6
5
Features
Features
Installing MSI Live Update
Using MSI Live Update Online
MICRO-STAR INT'L
MS-V230
1. Link to MSI's website at http://www.msi.com
2. Find Live Update Online under the selection of Downloads on the web page.
3. Select CLICK HERE to continue.
N430GT
Series
4. Select Yes, I would like to try it at my own risk to continue.
WARNING!!
5. Follow the on-screen instructions to complete the utility downloading and installing
procedures.
DO NOT touch the cooling
system since it may produce
a certain heat while
processing tasks.
CAUTION!!
Do not force the GPU cooler
against the fragile GPU to
avoid damage to the GPU.
MSI Live Update offers you with brand-new update service experience, which can
significantly save your time while searching files. MSI Live Update is capable to
automatically analyze and list drivers, BIOS, and utilities you need. With the easy-touse updating approaches, you can increase the performance of your system easily and
quickly. Follow the instructions below, with a few mouse clicks, you can acquire the
related files for the system updating.
1. Insert the supplied disk into the
CD-ROM drive, and start the
Setup program.
2. Click the Utility tab on the setup
screen.
3. Click the MSI Live Update.
Follow the on-screen instructions
to complete the installation.
!
4. Launch MSI Live Update utility to
proceed the updating function.
Using Live VGA Driver Update
Under the European Union ("EU") Directive on Waste Electrical
and Electronic Equipment, Directive 2002/96/EC, which takes
effect on August 13, 2005, products of "electrical and electronic
equipment" cannot be discarded as municipal waste anymore and
manufacturers of covered electronic equipment will be obligated
to take back such products at the end of their useful life.
This service enables you to update the latest VGA driver for your VGA card.
1. Click the selection of Live VGA Driver TM.
2. Click the green button on the left lower side of the main page to connect to the MSI
Live Update Series Server.
All trademarks used in this manual are the sole property of their respective owners.
6. Enter the page of MSI Live
Update Online [Search
Results]
3. The utility will automatically detect and download the latest driver, if available.
VGA is a trademark of International Business Machines Corporation.
Pentium is a registered trademark of Intel Corporation.
Windows is a registered trademark of Microsoft Corporation.
R
R
R
4. Follow the on-screen instructions to complete the updating procedure.
R
Using MSI Live VGA BIOS Update
7. Select the tag of Live VGA
Driver to download and
update the latest VGA driver,
if available.
8. Select the tag of Live VGA
BIOS to download and
update the latest VGA BIOS,
if available.
This service enables you to update the latest VGA BIOS for your VGA card.
1. Click the selection of Live VGA BIOS TM.
2. Follow the on-screen instructions to continue the procedures.
MICRO-STAR INT'L CO., LTD.
TEL. 886-2-32345599
http://www.msi.com
Insist on the best
3. Click the green button on the left lower side of the main page to connect to the MSI Live
Update Series Server.
4. The utility will automatically detect and download the latest BIOS, if available.
G52-V2302X2
November 2010
5. Follow the on-screen instructions to complete the updating procedure.
1
Overview
3
2
Getting Started
Getting Started
Getting Started
Unpacking
1
1G DDR3 memory or
512M DDR3 memory
Please check out the following items to make sure that you get the complete product:
VGA card
Disk: Drivers, documentation, and applications
Consult your dealer immediately if anything is missing or damaged.
1
2
NVIDIA
GeForce GT 430
System Requirements
To install the VGA card, your computer system needs to meet the following requirements:
2
3
PCI Express Interface
3
Intel Pentium 4, AMD Athlon XP class processor or higher.
R
PCI Express or PCI Express 2.0
slot.
R
- compliant motherboard with one dual-width x16 graphics
Hardware Decode Acceleration
Provides ultra-smooth playback of H.264, VC-1, WMV, DivX, MPEG-2 and MPEG-4 HD and SD
movies without the need for a dual or quad-core CPU.
TrueHD and DTS-HD Audio Bitstreaming Support
Full Support for TrueHD and DTS-HD advanced lossless multi-channel HD audio codecs brings
the rich sound of the master recording to your living room.
Microsoft Windows 7 Support
Windows 7 is the next generation operating system that will mark a dramatic improvement in
the way the OS takes advantage of the graphics processing unit (GPU) to provide a more
compelling user experience. By taking advantage of the GPU for both graphics and computing,
Windows 7 will not only make today's PCs more visual and more interactive but also ensure
that they have the speed and responsiveness customers want.
Fan Connector
200MB of available hard disk space.
5
HDMI Port
Minimum 450W or greater system power supply (with a minimum 12V current rating of 38A) is
recommended.
6
D-Sub Port
CD-ROM / DVD-ROM for driver installation.
Microsoft Windows 7, Windows Vista or Windows XP Operation System (32 or 64 bit)
Visiting MSI website for further information of operating system support.
7
5
6
7
DVI-I Port
- HDMI supported
- HDCP supported
- Dual-link DVI output
supported
Card Features
R
For reference only
R
NVIDIA GeForce Drivers
Unlock the full power and capability of your NVIDIA GeForce graphics processor. NVIDIA
Gforce Drivers deliver continuous performance optimizations for the life of your GeForce
GPU.
Dual-stream Hardware Acceleration
Supports picture-in-picture content for the ultimate interactive Blu-ray and HD DVD movie
experience.
Dynamic Contrast Enhancement & Color Stretch
Provides post-processing and optimization of High Definition movies on a scene by scene basis
for spectacular picture clarity.
Dual-link DVI Support
Able to drive industry's largest and highest resolution flat-panel displays up to 2560x1600 and
with support for High-bandwidth Digital Content Protection (HDCP).
HDMI 1.4a Support
Support for HDMI 1.4a including GPU accelerated Blu-ray 3D support.xvYCC, Deep color and
7.1 digital surround sound.
R
R
NVIDIA PhysX - Technology
Full support for NVIDIA PhysX technology technology,enabling a totally new class of physical
gaming interaction for a more dynamic and realistic experience with GeForce.
For further information,
please visit msi website at
www.msi.com
3. Put the card directly over the expansion slot
and press one end of the card into the slot
first. Gently but firmly press the other end
until the card is fully seated in the slot.
4. Secure the card with a bracket screw.
Software
R
To install the driver of the VGA card to your
computer, please follow the steps below:
TM
1. Turn on the computer.
Installing MSI
TM
Live
Update
3
the CD-ROM drive. The
2. Insert the CD into
Autorun program will start the Setup
program, and show the setup screen as left.
3. Click VGA Drivers. Follow the on-screen
instructions to complete the installation.
4. After finishing the installation, restart the
computer as instructed.
NVIDIA CUDA TM Technology
CUDA technology unlocks the power of the GPU's processing cores to accelerate the most
demanding system tasks - such as video transcoding - delivering up to 7x performance over
traditional CPUs.
Tip : If, on your computer, the Autorun program does not execute automatically, please
1) enable the CD-ROM drive Auto-detect function from Control Panel; or 2) find and run
the setup.exe file manually from the CD.
NVIDIA 3D VisionTM Support
Expand your games in full stereoscopic 3D for the ultimate "inside the game" experience
with the power of NVIDIA 3D Vision. NVIDIA 3D Vision automatically transforms hundreds of
PC games into full stereoscopic 3D.
Enabling HDMI Output
R
The VGA card shown here
is for reference, and may
vary from the actual card.
2. Locate the expansion slot on your mainboard.
Warning: Inserting the VGA card into a
wrong slot may damage your card (refer to
your mainboard manual for more Information).
6. Connect the monitor. Now, you are ready to
install the software on your computer.
R
2
Follow the steps below to install the VGA card:
1. Remove the computer case.
32x Anti-aliasing Technology
Lightning fast, high-quality anti-aliasing at up to 32x sample rates obliterates jagged edges.
R
Microsoft DirectX 11 Support
DirectX 11 GPU with ShaderModel 5.0 support designed for ultrahigh performance in the new
API's key graphics feature, GPU-accelerated tessellation.
Hardware
Hardware
5. Install all other cards and devices and
connect all the cables, and then install the
case.
1GB system memory (2GB recommended)
4
Quick Installation
OpenGL 4.0 Optimization and Support
Ensures top-notch compatibility and performance for OpenGL applications.
R
4
4
PCI Express 2.0 Support
Designed for the new PCI Express 2.0 bus architecture offering the highest data transfer
speeds for the most bandwidth-hungry games and 3D applications, while maintaining
backwards compatibility with existing PCI Express motherboards for the broadest support.
Follow the steps below to enable HDMI Output function:
R
1. Find the DVI-to-HDMI adapter that comes with the
package, if provided. Consult your dealer to purchase
the adapter if it is not provided.
2. Attach the DVI-to-HDMI adapter to the DVI connector.
3. Ensure that the adapter is firmly installed.
