Canon C3480 Printer User manual

Corporate Solutions
Specifications
DADF-L1
Platen Cover Type H
Document Tray-J1
Copy Tray-J1
Inner 2-Way
Tray-D1
Saddle Finisher-Y2
Finisher-Y1
MAIN UNIT
Type:
Copying Method:
Developing System:
Memory:
Hard Disk Drive:
Network Interface
Connections:
Other Interface:
First-Copy Time:
Warm-Up Time:
Copy/Print Speed
(B/W, Color):
Scan Resolution:
Copy Resolution:
Engine Resolution:
Halftone:
Paper Sources
Standard:
Optional:
Maximum:
Paper Sizes
Drawers:
Bypass:
Acceptable Paper Weight
Drawers:
Bypass:
Duplexing:
Color Digital Multifunction
Imaging System
Laser Dry Electrostatic Transfer
Dry Dual Component Developing
System
Standard 1GB RAM
Maximum 1.5GB RAM
80GB
10/100Base-TX (RJ-45)
USB 2.0 (Device), USB 2.0 (Host)
8.9 Seconds (Color)
5.9 Seconds (B/W)
38-Seconds After Powering On
C3480/C3480i: 34/30 ppm (Letter)
C3080/C3080i: 30/28 ppm (Letter)
600 dpi x 600 dpi
600 dpi x 600 dpi
1200 dpi x 1200 dpi
256 Gradations (Continuous-Tone)
Dual 550-Sheet x 2 Paper Cassettes
50-Sheet Stack Bypass
Dual 550-Sheet x 2 Paper Cassettes
2,700-Sheet Paper Deck
4,950 Sheets
12"x 18", 11" x 17", Legal, Letter,
Letter-R, Statement-R, Executive
12-5/8" x 17-11/16", 12" x 18",
11" x 17", Legal, Letter, Letter-R,
Statement, Statement-R, Executive,
Irregular size (3-7/8" x 5-9/16" to
12-5/8" x 18") and Envelopes
17 lb. Bond to 90 lb. Index
17 lb. Bond to 110 lb. Index
Standard Automatic Trayless
Duplexing (Executive to 12" x 18")
Image Reader:
Standard
Acceptable Originals: Sheet, Book, 3-Dimensional Objects
(Up to 4.4 lb.)
Max. Original Size:
11" x 17"
Document Feeding Method: Duplexing Automatic Document
Feeder (Standard on “i” Models)
Acceptable Originals:
Statement to 11" x 17"
Paper Capacity:
50 Sheets
Acceptable Paper
Weight of Originals:
Simplex 11 lb. to 32 lb. Bond
(42 to 128 g/m2)
Duplex 13 lb. to 32 lb. Bond
(50 to 128 g/m2)
Scan Speed:
44 ipm (300 dpi)
28 ipm (600 dpi)
Dimensions (H x W x D):
31-1/8" x 22-1/4" x 29-3/4"
(Main Unit)
36" x 22-1/4" x 29-3/4" (with DADF)
Installation Space (W x D): 34" x 29-3/4"
(when the Stack Bypass is extended)
Weight:
Approximately 256 lb.
(116kg Main Unit)
Approximately 275 lb.
(125kg with DADF)
Power Requirements:
120V AC, 60Hz, 15A
Puncher
Unit-M1
Power Consumption:
Plug:
Toner (Estimated Yield):
Copy Features
Multiple Copies:
Max. Copy Reservation:
Color Mode:
Copy Exposure:
Magnification
Preset Reduction:
Preset
Enlargement:
Zoom Mode:
Print Features
CPU:
Memory:
Hard Disk Drive:
Print Resolution
UFR II:
Printer Driver
UFR II:
XPS:*
Finisher-Z1
Cabinet-P1
Cassette
Feeding Unit-Y3
1,500W
NEMA 5-15P
Black: 26,000 Images
@ 5%Coverage
Color: 14,000 Images
@ 5% Coverage
1 to 999
10 Jobs
Auto Color, Full Color, Black,
Single Color, Two Colors
Automatic or Manual (9 Levels)
25%, 50%, 64%, 73%, 78%
121%, 129%, 200%, 400%
25% - 400% (1% increments)
Canon Dual Custom Processor
(Shared)
1GB RAM (Standard)
1.5GB RAM (Maximum) (Shared)
80GB (Shared)
1200 dpi x 1200 dpi 2400 dpi equivalent x 600 dpi
Windows® (Windows 2000/XP/
Server 2003/Windows Vista®)
Citrix MetaFrame
Macintosh® (OS 10.2.8 or later)
Windows Vista
Mail Box Features
Max. Mail Boxes Supported: 100 User Inboxes, One Memory RX
Inbox, 50 Confidential Fax Inboxes
Scan Features
Network TWAIN Scan:
Network Scan Utility:
Standard
Color Network ScanGear
Color Universal Send Features
Color Mode:
Auto Color Select
(Full Color/Grayscale)
Auto Color Select (Full Color, B/W)
Full Color, Grayscale, B/W
Address Book Capacity:
Max. 1,800 Destinations
(Includes 200 One-Touch Buttons)
Max. 5 LDAP Servers
Sending Methods:
E-mail, I-fax, SMB, File Server
(FTP, IPX, WebDAV), User Inbox,
Super G3 Fax (Optional)
Communication Protocol
File:
FTP (TCP/IP), SMB (TCP/IP),
NCP (IPX), WebDAV
E-mail/I-fax:
SMTP, POP3, I-fax (Simple, Full)
Data Format
File, E-mail:
TIFF, JPEG, PDF, PDF (Compact),**
PDF (Trace & Smooth),** PDF
(OCR),** Encrypted PDF,*** Digital
Signature PDF (Device,*** User †)
I-fax:
B/W: TIFF (MH, MR, MMR)
Color: TIFF (Profile-C)
OPTIONAL ACCESSORIES
Super G3 Fax Board-W2/Super G3 Multi-Line Fax Board-J2
Applicable Line:
Public Switched Telephone Network
(PSTN)
Paper Deck-Z1
Connection Lines:
Sending/Original Size:
Recording/Printing Size:
One-Line (Super G3 Fax Board W2),
Two-Lines (Super G3 Multi-Line Fax
Board-J2)
Statement to 11" x 17"
Statement to 11" x 17"
PCL Printer Kit-Q3 (Standard for “i” Models) ††
Canon Dual Custom Processor
CPU:
(Shared)
1GB RAM (Standard)
Memory:
1.5GB RAM (Maximum) (Shared)
80GB (Shared)
Hard Disk Drive:
PCL 5c/6
Supported PDL:
PostScript 3 Emulation
Optional PDL Support:
(PS Printer Kit-Q3††† )
Print Resolution
PCL 5c:
2400 dpi equivalent x 600 dpi
PCL 6:
1200 dpi x 1200 dpi 2400 dpi equivalent x 600 dpi
PS3 (Optional):
1200 dpi x 1200 dpi 2400 dpi equivalent x 600 dpi
Printer Drivers
PCL 5c/6:
Windows (Windows 98/Me/
2000/XP/Server 2003/
Windows Vista)
Citrix MetaFrame
PS3 (Optional):
Windows (Windows 98/Me/
2000/XP/Server 2003/
Windows Vista)
Citrix MetaFrame
Macintosh (OS 10.2.8 or later)
imagePASS-J1
Connectable Device:
CPU:
System:
Memory:
Hard Disk Drive:
Interfaces (to LAN):
Supported PDL:
Print Resolution:
Utility Software:
EFI Options:
Cassette Feeding Unit-Y3
Paper Sizes:
Color imageRUNNER C3480/C3080
Celeron M 1.2GHZ
System 8e
256MB (Std.)/512MB (Max.)
80GB
10/100/1000Base-T (RJ-45)
Adobe® PostScript® 3, PCL 5c
1200 dpi x 1200 dpi 2400 dpi equivalent x 600 dpi
Remote Scan
Command WorkStation for Windows
Command WorkStation for Mac
256MB RAM, Secure Erase v1.0,
Hot Folders v2.0, Impose v2.6
Dimensions (H x W x D):
Weight:
12" x 18", 11" x 17", Legal, Letter,
Letter-R, Statement-R, Executive
550-Sheet x 2 Cassettes
[20 lb. Bond (80 g/m2 )]
9-7/8" x 22-1/4" x 27-5/8"
Approximately 50.7 lb. (23kg)
Paper Deck-Z1
Paper Size:
Paper Deck Capacity:
Dimensions (H x W x D):
Installation Space (W x D):
Weight:
Letter
2,700 Sheets [20 lb. Bond (80 g/m2)]
18-5/8" x 14-5/8" x 23-1/4"
36-7/8" x 29-3/4"
Approximately 65.3 lb. (29.6kg)
Paper Drawers Capacity:
Finisher-Z1
Number of Trays:
Paper Size
Standard:
One Tray
12-5/8" x 17-11/16", 12" x 18",
11" x 17", Legal, Letter, Letter-R,
Statement, Statement-R, Envelopes
(COM10 No. 10, Monarch, DL,
ISO-B5, ISO-C5, Yougata 4,
Catalog Glove No.8)
Non-Standard Size:
Paper Weight:
Paper Capacity Per Tray:
Paper Capacity of
Staple Mode:
Max. Stapling Capacity
Letter:
11" x 17", Legal,
Letter-R:
Staple Mode:
Dimensions (H x W x D):
Installation Space (W x D):
Weight:
3-7/8" x 5-9/16" to 12-5/8" x 18"
17 lb. Bond to 80 lb. Cover
500 Sheets (Letter, Statement,
Statement-R) or 2-3/4" in Height
250 Sheets (11" x 17", Legal,
Letter-R) or 1-3/8" in Height
500 Sheets/30 Sets (Letter)
or 2-3/4" in Height
250 Sheets/30 Sets (11" x 17",
Legal, Letter-R) or 1-3/8" in Height
500 Sheets/30 Sets (Staple Mode
with Different Paper Sizes) or
2-3/4" in Height
50 Sheets (17 lb. to 20 lb. Bond)
30 Sheets (20 lb. to 28 lb. Bond)
2 Sheets (32 lb. Bond to 90 lb. Index)
30 Sheets (17 lb. to 20 lb. Bond)
20 Sheets (20 lb. to 28 lb. Bond)
2 Sheets (32 lb. Bond to 90 lb. Index)
Corner (11" x 17," Legal, Letter,
Letter-R)
Double (11" x 17", Letter)
8-1/2" x 27-3/8" x 21-5/8"
42" x 29-3/4" (when the Auxiliary
Tray is extended)
Approximately 26.5 lb. (12kg)
Finisher-Y1/Saddle Finisher-Y2
Two Trays
Number of Trays:
Paper Size
Standard:
12-5/8" x 17-11/16", 12" x 18",
11" x 17", Legal, Letter, Letter-R,
Statement, Statement-R, Executive
Non-Standard Size:
3-7/8" x 5-9/16" to 12-5/8" x 18"
Paper Weight:
17 lb. Bond to 80 lb. Cover
Paper Capacity Per Tray
Upper/Lower Tray:
1,000 Sheets (Letter, Statement,
Statement-R, Executive)
500 Sheets (11" x 17", Legal, Letter-R)
Paper Capacity of
Staple Mode
Upper/Lower Tray:
1,000 Sheets/30 Sets
(Letter, Executive)
500 Sheets/30 Sets
(11" x 17", Legal, Letter-R)
500 Sheets/30 Sets (Staple Mode
with Different Paper Sizes)
Max. Stapling Capacity
Letter, Executive:
50 Sheets (17 lb. to 20 lb. Bond)
30 Sheets (20 lb. to 28 lb. Bond)
2 Sheets (32 lb. Bond to 80 lb. Cover)
11" x 17", Legal,
Letter-R:
30 Sheets (17 lb. to 20 lb. Bond)
20 Sheets (20 lb. to 28 lb. Bond)
2 Sheets (32 lb. Bond to 80 lb. Cover)
Staple Mode:
Saddle-Stitching
Acceptable Paper
Sizes:
Saddle-Stitch
Capacity:
Tray Capacity:
Dimensions (H x W x D)
Finisher-Y1:
Saddle Finisher-Y2:
Installation Space (W x D)
Finisher-Y1:
Saddle Finsher-Y2:
Weight
Finisher-Y1:
Saddle Finisher-Y2:
Inner 2-Way Tray-D1
Paper Size
Standard:
Non-Standard:
Max. Paper Weight:
Paper Capacity Per Tray
Upper Output Tray:
Lower Output Tray:
Dimensions (H x W x D):
Installation Space (W x D):
Weight:
Puncher Unit-M1
Paper Size
Standard:
Federal Law prohibits copying of certain documents. Violators may be
subject to penalties. We suggest that you check with your own legal counsel.
Canon U.S.A., Inc. and Canon Canada, Inc. intend to cooperate with Law
Enforcement Agencies in connection with claims of unauthorized copying.
printed on recycled
paper in the u.s.a.
12" x 18", 11" x 17", Legal, Letter-R
15 Sheets (17 lb. to 20 lb. Bond)
10 Sheets (20 lb. to 28 lb. Bond)
25 Sets (1 to 5 Sheets)
15 Sets (6 to 10 Sheets)
10 Sets (11 to 15 Sheets)
42-1/4" x 26-1/8" x 25-7/8"
42-1/4" x 29-3/8" x 25-7/8"
59-3/8" x 29-3/4" (when the
Auxiliary Tray is extended)
63-1/4" x 29-3/4" (when the
Auxiliary Tray is extended)
OTHER OPTIONAL ACCESSORIES
• Encrypted Secured Print
Software-C1
• Barcode Printing Kit-A1
• Web Access Software-E1
• Universal Send PDF Advanced
Feature Set-A1
• Universal Send PDF Security
Feature Set-A1
• Digital User Signature PDF Kit-A1
• Secure Watermark-A1†††
• Super G3 Fax Board-W2
• Super G3 Multiline Fax Board-J2
• iR 512MB Expansion RAM-C1
• HDD Data Erase Kit-A1
• HDD Data Encryption Kit-B1
• Voice Guidance Kit-B1
• Voice Operation Kit-A1
• Remote Operator's Software Kit-A2
Approximately 96.1 lb. (43.6kg)
Approximately 162 lb. (73.6kg)
12-5/8" x 17-11/16", 12" x 18",
11" x 17", Legal, Letter, Letter-R,
Statement, Statement-R, Executive
3-7/8" x 5-9/16" to 12-5/8" x 18"
17 lb. Bond to 80 lb. Cover
100 Sheets (Letter)
50 Sheets (Other Sizes)
250 Sheets (Letter)
100 Sheets (Other Sizes)
6" x 7" x 21-1/2"
34" x 29-3/4"
Approximately 8.6 lb. (3.9kg)
11" x 17", Legal, Letter, Letter-R,
Executive
Max. Paper Weight:
17 lb. Bond to 80 lb. Cover
Punch Type:
3 Holes (Letter, 11" x 17")
2 Holes (Legal, Letter-R, Executive)
Punch Waste Tray Capacity: When Approximately 3,000 Sheets
of Paper Have Been Punched
Dimensions (H x W x D):
37-1/8" x 4-1/4" x 24-1/2"
Weight:
Approximately 15.9 lb. (7.2kg)
As an ENERGY STAR® Partner, Canon U.S.A., Inc. has determined that these products
meet the ENERGY STAR guidelines for energy efficiency. ENERGY STAR and the
ENERGY STAR mark are registered U.S. marks. Microsoft and Windows are registered
trademarks of Microsoft Corporation in the United States and/or other countries.
Adobe, Illustrator, and PostScript are registered trademarks or trademarks of Adobe
Systems Incorporated in the United States and/or other countries. Intel and Celeron
are trademarks or registered trademarks of Intel Corporation or its subsidiaries in
the United States and/or other countries. CANON, IMAGERUNNER, MEAP, and the
GENUINE logo are registered trademarks of Canon Inc. in the United States and may
also be registered trademarks or trademarks in other countries. IMAGEWARE is a
registered trademark of Canon U.S.A., Inc. in the United States and is a trademark
of Canon Inc. in certain other countries. IMAGEANYWARE is a trademark of Canon. All
referenced product names and other marks are trademarks of their respective owners.
Specifications and availability subject to change without notice.
©2008 Canon U.S.A., Inc. All rights reserved.
0408-C3480/C3080-PDF-IS
Corner (11" x 17", Legal, Letter,
Letter-R, Executive)
Double (11" x 17", Legal, Letter,
Letter-R, Executive)
• Platen Cover Type H
• Copy Tray-J1
• Envelope Feeder Attachment-C2
• FL Cassette-Y1
• FL Cassette-Z1
• Document Tray-J1
• Card Reader-C1
• Card Reader Kit-B1
• Key Switch Unit-A2
• Braille Label Kit-A1
• ADF Access Handle-A1
• Stamp Unit-A1
• eCopy Suite
• imageWARE Suite
• Access Management
System Kit-A1
• Workflow Composer-B3
• Wireless Network Interface
Adapter NB-W1
Footnotes:
Not available in top cassette.
If 1200-dpi print is selected, engine speed will slow down.
*
Check with your Authorized Canon Dealer for availability.
** When configured on C3480/C3080 models, requires
Universal Send PDF Advanced Feature Set-A1.
*** When configured on the C3480/C3080 models, requires
Universal Send PDF Security Feature Set-A1.
†
Requires Digital User Signature Kit-A1.
††
Color UFR II Printing is standard on C3480/C3080 Series models.
††† Requires imageRUNNER 512MB Expansion RAM-C1.
Available with Saddle Finisher-Y2 only.
Puncher Unit-M1 can only be installed with either the
Finisher-Y1 or Saddle Finisher-Y2.
When Configured on the C3480/C3080 models, requires
PCL Printer Kit-Q3.
Requires PS Printer Kit-Q3 if printing PDF files.
Standard on C3480i/C3080i models.
Voice Guidance Kit-1 and Voice Operation Kit-A1 cannot
be installed together.
Option on C3480/C3080 models.
Not supported with imagePASS-J1.
1-800-OK-CANON
www.usa.canon.com
Canon U.S.A., Inc.
One Canon Plaza
Lake Success, NY 11042

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
