the statistics.
Command Prompt
Microsoft Windows XP [Version 5.1.2600]
<C> Copyright 1985-2001 Mcirosoft Corp.
C:\Documents and Settings\temp\ping 192.168.0.2
Pinging 192.168.0.2 with 32 bytes of data:
Reply from 192.168.0.2: bytes=31 time=4ms TTL=64
Reply from 192.168.0.2: bytes=31 time=4ms TTL=64
Reply from 192.168.0.2: bytes=31 time=4ms TTL=64
Reply from 192.168.0.2: bytes=31 time=4ms TTL=64
Acceptable packets lost = 0
Any lost packets require you
to check the configurations.
Ping statistics for 192.168.0.2:
Packett: Sent = 4. Received = 4. Lost = 0 (0% lost).
Approximate round trip time in mili-seconds:
Minimum = 4ms. Maximum = 5ms. Average = 4 ms
C:\Documents and Setings\temp>
If you get an error, verify that Spot Vital Signs LXi power is on. Also verify the updates to
the External Devices Menu (Step 3).
46
Troubleshooting
Welch Allyn Spot Vital Signs LXi
Service Work Checklist
Spot Vital Signs
Model Number
Serial Number
Test
BP Cycle Count
Test Data
Technician
Date
Pass/Fail
Test Specification
Unit SW Version
SPO2 SW Version
Thermometry SW Version
Unit Pressure @ 0 mmHg
+/- 1 mmHg
Unit Pressure @ 50 mmHg
+/- 1 mmHg
Unit Pressure @ 150 mmHg
+/- 1.5 mmHg
Unit Pressure @ 250 mmHg
+/- 2.0 mmHg
Test Voltage @ 5.5 V
+/- 0.1 VDC
Current Test – Sleep State
< 0.5 A
Current Test – Patient DAQ
< 1.25 A
Current Test – Valve Pump
< 2.0 A
Noise Level
< 0.05 mmHg
Button Test
Pass/Fail
Interface Test
Pass/Fail
Leak Test
<= 6mmhg in 15 seconds
Dump Test
< 10 Seconds
Inflation Test
< 7 Seconds
Valve Control Test
Pass/Fail
Over Pressure Test
296 to 329 mmHg
SPO2 Sensor - Masimo
81% +/- 3% 61bpm +/- 1bpm
SPO2 Sensor - Nellcor
90% +/- 1% 60bpm +/- 1bpm
Temperature Calibration Suretemp Plus
96.8 +/- 0.2F 105.8 +/- 0.2F
Temperature Calibration Braun Pro 4000
96.8 +/- 0.2F 105.8 +/- 0.2F
Temperature Cal Key Suretemp Plus
97.3 +/- 0.2 F
Radio Ping Test
Pass or Fail
Pass
47
6
Disassembly and Repair
This chapter provides the instructions for removing and replacing serviceable modules in
the Spot Vital Signs LXi.
In general, re-assembly procedures are the reverse order of the disassembly procedures.
WARNING Electric shock hazard. There are no user-serviceable parts inside Spot
Vital Signs LXi other than battery replacement (see “Battery Replacement” on
page 88). An operator may only perform maintenance procedures specifically
described in this manual. For service, refer the device to an Authorized Service
Center.
Note
Always disconnect the sealed lead-acid battery in the Spot Vital Signs LXi before
performing any repair function.
Tool list
Description
Part Number
Qty
Source
Cable, USB A to 5-pin mini
704889
1
Welch Allyn or Electronics
Supply Store
Blood Pressure Test Volume Repair Fixture
401028
1
Welch Allyn
Spot Vital Signs LXi Repair Software
401710
1
Welch Allyn
Serivce Manual, Spot Vital Signs LXi
704432
1
Welch Allyn
Spot Vital Signs LXi Directions for Use
705310
1
Welch Allyn
Wireless Radio
706514
1
Welch Allyn
Spot Vital Signs LXi Manufacturing Process
Specifications
70012082
1
Welch Allyn
Tester, Calibration, 9600 Plus
01802-110
1
Welch Allyn
SureTemp Oral Probe
02895-000
1
Welch Allyn
Blood Pressure Y-Tube, No Fittings 1/8 Tube
5082-183
1
Welch Allyn
Spot Vital Signs LXi Work Instructions
MPD WI-PS-0090
1
Welch Allyn
Needle Nose Pliers
1
Tool/Supply Store
Wire Cutter
1
Tool/Supply Store
Tweezers
1
Tool/Supply Store
#2 Phillips Screwdriver
1
Tool/Supply Store
T10 Torx Driver
1
Tool/Supply Store
48
Disassembly and Repair
Welch Allyn Spot Vital Signs LXi
Description
Part Number
Qty
Source
4” PVC Pipe
1
Tool/Supply Store
Soldering Station
1
Tool/Supply Store
Cable Tie Tool - T9921
GS2B
1
Marsh Electronics
+1 800 877-8919
*Setra Pressure Meter
2270-01
1
Setra +1 800 257 3872
*Netech Pressure Meter
2000 in
1
Netech +1 800 547 6557
Nellcor Sensor Ext Cable (4’ Cable)
Dec-4
1
Nellcor +1 800 635 5267
Nellcor Sensor Ext Cable (8’ Cable)
Dec-8
1
Nellcor +1 800 635 5267
Nellcor Sensor
DS-100A
1
Nellcor +1 800 635 5267
Masimo SpO2 Tester
1795
1
Masimo +1 800 326-4890
Nellcor SRC-MAX SpO2 Tester
SRC-MAX
1
Nellcor +1 800 635 5267
Masimo Patient Cable
1005
1
Masimo +1 800 326-4890
Masimo Adult SpO2 Reusable Sensor
1269
1
Masimo +1 800 326-4890
Digital Volt Meter with 4 1/2 Digit Display
2
Electronics Supply Store
Power Supply: 0-20 Vdc adjustable with 0-3A
output
1
Electronics Supply Store
Wireless Router
1
Electronics Supply Store
Ethernet Cable
1
Electronics Supply Store
IBM compatible computer Windows 2000, XP,
NT4
1
* Only requires one of the pressure meters
To disassemble Spot Vital Signs LXi:
1.
Disconnect the power and all accessories from the Spot Vital Signs LXi.
2. Remove the four screws holding the battery door using a phillips-head screwdriver.
Remove the battery door to expose the battery.
CTIONS
ort
MAT: 703956
Top, back housing
screws (2 places)
II
I
Battery Door
Screws (4 places)
3. Tip the Spot Vital Signs LXi backward and slide the battery out. Disconnect the oneway connector.
Service Manual
Disassembly and Repair
49
4. Remove the two screws inside the battery housing that are identified with arrows
molded into the housing and the two screws at the top of the back upper housing.
5. Hold the device together, lay the back housing on the bench, and carefully lift the top
housing off.
6. Remove the screw and slightly lift the circuit board from the right facing side and
disconnect the flex cable (J103).
7.
Observe the locations of the two tubes before disconnecting. Lift and disconnect the
wire harnesses and the pneumatic tubing. The two wire harnesses are a 6-wire
harness that connects to J104 and a 2-wire harness that connects to J80 on the
small, mounted blood pressure board.
50
Disassembly and Repair
Welch Allyn Spot Vital Signs LXi
8. Disconnect the red electrical connector and the gold ribbon connector. This is located
on the main board. Lift up the tab on the white cable retainer so cable can slide out
after it is unplugged.
Gold Connector
Red Connector
9. Lift the flap on the beige connector (large ribbon cable) to remove the main board.
This releases the serial board cable from connector J108.
J108
Note
FOR MODELS NUMBERS (45MT0, 45ME0) ONLY: With diagonal cutting pliers
cut jumper JP2 twice so that it is open. Cut it on each end on the dotted lines as
illustrated, so that it is open connection.
Service Manual
Disassembly and Repair
Key Pad Disassembly
1.
Gently pull the button switch array out of the cover.
2. Align and push the new button switch array into place.
51
52
Disassembly and Repair
Welch Allyn Spot Vital Signs LXi
SpO2 Circuit Board Disassembly
Note
To assure proper SpO2 operation, replace the SpO2 board using only the Welch
Allyn specified part.
To assure patient electrical isolation, after the main board is nearly back in
position, verity that the SpO2 flex cable is freely floating in space and is not
pressed up against the main board.
Masimo
1.
Lay the LCD flat on an ESD mat.
2. Find the double-stack of circuit boards and remove the four corners screws. Carefully
lift the circuit board straight up.
3. Remove the three screws on the circuit board located behind the LCD.
Service Manual
Disassembly and Repair
53
4. Slightly rock the circuit board back and forth while lifting straight up.
5. Replace with a new circuit board.
Nellcor
1.
Lay the LCD flat on an ESD mat.
2. Remove the three screws on the circuit board located behind the LCD.
3. Slightly rock the circuit board back and forth while lifting straight up.
4. Replace with a new circuit board and set the dip switches to match the original board
(dip 1 and 2: up / dip 3 and 4: down).
54
Disassembly and Repair
Welch Allyn Spot Vital Signs LXi
Blood Pressure Circuit Board Disassembly
Note
When replacing the NIBP board see “To initialize the NIBP board” on page 34 for
instructions.
Remove the four screws and carefully lift the circuit board straight up. There is one
stationary connector.
Service Manual
Disassembly and Repair
55
LCD Inverter Ballast Board Disassembly
This is a small board held in place with two-sided tape. It is located towards the bottom of
the main board. Remove the connector at each end and pull straight up while taking care
not to damage the board because the adhesive tape has considerable sticking strength.
LCD Disassembly
1.
Remove the main board. At the bottom of this board is a circuit board with a pink
connector at the bottom.
2. Pull the brown tabs of the top connector forward and remove the ribbon cable.
Inspect connector tabs for wear and replace if worn.
3. Turn the board over and pull back the soft rubber holders. Pull the cable from the lug
to remove the grounding strap and remove the LCD.
4. Replace with a new LCD.
56
Disassembly and Repair
Welch Allyn Spot Vital Signs LXi
Pump Disassembly
Note
For proper blood pressure operation, replace the pump using only the Welch Allyn
specifed part.
To assure patient electrical isolation, route the pump wires through the rear
housing clip feature (near the pump terminals) and held in place with a tiewrap to
the holes in the rear housing at the back of the battery compartment.
To assure patient electrical isolation, do not modify the length of the pump wires.
1.
Snip the wire ties (2 places).
2. Disconnect the pneumatic tubing and unhook the wiring.
3. Replace with a new pump.
RS232-Communication Circuit Board Disassembly
1.
Remove the pneumatic connector and associated hoses from the pump and the two
screws in the rear housing. Remove the associated hoses.
2. Release the catch and remove the cover and inner handle assembly.
3. Remove the connection port panel.
4. Remove the two screws inside the back housing and the ribbon cable that hold the
RS232 board in place. Take care since the connector is easily broken.
5. Slide the board straight out and remove the wire harness.
6. Replace with a new circuit board.
Service Manual
Disassembly and Repair
57
Fan and Power Circuit Board Disassembly
Note
To prevent buildup of hydrogen gas, replace the fan using only the Welch Allyn
specified part.
This is a small board held in place with two-sided tape and one connector. Remove the
screw before disconnecting the connector.
Thermometry Circuit Board Disassembly
Caution To assure patient electrical isolation, trap the flex cable to the
thermometer pod behind the clip on the main housing adjacent to the main board
connection point.
Caution To assure patient electrical isolation, verify that the correct flex cable is
used to connect the thermometer pod to the main board. The Braun and
SureTemp Plus flex cables are slightly different in length and are not
interchangeable.
Caution To protect the user from high voltage, properly install the thermometer
pod insulating paper separating the LCD ballast wires from the housing crack.
SureTemp Plus
Caution Do not attempt to repair or clean the solder joints on either SureTemp
Plus board. Incorrect flux or technique can degrade thermomter accuracy.
1.
Remove the two screws located at the thermometer housing with a T-10 torx wrench.
Save the fish paper.
2. Locate the path of the notched tabs on the housing. Slide the housing up and out
following this path and set the case aside.
58
Disassembly and Repair
Welch Allyn Spot Vital Signs LXi
3. Remove the four screws from the mounting plate and save the fish paper. This
exposes the circuit board.
4. Remove the three Torx screws (T10) on the board (one on bottom and one on either
side of the probe well cover) and lift the board out of the housing and orient the part
as shown.
5. Disconnect all connectors and replace with a new board.
To replace the temperature connector, remove the one screw holding the temperature
board and connector. Verify the fish paper is properly mounted upon reassembly.
When replacing the SpO2/blood pressure housing, verify the orange and white twisted
wire is pushed as far into the handle housing as possible. Failure to do so can cause the
wires to stretch when the SpO2/blood pressure housing is inserted.
Service Manual
Disassembly and Repair
59
Braun ThermoScan PRO 4000
1.
Remove the two screws located at the thermometer housing with a T-10 torx wrench.
Save the fish paper.
2. Locate the path of the notched tabs on the housing. Slide the housing up and out
following this path and set the case aside.
3. Remove the four screws that hold the metal shield in place.
4. Remove the springs and posts. Carefully rock the board back and forth while lifting
straight up.
5. Disconnect all connectors and replace with a new board.
6. Reassembly is the reverse of disassembly.
60
Disassembly and Repair
Welch Allyn Spot Vital Signs LXi
61
7
Technical Overview
System Description
The Spot Vital Signs LXi automatically measures systolic and diastolic pressure (excluding
neonates), pulse rate, temperature (oral, adult axillary, pediatric axillary, rectal, and ear),
and pulse oximetry (SpO2) as well as calculates Mean Arterial Pressure (MAP).
Furthermore, Spot Vital Signs LXi allows the entry of height, weight, respiration rate, and
pain level. Spot Vital Signs LXi also calculates Body Mass Index (BMI) following height and
weight entry.
The device is intended to be used by clinicians and medically qualified personnel. It is
available for sale only upon the order of a physician or licensed health care provider.
Refer to the Spot Vital Signs LXi Directions for Use manual for complete information.
Battery System
Spot Vital Signs LXi includes a 6 Volt, 6 amp-hour sealed lead-acid battery that supplies all
power to the device. An external power supply charges the battery. The battery is always
on-line (floated) rather than switching out when attached to the external power supply.
Spot Vital Signs LXi uses a fuse and a shunt diode for protection against reverse battery
connections. The fuse is located on the main board in the negative battery line and a
reverse battery connection causes it to blow and require repair. The negative line location
is more likely to short the battery (+) wire to ground than short the battery (-) wire to the
VBUS node.
Battery Charger
Provides two levels of power to fast-charge or to float the battery at fixed voltages using
software control. The fast-charge level rapidly brings the battery up to near-full capacity (7
Volts) using software to not overcharge the battery. The float level, set per the
manufacturer’s recommendation, slowly tops-off the battery and can stay on indefinitely.
“CPU I/O” Power Supply
Provides power to the I/O pins of the DragonBall MPU and the attached peripheral IC’s.
The nominal voltage is set to a value of 3.15 Volts so that both the 3.0 Volt MPU and 3.3
Volts peripherals can operate within specifications. Spot Vital Signs LXi uses buck
switching topology for efficiency and an on-off power latch directly controls the power
supply.
62
Technical Overview
Welch Allyn Spot Vital Signs LXi
CPU Core Power Supply
Powers the MPU core only and operates at the recommended Dragonball voltage range
of 1.8 +/- 0.1 Volts; 2.0 Volts absolute max.
The +3.15 Volt supply powers the +1.8 Volt supply for efficiency and, more importantly, for
power sequencing. During power-on the +1.8 Volt supply cannot exceed the +3.15 Volt
supply. The R207/C182 further delays the +1.8 Volt supply. During power-off, D106
prevents the +1.8 Volt supply from exceeding the +3.15 Volt supply by more than a partial
diode drop.
+5V Supply
Provides supply to miscellaneous loads that require more than 3.15 Volts. The Power
Latch controls the supply and the average load current is small, so efficiency is not
important.
Clock/Calendar Power
The Clock/Calendar U19 receives power from two sources. During power on the clock
runs from the +5 Volt supply and during power down the clock receives power directly
from the battery potential using a voltage divider. Capacitor C131 provides power to the
U19 during the battery exchanges. Zener D102 prevents overvoltage to U19 in the case of
operation directly from the charger.
Mod F NIBP Power
This module is powered directly from VBUS through an EMI filter. Software via BP-PWRON-BAR controls the power. Level shifter Q115 / Q104 assures that the module remains
off when the MPU is unpowered.
SpO2 and Thermometer Power
A common structure supplies SpO2 and thermometry. A single push-pull driver delivers
squarewave power to a pair of isolation transformers, one for SpO2 and the other for
thermometry. THERM-PWR-BAR activates the driver under software control. Level
shifter Q118, Q119 assures that the module remains off when the MPU is unpowered.
In the push-pull (forward) configuration, VBUS is multiplied by the transformer turns ratio
and supplied to the input of the rectifier diodes. This is filtered and passed through lownoise 5-Volt linear regulators to supply power to the parameter modules.
LCD Power
The LCD data interface connects directly to the +3.15 Volt MPU I/O power supply. This
powers the driver ICs inside the LCD pane and assures the data interface to the LCD is
always powered when the unit is powered.
The contrast (bias) supply to the LCD panel and the LCD CCFL backlight both derive
power indirectly from a pre-regulator. A software control can shut down the pre-regulator.
For efficiency, it is implemented as a buck switcher operating directly from the battery.
The primary purpose of the pre-regulator is to protect the backlight inverter / ballast from
battery voltages that it cannot tolerate and to control current out of the unregulated
Service Manual
Technical Overview
63
ballast. The voltage is set to the low side of 5 Volts to reduce battery consumption, while
still driving the CCFL with adequate voltage.
External Load (RS-232) Power
There are two power outlet means on the Spot Vital Signs LXi – RS-232 port power and
the Braun PRO 4000 charger.
Two isolated power supplies provide power to each of the external RS-232 ports. This
power is available to external devices on pin 9 of each serial connector whenever the
software enables the corresponding RS-232 port.
SureTemp Plus Thermometer Interface
The SureTemp Plus OEM module is located in an optional pod and is connected to the
main PCB via a flex cable.The Thermometer Probe connection is located on a separate PC
board. It is connected to the SureTemp Plus OEM module by a ribbon cable. The
electrical interface to the thermometer pod is a 6-pin ribbon connector, Molex 52271-0690
or equivalent.
Braun ThermoScan PRO 4000 Thermometer Interface
The interface to the Braun ThermoScan PRO 4000 thermometer is located in the optional
pod and connects to the main PCB via a flex cable. The communications link is a single
duplex current loop that also charges the Braun battery pack.
The presence or absence of current passing through the Braun ThermoScan PRO 4000
charge contacts controls the interface charge LED, located within the pod, which mimics
the Braun ThermoScan Pro 4000 Base Station (type 6021).
SpO2 Description
A shielded flat-flex cable connects the user interface sensor connector J8 to the SpO2
electronics.
The Masimo SpO2 module mates to the Masimo Adaptor Board that, in turn, mates to the
Main board. This provides power and communications to the module from the Main
board.
The Nellcor SpO2 module mounts directly to the Main board. This provides power and
communications to the module, and brings the sensor signals to the main board where
EMI and ESD can be controlled. The sensor signals pass through the main board to the
mating connector for the shielded flat-flex cable.
64
Technical Overview
Welch Allyn Spot Vital Signs LXi
Wireless Radio Description
The Spot Vital Signs LXi Wireless Radio (ABDB-SE-WA107) is a fully integrated 802.11
wireless LAN device designed to provide wireless LAN connectivity from the Welch Allyn
Spot Vital Signs LXi to the Connex Data Management System.
FCC Compliance
This equipment has been tested and found to comply with the limits for Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and if not installed
and used in accordance with the instructions, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for assistance.
FCC RF Exposure Statement
To satisfy RF exposure requirements, this device and its antenna must operate with a
separation distance of at least 20 cm from all persons and must not be co-located or
operating in conjunction with any other antenna or transmitter.
IC Notice
This device has been designed to operate with an antenna having a maximum gain of 2.7
dB. An antenna having a higher gain is strictly prohibited per regulations of Industry
Canada. The required antenna impedance is 50 ohms.
To reduce potential radio interference to other users, the antenna type and its gain should
be so chosen that the equivalent isotropically radiated power (EIRP) is not more than
required for successful communication.
Key Features
Advanced security: WEP (64 and 128 bit), WPA, LEAP.
Low-power usage (radio on only during vitals transmission).
North American & European regulatory approvals (FCC, CE, IOC)
Service Manual
Technical Overview
LED
LED Color
Function
Power
Off
Bridge is not receiving power.
Red
Bridge failed its Power On Self Test (POST) and is not configured for
wireless communication.
Amber
Bridge passed its POST but is not configured for wireless communication.
Green
Bridge passed its POST and is configured for wireless communication.
Off
Bridge is not receiving power.
Red
Bridge is searching for an Access Point.
Green
Wireless network and MAC have associated with an Access Point.
Off
No power or no wireless TCP session is established and no physical serial
connection is detected.
Red
No wireless TCP sesion is established; a physical connection is detected.
Blinking Red
A physical serial connection was detected and there is serial traffic present
on that connection, but no wireless TCP session is established.
Amber
A wireless TCP connection is established but no physical serial connection
is detected (i.e. no serial cable is attached to the Bridge).
Blinking Green
A wireless TCP session is established, a physical serial connection is
detected, and the Bridge is transmitting or receiving data across the wired
serial port.
Green
A wireless TCP session is established, a physical serial connection is
detected, but there is n o active data movement across the wired serial port.
Link
Comm
The Wireless Radio interfaces to the Spot Vital signs LXi through an RS-232 female
connector with a 9-pin male/female null modem connection.
Figure 13. 9-pin Null Modem Pinout
MA 0051 (DB9M/F) Adapter Pin out:
09 Male
09 Female
2
3
3
2
4
1+6
5
5
1+6
4
7
8
8
7
9
9
G
G
65
66
Technical Overview
Welch Allyn Spot Vital Signs LXi
Bar Code Scanner Description
The Spot Vital Signs LXi has two types of bar code scanners available: a 1D scanner
(IMAGETEAM™ 3800) and a 2D scanner (IMAGETEAM™ 4600). These scanners are
programmed specifically for Welch Allyn. Scanners not purchased through Welch Allyn
will not work with the Spot Vital Signs LXi.
3800 LR-13 Settings
Parameter
Setting
Factory Default
9600
9600
7
7
Setting
Factory Default
9600
38400
Data Bits:
7
8
Stop Bits:
1
1
Parity:
Even
None
Handshaking:
None
None
Beeper - Good Read:
Off
On
Beeper Volume - Good
Read:
Off
Medium
Manual Trigger, Low Power
Manual/Serial Trigger
5 seconds
-
Prefix1:
<STX><SOH><DC2> (Ctl-BAR)
None
Suffix1:
<CR><LF>
<CR><LF>
Terminal Interfaces:
Baud Rate:
Data Bits:
4600SF031C Settings
Parameter
Terminal Interfaces:
Baud Rate:
Output:
Trigger Mode:
Lower Power Time Out:
Data Editing:
NOTES:
1. Applies to all symbologies.
2. Select the he <CR><LF> prior to revising the Terminal Interface parameters.
Service Manual
Technical Overview
67
Output Format
The data accepted as a valid bar code reading consists of an ASCII text string composed
of three elements: the prefix, the message consisting of the bar code data, and the suffix.
The format of the string is as follows:
“<STX><SOH><DC2>AA...AA(CR><LF>”
where:
Field
Description
STX
Start of Text character, 0x02.
SOH
Start of Header character, 0x01.
DC2
Device Control 2 character, 0x12.
A
Message data consisting of alphanumeric chacters in the range 0x20
through 0x7E. The message length can
range from 0 to 20 characters.
CR
Carriage return character, 0x0D.
LF
Line feed character, 0x0A.
Note
1.
Spot Vital Signs LXi issues a single beep for valid bar codes and displays the
message scanned in on the units display. If a bar code is invalid, Spot Vital
Signs displays nothing.
2. Spot Vital Signs LXi treats bar codes longer than 20 characters as invalid.
3. Spot Vital Signs LXi checks the parity bit of every character received. If a
parity error is detected in the preamble, Spot Vital Signs LXi ignores the
remainder of the bar code (no beep issued). If a parity error is detected in
the message data or suffix, Spot Vital Signs LXi treats the bar code as
invalid.
4. Refer to the bar code scanner manual for a list of supported symbologies.
Interface
The bar code scanner interfaces to Spot Vital Signs LXi through an isolated RS-232 DB-9
female connector. A started 3800LR-13 or 4600SF031C cable (Part #42204253-01 RS232,
9PIN D, HHP 0204 REF F) is required for use with the scanner.
68
Technical Overview
Welch Allyn Spot Vital Signs LXi
Printer Description
All models of the Ap1300 printer use an industry standard RS-232 interface. The default
parameters are 9600 baud, 8 data bits, 1 stop bit, and no parity.
Serial data is expected in standard RS-232C format with -12 Volt meaning ‘mark’ or ‘1’ and
+12 Volt a logical ‘0’, with reference to the common ground. The serial data output line,
TxD, transmits XON/XOFF and status information to the host at the same Baud rate and in
the same format as the serial data input. The hardware busy line is true (nominal -12 Volt)
when busy. Both serial output lines will relax to approximately 0 Volt when the Ap1300 is
in sleep mode and the user must allow a short period after awakening before relying on
the values of these signals.
The Ap1300 has three operating modes, when not actually printing.
Idle Mode
Ready to accept data, but no data are in the buffer
awaiting printing and the printer motor is not running.
Sleep Mode
Effectively switched off.
Spool Mode
Active, but storing data for later printing.
Different color combinations on the front-panel LED indicate the modes. No light is
emitted in sleep mode.
Table 16. LED Pattern Table
Pattern
Battery
Buffer Mode
Constant Green
Running
Normal
Fast Flashing Green
Running
Spool *
Long Green - Short Red
Battery Low
Normal
Short Green - Short Red
Battery Low
Spool *
Short Green - Long Orange
Trickle Charging
Normal
Long Orange Flash
Trickle Charging
Spool *
Fast Flashing Orange
Fast charging
Spool (Printing prohibited)
Fast Flashing Red
Error Condition
Spool (Printing prohibited)
No Light
Flat or in sleep mode
* Spool may have resulted from Paper Out or Head Up conditions)
No hardware power switch is fitted, as power control is either automatic or by command
from the host computer. To save power, the printer enters sleep mode after a period of
inactivity, factory-set to 30 seconds, but prorammable from the host. It can also be
programmed to stay idle indefinitely or to go to sleep on command.
The Ap1300 utilizes Fujitsu FTP-628MCL 103 printer mechanism, with a fixed (parallel)
print head with 384 horizontally-arranged thermal elements. A stepper motor advances
the paper and the printing takes place in a single-dot row for each step of the paper. Each
printed dot is approximately 1/8 mm square. The printing speed and dot density are
controlled according to the battery voltage and the head temperature.
Service Manual
Technical Overview
69
The Spot Vital Signs LXi provides two levels of power to fast-charge or to float the battery
at fixed voltages using software control. The fast-charge level rapidly brings the battery
up to near-full capacity (7 Volts) using software to not overcharge the battery. The float
level, set per the manufacturer’s recommendation, slowly tops-off the battery and can
stay on indefinitely.
InterconnectDiagram
Item
Description
Item
Description
A1
PCA, Main, Spot Vital Signs LXi
W1
Assy, Power Harness, Spot Vital Signs LXi
A1-F1
Fuse, FlastBlo, 5A
W1-A1
PCA, Power Interface, Spot Vital Signs LXi
A2
PCA, Serial Interface, Spot Vital Signs LXi
W2
Flex, Main, Spot Vital Signs LXi
A3
Display, LCD, 320 x 240, Mono
W3
Cbl Flx, 1/2mm, 15 POS
A4
Inverter, LCD
W4
Assy, Ballast Harness, Spot Vital Signs LXi
A5
Assy, Battery, Spot Vital Signs LXi
W5
Assy, LCD Gnd Harness
A5-F1
Wire Protection Fuse
W6
Assy, Cable, Flat Flex, SpO2
A6
Assy, Fan Unit Cooling
Wire Clip, Side Entry, .375 Wide
A7
PCA, Masimo Adapter, Spot Vital Signs LXi
Foam Strip, 2 Sided Adhesive
A8
Masimo MS-11 SpO2
W7
Cbl, Flx, 1mm, 6POS
Shield, Masimo EMI
W8
Cbl, Flx, 1mm, 8POS
Tape, Copper, Masimo Shield
W9
Cbl, Flx, Braun, Spot Vital Signs LXi
A9
PCA, SureTemp Plus, OEM w/o EDAC
A10
PCBA, BP OEM, (MOD F)
A11
Assy, Pump, and Tubing, Spot Vital Signs
LXi
A11-F1
Filter, Air, 1/8 Barbs
A12
Assy, Transducer Tubing, Spot Vital Signs
LXi
A13
PCA, EDAC, Spot Vital Signs LXi
A14
Nellcor MP506 SpO2 PCB
A15
PCA, Braun Interface, Spot Vital Signs LXi
Wire Color
BLK
Black
BRN
Brown
RED
Red
ORN
Orange
GRN
Green
BLU
Blue
PNK
Pink
70
Technical Overview
Welch Allyn Spot Vital Signs LXi
71
8
Field Replaceable Units
The following list identifies the available FRUs for Spot Vital Signs LXi. To order an FRU,
contact Welch Allyn Technical Support.
Table 17. Spot Vital Signs LXi Base Components
Component Number
Object Description
400163
ASSY, POWER HARNESS, Spot Vital Signs LXi
400170
ASSY, PUMP HARNESS
400198
PCA, SERIAL INTERFACE, Spot Vital Signs LXi
400199
PCA, MAIN, Spot Vital Signs LXi
400200
BASE UNIT, SURETEMP, NELLCOR - Spot Vital Signs LXi
400203
BASE UNIT COMPONENTS, Spot Vital Signs LXi
400207
LANGUAGE COMPONENTS, ENG, Spot Vital Signs LXi
4500-901
KIT, PUMP, PUMP AND VALVE TUBING
4500-902
ASSY, PUMP & VALVE TUBING Spot Vital Signs LXi
400387
PBCA BP OEM, (MOD F)
400720
ASSY, BALLAST HARNESS, Spot Vital Signs LXi
400732
ASSY, BATTERY, Spot Vital Signs LXi
401082
Assy, Bezel and Window, Spot Vital Signs LXi
421051-12
TUBING,1/8 X 1/4 X 2.50
421051-9
TUBING,1/8 X 1/4 X 0.95
59P586
FOOT, RUBBER
620028-E
LABEL, CAUTION
620217
FITTING, "T", 1/8 X 1/16X 1/8
700101
HSG, HANDLE, LXi
700102
HSG, HANDLE INSERT, LXi
700103
HSG, REAR, LXi
700105
HSG, BATT DOOR, Spot Vital Signs LXi
700110
BUMPER, LCD, Spot Vital Signs LXi
700114
SWITCH ARRAY, Spot Vital Signs LXi
700119
INVERTER, LCD
700824
HOUSING, FRONT, Spot Vital Signs LXi
704423
HSG, PANEL, SPO2-BLANK, LXi
72
Field Replaceable Units
Welch Allyn Spot Vital Signs LXi
Table 17. Spot Vital Signs LXi Base Components
401427
LABEL, ICON ID, Spot Vital Signs LXi
700863
CBL,FLX, 1/2mm,15POS,1.0"
704375
CBL,FLX, 1/2mm,30POS,6.0"
703956
LABEL, BATTERY
701040
FITTING, PLASTIC L, 1/16 X 1/16
701502
Valve,Pneumatic,6PSI,5V,TH
703077
STANDOFF, PCB, BROACHING, #4 X .500 LG
703118
BATTERY CLIP, AA, SINGLE
703354
DISPLAY,LCD,320X240,BLITE,MONO,3.3V,5.7"
703355
FILTER, AIR, 1/8 BARBS
703842
TUBING, SILICONE, .063ID X .125OD X 5.50
Table 18. SureTemp Plus Components
Component Number
Object Description
02692-100
PROBE ASSY,ORAL 9FT
02894-0000
ASSY,PRB WLL,BLUE,OEM,M690_692
400195
PCA, SURETEMP+, OEM W/O EDAC, CALIBRATED
400196
PCA, EDAC, LXi
700111
HOUSING, THERM OEM POD, LXi
700112
PLATE, POD MOUNTING, LXi
700858
CBL,FLX,1MM,6POS
700859
CBL,FLX,1MM,8POS
70999-0000
LABEL,SURETEMP TECHNOLOGY
02692-100
PROBE ASSY,ORAL 9FT
Table 19. Braun ThermoScan PRO 4000 Components
Component Number
Object Description
400652
PCA, BRAUN INTERFACE, Spot Vital Signs LXi
700112
PLATE, POD MOUNTING, LXi
700820
HSG, BOTTOM, BRAUN POD, Spot Vital Signs LXi
700822
HSG, BRAUN POD, Spot Vital Signs LXi
704365
WINDOW, BRAUN POD, Spot Vital Signs LXi
700859
CBL,FLX,1MM,8POS
703161
SECURITY LOCK, BRAUN POD, Spot Vital Signs LXi
703162
LATCH, BRAUN POD, Spot Vital Signs LXi
703164
CONTACT, BRAUN POGO, Spot Vital Signs LXi
703165
SPRING, COMPRESSION
703192
COVER, BRAUN SECURITY, Spot Vital Signs LXi
Service Manual
Field Replaceable Units
Table 20. Masimo SpO2 Components
Component Number
Object Description
008-0648-00
MASIMO - ADULT RESU. SENSOR
008-0692-01
MASIMO - 8' INTERFACE CABLE
400192
PCA, MASIMO OEM, Spot Vital Signs LXi
400205
MASIMO SPO2 COMPONENTS, Spot Vital Signs LXi
400555
PCA, MASIMO ADAPTOR, Spot Vital Signs LXi
400610
ASSY, CABLE, FLAT FLEX, SPO2
704422
HSG, PANEL, SPO2-MASIMO, LXi
Table 21. Nellcor SpO2 Components
Component Number
Object Description
400183
PCA, NELCOR OEM, Spot Vital Signs LXi
400201
NELLCOR SPO2 COMPONENTS, Spot Vital Signs LXi
400610
ASSY, CABLE, FLAT FLEX, SPO2
620377-1
"NELLCOR WORKS HERE" LABEL
704421
HSG, PANEL, SPO2-NELLCOR, LXi
DOC-10
CABLE, SP02 EXTENSION, NELCOR
DS-100A
DURASENSOR,ADULT,DS-100A
73
74
Field Replaceable Units
Welch Allyn Spot Vital Signs LXi
Table 22. Wireless Radio Components
Component Number
Object Description
706514
Wireless Radio
703380
Bracket
101620
ANTENNA, WIRELESS, ACH2-AT-DP002
106100-13
Screw 6-32 .500 Psn Phillips Other
4500-910
Image Team 3800/3900 1D Barcode Scanner Kit
4500-915
Image Team 4600 2D Barcode Scanner Kit
703878
Null Modem 9-Pin M/F 4-40
704889
USB Cable 5-Pin Mini-B Gold 6 Feet
403204
10 Feet 9-Pin Serial Cable
4500-920
Kit, Wireless Radio
4500-921
Wireless Radio Directions for Use
4500-905
Repair Tool CD, Spot Vital Signs LXi
4500-906
Spot Vital Signs LXi Configuration CD
4500-907
Spot Vital Signs LXi Firmware Loader CD
4500-925
Cable for wired connectivity
4500-926
Cable for wired connectivity, Keyspan (USB to serial adapter)
4500-927
USB 2.0/serial cable kit
75
9
Specifications
Performance
This section describes normal ranges for Spot Vital Signs LXi.
Blood Pressure Accuracy
Blood pressure accuracy meets or exceeds AAMI SP10:2002 standards for non-invasive
blood pressure accuracy (± 5 mmHg mean error, 8 mmHg standard deviation). Blood
pressure accuracy is validated for pressure measurement using the upper arm only.
Cuff Pressure Range
0 to 300 mmHg
Systolic Range
60 to 250 mmHg
Diastolic Range
30 to 160 mmHg
Blood Pressure Determination Time
Typical: 15 seconds
Mean Arterial Pressure Range
40 to 190 mmHg
Pulse Rate Range
(using SpO2 determination)
25 to 240 bpm
Pulse Rate Range
(using Blood Pressure determination)
35 to 199 bpm
Pulse Rate Accuracy (using SpO2
determination)
Without Motion: 25 to 245 bpm ± 3 digits1
With Motion: normal physiologic range (55 to 125 bpm) ± 5 digits
Low Perfusion: 25 to 245 bpm ± 3 digits1
Pulse Rate Accuracy
(using Blood Pressure determination)
Overpressure Cutoff
1 Specification applies to device performance and was validated with Biotek and Nellcor simulators.
±5.0%
315 mmHg ±15 mmHg
76
Specifications
Welch Allyn Spot Vital Signs LXi
Temperature Specifications
Temperature Range
SureTemp Plus
Braun ThermoScan PRO 4000
Calibration Accuracy
SureTemp Plus
Braun ThermoScan PRO 4000 for displayed
temperature ranges
Display Resolution
SureTemp Plus Predict Time
Oral
Adult Axillary
Pediatric Axillary
Rectal
80° to 110° F (26.7° to 43.3° C)
68° to 108° F (20° to 42.2° C)
±0.2° F (0.1° C) (Monitor Mode)
± 0.4° F (±0.2° C) 95.9° to 107.6° F (35.5° to 42° C)
±0.5° F (±0.25° C) (outside this temperature range)
0.1° F or ° C
Approx. 4 to 6 seconds
Approx. 12 to 15 seconds (age 18 years and older)
Approx. 10 to 13 seconds (age 17 years and younger)
Approx. 10 to 13 seconds
Service Manual
Specifications
77
SpO2 Specifications
Masimo Sensor Accuracy Guide
Accuracy specified when used with Masimo SET pulse oximetry monitors or with
licensed Masimo SET pulse oximetry modules using PC series patient cables, during no
motion. Numbers present ± 1 standard deviation. Plus or minus one standard deviation
represents 68% of the population. SpO2 accuracy from 70% to 100%. Pulse rate
accuracy from 25 to 240 bpm.
Performance Measurement Range
SpO2: 1 to 100%
Pulse Rate: 25 - 240 beats per minute (BPM)
Perfusion
0.02% to 20%
Accuracy
Saturation: 70% to 100%
No Motion: Adults, Pediatrics ± 2 digits
Neonates ± 3 digits
Motion: Adults, Pediatrics ± 3 digits
Neonates ± 3 digits
Low Perfusion: Adults, Pediatrics ± 2 digits
Neonates ± 3 digits
Pulse Rate Accuracy
Pulse Rate: 25 to 250 bpm
No Motion: Adults, Pediatrics, Neonates ± 3 digits
Motion: Adults, Pediatrics, Neonates ± 5 digits
Low Perfusion: Adults, Pediatrics, Neonates ± 5 digits
Table 23. Masimo Sensor Accuracy Guide
Saturation Accuracy
Sensor
Pulse Rate Accuracy
Weight Range
No Motion
Motion
No Motion
Motion
LNOP-ADT
> 30 kg
± 2%
± 3%
± 3 bpm
± 5 bpm
LNOP-PDT
10 to 50 kg
± 2%
± 3%
± 3 bpm
± 5 bpm
LNOP-NEO
< 10 kg
± 3%
± 3%
± 3 bpm
± 5 bpm
LNOP-NEOPT
< 1 kg
± 3%
± 3%
± 3 bpm
± 5 bpm
LNOP-DCI
> 30 kg
± 2%
± 3%
± 3 bpm
± 5 bpm
LNOP-DCIP
10 to 50 kg
± 2%
± 3%
± 3 bpm
± 5 bpm
Masimo Patents
The Masimo sensors and cables are covered under one or more of the following U.S.A.
patents: 5,758,644; 5,823,950; 6,011,986; 6,157,850; 6,263,222; 6,501,975; and other
applicable patents listed at www.masimo.com/patents.htm.
78
Specifications
Welch Allyn Spot Vital Signs LXi
Nellcor Sensor Accuracy Guide
Accuracy specifications are based on controlled hypoxia studies with healthy,
non-smoking adult volunteers over the specified saturation SpO2 range. Pulse oximeter
SpO2 readings were compared to SaO2 values of drawn blood samples measured by
hemoximetry. All accuracies are expressed as + “X” digits. This variation equals + one
standard deviation (+ 1 SD), which encompasses 68% of the population.
Table 24. OxiMax Sensor Models, Single Patient Use
Sensor Models
SpO2 Range
70% to 100%
MAX-AI1
±2
MAX-PI*
±2
MAX-II
±2
2
± 3.5
MAX-RI
1 The accuracy specification under motion conditions is ± 3. For a definition of motion, contact Nellcor
Technical Services or your local Nellcor representative.
2 The accuracy specification has been determined between saturations of 80% to 100%.
Table 25. OxiCliq Sensor Models, Single Patient Use
Sensor Models
OXICLIQ-PI
SpO2 Range
70% to 100%
± 2.5
Table 26. Reusable Sensor Models
Sensor Models
D-YS (Infant to Adult)
SpO2 Range
70% to 100%
±3
D-YS and D-YSE
± 3.5
D-YS and D-YSPD
± 3.5
DS-100A
±3
OXI-A/N (Adult/neonate)
Adult: ± 3
Neonate: ± 4
OXI-P/I (Pediatric/infant)
±3
Nellcor Patents
Covered by one or more of the following US Patents: 4,802,486; 4,869,254; 4,928,692;
4,934,372; 5,078,136; 5,351,685; 5,485,847; 5,533,507; 5,577,500; 5,803,910; 5,853,364;
5,865,736; 6,083,172; 6,708,049; Re. 35,122 and foreign equivalents.
Service Manual
Specifications
79
Mechanical
Dimensions
Height: 10.63 “ (27 cm)
Length/Braun: 8” (20.32 cm)
Length/SureTemp Plus: 7.5” (19 cm)
Depth: 5.25” (13.34 cm)
Weight
7.5 lbs (3.4 kg)
Mounting
Self-supporting on rubber feet
Custom mobile stand
Custom wall mount
Portability
May be hand-carried when held by the rear handle
Electrical
Power Requirements
Patient-rated isolation transformer is connected to AC mains:
100-240V, 50-60Hz, 0.4A or internal power: 6Vdc, 6Ah
Patents
6,827,488; 6,971,790; and other patents pending.
Battery
Sealed lead acid, with external charger.
The Spot Vital Signs LXi battery is 90 to 100% charged after 6 hours of charging. The
rechargeable batteries in the Braun ThermoScan PRO 4000 thermometer requires an
additional 1 hour to charge and the rechargeable batteries in the external printer require an
additional 4 hours to charge. The battery automatically charges when Spot Vital Signs LXi
is powered through the AC power transformer. An operator can use the device while the
battery is charging; however, the battery charges faster when the instrument is not in
operation.
Environmental
WARNING This device is not suitable for use in the presence of a flammable
anesthetic mixture with air or oxygen or nitrous oxide. An explosion may result.
Operating Temperature
Storage/Transport Temperature
50° to 104° F (10° to 40° C)
Device with SureTemp Plus: -13° to 131°F (-25° to 55°C)
Device with Braun ThermoScan PRO 4000: -4° to 122°F (-20° to 50°C)
Relative Humidity
15 to 95% (non-condensing)
Operating Altitude
-557 to 16,000 ft. (-170 to 4877 m)
80
Specifications
Welch Allyn Spot Vital Signs LXi
Wireless Radio
Wireless Network Interface
Frequency
Channels
IEEE 802.11b DSSS, WiFi Compliant
2.4 to 2.4835 GHz
11 US/Canada, 13 Europe, 14 Japan, 4 France
Security
WEP (64 & 128 bit), WPA (PSK & TKIP)
Antenna
Integrated Omni-directional RP-SMA +3dBi antenna
Power Input
Wireless Data Rates
Management
Agency Approvals
IP addresses
Protocols
Data Transfer Protocols
Network
ACK
From Spot Vital Signs LXi serial port
11 Mbps during vitals transmission only (approximately two seconds per reading)
Device Discovery
US: FCC Part 15 , Class B, C/UL, CE
Europe: CE
Canada: RSS-210
Fixed IP
Wireless access points do not assign IP addresses
Centraled DHCP Server for dynamic IP Address/Subnet/Gateway assignment
UDP,DHCP,TCP/IP
TCP/IP
The Spot Vital Signs LXi Wireless Radio communicates to a software component
which must be on the same sub-net as the radio APs.
Data is deleted from device only after an acknowledgement is received from
Connex.
Mechanical
Dimensions
Mounting
Operating Temperature
Storage Temperature
3.93” L x 2.38” W x 1.42” T
99.78mm L x 60.5 mm W x 36.1mm T
Nylon Bracket
-40° C to +85° C
-40° C to +125° C
Configuration Options
DHCP Enabled or Not
If not DHCP:
• IP Address
• Subnet Address
• Gateway
Encryption
• WEP
• WPA
WPA Pass Phrase
Channel
WEP Key 1-4
SSID
Default WEP Key
WEP Authentication
Service Manual
Specifications
81
Guidance and Manufacturer’s Declaration
Emissions and Immunity Information
Electromagnetic Emissions
The Spot Vital Signs LXi is intended for use in the electromagnetic environment specified below. The customer or user of the Spot Vital Signs
LXi should assure that it is used in such an environment.
Emissions Test
Compliance
Electromagnetic Environment - Guidance
RF emissions
Group 1
The Spot Vital Signs LXi uses RF energy only for its internal function. Therefore, its RF
emissions are very low and are not likely to cause any interference in nearby electronic
equipment.
Class B
The Spot Vital Signs LXi is suitable for use in all establishments, including domestic
establishments and those directly connected to the public low-voltage
power supply network that supplies buildings used for domestic purposes.
CISPR 11
RF emissions
CISPR 11
Harmonic emissions
Class A
IEC 61000-3-2
Voltage fluctuations/
flicker emissions
Complies
IEC 61000-3-3
Electromagnetic Immunity
The Spot Vital Signs LXi is intended for use in the electromagnetic environment specified below. The customer or user of the Spot Vital Signs
LXi should assure that it is used in such an environment.
Immunity Test
IEC 60601
Test Level
Compliance Level
Electromagnetic Environment - Guidance
Electrostatic discharge
(ESD)
± 6 kV contact
± 6 kV contact
± 8 kV air
± 8 kV air
Floors should be wood, concrete, or ceramic tile. If floors are
covered with synthetic material, the relative humidity should
be at least 30%.
Electrical fast transient/ ±2 kV for power supply
burst
lines
±2 kV for power supply
lines
Mains power quality should be that of a typical commercial or
hospital environment.
IEC 61000-4-4
±1 kV for input/output
lines
±1 kV for input/output
lines
Surge
±1 kV differential mode
±1 kV differential mode
IEC 61000-4-5
±2 kV common mode
±2 kV common mode
IEC 61000-4-2
Mains power quality should be that of a typical commercial or
hospital environment.
82
Specifications
Welch Allyn Spot Vital Signs LXi
Voltage dips, short
interruptions, and
voltage variations on
power supply input
lines.
>95% dip in 0.5 cycle
>95% dip in 0.5 cycle
60% dip in 5 cycles
60% dip in 5 cycles
30% dip for 25 cycles
30% dip for 25 cycles
IEC 61000-4-11
>95% dip in 5 seconds
>95% dip in 5 seconds
Power frequency
(50/60Hz)
magnetic field
3 A/m
3 A/m
Mains power quality should be that of a typical commercial or
hospital environment. If the user of the Spot Vital Signs LXi
requires continued operation during power mains
interruptions, it is recommended that the Spot Vital Signs LXi
be powered from an uninterruptible power supply or battery.
Power frequency magnetic fields should be at levels
characteristic of a typical location in a typical commercial or
hospital environment.
IEC 61000-4-8
Electromagnetic Immunity
The Spot Vital Signs LXi is intended for use in the electromagnetic environment specified below. The customer or user of the Spot Vital Signs
LXi should assure that it is used in such an environment.
Immunity Test
IEC 60601
Test Level
Compliance Electromagnetic Environment - Guidance
Level
Portable and mobile RF communications equipment should be used no closer
to any part of the Spot Vital Signs LXi, including cables, than the
recommended separation distance calculated from the equation applicable
to the frequency of the transmitter.
Recommended separation distance
Conducted RF
IEC 61000-4-6
3 Vrms
150 kHz to 80 MHz
3 Vrms
d = (1.17) P
Radiated RF
IEC 61000-4-3
3 V/m
80 MHz to 2.5 GHz
3 V/m
d = (1.17) P 80 MHz to 800 MHz
d = (2.33) P 800 MHz to 2.5 GHz
where P is the maximum output power rating of the transmitter in watts (W)
according to the transmitter manufacturer and d is the recommended
separation distance in metres (m).
Field strengths from fixed RF transmitters, as determined by an
electromagnetic site survey,a should be less than the compliance level in
each frequency range.b
Interference may occur in the vicinity of equipment marked with the
following symbol:
Note 1: At 80 MHz and 800 MHz, the higher frequency range applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures,
objects, and people.
a Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio,
AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due
to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the Spot
Vital Signs LXi is used exceeds the applicable RF compliance level above, the electrocardiograph should be observed to verify normal operation.
If abnormal performance is observed, additional measures may be necessary, such as reorienting or relocating the electrocardiograph.
b Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m.
Service Manual
Specifications
83
Recommended Separation Distances Between Portable and Mobile RF Communications Equipment and the Spot Vital Signs LXi
The Spot Vital Signs LXi is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer
or user of the Spot Vital Signs LXi can help prevent electromagnetic interference by maintaining a minimum distance between portable and
mobile RF communications equipment (transmitters) and the Spot Vital Signs LXi as recommended below, according to the maximum output
power of the communications equipment.
Separation Distance According to Frequency of Transmitter (m)
Rated Max. Output
Power of Transmitter
(W)
150 kHz to 80 MHz
80 MHz to 800 MHz
800 MHz to 2.5 GHz
d = (1.17) P
d = (1.17) P
d = (2.33) P
0.01
0.117
0.117
0.233
0.1
0.37
0.37
0.74
1
1.17
1.17
2.33
10
3.70
3.70
7.37
100
11.70
11.70
23.30
For transmitters rated at a maximum output power not listed above, the recommended separation distance d in meters (m) can be estimated
using the equation applicable to the frequency of the transmitter, where P is the maximum output power rating of the transmitter in watts (W)
according to the transmitter manufacturer.
Note 1: At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures,
objects, and people.
84
Specifications
Welch Allyn Spot Vital Signs LXi
85
10
Maintenance and Service
Cleaning
WARNING Before performing any maintenance or service to the Spot Vital
Signs LXi, disconnect the AC power line from the electrical outlet.
Spot Vital Signs LXi
Caution Prevent water or other fluids from entering any connectors. If the
connectors get wet, dry them with warm air. Check all measurement functions.
Caution Do not sterilize or autoclave the Spot Vital Signs LXi device.
As necessary, clean the device with a cloth slightly dampened with either 70% isopropyl
alcohol, 10% chlorine bleach solution, or mild detergent in water, or use PDI Sani-System
Cloths. Never immerse Spot Vital Signs LXi in any type of fluid.
Blood Pressure Cuff
Before washing the Reusable Two-Piece Cuff, remove the two connectors and bladder,
close off tubes with plugs (available as accessory 5082-163), and close the hook and loop
fasteners. After washing, allow the cuff to air dry. Re-assemble the tube fittings.
Never press with an iron.
Blood Pressure Hose and Cable
Wipe the pressure hose with a damp cloth moistened in a mild detergent solution. Do not
immerse hose.
86
Maintenance and Service
Welch Allyn Spot Vital Signs LXi
SureTemp Plus Thermometer
Temperature Probe
Caution DO NOT immerse or soak the probe in any type of fluid.
Caution DO NOT use steam, heat, or gas sterilization on the probe.
Caution DO NOT autoclave the probe.
Press down on the connector tab and slide the connector out of the port to remove the
temperature probe.
Regularly wipe the probe with a cloth dampened with warm water and a mild detergent
solution, a 70% isopropyl alcohol solution, or a 10% chlorine bleach solution.
Removable Probe Well
Caution DO NOT use hard or sharp objects to clean the probe well. This could
damage the probe well and cause the device to not function properly.
Caution DO NOT use steam, heat, or gas sterilization on the probe well.
Caution DO NOT autoclave the probe well.
1.
Remove the temperature probe from Spot Vital Signs LXi (see “Temperature Probe”
on page 86).
2. Grasp the well under the probe opening and pull up gently to remove it from the
device.
3. Swab the inner and outer surface of the probe well with a cloth dampened with a mild
detergent solution, 70% isopropyl alcohol, or 10% chlorine bleach solution. Immerse
the probe well in mild detergent solution as necessary for cleaning.
4. Dry all surfaces thoroughly before re-assembling the device (see “SureTemp Plus” on
page 20) for reassembly instructions.
Braun ThermoScan PRO 4000 Thermometer
Use a soft cloth slightly moistened with alcohol to clean the thermometer display and
exterior. Do not use abrasive cleaners.
Damage to the probe window or the presence of dirt or cerumen on the probe window
can affect the accuracy of your temperature measurement. To clean the window, gently
wipe it with a cotton swab slightly moistened with alcohol and immediately wipe dry with
a clean cotton swab. Allow to dry at least five minutes before taking a temperature.
Every month, clean the Braun ThermoScan PRO 4000 charging contacts within the Spot
Vital Signs LXi housing with a swab slightly dampened with alcohol.
Service Manual
Maintenance and Service
87
SpO2 Sensors
WARNING Do not immerse the sensor in water, solvents, or cleaning solutions
(the sensors and connections are not waterproof). Do not use irradiation, steam,
or ethylene oxide for sterilization.
Clean the reusable SpO2 sensor with a 70% isopropyl alcohol solution. Do not immerse
the sensor.
Wireless Radio
Use a soft cloth slightly moistened with a mild detergent solution to clean the exterior. Do
not use abrasive cleaners. Do not immerse the module in any liquid.
Printer
The printer label kit comes with a two-step head cleaner. Follow the directions provided
with the cleaner.
88
Maintenance and Service
Welch Allyn Spot Vital Signs LXi
Battery Replacement
Spot Vital Signs LXi
Caution Only use the Welch Allyn 4500-84 lead acid battery. Using an incorrect
battery will cause damage to the Spot Vital Signs LXi and void the warranty.
Caution Do not break the shrinkwrap around the battery.
If necessary, replace the internal battery after heavy use or the battery no longer charges.
1.
Power off the Spot Vital Signs LXi and disconnect the AC power transformer cord.
2. Remove the four screws holding the battery door using a phillips-head screwdriver.
Remove the battery door to expose the battery.
3. Tip the Spot Vital Signs LXi backward and slide the battery out. Disconnect the oneway connector and then attach a new battery to the connector as shown. The oneway connector ends only connect one way. Do this as quickly as possibly to prevent
loss of clock time.
Figure 14. Battery Removal and One-way Connector
One-way
connector
4. Slide the battery into the compartment as far as it will go. Push the connector down
into the case next to the battery.
5. Replace the battery door and tighten each of the four screws.
6. Connect the AC power transformer to the Spot Vital Signs LXi and allow the new
battery to charge for approximately 6 hours. The rechargeable batteries in the Braun
ThermoScan PRO 4000 thermometer requires an additional 1 hour to charge and the
rechargeable batteries in the external printer require an additional 4 hours to charge.
You can use the Spot Vital Signs LXi during this charging period via the AC power
cord.
If Spot Vital Signs LXi displays the E38 error code after power up, set the date (see
“Date/Time Menu Options” on page 25).
The battery is a non-spillable lead-acid battery and must be recycled or
disposed of properly according to national or local regulations.
Service Manual
Maintenance and Service
89
Braun ThermoScan PRO 4000
Caution Do not use alkaline batteries in the Braun ThermoScan PRO 4000
thermometer.
Welch Allyn supplies a rechargeable battery pack with the Braun ThermoScan PRO 4000
thermometer.
1.
Open the battery compartment.
2. Remove the battery pack and replace with a new battery pack, verify the poles are in
the right direction.
3. Slide the battery door back in until it snaps into place.
If the battery is completely discharged, the LEDs will not illuminate. Allow the unit to
charge at least 15 minutes before proceeding.
The battery is a rechargeable battery and must be recycled or disposed
of properly according to national or local regulations.
Printer
Caution Do not use alkaline batteries in the printer.
1.
Open the battery compartment.
2. Remove the battery pack and replace with a new battery pack, verify the poles are in
the right direction.
3. Slide the battery door back in until it snaps into place.
Allow the printer to charge at least 15 minutes before proceeding.
The battery is a rechargeable battery and must be recycled or disposed
of properly according to national or local regulations.
90
Maintenance and Service
Welch Allyn Spot Vital Signs LXi
Spot Vital Signs LXi Firmware Upgrade CD
This CD upgrades the Spot Vital Signs LXi unit software version. A detailed procedure is
available on the upgrade CD.
Spot Vital Signs LXi Wireless Radio Configuration CD
This CD configures the Spot Vital Signs LXi Wireless Radio to a local network. This feature
requires Welch Allyn Connex Version 2.0 or higher (not available in all countries). For more
information about Connex, see www.welchallyn.com.
Product Disposal
Do not dispose of this product as unsorted municipal waste. Prepare this product for
reuse or separate collection as specified by Directive 2002/96/EC of the European
Parliament and the Council of the European Union on Waste Electronic and Electrical
Equipment (WEEE). If this product is contaminated, this directive does not apply.
For more specific disposal information, see www.welchallyn.com/weee,or contact Welch
Allyn Customer Service at +44 207 365 6780.
91
A
Repair Test Specifications
This appendix refers to the Spot Vital Signs LXi without pneumatics (tubing and cuff),
temperature probe, SpO2 probe, or main battery attached, unless otherwise noted.
Use the Repair Software for the performing the tests on the Spot Vital Signs LXi. The
standard test voltage, unless otherwise stated is 6.5 Vdc (+0/-0.25 Vdc). Unless
otherwise stated, all calibrated volumes are ±10cc of the stated volume.
General Unit Test
A-D Noise Test
The A-D Noise Test is defined as the amount of noise on the Spot Vital Signs LXi A-D
pressure channel; over a 1 second sample time while 0.0 mmHg is applied to the Device
pressure port. The maximum limit is 0.050 mmHg.
Leak Test
The Leak Test is defined as the amount of pressure drop that is recorded over a 15-second
interval with a 100cc cylinder attached to the Spot Vital Signs LXi pressure port and that
volume having a stabilized pressure of 250 mmHg. The limit is 5 mmHg maximum.
Inflation Test
The Inflation Test is defined as the amount of time the Spot Vital Signs LXi pump can
inflate a 250 cc cylinder from 5 mmHg to 210 mHg. The limit is 7 seconds, maximum.
Dump Test
The Dump Test is defined as the amount of time it takes Spot Vital Signs LXi to deflate a
500 cc cylinder from 260 mmHg to less than 15 mmHg. The limit is 10 seconds.
Pneumatic Accuracy Test
Enter the Internal Configuration Mode to perform this test (see “Internal Configuration
Mode” on page 24).
Perform an Auto-zero before starting this test (“Blood Pressure Functional Check”, Step 1
on page 34 through Step 5 on page 34). The Pneumatic Accuracy test is defined as the
comparison of Spot Vital Signs LXi’s pressure measurement and applied pressure at 0, 50,
150, and 250 mmHg. The specification for each reading is within ±3 mmHg of the target
pressure except for the 0 mmHg reading which is within ±1.0 mmHg.
92
Repair Test Specifications
Welch Allyn Spot Vital Signs LXi
Valve Control Test
Connect a 100 cc cylinder to the Spot Vital Signs LXi pressure port and pressurize to 160
mmHg. Give Spot Vital Signs LXi the commands to open the valve for 10 mmHg/s, 15
mmHg/s, and 25 mmHg/s. Record each pressure drop: 4 to 12 mmHg, 4 to 15 mmHg,
and 4 to 25mmHg, respectively.
Voltage Calibration
Calibrate the Spot Vital Signs LXi battery voltage measurement circuit at 5.5 Vdc (+0.1/0.0 Vdc).
After performing a successful battery measurement circuit calibration, Spot Vital Signs
LXi’s memory will store a calibration signature of up to four printable characters.
Blank Mode Current Test
The Blank Mode Current Test is defined as the amount of current drawn through the
battery terminals. All LCD segments, the back light, and the SpO2 mode are all turned off.
The limit is 200 mA maximum.
Back Light (Idle) Current Test
The Back Light Current Test is defined as the amount of current drawn through the
battery. All LCD segments and the back light are turned on while the SpO2 mode is turned
off. The limit is 400 mA maximum.
Valve/Pump Mode Current Test
The Valve/Pump Mode Current Test is defined as the amount of current that is drawn
through the battery terminals; Spot Vital Signs LXi is in the Blank Mode while the valve
and pump are actuated to on. The limit is 700 mA maximum.
Interface Test
When given the proper commands, the Display Window will turn on or off all segments
and turn on or off the back light. When given the proper command, the buzzer sounds to
verify operation. The user determines the pass/fail criteria.
Temperature Option Requirements
Accuracy Test
Verify the accuracy of the temperature module is within ±0.2° F for readings with a nomal
temperature of 97.3° F (36.3° C) using a Cal Key (5200-25). Verify Spot Vital Signs LXi can
read a temperatures of 96.4° F (35.8° C) and 106° F (41.1° C) within ±0.3° F/±0.2° C using
a Welch Allyn 9600 Plus Calibrator.
Service Manual
Repair Test Specifications
93
Temperature Probe Test
Spot Vital Signs LXi displays “ORL” after you remove the blue thermometer probe from
the blue probe well.
SpO2 Option Requirements
These tests are only valid on Spot Vital Signs LXi models with the Masimo or Nellcor
SpO2 option.
SpO2 Functional Test
See “Masimo SpO2 Functional Check” or “Nellcor SpO2 Functional Check” on page 32
for the functional test.
SpO2 Mode Current Test
The SpO2 Mode Current Test is defined as the amount of current, less the Blank Mode
Current, that is drawn through the battery terminals, placing Spot Vital Signs LXi in the
Blank Mode, actuating the SpO2 mode and applying any SpO2 signal to the device. The
maximum limit is 120 mA maximum.
Fail Safe Test
Over Pressure Test
Verify that Spot Vital Signs LXi can detect over pressure on the pneumatic system
between 296.0 mmHg and 329 mmHg.
Over 15 mmHg
Verify that Spot Vital Signs LXi can detect static pressure over 15 mmHg for 180 seconds.
94
Repair Test Specifications
Welch Allyn Spot Vital Signs LXi
95
B
Supplies and Accessories
Blood Pressure
Table 1. Reusable Two-Piece Blood Pressure Cuffs (1 per pack)
REF
Size
REF
Size
4500-01
Child
4500-03
Large Adult
4500-02
Adult
4500-04
Thigh
Table 2. Reusable One-Piece Blood Pressure Cuffs (1 per pack)
REF
Size
REF
Size
REUSE-07-2MQ
Infant
REUSE-11-2MQ
Adult
REUSE-08-2MQ
Small Child
REUSE-12-2MQ
Large Adult
REUSE-09-2MQ
Child
REUSE-13-2MQ
Thigh
REUSE-10-2MQ
Small Adult
Table 3. Disposable One-Piece Blood Pressure Cuffs (5 per box)
REF
Size
REF
Size
SOFT-07-2MQ
Infant
SOFT-11-2MQ
Adult
SOFT-08-2MQ
Small Child
SOFT-12-2MQ
Large Adult
SOFT-09-2MQ
Child
SOFT-13-2MQ
Thigh
SOFT-10-2MQ
Small Adult
Table 4. Miscellaneous Supplies and Accessories
REF
Description
REF
Description
4500-30
Blood Pressure Hose (5ft/1.5M)
5200-08
Calibration T-Connector
96
Supplies and Accessories
Welch Allyn Spot Vital Signs LXi
Temperature
Table 5. SureTemp Plus
REF
Description
02895-000
SureTemp Plus Oral Probe and Well (9 feet/2.7M)
02895-100
SureTemp Plus Rectal Probe and Well (9 feet/2.7M)
02894-0000
SureTemp Plus Oral Well
02894-1000
SureTemp Plus Rectal Well
06138-000
SureTemp Plus Temperature Calibration Key
01802-110
9600 Plus Calibration Tester
05031-101
Disposable SureTemp Plus Probe Covers (1,000 covers, packaged 25/box)
Table 6. Braun ThermoScan PRO 4000
REF
Description
04000-200
Braun ThermoScan PRO 4000 Thermometer (for North America, South America, and
Asia Pacific)
04000-600
Braun ThermoScan PRO 4000 Thermometer (for Europe, Middle East, and Africa)
05075-800
Braun ThermoScan PRO 4000 Disposable Probe Covers (Case of 800 covers for North
America, South America, and Asia Pacific)
04000-800
Braun ThermoScan PRO 4000 Disposable Probe Covers (Case of 800 covers for Europe,
Middle East, and Africa)
01802-110
9600 Plus Calibration Tester
53020-0000
Braun ThermoScan PRO 4000 Rechargeable Battery Pack
4500-53
Braun Locking Key
Service Manual
Supplies and Accessories
Pulse Oximetry
Masimo Accessories
Table 7. Adhesive Sensors: Single-Patient Use
Catalog #
Description
Weight Range
Quantity
LNCS-ADTX
Adhesive Finger Sensor - Adult (20 per case)
>30 kg
LNCS-ADTX
LNCS-PDTX
Adhesive Finger Sensor - Pediatric (20 per case)
10 to 50 kg
LNCS-PDTX
LNCS INF-L
Adhesive Finger Sensor - Infant (20 per case)
3 to 20 kg
LNCS INF-L
LNOP-ADT
Adult sensor
>66 lbs (30 kg)
20
LNOP-PDT
Pediatric sensor
22 to 110 lbs
(10 to 50 kg)
20
LNOP-NEO
Neonatal sensor
<22 lbs (10 kg)
20
SofTouch neonatal preterm sensor
<2.2 lbs (1 kg)
20
LNOP-NEOPT
Table 8. Reusable Sensor
Catalog #
Description
Weight Range
Quantity
LNCS-DCI
Finger sensor - adult
>66 lbs (30 kg)
1
LNCS-DCIP
Finger sensor - pediatric
10 to 50 kg
1
LNOP-DCI
Finger clip probe - adult
>66 lbs (30 kg)
1
LNOP-DCIP
Finger clip probe - pediatric
10 to 50 kg
1
Weight Range
Quantity
Table 9. Sensor Cables
Catalog #
Description
LNC-4-WA
4-foot cable with DB-9 connector for LNCS
NA
1
LNC-10-WA
10-foot cable with DB-9 connector for LNCS
NA
1
PC-04
4-foot cable with sensor connector
NA
1
PC-08
8-foot cable with sensor connector
NA
1
PC-12
12-foot cable with sensor connector
NA
1
97
98
Supplies and Accessories
Welch Allyn Spot Vital Signs LXi
Nellcor Accessories
Table 10. OxiMax Adhesive Sensors: Single-Patient Use
Catalog #
Description
Weight Range
Quantity
MAX-AI
MAX-A Adhesive Sensor, adult
>66 lbs (30 kg)
Case of 24
MAX-PI
MAX-P Adhesive Sensor, pediatric
22 to 110 lbs
(10 to 50 kg)
Case of 24
MAX-II
MAX-I Adhesive Sensor, infant
6.5 to 44 lbs
(3 to 20 kg)
Case of 24
MAX-RI
MAX-R Adhesive Sensor, adult nasal
>110 lbs (50 kg)
Case of 24
Table 11. OxiMax OxiCliq® Sensors: Reusable Cable with Adhesive Sensor Bandage
Catalog #
OC-3
OXICLIQ-PI
Description
OxiCliq Sensor Cable (3 ft / 91cm)
OxiCliq P, pediatric
Weight Range
Quantity
N/A
1
22 to 110 lbs
(10 to 50 kg)
Case of 24
Table 12. OxiMax Resuable Sensors
Catalog #
Description
Weight Range
Quantity
DS-100A
Durasensor® DS-100A finger-clip sensor, adult
>88 lbs (40 kg)
1
OXI-A/N
Oxiband® OXI-A/N, adult/neonatal
< 6.5 lbs or > 88 lbs
(<3 kg or >40 kg)
1
OXI-P/I
Oxiband OXI-P/I, pediatric/infant
6.5 lbs to 88 lbs
(3 to 40 kg)
1
D-YS
Dura-Y® D-YS, multisite sensor
>2.2 lbs (1 kg)
1
D-YSE
D-YSE ear clip for Dura-Y sensor
>66 lbs (30 kg)
1
D-YSPD
PediCheck™ D-YSPD pediatric spot-check sensor
6.5lbs to 88 lbs
(3 to 40 kg)
1
Weight Range
Quantity
N/A
1
Table 13. OxiMax Sensor Cables
Catalog #
DOC-10
Description
DOC-10 (10 ft/3M)
Service Manual
Supplies and Accessories
Miscellaneous
REF
Description
101620
Antenna, Wireless, ACH2-AT-DP002
4500-60
Mobile Stand
4500-62
Wall Mount
4500-84
Lead Acid Battery
705310
Directions for Use
700862
Quick Reference Card
704432
Service Manual
4500-150E
Training Video
4500-100
Carrying Case
4500-101A
AC Power Transformer (desktop transformer, line cord not included)
4500-400
Line Cord (United States/Canadian/Japanese version)
4500-402
Line Cord (European version)
4500-404
Line Cord (United Kingdom version)
4500-406
Line Cord (Australian Version)
4500-408
Line Cord (South African version)
4500-500
Printer with Mounting Bracket
4500-505
Printer Rechargeable Battery Pack
4500-510
Printer Paper (10 rolls)
4500-520
Label Paper (10 rolls) and Cleaning Kit
4500-905
Repair Tool Software CD Kit
4500-906
Spot Vital Signs LXi Configuration CD
4500-907
Spot Vital Signs LXi Firmware Loader CD
4500-910
Image Team 3800/3900 1D Bar Code Scanner Kit
4500-915
Image Team 4600 2D Bar Code Scanner Kit
4500-920
Wireless Radio Kit
4500-921
Wireless Radio Directions for Use
4500-925
USB 2.0 Cable for Wired Connectivity
4500-926
Cable for wired connectivity, Keyspan (USB to serial adapter)
4500-927
USB/serial Cable Kit
403204
9-Pin Serial Cable
99
100
Supplies and Accessories
Welch Allyn Spot Vital Signs LXi
Service Contracts
REF
Description
4500-BT0
Blood Pressure with Thermometry
4500-BTS
Blood Pressure with Thermometry and SpO2
101
C
Miscellaneous Mounting
Accessories
Wall Mount Kit
Welch Allyn is NOT responsible for the integrity of any wall
mounting interface. Welch Allyn recommends that the
customer contact their Biomedical Engineering Department
or maintenance service to ensure professional installation,
safety, and reliability of any mounting accessory.
2
1
}
Attach bracket to wall before
assembling basket. See
Directions for Use.
3
4
5
102
Miscellaneous Mounting Accessories
Welch Allyn Spot Vital Signs LXi
Service Manual
Mobile Stand Kit
Miscellaneous Mounting Accessories
103
104
Miscellaneous Mounting Accessories
Welch Allyn Spot Vital Signs LXi
Service Manual
Miscellaneous Mounting Accessories
Wireless Mounting Accessory
A
2
B
1
3
5
4
105
106
Miscellaneous Mounting Accessories
Printer Mounting Accessory
Welch Allyn Spot Vital Signs LXi
Service Manual
Scanner Mounting Accessory
Miscellaneous Mounting Accessories
107
108
Miscellaneous Mounting Accessories
Welch Allyn Spot Vital Signs LXi
109
Warranty
Spot Vital Signs LXi
Welch Allyn warrants that the Spot Vital Signs LXi Wireless Radio products meet the
labeled specifications of the products and will be free from defects in materials and
workmanship that occur within one year after the date of purchase.
The date of purchase is: 1) the date specified in our records if you purchased the Product
directly from us, 2) the date specified in the warranty registration card that we ask you to
send to us, or 3) the date of purchase of product from the authorized Welch Allyn
distributor as documented from a receipt from said distributor.
This warranty does not cover damage caused by: 1) handling during shipping, 2) use or
maintenance contrary to labeled instructions, 3) alteration or repair by anyone not
authorized by Welch Allyn, and 4) accidents.
If a Product or accessory covered by this warranty is determined to be defective because
of defective materials, components, or workmanship, and the warranty claim is made
within the warranty period described above, Welch Allyn will, at its discretion, repair or
replace the defective Product or accessory free of charge.
You must obtain a service notification number from Welch Allyn to return your Product
before you send it to Welch Allyn’s designated service center for repair. Contact Welch
Allyn Technical Support.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE. WELCH ALLYN’S OBLIGATION UNDER
THIS WARRANTY IS LIMITED TO REPAIR OR REPLACEMENT OF PRODUCTS
CONTAINING A DEFECT. WELCH ALLYN IS NOT RESPONSIBLE FOR ANY INDIRECT OR
CONSEQUENTIAL DAMAGES RESULTING FROM A PRODUCT DEFECT COVERED BY
THE WARRANTY.
Accessories
Refer to the manufacturer’s Directions for Use for the Masimo and Nellcor finger sensor
and cable warranty.
Refer to the Directions for Use provided with the Welch Allyn Blood Pressure Cuff for
warranty information.
The SureTemp Plus probe is covered by a one-year warranty and the SureTemp Plus probe
well is covered by a 90-day warranty against original defects in material and workmanship.
Probe covers are intended for single-use only.
110
Warranty
Welch Allyn Spot Vital Signs LXi
The Braun ThermoScan PRO 4000 is covered by a three-year warranty against original
defects in material or workmanship.
The printer is covered by a one-year warranty against original defects in material or
workmanship.
The barcode scanner is covered by a five-year warranty against original defects in material
or workmanship.
The Wireless Radio is covered by a one-year warranty against original defects in material
or workmanship.
Reorder No. 4500-89
Material No.704432 Rev. C
