Preface
Revised: February 2016
Cisco Videoscape Distribution Suite (VDS) Transparent Caching (TC) Analytics provides visibility into
network performance, subscriber trends, and cache content. This business intelligence engine leverages
industry leading technology for the monitoring, reporting, and analysis of key performance indicators
(KPIs) with unique insight from the Cisco VDS TC cache engines.
The core of the Cisco VDS TC Analytics solution consists of KPIs and a Cache Detail Record (CDR)
database, which the VDS TC Analytics server uses to collect and store information from the Cisco VDS
TC cache engines. Cisco VDS TC systems on the network are connected to the foundation over the ISP
management network. Details from these cache engines are aggregated and analyzed to enable a
network-wide view of traffic, as it is delivered from the perspective of the VDS TC cache engines.
Administrators access this information through a central Cisco VDS TC Analytics server by viewing
dashboards and pre-defined reports, and can perform on-demand analysis of the network.
Analysis is delivered for all levels of the organization in a variety of displays. Different report packages
are available for various levels of the organization:
•
Network engineers obtain the details required for managing and expanding their networks.
•
The finance department can gain visibility into savings and growth planning.
•
Executives can draw summaries based on media trends and subscriber patterns
•
The marketing team can acquire insight necessary to develop new products and services.
Information is presented as webpage dashboards, which provide quick access to information, or in PDF
and HTML formats.
This preface contains the following sections:
•
Overview
•
Cisco VDS TC Analytics Navigational Overview
•
Terminology
•
Obtaining Documentation and Submitting a Service Request
Overview
Cisco VDS TC Analytics provides a high quality and rich variety of marketing and network engineering
performance reports. These dashboard reports provide the most important and valuable performance
KPIs that give a clear view of the business status. By just clicking the main window, the user has access
to the Dashboard Reports Navigation.
Cisco Videoscape Distribution Suite Transparent Caching Analytics User Guide
vii
Preface
Cisco VDS TC Analytics Navigational Overview
The VDS TC Analytics data collection engine and data intelligence system produces custom reports
about the media that flows through the entire pipeline. These reports are designed to provide analytical
answers to key business questions, such as content type distribution, the percentage of users driving
bandwidth growth, new and potential services, P2P class of service, the popularity of users by protocols
or services, individual system output, cache consumption, the IP addresses of the highest volume users,
services that are consumed by the highest volume users, weight items and number of requests, overall
load balance, and so on.
VDS TC Analytics translates the data that is generated by VDS TC cache engines and displays it in
charts and data tables designated according to specific Cisco Analytics user groups, such as network
engineers and operators, marketing personnel, and executives.
For each organizational user group, VDS TC Analytics presents pertinent information in predefined sets
of displays. The At a Glance dashboard is the summary page that opens for each of the organization user
groups, delivering an immediate overview at patterns and trends. At a Glance reports present the daily
summaries for the time frame you select, according to daily average values, breaking down the
information by services and protocols. Plotted comparisons of information visually convey the behavior
of traffic, as it is served from the VDS TC cache engine (cache traffic) and from the world (clear traffic).
You can easily list all charted data in numerical values to enhance your insight.
From this personalized dashboard look, you can drill down for more detailed analysis available through
the Data Mining dashboard. The Data Mining reports offer advanced filtering capabilities, according to
five minute polling, for the comparison of KPIs across services and protocols over any time frame.
Aggregate views for the entire network can be compared by IP address, zone, POP, or individual VDS
TC systems.
You can save or print every chart and data table in PDF or HTML format.
Cisco VDS TC Analytics Navigational Overview
Cisco VDS TC Analytics has an easy to use GUI to help you navigate to the various dashboards and
reports, which are accessed through the main menu of the VDS TC Analytics user interface (UI).
Clicking each choice allows the user to adjust what they view and how they view it.
Figure 1
Cisco VDS TC Analytics Main Toolbar
Cisco Videoscape Distribution Suite Transparent Caching Analytics User Guide
viii
Preface
Cisco VDS TC Analytics Navigational Overview
Table 1
GUI Items
Item
Description
Dashboard Type
The Analytics Dashboard provides different
analytical views. This area of the VDS TC
Analytics window designates which Dashboard
you are viewing.
Performance Tabs
These tabs display different measures of the KPI
throughput. The tabs available will vary
depending on which Dashboard you selected.
Search Option
The Search option allows the user to look for a
specific value. Enter the Name you want, click
Search and from the list that appears, add your
selection to the Selected list. Click OK to exit,
and then click Apply in Filter by.
Dashboards
From the Dashboards drop-down menu you can
choose which dashboard you want to view. Which
dashboards you will see depend on your
permissions and your license. The following
dashboards are available:
•
Administration: Provides a detailed look at
files and CDRs.
•
Marketing: Provides a brief view of specific
KPIs.
•
Network Engineering: Provides a detailed
drill-down view of specific KPIs.
•
Policy Reports: Provides a detailed view of
administrative behavior.
•
Summary Reports: Provides a general
summarized analyzed view.
•
Technology: Provides a detailed view of the
application, device controller, and operation
system that is being used to access the
Internet.
•
Virtual Network Delivery: Opens an
assortment of comprehensive reports that
analyze the content, domains, hashes and
revenue sharing.
Help
Opens the online help.
Signed In As
Displays the name of the user that is currently
logged in to VDS TC Analytics.
Sign Out
Click this link to log out of the VDS TC
Analytics.
Cisco Videoscape Distribution Suite Transparent Caching Analytics User Guide
ix
Preface
Terminology
Terminology
The VDS TC Analytics Terminology table describes terms and concepts that apply to the VDS TC
Analytics Software.
Table 2
VDS TC Analytics Terminology
Term
Description
AVG
Average
Bytes Hit Ratio (BHR)
The number of bytes of cached out traffic divided by the total number of
bytes of traffic, whether it was cached or not. For example, a 60% bytes hit
ratio means that 60% of the overall bandwidth came from the cache and
40% came from the world.
cache in
A connection where the object requested by a subscriber does not exist in
the cache (which creates a “miss”), and the requested incoming data from
the world is stored in the cache.
cache
Traffic served only from VDS TC.
cache out
A connection where the object requested by a subscriber exists in the cache
(which creates a “hit”), and the request is served from the cache as outgoing
traffic to the subscriber.
cache productivity
The total cached out traffic divided by the total cached in traffic.
cache quality of
experience (QoE)
The average delivery speed of traffic that is served from VDS TC per active
subscriber. QoE is analyzed by comparing cache QoE with clear QoE.
CDR
Cache/Content Data Record
clear
The status of a subscriber request when the requested file segment does not
exist in the cache. Subsequently, this object is either cached in or forwarded.
It is considered as traffic that is delivered directly from the Internet.
clear QoE
The average delivery speed of traffic served directly from the Internet (VDS
TC clear) per active subscriber. QoE is analyzed by comparing clear QoE
with cache QoE.
CLI
command-line interface
CMDB miss
The status of a subscriber request when the requested file segment does not
exist in the cache due to an unexpected deletion or corruption.
data
A connection where P2P or HTTP file segments are transferred.
downstream
Objects transmitted from the world to the subscriber. Also called W2I.
forward
The process of forwarding an object directly to its requesting subscriber
without caching it. This is applied to an object that does not yet exist in the
cache. At this stage, it is only listed in the cache, according to the predefined
license rules of the platform (see verify), and will only be cached upon
future request.
hit
The status of an ISP subscriber request when the requested file segment
exists in cache. Subsequently, this object is cached out.
hit miss ratio
The number of hits divided by the number of misses.
I2W
Upstream data flowing from the ISP to the world.
Cisco Videoscape Distribution Suite Transparent Caching Analytics User Guide
x
Preface
Terminology
Table 2
VDS TC Analytics Terminology (continued)
Term
Description
incoming
Traffic served only from the Internet.
Downstream and upstream objects transmitted from the redirector into the
cache server. Each incoming object is either cached in, cached out,
forwarded, or blocked. Also referred to as in traffic.
in traffic
See incoming.
IPMI
Intelligent Platform Management Interface
KPI
Key Performance Indicator
miss
A subscriber request that does not exist in the VDS TC cache.
monitored platforms
A Cisco system from which VDS TC Analytics collects polling data
NAS
Network Array Storage
non-data
A connection through which P2P clients communicate with each other but
do not transfer P2P file segments. For example, P2P clients may
communicate the details of the file segments and the uploader queue
number, but do not transfer the file segments.
outgoing
Downstream and upstream objects transmitted out from the redirector. Each
outgoing object was either cached in, cached out, or forwarded. Also
referred to as out traffic.
out traffic
See Outgoing.
P2PP
Peer-to-Peer Protocol
P2P
Peer to Peer
PBR
Policy Based Routing
POP
point of presence
QoE
Quality of Experience. Measured by comparing the speed of traffic served
from VDS TC (cache QoE) and the speed of traffic served from the Internet
(clear QoE).
request hit ratio
The first time a new session arrives in the cache, it is labeled as cache out,
cache in, or forward. The request hit ratio represents the number of cache
out sessions divided by the number non-cache out sessions. That is, the
request hit ratio measures the percentage of requests delivered from cache
versus the world.
SNMP
Simple Network Management Protocol
TIC
Transparent Internet Caching
total traffic
All of the traffic served from both the Internet (incoming traffic) and from
VDS TC (cache out traffic), i.e. incoming traffic + cache out traffic.
upstream
Objects transmitted from the subscriber to the world. Also called I2W.
verify
A predefined set of license dependent rules that determine the caching
parameters of an object.
world
The World Wide Web (WWW), also referred to as Internet or network.
W2I
Upstream traffic flowing to the ISP from the world.
Cisco Videoscape Distribution Suite Transparent Caching Analytics User Guide
xi
Preface
Obtaining Documentation and Submitting a Service Request
Table 3
Termination Reason Glossary
Acronym/Term
Description
Session Ended
Session ended after entire file was delivered to the
downloader
CMDBMISS
Request range (in P2P) or file (HTTP) is not in the
cache
DOWNLOADER
Downloader closed the session
TIMEOUT
Session timed out
ERROR
An error occurred serving the session
RST
One of the sides reset the connection
FIN
Connection terminated normally
UPLOADER
Uploader closed the session
UNKNOWN
None of the above reasons
Obtaining Documentation and Submitting a Service Request
For information on obtaining documentation, submitting a service request, and gathering additional
information, see the monthly What’s New in Cisco Product Documentation, which also lists all new and
revised Cisco technical documentation, at:
http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html
Subscribe to the What’s New in Cisco Product Documentation as an RSS feed and set content to be
delivered directly to your desktop using a reader application. The RSS feeds are a free service. Cisco currently
supports RSS Version 2.0.
Cisco Videoscape Distribution Suite Transparent Caching Analytics User Guide
xii
CH A P T E R
1
Getting Started
Data Retrieval and Polling Preferences
Cisco VDS TC Analytics retrieves information from SNMP and CDRs that are generated and controlled
by your Cisco Analytics management servers. Upon installation, your Analytics Administrator uses the
Configuration tab to define the architecture and collector parameters. After installation, if you have
permissions, you can use the Configuration tab in the VDS TC Analytics user interface to change the
parameters. You can also change your login password from the Configuration tab.
Note
Defining data retrieval and polling preferences is a task intended for the VDS TC Analytics
Administrator that has permissions to perform the required ongoing administrative procedures.
Changing User Password
To change your VDS TC Analytics password, use this procedure:
Note
You must be assigned the Network Engineering Viewers package to be able to change your password. If
you are not assigned the Network Engineering Viewers package, contact an administrator to change your
password.
Procedure
Step 1
Enter https://Analtyics_ServerIP into your web browser, where Analtyics_ServerIP is the IP address of
the VDS TC Analytics server and log in.
Step 2
From the menu bar on the right, choose Dashboards > Network Engineering > Data Mining.
Step 3
Click the Configuration tab and log in when prompted.
Step 4
Click the Change Password link located on the right of the VDS Transparent Caching Analytics Site
Administration title bar. The Password Change dialog box appears.
Step 5
Enter your current password in the Old Password text box, and enter the new password in the New
Password and Password (again) text boxes.
Step 6
Click Change My Password. The Password Change Successful message appears when the password has
been changed.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
1-1
Chapter 1
Getting Started
Data Retrieval and Polling Preferences
Starting or Stopping SNMP and CDR Data Collection
To stop or start collecting SNMP and CDR data, use this procedure:
Note
You must be assigned the Network Engineering Viewers package to perform this procedure.
Procedure
Step 1
From the VDS TC Analytics web page, From the menu bar on the right, choose Dashboards > Network
Engineering > Data Mining.
Step 2
Click the Configuration tab and log in when prompted. The Select System to Change window appears.
Step 3
From the Action drop-down list, choose either Start SNMP and CDR Data Collection or Stop SNMP
and CDR Data Collection depending on which action you want to perform.
Step 4
Check the check box in front of the system for which you want to stop or start the services. To choose
all systems, check the check box next to Name in the header row.
Step 5
Click Go.
Changing SNMP and CDR Polling Preferences
To change either the SNMP or CDR preferences, use this procedure:
Note
You must be assigned the Network Engineering Viewers package to perform this procedure.
Procedure
Step 1
From the VDS TC Analytics web page, From the menu bar on the right, choose Dashboards > Network
Engineering > Data Mining.
Step 2
Click the Configuration tab and log in when prompted. The Select System to Change window appears.
Step 3
From the Select System to Change window, click the name of the system for which you would like to
change SNMP or CDR polling preferences. The Change System window appears.
Step 4
To change the SNMP settings, click Show next to SNMP Collection. To change CDR settings, click
Show next to CDR Collection. Make the desired changes and click Save or Save and Continue Editing.
Adding a System
To add a new system to the VDS TC Analytics system to collect SNMP and CDR information from the
device, use this procedure:
Note
You must be assigned the Network Engineering Viewers package to perform this procedure.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
1-2
Chapter 1
Getting Started
Data Retrieval and Polling Preferences
Procedure
Step 1
From the VDS TC Analytics web page, From the menu bar on the right, choose Dashboards > Network
Engineering > Data Mining.
Step 2
Click the Configuration tab and log in when prompted. The Select System to Change window appears.
Step 3
From the Select System to Change window, click Add System above the Filter pane. The Add System
window appears.
Step 4
Use the System Properties table to complete the fields in the Add System window:
Table 1-1
System Properties
Field
Description
Name
The name for a VDS TC caching system. Enter a descriptive name
because this name appears in the Cisco Analytics Filter by options and
information.
Description
A description for the VDS TC system you are adding (optional).
POP
The POP to which system belongs. If you need to add a POP, click the
Plus (+) icon next to this field.
Host
The management IP address of the VDS TC caching engine that you
want to monitor.
SSH Port
The default is 22. Use caution if changing this port number and ensure
the VDS TC caching engine supports the new port number.
SSH Credentials
Username
The username that is required for accessing the management node of the
VDS TC caching engine.
Password
The password that is required for accessing the management node of the
VDS TC caching engine.
SNMP Credentials: The read community string for the VDS TC caching engine. This value
Read Community
can be obtained automatically with valid SSH credentials and
configuration path or set manually. It is recommended that only the
advanced administrator set the string manually.
REST API Credentials
API Username
The username required for accessing the REST API of the management
node.
API Password
The password required for accessing the REST API of the management
node.
SNMP Collection (Click Show to display the properties.)
SNMP check box
This check box is checked by default, which allows the VDS TC
Analytics database to collect SNMP polling information. To disable
SNMP polling, uncheck this check box.
Interval between
SNMP polls
The time interval in minutes between SNMP polls. The default value is
5.
SNMP timeout
(secs.)
The number of seconds to wait before considering the connection to the
SNMP server to be timed out.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
1-3
Chapter 1
Getting Started
Data Tables and Charts
Table 1-1
System Properties (continued)
Field
Description
CDR Collection (Click Show to display the properties.)
Step 5
Collect check box
This check box is checked by default, which allows the VDS TC
Analytics database to collect CDR polling information. To disable CDR
polling uncheck this check box.
Extract Path
The location from which to retrieve CDR files from the monitored
platform. The default path is /opt/pang/cdrs.
Remove files after
copy
Check this check box to delete CDR files from their source location
after retrieval into the VDS TC Analytics database, or uncheck this
check box to leave the files on the source. Unchecked is the default.
Rate limit in KB
Enter KB/s threshold to limit traffic.
Restriction
Choose your preference for restricting the CDR collection. Your options
are None, Time, and Interval. The default option is None.
Allowed poll hours
starts
If you chose either Time or Interval for Restriction, enter the time in
which to begin the data collection.
Allowed poll hours
ends
If you chose either Time or Interval for Restriction, enter the time in
which to end the data collection.
Collection interval
If you chose Interval for the Restriction value, state the time intervals
for collecting data.
If you would like to add another system, click Save and Add Another. If you are finished adding
systems, click Save.
Data Tables and Charts
The user can display the reports in the following data tables and charts:
Data Tables
•
Visual: Displays the Service by the general Request Number/Capacity Size
•
Data Table: Displays the variable by the actual request number (capacity) size
•
Visual (Capacity): Displays the general variable capacity with its percentage in relation
•
Extended Data Table: Displays the variable capacity with its percentage in relation
•
Data Table (Capacity): Displays the variable capacity with its percentage in relation
•
None: Hides the data table
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
1-4
Chapter 1
Getting Started
Data Tables and Charts
Charts
•
Pareto Charts: A Pareto Chart is a chart that contains both bars and a line graph. Using the Pareto
Chart enables you to see individual values in descending order by the bars and the cumulative total
in the line graph. The Pareto drop-down list enables you to choose the type of Pareto graph to
display: Cache Requests, Clear Requests, Total Requests, Cache Capacity, Clear Capacity, Total
Capacity, All, and None.
•
Bar Charts: A bar chart is a summary or categorical data. It displays the data using a number of
bars with the same width. The height of each bar is proportional to the specific category value it
represents.
•
Pie Charts: A Pie Chart is a circular chart that is divided into sectors. Each sector represents a
numerical proportion. The Pie Chart drop-down list enables you to choose the type of Pie chart to
display: Cache Requests, Clear Requests, Total Requests, Cache Capacity, Clear Capacity, Total
Capacity, All, and None.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
1-5
Chapter 1
Data Tables and Charts
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
1-6
Getting Started
CH A P T E R
2
Marketing Reports
Marketing Reports are used for quick retrieval of general researched information. You can filter the
Marketing Reports to view historical, current, and future trends in a general researched report.
The At a Glance Dashboards plot the daily average data, defined by your Data Retrieval and Polling
Preferences, filtered for the time frame that you select. Each tab opens to display information based on
the filtering criteria that is defined for that tab. At any time, and in any tab, you can change the filtering
to present the information that you want. Your last filtering criteria is passed on to the next tab that you
open in the AT a Glance view.
At a Glance Info for Marketing
The Marketing At a Glance reports provide an immediate overview of the marketing trends, displaying
daily average values for the time frame you select. Data is arranged in the following charts and data
tables:
•
Top 5 Percentages Subscribers
•
Top 5 Percentages Subscriber IP Addresses
•
Subscriber Packages
General Notes for Charts and Reports
•
Current day information not available: Charts that rely on information for IPs and domains
require an additional day for analysis. Because IP information is collected between 00:01 and 24:00
each day, and only analyzed after it is collected, no information is available for the current day,
therefore you can only present information up to the previous day. IP information for the current day
can only be presented the day after.
Top 5 Percentages Subscribers
The Top 5 Percentage of Subscribers tab provides information on the top 5 percent of the subscribers for
selected clear and cache requests by subscriber name. This summarized view focuses on the overall
subscriber requests or cached requests.
The Top 5 Percentage of Subscribers tables show the subscribers that are most highly served from both
the Internet (Clear) and Cisco Analytics (Cache), broken down by both total traffic capacity and the total
number of requests. By default, information is presented for the top 5 percent of subscribers that scored
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-1
Chapter 2
Marketing Reports
At a Glance Info for Marketing
the highest Cache Out traffic capacity, according to the selected day’s five minute polling values. To
change the date range for which the data is displayed, choose the date range in the Filter By section and
click Apply.
Figure 2-1
At a Glance Top 5 Percentages Subscribers
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-2
Chapter 2
Marketing Reports
At a Glance Info for Marketing
Working with the Data
Time Frame
To change the date range for which the data is displayed, choose the date range in the Filter By section
and click Apply. The dates appear in MM/DD/YY format. The chart is regenerated for the new time
frame, and this time frame is displayed in brackets in the title. The new time frame is also passed on to
all of the other tabs in this dashboard.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you
want to export and from the pop-up menu, choose the format to which would like to export the data. A
dialog box appears that asks you to either save or open the file. Choose which ever option you prefer.
Display Drop-Down List
From the Display drop-down list, you can choose the table or chart format to use to display the data. The
options will vary depending on the report you are viewing.
Reports
There are three different charts on the Top 5 Percent Subscribers tab:
•
Top 5 Percent Subscribers by Total Capacity: This report displays information for the users that
are in the top 5 percent of the subscribers, based on total requests. This table provides information
about the amount of clear and cached content that is served for each subscriber, displayed in both
traffic capacity and number of requests.
•
Top 5 Percent Subscribers by Cache Capacity: This report displays information for the users that
are in the top 5 percent of the subscribers, based on cache requests. This table provides information
about the amount of clear and cached content that is served for each subscriber, displayed in both
traffic capacity and number of requests.
•
Top 5 Percent Subscribers by Clear Capacity: This report displays information for the users that
are in the top 5 percent of the subscribers, based on clear requests. This table provides information
about the amount of clear and cached content that is served for each subscriber, displayed in both
traffic capacity and number of requests.
Top 5 Percentages Subscriber IP Addresses
The Top 5 Percentage of Subscribers IP tab provides information on the top 5 percent of the subscribers
for selected clear and cache requests by IP address. This summarized view focuses on the overall
subscriber requests or cached requests.
The Top 5 Percentage of Subscribers IP tables show the subscribers that are most highly served from
both the Internet (Clear) and Cisco Analytics (Cache), broken down by both total traffic capacity and the
total number of requests. By default, information is presented for the top 5 percent of subscribers that
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-3
Chapter 2
Marketing Reports
At a Glance Info for Marketing
scored the highest Cache Out traffic capacity, according to the selected day’s five minute polling values.
To change the date range for which the data is displayed, choose the date range in the Filter By section
and click Apply.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-4
Chapter 2
Marketing Reports
At a Glance Info for Marketing
Figure 2-2
At a Glance Top 5 Percentages Subscriber IPs
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-5
Chapter 2
Marketing Reports
At a Glance Info for Marketing
Working with the Data
Time Frame
To change the date range for which the data is displayed, choose the date range in the Filter By section
and click Apply. The dates appear in MM/DD/YY format. The chart is regenerated for the new time
frame, and this time frame is displayed in brackets in the title. The new time frame is also passed on to
all of the other tabs in this dashboard.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Display Drop-Down List
From the Display drop-down list, you can choose the table or chart format to use to display the data. The
options will vary depending on the report you are viewing.
Reports
There are three different charts on the Top 5 Percent Subscribers IPs tab:
•
Top 5 Percent Subscribers IP Addresses by Total Capacity: This report displays information for
the users that are in the top 5 percent of the subscribers, based on total requests, calculated for the
time frame specified. This table provides information about the amount of clear and cached content
that is served for each subscriber, displayed in both traffic capacity and number of requests.
•
Top 5 Percent Subscribers IP Addresses by Cache Capacity: This report displays information for
the users that are in the top 5 percent of the subscribers, based on cache requests, calculated for the
time frame specified. This table provides information about the amount of clear and cached content
that is served for each subscriber, displayed in both traffic capacity and number of requests.
•
Top 5 Percent Subscribers IP Addresses by Clear Capacity: This report displays information for
the users that are in the top 5 percent of the subscribers, based on clear requests, calculated for the
time frame specified. This table provides information about the amount of clear and cached content
that is served for each subscriber, displayed in both traffic capacity and number of requests.
Subscriber Packages
The Subscriber Packages tab provides a comparison of Internet (Clear) requests, Cisco Analytics
(Cache) requests, and total requests analyzed by both service and protocol, broken down by both total
traffic capacity and the total number of requests. The Subscriber Packages tab also provides a
comparison of total capacity, clear capacity, and cache capacity analyzed by both service and protocol.
By default information is presented based on the selected days five minute polling values. To change the
date range for which the data is displayed, choose the date range in the Filter By section and click Apply.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-6
Chapter 2
Marketing Reports
At a Glance Info for Marketing
Figure 2-3
At a Glance Subscriber Packages
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-7
Chapter 2
Marketing Reports
At a Glance Info for Marketing
Working with the Data
Time Frame
To change the date range for which the data is displayed, choose the date range in the Filter By section
and click Apply. The dates appear in MM/DD/YY format. The chart is regenerated for the new time
frame, and this time frame is displayed in brackets in the title. The new time frame is also passed on to
all of the other tabs in this dashboard.
Detailed Analysis
By default, information is displayed in a visual format. You can generate a data table that presents the
data as values listed in a table. To display information in a data table format, from the Display drop-down
list, choose Data Table.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Display Drop-Down List
From the Display drop-down list, you can choose the table or chart format to use to display the data. The
options will vary depending on the report you are viewing.
Reports
There are three different charts on the Subscriber Packages tab:
•
Content Comparison by Service: This data table presents information of content that is served
from both the Internet (Clear) and Cisco Analytics (Cache), broken down by services. By default,
information is presented as a data table for total traffic, cache traffic and clear traffic, by traffic
capacity or by the number of requests. By default, information is presented for services, according
to five minute polling values, for the entire time period.
The values presented in the data table are listed in ascending order. The highest value of each column
is also represented as a horizontal bar, constituting 100% of the width of that cell. Lower values in
that column are expressed as shorter horizontal bars respectively.
•
Content Comparison by Protocol: This data table presents information of content that is served
from both the Internet (Clear) and Cisco Analytics (Cache), broken down by protocol. By default,
information is presented as a data table for total traffic, cache traffic and clear traffic, by traffic
capacity or by the number of requests. By default, information is presented for services, according
to five minute polling values, for the entire time period.
The values presented in the data table are listed in ascending order. The highest value of each column
is also represented as a horizontal bar, constituting 100% of the width of that cell. Lower values in
that column are expressed as shorter horizontal bars respectively.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-8
Chapter 2
Marketing Reports
Data Mining for Marketing
•
Quality of Experience : The Quality of Experience report allows analysis and comparison of the
quality of experience of the network. QoE is measured by comparing the speed of content served
from Cisco Analytics (Cache) with the speed of content arriving directly from the World Wide Web
(Clear). QoE is presented for the entire network.
Data Mining for Marketing
The Data Mining Marketing reports provide an inclusive filtering mechanism that allows you to gather
specific information, uncovering traffic, domain, and IP patterns for individual systems. Data Mining is
intended for drilling-down into the performance of specific systems, top subscribers, and top domains,
by services or protocols. Data Mining presents five minute polling values (At a Glance charts are based
on daily average values), arranged in the following charts and data tables.
•
Content Analysis
•
Top Domains
•
Subscriber Package QoE
•
Top X Percentage Subscribers
•
Top X Percentage Subscriber IPs
•
Subscribers Usage Comparison
•
Bit Rate Analysis
General Notes for Charts and Reports
•
Current day information not available: Because IP information is collected between 00:01 and
24:00 each day, and only analyzed after it is collected, no information is available for the current
day for reports that require IP address and domain information. Therefore you can only present
information up to the previous day. IP and domain information for the current day can only be
presented the day after.
•
Selected time frame determines granularity: The selected time frame determines the chart
granularity. A chart or report with a time frame of up to and including 3 days, displays five minute
polling values. A chart or report with a time frame from 4 days to 30 days displays hourly average
points, which calculate all the five minute samples in each hour. A chart or report that has a time
frame of over 30 days displays only daily average values.
Content Analysis
The Content Analysis reports enable you to analyze the subscriber traffic patterns, by default filtered by
services, for the selected time frame, which by default is the last seven days. Information can be
displayed for a specific user, by either services or protocols. You can also filter the information that is
displayed based on systems, zone, POP, domain, subscriber IP, and host IP. By default, information is
displayed as numerical values. You can also choose to display information is as a pie chart and bar charts.
In this tab, the default Filter By preferences are set to display the previous seven days for the entire
network by services, sorted by Subscribers Popularity. You can filter information by a specific user, by
either services or protocols, and you can filter out several systems
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-9
Chapter 2
Marketing Reports
Data Mining for Marketing
or display a single case by zone, POP and system. Click a column header to sort the data table by that
column in ascending order. Your Filter By selections are passed on to all of the Marketing > Data Mining
tabs.
Figure 2-4
Data Mining Content Analysis
Reports
There is only one report displayed on the Content Analysis tab:
•
Content Comparison by Service/Protocol: This data table presents information of content that is
served from both the Internet (clear) and the VDS TC cache engines (cache), broken down by
services, protocols, or specific IP addresses. By default, information is presented as a data table for
total traffic, cache traffic, and clear traffic, by traffic capacity or by number of requests. By default,
information is presented for services, according to the five minute polling values, for the entire time
period.
The Content Comparison report displays the following information:
•
Service or Protocol: This column displays either the service type or protocol that is associated with
each request/capacity.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-10
Chapter 2
Marketing Reports
Data Mining for Marketing
•
Total Requests: This column displays the total number of clear and cached requests.
•
Clear Requests: This column displays the number of clear requests, whether the clear requests are
either cached in or forwarded. This traffic is considered traffic that is delivered directly from the
Internet.
•
Cache Requests: This column displays the amount of requested cached traffic.
•
Cache/Total Requests: This column displays the relation of Cache Capacity to Total Requests as a
percentage.
•
Total Capacity: This column displays the combined clear and cached capacity.
•
Clear Capacity: This column displays the capacity of clear traffic delivered directly from the
Internet.
•
Cache Capacity: This column displays the capacity of cached traffic.
•
Cache/Total Capacity: This column displays the relation of Cache Capacity to Total Capacity as a
percentage.
•
Subscribers Popularity: This column displays the traffic for each service.
Filtering the Data
Data Mining allows you to manipulate data and display the information according to the set of criteria
you specify. At any time, you can revert back to your previous filtering selection by clicking Reset.
Specific Zone, POP, System, or Subscriber
You can filter the information on the Content Analysis tab based on a specific zone, POP, system, or
Subscriber. The default filtering is set for the entire network, presenting cache out downstream services.
To present information for specific a zone, POP, system, or subscriber, in the Filter By section make your
selection, and click Apply. You can also click Search in the drop-down list of the item you would like
to filter by and search for items based on a name match, using the criteria listed in the Search Options
table.
.
Table 2-1
Search Options
Option
Description
Starts
In the search field enter the beginning of the item name to search
for in the Selected list. Click OK to exit and then click Apply in
the Filter By section.
Contains
In the search field enter any part of the item name to search for
in the Selected list. Click OK to exit and then click Apply in
the Filter By section.
Ends
In the search field enter the ending of the item name to search
for in the Selected list. Click OK to exit and then click Apply
in the Filter By section.
Is Like (Pattern Match)
To search for a pattern match, enter % on both sides of a partial
name to search for in the Selected list. Click OK to exit and then
click Apply in the Filter By section.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-11
Chapter 2
Marketing Reports
Data Mining for Marketing
Specific Protocol or Service
This tab enables you to filter information at the level of specific services or protocols. The default Filter
By is set for the entire network for all services. To present information for specific services or protocols,
in the Filter By section from the Category drop-down list, choose Protocol or Service. Next, from either
the Service or Protocol drop-down list make the selection you want. You can also click Search in the
drop-down list of the item you would like to filter by to search for items based on a name match. See the
Search Options table for the available search criteria. When you are finished entering the search criteria,
click Apply.
Time Frame
To change the time frame, in the Filter By section in the Time Frame drop-down list choose the time
frame for which you want to present information and then click Apply. The options are Last Day, Last
7 Days, Last 30 Days, Previous Month, or Custom Dates and the default is Last 7 Days. The chart is
regenerated for the new time frame, although the dates in the From and To fields do not update.
You can also enter the date range you want in the From and To text boxes. You can also use the Calendar
icon to select the date range that you want. After you change the dates, click Apply for the new range to
take effect.
The time frame that you set is displayed in brackets in the title, and is passed on to all the other tabs in
this dashboard.
rad_att_str Attributes
rad_att_str1, rad_att_str2, rad_att_str3, rad_att_str4, and rad_att_str5 are extra option attributes that you can
use to filter the data.
Domain, Subscriber IP, Host IP
You can filter the information on the Content Analysis tab based on Domain address, Subscriber IP, or
Host IP. To present information for a specific Domain, Subscriber IP, or Host IP, make your selection
from the drop-down lists and click Apply.
Options for Viewing the Data
Display
Information is presented in a data table, listing values in ascending order. The highest value of each
column is also represented as a horizontal bar, constituting 100% of that cell's width. Lower values in
that column are represented as shorter horizontal bars respectively.
To present full numerical values, from the Display drop-down list choose Data Table.
Detailed Analysis
To present charts in different display formats, you can choose a different format from the Detailed
Analysis drop-down list that is located below the data table.
•
Pie Charts: A circular chart that is divided into proportional sectors.
•
Bar Charts: A bar chart is a summary or categorical data. It displays the data using a number of
bars with the same width. The height of each bar is proportional to the specific category value it
represents.
•
Pareto Charts: A chart which contains both bars and a line graph. It displays in the bars, individual
values in a descending order and a cumulative total represented by the line.
•
Extended Data Table: This table is essentially the same as a data table with extended features.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-12
Chapter 2
Marketing Reports
Data Mining for Marketing
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Top Domains
The Top Domains reports enable you to analyze the domains with the highest total traffic capacity (the
default in this tab), for the selected time frame, which by default is the last seven days. For the listed
number of domains, which is by default 10 domains, you can also present information for clear traffic
or total traffic, breaking down each user consumption by capacity or requests. Information is displayed
in numerical values, also represented as horizontal bars to provide a visualize comparison within each
column.
In this tab, the default Filter By preferences are set to display the top 10 domains by their cache out
capacity, for the entire network, services and protocols. You can select only services or protocols, pick
a specific system, change the time frame, or select a breakdown of the information by clear or total
traffic, and by capacity or number of requests. Within this filtered selection, the list can be narrowed
down by specific domains. Your Filter By selections are passed on to all of the Marketing > Data Mining
tabs. Click a column header to sort the data table by that column in ascending order.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-13
Chapter 2
Marketing Reports
Data Mining for Marketing
Figure 2-5
Data Mining Top Domains
Filtering the Data
Data Mining allows you to manipulate data and display the information according to the set of criteria
you specify. At any time, you can revert back to your previous filtering selection by clicking Reset.
Specific Zone, POP, System, or Subscriber
You can filter the information on the Top Domains tab based on a specific zone, POP, system, or
subscriber. The default filtering is set for the entire network, presenting cache out downstream services.
To present information for specific a zone, POP, system, or subscriber, in the Filter By section make your
selection, and click Apply. You can also click Search in the drop-down list of the item you would like
to filter by and search for items based on a name match, using the criteria listed in the Search Options
table.
Specific Protocol or Service
This tab enables you to filter information at the level of specific services or protocols. The default Filter
By is set for the entire network for all services and protocols. To present information for specific services
or protocols, in the Filter By section from either the Service or Protocol drop-down list make the
selections you want. You can also click Search in the drop-down list of the item you would like to filter
by to search for items based on a name match. See the Search Options table for the available search
criteria. When you are finished entering the search criteria, click Apply.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-14
Chapter 2
Marketing Reports
Data Mining for Marketing
Content Information
By default, the top 10 domains are listed by cache capacity. You can choose to list a different number of
top domains or other content type, select total traffic or incoming traffic by requests or by capacity, and
refine this list by specific domains.
•
To select the number of top domains to display, from the Top text box enter the number of domains
you want to display and then click Apply. The data table is refreshed to show your selection.
•
To select the type of traffic on which to base the top domains, in the By drop-down list choose the
type of traffic that you want to use and then click Apply. The data table is refreshed to show your
selection.
•
To display information for specific domains, from the Domain drop-down list choose the domain
that you want to display and then click Apply. You can also click Search in the Domain drop-down
list to search for domains based on a name match. See the Search Options table for the available
search criteria. When you are finished entering the search criteria, click Apply.
rad_att_str Attributes
rad_att_str1, rad_att_str2, rad_att_str3, rad_att_str4, and rad_att_str5 are extra option attributes that you can
use to filter the data.
Display
Information is presented in a data table, listing values in ascending order. The highest value of each
column is also represented as a horizontal bar, constituting 100% of that cell's width. Lower values in
that column are represented as shorter horizontal bars respectively.
To present full numerical values, from the Display drop-down list choose Data Table.
Time Frame
To change the time frame, in the Filter By section in the Time Frame drop-down list choose the time
frame for which you want to present information and then click Apply. The options are Last Day, Last
7 Days, Last 30 Days, Previous Month, or Custom Dates and the default is Last 7 Days. The chart is
regenerated for the new time frame, although the dates in the From and To fields do not update.
You can also enter the date range you want in the From and To text boxes. You can also use the Calendar
icon to select the date range that you want. After you change the dates, click Apply for the new range to
take effect.
The time frame that you set is displayed in brackets in the title, and is passed on to all the other tabs in
this dashboard.
Options for Viewing the Data
Display
Information is presented in a data table, listing values in ascending order. The highest value of each
column is also represented as a horizontal bar, constituting 100% of that cell's width. Lower values in
that column are represented as shorter horizontal bars respectively.
To present full numerical values, from the Display drop-down list choose Data Table.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-15
Chapter 2
Marketing Reports
Data Mining for Marketing
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Reports
There is only one report displayed on the Top Domains tab:
•
Top Domains: According to your Filter By criteria, this data table presents information for the
domains most highly served from both the Internet (clear data) and the VDS TC cache engines
(cached data), broken down by traffic capacity and number of requests. By default, information is
presented for the top 10 domains that scored the highest Cache Out traffic capacity, according to the
current day's five minute polling values.
Information is presented in a data table, listing values in ascending order. The highest value in each
column is also represented as a horizontal bar, constituting 100% of that cell's width. Lower values
in that column are represented as shorter horizontal bars respectively.
Subscriber Package QoE
The Subscriber Package QoE reports enable you to analyze the quality of experience (QoE) of the user
for the selected time frame, which by default is the last seven days, for the subscriber package. QoE is
measured by comparing the speed of content served from the VDS TC cache engines (cache) with the
speed of content arriving directly from the Internet (clear). By default, QoE is presented As Is, where
the two lines for cache traffic and clear traffic are plotted for comparison. You can also present the QoE
as a single ratio line between cache data and clear data. You can select a Detailed Analysis of the
information that you want, as numerical values or individual charts. This tab delivers the same
information as the At a Glance, Subscriber Packages tab.
In this tab, the default Filter by preferences are set to display QoE by service per the current day's five
minute polling values, and is plotted As Is to show both cache and clear lines. You can choose Time
Reported By, change the time frame, choose a single ratio line chart, and generate a data table to list the
plotted values numerically, or select a breakdown of the information by Per Subscription Package Chart
or Per Subscriber Package Data Table. Your Filter By selections are passed on to all of the Marketing >
Data Mining tabs.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-16
Chapter 2
Marketing Reports
Data Mining for Marketing
Figure 2-6
Data Mining Subscriber Package QoE
Working with the Data
Data Mining allows you to manipulate data and display the information according to the set of criteria
you specify. At any time, you can revert back to your previous filtering selection by clicking Reset.
As Is or Ratio Chart
You can display the QoE As Is, where the two lines for cache traffic and clear traffic are plotted for
comparison or you can display the QoE as a single ratio line between cache data and clear data. The
default Filter By preferences are set to present the information As Is, displaying the two comparative
lines.
To display the ratio line between cache data and clear data, in the Filter By section from the For
drop-down list, choose Ratio and then click Apply. The chart refreshes to display a single line
constituting the ratio between the cache and the clear values.
To display cache data and clear separately in two comparative lines, in the Filter By section from the For
drop-down list, choose As Is and then click Apply. The chart refreshes and displays two separate lines,
constituting the cache and the clear values.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-17
Chapter 2
Marketing Reports
Data Mining for Marketing
Units
Traffic is presented in bps for the selected time frame. The default time frame is the current day, and the
charts are plotted according to points that represent five minute polling values.
Values
To see the numerical value of each point, hover over a line. At every plotted polled point, the numerical
value appears for that point. Or from the Detailed Analysis drop-down list you can choose Data Table.
A data table appears below the chart listing the numerical values for the plotted lines and the acceleration
ratios.
To see the numerical value of each point per service or protocol, from the Detailed Analysis drop-down
list choose Per Subscriber Package Chart or Per Subscriber Package Data Table. A data table
appears below the chart listing the numerical values for the plotted lines and the acceleration ratio. The
relative chart appears to the right of the chart.
Time Frame
To change the time frame, in the Filter By section in the Time Frame drop-down list choose the time
frame for which you want to present information and then click Apply. The options are Last Day, Last
7 Days, Last 30 Days, Previous Month, or Custom Dates and the default is Last 7 Days. The chart is
regenerated for the new time frame, although the dates in the From and To fields do not update.
You can also enter the date range you want in the From and To text boxes. You can also use the Calendar
icon to select the date range that you want. After you change the dates, click Apply for the new range to
take effect.
The time frame that you set is displayed in brackets in the title, and is passed on to all the other tabs in
this dashboard.
Time Report By
You can choose whether to base the time of the report on the Analytics Platform time or the Caching
Platform local time.
Detailed Analysis
By default, information is displayed only as a chart. You can also display the information in the
following formats by choosing them from the Detailed Analysis drop-down list:
•
Data Table: Displays a data table below the chart listing the numerical values for the plotted line(s),
and the acceleration ratios.
•
Per Subscription Package Chart: Displays individual charts for each subscription package.
•
Per Subscriber Package Data Table: Displays a data table below the chart, with the relative chart
appearing to the right of the data table.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-18
Chapter 2
Marketing Reports
Data Mining for Marketing
Reports
There are two reports on the Subscriber Package QoE tab:
•
Network Quality of Experience (day): Displays the quality of experience (QoE) of the subscriber
package for the selected time frame, based an a daily average. By default, information is presented
for the first system you configured in the Configuration tab. By default, QoE is presented As Is,
where the two lines for cache data and clear data are plotted for comparison. The higher the Cache
QoE line is above the Clear QoE line, the higher the QoE, indicating a higher level of network traffic
delivered faster by VDS TC. You can also present the QoE as a single Ratio line between cached
data and clear data by choosing Ratio from the For drop-down list. The higher the acceleration ratio,
the higher the QoE improvement delivered by VDS TC. You can select a Detailed Analysis of the
information you want, as numerical values or individual charts.
•
Network Quality of Experience (hour): Displays the quality of experience (QoE) of the subscriber
package for the selected time frame, based on an hourly average. By default, information is
presented for the first system you configured in the Configuration tab. By default, QoE is presented
As Is, where the two lines for cache data and clear data are plotted for comparison. The higher the
Cache QoE line is above the Clear QoE line, the higher the QoE, indicating a higher level of network
traffic delivered faster by VDS TC. You can also present the QoE as a single Ratio line between
cached data and clear data by choosing Ratio from the For drop-down list. The higher the
acceleration ratio, the higher the QoE improvement delivered by VDS TC. You can select a Detailed
Analysis of the information you want, as numerical values or individual charts.
Top X Percentage Subscribers
This tab presents the request information of the subscribers, by name, that are most highly served from
both the Internet (clear data) and the VDS TC cache engines (cached data), broken down by either traffic
capacity or number of requests. By default, information is presented for the top 2 percentile of
subscribers that scored the highest Cache Out traffic capacity, according to the current day's five minute
polling values. The information is displayed for both the top subscribers and the top domains. Using the
Filter By options you can change the display criteria, including the top percentile number you would like
to display, and what you want this percentile to be based on, such as total requests, total capacity, clear
capacity, clear requests, and so on.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-19
Chapter 2
Marketing Reports
Data Mining for Marketing
Figure 2-7
Data Mining Top X Percentage Subscribers
Filtering Data
Data Mining allows you to manipulate data and display the information according to the set of criteria
you specify. At any time, you can revert back to your previous filtering selection by clicking Reset.
Specific Zone, POP, System, or Subscriber
You can filter the information on the Top X Percentage Subscribers tab based on a specific zone, POP,
system, or subscriber. The default filtering is set for the entire network, presenting cache out downstream
services.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-20
Chapter 2
Marketing Reports
Data Mining for Marketing
To present information for a specific zone, POP, system, or subscriber in the Filter By section make your
selection, and click Apply. You can also click Search in the drop-down list of the item you would like
to filter by to search for items based on a name match. See the Search Options table for the available
search criteria. When you are finished entering the search criteria, click Apply.
rad_att_str Attributes
rad_att_str1, rad_att_str2, rad_att_str3, rad_att_str4, and rad_att_str5 are extra option attributes that you can
use to filter the data.
Specific Domain, Subscriber IP, or Host IP
You can also filter the information based on Domain, Subscriber IP or Host IP. The default filtering is
set for the entire network, presenting cache out downstream services.
To present information for a specific Domain, Subscriber IP, or Host IP, in the Filter By section make
your selection, and click Apply. You can also click Search in the drop-down list of the item you would
like to filter by to search for items based on a name match. See the Search Options table for the available
search criteria. When you are finished entering the search criteria, click Apply.
Specific Protocol or Service
This tab enables you to filter information at the level of specific services or protocols. The default Filter
By is set for the entire network for all services. To present information for specific services or protocols,
in the Filter By section from the Category drop-down list, choose Protocol or Service. Next, from either
the Service or Protocol drop-down list make the selection you want. You can also click Search in the
drop-down list of the item you would like to filter by to search for items based on a name match. See the
Search Options table for the available search criteria. When you are finished entering the search criteria,
click Apply.
Content Information
By default, the top 2 or 10 percent of subscribers and domains are listed by cache capacity. Which value
is the default depends on which report tab you choose first because the last filtering criteria is passed on
to the next tab that you open. You can choose to list a different percentage of top subscribers and domains
and you can choose to display a different content type. You can also choose to filter the output based on
a range on the total capacity.
•
To change the top percentile to display, from the Top(%) text box enter the top percentile that you
want to display and then click Apply. The data table is refreshed to show your selection.
•
To select the type of traffic to display, in the By drop-down list choose the type of traffic that you
want to display and then click Apply. The data table is refreshed to show your selection.
•
To filter based on the range of total capacity, enter a starting range in the Total Capacity (MB) From
text box and an ending range in the Total Capacity (MB) To text box.
Time Frame
To change the time frame, in the Filter By section in the Time Frame drop-down list choose the time
frame for which you want to present information and then click Apply. The options are Last Day, Last
7 Days, Last 30 Days, Previous Month, or Custom Dates and the default is Last 7 Days. The chart is
regenerated for the new time frame, although the dates in the From and To fields do not update.
You can also enter the date range you want in the From and To text boxes. You can also use the Calendar
icon to select the date range that you want. After you change the dates, click Apply for the new range to
take effect.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-21
Chapter 2
Marketing Reports
Data Mining for Marketing
The time frame that you set is displayed in brackets in the title, and is passed on to all the other tabs in
this dashboard.
Options for Viewing the Data
Display
By default, information is displayed in a visual format. You can generate a data table that presents the
data as values listed in a table. To display information in a data table format, from the Display drop-down
list, choose Data Table.
Detailed Analysis
For the Content Comparison by Service report in different formats, you can choose a different format
for the report from the Detailed Analysis drop-down list that is located below the data table.
•
Pie Charts: A circular chart that is divided into proportional sectors.
•
Bar Charts: A bar chart is a summary or categorical data. It displays the data using a number of
bars with the same width. The height of each bar is proportional to the specific category value it
represents.
•
Pareto Charts: A chart which contains both bars and a line graph. It displays in the bars, individual
values in a descending order and a cumulative total represented by the line.
•
Extended Data Table: This table is essentially the same as a data table with extended features.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Reports
The Top X Percentage Subscriber IPs tab has four reports:
•
Top Subscribers: This data table provides information on the subscribers by name that consume the
top percentage of total, clear, and cached traffic depending on which choice is selected in the By
drop-down list in the Filter By section.
•
Content Comparison by Service or Content Comparison by Protocol: This data table presents
information of content served from both the Internet (clear) and the VDS TC cache engines
(cached), broken down by services or protocols. By default this table presents information for the
top percentile of users based on the total capacity used. By default, information is presented for
services, according to five minute polling values, for the entire time period.
By default, information is presented as a data table, listing values in ascending order. The highest
value in each column is also represented as a horizontal bar, constituting 100% of that cell's width.
Lower values in that column are represented as shorter horizontal bars respectively. You can also
view the information for this report in a chart format.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-22
Chapter 2
Marketing Reports
Data Mining for Marketing
•
Top Domains: This data table provides information on the domains, by domain name, that consume
the top percentage of total, clear, and cached traffic depending on which choice is selected in the By
drop-down list in the Filter section.
•
Top Hosts: This data table provides information on the hosts by name, that consume the top
percentage of total, clear, and cached traffic depending on which choice is selected in the By
drop-down list in the Filter section.
Top X Percentage Subscriber IPs
This tab presents the request information of the subscribers, displayed by IP address, that are most highly
served from both the Internet (clear data) and the VDS TC cache engines (cached data), broken down by
either traffic capacity, or number of requests, displayed as IP address. By default, information is
presented for the top 2 percentile of subscribers that scored the highest Cache Out traffic capacity,
according to the current day's five minute polling values. The information is displayed for both the top
subscribers and the top domains. Using the Filter By options you can change the display criteria,
including the top percentile number you would like to display, and what you want this percentile to be
based on, such as total requests, total capacity, clear capacity, clear requests, and so on.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-23
Chapter 2
Marketing Reports
Data Mining for Marketing
Figure 2-8
Data Mining Top X Percentage Subscriber IPs
Sorting the Data
Data Mining allows you to manipulate data and display the information according to the set of criteria
you specify. At any time, you can revert back to your previous filtering selection by clicking Reset.
Specific Zone, POP, or System
You can filter the information on the Top X Percentage Subscriber IPs tab based on a specific zone, POP,
or system. The default filtering is set for the entire network, presenting cache out downstream services.
To present information for a specific zone, POP, or system, in the Filter By section make your selection,
and click Apply. You can also click Search in the drop-down list of the item you would like to filter by
to search for items based on a name match. See the Search Options table for the available search criteria.
When you are finished entering the search criteria, click Apply.
Specific Domain, Subscriber IP, or Host IP
You can also filter the information based on Domain, Subscriber IP or Host IP. The default filtering is
set for the entire network, presenting cache out downstream services.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-24
Chapter 2
Marketing Reports
Data Mining for Marketing
To present information for a specific Domain, Subscriber IP, or Host IP, in the Filter By section make
your selection, and click Apply. You can also click Search in the drop-down list of the item you would
like to filter by to search for items based on a name match. See the Search Options table for the available
search criteria. When you are finished entering the search criteria, click Apply.
Specific Protocol or Service
This tab enables you to filter information at the level of specific services or protocols. The default Filter
By is set for the entire network for all services. To present information for specific services or protocols,
in the Filter By section from the Category drop-down list, choose Protocol or Service. Next, from either
the Service or Protocol drop-down list make the selection you want. You can also click Search in the
drop-down list of the item you would like to filter by to search for items based on a name match. See the
Search Options table for the available search criteria. When you are finished entering the search criteria,
click Apply.
Content Information
By default, the top 2 or 10 percent of subscribers and domains are listed by cache capacity. Which value
is the default depends on which report tab you choose first because the last filtering criteria is passed on
to the next tab that you open. You can choose to list a different percentage of top subscribers and domains
and you can choose to display a different content type. You can also choose to filter the output based on
a range on the total capacity.
•
To change the top percentile to display, from the Top(%) text box enter the top percentile that you
want to display and then click Apply. The data table is refreshed to show your selection.
•
To select the type of traffic to display, in the By drop-down list choose the type of traffic that you
want to display and then click Apply. The data table is refreshed to show your selection.
•
To filter based on the range of total capacity, enter a starting range in the Total Capacity (MB) From
text box and an ending range in the Total Capacity (MB) To text box.
Time Frame
To change the time frame, in the Filter By section in the Time Frame drop-down list choose the time
frame for which you want to present information and then click Apply. The options are Last Day, Last
7 Days, Last 30 Days, Previous Month, or Custom Dates and the default is Last 7 Days. The chart is
regenerated for the new time frame, although the dates in the From and To fields do not update.
You can also enter the date range you want in the From and To text boxes. You can also use the Calendar
icon to select the date range that you want. After you change the dates, click Apply for the new range to
take effect.
The time frame that you set is displayed in brackets in the title, and is passed on to all the other tabs in
this dashboard.
Options for Viewing the Data
Display
By default, information is displayed in a visual format. You can generate a data table that presents the
data as values listed in a table. To display information in a data table format, from the Display drop-down
list, choose Data Table.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-25
Chapter 2
Marketing Reports
Data Mining for Marketing
Detailed Analysis
For the Content Comparison by Service report in different formats, you can choose a different format
for the report from the Detailed Analysis drop-down list that is located below the data table.
•
Pie Charts: A circular chart that is divided into proportional sectors.
•
Bar Charts: A bar chart is a summary or categorical data. It displays the data using a number of
bars with the same width. The height of each bar is proportional to the specific category value it
represents.
•
Pareto Charts: A chart which contains both bars and a line graph. It displays in the bars, individual
values in a descending order and a cumulative total represented by the line.
•
Extended Data Table: This table is essentially the same as a data table with extended features.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Reports
The Top X Percentage Subscribers tab has four reports:
•
Top Subscriber IP Addresses: This data table provides information on the subscribers by IP
address that consume the top percentage of total, clear, and cached traffic depending on which
choice is selected in the By drop-down list in the Filter section.
•
Content Comparison by Service or Content Comparison by Protocol: This data table presents
information of content served from both the Internet (clear) and the VDS TC cache engines
(cached), broken down by services or protocols. By default this table presents information for the
top percentile of users based on the total capacity used. By default, information is presented for
services, according to five minute polling values, for the entire time period.
By default, information is presented as a data table, listing values in ascending order. The highest
value in each column is also represented as a horizontal bar, constituting 100% of that cell's width.
Lower values in that column are represented as shorter horizontal bars respectively. You can also
view the information for this report in a chart format.
•
Top Domains: This data table provides information on the domains, by IP address, that consume
the top percentage of total, clear, and cached traffic depending on which choice is selected in the By
drop-down list in the Filter section.
•
Top Hosts: This data table provides information on the hosts, by IP address, that consume the top
percentage of total, clear, and cached traffic depending on which choice is selected in the By
drop-down list in the Filter section.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-26
Chapter 2
Marketing Reports
Data Mining for Marketing
Subscribers Usage Comparison
The Subscriber Usage Comparison tab displays subscriber usage capacity, requests, and average daily
speed compared between two different time frames. This summarized view focuses on the overall
subscriber usage requests or cached requests.
Figure 2-9
Data Mining Subscribers Usage Comparison
Filtering the Data
Data Mining allows you to manipulate data and display the information according to the set of criteria
you specify. At any time, you can revert back to your previous filtering selection by clicking Reset.
Specific Zone, POP, or System
You can filter the information on the Subscribers Usage Comparison tab based on a specific zone, POP,
or system. The default filtering is set for the entire network, presenting cache out downstream services.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-27
Chapter 2
Marketing Reports
Data Mining for Marketing
To present information for a specific zone, POP, or system, in the Filter By section make your selection,
and click Apply. You can also click Search in the drop-down list of the item you would like to filter by
to search for items based on a name match. See the Search Options table for the available search criteria.
When you are finished entering the search criteria, click Apply. You can choose different zones, POPs,
and systems for each time period.
Specific Protocol or Service
This tab enables you to filter information at the level of specific services or protocols. The default Filter
By is set for the entire network for all services and protocols. To present information for specific services
or protocols, in the Filter By section from either the Service or Protocol drop-down list make the
selections you want. You can also click Search in the drop-down list of the item you would like to filter
by to search for items based on a name match. See the Search Options table for the available search
criteria. When you are finished entering the search criteria, click Apply. You can choose different
services or protocols for each time period.
Time Periods
This report displays a comparison between two time periods. In the First Period field enter the first date
for which you want to analyze data, or use the calendar icon to choose a date. In the Second Period field,
enter the second date against which you want to compare the first date, or use the calendar icon to choose
a data. To choose how long each period covers, choose a number from the Time Frame (Days) drop-down
list. Click Apply.
The time periods that you set are displayed in brackets in the title.
Options for Viewing the Data
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Reports
There is one report on the Subscribers Usage Comparison:
•
Subscribers Usage Comparison: This report displays subscriber usage capacity, requests, and
average daily speed compared between two different time frames. This summarized view focuses on
the overall subscriber usage requests or cached requests. By default, the information is presented for
comparison, according to five minute polling values, for the entire time period. Information is
presented for the last day of each time period: from the current time and day, back to midnight 1 day
earlier.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-28
Chapter 2
Marketing Reports
Data Mining for Marketing
Bit Rate Analysis
The Bit Rate Analysis report enables you to analyze the bit rate (speed) with the highest total traffic
capacity, for the selected time frame, which by default is seven days. This is classified by the download
video files bit rate.This information can be displayed for either services or protocols, and you can filter
the output by the zone, POP, and system. The breakdown for each bit rate is presented separately.
Figure 2-10
Data Mining Bit Rate Analysis
Filtering the Data
Data Mining allows you to manipulate data and display the information according to the set of criteria
you specify. At any time, you can revert back to your previous filtering selection by clicking Reset.
Specific Zone, POP, or System
You can filter the information on the Bit Rate Analysis tab based on a specific zone, POP, or system. The
default filtering is set for the entire network, presenting cache out downstream services.
To present information for a specific zone, POP, or system, in the Filter By section make your selection,
and click Apply. You can also click Search in the drop-down list of the item you would like to filter by
to search for items based on a name match. See the Search Options table for the available search criteria.
When you are finished entering the search criteria, click Apply.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-29
Chapter 2
Marketing Reports
Data Mining for Marketing
Specific Protocol or Service
This tab enables you to filter information at the level of specific services or protocols. The default Filter
By is set for the entire network for all services and protocols. To present information for specific services
or protocols, in the Filter By section from either the Service or Protocol drop-down list make the
selections you want. You can also click Search in the drop-down list of the item you would like to filter
by to search for items based on a name match. See the Search Options table for the available search
criteria. When you are finished entering the search criteria, click Apply.
Bit Rate Range
You can filter the information based on the bit rate range determined by Total Capacity, Cache Capacity,
Cache Requests, Clear Capacity, Clear Requests, or Total Requests. To filter the output based on the bit
rate range, from the Bit Rate Range drop-down list choose the desired option. To select the type of traffic
to display, in the By drop-down list choose the type of traffic that you want to display and then click
Apply.
Options for Viewing the Data
Display
Information is presented in a data table, listing values in ascending order. The highest value of each
column is also represented as a horizontal bar, constituting 100% of that cell's width. Lower values in
that column are represented as shorter horizontal bars respectively.
To present full numerical values, from the Display drop-down list choose Data Table.
Time Frame
To change the time frame, in the Filter By section in the Time Frame drop-down list choose the time
frame for which you want to present information and then click Apply. The options are Last Day, Last
7 Days, Last 30 Days, Previous Month, or Custom Dates and the default is Last 7 Days. The chart is
regenerated for the new time frame, although the dates in the From and To fields do not update.
You can also enter the date range you want in the From and To text boxes. You can also use the Calendar
icon to select the date range that you want. After you change the dates, click Apply for the new range to
take effect.
The time frame that you set is displayed in brackets in the title, and is passed on to all the other tabs in
this dashboard.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Reports
There are three reports on the Bit Rate Analysis tab:
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-30
Chapter 2
Marketing Reports
Data Mining for Marketing
•
Content Comparison: This report displays information for total traffic, cache traffic, and clear
traffic showing both requests and capacity, broken down by bit rate range. By default this
information is calculated for all services and protocols for the entire network, but you can filter what
data is included by service, protocol, zone, POP, and System.
•
Content Comparison per Day: This report displays information for total traffic, cache traffic, and
clear traffic showing both requests and capacity, showing the information for each day in the date
range, broken down by bit rate range. By default this information is calculated for all services and
protocols for the entire network, but you can filter what data is included by service, protocol, zone,
POP, and System.
•
Content Comparison - Detailed: This report displays information for total traffic, cache traffic,
and clear traffic showing both requests and capacity, broken down by bit rate range, service, and
protocol. By default this information is calculated for all services and protocols for the entire
network, but you can filter what data is included by service, protocol, zone, POP, and System.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-31
Chapter 2
Data Mining for Marketing
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
2-32
Marketing Reports
CH A P T E R
3
Network Engineering Reporting
The Network Engineering reports provide an inclusive filtering mechanism that allows you to obtain
specific information, uncovering traffic, domain and IP patterns for individual systems.
At a Glance Info for Network Engineering
The Network Engineering At a Glance reports provide an immediate overview of the system, displaying
daily average values for the time frame you select. Data is arranged in the following charts and data
tables:
•
Traffic Analysis
•
Peak Traffic Analysis
•
Services Analysis
•
Protocol Analysis
•
QoE Analysis
General Notes for Charts and Reports
•
Current day information not available: Charts that rely on information for IPs and domains
require an additional day for analysis. Because IP information is collected between 00:01 and 24:00
each day, and only analyzed after it is collected, no information is available for the current day,
therefore you can only present information up to the previous day. IP information for the current day
can only be presented the day after.
Traffic Analysis
The Traffic Analysis tab delivers immediate visibility of the system performance, based on the selected
time frame, which by default is the current week. This summarized view focuses on the overall
subscriber consumption, or total downstream traffic, in comparison with the cached out traffic. This tab
also displays a chart that breaks down the information by service and by protocol.
By default, information is displayed as a chart for the current week, but you can filter the time frame you
want. You can also choose to generate a data table to view the information as values in a table.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-1
Chapter 3
Network Engineering Reporting
At a Glance Info for Network Engineering
Figure 3-1
At a Glance Traffic Analysis
Working with the Data
Units
In the chart, the total downstream traffic and cache out downstream capacity are presented in bps for the
selected time frame, where M in the Y axis stands for “million”. For the default time period of one week,
each line is plotted between points that represent the daily average value. If you select a shorter time
frame, such as one or two days, the curve is then plotted between points that represent 5 minute average
values.
Values
To see the numerical value of each point, hover over a line at a daily average value point. The numerical
value appears for that date in a pop-up box. You can also choose Data Table from the From Detailed
Analysis drop-down list to view a table that displays the daily average values for the total traffic
downstream and cache out downstream.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-2
Chapter 3
Network Engineering Reporting
At a Glance Info for Network Engineering
Time Frame
To change the date range for which the data is displayed, choose the date range in the Filter By section
and click Apply. The dates appear in MM/DD/YY format. The chart is regenerated for the new time
frame, and this time frame is displayed in brackets in the title. The new time frame is also passed on to
all of the other tabs in this dashboard.
Detailed Analysis
By default, information is displayed as a chart. You can generate a Detailed Analysis Data Table that
presents the data as values listed in a table. To display information in a data table format, from the
Detailed Analysis drop-down list, choose Data Table. The data table appears below the chart.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Reports
There are five different charts on the Traffic Analysis tab:
•
Total Traffic Downstream and Cache Out Downstream for the Entire Network: This chart
presents the mapping of all traffic served from Cisco VDS TC cache engines compared with all
traffic served from the Internet, for the selected time frame. The lines are plotted according to daily
average polling values, and presented in bps, where M in the Y axis stands for “million”. The closer
the lines are to each other, the higher level of network traffic is delivered by the VDS TC cache
engines.
•
Total Traffic Downstream by Service: This chart presents the mapping of all traffic served from
both the Internet and the VDS TC cache engines, broken down by services. Information is presented
for the selected time frame, plotted according to daily average polling values, and presented in bps.
The M in the Y axis stands for “million”. In this chart services are represented by different colors
and overlaid on each other. To see more detail for this information, go to Dashboard > Network
Engineering > Data Mining and click the Traffic Analysis tab.
•
Cache Out Downstream by Service: This chart presents the mapping of all traffic served from VDS
TC cache engines, broken down by services. Information is presented for the selected time frame,
plotted according to daily average polling values, and presented in bps. The M in the Y axis stands
for “million”. In this chart services are represented by different colors and overlaid on each other.
•
Total Traffic Downstream by Protocol: This chart presents the mapping of all traffic served from
both the Internet and the VDS TC cache engines, broken down by protocols. Information is
presented for the selected time frame, plotted according to daily average polling values, and
presented in bps. The M in the Y axis stands for “million”. In this chart protocols are represented
by different colors and overlaid on each other. To see more detail for this information, go to
Dashboard > Network Engineering > Data Mining and click the Traffic Analysis tab.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-3
Chapter 3
Network Engineering Reporting
At a Glance Info for Network Engineering
•
Cache Out Downstream by Protocol: This chart presents the mapping of all traffic served from
VDS TC cache engines, broken down by protocols. Information is presented for the selected time
frame, plotted according to daily average polling values, and presented in bps. The M in the Y axis
stands for “million”. In this chart protocols are represented by different colors and overlaid on each
other.
Peak Traffic Analysis
The Peak Traffic Analysis reports provide visibility into the values of network downstream traffic during
the peak bandwidth, for each day. The charts compare various views of the peak subscriber consumption,
or peak total downstream traffic, and cache out traffic, and of peak byte hit ratio and cache productivity
ratio. Peak BHR is analyzed by comparing total downstream traffic and cache out traffic. Peak cache
productivity is analyzed by comparing downstream incoming traffic and downstream cache out traffic.
By default, information is displayed as a chart. You can generate a data table to list the plotted values.
Figure 3-2
At a Glance Peak Traffic Analysis
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-4
Chapter 3
Network Engineering Reporting
At a Glance Info for Network Engineering
Working with the Data
Units
In the charts, the total downstream traffic and cache out downstream capacity are presented in bps for
the selected time frame, where M in the Y axis stands for “million”. For the default time period of one
week, each line is plotted between points that represent the daily average value. If you select a shorter
time frame, such as one or two days, the curve is then plotted between points that represent 5 minute
average values.
Values
To see the numerical value of each point, hover over a line at a daily average value point. The numerical
value appears for that date in a pop-up box. You can also choose Data Table from the From Detailed
Analysis drop-down list to view a table that displays the daily average values for the total traffic
downstream and cache out downstream.
Time Frame
To change the date range for which the data is displayed, choose the date range in the Filter By section
and click Apply. The dates appear in MM/DD/YY format. The chart is regenerated for the new time
frame, and this time frame is displayed in brackets in the title. The new time frame is also passed on to
all of the other tabs in this dashboard.
Detailed Analysis
By default, information is displayed as a chart. You can generate a Detailed Analysis Data Table that
presents the data as values listed in a table. To display information in a data table format, from the
Detailed Analysis drop-down list, choose Data Table. The data table appears below the chart.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Reports
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Reports
There are two reports on the Peak Traffic Analysis tab:
•
Peak BHR Analysis: This chart presents the mapping of BHR at daily peak times, when total traffic
is the highest. BHR is indicated by comparing all of the traffic that was served from both the Internet
and Cisco Analytics at daily peak time, and all traffic that was served from VDS TC cache engines
at the daily peak time, for the selected time frame. Information is presented for the selected time
frame, and presented in bps, where M in the Y axis stands for “million”. The closer the lines are to
each other, the more network traffic is delivered by the VDS TC cache engines at the peak time.
•
Peak Cache Productivity Analysis: This chart presents the mapping of cache productivity at daily
peak times, when total traffic is the highest. Cache productivity is indicated by comparing all
incoming traffic at the daily peak time to all traffic that was served from VDS TC cache engines at
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-5
Chapter 3
Network Engineering Reporting
At a Glance Info for Network Engineering
the daily peak time, for the selected time frame. Information is presented for the selected time frame,
and presented in bps, where M in the Y axes stands for “millions”. The closer the lines are to each
other, the more network traffic is delivered by the VDS TC cache engines at the peak time.
Services Analysis
The Service Analysis reports provide visibility into each service that is being served downstream on the
network. The charts provide a cumulative view where each service is indicated as a portion of the total
downstream traffic and cache out downstream traffic. In these charts, each service is plotted randomly
above another. In addition, pie charts provide percentile views of the information for specific time
frames:
•
Last day: This pie chart provides data from the current time and day, back to midnight one day
earlier. For example, clicking Apply at 08:35AM on Oct. 17th filters information from 8:35AM on
Oct. 17th back to 00:01AM on Oct. 16th.
If you choose a time frame that is in the past, the last day of that time frame is presented. For
example, if on Oct. 17th you select a time frame from Aug. 1 to Sept. 1, the last day of this selected
time frame is presented, which would be from 00:00AM on Sept. 1 to 00:00AM on Sept. 2.
•
Last week: This pie chart provides data from the current time and day, back to midnight seven days
earlier. For example, clicking Apply at 08:35AM on Oct. 17th filters information from 08:35AM on
Oct. 17th back to 00:01AM on Oct. 10th.
If you select a time frame that is in the past, the last week of that time frame is presented. For
example, if on Oct. 17th you select a time frame from Aug. 1st to Sept. 1st, the last week of this time
frame is presented, i.e. from 00:00AM Aug. 26th to 00:00AM Sept. 2nd.
•
Last month: This pie chart provides data from the current time and day, back to midnight 30 days
earlier. For example, clicking Apply at 08:35AM on Oct. 17th filters information from 08:35AM on
Oct. 17th back to 00:01AM on Sept. 16th.
If you select a time frame that is in the past, the last month of that time frame is presented. For
example, if on Oct. 17th you select a time frame from Aug. 1st to Sept. 1st, the last month of this
time frame is presented, i.e. from 00:00AM Aug. 2nd to 00:00AM Sept. 2th.
The bottom part of the page displays a chart for each service.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-6
Chapter 3
Network Engineering Reporting
At a Glance Info for Network Engineering
Figure 3-3
At a Glance Service Analysis
Working with the Data
Units
In the charts, the total downstream traffic and cache out downstream capacity are presented in bps for
the selected time frame, where M in the Y axis stands for “million” For the default time period of one
week, each line is plotted between points that represent the daily average value. If you select a shorter
time frame, such as one or two days, the curve is then plotted between points that represent 5 minute
average values.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-7
Chapter 3
Network Engineering Reporting
At a Glance Info for Network Engineering
Values
To see the numerical value of each point, hover over a line at a daily average value point. The numerical
value appears for that date in a pop-up box. You can also choose Data Table from the From Detailed
Analysis drop-down list to view a table that displays the daily average values for the total traffic
downstream and cache out downstream.
Time Frame
To change the date range for which the data is displayed, choose the date range in the Filter By section
and click Apply. The dates appear in MM/DD/YY format. The chart is regenerated for the new time
frame, and this time frame is displayed in brackets in the title. The new time frame is also passed on to
all of the other tabs in this dashboard.
Detailed Analysis
By default, information is displayed as a chart. You can generate a Detailed Analysis Data Table that
presents the data as values listed in a table. To display information in a data table format, from the
Detailed Analysis drop-down list, choose Data Table. The data table appears below the chart.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Reports
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Reports
There are six sections on the Service Analysis tab:
•
Total Traffic Downstream by Service: This chart presents the mapping of all traffic served from
both the Internet and VDS TC cache engines, broken down by services. Information is presented for
the selected time frame, plotted according to daily average polling values, and presented in bps,
where M in the Y axes stands for “million”. This is a cumulative view, where services are
represented by different colors overlaid on each other.
•
Cache Out Downstream by Service: This chart presents the mapping of all traffic served from VDS
TC cache engines, broken down by services. Information is presented for the selected time frame,
plotted according to daily average polling values, and presented in bps, where M in the Y axes stands
for “million”. This is a cumulative view, where services are represented by different colors overlaid
on each other.
•
Average Total Traffic and Cache Out Downstream by Service (Last Day): This section displays
two pie charts:
– Total Traffic Downstream: This pie chart displays all traffic that is served from both the
Internet and VDS TC cache engines.
– Cache Out Downstream: This pie chart displays all traffic served only from the VDS TC cache
engines, broken down by services.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-8
Chapter 3
Network Engineering Reporting
At a Glance Info for Network Engineering
Each service is represented according to the portion it constitutes from the total traffic. Information
is presented for the last day in the selected time frame, from the current time and day, back to
midnight one day earlier. For example, clicking Apply on 08:35AM on Oct. 17th filters information
from 08:35AM on Oct. 17th back to 00:01AM on Oct. 16th. If you choose a time frame that is in the
past, the last day of that time frame is presented. Information is plotted according to daily average
polling values, and presented in bps. The bigger the portion, the higher consumption this service
constitutes from the total traffic, for this last day.
•
Average Total Traffic and Cache Out Downstream by Service (Last Week): This section displays
two pie charts:
– Total Traffic Downstream: This pie chart displays all traffic that is served from both the
Internet and VDS TC cache engines.
– Cache Out Downstream: This pie chart displays all traffic served only from the VDS TC cache
engines, broken down by services.
Each service is represented according to the portion it constitutes from the total traffic. Information
is presented for the last week in the selected time frame, from the current time and day, back to
midnight 7 days earlier. For example, clicking Apply on 08:35AM on Oct. 17th filters information
from 08:35AM back to 00:01AM on Oct. 10th. If you choose a time frame that is in the past, the last
week of that time frame is presented. For example, if on Oct. 17th you choose a time frame from
Aug. 1st to Sept. 1st, the last week of this time frame is presented, i.e. from 00:00AM Aug. 26th to
00:00AM Sept. 2nd.
Information is plotted according to daily average polling values, and presented in bps. The bigger
the portion, the higher consumption this service constitutes from the total traffic, for this last week.
•
Average Total Traffic and Cache Out Downstream by Service (Last Month): This section
displays two pie charts:
– Total Traffic Downstream: This pie chart displays all traffic that is served from both the
Internet and VDS TC cache engines.
– Cache Out Downstream: This pie chart displays all traffic served only from the VDS TC cache
engines, broken down by services.
Each service is represented according to the portion it constitutes from the total traffic. Information
is presented for the last month in the selected time frame, from the current time and day, back to
midnight 30 days earlier. For example, clicking Apply on 08:35AM on Oct. 17th filters information
from 08:35AM back to 00:01AM on Sept. 16th. If you choose a time frame that is in the past, the
last month of that time frame is presented. For example, if on Oct. 17th you select a time frame from
Aug. 1st to Sept. 1st, the last month of this time frame is presented, i.e. from 00:00AM Aug. 2nd to
00:00AM Sept. 2th.
Information is plotted according to daily average polling values, and presented in bps. The bigger
the portion, the higher consumption this service constitutes from the total traffic, for this last week.
•
Per Service Traffic Analysis: These charts present the mapping of all traffic served from both
Internet and the VDS TC cache engines, broken down to show each service separately. Information
is presented for the selected time frame, plotted according to daily average polling values, and
presented in bps. The closer the lines are to each other, the higher the level of network traffic that is
delivered by the VDS TC cache engines.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-9
Chapter 3
Network Engineering Reporting
At a Glance Info for Network Engineering
Protocol Analysis
The Protocols Analysis reports provide visibility into each protocol, being served downstream on the
network. The charts provide a cumulated view where each service is indicated as a portion of the total
downstream traffic and cache out downstream traffic. In addition, pie charts provide percentile views of
the information for specific time frames:
•
Last day: This pie chart provides data from the current time and day, back to midnight one day
earlier. For example, clicking Apply at 08:35AM on Oct. 17th filters information from 8:35AM on
Oct. 17th back to 00:01AM on Oct. 16th.
If you choose a time frame that is in the past, the last day of that time frame is presented. For
example, if on Oct. 17th you select a time frame from Aug. 1 to Sept. 1, the last day of this selected
time frame is presented, which would be from 00:00AM on Sept. 1 to 00:00AM on Sept. 2.
•
Last week: This pie chart provides data from the current time and day, back to midnight seven days
earlier. For example, clicking Apply at 08:35AM on Oct. 17th filters information from 08:35AM on
Oct. 17th back to 00:01AM on Oct. 10th.
If you select a time frame that is in the past, the last week of that time frame is presented. For
example, if on Oct. 17th you select a time frame from Aug. 1st to Sept. 1st, the last week of this time
frame is presented, i.e. from 00:00AM Aug. 26th to 00:00AM Sept. 2nd.
•
Last month: This pie chart provides data from the current time and day, back to midnight 30 days
earlier. For example, clicking Apply at 08:35AM on Oct. 17th filters information from 08:35AM on
Oct. 17th back to 00:01AM on Sept. 16th.
If you select a time frame that is in the past, the last month of that time frame is presented. For
example, if on Oct. 17th you select a time frame from Aug. 1st to Sept. 1st, the last month of this
time frame is presented, i.e. from 00:00AM Aug. 2nd to 00:00AM Sept. 2th.
The bottom part of the page displays a chart for each protocol.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-10
Chapter 3
Network Engineering Reporting
At a Glance Info for Network Engineering
Figure 3-4
At a Glance Protocol Analysis
Working with the Data
Units
In the charts, the total downstream traffic and cache out downstream capacity are presented in bps for
the selected time frame, where M in the Y axis stands for “million” For the default time period of one
week, each line is plotted between points that represent the daily average value. If you select a shorter
time frame, such as one or two days, the curve is then plotted between points that represent 5 minute
average values.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-11
Chapter 3
Network Engineering Reporting
At a Glance Info for Network Engineering
Values
To see the numerical value of each point, hover over a line at a daily average value point. The numerical
value appears for that date in a pop-up box. You can also choose Data Table from the From Detailed
Analysis drop-down list to view a table that displays the daily average values for the total traffic
downstream and cache out downstream.
Time Frame
To change the date range for which the data is displayed, choose the date range in the Filter By section
and click Apply. The dates appear in MM/DD/YY format. The chart is regenerated for the new time
frame, and this time frame is displayed in brackets in the title. The new time frame is also passed on to
all of the other tabs in this dashboard.
Detailed Analysis
By default, information is displayed as a chart. You can generate a Detailed Analysis Data Table that
presents the data as values listed in a table. To display information in a data table format, from the
Detailed Analysis drop-down list, choose Data Table. The data table appears below the chart.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Reports
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Reports
There are six sections on the Protocol Analysis tab:
•
Total Traffic Downstream by Protocol: This chart presents the mapping of all traffic served from
both the Internet and VDS TC cache engines, broken down by protocols. Information is presented
for the selected time frame, plotted according to daily average polling values, and presented in bps,
where M in the Y axes stands for “million”. This is a cumulative view, where protocols are
represented by different colors overlaid on each other.
•
Cache Out Downstream by Protocol: This chart presents the mapping of all traffic served from
VDS TC cache engines, broken down by protocols. Information is presented for the selected time
frame, plotted according to daily average polling values, and presented in bps, where M in the Y
axes stands for “million”. This is a cumulative view, where protocols are represented by different
colors overlaid on each other.
•
Average Total Traffic and Cache Out Downstream by Protocol (Last Day): This section displays
two pie charts:
– Total Traffic Downstream: This pie chart displays all traffic that is served from both the
Internet and VDS TC cache engines, broken down by protocol.
– Cache Out Downstream: This pie chart displays all traffic served only from the VDS TC cache
engines, broken down by services, broken down by protocol.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-12
Chapter 3
Network Engineering Reporting
At a Glance Info for Network Engineering
Each protocol is represented according to the portion it constitutes from the total traffic. Information
is presented for the last day in the selected time frame, from the current time and day, back to
midnight one day earlier. For example, clicking Apply on 08:35AM on Oct. 17th filters information
from 08:35AM on Oct. 17th back to 00:01AM on Oct. 16th. If you choose a time frame that is in the
past, the last day of that time frame is presented. Information is plotted according to daily average
polling values, and presented in bps. The bigger the portion, the higher consumption this protocol
constitutes from the total traffic, for this last day.
•
Average Total Traffic and Cache Out Downstream by Protocol (Last Week): This section
displays two pie charts:
– Total Traffic Downstream: This pie chart displays all traffic that is served from both the
Internet and VDS TC cache engines, broken down by protocol.
– Cache Out Downstream: This pie chart displays all traffic served only from the VDS TC cache
engines, broken down by services, broken down by protocol.
Each protocol is represented according to the portion it constitutes from the total traffic. Information
is presented for the last week in the selected time frame, from the current time and day, back to
midnight 7 days earlier. For example, clicking Apply on 08:35AM on Oct. 17th filters information
from 08:35AM back to 00:01AM on Oct. 10th. If you choose a time frame that is in the past, the last
week of that time frame is presented. For example, if on Oct. 17th you choose a time frame from
Aug. 1st to Sept. 1st, the last week of this time frame is presented, i.e. from 00:00AM Aug. 26th to
00:00AM Sept. 2nd.
Information is plotted according to daily average polling values, and presented in bps. The bigger
the portion, the higher consumption this protocol constitutes from the total traffic, for this last week.
•
Average Total Traffic and Cache Out Downstream by Protocol (Last Month): This section
displays two pie charts:
– Total Traffic Downstream: This pie chart displays all traffic that is served from both the
Internet and VDS TC cache engines, broken down by protocol.
– Cache Out Downstream: This pie chart displays all traffic served only from the VDS TC cache
engines, broken down by services, broken down by protocol.
Each protocol is represented according to the portion it constitutes from the total traffic. Information
is presented for the last month in the selected time frame, from the current time and day, back to
midnight 30 days earlier. For example, clicking Apply on 08:35AM on Oct. 17th filters information
from 08:35AM back to 00:01AM on Sept. 16th. If you choose a time frame that is in the past, the
last month of that time frame is presented. For example, if on Oct. 17th you select a time frame from
Aug. 1st to Sept. 1st, the last month of this time frame is presented, i.e. from 00:00AM Aug. 2nd to
00:00AM Sept. 2th.
Information is plotted according to daily average polling values, and presented in bps. The bigger
the portion, the higher consumption this protocol constitutes from the total traffic, for this last week.
•
Per Protocol Traffic Analysis: These charts displays all traffic that is served from both Internet and
the VDS TC cache engines, broken down to show each protocol separately. Information is presented
for the selected time frame, plotted according to daily average polling values, and presented in bps.
The closer the lines are to each other, the higher the level of network traffic that is delivered by the
VDS TC cache engines.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-13
Chapter 3
Network Engineering Reporting
At a Glance Info for Network Engineering
QoE Analysis
The QoE Analysis report allows analysis and comparison of the quality of experience (QoE) of the user.
QoE is measured by comparing the speed of content served from cache with the speed of content arriving
directly from the Internet (Clear). QoE is presented for the entire network, i.e. total protocols, and in
comparison with HTTP protocol.
By default, QoE is presented As Is, where the two lines for cache and clear are plotted for comparison.
You can also present the QoE as a single Ratio line between cache and clear. You can select a Detailed
Analysis of the information you want, as numerical values.
Figure 3-5
At a Glance Network QoE
Working with the Data
Units
In the charts, the total downstream traffic and cache out downstream capacity are presented in bps for
the selected time frame, where K in the Y axes stands for “thousand”. For the default time period of one
week, each line is plotted between points that represent the daily average value. If you select a shorter
time frame, such as one or two days, the curve is then plotted between points that represent 5 minute
average values.
Values
To see the numerical value of each point, hover over a line at a daily average value point. The numerical
value appears for that date in a pop-up box. You can also choose Data Table from the Detailed Analysis
drop-down list to view a table that displays the daily average values for the total traffic downstream and
cache out downstream.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-14
Chapter 3
Network Engineering Reporting
Data Mining Info for Network Engineering
Time Frame
To change the date range for which the data is displayed, choose the date range in the Filter By section
and click Apply. The dates appear in MM/DD/YY format. The chart is regenerated for the new time
frame, and this time frame is displayed in brackets in the title. The new time frame is also passed on to
all of the other tabs in this dashboard.
Detailed Analysis
By default, information is displayed as a chart. You can generate a Detailed Analysis Data Table that
presents the data as values listed in a table. To display information in a data table format, from the
Detailed Analysis drop-down list, choose Data Table. The data table appears below the chart.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Reports
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Reports
There are two reports on the Network QoE tab:
•
Quality of Experience Comparison for Entire Network: This chart presents the mapping of the
Qoe of the subscribers data. QoE is indicated by comparing Cache QoE with Clear QoE, for the
selected time frame. The lines are plotted according to daily average polling values, and presented
in bps, where K in the Y axes stands for “thousand”. The higher that the Cache QoE line is above
the Clear QoE line, the higher the QoE, with higher level of network traffic delivered faster by the
VDS TC cache engines.
•
Quality of Experience Comparison by Protocol: This chart presents the mapping of the QoE of
the subscribers, by protocol. For each protocol, QoE is indicated by comparing Cache QoE with
Clear QoE, for the selected time frame. Information is presented for the selected time frame, plotted
according to daily average polling values, and presented in bps, where K in the Y axis stands for
“thousand”. For each protocol, the higher that the Cache QoE line is above the Clear QoE line, the
higher the QoE, indicating a higher level of network traffic delivered faster by the VDS TC cache
engines.
Data Mining Info for Network Engineering
The Network Engineering Data Mining reports panel provides an inclusive filtering mechanism that
enables you to collect specific information, uncovering traffic, domain and IP patterns for individual
systems. Augmenting the At a Glance panel that provides an immediate overview of the entire network,
Data Mining is intended for drilling-down into the performance of specific systems, top subscribers and
top domains, by services or protocols. The Data Mining tabs present five minute polling values (At a
Glance charts are based on daily average values), arranged in the following tabs:
•
Content Analysis
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-15
Chapter 3
Network Engineering Reporting
Data Mining Info for Network Engineering
•
Top Subscriber IPs
•
Traffic Distribution
•
Configuration
General Notes for Charts and Reports
•
Current day information not available: Because IP information is collected between 00:01 and
24:00 each day, and only analyzed after it is collected, no information is available for the current
day for reports that require IP address and domain information. Therefore you can only present
information up to the previous day. IP and domain information for the current day can only be
presented the day after.
•
Selected time frame determines granularity: The selected time frame determines the chart
granularity. A chart or report with a time frame of up to and including 3 days, displays five minute
polling values. A chart or report with a time frame from 4 days to 30 days displays hourly average
points, which calculate all the five minute samples in each hour. A chart or report that has a time
frame of over 30 days displays only daily average values.
Content Analysis
The Content Analysis reports enable you to analyze subscriber traffic patterns, filtered by services (the
default in this tab), for the selected time frame, which is the last seven days by default. You can filter the
information for a specific subscriber IP, by either services or protocols, and you can filter traffic based
on the zone, POP, and system. Information is displayed in numerical values and with horizontal bars to
provide visualize comparisons within each column. You can also choose to view the data in charts as
well.
In this tab, the default Filter by preferences are set to display information for all subscribers, for all
systems, by services. You can filter information by a specific IP address, select only services or
protocols, pick a specific system, zone, or POP, and change the time frame. Your Filter By selections are
passed on to all of the Network Engineering > Data Mining tabs.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-16
Chapter 3
Network Engineering Reporting
Data Mining Info for Network Engineering
Figure 3-6
Data Mining Content Analysis
Working with the Data
Data Mining allows you to manipulate data and display the information according to the set of criteria
you specify. At any time, you can revert back to your previous filtering selection by clicking Reset.
Specific Zone, POP, or System
You can filter the information on the Content Analysis tab based on a specific zone, POP, or system.
To present information for specific a zone, POP, or system, in the Filter By section make your selection,
and click Apply. You can also click Search in the drop-down list of the item you would like to filter by
to search for items based on a name match. See the Search Options table for the available search criteria.
When you are finished entering the search criteria, click Apply.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-17
Chapter 3
Network Engineering Reporting
Data Mining Info for Network Engineering
Specific Protocol or Service
This tab enables you to filter information at the level of specific services or protocols. The default Filter
By is set for all services. To present information for specific services or protocols, in the Filter By section
from the Category drop-down list, choose Protocol or Service. Next, from either the Service or Protocol
drop-down list make the selection you want. You can also click Search in the drop-down list of the item
you would like to filter by to search for items based on a name match. See the Search Options table for
the available search criteria. When you are finished entering the search criteria, click Apply.
Subscriber IP
By default information calculated across all subscriber IPs is displayed. You can choose to display
information for only specific IP address. From the Subscriber IP drop-down list, check the check boxes
for the Subscriber IP addresses that you would like to include in the report and click Apply.
Display
By default, information is presented in a data table, listing values in ascending order. The highest value
of each column is also represented as a horizontal bar, constituting 100% of that cell's width. Lower
values in that column are represented as shorter horizontal bars respectively.
To present full numerical values, from the Display drop-down list choose Data Table.
Detailed Analysis
To present the data in different display formats, you can choose a different format from the Detailed
Analysis drop-down list that is located below the data table:
•
Pie Charts: A circular chart that is divided into proportional sectors.
•
Bar Charts: A bar chart is a summary or categorical data. It displays the data using a number of
bars with the same width. The height of each bar is proportional to the specific category value it
represents.
•
Pareto Charts: A chart which contains both bars and a line graph. It displays in the bars, individual
values in a descending order and a cumulative total represented by the line.
•
Extended Data Table: This table is essentially the same as a data table with extended features.
Time Frame
To change the time frame, in the Filter By section in the Time Frame drop-down list choose the time
frame for which you want to present information and then click Apply. The options are Last Day, Last
7 Days, Last 30 Days, Previous Month, or Custom Dates and the default is the last 7 days. The chart is
regenerated for the new time frame, although the dates in the From and To fields do not update.
You can also enter the date range you want in the From and To text boxes. You can also use the Calendar
icon to select the date range that you want. After you change the dates, click Apply for the new range to
take effect.
The time frame that you set is displayed in brackets in the title, and is passed on to all the other tabs in
this dashboard.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-18
Chapter 3
Network Engineering Reporting
Data Mining Info for Network Engineering
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Reports
The following reports appear on the Content Analysis tab:
•
Content Comparison by Service: This data table presents information of content served from both
the Internet (clear) and the VDS TC cache engines (cache), broken down by services calculated for
all IP addresses, or just the IP addresses selected in the Subscriber IP drop-down list. By default,
information is presented as a data table for Total traffic, Cache traffic and Clear traffic, by traffic
capacity and by the number of requests. By default, information is presented for services, according
to five minute polling values, for the entire time period.
Information is presented in a data table, listing values in ascending order. The highest value of each
column is also represented as a horizontal bar, constituting 100% of that cell's width. Lower values
in that column are represented as shorter horizontal bars respectively.
•
Content Comparison by Service per Day: This report presents the breakdown for each day that is
calculated in the Content Comparison by Service report.
•
Content Comparison by Protocol: This data table presents information of content served from
both the Internet (clear) and the VDS TC cache engines (cache), broken down by protocols
calculated for all IP addresses, or just the IP addresses selected in the Subscriber IP drop-down list.
By default, information is presented as a data table for Total traffic, Cache traffic and Clear traffic,
by traffic capacity and by the number of requests. By default, information is presented for services,
according to five minute polling values, for the entire time period.
Information is presented in a data table, listing values in ascending order. The highest value of each
column is also represented as a horizontal bar, constituting 100% of that cell's width. Lower values
in that column are represented as shorter horizontal bars respectively.
•
Content Comparison by Protocol per Day: This report presents the breakdown for each day that
is calculated in the Content Comparison by Protocol report.
Top Subscriber IPs
The Top Subscriber IPs reports display information for those subscriber IPs that generate the highest
total traffic capacity, for the selected time frame, which is by default seven days. For the listed number
of subscribers, which is by default 10, you can present information for cache traffic, clear traffic, or total
traffic, breaking down each user consumption by capacity or requests. This information can be displayed
for either services or protocols, and you can filter based on systems, zone, POP, and subscriber IP. To
further refine your selection within the filtered group, you choose to view only those subscribers that fall
within a specific capacity range. Information is displayed in numerical values, also represented as
horizontal bars to provide a visualize comparison within each column.
In this tab, the default Filter by preferences are set to display the top 10 IPs by their total capacity, for
the entire network, for both services and protocols. Your Filter By selections are passed on to all of the
Network Engineering > Data Mining tabs. You can click a column header to sort the data table by the
ascending order of that column.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-19
Chapter 3
Network Engineering Reporting
Data Mining Info for Network Engineering
Figure 3-7
Data Mining Top Subscriber IPs
Working with the Data
Data Mining allows you to manipulate data and display the information according to the set of criteria
you specify. At any time, you can revert back to your previous filtering selection by clicking Reset.
Specific Zone, POP, or System
You can filter the information on the Top Subscriber IPs tab based on a specific zone, POP, or system.
The default filtering is set for the top 10 IP addresses for total capacity.
To present information for specific a zone, POP, or system, in the Filter By section make your selection,
and click Apply. You can also click Search in the drop-down list of the item you would like to filter by
to search for items based on a name match. See the Search Options table for the available search criteria.
When you are finished entering the search criteria, click Apply.
Specific Protocol or Service
This tab enables you to filter information at the level of specific services or protocols. The default Filter
By is set for the top 10 IP address for all services and protocols. To present information for specific
services or protocols, in the Filter By section from either the Service or Protocol drop-down list make
the selections you want. You can also click Search in the drop-down list of the item you would like to
filter by to search for items based on a name match. See the Search Options table for the available search
criteria. When you are finished entering the search criteria, click Apply.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-20
Chapter 3
Network Engineering Reporting
Data Mining Info for Network Engineering
Subscriber Traffic Information
By default the top 10 subscribers are listed by total capacity. You can choose to list a different number
of top subscribers, select clear traffic or cache traffic by requests or by capacity, and refine this list by
total capacity range and Subscriber IP.
To change any of these filter options, choose or enter the desired values in the Filter By section and click
Apply.
Time Frame
To change the time frame, in the Filter By section in the Time Frame drop-down list choose the time
frame for which you want to present information and then click Apply. The options are Last Day, Last
7 Days, Last 30 Days, Previous Month, or Custom Dates and the default is the last 7 days. The chart is
regenerated for the new time frame, although the dates in the From and To fields do not update.
You can also enter the date range you want in the From and To text boxes. You can also use the Calendar
icon to select the date range that you want. After you change the dates, click Apply for the new range to
take effect.
The time frame that you set is displayed in brackets in the title, and is passed on to all the other tabs in
this dashboard.
Display
Information is presented in a data table, listing values in ascending order. The highest value of each
column is also represented as a horizontal bar, constituting 100% of that cell's width. Lower values in
that column are represented as shorter horizontal bars respectively.
To present full numerical values, from the Display drop-down list choose Data Table. To present
approximated values shown with respective horizontal bars choose Visual from the Display drop-down
list.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Reports
The following report appears on the Top Subscriber IPs tab:
•
Top Subscriber IP Addresses: This data table presents IP information of subscribers most highly
served from both the Internet (clear data) and the VDS TC cache engines (cache data), based on total
data, cache data, or clear data, broken down by total, clear, and cache capacity, and the number of
total, clear, and cache requests. By default, information is presented for the top 10 subscribers that
scored the highest total capacity, according to the current day's five minute polling values.
Information is presented in a data table, listing values in ascending order. The highest value of each
column is also represented as a horizontal bar, constituting 100% of that cell's width. Lower values
in that column are represented as shorter horizontal bars respectively.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-21
Chapter 3
Network Engineering Reporting
Data Mining Info for Network Engineering
To present the breakdown of content for an IP, click the IP that you want and choose Content
Analysis from the pop-up menu that appears. The Content Analysis tab opens, listing the for that
IP. For more information, see the Content Analysis section.
Traffic Distribution
The Traffic Distribution reports enable you to analyze the correlation between IP addresses, cache
capacity, and cache requests, filtered by services, which is the default in this tab. By default, information
is displayed as a bar chart for the selected time frame, which is the last seven days by default, and
presented as percentages. You can filter the time frame you want and generate a data table to list the
plotted values. To further investigate the trends of subscribers, choose one of the reports in the Report
section.
Note
Because traffic information is collected between 00:01 and 24:00 each day, and only then analyzed, no
information is available for the current day. Although the last seven days is the default time frame, you
can only present information up to the previous day. Current day traffic information can only be
presented the day after.
Figure 3-8
Data Mining Traffic Distribution
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-22
Chapter 3
Network Engineering Reporting
Data Mining Info for Network Engineering
Working with the Data
Data Mining allows you to manipulate data and display the information according to the set of criteria
you specify. At any time, you can revert back to your previous filtering selection by clicking Reset.
Specific Zone, POP, or System
You can filter the information on the Traffic Distribution tab based on a specific zone, POP, or system.
To present information for specific a zone, POP, or system, in the Filter By section make your selection,
and click Apply. You can also click Search in the drop-down list of the item you would like to filter by
to search for items based on a name match. See the Search Options table for the available search criteria.
When you are finished entering the search criteria, click Apply.
Specific Protocol or Service
This tab enables you to filter information at the level of specific services or protocols. The default Filter
By is set for the entire network for all services. To present information for specific services or protocols,
in the Filter By section from the Category drop-down list, choose Protocol or Service. Next, from either
the Service or Protocol drop-down list make the selection you want. You can also click Search in the
drop-down list of the item you would like to filter by to search for items based on a name match. See the
Search Options table for the available search criteria. When you are finished entering the search criteria,
click Apply.
Units
In the Average Usage Comparison of IPs and Traffic chart, variables are presented as a percentile. In the
IP Addresses Count by Service chart, IP numbers are represented by the thousands.
Values
To see the numerical value of each point, in the Average Usage Comparison of IPs and Traffic chart, from
the Detailed Analysis drop-down list, choose Data Table. A data table appears below the chart listing
the numerical values for the plotted lines, including count, percentage, and sum.
In the IP Addresses Count by Service chart, from the Detailed Analysis drop-down list, choose Per
Service Data Table or Per Protocol Data Table.
Detailed Analysis
For the different reports that are available from the Traffic Distribution tab, you can choose to view the
data in different ways. To see what options are available, check the Detailed Analysis drop-down list.
Time Frame
To change the time frame, in the Filter By section in the Time Frame drop-down list choose the time
frame for which you want to present information and then click Apply. The options are Last Day, Last
7 Days, Last 30 Days, Previous Month, or Custom Dates and the default is Last 7 Days. The chart is
regenerated for the new time frame, although the dates in the From and To fields do not update.
You can also enter the date range you want in the From and To text boxes. You can also use the Calendar
icon to select the date range that you want. After you change the dates, click Apply for the new range to
take effect.
The time frame that you set is displayed in brackets in the title, and is passed on to all the other tabs in
this dashboard.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-23
Chapter 3
Network Engineering Reporting
Data Mining Info for Network Engineering
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Reports
The Traffic Distribution tab displays the following reports:
•
Average Usage Comparison of IPs and Traffic: This chart presents percentile information of the
number of IPs, cache capacity, and number of cache requests, grouped by services or protocols,
depending on what you choose from Category in the drop-down list. By default, information is
presented for the current day's five minute polling values and presented in percentage. Each variable
is represented as an individual bar, by service or protocol, allowing the comparison of each variable
across the network, and displaying the correlation between the three variables for each service.
•
IP Address Served: This report presents information of the number of IPs, broken down by total
traffic, grouped by services or protocols, depending on what you choose from Category in the
drop-down list. By default, information is presented for the current day's five minute polling values
and presented in their counted numbers. You can also display this information as a chart, where
values are represented by thousands (K). This is an accumulative view, where the IP count for each
service is piled randomly one above another, each comprising its respective amount from the total
number of subscribers.
•
IP Address Served by System: This report presents information of the number of IPs, broken down
by service or protocol, grouped by systems, depending on what you choose from Category in the
drop-down list. By default, information is presented for the current day's five minute polling values
and presented in their counted numbers.
•
IP Address Served per Day: This chart presents information of the number of IPs, broken down by
total traffic, grouped by services or protocols, depending on what you choose from Category in the
drop-down list. By default, information is presented for the current day's five minute polling values
averaged per day and presented as a percentage. You can choose to view and filter this information
by choosing different options from the drop-down list above the chart. For example, you can choose
to present the count information as a total number instead of a percentage.
•
IP Address Served per Day by System: This report presents information of the number of IPs, with
each service or protocol represented in a separate graph, depending on what you choose from
Category in the drop-down list, grouped by systems. By default, information is presented for the
current day's five minute polling values averaged per day and presented in their counted numbers.
You can choose to view and filter this information by choosing different options from the drop-down
list above the chart. For example, you can choose to present the count information as a total number
instead of a percentage.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-24
Chapter 3
Network Engineering Reporting
Data Mining Info for Network Engineering
Configuration
Unlike the other tabs that display charts and reports, the Configuration tab is focused on configuring the
VDS TC Analytics system. From the Configuration tab you can configure VDS TC Analytics
synchronization with the VDS TC systems, define the data collection mechanism, and determine the
system architecture by defining zones, POPs, and systems. The data retrieval and polling preferences can
be configured separately for each system.
Note
The Configuration tab is intended for the VDS TC Analytics Administrator who is required to perform
the ongoing administrative tasks. For more information on configuring the options available from the
Configuration tab, see the Cisco Videoscape Distribution Suite Transparent Caching Analytics Software
Installation Guide (part number OL-28018-02).
Select System to Change Window
When you click the Configuration tab, you will be asked to log in again. This is to confirm that you have
permissions to the Configuration section.
The default window that appears when you click the Configuration tab is the VDS Transparent Caching
Analytics Select System to Change window. This window lists the monitored platforms that are currently
configured for collection by the VDS TC Analytics system. This window indicates whether the CDR
collection or the SNMP collection is active for a system, and displays the date and time of the last CDR
and SNMP collection for each system.
Figure 3-9
Configuration Tab Select System to Change Window
Site Administration Window
You can view administrative information from the Site Administration window, including the VDS TC
Analytics version, serial number of the system, and recent VDS TC Analytics actions. From this window
you can also perform fundamental administrative tasks, such as adding POPs, systems, and zones.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-25
Chapter 3
Network Engineering Reporting
Data Mining Info for Network Engineering
Note
This page is intended for the VDS TC Analytics Administrator who is required to perform the ongoing
administrative tasks. For more information on configuring the options available from the Configuration
tab, see the Cisco Videoscape Distribution Suite Transparent Caching Analytics Software Installation
Guide (part number OL-28018-02).
To access the Site Administration window, click Home above the Select System to Change title bar.
Figure 3-10
Site Administration Window
The Site Administration window has the following sections. Which items you see, depends on what
group you belong to. Some options require that you belong to the Admin group:
•
Auth: From this section you can manage the user accounts. You must be assigned the Network
Engineering package and be assigned to the Admin group to manage users. Users can be assigned
three different types of permissions:
– Admin: A user that has been assigned to the Admin group can access all functions that are
available from the Site Administration page. This includes access to tools (such as upgrading
the software and license management), managing users, configuring notifications, and
managing the physical administration for POPs, systems, and zones.
– User: A user that has been assigned to the User group can only mange the physical
administration, which includes managing POPs, systems, and zones.
– Standard User: A user that has not been assigned to any groups is considered a “standard user”.
A standard user cannot access any of the configuration options available from the Configuration
tab, including being able to view a list of systems and their status.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-26
Chapter 3
Network Engineering Reporting
Data Mining Info for Network Engineering
Note
Note
For more information on managing the VDS TC Analytics users, see the Cisco Videoscape Distribution
Suite Transparent Caching Analytics Software Installation Guide (part number OL-28018-02).
•
Notification > Events: From this section you can view the events that have been logged on the VDS
TC Analytics system. You can also choose to filter these events by category, severity, and system.
You must be assigned the Network Engineering package and be assigned to the Admin group to view
the events.
•
Physical: From this section you can manage the listeners, POPs, systems, and zones. You must be
assigned the Network Engineering package and be assigned to either the Admin group or the Users
group to manage these items.
While Listeners also appears as an option in the Physical section, this feature is currently not supported.
•
Version: This section displays the version of the VDS TC Analytics software that is running.
•
Serial: This section displays the serial number of the VDS TC Analytics server.
•
Settings: In this section you can configure the your email address, to which notifications that you
have been assigned will be sent. You can also enable or disable the mailing of notifications for the
events that have been assigned to the user. You must be assigned the Network Engineering package
and be assigned to either the Admin group or the Users group to manage these items.
•
Tools: From this section you can perform the following actions:
– Software Upgrade
– Verify Configuration
– License Management
– Backup
– Data Retention Policy
– Radius Attributes
– Server Configuration
– Change the cdrget account password
•
Recent Actions: Displays all recent actions related to the VDS TC Analytics system.
The following sections describe how to perform some of the common administration tasks. For more
information on these tasks, see the Cisco Videoscape Distribution Suite Transparent Caching Analytics
Software Installation Guide (part number OL-28018-02).
Note
The configuration and management of zones, POPs, and systems are typically performed by someone
with advanced VDS TC Analytics administration experience.
Viewing the List of Existing Systems
To view the list of existing systems that are configured to be monitored by VDS TC Analytics, follow
these steps:
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-27
Chapter 3
Network Engineering Reporting
Data Mining Info for Network Engineering
Step 1
Choose Dashboards > Network Engineering > Data Mining and click the Configuration tab. Log in
when prompted. The VDS Transparent Caching Analytics Select System to Change window appears,
listing the existing systems that are monitored by VDS TC Analytics.
Step 2
If the VDS Transparent Caching Analytics Select System to Change window does not appear by default,
click Home above the Select System to Change title bar. In the Site Administration page that opens, click
Systems. The VDS Transparent Caching Analytics Select System to Change window opens, listing the
existing systems that are monitored by VDS TC Analytics.
From the VDS Transparent Caching Analytics Select System to Change window, you can do the
following:
•
Add a New System to be monitored by VDS TC Analytics
•
Start and Stop Data Collection
•
Change Polling Preferences of Monitored Systems
Add a New System
Follow this procedure to add VDS TC systems to be monitored by the VDS TC Analytics server.
Note
To configure systems you must be logged in as a user that has been assigned the Network Engineering
Viewers package and belong to either the Admin or User group.
Procedure
Step 1
Choose Network Engineering > Data Mining and click the Configuration tab. Log in when prompted.
The VDS Transparent Caching Analytics Select System to Change window appears.
Step 2
Click Physical above the Select System to Change title bar. The Physical Administration window
appears.
Step 3
Click Add in the Systems row. The Add System window appears.
Step 4
Use the System Properties table to complete the fields in the Add System window.
Table 3-1
System Properties
Field
Description
Name
The name for a VDS TC caching system. Enter a descriptive name
because this name appears in the Cisco Analytics Filter By options and
information.
Description
A description for the VDS TC system you are adding (optional).
POP
The POP to which system belongs. If you need to add a POP, click the
Plus (+) icon next to this field.
Host
The management IP address of the VDS TC caching engine that you
want to monitor.
SSH Port
The default is 22. Use caution if changing this port number and ensure
the VDS TC caching engine supports the new port number.
SSH Credentials
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-28
Chapter 3
Network Engineering Reporting
Data Mining Info for Network Engineering
Table 3-1
System Properties (continued)
Field
Description
Username
The username that is required for accessing the management node of the
VDS TC caching engine.
Password
The password that is required for accessing the management node of the
VDS TC caching engine.
SNMP Credentials:
Read Community
The read community string for the VDS TC caching engine. This value
can be obtained automatically with valid SSH credentials and
configuration path or set manually. It is recommended that only the
advanced administrator set the string manually.
SNMP Collection (Click Show to display the properties.)
SNMP check box
This check box is checked by default, which allows the VDS TC
Analytics database to collect SNMP polling information. To disable
SNMP polling, uncheck this check box.
Interval between
SNMP polls
The time interval in minutes between SNMP polls. The default value is
5.
CDR Collection (Click Show to display the properties.)
Step 5
Collect check box
This check box is checked by default, which allows the VDS TC
Analytics database to collect CDR polling information. To disable CDR
polling uncheck this check box.
Extract Path
The location from which to retrieve CDR files from the monitored
platform. The default path is /opt/pang/cdrs.
Remove files after
copy
Check this check box to delete CDR files from their source location after
retrieval into the VDS TC Analytics database, or uncheck this check box
to leave the files on the source. Unchecked is the default.
Rate limit in KB
Enter KB/s threshold to limit traffic.
Restriction
Choose your preference for restricting the CDR collection. Your options
are None, Time, and Interval. The default option is None.
Allowed poll hours
starts
If you chose either Time for the Restriction value, state the time in
which to begin data collection.
Allowed poll hours
ends
If you chose Time for the Restriction value, state the time in which to
end data collection.
Collection interval
If you chose Interval for the Restriction value, state the time intervals
for collecting data.
If you would like to add another system, click Save and Add Another. If you are finished adding
systems, click Save.
Start and Stop Data Collection
After you have added a new system, use this procedure to start and stop the SNMP and CDR collection
as needed:
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-29
Chapter 3
Network Engineering Reporting
Data Mining Info for Network Engineering
Procedure
Step 1
From the Select System to Change window, check the check box in front of the systems for which you
would like to start or stop the collection process.
Step 2
From the Action drop-down list, located above the list of systems, choose to either start the SNMP and
CDR data collection or to stop the SNMP and CDR data collection and then click Go.
Change Polling Preferences of Monitored Systems
Follow this procedure to change the polling preferences of an existing system:
Procedure
Step 1
Choose Dashboards > Network Engineering > Data Mining and click the Configuration tab. Log in
when prompted. The VDS Transparent Caching Analytics Select System to Change window appears.
Step 2
In the Select System to Change section, click the system for which you want to change the polling
preferences. The Change System window opens, displaying the current settings of the system.
Step 3
Use the System Properties table to help make changes to the system properties as desired.
Step 4
When you are finished making changes, click Save.
Viewing the List of Existing Zones
To view the list of existing zone that are configured on the VDS TC Analytics server, follow these steps:
Step 1
Choose Dashboard > Network Engineering > Data Mining and click the Configuration tab. Log in
when prompted. The VDS Transparent Caching Analytics Select System to Change window appears.
Step 2
Click Home above the Select System to Change title bar. In the Site Administration page that opens,
click Zones. The Select Zone to Change window appears, listing the existing zones.
From the Select Zone to Change window, you can do the following:
•
Add a new Zone
•
Change the Configuration of a zone
•
Add a new POP
•
Change the configuration of a POP
Add a New Zone
Zones are a way to organize the POPs. You assign POPs to a zone. Follow this procedure to configure
zones on the VDS TC Analytics server.
Note
To configure zones, you must be logged in as a user that has been assigned the Network Engineering
Viewers package and belongs to either the Admin or User group.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-30
Chapter 3
Network Engineering Reporting
Data Mining Info for Network Engineering
Procedure
Step 1
Choose Dashboards > Network Engineering > Data Mining. Click the Configuration tab. Log in
when prompted. The Select System to Change window appears.
Step 2
Click Physical above the Select System to Change title.bar The Physical Administration window
appears.
Step 3
Click Add in the Zones row. The Add Zone window appears.
Step 4
Enter a name for the zone and optionally a description.
Step 5
If you would like to add another zone, click Save and Add Another. If you are finished adding zones,
click Save.
Change the Configuration of a Zone
To change the configuration of an existing zone, follow this procedure:
Procedure
Step 1
Choose Dashboards > Network Engineering > Data Mining. Click the Configuration tab. Log in
when prompted. The Select System to Change window appears.
Step 2
Click Physical above the Select System to Change title.bar The Physical Administration window
appears.
Step 3
Click either Zones or Change in the Zones row. The Select Zone to Change window appears.
Step 4
Click the name of the zone you want to change. The Change Zone window appears.
Step 5
Modify either the name or the description of the zone and click Save.
Add a New POP
POPs are a way to organize the VDS TC caching engines. You will assign the VDS TC caching systems
to POPs. Follow this procedure to configure POPs on the VDS TC Analytics server.
Note
To configure POPs, you must be logged in as a user that has been assigned the Network Engineering
Viewers package and belongs to either the Admin or User group.
Procedure
Step 1
Choose Dashboards > Network Engineering > Data Mining. Click the Configuration tab. Log in
when prompted. The Select System to Change window appears.
Step 2
Click Physical above the Select System to Change title.bar The Physical Administration window
appears.
Step 3
Click Add in the POPs row. The Add POP window appears.
Step 4
Enter a name for the POP and optionally a description.
Step 5
From the Zone drop-down list, choose the zone that this POP belongs to.
Step 6
If you would like to add another zone, click Save and Add Another. If you are finished adding POPs,
click Save.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-31
Chapter 3
Network Engineering Reporting
Data Mining Info for Network Engineering
Change the Configuration of a POP
To change the configuration of an existing POP, follow this procedure:
Procedure
Step 1
Choose Dashboards > Network Engineering > Data Mining. Click the Configuration tab. Log in
when prompted. The Select System to Change window appears.
Step 2
Click Physical above the Select System to Change title.bar The Physical Administration window
appears.
Step 3
Click either POPs or Change in the POPs row. The Select POP to Change window appears.
Step 4
Click the name of the POP you want to change. The Change POP window appears.
Step 5
Make the necessary edits to the POP and click Save.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
3-32
CH A P T E R
4
Policy Reports
The Policy Analysis Dashboard provides an assortment of comprehensive reports that capture the
statistics about traffic based on the rules, policies, and categories the traffic fall into.
All explicitly created policies are global and are not connected to any configuration. If a global policy
is changed, it will be changed in all of the configuration versions. All implicitly created policies are
connected to their rules; they are not shown in the policies list and are deleted together with the rules.
This chapter describes the information that can be viewed from the Policy Analysis Dashboard and
contains these sections:
•
General Notes for Charts and Reports
•
Categories Analysis
•
Policies Analysis
•
Rules Analysis
•
Categories QoE Analysis
General Notes for Charts and Reports
•
Current day information not available: Because IP information is collected between 00:01 and
24:00 each day, and only analyzed after it is collected, no information is available for the current
day, therefore you can only present information up to the previous day. IP information for the current
day can only be presented the day after.
•
Selected time frame determines granularity: The selected time frame determines the chart
granularity. A time frame of less than 3 days displays five minute polling values. A time frame of
over 3 but less than 33 days, displays hourly average points, calculating all of the five minute
samples in each hour. A time frame of over 32 days reduces chart granularity to display only daily
average values.
Categories Analysis
The Categories Analysis reports provide visibility into content compared by the category that the traffic
falls into displayed as both a daily average and as a total for the time frame that is selected. It displays
information for total traffic, cache traffic, and clear traffic broken down by both requests and capacity.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
4-1
Chapter 4
Policy Reports
Categories Analysis
In the Categories Analysis tab, the default Filter By preferences are set to display information for all
categories across all of the systems, for the last seven days, based on total capacity. You can choose to
filter the data based on specific categories, zones, POPs, or systems.
Figure 4-1
Categories Analysis
Working with the Data
The Policy Analysis reports enable you to manipulate data and display the information according to the
set of criteria you specify. At any time, you can revert back to your previous filtering selection by
clicking Reset.
Specific Zone, POP, or System
You can filter the information on the Categories Analysis tab based on a specific zone, POP, or system.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
4-2
Chapter 4
Policy Reports
Categories Analysis
To present information for specific a zone, POP, or system, in the Filter By section make your selection,
and click Apply. You can also click Search in the drop-down list of the item you would like to filter by
to search for items based on a name match. See the Search Options table for the available search criteria.
When you are finished entering the search criteria, click Apply.
Table 4-1
Search Options
Option
Description
Starts
In the search field enter the beginning of the item name to search for in the
Selected list. Click OK to exit and then click Apply in the Filter By section.
Contains
In the search field enter any part of the item name to search for in the
Selected list. Click OK to exit and then click Apply in the Filter By section.
Ends
In the search field enter the ending of the item name to search for in the
Selected list. Click OK to exit and then click Apply in the Filter By section.
Is Like (Pattern
Match)
To search for a pattern match, enter % on both sides of a partial name to
search for in the Selected list. Click OK to exit and then click Apply in the
Filter By section.
Filter By Category
This tab enables you to filter information based on category. The default Filter By is set to display
information about all categories. To present information for specific categories, or by category types, in
the Filter By section from the Category Type drop-down list choose the category type that you want, or
choose the specific categories from the individual category type drop-down lists.
You can also click Search in the drop-down list of the item you would like to filter by to search for items
based on a name match. See the Search Options table for the available search criteria. When you are
finished entering the search criteria, click Apply.
Display
Information is presented in a data table, listing values in ascending order. The highest value of each
column is also expressed as a horizontal bar, constituting 100% of that cell's width. Lower values in that
column are expressed as shorter horizontal bars respectively.
To present full numerical values, from the Display drop-down list choose Data Table.
Detailed Analysis
For the Content Comparison per Day report and the Content Comparison per Day Combined report, you
can choose to view the data as charts or as extended data tables. To view the data as a chart or extended
data table, choose your option from the Detailed Analysis drop-down list.
Time Frame
To change the time frame, in the Filter By section in the Time Frame drop-down list choose the time
frame for which you want to present information and then click Apply. The options are Last Day, Last
7 Days, Last 30 Days, Previous Month, or Custom Dates and the default is the last 7 days. The chart is
regenerated for the new time frame, although the dates in the From and To fields do not update.
You can also enter the date range you want in the From and To text boxes. You can also use the Calendar
icon to select the date range that you want. After you change the dates, click Apply for the new range to
take effect.
The time frame that you set is displayed in brackets in the title, and is passed on to all the other tabs in
this dashboard.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
4-3
Chapter 4
Policy Reports
Policies Analysis
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Reports
The Categories Analysis tab displays the following reports:
•
Content Comparison by Category: This report displays information for total traffic, cache traffic,
and clear traffic showing both requests and capacity, organized by category type and category name.
•
Content Comparison by Category Combined: This report displays information for total traffic,
cache traffic, and clear traffic showing both requests and capacity, totaled across all categories. This
report also lists the categories that the traffic belongs to that is included in the report. This report
includes its own drop-down lists that you can use to filter the information.
•
Content Comparison per Day: This report displays information for total traffic, cache traffic, and
clear traffic showing both requests and capacity, organized by category type and category name,
showing the information for each day in the date range.
•
Content Comparison per Day Combined: This report displays information for total traffic, cache
traffic, and clear traffic showing both requests and capacity, totaled across all categories, broken
down by each day in the date range. This report also lists the categories that the traffic belongs to
that is included in the report. This report includes its own drop-down lists that you can use to filter
the information.
Policies Analysis
The Policies Analysis reports provide visibility into content compared by the policy that applies to the
traffic displayed as totals for the time frame that is selected. It displays information for total traffic, cache
traffic, and clear traffic broken down by both requests and capacity. You can also view the information
broken down by day and hour.
In the Policies Analysis tab, the default Filter By preferences are set to display information for all
policies across all of the systems, for the last seven days, based on total capacity. You can choose to filter
the data based on specific policies, zones, POPs, or systems.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
4-4
Chapter 4
Policy Reports
Policies Analysis
Figure 4-2
Policies Analysis
Working with the Data
The Policy Analysis reports enable you to manipulate data and display the information according to the
set of criteria you specify. At any time, you can revert back to your previous filtering selection by
clicking Reset.
Specific Zone, POP, or System
You can filter the information on the Policies Analysis tab based on a specific zone, POP, or system.
To present information for specific a zone, POP, or system, in the Filter By section make your selection,
and click Apply. You can also click Search in the drop-down list of the item you would like to filter by
to search for items based on a name match. See the Search Options table for the available search criteria.
When you are finished entering the search criteria, click Apply.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
4-5
Chapter 4
Policy Reports
Policies Analysis
Filter By Policy
This tab enables you to filter information based on policy. The default Filter By is set to display
information about all policies. To present information for specific policies, or by policy type, in the Filter
By section from the Policy Type drop-down list choose the policy type that you want, or choose the
specific policies from the individual policy type drop-down lists.
You can also click Search in the drop-down list of the item you would like to filter by to search for items
based on a name match. See the Search Options table for the available search criteria. When you are
finished entering the search criteria, click Apply.
Display
Information is presented in a data table, listing values in ascending order. The highest value of each
column is also expressed as a horizontal bar, constituting 100% of that cell's width. Lower values in that
column are expressed as shorter horizontal bars respectively.
To present full numerical values, from the Display drop-down list choose Data Table.
Detailed Analysis
For the Content Comparison per Day report and the Content Comparison per Hour report, you can
choose to view the data as charts or as extended data tables. To view the data as a chart or extended data
table, choose your option from the Detailed Analysis drop-down list.
Time Frame
To change the time frame, in the Filter By section in the Time Frame drop-down list choose the time
frame for which you want to present information and then click Apply. The options are Last Day, Last
7 Days, Last 30 Days, Previous Month, or Custom Dates and the default is the last 7 days. The chart is
regenerated for the new time frame, although the dates in the From and To fields do not update.
You can also enter the date range you want in the From and To text boxes. You can also use the Calendar
icon to select the date range that you want. After you change the dates, click Apply for the new range to
take effect.
The time frame that you set is displayed in brackets in the title, and is passed on to all the other tabs in
this dashboard.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Reports
The Policies Analysis tab displays the following reports:
•
Content Comparison by Policy: This report displays information for total traffic, cache traffic, and
clear traffic showing both requests and capacity, organized by policy type and policy name.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
4-6
Chapter 4
Policy Reports
Rules Analysis
•
Content Comparison by Policy Specific Hours: This report displays information for total traffic,
cache traffic, and clear traffic showing both requests and capacity, organized by policy type and
policy name, calculated for a specific set of hours.
•
Content Comparison per Day: This report displays information for total traffic, cache traffic, and
clear traffic showing both requests and capacity, organized by policy type and policy name, showing
the information for each day in the date range.
•
Content Comparison per Hour: This report displays information for total traffic, cache traffic, and
clear traffic showing both requests and capacity, organized by policy type and policy name, showing
the information for each hour in the date range.
Rules Analysis
The Rules Analysis reports provide visibility into content compared by the top 10 rules that apply to the
traffic displayed as totals for the time frame that is selected. It displays information for total traffic, cache
traffic, and clear traffic broken down by both requests and capacity. You can also view the information
broken down by day and hour.
In the Rules Analysis tab, the default Filter By preferences are set to display information for the top ten
rules across all of the systems, for the last seven days, based on total capacity. You can choose to filter
the data based on specific policies, zones, POPs, or systems.
Figure 4-3
Rules Analysis
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
4-7
Chapter 4
Policy Reports
Rules Analysis
Working with the Data
The Policy Analysis reports enable you to manipulate data and display the information according to the
set of criteria you specify. At any time, you can revert back to your previous filtering selection by
clicking Reset.
Specific Zone, POP, or System
You can filter the information on the Rules Analysis tab based on a specific zone, POP, or system.
To present information for specific a zone, POP, or system, in the Filter By section make your selection,
and click Apply. You can also click Search in the drop-down list of the item you would like to filter by
to search for items based on a name match. See the Search Options table for the available search criteria.
When you are finished entering the search criteria, click Apply.
Filter By Rule
This tab enables you to filter information based on the rule. The default Filter By is set to display
information about the top 10 rules. You can choose to present information for specific rules by choosing
the rules from the Rule drop-down list in the Filter By section. You can also choose to change the number
of top rules to display by choosing a new number from the Top Rules drop-down list.
You can also click Search in the drop-down list of the item you would like to filter by to search for items
based on a name match. See the Search Options table for the available search criteria. When you are
finished entering the search criteria, click Apply.
Display
Information is presented in a data table, listing values in ascending order. The highest value of each
column is also expressed as a horizontal bar, constituting 100% of that cell's width. Lower values in that
column are expressed as shorter horizontal bars respectively.
To present full numerical values, from the Display drop-down list choose Data Table.
Detailed Analysis
For the Content Comparison per Day report and the Content Comparison per Hour report, you can
choose to view the data as charts or as extended data tables. To view the data as a chart or extended data
table, choose your option from the Detailed Analysis drop-down list.
Time Frame
To change the time frame, in the Filter By section in the Time Frame drop-down list choose the time
frame for which you want to present information and then click Apply. The options are Last Day, Last
7 Days, Last 30 Days, Previous Month, or Custom Dates and the default is the last 7 days. The chart is
regenerated for the new time frame, although the dates in the From and To fields do not update.
You can also enter the date range you want in the From and To text boxes. You can also use the Calendar
icon to select the date range that you want. After you change the dates, click Apply for the new range to
take effect.
The time frame that you set is displayed in brackets in the title, and is passed on to all the other tabs in
this dashboard.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
4-8
Chapter 4
Policy Reports
Categories QoE Analysis
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Reports
The Policies Analysis tab displays the following reports:
•
Content Comparison by Rule: This report displays information for total traffic, cache traffic, and
clear traffic showing both requests and capacity, organized by rule name.
•
Content Comparison by Rule Specific Hours: This report displays information for total traffic,
cache traffic, and clear traffic showing both requests and capacity, organized by rule name,
calculated for a specific set of hours.
•
Content Comparison per Rule: This report displays information for total traffic, cache traffic, and
clear traffic showing both requests and capacity, organized by rule name, showing the information
for each day in the date range.
•
Content Comparison per Rule: This report displays information for total traffic, cache traffic, and
clear traffic showing both requests and capacity, organized by rule name, showing the information
for each hour in the date range.
Categories QoE Analysis
The Categories QoE Analysis report analyzes the quality of experience (QoE) of the category for the
selected time frame, which by default is the last seven days. QoE is measured by comparing the speed
of content served from the VDS TC cache engines (cache) with the speed of content arriving directly
from the Internet (clear). By default, QoE is presented As Is, where the two lines for cache traffic and
clear traffic are plotted for comparison. You can also present the QoE as a single ratio line between cache
data and clear data.
By default, the Categories QoE Analysis reports display the QoE for all categories for the last seven
days. You can change the time frame and filter which categories are displayed by category name or by
category type.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
4-9
Chapter 4
Policy Reports
Categories QoE Analysis
Working with the Data
The Policy Analysis reports enable you to manipulate data and display the information according to the
set of criteria you specify. At any time, you can revert back to your previous filtering selection by
clicking Reset.
Filter By Category
This tab enables you to filter information based on category. The default Filter By is set to display
information about all categories. To present information for specific categories, or by category types, in
the Filter By section from the Category Type drop-down list choose the category type that you want, or
choose the specific categories from the individual category type drop-down lists.
You can also click Search in the drop-down list of the item you would like to filter by to search for items
based on a name match. See the Search Options table for the available search criteria. When you are
finished entering the search criteria, click Apply.
As Is or Ratio Chart
You can display the Categories QoE As Is, where the two lines for cache traffic and clear traffic are
plotted for comparison or you can display the QoE as a single ratio line between cache data and clear
data. The default Filter By preferences are set to present the information As Is, displaying the two
comparative lines.
To display the ratio line between cache data and clear data, in the Filter By section from the For
drop-down list, choose Ratio and then click Apply. The chart refreshes to display a single line
constituting the ratio between the cache and the clear values.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
4-10
Chapter 4
Policy Reports
Categories QoE Analysis
To display cache data and clear data separately in two comparative lines, in the Filter By section from
the For drop-down list, choose As Is and then click Apply. The chart refreshes and displays two separate
lines, constituting the cache and the clear values.
Detailed Analysis
For the different reports that are available from the Traffic Distribution tab, you can choose to view the
data in different ways. To see what options are available, check the Detailed Analysis drop-down list.
Time Frame
To change the time frame, in the Filter By section in the Time Frame drop-down list choose the time
frame for which you want to present information and then click Apply. The options are Last Day, Last
7 Days, Last 30 Days, Previous Month, or Custom Dates and the default is the last 7 days. The chart is
regenerated for the new time frame, although the dates in the From and To fields do not update.
You can also enter the date range you want in the From and To text boxes. You can also use the Calendar
icon to select the date range that you want. After you change the dates, click Apply for the new range to
take effect.
The time frame that you set is displayed in brackets in the title, and is passed on to all the other tabs in
this dashboard.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Report
The Categories QoE Analysis tab displays the following report:
•
Categories QoE Analysis: This report analyzes the quality of experience (QoE) of the category for
the selected time frame, which by default is the last seven days. QoE is measured by comparing the
speed of content served from the VDS TC cache engines (cache) with the speed of content arriving
directly from the Internet (clear). By default, QoE is presented As Is, where the two lines for cache
traffic and clear traffic are plotted for comparison. You can also present the QoE as a single ratio
line between cache data and clear data.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
4-11
Chapter 4
Categories QoE Analysis
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
4-12
Policy Reports
CH A P T E R
5
Summary Reports
The Summary Analysis Dashboard provides an assortment of comprehensive reports that analyze the
cache data, clear data, total traffic, content, and storage within a specified time frame.
This chapter describes the information that can be viewed from the Policy Analysis Dashboard and
contains these sections:
•
General Notes for Charts and Reports
•
Traffic Analysis
•
QoE Analysis
•
Content Analysis
•
Top Analysis
•
Traffic Distribution
•
Traffic Distribution
General Notes for Charts and Reports
•
Current day information not available: Because IP information is collected between 00:01 and
24:00 each day, and only analyzed after it is collected, no information is available for the current
day, therefore you can only present information up to the previous day. IP information for the current
day can only be presented the day after.
•
Selected time frame determines granularity: The selected time frame determines the chart
granularity. A time frame of less than 3 days displays five minute polling values. A time frame of
over 3 but less than 33 days, displays hourly average points, calculating all of the five minute
samples in each hour. A time frame of over 32 days reduces chart granularity to display only daily
average values.
Traffic Analysis
The Summary Traffic Analysis tab delivers immediate visibility of the performance across all systems,
based on the selected time frame. This summarized view focuses on the overall subscriber consumption,
or total downstream traffic, in comparison with the cached out traffic, incoming traffic downstream, and
is plotted by five minute polling values.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
5-1
Chapter 5
Summary Reports
Traffic Analysis
This tab displays the same information as the At a Glance, Traffic Analysis tab, augmented by the
extensive filter capabilities. You can filter the traffic based on protocols, zone, POP and system. In
addition, you can choose to view the data in different formats by choosing different options from the
Detailed Analysis drop-down list.
In this tab, the default Filter by preferences are set to display information for all protocols, for the entire
network, based on the five minute polling values of the current day.
Figure 5-1
Traffic Analysis
Working with the Data
The Summary Analysis tabs enable you to manipulate data and display the information according to the
set of criteria you specify. At any time, you can revert back to your previous filtering selection by
clicking Reset.
Specific Zone, POP, or System
You can filter the information on the Traffic Analysis tab based on a specific zone, POP, or system.
To present information for specific a zone, POP, or system, in the Filter By section make your selection,
and click Apply. You can also click Search in the drop-down list of the item you would like to filter by
to search for items based on a name match. See the Search Options table for the available search criteria.
When you are finished entering the search criteria, click Apply.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
5-2
Chapter 5
Summary Reports
Traffic Analysis
Table 5-1
Search Options
Option
Description
Starts
In the search field enter the beginning of the item name to search for
in the Selected list. Click OK to exit and then click Apply in the
Filter By section.
Contains
In the search field enter any part of the item name to search for in
the Selected list. Click OK to exit and then click Apply in the Filter
By section.
Ends
In the search field enter the ending of the item name to search for in
the Selected list. Click OK to exit and then click Apply in the Filter
By section.
Is Like (Pattern
Match)
To search for a pattern match, enter % on both sides of a partial name
to search for in the Selected list. Click OK to exit and then click
Apply in the Filter By section.
Filter By Protocol
This tab enables you to filter information based on protocol. The default Filter By is set to display
information about all protocols. To present information for specific protocols in the Filter By section
from the Protocol drop-down list choose the protocols that you want.
You can also click Search in the drop-down list of the item you would like to filter by to search for items
based on a name match. See the Search Options table for the available search criteria. When you are
finished entering the search criteria, click Apply.
Detailed Analysis
For the Bandwidth Details by Protocol, Cache Productivity Downstream by Protocol, and BHR
Downstream by Protocol you can choose to view the data in different ways. To see what options are
available, check the Detailed Analysis drop-down list.
Time Frame
To change the time frame, in the Filter By section in the Time Frame drop-down list choose the time
frame for which you want to present information and then click Apply. The options are Last Day, Last
7 Days, Last 30 Days, Previous Month, or Custom Dates and the default is Last 7 Days. The chart is
regenerated for the new time frame, although the dates in the From and To fields do not update.
You can also enter the date range you want in the From and To text boxes. You can also use the Calendar
icon to select the date range that you want. After you change the dates, click Apply for the new range to
take effect.
The time frame that you set is displayed in brackets in the title, and is passed on to all the other tabs in
this dashboard.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
5-3
Chapter 5
Summary Reports
QoE Analysis
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Reports
The Traffic Analysis tab displays the following reports:
•
Traffic Max Summary: This report displays the total cache out downstream traffic, total traffic
downstream, total incoming traffic downstream, cache productivity downstream traffic, and BHR
downstream traffic for all protocols, broken down by each day in the time frame, added up across
all systems that are being monitored. You can use the Filter By section to restrict which systems or
protocols are included.
•
No Traffic Summary: This report displays the date and time when no traffic is on a system.
•
Traffic Max Summary by System: This report displays the total cache out downstream traffic, total
traffic downstream, total incoming traffic downstream, cache productivity downstream traffic, and
BHR downstream traffic for all protocols, broken down by each day in the time frame, broken down
by each monitored system.You can use the Filter By section to restrict which systems or protocols
are included.
•
Bandwidth Details (Hour): This section allows you to presents information on the bandwidth
details of the incoming and cache out traffic. By default the chart in this section displays the total
incoming and cache out traffic, in bps, added up across all systems and all protocols. By choosing
different options from the Detailed Analysis drop-down list, you can view the total incoming and
cache out traffic as both charts and data tables broken down by protocol, zone, POP, and system. You
can use the Filter By section to restrict which systems or protocols are included.
•
Cache Productivity (Hour): This section allows you to present informational the cache
productivity downstream, which is the total traffic cached out divided by the total traffic cached in.
By default the chart in this section displays the cache productivity as a percentage averaged across
all systems for all protocols. By choosing different options from the Detailed Analysis drop-down
list, you can view the cache productivity as both charts and data tables broken down by protocol,
zone, POP, and system. You can use the Filter By section to restrict which systems or protocols are
included.
•
BHR (Hour): This section allows you to present the number of cache out traffic bytes divided by
the total bytes of objects requested (not cached-out traffic and cached traffic), referred to as the
Bytes Hit Ratio (BHR). By default the chart in this section displays the BHR as a percentage
averaged across all systems for all protocols. By choosing different options from the Detailed
Analysis drop-down list, you can view the BHR as both charts and data tables broken down by
protocol, zone, POP, and system. You can use the Filter By section to restrict which systems or
protocols are included.
QoE Analysis
The QoE Analysis reports allow analysis of the users' Network quality of experience for each service or
protocol, per the selected time frame. The QoE Analysis is measured by comparing the speed of content
served from cache with the speed of content arriving directly from the Internet (Clear). By default, the
QoE is presented where the two lines for cache and clear are plotted for comparison. You can select a
Detailed Analysis of the information you want, as numerical values and/or individual charts.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
5-4
Chapter 5
Summary Reports
QoE Analysis
In this tab, the default Filter by preferences are set to display QoE by service and protocol, for the entire
network, based on the five minute polling values of the current day, and plotted to show both cache and
clear lines. You can filter the data based on protocols and services, and you can change the time frame.
Your Filter by selection is passed on to all the tabs in the Summary Analysis dashboard.
Figure 5-2
QoE Analysis
Working with the Data
The Summary Analysis tabs allow you to manipulate data and display the information according to the
set of criteria you specify. At any time, you can revert back to your previous filtering selection by
clicking Reset.
Specific Protocol or Service
This tab enables you to filter information at the level of specific services or protocols. The default Filter
By is set for the entire network for all services and protocols. To present information for specific services
or protocols, in the Filter By section from either the Service or Protocol drop-down list make the
selection you want. You can also click Search in the drop-down list of the item you would like to filter
by to search for items based on a name match. See the Search Options table for the available search
criteria. When you are finished entering the search criteria, click Apply.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
5-5
Chapter 5
Summary Reports
QoE Analysis
Time Frame
To change the time frame, in the Filter By section in the Time Frame drop-down list choose the time
frame for which you want to present information and then click Apply. The options are Last Day, Last
7 Days, Last 30 Days, Previous Month, or Custom Dates and the default is Last 7 Days. The chart is
regenerated for the new time frame, although the dates in the From and To fields do not update.
You can also enter the date range you want in the From and To text boxes. You can also use the Calendar
icon to select the date range that you want. After you change the dates, click Apply for the new range to
take effect.
The time frame that you set is displayed in brackets in the title, and is passed on to all the other tabs in
this dashboard.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Reports
The QoE Analysis tab displays the following reports:
•
Quality of Experience for Entire Traffic: This chart presents the QoE, calculated across all
systems for all services and protocols. You can use the Filter By section to determine which services
or protocols to include in the calculation. QoE is indicated by comparing between Cache QoE and
Clear QoE, for the selected time frame. The lines are plotted according to daily average polling
values, and presented in Mbps. The higher the Cache QoE line is above the Clear QoE line, the
higher the QoE, with a higher level of network traffic being delivered faster by VDS TC. To display
the information in the chart as a data table, from the Detailed Analysis drop-down list choose Data
Table.
To present a generalized view of this information, by daily average polling values, see the Quality
of Experience Comparison by Protocol chart on the Network Engineering > At a Glance, Services
QoE tab. To drill down into the information by individual systems, see the Systems Quality of
Experience by Service chart on the Network Engineering > Data Mining, Systems QoE Analysis tab.
•
Network Acceleration Ratio for Entire Traffic: This report presents the QoE as a single Ratio line
between cache and clear, calculated across all systems for all services and protocols. You can use
the Filter By section to determine which services or protocols to include in the calculation. Improved
acceleration is indicated by VDS TC servicing traffic faster than the speed of traffic arriving from
the world.
To present a generalized view of this information, by daily average polling values, see the Quality
of Experience Comparison by Protocol chart on the Network Engineering > At a Glance, Services
QoE tab and choose Ratio in the For drop-down list. To drill down into the information by individual
systems, see the Systems Quality of Experience by Service chart on the Network Engineering > Data
Mining, Systems QoE Analysis tab and choose Ratio in the For drop-down list.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
5-6
Chapter 5
Summary Reports
Content Analysis
•
Network Quality of Experience Protocols (Hour): This section presents a separate chart showing
the QoE for each protocol, calculated across all systems. By default, information is presented for
each day in the time frame, plotted according to five minute polling values, and presented in bps,
where K in the Y axis means “thousand”. To view this information in a data table, from the Detailed
Analysis drop-down list choose Per Protocol Data Table.
•
Network Quality of Experience Services (Hour): This section presents a separate chart showing
the QoE for each service, calculated across all systems. By default, information is presented for each
day in the time frame, plotted according to five minute polling values, and presented in bps, where
K in the Y axis means “thousand”. To view this information in a data table, from the Detailed
Analysis drop-down list choose Per Service Data Table.
To present a generalized view of this information, by daily average polling values, see the Quality
of Experience Comparison by Protocol chart on the Network Engineering > At a Glance, Services
QoE tab. To drill down into the information by individual systems, see the Systems Quality of
Experience by Service chart on the Network Engineering > Data Mining, Systems QoE Analysis tab.
Content Analysis
The Content Analysis reports evaluate the total content for the selected time frame, which by default is
the last seven days. These data tables present information of content served from both the Internet (clear)
and Cisco Analytics (cache), broken down by services and protocols. By default, information is
presented as a data table for total traffic, cache traffic, and clear traffic, by traffic capacity and by the
number of requests. You can filter the output based on service, protocol, zone, POP, and system.
Figure 5-3
Content Analysis
Working with the Data
The Summary Analysis tabs allow you to manipulate data and display the information according to the
set of criteria you specify. At any time, you can revert back to your previous filtering selection by
clicking Reset.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
5-7
Chapter 5
Summary Reports
Content Analysis
Specific Zone, POP, or System
You can filter the information on the Content Analysis tab based on a specific zone, POP, or system.
To present information for specific a zone, POP, or system, in the Filter By section make your selection,
and click Apply. You can also click Search in the drop-down list of the item you would like to filter by
to search for items based on a name match. See the Search Options table for the available search criteria.
When you are finished entering the search criteria, click Apply.
Specific Protocol or Service
This tab enables you to filter information at the level of specific services or protocols. The default Filter
By is set for the entire network for all services and protocols. To present information for specific services
or protocols, in the Filter By section from either the Service or Protocol drop-down list make the
selection you want. You can also click Search in the drop-down list of the item you would like to filter
by to search for items based on a name match. See the Search Options table for the available search
criteria. When you are finished entering the search criteria, click Apply.
Display
By default, information is presented in a data table, listing values in ascending order. The highest value
of each column is also expressed as a horizontal bar, constituting 100% of that cell's width. Lower values
in that column are expressed as shorter horizontal bars respectively.
To present full numerical values, from the Display drop-down list choose Data Table.
Detailed Analysis
For the reports, you can choose to view the data as charts or as extended data tables. To view the data as
a chart or extended data table, choose your option from the Detailed Analysis drop-down list.
Time Frame
To change the time frame, in the Filter By section in the Time Frame drop-down list choose the time
frame for which you want to present information and then click Apply. The options are Last Day, Last
7 Days, Last 30 Days, Previous Month, or Custom Dates and the default is the last 7 days. The chart is
regenerated for the new time frame, although the dates in the From and To fields do not update.
You can also enter the date range you want in the From and To text boxes. You can also use the Calendar
icon to select the date range that you want. After you change the dates, click Apply for the new range to
take effect.
The time frame that you set is displayed in brackets in the title, and is passed on to all the other tabs in
this dashboard.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
5-8
Chapter 5
Summary Reports
Top Analysis
Reports
The Content Analysis tab displays the following reports:
•
Content Comparison: This chart displays the total capacity and total requests compared to the clear
and cache capacity and requests. By default this information is calculated across all systems for all
services and protocols, for the last seven days, but you can use the options in the Filter By section
to change this. Information is presented based on the five minute polling values, and presented in
bps.
•
Content Comparison by Protocol: This section presents a separate chart per protocol showing the
total capacity and total requests compared to the clear and cache capacity and requests. By default
this information is calculated across all systems for all protocols, for the last seven days, but you
can use the options in the Filter By section to change this. Information is presented based on the five
minute polling values, and presented in bps, where M stands for “million” and TB stands for
“trillion”.
•
Content Comparison by Service: This section presents a separate chart per service showing the
total capacity and total requests compared to the clear and cache capacity and requests. By default
this information is calculated across all systems for all services, for the last seven days, but you can
use the options in the Filter By section to change this. Information is presented based on the five
minute polling values, and presented in bps, where M stands for “million” and TB stands for
“trillion”.
Top Analysis
The Top Analysis report allows you analyze the domains, hashes, subscribers, and hosts with the highest
total traffic capacity for the selected time frame, which is by default the last seven days. You can also
choose to determine the top domains, hashes, subscribers, and hosts based on clear traffic or cache
traffic.
By default the results display the top 10 items in each category (domains, hashes, subscribers, and hosts),
based on all services and all protocols. You can change the top results to include a different number of
items, such as 20, and you can choose to filter which services and protocols are included in the results.
You can also filter which zones, POPs and systems are included. By default all systems are included.
Information is displayed in numerical values, also represented as horizontal bars to provide a visualize
comparison within each column.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
5-9
Chapter 5
Summary Reports
Top Analysis
Figure 5-4
Top Analysis
Working with the Data
The Summary Analysis tabs allow you to manipulate data and display the information according to the
set of criteria you specify. At any time, you can revert back to your previous filtering selection by
clicking Reset.
Specific Zone, POP, or System
You can filter the information on the Top Analysis tab based on a specific zone, POP, or system.
To present information for specific a zone, POP, or system, in the Filter By section make your selection,
and click Apply. You can also click Search in the drop-down list of the item you would like to filter by
to search for items based on a name match. See the Search Options table for the available search criteria.
When you are finished entering the search criteria, click Apply.
Specific Protocol or Service
This tab enables you to filter information at the level of specific services or protocols. The default Filter
By is set for the entire network for all services and protocols. To present information for specific services
or protocols, in the Filter By section from either the Service or Protocol drop-down list make the
selection you want. You can also click Search in the drop-down list of the item you would like to filter
by to search for items based on a name match. See the Search Options table for the available search
criteria. When you are finished entering the search criteria, click Apply.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
5-10
Chapter 5
Summary Reports
Top Analysis
Content Information
By default, the top 10 domains, hashes, subscribers, and hosts are listed calculated by total capacity. You
can choose to list a different number of top domains, hashes, subscribers, and hosts, and you can choose
to determine the top items calculated by cache traffic or clear traffic, by requests or by capacity.
•
To select the number of top items to display, from the Top Results text box choose a value and then
click Apply. The data table is refreshed to show your selection.
•
To select the type of traffic on which to base the top domains, in the By drop-down list choose the
type of traffic that you want to use and then click Apply. The data table is refreshed to show your
selection.
Display
By default, information is presented in a data table, listing values in ascending order. The highest value
of each column is also represented as a horizontal bar, constituting 100% of that cell's width. Lower
values in that column are represented as shorter horizontal bars respectively.
To present full numerical values, from the Display drop-down list choose Data Table.
Time Frame
To change the time frame, in the Filter By section in the Time Frame drop-down list choose the time
frame for which you want to present information and then click Apply. The options are Last Day, Last
7 Days, Last 30 Days, Previous Month, or Custom Dates and the default is the last 7 days. The chart is
regenerated for the new time frame, although the dates in the From and To fields do not update.
You can also enter the date range you want in the From and To text boxes. You can also use the Calendar
icon to select the date range that you want. After you change the dates, click Apply for the new range to
take effect.
The time frame that you set is displayed in brackets in the title, and is passed on to all the other tabs in
this dashboard.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Reports
The Top Analysis tab displays the following reports:
•
Top Domains: Based on your Filter By criteria, this data table presents information for the domains
that are most highly served from both the Internet (Clear) and Cisco Analytics (Cache), broken down
by total traffic capacity and number of requests. By default, information is presented for the top
domains that scored the highest total traffic capacity, according to the five minute polling values of
the current day.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
5-11
Chapter 5
Summary Reports
Traffic Distribution
•
Top Hashes: Based on your Filter By criteria, this data table presents information for the hashes
that are most highly served from both the Internet (Clear) and Cisco Analytics (Cache), broken down
by total traffic capacity and number of requests. By default, information is presented for the top
domains that scored the highest total traffic capacity, according to the five minute polling values of
the current day.
•
Top Subscriber IP Addresses: Based on your Filter By criteria, this data table presents information
for the subscriber IP addresses that are most highly served from both the Internet (Clear) and Cisco
Analytics (Cache), broken down by total traffic capacity and number of requests. By default,
information is presented for the top domains that scored the highest total traffic capacity, according
to the five minute polling values of the current day.
•
Top Host IP Addresses: Based on your Filter By criteria, this data table presents information for
the host IP addresses that are most highly served from both the Internet (Clear) and Cisco Analytics
(Cache), broken down by total traffic capacity and number of requests. By default, information is
presented for the top domains that scored the highest total traffic capacity, according to the five
minute polling values of the current day.
Traffic Distribution
The Traffic Distribution reports provides information on the number of IP addresses that were served
cache content and clear content, to determine the percentage of total IP addresses that were provided
cache content. You can view this information as a total across all systems and protocols, or broken down
by system and protocol. By default this information is presented for the previous day.
Figure 5-5
Traffic Distribution
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
5-12
Chapter 5
Summary Reports
Traffic Distribution
Working with the Data
The Summary Analysis tabs allow you to manipulate data and display the information according to the
set of criteria you specify. At any time, you can revert back to your previous filtering selection by
clicking Reset.
Specific Zone, POP, or System
You can filter the information on the Traffic Distribution tab based on a specific zone, POP, or system.
To present information for specific a zone, POP, or system, in the Filter By section make your selection,
and click Apply. You can also click Search in the drop-down list of the item you would like to filter by
to search for items based on a name match. See the Search Options table for the available search criteria.
When you are finished entering the search criteria, click Apply.
Specific Protocol
This tab enables you to filter information at the level of specific protocols. The default Filter By is set
for the entire network for all protocols. To present information for specific protocols, in the Filter By
section from the Protocol drop-down list make the selection you want. You can also click Search in the
drop-down list of the item you would like to filter by to search for items based on a name match. See the
Search Options table for the available search criteria. When you are finished entering the search criteria,
click Apply.
Units
In the IP Addresses Served per Day reports, the values are presented as a percentile. In the IP Addresses
Served and the IP Addresses Served by System reports, the data is represented as a number by the
thousands.
Values
The IP Addresses Served per Day reports present the data in a chart. To see this information represented
in a data table, choose Data Table from the drop-down list above the chart. The IP Addresses Served
and the IP Addresses Served by System reports display the data in a data table. To see this data
represented in a chart, choose Per Protocol Chart or Per Protocol System from the drop-down list
above the data table.
Time Frame
To change the time frame, in the Filter By section in the Time Frame drop-down list choose the time
frame for which you want to present information and then click Apply. The options are Last Day, Last
7 Days, Last 30 Days, Previous Month, or Custom Dates and the default is the last 7 days. The chart is
regenerated for the new time frame, although the dates in the From and To fields do not update.
You can also enter the date range you want in the From and To text boxes. You can also use the Calendar
icon to select the date range that you want. After you change the dates, click Apply for the new range to
take effect.
The time frame that you set is displayed in brackets in the title, and is passed on to all the other tabs in
this dashboard.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
5-13
Chapter 5
Summary Reports
Storage Analysis
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Reports
The Traffic Distribution tab displays the following reports:
•
IP Addresses Served: This section provides a report that display the total number of IP addresses
that were served cache content and clear content, to determine the percentage of total IP addresses
that were provided cache content, for all protocols and all systems. This section also displays a
report that shows this same information broken down by protocol.
•
IP Addresses Served per Day: This section provides a chart that displays the percentage of IP
addresses that were served cache content, calculated across all protocols. This section also provides
a separate chart for each protocol that displays the percentage of IP addresses that were served cache
content for that protocol.
•
IP Addresses Served by System: This section provides a report that displays the total number of
IP addresses that were served cache content and clear content, to determine the percentage of total
IP addresses that were provided cache content, for all protocols, broken down by system.
•
IP Addresses Served per Day by System: This section provides a chart that displays the percentage
of IP addresses that were served cache content, calculated across all protocols, broken down by
system.
Storage Analysis
The Storage Analysis tab displays the number of files in cache broken down by protocol. The Storage
Analysis tab also displays the total number of bytes consumed by each protocol in cache. By default this
tab presents information based on all protocols and all systems, but you can use the Filter By options to
change this. By default this information is presented as a chart, but you can also choose to view the
information in a data table.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
5-14
Chapter 5
Summary Reports
Storage Analysis
Figure 5-6
Storage Analysis
Working with the Data
The Summary Analysis tabs allow you to manipulate data and display the information according to the
set of criteria you specify. At any time, you can revert back to your previous filtering selection by
clicking Reset.
Specific Zone, POP, or System
You can filter the information on the Storage Analysis tab based on a specific zone, POP, or system.
To present information for specific a zone, POP, or system, in the Filter By section make your selection,
and click Apply. You can also click Search in the drop-down list of the item you would like to filter by
to search for items based on a name match. See the Search Options table for the available search criteria.
When you are finished entering the search criteria, click Apply.
Specific Protocol
This tab enables you to filter information at the level of specific protocols. The default Filter By is set
for the entire network for all protocols. To present information for specific protocols, in the Filter By
section from the Protocol drop-down list make the selection you want. You can also click Search in the
drop-down list of the item you would like to filter by to search for items based on a name match. See the
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
5-15
Chapter 5
Summary Reports
Storage Analysis
Search Options table for the available search criteria. When you are finished entering the search criteria,
click Apply.
Time Frame
To change the time frame, in the Filter By section in the Time Frame drop-down list choose the time
frame for which you want to present information and then click Apply. The options are Last Day, Last
7 Days, Last 30 Days, Previous Month, or Custom Dates and the default is the last 7 days. The chart is
regenerated for the new time frame, although the dates in the From and To fields do not update.
You can also enter the date range you want in the From and To text boxes. You can also use the Calendar
icon to select the date range that you want. After you change the dates, click Apply for the new range to
take effect.
The time frame that you set is displayed in brackets in the title, and is passed on to all the other tabs in
this dashboard.
Printing Data
You can print the data in either PDF or HTML format. To print the data, click Print below the data that
you want to print and choose either Printable PDF or Printable HTML. The printable version of the data
will open in a new window or tab, from which you can print the data.
Exporting Data
You can export the data to multiple formats. To export the data, click Export below the data that you want
to export and from the pop-up menu, choose the format to which would like to export the data. A dialog
box appears that asks you to either save or open the file. Choose which ever option you prefer.
Reports
The Storage Analysis tab displays the following reports:
•
Cache Files by Protocol: This chart presents information on the number of cache files within the
specified time frame broken down by protocol. By default, information is presented for the current
day's five minute polling values and presented by the number of files across all systems included in
the Filter by criteria. By choosing options from the Detailed Analysis drop-down list you can break
the information down by zone, POP, or system displayed as either a chart or a data table.
•
Cache Size by Protocol: This chart presents information on the number of cache bytes for the
specified time frame broken down by protocol. By default, information is presented for the current
day's five minute polling values and presented by the cache size (bytes) of all systems included in
the Filter by criteria. By choosing options from the Detailed Analysis drop-down list you can break
the information down by zone, POP, or system displayed as either a chart or a data table.
Cisco Videoscape Distribution Suite Transparent Caching Software Integrated Appliance Installation Guide
5-16
A P P E N D I X
A
Frequently Asked Question
Revised: February 2016
This appendix provides answers to some frequently asked questions about VDS TC Analytics.
Time Frame
What is the default time frame for the reports?
The default time from for reports vary, although most of the reports have a default time from of the
last seven days. You can change the time frame at anytime. In the Filter By section enter the From
and To dates that you want, or use the calendar to select them, and then click Apply. The dates
appear in MM/DD/YY format. The chart or report is regenerated for the new time frame and the time
frame is displayed in brackets in the chart or report title bar. The new time frame that you enter is
passed on to the other tabs in the same dashboard.
Does the selected time frame change the plotted value and chart granularity?
In Data Mining, the selected time frame determines chart granularity. A chart or report with a time
frame of up to and including 3 days, displays five minute polling values. A chart or report with a
time frame from 4 days to 30 days displays hourly average points, which calculate all the five minute
samples in each hour. A chart or report that has a time frame of over 30 days displays only daily
average values.
How do you determine the time frame to be displayed?
You can change the time frame at any time and in any report, using the Filter By section of each tab.
The filtering preferences that are set in one tab are automatically carried on to all of the other tabs
in that specific dashboard.
Why is there no information displayed for the current day?
Because content information is collected between 00:01 and 24:00 each day and only then analyzed,
information for the current day is unavailable in some tabs. Although the last seven days is the
default Data Mining time frame, in the Top Subscribers, Top Contents, and Traffic Distribution tabs
you can only present information up to the previous day. Current day IP or domain information can
only be presented the day after.
Cisco Videoscape Distribution Suite Transparent Caching Software Blade Server Cluster Installation Guide
A-1
Appendix A
Frequently Asked Question
Filtering
Why is there a discrepancy in traffic patterns?
If traffic patterns do not make sense, it could be because the clocks of the VDS TC Analytics Server
and the VDS TC cache engines are not synchronized, causing a time mismatch.
Is daylight savings time automatically supported?
Daylight savings time is not supported. You must resynchronize the VDS TC Analytics clock and
the VDS TC cache engine clocks, to ensure accurate display of information.
Filtering
How is data filtered for display?
In each tab, Filter By settings define the data querying preferences. You can change filtering
preferences at any time and in any tab. Filtering preferences are carried on to all of the other tabs in
a dashboard, but not between dashboards.
At a Glance provides simplifies filtering options that only allow time frame filtering. Data Mining
provides in-depth filtering options, allowing you to set specific systems criteria and display either
services or protocols. Note that you must click Apply to refresh the page and display the information
according to what you selected in Filter By.
Note
Different reports in the Data Mining tabs will have different Filter By options, depending on what the
report is showing.
Why is no information presented for the current day?
Charts that rely on data of IPs and domains require an additional day for analysis. Because
information is collected between 00:01 and 24:00 each day, and then analyzed, no information is
available for the current day. Even when the default time frame includes the current day, you can
only present information up to the previous day for charts that rely on data from IPs or domains.
Current day IP or domain information can only be presented the day after.
Why is the display not refreshed to show latest filtering selection?
After making a new selection in the Filter By section, you must always click Apply. Clicking Apply
refreshes the charts to present the newly selected filtering criteria.
Data Collection
How is data collected by Analytics?
VDS TC Analytics retrieves information from SNMPs that are generated and controlled by your
Cisco Analytics management server(s). Upon installation, the VDS TC Analytics architecture and
collector parameters are set using the Configuration tab.
How to change SNMP poll intervals and CDR data collection?
SNMP polling and CDR data collecting parameters are defined in the Configuration tab. By default,
SNMP polling intervals are every 5 minutes. To change these values you must be assigned to either
the Admin or User group and you must be assigned the Network Engineering Values package.
Cisco Videoscape Distribution Suite Transparent Caching Software Blade Server Cluster Installation Guide
A-2

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
