MyPal A620
User’s Manual
E1250
First edition V1
June 2003
Copyright © 2003 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language in any form or by any means, except documentation kept by the purchaser for
backup purposes, without the express written permission of ASUSTeK COMPUTER INC.
(“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modified or
altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2)
the serial number of the product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES
OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE
LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
(INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE
OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR
ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED
FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME
WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS.
ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR
INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS
AND SOFTWARE DESCRIBED IN IT.
Microsoft, Activesync, Outlook, Pocket Outlook, Windows, and the Windows logo are either
registered trademarks or trademarks of Microsoft Corporation in the United States and/or in
other countries. Microsoft products are licensed to OEMs by Microsoft Lincensing, Inc., a
wholly owned subsidiary of Microsoft Corporation.
ii
Contents at a glance
This user’s manual contains the information you need to efficiently use
ASUS® MyPal A620 Pocket PC.
• Chapter 1 - Get started!.............................................................. 1-1
This chapter introduces the ASUS MyPal A620 Pocket PC, how to
set and power it up, and basic screens that will familiarize you with
its many features.
• Chapter 2 - Learn the basics ..................................................... 2-1
This chapter will teach you the basic functions in MyPal A620. You will
learn how to enter, find, and organize information, customize the
device, and use the bundled ASUS utilities.
• Chapter 3 - Microsoft® ActiveSync® ........................................... 3-1
This chapter tells you how to use the Microsoft® ActiveSync® to
synchronize your device with your desktop computer.
• Chapter 4 - Microsoft® Pocket Outlook ..................................... 4-1
This chapter details the procedures for the Microsoft® Pocket Outlook
Calendar, Contacts, Tasks, Notes, and Inbox.
• Chapter 5 - Companion programs ............................................. 5-1
This chapter includes information on Pocket Word, Pocket Excel,
MSN Messenger, Windows Media Player for Pocket PC, and
Microsoft Reader.
• Chapter 6 - Pocket Internet Explorer ......................................... 6-1
This chapter gives information and procedures on using Pocket
Internet Explorer, Mobile Favorites folder, and AvantGo interactive
service.
• Chapter 7 - Get connected ......................................................... 7-1
This chapter provides the procedures for connecting to the Internet,
and for transferring data using infrared (IR) and Bluetooth.
• Appendix - Notices ..................................................................... A-1
This part includes the safety notices and regulations.
iii
MyPal A620 specifications
Processor
Intel PXA255 400 MHz
Software
Microsoft Pocket PC 2003
Memory
64MB SDRAM (58.6 MB user accessible)
32MB Flash ROM
Display
3.5-inch, 240x320 pixels
65,536 colors, Transflective TFT LCD
Card slots
CompactFlash (CF) Type II slot
Infrared
FIR/SIR
Audio
Stereo headphone jack
Built-in microphone
Built-in speaker
Size
125 mm x 76.8 mm x 13.3 mm (L x W x H)
4.92 in. x 3.02 in. x 0.52 in. (L x W x H)
Weight
Approximately 141g
MyPal A620 package
Your package includes several accessories for the Pocket PC. After
unpacking, check the items against the list below and make sure that they
are in good condition. If any item is missing or damaged, contact your
dealer or retailer immediately.
Standard package contents
Optional accessories
• ASUS MyPal A620
• USB cradle with sync cable
• AC adapter
Input: 100V~240V
Output: 5V 2A 10W
• Stylus
• Microsoft Companion CD
• Bonus CD (optional)
• User’s Manual
• Quick Start Guide
• Warranty card
•
•
•
•
•
•
•
•
Stylus
Car charger
Foldable keyboard*
Leather handheld case
Leather waist case
Traveling USB sync cable
Cradle with cable
AC adapter with plug
(UL/CEE/UK/SAA/CCEE)
• GPS mouse
•
•
•
•
•
•
•
•
•
CF GPS card
CF Bluetooth card
CF wireless LAN card
CF LAN card
CF modem card
CF camera card
CF VGA card
CF FM radio card
CF GPRS card
* English version keyboard. Visit the ASUS website to check the availability of other language version keyboards.
iv
Chapter 1
Get started!
♦
Introducing MyPal ................................................ 1-2
Front features ........................................................................... 1-2
Side features ............................................................................ 1-3
Top features ............................................................................. 1-4
Bottom features ........................................................................ 1-4
Back features ........................................................................... 1-5
The stylus ................................................................................. 1-5
The cradle ................................................................................ 1-6
♦
Setting up MyPal ................................................... 1-7
Placing on the cradle ............................................................... 1-7
Connecting the AC adapter ...................................................... 1-7
Installing and removing a CF card ........................................... 1-8
Charging the battery .............................................................. 1-10
Activating MyPal .................................................................... 1-10
♦
Basic screens on MyPal ...................................... 1-11
Today screen ...........................................................................1-11
Start menu ............................................................................. 1-12
Command bar ........................................................................ 1-13
Pop-up menus ........................................................................ 1-13
Get started!
1-1
Introducing MyPal
The ASUS® MyPal A620 is truly a good companion wherever you go.
Powered by a 400MHz Intel® PXA255 processor, equipped with 64MB
SDRAM and 32MB Flash ROM, and bundled with the latest Microsoft
Pocket PC 2003 plus a host of useful utilities, you have everything you
need in your pocket!
Front features
Power button/
Backlight button
Record button/
Notes button
Built-in microphone
LCD touch screen
Contacts button
Calendar button
Tasks button
ASUS Settings button
Speaker
Navigation button
•
Power/Backlight button - turns the device power on or off if you press
the button quickly. Pressing and holding the button for a few seconds
turns the backlight on or off. Turning off the backlight saves battery
power.
NOTE
•
•
1-2
Press this button and the Tasks button simultaneously if you
wish to launch the Align Screen function.
Record/Notes button - allows you to record sounds and save them as
files if you press and hold the button, or launches the Notes program
when pressed once.
Built-in microphone - magnifies your sound recording.
Chapter 1
•
•
•
LCD touch screen - allows you to enter, read, send, receive, or edit data
by tapping on it. The screen lumination is increased or decreased by
changing the backlight settings.
ASUS Settings, Calendar, Tasks, and Contacts buttons - allow you
quick access to commonly used programs.
Navigation button - functions like the four arrow keys and the Enter key
on a keyboard. This multifunction button allows you to:
- move through the program icons, folders, or files in a menu by
scrolling up or down
•
- launch a selected program, list folder contents, or open a file by
pressing the center of the button
Speaker - allows you to hear alarms and other sound outputs from the
device.
Left side features
Charging status LED
System indicator LED
Infrared (IR) port
•
•
•
Charging status LED - lights up orange when the battery is charging;
lights up green when the battery is fully charged.
System indicator LED - indicates the system status.
Infrared (IR) port - allows you to copy or send data to another device
with an IR port.
Get started!
1-3
Top features
Headphone jack
•
•
•
CF card slot
Stylus
Headphone jack - connects a headphone.
CF card slot - accommodates a CompactFlash (CF) card. See list of
supported CF cards on page iv.
Stylus - used for tapping or writing on the LCD touch screen. Slide out
the stylus from its compartment. Refer to the description of the stylus on
the next page.
Bottom features
Cradle connector /
Sync cable connector
•
•
1-4
Power connector
Cradle connector / Sync cable connector - connects to the 26-pin
female connector on the cradle. If you are not using the cradle, connect
the 26-pin USB sync cable directly to this connector to synchronize your
device with your computer.
Power connector - connects the AC adapter cable. Use this connector if
you wish to use AC power without the cradle.
Chapter 1
Back features
CF card slot cover
Reset switch
•
•
Reset switch - allows you to perform a soft reset in case of device
malfunctions, or when an application hangs. Press the tip of the stylus on
the switch to reset the system.
CF card slot cover - protects the slot connector and the CF card.
The stylus
The stylus functions on a Pocket PC the same way a mouse functions on
a standard PC. Use the stylus to tap or drag on the LCD touch screen to
open programs or execute commands.
•
•
•
Tap. Touch the screen once with the stylus to open programs and select
options.
Drag. Hold the stylus on the screen and drag across the screen to select
text and images. Drag in a list to select multiple items.
Tap and hold. Tap and hold the stylus on an item to see a list of actions
available for that item. On the displayed pop-up menu, tap the action that
you want to perform.
Stylus
Get started!
1-5
The cradle
The cradle has three connectors.
•
•
•
Device connector - holds the device in place. This is a 26-pin connector
that matches the connector on the bottom of the device.
USB connector - synchronizes the device with your PC.
NOTE: The USB cable/connector is not detachable from the back of the
cradle.
Power connector - connects the bundled AC adapter. This connector is
located at the back side of the cradle.
USB connector
Device connector
1-6
Power connector
Chapter 1
Setting up MyPal
Placing on the cradle
Position the device on the cradle as shown. Match the connectors and
carefully insert the device until it fits in place.
Connecting the AC adapter
•
•
Connect the AC adapter cable to the connector at the back of the cradle.
Connect the power plug to a grounded wall socket. See Figure 1.
If you are not using the cradle, connect the AC adapter cable directly to
the power connector at the bottom of the device. Connect the power plug
to a grounded wall socket. See Figure 2.
Figure 1
Get started!
Figure 2
1-7
Installing and removing a CF card
The CF card slot on your device supports several types of CF card. Refer
to the list of supported cards under “Optional Accessories” on page iv of
this manual.
Install a CF card for additional storage, or if you wish to use the ASUS
backup features.
To install a CF card:
1. Locate the card side with the 50-pin female connector and insert into
the slot. The label side (usually the side with the card manufacturer’s
name) face down, and the bar code/serial number side face up.
Bar code/Serial number side
1
Label side/Manufacturer’s name
NOTE
A CF card fits only in one orientation, and slides smoothly into
the slot if inserted correctly. DO NOT force the CF card into
the slot!
2. Push the card all the way into the slot until it fits completely. If properly
installed, the CF card edge aligns with the top edge of the device.
2
1-8
Chapter 1
To remove a CF card:
1. Remove the CF card slot cover by pushing on the dent on the surface,
and sliding the cover outward.
Dent on the cover surface
1
2. Slide out the CF card.
2
3. Replace the cover back into the slot.
3
Get started!
1-9
Charging the battery
Your device includes a rechargeable Lithium
Ion battery. You must charge the battery
before using the device the first time. The
battery starts charging as soon as you
connect the AC adapter to a power source.
Use the AC adapter to plug your device to a
power source whenever possible, especially
when you are using a modem or other
peripherals, using the device backlight,
connecting to a PC, or letting notification
light flash for extended time periods.
To display the power status, tap
,
Settings, System tab, and the Power icon.
Activating MyPal
It is important that you properly calibrate and activate your device before
using it. This process ensures accurate positioning when entering text and
selecting menus.
Follow these steps to calibrate and activate MyPal.
1. Press the power button.
2. Use the stylus to tap the LCD touch screen to start the calibration and
activation.
3. At the prompt to align the screen, tap the center of the cross whenever
the travelling cross stops on the screen. You may have to do this step
several times to properly calibrate.
4. When done with the screen calibration, follow the screen instructions to
complete the activation.
• at the “Stylus” screen, tap Next to continue.
• at the “Pop-up menus” screens, perform the indicated operations.
• at the “Congratulations” screen, tap Next to continue.
• at the “Location” screen, select your time zone and tap Next to
continue.
• at the “Completion” screen, tap the screen to continue.
5. When the Today screen appears, MyPal is ready to use. Proceed to
the next section for information on the basic screens on your device.
1-10
Chapter 1
Basic screens on MyPal
Today screen
Normally, the Today screen appears when you turn on your device for the
first time each day.
NOTE
When the device is already on and the screen displays
another program, you can display the Today screen by
tapping the
icon. Then from the Navigation bar, tap Today.
As shown in the sample below, the Today screen lets you see at a glance
the summary of the important information for the day.
Tap to switch
to a program
Tap to set up or change network or modem connections
Tap to change volume or mute all sounds
Tap to display the date, time,
and your next appointment
Tap to change the date and time
Your day at a glance
Tap to create a new item
Tap to view PC connection status
From the Today screen, tap any of the listed items with the stylus to
display the details. See “Chapter 2: Learn the basics” to learn how to
modify the current tasks or activities, or to add new items or information.
Get started!
1-11
Start menu
From the Start menu, you can select programs, settings, and Help topics.
To display the Start menu, tap the
icon from the top of the screen.
Tap to open a recently used program
Tap to open a program
Tap to open the Programs menu
Tap to open the Settings menu
Tap to display the Help topics
Icon
1-12
Program
Description
ActiveSync
Synchronize information between your
device and your desktop computer.
Calendar
Keep track of your appointments and create
meeting requests.
Contacts
Keep track of your friends and colleagues.
Inbox
Send and receive e-mail messages.
Internet Explorer
Browse Web and WAP sites, and download
new programs and files from the Internet.
Notes
Create handwritten or typed notes, drawings,
and recordings.
Tasks
Keep track of your tasks.
Programs
Tap to see additional programs installed in
your device.
Settings
Tap to see items that you can customize or
adjust to your preference.
Find
Tap to find data in your device.
Help
Tap to see the Help contents.
Chapter 1
Command bar
At the bottom of the screen is the Command bar. You can use the menus
and buttons on the Command bar to perform tasks in programs.
NOTE
The menus and buttons vary depending on the programs you
are using.
Tap to select menu
commands
Tap to select
button commands
Tap to display
the input panel
Pop-up menus
With the pop-up menus, you can easily choose an action for an item.
For example, you can use the pop-up menu in Tasks to delete, copy, or
beam a task. The actions in the pop-up menus vary from program to
program. To access a pop-up menu, tap and hold the stylus on the item
that you wish to perform action on. When the menu appears, lift the stylus,
and tap the action that you want to execute. To close the pop-up menu
without performing an action, tap anywhere outside the menu.
Tap and hold until the pop-up menu appears
Tap the action that you wish to perform
Tap outside the pop-up menu to close it
without performing an action
Get started!
1-13
The pop-up menus are also available in most other programs in your
device. The pop-up menu items vary depending on the program or
application. For example, the File Explorer pop-up menu includes more
items than in Tasks.
Tap outside the pop-up menu to close it
without performing an action
Tap the action that you wish to perform
Tap and hold until the pop-up menu appears
1-14
Chapter 1
Chapter 2
Learn the basics
♦
Entering information ............................................ 2-2
Entering text using the Input Panel .......................................... 2-2
Writing on the screen ............................................................... 2-5
Drawing on the screen ............................................................. 2-8
Recording a message .............................................................. 2-9
Using a preset message ........................................................ 2-10
♦
Finding and organizing information .................. 2-11
Using the File Explorer ........................................................... 2-12
♦
Customizing your device ................................... 2-13
Adjusting settings ................................................................... 2-13
Selecting sounds and notifications ......................................... 2-15
Adding or removing programs ................................................ 2-15
♦
ASUS utilities ...................................................... 2-18
ASUS SmartKeeper ............................................................... 2-18
ASUS Backup ........................................................................ 2-24
ASUS Settings ....................................................................... 2-30
♦
Bundled programs .............................................. 2-34
ASUS Programs ..................................................................... 2-34
Games ................................................................................... 2-34
File Explorer ........................................................................... 2-35
Microsoft Reader .................................................................... 2-35
Calculator ............................................................................... 2-35
MSN Messenger .................................................................... 2-36
Pocket MSN ........................................................................... 2-36
Pocket Word .......................................................................... 2-36
Pocket Excel .......................................................................... 2-37
Pictures .................................................................................. 2-37
Terminal Services Client ........................................................ 2-37
Learn the basics
2-1
Entering information
You can enter information in your device in any of the following ways.
•
•
•
•
•
Use the input panel to enter text using the soft keyboard or the Letter
recorgnizer
Write directly on the screen with the stylus
Draw pictures on the screen
Speak into the device microphone to record a message
Use the Microsoft ActiveSync to synchronize or copy information from
your desktop computer to your device
Entering text using the Input Panel
Use the Input Panel to enter information in any program on your device.
you can either type using the soft keyboard or write using the Letter
Recognizer, Block Recognizer, or Transcriber. In either case, the
characters appear as typed text on the screen.
To show or hide the input panel, tap the Input Panel button. Tap the
arrow next to the Input Panel button to see your options.
Select an input method
Tap to display the input method options
Tap to show or hide the input panel
To type with the soft keyboard:
1. Tap the arrow next to the Input Panel button, then tap Keyboard.
NOTE
To demonstrate, open Notes.
2. Tap the keys with the stylus to enter information.
2-2
Chapter 2
When you use the Input Panel and the soft keyboard, your device
anticipates the word you are typing and displays it above the Input Panel.
When you tap the displayed word, it is inserted into your text at the
insertion point. The more your use your device, the more words it learns to
anticipate.
Tap here if this is the word you wish to use
NOTE
To change options on word completion feature:
1.
2.
3.
4.
5.
6.
.
Tap
Tap Settings.
Tap Personal tab.
Tap Input.
Tap Word Completion tab.
Make your desired changes.
To use Letter Recognizer:
With the Letter Recognizer, you can write letters on the screen with the
stylus as you would on paper.
1. Tap the arrow next to the Input Panel button, then tap Letter
Recognizer.
2. Write a letter in the box.
When you write a letter, it is converted to a typed text that appears on
the screen. For instructions and demonstation on using the Letter
Recognizer, tap the question mark next to the writing area.
Learn the basics
2-3
To use Block Recognizer:
With the Block Recognizer, you can input character strokes that are similar
to those use on other devices.
1. Tap the arrow next to the Input Panel button, then tap Block
Recognizer.
2. Write a letter in the box.
When you write a letter, it is converted to a typed text that appears on
the screen. For instructions and demonstation on using the Block
Recognizer, tap the question mark next to the writing area.
To use Transcriber:
With Transcriber, you can use the stylus to write anywhere on the screen
as you would on paper. Unlike Letter Recognizer and Block Recognizer,
you can write a sentence or additional information. Pause after writing and
let Transcriber convert the written characters to typed characters.
1. Tap the arrow next to the Input Panel button, then tap Transcriber.
2. Write anywhere on the screen.
For instructions and demonstation on using Transcriber, with
Transcriber open, tap the question mark in the lower right corner of the
screen.
To edit typed text:
1. Select the text that you wish to edit using either one of the following:
• drag the stylus over the text
• tap twice to select a word
• tap three times to select a paragraph
2. Tap Edit on the Command bar and select an action, or use one of the
tools in the Input Panel to enter a new text.
2-4
Chapter 2
Writing on the screen
In any program that accepts writing, such as the Notes program, and in the
Notes tab in Calendar, Contacts, and Tasks, you can use the stylus to
write directly on the screen. Write the way you do on paper. You can edit
and format what you have written and convert the information to text at a
later time.
To write on the screen:
1. Open the Notes program.
2. Tap the Pen button to switch to the writing mode. The screen displays
blank space with lines to help you write.
3. Write your text.
Tap the Pen button and use
your stylus like a pen
NOTE
Some programs that accept writing may not have the Pen
button. See the documentation for that program to find out
how to switch to writing mode.
Learn the basics
2-5
To edit your writing:
1. Tap and hold the stylus next to the text that you wish to select until the
insertion point appears.
2. Without lifting, drag the stylus across the text to select it.
If you accidentally write on the screen, tap Tools, then Undo and try
again. You can also select text by tapping the Pen button to deselect it
and then dragging the stylus across the screen.
3. Tap Edit on the Command bar and select an action, or use one of the
tools in the Input Panel to enter a new text.
To convert writing to text:
•
Tap Tools, then Recognize.
To select a zoom level:
•
Tap Tools, then tap a zoom percentage from the options.
The writing is turned into text
2-6
Chapter 2
If the conversion is incorrect, you can select different words from a list of
alternates or return to the original writing.
1. Tap and hold the incorrect word.
2. When the pop-up menu appears, tap Alternates to display a list of
alternate words for the selection.
3. Tap the word that you want to use, or tap the writing at the top of the
menu to return to the original writing.
Tap to return to your
original writing
Or, tap the word that
you want to use
Tips for getting good writing recognition
•
•
•
•
•
•
Write neatly.
Write on the line and draw descenders below the line. Write the cross of
the “t” and apostrophes below the top line so that they are not confused
with the word above. Write periods and commas above the line.
For better recognition, try increasing the zoom level to 300% using the
Tools menu.
Write the letters of a word closely and leave big gaps between words so
that the device can easily tell where the words begin and end.
Hyphenated words, foreign words that use special characters such as
accents, and some punctuation cannot be converted.
If you add writing to a word to change it (such as changing a “3” to an “8”)
after you attempt to recognize the word, the writing you add will not
included if you attempt to recognize the writing again.
Learn the basics
2-7
Drawing on the screen
You can draw on the screen in the same way that you write on the screen.
The difference between writing and drawing on the screen is how you
select items and how they can be edited. For example, selected drawings
can be resized, while writing cannot.
To create a drawing:
1. Use the stylus to make a stroke three ruled lines high. A dotted box
appears.
2. Make your drawing in or touching the drawing box and crossing three
ruled lines. If the drawing does not cross three lines, it changes to writing.
The drawing box indicates the
boundaries of the drawing
Pen button
NOTE
To easily work on or view your drawing, change the zoom
level by tapping Tools and selecting your desired zoom.
To edit your drawing:
1. Tap and hold the stylus on the drawing until the selection handle
appears. To select multiple drawings, deselect the Pen button then
drag to select the drawings you want.
2. Tap and hold the selected drawing, then tap an editing command on
the pop-up menu or tap a command on the Edit menu.
3. Resize the drawing by deselecting the Pen button (if selected) and
dragging a selection handle to your desired size.
2-8
Chapter 2
Recording a message
In any program where you can write or draw on the screen, you can also
quickly capture thoughts, reminders, and phone numbers by recording a
message. In Calendar, Tasks, and Contacts, you can include a recording
in the Notes tab. In the Notes program, you can either create a standalone recording or include a recording in a written note. If you want to
include the recording in a note, open the note first. In the Inbox program,
you can add a recording to an e-mail message.
To create a recording:
1. Hold your device with the microphone near your mouth or other source
of sound.
2. Press and hold the Record button on the device until you hear a beep.
3. While holding the Record button, make your recording.
4. To stop recording, release the Record button. You will hear two beeps.
The new recording appears in the Note list or as an embedded icon.
NOTE
You can also make your recording using the buttons on the
Recording toolbar.
5. To play the recording, tap it from the list, or if embedded in a note, tap
the speaker icon.
Indicates an embedded
recording
Tap to begin recording
Tap to show or hide the
Recording toolbar
Learn the basics
2-9
To change the recording format:
1. In the note list, tap Tools then
Options.
2. Tap the Global Input Options link.
3. Tap the Options tab.
Mobile Voice is a 2.4KB audio codec.
It is the recommended format because
it provides good voice recording and
less storage space.
Pulse Code Modulation (PCM)
provides slightly better sound quality
but takes up 50 times more storage
space tham Mobile Voice recordings.
Using a preset message
When using Inbox or MSN Messenger, use My Text to quickly insert preset
or frequently used messages into the text entry area. To insert a message,
tap My Text and tap your desired message.
NOTE
You can add text after inserting a My Text message.
However, you have to add it before sending the message.
To edit a preset message:
1. Tap Tools, then Edit My Text Messages.
2. Select a message and make your desired changes.
2-10
Chapter 2
Finding and organizing information
The Find and Help features on your device helps you quickly locate
information.
To find information:
1. Tap
, then tap Find.
2. Enter the text that you want to find, select a data type, then tap Go to
start the search. To quickly find information that is taking up space on
your device, select Larger than 64 KB in Type.
Type a word to find
Tap to search for the word
Topics found containing
the searched word
To use the Help feature:
1. Tap
, then tap Help.
2. Tap a link to the topic that you wish to
display.
Learn the basics
2-11
Using the File Explorer
To use the File Explorer to find and organize files:
1. Tap
, then tap Programs.
2. In the Program screen, tap the File Explorer icon to display the files in
your device.
Tap to display sort options
Tap to select a sort order
Tap to display the contents of the storage card
(appears only if a storage card is installed)
Tap to display the contents of My Documents folder
2-12
Chapter 2
Customizing your device
You can customize your device by adjusting the settings and installing
additional software.
Adjusting settings
You can adjust the device settings to your preference.
To see the available options:
1. Tap
, then tap Settings to display the Settings screen.
2. Tap the Personal or System tab on the bottom of the screen.
You may want to adjust any one of the following items.
•
Clock. Change the time or set alarms.
•
Menus. Customize what appears on the
menu, and enable a pop-up
menu from the New button.
Owner information. Enter your contact information.
Password. Add security to your device.
Power. Display the remaining battery power indicated by a bar chart.
Today. Customize the look and information displayed on the Today
screen.
•
•
•
•
NOTE
Refer to the section “ASUS utilities” later in this chapter for
details on the bundled ASUS programs.
Learn the basics
2-13
To change the date and time settings:
1. Tap Settings, then the System.
2. Tap the Clock icon.
3. Make your desired settings.
Tap to select a time zone
Highlight a Time item then
tap up or down arrow to set
Tap this down arrow to
display the Calendar
To change the alarm settings:
1. Tap Settings, then the System.
2. Tap the Clock icon, then the Alarm tab.
3. Make your desired settings.
Tap a day of the week for the alarm
Tap and type a description for the alarm
Tap to display the clock and
specify a time for the alarm
2-14
Chapter 2
Selecting sounds and notifications
Your device can remind you of things you have to do in several ways. For
example, if you have set up an appointment in Calendar, a task with a due
date, or an alarm in Clock, you will be notified in any of the following ways.
•
•
•
A message box appears on the screen
A sound is played (you can select the type of sound)
A light flashes on the device
To choose the reminder types and sounds:
1. Tap
icon then tap Settings.
2. From the Settings screen, tap the
Sounds and Notifications icon to
display the Volume screen.
3. Adjust the items to your desired
settings.
4. Tap the Notifications tab and set the
event notification details.
Learn the basics
2-15
Adding or removing programs
Programs added to your device at the factory are stored in ROM (ReadOnly Memory). You cannot remove this software, and you will never
accidentally lose ROM contents. ROM programs can be updated using
installation programs with a *.xip extension. All other programs and data
files added to your device after factory installation are stored in RAM
(Random Access Memory).
You can install any program created for your device, as long as it has
enough memory. The most popular place to find software for your device is
on the Pocket PC web site (http://www.microsoft.com/mobile/pocketpc).
To add programs using ActiveSync:
NOTE
You need to install the Microsoft ActiveSync on your desktop
computer before you can synchronize and/or add programs
to your device. Refer to “Chapter 3: Microsoft ActiveSync” for
installation instructions.
1. Determine your device and processor type so that you know which
, then tap Settings. On the
version of the software to install. Tap
System tab, tap About. In the Version tab, take note of the information
in Processor.
2. Download the program to your desktop computer (or insert the CD that
contains the program into your desktop computer). You may see a
single *.xip, *.exe, or *.zip file, a Setup.exe file, or several versions of
files for different device types and processors. Be sure to select the
program designed for the Pocket PC and your device processor type.
3. Read any installation instructions, Read Me files, or documentation
that comes with the program. Many programs provide special
installation instructions.
4. Connect your device to your desktop computer.
2-16
Chapter 2
5. Double-click the *.exe file.
• If the file is an installer, the installation wizard begins. Follow the
directions on the screen. Once the software is installed on your
desktop computer, the installer automatically transfers the software to
your device.
•
If the file is not an installer, you will see an error message stating that
the program is valid but it is designed for a different type of computer.
You need to move this file to your device. If you cannot find any
installation instructions for the program in the Read Me file or
documentation, use ActiveSync Explore to copy the program file to
the Program Files folder on your device. For more information on
copying files using ActiveSync, see ActiveSync Help.
6. When the installation is complete, tap
icon to switch to it.
, Programs, and the program
To add a program directly from the Internet:
NOTE
You need to be connected to the Internet through an optional
modem card or network card before you can add programs
directly from the Internet.
1. Determine your device and processor type so that you know which
, then tap Settings. On the
version of the software to install. Tap
System tab, tap About. In the Version tab, take note of the information
in Processor.
2. Download the program to your device straight from the Internet using
the Pocket Internet Explorer. You may see a single *.xip, *.exe, or *.zip
file, a Setup.exe file, or several versions of files for different device
types and processors. Be sure to select the program designed for the
Pocket PC and your device processor type.
3. Read any installation instructions, Read Me files, or documentation
that comes with the program. Many programs provide special
installation instructions.
4. Tap the file, such as a *.xip or *.exe file. The installation wizard begins.
Follow the directions on the screen.
Learn the basics
2-17
To add a program to the Start menu:
1. Tap
, tap Settings, tap Menus, tap the Start Menu tab, and tap the
check box for the program. If you do not see the program on the list,
you can either use File Explorer on the device to move the program to
the Start Menu folder, or use ActiveSync on the desktop computer to
create a shortcut to the program and place the shortcut in the Start
Menu folder.
2. If you are using the File Explorer on the device:
a. Tap
, tap Programs, tap File Explorer, and locate the program
(tap the folder list, labeled My Documents by default, then tap My
Device to see a list of all the folders on the device).
b. Tap and hold the program, then tap Cut on the pop-up menu. Open
the Start Menu folder located in the Windows folder, tap and hold a
blank area of the window, then tap Paste in the pop-up menu.
menu. For more information on
c. The program now appears on the
using the File Explorer, see the section “Finding and organizing
information” earlier in this chapter.
3. If you are using ActiveSync on the desktop computer:
a. Use the Explorer in ActiveSync to explore your device files and locate
the program. Right-click the program, then click Create Shortcut.
b. Move the shortcut to the Start Menu folder in the Windows folder. The
menu. For more information, see
shortcut now appears on the
ActiveSync Help.
To remove a program from the Start menu:
1. Tap
, then tap Settings. On the System tab, tap Remove
Programs.
2. If the program does not appear in the list of installed programs, use
File Explorer on your device to locate the program, tap and hold the
program, then tap Delete on the pop-up menu.
2-18
Chapter 2
ASUS utilities
Besides the Microsoft program that allows you to back up data, your
device also includes proprietary ASUS utilities. The ASUS utilities allow
you to backup or restore data, and adjust settings to customize your
device and maximize its use.
ASUS SmartKeeper
The ASUS SmartKeeper is an automatic backup feature that prompts you
to backup the current system status in a CF memory card whenever the
remaining battery power reaches a certain level. With the automatic
option, the backup process is done whether the device is ON or OFF as
long as a CF memory card is present in the slot.
Requirements for automatic backup
•
•
•
SmartKeeper is enabled
a CF memory card in the card slot (64MB free space recommended)
the remaining battery power in the device reaches a low level
To enable automatic backup:
1. Tap
, then tap Settings.
2. Tap the System tab on the bottom of
the Settings screen.
3. Tap the SmartKeeper icon to display
the Automatic screen.
Learn the basics
2-19
4. In the Automatic screen, check the
Automatic system backup box to
enable automatic backup. This box is
checked by default.
When SmartKeeper is set to
Automatic, make sure that a CF
memory card (64MB free space
recommended) is present in the CF
card slot.
5. Tap OK.
NOTE
To verify if the CF memory card is usable for system backup,
perform a Manual backup first. See the section “To use
manual backup” on page 2-22.
How the SmartKeeper automatic backup works
SmartKeeper is capable of performing the automatic backup process
whether your device is in use (ON) or in suspension (OFF).
When the device is ON
If a low battery status occurs while you are using the device, this message
appears, “Battery low! Back up the current system status?”
Backing up the “current system status” means that the entire
system and all the data in the system main memory are saved as
is to the ASUSBKUP.SAV file. For example, you are editing an
Excel file when a battery low status occurs and you confirmed to
back up. When you restore the system status from the
ASUSBKUP.SAV file, you will see exactly the same screen,
settings, and system configuration as earlier backed up.
2-20
Chapter 2
To back up the current system status:
1. Make sure that a CF memory
card is present in the slot.
If you tap Yes without the CF
memory card, an error message
appears.
2. Tap the Yes button on the screen
message window to start the
backup process. SmartKeeper
saves your current system status
to the file ASUSBKUP.SAV in the
CF memory card.
Tap No if you do not wish to back
up the system status at this time.
3. A confirmation message appears
when the backup process is
complete.
Learn the basics
2-21
When the device is OFF
If a low battery status occurs while the device is in standby or OFF,
SmartKeeper wakes up the system to backup the system status.
To perform the backup process:
1. SmartKeeper checks if a CF memory card is ready in the slot.
2. If found, SmartKeeper backs up the current system status to
ASUSBKUP.SAV file in the CF memory card. When the backup
process is complete, the system automatically goes back to sleep
(OFF).
If a CF memory card is not ready in the slot, the device goes back
to sleep without performing the backup process.
When you turn on the device, either one of the following messages is
flashed on the screen.
The system detected a battery
power low status. The system
status was automatically backed
up to ASUSBKUP.SAV file in the
CF memory card.
The system detected a battery
power low status and tried to
back up the system status at
2003/04/08, 10:21:27 AM. Backup
failed! CF memory card not ready.
The system detected a battery
power low status and tried to
back up the system status at
2003/04/08, 10:21:27 AM. Backup
failed! Cannot access CF memory
card.
The system detected a battery
power low status and tried to
back up the system status at
2003/04/08, 10:21:27 AM. Backup
failed! Insufficient space in the
CF memory card.
2-22
If automatic backup is successful
If automatic backup failed because
a CF memory card is not ready in
the slot
If automatic backup failed because
the CF memory card in the slot
may be defective and not
accessible
If automatic backup failed because
the available space in the CF
memory card is not enough to
back up the current system status
Chapter 2
The system detected a battery
power low status and tried to
back up the system status at
2003/04/08, 10:21:27 AM. Backup
failed! System error.
If automatic backup failed because
a system error occurred.
To use manual backup:
1. Tap
, then tap Settings.
2. Tap the System tab on the
bottom of the Settings screen.
3. Tap the SmartKeeper icon, then
the Manual tab.
4. Tap the Back up system button
to back up the current system
status to ASUSBKUP.SAV file in
the CF memory card.
5. A message appears to confirm
that the backup process is
complete.
To restore the system status:
1.
2.
3.
4.
Tap
, then tap Settings.
Tap the System tab on the bottom of the Settings screen.
Tap the SmartKeeper icon, then the Manual tab.
Tap the Restore system button to restore the saved system status
from the ASUSBKUP.SAV file in the CF memory card.
Learn the basics
2-23
SmartKeeper error messages
When backing up or restoring the system status, you may receive any one
of the following error messages. The messages tell you the reason why
the error occurred.
Back up
2-24
Restore
Chapter 2
ASUS Backup
The ASUS Backup utility lets you back up your system files and/or data
contained in the main system memory. Unlike the ASUS SmartKeeper
automatic backup feature that backs up the entire system status (system
and data) into one backup file, this utility allows you to manually create
separate backup files for your system files and data files. You may even
categorize the data files and place into different folders.
To access the ASUS backup utility:
1. Tap
NOTE
, then tap Programs.
You need to insert an CF memory card into the CF slot on top
of the device when backing up data. Otherwise, the message
“CF memory card not ready!” appears.
, then tap
.
2. Tap
A message appears asking you to
stop other programs before
running the backup utility.
3. Tap OK and stop all running
programs.
To stop all running programs:
1. Tap
, then tap Settings.
2. Tap the System tab, then tap the
Memory icon.
3. On the Memory screen, tap the
Running Programs tab.
4. Tap the Stop All button, then tap
OK.
Learn the basics
2-25
NOTE
See the online help on your device for online instructions to
back up or restore data.
To back up all data on your device:
1. Return to the ASUS programs
screen and tap the ASUS
Backup icon.
2. Tap the Backup tab on the ASUS
Backup screen.
3. Tap All Data button to back up all
data on your device.
NOTE
Make sure that a CF card is installed in the slot before you
continue with the backup process.
4. In the Backup File screen:
• specify a file name for the
backup
• specify the folder in which to
store the backup file (optional)
• select CF Card for the location
of your backup file
5. Tap OK to start the backup
process.
2-26
Chapter 2
6. The screen shows the status of the backup process. When done, a
message appears indicating that the backup is complete, and shows
the total size of the backed up files.
In case the program fails to back up any items, it will show the items on
the screen.
7. Tap OK.
To back up only PIM data on your device:
1. On the ASUS Backup screen, tap
PIM Data button to back up only
the personal information
management (PIM) data on your
device.
2. Select CF card in the Storage
Devices screen.
Tapping Cancel returns you to the
previous screen.
3. Tap the Backup tab.
Learn the basics
2-27
4. Type a name for your backup file
and the folder where you wish to
place it. You may opt not to
specify a folder.
5. Check the boxes opposite the
items that you wish to back up, or
tap Select All to select all listed
items.
If you checked the box User
Defined Folders, tap Define to
specify the folders that you wish
to include in the backup file, then
tap OK.
6. Tap Start to begin the backup
process.
7. When the backup process is
complete, the screen displays the
message “Complete” and a list of
all the backed up items.
8. Tap OK.
2-28
Chapter 2
To restore all data from the CF memory card:
1. Tap
NOTE
, then tap Programs.
You need to insert the CF memory card that contains your
backup file into the CF slot on the device when restoring
data. Otherwise, you will receive the message “No storage
device are found!”
2. On the ASUS Programs screen
Tap the ASUS Backup icon.
When prompted, stop all running
programs. See page 2-24 for
instructions.
3. Tap the Restore tab on the ASUS
Backup screen.
4. Tap All Data.
5. In the Backup File screen:
• select the backup file name
(tap the arrow to list down other
backup files, if any)
• select the folder that contains
your backup file (optional)
• select CF Card the location
where you stored your backup
6. Tap OK to start the restore
process.
7. When the restoration is done, a
message appears prompting you
to reset the device.
8. Tap OK to reset.
Learn the basics
2-29
To restore PIM data from the CF memory card:
1. On the ASUS Backup screen, tap
PIM Data.
2. When prompted, select CF card
where you stored your backup
file.
Tapping Cancel returns you to the
previous screen.
3. Tap the Restore tab.
4. Select the backup file name (tap
the arrow to list down other
backup files, if any).
5. Check the boxes opposite the
items that you wish to restore, or
tap Select All to select all listed
items.
If you checked the box User
Defined Folders, tap Define to
specify the folders that you wish
to restore, then tap OK.
6. Tap Start to begin the restore
process.
7. When the restoration is done, a
message appears prompting you
to reset the device.
8. Tap OK to reset.
2-30
Chapter 2
ASUS Settings
To access the ASUS settings:
1. Tap
, then tap Settings.
2. Tap the System tab on the
bottom of the Settings screen.
3. Tap the ASUS Settings icon to
display the system information
screen. This screen is displayed
whenever you tap the Info tab.
NOTE
Tap the left button of the
four AP keys.
To change the Run Mode:
Tap the Mode tab to display the
running mode of the CPU.
The Turbo Mode allows better CPU
performance. In this mode, the CPU
speed goes up to 400MHz. Set to this
mode when playing games or playing
video. However, setting to Turbo
mode may reduce the battery life.
The Standard Mode allows for up to
300MHz CPU speed. Set to this
mode when listening to MP3 audio
files or for applications that do not
require very fast CPU speed.
The Power Saving Mode sets the CPU to a fixed speed of 200MHz. Set
to this mode when using text based applications such as Word, Excel, etc.
This mode has a lower CPU performance but extends the battery life.
The Automatic Mode allows for 200MHz, 300MHz, or 400MHz CPU
speed depending on the program that you are running.
Check the Advanced Performance Enhancement box to increase
system performance.
Learn the basics
2-31
To change the Display settings:
1. Tap the Display tab.
2. Set the degree of brightness while
on battery power by tapping the
down arrow and selecting a
value, or by dragging the slider
to the left or to the right until you
achieve your desired brightness.
3. Follow step 2 to set the degree of
brightness when using external
power.
You may set the degree of brightness
on battery power and on external
power. Using a lower degree of
brightness while on battery power
substantially reduces battery power
consumption.
To change the Audio settings:
Tap the Audio tab to adjust the
volume, balance, treble, and bass
settings.
Drag the slider to the left or to the
right until you achieve your desired
sound output.
Tap the Default button to restore the
default audio settings.
2-32
Chapter 2
To change the Microphone settings:
Tap the AGC tab to adjust the
settings for the microphone sensitivity
and automatic gain control (AGC).
The AGC features allows you to
adjust the recording and environment
noise level.
•
•
The MIC Sensitivity controls the
sound recording input. Setting the
slider toward the “+” sign allows for
a louder recording, but the
environment noise level may be
louder also.
The Gain Control sets the sound
recording output.
To change the Wakeup Sources:
Tap the Wakeup tab to select the
source wakeup buttons.
Pressing any one of the checked
buttons wakes up the device.
The program assigned to a specific
button appears when you press that
button.
, Settings, and Buttons for
Tap
the button assignments. You may
customize the button assignments.
Learn the basics
2-33
To select Autorun Devices:
Tap the Autorun tab to select the
source devices to execute the
autorun program.
2-34
Chapter 2
Bundled programs
Your device includes the most common Windows programs and more.
To access the bundled programs:
1. Tap
, then tap Programs.
2. Tap any of the icons to launch a
specific application program.
ASUS Programs
Tapping the ASUS Programs icon
displays the ASUS Backup utility. Tap
the ASUS Backup icon if you wish to
use the utility. See section “ASUS
Backup” on page 2-24 for details.
Games
Tap the Games icon to display the
available games.
Learn the basics
2-35
Calculator
Tap the Calculator icon to use the
calculator.
File Explorer
Tap the File Explorer icon to access
your files.
Microsoft Reader
Tap the Microsoft Reader icon to
download and read online books.
2-36
Chapter 2
MSN Messenger
Tap the MSN Messenger icon to use
the service.
Pocket MSN
Tap the Pocket MSN icon to get
connected to the Internet through the
Pocket Internet Explorer.
Pocket Word
Tap the Pocket Word icon to create
Pocket Word documents.
Learn the basics
2-37
Pocket Excel
Tap the Pocket Excel icon to create
spreadsheet documents.
Pictures
Tap the Pictures icon to view .jpg
pictures stored on your device or on
a storage card. Refer to the online
help on your device for details on
using this feature.
Terminal Services Client
Tap the Terminal Services Client icon
to connect to a terminal server. Refer
to the online help on your device for
more information.
2-38
Chapter 2
Chapter 3
Microsoft® ActiveSync®
♦
Introduction ........................................................... 3-2
What is ActiveSync®? ............................................................... 3-2
♦
Installing ActiveSync® ......................................................................... 3-3
Installing ActiveSync® on your computer .................................. 3-3
♦
Synchronizing your device .................................. 3-5
Connecting your device to a computer .................................... 3-5
Setting up a partnership ........................................................... 3-6
Checking synchronized information ......................................... 3-8
Manually initiating synchronization ......................................... 3-9
Synchronization options ......................................................... 3-10
Microsoft® ActiveSync®
3-1
Introduction
What is ActiveSync®?
The Microsoft® ActiveSync® is one of the important bundled programs in
MyPal. With ActiveSync, you can synchronize the information on your
desktop computer with the information on your device. Synchronization
compares the data on your device with your desktop computer and
updates both computers with the most recent information.
For example:
•
•
Keep Pocket Outlook data up-to-date by synchronizing your device with
Microsoft Outlook data on your desktop computer.
Synchronize Microsoft Word and Microsoft Excel files between your
device and desktop computer. Your files are automatically converted to
the correct format.
NOTE
By default, ActiveSync does not automatically synchronize all
types of information. Use the ActiveSync options to turn
synchronization on or off for specific information types.
With ActiveSync, you can also:
•
•
•
•
Back up and restore your device data
Copy (rather than synchronize) files between your device and desktop
computer
Control when synchronization occurs by selecting a synchronization
mode. For example, you can synchronize continually while connected to
your desktop computer or only when you choose to synchronize.
Select which information types are synchronized and control how much
data is synchronized. For example, you can choose to synchronize your
appointments of the past two weeks only, appointments older than two
weeks are not synchronized.
For more information about using ActiveSync:
1. Start ActiveSync on your desktop computer.
2. From the Activesync menu bar, click Help then on Microsoft
ActiveSync Help.
3-2
Chapter 3
Installing ActiveSync®
The ActiveSync program is already installed on your device. To
synchronize information on your device with your computer, you must also
install ActiveSync on your computer. Install ActiveSync from the
Companion CD that came with your product package.
NOTE
Before starting the ActiveSync installation, make sure that
you have Microsoft® Outlook® installed on your computer. If
you do not have Outlook, install the Microsoft® Outlook® 2002
from the Companion CD. Even if you have Outlook 98 or
Outlook 2000 installed, you are encouraged to update to
Outlook 2002.
Installing ActiveSync® on your computer
To install ActiveSync on your computer:
1. Turn on your computer and monitor.
NOTE
Do not connect your device to your computer until you have
finished installing ActiveSync.
2. Insert the Companion CD into the CD-ROM drive of your computer.
The CD autoruns and displays the initial screen, then the Main Menu
from which you can start the installation.
3. Click on Start Here from the Main Menu.
Microsoft® ActiveSync®
3-3
4. Read the Overview before
installing ActiveSync 3.7 to make
sure that you perform the
installation sequence correctly.
5. If you have not installed Outlook,
install it now. Click Install
Outlook 2002 and follow the
screen instructions to complete
the installation.
6. Click Download Connection
Wizard and read the overview to
see if you require the wizard.
Follow the screen instructions to
install the wizard on your
computer. Return to the Main
Menu when done.
7. Click Install ActiveSync 3.7,
then click Install.
8. When prompted, select Run this
program from its current
location then click OK.
9. Follow the succeeding screen
instructions. Click Finish to
complete the installation.
10. Restart Windows when prompted,
then proceed to the next section
to connect your device to your
computer and start
synchronization.
3-4
Chapter 3
Synchronizing your device
Connecting your device to a computer
To connect your device to your computer:
1. Place the device on the cradle.
2. Connect the AC adapter to the power connector on the cradle.
3. Connect the USB sync cable from the cradle to a USB port on your
computer.
To connect your device to
your computer without the
cradle:
1. Connect the traveling USB sync
cable with 26-pin connector to the
26-pin connector at the bottom of
the device.
2. Connect the other end of the cable
to a USB port on your computer.
26-pin connector
Microsoft® ActiveSync®
3-5
Setting up a partnership
Immediately after you have completed the installation, the New
Partnership wizard will start automatically to help you establish a
partnership and customize your synchronization settings. At this point, you
can decide exactly which types of information you would like to
synchronize with your computer.
A partnership is a file that allows you to synchronize your device
with your desktop computer. This file is stored on your desktop
computer. An additional file that enables your desktop computer to
recognize your device is stored on your device.
To set up a partnership:
1. When the New Partnership
screen appears, select Standard
partnership for the type of
partnership to establsih between
your device and your computer.
Click Next.
2. On the next screen, select
Synchronize with the desktop
computer. Click Next.
3. Select the type of information that
you wish to synchronize. Click
Next.
OR
If you wish to customize a
synchronized item, highlight the
item then click Settings.
3-6
Chapter 3
On the Calendar
Synchronization Settings
window, for example, select from
the options how you wish to
synchronize the appointments on
your device with your computer.
Click OK.
4. Click Finish to complete setting a
partnership.
Immediately after you set up a
partnership, ActiveSync® starts
automatically and initiates the first
synchronization between your
device and your computer.
Refer to the succeeding sections
for more details on
synchronization.
Microsoft® ActiveSync®
3-7
Checking synchronized information
After your first synchronization, take a look at Calendar, Contacts, and
Tasks on your device. You will notice that the calendar information in
Microsoft Outlook on your computer was copied to your device, and the
information that you have on your device was copied to your computer.
NOTE
3-8
Open Microsoft Outlook on your desktop computer to see the
details of copied information from your device.
Chapter 3
Manually initiating synchronization
Once you have set up ActiveSync and completed the first synchronization
process, you can initiate synchronization from your device at any time.
To manually initiate synchronization:
1. Tap
, then tap ActiveSync to display the ActiveSync screen.
Connection status
Tap to connect and synchronize
Tap to stop synchronization
Tap to synchronize via IR or
change synchronization settings
2. To start synchronization, make a connection between your device and
your computer, then tap Sync.
To end synchronization, tap Stop.
For more information on synchronization:
Tap
while in the ActiveSync screen, then tap Help.
Microsoft® ActiveSync®
3-9
Synchronization options
The Microsoft ActiveSync program allows you to customize your
synchronization settings at any time. You can select the items to
synchronize, set the synchronization schedule, and specify the
synchronization rules.
To display the synchronization options:
•
•
From the ActiveSync window on your desktop computer, click on the
Options icon, or
From the menu bar, click on Tools, then Options.
To select items to synchronize:
1. Check the box opposite the item
that you wish to synchronize.
2. Highlight a checked item then
click on Settings to specify
synchronization options for the
item.
For example, highlight Calendar
then click on Settings to display
the Calendar Synchronization
Settings window. Customize the
available settings, then click OK
when done.
3. Do the same for the other
checked items.
NOTE: You cannot set the
options for unchecked items.
4. Click OK when done.
3-10
Chapter 3
To set synchronization schedule:
1. Click on the Schedule tab.
2. Select your desired
synchronization schedule.
3. Click OK when done.
To specify synchronization rules:
1. Click on the Rules tab.
2. Select your desired settings from
the available options.
3. Click OK when done.
Microsoft® ActiveSync®
3-11
3-12
Chapter 3
Chapter 4
Microsoft® Pocket Outlook
♦
Introduction ........................................................... 4-2
♦
Calendar ................................................................ 4-2
Creating appointments ............................................................. 4-3
Using the summary screen ...................................................... 4-4
Creating meeting requests ....................................................... 4-4
♦
Contacts ................................................................ 4-5
Creating contacts ..................................................................... 4-6
Using the summary screen ...................................................... 4-6
Finding a contact ...................................................................... 4-7
♦
Tasks ...................................................................... 4-8
Creating tasks .......................................................................... 4-8
Using the summary screen ...................................................... 4-9
♦
Notes .................................................................... 4-10
Creating notes .........................................................................4-11
♦
Inbox .................................................................... 4-12
Synchronizing e-mail messages ............................................ 4-12
Connecting directly to an e-mail server .................................. 4-13
Using the message list ........................................................... 4-14
Composing messages ........................................................... 4-16
Managing e-mail messages and folders ................................ 4-17
Microsoft® Pocket Outlook
4-1
Introduction
Microsoft® Pocket Outlook includes Calendar, Contacts, Tasks, Inbox, and
Notes. You can use these programs individually or together. For example,
e-mail address stored in Contacts can be used to address e-mail
messages in Inbox.
Using ActiveSync®, you can synchronize information in Microsoft Outlook
or Microsoft Exchange on your desktop computer with your device. You
can also synchronize this information directly with a Microsoft Exchange
server. Each time you synchronize, ActiveSync compares the changes you
mode on your device and desktop computer or server and updates both
computers with the latest information. For information on using ActiveSync,
see ActiveSync Help on your desktop computer.
You can switch to any of the Pocket Outlook programs by tapping
.
Calendar: Scheduling appointments
and meetings
Use Calendar to schedule appointments, including meetings and other
events. You can check your appointments in one of several views
(Agenda, Day, Week, Month, and Year) and easily switch views using the
View menu.
Tap to go to Today
Tap to display or edit the
appointment details
Tap to create a new appointment
NOTE
4-2
You can customize the Calendar display, such as changing
the first day of the week, by tapping Options on the Tools
menu.
Chapter 4
Creating appointments
To create an appointment:
1. If you are in Day or Week view, tap your desired date for the
appointment,
2. Tap New.
Tap to select from a predefined text
Tap to select from previously
entered locations
Tap to specify the time of appointment
Tap to specify the date of appointment
Tap to add notes to the appointment
3. Using the input panel, enter a description and a location. Tap first to
select the field.
4. If needed, tap the date and time to change them.
5. Enter other desired information. You will need to hide the input panel to
see all available fields.
6. To add notes, tap the Notes tab. You can enter text, draw, or create a
recording. For more information on creating notes, see the “Notes:
Capturing thoughts and ideas” later in this chapter.
7. When done, tap OK to return to Calendar.
NOTE
If you select Remind me in an appointment, your device will
remind you according to the options set in , Settings,
Personal tab, Sounds and Notifications.
Microsoft® Pocket Outlook
4-3
Using the summary screen
When you tap an appointment in Calendar, a summary screen is
displayed. To change the appointment, tap Edit.
Appointment details
Notes/additional information
on the appointment
Tap to change details of the appointment
Creating meeting requests
You can use Calendar to set up meetings with users of Outlook and
Pocket Outlook. The meeting request will be created automatically and
sent either when you synchronize Inbox or when you connect to your
e-mail server.
To create a meeting request:
1. Tap Tools then Options to indicate how you want meeting requests sent
2. If you send and receive e-mail messages through ActiveSync, select
ActiveSync.
To schedule a meeting:
1. Create an appointment.
2. In the appointment details, hide the input panel, then tap Attendees.
3. From the list of e-mail addresses you have entered in Contacts, select
the meeting attendees.
The meeting notice is created automatically and place in the Outbox
folder. For more information on sending and receiving meeting
requests, see Calendar Help and Inbox Help on the device.
4-4
Chapter 4
Contacts: Tracking friends and
colleagues
Contacts maintains a list of your friends and colleagues so that you can
easily find the information you look for, whether you are at home or on the
road. Using the infrared port (IR) on the device, you can quickly share
Contacts information with other device users.
Tap to select the category of
contacts you want to display
Tap and enter part of a name
to quickly find it on the list
Tap to display or edit the contact details
Tap to display additional phone
numbers and email addresses
Tap an action for a selected contact
Tap to sort contacts by name or company
Tap to create a new contact
NOTE
To change the way information is displayed in the list, tap
Tools then Options.
Microsoft® Pocket Outlook
4-5
Creating contacts
To create a contact:
1. Tap
, then tap Contacts.
2. Tap New to display a blank
contact form.
3. Using the input panel, enter a
name and other contact
information. You will need ot scroll
down to see all available fields.
4. To assign the contact a category,
scroll to and tap Categories, then
select a category from the list. On
the contact list, you can display
the contacts by category.
5. To add notes, tap the Notes tab. You can enter text, draw, or create a
recording. For more information on creating notes, see “Notes:
Capturing thoughts and ideas” later in this chapter.
6. Tap OK to return to the contact list when done.
Using the summary screen
Tapping a contact on the contact list displays a summary screen. To
change the contact information, tap Edit.
Contact details
Tap to display notes
Tap to change contact information
4-6
Chapter 4
Finding a contact
There are four ways to find a contact.
1. On the contact list, enter a contact
name in the box under the
navigation bar. To show all contacts
again, clear text from the box or tap
the button to the right of the box.
2. In the contact list, tap the category
list (labeled All Contacts by
default) and select the type of
contact that you wish to display. To
show all contacts again, select All
Contacts. To view a contact not
assigned to a category, select
None.
3. To view the names fo companies
your contacts work for, in the
contact list, tap View > By
Company. The number of contacts
that work for that company will be
displayed to the right of the
company name.
1
2
3
, Find, enter the contact
4. Tap
name, select Contacts for the type,
and tap Go.
Microsoft® Pocket Outlook
4
4-7
Tasks: Keeping a to do list
Use Tasks to keep track of what you have to do.
Tap to select the category of
tasks you want to display
Tap to select a sort
order of the task list
Indicates high priority
Tap to display or edit
the task details
Tap and hold to display a
pop-up menu of actions
Tap an action for the task
Tap to create a new task
Creating tasks
To create a task:
1. Tap
, then tap Tasks.
2. Tap New to display a blank task
form.
3. Using the input panel, enter a
description.
4. Enter a start date and due date,
or enter other information by
tapping the field first. If the input
panel is open, you will need to
hide it to see all available fields.
4-8
Chapter 4
5. To assign the task to a category, tap Categories and select a category
from the list. On the task list, you can display tasks by category.
6. To add notes, tap the Notes tab. You can enter text, draw, or create a
recording. For more information on creating notes, see “Notes:
Capturing thoughts and ideas” later in this chapter.
7. Tap OK to return to the task list when done.
TIP
To quickly create a task with
only a subject, tap Entry Bar on
the Tools menu. Tap Tap here
to add a new task and enter
your task information.
Using the summary screen
Tapping a task on the task list displays a summary screen. To change the
task details, tap Edit.
Task details
Tap to show or hide the task details
Notes/additional information on the task
Tap to change the task details
Microsoft® Pocket Outlook
4-9
Notes: Capturing thoughts and
ideas
Quickly capture thoughts, reminders, ideas, and phone numbers with
Notes. You can create a written note or a recording. You can also include a
recording in a note. If a note is open when you create the recording, it will
be included in the note as an icon. If the note is displayed, it will be
created as a stand-alone recording.
Tap to change the sort order of the list
Tap to open a note or play a recording
Tap and hold to display a
pop-up menu of actions
Tap an action for the item
Tap to record
Tap to show or hide the recording toolbar
Tap to create a new note or recording
You may change the default Notes options including the writing mode,
template, file storage, and record button action.
To change the Notes options:
1. Tap
, then tap Notes.
2. Tap Tools, then Options... to
display the options screen.
3. Make your desired changes.
4. Click OK.
4-10
Chapter 4
Creating notes
To create a note:
1. Tap
, then tap Notes.
2. Tap New to display a blank note.
3. Create your note by writing, drawing, typing, or recording. For more
information about using the input panel, writing and drawing on the
screen, and creating recordings, see Chapter 2.
Tap to save the note and
return to the note list
Tap to show or hide
the input panel
Tap to write on the screen
Tap to add a recording to the note
Microsoft® Pocket Outlook
4-11
Inbox: Sending and receiving e-mail
messages
Use Inbox to send and receive e-mail messages in one of these ways:
•
•
Synchronize e-mail messages with Microsoft Exchange of or Microsoft
Outlook on your desktop computer
Send and receive e-mail messages by connecting directly to an e-mail
server through an Internet service provider (ISP) or a network
Synchronizing e-mail messages
E-mail messages can be synchronized as part of the general
synchronization process. You will need to enable Inbox synchronization in
ActiveSync. For more information on enabling Inbox synchronization, see
ActiveSync Help on your desktop computer.
During synchronization:
•
•
•
Messages are copied from the mail folders of Exchange or Oultook on
your desktop computer to the ActiveSync folder in Inbox on your device.
By default, you will receive messages from the past three days only, the
first 100 lines of each message, and file attachments of less than 100KB
in size.
E-mail messages in the Outbox folder on your device are transferred to
Exchange or Outlook, then send from those programs.
E-mail messages in subfolder must be selected in ActiveSync on your
desktop computer in order to be transferred.
NOTE
4-12
You can also synchronize e-mail messages with your desktop
computer from a remote location. For more information, see
Chapter 7.
Chapter 4
Connecting directly to an e-mail server
In addition to synchronizing e-mail messages with your desktop computer,
you can send and receive e-mail messages by connecting to an e-mail
server using a modem or network card connected to your device. You
need to set up a remote connection to a network or an ISP, and a
connection to your e-mail server. For more information, see Chapter 7.
When you connect to the e-mail server, new messages are downloaded to
the device Inbox folder, messages in the device Outbox folders are sent,
and messages that have been deleted on the e-mail server are removed
from the device Inbox folder.
Messages that you receive directly from an e-mail server are linked to your
e-mail server rather than your desktop computer. When you delete a
message on your device, it is also deleted from the e-mail server the next
time you connect based on the settings you selected in ActiveSync.
You can work online or offline. When working online, you read and
respond to messages while connected to the e-mail server. Messages are
sent as soon as you tap Send, which saves space in your device.
When working offline, once you have downloaded new message headers
or partial messages, you can disconnect from the e-mail server and decide
which messages to download completely. The next time you connect,
Inbox downloads the complete messages you have marked for retrieval
and sends the messages you have composed.
Microsoft® Pocket Outlook
4-13
Using the message list
The messages you receive are displayed in the message list. By default,
the most recently received messages are displayed first in the list.
Tap to select the service, and the
folder that you wish to display
Tap to select the sort order
for the messages
Tap and hold to display a
pop-up menu of actions
Tap to connect, and to send/receive e-mail
Tap to connect to the selected service
When you receive a message, tap it to open it. Unread messages are
displayed in bold.
Tap to return to the message list
Tap to delete this message
Tap to reply to or forward this message
Tap to view the next message
Tap to view the previous message
4-14
Chapter 4
When you connect to your e-mail server or synchronize with your desktop
computer, by default, you will receive messages from the last five days
only, the first 100 lines of each new messages, and file attachments of less
than 100KB in size. The original messages remain on the e-mail server or
your desktop computer.
You can mark the messages that you want to retrieve in full during your
next synchronization or e-mail server connection. In the message list, tap
and hold the message that you want to retrieve. On the pop-up menu, tap
Mark for Download. The icons in the Inbox message list give you visual
indications of message status.
You can specify your downloading preferences when you set up the
service or select your synchronization options. You can change them at
any time.
•
•
Change options for Inbox synchronization using ActiveSync options. For
more information, see ActiveSync Help on your desktop computer.
Change options for direct e-mail server connections in Inbox on your
device. Tap Tools then Options. On the Service tab, tap the service that
you wish to change. Tap and hold the service and select Delete to
remove a service.
Microsoft® Pocket Outlook
4-15
Composing messages
To compose a message:
1. Tap New.
2. In the To field, enter an e-mail or SMS address of one or more
recipients, separating them with a semicolon, or select a name from
the Contacts list by tapping the Address Book button. All e-mail
addresses entered in the e-mail fields in Contacts appear in the
Address Book.
Tap to send the message
Tap to show or hide the
complete message header
Tap to show or hide the recording toolbar
Tap to display the e-mail address book
Tap to select a preset message
3. Compose your message. To enter
preset or frequently used
messages, tap My Text and
select a message.
4. Tap Send when you have finished
the message. If you are working
offline, the message is moved to
the Outbox folder and will be sent
the next time you connect.
4-16
Chapter 4
Managing e-mail messages and folders
The behavior of the folders you create depends on whether you are using
ActiveSync, SMS, POP3, or IMAP4.
•
•
•
•
If you use ActiveSync, e-mail messages in the Inbox folder in Outlook will
automatically be sunchronized with your device. You can select to
synchronize additional folders by designating them for ActiveSync. The
folders you create and the messages you move will then be mirrored on
the server. For example, if you move two messages from the Inbox folder
to a folder named Family, and you have designated Family for
synchronization, the server creates a copy of the Family folder and
copies the messages into that folder. You can then read messages while
away from your desktop computer.
If you use SMS, messages are stored in the Inbox folder.
If you use POP3 and you move e-mail messages to a folder you created,
the link is broken between the messages on the device and their copies
on the mail server. The next time you connect, the mail server will see
that the messages are missing from the device Inbox and delete them
from the server. This prevents you from having duplicate copies of a
message, but it also means that you will no longer have access to
messages that you move to folders created from anywhere except the
device.
If you use IMAP4, the folders you create and the e-mail messages you
move are mirrored on the server. Therefore, messages are available to
you anytime you connect to your mail server, whether it is from your
device or desktop computer. This synchronization of folders occurs
whenever you connect to your mail server, create new folders, or
rename/delete folders when connected.
Microsoft® Pocket Outlook
4-17
4-18
Chapter 4
Chapter 5
Companion programs
♦
Pocket Word .......................................................... 5-2
Creating Pocket Word documents ........................................... 5-3
Saving Pocket Word documents .............................................. 5-3
Modes of entering information ................................................. 5-5
♦
Pocket Excel ......................................................... 5-8
Creating Pocket Excel documents ........................................... 5-9
Saving Pocket Excel documents .............................................. 5-9
Securing your Excel document ...............................................5-11
Tips for working in Pocket Excel ............................................ 5-12
♦
MSN Messenger .................................................. 5-13
Setting up ............................................................................... 5-13
Working with contacts ............................................................ 5-14
Chatting with contacts ............................................................ 5-15
♦
Windows Media Player for Pocket PC .............. 5-16
♦
Microsoft Reader ................................................ 5-17
Getting books on your device ................................................ 5-17
Using the Library .................................................................... 5-18
Reading a book ...................................................................... 5-19
Using Reader features ........................................................... 5-20
Removing a book ................................................................... 5-20
Companion programs
5-1
The companion programs consist of Microsoft® Pocket Word, Microsoft®
Pocket Excel, Microsoft® Money, Windows Media™ Player for Pocket PC,
and Microsoft® Reader.
To switch to a companion program on your device, tap Programs on the
menu, then tap the program that you wish to open.
Pocket Word
Pocket Word works with Microsoft Word on your desktop computer to give
you easy access to copies of your documents. You can create new
documents on your device, or you can copy documents from your desktop
computer to your device. Synchronize documents between your desktop
computer and your device so that you have the most up-to-date content in
both locations.
Use Pocket Word to create documents, such as letters, meeting minutes,
and trip reports.
Creating Pocket Word documents
To create a new Word document:
1. Tap
, tap Programs, tap
Pocket Word to launch the
application.
If you have existing Microsoft
Word or Pocket Word documents
in your device, a list of the
documents appears.
NOTE
5-2
If you selected a template for new documents in the Options
dialog box, that template appears with the appropriate text
and formatting already provided.
Chapter 5
2. Tap New to display a blank document.
3. Use any of the tools in the input panel to type your text.
Tap to save and close your document
Type your text here
Formatting toolbar
Tap to select an input method
Tap to show or hide the input panel
Tap to show or hide the formatting toolbar
Saving Pocket Word documents
To save a Pocket Word document:
When you have finished editing your document, tap OK.
The document is saved using the first line as file name if you did not
specify a file name. For example, if your first line in the document has
the words Bits-n-Pieces, these words appear in your Word documents
list.
Companion programs
5-3
To specify save options:
1. With the document open, tap
Tools.
2. From the pop-up menu, tap Save
Document As... to display the
Save As screen.
3. Change the file name by simply
typing a new one in the Name
field.
4. Tap the down arrow in the Folder
field to select a folder where you
wish to place the file.
5. Tap the down arrow in the Type field to select a file format.
You can save the document you create or edit in a variety of formats:
• Word (.doc)
• Pocket Word (.psw)
• Rich Text Format (.rtf)
• Plain Text (.txt)
6. Tap the down arrow in the Location field to indicate the location of
your saved file, either in the main memory of your device, or in a
storage card, if available.
7. Tap OK when done.
NOTE
5-4
If you do not wish to change the document format, but would
like to change the file name, folder, and location of your
document, simply tap Edit from the command bar, then tap
Rename/Move... from the pop-up menu to make your
changes.
Chapter 5
Opening an existing Pocket Word document
Pocket Word contains a list of the files stored on your device. Tap a file in
the list to open. To delete, make copies of, and send files, tap and hold a
file in the list, then select the appropriate action on the pop-up menu.
Tap to select the folder you want to display
Tap to change the sort order of the list
Tap to open a document
Tap to change document settings
Tap to create a new document
NOTE
You can open only one Pocket Word document at a time;
when you open a second document, you will be asked to
save the first.
Companion programs
5-5
Modes of entering information
You can enter information in Pocket Word in one of four modes (typing,
writing, drawing, or recording), which are displayed on the View menu.
Each mode has its own toolbar that you can show or hide by tapping the
Show/Hide Toolbar button on the command bar.
If you are opening a Word document created on a desktop computer,
select Wrap to Window on the View menu so that you can see the entire
document.
To change the zoom magnification:
1. Tap View, then tap Zoom.
2. Select your desired percentage.
Select a higher percentage to enter text and lower one to see more of
your document.
Typing Mode
Using the input panel, enter typed text into the document. For more
information on entering typed text, see Chapter 2.
To format existing text and to edit text, first select the text. You can select
text as you do in a Word document, using your stylus instead of the mouse
to drag through the text you want to select. You can search a document to
find text by tapping Edit and Find/Replace.
5-6
Chapter 5
Writing mode
In writing mode, use your stylus to write directly on the screen. Ruled lines
are displayed as a guide, and the zoom magnification is greater than in
typing mode to allow you to write more easily. For more information on
writing and selecting writing, see Chapter 2.
Write your text here
With the Space button selected,
drag to insert space. An arrow
appears showing the space
direction direction and size.
Space button
Pen button
Tap to show or hide the writing/formatting toolbar
Tap to wrap text to screen
Tap to display zoom percentages
Tap to display the menu
NOTE
If you cross three ruled lines in a single stylus stroke, the
writing becomes a drawing, and can be edited and
manipulated as described in the next section.
Written words are converted to graphics (metafiles) when a
Pocket Word document is converted to a Word document on
your desktop computer.
Companion programs
5-7
Drawing mode
In drawing mode, use your stylus to draw on the screen. Gridlines appear
as a guide. When you lift your stylus off the screen after ther first stroke,
you will see a drawing box indicating the boundaries of the drawing. Every
subsequent stroke within or touching the drawing box becomes part of the
drawing. For more information on drawing and selecting drawings, see
Chapter 2.
Resize an object by dragging
the selection handles
Tap to select the formatting options
Drawing toolbar
Tap to show or hide the drawing toolbar
Tap an arrow to display the options
Pen button
Recording mode
In recording mode, embed a
recording into your document.
Recordings are saved as .wav files.
For more information on recording,
see Chapter 2.
Embedded recording
5-8
Chapter 5
Pocket Excel
Pocket Excel works with Microsoft Excel on your desktop computer to give
you easy access to copies of your workbooks. You can create new
workbooks on your device, or you can copy workbooks from your desktop
computer to your device. Synchronize workbooks between your desktop
computer and your device so that you have the most up-to-date contents
in both locations.
Use Pocket Excel to create workbooks, such as expense reports and
mileage logs.
Pocket Excel contains a list of the files stored on your device. Tap a file in
the list to open. To delete, make copies of, and send files, tap and hold a
file in the list, then select the appropriate action on the pop-up menu.
Pocket Excel provides fundamental spreadsheet tools, such as formulas,
functions, sorting, and filtering. To display the toolbar, tap View, then tap
Toolbar.
Cell contents appear here as you
type, or when you select the cell
Format button
AutoSum button
Zoom button
NOTE
You can open only one Pocket Excel document at a time;
when you open a second document, you will be asked to
save the first.
Companion programs
5-9
Creating Pocket Excel documents
To create a new Excel document:
1. Tap
, tap Programs, tap
Pocket Excel.
2. Tap New to display a blank
document.
If you selected a template for new
documents in the Options dialog
box, that template appears with
the appropriate text and
formatting already provided.
Saving Pocket Excel documents
To save an Excel document:
When you have finished editing your document, tap OK.
By default, your document is saved as Book1 as file name. You can
change the file name to one that is more descriptive of your document.
See next section for saving options.
5-10
Chapter 5
To specify save options:
1. With the document open, tap
Tools.
2. From the pop-up menu, tap Save
Workbook As... to display the
Save As screen.
3. Change the file name by simply
typing a new one in the Name
field.
4. Tap the down arrow in the Folder
field to select a folder where you
wish to place the file.
5. Tap the down arrow in the Type field to select a file format.
You can save the document you create or edit in a variety of formats:
• Pocket Excel (.pxl)
• Excel (.xls)
6. Tap the down arrow in the Location field to indicate the location of
your saved file, either in the main memory of your device, or in a
storage card, if available.
7. Tap OK when done.
NOTE
If you do not wish to save your workbook to a different format,
but would like to change the file name, folder, and location of
your document, simply tap Edit from the command bar, then
tap Rename/Move... from the pop-up menu to make your
changes.
Companion programs
5-11
Securing your Excel document
If your workbook contains sensitive or confidental information, you can
protect it with a password.
To set a password for your workbook:
1. Open the workbook.
2. Tap Edit from the command bar,
then tap Password... to display
the password setting screen.
3. Type a password in the
Password field.
4. Re-type the password in the
Verify Password field.
5. Tap OK when done.
If you have set a password for your
workbook, a password screen
appears asking you to type your
password whenever you try to open
the workbook.
Type your password, then tap OK. If
you type in a wrong password, a
message appears telling you so.
NOTE
5-12
DO NOT forget your password. You can not open your
workbook unless you type in the correct password.
Chapter 5
Tips for working in Pocket Excel
Take note of the following when working in large worksheets in Pocket
Excel:
•
•
•
•
•
View in full-screen mode to see as much of your worksheet as
possible. Tap View, then tap Full Screen. To exit full-screen mode, tap
Restore.
Show and hide window elements. Tap View, then tap the elements to
show or hide.
Freeze panes on a worksheet. First select the cell where you want to
freeze panes. Tap View, then tap Freeze Panes. You might want to
freeze the top and leftmost panes in a worksheet to keep row and
column labels visible as you scroll through a sheet.
Split panes to view different areas of a large worksheet. Tap View, then
tap Split. Drag the split bar to where you want it. To remove the split, tap
View, then tap Remove Split.
Show and hide rows and columns. To hide a row or column, select a
cell in the row or column that you want to hide. Tap Format, then tap
Row or Column, and tap Hide. To show a hidden row or column, tap
Tools, then tap Go To, and type a reference that is in the hidden row or
column. Tap Format, then tap Row or Column, and tap Unhide.
For more information on using Pocket Excel, tap
Companion programs
, then tap Help.
5-13
MSN Messenger
MSN Messenger on your device is an instant messaging program that
allows you to:
•
•
•
See who is online
Send and receive instant messages
Have instant message conversations with groups of contacts
To use MSN Messenger:
You must have a Microsoft Passport™ account or a Microsoft
Exchange e-mail account.
You must have a Passport to use the MSN Messenger Service. If you
have a Hotmail® or MSN account, you already have a passport. Once you
have obtained either a Microsoft Passport or Microsoft Exchange account,
you are ready to set up your account.
Sign up for a Microsoft Passport account at http://www.passport.com.
Get a free Microsoft Hotmail e-mail address at http://www.hotmail.com.
To launch MSN Messenger:
1. Tap
, then tap Programs.
2. Tap MSN Messenger.
5-14
Chapter 5
Signing up
To sign in to MSN Mesenger service:
1. Tap Tools then tap Sign in... from
the menu.
OR
Simply tap the Tap here to sign
in area.
2. In the sign-in screen, enter your
e-mail address and password.
Tap Sign In.
NOTE
If you already use MSN Messenger on your desktop
computer, your contacts will show up on your device without
being added again.
Companion programs
5-15
Working with contacts
The MSN Messenger window shows all of your messenger contacts at a
glance, divided into Online and Not Online categories. From this view,
while connected, you can chat, send an e-mail, block the contact from
chatting with you, or delete contacts from your list using the pop-up menu.
To see others online without being seen, tap My Status in the Tools menu
and select Appear Offline.
If you block a contact, you will appear offline but will remain on the blocked
contact’s list. To unblock a contact, tap and hold the contact, then tap
Unblock on the pop-up menu.
5-16
Chapter 5
Chatting with contacts
Tap a contact name to open a chat window. Enter your message in the text
entry area at the bottom of the screen, or tap My Text to enter a preset
message, then tap Send. To invite another contact to a multi-user chat, tap
Invite in the Tools menu, then tap the contact that you want to invite.
NOTE
To switch back to the main window without closing a chat, tap
the Contacts button. To go back to your chat window, tap
Chats and select the person whom you were chatting with.
To know if the contact you are chatting with is responding, look for the
message under the text entry area. For more information on using MSN
Messenger, tap
, then tap Help.
Companion programs
5-17
Windows Media Player for Pocket PC
Use Microsoft® Windows Media Player for Pocket PC to play digital audio
and video files that are stored on your device or on a network. To switch to
Windows Media Player for Pocket PC, tap
, tap Programs, then tap
Windows Media.
Indicates the progress
of the current track
Slide to adjust volume
Tap to mute sound
Tap to play the next track
Tap to play the previous track
Tap to stop
Tap to play or pause
Use Microsoft Windows Media Player on your desktop computer to copy
digital audio and video to your Pocket PC. You can play Windows Media
and MP3 files on your Pocket PC.
For more information on using Windows Media Player for Pocket PC, tap
, then tap Help.
5-18
Chapter 5
Microsoft Reader
Use Microsoft Reader to read eBooks on your device. Download books to
your desktop computer from your favorite eBook web site. Then, use
ActiveSync to copy the book files to your activated device. The books
appear in the Reader Library.
Each book consists of a cover page, an optional table of contents, and the
pages of the book. You can:
•
Page through the book using the Up/Down control on your device, or by
tapping the page number on each page.
• Annotate the book with highlighting, bookmarks, notes, and drawings.
• Search for text and look up definitions for words.
The Guidebook contains all the information that you need to use the
software. To open the Guidebook, tap Help on the Reader command bar.
Or, on a book page, tap and hold on the book title, then tap Help on the
pop-up menu.
To launch Microsoft Reader:
1. Tap
, then tap Programs.
2. Tap Microsoft Reader.
Companion programs
5-19
Getting books on your device
You can download book files from the Web. Just visit your favorite eBook
retailer and follow the instructions to download the book files.
Sample books and a dictionary ar also included in the MSReader folder in
the Extras folder on the Pocker PC Companion CD.
Use ActiveSync to download the files from your desktop computer to your
activated device as described in the Read Me file in the MSReader folder.
Using the Library
The Library is your Reader home page. It displays a list of all books stored
on your device or storage card.
To open the library:
1. On the Reader command bar, tap Library.
2. On a book page, tap the book title, then tap Library on the pop-up
menu.
To open a book, tap its title in the Library list.
Tap to scroll through
the Library list
Tap to select
a sort order
Tap to search books
by author or title
A list of books you
have stored appears
here
Tap to navigate to
other parts of the
Reader
5-20
Chapter 5
Reading a book
Each book consists of a cover page, and optional table of contents, and
the pages of the book. Navigation options are listed in the bottom portion
of the cover page.
The first time you open a book, you will probably want to go to the first
page or to the table of contents, if there is one. Subsequently, whenever
you open a book, you will be automatically taken to the last page read.
In addition to the text, each book page includes a page number and the
book title.
You can also page through a book using the Up/Down control on your
device.
Companion programs
5-21
Using Reader features
Reading a book electronically gives you several options not available with
paper books. These options are available from any book page.
Select text by dragging across the text on the page. Then, tap an option on
the pop-up menu, as described below.
•
•
•
•
•
•
Search for Text. Find text in a book by tapping Find on the pop-up
menu. Enter the word you want to search for, and tap the desired Find
option. Reader highlights found text on the page. To close Find, tap
outside the box. To return to your original page, tap the title then tap
Return on the pop-up menu.
Copy Text. You can copy text form books that support this feature into
any program that accepts text. On a book page, select the text that you
want to copy. Then, tap Copy Text on the pop-up menu. The text can be
pasted into the program of your choice.
Bookmarks. When you add a bookmark to a book, a color-coded
bookmark icon appears on the right margin. You can add multiple
bookmarks to a book. Then, from anywhere in the book, tap the
bookmark icon to go to the bookmarked page.
Highlights. When you highlight text, it appears with a colored
background.
Notes. When you attach a note to text, you enter the text in a note pad
that appears on top of the book page. A Note icon appears on the left
margin. To show or hide the note, tap the icon.
Drawings. When you add a drawing, a Drawing icon appears on the
bottom-left corner of the page, and drawing tools appear across the
bottom of the page. Draw by dragging your stylus.
NOTE
To see a list of a book’s annotations, including bookmarks,
highlights, text notes, and drawings, tap Annotations Index
on the book’s cover page. You can tap an entry in the list to
go to the annotated page.
Removing a book
When you finish reading a book, you can delete it to conserve space on
your device. If a copy of the book is stored on your desktop computer, you
can download it again at any time.
To remove a book from your device, tap and hold the title in the Library list,
then tap Delete on the pop-up menu.
5-22
Chapter 5
Chapter 6
Pocket Internet Explorer
♦
Introduction ........................................................... 6-2
♦
Using Pocket Internet Explorer ........................... 6-2
Changing View settings ...................................................... 6-3
Browsing the Internet ......................................................... 6-3
♦
AvantGo Channels................................................ 6-4
♦
Mobile Favorites folder ........................................ 6-5
Favorite links ...................................................................... 6-5
Mobile Favorites ................................................................. 6-5
Viewing mobile favorites and channels .............................. 6-7
Adding/Deleting mobile favorites and folders ..................... 6-8
Pocket Internet Explorer
6-1
Introduction
Use Microsoft Pocket Internet Explorer to view Web or WAP pages in any
of these ways.
•
During synchronization with your desktop computer, download your
favorite links and mobile favorites that are stored in the Mobile Favorites
sub-folder in the Internet Explorer on the desktop computer.
• Connect to an Internet service provider (ISP) or network and browse the
Web. To do this, you need to create the connection first. See Chapter 7
for information on creating a connection.
When connected to an ISP or network, you can also download files and
programs from the Internet or intranet.
Using Pocket Internet Explorer
You can use Pocket Internet Explorer to browse mobile favorites and
channels that have been downloaded to your device without connecting to
the Internet. You can also connect to the Internet through an ISP or a
network connection to browse the Web.
To launch Pocket Internet Explorer:
1. Tap
, then Internet Explorer
to display the Pocket MSN
services.
New Pocket MSN services
Tap to go back to previous page
Tap to stop/refresh
Tap to go to Pocket Internet Explorer home
Tap to launch Favorites
6-2
Chapter 6
2. Tap the Home button to display
the Pocket Internet Explorer
welcome screen with links to
some useful Web sites.
3. Tap any of the Web site buttons to
go to a specific site.
Changing View settings
To change View settings:
1. Tap View to display a pop-up
menu.
2. Tap Fit to Screen to see all the
screen items at the same time.
3. Tap Address Bar to display the
Web site address bar.
4. Tap and hold Text Size to display
another pop-up menu with a text
size selection. Select your desired
text size for the screen.
Browsing the Internet
To browse the Internet:
1. Set up a connection to your ISP or corporate network using
Connections. See Chapter 7 for details.
2. Do one of the following to connect and start browsing:
• Tap the Favorites button, then tap the favorite that you wish to view.
•
Tap View, then Address Bar. Enter the Web address that you want
to visit then tap Go.
Pocket Internet Explorer
6-3
AvantGo Channels
AvantGo is a free interactive service that gives you access to personalized
content and thousands of popular Web sites. You subscribe to AvantGo
channels directly from your device. Then, synchronize your device and
desktop computer, or connect to the Internet to download the content.
For more information, visit the AvantGo web site at http://avantgo.com/
To activate AvantGo:
1. In the ActiveSync window on your
desktop computer, click Options.
2. In the Sync Options tab, check
the box beside the AvantGo item.
Click OK.
ActiveSync automatically updates
the settings and synchronizes
with your device.
NOTE
Make sure that your computer is connected to the Internet.
3. When synchronization is
complete, the AvantGo home
page appears on your device.
To launch AvantGo:
1. In Pocket Internet Explorer on
your device, tap the Favorites
button to display your list of
favorites.
2. Tap the AvantGo Channels link
to go directly to the AvantGo
home page and see a few of the
most popular channels.
To add or remove channels:
Tap the Add or Remove link.
6-4
Chapter 6
The Mobile Favorites folder
Only items items stored in the Mobile Favorites sub-folder in the Favorites
folder in the Internet Explorer on your desktop computer will be
synchronized with your device. This folder was created automatically when
you installed ActiveSync.
Favorite links
During synchronization, the list of favorite links in the Mobile Favorites
folder on your desktop computer is synchronized with Pocket Internet
Explorer on your device. Both computers are updated with changes made
to either list each time you synchronize. Unless you mark the favorite link
as a mobile favorite, only the link will be downloaded to your device, and
you will need to connect to your ISP or network to view the content. For
more information on synchronization, see ActiveSync Help on the desktop
computer.
Mobile Favorites
If you are using Microsoft Internet Explorer 5.0 or later on your desktop
computer, you can download mobile favorites to your device.
Synchronizing mobile favorites downloads Web content to your device so
that you can view pages while you are disconnected from your ISP and
desktop computer.
Use the Internet Explorer plug-in installed with ActiveSync to create mobile
favorites quickly.
Pocket Internet Explorer
6-5
To create a mobile favorite:
1. In Internet Explorer on your desktop
computer, click Tools then Create
Mobile Favorite.
2. To change the link name, enter a new
name in the Name box.
3. Select your desired update schedule
in Update. This is optional.
4. Click OK. Internet Explorer downloads
the latest version of the page to your
desktop computer.
5. If you want to download the pages that
are linked to the mobile favorite you
just created, in Internet Explorer on the
desktop computer, right-click the
mobile favorite, then click Properties.
In the Download tab, specify the
number of links deep you want to
download. To conserve device
memory, go only one level deep.
6. Synchronize your device and your
desktop computer. Mobile favorites that
are stored in the Mobile Favorites in
Internet Explorer are downloaded to
your device.
NOTE
If you did not specify an update schedule in step 3, you will
need to manually download content to keep the information
updated on your desktop computer and device. Before
synchronizing with your device, in Internet Explorer on your
desktop computer, click Tools then Synchronize. You will
see the last time content was downloaded to the desktop
computer, and you can manually download content if needed.
You can add a button to the Internet Explorer toolbar for
creating mobile favorites. In Internet Explorer on your desktop
computer, click View, Toolbars, and Customize.
6-6
Chapter 6
Saving device memory
Mobile favorites take up storage memory on your device. To minimize the
amount of memory used:
•
•
In the settings for the Favorites information type in ActiveSync options,
turn off pictures and sounds, or stop some mobile favorites from being
downloaded to the device. For more information, see ActiveSync Help.
Limit the number of downloaded linked pages. In Interner Explorer on
your desktop computer, right-click the mobile favorite you want to
change, then click Properties. In the Download tab, specify 0 or 1 for
the number of linked pages you want to download.
Viewing mobile favorites and channels
To view mobile favorites and channels:
1. Tap
to display your list of favorites.
Tap the favorite that
you wish to view
Tap to add or delete a
folder or favorite link
2. Tap a Favorites page that you wish to view.
You will see the page that was downloaded the last time you
synchronized with your desktop computer. If the page is not on your
device, the favorite is dimmed. You need to synchronize with your
desktop computer again to download the page to your device, or
connect to the Internet to view the page.
Pocket Internet Explorer
6-7
Adding/Deleting mobile favorites and folders
To add a favorite:
1. Tap
to display your list of
favorites.
2. Tap the Add/Delete button to
display the Favorites screen.
3. Tap the Add... button to show the
Add Favorite screen.
4. Type a name for the favorite that
you wish to add in the Name field.
5. Type in the URL address in the
Address (URL) field.
6. Select a folder to place the
favorite from the Create in: box.
7. Tap Add to return to the Favorites
screen, which now shows the
favorite that you added.
To delete a favorite:
1. Tap
to display your list of
favorites.
2. Tap the Add/Delete button to
display the Favorites screen.
3. Select the favorite that you wish
to delete, then tap Delete.
4. When prompted to permanently
delete the favorite, tap Yes.
6-8
Chapter 6
To add a folder:
1. Tap
to display your list of
favorites.
2. Tap the Add/Delete button to
display the Favorites screen.
3. Tap the New Folder button.
4. Type a name for the folder that
you wish to create.
5. Tap Add to return to the Favorites
screen, which now shows the
folder that you added.
To delete a folder:
1. Tap
to display your list of
favorites.
2. Tap the Add/Delete button to
display the Favorites screen.
3. Select the folder that you wish to
delete, then tap Delete.
4. When prompted to permanently
delete the folder, tap Yes.
Pocket Internet Explorer
6-9
6-10
Chapter 6
Chapter 7
Get connected
♦
Introduction ........................................................... 7-2
♦
Connect to the Internet ........................................ 7-2
♦
Connect to Work ................................................... 7-3
♦
Set up connections .............................................. 7-3
Modem connections ................................................................. 7-3
VPN server connections .......................................................... 7-4
Proxy server settings ............................................................... 7-4
Network card connections ........................................................ 7-5
Wireless network connections ................................................. 7-6
Enter settings information ........................................................ 7-6
Configure authentication settings ............................................. 7-7
Change connection settings name ........................................... 7-7
♦
End a connection .................................................. 7-8
♦
Set up a WAP gateway ......................................... 7-8
♦
Use dialing rules ................................................... 7-9
♦
Infrared (IR) connection ..................................... 7-10
Sending information ................................................................7-11
Receiving information .............................................................7-11
♦
Bluetooth connection ......................................... 7-12
Bluetooth modes .................................................................... 7-12
Bluetooth settings .................................................................. 7-13
Making your device discoverable ........................................... 7-13
Beaming information with Bluetooth ...................................... 7-14
Receiving a Bluetooth beam .................................................. 7-14
Get connected
7-1
Introduction
You can set up connections to the Internet and corporate network at work
in order to do such activities as browse the Internet or intranet, send and
receive e-mail and instant messages, and synchronize information using
ActiveSync.
Connections can be made using a modem, wireless network, or
network (Ethernet) card. A modem connection can be used to set up
connections with an external modem, or through your mobile phone
network using a cellular line.
Your device has two groups of connection settings: My ISP and My Work
Network. My ISP settings are used to connect to the Internet, and My
Work Network settings can be used to connect to any private network,
such as a corporate network you use at work. Simply fill in the settings and
get ready to start connecting. For more information, see the sections
“Connect to the Internet” or “Connect to Work.”
You may also establish connection to another device with infrared (IR) or
Bluetooth features. For more information, see sections “Infrared (IR)
connection” or “Bluetooth connection.”
Connect to the Internet
To connect to the Internet:
1. Obtain the following information from your ISP: ISP server phone
number, user name, and password.
> Settings > Connections tab > Connections.
2. Tap
3. In My ISP, tap Add a new modem connection.
4. Create a modem connection. For more information, see section “Set
up modem connections.”
5. To start the connection, begin using the desired program. For example,
switch to Pocket Internet Explorer and browse a Web page. Your
device automatically connects.
NOTE
7-2
To set up a network card or wireless network connection to
your ISP, add a new connection under My Work Network.
Chapter 7
Connect to Work
1. Obtain the following information from your network administrator:
server phone number, user name, and password.
> Settings > Connections tab > Connections.
2. Tap
3. In My Work Network, set up either a modem, network card, wireless
network, or VPN server connection. Refer to the section “Set up
connections” for the procedure.
4. To start the connection, start using a desired program. For example,
switch to Pocket Internet Explorer and browse to a Web page. Your
device automatically starts connecting.
Set up connections
Modem connections
To set up a modem connection:
Obtain the following information from your ISP or network administrator:
telephone number, user name, password, domain name, and TCP/IP
settings.
If your device does not have access to a mobile phone network, insert a
modem card.
> Settings > Connections tab > Connections.
1. Tap
2. To create a new connection, in either My ISP or My Work Network,
tap Add a new modem connection, then follow the instructions in the
New Connection wizard.
3. To view additional information for any screen in the wizard or while
changing settings, tap
NOTE
.
To change modem connection settings in either My ISP or My
Work Network, tap Manage existing connections. Select
the desired modem connection, tap Settings, and follow the
instructions on the screen.
Get connected
7-3
VPN server connections
A VPN connection helps you to securely connect to servers, such as a
corporate network, via the Internet. Ask your network administrator for your
user name, password, domain name, TCP/IP settings, and host name or
IP address of the VPN server.
To set up a VPN server connection:
1. Tap
> Settings > Connections tab > Connections.
2. To create a new VPN server connection, in My Work Network, tap Add
a new VPN server connection, then follow the screen instructions.
3. To view additional information for any screen in the wizard or while
changing settings, tap
NOTE
.
To change existing settings, in My Work Network, tap
Manage existing connections > VPN tab. Select your
desired VPN connection, tap Settings, then follow the
instructions on the screen.
Proxy server settings
If you are connected to your ISP or private network during synchronization,
your mobile device should download the proper proxy settings from your
PC. If these settings are not on your PC or need to be changed, ask your
ISP or network administrator for the proxy server name, server type, port,
type of Socks protocol used, and your user name and password.
To change proxy server settings:
1. Tap
> Settings > Connections tab.
2. To create a new connection, in My Work Network, tap Add a new
proxy server.
3. To change proxy server settings, in My Work Network, tap Edit my
proxy server. Select the desired proxy server, and tap Settings.
4. Select This network connects to the Internet and This network uses a
proxy server to connect to the Internet.
5. In the Proxy server box, enter the proxy server name.
6. To change such settings as port number or proxy server type, tap
Advanced and change desired settings.
7-4
Chapter 7
Network card connections
Use a network (Ethernet) card to connect directly to a network. Once
connected, you can view the Internet or intranet, or download e-mail. You
do not need to create a new connection on your device. For more
information, see your network administrator. Make sure to purchase and
configure a network card that is compatible with your device.
To set up a network card:
1. Obtain the following information from your network administrator: user
name, password, and domain name.
2. Insert the network card into your device.
3. The first time you insert the card, Network Settings appears
automatically so that you can configure the network card. If it does not
appear, or to change settings later, tap
> Settings > Connections
tab > Connections > Advanced tab > Network Card.
4. If you need to enter specific server information, tap the appropriate
adapter, and then tap Properties. Most networks use DHCP, so you
should not have to change these settings unless your network
administrator instructs you to do so.
5. If necessary, connect the network card to the network by using a
network cable. For information, refer to the documentation that came
with your network card.
6. To start a connection, insert the network card, and begin using a
desired program. For example, switch to Pocket Internet Explorer
and browse a Web page. Your device automatically starts connecting.
If you use your network card with two networks, such as a private
network at work and one at home for the Internet, you need to change
the network to which the network card connects.
NOTE
You may need proxy server and VPN connection settings.
For more information, see your network administrator.
Get connected
7-5
Wireless network connections
Networks that you have already configured are preferred networks and are
listed in Wireless networks. You can select to connect to only preferred
networks or have your device search for and connect to any available
network whether it is preferred or not.
To set up a wireless network:
1. Tap
> Settings > Connections tab > Connections > Network
Card > Wireless tab.
2. To change network settings, in Wireless networks, tap a network. If
you do not see a desired network, tap Add new and follow the
instructions on the screen.
3. From Networks to access, select All available, Only access points,
or Only computer-to-computer depending on the type of network(s)
you connect to.
4. To connect only to networks you have already configured, clear
Automatically connect to non-preferred networks.
NOTE
If you select to automatically connect to non-preferred
networks, your device detects any new networks and provide
you the opportunity to configure them.
Enter settings information
A wireless network can be added either when the network is detected, or
manually by entering settings information.
To enter new settings:
1. To manually enter information, tap
> Settings > Connections tab
> Connections > Network Card > Wireless tab. Then, tap Add new.
If the network was detected, step one is not necessary.
2. In the General tab, enter a network name. If the network was detected,
the network name is automatically entered and can't be changed.
3. From Connects to, select what your network connects to, Work or the
Internet.
4. To connect to an ad-hoc connection, select This is a device-tocomputer (ad-hoc) connection.
7-6
Chapter 7
Configure authentication settings
A wireless network can be added either when the network is detected, or
manually by entering settings information. To determine if authentication
information is needed, see your network administrator.
To configure authentication settings:
1. To manually enter information, tap
> Settings > Connections tab
> Connections > Network Card > Wireless tab.
2. Tap Add new. If the network was detected, step one and two are not
necessary.
3. To use data encryption, tap Data encryption (WEP enabled).
4. To use Shared Key authentication, tap Network Authentication
(shared mode). You need a network key.
5. To automatically use a network key, tap The key is provided for me
automatically. Otherwise, enter the network key.
6. For increased security, select Use IEEE 802.1x network access
control, then select the appropriate EAP type.
Change connection settings name
Your mobile device is already set up with two sets of connection settings:
My ISP and My Work Network. You can change the name of these
settings to something more familiar. For example, if you put all of your
corporate settings under My Work Network, you can change the name
from My Work Network to your company name.
To change a connection name:
1. Tap
> Settings > Connections tab > Connections.
2. Under My ISP or My Work Network, tap Manage existing
connections.
3. Tap the General tab.
4. Enter a name for the settings.
Get connected
7-7
End a connection
•
•
•
•
•
When connected via modem or VPN, tap
on the navigation bar,
then tap Disconnect.
When connected via cable or cradle, detach your device from the cable
or cradle.
When connected via Infrared, move the device away from the other
computer or device.
When connected via a network (Ethernet) card, remove the card from
your device.
When connected via a wireless network, switch off the connection.
Set up a WAP gateway
To access WAP sites through Pocket Internet Explorer, configure your
device to use a WAP gateway. Use the following steps to create a new set
of connections to the Internet with WAP gateway settings.
NOTE
Some device models do not support the WAP sites viewing
feature.
1. Get the following information from your ISP: ISP server phone number,
user name, and password. Also, contact your mobile phone service
provider and ask for your WAP gateway server name and port number.
2. Tap
> Settings > Connections tab > Connections > Tasks tab.
3. Tap Edit my proxy server. If a proxy server has not been set up, tap Set
up my proxy server.
4. In Programs that automatically connect to the Internet should
connect using, tap New and enter a name for the ISP connection.
5. On the Proxy Settings tab, select This network connects to the
Internet and This network uses a proxy server to connect to the
Internet.
6. If necessary, in the Proxy server box, enter the proxy server name.
7. Tap Advanced.
8. In the WAP box, enter the WAP gateway server name. Under Port,
enter the port number. The most common WAP port number is 9201.
7-8
Chapter 7
9. Create a modem connection. See section “Set up connections.”
If necessary, set dialing rules. See section “Use dialing rules.”
10. If your device does not have a connection to a mobile phone network,
insert a modem card.
Use dialing rules
Additional numbers may need to be dialed depending on your given
location when connecting. For example, if you want to dial from work, a 9
prefix must often be dialed, or an area code is needed.
To avoid creating a new modem connection for each situation, set dialing
rules for the locations from which you connect often. Three dialing
locations, Home, Mobile, and Work, have been created for you, and you
can create more. If a connection cannot be made, your device gives you
an opportunity to change the dialing location.
> Settings > Connections tab > Connections > Advanced
1. Tap
tab.
2. Tap Select Location.
3. Tap Use dialing rules.
4. Select a location.
• Home - Dials the number as a local call without a 9 prefix.
•
Work - Dials the number as local call with the 9 prefix.
NOTE
To create a new location, tap New and follow the directions
on the screen. To view additional information at any time, tap.
Get connected
7-9
Infrared (IR) connection
By default, your device detects incoming infrared (IR) beams and prompts
you to accept them. If you do not want your device to detect or receive
beans, clear the Receive all incoming beams check box.
To set the Beam options:
1. Tap
, then Settings.
2. Tap the Connections tab.
3. Tap the Beam icon to display the
Settings screen.
4. Make your desired change and tap OK.
5. To receive an infrared beam from this screen, tap the link at the
bottom. Your device automtically looks for another device using
infrared.
7-10
Chapter 7
Sending information
To send information:
1. Switch to the program where you
created the item that you want to
send, and locate that item in the
list.
2. Align the IR ports so that they are
unobstructed and within a close
range.
3. Tap and hold the item, then tap
Beam File... on the pop-up menu.
NOTE
You can also send items, but not folders, from File Explorer.
Tap and hold the item that you want to send, then tap Beam
File on the pop-up menu.
Receiving information
To receive information:
1. Align the IR ports so that they are unobstructed and within a close
range.
2. Have the owner of the other device send the information to you. Your
device automatically receive the information.
Get connected
7-11
Bluetooth connection
Bluetooth is a short-range wireless communications technology. Devices
with Bluetooth capabilities can exchange information over a distance of
about 10 meters (30 feet) without requiring a physical connection.
Unlike infrared, you don’t need to line up the devices to beam information
with Bluetooth. The devices only need to be within a range of about 10
meters. You can even beam information to a device in a different room, as
long as it’s within range.
Microsoft Pocket PC 2003 software allows you to use Bluetooth in the
following ways:
•
Beam information, such as files, appointments, tasks, and contact
cards, between devices that have Bluetooth capabilities. For
example, if you and a co-worker each have a device with Bluetooth,
you can beam items between your devices, such as files, contact
cards, appointments, tasks, and so forth.
•
Create a dial-up modem connection between your device and a
Bluetooth phone. You can then use the Bluetooth phone as a
modem.
Your device might include additional Bluetooth features. For more
information, see the documentation included with your device.
Bluetooth modes
Bluetooth operates in three different modes:
•
•
•
7-12
On. The Bluetooth radio is turned on and you can use Bluetooth
features.
Off. The Bluetooth radio is turned off. In this mode, you can neither send
nor receive information by using Bluetooth. You might want to turn the
radio off at times in order to conserve battery power, or in situations
where radio use is prohibited, such as on airplanes and in hospitals.
Discoverable. The Bluetooth radio is turned on, and all of the other
Bluetooth devices within range (about 10 meters) can detect your device
and attempt to beam information to it, establish a bond, or use a
Bluetooth service. In this mode, other devices can detect your device
whether or not a bond has been created; however, in order to receive a
beam from another device, you must accept it on your device, as
described in Receiving a Bluetooth Beam.
Chapter 7
Bluetooth settings
To turn Bluetooth on or off:
1. Tap
> Settings > Connections
tab.
2. Tap Bluetooth.
3. Select On or Off. The Bluetooth
radio is turned on or off according to
your selection.
NOTE
By default the Bluetooth radio is turned off. If you turn it on,
and then turn off your device, the Bluetooth radio also turns
off. When you turn on your device again, the Bluetooth radio
turns on automatically.
Making your device discoverable
1. Tap
> Settings > Connections tab.
2. Tap Bluetooth.
3. Select Discoverable.
NOTES
Other Bluetooth devices can now detect your device and
attempt to beam information to it, establish a bond, or use a
Bluetooth service. Note that to receive beamed information,
you must accept it on your device.
Selecting Discoverable also turns on your Bluetooth radio.
If you no longer want your device to be discoverable, tap Off
to turn off the radio or On to leave the radio on, but not allow
detection by other devices.
Get connected
7-13
Beaming information with Bluetooth
1. Tap and hold an item to beam, such as an appointment in Calendar, a
task in Tasks, a contact card in Contacts, or a file in File Manager.
2. Tap Beam [type of item].
3. Tap the device to which you want to send the beam.
The item is beamed to the device you selected.
NOTE
If the device that you want to beam to does not appear in the
list, make sure that it is turned On, in discoverable mode, and
within 10 meters (30 feet) of your device. Also, make sure
that your Bluetooth radio is turned on.
Receiving a Bluetooth beam
1. Make sure that your device is configured to receive incoming beams.
2. Make sure that your device is within 10 meters (about 30 feet) of the
device beaming the information and that Bluetooth is in discoverable
mode.
3. When prompted to receive an incoming beam, tap Yes.
The information is received on your device.
7-14
Chapter 7
Appendix
Notices
Notices
A-1
Federal Communications Commission Statement
This device complies with FCC Rules Part 15. Operation is subject to the following two
conditions:
•
This device may not cause harmful interference, and
•
This device must accept any interference received including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
manufacturer’s instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
•
Consult the dealer or an experienced radio/TV technician for help.
WARNING! The use of shielded cables for connection of the monitor to
the graphics card is required to assure compliance with FCC
regulations. Changes or modifications to this unit not
expressly approved by the party responsible for compliance
could void the user’s authority to operate this equipment.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital
apparatus set out in the Radio Interference Regulations of the Canadian Department of
Communications.
This class B digital apparatus complies with Canadian ICES-003.
A-2
Appendix
UL Safety Notices
Required for UL 1459 covering telecommunications (telephone) equipment intended to be
electrically connected to a telecommunication network that has an operating voltage to ground that
does not exceed 200V peak, 300V peak-to-peak, and 105V rms, and installed or used in
accordance with the National Electrical Code (NFPA 70).
When using the Pocket PC, basic safety precautions should always be followed to reduce the risk
of fire, electric shock, and injury to persons, including the following:
•
•
•
Do not use the Pocket PC near water, for example, near a bath tub, wash bowl, kitchen sink
or laundry tub, in a wet basement or near a swimming pool.
Do not use the Pocket PC during an electrical storm. There may be a remote risk of electric
shock from lightning.
Do not use the Pocket PC in the vicinity of a gas leak.
Required for UL 1642 covering primary (nonrechargeable) and secondary (rechargeable) lithium
batteries for use as power sources in products. These batteries contain metallic lithium, or a lithium
alloy, or a lithium ion, and may consist of a single electrochemical cell or two or more cells
connected in series, parallel, or both, that convert chemical energy into electrical energy by an
irreversible or reversible chemical reaction.
•
•
Do not dispose the Pocket PC battery pack in a fire, as they may explode. Check with local
codes for possible special disposal instructions to reduce the risk of injury to persons due to fire
or explosion.
Do not use power adapters or batteries from other devices to reduce the risk of injury to
persons due to fire or explosion. Use only UL certified power adapters or batteries supplied by
the manufacturer or authorized retailers.
Replaceable batteries
If an equipment is provided with a replaceable batterym and if replacement by an incorrect type
could result in an explosion (e.g. with some lithium batteries), the following applies:
– if the battery is placed in an OPERATOR ACCESS AREA, there shall be a marking close
to the battery or a statement in both the operating and the servicing instructions;
– if the battery is placed elsewhere in the equipmen, there shall be a marking close to the
battery or a statement in the servicing instructions.
The marking or statement shall include the following or similar text:
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
THE INSTRUCTIONS
Compliance is checked by inspection.
Operator access with a tool
If a TOOL is necessary to gain access to an OPERATOR ACCESS AREA, either all other
compartments within that area containing a hazard shall be inaccessible to the OPERATOR by the
use of the same TOOL, or such compartments shall be marked to discourage OPERATOR access.
An acceptable marking for an electric shock hazard is
(ISO 3864, No. 5036)
Equipment for restricted access locations
For equipment intended only for installation in a RESTRICTED ACCESS LOCATION, the
instalation instructions shall contain a statement to this effect.
Notices
A-3
A-4
Appendix

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
