Arkon Slim-Grip SM515 User Manual

SM427 ||Slim-Grip™
SM515
Bicycle Handlebar
Universal Holder
Mount
with
with
MiniUniversal
Windshield
Holder
Suction and Dashboard Mount
Package Contents:
(1) SM050-HPB-2 Universal phone and portable device holder
(1) GN015-HPB-2 - Mini Windshield Suction and Dashboard Mount
(1) AP013 - Circular Adhesive Dashboard Disc
GN015-HPB-2
Mini Windshield
Suction Pedestal
•
82 mm
expandable to
118.5 mm
SM050-HPB-2
Universal Phone
Holder
AP013
Circular Adhesive
Dashboard Disk
Windshield Mounting
Step 1.
•
•
•
•
•
•
•
•
•
•
•
•
Compatible with most smartphones, mobile phones, and cell phones having
heights between 80mm and 115mm tall
Apple iPhone - All models
RIM BlackBerry - All non-flip models
HTC Phones - All non-flip models
Motorola Phones - All non-flip models
Nokia Mobile Phones - All non-flip models
Palm - All non-flip models
LG Mobile Phones - All non-flip models
Samsung - All non-flip models
Sony Ericsson - All non-flip models
Sanyo - All non-flip models
*All brand names and product
Pantech - All non-flip models
names are trademarks or registered
Google - All non-flip models
trademarks of their respective owners.
Connecting the Slim-Grip™ Holder to Dual T-Tab Pedestal
Find a safe location on the interior of the vehicle’s windshield
to mount the pedestal. Firmly push the suction base (A)
against the windshield and flip the base lever down (B) to the
locked position. See diagram below.
Step 1.
Connect the dual T-slots (A) on holder to the dual T-tabs (B) on
the pedestal head.
B
A
Optional Cord
Catcher
B
A
Install the Support Legs to the Holder
Step 1.
Insert the holder support legs (A) by sliding them into the
support leg grooves (B) on the top and bottom of the holder.
B
A
A
Insert Phone into Holder
Step 1.
Secure holder with your hand for support, as spring-loaded
mechanism requires significant force to operate. Hold your phone
and insert into universal holder by pushing down on the bottom
spring-loaded support legs with moderate amount of pressure
(C). Slide the top of the device under the top support legs (D) until
it fits snuggly in the holder.
D
A
A
B
C
Continued on other side...
!
Safety Precautions
Do not install Arkon products over an air bag cover or within the air
bag deployment zone. Arkon Resources, Inc. assumes no responsibility of liability for injury or death as a result of car crashes and / or
air bag deployment.
Consumer Hotline:
USA (800) 841-0884
INT’L (626) 254-9005
Monday - Friday 9 am - 5 pm, PST
Arkon is not responsible for any damages caused to your car, your
device, or yourself due to the installation or use of this pedestal mount.
www.arkon.com
Arcadia, CA 91006 USA
࣬ ৹ࢄߔ޺੦
Representative in KOREA
www.knctek.com
TEL : 02) 839-5701
FAX : 02) 830-5703
Designed in USA | Made in China And Taiwan
© Copyright 2010 Arkon Resources, Inc.
SM515 | Slim-Grip™ Universal Holder with Mini Windshield Suction and Dashboard Mount
Step 5. Push the pedestal suction cup (A) down onto the disk (C). Flip the
lever (B) down to secure the suction cup. Adjust the angle of the
pedestal head as needed.
Adjusting Holder to Fit Phone
E
E
Step 1. If necessary, adjust the support legs (E) on top and bottom by
sliding them laterally to avoid any buttons or ports that may be
on your phone.
Dashboard or Console Mounting Instructions
Step 1. Choose a suitable location for disc (and pedestal) installation.
Do not place mount in or near an air bag deployment zone
or where it will obstruct view of the road or hinder vehicle
operation.
Step 2. Clean the dashboard or console surface area thoroughly with
the included alcohol pad. Allow the area dry before applying
the mounting disc.
Step 3. Remove the paper backing of the disc and place on the
cleaned surface. Press the top of the disc down firmly to allow
the adhesive to stick to the surface. Allow 24 hours for the
adhesive to cure to the surface before applying any pressure.
Step 4. Place the suction cup of the pedestal firmly down on the center
of the mounting disc and lower the securing lever.
B
A
C
Continued in
next column...
!
Safety Precautions
Do not install Arkon products over an air bag cover or within the air
bag deployment zone. Arkon Resources, Inc. assumes no responsibility of liability for injury or death as a result of car crashes and / or
air bag deployment.
Consumer Hotline:
USA (800) 841-0884
INT’L (626) 254-9005
Monday - Friday 9 am - 5 pm, PST
Arkon is not responsible for any damages caused to your car, your
device, or yourself due to the installation or use of this pedestal mount.
www.arkon.com
Arcadia, CA 91006 USA
࣬ ৹ࢄߔ޺੦
Representative in KOREA
www.knctek.com
TEL : 02) 839-5701
FAX : 02) 830-5703
Designed in USA | Made in China And Taiwan
© Copyright 2010 Arkon Resources, Inc.
