Cisco Videoscape Distribution Suite Transparent Caching Installation Guide

Cisco Videoscape Distribution Suite
Transparent Caching Software C-Series
Cluster Installation Guide
Release 5.7.3
February 2016
Cisco Systems, Inc.
www.cisco.com
Cisco has more than 200 offices worldwide.
Addresses, phone numbers, and fax numbers
are listed on the Cisco website at
www.cisco.com/go/offices.
Text Part Number: OL-31421-04
THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL
STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT
WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.
THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT
SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE
OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY.
The following information is for FCC compliance of Class A devices: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio-frequency energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case users will be required
to correct the interference at their own expense.
The following information is for FCC compliance of Class B devices: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If the equipment causes interference to radio or television reception, which can be
determined by turning the equipment off and on, users are encouraged to try to correct the interference by using one or more of the following measures:
•
•
•
•
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Modifications to this product not authorized by Cisco could void the FCC approval and negate your authority to operate the product.
The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB’s public
domain version of the UNIX operating system. All rights reserved. Copyright © 1981, Regents of the University of California.
NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED “AS IS” WITH
ALL FAULTS. CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT
LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF
DEALING, USAGE, OR TRADE PRACTICE.
IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING,
WITHOUT LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO
OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this
URL: www.cisco.com/go/trademarks. Third-party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership
relationship between Cisco and any other company. (1110R)
Any Internet Protocol (IP) addresses and phone numbers used in this document are not intended to be actual addresses and phone numbers. Any examples, command display
output, network topology diagrams, and other figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses or phone numbers in
illustrative content is unintentional and coincidental.
© 2016 Cisco Systems, Inc. All rights reserved.
CONTENTS
Preface
vii
Cluster Installation Overview vii
Rack Server Cluster Models vii
Obtaining Documentation and Submitting a Service Request
CHAPTER
1
Prerequisites and C-Series Cluster Physical Installation
Prerequisites 1-1
Required Software
Firmware Versions
Rack Mounting
1-2
Power Cabling
1-2
viii
1-1
1-1
1-1
Network Cabling 1-3
Cache Engines 1-3
Management Server 1-4
Storage Enclosures 1-5
NetApp E2724 Storage Enclosure 1-5
IBM DS3524 Storage Enclosure 1-6
Additional Steps
CHAPTER
2
1-7
Configuring the Switches in a C-Series Cluster Installation
Initial Setup of the Cluster Switches 2-3
Preparing for the Configuration 2-3
VDS TC Management Switch 2-4
Configure Cisco SG500 Stack 2-4
Apply the Switch Configuration 2-4
VDS TC Data Switch 2-5
Configuring VSS on the First Switch 2-5
Configuring VSS on the Second Switch 2-6
Converting the Data Switches to Virtual Switch Mode
CHAPTER
3
Management Server Installation
Before You Begin
2-1
2-6
3-1
3-1
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
iii
Contents
Configuring the BIOS and Operating System with CIMC
3-2
Configuring the Management IP Address and Password for a PID TCE-1300MGR-K9 Management
Server 3-14
Configuring the Boot Image
CHAPTER
4
3-16
Copying the ISO to the VDS TC Management Server
3-25
Starting the VNC Server on the Management Server
3-26
Cache Engine Servers Installation
Before You Begin
4-1
4-1
Configuring the BIOS and Operating System with CIMC
4-2
Configuring the Management IP Address and Password for a PID TCE-1300CE-K9 Cache Engine
Preparing to Import the Cisco VIC Adapters Configuration
Importing the Cisco VIC Adapters Configuration
Configuring the Boot Image
CHAPTER
5
4-14
4-16
4-17
4-23
Configuring the Cache Storage
5-1
Configuring the Cache Storage Using IBM Storage Enclosures 5-1
Installing the Storage Manager Software on the VDS TC Management Server
Configuring the First IBM Storage Array 5-5
Configuring the Remaining IBM Storage Arrays 5-13
Confirm the Enclosure ID 5-14
Configuring the Cache Storage Using NetApp Storage Enclosures 5-16
Installing the SANtricity Storage Manager on the Management Server
Configuring the First NetApp Storage Array 5-20
Configuring the Remaining NetApp Storage Arrays 5-28
5-2
5-16
5-28
Confirm the Tray ID
5-29
Configuring the Storage Array and Formatting Storage Disks
CHAPTER
6
5-31
Installing and Configuring the Cisco VDS TC Cluster Software
Installing the Management Environment and Software
6-1
6-1
Post Installation Steps 6-4
Installing the License 6-6
APPENDIX
A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-2S Non-Redundant Cabling Scheme A-2
Cisco Catalyst 4500X Switch Cabling (VDS-TC-2S Non-Redundant)
Cisco SG500 Switch Cabling (VDS-TC-2S Non-Redundant) A-2
A-1
A-2
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
iv
OL-31421-04
Contents
VDS-TC-2S Redundant Cabling Scheme A-3
Cisco Catalyst 4500X-1 Switch Cabling (VDS-TC-2S Redundant)
Cisco Catalyst 4500X-2 Switch Cabling (VDS-TC-2S Redundant)
Cisco SG500-1 Switch Cabling (VDS-TC-2S Redundant) A-5
Cisco SG500-2 Switch Cabling (VDS-TC-2S Redundant) A-6
A-3
A-4
VDS-TC-4S Non-Redundant Cabling Scheme A-7
Cisco Catalyst 4500X Switch Cabling (VDS-TC-4S Non-Redundant)
Cisco SG500 Switch Cabling (VDS-TC-4S Non-Redundant) A-8
VDS-TC-4S Redundant Cabling Scheme A-9
Cisco Catalyst 4500X-2 Switch Cabling (VDS-TC-4S Redundant)
Cisco SG500-1 Switch Cabling (VDS-TC-4S Redundant) A-11
Cisco SG500-2 Switch Cabling (VDS-TC-4S Redundant) A-12
A-7
A-10
VDS-TC-8S Non-Redundant Cabling Scheme A-13
Cisco Catalyst 4500X Switch Cabling (VDS-TC-8S Non-Redundant) A-13
Cisco Nexus 3172TQ Switch Cabling (VDS-TC-8S Non-Redundant) A-14
VDS-TC-8S Redundant Cabling Scheme A-15
Cisco Catalyst 4500X-1 Switch Cabling (VDS-TC-8S Redundant) A-15
Cisco Catalyst 4500X-2 Switch Cabling (VDS-TC-8S Redundant) A-16
Cisco Nexus 3172TQ Switch Cabling (VDS-TC-8S Redundant) A-17
Cisco Catalyst 3172TQ-2 Switch Cabling (VDS-TC-8S Redundant) A-18
VDS-TC-16S Non-Redundant Cabling Scheme A-19
Cisco Catalyst 4500X Switch Cabling (VDS-TC-16S Non-Redundant) A-19
Cisco Nexus 3172TQ Switch Cabling (VDS-TC-16S Non-Redundant) A-20
VDS-TC-16S Redundant Cabling Scheme A-22
Cisco Catalyst 4500X-1 Switch Cabling (VDS-TC-16S Redundant) A-22
Cisco Catalyst 4500X-2 Switch Cabling (VDS-TC-16S Redundant) A-24
Cisco Catalyst 3172TQ-1 Switch Cabling (VDS-TC-16S Redundant) A-26
Cisco Catalyst 3172TQ-2 Switch Cabling (VDS-TC-16S Redundant) A-28
APPENDIX
B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-2S Redundant 2x4500X B-2
Cisco Catalyst 4500X-1 Switch Cabling (VDS-TC-2S 2x4500X Redundant)
Cisco Catalyst 4500X-2 Switch Cabling (VDS-TC-2S 2x4500X Redundant)
VDS-TC-4S Non-Redundant Cabling Scheme B-4
Cisco Catalyst 4500X Switch Cabling (VDS-TC-4S Non-Redundant)
Cisco Catalyst 4948E Switch Cabling (VDS-TC-4S Non-Redundant)
VDS-TC-4S Redundant Cabling Scheme B-6
Cisco Catalyst 4500X-2 Switch Cabling (VDS-TC-4S Redundant)
Cisco Catalyst 4948E-1 Switch Cabling (VDS-TC-4S Redundant)
B-1
B-2
B-3
B-4
B-5
B-7
B-8
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
v
Contents
Cisco Catalyst 4948E-2 Switch Cabling (VDS-TC-4S Redundant)
B-9
VDS-TC-8S Non-Redundant Cabling Scheme B-10
Cisco Catalyst 4500X Switch Cabling (VDS-TC-8S Non-Redundant)
Cisco Catalyst 4948E Switch Cabling (VDS-TC-8S Non-Redundant)
VDS-TC-8S Redundant Cabling Scheme B-12
Cisco Catalyst 4500X-1 Switch Cabling (VDS-TC-8S Redundant)
Cisco Catalyst 4500X-2 Switch Cabling (VDS-TC-8S Redundant)
Cisco Catalyst 4948E-1 Switch Cabling (VDS-TC-8S Redundant)
Cisco Catalyst 4948E-2 Switch Cabling (VDS-TC-8S Redundant)
B-10
B-11
B-12
B-13
B-14
B-16
VDS-TC-16S Non-Redundant Cabling Scheme B-18
Cisco Catalyst 4500X Switch Cabling (VDS-TC-16S Non-Redundant) B-18
Cisco Catalyst 4948E-1 Switch Cabling (VDS-TC-16S Non-Redundant) B-19
Cisco Catalyst 4948E-2 Switch Cabling (VDS-TC-16S Non-Redundant) B-21
VDS-TC-16S Redundant Cabling Scheme B-23
Cisco Catalyst 4500X-1 Switch Cabling (VDS-TC-16S Redundant)
Cisco Catalyst 4500X-2 Switch Cabling (VDS-TC-16S Redundant)
Cisco Catalyst 4948E-1 Switch Cabling (VDS-TC-16S Redundant)
Cisco Catalyst 4948E-2 Switch Cabling (VDS-TC-16S Redundant)
B-23
B-25
B-27
B-29
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
vi
OL-31421-04
Preface
Revised: February 2016, OL-31421-04
The Cisco Videoscape Distribution Suite Transparent Caching (VDS TC) solution is focused on reducing
costs and improving the quality of user experience in delivering unmanaged Internet-based content,
including Internet video, file sharing, software distribution, mobile application downloads, and web
browsing. VDS TC integrates highly scalable caching software with high-performance Cisco Unified
Computing System™ (UCS) C-Series Rack Servers and B-Series Blade Servers, Cisco switches, and
SAN storage. The VDS TC solution, combined with other Videoscape products, such as Cisco
Videoscape Distribution Suite for Internet Streaming (VDS IS), provides a complete platform for
optimizing managed and unmanaged content delivery.
Cluster Installation Overview
The Cisco VDS TC Cluster platform is a multi-server scalable system that is intended for the efficient
serving of P2P and HTTP user requests. A Cisco VDS-TC Cluster installation can optimize P2P and
HTTP object downloading traffic across ISP networks through high-performance caching.
Because of its flexible size, a Cisco VDS TC Cluster installation can meet both low-end and high-end
requirements, and can also grow in parallel with the customer network.
In a VDS TC Cluster configuration, the VDS TC software can run on the Cisco UCS C220 C- Series
Rack Servers or on the Cisco UCS B200 M3 B-Series Blade Servers. The cached objects for both
solutions are stored on an IBM or NetApp SAN storage device, and Cisco switches are used for data,
storage, and management connectivity. A VDS TC Cluster configuration that uses the Cisco UCS C220
Rack Servers can contain up to 16 Cisco UCS C220 cache engine servers and up to six NetApp E2724
or five IBM DS3524 SAN storage enclosures. A separate Cisco UCS C220 is used as the VDS TC
Management Server.
This installation guide provides instructions for installing VDS TC on a Cisco C-Series Cluster platform,
including installing and configuring the VDS TC Management Server, the VDS TC Cache Engines, and
the storage enclosures. This installation guide also discusses configuring the data and management
switches used by the VDS TC C-Series Cluster installation.
Rack Server Cluster Models
There are four VDS TC Server cluster models that use the Cisco UCS C220 Rack Servers:
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
vii
Preface
Obtaining Documentation and Submitting a Service Request
•
Cisco VDS-TC-2S: The Cisco VDS-TC-2S model contains two Cisco UCS C220 Cache Servers,
one Cisco UCS C220 Management Server, and one NetApp E2724 or IBM DS3524 SAN storage
enclosure.
•
Cisco VDS-TC-4S: The Cisco VDS-TC-4S model contains four Cisco UCS C220 Cache Servers,
one Cisco UCS C220 Management Server, and two NetApp E2724 or IBM DS3524 SAN storage
enclosures.
•
Cisco VDS-TC-8S: The Cisco VDS-TC-8S model contains eight Cisco UCS C220 Cache Servers,
one Cisco UCS C220 Management Server, and three NetApp E2724 or IBM DS3524 SAN storage
enclosures.
•
Cisco VDS-TC-16S: The Cisco VDS-TC-16S model contains 16 Cisco UCS C220 Cache Servers,
one Cisco UCS C220 Management Server, and six NetApp E2724 or five IBM DS3524 SAN storage
enclosures.
Each model can be installed in a redundant and a non-redundant configuration.
Obtaining Documentation and Submitting a Service Request
For information on obtaining documentation, submitting a service request, and gathering additional
information, see the monthly What’s New in Cisco Product Documentation, which also lists all new and
revised Cisco technical documentation, at:
http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html
Subscribe to the What’s New in Cisco Product Documentation as an RSS feed and set content to be
delivered directly to your desktop using a reader application. The RSS feeds are a free service. Cisco currently
supports RSS Version 2.0.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
viii
OL-31421-04
CH A P T E R
1
Prerequisites and C-Series Cluster Physical
Installation
This chapter outlines the preliminary requirements for installing a VDS TC C-Series Cluster platform
and describes how to connect both the power cables to the storage enclosure PDUs and the rack PDU,
and the network cabling scheme for the VDS TC Cache Engines, the VDS TC Management Server, and
the storage enclosures.
This chapter contains the following sections:
•
Prerequisites
•
Rack Mounting
•
Power Cabling
•
Network Cabling
•
Additional Steps
Prerequisites
Required Software
Before installing the VDS TC C-Series Cluster system, you must obtain the VDS TC ISO disk image
from Cisco.
Firmware Versions
The following table describes the supported hardware and firmware for a VDS TC C-Series Cluster
installation:
Note
Always refer to the Release Notes for your product to confirm the required firmware and image files.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
1-1
Chapter 1
Prerequisites and C-Series Cluster Physical Installation
Rack Mounting
Hardware Component
Model
Required Firmware Version and Image File
Management Server
Cisco UCS C220-M3S
Cisco UCS C220-M3S:
Cache Engine
Storage enclosure
Cisco UCS C220-M3S
IBM DS3524
•
Firmware version: 2.0(6f)
•
Image file: ucs-c220-huu-2.0.6f.iso
Cisco UCS C220-M3S:
•
Firmware version: 2.0(6f)
•
Image file: ucs-c220-huu-2.0.6f.iso
IBM DS3524:
or
•
Controller BIOS version: 07.86.46.00
NetApp E2724
•
Controller Image file:
ibm_fw_ds3k_07864600_anyos_anycpu.zip
•
HDD BIOS version: 4.18
•
HDD Image file:
ibm_fw_ds3khdd_4.18_anyos_anycpu.zip
•
Storage Manager 10.86
(SM10.86_Linux_64bit_x86-64_SMIA-10.8
6.x5.43.tgz)
NetApp E2724:
•
Controller BIOS version: 08.20.05.00
•
Storage Manager 11.20.0A
(SMIA-LINUXX64-11.20.0A00.0015.bin)
To check the firmware version on the Cisco C-Series server, use the CIMC.
Tip
For instructions on how to perform a firmware upgrade on the Cisco UCS C-Series Servers, see the Cisco
UCS C-Series Rack-Mount Server BIOS Upgrade Guide document available at
http://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/c/sw/bios/b_Upgrading_BIOS_Firmware
.html.
Rack Mounting
To mount the VDS TC Cluster server in a rack, refer to the Cisco UCS C220M3S installation guide.
Power Cabling
Using standard power cables, connect the power cables to both of the storage enclosure PSUs and the
rack PDU.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
1-2
OL-31421-04
Chapter 1
Prerequisites and C-Series Cluster Physical Installation
Network Cabling
Network Cabling
There are eight different configurations available in a VDS TC C-Series Cluster installation:
•
VDS-TC-2S non-redundant
•
VDS-TC-2S redundant
•
VDS-TC-4S non-redundant
•
VDS-TC-4S redundant
•
VDS-TC-8S non-redundant
•
VDS-TC-8S redundant
•
VDS-TC-16S non-redundant
•
VDS-TC-16S redundant
This section provides an overview of cabling the connections for the cache engines, the management
server, and the storage enclosures. For a complete cabling diagram for one of these VDS TC
configurations, please see Appendix A, “Cisco VDS TC C-Series Cabling Guides when Using the
NetApp E2724 Storage Enclosures”or Appendix B, “Cisco VDS TC C-Series Cabling Guides when
Using IBM DS3524 Storage Enclosures”.
Cache Engines
Make the following connections on each of the cache engine servers.
Figure 1-1
Table 1-1
Cache Server Connections
Cache Server Connections
Port # Description
Wire Connection
Notes
1
Power Supply 1
PDU A
2
Power Supply 2
PDU B
3
10GbE data and iSCSI
network
10GbE Port 1; Connects to
the first data switch
4
10GbE data and iSCSI
network
10GbE Port 2; Connects to
the second data switch if
available, or to the first
management switch if not.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
1-3
Chapter 1
Prerequisites and C-Series Cluster Physical Installation
Network Cabling
Table 1-1
Note
Cache Server Connections (continued)
Port # Description
Wire Connection
Notes
5
Interface 1 (eth0)
Eth0 management
Connects to the first
management switch
6
Interface 2 (eth1)
Eth1 redundant
management
Connects to the second
management switch if
available, or to the first
management switch if not.
Please see Appendix A, “Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724
Storage Enclosures” or Appendix B, “Cisco VDS TC C-Series Cabling Guides when Using IBM
DS3524 Storage Enclosures” for a full cabling diagram.
Management Server
Make the following connections on the management server to the management switch.
Figure 1-2
Table 1-2
Note
Management Server Connections
Management Server Connections
Port #
Description
Wire Connection
Notes
1
Power supply 1
PDU A
2
Power supply 2
PDU B
3
Interface 1 (eth0)
Eth0 management
Connects to first
management switch
4
Interface 2 (eth1)
Eth1 redundant
management
Connects to the second
management switch if
available, or to the first
management switch if not.
Please see Appendix A, “Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724
Storage Enclosures” or Appendix B, “Cisco VDS TC C-Series Cabling Guides when Using IBM
DS3524 Storage Enclosures” for a full cabling diagram.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
1-4
OL-31421-04
Chapter 1
Prerequisites and C-Series Cluster Physical Installation
Network Cabling
Storage Enclosures
NetApp E2724 Storage Enclosure
Make the following connections on each storage enclosure.
Figure 1-3
Table 1-3
NetApp E2724 Storage Connections
NetApp E2724 Storage Connections
Port #
Description
Wire Connection
Notes
1
iSCSI connection
Connects to the first
management switch
2
iSCSI connection
Connects to the second
management switch if present, or
to the first management switch if
not.
3
iSCSI connection
Connects to the first
management switch
4
iSCSI connection
Connects to the second
management switch if present, or
to the first management switch if
not.
5
Management 1
controller A
Man1 StoX
Connects to the first
management switch.
6
Management 2
controller B
Man2 StoX
Connects to the second
management switch if present, or
to the first management switch if
not.
7
Power Supply 1
PDU A
8
Power Supply 2
PDU B
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
1-5
Chapter 1
Prerequisites and C-Series Cluster Physical Installation
Network Cabling
Note
The storage enclosure has two controllers.
Note
Please see Appendix A, “Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724
Storage Enclosures” for a full cabling diagram.
Follow these steps to wire the storage server:
Step 1
Connect the two management cables between the two management ports on the storage server and the
ports on the management switches.
Step 2
Connect the iSCSI storage data cables between the storage server iSCSI in controller A and the
management switch. Connect the iSCSI storage data cables between the storage server iSCSI in
controller B and the management switch.
IBM DS3524 Storage Enclosure
Make the following connections on each storage enclosure.
Figure 1-4
Table 1-4
IBM DS3524 Storage Connections
Storage Connections
Port # Description
Wire Connection
Notes
1
iSCSI connection
Connects to the first
management switch
2
iSCSI connection
Connects to the second
management switch if
present, or to the first
management switch if not
3
iSCSI connection
Connects to the first
management switch
4
iSCSI connection
Connects to the second
management switch if
present, or to the first
management switch if not
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
1-6
OL-31421-04
Chapter 1
Prerequisites and C-Series Cluster Physical Installation
Additional Steps
Table 1-4
Storage Connections
Port # Description
Wire Connection
Notes
5
iSCSI connection
Connects to the first
management switch
6
iSCSI connection
Connects to the second
management switch if
present, or to the first
management switch if not
7
iSCSI connection
Connects to the first
management switch
8
iSCSI connection
Connects to the second
management switch if
present, or to the first
management switch if not
9
Management 1
controller A
Man1 StoX
Connects to the first
management switch
10
Management 2
controller B
Man2 StoX
Connects to the second
management switch if
present, or to the first
management switch if not
11
Power supply 1
PDU A
12
Power supply 2
PDU B
Note
The storage enclosure has two controllers.
Note
Please see Appendix B, “Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage
Enclosures” for a full cabling diagram.
Follow these steps to wire the storage server:
Step 1
Connect the two management cables between the two management ports on the storage server and the
ports on the management switches.
Step 2
Connect the iSCSI storage data cables between the storage server iSCSI in controller A and the
management switch. Connect the iSCSI storage data cables between the storage server iSCSI in
controller B and the management switch.
Additional Steps
You must also complete a proper installation and initial configuration of the Cisco UCS C220. For more
information see the following documents and web pages on www.cisco.com:
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
1-7
Chapter 1
Prerequisites and C-Series Cluster Physical Installation
Additional Steps
•
Cisco UCS C-Series Rack Servers Install and Upgrade Guides web page available at
http://www.cisco.com/en/US/products/ps10493/prod_installation_guides_list.html
•
Cisco UCS C-Series Rack Servers Configuration Guides web page available at
http://www.cisco.com/en/US/products/ps10493/products_installation_and_configuration_guides_l
ist.html
Next you will configure the switches in a cluster installation. This configuration is covered in the next
chapter, Chapter 2, “Configuring the Switches in a C-Series Cluster Installation”.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
1-8
OL-31421-04
CH A P T E R
2
Configuring the Switches in a C-Series Cluster
Installation
The VDS TC C-Series Cluster installation has switches that provide two different functions:
•
Data switch: A Cisco Catalyst 4500-X Series switch is used for the VDS TC data switch, to which
the cache engines are connected. In a redundant configuration there will be two of these switches.
•
Management switch: The VDS TC Management Server, the storage chassis, and the management
ports of the cache engines connect to the management switch. The following management switches
are used depending on the VDS TC configuration and storage enclosure that is used:
– For a VDS TC solution that uses the NetApp E2724 storage chassis:
•A Cisco Nexus 3172TQ Switch can be used as the VDS TC management switch for all VDS TC
C-Series Cluster installations. There will be one management switch for the non-redundant
installations and there will be two management switches for the redundant installations.
•A Cisco SG500 Stackable Managed Switch can be used as the VDS TC management switch for
the VDS-TC-2S non-redundant, VDS-TC-2S redundant, VDS-TC-4S non-redundant, and
VDS-TC-4S redundant configurations. There will be one management switch for the
non-redundant installations and there will be two management switches for the redundant
installations.
– For a VDS TC solution that uses the IBM DS3524 storage chassis:
•A Cisco Catalyst 4948E Ethernet switch is used for the VDS TC management switch in the
VDS-TC-4S, VDS-TC-8S, and VDS-TC-16S configurations. For the VDS-TC-4S and
VDS-TC-8S non-redundant installation, there will be one Cisco Catalyst 4948E management
switch. For a non-redundant VDS-TC-16S installation and the VDS-TC-4S, VDS-TC-8S, and
VDS-TC-16S redundant installations, there will be two Cisco Catalyst 4948E management
switches.
•The VDS-TC-2S configurations use the Cisco 4500-X switch for both the data switch and the
management switch. For a VDS-TC-2S non-redundant configuration, there is only one Cisco
4500-X Series switch. For a VDS-TC-2S redundant configuration, there are two Cisco
4500-X Series switches.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
2-1
Chapter 2
Figure 2-1
Note
Configuring the Switches in a C-Series Cluster Installation
Redundant C-Series Cluster Configuration using NetApp Storage Enclosure
The Cisco 4500-2 and Mgmt-2 are required only for redundant installations.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
2-2
OL-31421-04
Chapter 2
Configuring the Switches in a C-Series Cluster Installation
Initial Setup of the Cluster Switches
Figure 2-2
Note
Redundant C-Series Cluster Configuration using IBM Storage Enclosure
The Cisco 4500-2 is required only for a redundant installation. The 4948-2 switch is required for the
non-redundant VDS-TC-16S installation and the VDS-TC-4S, VDS-TC-8S, and VDS-TC-16S
redundant installations that use an IBM storage enclosure.
Initial Setup of the Cluster Switches
After initially installing the Cisco switches and configuring them with a management IP address and
password, you must perform an initial setup on the switch for the VDS TC connections. You must install
and configure the switches before you install the Cisco VDS TC Management Server.
Preparing for the Configuration
Before you can configure the switches to support the VDS TC installation, you must obtain a copy of the
switch configuration files. The switch configuration files are available in a .tgz file that is available from
the same location as the VDS TC ISO image file on www.cisco.com.
Caution
The example switch configuration files are just examples. Please make sure to edit these files as
appropriate for the network environment of your company.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
2-3
Chapter 2
Configuring the Switches in a C-Series Cluster Installation
Initial Setup of the Cluster Switches
VDS TC Management Switch
Confirm that your management switch is running the correct version of software. The software version
that the switch should use depends on the type of management switch that your configuration uses, as
follows:
•
Note
If you are using the Cisco Catalyst 4948E switch as the management switch, it should run Cisco IOS
Release 15.2(2)E or later, with the LAN BASE W/O CRYPTO feature set, for example
cat4500e-lanbase-mz.152-2.E.bin. You can use the show version command to verify the version and
feature set information for the switch.
The IP BASE W/O CRYPTO feature set can also be used (cat4500e-ipbase-mz.152-2.E.bin).
•
If you are using the Cisco Nexus 3172TQ Switch as the management switch, it should run Cisco
NX-OS Release 6.0(2)U5(1) or later. You can use the show version command to verify the version
and feature set information for the switch.
•
If you are using the Cisco SG500 Switch as the management switch, it should run a software version
1.4.0 or later. You can use the show version command to verify the software version for the switch.
Configure Cisco SG500 Stack
Note
Complete the steps in this section only if you are using Cisco SG500 Switches as the management
switches.
Follow these steps to configure the stack on the Cisco SG500:
Step 1
Connect to the console of the first Cisco SG500 switch.
Step 2
Log into the CLI of the first Cisco SG500 switch and enter the stack native xg-15 xg-16 auto 1 reboot
command. This will cause the switch to reboot.
Step 3
If you have a second Cisco SG500 switch for a redundant configuration, connect to the console of the
second Cisco SG500 switch.
Step 4
Log into the CLI of the second Cisco SG500 switch and enter the stack native xg-15 xg-16 auto 2
reboot command. This will cause the switch to reboot.
Step 5
Continue to the Apply the Switch Configuration section.
Apply the Switch Configuration
You must apply a configuration to the VDS TC management switch. The configuration files are available
in a .tgz file that is available from the same location as the VDS TC ISO image file on www.cisco.com.
Note
There are different configuration files for the Cisco Nexus 3172TQ, Cisco SG500, and the Cisco Catalyst
4948E switch. Make sure that you use the correct configuration file for the model of Cisco switch that
your Cisco VDS TC installation uses.
Use this procedure to copy the appropriate configuration file to the management switch:
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
2-4
OL-31421-04
Chapter 2
Configuring the Switches in a C-Series Cluster Installation
Initial Setup of the Cluster Switches
Procedure
Step 1
Using a text editor, such as Notepad, open the configuration file for your management switch and review
the switch configuration file.
Step 2
Make sure that the configuration file will not overwrite any necessary settings in your current switch
configuration. Make any necessary changes to the switch configuration file that are appropriate for your
installation and save the changes, including the management IP address of the switch.
Step 3
Log into the CLI of the management switch and enter enable to enter Enable mode. You will need the
Enable mode password. If you are using the Cisco SG500 switch as the management switch, do not
perform this step.
Step 4
You should make a backup copy of the current switch configuration before you apply the VDS TC switch
configuration file. To save a copy of the current switch configuration, use the copy run tftp command.
Step 5
After you have backed up your current running configuration, enter the config t command to enter global
configuration mode. The global configuration mode prompt appears, switch(config)#.
Step 6
Copy all of the configuration lines from the switch configuration file that you opened in Step 1 and paste
them into the global configuration mode prompt.
Note
If you are using the Cisco SG500 switch as the management switch in a redundant configuration, apply
the switch configuration file only to the first (master) switch.
Step 7
Enter exit to return to Enable mode.
Step 8
To save the configuration to nvram, enter the command copy run start.
VDS TC Data Switch
The Cisco Catalyst 4500-X Series Switch that you are using for the VDS TC data switch should run
version Cisco IOS XE Release 03.4.4.SG, Universal image, or later. You can use the show version
command to see the version and features information of the switch.
Before you can apply a configuration file to your data switches, you must configure the switches to
support VSS. Follow these steps to configure the Cisco Catalyst 4500-X Series Switches for VSS:
Configuring VSS on the First Switch
Procedure
Step 1
Log into the first Cisco Catalyst 4500-X Series switch and enter global configuration mode.
Step 2
From global configuration mode, follow these steps to assign the Virtual Switch Domain and switch
number:
a.
Note
Enter the command switch virtual domain 10. This will enter the vs-domain configuration mode.
In a multicluster solution, the virtual domain id must be unique within a given network.
b.
From the vs-domain configuration mode, enter the command switch 1.
c.
Enter exit to return to global configuration mode.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
2-5
Chapter 2
Configuring the Switches in a C-Series Cluster Installation
Initial Setup of the Cluster Switches
Step 3
Step 4
From global configuration mode, follow these steps to configure the VSL Port Channel:
a.
Enter the command int Port-channel5. This will enter interface configuration mode.
b.
From interface configuration mode, enter the command switchport.
c.
From interface configuration mode, enter the command switch virtual link 1.
d.
Enter the command no shutdown do enable the port.
e.
Enter exit to return to global configuration mode.
From global configuration mode, follow these steps to configure the VSL ports:
a.
Enter the command int range ten2/1 - 8. This will enter interface range configuration mode.
b.
Enter the command channel-group 5 mode on to assign the ports to the VSL Port Channel.
Configuring VSS on the Second Switch
Note
For non-redundant configurations, do not perform these steps.
Procedure
Step 1
Log into the second Cisco Catalyst 4500-X Series switch and enter global configuration mode.
Step 2
From global configuration mode, follow these steps to assign the Virtual Switch Domain and switch
number:
Step 3
Step 4
a.
Enter the command switch virtual domain 10. This will enter the vs-domain configuration mode.
b.
From the vs-domain configuration mode, enter the command switch 2.
c.
Enter exit to return to global configuration mode.
From global configuration mode, follow these steps to configure the VSL Port Channel:
a.
Enter the command int Port-channel10. This will enter interface configuration mode.
b.
From interface configuration mode, enter the command switchport.
c.
From interface configuration mode, enter the command switch virtual link 2.
d.
Enter the command no shutdown do enable the port.
e.
Enter exit to return to global configuration mode.
From global configuration mode, follow these steps to configure the VSL ports:
a.
Enter the command int range ten2/1 - 8. This will enter interface range configuration mode.
b.
Enter the command channel-group 10 mode on to assign the ports to the VSL Port Channel.
Converting the Data Switches to Virtual Switch Mode
Follow these steps to convert the switches to Virtual Switch Mode:
Step 1
From privilege mode on the first data switch, enter the command switch convert mode virtual. You will
see the following output:
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
2-6
OL-31421-04
Chapter 2
Configuring the Switches in a C-Series Cluster Installation
Initial Setup of the Cluster Switches
Note
This command will save the running configuration and reload the switch.
VDS-TC-8S-4500-X-VSS1#switch convert mode virtual
This command will convert all interface names
to naming convention "interface-type switch-number/slot/port",
save the running config to startup-config and
reload the switch.
Do you want to proceed? [yes/no]: yes
Step 2
When prompted with “Do you want to proceed?[yes/no]:”, enter yes.
Do you want to proceed? [yes/no]: yes
Converting interface names
Building configuration...
Compressed configuration from 6551 bytes to 2893 bytes[OK]
Saving converted configuration to bootflash: ...
Destination filename [startup-config.converted_vs-20130124-062921]?
Please stand by while rebooting the system...
Restarting system.
Rommon (G) Signature verification PASSED
Rommon (P) Signature verification PASSED
FPGA
(P) Signature verification PASSED
Step 3
Note
In a redundant configuration, to convert the second switch to Virtual Switch Mode, from privilege mode
on the second switch, enter the command switch convert mode virtual. If you have a non-redundant
configuration, go to Step 5.
This command will save the running configuration and reload the switch.
VDS-TC-8S-4500-X-VSS2#switch convert mode virtual
This command will convert all interface names
to naming convention "interface-type switch-number/slot/port",
save the running config to startup-config and
reload the switch.
Do you want to proceed? [yes/no]: yes
Step 4
When prompted with “Do you want to proceed? [yes/no]:”, enter yes.
Do you want to proceed? [yes/no]: yes
Converting interface names
Building configuration...
Compressed configuration from 6027 bytes to 2774 bytes[OK]
Saving converted configuration to bootflash: ...
Destination filename [startup-config.converted_vs-20130124-052526]?
Please stand by while rebooting the system...
Restarting system.
Rommon (G) Signature verification PASSED
Rommon (P) Signature verification PASSED
FPGA
(P) Signature verification PASSED
Step 5
After the switches have rebooted, log into the CLI of the primary data switch and enter enable to enter
Enable mode.
Step 6
To confirm the status of the VSS, enter the command show switch virtual. Under the heading
“Executing the command on VSS member switch role = VSS Active, id = 1”, you should see that the
Switch Mode displays “Virtual Switch”, the local switch number is 1, and the local switch operational
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
2-7
Chapter 2
Configuring the Switches in a C-Series Cluster Installation
Initial Setup of the Cluster Switches
mode is “Virtual Switch Active”. Under the heading “Executing the command on VSS member switch
role = VSS Standby, id = 2”, you should se that the Switch Mode displays “Virtual Switch”, the local
switch number is 2, and the local switch operational mode is “Virtual Switch Standby”.
Figure 2-3
Note
Step 7
Confirm VSS Configuration
In a non-redundant configuration, you will not see the Local Switch number 2 information.
If you do not see these results, contact Cisco support.
Next you must apply a configuration to the first VDS TC data switch. The configuration files are
available in a .tgz file that is available from the same location as the VDS TC ISO image file on
www.cisco.com. Follow this procedure to apply the appropriate configuration to the data switch:
Procedure
Step 1
Using a text editor, such as Notepad, open the configuration file for your data switch and review the
switch configuration file.
Step 2
Make sure that the configuration file will not overwrite any necessary settings in your current switch
configuration. Make any necessary changes to the switch configuration file that are appropriate for your
installation and save the changes.
Step 3
Log into the CLI of the data switch and enter enable to enter Enable mode. You will need the Enable
mode password.
Step 4
You should make a backup copy of the current switch configuration before you apply the VDS TC switch
configuration file. To save a copy of the current switch configuration, use the copy command.
Step 5
After you have backed up your current running configuration, enter the config t command to enter global
configuration mode. The global configuration mode prompt, switch(config)#, appears.
Step 6
Copy all of the configuration lines from the switch configuration file that you opened in Step 1 and paste
them into the global configuration mode prompt.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
2-8
OL-31421-04
Chapter 2
Configuring the Switches in a C-Series Cluster Installation
Initial Setup of the Cluster Switches
Note
Because the switches are part of a VSS, you only need to copy the configuration to the first switch and
it will apply the configuration to the second switch.
Note
In a multicluster solution, the MAC address of the vs-domain must be unique between the clusters.
Step 7
Enter exit to return to Enable mode.
Step 8
To save the configuration to nvram, enter the command copy run start.
Next you will install the VDS TC Management Server. This configuration is covered in the next chapter,
Chapter 3, “Management Server Installation”.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
2-9
Chapter 2
Configuring the Switches in a C-Series Cluster Installation
Initial Setup of the Cluster Switches
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
2-10
OL-31421-04
CH A P T E R
3
Management Server Installation
This chapter describes how to configure the VDS TC Management server, including configuring the
BIOS and operating system, internal system disk, and boot image. This chapter contains these sections:
•
Before You Begin
•
Configuring the BIOS and Operating System with CIMC
•
Configuring the Management IP Address and Password for a PID TCE-1300MGR-K9 Management
Server
•
Configuring the Boot Image
•
Copying the ISO to the VDS TC Management Server
•
Starting the VNC Server on the Management Server
Before You Begin
Note
Perform the steps in this section only if you are not using a VDS TC Management server that was
purchased using PID TCE-1300MGR-K9. If you are using a VDS TC Management server that was
purchased using PID TCE-1300MGR-K9, go to the Configuring the Management IP Address and
Password for a PID TCE-1300MGR-K9 Management Server section.
If you are installing a VDS TC Management server that was not purchased using PID
TCE-1300MGR-K9, make sure there is no existing configuration on the Management server. If you do
not have a system direct from the factory, or if you want to reset the Cisco UCS Integrated Management
Controller (CIMC) configuration to factory defaults, perform these steps:
Caution
After you reset the CIMC, you are logged off of the system and you must log back in. You may also lose
connectivity and may need to reconfigure the network settings.
Procedure
Step 1
From the CIMC CLI, enter the command scope cimc to enter the CIMC command mode.
Step 2
From the CIMC command mode, enter the command factory-default to reset the CIMC to factory
defaults.
Step 3
When you are prompted to Continue, press Y to continue resetting the CIMC to the factory defaults.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
3-1
Chapter 3
Management Server Installation
Configuring the BIOS and Operating System with CIMC
Example:
Server# scope cimc
Server /cimc # factory-default
This operation will reset the CIMC configuration to factory default.
All your configuration will be lost.
Continue?[y|N]y
The CIMC factory defaults include the following conditions:
•
SSH is enabled for access to the CIMC CLI. Telnet is disabled.
•
HTTPS is enabled for access to the CIMC GUI.
•
A single user account exists (the user name is admin, and the password is password).
•
DHCP is enabled on the management port.
•
The boot order is EFI, CDROM, PXE (using LoM), FDD, HDD.
•
KVM and vMedia are enabled.
•
USB is enabled.
•
SoL is disabled.
Configuring the BIOS and Operating System with CIMC
Note
Perform the steps in this section only if you are not using a VDS TC Management server that was
purchased using PID TCE-1300MGR-K9. If you are using a VDS TC Management server that was
purchased using PID TCE-1300MGR-K9, go to the Configuring the Management IP Address and
Password for a PID TCE-1300MGR-K9 Management Server section.
You will use the Cisco Integrated Management Controller (CIMC) to configure the VDS TC
management server.
Note
Do not perform these steps until you have completed the proper initial installation of the Cisco UCS
server that is being used as the VDS TC management server. For more information, please refer to the
Server Installation and Service Guide for the UCS C-Series Rack Server model that you are using for the
VDS TC management server, available at
http://www.cisco.com/c/en/us/support/servers-unified-computing/ucs-c-series-rack-servers/products-in
stallation-guides-list.html.
Use this procedure to configure the BIOS and Operating System using the CIMC.
Procedure
Caution
Before you begin these configuration steps, confirm that the VDS TC management server is using the
correct version of BIOS firmware. The BIOS firmware of the Cisco UCS C220 M3S should be Release
2.0(6f). For instructions on how to perform a firmware upgrade see the Cisco UCS C-Series Rack-Mount
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
3-2
OL-31421-04
Chapter 3
Management Server Installation
Configuring the BIOS and Operating System with CIMC
Server BIOS Upgrade Guide available at
http://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/c/sw/bios/b_Upgrading_BIOS_Firmware
.html.
Step 1
Note
Connect to the VDS TC management sever. You can use either a KVM cable and the KVM connector,
or the CIMC to connect to the VDS TC management server.
For more information on how to connect to the VDS TC management server, please refer to the Server
Installation and Service Guide for the UCS C-Series Rack Server model that you are using for the VDS
TC management server, available at
http://www.cisco.com/c/en/us/support/servers-unified-computing/ucs-c-series-rack-servers/products-in
stallation-guides-list.html.
Step 2
Boot up the VDS TC management server. From the Cisco BIOS screen press F8 when prompted. The
CIMC Configuration Utility window appears.
Step 3
From the CIMC Configuration Utility window, configure the following:
•
NIC Mode: Choose Shared LOM.
•
IP (Basic):
– Choose the IPv4 option to configure an IPv4 management address, or choose the IPv6 option
to configure an IPv6 management address.
– Clear the DHCP Enabled option. This is enabled by default.
– Enter the IP address and subnet mask (or prefix length for IPv6) to use for CIMC.
– Enter the default gateway for the CIMC to use.
Note
For a multicluster installation, each cluster should have its own VDS TC management server, and the
CIMC IP address for each management server should be in a different subnet.
•
Step 4
NIC Redundancy: Choose Active-active.
Press F10 to save the configuration and F5 to refresh.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
3-3
Chapter 3
Management Server Installation
Configuring the BIOS and Operating System with CIMC
Figure 3-1
Step 5
Press F1 to access the Additional Settings screens. In the screen that appears, under the Default
User(Basic) settings, enter and re-enter the password for the CIMC user. The default password is
password.
Figure 3-2
Step 6
CIMC Configuration Utility Screen
Additional Settings
Press F10 to Save the password and press <Esc> to Exit the CIMC configuration Utility.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
3-4
OL-31421-04
Chapter 3
Management Server Installation
Configuring the BIOS and Operating System with CIMC
Figure 3-3
Step 7
Open a web browser and enter the IP address that you configured to access CIMC in Step 2. The CIMC
login window appears.
Step 8
Enter the username admin and the password that you configured in Step 2 and click Login. The default
password is password.
Step 9
The Cisco Integrated Management Controller: Server Summary window appears.
CIMC: Server Summary Window
Step 10
From the Server tab, choose Remote Presence. The Remote Presence window appears.
Step 11
Click the Serial Over LAN tab and check the Enabled check box.
Step 12
From the Baud Rate drop-down list choose 115.2 kbps and from the Com Port drop-down list choose
com0.
Step 13
Click the Save Changes button.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
3-5
Chapter 3
Management Server Installation
Configuring the BIOS and Operating System with CIMC
Figure 3-4
Serial Over LAN Window
Step 14
From the Admin tab, choose Communications Services.
Step 15
In the IPMI over LAN Properties section, check the Enabled check box.
Step 16
Click the Save Changes button.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
3-6
OL-31421-04
Chapter 3
Management Server Installation
Configuring the BIOS and Operating System with CIMC
Figure 3-5
Enable IPMI over LAN
Step 17
From the Server tab, choose BIOS.
Step 18
In the BIOS window, click Configure BIOS. The Configure BIOS Parameters window appears.
Step 19
Click the Advanced tab.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
3-7
Chapter 3
Management Server Installation
Configuring the BIOS and Operating System with CIMC
Figure 3-6
Configure BIOS Parameters Window: Advanced Tab on Cisco UCS 220 M3S
s
Step 20
Note
Use the Advanced BIOS Parameters table to configure the settings on the Advanced tab. Use Table 3-1
to configure a Cisco UCS 220M3S.
Parameters that are not listed in the following table should be left set to their default value.
Table 3-1
Cisco UCS 220 M3S Advanced BIOS Parameters
Processor Configuration
State
Hyper - Threading Technology
Disabled
Number Of Enabled Cores
All
Execute Disable
Enabled
Intel VT
Disabled
Intel VT-d
Disabled
Intel VT-d Coherency Support
Disabled
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
3-8
OL-31421-04
Chapter 3
Management Server Installation
Configuring the BIOS and Operating System with CIMC
Intel VT-d ATS Support
Disabled
CPU Performance
High Throughput
Hardware Prefetcher
Disabled
Adjacent Cache Line Prefetch
Disabled
DCU Streamer Prefetch
Disabled
DCU IP Prefetcher
Enabled
Direct Cache Access Support
Enabled
Power Technology
Disabled
Enhanced Intel Speedstep Technology
Enabled
Intel Turbo Boost Technology
Disabled
Processor Power State C6
Disabled
Processor Power State C1 Enhanced
Disabled
Frequency Floor Override
Disabled
P-STATE Coordination
HW ALL
Energy Performance
Performance
Memory Configuration
Status
Select Memory RAS
Maximum Performance
DRAM Clock Throttling
Performance
NUMA
Enabled
Low Voltage DDR Mode
Performance Mode
DRAM Refresh rate
Auto
Channel Interleaving
Auto
Rank Interleaving
Auto
Patrol Scrub
Enabled
Demand Scrub
Enabled
Altitude
300 M
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
3-9
Chapter 3
Management Server Installation
Configuring the BIOS and Operating System with CIMC
QPI Configuration
QPI Link Frequency Select
Onboard Storage
Status
Auto
Status
Onboard SCU Storage Support
Disabled
Onboard SCU Storage SW Stack
LSI SW RAID
USB Configuration
Status
Legacy USB Support
Enabled
Port 60/64 Emulation
Enabled
All USB Devices
Enabled
USB Port:Rear
Enabled
USB Port:Front
Enabled
USB Port:Internal
Enabled
USB Port:KVM
Enabled
USB Port:VMedia
Enabled
USB Port:SD Card
Disabled
PCI Configuration
Status
MMIO above 4GB
Disabled
ASPM Support
Disabled
VGA Priority
Onboard
Serial Configuration
Status
Out-of-Band Mgmt Port
Disabled
Console Redirection
Disabled
Terminal Type
VT100+
Bits per Second
115200
Flow Control
None
Putty KeyPad
ESCN
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
3-10
OL-31421-04
Chapter 3
Management Server Installation
Configuring the BIOS and Operating System with CIMC
Redirection After BIOS POST
LOM and PCIe Slots Configuration
Always Enable
Status
All Onboard LOM Ports
Enabled
LOM Port 0 OptionROM
Enabled
LOM Port 1 OptionROM
Enabled
All PCIe Slots OptionROM
Enabled
PCIe Slot:1 OptionROM
Enabled
PCIe Slot:2 OptionROM
Enabled
PCIe Mezzanine OptionROM
Enabled
PCIe Slot:1 Link Speed
GEN3
PCIe Slot:2 Link Speed
GEN3
Step 21
Click Save Changes.
Step 22
From the Server tab, choose Power Policies. The Power Policies window appears.
Step 23
In the Power Policies window configure the following settings:
Step 24
•
From the Power Restore Policy drop-down list, choose Power On.
•
From the Power Delay Type drop-down list, choose Fixed.
•
In the Power Delay Value text box, enter 0.
•
From the Fan Policy drop-down list, choose Maximum Power.
Click Save Changes.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
3-11
Chapter 3
Management Server Installation
Configuring the BIOS and Operating System with CIMC
Figure 3-7
Power Policies Screen
Step 25
From the Server tab choose BIOS.
Step 26
From the BIOS window, click Configure Boot Order.
Step 27
Click OK to close the Manage Boot Order dialog box. The Configure Boot Order dialog box appears.
Step 28
Add the following Device Types to the Boot Order list:
Step 29
•
HDD
•
CDROM
Click Apply.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
3-12
OL-31421-04
Chapter 3
Management Server Installation
Configuring the BIOS and Operating System with CIMC
Figure 3-8
Configure Boot Order Window
Step 30
The BIOS is now configured.
Step 31
From the Server tab, choose Summary.
Step 32
In the Actions pane, click Launch KVM Console. This will launch the KVM Console window for this
server. You will use the KVM Console to configure the boot image in the next section.
Note
If you do not have Java™ installed on your computer, or your version is older than that required by the
KVM Console, a dialog box will appear. Install or update Java ™ and continue with the installation
procedure.
Step 33
In the Actions pane, click Hard Reset Server.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
3-13
Chapter 3
Management Server Installation
Configuring the Management IP Address and Password for a PID TCE-1300MGR-K9 Management Server
Figure 3-9
Step 34
Note
Step 35
Server Summary Window
From the Hard Reset Server popup window, click OK to reset the server.
This will drop your connection to the CIMC UI momentarily and you will have to log back into the
system.
Continue to the Configuring the Boot Image section.
Configuring the Management IP Address and Password for a PID
TCE-1300MGR-K9 Management Server
Note
Perform the steps in this section only if you purchased a VDS TC management server using PID
TCE-1300MGR-K9.
The PID TCE-1300MGR-K9 ships with a default management IP address (10.11.12.253) and password
that you should change before installing VDS TC. Follow these steps to changes these settings:
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
3-14
OL-31421-04
Chapter 3
Management Server Installation
Configuring the Management IP Address and Password for a PID TCE-1300MGR-K9 Management Server
Procedure
Step 1
Note
Connect to the VDS TC management server. You can use either a KVM cable and the KVM connector,
or you can use a web browser and the default IP address of 10.11.12.253 that is preconfigured on the
TCE-1300MGR-K9 VDS TC management server to connect to the CIMC. The default password is preset
by Cisco specifically for VDS-TC. Please contact your Cisco account system engineer if you need this
password.
For more information on how to connect to the VDS TC management server, refer to the Cisco UCS
C-Series Rack Servers Install and Upgrade Guides web page available at
http://www.cisco.com/en/US/products/ps10493/prod_installation_guides_list.html.
Step 2
Boot up the VDS TC management server. From the Cisco BIOS screen press F8 when prompted. The
CIMC Configuration Utility window appears.
Step 3
From the CIMC Configuration Utility window, configure the following:
•
IPV4 (Basic):
– Enter the IP address and subnet mask to use for CIMC. This should be an IP address on your
network.
– Enter the default gateway for the CIMC to use.
Note
For a multicluster installation, each cluster should have its own VDS TC management server, and the
CIMC IP address for each management server should be in a different subnet.
•
Default User (Basic): Enter and re-enter a new password for the CIMC user. The default password
has been preconfigured by Cisco specifically for VDS TC. Please contact your Cisco account system
engineer for details.
Step 4
Press F10 to save the configuration and F5 to refresh.
Step 5
Open a web browser and enter the IP address that you configured in Step 3. The CIMC login window
appears.
Step 6
Enter the username admin and the password that you configured in Step 3 and click Login. The default
password has been preconfigured by Cisco specifically for VDS TC. Please contact your Cisco account
system engineer for details.
Step 7
The Cisco Integrated Management Controller: Server Summary window appears.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
3-15
Chapter 3
Management Server Installation
Configuring the Boot Image
Figure 3-10
CIMC: Server Summary Window
Step 8
From the Server tab, choose Summary.
Step 9
In the Actions pane, click Launch KVM Console. This will launch the KVM Console window for this
server. You will use the KVM Console to configure the boot image in the next section.
Note
If you do not have Java™ installed on your computer, or your version is older than that required by the
KVM Console, a dialog box will appear. Install or update Java ™ and continue with the installation
procedure.
Configuring the Boot Image
The next step in the VDS TC C-Series cluster installation process is to configure the boot image. Follow
this procedure to configure the boot image:
Procedure
Step 1
From the KVM console, click the Virtual Media tab.
Step 2
If you see the Unencrypted Virtual Media Session window appears, choose Accept this session and click
Apply.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
3-16
OL-31421-04
Chapter 3
Management Server Installation
Configuring the Boot Image
Figure 3-11
Step 3
Click Add Image.
Figure 3-12
Step 4
Unencrypted Virtual Media Session
Virtual Media Tab
Browse for and select the ISO installer image and click Open.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
3-17
Chapter 3
Management Server Installation
Configuring the Boot Image
Figure 3-13
Step 5
Browse for Image
Check the Mapped check box for the newly added ISO image file.
Figure 3-14
Mapped ISO File
Step 6
Reboot the system by choosing Macros > Static Macros > Ctrl-Alt-Del from the KVM console, or from
the CIMC user interface choose Server > Summary and click Hard Reset Server.
Step 7
As the system reboots, switch back to the KVM console and click the KVM tab.
Step 8
When you see the prompt that says to press F6 to enter the boot menu, press F6. The Please Select Boot
Device dialog box appears.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
3-18
OL-31421-04
Chapter 3
Management Server Installation
Configuring the Boot Image
Figure 3-15
System Reboot Window
Step 9
Using the up and down arrows, choose Cisco vKVM-Mapped vDVD1.22. The system will reboot from
the virtual ISO image.
Step 10
When the VDS-TC Installer environment displays in the KVM console window, choose Installer - No
Serial.
Figure 3-16
Step 11
VDS TC Installer Window
When the Welcome screen appears, enter Y to continue the installation process.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
3-19
Chapter 3
Management Server Installation
Configuring the Boot Image
Figure 3-17
Step 12
Welcome Screen
When the Firmware Checks window appears, click Yes to proceed with running a firmware check. Note
that this may take a while.
Figure 3-18
Firmware Checks Window
Step 13
After the firmware check is finished, if your firmware is up to date, you will see the following message
at the bottom of the screen: “Press Enter to Continue.” When you see this message, press Enter.
Note
If your firmware is not up to date, you must stop the installation process and update the firmware. After
the firmware is up to date, you can restart the installation process.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
3-20
OL-31421-04
Chapter 3
Management Server Installation
Configuring the Boot Image
Figure 3-19
Step 14
When you see the Choose the Appliance Deployment window, choose Management and select OK.
Figure 3-20
Step 15
Note
Press Enter to Continue
Choose the Appliance Deployment Window
When prompted, enter a management IP address for the VDS TC management server and choose OK.
You will use this IP address to connect to the CLI of the VDS TC management server using SSH and to
connect to the VDS TC management server using VDS TC Manager.
For a multicluster installation, each cluster should have its own VDS TC management server, and the
management IP address for each management server should be in a different subnet.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
3-21
Chapter 3
Management Server Installation
Configuring the Boot Image
Figure 3-21
Step 16
When prompted, enter the subnet mask for the management IP address and choose OK.
Figure 3-22
Step 17
Enter IP Address Window
Enter Subnet Mask Window
When prompted, enter the default gateway for the VDS TC management server to use and choose OK.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
3-22
OL-31421-04
Chapter 3
Management Server Installation
Configuring the Boot Image
Step 18
Figure 3-23
Enter Default Gateway Window
Figure 3-24
Confirm Configuration
From the KVM window you will see the installation begin.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
3-23
Chapter 3
Management Server Installation
Configuring the Boot Image
Figure 3-25
Note
Step 19
Please be aware that the installation may take more than an hour.
When the installation completes, you must unmap the ISO image file. When the “Installation completed.
Press <Enter> to reboot.” message appears, press Enter.
Figure 3-26
Note
VDS TC Installation Process: System Image Dumping Screen
Installation Completed Window
Wait for the system to reboot and display the BIOS splash screen, as shown in Figure Figure 3-15
“System Reboot Window” before proceeding to the next step.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
3-24
OL-31421-04
Chapter 3
Management Server Installation
Copying the ISO to the VDS TC Management Server
Step 20
From the KVM console window, click the Virtual Media tab and uncheck the Mapped check box next
to the ISO image file.
Step 21
In the Unmap Drive Requested dialog box, click Yes to confirm the unmapping the image file. This
unmounts the ISO image.
Figure 3-27
Unmap Drive Requested Window
Step 22
Reboot the system by choosing Macros > Static Macros > Ctrl-Alt-Del from the KVM console, or by
using the CIMC user interface.
Note
The first time you reboot the system after the installation can take up to 10 minutes because of the initial
disk checkup.
Copying the ISO to the VDS TC Management Server
Next you must copy the ISO image to the management server. Follow this procedure to copy the ISO
image to the VDS TC Management Server.
Procedure
Step 1
Using SFTP software, such as WinSCP, connect to the VDS TC Management Server using the IP address
that you assigned during the “Configuring the Boot Image” process. Log in using the user name padmin
and the password that was provided by Cisco.
Step 2
Create the folder /opt/pang/iso. Copy the ISO file that you received from Cisco into this folder.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
3-25
Chapter 3
Management Server Installation
Starting the VNC Server on the Management Server
Note
You must copy the ISO image to the VDS TC Management Server because it is the only system that has
access to the management interfaces of the cache engines and the CIMC.
Starting the VNC Server on the Management Server
Follow this procedure to start the VNC server on the VDS TC Management Server:
Procedure
Step 1
Using SSH software, such as Putty, open an SSH connection to the IP address that was assigned to the
VDS TC Management Server.
Step 2
Log into the system using the username padmin and the password provided by Cisco.
Step 3
Enter the command sudo -l to change to superuser. Enter the password for the root user when prompted.
This password is provided by Cisco.
Step 4
Enter the command vncserver :1 to start the VNC Server.
Step 5
Use VNC to connect from your local computer to the VDS TC Management Server, using the IP address
that you configured.
Figure 3-28
VNC Viewer
Next you will install the VDS TC Cache Engine. This configuration is covered in the next chapter,
Chapter 4, “Cache Engine Servers Installation”.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
3-26
OL-31421-04
CH A P T E R
4
Cache Engine Servers Installation
This chapter describes how to configure the VDS TC Cache Engine servers in a Cisco C-Series cluster
installation including configuring the BIOS and operating system. This chapter includes the following
sections:
•
Before You Begin
•
Configuring the BIOS and Operating System with CIMC
•
Configuring the Management IP Address and Password for a PID TCE-1300CE-K9 Cache Engine
•
Importing the Cisco VIC Adapters Configuration
•
Configuring the Boot Image
Before You Begin
Note
Perform the steps in this section only if you are not using a VDS TC Cache Engine that was purchased
using PID TCE-1300CE-K9. If you are using a VDS TC Cache Engine that was purchased using PID
TCE-1300CE-K9, go to the Configuring the Management IP Address and Password for a PID
TCE-1300CE-K9 Cache Engine section.
The PID TCE-1300CE-K9 will come preconfigured with a CIMC user password. To obtain this
password, contact your Cisco account team system engineer. The PID TCE-1300CE-K9 also comes
preconfigured with a default IP address of 10.11.12.253.
If you are installing a VDS TC Cache Engine that was not purchased using PID TCE-1300CE-K9, make
sure there is no existing configuration on the Management server. If you do not have a system direct from
the factory, or if you want to reset the Cisco UCS Integrated Management Controller (CIMC)
configuration to factory defaults, perform these steps:
Caution
After you reset the CIMC, you are logged off of the system and you must log back in. You may also lose
connectivity and may need to reconfigure the network settings.
Procedure
Step 1
From the CIMC CLI, enter the command scope cimc to enter the CIMC command mode.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
4-1
Chapter 4
Cache Engine Servers Installation
Configuring the BIOS and Operating System with CIMC
Step 2
From the CIMC command mode, enter the command factory-default to reset the CIMC to factory
defaults.
Step 3
When you are prompted to Continue, press Y to continue resetting the CIMC to the factory defaults.
Example:
Server# scope cimc
Server /cimc # factory-default
This operation will reset the CIMC configuration to factory default.
All your configuration will be lost.
Continue?[y|N]y
The CIMC factory defaults include the following conditions:
•
SSH is enabled for access to the CIMC CLI. Telnet is disabled.
•
HTTPS is enabled for access to the CIMC GUI.
•
A single user account exists (the user name is admin, and the password is password).
•
DHCP is enabled on the management port.
•
The boot order is EFI, CDROM, PXE (using LoM), FDD, HDD.
•
KVM and vMedia are enabled.
•
USB is enabled.
•
SoL is disabled.
Configuring the BIOS and Operating System with CIMC
Note
Perform the steps in this section only if you are not using a VDS TC Cache Engine that was purchased
using PID TCE-1300CE-K9. If you are using a VDS TC Cache Engine that was purchased using PID
TCE-1300CE-K9, go to the Configuring the Management IP Address and Password for a PID
TCE-1300CE-K9 Cache Engine section.
The PID TCE-1300CE-K9 comes preconfigured with a CIMC user password. To obtain this password,
contact your Cisco account team system engineers. The PID TCE-1300CE-K9 also comes preconfigured
with a default IP address of 10.11.12.253.
You will use the Cisco Integrated Management Controller (CIMC) to configure the VDS TC Cache
Engine servers.
Note
Do not perform these steps until you have completed the proper initial installation of the Cisco UCS
servers that are being used as cache engines. For more information, please refer to the Server Installation
and Service Guide for the UCS C-Series Rack Server model that you are using for the VDS TC cache
engines available at
http://www.cisco.com/c/en/us/support/servers-unified-computing/ucs-c-series-rack-servers/products-in
stallation-guides-list.html.
Use this procedure to configure the BIOS and Operating System with CIMC.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
4-2
OL-31421-04
Chapter 4
Cache Engine Servers Installation
Configuring the BIOS and Operating System with CIMC
Note
This procedure needs to be completed on all Cache Engines.
Procedure
Caution
Before you begin these configuration steps, confirm that the Cisco C220 M3S cache engine is using the
correct version of BIOS firmware. The BIOS firmware of the Cisco UCS C220 M3S should be Release
2.0(6f). For instructions on how to perform a firmware upgrade see the Cisco UCS C-Series Rack-Mount
Server BIOS Upgrade Guide available at
http://www.cisco.com/c/en/us/td/docs/unified_computing/ucs/c/sw/bios/b_Upgrading_BIOS_Firmware
.html.
Step 1
Connect to the VDS TC cache engine. You can use either a KVM cable and the KVM connector, or the
CIMC to connect to the VDS TC cache engine.
Note
For more information on how to connect to the VDS TC management server, please refer to the Server
Installation and Service Guide for the UCS C-Series Rack Server model that you are using for the VDS
TC management server, available at
http://www.cisco.com/c/en/us/support/servers-unified-computing/ucs-c-series-rack-servers/products-in
stallation-guides-list.html.
Step 2
Boot up the VDS TC cache engine. From the Cisco BIOS screen press F8 when prompted. The CIMC
Configuration Utility window appears.
Step 3
If you are using the Cisco UCS C220-M3S for the cache engines, configure the following settings from
the CIMC Configuration Utility window:
•
NIC Mode: Choose Shared LOM.
•
IP (Basic):
– Choose IPv4.
– Clear the DHCP Enabled option. This is enabled by default.
– CIMC IP: Enter 10.11.12.1xx where xx is the number of the cache engine you are configuring.
For example if you are configuring VDS TC Cache Engine 01, enter the IP address
10.11.12.101. If you are configuring VDS TC Cache Engine 16, enter the IP address
10.11.12.116.
– Subnet mask: Enter 255.255.255.0.
– Gateway: Leave this value at 0.0.0.0.
•
Step 4
NIC Redundancy: Choose Active-active
Press F10 to save the configuration and F5 to refresh.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
4-3
Chapter 4
Cache Engine Servers Installation
Configuring the BIOS and Operating System with CIMC
Figure 4-1
Step 5
Press F1 to access the Additional Settings screens. In the screen that appears, under the Default
User(Basic) settings, enter and re-enter the password for the CIMC user. The default password is
password.
Figure 4-2
Step 6
CIMC Configuration Utility Screen: iSCSI and Management on Different NICs
Additional Settings
Press F10 to Save the password and press <Esc> to Exit the CIMC configuration Utility.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
4-4
OL-31421-04
Chapter 4
Cache Engine Servers Installation
Configuring the BIOS and Operating System with CIMC
Caution
Step 7
You must use the password that is provided by Cisco specifically for VDS TC cache engines and you
must not change this password. For more information on the password, contact your Cisco account
system engineer.
If you do not already have a VNC client connection open to the VDS TC Management Server, open one
now. If you encounter problems opening a VNC client connection to the VDS TC Management Server,
you may need to restart VNC Server 1 on the VDS TC Management Server. Follow these steps to restart
this server:
a.
From an SSH connection to the VDS TC Management server where you are logged in with root
permissions, enter the command rm /tmp/.X11-unix/X1.
b.
Enter the command vncserver :1 to start the VNC Server.
Note
If you have problems restarting the VNC Server 1 instance, you can also start another VNC
Server instance by entering the command vncserver :2.
Step 8
Enter the whoami command to determine the username of the current session. Make sure that you are
logged in as root. If you are not logged in as root, enter the su root command to switch to the root user.
Enter the password that was provided by Cisco for the root account.
Step 9
From the VNC console, enter the command firefox &.
Figure 4-3
Step 10
VNC Console
In the Firefox window that opens, enter https://bmc-X, where X is the number of the VDS TC Cache
Engine to connect to the CIMC of the VDS TC Cache Engine that you are configuring. For example, if
you are configuring VDS TC Cache Engine 1, enter https://bmc-1.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
4-5
Chapter 4
Cache Engine Servers Installation
Configuring the BIOS and Operating System with CIMC
Figure 4-4
FireFox URL
Step 11
The CIMC login window appears. Enter the username admin and the password that was provided by
Cisco specifically for VDS TC cache engines.
Step 12
The Cisco Integrated Management Controller: Server Summary window appears.
Step 13
From the Server tab, choose Remote Presence. The Remote Presence window appears.
Step 14
Click the Serial Over LAN tab and check the Enabled check box.
Step 15
Ensure that the Baud Rate is set to 115.2 kbps.
Step 16
Click the Save Changes button.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
4-6
OL-31421-04
Chapter 4
Cache Engine Servers Installation
Configuring the BIOS and Operating System with CIMC
Figure 4-5
Serial Over LAN Window
Step 17
From the Admin tab, choose Communications Services.
Step 18
In the IPMI over LAN Properties section, check the Enabled check box.
Step 19
Click the Save Changes button.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
4-7
Chapter 4
Cache Engine Servers Installation
Configuring the BIOS and Operating System with CIMC
Figure 4-6
Enable IPMI over LAN
Step 20
From the Server tab, choose BIOS.
Step 21
In the BIOS window, click Configure BIOS. The Configure BIOS Parameters window appears.
Step 22
Click the Advanced tab.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
4-8
OL-31421-04
Chapter 4
Cache Engine Servers Installation
Configuring the BIOS and Operating System with CIMC
Figure 4-7
Step 23
Configure BIOS Parameters Window: Advanced Tab on Cisco UCS 220 M3S
Use the Advanced BIOS Parameters table to configure the settings on the Advanced tab. Use Table 4-1
to configure a Cisco UCS 220M3S.
Table 4-1 Cisco UCS 220M3S Advanced BIOS Parameters
Processor Configuration
State
Hyper - Threading Technology
Enabled
Number Of Enabled Cores
All
Execute Disable
Enabled
Intel VT
Disabled
Intel VT-d
Disabled
Intel VT-d Coherency Support
Disabled
Intel VT-d ATS Support
Disabled
CPU Performance
High Throughput
Hardware Prefetcher
Disabled
Adjacent Cache Line Prefetch
Disabled
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
4-9
Chapter 4
Cache Engine Servers Installation
Configuring the BIOS and Operating System with CIMC
Table 4-1 Cisco UCS 220M3S Advanced BIOS Parameters (continued)
DCU Streamer Prefetch
Disabled
DCU IP Prefetcher
Enabled
Direct Cache Access Support
Enabled
Power Technology
Disabled
Enhanced Intel Speedstep Technology
Enabled
Intel Turbo Boost Technology
Enabled
Processor Power State C6
Disabled
Processor Power State C1 Enhanced
Disabled
Frequency Floor Override
Disabled
P-STATE Coordination
HW ALL
Energy Performance
Performance
Memory Configuration
Status
Select Memory RAS
Maximum Performance
DRAM Clock Throttling
Performance
NUMA
Enabled
Low Voltage DDR Mode
Performance Mode
DRAM Refresh rate
Auto
Channel Interleaving
Auto
Rank Interleaving
Auto
Patrol Scrub
Enabled
Demand Scrub
Enabled
Altitude
300 M
QPI Configuration
QPI Link Frequency Select
Onboard Storage
Onboard SCU Storage Support
Status
Auto
Status
Disabled
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
4-10
OL-31421-04
Chapter 4
Cache Engine Servers Installation
Configuring the BIOS and Operating System with CIMC
Table 4-1 Cisco UCS 220M3S Advanced BIOS Parameters (continued)
Onboard SCU Storage SW Stack
USB Configuration
LSI SW RAID
Status
Legacy USB Support
Enabled
Port 60/64 Emulation
Enabled
All USB Devices
Enabled
USB Port:Rear
Enabled
USB Port:Front
Enabled
USB Port:Internal
Enabled
USB Port:KVM
Enabled
USB Port:VMedia
Enabled
USB Port:SD Card
Disabled
PCI Configuration
Status
MMIO above 4GB
Disabled
ASPM Support
Disabled
VGA Priority
Onboard
Serial Configuration
Status
Out-of-Band Mgmt Port
Disabled
Console Redirection
Disabled
Terminal Type
VT100+
Bits per Second
115200
Flow Control
None
Putty KeyPad
ESCN
Redirection After BIOS POST
Always Enable
LOM and PCIe Slots Configuration
Status
All Onboard LOM Ports
Enabled
LOM Port 0 OptionROM
Enabled
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
4-11
Chapter 4
Cache Engine Servers Installation
Configuring the BIOS and Operating System with CIMC
Table 4-1 Cisco UCS 220M3S Advanced BIOS Parameters (continued)
LOM Port 1 OptionROM
Enabled
All PCIe Slots OptionROM
Enabled
PCIe Slot:1 OptionROM
Enabled
PCIe Slot:2 OptionROM
Enabled
PCIe Mezzanine OptionROM
Enabled
PCIe Slot:1 Link Speed
GEN3
PCIe Slot:2 Link Speed
GEN3
Step 24
Click Save Changes.
Step 25
When you receive the message “Reboot Host Immediately is not selected; BIOS settings will be applied
only on next host reboot. Continue?” click Yes.
Step 26
From the Server tab, choose Power Policies. The Power Policies window appears.
Step 27
In the Power Policies window configure the following settings:
Step 28
•
From the Power Restore Policy drop-down list, choose Power On.
•
From the Power Delay Type drop-down list, choose Fixed.
•
From the Power Delay Value drop-down list, choose 0.
•
From the Fan Policy drop-down list, choose Maximum Power.
Click Save Changes.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
4-12
OL-31421-04
Chapter 4
Cache Engine Servers Installation
Configuring the BIOS and Operating System with CIMC
Figure 4-8
Power Policies Screen
Step 29
From the Server tab choose BIOS.
Step 30
From the BIOS window, click Configure Boot Order.
Step 31
Click OK to close the Manage Boot Order dialog box. The Configure Boot Order dialog box appears.
Step 32
Add the following Device Types to the Boot Order list:
Step 33
•
HDD
•
CDROM
Click Apply.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
4-13
Chapter 4
Cache Engine Servers Installation
Configuring the Management IP Address and Password for a PID TCE-1300CE-K9 Cache Engine
Figure 4-9
Configure Boot Order Window
Step 34
The BIOS is now configured.
Step 35
Continue to the Importing the Cisco VIC Adapters Configuration section.
Configuring the Management IP Address and Password for a PID
TCE-1300CE-K9 Cache Engine
Note
Perform the steps in this section only if you purchased a VDS TC cache engine using PID
TCE-1300CE-K9.
Note
You must perform these steps on all Cache Engines. Do not power on the next Cache Engine until you
have finished configuring the current Cache Engine. For example, while you are configuring Cache
Engine 1, all other Cache Engines should be powered off. After you finish configuring Cache Engine 1,
you can power on Cache Engine 2, but all other Cache Engines should remain powered off until you are
ready to configure them.
The PID TCE-1300CE-K9 ships with a default management IP address of 10.11.12.253 that you must
change before installing VDS TC. Follow these steps to changes these settings:
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
4-14
OL-31421-04
Chapter 4
Cache Engine Servers Installation
Configuring the Management IP Address and Password for a PID TCE-1300CE-K9 Cache Engine
Procedure
Step 1
Connect to the VDS TC cache engine. You can use either a KVM cable and the KVM connector, or you
can use a web browser and the default IP address of 10.11.12.253 that is preconfigured on the
TCE-1300CE-K9 VDS TC cache engine to connect to the CIMC. The password is preconfigured by
Cisco specifically for VDS-TC cache engines. Please contact your Cisco account system engineer for
details.
Note
For more information on how to connect to the VDS TC cache engine, refer to the Cisco UCS C-Series
Rack Servers Install and Upgrade Guides web page available at
http://www.cisco.com/en/US/products/ps10493/prod_installation_guides_list.html.
Step 2
Boot up the VDS TC cache engine. From the Cisco BIOS screen press F8 when prompted. The CIMC
Configuration Utility window appears.
Step 3
From the CIMC Configuration Utility window, configure the following:
•
IPV4 (Basic):
– CIMC IP: Enter 10.11.12.1xx where xx is the number of the cache engine that you are
configuring. For example if you are configuring VDS TC Cache Engine 01, enter the IP address
10.11.12.101. If you are configuring VDS TC Cache Engine 16, enter the IP address
10.11.12.116.Enter the default gateway for the CIMC to use.
– Subnet mask: Enter 255.255.255.0.
– Gateway: Leave this value at 0.0.0.0.
Note
Step 4
The CIMC user password is preconfigured to a preset password specifically for VDS TC cache engines
and you must not change this password.
Press F10 to save the configuration and F5 to refresh.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
4-15
Chapter 4
Cache Engine Servers Installation
Preparing to Import the Cisco VIC Adapters Configuration
Figure 4-10
CIMC Configuration Utility Screen
Preparing to Import the Cisco VIC Adapters Configuration
Follow these steps to download and extract the VIC adapter configuration files:
Procedure
Step 1
Using SFTP software, such as WinSCP, connect to the VDS TC Management Server using the IP address
that you assigned during the “Configuring the Boot Image” process. Log in using the user name padmin
and the password that was provided by Cisco.
Step 2
Copy the configuration files that you downloaded in Chapter 2 “Configuring the Switches in a C-Series
Cluster Installation” into the /tftpboot directory.
Note
The switch configuration files are available in a .tgz file that is available from the same location as the
VDS TC ISO image file on www.cisco.com.
Step 3
Close the SFTP software.
Step 4
Using an SSH session that is connected to the VDS TC Management server, enter the command su root
to login as the root user. Enter the password for the root user when prompted. This password is provided
by Cisco.
Step 5
Enter the command cd /tftpboot to change folders.
Step 6
Enter the ls command to find the name of the file that you copied to the /tftpboot folder in Step 2. The
file you are looking for should contain “Cisco_configurations”. Record the name of the file.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
4-16
OL-31421-04
Chapter 4
Cache Engine Servers Installation
Importing the Cisco VIC Adapters Configuration
Step 7
Enter the command tar -zxvf configuration_filename, where configuration_filename is the name of the
configuration file that you discovered in Step 6. For example, enter the command tar -zxvf
VDS-TC_Installer_5.7.3b53-5.7.3b54-ISO-7-Cisco_configurations.tgz.
Step 8
To confirm that the correct date and time are configured on the VDS TC Manager, enter the command
date. If the date and time are incorrect, adjust them using the date -s command.
Note
If the time on the VDS TC Manager is not correct, you will not be able to start the KVM console in next
section.
Importing the Cisco VIC Adapters Configuration
Follow these steps to import the configuration file for the Cisco VIC adapters:
Procedure
Step 1
If you do not already have a VNC client connection open to the VDS TC Management Server, open one
now. If you encounter problems opening a VNC client connection to the VDS TC Management Server,
you may need to restart VNC Server 1 on the VDS TC Management Server. Follow these steps to restart
this server:
a.
From an SSH connection to the VDS TC Management server where you are logged in with root
permissions, enter the command rm /tmp/.X11-unix/X1.
b.
Enter the command vncserver :1 to start the VNC Server.
Note
If you have problems restarting the VNC Server 1 instance, you can also start another VNC
Server instance by entering the command vncserver :2.
Step 2
Enter the whoami command to determine the username of the current session. Make sure that you are
logged in as root. If you are not logged in as root, enter the su root command to switch to the root user.
Enter the password that was provided by Cisco for the root account.
Step 3
From the VNC console, enter the command firefox &.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
4-17
Chapter 4
Cache Engine Servers Installation
Importing the Cisco VIC Adapters Configuration
Figure 4-11
Step 4
VNC Console
In the Firefox window that opens, enter https://bmc-X, where X is the number of the VDS TC Cache
Engine to connect to the CIMC of the VDS TC Cache Engine that you are configuring. For example, if
you are configuring VDS TC Cache Engine 1, enter https://bmc-1.
Figure 4-12
FireFox URL
Step 5
The CIMC login window appears. Enter the username admin and the password that was provided by
Cisco.
Step 6
The Cisco Integrated Management Controller: Server Summary window appears.
Step 7
From the Cisco Integrated Management Controller Server tab, click Inventory.
Step 8
Click the Cisco VIC Adapters tab. In the Adapter Card 1 section, click the General tab.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
4-18
OL-31421-04
Chapter 4
Cache Engine Servers Installation
Importing the Cisco VIC Adapters Configuration
Step 9
In the Adapter Cards section make sure that the UCS VIC 1225 card is selected.
Step 10
In the Actions pane, click the Reset to Defaults link. You may need to scroll down to see this link.
Figure 4-13
Step 11
In the Actions pane, click Import Configuration. You may need to scroll up to see this link.
Figure 4-14
Step 12
CIMC: Reset to Defaults
CIMC: Import Configuration
The Import Adapter Configuration dialog box appears.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
4-19
Chapter 4
Cache Engine Servers Installation
Importing the Cisco VIC Adapters Configuration
Step 13
From the Import From drop-down list, choose SFTP and in the SFTP Server IP Address field, enter
10.11.12.1, which is the SFTP server associated with the VDS TC Management Server.
Step 14
In the Path and Filename field, enter
tftpboot/examples/S-Series/VDS-TC-XS/VNIC_Configuration/vnic_v8r.cfg, where X is the number
of cache engines in your installation. For example, if you have a VDS-TC-16S installation, you would
enter tftpboot/examples/S-Series/VDS-TC-16S/VNIC_Configuration/vnic_v8r.cfg.
Step 15
For the Username, enter padmin and the password that was provided by Cisco. Click Import
Configuration.
Figure 4-15
Import Adapter Configuration
Step 16
In the Import Successful dialog box, click Finish.
Step 17
From the Server tab, choose Summary.
Step 18
In the Actions pane, click Launch KVM Console. This will launch the KVM Console window for this
server. You will use the KVM Console to configure the boot image in the next section. If prompted to
log in use the root user with the password that was provided by Cisco.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
4-20
OL-31421-04
Chapter 4
Cache Engine Servers Installation
Importing the Cisco VIC Adapters Configuration
Figure 4-16
Note
Step 19
Launch KVM Console
If you do not have Java™ installed on your computer, or your version is older than that required by the
KVM Console, a dialog box will appear. Install or update Java ™ and continue with the installation
procedure.
After the KVM console displays, return to the CIMC window, click the Server tab, and then click
Summary. In the Actions pane, click Hard Reset Server.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
4-21
Chapter 4
Cache Engine Servers Installation
Importing the Cisco VIC Adapters Configuration
Figure 4-17
Step 20
Note
Hard Reset Screen
From the Hard Reset Server popup window, click OK to reset the server.
This will drop your connection to the CIMC UI momentarily and you will have to log back into the
system.
After you are finished configuring the BIOS and operating system of the VDS TC cache engines, the
vNICs will be created on each cache engine. For example, the following vNICs will be created on each
cache engine when you are using four routers:
Table 4-2
vNIC to VLAN Mapping
vNIC
VLAN
Physical Port Number
eth0
Trunk
0
eth1
Trunk
1
eth2
70
0
eth3
201
0
eth4
202
0
eth5
203
0
eth6
204
0
eth7
201
1
eth8
202
1
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
4-22
OL-31421-04
Chapter 4
Cache Engine Servers Installation
Configuring the Boot Image
Table 4-2
vNIC to VLAN Mapping
vNIC
VLAN
Physical Port Number
eth9
203
1
eth10
204
1
eth11
70
1
Configuring the Boot Image
The next step in the VDS TC C-Series Cluster installation process is to configure the boot image on the
VDS TC Cache Engine. Use this procedure to configure the boot image:
Note
This procedure must be completed on all cache engines.
Procedure
Step 1
From the KVM console, click the Virtual Media tab and click Add Image.
Step 2
If you see the Unencrypted Virtual Media Session window appears, choose Accept this session and click
Apply.
Figure 4-18
Step 3
Unencrypted Virtual Media Session
Click Add Image.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
4-23
Chapter 4
Cache Engine Servers Installation
Configuring the Boot Image
Figure 4-19
Step 4
Browse to the /opt/pang/iso/ folder to find the ISO installer image and click Open.
Figure 4-20
Step 5
Virtual Media Tab
Browse for Image
Check the Mapped check box for the newly added ISO image file.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
4-24
OL-31421-04
Chapter 4
Cache Engine Servers Installation
Configuring the Boot Image
Figure 4-21
Map IOS Image
Step 6
Reboot the system by choosing Macros > Static Macros > Ctrl-Alt-Del from the KVM console, or by
using the CIMC user interface.
Step 7
When you see the prompt to press F6 to enter the boot menu, click the KVM Console window to make
sure it has focus and press F6. The Please Select Boot Device dialog box appears.
Note
You may need to press F6 several times to see the Please Select Boot Device dialog box.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
4-25
Chapter 4
Cache Engine Servers Installation
Configuring the Boot Image
Figure 4-22
System Reboot Window
Step 8
Using the up and down arrows, choose Cisco vKVM-Mapped vDVD1.22. The system will reboot from
the virtual ISO image.
Step 9
When the VDS-TC Installer environment displays in the KVM console window, choose Installer - No
Serial.
Figure 4-23
Step 10
VDS TC Installer Window
When the Welcome screen appears, enter Yes to continue the installation process.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
4-26
OL-31421-04
Chapter 4
Cache Engine Servers Installation
Configuring the Boot Image
Figure 4-24
Step 11
When the Firmware Checks window appears, click Yes to proceed with running a firmware check. Note
that this may take a while.
Figure 4-25
Step 12
Welcome Screen
Firmware Checks Window
After the firmware check is finished, you will see the following message at the bottom of the screen:
“Press Enter to Continue.” When you see this message, press Enter.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
4-27
Chapter 4
Cache Engine Servers Installation
Configuring the Boot Image
Figure 4-26
Step 13
From the Choose the Appliance Deployment, choose Cache Engine and select OK.
Figure 4-27
Step 14
Press Enter to Continue
Choose the Appliance Deployment Window
When prompted, enter the cache engine number for the cache engine that you are configuring and choose
OK.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
4-28
OL-31421-04
Chapter 4
Cache Engine Servers Installation
Configuring the Boot Image
Figure 4-28
Step 15
Note
Confirm the configuration. If everything is correct, choose Yes. If there is a mistake, choose No and
repeat Step 10 through Step 14.
Be careful. If you enter the wrong Cache Engine number, you may have to reinstall the Cache Engine.
Figure 4-29
Step 16
Note
Enter Cache Engine Number
Confirm Configuration
From the KVM window you will see the installation begin. You must wait for this installation process
to complete before you continue.
Please be aware that the installation may take more than an hour.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
4-29
Chapter 4
Cache Engine Servers Installation
Configuring the Boot Image
Figure 4-30
Step 17
When the installation completes, you must unmap the ISO image file. When the “Installation completed.
Press <Enter> to reboot.” message appears, press Enter.
Figure 4-31
Note
Cache Engine Installation Process
Installation Completed Window
Wait for the system to reboot and display the BIOS splash screen, as shown in Figure 4-22 “System
Reboot Window”, before proceeding to the next step.
Step 18
After the system reboots, from the KVM console, click the Virtual Media tab and uncheck the Mapped
check box next to the ISO image file.
Step 19
In the Unmap Drive Requested dialog box, click Yes to confirm the unmapping the image file. This
unmounts the ISO image.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
4-30
OL-31421-04
Chapter 4
Cache Engine Servers Installation
Configuring the Boot Image
Figure 4-32
Unmap Drive Requested Window
Step 20
Reboot the system by choosing Macros > Static Macros > Ctrl-Alt-Del from the KVM console, or by
using the CIMC user interface.
Step 21
Close the KVM console window.
Next you will configure the storage for the cache engines. This configuration is covered in the next
chapter, Chapter 5, “Configuring the Cache Storage”.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
4-31
Chapter 4
Cache Engine Servers Installation
Configuring the Boot Image
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
4-32
OL-31421-04
CH A P T E R
5
Configuring the Cache Storage
This chapter includes information about configuring the storage, installing Storage Manager, connecting
to the storage using Storage Manager software, and integrating the VDS TC Cache Engines with the
storage.
Ensure that you have installed the operating system on your VDS TC Management Server and the VDS
TC Cache Engines before starting the configuration in this chapter.
This chapter contains the following sections:
•
Configuring the Cache Storage Using IBM Storage Enclosures
– Installing the Storage Manager Software on the VDS TC Management Server
– Configuring the First IBM Storage Array
– Configuring the Remaining IBM Storage Arrays
– Confirm the Enclosure ID
•
Configuring the Cache Storage Using NetApp Storage Enclosures
– Installing the SANtricity Storage Manager on the Management Server
– Configuring the First NetApp Storage Array
– Configuring the Remaining NetApp Storage Arrays
– Confirm the Tray ID
•
Configuring the Storage Array and Formatting Storage Disks
Configuring the Cache Storage Using IBM Storage
Enclosures
Note
This process is only for the IBM storage enclosure. If you are installing the NetApp E2724 storage
enclosure, refer to Configuring the Cache Storage Using NetApp Storage Enclosures section.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
5-1
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using IBM Storage Enclosures
Installing the Storage Manager Software on the VDS TC Management Server
Follow these steps to install the IBM storage manager software on the VDS TC management server:
Procedure
Step 1
If you do not already have a VNC client connection open to the VDS TC Management Server, open one
now.
Step 2
From the VNC console window, if you are prompted to log in, enter the root user with the password that
was provided by Cisco. If you are not prompted to log in, enter the whoami command to determine the
username of the current session. Make sure that you are logged in as root. If you are not logged in as
root, enter the su root command to switch to the root user. Enter the password that was provided by Cisco
for the root account.
Step 3
From the VNC console, enter the command cd /opt/pang/utilities/MGMT/IBM/DS3500 to change
folders.
Step 4
Enter the command tar -zxvf SM10.86_Linux_64bit_x86-64_SMIA-10.86.x5.43.tgz.
Step 5
After the files are extracted, enter the command cd ./Linux_x64_10p86/Linux_x86-64/ to change
folders.
Step 6
Enter the command chmod 777 SMIA-LINUXX64-10.86.0A05.0043.bin to set permissions on the file.
Step 7
Next, to start the Management Station installation enter the command
./SMIA-LINUXX64-10.86.0A05.0043.bin.
Step 8
The IBM System Storage™ DS Storage Manager installation window appears. From the initial screen,
click OK to continue in English.
Figure 5-1
Step 9
IBM DS Storage Manager Initial Screen
The Introduction window appears. Click Next.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
5-2
OL-31421-04
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using IBM Storage Enclosures
Figure 5-2
Step 10
Note
When the Copyright window appears, click Next.
It may take awhile for the Copyright window to appear.
Figure 5-3
Step 11
IBM DS Storage Manager Introduction Window
IBM DS Storage Manager Copyright Window
Choose I accept the terms of the License Agreement and click Next.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
5-3
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using IBM Storage Enclosures
Figure 5-4
Step 12
From the Select Installation Type window, click Management Station and click Next.
Figure 5-5
Step 13
IBM DS Storage Manager License Agreement
Installation Type Window
You will see the installation begin.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
5-4
OL-31421-04
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using IBM Storage Enclosures
Figure 5-6
Step 14
IBM DS Storage Manager Installation
When the installation completes, click Done.
Figure 5-7
IBM DS Manager Installation Complete
Configuring the First IBM Storage Array
After the Management Station installation completes, you must configure the first storage array. Follow
these steps to configure the first storage array:
Procedure
Step 1
After the Management Station installation completes, in the xterm window enter the command
cd /opt/IBM_DS/client to change folders.
Step 2
Enter the command ./SMclient to start the The IBM System Storage™ DS Storage Manager software.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
5-5
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using IBM Storage Enclosures
Step 3
Caution
Power down all storage arrays that you are not currently configuring or that are not already configured.
For example, if you are configuring storage array 1, it should be the only storage array powered up. When
powering up a storage array, wait at least 5 minutes before you proceed.
Verify, physically, that only one none-configured storage array is powered-up.
Step 4
From the Storage Manager client, click the Setup tab.
Step 5
From the Initial Setup Tasks window, click Add Storage Subsystem.
Figure 5-8
Step 6
Initial Setup Tasks
From the Select Addition Method window, click Manual.
Figure 5-9
Select Addition Method
Step 7
From the Add New Storage Subsystem window, in the first Controller field under Out-of-band
Management, enter 192.168.128.101.
Step 8
In the second Controller field under Out-of-Band Management, enter 192.168.128.102.
Note
Step 9
Ensure that a single IP address is entered in each controller field.
Click Add.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
5-6
OL-31421-04
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using IBM Storage Enclosures
Figure 5-10
Add New Storage Subsystem Window
Step 10
From the Add Additional Devices window, click No.
Step 11
From the Devices tab, click Storage Subsystem Unnamed.
Figure 5-11
Storage Subsystem
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
5-7
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using IBM Storage Enclosures
Step 12
From the Unnamed Disk Pool Automatic Configuration window, click No.
Figure 5-12
Note
If the Storage Array Password dialog box appears, click No.
Figure 5-13
Step 13
Unamed Disk Pool Automatic Configuration
Storage Subsystem Password Dialog Box
In the Initial Setup Tasks window, click the Setup tab and click Configure Ethernet Management
Ports.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
5-8
OL-31421-04
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using IBM Storage Enclosures
Figure 5-14
Configure Ethernet Management Ports
Step 14
From the window that appears, from the Ethernet Port drop-down list ensure that Controller A, Port 1
is selected.
Step 15
From the Speed and Duplex Mode drop-down list, choose 1Gbps, Full Duplex.
Step 16
From the IPv4 Settings tab, click the Specify Configuration radio button.
Step 17
In the IP address field, enter 10.11.18.200.
Step 18
In the Subnet Mask field, enter 255.255.255.0.
Step 19
From the Ethernet Port drop-down list, choose Controller B, Port 1.
Step 20
From the Speed and Duplex Mode drop-down list, choose 1Gbps, Full Duplex.
Step 21
From the IPv4 Settings tab, click the Specify Configuration radio button.
Step 22
In the IP address field, enter 10.11.18.201.
Step 23
In the Subnet Mask field, enter 255.255.255.0.
Step 24
Click OK. The storage array disconnects.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
5-9
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using IBM Storage Enclosures
Figure 5-15
Controller Configuration
Step 25
Close the subsystem management window.
Step 26
From the Enterprise Management window, remove the system that was previously added using the
default factory IPs (The system is highlighted in red when the IP addresses change.)
Step 27
Click the Setup tab and click Add Storage Subsystem to re-add the system with the new IP addresses.
Step 28
From the Add New Storage Subsystem window, in the IP address fields under Out-of-band Management,
enter 10.11.18.200 and 10.11.18.201. These are the IP addresses that were assigned to Controller A, port
1 and Controller B, port1.
Step 29
Click Add.
Figure 5-16
Add New Storage Subsystem Window
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
5-10
OL-31421-04
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using IBM Storage Enclosures
Step 30
In the Automatic Configuration window, click No.
Step 31
If the Storage Subsystem Password window appears, click No.
Figure 5-17
Password Not Set Window
Step 32
From the Initial Setup Tasks window, click the Setup tab.
Step 33
Click Configure iSCSI Host Ports.
Caution
If the user-interface does not show the Configure iSCSI Host Ports link, STOP here and contact the
storage vendor, because this storage array is not running the correct firmware version that supports an
iSCSI configuration. You must update the storage firmware to version 07.86.40.
Figure 5-18
Configure iSCSI Host Ports
Step 34
From the window that appears, from the Ethernet Port drop-down list choose Controller A, HIC 1, Port
3.
Step 35
From the IPv4 Settings tab, click the Specify Configuration radio button.
Step 36
In the IP address field, enter 10.11.14.100.
Step 37
In the Subnet Mask field, enter 255.255.255.0.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
5-11
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using IBM Storage Enclosures
Figure 5-19
Configure IP Address
Step 38
Click Advanced Port Settings.
Step 39
From the window that appears, check the Enable Jumbo Frames check box and enter 9000 in the MTU
Size field.
Figure 5-20
Step 40
Enable Jumbo Frames
Repeat Steps 34 through 39 for the following ports:
•
Controller A port 4: 10.11.15.100
•
Controller A port 5: 10.11.16.100
•
Controller A port 6: 10.11.17.100
•
Controller B port 3: 10.11.14.101
•
Controller B port 4: 10.11.15.101
•
Controller B port 5: 10.11.16.101
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
5-12
OL-31421-04
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using IBM Storage Enclosures
•
Step 41
Controller B port 6: 10.11.17.101
Click OK when finished.
Configuring the Remaining IBM Storage Arrays
Next you must configure the remaining storage enclosures. To do this, power up the next storage
enclosure to be configured. Wait five minutes to make sure the unit is powered up and then repeat Steps
4 through 41 in the Configuring the First IBM Storage Array section. Use the Storage Enclosure
Management IP Addresses table to determine the management IP addresses to assign to the different
enclosures and use the iSCSI Port Addresses table to determine the IP addresses to assign to the ports
en each enclosure.
Table 5-1
Storage Enclosure Management IP Addresses
Enclosure
Management IP Addresses
Enclosure 2
10.11.18.202, 10.11.18.203
Enclosure 3
10.11.18.204, 10.11.18.205
Enclosure 4
10.11.18.206, 10.11.18.207
Enclosure 5
10.11.18.208, 10.11.18.209
Table 5-2
iSCSI Port Addresses
Enclosure
Port
IP Address
Enclosure 2
Controller A, port 3 10.11.14.102
Enclosure 2
Controller A, port 4 10.11.15.102
Enclosure 2
Controller A, port 5 10.11.16.102
Enclosure 2
Controller A, port 6 10.11.17.102
Enclosure 2
Controller B, port 3
10.11.14.103
Enclosure 2
Controller B, port 4
10.11.15.103
Enclosure 2
Controller B, port 5
10.11.16.103
Enclosure 2
Controller B, port 6
10.11.17.103
Enclosure 3
Controller A, port 3 10.11.14.104
Enclosure 3
Controller A, port 4 10.11.15.104
Enclosure 3
Controller A, port 5 10.11.16.104
Enclosure 3
Controller A, port 6 10.11.17.104
Enclosure 3
Controller B, port 3
10.11.14.105
Enclosure 3
Controller B, port 4
10.11.15.105
Enclosure 3
Controller B, port 5
10.11.16.105
Enclosure 3
Controller B, port 6
10.11.17.105
Enclosure 4
Controller A, port 3 10.11.14.106
Enclosure 4
Controller A, port 4 10.11.15.106
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
5-13
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using IBM Storage Enclosures
Table 5-2
iSCSI Port Addresses
Enclosure
Port
IP Address
Enclosure 4
Controller A, port 5 10.11.16.106
Enclosure 4
Controller A, port 6 10.11.17.106
Enclosure 4
Controller B, port 3
10.11.14.107
Enclosure 4
Controller B, port 4
10.11.15.107
Enclosure 4
Controller B, port 5
10.11.16.107
Enclosure 4
Controller B, port 6
10.11.17.107
Enclosure 5
Controller A, port 3 10.11.14.108
Enclosure 5
Controller A, port 4 10.11.15.108
Enclosure 5
Controller A, port 5 10.11.16.108
Enclosure 5
Controller A, port 6 10.11.17.108
Enclosure 5
Controller B, port 3
10.11.14.109
Enclosure 5
Controller B, port 4
10.11.15.109
Enclosure 5
Controller B, port 5
10.11.16.109
Enclosure 5
Controller B, port 6
10.11.17.109
Confirm the Enclosure ID
Step 1
Note
Before you configure the storage devices, you must verify that the Enclosure ID is 99 for each storage
subsystem. Follow these steps to confirm the Enclosure ID and change if necessary:
Perform these steps on all of the storage subsystems:
a.
From the IBM DS Storage Manager, click the Devices tab.
b.
Right-click the storage subsystem and choose Manage Storage Subsystem.
c.
Click the Hardware tab.
d.
From the Hardware tab, verify that the Enclosure ID is 99. You can verify this information in
multiple places on the Hardware tab, as shown in the following figure.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
5-14
OL-31421-04
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using IBM Storage Enclosures
Figure 5-21
Storage Subsystem Enclosure ID
e.
If the Enclosure ID is 99, go to step j. If the Enclosure ID is not 99, click View Enclosure
Components, located above the front view of the enclosure.
f.
From the Enclosure Component Information window, click Change Enclosure ID.
Figure 5-22
Enclosure Component Information
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
5-15
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using NetApp Storage Enclosures
g.
The Change Enclosure ID window appears. From this window, choose 99 from the “Change
Enclosure ID to” drop-down list and click OK.
Figure 5-23
Note
Change Enclosure ID
h.
Click Close to close the Enclosure Component Information window.
i.
Choose Storage Subsystem > Exit to close the Subsystem Management window.
Repeat these steps for the rest of the storage subsystems. When you have finished confirming the
enclosure ID on the rest of the storage subsystems, continue to the Configuring the Storage Array and
Formatting Storage Disks. Do not perform the steps in the “Configuring the Cache Storage Using
NetApp Storage Enclosures” section.
Configuring the Cache Storage Using NetApp Storage
Enclosures
Note
This process is only for the NetApp E2724 Storage. If you have an IBM storage enclosure, refer to the
Configuring the Cache Storage Using IBM Storage Enclosures section.
Installing the SANtricity Storage Manager on the Management Server
Follow these steps to install the NetApp Storage Manager software on the VDS TC Management Server:
Procedure
Step 1
Obtain the SANtricity Storage Manager software from your Cisco representative.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
5-16
OL-31421-04
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using NetApp Storage Enclosures
Step 2
Note
If you do not already have a VNC client connection open to the VDS TC Management Server, open one
now. If you encounter problems opening a VNC client connection to the VDS TC Management Server,
you may need to restart VNC Server 1 on the VDS TC Management Server. Follow these steps to restart
this server:
a.
From an SSH connection to the VDS TC Management server where you are logged in with root
permissions, enter the command rm /tmp/.X11-unix/X1.
b.
Enter the command vncserver :1 to start the VNC Server.
If you have problems restarting the VNC Server 1 instance, you can also start another VNC Server
instance by entering the command vncserver :2.
Step 3
From the VNC console window, if you are prompted to log in, enter the root user with the password that
was provided by Cisco. If you are not prompted to log in, enter the whoami command to determine the
username of the current session. Make sure that you are logged in as root. If you are not logged in as
root, enter the su root command and switch to the root user. Enter the password that was provided by
Cisco for the root account.
Step 4
Enter the command mkdir /opt/pang/utilities/MGMT/NetApp/ to create a folder for the SANtricity
Storage Manager software.
Step 5
Enter the command mkdir /opt/pang/utilities/MGMT/NetApp/E2700_SM_11_20_0A to create a
subfolder for the SANtricity Storage Manager software.
Step 6
Using SFTP software, such as WinSCP, connect to the VDS TC Management Server using the IP
address. Log in using the user name padmin and the password that was provided by Cisco.
Step 7
Copy the SANtricity Storage Manager software file that you received from Cisco into the /tmp folder
that you created.
Step 8
Close the SFTP software.
Step 9
From the VNC console window, enter the command cd /tmp.
Step 10
To move the file that you uploaded in Step 7 to the correct folder, enter the command mv
SMIA-LINUXX64-11.20.0A00.0015.bin /opt/pang/utilities/MGMT/NetApp/E2700_SM_11_20_0A
Step 11
From the VNC console window, enter the command cd
/opt/pang/utilities/MGMT/NetApp/E2700_SM_11_20_0A to change folders.
Step 12
Enter the command chmod 777 SMIA-LINUXX64-11.20.0A00.0015.bin to set permissions on the file.
Step 13
Next, enter the command ./SMIA-LINUXX64-11.20.0A00.0015.bin to start the SANtricity Storage
Manager installation.
Step 14
The SANtricity ES Storage Manager installation window appears. From the Introduction window screen,
click Next.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
5-17
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using NetApp Storage Enclosures
Figure 5-24
Step 15
Choose I accept the terms of the License Agreement and click Next.
Figure 5-25
Step 16
SANtricity Storage Manager Initial Screen
SANtricity Storage Manager License Agreement
From the Select Installation Type window, click Management Station and click Next.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
5-18
OL-31421-04
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using NetApp Storage Enclosures
Figure 5-26
Step 17
In the Pre-Installation Summary window, the installation destination is displayed in addition to the
required disk space, and available disk space. Verify the installation details and click Install to begin the
installation.
Figure 5-27
Step 18
Installation Type Window
Pre-Installation Summary
The installation procedure begins.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
5-19
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using NetApp Storage Enclosures
Figure 5-28
Step 19
SANtricity Storage Manager Installation
When the installation completes, click Done.
Figure 5-29
SANtricity Manager Installation Complete
Configuring the First NetApp Storage Array
After the Management Station installation completes, you must configure the first storage array. Follow
these steps to configure the first storage array:
Procedure
Step 1
After the Management Station installation completes, from the xterm window, enter the command
cd /opt/SMgr/client to change folders.
Step 2
Enter the command ./SMclient to start the SANtricity ™ ES Storage Manager software.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
5-20
OL-31421-04
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using NetApp Storage Enclosures
Step 3
Caution
Power down all storage arrays that you are not currently configuring or that are not already configured.
For example, if you are configuring storage array 1, it should be the only storage array powered up. When
powering up a storage array, wait at least 5 minutes before you proceed.
Verify, physically, that only one none-configured storage array is powered-up.
Step 4
From the Storage Manager, click the Setup tab.
Step 5
From the Initial Setup Tasks window, click Add Storage Arrays.
Figure 5-30
Step 6
Initial Setup Tasks
From the Select Addition Method window, click Manual.
Figure 5-31
Select Addition Method
Step 7
From the Add New Storage Array window, in the first Controller field under Out-of-band Management,
enter 192.168.128.101.
Step 8
In the second Controller field under Out-of-Band Management, enter 192.168.128.102.
Note
Ensure that a single IP address is entered in each controller field.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
5-21
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using NetApp Storage Enclosures
Step 9
Click Add.
Figure 5-32
Add New Storage Array Window
Step 10
From the Add Additional Devices window, click No.
Step 11
From the Devices tab, click Storage Array Unnamed.
Figure 5-33
Step 12
Storage Array
From the Unnamed Disk Pool Automatic Configuration window, click No.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
5-22
OL-31421-04
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using NetApp Storage Enclosures
Figure 5-34
Note
Step 13
Un-named Disk Pool Automatic Configuration
If the Storage Array Password dialog box appears, click No.
In the Initial Setup Tasks window, click the Setup tab and click Configure Ethernet Management
Ports.
Figure 5-35
Configure Ethernet Management Ports
Step 14
From the window that appears, from the Ethernet Port drop-down list ensure that Controller A, Port 1
is selected.
Step 15
Make sure the Speed and Duplex Mode drop-down list have Auto-negotiate selected.
Step 16
From the IPv4 Settings tab, click the Specify Configuration radio button.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
5-23
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using NetApp Storage Enclosures
Step 17
In the IP address field, enter 10.11.18.200.
Step 18
In the Subnet Mask field, enter 255.255.255.0.
Step 19
From the Ethernet Port drop-down list, choose Controller B, Port 1.
Step 20
Make sure the Speed and Duplex Mode drop-down list have Auto-negotiate selected.
Step 21
From the IPv4 Settings tab, click the Specify Configuration radio button.
Step 22
In the IP address field, enter 10.11.18.201.
Step 23
In the Subnet Mask field, enter 255.255.255.0.
Step 24
Click OK. The storage array disconnects.
Figure 5-36
Controller Configuration
Step 25
Close the Array management window.
Step 26
From the Enterprise Management window, remove the system that was previously added using the
default factory IP addresses. (The system is highlighted in red when the IP addresses change.)
Step 27
Click the Setup tab and click Add Storage Array to re-add the system with the new IP addresses.
Step 28
From the Add New Storage Array window, in the IP address fields under Out-of-band Management,
enter 10.11.18.200 and 10.11.18.201. These are the IP addresses that were assigned to Controller A, port
1 and Controller B, port1.
Step 29
Click Add.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
5-24
OL-31421-04
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using NetApp Storage Enclosures
Figure 5-37
Step 30
Note
Add New Storage Array Window
From the Automatic Configuration window, click No.
If the Storage Array Password dialog box appears, click No.
Step 31
From the Initial Setup Tasks window, click the Setup tab.
Step 32
Click Configure iSCSI Host Ports.
Caution
If the user-interface does not show the Configure iSCSI Host Ports link, STOP here and contact the
storage vendor because this storage array is not running the correct firmware version that supports an
iSCSI configuration.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
5-25
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using NetApp Storage Enclosures
Figure 5-38
Configure iSCSI Host Ports
Step 33
From the window that appears, from the Ethernet Port drop-down list choose Controller A, HIC 1, Port
3.
Step 34
From the IPv4 Settings tab, click the Specify Configuration radio button.
Step 35
In the IP address field, enter 10.11.14.100.
Step 36
In the Subnet Mask field, enter 255.255.255.0.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
5-26
OL-31421-04
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using NetApp Storage Enclosures
Figure 5-39
Configure IP Address
Step 37
Click Advanced Port Settings.
Step 38
From the window that appears, check the Enable Jumbo Frames check box and enter 9000 in the MTU
Size field.
Figure 5-40
Step 39
Enable Jumbo Frames
Repeat Steps 33 through 38 for the following ports:
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
5-27
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using NetApp Storage Enclosures
Step 40
•
Controller A port 4: 10.11.15.100
•
Controller B port 3: 10.11.14.101
•
Controller B port 4: 10.11.15.101
Click OK when finished.
Configuring the Remaining NetApp Storage Arrays
Next you must configure the remaining storage enclosures. To do this, power up the next storage
enclosure to be configured. Wait five minutes to make sure that the unit is powered up and then repeat
Steps 4 through 40 from the Configuring the First NetApp Storage Array section. Use the Storage Enclosure
Management IP Addresses table to determine the management IP addresses for assigning the different
enclosures and use the iSCSI Port Addresses table to determine the IP addresses to assign to the ports en
each enclosure.
Table 5-3 Storage Enclosure Management IP Addresses
Enclosure
Management IP Addresses
Enclosure 2
10.11.18.202, 10.11.18.203
Enclosure 3
10.11.18.204, 10.11.18.205
Enclosure 4
10.11.18.206, 10.11.18.207
Enclosure 5
10.11.18.208, 10.11.18.209
Enclosure 6
10.11.18.210, 10.11.18.211
Table 5-4
iSCSI Port Addresses
Enclosure
Port
IP Address
Enclosure 2
Controller A, port 3
10.11.14.102
Enclosure 2
Controller A, port 4
10.11.15.102
Enclosure 2
Controller B, port 3
10.11.14.103
Enclosure 2
Controller B, port 4
10.11.15.103
Enclosure 3
Controller A, port 3
10.11.14.104
Enclosure 3
Controller A, port 4
10.11.15.104
Enclosure 3
Controller B, port 3
10.11.14.105
Enclosure 3
Controller B, port 4
10.11.15.105
Enclosure 4
Controller A, port 3
10.11.14.106
Enclosure 4
Controller A, port 4
10.11.15.106
Enclosure 4
Controller B, port 3
10.11.14.107
Enclosure 4
Controller B, port 4
10.11.15.107
Enclosure 5
Controller A, port 3
10.11.14.108
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
5-28
OL-31421-04
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using NetApp Storage Enclosures
Table 5-4
iSCSI Port Addresses (continued)
Enclosure
Port
IP Address
Enclosure 5
Controller A, port 4
10.11.15.108
Enclosure 5
Controller B, port 3
10.11.14.109
Enclosure 5
Controller B, port 4
10.11.15.109
Enclosure 6
Controller A, port 3
10.11.14.110
Enclosure 6
Controller A, port 4
10.11.15.110
Enclosure 6
Controller B, port 3
10.11.14.111
Enclosure 6
Controller B, port 4
10.11.15.111
Confirm the Tray ID
Step 1
Note
Before you configure the storage devices, you must verify that the Tray ID is 99 for each Storage Array.
Follow these steps to confirm the Tray ID and change if necessary:
Perform these steps on all of the Storage Array:
a.
From the SANtricity Storage Manager, click the Devices tab.
b.
Right-click the storage subsystem and choose Manage Storage Array.
c.
Click the Hardware tab.
d.
From the Hardware tab, verify that the Tray ID is 99. You can verify this information in multiple
places on the Hardware tab, as shown in the following figure.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
5-29
Chapter 5
Configuring the Cache Storage
Configuring the Cache Storage Using NetApp Storage Enclosures
Figure 5-41
Storage Array Tray ID
e.
If the Tray ID is 99, go to step j. If the Tray ID is not 99, click View Tray Components, located
above the front view of the Tray.
f.
From the Tray Component Information window, click Change Tray ID.
Figure 5-42
Tray Component Information
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
5-30
OL-31421-04
Chapter 5
Configuring the Cache Storage
Configuring the Storage Array and Formatting Storage Disks
g.
The Change Tray ID window appears. From this window, choose 99 from the “Change Tray ID to”
drop-down list and click OK.
Figure 5-43
Note
Change Tray ID
h.
Click Close to close the Tray Component Information window.
i.
Choose Storage Array > Exit to close the Array Management window.
j.
Repeat these steps for the rest of the Storage Array.
Continue with the Configuring the Storage Array and Formatting Storage Disks section.
Configuring the Storage Array and Formatting Storage Disks
Use this procedure to configure the storage and format the storage disks:
Procedure
Step 1
From the VNC console connection to the VDS TC Management Server, enter the command cd
/opt/pang/useful/configure_storages/ to change folders.
Step 2
Next, enter the command ./configure_storages.py -s [no_of_storage_enclosures] -b [no_of_blades].
Step 3
The configure storages script will format the data disks. To configure the storages without formatting the
disks, enter the command ./configure_storages.py -s [no_of_storage_enclosures] -b [no_of_blades] -x.
The following warning message regarding the disk formatting will appear:
*********** WARNING! **********
All storages are about to be reconfigured. All data on the data disks will be lost.
Do you want to continue? (y/n)
Step 4
To continue the storages configuration and formatting of the their disks, enter y.
Step 5
Follow the on screen instructions. If prompted, enter the password for the root user that was provided by
Cisco.
Note
You may be prompted to enter the password several times.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
5-31
Chapter 5
Configuring the Cache Storage
Configuring the Storage Array and Formatting Storage Disks
Step 6
If you see the message “MegaCLI is not installed, so SSD disks will not be detected and formatted. Do
you wish to continue anyway?”, enter Y.
Figure 5-44
Step 7
SSD Dialog
After running this script, the storage arrays should be configured and formatted and all of the VDS TC
Cache Engines will connect to the storage enclosures.
Next you will install and configure the Cisco VDS TC Cluster Software. This configuration is covered
in the next chapter, Chapter 6, “Installing and Configuring the Cisco VDS TC Cluster Software”.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
5-32
OL-31421-04
CH A P T E R
6
Installing and Configuring the Cisco VDS TC
Cluster Software
This chapter includes information for installing the VDS TC Cluster platform software, including
pre-installation and post-installation steps.
The VDS TC Cluster software installation script installs the VDS TC caching software and installs
management tools, such as the VDS TC Management software, SNMP MIBs, and the CLI environment.
Upon completion, the installer performs some verification tests, such as verifying the directory structure
accessibility and the reachability of IP addresses.
Note
The steps in this chapter should only be run on the VDS TC Management Server. The procedures in this
chapter will distribute the Cisco software packages to all of the servers.
This chapter contains the following sections:
•
Installing the Management Environment and Software
•
Post Installation Steps
Installing the Management Environment and Software
Use this procedure to install the management environment and software:
Procedure
Step 1
Using an SSH session that is connected to the VDS TC Management Server, enter the command su root
to login as the root user.
Step 2
Enter the command cd /tftpboot to change folders.
Step 3
Enter the command ls to see the name of the archive file. The file you are looking for will start with
VDS-TC_FI and will include Server_Cluster in the filename. Record the name of this file because you
will need it in a later step. The numbers in the archive file represent the version of the VDS TC caching
software. For example, the file named VDS-TC_FI_5.7.3b54_Server_Cluster.tar.gz would be for a VDS
TC Cluster installation and the version number of the software is 5.7.3b54.
Step 4
Enter the command mkdir version, where version is the version number in the archive file you
discovered in Step 3. For example, if the file you discovered in Step 3 was
VDS-TC_FI_5.7.3b54_Server_Cluster.tar.gz, enter the command mkdir 5.7.3b54.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
6-1
Chapter 6
Installing and Configuring the Cisco VDS TC Cluster Software
Installing the Management Environment and Software
Step 5
Use the cd command to change to the directory you created in Step 4, for example cd 5.7.3b54.
Step 6
You must extract the VDS-TC software from the packed archive, located in the /tftpboot folder. Enter
the command tar -zxvf ../archive_name, where archive_name is the name of the file you discovered in
Step 3. For example, enter the command
tar -zxvf ../VDS-TC_FI_5.7.3b54_Server_Cluster.tar.gz.
Step 7
Next you must review and possibly edit the GA_installer.rc file to reflect the number of cache engine
servers to be installed in the Cluster. Use the command vi GA_installer.rc to review and edit this file if
necessary. The following is an example of what that file should look like for the first time install of four
servers and the management server.
#MANAGEMENT_SOFTWARE {no, yes}
MANAGEMENT_SOFTWARE=yes
#UPGRADEL_CACHE_SOFTWARE {all, none, space separated list(ce-1 ce-2 ce-3 ce-4 ce-5 ce-6
ce-7 ce-8 ce-9 ce-10 ce-11 ce-12 ce-13 ce-14 ce-15 ce-16)}
UPGRADEL_CACHE_SOFTWARE=ce-1 ce-2 ce-3 ce-4
UPGRADE_TAR_BALL=<filename>.tar.gz
MANAGEMENT_ENVIRONMENT=yes
GRACE_UPGRADE=yes
FIRST_INSTALL=yes
Step 8
To adjust the number of cache engine servers being installed, edit the line
UPGRADEL_CACHE_SOFTWARE=ce-1 ce-2 ce-3 ce-4, listing the cache engines that you are
installing.
Step 9
When you are finished editing the GA_installer.rc file, in the vi editor enter :x and press Enter to save
and exit the file.
Step 10
Enter the command ./GA_installer.sh to run the first installation script.
Step 11
At the Enter primary name server IP prompt, enter the IP address of your primary DNS server. Enter y
to confirm the entry.
Note
Step 12
Note
If a DNS server is unavailable, enter 0.0.0.0 as the IP address of the DNS server to prevent system
functionality from being negatively affected.
At the Enter secondary name server IP prompt, enter the IP address of your secondary DNS server. Enter
y to confirm the entry.
If a secondary DNS server is unavailable, leave this entry blank.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
6-2
OL-31421-04
Chapter 6
Installing and Configuring the Cisco VDS TC Cluster Software
Installing the Management Environment and Software
Figure 6-1
Installation Script Dialog
Step 13
The GA Installer script displays a summary of the configuration. Review this configuration. If the
configuration is correct, press Y to proceed. If the configuration is not correct, press N to exit the
installation and start over.
Step 14
When asked if you want to change the management IPv4 settings, enter N unless you need to change the
IP address information that was configured during the original VDS TC Management Server installation.
If you enter Y, enter information at the following prompts:
Note
Step 15
•
Management IPv4 address ():
•
Management IPv4 netmask ():
•
Default IPv4 gateway ():
To accept the current setting, press Enter.
When asked if you want to change the management IPv6 settings, enter N.
Note
Step 16
While the VDS TC software contains the infrastructure to configure IPv6 on the management
server, this functionality is not currently supported.
Wait for the installation script to finish before continuing on to the next step.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
6-3
Chapter 6
Installing and Configuring the Cisco VDS TC Cluster Software
Post Installation Steps
Post Installation Steps
Use the following procedure after installing the management environment and software to perform the
post installation steps. Part of the post installation steps is to copy a configuration file to the VDS TC
Management Server. The configuration file sets the environment variables and configuration for the VDS
TC application. A sample configuration file is provided in a .tgz file that is available from the same
location as the VDS TC ISO image file on www.cisco.com. In this section you will copy an example
configuration file, edit this file, and import the new configuration file to the VDS TC Management
Server.For more information about editing the configuration files in this section, see the Cisco
Videoscape Distribution Suite Transparent Caching Software Configuration Guide (part number
OL-28016-03).
Procedure
Step 1
Download the .tgz file that is available from the same location as the VDS TC ISO image file on
www.cisco.com. In this .tgz file, locate the sample configuration file that matches the number of VDS
TC Cache Engines that are installed in your VDS TC C-Series installation.
Step 2
Edit the sample configuration file and make the required changes in the following sections. For more
information editing the required parameters in the cluster_conf.xml file, see the Cisco Videoscape
Distribution Suite Transparent Caching Software Configuration Guide (part number OL-28016-02).
•
The <mgmt-config> controls the management IP environment section.
•
The <network> section controls the data network addresses.
•
The <service> section controls the cache out port configuration.
Step 3
Save your changes and rename the file cluster_conf.xml.
Step 4
Using SFTP software, such as WinSCP, connect to the management IP address that you assigned to the
VDS TC Management Server. Log in using the user name padmin and the password that was provided
by Cisco.
Step 5
Copy the example configuration file that you saved in Step 3 into the /tftpboot folder on the VDS TC
Management Server.
Step 6
From an SSH session that is connected to the VDS TC Management Server, enter the command su
admin. The system will notify you that the cluster_conf.xml file is not valid because the file does not
exit and then the Regular mode prompt, console>, appears.
Figure 6-2
Note
System Notification of no cluster_conf.xml File
If you need to open a new SSH window to the VDS TC cache engine, enter the management IP address
of the VDS TC cache engine and log in using the username padmin and the password that was provided
by Cisco. Enter the command su root to change to the root user and when prompted, enter the password
for the root user that was provided by Cisco.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
6-4
OL-31421-04
Chapter 6
Installing and Configuring the Cisco VDS TC Cluster Software
Post Installation Steps
Step 7
To log into the Enable mode, you need the system ID to use for the password. Enter the command show
systemid to determine the system ID.
Step 8
Enter the command enable to switch to Enable mode. Enter the first system ID that was discovered in
Step 7 for the password, excluding the leading *. The prompt changes to console#.
Step 9
To be able to import and apply the new configuration, enter the command config to switch to
Configuration mode.
Step 10
To import the edited configuration file, enter the command import 127.0.0.1 cluster_conf.xml.
Step 11
To confirm your changes to the configuration file, enter the command diff. The new configuration
parameters are indicated by a plus (+) sign as the first character on the line.
Step 12
To apply the imported configuration file, enter the command apply. After you enter the apply command,
the system may ask you to confirm some of the settings. If prompted to confirm any settings, either enter
y to confirm the entry or enter n to ignore that particular setting if necessary.
Caution
If you have configured the timezone of the VDS TC management server or cache engines, or if you have
configured the VDS TC management server to use an external NTP time server, you must repeat the NTP
configuration after importing a cluster_conf file.
Step 13
After the system is finished applying the configuration file, it may log you out of the CLI.
Step 14
If you were logged out of the VDS TC CLI, enter the command su admin to log back into the VDS TC
CLI. To log into the Enable mode, you need the system ID to use for the password. Enter the command
show systemid to determine the system ID.
Step 15
Enter the command enable to switch to Enable mode. Enter the first system ID that was discovered in
Step 15 for the password, excluding the leading *. The prompt changes to console#.
Step 16
Enter the command show cluster-bus-ip to check if the spread communication among cluster members
is set to broadcast.
console# show cluster-bus-ip
Processing...
MG-1: [Broadcast]
CE-1: [Broadcast]
CE-2: [Broadcast]
CE-3: [Broadcast]
CE-4: [Broadcast]
CE-5: [Broadcast]
CE-6: [Broadcast]
CE-7: [Broadcast]
CE-8: [Broadcast]
OK. All the CEs are configured to work with Broadcast IP.
Step 17
If the communication is set to broadcast, continue on to the Installing the License section. If the
communication is set to multicast instead of broadcast, enter the command config to switch to
Configuration mode and then enter the command cluster-bus-ip broadcast. For example:
configuration# cluster-bus-ip broadcast
Processing...
All the CEs are configured to work with Broadcast IP.
Step 18
Enter the command exit to exit the Configuration mode.
Step 19
Enter the command show cluster-bus-ip to confirm that the management server and all cache engines
are configured to use broadcast. For example:
console# show cluster-bus-ip
Processing...
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
6-5
Chapter 6
Installing and Configuring the Cisco VDS TC Cluster Software
Post Installation Steps
MG-1: [Broadcast]
CE-1: [Broadcast]
CE-2: [Broadcast]
CE-3: [Broadcast]
CE-4: [Broadcast]
CE-5: [Broadcast]
CE-6: [Broadcast]
CE-7: [Broadcast]
CE-8: [Broadcast]
OK. All the CEs are configured to work with Broadcast IP.
Installing the License
After importing the configuration file you need to install a valid license. After you obtain a valid VDS
TC license from Cisco use this procedure to install the VDS TC license:
Procedure
Step 1
Copy the license file to the /tftpboot/ folder on the VDS TC Management Server using SFTP software,
such as WinSCP.
Step 2
To import the license file to the system from the VDS TC Enable mode CLI, enter the command
license import 127.0.0.1 filename, where filename is the license file name, such as
0000000-5.7-CISCO_UCS220-License_20150913_190733.xml. When you enter this command, the
details of the license will be displayed. Verify the features of the license and the expiration date.
Note
You must be in Enable mode, not Configuration mode to import a new license.
For example:
console# license import 127.0.0.1 0000000-5.7-CISCO_UCS220-License_20150913_190733.xml
Step 3
To activate the imported license, enter the command license activate. Enter Y when prompted to confirm
the activation.
Step 4
After activating the license, exit completely from the VDS TC CLI.
Step 5
To confirm that the license is activated, log back into the CLI of the system using the username admin.
From the VDS TC CLI prompt, enter the command enable. When prompted, enter the Enable mode
password and press Enter. Enter the command show license to confirm that the license is activated.
Note
If you see the message “No valid license found”, make sure that you exit completely from the CLI of the
VDS TC system and repeat Step 5.
Step 6
Enter the command oper service start to start the VDS TC service.
Step 7
To confirm that the VDS TC service has successfully started, enter the command show status and look
for a device state of “started”.
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
6-6
OL-31421-04
A P P E N D I X
A
Cisco VDS TC C-Series Cabling Guides when
Using the NetApp E2724 Storage Enclosures
Revised: February 2016, OL-31421-04
This appendix provides cabling guidelines for cabling a VDS TC Cluster solution that uses Cisco
C-Series servers with the NetApp E2724 storage enclosures. This appendix provides a separate set of
tables for each one of the following configurations:
•
VDS-TC-2S Non-Redundant Cabling Scheme
•
VDS-TC-2S Redundant Cabling Scheme
•
VDS-TC-4S Non-Redundant Cabling Scheme
•
VDS-TC-4S Redundant Cabling Scheme
•
VDS-TC-8S Non-Redundant Cabling Scheme
•
VDS-TC-8S Redundant Cabling Scheme
•
VDS-TC-16S Non-Redundant Cabling Scheme
•
VDS-TC-16S Redundant Cabling Scheme
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
A-1
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-2S Non-Redundant Cabling Scheme
VDS-TC-2S Non-Redundant Cabling Scheme
This section provides the cabling scheme for the VDS-TC-2S non-redundant solution.
Cisco Catalyst 4500X Switch Cabling (VDS-TC-2S Non-Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X
Te 1/1
CE-1
Te 0
Te 1/2
CE-2
Te 0
Te 1/5
PBR Router 1
To customer environment
Te 1/6
PBR Router 1
To customer environment
Te 1/7
PBR Router 2
To customer environment optional
Te 1/8
PBR Router 2
To customer environment optional
Te 1/9
PBR Router 3
To customer environment optional
Te 1/10
PBR Router 3
To customer environment optional
Te 1/11
PBR Router 4
To customer environment optional
Te 1/12
PBR Router 4
To customer environment optional
Te 1/13
SG500-1
Te 2/13
Cisco SG500 Switch Cabling (VDS-TC-2S Non-Redundant)
Note
Refer to the Notes column in the table for cable type. For the 10GBase-T connections, you can use either
CAT6 or CAT7 cables.
Local Device
Local Port
Remote Device
Remote Port
Notes
SG500
Te 2/1
NetApp Storage 1
Controller1 port 1
10GBase-T
Te 2/2
NetApp Storage 1
Controller2 port 1
10GBase-T
Te 2/5
NetApp Storage 1
Controller1 Mgmt port 1
1000Base-T
Te 2/6
Mgmt Server
Eth 1
1000Base-T
Te 2/7
CE-1 Mgmt
Eth1
1000Base-T
Te 2/8
CE-2 Mgmt
Eth1
1000Base-T
Te 2/11
NetApp Storage 1
Controller1 Mgmt port 2
Te 2/13
4500X-1
Te 1/13
Gi 2/1
Mgmt Uplink
To customer environment 1000Base-T
SFP+ 10G
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
A-2
OL-31421-04
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-2S Redundant Cabling Scheme
VDS-TC-2S Redundant Cabling Scheme
This section provides the cabling scheme for the VDS-TC-2S redundant solution.
Cisco Catalyst 4500X-1 Switch Cabling (VDS-TC-2S Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X-1
Te 1/1
CE-1
Te 0
Te 1/2
CE-2
Te 0
Te 1/5
PBR Router 1
To customer environment
Te 1/6
PBR Router 1
To customer environment
Te 1/7
PBR Router 2
To customer environment optional
Te 1/8
PBR Router 2
To customer environment optional
Te 1/9
PBR Router 3
To customer environment optional
Te 1/10
PBR Router 3
To customer environment optional
Te 1/11
PBR Router 4
To customer environment optional
Te 1/12
PBR Router 4
To customer environment optional
Te 1/13
SG500-1
Te 2/13
Te 1/14
SG500-2
Te 2/13
Te 1/15
4500X-2
Te 1/15
Port-channel 5
Te 1/16
4500X-2
Te 1/16
Port-channel 5
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
A-3
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-2S Redundant Cabling Scheme
Cisco Catalyst 4500X-2 Switch Cabling (VDS-TC-2S Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X-2
Te 1/1
CE-1
Te 1
Te 1/2
CE-2
Te 1
Te 1/5
PBR Router 1
To customer environment
Te 1/6
PBR Router 1
To customer environment
Te 1/7
PBR Router 2
To customer environment optional
Te 1/8
PBR Router 2
To customer environment optional
Te 1/9
PBR Router 3
To customer environment optional
Te 1/10
PBR Router 3
To customer environment optional
Te 1/11
PBR Router 4
To customer environment optional
Te 1/12
PBR Router 4
To customer environment optional
Te 1/13
SG500-1
Te 2/14
Te 1/14
SG500-2
Te 2/14
Te 1/15
4500X-1
Te 1/15
Port-channel 10
Te 1/16
4500X-1
Te 1/16
Port-channel 10
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
A-4
OL-31421-04
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-2S Redundant Cabling Scheme
Cisco SG500-1 Switch Cabling (VDS-TC-2S Redundant)
Note
Refer to the Notes column in the table for cable type. For the 10GBase-T connections, you can use either
CAT6 or CAT7 cables.
Local Device
Local Port
Remote Device
Remote Port
Notes
SG500-1
Te 2/1
NetApp Storage 1
Controller1 port 1
10GBase-T
Te 2/2
NetApp Storage 1
Controller2 port 1
10GBase-T
Te 2/5
NetApp Storage 1
Controller1 Mgmt port 1
1000Base-T
Te 2/6
Mgmt Server
Eth 1
1000Base-T
Te 2/7
CE-1 Mgmt
Eth1
1000Base-T
Te 2/8
CE-2 Mgmt
Eth1
1000Base-T
Te 2/13
4500X-1
Te 1/14
SFP+ 10G
Te 2/14
4500X-2
Te 1/13
SFP+ 10G
Te 2/15
SG500-2
Te 2/15
Interlink stack
port
SFP+ 10G
Te 2/16
SG500-2
Te 2/16
Interlink stack
port
SFP+ 10G
Gi 2/1
Mgmt Uplink
To customer environment 1000Base-T
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
A-5
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-2S Redundant Cabling Scheme
Cisco SG500-2 Switch Cabling (VDS-TC-2S Redundant)
Note
Refer to the Notes column in the table for cable type. For the 10GBase-T connections, you can use either
CAT6 or CAT7 cables.
Local Device
Local Port
Remote Device
Remote Port
Notes
SG500-2
Te 2/1
NetApp Storage 1
Controller1 port 2
10GBase-T
Te 2/2
NetApp Storage 1
Controller2 port 2
10GBase-T
Te 2/5
NetApp Storage 1
Controller2 Mgmt port 1
1000Base-T
Te 2/6
Mgmt Server
Eth 1
1000Base-T
Te 2/7
CE-1 Mgmt
Eth1
1000Base-T
Te 2/8
CE-2 Mgmt
Eth1
1000Base-T
Te 2/13
4500X-1
Te 1/13
SFP+ 10G
Te 2/14
4500X-2
Te 1/14
SFP+ 10G
Te 2/15
SG500-1
Te 2/15
Interlink stack
port
SFP+ 10G
Te 2/16
SG500-1
Te 2/16
Interlink stack
port
SFP+ 10G
Gi 2/1
Mgmt Uplink
To customer environment 1000Base-T
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
A-6
OL-31421-04
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-4S Non-Redundant Cabling Scheme
VDS-TC-4S Non-Redundant Cabling Scheme
This section provides the cabling scheme for the VDS-TC-4S non-redundant solution.
Cisco Catalyst 4500X Switch Cabling (VDS-TC-4S Non-Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X
Te 1/1
CE-1
Te 0
Te 1/2
CE-2
Te 0
Te 1/3
CE-3
Te 0
Te 1/4
CE-4
Te 0
Te 1/5
PBR Router 1
To customer
environment
Te 1/6
PBR Router 1
To customer
environment
Te 1/7
PBR Router 2
To customer
environment
optional
Te 1/8
PBR Router 2
To customer
environment
optional
Te 1/9
PBR Router 3
To customer
environment
optional
Te 1/10
PBR Router 3
To customer
environment
optional
Te 1/11
PBR Router 4
To customer
environment
optional
Te 1/12
PBR Router 4
To customer
environment
optional
Te 1/13
SG500
Te 2/13
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
A-7
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-4S Non-Redundant Cabling Scheme
Cisco SG500 Switch Cabling (VDS-TC-4S Non-Redundant)
Note
Refer to the Notes column in the table for cable type. For the 10GBase-T connections, you can use either
CAT6 or CAT7 cables.
Local Device
Local Port
Remote Device
Remote Port
Notes
SG500
Te 2/1
NetApp Storage 1
Controller1 port 1
10GBase-T
Te 2/2
NetApp Storage 1
Controller2 port 1
10GBase-T
Te 2/3
NetApp Storage 2
Controller1 port 1
10GBase-T
Te 2/4
NetApp Storage 2
Controller2 port 1
10GBase-T
Te 2/5
NetApp Storage 1
Controller1 Mgmt port 1
1000Base-T
Te 2/6
Mgmt Server
Eth 1
1000Base-T
Te 2/7
CE-1 Mgmt
Eth1
1000Base-T
Te 2/8
CE-2 Mgmt
Eth1
1000Base-T
Te 2/9
CE-3 Mgmt
Eth1
1000Base-T
Te 2/10
CE-4 Mgmt
Eth1
1000Base-T
Te 2/11
NetApp Storage 2
Controller1 Mgmt port 1
1000Base-T
Te 2/13
4500X
Te 1/13
SFP+ 10G
Gi 2/1
Mgmt Uplink
To customer environment 1000Base-T
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
A-8
OL-31421-04
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-4S Redundant Cabling Scheme
VDS-TC-4S Redundant Cabling Scheme
This section provides the cabling scheme for the VDS-TC-4S redundant solution.
Cisco Catalyst 4500X-1 Switch Cabling (VDS-TC-4S Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X-1
Te 1/1
CE-1
Te 0
Te 1/2
CE-2
Te 0
Te 1/3
CE-3
Te 0
Te 1/4
CE-4
Te 0
Te 1/5
PBR Router 1
To customer environment
Te 1/6
PBR Router 1
To customer environment
Te 1/7
PBR Router 2
To customer environment optional
Te 1/8
PBR Router 2
To customer environment optional
Te 1/9
PBR Router 3
To customer environment optional
Te 1/10
PBR Router 3
To customer environment optional
Te 1/11
PBR Router 4
To customer environment optional
Te 1/12
PBR Router 4
To customer environment optional
Te 1/13
SG500-1
Te 2/13
Te 1/14
SG500-2
Te 2/13
Te 1/15
VSS to 4500X-2
Te 1/15
Port-Channel 5
Te 1/16
VSS to 4500X-2
Te 1/16
Port-Channel 5
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
A-9
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-4S Redundant Cabling Scheme
Cisco Catalyst 4500X-2 Switch Cabling (VDS-TC-4S Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X-2
Te 1/1
CE-1
Te 1
Te 1/2
CE-2
Te 1
Te 1/3
CE-3
Te 1
Te 1/4
CE-4
Te 1
Te 1/5
PBR Router 1
To customer environment
Te 1/6
PBR Router 1
To customer environment
Te 1/7
PBR Router 2
To customer environment optional
Te 1/8
PBR Router 2
To customer environment optional
Te 1/9
PBR Router 3
To customer environment optional
Te 1/10
PBR Router 3
To customer environment optional
Te 1/11
PBR Router 4
To customer environment optional
Te 1/12
PBR Router 4
To customer environment optional
Te 1/13
SG500-1
Te 2/14
Te 1/14
SG500-2
Te 2/14
Te 1/15
VSS to 4500X-2
Te 1/15
Port-Channel 10
Te 1/16
VSS to 4500X-2
Te 1/16
Port-Channel 10
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
A-10
OL-31421-04
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-4S Redundant Cabling Scheme
Cisco SG500-1 Switch Cabling (VDS-TC-4S Redundant)
Note
Refer to the Notes column in the table for cable type. For the 10GBase-T connections, you can use either
CAT6 or CAT7 cables.
Local Device
Local Port
Remote Device
Remote Port
Notes
SG500-1
Te 2/1
NetApp Storage 1
Controller1 port 1
10GBase-T
Te 2/2
NetApp Storage 1
Controller2 port 1
10GBase-T
Te 2/3
NetApp Storage 2
Controller1 port 1
10GBase-T
Te 2/4
NetApp Storage 2
Controller2 port 1
10GBase-T
Te 2/5
NetApp Storage 1
Controller1 Mgmt
port 1
1000Base-T
Te 2/6
Mgmt Server
Eth1
1000Base-T
Te 2/7
CE-1 Mgmt
Eth1
1000Base-T
Te 2/8
CE-2 Mgmt
Eth1
1000Base-T
Te 2/9
CE-3 Mgmt
Eth1
1000Base-T
Te 2/10
CE-4 Mgmt
Eth1
1000Base-T
Te 2/11
NetApp Storage 1
Controller1 Mgmt
port 2
1000Base-T
Te 2/13
4500X-1
Te 1/13
SFP+ 10G
Te 2/14
4500X-2
Te 1/13
SFP+ 10G
Te 2/15
SG500-2
Te 2/15
Interlink stack
port
SFP+ 10G
Te 2/16
SG500-2
Te 2/16
Interlink stack
port
SFP+ 10G
Gi 2/1
Mgmt Uplink
To customer
environment
1000Base-T
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
A-11
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-4S Redundant Cabling Scheme
Cisco SG500-2 Switch Cabling (VDS-TC-4S Redundant)
Note
Refer to the Notes column in the table for cable type. For the 10GBase-T connections, you can use either
CAT6 or CAT7 cables.
Local Device
Local Port
Remote Device
Remote Port
Notes
SG500-2
Te 2/1
NetApp Storage 1
Controller1 port 2
10GBase-T
Te 2/2
NetApp Storage 1
Controller2 port 2
10GBase-T
Te 2/3
NetApp Storage 2
Controller1 port 2
10GBase-T
Te 2/4
NetApp Storage 2
Controller2 port 2
10GBase-T
Te 2/5
NetApp Storage 2
Controller1 Mgmt
port 1
1000Base-T
Te 2/6
Mgmt Server
Eth2
1000Base-T
Te 2/7
CE-1 Mgmt
Eth2
1000Base-T
Te 2/8
CE-2 Mgmt
Eth2
1000Base-T
Te 2/9
CE-3 Mgmt
Eth2
1000Base-T
Te 2/10
CE-4 Mgmt
Eth2
1000Base-T
Te 2/11
NetApp Storage 2
Controller1 Mgmt
port 2
1000Base-T
Te 2/13
4500X-1
Te 1/14
SFP+ 10G
Te 2/14
4500X-2
Te 1/14
SFP+ 10G
Te 2/15
SG500-1
Te 2/15
Interlink stack
port
SFP+ 10G
Te 2/16
SG500-1
Te 2/16
Interlink stack
port
SFP+ 10G
Gi 2/1
Mgmt Uplink
To customer
environment
1000Base-T
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
A-12
OL-31421-04
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-8S Non-Redundant Cabling Scheme
VDS-TC-8S Non-Redundant Cabling Scheme
This section provides the cabling scheme for the VDS-TC-8S non-redundant solution.
Cisco Catalyst 4500X Switch Cabling (VDS-TC-8S Non-Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X
Te 1/1
CE-1
Te 0
Te 1/2
CE-2
Te 0
Te 1/3
CE-3
Te 0
Te 1/4
CE-4
Te 0
Te 1/5
CE-5
Te 0
Te 1/6
CE-6
Te 0
Te 1/7
CE-7
Te 0
Te 1/8
CE-8
Te 0
Te 1/21
3172TQ
Eth1/49/1
Te 1/22
3172TQ
Eth1/49/2
Te 1/23
3172TQ
Eth1/50/1
Te 1/24
3172TQ
Eth1/50/2
Te 1/25
PBR Router 1
To customer
environment
Te 1/26
PBR Router 1
To customer
environment
Te 1/27
PBR Router 2
To customer
environment
optional
Te 1/28
PBR Router 2
To customer
environment
optional
Te 1/29
PBR Router 3
To customer
environment
optional
Te 1/30
PBR Router 3
To customer
environment
optional
Te 1/31
PBR Router 4
To customer
environment
optional
Te 1/32
PBR Router 4
To customer
environment
optional
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
A-13
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-8S Non-Redundant Cabling Scheme
Cisco Nexus 3172TQ Switch Cabling (VDS-TC-8S Non-Redundant)
Note
Refer to the Notes column in the table for cable type. For the 10GBase-T connections, you can use either
CAT6 or CAT7 cables.
Local Device
Local Port
Remote Device
Remote Port
Notes
3172TQ
Ethernet 1/1
CE-1 Mgmt
Eth1
1000Base-T
Ethernet 1/2
CE-2 Mgmt
Eth1
1000Base-T
Ethernet 1/3
CE-3 Mgmt
Eth1
1000Base-T
Ethernet 1/4
CE-4 Mgmt
Eth1
1000Base-T
Ethernet 1/5
CE-5 Mgmt
Eth1
1000Base-T
Ethernet 1/6
CE-6 Mgmt
Eth1
1000Base-T
Ethernet 1/7
CE-7 Mgmt
Eth1
1000Base-T
Ethernet 1/8
CE-8 Mgmt
Eth1
1000Base-T
Ethernet 1/18
Mgmt Srv
Eth1
1000Base-T
Ethernet 1/19
Mgmt Uplink
To customer environment 1000Base-T
Ethernet 1/20
NetApp Storage 1 Controller1 Mgmt port 1
1000Base-T
Ethernet 1/21
NetApp Storage 2 Controller1 Mgmt port 1
1000Base-T
Ethernet 1/22
NetApp Storage 3 Controller1 Mgmt port 1
1000Base-T
Ethernet 1/25
NetApp Storage 1 Controller1 port 1
10GBase-T
Ethernet 1/26
NetApp Storage 1 Controller2 port 1
10GBase-T
Ethernet 1/27
NetApp Storage 2 Controller1 port 1
10GBase-T
Ethernet 1/28
NetApp Storage 2 Controller2 port 1
10GBase-T
Ethernet 1/29
NetApp Storage 3 Controller1 port 1
10GBase-T
Ethernet 1/30
NetApp Storage 3 Controller2 port 1
10GBase-T
Ethernet 1/49/1
4500X
Te 1/21
SFP+ 40G
Breakout Cable
Ethernet 1/49/2
4500X
Te 1/22
SFP+ 40G
Breakout Cable
Ethernet 1/50/1
4500X
Te 1/23
SFP+ 40G
Breakout Cable
Ethernet 1/50/2
4500X
Te 1/24
SFP+ 40G
Breakout Cable
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
A-14
OL-31421-04
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-8S Redundant Cabling Scheme
VDS-TC-8S Redundant Cabling Scheme
This section provides the cabling scheme for the VDS-TC-8S redundant solution.
Cisco Catalyst 4500X-1 Switch Cabling (VDS-TC-8S Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X-1
Te 1/1
CE-1
Te 0
Te 1/2
CE-2
Te 0
Te 1/3
CE-3
Te 0
Te 1/4
CE-4
Te 0
Te 1/5
CE-5
Te 0
Te 1/6
CE-6
Te 0
Te 1/7
CE-7
Te 0
Te 1/8
CE-8
Te 0
Te 1/13
4500X-2
Te 1/13
Port-channel 5
Te 1/14
4500X-2
Te 1/14
Port-channel 5
Te 1/15
4500X-2
Te 1/15
Port-channel 5
Te 1/16
4500X-2
Te 1/16
Port-channel 5
Te 1/17
4500X-2
Te 1/17
Port-channel 5
Te 1/18
4500X-2
Te 1/18
Port-channel 5
Te 1/19
4500X-2
Te 1/19
Port-channel 5
Te 1/20
4500X-2
Te 1/20
Port-channel 5
Te 1/21
3172TQ-1
Eth 1/49/2
Te 1/22
3172TQ-2
Eth 1/49/2
Te 1/23
3172TQ-1
Eth 1/49/1
Te 1/24
3172TQ-2
Eth 1/49/1
Te 1/25
PBR Router 1
To customer environment
Te 1/26
PBR Router 1
To customer environment
Te 1/27
PBR Router 2
To customer environment optional
Te 1/28
PBR Router 2
To customer environment optional
Te 1/29
PBR Router 3
To customer environment optional
Te 1/30
PBR Router 3
To customer environment optional
Te 1/31
PBR Router 4
To customer environment optional
Te 1/32
PBR Router 4
To customer environment optional
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
A-15
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-8S Redundant Cabling Scheme
Cisco Catalyst 4500X-2 Switch Cabling (VDS-TC-8S Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X-2
Te 1/1
CE-1
Te 1
Te 1/2
CE-2
Te 1
Te 1/3
CE-3
Te 1
Te 1/4
CE-4
Te 1
Te 1/5
CE-5
Te 1
Te 1/6
CE-6
Te 1
Te 1/7
CE-7
Te 1
Te 1/8
CE-8
Te 1
Te 1/13
4500X-1
Te 1/13
Port-channel 10
Te 1/14
4500X-1
Te 1/14
Port-channel 10
Te 1/15
4500X-1
Te 1/15
Port-channel 10
Te 1/16
4500X-1
Te 1/16
Port-channel 10
Te 1/17
4500X-1
Te 1/17
Port-channel 10
Te 1/18
4500X-1
Te 1/18
Port-channel 10
Te 1/19
4500X-1
Te 1/19
Port-channel 10
Te 1/20
4500X-1
Te 1/20
Port-channel 10
Te 1/21
3172TQ-1
Eth 1/50/2
Te 1/22
3172TQ-2
Eth 1/50/2
Te 1/23
3172TQ-1
Eth 1/50/1
Te 1/24
3172TQ-2
Eth 1/50/1
Te 1/25
PBR Router 1
To customer environment
Te 1/26
PBR Router 1
To customer environment
Te 1/27
PBR Router 2
To customer environment optional
Te 1/28
PBR Router 2
To customer environment optional
Te 1/29
PBR Router 3
To customer environment optional
Te 1/30
PBR Router 3
To customer environment optional
Te 1/31
PBR Router 4
To customer environment optional
Te 1/32
PBR Router 4
To customer environment optional
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
A-16
OL-31421-04
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-8S Redundant Cabling Scheme
Cisco Nexus 3172TQ Switch Cabling (VDS-TC-8S Redundant)
Note
Refer to the Notes column in the table for cable type. For the 10GBase-T connections, you can use either
CAT6 or CAT7 cables.
Local Device
Local Port
Remote Device
Remote Port
Notes
3172TQ-1
Ethernet 1/1
CE-1 Mgmt
Eth1
1000Base-T
Ethernet 1/2
CE-2 Mgmt
Eth1
1000Base-T
Ethernet 1/3
CE-3 Mgmt
Eth1
1000Base-T
Ethernet 1/4
CE-4 Mgmt
Eth1
1000Base-T
Ethernet 1/5
CE-5 Mgmt
Eth1
1000Base-T
Ethernet 1/6
CE-6 Mgmt
Eth1
1000Base-T
Ethernet 1/7
CE-7 Mgmt
Eth1
1000Base-T
Ethernet 1/8
CE-8 Mgmt
Eth1
1000Base-T
Ethernet 1/18
MG-1
Eth1
1000Base-T
Ethernet 1/19
Mgmt Uplink
To customer environment 1000Base-T
Ethernet 1/20
NetApp Storage 1
Controller1 Mgmt port 1
1000Base-T
Ethernet 1/21
NetApp Storage 2
Controller1 Mgmt port 1
1000Base-T
Ethernet 1/22
NetApp Storage 3
Controller1 Mgmt port 1
1000Base-T
Ethernet 1/25
NetApp Storage 1
Controller1 port 1
10GBase-T
Ethernet 1/26
NetApp Storage 1
Controller2 port 1
10GBase-T
Ethernet 1/27
NetApp Storage 2
Controller1 port 1
10GBase-T
Ethernet 1/28
NetApp Storage 2
Controller2 port 1
10GBase-T
Ethernet 1/29
NetApp Storage 3
Controller1 port 1
10GBase-T
Ethernet 1/30
NetApp Storage 3
Controller2 port 1
10GBase-T
Ethernet 1/45
3172TQ-2
Ethernet 1/45
10GBase-T
Ethernet 1/46
3172TQ-2
Ethernet 1/46
10GBase-T
Ethernet 1/47
3172TQ-2
Ethernet 1/47
10GBase-T
Ethernet 1/48
3172TQ-2
Ethernet 1/48
10GBase-T
Ethernet 1/49/1
4500X-1
Te 1/23
SFP+ 40G
Breakout Cable
Ethernet 1/49/2
4500X-1
Te 1/21
SFP+ 40G
Breakout Cable
Ethernet 1/50/1
4500X-2
Te 1/23
SFP+ 40G
Breakout Cable
Ethernet 1/50/2
4500X-2
Te 1/21
SFP+ 40G
Breakout Cable
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
A-17
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-8S Redundant Cabling Scheme
Cisco Catalyst 3172TQ-2 Switch Cabling (VDS-TC-8S Redundant)
Note
Refer to the Notes column in the table for cable type. For the 10GBase-T connections, you can use either
CAT6 or CAT7 cables.
Local Device
Local Port
Remote Device
Remote Port
Notes
3172TQ-2
Ethernet 1/1
CE-1 Mgmt
Eth2
1000Base-T
Ethernet 1/2
CE-2 Mgmt
Eth2
1000Base-T
Ethernet 1/3
CE-3 Mgmt
Eth2
1000Base-T
Ethernet 1/4
CE-4 Mgmt
Eth2
1000Base-T
Ethernet 1/5
CE-5 Mgmt
Eth2
1000Base-T
Ethernet 1/6
CE-6 Mgmt
Eth2
1000Base-T
Ethernet 1/7
CE-7 Mgmt
Eth2
1000Base-T
Ethernet 1/8
CE-8 Mgmt
Eth2
1000Base-T
Ethernet 1/18
MG-1
Eth2
1000Base-T
Ethernet 1/19
Mgmt Uplink
To customer
environment
1000Base-T
Ethernet 1/20
NetApp Storage 1
Controller2 Mgmt port 1 1000Base-T
Ethernet 1/21
NetApp Storage 2
Controller2 Mgmt port 1 1000Base-T
Ethernet 1/22
NetApp Storage 3
Controller2 Mgmt port 1 1000Base-T
Ethernet 1/25
NetApp Storage 1
Controller1 port 2
10GBase-T
Ethernet 1/26
NetApp Storage 1
Controller2 port 2
10GBase-T
Ethernet 1/27
NetApp Storage 2
Controller1 port 2
10GBase-T
Ethernet 1/28
NetApp Storage 2
Controller2 port 2
10GBase-T
Ethernet 1/29
NetApp Storage 3
Controller1 port 2
10GBase-T
Ethernet 1/30
NetApp Storage 3
Controller2 port 2
10GBase-T
Ethernet 1/45
3172TQ-1
Ethernet 1/45
10GBase-T
Ethernet 1/46
3172TQ-1
Ethernet 1/46
10GBase-T
Ethernet 1/47
3172TQ-1
Ethernet 1/47
10GBase-T
Ethernet 1/48
3172TQ-1
Ethernet 1/48
10GBase-T
Ethernet 1/49/1
4500X-1
Te 1/24
SFP+ 40G
Breakout Cable
Ethernet 1/49/2
4500X-1
Te 1/22
SFP+ 40G
Breakout Cable
Ethernet 1/50/1
4500X-2
Te 1/24
SFP+ 40G
Breakout Cable
Ethernet 1/50/2
4500X-2
Te 1/22
SFP+ 40G
Breakout Cable
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
A-18
OL-31421-04
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-16S Non-Redundant Cabling Scheme
VDS-TC-16S Non-Redundant Cabling Scheme
This section provides the cabling scheme for the VDS-TC-16S non-redundant solution.
Cisco Catalyst 4500X Switch Cabling (VDS-TC-16S Non-Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X
Te 1/1
CE-1
Te 0
Te 1/2
CE-2
Te 0
Te 1/3
CE-3
Te 0
Te 1/4
CE-4
Te 0
Te 1/5
CE-5
Te 0
Te 1/6
CE-6
Te 0
Te 1/7
CE-7
Te 0
Te 1/8
CE-8
Te 0
Te 1/9
CE-9
Te 0
Te 1/10
CE-10
Te 0
Te 1/11
CE-11
Te 0
Te 1/12
CE-12
Te 0
Te 1/13
CE-13
Te 0
Te 1/14
CE-14
Te 0
Te 1/15
CE-15
Te 0
Te 1/16
CE-16
Te 0
Te 1/21
3172TQ
Eth 1/49/1
Te 1/22
3172TQ
Eth 1/49/2
Te 1/23
3172TQ
Eth 1/50/1
Te 1/24
3172TQ
Eth 1/50/2
Te 1/25
PBR Router 1
To customer environment
Te 1/26
PBR Router 1
To customer environment
Te 1/27
PBR Router 2
To customer environment optional
Te 1/28
PBR Router 2
To customer environment optional
Te 1/29
PBR Router 3
To customer environment optional
Te 1/30
PBR Router 3
To customer environment optional
Te 1/31
PBR Router 4
To customer environment optional
Te 1/32
PBR Router 4
To customer environment optional
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
A-19
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-16S Non-Redundant Cabling Scheme
Cisco Nexus 3172TQ Switch Cabling (VDS-TC-16S Non-Redundant)
Note
Refer to the Notes column in the table for cable type. For the 10GBase-T connections, you can use either
CAT6 or CAT7 cables.
Local Device
Local Port
Remote Device
Remote Port
Notes
3172TQ
Ethernet 1/1
CE-1 Mgmt
Eth1
1000Base-T
Ethernet 1/2
CE-2 Mgmt
Eth1
1000Base-T
Ethernet 1/3
CE-3 Mgmt
Eth1
1000Base-T
Ethernet 1/4
CE-4 Mgmt
Eth1
1000Base-T
Ethernet 1/5
CE-5 Mgmt
Eth1
1000Base-T
Ethernet 1/6
CE-6 Mgmt
Eth1
1000Base-T
Ethernet 1/7
CE-7 Mgmt
Eth1
1000Base-T
Ethernet 1/8
CE-8 Mgmt
Eth1
1000Base-T
Ethernet 1/9
CE-9 Mgmt
Eth1
1000Base-T
Ethernet 1/10
CE-10 Mgmt
Eth1
1000Base-T
Ethernet 1/11
CE-11 Mgmt
Eth1
1000Base-T
Ethernet 1/12
CE-12 Mgmt
Eth1
1000Base-T
Ethernet 1/13
CE-13 Mgmt
Eth1
1000Base-T
Ethernet 1/14
CE-14 Mgmt
Eth1
1000Base-T
Ethernet 1/15
CE-15 Mgmt
Eth1
1000Base-T
Ethernet 1/16
CE-16 Mgmt
Eth1
1000Base-T
Ethernet 1/18
MG-1
Eth1
1000Base-T
Ethernet 1/19
Mgmt Uplink
To customer
environment
1000Base-T
Ethernet 1/20
NetApp Storage 1
Controller1 Mgmt port 1 1000Base-T
Ethernet 1/21
NetApp Storage 2
Controller1 Mgmt port 1 1000Base-T
Ethernet 1/22
NetApp Storage 3
Controller1 Mgmt port 1 1000Base-T
Ethernet 1/23
NetApp Storage 4
Controller1 Mgmt port 1 1000Base-T
Ethernet 1/24
NetApp Storage 5
Controller1 Mgmt port 1 1000Base-T
Ethernet 1/25
NetApp Storage 6
Controller1 Mgmt port 1 1000Base-T
Ethernet 1/26
NetApp Storage 1
Controller1 port 1
10GBase-T
Ethernet 1/27
NetApp Storage 1
Controller2 port 1
10GBase-T
Ethernet 1/28
NetApp Storage 2
Controller1 port 1
10GBase-T
Ethernet 1/29
NetApp Storage 2
Controller2 port 1
10GBase-T
Ethernet 1/30
NetApp Storage 3
Controller1 port 1
10GBase-T
Ethernet 1/31
NetApp Storage 3
Controller2 port 1
10GBase-T
Ethernet 1/32
NetApp Storage 4
Controller1 port 1
10GBase-T
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
A-20
OL-31421-04
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-16S Non-Redundant Cabling Scheme
Cisco Nexus 3172TQ Switch Cabling (VDS-TC-16S Non-Redundant) (continued)
Note
Refer to the Notes column in the table for cable type. For the 10GBase-T connections, you can use either
CAT6 or CAT7 cables.
Local Device
Local Port
Remote Device
Remote Port
Notes
3172TQ
Ethernet 1/33
NetApp Storage 4
Controller2 port 1
10GBase-T
Ethernet 1/34
NetApp Storage 5
Controller1 port 1
10GBase-T
Ethernet 1/35
NetApp Storage 5
Controller2 port 1
10GBase-T
Ethernet 1/36
NetApp Storage 6
Controller1 port 1
10GBase-T
Ethernet 1/37
NetApp Storage 6
Controller2 port 1
10GBase-T
Ethernet 1/49/1
4500X
Te 1/21
SFP+ 40G
Breakout Cable
Ethernet 1/49/2
4500X
Te 1/22
SFP+ 40G
Breakout Cable
Ethernet 1/50/1
4500X
Te 1/23
SFP+ 40G
Breakout Cable
Ethernet 1/50/2
4500X
Te 1/24
SFP+ 40G
Breakout Cable
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
A-21
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-16S Redundant Cabling Scheme
VDS-TC-16S Redundant Cabling Scheme
This section provides the cabling scheme for the VDS-TC-16S redundant solution.
Cisco Catalyst 4500X-1 Switch Cabling (VDS-TC-16S Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X-1
Te 1/1
CE-1
Te 0
Te 1/2
CE-2
Te 0
Te 1/3
CE-3
Te 0
Te 1/4
CE-4
Te 0
Te 1/5
CE-5
Te 0
Te 1/6
CE-6
Te 0
Te 1/7
CE-7
Te 0
Te 1/8
CE-8
Te 0
Te 1/9
CE-9
Te 0
Te 1/10
CE-10
Te 0
Te 1/11
CE-11
Te 0
Te 1/12
CE-12
Te 0
Te 1/13
CE-13
Te 0
Te 1/14
CE-14
Te 0
Te 1/15
CE-15
Te 0
Te 1/16
CE-16
Te 0
Te 1/21
3172TQ-1
Ethernet 1/49/2
Te 1/22
3172TQ-2
Ethernet 1/49/2
Te 1/23
3172TQ-1
Ethernet 1/49/1
Te 1/24
3172TQ-2
Ethernet 1/49/1
Te 1/25
PBR Router 1
To customer environment
Te 1/26
PBR Router 1
To customer environment
Te 1/27
PBR Router 2
To customer environment
optional
Te 1/28
PBR Router 2
To customer environment
optional
Te 1/29
PBR Router 3
To customer environment
optional
Te 1/30
PBR Router 3
To customer environment
optional
Te 1/31
PBR Router 4
To customer environment
optional
Te 1/32
PBR Router 4
To customer environment
optional
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
A-22
OL-31421-04
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-16S Redundant Cabling Scheme
Cisco Catalyst 4500X-1 Switch Cabling (VDS-TC-16S Redundant) (continued)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X-1
Te 2/1
4500X-2
Te 2/1
port-channel 5
Te 2/2
4500X-2
Te 2/2
port-channel 5
Te 2/3
4500X-2
Te 2/3
port-channel 5
Te 2/4
4500X-2
Te 2/4
port-channel 5
Te 2/5
4500X-2
Te 2/5
port-channel 5
Te 2/6
4500X-2
Te 2/6
port-channel 5
Te 2/7
4500X-2
Te 2/7
port-channel 5
Te 2/8
4500X-2
Te 2/8
port-channel 5
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
A-23
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-16S Redundant Cabling Scheme
Cisco Catalyst 4500X-2 Switch Cabling (VDS-TC-16S Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X-2
Te 1/1
CE-1
Te 1
Te 1/2
CE-2
Te 1
Te 1/3
CE-3
Te 1
Te 1/4
CE-4
Te 1
Te 1/5
CE-5
Te 1
Te 1/6
CE-6
Te 1
Te 1/7
CE-7
Te 1
Te 1/8
CE-8
Te 1
Te 1/9
CE-9
Te 1
Te 1/10
CE-10
Te 1
Te 1/11
CE-11
Te 1
Te 1/12
CE-12
Te 1
Te 1/13
CE-13
Te 1
Te 1/14
CE-14
Te 1
Te 1/15
CE-15
Te 1
Te 1/16
CE-16
Te 1
Te 1/21
3172TQ-1
Eth 1/50/2
Te 1/22
3172TQ-2
Eth 1/50/2
Te 1/23
3172TQ-1
Eth 1/50/1
Te 1/24
3172TQ-2
Eth 1/50/1
Te 1/25
PBR Router 1
To customer environment
Te 1/26
PBR Router 1
To customer environment
Te 1/27
PBR Router 2
To customer environment
optional
Te 1/28
PBR Router 2
To customer environment
optional
Te 1/29
PBR Router 3
To customer environment
optional
Te 1/30
PBR Router 3
To customer environment
optional
Te 1/31
PBR Router 4
To customer environment
optional
Te 1/32
PBR Router 4
To customer environment
optional
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
A-24
OL-31421-04
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-16S Redundant Cabling Scheme
Cisco Catalyst 4500X-2 Switch Cabling (VDS-TC-16S Redundant) (continued)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X-2
Te 2/1
4500X-1
Te 2/1
port-channel 10
Te 2/2
4500X-1
Te 2/2
port-channel 10
Te 2/3
4500X-1
Te 2/3
port-channel 10
Te 2/4
4500X-1
Te 2/4
port-channel 10
Te 2/5
4500X-1
Te 2/5
port-channel 10
Te 2/6
4500X-1
Te 2/6
port-channel 10
Te 2/7
4500X-1
Te 2/7
port-channel 10
Te 2/8
4500X-1
Te 2/8
port-channel 10
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
A-25
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-16S Redundant Cabling Scheme
Cisco Catalyst 3172TQ-1 Switch Cabling (VDS-TC-16S Redundant)
Note
Refer to the Notes column in the table for cable type. For the 10GBase-T connections, you can use either
CAT6 or CAT7 cables.
Local Device
Local Port
Remote Device
Remote Port
Notes
3172TQ-1
Ethernet 1/1
CE-1 Mgmt
Eth1
1000Base-T
Ethernet 1/2
CE-2 Mgmt
Eth1
1000Base-T
Ethernet 1/3
CE-3 Mgmt
Eth1
1000Base-T
Ethernet 1/4
CE-4 Mgmt
Eth1
1000Base-T
Ethernet 1/5
CE-5 Mgmt
Eth1
1000Base-T
Ethernet 1/6
CE-6 Mgmt
Eth1
1000Base-T
Ethernet 1/7
CE-7 Mgmt
Eth1
1000Base-T
Ethernet 1/8
CE-8 Mgmt
Eth1
1000Base-T
Ethernet 1/9
CE-9 Mgmt
Eth1
1000Base-T
Ethernet 1/10
CE-10 Mgmt
Eth1
1000Base-T
Ethernet 1/11
CE-11 Mgmt
Eth1
1000Base-T
Ethernet 1/12
CE-12 Mgmt
Eth1
1000Base-T
Ethernet 1/13
CE-13 Mgmt
Eth1
1000Base-T
Ethernet 1/14
CE-14 Mgmt
Eth1
1000Base-T
Ethernet 1/15
CE-15 Mgmt
Eth1
1000Base-T
Ethernet 1/16
CE-16 Mgmt
Eth1
1000Base-T
Ethernet 1/18
MG-1
Eth1
1000Base-T
Ethernet 1/19
Mgmt Uplink
To customer
environment
1000Base-T
Ethernet 1/20
NetApp Storage 1
Controller1 Mgmt port 1 1000Base-T
Ethernet 1/21
NetApp Storage 2
Controller1 Mgmt port 1 1000Base-T
Ethernet 1/22
NetApp Storage 3
Controller1 Mgmt port 1 1000Base-T
Ethernet 1/23
NetApp Storage 4
Controller1 Mgmt port 1 1000Base-T
Ethernet 1/24
NetApp Storage 5
Controller1 Mgmt port 1 1000Base-T
Ethernet 1/25
NetApp Storage 6
Controller1 Mgmt port 1 1000Base-T
Ethernet 1/26
NetApp Storage 1
Controller1 port 1
10GBase-T
Ethernet 1/27
NetApp Storage 1
Controller2 port 1
10GBase-T
Ethernet 1/28
NetApp Storage 2
Controller1 port 1
10GBase-T
Ethernet 1/29
NetApp Storage 2
Controller2 port 1
10GBase-T
Ethernet 1/30
NetApp Storage 3
Controller1 port 1
10GBase-T
Ethernet 1/31
NetApp Storage 3
Controller2 port 1
10GBase-T
Ethernet 1/32
NetApp Storage 4
Controller1 port 1
10GBase-T
Ethernet 1/33
NetApp Storage 4
Controller2 port 1
10GBase-T
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
A-26
OL-31421-04
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-16S Redundant Cabling Scheme
Cisco Catalyst 3172TQ-1 Switch Cabling (VDS-TC-16S Redundant) (continued)
Note
Refer to the Notes column in the table for cable type. For the 10GBase-T connections, you can use either
CAT6 or CAT7 cables.
Local Device
Local Port
Remote Device
Remote Port
Notes
3172TQ-1
Ethernet 1/34
NetApp Storage 5
Controller1 port 1
10GBase-T
Ethernet 1/35
NetApp Storage 5
Controller2 port 1
10GBase-T
Ethernet 1/36
NetApp Storage 6
Controller1 port 1
10GBase-T
Ethernet 1/37
NetApp Storage 6
Controller2 port 1
10GBase-T
Ethernet 1/45
3172TQ-2
Ethernet 1/45
10GBase-T
Ethernet 1/46
3172TQ-2
Ethernet 1/46
10GBase-T
Ethernet 1/47
3172TQ-2
Ethernet 1/47
10GBase-T
Ethernet 1/48
3172TQ-2
Ethernet 1/48
10GBase-T
Ethernet 1/49/1
4500X-1
Te 1/23
SFP+ 40G
Breakout Cable
Ethernet 1/49/2
4500X-1
Te 1/21
SFP+ 40G
Breakout Cable
Ethernet 1/50/1
4500X-2
Te 1/23
SFP+ 40G
Breakout Cable
Ethernet 1/50/2
4500X-2
Te 1/21
SFP+ 40G
Breakout Cable
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
A-27
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-16S Redundant Cabling Scheme
Cisco Catalyst 3172TQ-2 Switch Cabling (VDS-TC-16S Redundant)
Note
Refer to the Notes column in the table for cable type. For the 10GBase-T connections, you can use either
CAT6 or CAT7 cables.
Local Device
Local Port
Remote Device
Remote Port
Notes
3172TQ-2
Ethernet 1/1
CE-1 Mgmt
Eth2
1000Base-T
Ethernet 1/2
CE-2 Mgmt
Eth2
1000Base-T
Ethernet 1/3
CE-3 Mgmt
Eth2
1000Base-T
Ethernet 1/4
CE-4 Mgmt
Eth2
1000Base-T
Ethernet 1/5
CE-5 Mgmt
Eth2
1000Base-T
Ethernet 1/6
CE-6 Mgmt
Eth2
1000Base-T
Ethernet 1/7
CE-7 Mgmt
Eth2
1000Base-T
Ethernet 1/8
CE-8 Mgmt
Eth2
1000Base-T
Ethernet 1/9
CE-9 Mgmt
Eth2
1000Base-T
Ethernet 1/10
CE-10 Mgmt
Eth2
1000Base-T
Ethernet 1/11
CE-11 Mgmt
Eth2
1000Base-T
Ethernet 1/12
CE-12 Mgmt
Eth2
1000Base-T
Ethernet 1/13
CE-13 Mgmt
Eth2
1000Base-T
Ethernet 1/14
CE-14 Mgmt
Eth2
1000Base-T
Ethernet 1/15
CE-15 Mgmt
Eth2
1000Base-T
Ethernet 1/16
CE-16 Mgmt
Eth2
1000Base-T
Ethernet 1/18
MG-1
Eth2
1000Base-T
Ethernet 1/19
Mgmt Uplink
To customer
environment
1000Base-T
Ethernet 1/20
NetApp Storage 1
Controller2 Mgmt port 1 1000Base-T
Ethernet 1/21
NetApp Storage 2
Controller2 Mgmt port 1 1000Base-T
Ethernet 1/22
NetApp Storage 3
Controller2 Mgmt port 1 1000Base-T
Ethernet 1/23
NetApp Storage 4
Controller2 Mgmt port 1 1000Base-T
Ethernet 1/24
NetApp Storage 5
Controller2 Mgmt port 1 1000Base-T
Ethernet 1/25
NetApp Storage 6
Controller2 Mgmt port 1 1000Base-T
Ethernet 1/26
NetApp Storage 1
Controller1 port 2
10GBase-T
Ethernet 1/27
NetApp Storage 1
Controller2 port 2
10GBase-T
Ethernet 1/28
NetApp Storage 2
Controller1 port 2
10GBase-T
Ethernet 1/29
NetApp Storage 2
Controller2 port 2
10GBase-T
Ethernet 1/30
NetApp Storage 3
Controller1 port 2
10GBase-T
Ethernet 1/31
NetApp Storage 3
Controller2 port 2
10GBase-T
Ethernet 1/32
NetApp Storage 4
Controller1 port 2
10GBase-T
Ethernet 1/33
NetApp Storage 4
Controller2 port 2
10GBase-T
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
A-28
OL-31421-04
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-16S Redundant Cabling Scheme
Cisco Catalyst 3172TQ-2 Switch Cabling (VDS-TC-16S Redundant) (continued)
Note
Refer to the Notes column in the table for cable type. For the 10GBase-T connections, you can use either
CAT6 or CAT7 cables.
Local Device
Local Port
Remote Device
Remote Port
Notes
3172TQ-2
Ethernet 1/34
NetApp Storage 5
Controller1 port 2
10GBase-T
Ethernet 1/35
NetApp Storage 5
Controller2 port 2
10GBase-T
Ethernet 1/36
NetApp Storage 6
Controller1 port 2
10GBase-T
Ethernet 1/37
NetApp Storage 6
Controller2 port 2
10GBase-T
Ethernet 1/45
3172TQ-1
Ethernet 1/45
10GBase-T
Ethernet 1/46
3172TQ-1
Ethernet 1/46
10GBase-T
Ethernet 1/47
3172TQ-1
Ethernet 1/47
10GBase-T
Ethernet 1/48
3172TQ-1
Ethernet 1/48
10GBase-T
Ethernet 1/49/1
4500X-1
Te 1/24
SFP+ 40G
Breakout Cable
Ethernet 1/49/2
4500X-1
Te 1/22
SFP+ 40G
Breakout Cable
Ethernet 1/50/1
4500X-2
Te 1/24
SFP+ 40G
Breakout Cable
Ethernet 1/50/2
4500X-2
Te 1/22
SFP+ 40G
Breakout Cable
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
A-29
Appendix A
Cisco VDS TC C-Series Cabling Guides when Using the NetApp E2724 Storage Enclosures
VDS-TC-16S Redundant Cabling Scheme
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
A-30
OL-31421-04
A P P E N D I X
B
Cisco VDS TC C-Series Cabling Guides when
Using IBM DS3524 Storage Enclosures
Revised: February 2016, OL-31421-04
This appendix provides cabling guidelines for cabling a VDS TC Cluster solution that uses Cisco
C-Series servers and IBM DS3524 storage enclosures. There are nine different configurations available
for a VDS TC C-Series Cluster installation. This appendix provides a separate set of tables for each one
of these configurations:
•
VDS-TC-2S Redundant 2x4500X
•
VDS-TC-4S Non-Redundant Cabling Scheme
•
VDS-TC-4S Redundant Cabling Scheme
•
VDS-TC-8S Non-Redundant Cabling Scheme
•
VDS-TC-8S Redundant Cabling Scheme
•
VDS-TC-16S Non-Redundant Cabling Scheme
•
VDS-TC-16S Redundant Cabling Scheme
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
B-1
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-2S Redundant 2x4500X
VDS-TC-2S Redundant 2x4500X
This section provides the cabling scheme for the VDS-TC-2S redundant solution that uses two Cisco
Catalyst 4500X switches.
Cisco Catalyst 4500X-1 Switch Cabling (VDS-TC-2S 2x4500X Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X-1
Te 1/1
CE-1
Te 0
Te 1/2
CE-2
Te 0
Te 1/4
MGMT-1
Eth 1
Te 1/5
Mgmt CE-1
Eth 1
Te 1/6
Mgmt CE-2
Eth 1
Te 1/8
IBM Storage 1
Controller1 Mgmt port 1
Te 1/9
IBM Storage 1
Controller1 port 3
Te 1/10
IBM Storage 1
Controller1 port 4
Te 1/11
IBM Storage 1
Controller2 port 3
Te 1/12
IBM Storage 1
Controller2 port 4
Te 1/13
PBR Router 1
To customer environment
Te 1/14
PBR Router 1
To customer environment
Te 1/15
PBR Router 2
To customer environment optional
Te 1/16
PBR Router 2
To customer environment optional
Te 1/17
PBR Router 3
To customer environment optional
Te 1/18
PBR Router 3
To customer environment optional
Te 1/19
PBR Router 4
To customer environment optional
Te 1/20
PBR Router 4
To customer environment optional
Te 1/21
4500X-2
Te 1/21
Port-channel 5
Te 1/22
4500X-2
Te 1/22
Port-channel 5
Te 1/24
Mgmt Uplink
To customer environment
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
B-2
OL-31421-04
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-2S Redundant 2x4500X
Cisco Catalyst 4500X-2 Switch Cabling (VDS-TC-2S 2x4500X Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X-2
Te 1/1
CE-1
Te 0
Te 1/2
CE-2
Te 0
Te 1/4
MGMT-1
Eth 1
Te 1/5
Mgmt CE-1
Eth 1
Te 1/6
Mgmt CE-2
Eth 1
Te 1/8
IBM Storage 1
Controller2 Mgmt port 1
Te 1/9
IBM Storage 1
Controller2 port 5
Te 1/10
IBM Storage 1
Controller2 port 6
Te 1/11
IBM Storage 1
Controller1 port 5
Te 1/12
IBM Storage 1
Controller1 port 6
Te 1/13
PBR Router 1
To customer environment
Te 1/14
PBR Router 1
To customer environment
Te 1/15
PBR Router 2
To customer environment optional
Te 1/16
PBR Router 2
To customer environment optional
Te 1/17
PBR Router 3
To customer environment optional
Te 1/18
PBR Router 3
To customer environment optional
Te 1/19
PBR Router 4
To customer environment optional
Te 1/20
PBR Router 4
To customer environment optional
Te 1/21
4500X-2
Te 1/21
Port-channel 10
Te 1/22
4500X-2
Te 1/22
Port-channel 10
Te 1/24
Mgmt Uplink
To customer environment
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
B-3
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-4S Non-Redundant Cabling Scheme
VDS-TC-4S Non-Redundant Cabling Scheme
This section provides the cabling scheme for the VDS-TC-4S non-redundant solution.
Cisco Catalyst 4500X Switch Cabling (VDS-TC-4S Non-Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X
Te 1/1
CE-1
Te 0
Te 1/2
CE-2
Te 0
Te 1/3
CE-3
Te 0
Te 1/4
CE-4
Te 0
Te 1/21
4948E
Te 1/49
Te 1/22
4948E
Te 1/50
Te 1/23
4948E
Te 1/51
Te 1/24
4948E
Te 1/52
Te 1/25
PBR Router 1
To customer
environment
Te 1/26
PBR Router 1
To customer
environment
Te 1/27
PBR Router 2
To customer
environment
optional
Te 1/28
PBR Router 2
To customer
environment
optional
Te 1/29
PBR Router 3
To customer
environment
optional
Te 1/30
PBR Router 3
To customer
environment
optional
Te 1/31
PBR Router 4
To customer
environment
optional
Te 1/32
PBR Router 4
To customer
environment
optional
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
B-4
OL-31421-04
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-4S Non-Redundant Cabling Scheme
Cisco Catalyst 4948E Switch Cabling (VDS-TC-4S Non-Redundant)
Note
All connections from the Cisco Catalyst 4948E switch use a 1000Base-T CAT 5 or CAT6 cable except
for the connections to the Cisco Catalyst 4500X switch. The connections from the Cisco Catalyst 4948E
switch to the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable. If a cable
longer than 3 meters is required, please refer to the specific product documentation to verify which
longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
4948E
GigabitEthernet1/1
Mgmt CE-1
Eth1
GigabitEthernet1/2
Mgmt CE-2
Eth1
GigabitEthernet1/3
Mgmt CE-3
Eth1
GigabitEthernet1/4
Mgmt CE-4
Eth1
GigabitEthernet1/18
MG-1
Eth1
GigabitEthernet1/19
Mgmt Uplink
To customer environment
GigabitEthernet1/20
IBM Storage 1
Controller1 Mgmt port 1
GigabitEthernet1/21
IBM Storage 2
Controller1 Mgmt port 1
GigabitEthernet1/25
IBM Storage 1
Controller1 port 3
GigabitEthernet1/26
IBM Storage 1
Controller1 port 4
GigabitEthernet1/27
IBM Storage 1
Controller1 port 5
GigabitEthernet1/28
IBM Storage 1
Controller1 port 6
GigabitEthernet1/29
IBM Storage 2
Controller1 port 3
GigabitEthernet1/30
IBM Storage 2
Controller1 port 4
GigabitEthernet1/31
IBM Storage 2
Controller1 port 5
GigabitEthernet1/32
IBM Storage 2
Controller1 port 6
Te 1/49
4500X
Te 1/21
Te 1/50
4500X
Te 1/22
Te 1/51
4500X
Te 1/23
Te 1/52
4500X
Te 1/24
Notes
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
B-5
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-4S Redundant Cabling Scheme
VDS-TC-4S Redundant Cabling Scheme
This section provides the cabling scheme for the VDS-TC-4S redundant solution.
Cisco Catalyst 4500X-1 Switch Cabling (VDS-TC-4S Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X-1
Te 1/1
CE-1
Te 0
Te 1/2
CE-2
Te 0
Te 1/3
CE-3
Te 0
Te 1/4
CE-4
Te 0
Te 1/13
4500X-2
Te 1/13
Port-channel 5
Te 1/14
4500X-2
Te 1/14
Port-channel 5
Te 1/15
4500X-2
Te 1/15
Port-channel 5
Te 1/16
4500X-2
Te 1/16
Port-channel 5
Te 1/17
4500X-2
Te 1/17
Port-channel 5
Te 1/18
4500X-2
Te 1/18
Port-channel 5
Te 1/19
4500X-2
Te 1/19
Port-channel 5
Te 1/20
4500X-2
Te 1/20
Port-channel 5
Te 1/21
4948E-1
Te 1/50
Te 1/22
4948E-2
Te 1/50
Te 1/23
4948E-1
Te 1/52
Te 1/24
4948E-2
Te 1/52
Te 1/25
PBR Router 1
To customer environment
Te 1/26
PBR Router 1
To customer environment
Te 1/27
PBR Router 2
To customer environment optional
Te 1/28
PBR Router 2
To customer environment optional
Te 1/29
PBR Router 3
To customer environment optional
Te 1/30
PBR Router 3
To customer environment optional
Te 1/31
PBR Router 4
To customer environment optional
Te 1/32
PBR Router 4
To customer environment optional
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
B-6
OL-31421-04
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-4S Redundant Cabling Scheme
Cisco Catalyst 4500X-2 Switch Cabling (VDS-TC-4S Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X-2
Te 1/1
CE-1
Te 1
Te 1/2
CE-2
Te 1
Te 1/3
CE-3
Te 1
Te 1/4
CE-4
Te 1
Te 1/13
4500X-1
Te 1/13
Port-channel 10
Te 1/14
4500X-1
Te 1/14
Port-channel 10
Te 1/15
4500X-1
Te 1/15
Port-channel 10
Te 1/16
4500X-1
Te 1/16
Port-channel 10
Te 1/17
4500X-1
Te 1/17
Port-channel 10
Te 1/18
4500X-1
Te 1/18
Port-channel 10
Te 1/19
4500X-1
Te 1/19
Port-channel 10
Te 1/20
4500X-1
Te 1/20
Port-channel 10
Te 1/21
4948E-1
Te 1/49
Te 1/22
4948E-2
Te 1/49
Te 1/23
4948E-1
Te 1/51
Te 1/24
4948E-2
Te 1/51
Te 1/25
PBR Router 1
To customer environment
Te 1/26
PBR Router 1
To customer environment
Te 1/27
PBR Router 2
To customer environment optional
Te 1/28
PBR Router 2
To customer environment optional
Te 1/29
PBR Router 3
To customer environment optional
Te 1/30
PBR Router 3
To customer environment optional
Te 1/31
PBR Router 4
To customer environment optional
Te 1/32
PBR Router 4
To customer environment optional
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
B-7
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-4S Redundant Cabling Scheme
Cisco Catalyst 4948E-1 Switch Cabling (VDS-TC-4S Redundant)
Note
All connections from the Cisco Catalyst 4948E switch use a 1000Base-T CAT 5 or CAT6 cable except
for the connections to the Cisco Catalyst 4500X switch. The connections from the Cisco Catalyst 4948E
switch to the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable. If a cable
longer than 3 meters is required, please refer to the specific product documentation to verify which
longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
4948E-1
GigabitEthernet1/1
CE-1 Mgmt
Eth1
GigabitEthernet1/2
CE-2 Mgmt
Eth1
GigabitEthernet1/3
CE-3 Mgmt
Eth1
GigabitEthernet1/4
CE-4 Mgmt
Eth1
GigabitEthernet1/18
MG-1
Eth1
GigabitEthernet1/19
Mgmt Uplink
To customer
environment
GigabitEthernet1/20
IBM Storage 1
Controller1 Mgmt
port 1
GigabitEthernet1/21
IBM Storage 2
Controller1 Mgmt
port 1
GigabitEthernet1/25
IBM Storage 1
Controller1 port 3
GigabitEthernet1/26
IBM Storage 1
Controller1 port 4
GigabitEthernet1/27
IBM Storage 1
Controller2 port 3
GigabitEthernet1/28
IBM Storage 1
Controller2 port 4
GigabitEthernet1/29
IBM Storage 2
Controller1 port 3
GigabitEthernet1/30
IBM Storage 2
Controller1 port 4
GigabitEthernet1/31
IBM Storage 2
Controller2 port 3
GigabitEthernet1/32
IBM Storage 2
Controller2 port 4
GigabitEthernet1/45
4948E-2
GigabitEthernet1/45
GigabitEthernet1/46
4948E-2
GigabitEthernet1/46
GigabitEthernet1/47
4948E-2
GigabitEthernet1/47
GigabitEthernet1/48
4948E-2
GigabitEthernet1/48
Te 1/49
4500X-2
Te 1/21
Te 1/50
4500X-1
Te 1/21
Te 1/51
4500X-2
Te 1/23
Te 1/52
4500X-1
Te 1/23
Notes
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
B-8
OL-31421-04
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-4S Redundant Cabling Scheme
Cisco Catalyst 4948E-2 Switch Cabling (VDS-TC-4S Redundant)
Note
All connections from the Cisco Catalyst 4948E switch use a 1000Base-T CAT 5 or CAT6 cable except
for the connections to the Cisco Catalyst 4500X switch. The connections from the Cisco Catalyst 4948E
switch to the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable. If a cable
longer than 3 meters is required, please refer to the specific product documentation to verify which
longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
4948E-2
GigabitEthernet1/1
CE-1 Mgmt
Eth2
GigabitEthernet1/2
CE-2 Mgmt
Eth2
GigabitEthernet1/3
CE-3 Mgmt
Eth2
GigabitEthernet1/4
CE-4 Mgmt
Eth2
GigabitEthernet1/18
MG-1
Eth2
GigabitEthernet1/19
Mgmt Uplink
To customer
environment
GigabitEthernet1/20
IBM Storage 1
Controller2 Mgmt
port 1
GigabitEthernet1/21
IBM Storage 2
Controller2 Mgmt
port 1
GigabitEthernet1/25
IBM Storage 1
Controller2 port 5
GigabitEthernet1/26
IBM Storage 1
Controller2 port 6
GigabitEthernet1/27
IBM Storage 1
Controller1 port 5
GigabitEthernet1/28
IBM Storage 1
Controller1 port 6
GigabitEthernet1/29
IBM Storage 2
Controller2 port 5
GigabitEthernet1/30
IBM Storage 2
Controller2 port 6
GigabitEthernet1/31
IBM Storage 2
Controller1 port 5
GigabitEthernet1/32
IBM Storage 2
Controller1 port 6
GigabitEthernet1/45
4948E-1
GigabitEthernet1/45
GigabitEthernet1/46
4948E-1
GigabitEthernet1/46
GigabitEthernet1/47
4948E-1
GigabitEthernet1/47
GigabitEthernet1/48
4948E-1
GigabitEthernet1/48
Te 1/49
4500X-2
Te 1/22
Te 1/50
4500X-1
Te 1/22
Te 1/51
4500x-2
Te 1/24
Te 1/52
4500X-1
Te 1/24
Notes
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
B-9
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-8S Non-Redundant Cabling Scheme
VDS-TC-8S Non-Redundant Cabling Scheme
This section provides the cabling scheme for the VDS-TC-8S non-redundant solution.
Cisco Catalyst 4500X Switch Cabling (VDS-TC-8S Non-Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X
Te 1/1
CE-1
Te 0
Te 1/2
CE-2
Te 0
Te 1/3
CE-3
Te 0
Te 1/4
CE-4
Te 0
Te 1/5
CE-5
Te 0
Te 1/6
CE-6
Te 0
Te 1/7
CE-7
Te 0
Te 1/8
CE-8
Te 0
Te 1/21
4948E
Te 1/49
Te 1/22
4948E
Te 1/50
Te 1/23
4948E
Te 1/51
Te 1/24
4948E
Te 1/52
Te 1/25
PBR Router 1
To customer
environment
Te 1/26
PBR Router 1
To customer
environment
Te 1/27
PBR Router 2
To customer
environment
optional
Te 1/28
PBR Router 2
To customer
environment
optional
Te 1/29
PBR Router 3
To customer
environment
optional
Te 1/30
PBR Router 3
To customer
environment
optional
Te 1/31
PBR Router 4
To customer
environment
optional
Te 1/32
PBR Router 4
To customer
environment
optional
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
B-10
OL-31421-04
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-8S Non-Redundant Cabling Scheme
Cisco Catalyst 4948E Switch Cabling (VDS-TC-8S Non-Redundant)
Note
All connections from the Cisco Catalyst 4948E switch use a 1000Base-T CAT 5 or CAT6 cable except
for the connections to the Cisco Catalyst 4500X switch. The connections from the Cisco Catalyst 4948E
switch to the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable. If a cable
longer than 3 meters is required, please refer to the specific product documentation to verify which
longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
4948E
GigabitEthernet1/1
CE-1
Eth1
GigabitEthernet1/2
CE-2
Eth1
GigabitEthernet1/3
CE-3
Eth1
GigabitEthernet1/4
CE-4
Eth1
GigabitEthernet1/5
CE-5
Eth1
GigabitEthernet1/6
CE-6
Eth1
GigabitEthernet1/7
CE-7
Eth1
GigabitEthernet1/8
CE-8
Eth1
GigabitEthernet1/18
MG-1
Eth1
GigabitEthernet1/19
Mgmt Uplink
To customer environment
GigabitEthernet1/20
IBM Storage 1
Controller1 Mgmt port 1
GigabitEthernet1/21
IBM Storage 2
Controller1 Mgmt port 1
GigabitEthernet1/22
IBM Storage 3
Controller1 Mgmt port 1
GigabitEthernet1/25
IBM Storage 1
Controller1 port 3
GigabitEthernet1/26
IBM Storage 1
Controller1 port 4
GigabitEthernet1/27
IBM Storage 1
Controller1 port 5
GigabitEthernet1/28
IBM Storage 1
Controller1 port 6
GigabitEthernet1/29
IBM Storage 2
Controller1 port 3
GigabitEthernet1/30
IBM Storage 2
Controller1 port 4
GigabitEthernet1/31
IBM Storage 2
Controller1 port 5
GigabitEthernet1/32
IBM Storage 2
Controller1 port 6
GigabitEthernet1/33
IBM Storage 3
Controller1 port 3
GigabitEthernet1/34
IBM Storage 3
Controller1 port 4
GigabitEthernet1/35
IBM Storage 3
Controller1 port 5
GigabitEthernet1/36
IBM Storage 3
Controller1 port 6
Te 1/49
4500X
Te 1/21
Te 1/50
4500X
Te 1/22
Te 1/51
4500X
Te 1/23
Te 1/52
4500X
Te 1/24
Notes
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
B-11
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-8S Redundant Cabling Scheme
VDS-TC-8S Redundant Cabling Scheme
This section provides the cabling scheme for the VDS-TC-8S redundant solution.
Cisco Catalyst 4500X-1 Switch Cabling (VDS-TC-8S Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X-1
Te 1/1
CE-1
Te 0
Te 1/2
CE-2
Te 0
Te 1/3
CE-3
Te 0
Te 1/4
CE-4
Te 0
Te 1/5
CE-5
Te 0
Te 1/6
CE-6
Te 0
Te 1/7
CE-7
Te 0
Te 1/8
CE-8
Te 0
Te 1/13
4500X-2
Te 1/13
Port-channel 5
Te 1/14
4500X-2
Te 1/14
Port-channel 5
Te 1/15
4500X-2
Te 1/15
Port-channel 5
Te 1/16
4500X-2
Te 1/16
Port-channel 5
Te 1/17
4500X-2
Te 1/17
Port-channel 5
Te 1/18
4500X-2
Te 1/18
Port-channel 5
Te 1/19
4500X-2
Te 1/19
Port-channel 5
Te 1/20
4500X-2
Te 1/20
Port-channel 5
Te 1/21
4948E-1
Te 1/50
Te 1/22
4948E-2
Te 1/50
Te 1/23
4948E-1
Te 1/52
Te 1/24
4948E-2
Te 1/52
Te 1/25
PBR Router 1
To customer environment
Te 1/26
PBR Router 1
To customer environment
Te 1/27
PBR Router 2
To customer environment optional
Te 1/28
PBR Router 2
To customer environment optional
Te 1/29
PBR Router 3
To customer environment optional
Te 1/30
PBR Router 3
To customer environment optional
Te 1/31
PBR Router 4
To customer environment optional
Te 1/32
PBR Router 4
To customer environment optional
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
B-12
OL-31421-04
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-8S Redundant Cabling Scheme
Cisco Catalyst 4500X-2 Switch Cabling (VDS-TC-8S Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X-2
Te 1/1
CE-1
Te 1
Te 1/2
CE-2
Te 1
Te 1/3
CE-3
Te 1
Te 1/4
CE-4
Te 1
Te 1/5
CE-5
Te 1
Te 1/6
CE-6
Te 1
Te 1/7
CE-7
Te 1
Te 1/8
CE-8
Te 1
Te 1/13
4500X-1
Te 1/13
Port-channel 10
Te 1/14
4500X-1
Te 1/14
Port-channel 10
Te 1/15
4500X-1
Te 1/15
Port-channel 10
Te 1/16
4500X-1
Te 1/16
Port-channel 10
Te 1/17
4500X-1
Te 1/17
Port-channel 10
Te 1/18
4500X-1
Te 1/18
Port-channel 10
Te 1/19
4500X-1
Te 1/19
Port-channel 10
Te 1/20
4500X-1
Te 1/20
Port-channel 10
Te 1/21
4948E-1
Te 1/49
Te 1/22
4948E-2
Te 1/49
Te 1/23
4948E-1
Te 1/51
Te 1/24
4948E-2
Te 1/51
Te 1/25
PBR Router 1
To customer environment
Te 1/26
PBR Router 1
To customer environment
Te 1/27
PBR Router 2
To customer environment optional
Te 1/28
PBR Router 2
To customer environment optional
Te 1/29
PBR Router 3
To customer environment optional
Te 1/30
PBR Router 3
To customer environment optional
Te 1/31
PBR Router 4
To customer environment optional
Te 1/32
PBR Router 4
To customer environment optional
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
B-13
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-8S Redundant Cabling Scheme
Cisco Catalyst 4948E-1 Switch Cabling (VDS-TC-8S Redundant)
Note
All connections from the Cisco Catalyst 4948E switch use a 1000Base-T CAT 5 or CAT6 cable except
for the connections to the Cisco Catalyst 4500X switch. The connections from the Cisco Catalyst 4948E
switch to the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable. If a cable
longer than 3 meters is required, please refer to the specific product documentation to verify which
longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
4948E-1
GigabitEthernet1/1
CE-1
Eth1
GigabitEthernet1/2
CE-2
Eth1
GigabitEthernet1/3
CE-3
Eth1
GigabitEthernet1/4
CE-4
Eth1
GigabitEthernet1/5
CE-5
Eth1
GigabitEthernet1/6
CE-6
Eth1
GigabitEthernet1/7
CE-7
Eth1
GigabitEthernet1/8
CE-8
Eth1
GigabitEthernet1/18 MG-1
Eth1
GigabitEthernet1/19 Mgmt Uplink
To customer environment
GigabitEthernet1/20 IBM Storage 1
Controller1 Mgmt port 1
GigabitEthernet1/21 IBM Storage 2
Controller1 Mgmt port 1
GigabitEthernet1/22 IBM Storage 3
Controller1 Mgmt port 1
GigabitEthernet1/25 IBM Storage 1
Controller1 port 3
GigabitEthernet1/26 IBM Storage 1
Controller1 port 4
GigabitEthernet1/27 IBM Storage 1
Controller2 port 3
GigabitEthernet1/28 IBM Storage 1
Controller2 port 4
GigabitEthernet1/29 IBM Storage 2
Controller1 port 3
GigabitEthernet1/30 IBM Storage 2
Controller1 port 4
GigabitEthernet1/31 IBM Storage 2
Controller2 port 3
GigabitEthernet1/32 IBM Storage 2
Controller2 port 4
GigabitEthernet1/33 IBM Storage 3
Controller1 port 3
GigabitEthernet1/34 IBM Storage 3
Controller1 port 4
GigabitEthernet1/35 IBM Storage 3
Controller2 port 3
GigabitEthernet1/36 IBM Storage 3
Controller2 port 4
GigabitEthernet1/45 4948E-2
GigabitEthernet1/45
GigabitEthernet1/46 4948E-2
GigabitEthernet1/46
GigabitEthernet1/47 4948E-2
GigabitEthernet1/47
GigabitEthernet1/48 4948E-2
GigabitEthernet1/48
Notes
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
B-14
OL-31421-04
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-8S Redundant Cabling Scheme
Cisco Catalyst 4948E-1 Switch Cabling (VDS-TC-8S Redundant) (continued)
Note
All connections from the Cisco Catalyst 4948E switch use a 1000Base-T CAT 5 or CAT6 cable except
for the connections to the Cisco Catalyst 4500X switch. The connections from the Cisco Catalyst 4948E
switch to the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable. If a cable
longer than 3 meters is required, please refer to the specific product documentation to verify which
longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
4948E-1
Te 1/49
4500X-2
Te 1/21
Te 1/50
4500X-1
Te 1/21
Te 1/51
4500X-2
Te 1/23
Te 1/52
4500X-1
Te 1/23
Notes
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
B-15
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-8S Redundant Cabling Scheme
Cisco Catalyst 4948E-2 Switch Cabling (VDS-TC-8S Redundant)
Note
All connections from the Cisco Catalyst 4948E switch use a 1000Base-T CAT 5 or CAT6 cable except
for the connections to the Cisco Catalyst 4500X switch. The connections from the Cisco Catalyst 4948E
switch to the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable. If a cable
longer than 3 meters is required, please refer to the specific product documentation to verify which
longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
4948E-2
GigabitEthernet1/1
CE-1
Eth2
GigabitEthernet1/2
CE-2
Eth2
GigabitEthernet1/3
CE-3
Eth2
GigabitEthernet1/4
CE-4
Eth2
GigabitEthernet1/5
CE-5
Eth2
GigabitEthernet1/6
CE-6
Eth2
GigabitEthernet1/7
CE-7
Eth2
GigabitEthernet1/8
CE-8
Eth2
GigabitEthernet1/18 MG-1
Eth2
GigabitEthernet1/19 Mgmt Uplink
To customer
environment
GigabitEthernet1/20 IBM Storage 1
Controller2 Mgmt port 1
GigabitEthernet1/21 IBM Storage 2
Controller2 Mgmt port 1
GigabitEthernet1/22 IBM Storage 3
Controller2 Mgmt port 1
GigabitEthernet1/25 IBM Storage 1
Controller2 port 5
GigabitEthernet1/26 IBM Storage 1
Controller2 port 6
GigabitEthernet1/27 IBM Storage 1
Controller1 port 5
GigabitEthernet1/28 IBM Storage 1
Controller1 port 6
GigabitEthernet1/29 IBM Storage 2
Controller2 port 5
GigabitEthernet1/30 IBM Storage 2
Controller2 port 6
GigabitEthernet1/31 IBM Storage 2
Controller1 port 5
GigabitEthernet1/32 IBM Storage 2
Controller1 port 6
GigabitEthernet1/33 IBM Storage 3
Controller2 port 5
GigabitEthernet1/34 IBM Storage 3
Controller2 port 6
GigabitEthernet1/35 IBM Storage 3
Controller1 port 5
GigabitEthernet1/36 IBM Storage 3
Controller1 port 6
GigabitEthernet1/45 4948E-1
GigabitEthernet1/45
GigabitEthernet1/46 4948E-1
GigabitEthernet1/46
GigabitEthernet1/47 4948E-1
GigabitEthernet1/47
GigabitEthernet1/48 4948E-1
GigabitEthernet1/48
Notes
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
B-16
OL-31421-04
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-8S Redundant Cabling Scheme
Cisco Catalyst 4948E-2 Switch Cabling (VDS-TC-8S Redundant)
Note
All connections from the Cisco Catalyst 4948E switch use a 1000Base-T CAT 5 or CAT6 cable except
for the connections to the Cisco Catalyst 4500X switch. The connections from the Cisco Catalyst 4948E
switch to the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable. If a cable
longer than 3 meters is required, please refer to the specific product documentation to verify which
longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
4948E-2
Te 1/49
4500X-2
Te 1/22
Te 1/50
4500X-1
Te 1/22
Te 1/51
4500X-2
Te 1/24
Te 1/52
4500X-1
Te 1/24
Notes
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
B-17
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-16S Non-Redundant Cabling Scheme
VDS-TC-16S Non-Redundant Cabling Scheme
This section provides the cabling scheme for the VDS-TC-16S non-redundant solution.
Cisco Catalyst 4500X Switch Cabling (VDS-TC-16S Non-Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X
Te 1/1
CE-1
Te 0
Te 1/2
CE-2
Te 0
Te 1/3
CE-3
Te 0
Te 1/4
CE-4
Te 0
Te 1/5
CE-5
Te 0
Te 1/6
CE-6
Te 0
Te 1/7
CE-7
Te 0
Te 1/8
CE-8
Te 0
Te 1/9
CE-9
Te 0
Te 1/10
CE-10
Te 0
Te 1/11
CE-11
Te 0
Te 1/12
CE-12
Te 0
Te 1/13
CE-13
Te 0
Te 1/14
CE-14
Te 0
Te 1/15
CE-15
Te 0
Te 1/16
CE-16
Te 0
Te 1/21
4948E
Te 1/49
Te 1/22
4948E
Te 1/50
Te 1/23
4948E
Te 1/51
Te 1/24
4948E
Te 1/52
Te 1/25
PBR Router 1
To customer environment
Te 1/26
PBR Router 1
To customer environment
Te 1/27
PBR Router 2
To customer environment optional
Te 1/28
PBR Router 2
To customer environment optional
Te 1/29
PBR Router 3
To customer environment optional
Te 1/30
PBR Router 3
To customer environment optional
Te 1/31
PBR Router 4
To customer environment optional
Te 1/32
PBR Router 4
To customer environment optional
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
B-18
OL-31421-04
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-16S Non-Redundant Cabling Scheme
Cisco Catalyst 4948E-1 Switch Cabling (VDS-TC-16S Non-Redundant)
Note
All connections from the Cisco Catalyst 4948E switch use a 1000Base-T CAT 5 or CAT6 cable except
for the connections to the Cisco Catalyst 4500X switch. The connections from the Cisco Catalyst 4948E
switch to the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable. If a cable
longer than 3 meters is required, please refer to the specific product documentation to verify which
longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
4948E-1
GigabitEthernet1/1
CE-1
Eth1
GigabitEthernet1/2
CE-2
Eth1
GigabitEthernet1/3
CE-3
Eth1
GigabitEthernet1/4
CE-4
Eth1
GigabitEthernet1/5
CE-5
Eth1
GigabitEthernet1/6
CE-6
Eth1
GigabitEthernet1/7
CE-7
Eth1
GigabitEthernet1/8
CE-8
Eth1
GigabitEthernet1/9
CE-9
Eth1
GigabitEthernet1/10 CE-10
Eth1
GigabitEthernet1/11 CE-11
Eth1
GigabitEthernet1/12 CE-12
Eth1
GigabitEthernet1/13 CE-13
Eth1
GigabitEthernet1/14 CE-14
Eth1
GigabitEthernet1/15 CE-15
Eth1
GigabitEthernet1/16 CE-16
Eth1
GigabitEthernet1/18 MG-1
Eth1
GigabitEthernet1/19 Mgmt Uplink
To customer
environment
GigabitEthernet1/20 IBM Storage 1
Controller1 Mgmt port 1
GigabitEthernet1/21 IBM Storage 2
Controller1 Mgmt port 1
GigabitEthernet1/22 IBM Storage 3
Controller1 Mgmt port 1
GigabitEthernet1/23 IBM Storage 4
Controller1 Mgmt port 1
GigabitEthernet1/24 IBM Storage 5
Controller1 Mgmt port 1
GigabitEthernet1/25 IBM Storage 1
Controller1 port 3
GigabitEthernet1/26 IBM Storage 1
Controller1 port 4
GigabitEthernet1/27 IBM Storage 1
Controller2 port 3
GigabitEthernet1/28 IBM Storage 1
Controller2 port 4
GigabitEthernet1/29 IBM Storage 2
Controller1 port 3
GigabitEthernet1/30 IBM Storage 2
Controller1 port 4
Notes
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
B-19
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-16S Non-Redundant Cabling Scheme
Cisco Catalyst 4948E-1 Switch Cabling (VDS-TC-16S Non-Redundant) (continued)
Note
All connections from the Cisco Catalyst 4948E switch use a 1000Base-T CAT 5 or CAT6 cable except
for the connections to the Cisco Catalyst 4500X switch. The connections from the Cisco Catalyst 4948E
switch to the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable. If a cable
longer than 3 meters is required, please refer to the specific product documentation to verify which
longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
4948E-1
GigabitEthernet1/31 IBM Storage 2
Controller2 port 3
GigabitEthernet1/32 IBM Storage 2
Controller2 port 4
GigabitEthernet1/33 IBM Storage 3
Controller1 port 3
GigabitEthernet1/34 IBM Storage 3
Controller1 port 4
GigabitEthernet1/35 IBM Storage 3
Controller2 port 3
GigabitEthernet1/36 IBM Storage 3
Controller2 port 4
GigabitEthernet1/37 IBM Storage 4
Controller1 port 3
GigabitEthernet1/38 IBM Storage 4
Controller1 port 4
GigabitEthernet1/39 IBM Storage 4
Controller2 port 3
GigabitEthernet1/40 IBM Storage 4
Controller2 port 4
GigabitEthernet1/41 IBM Storage 5
Controller1 port 3
GigabitEthernet1/42 IBM Storage 5
Controller1 port 4
GigabitEthernet1/43 IBM Storage 5
Controller2 port 3
GigabitEthernet1/44 IBM Storage 5
Controller2 port 4
GigabitEthernet1/45 4948E-2
GigabitEthernet1/45
GigabitEthernet1/46 4948E-2
GigabitEthernet1/46
GigabitEthernet1/47 4948E-2
GigabitEthernet1/47
GigabitEthernet1/48 4948E-2
GigabitEthernet1/48
Te 1/50
4500X-1
Te 1/21
Te 1/52
4500X-1
Te 1/23
Notes
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
B-20
OL-31421-04
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-16S Non-Redundant Cabling Scheme
Cisco Catalyst 4948E-2 Switch Cabling (VDS-TC-16S Non-Redundant)
Note
All connections from the Cisco Catalyst 4948E switch use a 1000Base-T CAT 5 or CAT6 cable except
for the connections to the Cisco Catalyst 4500X switch. The connections from the Cisco Catalyst 4948E
switch to the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable. If a cable
longer than 3 meters is required, please refer to the specific product documentation to verify which
longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
4948E-2
GigabitEthernet1/1
CE-1
Eth2
GigabitEthernet1/2
CE-2
Eth2
GigabitEthernet1/3
CE-3
Eth2
GigabitEthernet1/4
CE-4
Eth2
GigabitEthernet1/5
CE-5
Eth2
GigabitEthernet1/6
CE-6
Eth2
GigabitEthernet1/7
CE-7
Eth2
GigabitEthernet1/8
CE-8
Eth2
GigabitEthernet1/9
CE-9
Eth2
GigabitEthernet1/10 CE-10
Eth2
GigabitEthernet1/11 CE-11
Eth2
GigabitEthernet1/12 CE-12
Eth2
GigabitEthernet1/13 CE-13
Eth2
GigabitEthernet1/14 CE-14
Eth2
GigabitEthernet1/15 CE-15
Eth2
GigabitEthernet1/16 CE-16
Eth2
GigabitEthernet1/18 MG-1
Eth2
GigabitEthernet1/19 Mgmt Uplink
To customer
environment
GigabitEthernet1/20 IBM Storage 1
Controller2 Mgmt port 1
GigabitEthernet1/21 IBM Storage 2
Controller2 Mgmt port 1
GigabitEthernet1/22 IBM Storage 3
Controller2 Mgmt port 1
GigabitEthernet1/23 IBM Storage 4
Controller2 Mgmt port 1
GigabitEthernet1/24 IBM Storage 5
Controller2 Mgmt port 1
GigabitEthernet1/25 IBM Storage 1
Controller2 port 5
GigabitEthernet1/26 IBM Storage 1
Controller2 port 6
GigabitEthernet1/27 IBM Storage 1
Controller1 port 5
GigabitEthernet1/28 IBM Storage 1
Controller1 port 6
GigabitEthernet1/29 IBM Storage 2
Controller2 port 5
GigabitEthernet1/30 IBM Storage 2
Controller2 port 6
Notes
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
B-21
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-16S Non-Redundant Cabling Scheme
Cisco Catalyst 4948E-2 Switch Cabling (VDS-TC-16S Non-Redundant) (continued)
Note
All connections from the Cisco Catalyst 4948E switch use a 1000Base-T CAT 5 or CAT6 cable except
for the connections to the Cisco Catalyst 4500X switch. The connections from the Cisco Catalyst 4948E
switch to the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable. If a cable
longer than 3 meters is required, please refer to the specific product documentation to verify which
longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
4948E-2
GigabitEthernet1/31 IBM Storage 2
Controller1 port 5
GigabitEthernet1/32 IBM Storage 2
Controller1 port 6
GigabitEthernet1/33 IBM Storage 3
Controller2 port 5
GigabitEthernet1/34 IBM Storage 3
Controller2 port 6
GigabitEthernet1/35 IBM Storage 3
Controller1 port 5
GigabitEthernet1/36 IBM Storage 3
Controller1 port 6
GigabitEthernet1/37 IBM Storage 4
Controller2 port 5
GigabitEthernet1/38 IBM Storage 4
Controller2 port 6
GigabitEthernet1/39 IBM Storage 4
Controller1 port 5
GigabitEthernet1/40 IBM Storage 4
Controller1 port 6
GigabitEthernet1/41 IBM Storage 5
Controller2 port 5
GigabitEthernet1/42 IBM Storage 5
Controller2 port 6
GigabitEthernet1/43 IBM Storage 5
Controller1 port 5
GigabitEthernet1/44 IBM Storage 5
Controller1 port 6
GigabitEthernet1/45 4948E-1
GigabitEthernet1/45
GigabitEthernet1/46 4948E-1
GigabitEthernet1/46
GigabitEthernet1/47 4948E-1
GigabitEthernet1/47
GigabitEthernet1/48 4948E-1
GigabitEthernet1/48
Te 1/50
4500X-1
Te 1/22
Te 1/52
4500X-1
Te 1/24
Notes
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
B-22
OL-31421-04
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-16S Redundant Cabling Scheme
VDS-TC-16S Redundant Cabling Scheme
This section provides the cabling scheme for the VDS-TC-16S redundant solution.
Cisco Catalyst 4500X-1 Switch Cabling (VDS-TC-16S Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X-1
Te 1/1
CE-1
Te 0
Te 1/2
CE-2
Te 0
Te 1/3
CE-3
Te 0
Te 1/4
CE-4
Te 0
Te 1/5
CE-5
Te 0
Te 1/6
CE-6
Te 0
Te 1/7
CE-7
Te 0
Te 1/8
CE-8
Te 0
Te 1/9
CE-9
Te 0
Te 1/10
CE-10
Te 0
Te 1/11
CE-11
Te 0
Te 1/12
CE-12
Te 0
Te 1/13
CE-13
Te 0
Te 1/14
CE-14
Te 0
Te 1/15
CE-15
Te 0
Te 1/16
CE-16
Te 0
Te 1/21
4948E-1
Te 1/50
Te 1/22
4948E-2
Te 1/50
Te 1/23
4948E-1
Te 1/52
Te 1/24
4948E-2
Te 1/52
Te 1/25
PBR Router 1
To customer environment
Te 1/26
PBR Router 1
To customer environment
Te 1/27
PBR Router 2
To customer environment
optional
Te 1/28
PBR Router 2
To customer environment
optional
Te 1/29
PBR Router 3
To customer environment
optional
Te 1/30
PBR Router 3
To customer environment
optional
Te 1/31
PBR Router 4
To customer environment
optional
Te 1/32
PBR Router 4
To customer environment
optional
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
B-23
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-16S Redundant Cabling Scheme
Cisco Catalyst 4500X-1 Switch Cabling (VDS-TC-16S Redundant) (continued)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X-1
Te 2/1
4500X-2
Te 2/1
port-channel 5
Te 2/2
4500X-2
Te 2/2
port-channel 5
Te 2/3
4500X-2
Te 2/3
port-channel 5
Te 2/4
4500X-2
Te 2/4
port-channel 5
Te 2/5
4500X-2
Te 2/5
port-channel 5
Te 2/6
4500X-2
Te 2/6
port-channel 5
Te 2/7
4500X-2
Te 2/7
port-channel 5
Te 2/8
4500X-2
Te 2/8
port-channel 5
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
B-24
OL-31421-04
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-16S Redundant Cabling Scheme
Cisco Catalyst 4500X-2 Switch Cabling (VDS-TC-16S Redundant)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X-2
Te 1/1
CE-1
Te 1
Te 1/2
CE-2
Te 1
Te 1/3
CE-3
Te 1
Te 1/4
CE-4
Te 1
Te 1/5
CE-5
Te 1
Te 1/6
CE-6
Te 1
Te 1/7
CE-7
Te 1
Te 1/8
CE-8
Te 1
Te 1/9
CE-9
Te 1
Te 1/10
CE-10
Te 1
Te 1/11
CE-11
Te 1
Te 1/12
CE-12
Te 1
Te 1/13
CE-13
Te 1
Te 1/14
CE-14
Te 1
Te 1/15
CE-15
Te 1
Te 1/16
CE-16
Te 1
Te 1/21
4948E-1
Te 1/49
Te 1/22
4948E-2
Te 1/49
Te 1/23
4948E-1
Te 1/51
Te 1/24
4948E-2
Te 1/51
Te 1/25
PBR Router 1
To customer environment
Te 1/26
PBR Router 1
To customer environment
Te 1/27
PBR Router 2
To customer environment
optional
Te 1/28
PBR Router 2
To customer environment
optional
Te 1/29
PBR Router 3
To customer environment
optional
Te 1/30
PBR Router 3
To customer environment
optional
Te 1/31
PBR Router 4
To customer environment
optional
Te 1/32
PBR Router 4
To customer environment
optional
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
B-25
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-16S Redundant Cabling Scheme
Cisco Catalyst 4500X-2 Switch Cabling (VDS-TC-16S Redundant) (continued)
Note
All connections from the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable.
If a cable longer than 3 meters is required, please refer to the specific product documentation to verify
which longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
Notes
4500X-2
Te 2/1
4500X-1
Te 2/1
port-channel 10
Te 2/2
4500X-1
Te 2/2
port-channel 10
Te 2/3
4500X-1
Te 2/3
port-channel 10
Te 2/4
4500X-1
Te 2/4
port-channel 10
Te 2/5
4500X-1
Te 2/5
port-channel 10
Te 2/6
4500X-1
Te 2/6
port-channel 10
Te 2/7
4500X-1
Te 2/7
port-channel 10
Te 2/8
4500X-1
Te 2/8
port-channel 10
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
B-26
OL-31421-04
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-16S Redundant Cabling Scheme
Cisco Catalyst 4948E-1 Switch Cabling (VDS-TC-16S Redundant)
Note
All connections from the Cisco Catalyst 4948E switch use a 1000Base-T CAT 5 or CAT6 cable except
for the connections to the Cisco Catalyst 4500X switch. The connections from the Cisco Catalyst 4948E
switch to the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable. If a cable
longer than 3 meters is required, please refer to the specific product documentation to verify which
longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
4948E-1
GigabitEthernet1/1
CE-1
Eth1
GigabitEthernet1/2
CE-2
Eth1
GigabitEthernet1/3
CE-3
Eth1
GigabitEthernet1/4
CE-4
Eth1
GigabitEthernet1/5
CE-5
Eth1
GigabitEthernet1/6
CE-6
Eth1
GigabitEthernet1/7
CE-7
Eth1
GigabitEthernet1/8
CE-8
Eth1
GigabitEthernet1/9
CE-9
Eth1
GigabitEthernet1/10 CE-10
Eth1
GigabitEthernet1/11 CE-11
Eth1
GigabitEthernet1/12 CE-12
Eth1
GigabitEthernet1/13 CE-13
Eth1
GigabitEthernet1/14 CE-14
Eth1
GigabitEthernet1/15 CE-15
Eth1
GigabitEthernet1/16 CE-16
Eth1
GigabitEthernet1/18 MG-1
Eth1
GigabitEthernet1/19 Mgmt Uplink
To customer
environment
GigabitEthernet1/20 IBM Storage 1
Controller1 Mgmt port 1
GigabitEthernet1/21 IBM Storage 2
Controller1 Mgmt port 1
GigabitEthernet1/22 IBM Storage 3
Controller1 Mgmt port 1
GigabitEthernet1/23 IBM Storage 4
Controller1 Mgmt port 1
GigabitEthernet1/24 IBM Storage 5
Controller1 Mgmt port 1
GigabitEthernet1/25 IBM Storage 1
Controller1 port 3
GigabitEthernet1/26 IBM Storage 1
Controller1 port 4
GigabitEthernet1/27 IBM Storage 1
Controller2 port 3
GigabitEthernet1/28 IBM Storage 1
Controller2 port 4
GigabitEthernet1/29 IBM Storage 2
Controller1 port 3
GigabitEthernet1/30 IBM Storage 2
Controller1 port 4
Notes
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
B-27
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-16S Redundant Cabling Scheme
Cisco Catalyst 4948E-1 Switch Cabling (VDS-TC-16S Redundant) (continued)
Note
All connections from the Cisco Catalyst 4948E switch use a 1000Base-T CAT 5 or CAT6 cable except
for the connections to the Cisco Catalyst 4500X switch. The connections from the Cisco Catalyst 4948E
switch to the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable. If a cable
longer than 3 meters is required, please refer to the specific product documentation to verify which
longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
4948E-1
GigabitEthernet1/31 IBM Storage 2
Controller2 port 3
GigabitEthernet1/32 IBM Storage 2
Controller2 port 4
GigabitEthernet1/33 IBM Storage 3
Controller1 port 3
GigabitEthernet1/34 IBM Storage 3
Controller1 port 4
GigabitEthernet1/35 IBM Storage 3
Controller2 port 3
GigabitEthernet1/36 IBM Storage 3
Controller2 port 4
GigabitEthernet1/37 IBM Storage 4
Controller1 port 3
GigabitEthernet1/38 IBM Storage 4
Controller1 port 4
GigabitEthernet1/39 IBM Storage 4
Controller2 port 3
GigabitEthernet1/40 IBM Storage 4
Controller2 port 4
GigabitEthernet1/41 IBM Storage 5
Controller1 port 3
GigabitEthernet1/42 IBM Storage 5
Controller1 port 4
GigabitEthernet1/43 IBM Storage 5
Controller2 port 3
GigabitEthernet1/44 IBM Storage 5
Controller2 port 4
GigabitEthernet1/45 4948E-2
GigabitEthernet1/45
GigabitEthernet1/46 4948E-2
GigabitEthernet1/46
GigabitEthernet1/47 4948E-2
GigabitEthernet1/47
GigabitEthernet1/48 4948E-2
GigabitEthernet1/48
Te 1/49
4500X-2
Te 1/21
Te 1/50
4500X-1
Te 1/21
Te 1/51
4500X-2
Te 1/23
Te 1/52
4500X-1
Te 1/23
Notes
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
B-28
OL-31421-04
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-16S Redundant Cabling Scheme
Cisco Catalyst 4948E-2 Switch Cabling (VDS-TC-16S Redundant)
Note
All connections from the Cisco Catalyst 4948E switch use a 1000Base-T CAT 5 or CAT6 cable except
for the connections to the Cisco Catalyst 4500X switch. The connections from the Cisco Catalyst 4948E
switch to the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable. If a cable
longer than 3 meters is required, please refer to the specific product documentation to verify which
longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
4948E-2
GigabitEthernet1/1
CE-1
Eth2
GigabitEthernet1/2
CE-2
Eth2
GigabitEthernet1/3
CE-3
Eth2
GigabitEthernet1/4
CE-4
Eth2
GigabitEthernet1/5
CE-5
Eth2
GigabitEthernet1/6
CE-6
Eth2
GigabitEthernet1/7
CE-7
Eth2
GigabitEthernet1/8
CE-8
Eth2
GigabitEthernet1/9
CE-9
Eth2
GigabitEthernet1/10 CE-10
Eth2
GigabitEthernet1/11 CE-11
Eth2
GigabitEthernet1/12 CE-12
Eth2
GigabitEthernet1/13 CE-13
Eth2
GigabitEthernet1/14 CE-14
Eth2
GigabitEthernet1/15 CE-15
Eth2
GigabitEthernet1/16 CE-16
Eth2
GigabitEthernet1/18 MG-1
Eth2
GigabitEthernet1/19 Mgmt Uplink
To customer
environment
GigabitEthernet1/20 IBM Storage 1
Controller2 Mgmt port 1
GigabitEthernet1/21 IBM Storage 2
Controller2 Mgmt port 1
GigabitEthernet1/22 IBM Storage 3
Controller2 Mgmt port 1
GigabitEthernet1/23 IBM Storage 4
Controller2 Mgmt port 1
GigabitEthernet1/24 IBM Storage 5
Controller2 Mgmt port 1
GigabitEthernet1/25 IBM Storage 1
Controller2 port 5
GigabitEthernet1/26 IBM Storage 1
Controller2 port 6
GigabitEthernet1/27 IBM Storage 1
Controller1 port 5
GigabitEthernet1/28 IBM Storage 1
Controller1 port 6
GigabitEthernet1/29 IBM Storage 2
Controller2 port 5
GigabitEthernet1/30 IBM Storage 2
Controller2 port 6
Notes
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
OL-31421-04
B-29
Appendix B
Cisco VDS TC C-Series Cabling Guides when Using IBM DS3524 Storage Enclosures
VDS-TC-16S Redundant Cabling Scheme
Cisco Catalyst 4948E-2 Switch Cabling (VDS-TC-16S Redundant) (continued)
Note
All connections from the Cisco Catalyst 4948E switch use a 1000Base-T CAT 5 or CAT6 cable except
for the connections to the Cisco Catalyst 4500X switch. The connections from the Cisco Catalyst 4948E
switch to the Cisco Catalyst 4500X switch use a 10GBASE-CU SFP+ 3 meter twinax cable. If a cable
longer than 3 meters is required, please refer to the specific product documentation to verify which
longer cables are supported.
Local Device
Local Port
Remote Device
Remote Port
4948E-2
GigabitEthernet1/31 IBM Storage 2
Controller1 port 5
GigabitEthernet1/32 IBM Storage 2
Controller1 port 6
GigabitEthernet1/33 IBM Storage 3
Controller2 port 5
GigabitEthernet1/34 IBM Storage 3
Controller2 port 6
GigabitEthernet1/35 IBM Storage 3
Controller1 port 5
GigabitEthernet1/36 IBM Storage 3
Controller1 port 6
GigabitEthernet1/37 IBM Storage 4
Controller2 port 5
GigabitEthernet1/38 IBM Storage 4
Controller2 port 6
GigabitEthernet1/39 IBM Storage 4
Controller1 port 5
GigabitEthernet1/40 IBM Storage 4
Controller1 port 6
GigabitEthernet1/41 IBM Storage 5
Controller2 port 5
GigabitEthernet1/42 IBM Storage 5
Controller2 port 6
GigabitEthernet1/43 IBM Storage 5
Controller1 port 5
GigabitEthernet1/44 IBM Storage 5
Controller1 port 6
GigabitEthernet1/45 4948E-1
GigabitEthernet1/45
GigabitEthernet1/46 4948E-1
GigabitEthernet1/46
GigabitEthernet1/47 4948E-1
GigabitEthernet1/47
GigabitEthernet1/48 4948E-1
GigabitEthernet1/48
Te 1/49
4500X-2
Te 1/22
Te 1/50
4500X-1
Te 1/22
Te 1/51
4500X-2
Te 1/24
Te 1/52
4500X-1
Te 1/24
Notes
Cisco Videoscape Distribution Suite Transparent Caching Software C-Series Cluster Installation Guide
B-30
OL-31421-04

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
